Spatially resolved vertical vorticity in solar supergranulation using helioseismology and local correlation tracking^{⋆,}^{⋆⋆}
^{1} GeorgAugustUniversität, Institut für Astrophysik, FriedrichHundPlatz 1, 37077 Göttingen, Germany
email: jlangfe@astro.physik.unigoettingen.de
^{2} MaxPlanckInstitut für Sonnensystemforschung, JustusvonLiebigWeg 3, 37077 Göttingen, Germany
Received: 5 March 2015
Accepted: 15 June 2015
Flow vorticity is a fundamental property of turbulent convection in rotating systems. Solar supergranules exhibit a preferred sense of rotation, which depends on the hemisphere. This is due to the Coriolis force acting on the diverging horizontal flows. We aim to spatially resolve the vertical flow vorticity of the average supergranule at different latitudes, both for outflow and inflow regions. To measure the vertical vorticity, we use two independent techniques: timedistance helioseismology (TD) and local correlation tracking of granules in intensity images (LCT) using data from the Helioseismic and Magnetic Imager (HMI) on board the Solar Dynamics Observatory (SDO). Both maps are corrected for centertolimb systematic errors. We find that 8 h TD and LCT maps of vertical vorticity are highly correlated at large spatial scales. Associated with the average supergranule outflow, we find tangential (vortical) flows that reach about 10 m s^{1} in the clockwise direction at 40° latitude. In average inflow regions, the tangential flow reaches the same magnitude, but in the anticlockwise direction. These tangential velocities are much smaller than the radial (diverging) flow component (300 m s^{1} for the average outflow and 200 m s^{1} for the average inflow). The results for TD and LCT as measured from HMI are in excellent agreement for latitudes between −60° and 60°. From HMI LCT, we measure the vorticity peak of the average supergranule to have a full width at half maximum of about 13 Mm for outflows and 8 Mm for inflows. This is larger than the spatial resolution of the LCT measurements (about 3 Mm). On the other hand, the vorticity peak in outflows is about half the value measured at inflows (e.g., 4 × 10^{6} s^{1} clockwise compared to 8 × 10^{6} s^{1} anticlockwise at 40° latitude). Results from the Michelson Doppler Imager (MDI) on board the Solar and Heliospheric Observatory (SOHO) obtained in 2010 are biased compared to the HMI/SDO results for the same period.
Key words: convection / Sun: helioseismology / Sun: oscillations / Sun: granulation
Appendices are available in electronic form at http://www.aanda.org
The azimuthally averaged velocity components v_{r} and v_{t} for supergranular outflows and inflows at various latitudes are only available at the CDS via anonymous ftp to cdsarc.ustrasbg.fr (130.79.128.5) or via http://cdsarc.ustrasbg.fr/vizbin/qcat?J/A+A/581/A67
© ESO, 2015
1. Introduction
Duvall & Gizon (2000) and Gizon & Duvall (2003) revealed that supergranules (see Rieutord & Rincon 2010, for a review) possess a statistically preferred sense of rotation that depends on solar latitude. In the northern hemisphere supergranules tend to rotate clockwise, in the southern hemisphere anticlockwise. This is due to the Coriolis force acting on the divergent horizontal flows of supergranules. For supergranulation (lifetime > 1 day), the Coriolis number is close to unity (see Gizon et al. 2010). As a consequence, the vorticity induced by the Coriolis force should be measurable by averaging the vorticity of many realizations of supergranules at a particular latitude.
For single realizations, Attie et al. (2009) detected strong vortices associated with supergranular inflow regions by applying a technique called balltracking. Komm et al. (2007) presented maps of vortical flows in quiet Sun convection using helioseismic ringdiagram analysis. With the same technique, Hindman et al. (2009) resolved the circular flow component associated with inflows into active regions; however, the spatial structure of such vortical flows has not yet been studied for many realizations. Knowledge of the flow structure of the average supergranule will help constrain models and simulations of turbulent convection that take rotation into account.
Here, we aim to spatially resolve the vertical component of flow vorticity associated with the average supergranule. We investigate both outflows from supergranule centers and inflows into the supergranular network. To measure the flow divergence and vorticity, we use two independent techniques: timedistance helioseismology (TD) and local correlation tracking (LCT) of granules. We use the TD method from Langfellner et al. (2014), where a measurement geometry that is particularly sensitive to the vertical component of flow vorticity was defined.
1.1. Timedistance helioseismology
Timedistance helioseismology makes use of waves travelling through the Sun (Duvall et al. 1993). A wave travelling from the surface point r_{1} through the solar interior to another surface point r_{2} is sensitive to local physical conditions (e.g., the wave speed or density). A flow in the direction r_{2} − r_{1} will increase the wave speed, thus reducing the travel time τ^{+} from r_{1} to r_{2}. A flow in the opposite direction will result in a longer travel time. The travel time is measured from the temporal crosscovariance, labeled C, of the observable φ obtained at the points r_{1} and r_{2}, (1)where h_{t} is the temporal cadence, T = 2(N + 1)h_{t} is the observation time, and t_{i} = ( − N, − N + 1,...,N)h_{t} are the times when φ is sampled. Typically, the observable φ is the Doppler lineofsight velocity component.
The travel time can be obtained from C by fitting a wavelet (Duvall et al. 1997) or by comparison with a reference crosscovariance and application of an appropriate weight function (Gizon & Birch 2004). To distinguish the flow signal in the travel time from other perturbations (e.g., local sound speed changes), we use the traveltime difference (2)Travel times that are especially sensitive to the horizontal flow divergence can be obtained by replacing r_{2} with an annulus around r_{1} (see Fig. 1a). Averaging φ over the annulus yields the “outward–inward” travel time τ^{oi} (Duvall et al. 1996). To obtain travel times that measure the vertical component of the flow vorticity, we average τ^{diff} components along a closed contour in the anticlockwise direction (Langfellner et al. 2014). We choose the contour to be a regular polygon with n points and edge length Δ in order to approximate an annulus (see Fig. 1b). The mean over the τ^{diff} components gives the vorticitysensitive τ^{ac} travel time, (3)where we use the notation r_{n + 1} = r_{1}.
Fig. 1 Measurement geometries for divergence and vorticitysensitive travel times and LCT velocities. a) The divergencesensitive travel time τ^{oi} is obtained by measuring the traveltime difference between a central point r and a surrounding annulus of radius Δ. b) The vorticitysensitive travel time τ^{ac} is obtained by measuring the traveltime differences τ^{diff} between adjacent points along a regular polygon surrounding r. The polygon consists of n points and has edges of length Δ. The points are situated on a circle of radius R = Δ/ [2sin(π/n)]. The travel time τ^{ac} is the average over the components τ^{diff} (see Eq. (3)). We obtain circulation velocities v^{ac} by multiplying τ^{ac} by a calibration factor. c) From LCT, we obtain the horizontal velocity components v_{x} and v_{y}. Given a reference point r, the LCT velocities can be expressed in 2D polar coordinates (r,θ) by the outward pointing radial velocity component v_{r} and the anticlockwise pointing tangential velocity component v_{t}. d) Using LCT velocities, we approximate v^{ac} by averaging the tangential velocity component v_{t} over the annulus shaded in green. The annulus is defined by its radius R and halfwidth s. We choose R = Δ for n = 6 and s = 2 Mm.

Open with DEXTER
Fig. 2 Comparison of lineofsight velocity from two different data products at 40° solar latitude on 6 June 2010. a) HMI Dopplergram averaged over 8 h. The map was convolved with a Gaussian of Mm and subsampled to match the coarser LCT resolution. The mean over the map and a linear function in the x direction (parameters determined by a leastsquares fit) were subtracted. b) LCT map from HMI intensity images, averaged over 8 h. The lineofsight velocity component was computed from the v_{x} and v_{y} components. For v_{y}, the mean over the map and a linear function in the y direction were subtracted. c) Scatter plot of the two maps. The Pearson correlation coefficient is 0.94. The red line shows the direction of largest scatter and crosses the origin. It is a bestfit line in the sense that it minimizes the sum of squared distances of the points perpendicular to the line (Pearson 1901). This is different from linear regression, where no error in the x coordinate is assumed and only the sum of squared distances in the y coordinate is minimized. The slope of the red line is 1.08; the error in the direction of lowest scatter is 33.9 m s^{1}.

Open with DEXTER
1.2. Local correlation tracking
Local correlation tracking measures how structures in solar images are advected by background flows. For the tracer, it is common to use solar granulation observed in photospheric intensity images (November & Simon 1988). The general procedure is as follows. Pairs of images are selected that observe the same granules but are separated by a time Δt. This time separation must be small compared to the lifetime of granules, i.e., Δt ≪ 10 min. To obtain spatially resolved velocity maps, an output map grid is defined. For each grid point, subsets of the intensity images that are centered around the grid point are selected by applying a spatial window and multiplied by a Gaussian with a full width at half maximum (FWHM), typically of a few megameters. The subsets are then crosscorrelated in the two spatial image dimensions x and y. The peak position (Δx,Δy) of the crosscorrelation yields the spatial shift. Since the measured shift is usually only a small fraction of a pixel, it must be obtained using an appropriate fitting procedure. Finally, the velocity components in the x and y directions are given by v_{x} = Δx/ Δt and v_{y} = Δy/ Δt.
The LCT method has proven valuable when measuring flow patterns in the Sun. For instance, Brandt et al. (1988) and Simon et al. (1989) observed single vortex flows at granulation scale. Hathaway et al. (2013) detected giant convection cells with LCT of supergranules in Doppler velocity images. For a comparison of different LCT techniques, see Welsch et al. (2007).
2. Observations and data processing
The basis for our measurements of wave travel times and flow velocities from local correlation tracking are two independent observables. We use Doppler velocity images for the TD and intensity images for the LCT. Both observables are measured for the full solar disk by the Helioseismic and Magnetic Imager (HMI) on board the Solar Dynamics Observatory (SDO) (Schou et al. 2012) and are available for the same periods of time. This allows a direct comparison of the two methods for looking at “the same Sun” but utilizing independent data.
We used 112 days of both SDO/HMI Dopplergrams and intensity images in the period from 1 May through 28 August 2010. Patches of approximate size 180 × 180 Mm^{2} were selected that are centered at solar latitudes from −60° to 60° in steps of 20°. They were tracked for 24 h each at a rate consistent with the solar rotation rate from Snodgrass (1984) at the center of the patch. The data cubes cross the central meridian at approximately half the tracking time. They were remapped using Postel’s projection with a spatial sampling of 0.5 arcsec px^{1} (0.348 Mm px^{1}). The temporal cadence is 45 s. We divided each data cube into three 8 h datasets. The x direction of the remapped images points to the west, the y direction points to the north.
For further comparison, we also used Dopplergrams from the Michelson Doppler Imager (MDI) on board the Solar and Heliospheric Observatory (SOHO) spacecraft (Scherrer et al. 1995). We chose 59 days of images taken in the MDI fulldisk mode that overlap in time with the HMI data (8 May through 11 July 2010). We tracked and remapped the MDI Dopplergrams in the same manner as for HMI, although with a coarser spatial sampling of 2.0 arcsec px^{1} (1.4 Mm px^{1}).
2.1. Flow velocity maps from local correlation tracking
For the LCT, we used our own code with the HMI photospheric intensity images as input. Our code is similar to the Fourier local correlation tracking (FLCT) code by Fisher & Welsch (2008), but uses another procedure to measure the peak positions of the crosscorrelation (described later in this section).
We removed the temporal mean image for every dataset and chose an output grid with a sampling of 2.5 arcsec px^{1} (1.7 Mm px^{1}), thus five times coarser than the input images. The size of the image subsets used for the crosscorrelation is adapted to the width of the Gaussian the subsets are multiplied by. We chose σ = 2 Mm for the Gaussian and a diameter of 4σ = 8 Mm for the subsets in both the x and y directions. The subsets are separated in time by Δt = 45 s (the cadence), which is sufficiently small compared to the granules’ evolution timescale. We averaged the crosscorrelations over the whole 8 h dataset.
To measure the peak position (Δx,Δy) of the crosscorrelation, we calculated (separately for x and y directions) the parameters of a parabola matching the crosscorrelation at the maximum and the adjacent pixels. To improve the estimate of the peak position, we translated the crosscorrelation by (− Δx, − Δy) using Fourier interpolation and iterated the parabolic fit. We repeated this procedure four times in total. The measured shifts converge quickly, the maximum additional shift in a fifth iteration is of the order of 10^{5} px at 60° latitude (corresponding to 0.2 m s^{1} or less), and the root mean square of the additional velocity shift is less than 0.02 m s^{1}. The measured peak position is the sum of the shifts measured in each step.
In Fig. 2 we compare the lineofsight component v_{LOS} of the LCT velocity with the velocity of an average Dopplergram, obtained by averaging Dopplergrams over the same time period as the LCT maps (8 h). Both images are for the same region at 40° latitude around the central meridian. At this latitude, the average Dopplergrams are dominated by the horizontal flows that can be measured with LCT, but systematic effects like foreshortening are weak (see Appendix C.1). We convolved the average Dopplergram with a Gaussian of width Mm (FWHM roughly 3 Mm). This resembles the convolution of the intensity maps prior to computing the correlation of image subsets in the LCT. The chosen width maximizes the correlation coefficient between the average Dopplergram and the LCT image. In addition, we interpolated the average Dopplergram onto the coarser LCT grid and at each pixel subtracted the mean velocity over the map. To remove the residual rotation signal, we further subtracted a linear gradient in the x direction that we obtained from a leastsquares fit of v_{x} averaged over y. The LCT lineofsight velocity component was computed from v_{x} and v_{y}. The v_{y} map showed a linear gradient in the y direction leading to an average velocity difference of about −200 m s^{1} between the bottom and the top of the map. This gradient is presumably due to the “shrinking Sun” effect, which has been discussed in Lisle & Toomre (2004), although for LCT of Dopplergrams (a short description is also given in Appendix C.1). The gradient (and the mean over the v_{y} map) was removed before computing v_{LOS}.
The processed v_{LOS} maps from direct Doppler data and LCT agree well (correlation coefficient 0.94). The scatter plot shows that on average the velocity values from LCT are slightly larger (by a factor of 1.08) than from the Dopplergrams. This is different from what other authors have reported. De Rosa & Toomre (1998) measured a slope of 0.89 and later (De Rosa & Toomre 2004) 0.69 using their LCT code and SOHO/MDI Dopplergrams. Rieutord et al. (2001) and Verma et al. (2013) found that LCT underestimates the real velocities in convection simulations (however at smaller spatial scales than we are studying).
Fig. 3 Power spectra (averaged over azimuth of wavevector k and 336 datasets) of TD traveltime maps, and LCT div_{h} and ω_{z} maps computed from HMI Dopplergrams and intensity images at the solar equator near disk center (distributed symmetrically between 7° east and west of the central meridian). a) Divergencesensitive travel times τ^{oi} for f modes and p_{1} modes as well as LCT div_{h}. b) Vorticitysensitive travel times τ^{ac} for f modes and p_{1} modes as well as LCT ω_{z}. The amplitudes of LCT div_{h} and ω_{z} power were rescaled to match the range of the traveltime power. The dashed lines represent noise models for the f and p_{1} modes based on Gizon & Birch (2004). The thickness of the lines denotes the 1σ error.

Open with DEXTER
2.2. Traveltime maps for horizontal divergence and vertical vorticity
As input for the traveltime measurements, we used the HMI Dopplergrams. In Fourier space, we filtered the 8 h datasets to select either the fmode or p_{1}mode ridge. The filters consist of a raised cosine function with a plateau region in frequency around the ridge maximum for every wavenumber k. Additionally, power for kR_{⊙}< 300 and kR_{⊙}> 2 600 (f modes) and for kR_{⊙}< 180 and kR_{⊙}> 1 800 (p_{1} modes) is discarded. The symbol R_{⊙} denotes the solar radius. The filter details are given in Appendix A.
We computed the crosscorrelation C from each filtered Doppler dataset in temporal Fourier space using (4)where ω denotes the angular frequency, h_{ω} = 2π/T (with T = 8 h) is the frequency resolution, and φ_{T} is the temporal Fourier transform of the filtered dataset (multiplied by the temporal window function).
For each dataset, we measured travel times τ^{oi} with an annulus radius of 10 Mm and τ^{ac} with the parameters Δ = 10 Mm and n = 6 (regular hexagon). We rotated the hexagon structure successively three times by an angle of 15° to obtain four τ^{ac} measurements for the same dataset that are only weakly correlated (see Langfellner et al. 2014, for details). Averaging over these measurements yields a higher signaltonoise ratio (S/N). We used the linearized traveltime definition by Gizon & Birch (2004) and a sliding reference crosscovariance that we obtained by averaging C over the entire map.
3. Comparison of horizontal divergence and vertical vorticity from TD and LCT
We now want to compare the measurements of horizontal divergence and vertical vorticity from TD and LCT for HMI. For TD, we use τ^{oi} and τ^{ac} as divergence and vorticitysensitive quantities. For LCT, we can directly compute div_{h} = ∂_{x}v_{x} + ∂_{y}v_{y} and ω_{z} = ∂_{x}v_{y} − ∂_{y}v_{x} from the v_{x} and v_{y} maps. To compute the derivatives of the LCT velocities, we apply SavitzkyGolay filters (Savitzky & Golay 1964) for a polynomial of degree three and a window length of 15 pixels (about 5 Mm, with a FWHM of about 3 Mm of the smoothing kernel). The SavitzkyGolay filters smooth out variations in the derivatives on spatial scales below the LCT resolution.
In the case of vorticity, we can also attempt a more direct comparison of TD and LCT. Consider the horizontal velocity field in 2D polar coordinates around r (see Fig. 1c). Instead of using v_{x} and v_{y} for LCT, we can study the velocity component in the radial (divergent) direction, v_{r}, and the component in the tangential (anticlockwise) direction, v_{t}. The travel time τ^{ac} essentially measures v_{t} averaged over the closed contour. The traveltime τ^{ac} is built up of pointtopoint components τ^{diff} that capture the flow component that is parallel to the line connecting the two measurement points. The velocity magnitude that corresponds to the travel time τ^{diff} can roughly be estimated by calibration measurements using a uniform flow (Appendix B). We use this calibration to convert τ^{ac} travel times into flow velocities and call the result v^{ac}. We note, however, that convective flows are highly turbulent, and thus a conversion factor obtained from uniform flows has to be treated with caution. Additionally, the conversion factor is sensitive to the details of the ridge filter (Appendix C.3). We also note that because no inversion is applied, the velocities v^{ac} represent an average over a depth range given by traveltime sensitivity kernels. For f modes, the range is from the surface to a depth of about 2 Mm, with a maximum of sensitivity near the surface, and for p_{1} modes from the surface to roughly 3 Mm, with one maximum near the surface and another at a depth of about 2 Mm (see, e.g., Birch & Gizon 2007). With LCT, we approximate v^{ac} by averaging v_{t} over a hardedge annulus with radius R = 10 Mm and halfwidth s = 2 Mm (see Fig. 1d). The annulus width roughly corresponds to the width of traveltime sensitivity kernels (see, e.g., Jackiewicz et al. 2007).
For the divergencesensitive measurements, this comparison is not possible without an inversion of the τ^{oi} maps. Therefore, we limit our comparison to TD τ^{oi} and LCT div_{h} in the following.
3.1. Spatial power spectra of horizontal divergence and vertical vorticity
From the TD τ^{oi} and τ^{ac} maps as well as the LCT div_{h} and ω_{z} maps, we calculated the spatial power spectra and averaged them over azimuth. The result for HMI is shown in Fig. 3. We rescaled the amplitude of the LCT power in order to show it together with the traveltime power.
For the divergence, the TD and LCT powers show a similar behavior at larger scales (except for kR_{⊙} = 25, which corresponds to the map size). However, all three curves peak at different scales – f modes at kR_{⊙} = 120, p_{1} modes at kR_{⊙} = 100 and LCT at kR_{⊙} = 150. The comparison with the curves for the TD noise model (Gizon & Birch 2004) shows that the highest S/N for the TD τ^{oi} occurs at supergranulation scale, with p_{1} modes probing slightly larger scales than f modes. For LCT, no noise model is available that we know of. Thus it remains unclear if the peak of the power coincides with the peak of the S/N. For small scales (kR_{⊙} larger than 300) the LCT power vanishes quickly, whereas the TD power reaches a noise plateau (f at kR_{⊙} = 500, p_{1} at kR_{⊙} = 300).
In the case of vorticity, the curves for TD and LCT look similar at large scales, although the power for LCT ω_{z} drops more quickly toward larger scales than for TD τ^{ac}. Compared to the divergence case, the peak positions are slightly shifted toward larger scales. However, the comparison with the TD noise model reveals that the S/N does not have a peak at supergranulation scale but continues to increase toward larger scales (cf. Langfellner et al. 2014). At mid scales, the LCT power drops off only slowly, whereas the TD power quickly reaches the noise level (f at kR_{⊙} = 250, p_{1} at kR_{⊙} = 200). It is not clear if the considerably larger power of LCT ω_{z} at mid scales (150 <kR_{⊙}< 500) is due to real flows or noise. At smaller scales, both TD curves behave more erratically. This happens, however, in a regime of almost pure noise. The LCT power drops off quickly beyond kR_{⊙} = 400.
3.2. Maps of horizontal divergence and vertical vorticity
Fig. 4 Comparison of TD and LCT maps at the equator. All maps are based on 8 h of HMI images (intensity and Doppler velocity) taken on 1 May 2010 and have been bandpass filtered around kR_{⊙} = 100. The color bar limits are set to the maximum absolute value of the corresponding map and symmetrized around zero. Left column: divergencesensitive travel times τ^{oi} for f modes as well as LCT horizontal divergence div_{h}. Right column: circulation velocities v^{ac} for TD as well as LCT vertical vorticity ω_{z}. The TD τ^{ac} maps were converted into velocity maps by pointwise multiplication with a constant factor −5.62 m s^{2} (f modes) and −11.1 m s^{2} (p_{1} modes), see Appendix B for details.

Open with DEXTER
When comparing maps of horizontal divergence and vertical vorticity, one point to consider is the different spatial sampling for TD and LCT maps. To correct for this, we interpolate the velocity maps derived from LCT onto the finer traveltime grid. In order to compare the maps on different spatial scales, we apply different bandpass filters to the individual maps in Fourier space. The individual filters are centered around kR_{⊙} values of 50 through 400 in steps of 50. Each filter is in a plateau region of width 50, centered around these values. Adjacent to both sides of the plateau are raised cosine flanks that make the filter smoothly reach zero within a kR_{⊙} range of 50. Additionally, we employ a highpass filter for kR_{⊙}> 400. From all maps, we subtract the respective mean map over all 336 datasets prior to filtering.
Example 8 h maps for τ^{oi} and v^{ac} from fmode travel times as well as div_{h} and ω_{z} from LCT are depicted in Fig. 4. The maps are filtered around kR_{⊙} = 100. We note that for the sake of easier comparison, we plotted −τ^{oi} rather than τ^{oi}. For the flow divergence, all three maps are highly correlated. The average correlation coefficients over all 336 maps are 0.96 between LCT div_{h} and −τ^{oi} for f modes and 0.92 between LCT div_{h} and −τ^{oi} for p_{1} modes.
In the case of flow vorticity, the agreement of the LCT and TD maps is weaker than for the divergence. The average correlation coefficient over all 336 maps is 0.68 between LCT ω_{z} and fmode v^{ac} and 0.51 between LCT ω_{z} and p_{1}mode v^{ac} (not shown). When comparing LCT v^{ac} instead of ω_{z} with TD v^{ac}, the correlation coefficients are noticably higher (0.75 for f modes and 0.57 for p_{1} modes). The flow magnitudes are roughly comparable.
Correlation between LCT maps and TD traveltime maps derived from HMI intensity images and Dopplergrams.
Table 1 shows the correlation coefficients between LCT and TD averaged over all datasets for all filters and including p_{1} modes. The error in the correlation coefficients is less than 0.01. We note that the edges (12 Mm) were removed from the maps before the correlation coefficients were computed. For the flow divergence, the correlation coefficients are almost constantly high for smaller kR_{⊙} values. In the range kR_{⊙} = 300 − 400, the correlation coefficient between LCT div_{h} and −τ^{oi} for f modes rapidly decreases from 0.78 to 0.31. For LCT and p_{1} modes, the correlation coefficient decreases from 0.83 to 0.15 from kR_{⊙} = 200 − 350. For the highpass filters, the LCT and TD maps are completely uncorrelated.
In the case of vorticity, the correlation decreases rapidly for both f and p_{1} modes at kR_{⊙} = 200. Again, the LCT and TD maps are uncorrelated for large kR_{⊙}. The correlation coefficients for LCT v^{ac} are significantly higher than for LCT ω_{z}.
The dependence of the correlation coefficients on spatial scale conceptually agrees well with the power spectra in Fig. 3. There is a high correlation on large scales where the observed TD traveltime power clearly exceeds the power of the TD noise model. On the other hand, the very low correlation on smaller scales reflects that the power of TD observations and noise model are almost equal.
Qualitatively, the correlation coefficients are comparable with the value 0.89 from De Rosa et al. (2000) who obtained traveltime and LCT velocity maps from SOHO/MDI Dopplergrams and smoothed the divergence maps by convolving with a Gaussian with FWHM 6.2 Mm.
4. Net vortical flows in the average supergranule
The main goal of this paper is to spatially resolve the vorticity of the average supergranule at different solar latitudes. In the following, we describe the averaging process and show average divergence and vorticity maps.
4.1. Obtaining maps of the average supergranule
To construct the average supergranule, we started by identifying the location of supergranule outflows and inflows in fmode τ^{oi} maps from HMI and MDI. We smoothed the maps by removing power for kR_{⊙}> 300 and applied an image segmentation algorithm (Hirzberger et al. 2008). The coordinates of the individual supergranules were used to align maps of various data products. For each identified position, we translated a copy of the map to move the corresponding supergranule to the map center. These translated maps were then averaged. At each latitude, we averaged over roughly 3000 supergranules in total for HMI (1500 supergranules for MDI). Supergranules closer than 8 Mm to the map edges were discarded.
We produced maps for the average supergranule outflow and inflow from τ^{oi} and τ^{ac} traveltime maps as well as LCT v_{x} and v_{y} maps. Prior to the averaging process, the LCT maps were spatially interpolated onto the (finer) traveltime grid. For all maps, we subtracted the mean map over all 336 HMI datasets (177 datasets in the case of MDI). This removes signal that does not change with time (or changes only slowly), including differential rotation. Additionally, we removed power for kR_{⊙}> 300 by applying a lowpass filter in Fourier space.
The resulting average τ^{ac} maps were converted into v^{ac} maps. From the LCT v_{x} and v_{y} maps for the average supergranule, we computed div_{h}, ω_{z}, and v^{ac}. The SavitzkyGolay filters that we employed to compute the spatial derivatives smooth out step artifacts from the image alignment process, yet preserve the signal down to the resolution limit of the LCT.
We corrected the v^{ac} and ω_{z} maps for geometrical centertolimb systematics (unless stated otherwise). We measured these effects using HMI and MDI observations west and east of the disk center, at relative longitudes corresponding to the latitudes of the regular observations. The idea is that any difference (beyond the noise background) between maps at disk center and a location west or east from disk center is due to geometrical centertolimb systematics. These systematics only depend on the distance to the disk center. Therefore, our raw measurements of v^{ac} and ω_{z} that we obtained north and south of the equator should be affected by the systematics in the same way as measurements west and east of the disk center. We corrected the raw data by subtracting the v^{ac} and ω_{z} maps west and east of the disk center. This approach is analogous to Zhao et al. (2013) who used the method to correct measurements of the meridional circulation. Figure 5 illustrates the correction process for v^{ac} maps at 60° latitude. The correction is particularly important for LCT at high latitudes. We note that the measured centertolimb systematics at lower latitudes (up to 40° north and south) are much weaker and only lead to a mild correction of the v^{ac} and ω_{z} maps. A further discussion of the centertolimb systematics can be found in Appendix C.1.
Fig. 5 Correction for geometrical centertolimb systematics in maps of circulation velocity v^{ac} for LCT and TD using HMI observations. This example shows the correction of v^{ac} maps at 60° latitude. a) Patch 1 (raw data) is located at 60° latitude at the central meridian. Patch 2 (systematics data) is situated at the equator, 60° west of the central meridian. We corrected the raw data by subtracting patch 2 from patch 1 (after rotating patch 2 anticlockwise by 90°). We note that we also use measurements of the systematics from the east for the correction (rotated clockwise by 90°). This is omitted in the sketch for clarity. b) Maps of v^{ac} for LCT and fmode TD. The three columns of panels show (from left to right) the measured raw data at 60° latitude, the measured systematics from 60° west and east (rotated and averaged), and the corrected data.

Open with DEXTER
4.2. Latitudinal dependence of the vertical vorticity in outflow regions
Figure 6 shows the circulation velocity v^{ac} in the average supergranule outflow region for LCT and fmode TD for latitudes from −60° to 60°, in steps of 20°. For comparison, the left column shows the horizontal divergence div_{h} from LCT. At all latitudes, there is a peak of positive divergence at the origin. All divergence peaks are surrounded by rings of negative divergence. This suggests that on average every supergranule outflow region is isotropically surrounded by inflow regions. The strength of the divergence peak slightly decreases toward higher latitudes. Furthermore, the divergence peaks are slightly shifted toward the equator at high latitudes (by about 0.7 Mm at ± 60°). These effects are presumably due to centertolimb systematics.
Fig. 6 Maps of horizontal divergence div_{h} and circulation velocity v^{ac} for the average supergranule outflow regions at various solar latitudes (after correction for geometrical centertolimb systematics). The maps were derived from HMI intensity images and Dopplergrams. The horizontal divergence div_{h} was computed from LCT v_{x} and v_{y} horizontal velocity maps. The LCT v^{ac} maps were obtained by averaging the tangential velocity component v_{t} over an annulus with radius 10 Mm and halfwidth 2 Mm to resemble the τ^{ac} measurement geometry (Fig. 1d). For TD, the v^{ac} maps are based on τ^{ac} traveltime maps (Fig. 1b) that were computed from Dopplergrams.

Open with DEXTER
The v^{ac} maps (center and right columns) show negative peaks (clockwise motion) in the northern hemisphere and positive peaks (anticlockwise motion) in the southern hemisphere. The peaks are surrounded by rings of opposite sign, as for the divergence maps. There is a remarkable agreement between LCT and TD in both shape and strength of the peak structures. At the solar equator, no peak and ring structures are visible; however, we note that the LCT and TD v^{ac} maps at the equator are still correlated. This shows that the “noise” background is due to real flows rather than measurement noise that is dependent on the technique.
To study the latitudinal dependence of the observed and corrected signal in more detail, we plot in Fig. 7a the peak velocity v^{ac} from Fig. 6, including p_{1}mode TD, as a function of solar latitude (lines). The peak velocity shows an overall decrease from south to north, with a zerocrossing at the equator. The curves are antisymmetric with respect to the origin. The peak velocities have similar values at a given latitude, with fmode velocities appearing slightly stronger than LCT and p_{1}mode velocities (in this order). The highest velocities are slightly above 10 m s^{1}. Figure 7b shows the peak magnitude in maps of the vertical vorticity ω_{z}, as measured from LCT. The overall appearance is similar to the circulation velocities v^{ac}. The highest absolute vorticity value is about 5 × 10^{6} s^{1}.
Figure 8a shows cuts through y = 0 for the maps of LCT and TD v^{ac} (including p_{1} modes) at 40° latitude. We use this latitude because the S/N in the v^{ac} and ω_{z} peaks is high compared to other latitudes, whereas the measurements are only mildly affected by centertolimb systematics. The velocity magnitudes and shapes of the curves are comparable for the three cases. For the LCT and fmode curves, an asymmetry in the westeast direction is visible. This means that the ring structures surrounding the peaks in the v^{ac} maps are stronger in the west than in the east. The FWHM is about 13 Mm in all cases. The peaks are very slightly shifted eastward. However, this east shift does not appear to be a general feature at all latitudes. Mostly, the shifts are consistent with random fluctuations. Partly, the shifts might also be due to other effects, for instance an incomplete removal of centertolimb systematics.
For comparison, the FWHM of the τ^{oi} peak structure is about 13 Mm for p_{1} modes, compared to about 11 Mm for fmode τ^{oi}. The horizontal divergence div_{h} from LCT at 40° latitude peaks at about 170 × 10^{6} s^{1} with a FWHM of about 10 Mm.
From the v^{ac} peak velocities, we can estimate the average vorticity ⟨ ω_{z} ⟩ _{A} over the circular area A of radius R = 10 Mm that is enclosed by the τ^{ac} measurement contour (see Fig. 1). The average vorticity is given by (5)where Γ is the flow circulation along the τ^{ac} measurement contour that we approximated with Γ ≈ 2πRv^{ac}. By taking the v^{ac} peak values, we obtain ⟨ ω_{z} ⟩ _{A} ≈ − 2.4 × 10^{6}s^{1} for the f modes, ⟨ ω_{z} ⟩ _{A} ≈ − 1.6 × 10^{6}s^{1} for the p_{1} modes, and ⟨ ω_{z} ⟩ _{A} ≈ − 2.0 × 10^{6}s^{1} for LCT. Thus the average vorticity in the circular region is roughly half the peak vorticity at 40° latitude.
4.3. Inflow regions
So far we have discussed vortical flows around supergranule outflow centers. It is interesting though to compare the magnitude and profile of these flows with the average inflow regions, which have a different geometrical structure (connected network instead of isolated cells). Analogously to Fig. 6 for the outflows, Fig. 9 shows maps of div_{h} and v^{ac} around the average supergranule inflow center. As for the outflows, the v^{ac} maps from TD and LCT agree very well at all analyzed latitudes. The peaks in the v^{ac} maps have the opposite sign compared to the outflows. This indicates that flows are preferentially in the clockwise (anticlockwise) direction in the average supergranular outflow region and anticlockwise (clockwise) in the average inflow region in the northern (southern) hemisphere. Cuts through y = 0 of the v^{ac} maps at 40° latitude are shown in Fig. 8b. The v^{ac} curves have the same shape as the corresponding curves for the average outflow center (with a FWHM of 14 to 16 Mm), but the peak flow magnitude is reduced and the sign is switched. As in the case of the outflows, the ring structures are stronger on the west side than on the east side.
The horizontal flow divergence div_{h} in the average inflow is similar to the average outflow (about the same FWHM) but with reversed signs and reduced magnitude. The peak divergence is about −120 × 10^{6} s^{1} at 40° latitude with a FWHM of about 10 Mm. As in the case of the outflows, there is a systematic decrease in peak magnitude and a slight equatorward shift of the div_{h} peak at high latitudes.
The latitude dependence of the v^{ac} peak values for the average supergranule inflow region (dashed lines in Fig. 7a) is almost mirrorsymmetric to the outflow regions. The values are slightly smaller compared to the average outflow, with a ratio inflow/outflow of −0.87 ± 0.03 for the f modes, −0.85 ± 0.06 for the p_{1} modes, and −0.72 ± 0.05 for the LCT v^{ac}. In the case of ω_{z} (Fig. 7b), on the other hand, the ratio between the average inflow and outflow center is −1.8 ± 0.2.
From the peak values of v^{ac}, we can estimate the average vorticity ⟨ ω_{z} ⟩ _{A} over the circular area A of radius R = 10 Mm in the same way as for the outflow regions. We obtain ⟨ ω_{z} ⟩ _{A} ≈ 1.8 × 10^{6}s^{1} for the f modes, ⟨ ω_{z} ⟩ _{A} ≈ 1.2 × 10^{6}s^{1} for the p_{1} modes, and ⟨ ω_{z} ⟩ _{A} ≈ 1.4 × 10^{6}s^{1} for LCT. The peak vorticity at 40° latitude is therefore larger by a factor of about five compared to the vorticity averaged over the circular area.
Fig. 7 Peak v^{ac} and ω_{z} values for the average supergranule at different solar latitudes. a) Circulation velocity v^{ac} for LCT, f modes, and p_{1} modes. b) Vertical component of flow vorticity ω_{z} obtained from LCT. Solid lines are for the average supergranule outflow region, dashed lines for the average supergranule inflow region. At 0° latitude, the values at the map center are shown instead of the peak values. The error bars were computed by dividing the 336 datasets into eight parts and measuring the variance of v^{ac} and ω_{z} at the peak positions over the eight parts.

Open with DEXTER
Fig. 8 a) Cuts through the maps of the circulation velocity v^{ac} for the average supergranule outflow region at 40° latitude (shown in Fig. 6), at y = 0. The TD and LCT maps were derived from HMI Dopplergrams and intensity images. The thin lines denote estimates of the variability of the data as obtained from dividing the 336 datasets into eight parts. The 1σ level is shown. b) As a), but for the average supergranule inflow region at 40° latitude.

Open with DEXTER
4.4. Dependence of the vertical vorticity on horizontal divergence
The detection of net tangential flows in the average supergranule raises the question of how much the magnitudes of v^{ac} and ω_{z} depend on the selection of supergranules. As a test, we sort the identified supergranules at 40° latitude from HMI with respect to their divergence strength, as measured by the peak fmode τ^{oi} of each supergranule. The sorted supergranules are assigned to four bins, which each contain roughly the same number of supergranules. The boundaries of the bins for fmode τ^{oi} are about −96.9, −53.8, −42.1, −31.5, and −16.0 s for the outflows and 67.5, 38.3, 32.1, 26.0, and 11.1 s for the inflows. We note that a simple scatter plot would be very noisy because the v^{ac} and ω_{z} maps are dominated by turbulence.
For each bin, we computed the peak TD τ^{oi} and τ^{ac} as well as LCT div_{h} and ω_{z} in the same way as for all identified supergranules that we discussed in the previous sections, but without the correction for centertolimb systematics. In Fig. 10a, we plot the peak τ^{ac} as a function of the peak τ^{oi} from f modes and p_{1} modes both for outflows and inflows. The magnitude of τ^{ac} clearly increases with τ^{oi}. The ratio τ^{ac}/τ^{oi} is roughly constant. Only the fmode bin for the weakest inflows deviates substantially from this behavior. Figure 10b shows the peak ω_{z} versus the peak div_{h} from LCT. In this case, the relationship is less clear, considering the large vertical error bars. A constant ratio ω_{z}/ div_{h} is (at least by eye) consistent with the measurements. However, for outflows ω_{z} might also be constant. We note that the fit lines for the travel times in Fig. 10a have almost the same slopes for outflows and inflows, whereas in the case of LCT div_{h} and ω_{z} the slope for the inflows is much steeper than for the outflows. This is consistent with Fig. 7, where ω_{z} was shown to be twice as strong in the inflows as in the outflows, whereas the velocities v^{ac} are of similar magnitude (not just for TD, but also for LCT). As discussed in Sects. 4.2 and 4.3, the velocities v^{ac} do not directly measure the vorticity at a given position, but rather a spatial average.
In general, we can conclude that a selection bias in favor of stronger or weaker supergranules probably does not affect the measured ratio of vertical vorticity to horizontal divergence.
4.5. Comparison of SDO/HMI and SOHO/MDI
While the results for the average supergranule were obtained using different methods (TD and LCT) and image types (Dopplergrams and intensity images), they are all based on the same instrument, HMI. It is thus useful to compare the HMI results to v^{ac} maps that have been measured from independent MDI data. Since MDI cannot sufficiently resolve granules at higher latitudes to successfully perform LCT, however, we only discuss TD.
Fig. 9 Same as Fig. 6, but for the average supergranule inflow regions.

Open with DEXTER
In contrast to HMI, the correction for geometric centertolimb systematics is not sufficient for MDI. For example, for fmode TD at 40° latitude, the central peak structure appears elongated (see Fig. C.1). Nevertheless, the v^{ac} values at the origin are remarkably similar for HMI and MDI. At the average outflow, we measure (− 11.1 ± 0.4) m s^{1} (HMI) versus (− 10.1 ± 0.8) m s^{1} (MDI) for f modes and (− 7.7 ± 0.3) m s^{1} compared to (− 6.5 ± 0.8) m s^{1} for p_{1} modes.
For inflows, the MDI v^{ac} maps compare to HMI in the same manner, with MDI being slightly weaker than HMI. The flow magnitudes for HMI and MDI at the origin after correction are (8.9 ± 0.4) m s^{1} versus (7.2 ± 1.0) m s^{1} for f modes and (6.1 ± 0.3) m s^{1} compared to (4.2 ± 0.5) m s^{1} for p_{1} modes. We note that the noise background is stronger for MDI. This is, however, not surprising, since only about half the number of Dopplergrams (compared to HMI) have been used to produce these maps.
The latitude dependence of v^{ac} at the origin for MDI is qualitatively comparable with HMI (see Fig. 11). We measure a zerocrossing and sign change of v^{ac} at the equator, both for the average supergranule outflow and inflow regions. However, the v^{ac} magnitudes are systematically smaller for MDI. This difference increases farther away from the equator. It is especially dramatic for f modes at ± 60° latitude. Whereas v^{ac} reaches values between 10 and 12 m s^{1} at these latitudes in HMI, for MDI the velocity magnitudes are below 5 m s^{1}. This is probably connected to the lower spatial resolution of MDI, which results in a larger impact of geometrical foreshortening effects at high latitudes compared to HMI.
While MDI clearly does not perform as well as HMI, the agreement with HMI at the origin gives reason to believe that MDI v^{ac} measurements are still useful. This would be especially interesting for longterm studies of the solar cycle dependence since continuous data reaching back to 1996 could be used.
5. Differences between outflow and inflow regions
The differences between the average supergranule outflow and inflow regions as measured from LCT in HMI data are summarized in Fig. 12. The arrows show the horizontal velocity magnitudes and directions at 40° latitude. The flows are dominated by the radial velocity component. For direct comparison, the filled contours give the vertical vorticity ω_{z} of the flows. In the average outflow region (Fig. 12a), the vorticity shows a broad plateau region (FWHM about 13 Mm). The region of negative vorticity is surrounded by a ring of positive vorticity with a diameter of about 30 Mm.
In contrast, the vorticity in the average inflow region (Fig. 12b) falls off rapidly from its narrow center (FWHM 8 Mm). We note that the FWHM of the vorticity peak is smaller than for the divergence peak (about 10 Mm), but it is still larger than the FWHM of the LCT correlation measurements (roughly 3 Mm). The peak vorticity magnitude is about twice the value of the outflow region (about 8 × 10^{6} s^{1} anticlockwise compared to 4 × 10^{6} s^{1} clockwise). As it is for the average outflow region, the central vorticity structure in the inflow region is surrounded by a ring of vorticity with opposite sign. The vorticity magnitude in the ring appears to be smaller than in Fig. 12a.
These differences in the vortex structures of outflow and inflow regions are visible at all latitudes (except at the equator, where we measure no net vorticity). The FWHM of the peak structures as well as the ratio of the peak vorticities (between outflow and inflow regions) are constant over the entire observed latitude range. Such differences do not appear in maps of the horizontal divergence div_{h} (the FWHM is about 10 Mm in both outflow and inflow regions).
Differences in the vorticity strength between regions of divergent and convergent flows have also been reported by other authors who studied the statistics of vortices in solar convection. Wang et al. (1995) found, on granular scales, the root mean square of ω_{z} to be slightly higher in inflow regions. Pötzi & Brandt (2007) observed that vortices are strongly connected to sinks at mesogranular scales. Concentration of fluid vorticity in inflows has also been found in simulations of solar convection (e.g., Stein & Nordlund 1998, on granulation scale). However, the authors did not find any preferred sign of ω_{z}. The increased vorticity strength in inflows might be a manifestation of the “bathtub effect” (Nordlund 1985). In that scenario, initially weak vorticity becomes amplified in inflows due to angular momentum conservation. In the downflows that are associated with the horizontal inflows because of mass conservation, the vortex diameter is reduced since the density rapidly increases with depth. This further enhances the vorticity.
Fig. 10 Vorticity as a function of divergence for the average supergranule at 40° latitude from HMI data. a) Vorticity travel times τ^{ac} versus divergence travel times τ^{oi} for TD f modes and p_{1} modes. The upper left quadrant shows the values for the average outflows, the lower right quadrant for the average inflows. The solid and the dashed lines show leastsquares fits of a linear function through the origin for outflows and inflows, respectively. The error bars were obtained by dividing the 336 datasets into eight parts. b) As a) but the peak ω_{z} versus the peak div_{h} from LCT is shown. We note that the quadrants depicting outflows and inflows are flipped compared to the travel times in a).

Open with DEXTER
6. Radial and tangential velocities versus radial distance
We now look in greater detail at the isotropic part of the horizontal flow profile of the average supergranule. Figures 13a and b show the azimuthal averages of v_{r} and v_{t} around both the average supergranule outflow and inflow centers as a function of horizontal distance r to the outflow/inflow center at 40° latitude. In both cases, the magnitude of v_{r} increases from the outflow/inflow center until it reaches a peak velocity (which we call ) of slightly more than 300 m s^{1} and −200 m s^{1}, respectively, at r = 7 Mm. The flow magnitudes then decrease and v_{r} switches sign at a distance of about 14 Mm, marking the edge of the average inflow/outflow region. In general, the v_{r} curves for outflow and inflow regions are similar except for the difference in flow magnitude.
The tangential velocity v_{t}, on the other hand, exhibits similar peak velocities for outflow and inflow regions (both m s^{1}), but has opposite signs and reaches these peaks at different distances. The peak magnitude is about 26 times smaller than in the outflow region and 18 times smaller in the inflow region. In the outflow region, the peak is located at r = 9 Mm, whereas it lies at r = 5 Mm around the average inflow center. Despite the different peak locations, v_{t} switches sign at a distance of about 17 Mm around the outflow and the inflow centers.
The different peak locations of v_{t} possibly explain why the magnitude ratio of v^{ac} between the average supergranule inflow and outflow region is smaller than one. The v^{ac} measurements are especially sensitive to v_{t} at r = 10 Mm (the annulus radius). At this distance, we have v_{t} = 10 m s^{1} around the outflow centers, but v_{t} = −7 m s^{1} around the inflow centers, yielding a factor of −0.7. This agrees well with the ratio of the slopes for LCT v^{ac} in Fig. 7 that we discussed in Sect. 4.3.
Measuring the peak values of v_{r} and v_{t} at all latitudes except the equator leads to the following approximate relations, where we used the differential rotation model from Snodgrass (1984) to compute Ω(λ), and Ω_{0} denotes the rotation rate at the equator. The coefficients b_{out}: = −0.059 ± 0.001 and b_{in}: = −0.089 ± 0.002 are remarkably constant over the whole latitude range from −60° to 60°, although decreases from the equator (335 m s^{1} for outflows and −237 m s^{1} for inflows) toward high latitudes (e.g., 272 m s^{1} for outflows and −188 m s^{1} for inflows at 60° north). The same trend is observed for measuring west and east off disk center (e.g., 272 m s^{1} for outflows and −187 m s^{1} for inflows at 60° west), suggesting that the decrease is a systematic centertolimb effect. Since b_{out} and b_{in} are not affected, is likely to suffer from the same systematic decrease as .
We can use Eqs. (6) and (7) to predict for supergranules in the polar regions. Assuming b_{out} and b_{in} are independent of latitude even beyond λ = ± 60° and employing from the equator where centertolimb effects are small, the average supergranule at the north pole should rotate with m s^{1}) × Ω(90°)/Ω_{0} for outflows and m s^{1}) × Ω(90°)/Ω_{0} for inflows. At the south pole, merely the sign of should change.
Fig. 11 Velocities v^{ac} for the average supergranule measured at the origin at different solar latitudes from MDI TD (f modes and p_{1} modes). Solid lines are for the average supergranule outflow region, dashed lines for the average supergranule inflow region. The error bars were computed by dividing the 177 datasets into eight parts.

Open with DEXTER
Fig. 12 LCT horizontal velocity (black arrows) and vertical vorticity ω_{z} (filled contours) for the average supergranule at solar latitude 40°. a) Average outflow region. b) Average inflow region. Arrows for velocity magnitudes less than 60 m s^{1} are omitted.

Open with DEXTER
Fig. 13 Azimuthally averaged horizontal velocities around the average supergranule outflow and inflow centers at solar latitude 40°. The measurements were obtained from LCT of granules in HMI intensity images. a) Horizontal velocities v_{r} and v_{t} around the average supergranule outflow center. The thin lines mark an estimate of the variability of the data as measured by dividing the 336 datasets into eight parts. For v_{r}, the 10σ level is shown, for v_{t} the 3σ level. b) As a), but around the average supergranule inflow center.

Open with DEXTER
Various authors have proposed models to describe vortex flows (e.g., Taylor 1918; Veronis 1959; Simon & Weiss 1997), introducing the (turbulent) kinematic viscosity η as a parameter that influences the tangential velocity component v_{t}(r). In the Veronis model, the tangential flow is given by (8)where l and d are the horizontal size and depth of the supergranule, respectively. This relationship is consistent with the measurements in Eqs. (6) and (7). We note, however, that the Veronis convection model does not include turbulence (beyond η) or stratification.
Taylor (1918) presented a simple model that describes the decay of a narrow isolated vortex with v_{r} = 0 due to fluid viscosity. In this case, the tangential velocity component is (9)with a constant a and the “age” of the vortex t. A leastsquares fit of Eq. (9) to our measured curve v_{t}(r) describes the v_{t} profile for the average inflow surprisingly well. We can use 4ηt ≈ 7.8 Mm from the fit to obtain a crude estimate of the turbulent viscosity. By identifying the vortex age t with the supergranule lifetime (~ 1 day), we get η ~ (1 day /t) × 180 km^{2} s^{1}. This is similar to values from the literature. For example, Duvall & Gizon (2000) and Simon & Weiss (1997) obtained η = 250 km^{2} s^{1} using helioseismology and local correlation tracking of granules, respectively. The order of magnitude of our estimate for η also agrees with previous measurements of the diffusion coefficient of small magnetic elements (Jafarzadeh et al. 2014, and references therein).
7. Summary
7.1. Validation
We have successfully measured the horizontal divergence and vertical vorticity of nearsurface flows in the Sun using different techniques (TD and LCT), as well as different instruments (HMI and MDI). Horizontal flow velocities from LCT compare well with lineofsight Dopplergrams (correlation coefficient 0.94). Horizontal divergence maps from TD and LCT are in excellent agreement for 8 h averaging (correlation coefficient 0.96 for 75 ≲ kR_{⊙} ≲ 175). Vertical vorticity measurements from TD and LCT are highly correlated at large spatial scales (correlation coefficient larger than 0.7 for kR_{⊙} ≤ 100).
We studied the average properties of supergranules by averaging over 3 000 of them in latitude strips from −60° to 60°. The vertical vorticity maps as measured from HMI TD and HMI LCT for the average supergranule agree at low and mid latitudes. Above ± 40° latitude, however, the LCT and TD results are different owing to geometrical centertolimb systematic errors. After correcting for these errors using measurements at the equator away from the central meridian (cf. Zhao et al. 2013), TD and LCT results agree well. For MDI, the TD maps are dominated by systematic errors even at low latitudes. Therefore, HMI is a significant improvement over MDI.
7.2. Scientific results: spatial maps of vertical vorticity
Our findings can be summarized as follows. The root mean square of the vertical vorticity in a map of size ~ 180 × 180 Mm^{2} at the equator and 8 h averaging is about 15 × 10^{6}s^{1} after lowpass filtering (power at scales kR_{⊙}< 300).
After averaging over several thousand supergranules, the average outflow and inflow regions possess a net vertical vorticity (except at the equator). The latitudinal dependence of the vorticity magnitude is consistent with the action of the Coriolis force: ω_{z}(λ) ∝ Ω(λ)sinλ/ Ω_{0}. In the northern hemisphere, horizontal outflows are associated with clockwise motion, whereas inflows are associated with anticlockwise motion. In the southern hemisphere, the sense of rotation is reversed. This resembles the behavior of high and low pressure areas in the Earth’s weather system (e.g., hurricanes).
Vortices in the average supergranular inflow regions are stronger and more localized than in outflow regions. For example, at 40° latitude the vertical vorticity is 8 × 10^{6}s^{1} anticlockwise in inflows versus 4 × 10^{6}s^{1} clockwise in outflows, whereas the FWHM is 8 Mm versus 13 Mm. The maximum tangential velocity in the average vortex is about 12 m s^{1} at ± 40° latitude, which is about 26 and 18 times smaller than the maximum radial flow component for outflow and inflow regions, respectively.
We have demonstrated the ability of TD and LCT to characterize rotating convection near the solar surface. This information can be used in the future to constrain models of turbulent transport mechanisms in the solar convection zone (see, e.g., Rüdiger et al. 2014). The azimuthally averaged velocity components v_{r} and v_{t} for supergranular outflows and inflows at various latitudes are available at the CDS.
Acknowledgments
J.L., L.G., and A.C.B. designed research. J.L. performed research, analyzed data, and wrote the paper. J.L. and L.G. acknowledge research funding by Deutsche Forschungsgemeinschaft (DFG) under grant SFB 963/1 “Astrophysical flow instabilities and turbulence” (Project A1). The HMI data used are courtesy of NASA/SDO and the HMI science team. SOHO is a project of international cooperation between ESA and NASA. The data were processed at the German Data Center for SDO (GDCSDO), funded by the German Aerospace Center (DLR). We thank J. Schou, T. L. Duvall Jr., and R. Cameron for useful discussions. We are grateful to R. Burston and H. Schunker for providing help with the data processing, especially the tracking and mapping. We used the workflow management system Pegasus (funded by The National Science Foundation under OCI SI2SSI program grant #1148515 and the OCI SDCI program grant #0722019).
References
 Attie, R., Innes, D. E., & Potts, H. E. 2009, A&A, 493, L13 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Birch, A. C., & Gizon, L. 2007, Astron. Nachr., 328, 228 [NASA ADS] [CrossRef] [Google Scholar]
 Brandt, P. N., Scharmer, G. B., Ferguson, S., Shine, R. A., & Tarbell, T. D. 1988, Nature, 335, 238 [NASA ADS] [CrossRef] [Google Scholar]
 De Rosa, M. L., & Toomre, J. 1998, in Structure and Dynamics of the Interior of the Sun and Sunlike Stars, ed. S. Korzennik, ESA SP, 418, 753 [Google Scholar]
 De Rosa, M. L., & Toomre, J. 2004, ApJ, 616, 1242 [NASA ADS] [CrossRef] [Google Scholar]
 De Rosa, M., Duvall, Jr., T. L., & Toomre, J. 2000, Sol. Phys., 192, 351 [NASA ADS] [CrossRef] [Google Scholar]
 Duvall, Jr., T. L., & Gizon, L. 2000, Sol. Phys., 192, 177 [NASA ADS] [CrossRef] [Google Scholar]
 Duvall, T. L., & Hanasoge, S. M. 2013, Sol. Phys., 287, 71 [NASA ADS] [CrossRef] [Google Scholar]
 Duvall, Jr., T. L., Jefferies, S. M., Harvey, J. W., & Pomerantz, M. A. 1993, Nature, 362, 430 [NASA ADS] [CrossRef] [Google Scholar]
 Duvall, Jr., T. L., D’Silva, S., Jefferies, S. M., Harvey, J. W., & Schou, J. 1996, Nature, 379, 235 [NASA ADS] [CrossRef] [Google Scholar]
 Duvall, Jr., T. L., Kosovichev, A. G., Scherrer, P. H., et al. 1997, Sol. Phys., 170, 63 [NASA ADS] [CrossRef] [Google Scholar]
 Fisher, G. H., & Welsch, B. T. 2008, in Subsurface and Atmospheric Influences on Solar Activity, eds. R. Howe, R. W. Komm, K. S. Balasubramaniam, & G. J. D. Petrie, ASP Conf. Ser., 383, 373 [Google Scholar]
 Gizon, L., & Birch, A. C. 2004, ApJ, 614, 472 [NASA ADS] [CrossRef] [Google Scholar]
 Gizon, L., & Duvall, Jr., T. L. 2003, in GONG+ 2002. Local and Global Helioseismology: the Present and Future, ed. H. SawayaLacoste, ESA SP, 517, 43 [Google Scholar]
 Gizon, L., Birch, A. C., & Spruit, H. C. 2010, ARA&A, 48, 289 [NASA ADS] [CrossRef] [Google Scholar]
 Hathaway, D. H., Upton, L., & Colegrove, O. 2013, Science, 342, 1217 [NASA ADS] [CrossRef] [Google Scholar]
 Hindman, B. W., Haber, D. A., & Toomre, J. 2009, ApJ, 698, 1749 [NASA ADS] [CrossRef] [Google Scholar]
 Hirzberger, J., Gizon, L., Solanki, S. K., & Duvall, T. L. 2008, Sol. Phys., 251, 417 [NASA ADS] [CrossRef] [Google Scholar]
 Jackiewicz, J., Gizon, L., Birch, A. C., & Duvall, Jr., T. L. 2007, ApJ, 671, 1051 [NASA ADS] [CrossRef] [Google Scholar]
 Jafarzadeh, S., Cameron, R. H., Solanki, S. K., et al. 2014, A&A, 563, A101 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Komm, R., Howe, R., Hill, F., et al. 2007, ApJ, 667, 571 [NASA ADS] [CrossRef] [Google Scholar]
 Korzennik, S. G., RabelloSoares, M. C., & Schou, J. 2004, ApJ, 602, 481 [NASA ADS] [CrossRef] [Google Scholar]
 Langfellner, J., Gizon, L., & Birch, A. C. 2014, A&A, 570, A90 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lisle, J., & Toomre, J. 2004, in SOHO 14 Helio and Asteroseismology: Towards a Golden Future, ed. D. Danesy, ESA SP, 559, 556 [Google Scholar]
 Nordlund, A. 1985, Sol. Phys., 100, 209 [NASA ADS] [CrossRef] [Google Scholar]
 November, L. J., & Simon, G. W. 1988, ApJ, 333, 427 [NASA ADS] [CrossRef] [Google Scholar]
 Pearson, K. 1901, Philosophical Magazine, 2, 559 [CrossRef] [Google Scholar]
 Pötzi, W., & Brandt, P. N. 2007, Central Eur. Astrophys. Bull., 31, 11 [NASA ADS] [Google Scholar]
 Rieutord, M., & Rincon, F. 2010, Liv. Rev. Sol. Phys., 7, 2 [Google Scholar]
 Rieutord, M., Roudier, T., Ludwig, H.G., Nordlund, Å., & Stein, R. 2001, A&A, 377, L14 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Rüdiger, G., Küker, M., & Tereshin, I. 2014, A&A, 572, L7 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Savitzky, A., & Golay, M. J. E. 1964, Anal. Chem., 36, 1627 [NASA ADS] [CrossRef] [Google Scholar]
 Scherrer, P. H., Bogart, R. S., Bush, R. I., et al. 1995, Sol. Phys., 162, 129 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Schou, J., Scherrer, P. H., Bush, R. I., et al. 2012, Sol. Phys., 275, 229 [NASA ADS] [CrossRef] [Google Scholar]
 Simon, G. W., & Weiss, N. O. 1997, ApJ, 489, 960 [NASA ADS] [CrossRef] [Google Scholar]
 Simon, G. W., November, L. J., Ferguson, S. H., et al. 1989, in NATO Advanced Science Institutes (ASI) Series C 263, eds. R. J. Rutten & G. Severino, 371 [Google Scholar]
 Snodgrass, H. B. 1984, Sol. Phys., 94, 13 [NASA ADS] [CrossRef] [Google Scholar]
 Stein, R. F., & Nordlund, Å. 1998, ApJ, 499, 914 [NASA ADS] [CrossRef] [Google Scholar]
 Taylor, G. I. 1918, Reports and Memoranda of the Advisory Committee for Aeronautics, 598, 73 [Google Scholar]
 Verma, M., Steffen, M., & Denker, C. 2013, A&A, 555, A136 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Veronis, G. 1959, J. Fluid Mech., 5, 401 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Wang, Y., Noyes, R. W., Tarbell, T. D., & Title, A. M. 1995, ApJ, 447, 419 [NASA ADS] [CrossRef] [Google Scholar]
 Welsch, B. T., Abbett, W. P., De Rosa, M. L., et al. 2007, ApJ, 670, 1434 [NASA ADS] [CrossRef] [Google Scholar]
 Zhao, J., Bogart, R. S., Kosovichev, A. G., Duvall, Jr., T. L., & Hartlep, T. 2013, ApJ, 774, L29 [NASA ADS] [CrossRef] [Google Scholar]
Online material
Appendix A: Ridge filters
Parameters of the ridge filters that are used for the traveltime measurements in this paper (see text for details).
Prior to the traveltime measurements, the wavefield that is present in the Dopplergrams is filtered to select single ridges (the f modes or the p_{1} modes). The goal is to capture as much of the ridge power as possible, even if the waves are Dopplershifted by flows. At the same time, we want to prevent power from neighboring ridges from leaking in and select as little background power as possible.
To construct the filter, we first measure the power spectra of the Dopplergrams at the equator and average over 60 days (59 days) of data in the case of HMI (MDI). After further azimuthal averaging, we identify the frequency ω_{mode} where the ridge maximum is located as a function of wavenumber k.
The filter is constructed for each k as a plateau of width 2ω_{δ} centered around the ridge maximum ω_{mode}. The lower and upper boundaries of the plateau we call ω_{b} and ω_{c}. Next to the plateau, we add a transition region of width ω_{slope}, which consists of a raised cosine function that guides the filter from one to zero, symmetrically around ω_{mode}. The lower and upper limits of the filter we call ω_{a} and ω_{d}, respectively.
The plateau halfwidth ω_{δ} consists of the following terms (A.1)where ω_{Γ}(k) is the FWHM of the ridge (measured from the average power spectra), ω_{v}(k) = akv_{max} is the Doppler shift due to a hypothetical flow of magnitude v_{max} multiplied by a scale factor a, and ω_{const} is a constant term of small magnitude that broadens the filter predominantly at small wavenumbers.
The width of the transition region relative to the plateau width is (A.2)where j is a unitless factor.
In addition, we restrict the filter to a range of wavenumbers. Above and below a k interval, the filters are set to zero. The k limits of the interval are chosen such that the ridge power is roughly twice the background power. Because ω_{mode} is a function of wavenumber, these limits can also be expressed as frequencies ω_{min} and ω_{max}.
Table A.1 lists the filter parameters we chose for the fmode and p_{1}mode ridge filters that we use throughout the paper. We note that we use the same filters for all latitudes and longitudes. For the p_{1} modes, we also list an alternative filter that we use to discuss the impact of the filter details on the traveltime measurements (see Appendix C.3).
Appendix B: Conversion of travel times into flow velocities
Pointtopoint travel times τ^{diff}(r_{1},r_{2}) are sensitive to flows in the direction of r_{1} − r_{2}. If the flow structure is known, travel times τ^{diff} can be predicted with the knowledge of sensitivity kernels. Conversely, the velocity field can be obtained from measured travel times by an inversion. Such inversions are, however, delicate, as they are, in general, illposed problems. A simple way to obtain rough estimates of the flow velocity while avoiding inversions is the multiplication of the travel times by a constant conversion factor. Such a conversion factor can be calculated by artificially adding the signature of a uniform flow of known magnitude and direction to Dopplergrams. The magnitude of the measured travel time divided by the input flow speed yields the conversion factor. In the following, we describe this process.
First, we create data cubes φ_{v}(r,t) that have Dopplershifted power spectra to mimic the effect of a flow v independent of position r and time t. The data cubes are based on the noise model by Gizon & Birch (2004), so signatures from flows others than v are not present. Following the noise model, we construct in Fourier space . Here k is the horizontal wave vector; is a Dopplershifted power spectrum; and, at each (k,ω), are independent complex Gaussian random variables with zero mean and unit variance. Employing ensures that the values φ_{v}(k,ω) are uncorrelated, which means that there is no signal from wave scattering. We use based on an average power spectrum that was measured from 60 days of HMI Dopplergrams (and 59 days of MDI Dopplergrams) at the solar equator. The quantity δω = k·v is the frequency shift due to a background flow v = (v_{x},0) that we add. We construct 8 h datasets φ_{v}(r,t) for v_{x} in the range between −1000 and 1000 m s^{1} in steps of 100 m s^{1}. For each velocity value, we compute ten realizations.
As a consistency check, we apply a second method for adding an artificial velocity signal to the HMI Dopplergram datasets. This procedure consists of tracking at an offset rate. The tracking parameters from Snodgrass (1984) are modified by a constant corresponding to a v_{x} velocity of −100 m s^{1} and 100 m s^{1}, respectively. The tracking and mapping procedure is as for the regular HMI observations. We produce 112 such datacubes for each v_{x} value at the solar equator.
For both methods, the 8 h datasets are ridgefiltered like the normally tracked Doppler observations (f modes and p_{1} modes). We measure travel times τ^{diff} in the x direction with the pairs of measurement points separated by 10 Mm. This distance matches the separation in the τ^{ac} measurements. The reference crosscovariance C^{ref} is taken from the regularly tracked HMI (MDI) observations averaged over 60 days (59 days) of data at the solar equator. This ensures that the artificial flow signal is captured by the traveltime measurements.
Fig. B.1 Pointtopoint travel times from HMI Dopplergrams with artificial velocity signal. The point separation is 10 Mm in the eastwest direction. a)f modes. b) p_{1} modes. The blue dots give the travel times from Dopplergram series that were constructed using the noise model by Gizon & Birch (2004). We applied a leastsquares fit with a polynomial of degree three to the resulting data (black curves). The red curves show the linear term of the fit. For comparison, the black filled circles show travel times from HMI Dopplergrams that were tracked at an offset rate.

Open with DEXTER
The resulting τ^{diff} values averaged over maps and datasets are shown for HMI in Fig. B.1. For both f and p_{1} modes, the travel times from offset tracking are systematically larger than for the Dopplershifted power spectra by about 10 to 15%. In general, the traveltime magnitudes are larger for the f modes than for the p_{1} modes for the same input velocity value. The relation between input velocity v_{x} and output travel time τ^{diff} is linear only in a limited velocity range. Whereas this range spans from roughly −700 m s^{1} to 700 m s^{1} for the p_{1} modes, it only reaches from −200 m s^{1} to 200 m s^{1} for the f modes. For velocity magnitudes larger than 700 m s^{1}, the measured fmode travel times even decrease. However, the supergranular motions that we analyze reach typical velocities of ~ 300 m s^{1}, which is well below that regime.
We applied a leastsquares fit to a polynomial of degree three to the τ^{diff} measurements from Dopplershifted cubes (pink curve): (B.1)The linear term of the polynomial is shown for HMI as the red curve in Fig. B.1. For the actual conversion, only the linear coefficient h_{1} is used. We obtain h_{1} = −0.178 s^{2} m^{1} for the f modes and h_{1} = −0.090 s^{2} m^{1} for the p_{1} modes. For comparison, the coefficients h_{1} are listed for different distances in Table B.1. The table also contains the coefficients for MDI. We convert travel times into velocities by multiplying the travel times by 1 /h_{1}. The velocities obtained from converting τ^{ac} maps we call v^{ac}.
Appendix C: Systematic errors
Appendix C.1: Centertolimb systematics
At high latitudes, the original v^{ac} and LCT ω_{z} maps for the average supergranule show strong deviations from the azimuthally symmetric peakring structures that are visible at low latitudes. Considering that the magnitude of τ^{ac} and ω_{z} is much smaller than the magnitude of τ^{oi} and div_{h} at any latitude, it is possible that even a small anisotropy in the divergent flow component of the average supergranule is picked up by the v^{ac} and ω_{z} measurements and added to the signal from the tangential flow component that we want to measure. Such anisotropies can arise from various origins. Among them are geometrical effects that depend on the distance to the disk center.
For TD measurements, the sensitivity kernels depend on the distance to the limb. At 60° off disk center, τ^{diff} sensitivity kernels for measurements in the direction along the limb differ strongly from kernels for measurements in the centertolimb direction (see, e.g., Jackiewicz et al. 2007, for a discussion). Additionally, there is a gradient of the root mean square travel time in the centertolimb direction.
Fig. C.1 Circulation velocities v^{ac} of the average supergranule outflow region at solar latitude 40° derived from HMI and MDI Dopplergrams (after the correction for centertolimb systematics). The velocity maps were obtained by applying the respective conversion factors from Appendix B to the travel times τ^{ac}. The limits of the colorscale are arbitrarily set to ± 15 m s^{1}.

Open with DEXTER
Fig. C.2 Peak v^{ac} values for p_{1} modes using different parameter combinations (Δ,n) for the average supergranule at solar latitude 40°. a) In the average outflow region. b) In the average inflow region. The blue symbols give the results for the p_{1} ridge filter that has been used throughout this paper. For the results in black, an alternative p_{1} ridge filter with slightly different parameters was used (see text for details). The error bars were computed as in Fig. 7. The annulus radii corresponding to the various combinations (Δ,n) are all within (10.0 ± 0.5) Mm.

Open with DEXTER
In the case of LCT, the shrinking Sun effect causes largescale gradients of the horizontal velocity (of several hundred meters per second) pointing toward disk center (Lisle & Toomre 2004). This effect is presumably caused by insufficient resolution of the granules. Although HMI intensity and Doppler images have a pixel size of about 350 km at disk center, the point spread function has a FWHM of about twice that value. In Dopplergrams, the hot, bright, and broad upflows in the granule cores cause stronger blueshifts than the redshifts from the cooler, darker, and narrow downflows. Because of the insufficient resolution, the granules appear blueshifted as a whole. This blueshift adds to the blueshift of granules that move toward the observer (i.e., toward disk center), giving them a stronger signal in the Dopplergram. Lisle & Toomre argue that LCT of Dopplergrams gives more weight to these granules than to those granules that move away from the observer. However, it is not clear what causes the shrinking Sun effect in LCT of intensity images. Fortunately, the shrinking Sun effect appears to be a predominantly largescale and timeindependent effect, so it can easily be removed from LCT velocity maps by subtracting a mean image.
Another problem is the foreshortening. Far away from the disk center, the granules are not as well resolved in the centertolimb direction as in the perpendicular horizontal direction. This introduces a dependence of the measurement sensitivity on angle. We measure at ± 60° latitude that the radial flow component v_{r} of the average supergranule is weaker by 15 to 20% in the centertolimb direction compared to the perpendicular direction. This corresponds to a maximum velocity difference of about 50 m s^{1} for outflows and 30 m s^{1} for inflows. At 40° latitude, in contrast, this difference is less than 2% (6 m s^{1}).
Appendix C.2: MDI instrumental systematics
Whereas for HMI the removal of geometrical centertolimb effects results in similar v^{ac} peak structures in the supergranule outflow regions in the whole latitude range from −60° to 60°, for MDI the peak structures appear asymmetric and distorted even after the correction. An example for fmode TD at 40° latitude is shown in Fig. C.1. Even at disk center where geometrical effects should not play a role, there are visible systematic features (that do not appear for HMI, cf. Fig. 6). This is probably due to instrumental effects that are specific to MDI (see, e.g., Korzennik et al. 2004, for a discussion of instrumental errors in MDI).
Appendix C.3: Selection of filter and τ^{ac} geometry parameters
We note that the v^{ac} velocity results for TD depend on the details of the ridge filter as well as the geometry parameters (Δ,n) of the τ^{ac} measurements.
To give an idea of this, we construct an alternative p_{1} ridge filter with slightly different width parameters (see Appendix A). Additionally, we select four other combinations (Δ,n) of τ^{ac} measurements that preserve the annulus radius R, so that R is within (10.0 ± 0.5) Mm for all the combinations (Δ,n). As we did for the standard combination (Δ = 10 Mm, n = 6), we use four different angles β for each additional combination.
For all these combinations and both the standard and modified p_{1} filters, we calculated v^{ac} for the average supergranule at 40° latitude. The resulting peak velocities are shown in Fig. C.2
for both inflow and outflow regions. We did not apply the centertolimb correction since it only has a weak influence on the peak velocity magnitude at 40° latitude.
Evidently, the modified p_{1} filter results in systematically larger v^{ac} amplitudes. The difference with respect to the standard filter increases with decreasing Δ. For Δ = 10 Mm and n = 6, it is about 10%. This is qualitatively in line with Duvall & Hanasoge (2013). Using phasespeed filters, Duvall & Hanasoge observed that the strength of the traveltime signal from supergranulation is strongly dependent on the filter width. This shows that one should be careful when comparing absolute velocities from TD and LCT. For more reliable velocity values, an inversion of τ^{oi} and τ^{ac} maps would be needed.
The comparison of different combinations (Δ,n) for the same filter shows that for n = 4, 6, and 8 the v^{ac} amplitudes are similar, so selecting the combination (Δ = 10 Mm,n = 6), as we did for most of this work, appears justified. Decreasing Δ to about 5 Mm changes the peak v^{ac} values. A possible reason is that Δ in this case becomes comparable to the wavelength of the oscillations, so it is harder to distinguish between flows in opposite directions. For small n, on the other hand, the measurement geometry deviates strongly from a circular contour. This might explain the deviations in v^{ac} for n = 3.
All Tables
Correlation between LCT maps and TD traveltime maps derived from HMI intensity images and Dopplergrams.
Parameters of the ridge filters that are used for the traveltime measurements in this paper (see text for details).
All Figures
Fig. 1 Measurement geometries for divergence and vorticitysensitive travel times and LCT velocities. a) The divergencesensitive travel time τ^{oi} is obtained by measuring the traveltime difference between a central point r and a surrounding annulus of radius Δ. b) The vorticitysensitive travel time τ^{ac} is obtained by measuring the traveltime differences τ^{diff} between adjacent points along a regular polygon surrounding r. The polygon consists of n points and has edges of length Δ. The points are situated on a circle of radius R = Δ/ [2sin(π/n)]. The travel time τ^{ac} is the average over the components τ^{diff} (see Eq. (3)). We obtain circulation velocities v^{ac} by multiplying τ^{ac} by a calibration factor. c) From LCT, we obtain the horizontal velocity components v_{x} and v_{y}. Given a reference point r, the LCT velocities can be expressed in 2D polar coordinates (r,θ) by the outward pointing radial velocity component v_{r} and the anticlockwise pointing tangential velocity component v_{t}. d) Using LCT velocities, we approximate v^{ac} by averaging the tangential velocity component v_{t} over the annulus shaded in green. The annulus is defined by its radius R and halfwidth s. We choose R = Δ for n = 6 and s = 2 Mm.

Open with DEXTER
In the text
Fig. 2 Comparison of lineofsight velocity from two different data products at 40° solar latitude on 6 June 2010. a) HMI Dopplergram averaged over 8 h. The map was convolved with a Gaussian of Mm and subsampled to match the coarser LCT resolution. The mean over the map and a linear function in the x direction (parameters determined by a leastsquares fit) were subtracted. b) LCT map from HMI intensity images, averaged over 8 h. The lineofsight velocity component was computed from the v_{x} and v_{y} components. For v_{y}, the mean over the map and a linear function in the y direction were subtracted. c) Scatter plot of the two maps. The Pearson correlation coefficient is 0.94. The red line shows the direction of largest scatter and crosses the origin. It is a bestfit line in the sense that it minimizes the sum of squared distances of the points perpendicular to the line (Pearson 1901). This is different from linear regression, where no error in the x coordinate is assumed and only the sum of squared distances in the y coordinate is minimized. The slope of the red line is 1.08; the error in the direction of lowest scatter is 33.9 m s^{1}.

Open with DEXTER
In the text
Fig. 3 Power spectra (averaged over azimuth of wavevector k and 336 datasets) of TD traveltime maps, and LCT div_{h} and ω_{z} maps computed from HMI Dopplergrams and intensity images at the solar equator near disk center (distributed symmetrically between 7° east and west of the central meridian). a) Divergencesensitive travel times τ^{oi} for f modes and p_{1} modes as well as LCT div_{h}. b) Vorticitysensitive travel times τ^{ac} for f modes and p_{1} modes as well as LCT ω_{z}. The amplitudes of LCT div_{h} and ω_{z} power were rescaled to match the range of the traveltime power. The dashed lines represent noise models for the f and p_{1} modes based on Gizon & Birch (2004). The thickness of the lines denotes the 1σ error.

Open with DEXTER
In the text
Fig. 4 Comparison of TD and LCT maps at the equator. All maps are based on 8 h of HMI images (intensity and Doppler velocity) taken on 1 May 2010 and have been bandpass filtered around kR_{⊙} = 100. The color bar limits are set to the maximum absolute value of the corresponding map and symmetrized around zero. Left column: divergencesensitive travel times τ^{oi} for f modes as well as LCT horizontal divergence div_{h}. Right column: circulation velocities v^{ac} for TD as well as LCT vertical vorticity ω_{z}. The TD τ^{ac} maps were converted into velocity maps by pointwise multiplication with a constant factor −5.62 m s^{2} (f modes) and −11.1 m s^{2} (p_{1} modes), see Appendix B for details.

Open with DEXTER
In the text
Fig. 5 Correction for geometrical centertolimb systematics in maps of circulation velocity v^{ac} for LCT and TD using HMI observations. This example shows the correction of v^{ac} maps at 60° latitude. a) Patch 1 (raw data) is located at 60° latitude at the central meridian. Patch 2 (systematics data) is situated at the equator, 60° west of the central meridian. We corrected the raw data by subtracting patch 2 from patch 1 (after rotating patch 2 anticlockwise by 90°). We note that we also use measurements of the systematics from the east for the correction (rotated clockwise by 90°). This is omitted in the sketch for clarity. b) Maps of v^{ac} for LCT and fmode TD. The three columns of panels show (from left to right) the measured raw data at 60° latitude, the measured systematics from 60° west and east (rotated and averaged), and the corrected data.

Open with DEXTER
In the text
Fig. 6 Maps of horizontal divergence div_{h} and circulation velocity v^{ac} for the average supergranule outflow regions at various solar latitudes (after correction for geometrical centertolimb systematics). The maps were derived from HMI intensity images and Dopplergrams. The horizontal divergence div_{h} was computed from LCT v_{x} and v_{y} horizontal velocity maps. The LCT v^{ac} maps were obtained by averaging the tangential velocity component v_{t} over an annulus with radius 10 Mm and halfwidth 2 Mm to resemble the τ^{ac} measurement geometry (Fig. 1d). For TD, the v^{ac} maps are based on τ^{ac} traveltime maps (Fig. 1b) that were computed from Dopplergrams.

Open with DEXTER
In the text
Fig. 7 Peak v^{ac} and ω_{z} values for the average supergranule at different solar latitudes. a) Circulation velocity v^{ac} for LCT, f modes, and p_{1} modes. b) Vertical component of flow vorticity ω_{z} obtained from LCT. Solid lines are for the average supergranule outflow region, dashed lines for the average supergranule inflow region. At 0° latitude, the values at the map center are shown instead of the peak values. The error bars were computed by dividing the 336 datasets into eight parts and measuring the variance of v^{ac} and ω_{z} at the peak positions over the eight parts.

Open with DEXTER
In the text
Fig. 8 a) Cuts through the maps of the circulation velocity v^{ac} for the average supergranule outflow region at 40° latitude (shown in Fig. 6), at y = 0. The TD and LCT maps were derived from HMI Dopplergrams and intensity images. The thin lines denote estimates of the variability of the data as obtained from dividing the 336 datasets into eight parts. The 1σ level is shown. b) As a), but for the average supergranule inflow region at 40° latitude.

Open with DEXTER
In the text
Fig. 9 Same as Fig. 6, but for the average supergranule inflow regions.

Open with DEXTER
In the text
Fig. 10 Vorticity as a function of divergence for the average supergranule at 40° latitude from HMI data. a) Vorticity travel times τ^{ac} versus divergence travel times τ^{oi} for TD f modes and p_{1} modes. The upper left quadrant shows the values for the average outflows, the lower right quadrant for the average inflows. The solid and the dashed lines show leastsquares fits of a linear function through the origin for outflows and inflows, respectively. The error bars were obtained by dividing the 336 datasets into eight parts. b) As a) but the peak ω_{z} versus the peak div_{h} from LCT is shown. We note that the quadrants depicting outflows and inflows are flipped compared to the travel times in a).

Open with DEXTER
In the text
Fig. 11 Velocities v^{ac} for the average supergranule measured at the origin at different solar latitudes from MDI TD (f modes and p_{1} modes). Solid lines are for the average supergranule outflow region, dashed lines for the average supergranule inflow region. The error bars were computed by dividing the 177 datasets into eight parts.

Open with DEXTER
In the text
Fig. 12 LCT horizontal velocity (black arrows) and vertical vorticity ω_{z} (filled contours) for the average supergranule at solar latitude 40°. a) Average outflow region. b) Average inflow region. Arrows for velocity magnitudes less than 60 m s^{1} are omitted.

Open with DEXTER
In the text
Fig. 13 Azimuthally averaged horizontal velocities around the average supergranule outflow and inflow centers at solar latitude 40°. The measurements were obtained from LCT of granules in HMI intensity images. a) Horizontal velocities v_{r} and v_{t} around the average supergranule outflow center. The thin lines mark an estimate of the variability of the data as measured by dividing the 336 datasets into eight parts. For v_{r}, the 10σ level is shown, for v_{t} the 3σ level. b) As a), but around the average supergranule inflow center.

Open with DEXTER
In the text
Fig. B.1 Pointtopoint travel times from HMI Dopplergrams with artificial velocity signal. The point separation is 10 Mm in the eastwest direction. a)f modes. b) p_{1} modes. The blue dots give the travel times from Dopplergram series that were constructed using the noise model by Gizon & Birch (2004). We applied a leastsquares fit with a polynomial of degree three to the resulting data (black curves). The red curves show the linear term of the fit. For comparison, the black filled circles show travel times from HMI Dopplergrams that were tracked at an offset rate.

Open with DEXTER
In the text
Fig. C.1 Circulation velocities v^{ac} of the average supergranule outflow region at solar latitude 40° derived from HMI and MDI Dopplergrams (after the correction for centertolimb systematics). The velocity maps were obtained by applying the respective conversion factors from Appendix B to the travel times τ^{ac}. The limits of the colorscale are arbitrarily set to ± 15 m s^{1}.

Open with DEXTER
In the text
Fig. C.2 Peak v^{ac} values for p_{1} modes using different parameter combinations (Δ,n) for the average supergranule at solar latitude 40°. a) In the average outflow region. b) In the average inflow region. The blue symbols give the results for the p_{1} ridge filter that has been used throughout this paper. For the results in black, an alternative p_{1} ridge filter with slightly different parameters was used (see text for details). The error bars were computed as in Fig. 7. The annulus radii corresponding to the various combinations (Δ,n) are all within (10.0 ± 0.5) Mm.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
