1. Introduction

1.1. Deuteration and star formation

During the past decade, the chemistry of deuterium has become an important tool for understanding the formation of stars and planets. However, the deuteration processes are not fully understood yet, and important uncertainties remain in the interpretation of observational data. The cosmological ratio of the elemental abundances between deuterium and hydrogen (D/H) is approximately 1–2 × 10-5 (Roberts & Millar 2000; Linsky et al. 2006; Pety et al. 2007). However, higher abundances of deuterated molecules have been observed in many astrophysical environments, including cold dense cores (Guelin et al. 1982), mid-planes of circumstellar disks (van Dishoeck et al. 2003; Guilloteau et al. 2006), hot molecular cores (Hatchell et al. 1998), and even photon-dominated regions (PDRs; see Leurini et al. 2006). Several chemical pathways have been proposed to produce this deuterium enrichment.

Deuteration in the gas phase is driven by ion-molecule reactions in which deuterium and hydrogen atoms are exchanged. For a cold source with kinetic temperatures Tk = 10−20 K, the dominant process is H+HD H2D++H2. This reaction proceeds left-to-right with an exothermicity of ~232 K (Gerlich et al. 2002; Pagani et al. 2011, 2013) and is very rapid at low temperatures, raising the abundance ratio [H2D+ ] / [H] to values much higher than 10-5 (see e.g. Caselli et al. 2003). The production of the deuterated ions of H leads to high abundances of other deuterated species through secondary ion-molecule reactions. In addition to singly deuterated isotopologs, doubly and triply deuterated species such as NHD2, ND3, and D2CO can be explained, at least partially, in terms of gas-phase synthesis (Gerin et al. 2006; Roueff et al. 2005). The deuteration via H2D+ becomes very inefficient when Tk is higher than 30 K. At temperatures Tk = 3050 K, CH and C2H react rapidly with HD, leading to the ions CH2D+ and C2HD+ (Herbst et al. 1987; Millar et al. 1989) via the reactions CH3+HD CH2D++H2; C2H+HD C2HD++H2. The left-to-right exothermicities, ~390 K (Asvany et al. 2004) and ~550 K (Herbst et al. 1987), respectively, are considerably higher than for the reaction involving H. Detailed gas-phase models including deuterated species have been constructed using large networks of gas-phase reactions with both the steady-state and pseudo-time-dependent pictures showing that significant deuterium fraction enhancements can be detected at temperatures up to Tk ~ 70 K (Roueff et al. 2005, 2007, 2013).

Deuterated isotopologs of methanol and formaldehyde have been detected in hot cores and corinos where Tk> 100 K (see e.g. Parise et al. 2002, 2004; Fuente et al. 2005a). In these cases, the deuteration is thought to occur on grain surfaces. The deuterium and hydrogen atoms on the grain surface react with complex molecules, leading to both deuterated and normal isotopologs (Tielens 1983; Stantcheva & Herbst 2003; Nagaoka et al. 2005). The deuterated compounds are released to the gas phase when the ice is evaporated, producing high abundances of the deuterated isotopologs of methanol and formaldehyde (Parise et al. 2002, 2004, 2006).

Observationally, deuteration has been widely studied in cold pre-stellar regions and hot corinos, and the results are interpreted on the basis of the deuteration pathways explained above. Much less studied is the deuteration in warm (Tk = 3070 K) cores, in which the dust temperature is too high for the deuteration via H2D+ to proceed efficiently and it is not high enough for the icy mantles to evaporate. Parise et al. (2007) observed a sample of deuterated species toward a warm (~30 K) clump in the Orion Bar. They detected DCN, DCO+ and HDCO and derived [XD]/[XH] fractions (hereafter Dfrac) of 0.01, 0.0006 and 0.006 for HCN, HCO+ and H2CO, respectively. Because of the good agreement with chemical models (Roueff et al. 2005, 2007), they interpreted these high values of deuteration as the consequence of gas-phase chemistry driven by ion-molecule reactions with CH2D+ and C2HD+. Later, Guzmán et al. (2011) proved that photo-desorption from the grain mantles could also be an important formation mechanism in the PDRs for species like H2CO, suggesting that the deuteration on grain surfaces could also contribute to the enhancement of the deuterium fraction in UV-irradiated regions. Species such as C2D and DNC, which are not expected to form on grain surfaces, were not detected in the Orion Bar, and an extensive comparison with gas-phase models was not possible in this source. A complete observational study including more deuterated species is necessary to distinguish among the different deuteration mechanisms at work.

1.2. Ultracompact HII region in Mon R2

Ultracompact (UC) Hii regions represent one of the earliest phases in the formation of a massive star. They are characterized by extreme UV radiation (G0> 105 in units of Habing field), small physical scales (0.1 pc), and are found embedded in dense molecular clumps with densities 106 cm-3 (Hoare et al. 2007). The UV radiation from the star forms a first layer of ionized hydrogen (Hii), followed by the PDR. PDRs are environments where the thermal balance and chemistry are driven by UV photons (6 eV 13.6 eV). The PDRs associated with UC Hii are characterized by extreme UV field intensities (>104 expressed in units of the Habing field G0, see Habing 1968) and high densities (n> 105 cm-3). They are typically located farther than a few kpc from the Sun, which makes their observational study very difficult. However, fully comprehension is of paramount importance for our understanding of the interaction of the massive star formation process with the interstellar medium both in our Galaxy and in extragalactic objects.

thumbnail Fig. 1

In colors, the Spitzer-IRAC 8 μm emission from small dust (Ginard et al. 2012). In contours, the integrated emission between 5 and 15 km s-1of the C18O 2–1 line (Pilleri et al. 2012a). Green squares show the two positions analyzed in this paper. Black stars show the positions of the brightest infrared sources, following the nomenclature of Henning et al. (1992). The beams at 3 mm (~29) and 2 mm (~16) toward the IF and MP2 positions are drawn.

Open with DEXTER

Monoceros R2 (Mon R2, van den Bergh 1966) is the closest UC Hii region (d = 830 pc; Herbst & Racine 1976), and can be spatially resolved with the current instrumentation in the mm and IR domains. Due to its brightness and proximity, this source is an ideal case to study the physical and chemical conditions in an extreme PDR and can be used as pattern for other PDRs that are illuminated by a strong UV field. The UC Hii region has a cometary shape and its continuum peaks toward the infrared source Mon R2 IRS 1. Previous millimeter and far-infrared spectroscopic and continuum studies (Henning et al. 1992; Giannakopoulou et al. 1997; Tafalla et al. 1997; Choi et al. 2000; Rizzo et al. 2003, 2005; Pilleri et al. 2012, 2013) showed that the molecular emission presents an arc-like structure surrounding the Hii region, with the bulk of the emission to the SW (see Fig. 1). The advent of the new IR facilities Spitzer and Herschel, together with the high spatial resolution at mm wavelengths provided by the IRAM-30 m telescope have allowed us to probe the PDR in the interface between the ionized and the molecular gas (Rizzo et al. 2003, 2005; Berné et al. 2009; Pilleri et al. 2012, 2013; Ginard et al. 2012). These studies showed that the UC Hii region is surrounded by a dense PDR (n>105 cm-3) that is well detected in the pure rotational lines of H2, the mid-infrared bands of polycyclic aromatic hydrocarbons (PAHs) and in the emission of rotational lines of reactive molecular ions such as CO+ and HOC+. In addition, a second PDR is detected 40″ north from IRS 1, which corresponds to a second molecular peak (hereafter, MP2). The position MP2 is well detected in the PAH emission at 8 μm and its chemical properties are similar to those of low- to mild-UV irradiated PDRs such as the Horsehead (see Fig. 1; Ginard et al. 2012; Pilleri et al. 2013).

In this paper, we present an extensive study of deuterated compounds in the PDRs around the UC Hii Mon R2 that includes DCN, DNC, DCO+, C2D, HDCO, D2CO, NH2D, and N2D+. We focus our study on the chemistry toward the ionization front (hereafter IF) and the second PDR in MP2 position and discuss the implications of our observations. In Sects. 2 and 3 the observational setup and results are described. In Sect. 4, we calculate column densities and abundances for each species, while in Sects. 5 and 6 we discuss our main results. Finally, Sect. 7 presents our conclusions.

2. Observations and data reduction

The data presented in this paper are part of the 3, 2, and 1 mm spectral surveys we have carried out using the IRAM-30 m telescope at Pico Veleta (Spain) toward the PDRs around the UC Hii region Mon R2. The observations were performed in three observational blocks in 2012 January, September, and December. All observations were performed in dual polarization using the EMIR receivers (Carter et al. 2012) with the fast Fourier transform spectrometer (FTS) at 200 kHz of resolution (Klein et al. 2012). During the observations we pointed on the strong nearby quasar (0605-058) every 2 h and checked the focus on a planet every 4 h. Pointings and focus corrections were stable throughout the whole run. A line calibrator was observed for every tuning to check that the intensities of the lines were correct. The emission from the sky was substracted using an OFF position free of molecular emission (+ 400′′, − 400′′). The offsets are given relative to the coordinates of the IF position: α(J2000) = 06h07m46.2s, δ(J2000) = −06°23′08.3′′. For the on-the-fly (OTF) maps the OFF position was observed every 2 minutes for 20 s. For the single pointing observations the OFF position was observed in position switching mode every 30 s. Throughout the paper, we use the main-beam brightness temperature (TMB) as intensity scale. To do so, we multiplied our spectra in by a factor Feff/Beff1. A summary of the observational parameters is shown in Table A.1.

In the first observational block we covered the frequency range from 202.00 GHz to 265.00 GHz. In this block we used the OTF observing mode to cover a 120′′ × 120′′ region centered on the IF position. In the second observational block we performed single-pointing observations toward both the IF and MP2 positions, to cover the frequency ranges of 84.00–99.78 GHz and 104.00–111.96 GHz for the 3 mm band; 132.80–136.89 GHz, 141.80–145.89 GHz and 150.60–154.68 GHz for the 2 mm band; 210.30–218.00 GHz and 225.90–233.70 GHz for the 1 mm band. In the last observational block we made single-pointing observations in the IF and MP2 position (molecular peak at offset [0′′,40′′]), to cover the frequency ranges of 250.50–258.30 GHz and 266.20–274.00 GHz.

The data were reduced using the CLASS/GILDAS package2 (Pety et al. 2005). Initial inspection of the data revealed a few single-channel spikes, platforming of individual FTS units, but otherwise clean baselines. To fix the spikes problem we flagged individual channels and filled them with white noise corresponding to the rms measured by a baseline fit. To correct for the platforming, a zero-order baseline was subtracted from each FTS sub-bands of each spectrum using a dedicated procedure provided by IRAM. In addition, a second-order baseline was needed for almost all the detected lines. All resulting spectra were smoothed to a velocity resolution of 0.65 km s-1.

thumbnail Fig. 2

Observed spectra toward the IF and MP2 position. The blue dashed line shows the velocity of 10 km s-1 relative to the rest frequency of the transition. Two different velocity components can be distinguished at each position. Left: transitions of H2CO (211.211 and 218.222 GHz), H13CN at 259.011 GHz and HNC at 90.663 GHz (from top to bottom) at the IF and MP2 positions. Right: observed spectra for the deuterated species DCO+, C2D, DCN and DNC transitions toward the IF and MP2 positions. The velocities are relative to the frequencies 144.077, 144.241, 144.828, and 152.609 GHz (from top to bottom).

Open with DEXTER

thumbnail Fig. 3

2′ × 2′ OTF maps of DCO+ (at 216.112 GHz), DCN (at 217.238 GHz), DNC (at 228.910 GHz), H2CO (218.222, 218.475, 218.760 and 225.697 GHz), C2H (at 262.004 and 262.064 GHz), HC15N (at 258.156 GHz), H13CN (at 259.011 GHz) and H13CO+ (at 260.255 GHz). The cross marks the IF position, the triangle marks the MP2 position, and the circle shows the MP1 position at the offset (− 15′′,15′′). The contour levels are 40% to 100%, in steps of 15% of the peak intensity; ~2 K km s-1 for DNC; ~3 K km s-1 for DCO+ and HC15N; ~4 K km s-1 for H2CO at ~218.00 GHz; ~5 K km s-1 for H13CN and H13CO+; ~7 K km s-1 for DCN; ~15 K km s-1 for H2CO and C2H at ~262.00 GHz.

Open with DEXTER

3. Results

3.1. Observed spectra

Figures A.1A.12 show the spectra of hydrogenated (Figs. A.1A.8) and deuterated (Figs. A.9A.12) species toward the IF and MP2 positions (i.e., the offsets [+0′′,+0′′] and [+0′′,+40′′], respectively). The spectra show a different velocity profile toward the two positions. Two velocity components were found at each position for almost all the molecules. At the IF position we detect a velocity component at ~10 km s-1 and a second one at ~12 km s-1; while at the MP2 position, the two velocity components correspond to ~8 km s-1 and ~10 km s-1. The component at 10 km s-1 is detected at both positions and seems associated with the layer most exposed to the UV radiation from IRS 1 (see Sect. 3.3). The component at 12 km s-1 is found toward the IF position but it is related to the SW part of the molecular cloud. Finally, the component at 8.5 km s-1 is only detected toward the MP2 position and related to a low-UV irradiated PDR.

All the hydrogenated species are detected toward the two positions, and with a few exceptions, e. g., H13CN at 259.011 GHz and HC15N at 258.156 GHz, the lines are more intense at the MP2 than at the IF position (see Fig. 2). The deuterated species DCN, DNC, DCO+, C2D, HDCO, and NH2D are detected at both positions. We have detected N2D+ only toward the IF position, but the lack of detection toward the MP2 position is very likely due to the poor quality of our spectrum at this frequency. D2CO is only detected toward the MP2 position.

Initial inspection of the spectra reveals some differences in the intensity line ratios between the two velocity components at each position. For instance, toward the IF position the H13CN (32) line is more intense at 10 km s-1. However, the intensity of the HNC (10) line is similar for the two components (see Fig. 2). To study these differences quantitatively, we fitted a Gaussian to each velocity component using the CLASS software of the GILDAS package. Table A.2 lists the results of the Gaussian fits for the deuterated species, and Tables A.3 and A.4 list the Gaussian fits for the hydrogenated species.

thumbnail Fig. 4

Channel maps for the molecules DCN at 216.112 GHz, DNC at 217.238 GHz, H13CN at 259.011 GHz, H2CO at 218.960 GHz and H13CO+ at 260.255 GHz, from top to bottom. The velocities for every channel are 8.5, 9.5, 10.5, 11.5, and 12.5 km s-1 from left to right. The peak intensity is ~2 K km s-1 for each line.

Open with DEXTER

3.2. Integrated intensity maps

The maps carried out with the IRAM-30 m telescope allow us to characterize the spatial distribution of different deuterated and hydrogenated species in Mon R2. In Fig. 3 we show the integrated line intensity maps of different transitions of DCO+, DCN, DNC, H2CO, C2H, HC15N, H13CN, and H13CO+. All the maps have an angular resolution between 9′′ and 11′′, allowing a direct comparison. The spatial distribution of all these molecules is quite similar, consisting of an arc structure of ~30′′ in radius, pointing to the SE and opened to the NW, following the cometary shape of the nebula. H2CO is a very abundant species in PDRs and therefore presents a very intense and extended structure. This molecule extends up to ~1 from the IF position and consists of three peaks at the positions (25′′,+55′′), (+10′′,25′′), and (+20′′,+35′′) surrounded by faint emission. The C2H molecule is also very abundant and presents an extended structure, with an intense peak toward the MP2 position. The emission of the H2CO and C2H molecules come from the inner clumps and the envelope of the region, but seems to be dominated by a lower density envelope. The HC15N, H13CN, and H13CO+ molecules are less abundant and their distributions are more compact, they present peaks at the offsets (+10′′,+25′′), (10′′,10′′), and (20′′,+20′′). The emission of DCN and DNC species are compact and intense, while the DCO+ emission is weaker and more extended.

3.3. Spectral maps

Figure 4 shows the intensity maps at different velocities for DCN (32), DNC (32), H13CN (32), HN13C (32) and H13CO+ (32). In all the species we find the three velocity components described above. The emission at ~8 km s-1 is located in the NW, the gas emitting at ~10 km s-1 is surrounding the Hii region, and the gas in the SW is at a velocity of ~12 km s-1 (see Fig. 4). The transition from one component to another is abrupt and does not occur smoothly, as expected in the case of a global and coherent rotation. Moreover, two velocity components coexist at many positions, for example at the IF and MP2 positions. This suggests that the observed velocity behavior is the result of the superposition of three filaments around the expanding UC Hii region or, alternatively, the existence of a twisted filament, with the gas at ~12 km s-1 and at ~8 km s-1  located at the front and the back of the UC Hii region as observed from the Sun.

4. Analysis

4.1. Molecular column densities

Table 1

Column densities and excitation temperatures derived from rotation diagrams.

To derive reliable column densities, we combined our 1 mm maps with single-pointing observations obtained at 3 mm and 2 mm toward both the IF and MP2 positions. To do that, we convolved the 1 mm maps to the angular resolution of the lower excitation transitions at 3 mm or 2 mm. The beam-averaged column densities were calculated assuming that the emission comes from a layer with uniform physical conditions and using the rotational diagram technique. This technique is valid for optically thin emission and assumes the same excitation temperature for all transitions. Within this approximation,

where Nu is the column density, in cm-2, of the upper level “u” of the corresponding transition, ν is the frequency of the transition in GHz, W is the area derived from the Gaussian fitting in K km s-1 (Tables A.1–A.4), Aul is the Einstein coefficient for spontaneous emission, Ntot is the total column density of the molecule in cm-2, Eu is the energy of the upper level in K, Trot is the rotation temperature in K, and Q is the partition function, which depends on Trot. The values of Q were taken from the Cologne Database for Molecular Spectroscopy (CDMS webpage3; Müller et al. 2001, 2005). Since our approximation requires optically thin emission, we used the 13C and 18O isotopologs to calculate the column density of the hydrogentated species, assuming [12C]/[13C] = 50 (Savage et al. 2002; Ginard et al. 2012) and [16O]/[18O] = 5004 (Wilson & Rood 1994; Ginard et al. 2012). We assumed a beam filling factor of 1 for all the transitions, and the obtained values were averaged values within the beam of the lower energy transitions (at 3 mm or 2 mm, depending on the species).

Table 1 shows the results of the rotational diagrams. Rotation temperatures vary between ~10 K and ~40 K. These differences are due to the different dipole moments of the molecules (μ ~ 15 Debye) and to the different spatial resolution of the lower energy transitions. For instance, the rotation temperature obtained from H13CN lines corresponds to a 29 beam, while the rotational temperature of DCN corresponds to a 16 beam. The 29 beam encompasses a larger fraction of cold gas than the 16 one, and the average rotation temperature is therefore lower (see Fig. 3). This different spatial resolution is also the cause of the higher rotation temperature measured for the deuterated species of HNC compared with that of the 13C isotopolog. Moreover, the high rotation temperatures found in DCN and DNC towards IF position confirm that the high deuterium fractions are associated with dense clumps around the Hii region at temperatures ~50 K instead of the cooler envelope. In the case of HCO+, the rotation temperature is similar for the 13C isotopolog and the deuterated species. This is consistent with the spatial distribution of DCO+ (see Fig. 3), where intense emission comes from the envelope. The rotation temperatures are similar for H2CO and their related species. In this case, all the column densities of all the molecules are averaged over a ~16 beam. Similarly to DCN and DNC, the emission of this family of molecules comes mainly from the warm clumps around the Hii region.

For some compounds, only one transition is detected. In these cases, we calculated the column density assuming a fixed value of the rotation temperature. For these cases we considered three rotational temperatures (Trot = 10 K, Trot = 19 K and Trot = 38 K) and calculated the column density for every case. We found that the variation of a factor 2 in the rotation temperature affects the column density by less than a factor 2. For H213CO and its deuterated compounds, HDCO and D2CO, we used Trot = 38 K (because this temperature is more similar to that derived from H2CO) and for the remaining species we assumed Trot = 19 K.

Table 2 shows the deuterium fractions (Dfrac(XH) = [XD]/[XH]) for each velocity component toward the IF and MP2 positions. When possible, we derived them by comparing the 13C isotopolog with the deuterated species and assuming 12C/13C = 50. Since the abundances and excitation conditions of both molecules are similar, the derived Dfrac are not strongly affected by possible line opacity effects. As commented above, we have assumed a beam filling factor of 1 for the emission of all the studied transitions. To check the validity of our assumption and the possible impact on the estimated values of Dfrac, we produced maps of the [DCN (32)]/[H13CN (32)] and [DCO+ (32)]/[H13CO+ (32)] line-integrated intensity ratios (see Fig. 4). These maps have an angular resolution of ~10 and provide information about the spatial variations of the values of Dfrac in the region. For the two family of species, HCO+ and HCN, the values of the line-integrated intensity ratio varies by less than a factor of 2 within the 29′′ beam, suggesting that the beam-filling assumption is good enough and our values of Dfrac are correct within the same factor. Toward the MP2 position, the deuterium fractions are highest toward the center, suggesting that the center is cooler and this PDR represents a clump illuminated from the outside, rather than one harboring a young star.

The only exception is the [NH2D]/[NH3] ratio. To calculate the [NH2D]/[NH3] ratio, we took the NH3 column density derived by Montalban et al. (1990) from the integrated intensity maps of the (1,1) and (2,2) lines observed with the Effelsberg telescope. The beam of the NH3 observations was ~42′′. Taking into account possible calibration differences between the two telescopes and that the pointings are not exactly the same, we consider that the uncertainty could be as large as a factor of ~5.

4.2. Comparison of the IF and MP2 positions

In this section we compare the chemistry of the different velocity components. The 10 km s-1 component presents similar abundance ratios toward the two positions, and these ratios are different from those in the 12 km s-1 and 8 km s-1 components. This component is characterized by a very high [HCN]/[HNC] abundance ratio, [HCN]/[HNC] ~ 10. Regarding the spatial distribution, this component is adjacent to the Hii region and is the closest (in projected distance) from IRS 1. The 8 km s-1 and 12 km s-1 present [HCN]/[HNC] ratios of about ~1–3, characteristic of cold or moderately warm clouds. There are no important chemical differences between the 8 km s-1 and 12 km s-1 components, suggesting that they correspond to gas at a similar kinetic temperature, probably because they are equidistant from IRS 1.

Table 2

Fractional abundances ratios.

The values of the deuterium fractions are quite similar for the three velocity components. Values around 0.01 are found for all of the observed species except for DCO+ and N2D+, which present a deuterium fraction 10 times lower. The largest differences are found for C2D, Dfrac(C2H) being ~4 times higher in the 8 km s-1 component toward the MP2 position than in the others. The hydrogenated compound of this species is also very abundant in this component, suggesting that opacity effects could contribute to this higher value of the deuterium fraction. We would need to observe the 13C isotopolog to obtain a more accurate value of Dfrac(C2H). The deuterated species N2D+ and D2CO have only been detected in the more shielded components at 12.0 km s-1 (N2D+) and 8 km s-1 (D2CO), again consistent with these velocity components being associated with colder gas, farther from IRS 1.

Table 3

DX/HX ratio comparison.

thumbnail Fig. 5

Left: the color scale shows the [DCN]/[HCN] ratio, the red contours mark the DCN emission at 216.112 GHz, the blue contours the H13CN emission at 259.011 GHz. Right: the color scale shows the [DCO+]/[HCO+] ratio, the red contours mark the DCO+ emission at 144.07728 GHz, the blue contours the H13CO+ emission at 260.255 GHz. The contour levels are 5σ, 10σ, 15σ, 20σ, and 25σ. The black circles represent the 2 and 3 mm beams.

Open with DEXTER

thumbnail Fig. 6

Histogram comparing the deuterium fractions in different regions: the dark cloud TMC 1, the young protostellar object Barnard 1, the hot corino IRAS+16293-2422, the hot core Orion KL, and the PDRs in the Orion Bar and Mon R2. References for the plotted values are shown in Table 3.

Open with DEXTER

4.3. Comparison with other sources

In Table 3 we compare the deuterium fractions measured in Mon R2 with those in some prototypical objects. In particular, we compare with a dark cloud (TMC1; Turner 2001), a young protostellar object (Barnard 1; Daniel et al. 2013; Gerin et al. 2001; Marcelino et al. 2005), a hot corino (IRAS 16293-2422; Lis et al. 2001; Loinard et al. 2000, 2001; Tiné et al. 2000), and a hot core (Orion KL; Turner 1990). While the deuterium fractions of HCN and HNC are quite similar for all the sources ([DCN]/[HCN] ~ [DNC]/[HNC] ~ 0.01), the deuterium fractions of H2CO, HCO+, N2H+ and NH3 do change. Values of the [HDCO]/[H2CO] ratio measured toward hot cores and hot corinos are found to be higher (~0.15) than those in dark clouds (~0.05) and PDRs (~0.01). This indicates that the deuteration of formaldehyde proceeds more efficiently on the grain surfaces and the deuterated compounds are released in to the gas phase when the dust is heated to high temperatures (>100 K). The low values of Dfrac found in Mon R2 suggest that surface chemistry and subsequent ice evaporation is not the main deuteration pathway, as in the case of hot corinos (see Fig. 6).

In contrast, the [DCO+]/[HCO+] ratio is higher in dark clouds (~0.01) than in hot cores (~0.007) and the PDRs associated with Mon R2 and the Orion Bar (~0.002). This result is also supported by the study carried out by Pety et al. (2007) toward the Horsehead nebula. They found that the HCO+ deuterium fraction is larger than 2% in the cold dense core and lower than 0.1% in the PDR. The deuteration of HCO+ proceeds via ion molecule reactions in the gas phase that are quite sensitive to the gas temperature. The behavior observed in Fig. 6 can be explained as the consequence of the increasing kinetic temperature. Note that for IRAS 16293-2422, the observed DCO+ more likely comes from the envelope in which the hot corino is embedded.

For the other N-bearing molecules the [N2D+]/[N2H+] ratio is higher in the very first evolutionary stages of the stellar formation, represented the by the dark cloud TMC1 (~0.08) and the young protostellar object Barnard 1 (~0.3), than in more evolved objects such as Mon R2 (~0.03). This result agrees with the recent study of Fontani et al. (2011), in which the authors derived the N2H+ deuterium fraction for a large sample of massive young stellar objects. They showed that the N2H+ deuteration is lower (~0.02) in objects associated with ultracompact Hii regions (i.e., similar to our PDRs).

The situation is less clear for the NH3. From the ratios listed in Table 3, the [NH2D]/[NH3] ratio is similar in hot cores (~0.06), dark clouds (~0.02) and PDRs (~0.06), but it reaches a value of ~0.33 toward Barnard 1 (see Table 3). The young protostellar object (YSO) Barnard 1 is a special object where the deuterium fractions are known to be higher than in other cold cores. Daniel et al. (2013) interpreted the high [NH2D]/[NH3] ratio as a time evolution effect, the consequence of its peculiar evolutionary stage, with fewer than 500 yr after the formation of the early hidrostatic core. This interpretation was based on calcuations by Aikawa et al. (2012).

Finally, because of their similarities, it is natural to compare our results in more detail with those in the Orion Bar (Parise et al. 2009). Both clouds are massive star-forming regions, and in the two cases the PDRs are located at the interface of the Hii region and the molecular cloud. The only difference is that the Orion Bar is a more evolved Hii region, and the densities and the radiation field in the PDR associated with it are a factor of ~10 lower than in Mon R2. Both regions have been observed using the IRAM-30 m telescope, which avoids possible calibration problems when comparing lines observed with different telescopes, but the spatial scales are different because the distance to Mon R2 is twice than to Orion. The [DNC]/[HNC] ratio is ~0.01 in Mon R2, similar to the [DCN]/[HCN] ratio. Parise et al. (2009) did not detect DNC toward the so-called “clump 3” in the Orion Bar and derived an upper limit to the deuterium fraction of 0.01, which is still consistent with our results. The same can be said for C2D, which was not detected toward clump 3, with an upper limit of <0.11 for Dfrac(C2H). For HDCO, we have the opposite behavior, the Dfrac(H2CO) in the 10 km s-1 component is a factor of 2 lower than in the Orion Bar. Taking into account the uncertainties because of the beam-filling factor and the different distance of Mon R2 and the Orion Bar from the Sun, we do not consider that this difference is significant. Summarizing, although the number of deuterated compounds detected in Mon R2 is higher than in the Orion Bar, the values of Dfrac agree, within the uncertainties, in both PDRs.

The main difference between Mon R2 and Orion Bar is the different [HCN]/[HNC] ratio, which is a factor of ~3 higher in the 10 km s-1 Mon R2 component. It is well known that the [HCN]/[HNC] ratio depends on the gas tempeature with values ~1 in cold clouds and higher in warm regions. This is consistent with the values shown in Table 3. The [H13CN]/[HN13C] ratio in the 10 km s-1 component in Mon R2 is significantly higher than in the Orion Bar, in line with the different gas kinetic temperatures (~30 K in the Orion Bar and ~50 K in Mon R2). As discussed in Section 5, this difference can also be due to the different timescales and densities, because the Orion Bar is a more evolved object than Mon R2. Within Mon R2, the [H13CN]/[HN13C] ratio is higher in the 10 km s-1 component than in the PDR toward of MP2 position. The lower rotation temperature of the HCN and the HNC isotopologs toward the MP2 position suggests that the gas kinetic temperature and/or density are lower at the latter.

Table 4

Model parameters.

5. Chemical model

We compare our observational results with a pseudo-time-dependent gas phase chemical model. We chose this code to be consistent with previous conclusions by Pilleri et al. (2012) about early-time chemistry for small hydrocarbons.

One concern could be the influence of the UV radiation on the deuteration (not accounted for our pseudo-time-dependent model). The detection of the reactive ions CO+ and HOC+ (Rizzo et al. 2003) and the pure H2 rotational lines (Berné et al. 2009) toward the IF position showed that the UV radiation is impinging into molecular gas at this region. We used the steady-state PDR Meudon code to investigate the influence of UV photons on the deuterium fractions. The UV photons do not influence the deuterium fractions directly, but through the increased gas temperature because of the UV heating. With high UV fields, ~105 Habing field, the gas temperatures are very high in the first layers of the PDR, and consequently, the deuterium fractions are very low. Since the deuteration via ion-molecule reactions is not efficient for temperatures >70 K, the emission of the deuterated species is more likely arising from shielded (AV ~ 8–10 mag) dense clumps where the gas kinetic temperature is ~50 K. At these moderate temperatures, 50 K, the high deuterium fractions measured toward Mon R2 cannot be explained with steady-state chemistry, and we needed to use a time-depedent code to account for them.

The chemical network used in our pesudo-time-dependent code includes recent modifications of the reaction rate coefficients involving nitrogen, as reported in Wakelam et al. (2013) following recent experiments on neutral-neutral reactions at low temperatures by Daranlot et al. (2011, 2013) and is based on previous studies by Roueff et al. (2005, 2013) and Pagani et al. (2011). The ortho/para ratio of H2 (hereafter OPR) is considered as an input parameter that does not evolve with time, and influences the reverse reaction of the H3+ fractionation reaction with HD, where the presence of ortho H2 reduces the endothermicity of the reaction by a significant amount of energy (170.5 K), and then the deuteration efficiency as first pointed out by Pagani et al. (1992). The contribution of para- and ortho-H2 is also explicitly introduced in the initial step of nitrogen hydride chemistry, the N+ + H2 reaction, following the prescription by Dislaire et al. (2012). Within this approximation, the chemical network includes 214 species and 3307 chemical reactions.

To fit the observed abundance ratios we considered a grid of chemical models with the temperature fixed at 50 K and varied the density, initial conditions, and OPR. We considered two densities: nH = 3 × 105 cm-3 and nH = 2 × 106 cm-3, which are representative of the range of densities measured in this region (Pilleri et al. 2012, 2013). Table 4 shows the elemental abundances of the low- (A and B) and high- (C and D) metallicity models. In the model, the adsorption and evaporation of molecules on/from the grains are not included. When molecules such as H2CO or CH3OH evaporate, the elemental abundances of O and C in the gas phase increase. Given the limitation of our model, we mimicked this situation with the high-metallicity case.

We also used a constant OPR because it is difficult to deal with the full ortho-para chemistry in the time-dependent code, but we considered different values of OPR: 0.3, that is the equilibrium value at TK = 50 K, 1 × 10-2, 1 × 10-3 and 1 × 10-4 for every model. The results of these models were quite similar for t< 1 Myr. The OPR mainly affects the [NH2D]/[NH3] ratio. We can fit the observed values with both OPR = 1 × 10-2 and 0.3.

In Fig. 7, we show the results of our pseudo-time-dependent model. The first important conclusion is that all the models give values of Dfrac and on [HCN]/[HNC] ratio very far from the observed ones in the steady state, that is, for ages >1 Myr. We find, however, values closer to our observations for ages between 104 to a few 105 yr. Similarly, Pilleri et al. (2013) showed that the abundances of small hydrocarbons are better explained with an early-time chemistry. This age, from 104 to a few 105 yr, also agrees with the typical ages of UC Hii regions. The data suggest that the collapse and the chemical evolution of the region occur quickly. Nevertheless, it is important to stress the fact that our models (from A to D) consider that the temperature and the density of the region are constant when in fact these parameters are variable. As a consequence, our age estimate is illustrative and mainly proves that the deuterium chemistry is out of equilibrium. The second conclusion is that the observations cannot be fitted with the high metallicity case, that is, the models C and D. This is also consistent with the emission from the deuterated molecules coming from shielded clumps where the temperature is not high enough to fully evaporate the ice mantles.

The deuterium fractions are not very dependent on the assumed density within the range considered in our grid of models (see Fig. 7), but it is the [HCN]/[HNC] ratio. The variation of the [HCN]/[HNC] ratio comes from the differences in the atomic oxygen abundance. HCN does not react with O, whereas we allowed the reaction HNC+ O NH + CO. This reaction was introduced by Pineau des Forets et al. (1990), but has never been measured in the laboratory, however. When O increases, the [HNC]/[HCN] ratio decreases drastically. The high [HCN]/[HNC] ratio measured in the 10.5 km s-1 component is higher than the values predicted by high-metallicity models. The [HCN]/[HNC] ratio is very dependent on the time and density (e. g., models A and B in Fig. 7). Taking into account that we expect a density gradient in the region, we consider that there is a reasonable agreement with the low-metallicity case. This also suggests that the different [HCN]/[HNC] ratios measured among the three velocity components in Mon R2 could be the consequence of small differences in density and gas kinetic temperature.

The best fit is obtained for model A (see Fig. 7). As commented above, this model assumes constant density and temperature. To obtain a more realistic view, we ran two more models (E and F) consisting of two sequential phases at a different temperature and OPR: (i) in phase 1, we ran a model with T = 15 K and OPR = 1 × 10-4 to simulate the cold collapse phase, (ii) then in phase 2, we ran a second model with T = 50 K and OPR = 1 × 10-2, using as input the abundances of the previous models for the ages 105 yr (model E) and 106 yr (model F). Table 4 summarizes the parameters of all the models. Model E is quite similar to model A, while model F is very different from the others. This model provides a good fit for the [C2D]/[C2H], [DNC]/[HNC], [DCN]/[HCN], and [NH2D]/[NH3] ratios, but it fails for the other observed ratios. The main disagreement of model F are the low absolute abundances of the molecular species, in particular, the C2H abundance is two orders of magnitude lower than those obtained for the other models. This indicates that the collapse phase before the formation of the UC Hii region should be fast enough to avoid the gas to achieve the steady state (see also Pilleri et al. 2012). In model E, we assumed a constant density of 2 × 106 cm-3 during phase I. The chemical equilibrium is reached faster at higher densities. In a real time-dependent model in which the density is low at the beginning and increases with time, the collapse time could be longer than 0.1 Myr.

Figure A.13 shows the abundances fits of HCN, HCO+, and C2H relative to H2 considering a gas kinetic temperature of Tk = 50 K and OPR = 1 × 10-2 (from model A to model D). The red line represents the [HCN]/[H2] ratio, the purple line shows the [HCO+]/[H2] ratio, and the blue line shows the [C2H]/[H2] ratio. The dashed lines shows the ratios of observational results toward MonR2 for the 10.5 km s-1 component at the IF position. As commented above, the best fit is obtained for the model A and the worst one is the model D (see Fig. A.13). The observational abundances relative to H2 were calculated considering N(C18O) = 7.3 × 1015 cm-2 and X(C18O) = 1.7 × 10-7 for the IF position (Ginard et al. 2012).

thumbnail Fig. 7

Chemical models considering a gas kinetic temperature of Tk = 50 K and OPR = 1 × 10-2 (from model A to model D). Models E and F consider a temperature Tk = 50 K, but their initial abundances are obtained using another model (with Tk = 15 K and OPR = 1 × 10-4) at a time of 105 yr (for model E) and 106 yr (for model F). At the top part of the figures of every model, the red line represents the [HNC]/[HCN] ratio, the green represents the [DCN]/[HCN] ratio, the purple line shows the [DNC]/[HNC] ratio, and the blue line shows the [C2D]/[C2H] ratio. In the bottom part of the figures of every model, the blue line represents the [HDCO]/[H2CO] ratio, the green line shows the [D2CO]/[H2CO] ratio, the purple line shows the [DCO+]/[HCO+] ratio, and the yellow one shows the [NH2D]/[NH3] ratio. The dashed lines shows the ratios of observational results toward MonR2 for the 10.5 km s-1 component at the IF position.

Open with DEXTER

6. Discussion: can Dfrac(N2H+) be used as an evolutionary indicator in massive star-forming regions?

Deuteration has been used extensively as an evolutionary indicator in low-mass star-forming cores. Dfrac(N2H+) is found to be >0.1 in starless cores close to the onset of gravitational collapse (Crapsi et al. 2005). After the formation of the star, Dfrac(N2H+) decreases as the core evolves (Emprechtinger et al. 2009; Caselli et al. 2008). The reason is that Dfrac and N(H2D+) are very dependent on the gas temperature in the range 10 K30 K in which the CO frozen out on the grain surfaces is released to the gas phase.

It is not clear, however, that Dfrac(N2H+) can be used as evolutionary indicator in the high-mass regime. Fontani et al. (2011) showed that the Dfrac(N2H+) in massive starless cores is ~0.2, i.e., as high as in low-mass pre-stellar cores, but it drops to values of ~0.04 for high-mass protostars and UC Hii regions. Less clear results were obtained by Miettinen et al. (2011) toward a sample of IRDCs. They found that CO was not depleted in the observed sources and that Dfrac(N2H+) was lower than in low-mass starless cores (see Tan et al. 2013, for a recent review).

Our results for Mon R2 suggest that the deuterium fractions of molecules in massive protostars are dominated by ion-molecule reactions and are strongly time dependent. When the gas temperature increases over 20 K and the CO on the icy mantles is released to the gas phase, Dfrac(N2H+) decreases rapidly and reaches the steady-state value in less than 0.1 Myr. Even in the starless phase, if the core is turbulent and the temperature is higher than 20 K, Dfrac(N2H+) can reach values lower than those typical in the low-mass starless cores. The same is true for Dfrac(HCO+). Other molecules such as HCN and HNC need about 1 Myr to reach the steady the state and could be useful to age massive protostellar cores and UC Hii regions. Dfrac(H2CO) is only useful to prove the hot-core phase. When all the icy mantles are evaporated, Dfrac(H2CO) reaches the steady-state value in a short time.

7. Conclusions

We have determined the values of Dfrac for a large sample of molecules (C2H, HCN, HNC, HCO+, H2CO, N2H+, and NH3) toward the PDRs IF and MP2 position, around the UC Hii region Mon R2. Our results can be summarized as follows:

  • Our observations show that Mon R2 presents a complex morphological and kinematical structure. We detected two velocity components toward the IF and MP2 positions. The component at 10 km s-1 is detected at both positions and seems associated with the layer most exposed to the UV radiation from IRS 1. The component at 12 km s-1 is only detected toward the IF position and is related to the bulk of the molecular cloud with its maximum in the SW. The component at 8.5 km s-1 is only detected toward the MP2 position and is related to the second low-UV PDR described by Ginard et al. (2012) and Pilleri et al. (2013).

  • There are no important differences between the values of Dfrac toward the two PDRs. This is interpreted in the scenario of the deuterated compounds coming from dense and warm clumps with gas kinetic temperatures of 50 K, instead of the most exposed PDR layers.

  • Values of Dfrac of ~0.01 are found for HNC, HCN, C2H and H2CO, and <0.001 for HCO+, N2H+, and NH3. These values are consistent with the predictions of the gas-phase model at an early time, ~0.1 Myr. This time is consistent with the ages estimated for UC Hii regions on the basis of statistical studies.

  • The deuterium chemistry is a good chemical clock in both the low-mass and high-mass regime. However, the values of Dfrac(N2H+) and Dfrac(HCO+) cannot provide a good estimate of the evolutionary stage of massive protostar regions because this abundance ratio reaches the steady-state value on a short scale time after all the CO is released from the grains into the gas phase. We need to use the values of Dfrac for different molecules (e. g., HCN, HNC and C2H) with longer chemical scales time to provide accurate age estimates.


1

The values of the and where taken from the IRAM-30 m webpage; http://www.iram.es/IRAMES/mainWiki/Iram30mEfficiencies

2

See http://www.iram.fr/IRAMFR/GILDAS for more information about the GILDAS software.

4

The values of the [12C]/[13C] and [16O]/[18O] ratios correspond to the galactocentric distance of Mon R2, i. e., ~9 Kpc.

Acknowledgments

We acknowledge Á. Sánchez-Monge for useful comments and suggestions. We also thank J. A. Toalá for a critical reading of the manuscript. We thank the anonymous referee for his/her comments. We thank the Spanish MINECO for funding support from grants CSD2009-00038, AYA2009-07304, and AYA2012-32032.

References

Online material

Appendix A: Tables and figures

In this section we show all the spectra of the hydrogenated (Figs. A.1A.8) and deuterated (Figs. A.9A.12) species toward the IF and MP2 positions. The tables of the parameters (Table A.1), the tables of the Gaussian fits (Tables A.2 –A.4), and the molecular abundances of HCN, HCO+, and C2 relative to H2 predicted by models A to D (Fig. A.13).
