1. Introduction

Understanding galaxy formation and evolution is one of the central questions in modern astrophysics. Major efforts have been made over the last few decades to understand the physical processes that drive the transformation of the protogalaxies which are seen at high redshift into the diverse range of galaxies we see in the local Universe. Large-scale numerical simulations have become increasingly important tools over the last ten years and have made remarkable breakthroughs. With recent advances in computing power, cosmological simulations, which were initially limited to massive structures, now have a mass resolution sufficient to resolve objects down to dwarf galaxies in large volumes (e.g. Guo et al. 2011) yielding unprecedented insight into the formation and evolution of galaxies across a large dynamical range of types and masses.

What determines the formation and evolution of galaxies is the transformation of baryonic matter, but the computational cost of an extensive physical model of the processes affecting this matter (gas heating and cooling, star formation, feedback, active nuclei, metal enrichment, etc.) at the sub-grid level remains particularly high. Even large hydrodynamical simulations, such as the OverWhelmingly Large Simulations project (Schaye et al. 2010), that model in detail the physics of the baryons are either limited to significantly smaller volumes or require a dazzling amount of computing power: 105 cores and 65.5 × 109 particles in the case of the MassiveBlack simulation (Di Matteo et al. 2012), for instance. Large-scale cosmological simulations such as the Millennium simulation (Springel et al. 2005), which are limited to dark matter, are then coerced to employ coarser, yet physically sound, recipes. Still, the baryonic matter is key in constraining the formation and evolution of galaxies because it is directly traced through high-redshift surveys. The connection between the dark matter traced by N-body simulations and the baryonic matter traced by observations can be made through semi-analytic models (SAMs) such as the ones developed by Croton et al. (2006) or De Lucia et al. (2006), among many others. Reassuringly, comparisons between different SAMs show that they are globally consistent, but some systematic uncertainties can nevertheless be found (Fontanot et al. 2009a). To constrain models, simulated observations can be computed from the combination of numerical simulations with SAMs. These artificial catalogues can then be compared with observations (e.g. Henriques et al. 2012).

The attenuation due to dust dramatically affects the observed or predicted fluxes, colours, and spectral energy distributions (SEDs) of galaxies that are reddened. Computing the attenuation in galaxies is an important observational challenge, and one of the most delicate aspects of SAMs (Fontanot et al. 2009b; Gonzalez-Perez et al. 2013) along with the computation of the amount of cold gas (Obreschkow et al. 2009). As the radiation from different stellar populations propagates through clouds of gas and dust, it finds itself partly absorbed and reprocessed towards longer wavelengths. Because the energetic radiation from the youngest stellar populations is the most affected by the presence of dust, the most widely used star formation tracers are strongly influenced, either positively (the infrared) or negatively (the ultraviolet or Hα). This strongly affects our ability to trace star formation and by extension our understanding of galaxy formation and evolution across cosmic times.

In galaxies, the observed attenuation is actually the consequence of an intricate interplay between 1) the relative weights of the different stellar populations across the SED; 2) the relative geometry of the dust and the stars; and 3) the line-of-sight of the observation. Radiation transfer codes can be used to model in detail the emerging light of dusty galaxies (Baes & Dejonghe 2001; Tuffs et al. 2004; Bianchi 2008; Popescu et al. 2011). Unfortunately their high computational cost makes them unsuitable for cosmological simulations. In SAMs, different methods for computing the attenuation yield different predicted counts in ultraviolet (UV) luminosity functions (LFs) by a factor  ~ 2 (Finlator et al. 2006; Fontanot et al. 2009b). This is worrisome as the UV is one of the most widely used star formation tracers (Kennicutt 1998; Kennicutt & Evans 2012) and is observable by ground-based surveys for galaxies with z ≳ 1. One of the methods followed for computing the attenuation in SAMs revolves around variations of the following: 1) link the face-on optical depth to the gas surface density, which is a known quantity, and 2) assuming a given extinction curve, geometry, and line-of-sight, retrieve the V-band attenuation from the face-on optical depth (e.g. Guiderdoni & Rocca-Volmerange 1987; Devriendt et al. 1999; De Lucia & Blaizot 2007). Even though galaxies have a complex geometry, such methods are generally calibrated on objects in the Milky Way. In our galaxy, the reddening can be linked with the gas column density (Burstein & Heiles 1978, 1982; Schlegel et al. 1998). However, studies carried out by Xu et al. (1997) and Boissier et al. (2004, 2007) on different samples of galaxies actually found only weak relations between the face-on optical depth and the gas surface density. This sheds doubt on the reliability of such methods, and raises the issue of the potential impact on our understanding of galaxy formation and evolution. The main difficulties in performing studies on galaxies until recently revolved around the coarse resolution available for tracing both the gas and the attenuation in galaxies. The increasing availability of high-resolution maps of the gas through HI and CO observations, and multi-wavelength observations from the far-ultraviolet (FUV) to the far-infrared (FIR) now allow us to gain a much needed insight into the relation between the gas and the attenuation in galaxies. Beyond the direct impact of such relations on SAMs, with the inception of Atacama Large Millimetre Array and other millimetre instruments, we can trace the gas content of galaxies across the Universe indirectly through the emission of the dust and directly through molecular lines such as CO. The gas can then be used to correct the SED for the attenuation. Therefore, it is now now the right moment to reexamine the relation between the attenuation and the gas surface density in galaxies.

The principal aim of this paper is to determine whether there is a physical relation between the face-on optical depth and the gas surface density in galaxies at kpc scales and if so, to provide new, well calibrated, but still simple and easy to use relations to compute the attenuation for observations and for models. To do so we carry out a study on two samples of nearby resolved and unresolved galaxies and defined in Sect. 2. The sensitive and delicate issue of the determination of the attenuation and of the gas mass surface density is detailed in Sect. 3. We provide a first overview of the relation between the attenuation and the different gas phases in Sect. 4. We then derive new relations between the face-on optical depth and the gas mass surface density for resolved galaxies (Sect. 5). In Sect. 6 we examine the case of unresolved galaxies. We then describe how to apply these new relations to obtain a reliable estimate of the attenuation (Sect. 7). We compare the new relations we have obtained to standard relations from the literature in Sect. 8. The impact of the new relations on LFs is discussed in Sect. 9, and we present our conclusions in Sect. 10.

Table 1

Sample A.

2. Sample and data

2.1. Sample selection

2.1.1. Multi-wavelength requirements

We want to determine the relation between the attenuation and the gas in nearby galaxies. To reach this goal we need to determine these two quantities in resolved galaxies as well as in unresolved galaxies.

The attenuation due to absorption and scattering of the radiation out and into the line-of-sight can be determined in several ways. One method to correct for the attenuation in nearby galaxies is to compute the ionised, gas-phase attenuation from the Balmer decrement between the Hα and Hβ lines (e.g. Lequeux et al. 1979; Kennicutt 1992, and many others). This is best performed using spectra, and would ideally require integral field spectroscopy of the disk to map the attenuation reliably when considering resolved galaxies. Narrow-band observations of galaxies can be adversely affected by underlying absorption features, especially for the Hβ line. In any case this method requires stellar populations typically no older than 10 Myr. Another method is to combine extinguished and unextinguished star formation tracers such as UV or Hα with 24 μm. However, such methods often rely on a statistical analysis over a sample of galaxies (Kennicutt et al. 2009; Calzetti et al. 2010) or a sample of star-forming regions (Calzetti et al. 2005, 2007; Kennicutt et al. 2007; Relaño et al. 2007; Li et al. 2010) rather than being specifically tailored to each individual region. With the availability of large multi-wavelength datasets from the FUV to the FIR at sufficient resolution to resolve nearby galaxies, it is now possible to accurately determine the attenuation from the continuum emission by modelling the SED of entire galaxies or one pixel at a time, naturally taking into account the local physical parameters (e.g. Boquien et al. 2012). Ly et al. (2012) showed that at least in the case of unresolved galaxies, the use of SED fitting to determine the attenuation is as robust as using the Balmer decrement from spectra. We therefore determine the attenuation from a full SED modelling.

The gas is principally made of hydrogen either in atomic or molecular form. The atomic gas is easily detectable through its 21 cm spin-flip transition. The detection of molecular gas, however, is more difficult because of the intrinsic nature of H2, which accounts for the bulk the molecular gas mass. The most widespread method is to observe a rotational transition of the CO molecule which is a good tracer of molecular gas even though it is dependent on the temperature or the density of the gas (Maloney & Black 1988), and its metallicity (Wilson 1995; Israel 1997, 2000, 2005; Barone et al. 2000; Israel et al. 2003; Strong et al. 2004).

Following the multi-wavelength requirements we have exposed, to examine the relation between the gas and the attenuation at local and global scales in galaxies we need 1) high-resolution HI and CO data to trace the atomic and molecular gas; and 2) high-resolution multi-wavelength data from the FUV to the FIR to determine the attenuation. For unresolved galaxies the wavelengths requirements are the same.

2.1.2. Targets and data

We carried out the current study in the context of the Herschel SPIRE guaranteed time consortium. We relied on two surveys dedicated to the observation of galaxies in the nearby Universe: the Herschel Reference Survey (HRS, Boselli et al. 2010) and the Very Nearby Galaxies Survey1 (VNGS). We used these surveys as a baseline to guide our selection of a resolved sample (hereafter sample A), and an unresolved sample (hereafter sample B).

For sample A we selected all late-type galaxies from these two surveys that are not dominated by a strong active nucleus, and that have high-resolution data available in all bands at a sufficient depth: UV, optical, near-infrared (NIR), and FIR to model the SED accurately and determine the local physical parameters (including the attenuation), and also HI and CO to trace the atomic and molecular gas. To decide whether a galaxy is sufficiently resolved or not, which depends on its size, distance, and inclination, we relied on visual inspection of the data at 350 μm. We dropped the 500 μm band because its resolution is coarser and it does not add value to compute the attenuation. If structures are visible, the galaxy is deemed resolved for our purpose. We carried out the analysis at a resolution of 30′′, only slightly coarser than that of the 350 μm band. The shallow depth of GALEX UV data for some galaxies caused further reduction in the number of elements in the sample. The final set of photometric bands is the following: FUV, NUV (GALEX), u′, g′, r′, i′, z′ (SDSS), J, H, Ks (2MASS), 70 μm (Spitzer/MIPS), 250 μm, and 350 μm (Herschel/SPIRE), in addition to HI and CO maps. Despite the tremendous development of millimetre and radio imaging, high-quality data covering the entire body of nearby galaxies at a resolution better than 30′′ remain rare. This was the most stringent criterion limiting the number of galaxies in the sample. We relied on two large surveys for HI data using the Very Large Array (VLA): VIVA (Chung et al. 2009) and THINGS (Walter et al. 2008). To map the molecular gas, we relied on the HERACLES survey (Bigiel et al. 2008) carried out at the Institut de Radioastronomie Millimétrique (IRAM), which covers a sample of nearby galaxies in the CO(2 − 1) transition at 6′′. In conclusion, there are four galaxies in sample A: NGC 2403, NGC 4254, NGC 4321, and NGC 5194 (Table 1).

For sample B, we applied the same basic criteria on the original HRS sample, substituting the requirement on the resolution for a similar requirement on the inclination b/a > 0.33 to limit radiation transfer effects. We used the following combination of photometric bands: FUV, NUV, U, g′, V, r′, i′, J, H, Ks, 60 μm (IRAS), 250 μm, and 350 μm, in addition to HI and CO measurements; this choice maximised the size of the sample. The requirement on the availability of both HI and CO was very stringent, along with the low-inclination requirement, both eliminating a large number of candidates. Sample B includes 27 galaxies (Table 2).

Table 2

Sample B.

Finally, we summarise the origin of the data used in this study in Table 3.

Table 3

Origin of the selected data.

2.2. Data processing

The data processing requirements were different for both samples. We had to ensure that sample A allowed us to perform a pixel-by-pixel analysis across the entire SED. Conversely, for sample B we could use directly the fluxes published in the literature so no extra processing was required.

For galaxies in sample A, the processing of the FUV to FIR bands, including HI and CO maps was performed as in Boquien et al. (2012). In a nutshell: background and foreground objects were masked; UV and optical data were corrected for the foreground Galactic attenuation using the attenuation value from Schlegel et al. (1998) combined with a Cardelli et al. (1989) extinction curve including the O’Donnell (1994) update; using the convolution kernels published by Aniano et al. (2011), images were convolved to a Gaussian with a 30′′ full width half maximum (from 0.5 kpc for NGC 2403, up to 2.5 kpc for NGC 4254 and NGC 4321) corresponding to the lowest resolution of the entire dataset; they were projected on the same reference grid with a pixel size of 10′′; the background was subtracted; finally pixels under a 3-σ threshold in any band, were discarded. The standard deviation of each image was computed taking into account both the variation of the background and the pixel-to-pixel noise. The entire procedure is described in greater detail in the aforementioned article.

Table 4

List of CIGALE parameters.

3. Attenuation and gas surface mass density

3.1. Determination of the attenuation

As mentioned in Sect. 2.1.1, to determine the attenuation we modelled the SED for each pixel in each galaxy (sample A), or of unresolved galaxies (sample B). We present here how this modelling was performed, and what the expected accuracy is. The impact of using alternative methods such as the relation between the IR-to-UV ratio and the attenuation is discussed in Appendix A.

3.1.1. CIGALE

We used the SED modelling code CIGALE (Burgarella et al. 2005; Noll et al. 2009) which handles both the emission of the stars in the UV-optical domain, and the absorption and reemission of this radiation by the dust at longer wavelength through an energy balance requirement. Several recent works have made use of it to determine the physical parameters of low- and high-redshift galaxies (Buat et al. 2011a,b; Burgarella et al. 2011; Giovannoli et al. 2011) as well as subregions within galaxies (Boquien et al. 2012). CIGALE is amply described in the aforementioned articles. We summarise briefly its main characteristics here.

3.1.2. Physical parameters

CIGALE handles a large number of input parameters that can be fine-tuned to achieve different goals. This means that we have to select the parameter space carefully to constrain the attenuation precisely. We use the set of parameters defined in Boquien et al. (2012) as a baseline. We briefly describe the choice of these parameters hereafter.

The stellar component which dominates the UV, optical, and NIR domains is made of two populations: the first one modelling the old stellar population, and the second one modelling the most recent burst of star formation. Both populations follow a Kroupa (2001) initial mass function with a standard metallicity of Z = 0.02. We take this last parameter as fixed because our samples are made of objects that have typically a solar neighbourhood metallicity and there is no object with an extreme metallicity that would induce a strong effect on the blue end of the stellar spectrum. The relative masses of these two populations can vary freely to take into account the strength of the last star formation episode compared to the older stellar population. The emission of the stellar populations in the UV and in the optical is attenuated following a bump-less starburst-like attenuation law (Calzetti et al. 1994, 2000) of varying slope, parameterised by a multiplying factor, with λ the wavelength, λ0 the normalisation wavelength, and δ the slope-modifying parameter. Allowing for a differential attenuation between the older and younger stellar populations, the energy is absorbed by the dust following the previously defined attenuation curve and is re-emitted in the IR, conserving the total energy. The dust emission is modelled using the star-forming galaxies templates from Dale & Helou (2002), parameterised by the IR power-law slope α. We should mention that because the computation of the IR luminosity is largely independent from the chosen library, this choice of the template library has no impact on our results. In Table 4, we present the list and the values of the parameters used.

Using this space of parameters, we generated a total of 1 455 300 models with CIGALE. In Fig. 1 we present a comparison between observed and modelled flux ratios constraining star formation, the attenuation, and the properties of the IR emission.

thumbnail Fig. 1

Comparison between observed and modelled flux ratios. The shade of the grey hexagons represents the logarithm of the density of models, with a darker shade indicating a higher number of models in the bin. The observed fluxes are indicated by circles, the colour depending on the galaxy. The median error bars including systematic uncertainties are shown on the upper-left side of the plots. The left plot shows the r′/NUV versus NUV/FUV flux ratios and the right plot shows the 70/FUV versus r′/NUV flux ratios.

Open with DEXTER

We see that these models and the observations overlap, showing that this set of CIGALE models is adequate to reproduce the observations. In the case of NGC 5194, we notice that there is a tail towards high r′/NUV and 70/FUV flux ratios. These regions correspond to the northern end of the galaxy that is contaminated by NGC 5195, a peculiar SB0 galaxy (Sandage & Bedke 1994), with which NGC 5194 is interacting.

Even if the models can reproduce the observations, it is not known how accurately the intrinsic physical parameters can be retrieved from such modelling with this combination of bands. Ensuring that the attenuation is reliably determined is especially important to understand its relation with the gas surface density. To do so, we followed the procedure outlined in Giovannoli et al. (2011) and Boquien et al. (2012) for instance. As a first step, we fitted the SED of each pixel in each galaxy in sample A. Using the best fits, we then created a catalogue of artificial SEDs and their associated parameters which are perfectly known. Subsequently to model uncertainties on the observed fluxes, we added a random flux to each band in each artificial SED, following a Gaussian distribution whose width is determined from the standard deviation of the original data. This allowed us to obtain an artificial catalogue of simulated observations of perfectly known regions in galaxies that are at the same time representative of the original sample. Finally, we compared the parameters of the artificial galaxies determined through the analysis of the probability distribution function by CIGALE, with the intrinsic, true parameters. The analysis of the results shows that the determination of the FUV attenuation is more reliable than the V-band attenuation (Fig. 2).

thumbnail Fig. 2

Attenuation derived from the analysis of the probability distribution function performed with CIGALE versus the true value for artificial regions in galaxies, in order to test the accuracy of the modelling. In each quadrant we indicate the number of data points N, the Spearman correlation coefficient ρ at the top, and the scatter of the relative difference in the attenuation at the bottom. The solid black line indicates the 1-to-1 relation. The error bar on the left indicates the median uncertainty as computed from the analysis of the probability distribution function. For consistency with the analysis carried out later in this paper, we have only selected datapoints with a good best fit (χ2 < 2). The left panel describes the FUV-band attenuation whereas the right one describes the V-band attenuation.

Open with DEXTER

We note, however, a slight underestimate of the attenuation for the highest values (AFUV ≳ 2). These biases remain no larger than the typical uncertainty which is computed from the probability distribution function. As such, they should not affect the results of the paper. We see that the relative scatter of the attenuation in the FUV band is typically 30% to 50% smaller than for the V band, while the Spearman correlation coefficients are higher. For this reason, and because FUV more closely traces star formation than optical bands, we will derive relations between the gas surface density and the FUV attenuation rather than the V-band attenuation as is customary. We provide a systematic method for extending the FUV attenuation to all wavelengths in Sect. 7.

3.2. Determination of the atomic and molecular gas mass surface density

3.2.1. Sample A

The atomic and molecular gas components can be traced indirectly through the emission of the dust, or in a more standard way through HI and CO observations. We have adopted the latter method as a baseline in this paper as it allows us to ensure that the determination of the gas surface density is entirely independent from the determination of the attenuation, which would not be the case with the former method. The impact of using the dust to trace the gas is discussed in Appendix B.

As long as HI remains optically thin, the conversion from HI emission to surface mass density is straightforward and reliable. For sample A, we converted the maps from brightness temperature to gas mass surface density using the relation (see Appendix C for the derivation) (1)with ΣHI the atomic gas surface density in M pc-2, Δα and Δδ the major and minor axes of the beam in arcsec, Si the HI flux density in Jy per beam in channel i, and ΔV the channel width in m s-1. We have to note, however, that self-absorption is not always negligible. A recent study by Braun et al. (2009) on the inclined galaxy M 31 found that the HI mass had to be increased globally by 30% to correct for self-absorption, and even more locally. The lower inclination of our galaxies and the relatively coarser resolution should limit the problem of HI self-absorption and its spatial variation.

The rotational transitions of CO are, in theory, good tracers of the molecular gas because its critical density is low enough to be excited collisionally in the bulk of the molecular gas. The relation between CO emission and the amount of molecular gas has been extensively studied in the literature but remains the subject of significant uncertainties that depend on the metallicity, the temperature, the density, etc. Ideally, the combination of several CO transitions permits us to constrain the physical properties of the CO emitting regions to trace the molecular gas as accurately as possible. Unfortunately, such a large dataset is not available for the current sample. While CO(1 − 0) maps are often the most commonly available, for sample A we used the CO(2 − 1) maps from the HERACLES survey (Leroy et al. 2009) because they provide simultaneously a good resolution and a good sensitivity. In Appendix D we discuss the impact of using different CO transitions. To convert the CO emission to molecular gas surface density, in a first approach, we used a standard XCO conversion factor valid for galaxies that have a metallicity similar to that of the Milky Way (Strong et al. 1988) (2)the molecular gas surface density coming directly (3)with mp the mass of a proton, and ICO the CO line intensity. Even though there are more recent estimates, it is well within the typical range of XCO found in the local group (1 − 4 × 1020 cm-2 (K km s-1)-1). As we will see later the choice of this value was made for consistency with Boselli et al. (2002). As mentioned before, one of the main parameters affecting the XCO factor is the metallicity, with the conversion factor being higher in less metallic environments owing to complex factors linked to differences in dust shielding, lower CO abundance, etc. The impact of such a dependence on the metallicity is discussed in Sect. 5.3.

The XCO factor is generally defined for the CO(1 − 0) line. As shown by Braine & Combes (1992), the typical CO(2 − 1)/CO(1 − 0) ratio for star-forming galaxies does not show large variations from one galaxy to another: 0.89 ± 0.06. We therefore divided CO(2 − 1) maps by this factor before computing the molecular gas surface density with Eq. (3). We should note that this ratio could be lower in the interarm regions (in the range 0.4 − 0.6) compared to the arms (in the range 0.8 − 1.0) as can be seen in NGC 5194 for instance (Koda et al. 2012).

Finally, to account for the presence of helium, we multiplied the gas masses by a factor 1.38. This value is derived assuming X = 0.7154 and Y = 0.2703 (Asplund et al. 2009). All quoted gas masses are implicitly inclusive of helium.

3.2.2. Sample B

For unresolved galaxies, the computation of the mean gas surface density is more complex as it depends on the large-scale distribution of the gas and the intrinsic characteristics of the observations (beam size, pointing strategy, etc.). The atomic gas is generally distributed on a large scale length and can extend well beyond the optical disk, fueling star-forming regions seen in the UV with GALEX (Thilker et al. 2005, 2007). Conversely on a broad scale the molecular gas is mostly concentrated towards the centre of the galaxy with an exponentially declining profile. High-resolution observations reveal, however, much more complex profiles with important variations in the azimuthal distribution (Regan et al. 2001). As do Xu et al. (1997), we considered different distributions to compute the mean gas surface density. When considering the atomic hydrogen only, we assumed the gas has an exponential distribution and we averaged over a radius rHI corresponding to 3 scale-lengths, rHI = 3 × 0.61 × r25 (Bigiel & Blitz 2012), with r25, the optical radius of the galaxy at 25 mag arcsec-2. When considering the molecular hydrogen, which was traced through CO(1 − 0) for all galaxies in sample B, we also assumed an exponential distribution and we similarly averaged over 3 scale-lengths, rH2 = 3 × 0.2 × r25 (Leroy et al. 2008; Lisenfeld et al. 2011). When considering both, we simply summed the atomic and molecular gas surface densities. We caution that these are only coarse estimates of the actual distribution of the gas and variations from galaxy to galaxy are to be expected.

As in sample A, all masses were corrected to take into account the presence of helium.

3.3. Other gas components

We have considered here only atomic gas traced through the 21 cm line and molecular gas traced through CO. However, that may not account for the total mass of gas in the galaxy as it does not take into account the dark gas and the ionised gas.

3.3.1. Dark gas

Besides the molecular gas traced by CO, there can also be so-called dark gas which is not traced by CO and therefore may be missed. This gas can be found in large quantities in relatively low-metallicity galaxies such as the Large Magellanic Cloud for instance (Galliano et al. 2011), and also in a handful of high-redshift objects (Maiolino et al. 2009), perhaps also because of the lower metallicity of these objects compared to local spiral galaxies. Our sample is made of relatively metal-rich spiral galaxies for which CO should be a more reliable tracer of the total molecular content. Still, some dark gas can also be found in the Milky Way (Grenier et al. 2005; Langer et al. 2010; Pineda et al. 2010; Velusamy et al. 2010; Planck Collaboration 2011). However, theoretical models suggest that for a given mean attenuation, the fraction of dark gas remains constant (Wolfire et al. 2010). Considering this, we have decided not to explicitly take into account this component. If necessary, it can be taken into account afterwards, rescaling the derived relations.

One way to naturally allow for the presence of this dark gas is to compute the gas surface density indirectly from the emission of the dust. We discuss this in detail in Appendix B.

3.3.2. Ionised gas

The last component we discuss here is the ionised gas. It can be found in the disk in regions that have recently seen star formation and in the warm medium surrounding galaxies (e.g. Ferrière 2001; Haffner et al. 2009). Even though some dust has been detected in the warm medium (Lagache et al. 1999, 2000), its contribution to the optical depth is difficult to ascertain. Consequently, we chose here to consider only the gas ionised by young, massive stars in the disk. This may induce an increase in the uncertainties on the determination of the final attenuation. However, regions with recent star formation are also regions where the atomic and molecular gas have the highest surface density, which makes their relative importance uncertain. Studies have shown that the emission of the warm gas is more closely associated to star formation than the emission of the cold gas (Bendo et al. 2010, 2012a; Boquien et al. 2011). In nearby galaxies, the warm-to-cold dust mass ratio has been shown to vary from  ~ 100 to a few 1000 s (e.g. Willmer et al. 2009; Kramer et al. 2010), suggesting that only a small fraction of the dust actually lies in ionised gas. To ensure this, we computed the approximate mass of ionised gas in each pixel. We first computed the ionising photon luminosity following the case B recombination (Osterbrock 1989): (4)with R the radius of a spherical HII region, ne the mean electron density, and αB the case B recombination coefficient for the Hβ line. By doing this we assume a constant density of ionised hydrogen within the radius R and a fully neutral hydrogen beyond. It easily comes that (5)Expressing as a function of the Hβ luminosity (6)with h the Planck constant and ν the frequency of the Hβ line. Accounting for helium, the total gas mass associated with the HII region can then be easily calculated (7)with mH the mass of an hydrogen atom.

We computed the Hβ luminosity from the SFR. First we converted the SFR to an Hα luminosity. Then we considered a temperature of 10 000 K, which yields L(Hα)/L(Hβ) = 2.87. Assuming that each 10′′ pixel typically contains an HII region with a radius of 50 pc, we found that ⟨ΣHII⟩ = 0.3 ± 0.4 M pc-2, with a maximum of ΣHII = 3.5 M pc-2. While these estimates remain uncertain because of the number and sizes of HII regions within a single pixel, they show that the total mass of the gas in HII regions is very small compared to the atomic and molecular gas components we have considered so far. Thus, we have decided not to account for the ionised gas mass to determine the relation between the attenuation and the optical depth.

4. A first overview of the relation between the gas and the attenuation in resolved galaxies

In Fig. 3 we plot for resolved galaxies the pixel-by-pixel relation between the FUV band attenuation derived in Sect. 3.1 and the gas surface density derived in Sect. 3.2.

thumbnail Fig. 3

Attenuation in the FUV band versus the atomic (top), molecular (middle), and total (bottom) gas mass surface density in units of M pc-2 for individual regions in galaxies (sample A). Each data point corresponds to a single pixel which has been detected at a 3-σ level from the FUV to the FIR. No selection has been applied on CO and HI data. Data points with a poor fit (χ2 ≥ 2) have also been removed. At the bottom of each panel we display the number of selected pixels N and the Spearman correlation coefficient ρ. Finally, the median uncertainty on AFUV computed by CIGALE is indicated in the bottom-right corner.

Open with DEXTER

There is little correlation between the attenuation and the atomic gas in general ( | ρ |  ≤ 0.18), except for NGC 2403 (ρ = 0.72). Conversely, we observe mild correlations with the molecular gas for all galaxies (ρ ≥ 0.47) except for NGC 2403 (ρ = 0.27). This difference between the atomic and molecular gas can be useful to understand where the attenuation takes place in galaxies as we will see hereafter. A good relation can also been seen when considering the total (HI+H2) gas surface density for all galaxies (ρ ≥ 0.47).

Interestingly, we see that the relation between the attenuation and the gas column density follows two regimes. At high column density (typically beyond 10 − 20 M pc-2), there is a clear increase of the attenuation with the gas column density. Conversely, under this threshold, the attenuation seems to be independent from the gas column density and converges to a value of about 1.5 mag. This is best seen in the molecular gas, but can also be noted when the total gas column density is considered. We will examine the physical origin of this dual behaviour in Sect. 5.2.

At low molecular gas mass surface density, we see an increase of the scatter in AFUV. This is, at least in part, a consequence of larger relative uncertainties on the determination of AFUV. These regions tend to be on the outskirts of star-forming regions, with lower fluxes and therefore larger relative errors than in more active regions. This ultimately propagates to the determination of the FUV attenuation.

The reason why we see a correlation between CO and dust attenuation in some galaxies but not others may be related to changes in the dust heating among galaxies. The particular case of NGC 2403 is interesting in that it shows an opposite behaviour compared to the other elements of the sample. Bendo et al. (2010) found that in NGC 2403 the CO emission does not correlate well with tracers of cold dust when examined at small spatial scales, which may partly explain the absence of a good correlation between the molecular gas and the attenuation. Along this line, a recent study of Bendo et al. (2012a) has shown that NGC 2403 has a thermal component that is not heated by the star-forming regions. A similar analysis on NGC 4254 and NGC 4321 (Bendo et al., in prep.) does not find a similar dust component. The recent results of Mentuch Cooper et al. (2012) on NGC 5194 also suggest that the dust is mainly heated by star-forming regions. Hence, in NGC 4254, NGC 4321, and NGC 5194, the molecular gas and most of the dust attenuation is associated with the FIR emission near regions of star formation. In NGC 2403, however, the dust attenuation associated with FIR emission is not in the same place as the molecular clouds, which causes the relation to break down. Since the FIR emission in NGC 2403 is at least partly from dust absorbing light in the diffuse interstellar medium (ISM), and because the atomic gas is also in the diffuse ISM and not in star-forming regions, the dust attenuation appears correlated with atomic gas. While studying further the relation between the star formation and the attenuation is of utmost interest to improve our understanding of star formation across the Universe, this would go well beyond the scope of the present paper. We refer to the aforementioned papers for further details. We nevertheless briefly discuss the relation between the molecular gas fraction and the attenuation in Appendix E.

5. Relation between the gas and the face-on optical depth in resolved galaxies

As we have shown earlier, in external galaxies the attenuation and the gas surface density are related in a non-trivial way. Whether a photon is affected or not by dust depends both on the relative geometry of the stars and the dust, but also on the line of sight of the observer. Unfortunately, no analytic model can fully grasp the impact of complex geometries of galaxies. They are bound to be coarse approximations. This may be problematic as for a given quantity of dust some geometries will cause a more efficient attenuation than others, and edge-on galaxies will be more attenuated than face-on galaxies. If the attenuation is dependent on the inclination of the galaxy in a complex way, it is much easier to correct for it if we work on face-on optical depths. The overarching aim of this paper is to provide relations to compute the attenuation rather than estimates of the face-on optical depth per se, which are a means and not an end. Therefore, we adopt a two-step approach. First, we assume a given geometry to compute the relation between the face-on optical depth and the gas mass surface density (Sects. 5 and 6). In a second step, these relations can be applied on any object, assuming the same geometry, to retrieve the attenuation as explained in Sect. 7. The use of the same geometry largely cancels out its initial impact on the determination of the relation between the attenuation and the face-on optical depth (Appendix F).

In this section we present the stars-dust geometry we adopt (Sect. 5.1) in order to compute the relation between the attenuation and the face-on optical depth (Sect. 5.2), and we examine the impact of the metallicity in Sect. 5.3.

5.1. Geometry

5.1.1. Choice of the geometry

As described by Disney et al. (1989), several geometries between the dust and the stars can be reasonably considered in galaxies, such as a simple dust screen, a sandwich model (a thin layer of dust embedded in a thick layer of stars), a slab (an infinite plane-parallel geometry in which stars and dust are perfectly mixed over the same scale), or even a clumpy ISM. While the screen model can be adapted for studies in the Milky Way, it is probably too simplistic to reproduce the complex relative distributions of stars and dust in external galaxies. The slab model is more realistic as gas is intimately mixed with stars in star-forming regions. In the sandwich model, the relative heights of the dust and the stars can be freely adjusted to take into account their different scales (e.g. Boselli et al. 2003). Another common model is that of a clumpy ISM (e.g. Witt & Gordon 1996, 2000). The clumps of dust can be modelled following a Poisson distribution, the source being partially attenuated by the presence of a variable number of clumps that all have the same size and optical depth (Natta & Panagia 1984).

More complex models, such as the one presented by Charlot & Fall (2000) for instance, beyond defining a geometry also take into account the differential attenuation between stellar populations of different ages, as younger stars are still embedded in their dusty birth clouds whereas older ones have broken out of these clouds. Such models are by nature very dependent on the star formation history (SFH) of galaxies. However, as we concentrate here exclusively on the FUV band where the youngest stellar populations dominate, such models do not present a significant advantage over simpler ones. To ensure this, we have carried out a supplementary run of CIGALE without differential attenuation. It yields FUV attenuations very close to the results of a differential attenuation showing that the FUV band is dominated by one stellar population.

As stated earlier, the adopted geometry is a means to correct for the inclination and determine intrinsic relations between the optical gas and the gas surface density. As long as the geometry is fully consistent end-to-end, its choice is not critical. To determine the relation between the face-on optical depth and the gas mass surface density, we have decided to adopt the widely used slab geometry. We examine the impact of using different geometries in Sect. 5.1.2 and Appendix F.

For a slab geometry, if we assume an isotropic scattering, the attenuation and the face-on optical depth are then related through the following equation adapted from Natta & Panagia (1984)(8)with Aλ the attenuation and τλ the face-on optical depth at wavelength λ, i the inclination angle of the galaxy, and ωλ the albedo at wavelength λ. The isotropic scattering is introduced through the term . This is only a simple approximation. To take scattering fully into account radiative transfer models would be necessary (Baes & Dejonghe 2001; Pierini et al. 2004; Tuffs et al. 2004; Inoue 2005; Rocha et al. 2008), which is much beyond the scope of the present article. Nevertheless, for the remainder of the paper we take ωFUV = 0.38, following the values published by Draine (2003b) for a Milky Way extinction curve with RV = 3.1.

To compute the face-on optical depth from the attenuation, we have inverted Eq. (8) (9)with W the Lambert W function. The derivation of this relation is provided in Appendix G.

5.1.2. Impact of the inclination correction on the derived attenuation

As we will see later, the relations we determine to compute the face-on optical depth from the gas surface density depend significantly on the geometry because a given attenuation corresponds to very different optical depths depending on the geometry. This is not necessarily a problem as long as the geometry is kept consistent. The application of these relations would yield identical attenuations if all galaxies were face-on with no scatter around the relations. As our data deviate from these ideal conditions, to evaluate the actual impact of the geometry we present in Fig. 4 the ratio between the attenuation obtained assuming a given geometry and that obtained assuming a slab geometry, for the gas surface density spanned by sample A.

thumbnail Fig. 4

Ratio of the FUV attenuation obtained from a relation for a given geometry to the attenuation for a slab geometry versus the gas surface density. We assume an inclination of 45°, corresponding to the mean of datapoints in sample A, which is necessary to compare adequately with relations for clumpy geometries, as the number of clumps can vary according to the inclination.

Open with DEXTER

We see that while using relations other than for a slab geometry induces an offset, generally towards a lower attenuation, it is limited to 15% at most when we consider an extreme, screen geometry. This shows that our original assumption that the geometry would only have a limited impact on the results is validated. In Fig. 5, we show how the relative attenuations vary as a function of the inclination angle and the gas surface density, assuming slab and screen geometries.

thumbnail Fig. 5

Ratio of the FUV attenuation assuming screen and slab geometries. The inclination angle varies from 0° (blue) to 90° (red).

Open with DEXTER

We see that for inclinations no larger than 50°, we see attenuations within 20% from either a screen or a slab geometry. However, the attenuations become increasingly contradictory for higher inclinations. This translates the uncertainties due to the scatter around the relations, and probably the complexity of the geometry within galaxies compared to these simple models. We therefore warn of the greater uncertainties when deriving the attenuation from the face-on gas column density for highly inclined galaxies.

5.2. Gas surface density and face-on optical depth

Following the choice of a slab geometry in the previous section, we have computed the face-on optical depth in the FUV band using Eq. (9). To compute the gas column density, in this first step we do not take into account the impact of the metallicity which will be explored in detail in Sect. 5.3. We present in Fig. 6 the relation between the face-on optical depth and the gas surface density.

thumbnail Fig. 6

Face-on optical depth in the FUV band versus the total gas mass surface density in units of M pc-2 for a slab geometry, and assuming a metallicity-independent XCO factor. The blue curves represent the best fit for the full sample whereas the black curves represent the best fit for individual galaxies for which the equation is given at the top of each panel. The uncertainties on τFUV are indicated by the error bar at the bottom right of each panel.

Open with DEXTER

Combining data points from all regions of the galaxies in sample A, we find the relation between the face-on optical depth and the gas surface density (10)for 2.5 ≤ ΣH ≤ 221.0 M pc-2. The presence of a non-zero constant is surprising at first sight. A first explanation could be that there is a selection effect against FUV-bright, low-attenuation regions with a low gas surface mass density, as we require emission at a 3-σ level in all bands. However, the inspection of selected regions shows that except for the most external regions, the entire extent of galaxies has been selected, within the limit of the observed field-of-view. We conclude that this is unlikely to be the reason for the observed levelling at low gas mass surface density. A more likely explanation would be that this is actually an effect due to the mixing of different regions because of the level of the resolution. At a resolution of 0.5 kpc to 2.5 kpc (30′′ beamwidth) there is a blending between different regions. This affects the measure of the gas mass surface density and the attenuation differently. The computation of the resulting gas mass surface density is straightforward, being simply the average of all regions within the resolution element. However, the attenuation is strongly weighted towards the brightest regions in the FIR and in the FUV band. As a consequence, if we consider that a given resolution element actually contains two regions that have respective gas mass surface densities s1 and s2 covering the same area and with s1 ≫ s2, the measured gas surface density over the entire resolution element will be  ~ s1/2. If we assume that these regions have attenuations a1 and a2, if the first region is much brighter than the second one, the measured attenuation in the resolution element will the  ~ a1. We therefore see that such blending will affect the gas mass surface density and the attenuation differently. In other words, the latter is luminosity weighted, whereas the former is governed by a simple geometrical mean over the surface of a pixel. This is even more evident if we consider that denser regions tend to form stars more actively, and will then drive the attenuation within the resolution element. The consequence is that if there is blending between different regions within a galaxy there will be a plateau at low gas mass surface density, which is what we see here. This means that the relations we derive in this paper should not be applied at a resolution more refined than that considered here. Conversely, this suggests that standard relations that do not take into account such blending should not be applied to unresolved galaxies or sufficiently large regions.

The second aspect to be noted is the large scatter, both within galaxies and from one galaxy to another. The internal scatter can largely be explained by the uncertainty on the face-on optical depth. This uncertainty is computed from the uncertainty on the FUV attenuation provided by CIGALE. When comparing the relation provided in Eq. (10) to relations derived for individual galaxies (Fig. 6) there are clear differences. The slope is relatively similar for NGC 4254, NGC 4321, and NGC 5194, but it is about twice as steep for NGC 2403. Conversely, NGC 2403 levels at a much lower face-on optical depth than average, whereas NGC 4254 and NGC 4321 level at a higher face-on optical depth, and NGC 5194 is close to the value for the entire sample. This is probably due to intrinsic differences between galaxies in the sample. Another possibility would be that it is due to the physical resolution. However, after having carried out a similar study at a resolution of 64′′ we found that such a coarsening had no effect on the relative levels. This suggests that beyond a certain resolution, the level of the face-on optical depth at low column density is left mostly unchanged. If the mixing within a resolution element is already representative of the content of the galaxy, increasing the mixing will not change the properties within a resolution element.

Finally, we see that for NGC 4321, there is a visible saturation in the optical depth at high column density. This undoubtedly affects the fit. Performing a fit only when ΣH ≤ 60 M pc-2 yields a steeper slope for NGC 2403 than when all regions are considered but only change marginally the parameters for other galaxies.

5.3. Impact of the metallicity

A change in the metallicity can have dramatic effects on the measurement of the molecular gas reservoir of galaxies. The reason is that the molecular content is generally traced through quantities that are dependent on the metallicity. For instance the XCO factor mentioned in Sect. 3.2 is expected to vary with the metallicity. Ignoring this effect naturally increases uncertainties on the gas mass derived from the CO emission. At lower metallicities CO lines trace an increasingly small fraction of the total molecular gas, directly increasing the value of the XCO factor, barring any other effect.

Several studies have been dedicated to quantifying the relation between the metallicity and the XCO factor. Wilson (1995) in a seminal study found a sub-linear relation between the XCO factor and the oxygen abundance. Arimoto et al. (1996) and Boselli et al. (2002) found nearly linear slope ( − 1.01 and  − 1.00, respectively). Recently, Schruba et al. (2012) have found especially steep slopes between  − 2.8 and  − 2.0. Conversely, Blitz et al. (2007) or Bolatto et al. (2008) did not find any relation with the metallicity.

To investigate the influence of the metallicity on the relation between the gas surface density and the face-on optical depth, we examine how this relation changes when we consider a metallicity-dependent XCO factor. To do so we adopt the relation derived by Boselli et al. (2002), which is intermediate between the steep slopes found by Schruba et al. (2012), and the lack of relation found by Blitz et al. (2007) or Bolatto et al. (2008)(11)with XCOgal the standard Milky Way factor. To be consistent with the metallicity scale used by Boselli et al. (2002), we adopt the metallicity gradients measured by Zaritsky et al. (1994) rather than the newer gradients published by Moustakas et al. (2010). This prevents the introduction of biases due to differences between metallicity estimators. In Fig. 7, we plot the relation between the total gas surface density and the face-on optical depth when using the relation given in Eq. (11).

thumbnail Fig. 7

Face-on optical depth in the FUV band versus the total gas mass surface density in units of M pc-2. The colour of each point indicates the oxygen abundance determined from the gradients published by Zaritsky et al. (1994). The black line represents the best fit for the entire sample (Eq. (12)) when taking into account a metallicity-dependent XCO factor (Eq. (11)). The coloured lines represent the best fit for the entire sample (Eq. (13)) for different values of 12 + log O/H, when fitting the gas column density and the oxygen abundance simultaneously. At the top of each panel the number of datapoints and the Spearman correlation coefficient is indicated.

Open with DEXTER

Computing the relation between the gas surface density and the face-on optical depth, we find (12)There is a clear steepening of the relations compared to those shown in Fig. 6. This is expected because Eq. (11) naturally yields a lower (respectively higher) XCO factor for 12 + log O/H > 8.83 (resp. 12 + log O/H < 8.83).

Beyond affecting the estimate of the molecular gas surface density, the metallicity also has a direct impact on the gas-to-dust mass ratio and therefore on the amount of dust attenuating the interstellar radiation. The simple relations we have derived do not fully capture the impact of the variation of the metallicity, in effect averaging over all the line-of-sights, objects, and metallicities. To take into account these variations, different methods can be used. A first, very naïve, method would be to correct the face-on optical depth computed as in Eq. (12) for the difference of the gas-to-dust mass ratios between sample A and that of the observed object , with  the metallicity corrected face-on optical depth, the face-on optical depth obtained from Eq. (12), and MH/Mdust the gas-to-dust mass ratio for sample A (subscript sample A), and for the targeted object (subscript object). As mentioned before, a variation of the gas-to-dust mass ratio will directly affect the quantity of dust affecting the emission. This ratio is evidently strongly dependent on the metallicity. Therefore, it is important that the metallicity of the sample the relation was derived on is homogeneous and well-known. With a metallicity spread over more than 0.5 dex in sample A, the former criterion is certainly not fulfilled as there are significant variations of the gas-to-dust mass ratio from one region to another, and from one galaxy to another. A better way to take the metallicity into account is to derive relations between the face-on optical depth and the gas surface density, parameterising them explicitly on the oxygen abundance. With this method, we find (13)The normalisation of the oxygen abundance, here 9.00, is arbitrary. We have chosen this value because it is close to the typical values yielded by the oxygen abundance estimator of Zaritsky et al. (1994) for nearby spiral galaxies. This relation is necessarily dependent on the way the metallicity has been determined as different methods give different estimates. One can use the relations provided by Kewley & Ellison (2008) to convert the metallicity computed from one method to the Zaritsky et al. (1994) method. Note that because the metallicity and the gas surface density are not completely independent quantities in galaxies (regions with a higher gas surface density tend to be more metal rich than regions with a lower gas column density), great care must be taken to interpret the coefficients of the best-fit related to the gas surface density and the metallicity. Examining the variance-covariance matrix of the best-fit parameters, we find that the correlation coefficient between the coefficients related to these quantities is r =  − 0.63.

In Fig. 8 we show the face-on optical depth computed with these relations versus the face-on optical depth derived from the attenuation provided by CIGALE and an assumed slab geometry.

thumbnail Fig. 8

FUV face-on optical depth computed with Eq. (12) taking into account the gas surface density (green dots), and Eq. (13) taking into account the gas surface density and the metallicity (red dots), versus the measured face-on optical depth from the attenuation provided by CIGALE and an assumed geometry. The black line represents to 1-to-1 relation.

Open with DEXTER

Taking into account the metallicity brings as expected substantial improvements. The most notable change is due to the regions belonging to NGC 2403 which have a systematically lower metallicity than other galaxies in the sample. The regions belonging to NGC 2403 correspond to the concentration of points in the lower left corner in Fig. 8. If the impact of the metallicity is not taken into account, Eq. (12) would systematically overestimate the optical depth. Equation (13) brings a strong improvement, yielding optical depths much closer to the ones obtained from CIGALE attenuations.

The relative difference of the face-on optical depth goes from (14)with ΔτFUV = τFUV,  fit − τFUV,  measured when considering only the gas surface density, to (15)when also taking into account the metallicity. This means that the uncertainty on the face-on optical depth is of the order of  ~ 50%. This hints at the importance of additional, undetermined, parameters, and it shows the inherent complexity of determining the attenuation, and by extension the face-on optical depth, from the gas column density.

For the remainder of this article we will always consider a metallicity dependent XCO factor unless specifically noted otherwise.

6. Comparison with unresolved galaxies

The relation between the gas surface density and the face-on optical depth in unresolved galaxies is expected to be more challenging to determine because of the more complex large-scale geometries, gas distribution, and stellar populations found in these galaxies. It is important to verify whether the relations previously obtained provide reliable results for unresolved galaxies as their reliability conditions their applicability. One of the first attempts to connect the attenuation and the gas surface density in unresolved galaxies was made by Xu et al. (1997). They found weak relations between the attenuation in the B band and the face-on optical depth. More recent studies have yielded similar results (Boissier et al. 2004, 2007).

A first inspection of the relation between the FUV attenuation and the gas surface density in sample B is shown in Fig. 9.

thumbnail Fig. 9

Same as Fig. 3 for sample B.

Open with DEXTER

There is a weak anti-correlation between the attenuation and the atomic gas mass surface density (ρ =  − 0.33). Conversely, there is a clear correlation with both the molecular (ρ = 0.64) and the total gas content (ρ = 0.54). This is actually because some galaxies have a high molecular fraction. If attenuation is linked to denser regions, then it is expected that galaxies with relatively little HI due to the high molecular fraction will be more attenuated.

In Fig. 10 we show the relation between the face-on optical depth and the gas surface density.

thumbnail Fig. 10

Relation between the FUV face-on optical depth and the gas surface density for unresolved galaxies (black circles with error bars). The blue line corresponds to the best linear fit for the unresolved sample. The corresponding relation is indicated at the top of the figure, along with the number of elements and the Spearman correlation coefficient. The black dashed line corresponds to the relation for resolved galaxies when assuming a solar metallicity (Eq. (10)). The absence of metallicity estimates for a number of galaxies prevents us from using a metallicity-dependent XCO factor. The red dots represent the four galaxies in sample A, with the bars indicating the full dynamical range probed by each of them.

Open with DEXTER

In spite of the scatter and the limited size of the sample, for most of the galaxies the relation derived for resolved galaxies provides a reasonable estimate of the face-on optical depth. The relations derived for both samples prove to be very similar. This suggests that both resolved and unresolved galaxies follow relatively similar laws. Had they been markedly different, the derived relations would have shown obvious differences. This is especially important as sample B is made of only 27 galaxies and the scatter is large. A larger sample would be particularly useful to ascertain this result. Ultimately, the similarity between the relations suggests that the relations derived from resolved galaxies can be reasonably applied to unresolved galaxies.

To compare the dynamical range covered by resolved galaxies versus unresolved ones, we have computed the global face-on optical depth for each galaxy in sample A. To do so 1) we correct each pixel for the FUV attenuation using the estimate from CIGALE, 2) we sum the attenuation corrected flux in each pixel, 3) we compute the global FUV attenuation of each galaxy comparing the summed corrected and uncorrected FUV fluxes, and finally 4) assuming a slab geometry, we compute the face-on optical depth. The red dots in Fig. 10 represent these integrated values and the bars around them the dynamical range covered by individual pixels within each of these galaxies. We see that our sample is well within the envelope described by sample B. Note that the mean gas surface densities for the four galaxies in sample A determined this way are much more secure than the values derived for sample B as they do not depend on assumptions on the distribution of the gas in galaxies.

7. Practical methods for computing the attenuation

In this section we present some methods for computing the attenuation at all wavelengths in galaxies from the relations presented above, at kpc scales for resolved galaxies and for unresolved galaxies as a whole. The computation of the attenuation can be broken into several individual steps which we describe in detail here:

  • 1.

    The mean gas surface density must be computed for eachelement (either an unresolved galaxy or an individual subregion)in the sample, taking into account both the atomic and moleculargas.

    • (a)

      If either component is missing, it can be compensated forby assuming a certain molecular fraction.

    • (b)

      In the case of unresolved galaxies, the computation of the gas surface density will be especially dependent on the actual distribution of the gas in the galaxy because this determines the area it should be averaged upon. We recommend averaging over 3 scale-lengths as we mentioned in Sect. 3.2.2: rHI = 3 × 0.61 × r25 (Bigiel & Blitz 2012), and rH2 = 3 × 0.2 × r25 (Leroy et al. 2008; Lisenfeld et al. 2011), with r25 the optical radius at 25 mag arcsec-2.

  • 2.

    From the gas surface density, the optical depth in the FUV band should be computed using one of the relations provided in this paper.

    • (a)

      If an estimate of the metallicity is available, we strongly recommend the use of a relation explicitly dependent on the metallicity (Eq. (13)). This is important as the metallicity affects the gas-to-dust mass ratio which has a direct consequence on the optical depth. We would like to stress, as already mentioned in Sect. 5.3, that for consistency, the oxygen abundance estimator of Zaritsky et al. (1994) has been adopted throughout this paper. It is known to yield rather high values compared to other estimators. When estimates of the metallicity have been carried out with another estimator, we recommend either recomputing it with the Zaritsky et al. (1994) estimator, or converting it with the formulas published in Kewley & Ellison (2008).

    • (b)

      If no estimate of the metallicity is available, we recommend the use of a relation parameterised only on the gas surface density (Eq. (12)). We caution that these relations have been derived on local galaxies that are relatively metal rich on average, 8.8 ≲ 12 + log O/H ≲ 9.4 with the Zaritsky et al. (1994) estimator, which could lead to large biases in the estimate of the optical depth if applied without correction to lower metallicity objects.

  • 3.

    From the FUV face-on optical depth, the FUV attenuation can be computed assuming a given geometry (Eq. (8) for a slab geometry).

    • (a)

      As the relations we have derived between the gas surface density and the face-on optical depth depend on the geometry we initially assumed, it is of utmost importance to adopt the same geometry2.

    • (b)

      For consistency, we recommend the use the value of the albedo published by Draine (2003b).

  • 4.

    Finally, from the attenuation in the FUV band, it is possible to compute the attenuation at any wavelength assuming an attenuation curve. In case of a starburst galaxy, the starburst attenuation curve (Calzetti et al. 1994, 2000) can be applied. For high-redshift galaxies, the recently derived attenuation curve of Buat et al. (2011a) can also be used.

8. Comparison with relations from the literature

In this section we examine how the relations we have obtained compare to some of the relations published in the literature.

In the Milky Way it is possible to directly measure the quantity of gas towards individual objects and the extinction undergone by these objects. In this case, relations between the optical depth and the gas surface density take the form of a linear relation between these two quantities, and have an explicit dependency on the attenuation curve and the gas-to-dust mass ratio. Guiderdoni & Rocca-Volmerange (1987) expressed this as (16)with ΣH the face-on gas surface density, E(B − V)/NH the quantification of the reddening, which is generally calibrated in the Milky Way with a screen geometry, Z the metallicity, Z the solar metallicity, and s a wavelength-dependent parameter to take into account the variation of the shape and the amplitude of the reddening with the metallicity. Following Guiderdoni & Rocca-Volmerange (1987), we take s = 1.35 in the FUV band. If we assume an extinction curve with RV = 3.1 and E(B − V)/NH = 1.81 × 10-2 mag (M pc-2)-1 from Güver & Özel (2009), in the V band and for a solar metallicity it reduces to (17)which is close to the widely used relation of Guiderdoni & Rocca-Volmerange (1987) and Devriendt et al. (1999)(18)We have to note that at very high column density, RV may be larger as can be seen in dense molecular clouds. For instance in the Perseus cloud, Foster et al. (2013) measured an increase from RV = 3 for AV = 2, to RV = 5 for AV = 10. At such attenuations, no significant quantity of UV photon could escape. However, on the scale of the current study, it should concern only a small fraction of UV photons. Otherwise, CIGALE fits would fail catastrophically, which is not the case. We therefore think that the adopted value of RV = 3.1 is reasonable under the present conditions.

Using such relations directly has several drawbacks for tracing star formation in galaxies. First of all they are normalised to the V band which is a poor tracer of star formation. Computing the optical depth in the FUV, which is critical for computing attenuated and non-attenuated SFR, requires not only assuming an extinction curve (typically Milky Way, Large Magellanic Cloud, or Small Magellanic Cloud depending on the metallicity of the object), but also taking into account the mixing of different populations which are differently affected by the attenuation. Also, these relations are calibrated on individual lines of sight in the Milky Way or in the Magellanic Clouds assuming a screen geometry, but not on large-scale regions or even unresolved galaxies that have more complex stars-dust geometries.

To compare these relations to the ones we have obtained at kpc scales, we assume an extinction curve with τFUV/τV = 2.5 which approximately corresponds to a Milky Way-like extinction curve. Steeper extinction curves such as the LMC or the SMC would yield larger FUV optical depths. We present the results in Fig. 11.

thumbnail Fig. 11

Comparison of the relations between the face-on optical depth and the gas surface density obtained in this paper (solid lines, Eqs. (12) and (13)), with the relation from Guiderdoni & Rocca-Volmerange (1987) (dashed line), and with the relation from Güver & Özel (2009) (dotted line). The coloured lines show metallicity-dependent relations according to the oxygen abundance scale shown on the right. For clarity, we have plotted the Güver & Özel (2009) relation only for solar metallicity.

Open with DEXTER

There are several striking differences that must be noted. First of all, as discussed earlier, at low gas surface density the relations derived in this paper are asymptotically constant in the typical range 1.5 ≲ τFUV ≲ 4.5. The relations from Guiderdoni & Rocca-Volmerange (1987) or Güver & Özel (2009) instead fall linearly to τFUV = 0 as ΣH → 0 because these relations are calibrated along a set of individual line-of-sights in the Local Group, with an actual geometry that is close to the assumed screen geometry, without any mixing between different regions. Conversely, the relations derived in this paper are based on large regions in galaxies and, naturally, undergo a strong mixing between high and low gas surface density regions that have a different face-on optical depth (Sect. 5.2). The difference at low column density shows in particular the expected effect of mixing compared to classically used relations; at zero metallicity τFUV = 0 for all relations. The second feature we can note is that as the gas surface density increases, the metallicity-dependent relation of Guiderdoni & Rocca-Volmerange (1987) yields, for the same metallicity, higher optical depths. Once again, the empirical relations obtained in this paper more naturally take into account the complexity of the galaxies, which we see makes dust less efficient at attenuating stellar radiation than the relation of Guiderdoni & Rocca-Volmerange (1987).

9. Impact on galaxy formation and evolution

The study of the LFs is one of the main tools for understanding galaxy formation and evolution, either through observations or models. It is therefore important to understand the exact impact of the new relations we have derived in this paper on LFs output from SAMs. As mentioned in Sect. 1, UV LF obtained from hydrodynamical simulations can be sensitive to the way the attenuation is computed (Finlator et al. 2006; Fontanot et al. 2009b; Gonzalez-Perez et al. 2013) To understand the impact of different gas-attenuation prescriptions on models, we examine here how such relations would affect UV and IR LFs derived from cosmological simulations, as these are among the main targets for applying such relations. To do so we exploit the catalogue of galaxies of Guo et al. (2011) which is based on the Millennium (Springel et al. 2005) and Millennium-II (Boylan-Kolchin et al. 2009) simulations.

9.1. Sample and observational parameters

Before computing LFs we need to select a sample of galaxies from the simulated catalogue, and to derive their observational parameters such as the mean gas surface density or the UV and IR luminosities. The objective is to test the relative effect of different attenuation-gas surface density relations, but not to constitute highly accurate LFs in an absolute way, therefore the UV and IR luminosities will be built from relations widely used in the literature that we will describe hereafter. The reproducibility of local LFs is discussed in Appendix H.

As a first step, we select all star-forming galaxies (SFR > 0) at z = 0 from the Guo et al. (2011) catalogue, which yields a sample of 708 005 galaxies out of a full catalogue of 13 191 859 galaxies.

For each galaxy the Guo et al. (2011) catalogue provides the cold gas mass in units of 1010 M/h, and the size of the gas disk in units of Mpc/h, which is defined as 3 times the scale length, assuming an exponential disk, which is similar to the way we have determined the disk sizes for sample B. We assume h = 0.73 to follow the parameters used for the simulation (Boylan-Kolchin et al. 2009). We compute the mean gas surface density simply by dividing the cold gas mass by the disk area.

To compute the attenuation in the FUV band, we use the relations between the face-on optical depth and the gas surface density determined for sample A. The inclination of each galaxy is drawn randomly from a uniform distribution between 0° and 80°. As the catalogue of Guo et al. (2011) does not directly provide an estimate of the metallicity, we compute the oxygen abundance using the stellar mass-metallicity relation of Kewley & Ellison (2008) adapted for the Zaritsky et al. (1994) scale.

Ideally, the FUV luminosity could be determined from the SFH of each galaxy. Unfortunately, the sampling in redshift is too sparse to trace accurately the variations of the SFH over the sensitivity timescale of the FUV. As a consequence, to compute the FUV luminosity, we assume that the FUV contamination from previous star formation episodes is small and therefore that it traces the current star formation. Following Murphy et al. (2011), if we assume that galaxies have been forming stars at a constant rate over the last 100 Myr and follow a Kroupa (2001) IMF, we find (19)with L(FUV) the FUV luminosity in L, and the SFR in M yr-1. The use of another relation, such as the one of Salim et al. (2007) for instance, would yield slightly different FUV luminosities but would not affect the results. The IR luminosity can be determined from a relation between the UV-to-IR luminosity ratio (IRX), and the attenuation. Several of such relations have been published based on local star-forming galaxies. They yield very similar results (Boquien et al. 2012). We adopt the formula determined by Buat et al. (2005)(20)with x ≡ log L(IR)/L(FUV). To retrieve the value of L(IR), we simply invert this equation numerically. Because galaxies are mostly optically thin in the mid- and far-IR, the IR emission does not depend on the inclination of the galaxy. We therefore determine the value of L(IR) for an AFUV calculated for a face-on observer.

9.2. Impact of relations between the face-on optical depth and the gas surface density

To evaluate the impact of different relations between the face-on optical depth and the gas surface density, in Fig. 12 we compare the FUV and IR LFs derived for the relation we derived for sample A (Eqs. (12) and (13)) to the relation presented in Guiderdoni & Rocca-Volmerange (1987); Devriendt et al. (1999). In this section we select only galaxies that have 8.5 < log M   < 11 because the stellar mass-metallicity relation of Kewley & Ellison (2008) is valid only in this range, reducing the catalogue to 54 716 objects. This does not affect our results as we only examine here the relative variations on LFs induced by different relations.

thumbnail Fig. 12

Top: FUV LFs derived following the method outlined in Sect. 9.1. The black lines represent the LFs when using the gas surface density versus the attenuation relation of Guiderdoni & Rocca-Volmerange (1987); Devriendt et al. (1999), whereas the blue lines represent the LFs when using the relations presented in the current paper, assuming a slab geometry. For both relations, the solid line represents a relation parameterised only on the gas surface density, whereas the dashed lines represent relations paramaterised both on the gas mass surface density and the oxygen abundance. Bottom: IR LF, the red lines represent the use of the relations derived in this paper.

Open with DEXTER

There are several striking features. First of all, the use of a metallicity-dependent estimator can make a large difference. For instance, when selecting bright galaxies that have M(FUV) <  − 18, taking the metallicity into account systematically lowers the counts in each bin by  − 0.19 ± 0.22 dex on average for the relation of Guiderdoni & Rocca-Volmerange (1987); Devriendt et al. (1999) and increases by 0.21 ± 0.14 dex for our relations (Eqs. (12) and 13). For fainter galaxies with M(FUV) ≥  − 18, even if the number counts are left nearly unchanged, the values are  − 0.00 ± 0.01 dex and  − 0.00 ± 0.08 dex, respectively. There is a change of behaviour around M(FUV) =  − 14.5. Fainter than this threshold the number counts are lower with the metallicity-dependent relation and higher when brighter than this threshold. A difference in the number counts between metallicity-independent and metallicity-dependent relations is seen for the IR LFs. This shows the importance of taking the metallicity explicitly into account, especially when studying the bright end of the LFs. When considering different metallicity-dependent relations between the gas surface density and the attenuation, we see that there are again significant differences that affect the overall LFs. The peak difference for UV bright galaxies reaches nearly 0.6 dex. Conversely in the IR, the difference in number counts remains small.

To ensure that these results are not affected by the 0.2 mag width of the bins (smaller bins are more affected by random sampling effects), we have also examined the FUV LFs using a bin width of 0.5 mag. This size is similar to that of the observed FUV LF published by Wyder et al. (2005). We find that the previous results remain unaffected by an increase of the FUV bin width to 0.5 mag.

These results are in line with those obtained by Fontanot et al. (2009b) and show the significant impact the relation between the gas surface density and the face-on optical depth can have on the predicted LFs with peak differences in counts reaching about 1 dex.

10. Summary and conclusions

In this paper we have studied a sample of 4 resolved galaxies, and a sample of 27 unresolved galaxies to determine new but still simple relations between the gas surface density and the face-on optical depth at kpc scales, while also taking into account the effect of the metallicity.

To do so, we have determined the gas mass surface density from HI and CO observations. At the same time, we have determined the face-on optical depth in two steps.

  • 1.

    We have determined the attenuation for each pixel in theresolved galaxies and for each unresolved galaxy using theCIGALE SED fitting code, which is based on an energy balanceprinciple between the attenuation in the UV-optical domain andthe emission of the dust in the FIR.

  • 2.

    From the attenuation, we have determined the face-on optical depth assuming a slab geometry.

We have then determined new relations between the gas surface density, and the face-on optical depth in resolved galaxies, taking into account the metallicity indirectly by way of only metallicity-dependent XCO and gas-to-dust mass ratios, or also adding an explicit parameterisation. We have found that for galaxies with an inclination no larger than 50°, the assumptions made on the geometry have little impact on the derived attenuation. For larger inclinations, deviations over 30% can be found, depending on the geometry. We can summarise our main findings as following:

  • 1.

    The attenuation seems to take place primarily in regions thathave a high molecular fraction, which is consistent with the factthat star-forming regions are more attenuated than morequiescent ones.

  • 2.

    The attenuation and the gas column density are affected differently by the averaging between different regions within a given resolution element in galaxies. This mixing effect strongly affects the relation between the face-on optical depth and the gas surface density, in particular in regions with a low surface density. This shows that oft-used relations calibrated in the Milky Way are not adapted for use on large areas in galaxies or even entire galaxies.

  • 3.

    Unsurprisingly the impact of the metallicity is very significant, even for nearby spiral galaxies whose metallicity range is not extreme. As such it should be taken into account whenever possible.

  • 4.

    Relations between the gas surface density and the face-on optical depth derived on resolved galaxies are able to reproduce the trend for unresolved galaxies despite the scale difference of these objects and the intrinsic difficulty to measure reliably the total gas surface density in unresolved galaxies.

  • 5.

    There is both a significant scatter around the best-fit and galaxy-to-galaxy variations. This shows that there are additional physical parameters governing the relation between the face-on optical depth and the gas surface density.

  • 6.

    The new relations have a visible impact on LFs from the Millennium-II simulation when compared to the frequently-used relation of Guiderdoni & Rocca-Volmerange (1987) and Devriendt et al. (1999). This is especially visible at the bright end, and could therefore have a significant impact on the study of galaxy evolution through the use of large cosmological simulations combined with SAMs.

Finally, to compute the attenuation from the gas surface density in practice, we recommend applying the method laid out in Sect. 7. We remind the readers that if another geometry is assumed, the lead author of this paper should be contacted for the relations adapted to the geometry used.


2

If another geometry is adopted, please contact the lead author of this paper to obtain updated relations applicable to this geometry.

Acknowledgments

Herschel is an ESA space observatory with science instruments provided by European-led Principal Investigator consortia and with important participation from NASA. SPIRE has been developed by a consortium of institutes led by Cardiff University (UK) and including Univ. Lethbridge (Canada); NAOC (China); CEA, LAM (France); IFSI, Univ. Padua (Italy); IAC (Spain); Stockholm Observatory (Sweden); Imperial College London, RAL, UCL-MSSL, UKATC, Univ. Sussex (UK); and Caltech, JPL, NHSC, Univ. Colorado (USA). This development has been supported by national funding agencies: CSA (Canada); NAOC (China); CEA, CNES, CNRS (France); ASI (Italy); MCINN (Spain); SNSB (Sweden); STFC (UK); and NASA (USA). The Millennium-II Simulation database used in this paper and the web application providing online access to them were constructed as part of the activities of the German Astrophysical Virtual Observatory. This research has made use of the NASA/IPAC Extragalactic Database (NED) which is operated by the Jet Propulsion Laboratory, California Institute of Technology, under contract with the National Aeronautics and Space Administration. The research leading to these results has received funding from the European Community’s Seventh Framework Programme (/FP7/2007-2013/) under grant agreement No 229517.

References

Online material

Appendix A: The combination of FUV and dust emission as a proxy to the attenuation

While we have shown in Sect. 3.1.2 that the determination of the FUV attenuation with CIGALE is reliable, we examine here whether and how the results we have obtained are affected by using an alternative method for computing the attenuation and therefore the face-on optical depth. Several relations exist in the literature to quantify the attenuation from the FUV and the emission of the dust. These relations have generally been derived from the observation of unresolved star-forming galaxies (Cortese et al. 2008; Buat et al. 2011b; Hao et al. 2011). Boquien et al. (2012) have also derived a similar relation but on subregions in star-forming galaxies using CIGALE. Even though it yields attenuations close to that of previous relations, we do not consider it here as it has also been determined using CIGALE. Among the relations from the literature, Boquien et al. (2012) found that the one provided by Hao et al. (2011) yields the largest difference with the attenuation determined with CIGALE in resolved galaxies: ⟨ΔAFUV⟩ = 0.156 ± 0.056 mag. We therefore adopt this relation, as it will be indicative of the maximum deviation that could be induced by such an attenuation tracer compared to SED modelling. In Fig. A.1, we present the relations between the gas surface density and the FUV face-on optical depth determined from the formula published in Hao et al. (2011), assuming a slab geometry.

thumbnail Fig. A.1

Face-on optical depth in the FUV band determined from the FUV and dust emission (Hao et al. 2011) versus the atomic total gas mass surface density in units of M pc-2.

Open with DEXTER

We see that using an alternative method for determining the attenuation leaves the relations qualitatively unchanged. After verification, the relations provided by Cortese et al. (2008) and Buat et al. (2011b) show little qualitative difference from the relation of Hao et al. (2011). However, the lower attenuations yielded by the relation of Hao et al. (2011) naturally affect the quantitative relations between the face-on optical depth and the gas surface density (A.1)and (A.2)These relations yield smaller optical depths. Averaging over the entire sample, we obtain ⟨ΔτFUV/τFUV⟩ = 0.02 ± 0.04 when taking only the gas surface density into account, and ⟨ΔτFUV/τFUV⟩ = 0.10 ± 0.07 when taking into account both the gas surface density and the metallicity. The amplitude of these shifts is not larger than the error bars on the optical depths deduced from the uncertainties on the FUV attenuation provided by CIGALE. Therefore the use of different methods for determining the attenuation should only have a limited impact on the derived optical depth, with offsets of the order of 10%.

Appendix B: Dust emission as a proxy to the gas surface density

If the 21 cm emission is a direct tracer of the atomic gas, as mentioned earlier, the molecular gas is generally traced indirectly through CO emission. An alternative way to measure the total gas content in a galaxy is through the emission of the dust. As gas and dust are intimately intertwined, assuming a given gas-to-dust mass ratio one can retrieve the gas mass from the dust mass. Both methods have different biases. Whether the gas mass determination method affects our results or not is important to estimate their reliability.

One common method for determining the dust mass is to fit the FIR emission with a modified black body (e.g. Boselli et al. 2002; James et al. 2002; Eales et al. 2010, 2012,and many others). It is described in Eq. (B.1) (B.1)with fν the flux density, D the distance of the object, h the Planck constant, ν the frequency, c the speed of light in vacuum, k the Boltzmann constant, T the temperature of the dust, κ the dust emissivity taken at frequency νκ, β the emissivity index, and Mdust the dust mass. Following Draine (2003a) we adopt κ = 0.192 m2 kg-1 at νκ = 857 GHz (350 μm). The value of β is the subject of an intense debate in the literature. A value between 1.5 and 2.0 is adequate for star-forming galaxies. Even though β can vary from region to region (Smith et al. 2012), Boselli et al. (2012) found that β = 1.5 best reproduces the FIR properties of the star-forming galaxies in the HRS sample. We therefore adopt their value. Note, however, that this emissivity has been determined from a dust model that assumes β = 2 rather than β = 1.5, which may induce a bias in the dust mass. We determine the dust mass by fitting Eq. (B.1) to the data at 70 μm, 250 μm, and 350 μm, using the curve_fit function in the scipy library (Jones et al. 2001), which is based on a Levenberg-Marquardt algorithm. This combination of bands allows us to get a good handle on the dust temperature because these bands straddle the FIR emission peak, and the dust mass as the 350 μm band does not show a strong dependence upon temperature variations. In the case of NGC 2403, the 70 μm emission comes from a distinctly different dust component rather than the dust emitting at longer wavelength. As a consequence, the dust mass within this galaxy will be underestimated. In Fig. B.1, we compare the gas mass estimated from the dust mass, versus the one derived from HI and CO emission. In both cases we use the metallicity-dependent conversion factors of Boselli et al. (2002) which assumes a gas-to-dust mass ratio of 160 for 12 + log O/H = 8.91.

thumbnail Fig. B.1

Total gas surface density derived from a modified black-body fit (Eq. (B.1)) of the FIR data from 70 μm to 350 μm versus the total gas surface density derived from the combination of HI and CO observations. The colour of each dot indicates the metallicity indicated by the scale on the right. The black lines show the 1-to-1 relation between these quantities.

Open with DEXTER

We see that there is a tight correlation between the total gas surface density derived with a modified black body and from the combination of HI and CO observation as shown by the high value of the Spearman correlation coefficient for NGC 2403 (ρ = 0.79), NGC 4254 (ρ = 0.95), NGC 4321 (ρ = 0.96), and NGC 5194 (ρ = 0.95). We observe that the surface densities obtained using either method are similar even though there are some small offsets, generally towards lower masses except for NGC 2403. However, they are small compared to the full dynamical range.

To verify whether determining the total gas surface density affects the results, we plot in Fig. B.2 the relation between the face-on optical depth and the total gas surface density derived from a modified black body fit.

thumbnail Fig. B.2

Face-on optical depth in the FUV band versus total gas surface density determined by fitting the FIR emission with a modified black body as described in Eq. (B.1).

Open with DEXTER

When comparing this to Fig. 7, we see that the results are very similar. The Spearman correlation coefficients for NGC 4254, NGC 4321, and NGC 5194 yield values close to what is found when combining CO and HI observations. However, in the case of NGC 2403 there is a significant decrease from ρ = 0.72 to ρ = 0.45. This could be due to the lower metallicity of this galaxy (⟨12 + log O/H⟩ = 8.90) compared to the rest of the sample (⟨12 + log O/H⟩ = 9.20). As such there could be a significant quantity of dark molecular gas not traced by CO. Quantitatively, the relations we derive are close to Eqs. (12) and (13) (B.2)and (B.3)These relations yield similar optical depths. Averaging over the entire sample, we obtain ⟨ΔτFUV/τFUV⟩ = 0.09 ± 0.05 when taking only the gas surface density into account, and ⟨ΔτFUV/τFUV⟩ =  − 0.02 ± 0.06 when taking into account both the gas surface density and the metallicity. The amplitude of these shifts is not larger than the error bars on the optical depths deduced from the uncertainties on the FUV attenuation provided by CIGALE. Therefore the use of different methods for determining the gas surface density should only have a limited impact on the derived face-on optical depth, with offsets of the order of 10%.

Appendix C: Computation of the HI surface density

In Sect. 3.2 we provide a relation to compute the HI mass surface density. It is derived in the following way. First we consider this well-known relation linking NHI, the HI column density in atoms cm-2, to the brightness temperature TB in K (C.1)with ΔV in m s-1. Considering that 1 M pc-2 = 1.248 × 1020 atoms cm-2, we have (C.2)The brightness temperature and the flux density per beam are related through the following equation (C.3)with P the angular power pattern of the beam, dΩ the solid angle, and mb denoting the main beam. For a Gaussian beam with a full width half maximum size Δα and Δδ along the major and minor axes, it easily comes that (C.4)Combining the two previous equations we get (C.5)Inserting this relation into Eq. (C.2) (C.6)Assuming that Δα and Δδ are expressed in arcsec, Si in Jy per beam, and ΔV in m s-1, a simple numerical application yields (C.7)

Appendix D: Impact of different CO transitions

As explained earlier, to trace the molecular gas this study relies on the CO(2 − 1) transition. Yet different transitions may yield different results. The intensity of the emission of the various CO transitions depends not only on the abundance of CO but also on the local physical conditions of the molecular gas, such as the density or the temperature. For a given quantity of CO, a high-level transition will trace more closely the denser and warmer part of the gas. Disentangling between these effects is particularly challenging and would require a dedicated study of the sample with appropriate data. Here, we do not attempt to separate these parameters; instead, we examine whether and how using different transitions would affect our results.

To complement our CO(2 − 1) data, we need additional transitions at a resolution that is similar or better than 30′′. This is a particularly limiting factor because CO(1 − 0) observations have a resolution twice as coarse as that of CO(2 − 1) for a given instrument. For higher order transitions, such as CO(3 − 2), observations are difficult to carry out as they require optimal atmospheric conditions. Nevertheless, 3 galaxies in our sample have adequate CO(3 − 2) maps to further our study. As part of the JCMT Nearby Galaxies Legacy Survey (Wilson et al. 2009), Bendo et al. (2010) published a CO(3 − 2) map of NGC 2403, and Wilson et al. (2009) maps of NGC 4254 and NGC 4321. For NGC 5194, Koda et al. (2011) have published a high-resolution single-dish CO(1 − 0) map which we adopt. Additional CO(1 − 0) observations of several galaxies in the sample have been published by Kuno et al. (2007). Unfortunately, their 15′′ beam is not Nyquist-sampled which makes the maps unsuitable for a pixel-by-pixel analysis. In Fig. D.1 we present the molecular gas surface density derived from the baseline CO(2 − 1) observations and the CO(3 − 2) ones (CO(1 − 0) for NGC 5194). Note that we divided our CO(2 − 1) intensities by a factor of 0.89 to scale them to the CO(1 − 0) line. We also scaled the CO(3 − 2) observations to CO(1 − 0) by dividing the intensities by a factor of 0.34 (Wilson et al. 2009).

thumbnail Fig. D.1

Molecular gas surface densities computed from CO(3 − 2) observations (CO(1 − 0) for NGC 5194) versus the molecular gas surface densities computed from the CO(2 − 1) transition. All CO lines have been scaled to the CO(1 − 0) line in order to apply the same XCO factor. The black line represents the 1-to-1 relation where both lines yield the same molecular gas surface densities.

Open with DEXTER

Visibly there is a strong correlation between CO(2 − 1) and other CO lines, with the Spearman correlation coefficient ranging from ρ = 0.68 for NGC 2403 to ρ = 0.96 for NGC 5194. In Fig. D.2 we plot the relation between the face-on optical depth and the gas mass surface density.

thumbnail Fig. D.2

Same as for Fig. 3 with the molecular gas surface density determined from the CO(3 − 2) line (CO(1 − 0) for NGC 5194).

Open with DEXTER

We see that qualitatively the use of different CO transitions does not affect the global trends between these quantities and that the qualitative relations remain unchanged. We note, however, that there are far fewer datapoints for NGC 5194, which makes the flattening at low surface densities less evident. After inspection of the images, these are regions on the outskirts of the galaxy which are not in the field-of-view of the CO(1 − 0) map and have therefore been eliminated from the analysis. We should note that as commented by Wilson et al. (2009) and Bendo et al. (2010), there is a significant scatter in the ratio between the CO(3 − 2) line and lower CO transitions. It has been suggested that the CO(3 − 2) line is more closely associated with molecular gas fueling star formation than lower order lines, which may contribute to the pixel-to-pixel scatter.

Quantitatively, the relations we derive are close to Eqs. (12) and (13) (D.1)and (D.2)These relations yield similar optical depths. Averaging over the entire sample, we obtain ⟨ΔτFUV/τFUV⟩ = 0.08 ± 0.05 when taking only the gas surface density into account, and ⟨ΔτFUV/τFUV⟩ = 0.05 ± 0.04 when taking into account both the gas surface density and the metallicity. The amplitude of these shifts is not larger than the error bars on the optical depths deduced from the uncertainties on the FUV attenuation provided by CIGALE. Therefore, the use of different CO transitions to determine the gas surface density should only have a limited impact on the derived face-on optical depth, with offsets of the order of 10%.

Appendix E: Relation with the molecular fraction

Whether the attenuation chiefly takes place in HI or H2 dominated regions gives us an interesting insight into radiation transfer in galaxies. In Fig. E.1 we show the FUV attenuation versus the molecular fraction.

thumbnail Fig. E.1

Relation between the molecular gas fraction and the attenuation. There is a clear trend, with increasing molecular fraction the attenuation increases, with the exception of NGC 2403 which shows no trend. This is consistent with the trends observed in Fig. 3. The number of elements and the Spearman correlation coefficient are indicated at the bottom of each panel whereas the uncertainty on AFUV is shown in the bottom-right corner.

Open with DEXTER

The regions that have a low molecular fraction generally correspond to peripheral regions. In the case of NGC 2403 we do not see any trend of the attenuation with the molecular fraction. Conversely the other three galaxies show two regimes. Up to a molecular fraction of 0.6 − 0.8, there is little to no trend, the attenuation remaining constant. Beyond this limit, the attenuation strongly increases with the molecular fraction. This suggests that where the molecular fraction is high, the attenuation is strongly linked to the quantity of molecular gas. At lower molecular fraction it is possible that the atomic gas plays a larger role in the attenuation. However, there could also be mixing effects if the FUV attenuation is driven by regions more closely linked to molecular gas even in low-density regions. We examine this possibility in more detail in Sect. 5.2.

Appendix F: Impact of the geometry

F.1. Attenuation-optical depth relations

For this study, we have adopted a slab geometry. However, as mentioned in Sect. 5.1, other geometries can also be considered. First of all, we examine the case of a sandwich model. Following Boselli et al. (2003), the relation between the face-on optical depth τλ and the attenuation is (F.1)with ζ the height ratio between the dust and stars layers. Boselli et al. (2003) provide the following calibration based on observations (F.2)with λ the wavelength in m. For the FUV band at 151.6 nm, ζ ≃ 1.0033. When ζ = 1, Eq. (F.1) is identical to the slab case (Eq. (8)). As we limit the computation of the face-on optical depth to the FUV band (see Sect. 7 for the extension to other wavelengths), we will not discuss the sandwich geometry further.

We also consider the case where dust is concentrated into clumps that are distributed following a Poisson distribution. In this case the relation between the attenuation and the optical depth is

(F.3)with the average number of clouds along the line of sight, and τλc the optical depth of an individual cloud.

In Fig. F.1, we compare the effective attenuation for various geometries, versus the mean optical depth .

thumbnail Fig. F.1

Attenuation versus the mean optical depth at a given wavelength λ, for a face-on galaxy with a slab geometry (solid black line), and a clumpy geometry assuming a mean number of clouds on the line of sight of 1 (blue), 2 (green), 3 (red), or 4 (cyan). A simple screen geometry is also shown for reference (dashed black line). For simplicity, we have not taken into account the effect of the albedo in this plot; that is, we have assumed that ωλ = 0.

Open with DEXTER

At low mean optical depths, all geometries yield the same attenuation. This means that the actual distribution of the dust, slab, clumpy, or even screen has little impact on the effective attenuation. However, from an optical depth of unity, there is a strong divergence. For a slab geometry (solid black line in Fig. F.1), , whereas in the case of a clumpy distribution, , when . As a consequence, in the latter case the resulting attenuation curve becomes more grey as the optical depth increases. As we see, in the case of a distribution of very opaque clumps, the maximum attenuation is directly determined by the number of clumps and not by the optical depth of individual clouds.

F.2. Gas surface density and the optical depth for different geometries

We compute the relation between the gas surface density and the face-on optical depth for screen, and clumpy geometries to understand the impact of the assumed geometries on these relations.

If we assume that all galaxies in the sample have the same average number of clumps along the line of sight, we need to be able to reproduce the observations. This is slightly larger than what was found by Holwerda et al. (2007) for a sample of 14 disk galaxies in the nearby Universe (). Considering and , we find the following relations between the optical depth and the gas surface density (F.4)and (F.5)for , and (F.6)and (F.7)for .

When we compare Eqs. (12) to (F.4) or (F.6), it yields very different optical depths. For instance, if we assume ΣH = 10 M pc-2, τFUV = 3.426 for a slab geometry and τFUV = 1.988 for a clumpy geometry with , reaching τFUV = 15.715 and τFUV = 6.704 respectively for ΣH = 100 M pc-2. This exemplifies strongly the model-dependence of such relations. In order to avoid biases, it is particularly important to use the same geometry when computing the attenuation as the one that was assumed for the relation between the gas surface density and the optical depth.

Appendix G: Inversion of the relation between the attenuation and the face-on optical depth for a slab geometry

In Sect. 5.1 we introduced the Lambert W function to express the face-on optical depth as a function of the attenuation (Eq. (9)). We indicate here how we have derived this equation and how the Lambert W function was introduced. First of all, we consider the equation we want to invert (G.1)Let . We easily get Using the W Lambert function, which gives the invert relation of , this is equivalent to (G.6)Redeveloping τ′ and rearranging slightly we obtain the final relation (G.7)

Appendix H: On the reproducibility of local LFs

As stated before, the aim of this exercise is not to reproduce exactly the LFs of nearby galaxies but to examine the impact of different gas surface density attenuation relations. Several intrinsic aspects of the simulations tend to incur biases affecting the LFs.

A first well-known problem is that semi-analytic relations can yield too much gas compared to what is observed in the local universe. To correct for this effect, following Obreschkow et al. (2009), we rescale the gas mass in each galaxy so that the total cold gas mass density at z = 0 is consistent with the value derived by Obreschkow & Rawlings (2009), with normalised to the critical density for closure (H.1)H being the Hubble constant, and G the gravitational constant. For H = 73 km s-1 Mpc-1, ρcrit = 1.0 × 10-26 kg m-3. We then rescale the cold gas masses from the simulation by multiplying them by the factor ξ-1, with ξ defined as (H.2)with the mean gas mass density of the simulation over the entire volume. We find that  kg m-3, leading to ξ = 1.5. This is very similar to the factor 1.45 found by Obreschkow et al. (2009) for the De Lucia & Blaizot (2007) catalogue which was based on the Millennium simulation. In Fig. H.1, we show the Millennium-II cold gas mass luminosity.

thumbnail Fig. H.1

Mass function of the cold gas mass of the Millennium-II simulation (black lines), uncorrected (dashed line), and corrected (solid) for the mass excess. For comparison, the observed cold gas mass function derived by Obreschkow & Rawlings (2009) is shown in red. All functions have been rescaled to h = 0.73, following the Millennium-II simulation parameters (Boylan-Kolchin et al. 2009).

Open with DEXTER

At high mass, the model slightly underestimates the cold gas mass function compared to the observed one by Obreschkow & Rawlings (2009). Conversely, there is a very large excess of galaxies with a lower mass of gas, up to about 1 dex for log M(H) = 7.0.

The SFR distribution function, which is not affected by the attenuation, can also be compared to the observed functions in the local Universe.

thumbnail Fig. H.2

SFR function of the Millennium-II simulation (black line). For comparison, the Martin et al. (2005) function (cyan), the IR (red), and UV (blue) selected Buat et al. (2007) functions, and the Bothwell et al. (2011) functions observed in the local universe have also been plotted. All functions have been scaled to h = 0.73 and to a Chabrier (2003) IMF.

Open with DEXTER

In Fig. H.2, we show the observed SFR distribution functions of Martin et al. (2005),

Buat et al. (2007), and Bothwell et al. (2011). It turns out that the simulated SFR distribution function does not convincingly reproduce any of them. At the same time, there are significant differences among them. The difference is the smallest at relatively high SFR, but the difference rapidly increases under SFR = 10 M yr-1, at the level of the “knee” of the distribution. For an SFR < 1 M yr-1, the simulated SFR distribution function presents a much flatter slope than the observed ones. At the same time, Guo et al. (2011) remarked that the Millennium-II simulation produces a large fraction of non-star-forming dwarf galaxies compared to what is observed. This dearth of star-forming galaxies combined with the effect of the SFH  −  dwarf galaxies tend to have a more bursty SFH than large spirals which form stars at a steady rate  −  could explain this flattening of the slope. At optical and NIR wavelengths which are increasingly less sensitive to the exact SFH, this problem has a much weaker impact. Guo et al. (2011) showed that the Millennium-II simulations can reproduce convincingly the SDSS LFs derived by Blanton et al. (2005) in the g′, r′, i′, and z′ bands. However, in the star-formation tracing bands, these departures from the observed SFR distribution functions indicate that because we derive the extinction-free UV luminosity of each galaxy from the SFR as we saw in Sect. 9.1, we cannot compare directly our simulated UV and IR LFs with the observed ones. This is the reason why we do not attempt to carry out a comparison between our LFs and the observed ones.

All Tables

Table 3

Origin of the selected data.

Table 4

List of CIGALE parameters.

All Figures

thumbnail Fig. 1

Comparison between observed and modelled flux ratios. The shade of the grey hexagons represents the logarithm of the density of models, with a darker shade indicating a higher number of models in the bin. The observed fluxes are indicated by circles, the colour depending on the galaxy. The median error bars including systematic uncertainties are shown on the upper-left side of the plots. The left plot shows the r′/NUV versus NUV/FUV flux ratios and the right plot shows the 70/FUV versus r′/NUV flux ratios.

Open with DEXTER
In the text
thumbnail Fig. 2

Attenuation derived from the analysis of the probability distribution function performed with CIGALE versus the true value for artificial regions in galaxies, in order to test the accuracy of the modelling. In each quadrant we indicate the number of data points N, the Spearman correlation coefficient ρ at the top, and the scatter of the relative difference in the attenuation at the bottom. The solid black line indicates the 1-to-1 relation. The error bar on the left indicates the median uncertainty as computed from the analysis of the probability distribution function. For consistency with the analysis carried out later in this paper, we have only selected datapoints with a good best fit (χ2 < 2). The left panel describes the FUV-band attenuation whereas the right one describes the V-band attenuation.

Open with DEXTER
In the text
thumbnail Fig. 3

Attenuation in the FUV band versus the atomic (top), molecular (middle), and total (bottom) gas mass surface density in units of M pc-2 for individual regions in galaxies (sample A). Each data point corresponds to a single pixel which has been detected at a 3-σ level from the FUV to the FIR. No selection has been applied on CO and HI data. Data points with a poor fit (χ2 ≥ 2) have also been removed. At the bottom of each panel we display the number of selected pixels N and the Spearman correlation coefficient ρ. Finally, the median uncertainty on AFUV computed by CIGALE is indicated in the bottom-right corner.

Open with DEXTER
In the text
thumbnail Fig. 4

Ratio of the FUV attenuation obtained from a relation for a given geometry to the attenuation for a slab geometry versus the gas surface density. We assume an inclination of 45°, corresponding to the mean of datapoints in sample A, which is necessary to compare adequately with relations for clumpy geometries, as the number of clumps can vary according to the inclination.

Open with DEXTER
In the text
thumbnail Fig. 5

Ratio of the FUV attenuation assuming screen and slab geometries. The inclination angle varies from 0° (blue) to 90° (red).

Open with DEXTER
In the text
thumbnail Fig. 6

Face-on optical depth in the FUV band versus the total gas mass surface density in units of M pc-2 for a slab geometry, and assuming a metallicity-independent XCO factor. The blue curves represent the best fit for the full sample whereas the black curves represent the best fit for individual galaxies for which the equation is given at the top of each panel. The uncertainties on τFUV are indicated by the error bar at the bottom right of each panel.

Open with DEXTER
In the text
thumbnail Fig. 7

Face-on optical depth in the FUV band versus the total gas mass surface density in units of M pc-2. The colour of each point indicates the oxygen abundance determined from the gradients published by Zaritsky et al. (1994). The black line represents the best fit for the entire sample (Eq. (12)) when taking into account a metallicity-dependent XCO factor (Eq. (11)). The coloured lines represent the best fit for the entire sample (Eq. (13)) for different values of 12 + log O/H, when fitting the gas column density and the oxygen abundance simultaneously. At the top of each panel the number of datapoints and the Spearman correlation coefficient is indicated.

Open with DEXTER
In the text
thumbnail Fig. 8

FUV face-on optical depth computed with Eq. (12) taking into account the gas surface density (green dots), and Eq. (13) taking into account the gas surface density and the metallicity (red dots), versus the measured face-on optical depth from the attenuation provided by CIGALE and an assumed geometry. The black line represents to 1-to-1 relation.

Open with DEXTER
In the text
thumbnail Fig. 9

Same as Fig. 3 for sample B.

Open with DEXTER
In the text
thumbnail Fig. 10

Relation between the FUV face-on optical depth and the gas surface density for unresolved galaxies (black circles with error bars). The blue line corresponds to the best linear fit for the unresolved sample. The corresponding relation is indicated at the top of the figure, along with the number of elements and the Spearman correlation coefficient. The black dashed line corresponds to the relation for resolved galaxies when assuming a solar metallicity (Eq. (10)). The absence of metallicity estimates for a number of galaxies prevents us from using a metallicity-dependent XCO factor. The red dots represent the four galaxies in sample A, with the bars indicating the full dynamical range probed by each of them.

Open with DEXTER
In the text
thumbnail Fig. 11

Comparison of the relations between the face-on optical depth and the gas surface density obtained in this paper (solid lines, Eqs. (12) and (13)), with the relation from Guiderdoni & Rocca-Volmerange (1987) (dashed line), and with the relation from Güver & Özel (2009) (dotted line). The coloured lines show metallicity-dependent relations according to the oxygen abundance scale shown on the right. For clarity, we have plotted the Güver & Özel (2009) relation only for solar metallicity.

Open with DEXTER
In the text
thumbnail Fig. 12

Top: FUV LFs derived following the method outlined in Sect. 9.1. The black lines represent the LFs when using the gas surface density versus the attenuation relation of Guiderdoni & Rocca-Volmerange (1987); Devriendt et al. (1999), whereas the blue lines represent the LFs when using the relations presented in the current paper, assuming a slab geometry. For both relations, the solid line represents a relation parameterised only on the gas surface density, whereas the dashed lines represent relations paramaterised both on the gas mass surface density and the oxygen abundance. Bottom: IR LF, the red lines represent the use of the relations derived in this paper.

Open with DEXTER
In the text
thumbnail Fig. A.1

Face-on optical depth in the FUV band determined from the FUV and dust emission (Hao et al. 2011) versus the atomic total gas mass surface density in units of M pc-2.

Open with DEXTER
In the text
thumbnail Fig. B.1

Total gas surface density derived from a modified black-body fit (Eq. (B.1)) of the FIR data from 70 μm to 350 μm versus the total gas surface density derived from the combination of HI and CO observations. The colour of each dot indicates the metallicity indicated by the scale on the right. The black lines show the 1-to-1 relation between these quantities.

Open with DEXTER
In the text
thumbnail Fig. B.2

Face-on optical depth in the FUV band versus total gas surface density determined by fitting the FIR emission with a modified black body as described in Eq. (B.1).

Open with DEXTER
In the text
thumbnail Fig. D.1

Molecular gas surface densities computed from CO(3 − 2) observations (CO(1 − 0) for NGC 5194) versus the molecular gas surface densities computed from the CO(2 − 1) transition. All CO lines have been scaled to the CO(1 − 0) line in order to apply the same XCO factor. The black line represents the 1-to-1 relation where both lines yield the same molecular gas surface densities.

Open with DEXTER
In the text
thumbnail Fig. D.2

Same as for Fig. 3 with the molecular gas surface density determined from the CO(3 − 2) line (CO(1 − 0) for NGC 5194).

Open with DEXTER
In the text
thumbnail Fig. E.1

Relation between the molecular gas fraction and the attenuation. There is a clear trend, with increasing molecular fraction the attenuation increases, with the exception of NGC 2403 which shows no trend. This is consistent with the trends observed in Fig. 3. The number of elements and the Spearman correlation coefficient are indicated at the bottom of each panel whereas the uncertainty on AFUV is shown in the bottom-right corner.

Open with DEXTER
In the text
thumbnail Fig. F.1

Attenuation versus the mean optical depth at a given wavelength λ, for a face-on galaxy with a slab geometry (solid black line), and a clumpy geometry assuming a mean number of clouds on the line of sight of 1 (blue), 2 (green), 3 (red), or 4 (cyan). A simple screen geometry is also shown for reference (dashed black line). For simplicity, we have not taken into account the effect of the albedo in this plot; that is, we have assumed that ωλ = 0.

Open with DEXTER
In the text
thumbnail Fig. H.1

Mass function of the cold gas mass of the Millennium-II simulation (black lines), uncorrected (dashed line), and corrected (solid) for the mass excess. For comparison, the observed cold gas mass function derived by Obreschkow & Rawlings (2009) is shown in red. All functions have been rescaled to h = 0.73, following the Millennium-II simulation parameters (Boylan-Kolchin et al. 2009).

Open with DEXTER
In the text
thumbnail Fig. H.2

SFR function of the Millennium-II simulation (black line). For comparison, the Martin et al. (2005) function (cyan), the IR (red), and UV (blue) selected Buat et al. (2007) functions, and the Bothwell et al. (2011) functions observed in the local universe have also been plotted. All functions have been scaled to h = 0.73 and to a Chabrier (2003) IMF.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
