2D disc modelling of the JWST line spectrum of EX Lupi
^{1}
Space Research Institute, Austrian Academy of Sciences,
Schmiedlstr. 6,
8042
Graz, Austria
email: peter.woitke@oeaw.ac.at
^{2}
MaxPlanckInstitut für extraterrestrische Physik,
Giessenbachstrasse 1,
85748
Garching, Germany
^{3}
Kapteyn Astronomical Institute, University of Groningen,
PO Box 800,
9700 AV
Groningen, The Netherlands
^{4}
Konkoly Observatory, HUNREN Research Centre for Astronomy and Earth Sciences,
KonkolyThege Miklós út 15–17,
1121
Budapest, Hungary
^{5}
CSFK, MTA Centre of Excellence,
Konkoly Thege Miklós út 15–17,
1121
Budapest, Hungary
^{6}
ELTE Eötvös Loránd University, Institute of Physics,
Pázmány Péter sétány 1/A,
1117
Budapest, Hungary
^{7}
Max Planck Institute for Astronomy,
Königstuhl 17,
69117
Heidelberg, Germany
Received:
16
August
2023
Accepted:
28
November
2023
We introduce a number of improvements to the thermochemical disc modelling code PRODIMO and new theoretical approaches that can be used to better predict and analyse the JWST line spectra of protoplanetary discs. We developed a new line escape probability method for disc geometries, and a new scheme for dust settling, and discuss how to apply UV molecular shielding factors to photo rates in 2D disc geometry. We show that these assumptions are crucial for the determination of gas heating and cooling rates and discuss how they affect the predicted molecular concentrations and line emissions. We apply our revised 2D models to the protoplanetary disc around the T Tauri star EX Lupi in quiescent state. We calculate infrared line emission spectra between 5 and 20 µm from CO, H_{2}O, OH, CO_{2}, HCN, C_{2}H_{2}, and H_{2}, including lines of atoms and ions, using our full 2D predictions of molecular abundances, dust opacities, and gas and dust temperatures. We developed a disc model with a slowly increasing surface density structure around the inner rim that can simultaneously fit the spectral energy distribution, the overall shape of the JWST spectrum of EX Lupi, and the main observed molecular characteristics in terms of column densities, emitting areas, and molecular emission temperatures, which all result from one consistent disc model. The spatial structure of the lineemitting regions of the different molecules is discussed. High abundances of HCN and C_{2}H_{2} are caused in the model by stellar Xray irradiation of the gas around the inner rim.
Key words: astrochemistry / line: formation / methods: numerical / protoplanetary disks
© The Authors 2024
Open Access article, published by EDP Sciences, under the terms of the Creative Commons Attribution License (https://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
This article is published in open access under the Subscribe to Open model. Subscribe to A&A to support open access publication.
1 Introduction
Mediumresolution spectroscopy of protoplanetary discs with the Spitzer Space Telescope has revealed a dense forest of H_{2}O emission lines (Carr & Najita 2008; Salyk et al. 2008), in addition to overlapping line emission features from OH, C_{2}H_{2}, HCN, and CO_{2}. From the emission temperatures of these molecules, which are of a few hundred Kelvin to about 1000 K, and the derived sizes of the lineemitting areas, it was immediately clear that these molecular spectra probe the chemistry in the terrestrial planetforming regions; see for example the review by Pontoppidan et al. (2014). Over the past 15 yr, more than 100 Spitzer/IRS disc spectra have been analysed using simple slabmodels, which has revealed certain properties of these line emissions in terms of molecular column densities, emission temperatures, and line emission areas; see Pontoppidan et al. (2010); Carr & Najita (2011); Salyk et al. (2011). Some statistics are also available, and certain trends have been identified concerning the influence of the accretion luminosity, the disc mass, the depletion of molecules in discs with large inner dust cavities, and chemical differences as a function of stellar type; see, for example, Pascucci et al. (2013); Najita et al. (2013); Walsh et al. (2015); Banzatti et al. (2017).
However, the significance of these measured molecular properties, where in the disc these molecules are present, both radially and vertically, and how this all fits together are open questions. The slabmodels used for the analysis of the spectra do not provide such insights, and also have certain principle weaknesses, such as their inability to predict absorption lines, and an uncertainty as to how to include the effects of Keplerian broadening, continuous dust emission, and dust absorption under a given inclination angle.
Ultimately, we are seeking a higher level of understanding, and predictions of molecular emission features that are in accordance with the disc chemistry and the heating and cooling balance based on a model for the physical structure of the gas and dust in the disc that can predict the emission features of all molecules simultaneously. However, thermochemical disc models, such as those of Akimkin et al. (2013); Zhang et al. (2013); Walsh et al. (2015); Bruderer et al. (2015); Woitke et al. (2018a); Anderson et al. (2021), have yet to demonstrate that this is possible.
The puzzle of revealing the physical structure of the disc, which produces these emission lines, is complicated by the fact that we presently have little understanding of the element abundances of the gas in the inner disc. Indeed, there are very good reasons to assume that the transport of icy grains in the disc can profoundly change these element abundances during disc evolution (e.g. Ciesla & Cuzzi 2006). For example, pebble drift through the water snowline has been demonstrated in hydrodynamical disc models to increase the oxygen abundance in the inner disc (Bosman et al. 2017; Booth & Ilee 2019).
However, results from the Very Large Telescope (VLT)/MATISSE interferometer (Kokoulina et al. 2021) suggest that the dust in the inner 10 au of the disc around HD 179218 is carbonenriched in the form of nanocarbon grains. These conclusions are based on the spectral shape of the solid opacities. Studying new VLT/MATISSE and VLT/GRAVITY data of HD 144432, Varga et al. (accepted by A&A) concluded that most of the carbon in the inner disc is in the gas phase, whereas solid iron and FeS are the main sources of dust opacity at wavelengths in the L, M, and Nbands. Additional clues about element transport processes have been obtained by linking the midinfrared (MIR) line spectra to continuum images obtained with the Atacama Large Millimeter Array (ALMA). Expanding on earlier results from Najita et al. (2013), Banzatti et al. (2020) reported an anticorrelation between the infrared water line luminosity tracing the gas within a few astronomical units (au) and the distribution of solid pebbles at 10–200 au in discs. That is, radially compact discs show stronger water lines than large discs. Based on new James Webb Space Telescope (JWST) data, Banzatti et al. (2023) see more evidence for this anticorrelation. van ‘t Hoff et al. (2020) and Nazari et al. (2023) proposed that the inward transport and subsequent sublimation of carbonaceous dust grains and Polycyclic Aromatic Hydrocarbon molecules (PAHs) might enrich the inner disc with carbon.
New evidence for carbonrich/oxygenpoor inner discs has recently been found in the first published disc spectra obtained with the James Webb Space Telescope (JWST); see Kóspál et al. (2023); Grant et al. (2023); Tabone et al. (2023); Banzatti et al. (2023); Perotti et al. (2023). A rich hydrocarbon chemistry was identified by Tabone et al. (2023) in the inner disc around the M5star 2MASSJ160532151933159, with exceptionally optically thick C_{2}H_{2} emission features around 7 µm and 14 µm, which are so strong that they form a wide quasicontinuum with tens of thousands of overlapping weak lines, without detecting any water lines. This is very clear evidence for a strong oxygen depletion in the inner disc of this star. Tabone et al. (2023) also mention a carbonenrichment of the inner disc by the destruction of PAHs or carbonaceous grains as a possible cause for the large column densities of hydrocarbon molecules. However, this appears to be inconsistent with the very weak CO fundamental rovibrational lines as measured with JWST. To fit these lines, removal of the oxygen appears to be required, rather than enrichment of the carbon (Kanwar et al., in prep.).
In this paper, we take on the challenge of fitting the first publisheD JWST spectrum of a T Tauri star (Kóspál et al. 2023) using the 2D thermochemical disc model PRODIMO (Woitke et al. 2009, 2016). In Sect. 2, we report a number of important PRODIMO code changes that result in considerably improved predictions of the various MIR molecular emission features in general. In Sect. 3, we explain how we set up our disc model and how we fitted that model to the spectral energy distribution (SED) of EXLupi and its JWST/MIRI spectrum. Section 4 contains a thorough analysis of the bestfitting disc model in terms of the physical and chemical disc structure, including the calculated dust and gas temperatures. We also derive molecular column densities and emission temperatures from this model that can be compared to the values derived from slabmodels, and analyse the chemical pathways in the lineforming regions of the various molecules in this section. Our conclusions are presented in Sect. 5.
2 Code improvements
Woitke et al. (2018a) demonstrated the problems faced by current standard thermochemical models for T Tauri discs in explaining the approximately equally strong emission features of H_{2}O, CO_{2}, HCN, and C_{2}H_{2}. First, a regular gas/dust mass ratio of 100 generally results in overly weak MIR molecular emissions. Second, while the molecular emission features of H_{2}O and OH can be pushed to the observed flux levels using a larger gas/dust ratio of 1000 (Bruderer et al. 2015; Woitke et al. 2018a; Greenwood et al. 2019), the CO_{2} emission feature at 15 µm becomes too strong. Finally, the emission lines of HCN and C_{2}H_{2} mostly come from a radially extended optically thin photodissociation region high above the disc in these models, but the emission lines created in these layers are generally optically thin, and their emission characteristics are in conflict with observations, in particular the molecular column densities are too low in these models; see for example Bruderer et al. (2015) for HCN. Kanwar et al. (2024) thoroughly analysed these dilute photodissociation regions using an extended hydrocarbon chemical network.
Increasing the C/O ratio can indeed boost the HCN and C_{2}H_{2} line fluxes, but this leads to the loss of the CO_{2} emission feature (Woitke et al. 2018a), and a very finetuned C/O value would be required to explain the ratios of the emission line features of different molecules. In contrast, what the observations tell us is that the emission features of H_{2}O, CO_{2}, HCN, and C_{2}H_{2} are optically thick in most cases, with column densities in excess of 10^{15}cm^{−2}, which causes the flux levels of these features to be on a similar level in a more robust way. We therefore carefully analysed our PRODIMO models to see how we can possibly create larger amounts of optically thick HCN and C_{2}H_{2} molecules. These efforts resulted in a number of important code changes that are reported in this section. These changes are essential for fitting the first JWST spectrum, as described in Sect. 3.
2.1 A new escape probability theory for discs
Many published line fluxes from models of protoplanetary discs rely on the concept of escape probability; for example Nomura et al. (2007). Different variants of the escape probability formalism have been developed (Woods & Willacy 2009; Woitke et al. 2009; Du & Bergin 2014). In PRODIMO, while we normally perform formal solutions of the 3D linetransfer problem to calculate the line fluxes, an escape probability method is still required to compute the nonlocal thermodynamic equilibrium (nonLTE) populations and the heating and cooling rates. The previously used escape probability method in PRODIMO is based on Eq. (73) in Woitke et al. (2009), which is a rather crude approximation as it only considers radiative pumping by continuum photons in the radial direction and line photon escape into the upward vertical direction. In particular, the IR pumping from the disc below is incorrectly attenuated by the radial line optical depth ${\tau}_{ul}^{\text{rad}}$, which can be huge, which means we are likely underestimating the true IR pumping. In addition, in the outer optically thin disc regions, the escape probability is currently limited to ${P}_{ul}^{\text{esc}}\le \frac{1}{2}$, whereas it should be ${P}_{ul}^{\text{esc}}\to 1$ in the optically thin limit.
This paper introduces a new idea about how to calculate the lineaveraged mean intensity ${\overline{J}}_{ul}$ by taking into account continuum radiative transfer effects in the line resonance region:
$${\overline{J}}_{ul}=\frac{1}{4\pi}{\displaystyle \int {\displaystyle \int {\varphi}_{v}{I}_{v}\left(n\right)d\text{\Omega}dv}},$$(1)
where ϕ_{v} is the line profile function associated with the spectral line u → 1 and I_{v} is the spectral intensity. Finding ${\overline{J}}_{ul}$ is key to formulating the effective nonLTE rates and heating and cooling functions associated with line absorption and emission; see Eqs. (80), (81), (85), and (86) in Woitke et al. (2009). Here, we show that, by making certain assumptions about disc geometry and the locality of the radiative transfer quantities explained below, it is possible to obtain a final expression that again reads $${\overline{J}}_{ul}={P}_{ul}^{\text{pump}}{J}_{v}^{\text{cont}}+\left(1{P}_{ul}^{\text{esc}}\right){S}_{\text{L}},$$(2)
but now with new pumping and escape probabilities, ${P}_{ul}^{\text{pump}}$ and ${P}_{ul}^{\text{esc}}$, that depend not only on line optical depths, but also on continuum optical depths, and take into account the pumping from and the escape in all directions. S_{L} is the line source function and ${J}_{v}^{\text{cont}}$ the continuous mean intensity that would result from the line having zero opacity. We write the continuum and line radiative transfer equation as $$\frac{d{I}_{v}}{ds}=\left({\kappa}_{\text{C}}+{\kappa}_{\text{L}}{\varphi}_{v}\right){I}_{v}+{\kappa}_{\text{C}}{S}_{\text{C}}+{\kappa}_{\text{L}}{\varphi}_{v}{S}_{\text{L}},$$(3)
where the continuum, absorption and scattering opacities [cm^{−1}], and the continuum source function, assuming isotropic scattering, are given by $${\kappa}_{\text{C}}={\kappa}_{y}^{\text{abs}}+{\kappa}_{y}^{\text{sca}},$$(4)
$${\kappa}_{\text{C}}{S}_{\text{C}}={\kappa}_{v}^{\text{abs}}{B}_{v}\left({T}_{\text{d}}\right)+{\kappa}_{v}^{\text{sca}}{J}_{v}^{\text{cont}}.$$(5)
The line opacity [cm^{−1} Hz], Gaussian line profile function [Hz^{−1}], and line source function [erg cm^{−2} s^{−1} Hz^{−1} sr^{−1}] are $${\kappa}_{\text{L}}=\frac{h{v}_{ul}}{4\pi}\left({n}_{l}{B}_{lu}{n}_{u}{B}_{ul}\right),$$(6)
$${\varphi}_{v}=\frac{1}{\sqrt{\pi}\text{\Delta}{\nu}_{\text{D}}}\mathrm{exp}\left({\left(\frac{v{v}_{ul}}{\text{\Delta}{v}_{\text{D}}}\right)}^{2}\right),$$(7)
$${S}_{\text{L}}=\frac{2h{v}_{ul}^{3}}{{c}^{2}}{\left(\frac{{g}_{u}{n}_{l}}{{g}_{l}{n}_{u}}1\right)}^{1},$$(8)
where v_{ul} is the line centre frequency, v_{D} = v_{u1} Δv/c is the Doppler width, and $\text{\Delta}v={\left({v}_{\text{th}}^{2}+{v}_{\text{turb}}^{2}\right)}^{1/2}$ is the line width in velocity space. Introducing the optical depth and maximum optical depth as $${t}_{v}(s)={{{\displaystyle \int}}^{\text{}}}_{0}^{s}{\kappa}_{\text{C}}+{\kappa}_{\text{L}}{\varphi}_{v}ds,$$(9)
$${\tau}_{v}={t}_{v}({s}_{\text{max}}),$$(10)
the formal solution of Eq. (3) is $${I}_{v}(n)={I}_{v}^{0}(n){\text{e}}^{{\tau}_{v}}+{{{\displaystyle \int}}^{\text{}}}_{0}^{{s}_{\mathrm{max}}}\left({\kappa}_{\text{C}}{S}_{\text{C}}+{\kappa}_{\text{L}}{\varphi}_{v}{S}_{\text{L}}\right){\text{e}}^{{t}_{v}}ds,$$(11)
where n is the direction of the ray (unit vector) and s_{max} is the distance backward along the ray up to the point where the ray enters the model volume. ${I}_{v}^{0}(n)$ is the incident intensity at that point in direction n.
Assumption 1 (locality). We assume that all radiative transfer quantities, that is κ_{C}, κ_{L}, S_{L}, S_{C}, and ϕ_{v}, are independent of location and direction, and are given by their local values. Assuming S_{L} = const is standard in escape probability theory, because the line photons typically interact only within a small ‘resonance volume’ around the point of interest. Generalising this concept to the continuum transfer properties is a new idea (however, see Hummer & Rybicki 1985).
Using the above strategy, we can capture the most relevant continuum radiative transfer effects in that resonance region, where there is competition between line and continuum absorption and emission. Constant ϕ_{v} also means that we neglect line velocity shifts; that is, we assume a static medium. The only quantities that are allowed to depend on direction are ${I}_{v}^{0}(n)$ and s_{max} (and hence τ_{v}). The formal solution of the RT Eq. (11) then simplifies to $${I}_{v}(n)={I}_{v}^{0}(n){\text{e}}^{{\tau}_{\text{C}}{\tau}_{\text{L}}{\varphi}_{v}}+\frac{{\tau}_{\text{C}}{S}_{\text{C}}+{\tau}_{\text{L}}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}+{\tau}_{\text{L}}{\varphi}_{v}}\left(1{\text{e}}^{{\tau}_{\text{C}}{\tau}_{\text{L}}{\varphi}_{v}}\right),$$(12)
where we use the continuum and line centre optical depths τ_{C} = κ_{C}s_{max} and τ_{L}= κ_{L} s_{max}.
Assumption 2 (disc geometry). We consider three major directions: radial (the rays coming from the stellar surface, which are often important for pumping), vertically upwards, and vertically downwards. At any given location in the disc, the star occupies a small solid angle Σ_{*}. The other two principle directions each cover half of Σ_{d} = 4π − Σ_{*}. All rays coming from the stellar surface are represented by a single radial ray. For the upward and downward directions, we approximate the disc as being planeparallel with µ = cos(θ), where θ is the angle with the vertical. Thus, we find from Eq. (1) that $$\begin{array}{l}{\overline{J}}_{ul}=\frac{{\text{\Omega}}_{\star}}{4\pi}{\displaystyle \int {\varphi}_{v}{I}_{v}^{\text{rad}}dv}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{\displaystyle \int {\varphi}_{v}}{{{\displaystyle \int}}^{\text{}}}_{0}^{1}{I}_{v}(\mu )d\mu \text{\hspace{0.17em}}dv\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{\displaystyle \int {\varphi}_{v}}{{{\displaystyle \int}}^{\text{}}}_{1}^{0}{I}_{v}\left(\mu \right)d\mu \text{\hspace{0.17em}}dv.\hfill \end{array}$$(13)
Introducing the vertically upwards and downwards (across the disc) line and continuum optical depths, ${\tau}_{\text{L}}^{\uparrow}$, ${\tau}_{\text{L}}^{\downarrow}$, ${\tau}_{\text{C}}^{\uparrow}$, and ${\tau}_{\text{C}}^{\downarrow}$, respectively, and the radially inward line and continuum optical depths, ${\tau}_{\text{L}}^{\text{rad}}$ and ${\tau}_{\text{C}}^{\text{rad}}$, and using planeparallel geometry τ(µ) = τ(µ = 0)/µ, we obtain from Eqs. (12) and (13) that $$\begin{array}{l}{\overline{J}}_{ul}=\frac{{\text{\Omega}}_{\star}}{4\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}({I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\text{rad}}{S}_{\text{C}}+{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\text{rad}}+{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\left(1{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\right))dv\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}{{{\displaystyle \int}}^{\text{}}}_{0}^{1}{I}_{v}^{\text{ISM}}{\text{e}}^{\frac{{\tau}_{\text{C}}^{\uparrow}}{\mu}\frac{{\tau}_{\text{L}}^{\uparrow}}{\mu}{\varphi}_{v}}\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\uparrow}{S}_{\text{C}}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\uparrow}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}}\left(1{\text{e}}^{\frac{{\tau}_{\text{C}}^{\uparrow}}{\mu}\frac{{\tau}_{\text{L}}^{\uparrow}}{\mu}{\varphi}_{v}}\right)d\mu \text{\hspace{0.17em}}dv\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}{{{\displaystyle \int}}^{\text{}}}_{1}^{0}{I}_{v}^{\text{ISM}}{\text{e}}^{\frac{{\tau}_{\text{C}}^{\downarrow}}{\left\mu \right}\frac{{\tau}_{\text{L}}^{\downarrow}}{\left\mu \right}{\varphi}_{v}}\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\downarrow}{S}_{\text{C}}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\downarrow}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}}\left(1{\text{e}}^{\frac{{\tau}_{\text{C}}^{\downarrow}}{\left\mu \right}\frac{{\tau}_{\text{L}}^{\downarrow}}{\left\mu \right}{\varphi}_{v}}\right)d\mu \text{\hspace{0.17em}}dv,\hfill \end{array}$$(14)
where ${I}_{v}^{\star}$ and ${I}_{v}^{\text{ISM}}$ are the stellar and interstellar incident intensities, respectively. Introducing the second exponential integral function ${E}_{2}(\tau )={\displaystyle {\int}_{0}^{1}\mathrm{exp}\text{\hspace{0.17em}}}\left(\frac{\tau}{\mu}\right)\text{\hspace{0.17em}\hspace{0.17em}}d\mu $, we find $$\begin{array}{l}{\overline{J}}_{ul}=\frac{{\text{\Omega}}_{\star}}{4\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}({I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\text{rad}}{S}_{\text{C}}+{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\text{rad}}+{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\left(1{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}{\tau}_{\text{L}}^{\text{rad}}{\varphi}_{v}}\right))dv\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}({I}_{v}^{\text{ISM}}{E}_{2}\left({\tau}_{\text{C}}^{\uparrow}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\uparrow}{S}_{\text{C}}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\uparrow}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}}\left(1{E}_{2}\left({\tau}_{\text{C}}^{\uparrow}+{\tau}_{\text{L}}^{\uparrow}{\varphi}_{v}\right)\right))dv\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{{\displaystyle \int}}^{\text{}}{\varphi}_{v}({I}_{v}^{\text{ISM}}{E}_{2}\left({\tau}_{\text{C}}^{\downarrow}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\tau}_{\text{C}}^{\downarrow}{S}_{\text{C}}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}{S}_{\text{L}}}{{\tau}_{\text{C}}^{\downarrow}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}}\left(1{E}_{2}\left({\tau}_{\text{C}}^{\downarrow}+{\tau}_{\text{L}}^{\downarrow}{\varphi}_{v}\right)\right))dv\hfill \end{array}$$(15)
We now introduce the dimensionless profile function $\varphi (x)=\mathrm{exp}\left({x}^{2}\right)/\sqrt{\pi}$ with $x=\left(v{v}_{ul}\right)/\text{\Delta}{v}_{\text{D}}$, and six basic 2D functions, which all produce values of between 0 and 1, to further simplify the result: $${\alpha}_{0}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x){\text{e}}^{{\tau}_{\text{C}}{\tau}_{\text{L}}\varphi (x)}dx,$$(16)
$${\alpha}_{1}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x)\frac{{\tau}_{\text{C}}}{{\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)}\left(1{\text{e}}^{{\tau}_{\text{C}}{\tau}_{\text{L}}\varphi (x)}\right)dx,$$(17)
$${\alpha}_{2}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x)\frac{{\tau}_{\text{L}}\varphi (x)}{{\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)}\left(1{\text{e}}^{{\tau}_{\text{C}}{\tau}_{\text{L}}\varphi (x)}\right)dx,$$(18)
$${\beta}_{0}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x){E}_{2}\left({\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)\right)dx,$$(19)
$${\beta}_{1}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x)\frac{{\tau}_{\text{C}}}{{\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)}\left(1{E}_{2}\left({\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)\right)\right)dx,$$(20)
$${\beta}_{2}\left({\tau}_{\text{L}},{\tau}_{\text{C}}\right)={{\displaystyle \int}}^{\text{}}\varphi (x)\frac{{\tau}_{\text{L}}\varphi (x)}{{\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)}\left(1{E}_{2}\left({\tau}_{\text{C}}+{\tau}_{\text{L}}\varphi (x)\right)\right)dx,$$(21)
where, using the Einstein relations, $$\begin{array}{l}{\tau}_{\text{L}}={{\displaystyle \int}}^{\text{}}\frac{{\kappa}_{\text{L}}}{\text{\Delta}{v}_{\text{D}}}ds={{\displaystyle \int}}^{\text{}}\frac{h{v}_{ul}}{4\pi \text{\Delta}{v}_{\text{D}}}\left({n}_{l}{B}_{lu}{n}_{u}{B}_{ul}\right)ds\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}={{\displaystyle \int}}^{\text{}}\frac{{A}_{ul}}{8\pi \text{\Delta}v}{\left(\frac{c}{{v}_{ul}}\right)}^{3}\left({n}_{l}\frac{{g}_{u}}{{g}_{l}}{n}_{u}\right)ds.\hfill \end{array}$$(22)
The results are $$\begin{array}{l}{\overline{J}}_{ul}=\frac{{\text{\Omega}}_{\star}}{4\pi}\left({I}_{v}^{\star}{\alpha}_{0}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)+{S}_{\text{C}}{\alpha}_{1}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)+{S}_{\text{L}}{\alpha}_{2}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}\left({I}_{v}^{\text{ISM}}{\beta}_{0}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)+{S}_{\text{C}}{\beta}_{1}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)+{S}_{\text{L}}{\beta}_{2}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}\left({I}_{v}^{\text{ISM}}{\beta}_{0}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)+{S}_{\text{C}}{\beta}_{1}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)+{S}_{\text{L}}{\beta}_{2}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)\right)\hfill \end{array}$$(23)
From this geometric model, we also get a prediction of the continuum; that is, the mean intensity at line centre frequency, as would be present if the line opacity was zero: $$\begin{array}{l}{J}_{v}^{\text{cont}}=\frac{{\text{\Omega}}_{\star}}{4\pi}\left({I}_{v}^{\star}{\alpha}_{0}\left(0,{\tau}_{\text{C}}^{\text{rad}}\right)+{S}_{\text{C}}{\alpha}_{1}\left(0,{\tau}_{\text{C}}^{\text{rad}}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}\left({I}_{v}^{\text{ISM}}{\beta}_{0}\left(0,{\tau}_{\text{C}}^{\uparrow}\right)+{S}_{\text{C}}{\beta}_{1}\left(0,{\tau}_{\text{C}}^{\uparrow}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}\left({I}_{v}^{\text{ISM}}{\beta}_{0}\left(0,{\tau}_{\text{C}}^{\downarrow}\right)+{S}_{\text{C}}{\beta}_{1}\left(0,{\tau}_{\text{C}}^{\downarrow}\right)\right).\hfill \end{array}$$(24)
Equation (24) is used to determine S_{C}. This means that we can calibrate S_{C} in such a way that our simple threeway RT model with constant continuum quantities results in the correct ${J}_{v}^{\text{cont}}$ as known from the proper solution of the continuum radiative transfer problem. This confers a significant advantage as it allows us to eliminate most of the principle problems arising from the simplified threeway RT model in the continuum.
Comparing Eq. (23) to Eq. (2), we find the definitions of our new pumping and escape probabilities: $$\begin{array}{l}{P}_{ul}^{\text{pump}}=\frac{1}{{J}_{v}^{\text{cont}}}(\frac{{\text{\Omega}}_{\star}}{4\pi}\left[{I}_{v}^{\star}{\alpha}_{0}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)+{S}_{\text{C}}{\alpha}_{1}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)\right]\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}[{I}_{v}^{\text{ISM}}\left({\beta}_{0}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)+{\beta}_{0}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+{S}_{\text{C}}\left({\beta}_{1}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)+{\beta}_{1}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)\right)])\hfill \end{array},$$(25)
$${P}_{ul}^{\text{esc}}=1\frac{{\text{\Omega}}_{\star}}{4\pi}{\alpha}_{2}\left({\tau}_{\text{L}}^{\text{rad}},{\tau}_{\text{C}}^{\text{rad}}\right)\frac{{\text{\Omega}}_{\text{d}}}{8\pi}\left({\beta}_{2}\left({\tau}_{\text{L}}^{\uparrow},{\tau}_{\text{C}}^{\uparrow}\right)+{\beta}_{2}\left({\tau}_{\text{L}}^{\downarrow},{\tau}_{\text{C}}^{\downarrow}\right)\right).$$(26)
The interpretation of these results is as follows. ${P}_{ul}^{\text{pump}}$ is the probability that continuum photons make it to the considered point, given the presence of line opacity. The average is taken over all continuum photons that contribute to ${J}_{v}^{\text{cont}}$, whether they are emitted by the star or by any point in the disc, averaged over the local line profile function. ${P}_{ul}^{\text{esc}}$ is the probability that line photons emitted anywhere in the disc – in the direction of the considered point – do not make it to the considered point, averaged over the local line profile function. ${P}_{ul}^{\text{esc}}<1$ means that these line photons are either reabsorbed by line opacity, or are reabsorbed or scattered by continuum opacity along the path to the considered point.
As the order of photon emission and reabsorption and the optical depth effects along the photon paths can be reversed, ${P}_{ul}^{\text{esc}}$ can also be interpreted as the probability that a line photon emitted from the considered point will not have another line interaction in the disc. It is important to realise the emphasis on further line interaction here. ${P}_{ul}^{\text{esc}}$ is not the probability that line photons will escape the disc. This latter interpretation is only valid when there are no continuum opacities. Continuum opacity will prevent further line interaction, and so it increases ${P}_{ul}^{\text{esc}}$. The latter could be interpreted as ‘intrinsic escape’, meaning that, once a line photon is absorbed and reemitted by the dust, that continuum photon will escape the disc somehow, but this is not what the equations tell us. In particular, in the optically thick limiting case with τ_{L} ≪ τ_{C}, the result is ${P}_{ul}^{\text{esc}}\to 1$ and ${P}_{ul}^{\text{pump}}\to 1$.
The six basic 2D functions α_{0}(τ_{L}, τ_{C}) …β_{2}(τ_{L}, τ_{C}) are precalculated in the form of 2D numerical tables. ${I}_{\nu}^{\star}$ and ${I}_{v}^{\text{ISM}}$ are known functions, and ${\tau}_{\text{C}}^{\text{rad}}$, ${\tau}_{\text{C}}^{\uparrow}$, and ${\tau}_{\text{C}}^{\downarrow}$ are available after initialisation of the disc structure and dust opacities in PRODIMO. As ${J}_{v}^{\text{cont}}$ is available from the proper solution of the continuum transfer problem, we can use Eq. (24) to determine and precalculate S_{C} for every line at any point in the disc. The centre line optical depths ${\tau}_{\text{L}}^{\text{rad}}$ and ${\tau}_{\text{L}}^{\uparrow}$ are integrated during the downward and outward sweep of the chemistry and the heating and cooling balance in PRODIMO, but we also need ${\tau}_{\text{L}}^{\downarrow}$ here, which requires another assumption.
Assumption 3 (downward line optical depths). We calculate ${\tau}_{\text{L}}^{\downarrow}$ by assuming that the local line/continuum opacity ratio remains the same on the way down and across the disc: $${\tau}_{\text{L}}^{\downarrow}={\tau}_{\text{C}}^{\downarrow}\frac{{\kappa}_{\text{L}}}{{\kappa}_{\text{C}}},$$(27)
where κ_{L} and κ_{C} are the local line and continuum opacities. The old escape probability method in PRODIMO was based on $${P}_{ul}^{\text{pump,old}}={{\displaystyle \int}}^{\text{}}\varphi (x){\text{e}}^{{\tau}_{\text{L}}^{\text{rad}}\varphi (x)}dx,$$(28)
$${P}_{ul}^{\text{esc,old}}=\frac{1}{2}{{\displaystyle \int}}^{\text{}}\varphi (x){E}_{2}\left({\tau}_{\text{L}}^{\uparrow}\varphi (x)\right)dx.$$(29)
As can be easily shown, ${P}_{ul}^{\text{pump}}={P}_{ul}^{\text{pump,old}}$ is only valid when the direct stellar illumination dominates; that is, when ${J}_{v}^{\text{cont}}=\frac{{\text{\Omega}}_{\star}}{4\pi}{I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}}$. In all other cases, the new ${P}_{ul}^{\text{pump}}$ probabilities are larger. ${P}_{ul}^{\text{esc}}={P}_{ul}^{\text{esc},\text{old}}$ is only valid when ${\text{\Omega}}_{\star}\to 0,{\tau}_{\text{C}}^{\uparrow}=0$ and ${\tau}_{\text{C}}^{\downarrow}\to \infty $. Under any other, more realistic circumstances, the new ${P}_{ul}^{\text{esc}}$ probabilities are also generally larger. Both effects are caused by the inclusion of line–continuum interactions, namely (i) locally produced continuum photons can be absorbed in the line, and (ii) line photons can be absorbed locally in the continuum. We use both limiting cases discussed above to check the numerical implementation of the new escape probability method in PRODIMO.
Figure 1 shows a comparison between old and new escape and pumping probabilities based on our T Tauri standard disc model. This model was introduced by Woitke et al. (2016) and has stellar, dust, and disc parameters as listed in Table A.2. The results of the new treatment show larger ${P}_{ul}^{\text{pump}}$ and ${P}_{ul}^{\text{esc}}$ in general. The deviations are particularly obvious in the disc midplane close to the star, where trie continuum is optically thick. We see large and about equal ${P}_{ul}^{\text{pump}}$ and ${P}_{ul}^{\text{esc}}$ here, in contrast to the old treatment. More significant for line observations are the changes in the more transparent upper disc regions, where ${P}_{ul}^{\text{esc}}\sim {P}_{ul}^{\text{esc,old}}$ and ${P}_{ul}^{\text{pump}}{P}_{ul}^{\text{pump,old}}$ in the inner disc. However, in the outer disc, this relation is reversed and we find ${P}_{ul}^{\text{pump}}{P}_{ul}^{\text{pump,old}}$. The reasons for these changes are more complex, as ${J}_{v}^{\text{cont}}$ is not given by the attenuated stellar irradiation but is created mostly by continuum emission from the disc below.
Figure 2 shows the resulting leading heating and cooling processes in the innermost 10 AU of the disc (T Tauri standard model). Figure A.1 shows additional vertical cuts at selected radii with more details. There are two significant changes:
 (i)
In the disc surface regions inside of 1 au, which are borderline optically thin and relevant for the IR line emission, we find increased H_{2}O heating and cooling rates, whereas previously there was a balance between UVdriven heating by H_{2} formation and H_{2}O cooling. This is due to the increased pumping and escape probabilities in these regions.
 (ii)
Thermal accommodation in the midplane is now quite unimportant for both heating and cooling, unless the midplane becomes so cold that it barely contains any molecules other than H_{2} due to freezeout. In the optically thick midplane, dust and gas now exchange energy very efficiently via line photons, more efficiently than by inelastic collisions. And since the formulation of the line heating and cooling in PRODIMO is robust, including all reverse processes and stimulated emission, ${J}_{v}^{\text{cont}}={B}_{v}\left({T}_{\text{d}}\right)$ implies that a balance between line heating and cooling can only be achieved when T_{g} = T_{d}.
Fig. 1 Escape probability (${P}_{ul}^{\text{esc}}$, top) and continuum pumping probability (${P}_{ul}^{\text{pump}}$, bottom) of the [OI] 63 µm line in the PRODIMO standard T Tauri model. Left and right plots show the results from the previous and the new escape probability theory. The white dashed contours show the particle density of atomic oxygen log_{10} n_{OI}[ cm^{−3}] = {8, 6, 4, 2, 0, −2}.
Fig. 2 Change in heating and cooling balance with the new escape probability treatment and the new 2D concept to apply UV molecular shielding factors. The plots show the leading heating process (top) and the leading cooling process (bottom) in a zoomedin disc region responsible for the disc IR line emissions. Processes are only plotted when they fill at least 1% of the area in these plots. The dashed lines mark the visual disc surface A_{v,rad} = 1 and the vertical optical extinction A_{V} = 10. The model includes 103 heating and 95 cooling processes with 64910 spectral lines altogether.
2.2 New escape probabilities for lineflux estimations
In PRODIMO, the observable line fluxes are estimated based on the escape probabilities, summing up the contributions from all spatial cells. The following expression is used to calculate the luminosity [erg s^{−1}] of photon energy escaping in the form of line photons from a single cell in the old model: $${L}^{\text{cell}}=\text{\Delta}V\text{\hspace{0.17em}}{n}_{\text{u}}{A}_{\text{ul}}\text{\hspace{0.17em}}h{v}_{\text{ul}}{{\displaystyle \int}}^{\text{}}\varphi (x){\text{e}}^{{\tau}_{\text{L}}\varphi (x){\tau}_{\text{C}}}dx,$$(30)
where ΔV [cm^{−3}] is the volume of a cell k centred around point grid point (ix, iz). The line flux [erg s^{−1} cm^{−2}] is then calculated as $${F}_{\text{line}}=\frac{{\displaystyle {\sum}_{k}{L}_{k}^{\text{cell}}}}{4\pi {d}^{2}},$$(31)
where d is the distance to the object. We consider the vertical escape here (faceon disc), and so the line and continuum optical depths are ${\tau}_{\text{L}}={\tau}_{\text{L}}^{\uparrow}$ and ${\tau}_{\text{C}}={\tau}_{\text{C}}^{\uparrow}$. Using the definition of the line emission coefficient, we have ${n}_{\text{u}}{A}_{\text{ul}}h{v}_{\text{ul}}=4\pi {\kappa}_{\text{L}}{S}_{\text{L}}$, and we can express the line luminosity of a cell, according to the old implementation, by $${L}^{\text{cell}}=4\pi \text{\Delta}V{\kappa}_{\text{L}}{S}_{\text{L}}{\text{e}}^{{\tau}_{\text{C}}}{{\displaystyle \int}}^{\text{}}\varphi (x){\text{e}}^{{\tau}_{\text{L}}\varphi (x)}dx.$$(32)
This result corresponds to the case of a cold background S_{C} = 0, where the result is always positive; see area A in Fig. 3. However, line and continuum interfere in more complicated ways than that; there is not a simple superposition, as sketch (d) in Fig. 3 suggests, because the escaping continuum photons are partly blocked by line opacity. This effect is visualised by the lower graph in case (b).
In a more detailed model, we need to compute the upper graph in case (b) and the pure continuum, and then subtract the two to simulate the way that line fluxes are measured from observations. Without continuum, we have area A in Fig. 3:
$${L}^{\text{cell}}=4\pi \text{\Delta}V{{\displaystyle \int}}^{\text{}}{\kappa}_{\text{L}}{S}_{\text{L}}{\varphi}_{v}{\text{e}}^{{\tau}_{\text{L}}\varphi (x){\tau}_{\text{C}}}dv.$$(33)
With continuum, the (infinite) result is
$${L}^{\text{cell}}=4\pi \text{\Delta}V{{\displaystyle \int}}^{\text{}}\left({\kappa}_{\text{L}}{S}_{\text{L}}{\varphi}_{v}+{\kappa}_{\text{C}}{S}_{\text{C}}\right){\text{e}}^{{\tau}_{\text{L}}\varphi (x){\tau}_{\text{C}}}dv.$$(34)
Considering only the continuum, the (infinite) result is
$${L}^{\text{cell}}=4\pi \text{\Delta}V{{\displaystyle \int}}^{\text{}}{\kappa}_{\text{C}}{S}_{\text{C}}{\text{e}}^{{\tau}_{\text{C}}}dv.$$(35)
The continuumsubtracted line flux (area O in Fig. 3) is
$$\begin{array}{l}{L}^{\text{cell}}=4\pi \text{\Delta}V{\text{e}}^{\pi}\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\times \left({\kappa}_{\text{L}}{S}_{\text{L}}\underset{{C}_{1}\left({\tau}_{\text{L}}\right)}{\underbrace{{\displaystyle \int \varphi (x){\text{e}}^{{\tau}_{\text{L}}\varphi (x)}dx}}}{\kappa}_{\text{C}}{S}_{\text{C}}\text{\Delta}{\nu}_{\text{D}}\underset{{C}_{2}\left({\tau}_{\text{L}}\right)}{\underbrace{{\displaystyle \int \left(1{\text{e}}^{{\tau}_{\text{L}}\varphi (x)}\right)dx}}}\right)\hfill \end{array}.$$(36)
Equation (36) shows that there is an additional correction term with respect to the old way of calculating the escaping line luminosity from a cell (Eq. (32)), which is always negative. This new term describes the loss of continuum flux due to line absorption. The integration boundaries in these equations are −∞and +∞, and so both intermediate results (Eqs. (34) and (35)) are infinite, but the subtraction of the two (Eq. (36)) is finite. The function C_{1}(τ_{L}) describes the probability that an outgoing line photon is not reabsorbed in the line again, and C_{2}(τ_{L}) describes the reduction of continuum photons escaping the object due to line opacity. The two functions C_{1}(τ_{L}) and C_{2}(τ_{L}) are plotted in Fig. 4.
According to this new formulation of escape probability, the line flux is always smaller when continuum emission effects are included, and can become negative when the continuum source function S_{C} is as large as the line source function S_{L}. However, we note that the continuum and the line are usually emitted from different disc regions.
Figure 5 shows a comparison between the lineflux predictions obtained with the old and the new escape probability treatment. All results are shown with respect to the proper full PRODIMO line RT results for faceon inclination. We generally see a good agreement between the results of all three methods, with differences being of order 10–30%. The differences become more noticeable at shorter wavelengths, where the lines are mostly emitted from the inner disc. The new escape probability treatment is superior and more balanced around the y = 1 line, whereas the old escape probability treatment has the tendency to overpredict the line fluxes. Two NH_{3} lines at around 10.5 µm turn out to be absorption lines according to the proper line RT, and are not plotted in Fig. 5. Both escape probability methods fail to predict these lines correctly. The old escape probability method predicts (by design) emission lines. The new escape probability method does produce absorption lines as it should, but the negative fluxes are too large. We note that both escape probability methods can predict the submillimetre (submm) lines very well (e.g. lowJ CO lines, CN, HCN, HCO^{+} in Fig. 5). The fluxes of the farinfrared (FIR) lines (e.g. Herschel/HIFI water lines, finestructure cooling lines of oxygen) are predicted better than 10%.
Fig. 3 Effect of continuum emission on line flux. Case (a) shows an emission line on a cold continuum S_{C} = 0. Case (b) is an emission line on a warm continuum S_{L} > S_{C}, and case (c) is an absorption line where the continuum is hot S_{L} < S_{C}. The area A is the flux of photon energy [erg s^{−1} cm^{−2}] carried away by line photons escaping from the object (after continuum extinction and line selfabsorption) and is the same in cases (a), (b) and (c). However, the objective is to derive the area O, which is the line flux as measured by observers. For a warm continuum, clearly O < A, and for an absorption line O < 0 (although A > 0).
2.3 Photo cross sections
PRODIMO now uses the new highresolution photoionisation and photodissociation cross sections ${\sigma}_{\text{ph}}^{\text{mol}}$ of Heays et al. (2017) obtained from the Leiden database^{1}.
Fig. 5 Line fluxes predicted by the old escape probability treatment (blue) and new escape probability treatment (orange). All line fluxes are divided by the results from the full line RT for zero inclination (faceon).
2.4 Ultraviolet molecular shielding and selfshielding
Shielding factors are used in PRODIMO to reduce the molecular photoionisation and photodissociation rates:
$${R}_{\text{ph}}=4\pi {{\displaystyle \int}}^{\text{}}{\sigma}_{\text{ph}}(v)\frac{{J}_{v}}{hv}dv,$$(37)
where σ_{ph}(v) is the photodissociation cross section and J_{v} is the local mean intensity. Without molecular shielding, we have ${J}_{v}={J}_{v}^{\text{cont}}$ where ${J}_{v}^{\text{cont}}$ is the result from the continuum radiative transfer (RT). However, the UV molecular opacities are not included in the continuum RT; they generally cause ${J}_{v}<{J}_{v}^{\text{cont}}$, because there is no molecular UV emission in the disc. These opacities therefore reduce the photo rates.
There are various molecular shielding effects included, both selfshielding i→i and shielding of a molecule j by another molecule i; see for example Bethell & Bergin (2009). Water shielding was recently discussed by Bosman et al. (2022a,b). In some cases, the shielding factors s_{i→j} are taken from published 1D semiinfinite slabmodels, which resolve the UV lines and have published efficiency factors as a function of the column density of the molecular absorber ‘towards the source’ and (local) temperature:
$${s}_{i\to j}={s}_{i\to j}\left({N}_{i},{T}_{\text{g}}\right)\text{\hspace{1em}with\hspace{1em}}{N}_{i}={{\displaystyle \int}}^{\text{}}n(i)\text{\hspace{0.17em}}ds.$$(38)
In general, the shielding factors can be applied as a product, because $\mathrm{exp}\left({\tau}_{\text{all}\to j}\right)=\mathrm{exp}\left(\underset{i}{{{\displaystyle \sum}}^{\text{}}}{\sigma}_{\text{i}}(v){N}_{i}\right)={\prod}_{i}\mathrm{exp}\left({\sigma}_{\text{i}}(v){N}_{i}\right)$, at least approximately. Table 1 summarises the basic selfshielding functions used. In PRODIMO, all photorates are calculated by numerical integration of Eq. (37) over the frequencydependent photo cross sections and the local UV radiation field J_{v} The latter is interpolated between the values known on approximately seven UV spectral gridpoints used in the continuum radiative transfer; see Woitke et al. (2009) for details. In cases where we do not have detailed photo cross sections, but only the a, β, and γ coefficients from a chemical database, we fit a generic crosssection ${\sigma}_{\text{ph}}(\lambda )={\sigma}_{0}\mathrm{exp}\left({\left({\lambda}_{0}\lambda \right)}^{2}/\text{\Delta}{\lambda}^{2}\right)$, with two free parameters σ_{0} and λ_{0}, until the photorates are correct for optical extinctions A_{V} = 0 and A_{V} = 0.5 using standard interstellar dust extinction properties.
Therefore, it is relatively straightforward to use any frequencydependent recipes to account for the effect of molecular shielding. In particular, and this is new in PRODIMO, we use the following idea to account for generic selfshielding:
$${s}_{i\to i}={{\displaystyle \int}}^{\text{}}{\sigma}_{\text{ph}}(v)\frac{{J}_{v}}{hv}{\text{e}}^{{N}_{i}{\sigma}_{\text{ph}}(v)}dv/{{\displaystyle \int}}^{\text{}}{\sigma}_{\text{ph}}(v)\frac{{J}_{v}}{hv}dv.$$(39)
Other recipes are applied to the shielding of any molecule by H_{2} and C; see Table 1. For example, Eq. (8) in Kamp & Bertoldi (2000) describes the Tdependent reduction of UV light by H_{2} lines when detected with the flat opacity of neutral C, which is assumed to provide a first approximation of the shielding effect on any molecule with uncorrected σ_{ph}(λ) for wavelengths shorter than 1100 Å.
Molecular shielding and selfshielding factors in PRODIMO
2.5 New 2D treatment of molecular shielding
The question arises as to how to deal with the problem of molecular shielding in 2D, and specifically as to which column density N_{i} is to be considered, choosing from the radial one, the vertically upward one, a mixture, or even something else. Equation (24) holds an answer to this question. Using the explicit shapes of α_{0}, β_{0} an β_{1} for τ_{L} → 0, and neglecting the α_{1} term, which is the continuum emission of the disc in the solid angle of the star, and is usually very small, this equation reads
$$\begin{array}{l}{J}_{v}^{\text{cont}}=\frac{{\text{\Omega}}_{\star}}{4\pi}{I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{I}_{v}^{\text{ISM}}\left({E}_{2}\left({\tau}_{\text{C}}^{\uparrow}\right)+{E}_{2}\left({\tau}_{\text{C}}^{\downarrow}\right)\right)\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}+\frac{{\text{\Omega}}_{\text{d}}}{8\pi}{S}_{\text{C}}\left(2{E}_{2}\left({\tau}_{\text{C}}^{\uparrow}\right){E}_{2}\left({\tau}_{\text{C}}^{\downarrow}\right)\right).\hfill \end{array}$$(40)
Equation (40) states the influence of the three principle sources (the star, the ISM background, and the disc itself) on the calculated ${J}_{v}^{\text{cont}}$. Contrary to the IR pumping of molecules, which often comes from the warm extended dust below the point of interest, the UV radiation mainly arrives from two directions, the direct radial and the vertically downward directions. Clearly, if direct illumination from the star dominates, then ${J}_{v}^{\text{cont}}\approx \frac{{\text{\Omega}}_{\star}}{4\pi}{I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}}$ and one should use the radial column densities towards the star to compute the shielding factors. If interstellar UV irradiation dominates, one should take the vertical column densities. However, in the IRlineemitting disc regions, neither of these two terms is usually the important one, and it is the downward scattering of star light by the small dust in the disc’s upper layers that dominates, which is represented by S_{C} and expressed by the third term in Eq. (40).
It is not obvious which molecular column densities should be considered for the molecular shielding factors applied to the third term in Eq. (40). The proper approach would be to consider the molecular column density along the average scattered photon path, but this information is not available. One could argue in favour of taking the radial column density at a much higher disc level up to the scattering point and then adding the downward vertical column density from that point when considering single vertical scattering events, but then the point at which that scattering event takes place needs to be determined.
Instead we follow a much more simple approach here. We assume that the second part of the molecular column density along the scattered photon path is dominant, namely the downward vertical column density from the scattering site. Since the vertical column density increases exponentially on the way down, because (a) the density increases and (b) the molecular concentration increases, it is mostly determined locally, and there is no significant difference when simply taking the full vertical column density.
According to this approach, we use the radial column densities for the first, and the vertical column densities for the second and third terms in Eq. (40), which can be reformulated as
$${J}_{v,\text{rad}}^{\text{cont}}=\frac{{\text{\Omega}}_{\star}}{4\pi}{I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rad}}}$$(41) $${J}_{v,\text{ver}}^{\text{cont}}={J}_{v}^{\text{cont}}{J}_{v,\text{rad}}^{\text{cont}}$$(42) $${J}_{v}={s}_{i\to j}\left({N}_{i}^{\text{rad}},{T}_{\text{g}}\right){J}_{v,\text{rad}}^{\text{cont}}+{s}_{i\to j}\left({N}_{i}^{\text{ver}},{T}_{\text{g}}\right){J}_{v,\text{vert}}^{\text{cont}}.$$(43)
In previous PRODIMO models, we used the stellar and interstellar irradiation terms (parts 1 and 2 in Eq. (40)) to calculate weighting factors for the application of shielding factors according to the following scheme:
$${J}_{v,\text{rad}}^{\text{cont}}=\frac{{\text{\Omega}}_{\star}}{4\pi}{I}_{v}^{\star}{\text{e}}^{{\tau}_{\text{C}}^{\text{rd}}}$$(44) $${J}_{v,\text{ver}}^{\text{cont}}={I}_{v}^{\text{ISM}}{E}_{2}\left({\tau}_{\text{C}}^{\uparrow}\right)$$(45) $${w}_{\text{rad}}={J}_{v,\text{rad}}^{\text{cont}}/\left({J}_{v,\text{rad}}^{\text{cont}}+{J}_{v,\text{ver}}^{\text{cont}}\right)$$(46) $${w}_{\text{vert}}={J}_{v,\text{ver}}^{\text{cont}}/\left({J}_{v,\text{rad}}^{\text{cont}}+{J}_{v,\text{ver}}^{\text{cont}}\right)$$(47) $${s}_{i\to j}={w}_{\text{rad}}{s}_{i\to j}\left({N}_{j}^{\text{rad}},{T}_{\text{g}}\right)+{w}_{\text{vert}}{s}_{i\to j}\left({N}_{j}^{\uparrow},{T}_{\text{g}}\right)$$(48) $${J}_{v}={s}_{i\to j}{J}_{v}^{\text{cont}},$$(49)
where w_{rad} and w_{vert} are the radial and vertical weights. However, this approach involves a clearly far more questionable assumption, because the often most important term (the third term in Eq. (40)) is not even considered, and thus ${J}_{v}^{\text{cont}}\gg {J}_{v}^{\text{rad}}+{J}_{v}^{\text{vert}}$. Instead, based on the mixing ratio between ${J}_{v}^{\text{rad}}$ and ${J}_{v}^{\text{vert}}$, an effective shielding factor was calculated and applied to all of ${J}_{v}^{\text{cont}}$. As Eq. (48) ignores the scattering altogether, the old vertical part ${J}_{v,\text{ver}}^{\text{cont}}$ is too small, and therefore we switched from radial to vertical column densities too late. As the radial column densities are generally larger than the vertical ones, the effects of molecular shielding were overestimated in the old models.
Figure 6 shows that, as expected, the formation of CO now happens slightly deeper in the disc. In both models, CO is found to be abundant when (i) the ionisation parameter χ/n is low enough (χ is the strength of the UV field; see Eq. (42) in Woitke et al. (2009), and n is the total hydrogen nuclei density [cm^{−3}]) and (ii) the dust temperature is high enough T_{d} ≳ 20 K. These two criteria are related to CO photodissociation and freezeout. The critical value for the CO photodissociation log_{10}(χ/n) changes from about 4.5 to 5 in the new models.
The feedback on the more complex molecules, such as HCN and C_{2}H_{2}, is remarkable, leading to profoundly different chemical conditions in the IRlineemitting disc regions. In Fig. 6, we concentrate on the upper, warm lineemitting regions. There are also some regions with high concentrations of HCN and C_{2}H_{2} in the midplane, but these molecules are covered by optically thick dust and play no significant role in the IRline emission in this T Tauri standard disc setup. The formation of these IRactive molecules in the upper disc happens in slightly deeper layers according to the new models, and as the gas densities are larger there, the formation of more complex molecules is generally favoured in the new models.
In particular, the formation of C_{2}H_{2} needs both H_{2} and neutral carbon atoms; see e.g. Agúndez et al. (2008). In the lower part of Fig. 6, we overplot H/H_{2} = 10 and CO/C = 100 contour lines. These two lines nicely encircle the region of high C_{2}H_{2} concentrations in the model. Similar results were reported by Walsh et al. (2015) and Anderson et al. (2021). In the inner disc, these lines are crossed in our models, and so when H_{2} finally forms, there is no longer any neutral C, and we get no C_{2}H_{2}; see also Kanwar et al. (2024). In the new model, these two lines are further apart, there is a wider region to form C_{2}H_{2}, and that region now also extends to smaller radii.
A similar effect is found for HCN, where the changes are even more pronounced. The formation of HCN requires H_{2} and neutral N atoms. In the new models, both transitions H → H_{2} and N → N_{2} happen deeper in the disc, and they are vertically more separated, leading to increased HCN column densities in the upper layers of the inner disc.
2.6 Heating by photodissociation
One heating process that has so far been partly neglected in PRODIMO is the ‘direct’ heating by photodissociation:
$${\text{\Gamma}}_{\text{pd}}=\underset{\text{mol}}{{{\displaystyle \sum}}^{\text{}}}{n}_{\text{mol}}{R}_{\text{mol}}^{\text{ph}}\text{\Delta}{E}_{\text{mol}},$$(50)
where n_{mol} [cm^{−3}] is the molecular particle density, ${R}_{\text{mol}}^{\text{ph}}$ [s^{−1}] the photodissociation rate, and ΔE_{mol} is the mean energy liberated per photodissociation. Similar to photoionisation, the excess photon energy can create superthermal dissociation products, or can lead to vibrationally or electronically excited molecular fragments, and the key question pertains to how much of this energy is thermalised by the gas.
Gu et al. (2020) treated this process with 100% efficiency, assuming that the energy released as local heat is set as the incident photon energy in excess of the respective dissociation threshold: $$\text{\Delta}{E}_{\text{mol}}=\frac{{{{\displaystyle \int}}^{\text{}}}_{{v}_{0}}^{\infty}\frac{{J}_{v}}{hv}{\sigma}_{\text{ph}}^{\text{mol}}(v)h\left(v{v}_{0}\right)dv}{{{{\displaystyle \int}}^{\text{}}}_{{v}_{0}}^{\infty}\frac{{J}_{v}}{hv}{\sigma}_{\text{ph}}^{\text{mol}}(v)dv},$$(51)
where v_{0} is the photodissociation threshold frequency. However, more detailed studies show that not all of this energy is thermalised; for example, excited dissociation products can decay radiatively, or can trigger followup chemical reactions.
Glassgold & Najita (2015) published detailed energies per photodissociation ΔE for H_{2} (1.2 eV), CO (1.4 eV), H_{2}O (1.2 eV), and OH (3.6 eV), and we have now implemented these data into PRODIMO. For all other molecules, we conservatively assume ΔE ≈ 2 eV. Previously in PRODIMO, only H_{2}, with ΔE(H_{2}) = 0.4 eV (Black & van Dishoeck 1987), was considered for the heating by photodissociation in addition to the heating by photoionisation of H^{−}, C, Fe, Si, and Mg. Figure 2 shows that this additional heating process can be quite relevant in the IRactive molecular layer. Interestingly, the reduced UV molecular shielding factors cause larger photorates, which lead to a more active chemistry, where the molecular fragments created by photodissociation react further exothermally, which increases the area where chemical heating is important.
Fig. 6 Change of molecular concentrations caused by introducing our new 2D concept to apply molecular shielding factors.
2.7 Chemical rate network
We used the large DIANA standard chemical network (Kamp et al. 2017) in this work, which has 235 chemical species, with reaction rates mostly taken from the UMIST 2012 database (McElroy et al. 2013), but including a simple freezeout and desorption ice chemistry (Woitke et al. 2009), Xray processes partly based on doubly ionised species (Aresu et al. 2011), excited molecular hydrogen (see Kamp et al. 2017), and polycyclic aromatic hydrocarbons in five different charging states (Thi et al. 2019), which is 3066 reactions altogether. H_{2} formation of grain surfaces is calculated according to Cazaux & Tielens (2002, 2004) with updates described in Cazaux & Spaans (2009); Cazaux & Tielens (2010). We use our standard element abundances (Table A.1), which are close to solar (C/O = 0.46) except for the depleted metals Na, Mg, Si, S, and Fe.
PAH molecules are included in the radiative transfer, with opacities calculated from their overall abundance and an assumed ratio between charged and neutral PAHs to avoid global iterations; see details in Woitke et al. (2016, 2019). PAHs are also included in the chemical network with five charging states (Thi et al. 2019), and are included in the calculation of heating and cooling rates, as the photoelectric effect on PAHs is one of the most important heating processes in the upper disc layers. The PAH heating rate is calculated from the calculated abundances of the different charging states, their individual photocross sections, and the calculated local radiation field.
In recent updates of our chemical network, we added a few handpicked gasphase reactions not included in UMIST 2012. One of these reactions turned out to be critical for the fitting of the JWST spectrum of EX Lupi (Sect. 3): $$\text{C}+{\text{H}}_{2}\text{O\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\to \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}HCO}+\text{H,}$$(52)
from Hickson et al. (2016), who measured surprisingly large rates for this reaction at low temperatures, enhanced by quantum mechanical tunnelling. Although the Kinetic Database For Astrochemistry (KIDA^{2}) does not include this reaction in their standard releases, they list it with Arrhenius parameters {α = 1.07 × 10^{−8}cm^{3}s^{−1}, β = −1.59 , γ = 0} with reference to Hickson et al. (2016). In our models, whenever a CObond is broken, for example by photodissociation or Xrayinduced reactions, this reaction would be very efficient in immediately reforming that bond, which would prohibit the subsequent formation of hydrocarbon molecules and HCN as discussed in Sect. 4.3. Tests show that if we were to include this reaction with the Arrhenius coefficients from the KIDA database, the C_{2}H_{2} column density in the line emitting regions of our EX Lupi model would decrease by a factor of about 300, and peak line flux at 13.7 µm would decrease by a factor of about 5. However, closer inspection of Fig. 3 in Hickson et al. (2016) shows that the Arrhenius coefficients {α = 4.2 × 10^{−13}cm^{3}s^{−1} , β = −2.5 , γ = 0} fit the original data points at 50 K, 75 K, and 100 K much better, and are consistent with the measurements of Husain & Kirsch (1971), which show that the rate coefficient of this reaction is very small at room temperature (< 10^{−12} cm^{3}s^{−1}). We therefore decided to use our own Arrhenius fit of this reaction in this paper.
Line selection criteria for the HITRAN 2020 database.
2.8 New HITRAN lineselection rules
The expansion from the Spitzer/IRS to the JWST/MIRI wavelength range made it necessary to revise our lineselection strategy, by which we import only a limited number of molecular lines from the HITRAN database. We also updated PRODIMO to use the HITRAN 2020 catalogue (Gordon et al. 2022) instead of the HITRAN 2012 catalogue. The imported data are the upper level energies E_{u}, line wavelengths λ_{ul}, Einstein coefficients A_{ul}, and level degeneracies g_{u}. The new HITRAN 2020 database has a greater number of lines, which, if we would import all lines, would vastly increase PRODIMO’s memory consumption. As explained in Woitke et al. (2018a), we therefore have to limit our line selection to lines with a minimum line strength, defined as $$\text{linestrength}={A}_{ul}\text{\hspace{0.17em}}{g}_{u}\text{\hspace{0.17em}}\mathrm{exp}\left(\frac{{E}_{u}}{k(1500\text{K})}\right)\text{.}$$(53)
In combination with further restrictions on wavelength range and upper level energy E_{u}, see Table 2, we aim to select only the relevant, strong observable lines. Together with the rovibrational CO lines of the first four vibrationally excited states (Thi et al. 2013), rovibrational H_{2}O lines, rotational lines of various molecules, and lines of atoms and ions (Woitke et al. 2018a), we are now tracing 64890 lines altogether in this model. All lines are automatically considered for heating and cooling.
2.9 Dust settling
Considering a turbulent onedimensional column of gas and dust, Mulders & Dominik (2012) write down the continuity equation for passive dust particles with a size distribution function f (a, z, t) as $$\frac{\partial f\left(a,z\right)}{\partial}=\frac{\partial}{\partial z}\underset{j\text{diff}}{\underbrace{\left(\rho \text{\hspace{0.17em}}{D}_{\text{d}}\left(a\right)\frac{\partial}{\partial z}\left(\frac{f\left(a,z\right)}{\rho}\right)\right)}}\frac{\partial}{\partial z}\underset{j\text{set}}{\underbrace{\left(f\left(a,z\right)\text{\hspace{0.17em}}{\stackrel{\xb0}{\upsilon}}_{\text{dr}}\left(a,z\right)\right)}},$$(54)
where ρ is the gas mass density, t the time, z the vertical coordinate, and a the dust particle radius. Assuming that there is no bulk gas motion, the grains are transported downwards by gravitational settling with their sizedependent equilibrium settling velocity ${\stackrel{\circ}{v}}_{\text{dr}}\text{\hspace{0.17em}}(a,z)$, and are transported upwards by eddy diffusion, The upward mixing is driven by vertical dust particle concentration gradients $\frac{\partial}{\partial z}\left(\frac{f(a,z)}{\rho}\right)$ and calculated according to the local dust diffusion coefficient D_{d}. Assuming that the grains have relaxed towards a steady state, we have for each size ∂/∂t f(a, z) → 0 and zero net flux j_{diff} – j_{set} → 0, and therefore $$\rho {D}_{\text{d}}\frac{\partial}{\partial z}\left(\frac{f(a,z)}{\rho}\right)=f(a,z)\text{\hspace{0.17em}}{\stackrel{\xb0}{\upsilon}}_{\text{dr}}(a,z),$$(55)
from which we find $$\frac{\partial}{\partial z}\left(\mathrm{ln}\frac{f\left(a,z\right)}{\rho}\right)=\frac{{\stackrel{\xb0}{\upsilon}}_{\text{dr}}\left(a,z\right)}{{D}_{\text{d}}}.$$(56)
For large Knudsen numbers and subsonic particle velocities (Epstein regime), the equilibrium settling velocity, also referred to as the terminal fall speed, is given by Schaaf (1963) $${\stackrel{\xb0}{\upsilon}}_{\text{dr}}(a,z)={g}_{z}{\tau}_{\text{stop}}(a,z)=z{\text{\Omega}}^{2}{\tau}_{\text{stop}}(a,z),$$(57)
where g_{z} is the vertical gravitational acceleration, and Ω is the Keplerian circular frequency. The stopping timescale, or frictional coupling timescale, is given by $${\tau}_{\text{stop}}(a,z)=\frac{{\rho}_{\text{m}}a}{\rho (z){v}_{\text{th}}},$$(58)
where ρ_{m} is the dust material density, and the thermal velocity is $${v}_{\text{th}}=\sqrt{\frac{8k{T}_{\text{g}}}{\pi \mu}}=\sqrt{\frac{8}{\pi}}{c}_{\text{S}},$$(59)
where k the Boltzmann constant, T_{g} the local gas temperature, µ the mean molecular weight, c_{S} the local isothermal speed of sound, and $p={c}_{\text{S}}^{2}\rho $ is the local gas pressure. Equation (58) appears to be widely incorrect in the literature, where c_{S} is often erroneously used instead of the correct mean of the magnitude of the thermal velocities of gas particles υ_{th}, as required in Schaaf’s formula; see Woitke & Helling (2003).
Eddy diffusion (‘turbulent mixing’) is assumed to be dominant over gaskinetic diffusion. The eddy diffusion coefficient is given by a characteristic velocity multiplied by a characteristic length, $${D}_{\text{gas}}=\langle {v}_{z}\rangle L,$$(60)
where L is the size of the largest eddies (‘mixing length’) and 〈υ_{z}〉 is the rootmeansquare average of the fluctuating part of the vertical gas velocities. In a Kolmogorovtype power spectrum P(k) ∝ k^{−5/3}, there are different turbulent modes associated with different wavenumbers k or different spatial eddy sizes l. Any given particles of size a tend to comove with the sufficiently large and slow turbulent eddies, whereas their inertia prevents them from following the shortterm, small turbulence modes. In order to arrive at an effective particle diffusion coefficient, the advective effect of all individual turbulent eddies has to be averaged, and thereby transformed into a collective particlediffusion coefficient. This procedure has been carried out, with different methods and approximations, by Dubrulle et al. (1995), Schräpler & Henning (2004), Youdin & Lithwick (2007), and Mulders & Dominik (2012). The result of Mulders & Dominik (2012) is $${D}_{\text{d}}=\frac{{D}_{\text{gas}}}{1+S{t}^{2}},$$(61)
where St is the Stokes number given by $$St=\frac{{\tau}_{\text{stop}}}{{\tau}_{\text{eddy}}}$$(62)
where τ_{eddy} is the eddy turnover or turbulence correlation timescale in consideration of the largest eddy, which is assumed to be equal to the mixing length L.
$${\tau}_{\text{eddy}}=\frac{L}{\langle {v}_{z}\rangle}.$$(63)
According to an α disc model (Shakura & Sunyaev 1973), the typical vertical length scale is $L=\sqrt{\alpha}\text{\hspace{0.17em}}{H}_{p}$ and ${v}_{z}=\sqrt{\alpha}\text{\hspace{0.17em}}{c}_{s}$ (Ormel et al. 2007), and therefore
$${D}_{\text{gas}}=\alpha \text{\hspace{0.17em}}{c}_{\text{S}}{H}_{p},$$(64) $${\tau}_{\text{eddy}}=\frac{{H}_{p}}{{c}_{\text{S}}}=\frac{1}{\text{\Omega}}.$$(65)
Our basic Eq. (56) for the balance between upward mixing and downward gravitational settling is therefore
$$\frac{\partial}{\partial z}\left(\mathrm{ln}\frac{f(a,z)}{\rho}\right)=\frac{z\text{\hspace{0.17em}\Omega}{\tau}_{\text{stop}}}{\alpha {H}_{p}^{2}}\left(1+S{t}^{2}\right),$$(66)
where all quantities on the right hand side of Eq. (66), that is, Ω, α, D_{gas}, T, c_{S}, µ, ρ, and ρ_{m}, can in general depend on height z. In addition, St and τ_{stop} depend on z and on grain size a.
Dubrulle et al. (1995) ignored all zdependencies on the ride hand side of Eq. (66) and replaced all variables with their midplane values. These authors also dropped the (1 + St^{2}) term. In that case, we can carry out the zintegration to find
$$\mathrm{ln}\frac{f(a,z)/f(a,0)}{\rho (z)/\rho (0)}=\frac{\text{\Omega}{\tau}_{\text{stop}}(0)}{\alpha {H}_{p}^{2}}{{{\displaystyle \int}}^{\text{}}}_{0}^{z}{z}^{\prime}d{z}^{\prime}=\frac{{z}^{2}}{2{H}_{p}^{2}}\frac{\text{\Omega}{\tau}_{\text{stop}}(0)}{\alpha}.$$
Introducing the sizedependent dust scale height H_{a} via $f(a,z)=f(a,0)\text{\hspace{0.17em}}\mathrm{exp}\text{\hspace{0.17em}}\left(\frac{{z}^{2}}{2{H}_{a}^{2}}\right)$, and using $\rho (z)=\rho (0)\text{\hspace{0.17em}}\mathrm{exp}\text{\hspace{0.17em}}\left(\frac{{z}^{2}}{2{H}_{p}^{2}}\right)$, the result is
$$\frac{{H}_{p}^{2}}{{H}_{a}^{2}}=1+\frac{\text{\Omega}{\tau}_{\text{stop}}(0)}{\alpha}.$$(67)
Riols & Lesur (2018) also drop the (1 + St^{2}) term in Eq. (66), but take into account that τ_{stop} depends on density, and is therefore zdependent. Furthermore, these authors explicitly assume a Gaussian for the vertical gas density distribution. In that case, the stopping timescale can be expressed as
$${\tau}_{\text{stop}}={\tau}_{\text{stop}}(0)\mathrm{\hspace{0.17em}exp\hspace{0.17em}}\left(\frac{{z}^{2}}{2{H}_{p}^{2}}\right),$$(68)
and integration of Eq. (66), assuming that α, c_{S}, H_{p}, and Ω are heightindependent, yields
$$\mathrm{ln}\frac{f(a,z)/f(a,0)}{\rho (z)/\rho (0)}=\frac{\text{\Omega}{\tau}_{\text{stop}}(0)}{\alpha {H}_{p}^{2}}{{{\displaystyle \int}}^{\text{}}}_{0}^{z}{z}^{\prime}\mathrm{exp}\left(\frac{{z}^{\prime 2}}{2{H}_{p}^{2}}\right)d{z}^{\prime},$$(69)
which reproduces Eq. (33) in Riols & Lesur (2018). The analytical solution of Eq. (69) is
$$\frac{{H}_{p}^{2}}{{H}_{a}^{2}(z)}=1+\frac{\text{\Omega}{\tau}_{\text{stop}}(0)}{\alpha}\left(\frac{2{H}_{p}^{2}}{{z}^{2}}\right)\left(\mathrm{exp}\left(\frac{{z}^{2}}{2{H}_{p}^{2}}\right)1\right).$$(70)
The decrease in H_{a} with respect to Eq. (67) is remarkable; the function (2/x^{2})^{[} exp(x^{2}/2) – 1] is 3.2 at x = 2, 20 at x = 3, and 370 at x = 4. Infrared emission lines from discs are quite typically emitted from layers located at about 3–4 scaleheights (Woitke et al. 2018b). The Riols & Lesur settling description reduces the local dust/gas ratios by orders of magnitude in these regions (see Fig. 7), and even reduces the abundance of the smallest grains at high altitudes. We suggest that Eq. (70) should become the standard in disc modelling; we have implemented it in PRODIMO, and used it in the present study.
However, in order to remain consistent with previous publications, in PRODIMO, we multiply the second terms on the right side of Eqs. (67) and (70) by a factor $\sqrt{1+{\gamma}_{0}}$, with γ_{0} = 2 for compressible turbulence, and incorrectly use c_{S} instead of υ_{th} in Eq. (57). These two changes amount to a factor of $\sqrt{8\times 3/\pi}\approx 2.8$, which can be compared to the uncertainty in the settling parameter α. Equation (70) can be generalised to a numerical integration of Eq. (56) for cases where $\rho (z)=\rho (0)\text{\hspace{0.17em}}\mathrm{exp}\text{\hspace{0.17em}}\left(\frac{{z}^{2}}{2{H}_{p}^{2}}\right)$ is not valid, and c_{S} = H_{p} Ω is not valid, for example in hydrostatic disc models where both the gas temperature and the mean molecular weight depend on z.
Fig. 7 PRODIMO model for the quiescent state of EX Lupi. The top plots show the assumed gas and dust column densities (left) and scale heights (right). The second row shows the corresponding gas densities (left) and gastodust mass ratio after settling (right). The third row shows the UV field strength χ (left), and the Xray ionisation rate ζ_{X} in comparison to the cosmicray ionisation rate (right). The bottom row shows the resulting dusttemperature (left) and gastemperature (right) structures. Additional contour lines show selected values for the vertical optical extinction A_{V} and the radial optical extinction A_{V,rad} as indicated.
2.10 Rounded inner rims
As previous Spitzer and recent JWST observations show (Banzatti et al. 2017, 2023; Kóspál et al. 2023; Grant et al. 2023; Tabone et al. 2023), the MIR line spectroscopy of discs first and foremost probes the physics and chemistry in the innermost disc regions ≲ 1 au, close to where the dust reaches its sublimation temperature, with lineemitting radii sometimes as small as 0.1 au for T Tauri stars. Therefore, the shape of the inner rim becomes a significant factor for understanding the new JWST spectra. Our knowledge about these inner disc regions is still rather limited, because of both the difficulty in observing these regions with sufficient resolution and the complexity of the physics involved. According to radiation hydrodynamics models, the direct stellar irradiation causes the dust around the inner rim to evaporate and form a puffedup inner rim (Natta et al. 2001; Dullemond et al. 2001; Dullemond & Monnier 2010). The radial transition in terms of gas surface density across the inner rim is not an infinitely sharp jump, but a relatively diffuse region, which means that the gas pressure stabilises the rim (Isella & Natta 2005; Kama et al. 2009; Woitke et al. 2009; Flock et al. 2017). In addition, evolutionary MHD models suggest that the switch from magnetically active inner disc to the dead zone may cause a local pressure maximum and formation of gas–dust rings (Masset et al. 2006; Dzyurkevich et al. 2010; Kadam et al. 2019, 2022), which causes a more gradual buildup of the column density towards the first pressure bump. Inspired by the inner disc structures suggested by these models, here we introduce a parametric approach, assuming
$$\begin{array}{l}\text{\Sigma}(r)\propto \mathrm{exp}\text{\hspace{0.17em}}\left[{\left(\frac{{R}_{\text{soft}}}{r}\right)}^{s}\right]\text{\hspace{0.17em}}{r}^{\u03f5}\mathrm{exp}\text{\hspace{0.17em}}\left[{\left(\frac{r}{{R}_{\text{tap}}}\right)}^{2\gamma}\right],\hfill \\ {R}_{\text{soft}}=\text{raduc}\times {R}_{\text{in}},\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}s=\frac{\mathrm{ln}[\mathrm{ln}(1/\text{reduc})]}{\mathrm{ln}(\text{raduc})},\hfill \end{array}$$(71)
where Σ(r) is the mass column density at radius r, raduc is the radius up to which the column density initially increases, in units of the inner disc radius R_{in}, and reduc is the factor by which the column density is reduced in Eq. (71) at R_{in}. As in previous publications, R_{tap} is the tapering off radius, and the selfsimilar solution is obtained for γ = ϵ, but we rather keep ϵ and γ as independent parameters.
In hydrostatic models, where the hydrostatic equilibrium is solved in each vertical column (Natta et al. 2001; Kama et al. 2009; Dullemond & Monnier 2010), we see large scaleheights at the inner rim that is directly heated by the star, followed by a dip in Hp(r) behind the inner rim, because the inner rim casts a shadow on the subsequent disc where the temperatures are lower; see for example Fig. 9 in Woitke et al. (2009) and Fig. 6 in Woitke et al. (2016). We introduce two more parameters to describe this ubiquitous feature of hydrostatic models:
$$\begin{array}{l}{H}_{p}(r)={H}_{0}{\left(\frac{r}{{r}_{0}}\right)}^{\beta}f(r),\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}f(r)=1\text{deduc}\times \mathrm{exp}\text{\hspace{0.17em}}\left({\left(\frac{\text{\Delta}r}{w}\right)}^{2}\right),\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\Delta}r=\mathrm{ln}\left(r/{R}_{\text{in}}\right)\mathrm{ln}(\text{daduc}),\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}w=\{\begin{array}{ll}\frac{1}{2}\mathrm{ln}(\text{deduc}),\hfill & \text{if\Delta}r<0\hfill \\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\mathrm{ln}(\text{deduc}),\hfill & \text{otherwise\u2019}\hfill \end{array}\hfill \end{array}$$(72)
where daduc is the dip radius in units of the inner radius, and deduc is the reduction of the scale height at the dip radius. The effect of the new disc shape parameters reduc, raduc, deduc, and daduc on column density structure and scale heights is visualised in the upper panel of Fig. 7.
3 The PRODIMO disc model for EX Lupi
3.1 Stellar setup
Our photometric data collection for the quiescent state of EX Lupi is shown in Table 3, and the assumed stellar properties are listed in Table 4. Stellar luminosity, effective temperature, and optical extinction are taken from Sipos et al. (2009). Stellar mass, distance to EXLupi, and disc inclination are taken from the collection of ALMA observations by White et al. (2020). The stellar excess UV parameters are derived from XMM UV photometric observations (see Table 3). The quantity f_{UV} = L_{UV}/L_{*} is the UV excess between 91.2 nm and 250 nm. p_{UV} is a powerlaw index explained in Appendix A of Woitke et al. (2016). The Xray properties are explained in Appendix A of Woitke et al. (2016) and are taken from measurements of Teets et al. (2012), which indicate a significant increase in the Xray luminosity during burst phase, in particular for the soft Xrays. The accretion rate Ṁ_{acc} = 4 × 10^{−10} M_{⊙} yr^{−1} is taken from SiciliaAguilar et al. (2015), which is used for viscous gas heating according to Eq. (2) in D'Alessio et al. (1998); see details in Woitke et al. (2019).
Recently, CruzSáenz de Miera et al. (2023) analysed an XSHOOTER spectrum of EX Lupi taken in July 2022, just one month before the JWST observations were carried out. This 0.3–2.2 µm spectrum suggests a much higher massaccretion rate of Ṁ_{acc} ≈ (2–3) × 10^{−8} M_{⊙} yr^{−1}. Another value was reported by Wang et al. (2023), namely Ṁ_{acc} ≈ 3 × 10^{−9} M_{⊙} yr^{−1}. The data analysis is intertwined with the determination of the optical extinction A_{V} of the star. CruzSáenz de Miera et al. 2023 arrive at a large value of A_{V} ≈ 1.1 using R_{V} = 3.1. In contrast, most published works on EX Lupi have so far assumed A_{V} ≈ 0, including Sipos et al. (2009). Varga et al. (2018) used A_{V} = 0.2, Alcalá et al. (2017) used A_{V} = 1.1, and Wang et al. (2023) used A_{V} = 0.1. If A_{V} is indeed as large as 1.1, the XMM photometric data would imply a ten times greater UV luminosity ( f_{UV} ≈ 0.1). Extrapolating the slabmodel for the continuum emission due to accretion of CruzSáenz de Miera et al. 2023 to shorter wavelengths, Ábrahám (2023, priv. comm.) derive f_{UV} ≈ 0.02, but this UV excess would not contain the strong emission lines, such as Lyα, because of stellar activity. A discussion on how our modelling results change if larger values of f_{UV} and Ṁ_{acc} are used can be found in Sect. 4.5.
Ansdell et al. (2018) observed EX Lupi with ALMA in band 6 continuum and ^{12}CO 2−1, measuring a continuum disc radius of 62 ± 2 au and a CO disc radius of 178 ± 12 au. Hales et al. (2018) also imaged the disc of EX Lupi with ALMA band 6 continuum and CO isotopologues, and fitted a disc model with a taperingoff radius of R_{tap} ≈ 20 au. Based on SPHEREIRDIS polarimetric observations, Rigliaco et al. (2020) favoured a scenario where the nearinfrared (NIR) light is scattered by a circumstellar disc rather than an outflow, and suggest that the disc region between about 10 and 30 au might be depleted in µmsized grains. Furlan et al. (2009) introduced an index that characterises the MIR SED slope by
$${n}_{1331}=\frac{\mathrm{log}\left({v}_{31}{F}_{{v}_{31}}\right)\mathrm{log}\left({v}_{13}{F}_{{v}_{13}}\right)}{\mathrm{log}\left({\lambda}_{31}\right)\mathrm{log}\left({\lambda}_{13}\right)},$$(73)
where λ_{13} = 13 µm, λ_{31} = 31 µm, v_{13}, and v_{31} are the corresponding frequencies, and ${F}_{{v}_{13}}$ and ${F}_{{v}_{31}}$ are the continuum fluxes [Jy] at λ_{13} and λ_{31}, respectively. This index has been used to identify transitional discs (n_{13–31} > 1), disc flaring, and dust settling (Furlan et al. 2009). From the Spitzer/IRS spectrum of EX Lupi shown by Kóspál et al. (2023), with reference to Ábrahám et al. (2009), we derive a value of n_{13–31} ≈ −0.57, which suggests a continuous disc.
Banzatti et al. (2023) defined two classes of discs: (i) compact discs with strong lowexcitation water lines and (ii) large discs, possibly with gaps and rings, with faint lowexcitation water lines. Banzatti et al. (2023) associated these classes with different waterice transport mechanisms by pebbles, favouring water enrichment in case (i), and water depletion in case (ii). Based on the published dust radii cited above, and the derived n_{13–31} value, EX Lupi is a relatively large but continuous disc, which does not clearly fall into either of these categories. We did not use any ALMA data in this study for the fitting, and assumed standard element abundances for our disc model; see Table A.1.
Photometric data collection for the quiescent state of EX Lupi.
Model parameters for the quiescent state of EX Lupi.
3.2 Disc shape
Finding a PRODIMO model setup that can roughly reproduce the observed JWST line and continuum data was a difficult task. Looking at Fig. 3 of Kóspál et al. (2023), the water emission lines and the peak emissions at the Qbranches of C_{2}H_{2}, HCN, and CO_{2} in the 13–17 µm spectral region all reach similar flux levels of the order of 30–60 mJy. This immediately tells us that all these spectral features must be optically thick, otherwise the certainly very different concentrations and masses of these molecules in the disc would result in very different flux levels. This conclusion is underlined by slabmodel fits presented by Kóspál et al. (2023), which resulted in column densities of order 10^{15} – 10^{16} cm^{−2} for C_{2}H_{2}, HCN, and CO_{2}, 10^{17} – 10^{18} cm^{−2} for H_{2}O, and approximately 10^{19} cm^{−2} for CO.
In our standard T Tauri disc model (with parameters listed in Table A.2), the lines of C_{2}H_{2} and HCN are emitted from radially extended, tenuous layers high in the disc (see Fig. 6), where UV photons dissociate CO and N_{2}, and the resulting carbon and nitrogen atoms react further to form some C_{2}H_{2} and HCN in the presence of H_{2}. Although we can explain the overall line flux levels of H_{2}O and CO_{2} from T Tauri stars this way, our standard models generally result in excessively low molecular column densities above the optically thick dust when compared to the values derived from slabmodel fits to observations (e.g. Banzatti et al. 2017).
The key idea for the EX Lupi model presented in this paper was to tap into the large reservoir of C_{2}H_{2} and HCN molecules that is present in our disc models in the midplane regions inside of 1 au, which are normally covered by dust opacity. To reveal these regions, we assume a slowly increasing surface density profile around the inner rim, combined with strong dust settling, which creates an almost dustfree gas around the inner dust rim; see Fig. 7. The parameters for this model are listed in Table 4. The position of the inner dust rim thereby becomes wavelength dependent. Using the radius where the vertical dust optical depth is one, the results are about 0.1 au at optical wavelengths, but about 0.4 au at λ = 15 µm in this model; see Sect. 4.2. For comparison, Sipos et al. (2009) used an inner hole of radius 0.2 au in their SED fits using RADMC to reproduce the relatively low continuum fluxes between 3 and 8 µm. This idea was later adopted by Juhász et al. (2012) and Ábrahám et al. (2019). MIDI interferometry of EX Lupi was presented by Varga et al. (2018), who measured a halflight radius of (0.77 ± 0.09) au.
3.3 Model fitting
Once an initial disc setup was found that could roughly reproduce the observed SED and JWST molecular line emission features within a factor of about 2–5, we utilised the (12, 1) genetic algorithm of Rechenberg (2000) – as explained in Woitke et al. (2019) – to optimise 17 parameters regarding disc shape, dust material and size, and PAHs. The optimised parameters are marked in Table 4. The genetic fitting algorithm seeks to minimise a total χ^{2},
$${\chi}^{2}=\frac{1}{4}{\chi}_{\text{phot}}^{2}+\frac{1}{4}{\chi}_{\text{JWST}}^{2}+\frac{1}{2}{\chi}_{\text{line}}^{2},$$(74)
in order to simultaneously fit the photometric data, the absolute JWST spectrum, and the continuumsubtracted JWST line spectrum. We used fast PRODIMO models with a lowresolution spatial grid 70 × 60 during the fitting phase. The models calculated the SED on 500 wavelength points between 0.1 µm and 4 mm. Based on these results, we calculated the mean quadratic deviation between model and photometric fluxes ${\chi}_{\text{phot}}^{2}$ using the various filter transmission functions and the mean quadratic deviation between model and the absolute JWST spectrum ${\chi}_{\text{JWST}}^{2}$. A minimum error of 10% was assumed for all photometric and spectral data points.
Each PRODIMO call was followed by two calls of the Fast Line Tracer (FLITS) developed by M. Min (Woitke et al. 2018a) in order to calculate highresolution model spectra between 4.9 and 7.5 µm (10353 lines) and between 13 and 17.7 µm (17228 lines), respectively, both with a velocity resolution of 3 km s^{−1}. Here we considered the atoms and ions Ne^{+}, Ne^{++}, Ar^{+}, Ar^{++}, Mg^{+}, Fe^{+}, Si^{+}, S, S^{+}, and S^{++}, and the molecules H_{2}O, OH, HCN, CO_{2}, NH_{3}, H_{2}, C_{2}H_{2}, CH_{4}, and CO. Each FLITS call calculates two spectra, a continuum model with only dust opacities and source functions, and a line and continuum model with dust and gas opacities and source functions. We then subtracted these two, and convolved the continuumsubtracted FLITS spectrum to a spectral resolution of 2500^{3}. To reduce the observational noise, we applied a boxfilter of size ${\lambda}_{i+1}^{\text{obs}}{\lambda}_{i1}^{\text{obs}}$ to both the observational data and the convolved model spectrum, where ${\lambda}_{i}^{\text{obs}}$ are the observational data points. Finally, we calculated the mean quadratic deviation between the continuumsubtracted FLITS model and the continuumsubtracted JWST data as ${\chi}_{\text{line}}^{2}$, where a 20 times higher weight was applied to the 13.5–14.1 µm and 14.8–15 µm spectral regions, which contain the crucial Qbranches of C_{2}H_{2}, HCN, and CO_{2}. We assume an error of $0.5\text{\%}\times {F}_{v}^{\text{obs}}$ for the observed continuumsubtracted flux, where ${F}_{v}^{\text{obs}}$ is the absolute JWST flux, to reflect the uncertainties in the continuum subtraction procedure.
Each combined PRODIMOFLITS model takes about 2 h of computational time on 16 CPUs. We ran 12 such models in parallel to complete one generation. The genetic optimisation was stopped after about 100–200 generations, which amounts to a computational cost of about 150 × 12 × 2h × 16 CPUs ≈ 60 000 CPU hours per genetic fitting run. We experimented with five such runs, using slightly different setups (total ~3 × 10^{5} CPU hours), and selected the best one for publication.
Finally, a highresolution 200 × 200 PRODIMO model was run for the bestfitting model to produce the results depicted in Figs. 7, 9, and 11. All PRODIMO models were performed with git version e8e68ec6 dated 2023/08/08.
4 The MIRlineemitting regions of EX Lupi
4.1 Physicochemical structure of the bestfitting model
Figure 7 shows the assumed gas and dust distributions in the bestfitting model. As discussed later in this section, the main lineemitting molecules observable with JWST are located at r ≈ 0.1–0.5 au around the optical disc surface marked by the A_{V,rad} = 1 line, which corresponds to relative heights of z/r ≈ 0.05–0.3 in this model. The dust settling according to the applied recipe of Riols & Lesur (2018) with α = 5 × 10^{−4} is so strong that the local gas/dust ratio is about 10^{4} along this line, and the calculated UV field strength χ is about 10^{4}–10^{6} at densities of 10^{10} – 10^{11} cm^{−3}, and so we need to discuss the physics and chemistry in a highdensity Xray photonDominated Region (XDR) with an unusually high gas/dust ratio.
We found the gas to be cooler than the dust in the lineemitting regions, but this does not lead to absorption lines in this model, because the dust is rather transparent at these radii. Therefore, the full column of gas located at these radii can contribute to the observable line spectrum in this model. Here, our working definition for molecular column densities – for the purpose to compare with the results from slabmodels – is
$${N}_{\text{col}}^{\text{line}}={\displaystyle {\int}_{z\left({\tau}_{\text{cont}}^{\text{ver}}\left({\lambda}^{\text{line}}\right)=1\right)}^{\infty}{n}_{\text{mol}}(z)dz,}$$(75)
which is the vertical integral over the molecular particle density down to the point where the dust becomes optically thick at line wavelength. In contrast, in our standard T Tauri disc model (see Fig. 6), the high gas column densities in the inner disc (> 10^{26} cm^{−2}), combined with a standard gas/dust ratio of 100, ensure that the disc is optically thick up to about three scale heights. In this case, the dust covers most of the molecular gas, and the molecular column densities defined by Eq. (75) are often found to be lower than those derived from observations.
Figure 8 shows the obtained SED fit, with a magnification of the MIR spectral region in comparison to the JWST spectrum. We did not attempt any detailed dust opacity fitting in this model, and so cannot expect a much better fit than this. We achieved a reduced χ_{phot} of 1.45 and χ_{JWST} = 0.81.
Figure 9 shows some selected molecular concentrations in our bestfit model. The JWST lineemitting regions are located just below the χ/n = 10^{−4} line, where the major phase transitions H → H_{2}, C → CO, and N → N_{2} occur. H_{2}O extends a little higher than this, to about T_{g} = 2000K, and OH even higher, to about T_{g} = 4000 K. The CO_{2}, HCN, and C_{2}H_{2} concentrations are more difficult to understand. These molecules obtain their maximum concentrations of about 10^{−6} – 10^{−5} not far from the midplane and inside the snowline. Concerning HCN and C_{2}H_{2}, there are also some radially extended, high, tenuous, and spatially thin photodissociation layers with maximum concentrations of 10^{−9} – 10^{−8} just below H/H_{2} ≈ 1000 and 100, respectively, but the major reservoir of these molecules is the close midplane, between about 0.1 au and 0.5 au, which in this model coincides with the MIR lineemitting regions. Normally, these regions are covered by dust opacity.
Figure 10 presents the line spectrum of the bestfitting PRODIMO–FLITS model in comparison to the continuumsubtracted JWST data (Kóspál et al. 2023). The spectral contributions of H_{2}O, CO, C_{2}H_{2}, HCN, CO_{2}, OH, and H_{2} are indicated by different colours. Our 2D disc model can reproduce most of the observed spectral features surprisingly well. We achieve an overall fit quality with reduced χ_{line} values of 3.2 and 2.1 in the spectral regions 4.9–7.5 µm and 13–17.7 µm, respectively. The HCN fluxes are slightly weak, and some of the water line peaks are slightly too shallow; for example, the lowexcitation water lines at longer wavelengths. However, some of the visible deviations are also affected by imperfect data reduction and continuum subtraction. We used the continuumsubtracted JWST data – as published in Kóspál et al. (2023; priv. comm. A. Banzatti) – reduced with JWST pipeline version 1.8.2 and continuumsubtracted at that time.
The fit is clearly not as good as what can be achieved with slabmodels, where one can directly tune the molecular column densities, the sizes of the emission areas, and the emission temperatures. Nevertheless, our model is able to simultaneously explain the SED, the overall spectral shape of the JWST spectrum, and the main characteristics of the line emissions from CO, from H_{2}O in both considered wavelength bands, and from the Qbranches of C_{2}H_{2}, HCN, and CO_{2} between 13.7 and 15 µm, and even some minor contributions of OH and H_{2}. In our model, all column densities, dust opacities, emission temperatures, and sizes of lineemitting areas are consistent results of our 2D thermochemical disc structure, and we are using this complex structure under an inclination of 32° to calculate our spectra.
Fig. 8 Fit of the SED of EX Lupi in the quiescent state. The orange and green data points in the upper plot are Herschel/SPIRE and ALMA measurements. The orange spectrum is the JWST/MIRI data. The lower plot shows a magnification of the MIR spectral region.
Total line fluxes ΣF_{line} [W m^{−2}], fluxmean column densities 〈N_{col}〉 [cm^{−2}], fluxmean emission temperatures 〈T_{g}〉 [K], and fluxmean emission radius interval 〈r_{1} – r_{2}〉 of molecules, considering all lines emitted in two different spectral regions in the 2D disc model.
Fig. 9 Resulting chemical concentrations ϵ_{i} = n_{i}/n_{〈H〉} of selected molecules in the PRODIMO disc model for EX Lupi. Additional contour lines are plotted as boundaries, including the ionisation parameter χ/n_{〈H〉} (i.e. the UV field strength divided by the hydrogen nuclei particle density) and the ratios of the concentrations of the major molecules. For example, ‘H/H2=100’ means that H atoms are 100 times more abundant than H_{2} molecules.
Fig. 10 Continuumsubtracted JWST spectrum (black line) in comparison to the PRODIMOFLITS disc model for EX Lupi. The coloured areas show the contributions of the different molecules to the total model line spectrum. These are therefore cumulative; i.e. the CO_{2}spectrum is plotted on top of the C_{2}H_{2}spectrum, the HCNspectrum on top of the (C_{2}H_{2}+CO_{2})spectrum, and so on, such that the top of the water spectrum represents the total continuumsubtracted model spectrum. The model spectrum has been convolved to R = 2500. Furthermore, both the observational data and the model spectrum were slightly boxfiltered before plotting in order to increase clarity; see main text. The broad bumps in the observational data (e.g. those around 6.3 µm and in the region 15.5 – 17.7 µm) are likely due to problems with the early data reduction and continuum subtraction.
4.2 Deriving column densities and emission temperatures from the 2D disc model
Table 5 lists some mean quantities of the molecular emission features derived from the 2D disc structure using the line fluxes and their analysis based on escape probability in faceon geometry; see Sect.2.2. We consider the molecular column densities N_{col} as defined in Eq. (75) as an integral upwards from the height z in the disc where the vertical continuum optical depth is one at line wavelength. This quantity depends on the considered line, because different lines are emitted from different radii and from different depths. We also compute mean molecular emission temperatures 〈T_{g}〉, where we read off the gas temperatures in the identified lineemitting regions, and the overall radial range of significant line emission. All these quantities are calculated by averaging over all lines of a selected molecule in a given spectral range and over all vertical columns in the disc model, weighted by the line flux that is generated by this column in this line, $\delta {F}_{\text{col}}^{\text{line}}$, where ${F}^{\text{line}}=\underset{\text{cols}}{{{\displaystyle \sum}}^{\text{}}}\text{\hspace{0.17em}\hspace{0.17em}}\delta {F}_{\text{col}}^{\text{line}}$ is the total line flux,
$$\begin{array}{l}\langle X\rangle =\frac{\underset{\text{lines}}{{{\displaystyle \sum}}^{\text{}}}{\displaystyle \sum _{\text{cols}}{X}_{\text{col}}^{\text{line}}\delta {F}_{\text{col}}^{\text{line}}}}{\underset{\text{lines}}{{{\displaystyle \sum}}^{\text{}}}{\displaystyle \sum _{\text{cols}}\delta {F}_{\text{col}}^{\text{line}}}},\hfill \\ \text{\Delta}X=\sqrt{\langle {X}^{2}\rangle {\langle X\rangle}^{2}}.\hfill \end{array}$$(76)
The resulting mean values and standard deviations for the molecular column densities 〈log_{10} N_{col}〉, the emission temperatures 〈T_{g}〉, and the radial line emission intervals are listed in Table 5. These data roughly match the characteristics derived from slabmodel fitting of the JWST EX Lupi observations as published by Kóspál et al. (2023), with CO having the largest column density of order 10^{19}cm^{−2}, followed by water, and then the molecules C_{2}H_{2}, HCN, and CO_{2}, with column densities of 10^{17} – 10^{18} cm^{−2}. The water emission temperature is found to be about 600–700 K depending on wavelength. The emission temperatures of C_{2}H_{2} and HCN are found to be similar, 580–750 K, whereas CO_{2} emits at somewhat lower temperatures of ~300 K in the model. In contrast, the weak OH emission lines are emitted from much hotter gas, of namely ~1700 K. These trends are in general agreement with slabmodel fits published for other TTauri stars (Salyk et al. 2011; Grant et al. 2023; Tabone et al. 2023). Interestingly, we also modelled NH_{3} and CH_{4} lines, but although the column densities of these molecules are not small in the model, these lines do not show up, or even go into absorption at shorter wavelengths.
Figure 11 visualises the lineemitting regions of the various molecules in two different spectral bands. We see a pattern that reoccurs in almost all PRODIMO models. The OH lines are emitted from the highest disc layers. Here, the OH molecule is crucial for cooling down the otherwise hot atomic gas, even before H_{2} becomes the dominant molecule. Below this OHemitting layer, we find that first CO and then H_{2}O are emitting. The lower row of plots shows the corresponding gas temperatures and shows that the carbontooxygen ratio C/O in the gas phase is constant at C/O = 0.46 by assumption in the model, except in the region where water ice is found to condense, which happens in the midplane outside of about 2 au in this model.
What is special in this particular disc model for EX Lupi is that the low and increasing surface densities around the inner rim (only ~5 × 10^{22} cm^{−2} at r = 0.1 au) causes very efficient dust settling, which reveals an almost dustfree gas. Indeed, the molecular column densities above the $z\left({\tau}_{\text{cont}}^{\text{ver}}\left({\lambda}^{\text{line}}\right)=1\right)$ level are much larger at small radii in this model than in our standard T Tauri model (2 × 10^{26} cm^{−2} at r = 0.1 au), which uses a sharp inner rim. Therefore, line emissions by C_{2}H_{2} and HCN from deep layers close to the midplane at small radii become visible. We see that the lineemitting regions of C_{2}H_{2} and HCN approximately spatially coincide, whereas the lineemitting region of CO_{2} is located further out, which explains the somewhat lower emission temperature of CO_{2}. All these molecules emit from significantly deeper layers compared to OH, CO, and H_{2}O, which explains why the emission temperatures of the latter molecules are usually higher.
Figure 12 shows that at short wavelengths (≈ 5 µm), the lines and the continuum are coming from roughly the same disc regions, and so this is where absorption lines are more likely to occur. In contrast, at longer wavelengths (≈ 20 µm), the continuum is produced by more distant disc regions than the lines, and so a simple addition of continuum and line emission is valid, as is implicitly assumed in all slabmodels.
Fig. 11 Location and physical properties in the MIR lineemission regions of the EX Lupi disc model. Upper row: Lineemitting regions of different molecules in two different spectral bands in the bestfitting EX Lupi model. The left upper plot considers λ = 407 µm, and the right upper plot λ = 1317 µm. The white lines at the bottom of the plots mark the location where the vertical continuum optical depth is one, considering an average of the wavelengths of all water lines in the considered wavelength region. The bottom row shows the corresponding gas temperatures (left) and the carbontooxygen ratio C/O in the gas phase (right). C/O = 0.46 is constant by assumption, except for the region where water ice is found to be stable, where C/O instantly jumps to very large values of >1000.
Fig. 12 Continuumemitting regions responsible for about 50% of the flux at different wavelengths under faceon inclination. Contour lines for the vertical optical extinction A_{V} at 1 and 10 are added.
4.3 Chemical pathways
For each molecule, we analysed the chemistry in the centre of the respective lineforming regions as depicted in Fig. 11. For OH, H_{2}O, and CO_{2}, we do not need a very sophisticated chemistry to understand their formation; a few basic photoreactions in combination with neutralneutral reactions, and the H_{2}formation on grains, are sufficient. Previous work on such chemical pathways can be found for example in Thi & Bik (2005), Glassgold et al. (2009), Woitke et al. (2009), and Najita et al. (2011).
At the top of the photodissociation layer at r = 0.2 au, where A_{V,rad} ≈ 0.07 (optically thin), the gas temperature is of the order of 3000 K, carbon is mostly ionised, oxygen is atomic, and there is almost no molecular hydrogen yet: ${n}_{\text{H}}/{n}_{{\text{H}}_{2}}\approx 10\text{\hspace{0.17em}}000$. In these circumstances, the first IRactive molecule to form is OH, with concentrations of ~10^{−7} via $$\text{H}+\text{H}\stackrel{\text{dust}}{\to}{\text{H}}_{2}\stackrel{\text{O}}{\to}\text{OH}+\text{H}.$$(77)
The amount of OH that can form in this way is limited by the photodissociation of OH, and by the back reaction OH + H → O + H_{2}.
In only slightly lower layers, where A_{V,rad} ≈ 0.3, the gas temperature is ~1500 K, carbon is still mostly ionised, oxygen is atomic, and ${n}_{\text{H}}/{n}_{{\text{H}}_{2}}\approx 200$. Here, OH reacts further to form water with concentrations of ~10^{−7} : $$\text{OH}+{\text{H}}_{2}\text{\hspace{0.17em}\hspace{0.17em}}\to \text{\hspace{0.17em}\hspace{0.17em}}{\text{H}}_{2}\text{O}+\text{H,}$$(78)
limited by H_{2}O photodissociation.
CO_{2} forms in similar ways to water, but only in deeper regions where H_{2} and CO are already abundant; see for example Thi & Bik (2005). At r = 0.5 au, at a height where Av,rad ≈ 3 and A_{v} ≈ 0.2, we find T_{g} ≈ T_{d} ≈ 360 K. Carbon is mostly present in the form of CO, oxygen is present in H_{2}O, and hydrogen in H_{2}. Under these circumstances, CO_{2} reaches concentrations of ~10^{−7} via $$\text{OH}+\text{C\hspace{0.17em}\hspace{0.17em}}\to \text{\hspace{0.17em}\hspace{0.17em}CO}+\text{H}$$(79) $$\text{OH}+\text{CO\hspace{0.17em}\hspace{0.17em}}\to \text{\hspace{0.17em}\hspace{0.17em}}{\text{CO}}_{2}+\text{H,}$$(80)
limited by CO_{2} photodissociation.
The formation of HCN and C_{2}H_{2} in the close midplane is more complicated; see Fig. 11. Previous works on the chemical pathways of these species have been published; for example by Walsh et al. (2015) and Bosman et al. (2022a,b). Similar to CO_{2}, UVshielded conditions are required, but Xrays also play an important role here, and this is why these lineemitting regions need to be so close to the star, before the Xrays are absorbed by the gas. At r = 0.1 au, at a height where A_{V,rad} ≈ 7 and A_{v} ≈ 0.7, we find T_{g} ≈ 640 K and T_{d} ≈ 630 K. As before, carbon is in CO, oxygen in H_{2}O, nitrogen in N_{2}, and hydrogen in H_{2}. The chemical destruction timescales due to Xray ionisations are about ζ_{X} ≈ 10^{−10} s^{−1} in this region, which means typical Xray molecular lifetimes are a few hundred years.
Figure 13 shows the chemical pathways in this region leading to HCN and C_{2}H_{2}. A similar analysis was presented by Walsh et al. (2015), see their Sect. 3.2.2. The starting point is the Xraydriven dissociation of CO, N_{2}, and H_{2}, which creates small amounts of C^{+}, N, N^{+}, and e^{−}. By fast H_{2}addition reactions, C^{+} forms CH_{3}^{+}, which recombines dissociatively to CH, which is in kinetic equilibrium with CH_{2}. These two neutral molecules react with N and C to eventually form HCN and C_{2}H_{2}. Another reaction chain starts with N^{+}. By fast H_{2}addition reactions, N^{+} forms NH_{4}^{+}, which recombines dissociatively to NH_{3}. NH_{3}, NH_{2}, and NH are in kinetic equilibrium with each other (neutralneutral reactions vs. photodissociation), and the reaction NH + C → CN + H contributes to the production of CN, in addition to the reactions CH_{2} + N → CN + H_{2} and CH + N → CN + H from the reaction chain starting with C^{+}. CN is in kinetic equilibrium with HCN. We find large concentrations of HCN and C_{2}H_{2} this way, ~10^{−5} and 10^{−6}, respectively.
Neutral carbon primarily forms via the C_{3} + hv → C_{2} + C reaction, and is mainly destroyed by the C_{2}H_{2} + C → C_{3}H + H and C_{2}H_{2} + C → C_{3} + H_{2} reactions as indicated in the diagram. Concerning the C + H_{2}O → HCO + H reaction, if we were to use reaction parameters from the KIDA database (see Sect. 2.7), the concentration of C atoms would be strongly reduced, and the formation of HCN and C_{2}H_{2} strongly suppressed. In the situation shown in Fig. 13, the C + H_{2}O → HCO + H reaction only contributes with a rate of 7 × 10^{−2} cm^{−3}s^{−1} to the destruction of neutral carbon, that is, with less than 4%.
4.4 Chemical and cooling timescales
The chemical relaxation timescales (see Eq. (117) in Woitke et al. 2009) in the lineemitting regions are of order 0.1–10 yr.
Although this is short compared to overall disc evolutionary timescales, this could mean that the chemistry is not yet fully relaxed, because EX Lupi went through a phase of seventimesstronger accretion about 5 months before the JWST spectrum was taken (Kóspál et al. 2023). The cooling timescales are shorter, about 10^{−3} − 0.1 yr, and so we do not expect any significant memory effects concerning the gas temperature in the lineemitting regions.
The most important heating and cooling processes in the inner disc of the EX Lupi model are shown in Fig. 14. In the IR lineemission regions around and below the A_{V,rad} = 1 line, inside of about 0.5 au, there are three significant heating mechanisms: (1) viscous heating, (2) absorption of IR continuum photons – emitted from the star and from the disc – by water molecules, and (3) photodissociation heating. This heating is mostly balanced by water, CO, and OH line cooling. Below the A_{V,rad} = 1 line, relevant for the HCN and C_{2}H_{2} line emissions, there is simply a balance between water line heating and cooling. Therefore, this region has a rather specific temperature, namely the radiative equilibrium temperature in consideration of the water line opacity. As the water line opacity has a redder characteristic than the dust opacity, this region is generally found to be somewhat cooler than the local dust temperature T_{g} < T_{đ}. However, for higher massaccretion rates, the viscous heating will eventually cause T_{g} > T_{đ}.
Fig. 13 Reaction pathways to form HCN and C_{2}H_{2} in the close midplane, where n_{〈H〉}> = 2 × 10^{11} cm^{−3}, T_{g} = 640 K, T_{d} = 630 K, A_{V,rad} = 7, and A_{V} = 0.7. The major species are marked with thick boxes. Red species are rare and created by Xray processes. The green numbers are the particle concentrations n_{mol}/n_{〈H〉}, and the blue numbers are the rates [cm^{−3}s^{−1}]. Wiggly arrows indicate photodissociation, and red arrows indicate Xray processes: XPHOT is the Xray primary ionisation of He, and XG and XI are the Xray secondary ionisations by fast electrons.
4.5 Dependencies on L_{UV}, L_{X}, and Ṁ_{acc}
The analysis of the chemical pathways in Sect. 4.3 suggests that the line fluxes of OH and H_{2}O should depend on the UV luminosity of the star, whereas the HCN and C_{2}H_{2} lines should be excited by Xrays. Table 6 shows that in our models, indeed the OH and H_{2}O lines become stronger with increasing stellar UV luminosity. Both the sizes of the lineemitting areas and the emission temperatures become larger when L_{UV} is increased. This trend is confirmed by observations (e.g. Fig. 3 in Banzatti et al. 2023), which show a positive correlation between the H_{2}O line luminosity and accretion luminosity, which physically implies larger L_{UV}. The highUV model can be considered to represent a case in which a larger optical extinction A_{V} was assumed for EX Lupi; see discussion in Sect. 3.1. From a theoretical point of view, the positive correlation with L_{UV} is expected from the global energy budget of the gas in the inner disc, which is heated by stellar UV photons, and mainly cools through water emission lines. As long as the UV is mostly absorbed by the gas and not by the dust, a higher stellar UV luminosity should therefore result in stronger water emission lines. Both the OH and water line luminosities are not significantly affected by the Xray luminosity. Concerning the increase in the massaccretion rate, OH is not affected, but the water lines become slightly brighter. This is because the water emissions come from slightly deeper regions than OH, where viscous heating is more relevant; see Fig. 14.
The HCN and C_{2}H_{2} lines behave in a different way. They actually become weaker with increasing UV, because photodissociation limits the concentrations that can build up at given Xrayinduced production rates. Table 6 shows how the column densities of HCN and C_{2}H_{2} decrease when L_{UV} is increased. However, only the C_{2}H_{2} lines become clearly stronger and the C_{2}H_{2} column density clearly larger when L_{X} is increased. The HCN line fluxes and column densities remain at a similar level as LX is varied. The lineemitting areas and emission temperatures of all considered molecules do not change significantly when L_{X} is changed; it is the column densities that are affected, which is a chemical effect.
Table 6 also shows the results for a model with a threetimeshigher massaccretion rate, a value that is close to the Ṁ_{acc} reported by Wang et al. (2023) for EX Lupi. While the H_{2}O, OH, and CO_{2} line fluxes and their characteristics remain rather similar, the HCN and C_{2}H_{2} lines show a strong response. Their line fluxes increase by factors of 3.0 and 2.6, respectively, while also increasing their column densities and emission temperatures. This effect is likely related to the fact that these emission lines come from relatively deep disc layers, where the viscous heating is more relevant; see Fig. 14. In addition, the line photons have to outshine the continuum photons – which come from even deeper layers – to create an emission line. The observable line fluxes therefore depend on the contrast between line and continuum emission temperatures. Although the viscous heating due to Ṁ_{acc} only slightly increases T_{g} locally in the deep lineemitting regions, it has a profound impact on the temperature contrast T_{g} − T_{d}, creating an almost linear response to increasing Ṁ_{acc}.
5 Summary and conclusions
We implemented a number of new theories and improvements in our thermochemical disc modelling code PRODIMO. These improvements include a new escape probability method for spectral lines, which is relevant for the calculation of line heating and cooling rates, a new treatment of dust settling, and a new concept to apply UV molecular shielding factors to photorates within a 2D disc geometry. We show that these measures altogether result in significant changes to our predicted MIR molecular line spectra. The last column in Table 6 shows that the same disc model with the previous code version concerning escape probability, molecular shielding, and dust settling results in molecular emission features that are too strong for CO_{2} by a factor of 4, and too weak for HCN and C_{2}H_{2} by factors of 80 and 40, respectively. The code improvements allow us to get closer to the observed JWST spectra and to the molecular properties derived from slabmodel fits, such as column densities, molecular emission temperatures, and lineemitting areas.
Based on the new PRODIMO code, we developed a disc model for the quiescent state of the T Tauri star EX Lupi that can simultaneously fit the SED, the overall spectral shape of the JWST spectrum, and all important molecular emission features in the continuumsubtracted JWST spectrum between 4.9 µm and 7.5 µm, and between 13 µm and 17.7 µm, including CO, H_{2}O, OH, C_{2}H_{2}, HCN, CO_{2}, and H_{2}. To the best of our knowledge, this is the first time that a full Spitzer or JWST line spectrum has been fitted using the complex 2D disc structure of a thermochemical model, with consistent dust opacities, molecular concentrations, and calculated dust and gas temperatures.
Our model uses standard element abundances with solar carbontooxygen ratio (C/O = 0.46) throughout the disc. However, we do not claim that this is a unique solution. If the transport by pebble drift and subsequent sublimation of water (e.g. Booth & Ilee 2019; Banzatti et al. 2023) or carbonaceous grains and PAHs (e.g. Nazari et al. 2023; Tabone et al. 2023) can be taken into account in a quantitative way, it is very likely that other disc shapes will be able to fit the JWST data.
Our model explains the observed molecular emission features by a slowly increasing surface density profile around the inner rim in combination with strong dust settling, which creates an almost dustfree gas with large molecular column densities above the settled dust. According to this model, the observed line emissions are produced mostly by the inner disc 0.1–0.5 au, with a certain layered structure, where hot OH emits from the top, warm CO and H_{2}O emit from the middle, and C_{2}H_{2}, HCN, and CO_{2} emit from deeper layers. The CO_{2}emitting region is located slightly further away from the star as compared to C_{2}H_{2} and HCN, leading to lower CO_{2} emission temperatures. This pattern is in agreement with the general trends published for a number of T Tauri stars observed with Spitzer (e.g. Salyk et al. 2011; Najita et al. 2013; Banzatti et al. 2020) and JWST (Grant et al. 2023; Tabone et al. 2023; Banzatti et al. 2023).
At the top of the photodissociation layer, the OH molecule plays a key role in forming CO and H_{2}O, and in cooling down the predominantly atomic gas from about 4000 K to 2000 K before the water cooling takes over, which establishes temperature conditions wherein, subsequently, other molecules can form as well. This happens at densities of about ~10^{9}−10^{10} cm^{−3} in the inner disc, where it seems critical to have a nonLTE treatment of the statistical populations of the excited rovibrational states of the OH molecule. The required collisional rates are available in the literature  see for example Rahmann et al. (1999); Tabone et al. (2021) – but are not yet implemented in PRODIMO. Concerning the line emissions from C_{2}H_{2}, HCN, and CO_{2}, this seems less critical, because these lines are emitted from a denser gas >10^{11}cm^{−3}.
The existence of large amounts of HCN and C_{2}H_{2} molecules in the oxygenrich gas inside of the snowline is a consequence of an Xraydriven chemistry in our model, where the most abundant CO and N_{2} molecules are partly dissociated by He^{+} created by the Xray irradiation. Similar conclusions were presented by Walsh et al. (2015). These free atoms and ions quickly form C_{2}H_{2} and HCN in large concentrations of about 10^{−6} to 10^{−5} in our model. But this effect is limited to the regions close to the inner rim, before the Xrays get absorbed by the gas. The chemical and cooling timescales are short in the lineemitting regions, that is, shorter than about 10 yr and 0.1 yr, respectively.
Our models show that the water and OH line luminosities increase with stellar UV luminosity, whereas the HCN and C_{2}H_{2} lines show the opposite trend. We predict a positive correlation between C_{2}H_{2} line luminosity and stellar Xray luminosity. Concerning the massaccretion rate Ṁ_{acc}, our models show an almost linear response of both the HCN and C_{2}H_{2} line luminosities, whereas other molecular emissions are less affected.
Fig. 14 Leading heating (left) and cooling processes (right) in the bestfitting EX Lupi model. The plots show a magnification of the inner disc relevant for the IR molecular line emissions. The dashed contour line marks the disc surface, where the radial optical extinction A_{V,rad} = 1.
Total line fluxes ${\sum}_{\text{line}}{F}_{\text{mol}}^{\text{line}}}\text{\hspace{0.17em}}\left[{\text{Wm}}^{2}\right]$ [W m^{−2}], column densities 〈N_{col}〉 [cm^{−2}], emission temperatures 〈T_{g}〉 [K], and emitting radii 〈r_{1} − r_{2}〉 [au] of selected molecules, affected by stellar UV luminosity, Xray luminosity, and massaccretion rate, considering all lines between 13 and 17.7 µm.
Acknowledgements
P.W. acknowledges funding from the European Union H2020MSCAITN2019 under Grant Agreement no. 860470 (CHAMELEON). I.K. and A.M.A. acknowledge support from grant TOP1 614.001.751 from the Dutch Research Council (NWO).
Appendix A Additional figures and tables
Table A.1 shows the element abundances assumed throughout this paper, ${n}_{\langle \text{el}\rangle}/{n}_{\langle \text{H}\rangle}=10{\text{\hspace{0.17em}}}^{{\u03f5}_{\text{el}}12}$. The assumed carbontooxygen ratio is 0.46. This table is a copy of Table 5 in Kamp et al. (2017). In the case of the bestfitting EX Lupi model, the PAH abundance is larger by a factor of 2.9, and so ϵ_{PAH} = 5.94.
Figure A.1 shows vertical cuts through the disc at r = 0.1 au, 0.3 au, 1 au, 3 au, 10 au, and 30 au through our standard T Tauri disc model after the PRODIMO changes discussed in Sect. 2.1. This figure shows more details than Figure 2, but both figures show the same model.
Element abundances assumed throughout this paper.
Parameters for the PRODIMO standard T Tauri disc model.
Fig. A.1 Vertical cuts at r = 0.1 au, 0.3 au, and 1 au through the standard PRODIMO T Tauri disc model after the code modifcations described in Sect. refsec:CodeChanges. The xaxis is the hydrogen nuclei column density measured from the top, relevant line formation typically happens between about 10^{21} cm^{−2} and 10^{24} cm^{−2}. The left plots show the assumed hydrogen nuclei particle density n_{〈H〉} and the calculated gas and dust temperatures. The middle and left plots show the relevant heating and cooling rates, annotated below, where the thick grey line is the total heating and cooling rate. We note that ${{\displaystyle \sum}}^{\text{}}\text{\hspace{0.17em}}{Q}_{\text{heat}}={{\displaystyle \sum}}^{\text{}}\text{\hspace{0.17em}}{Q}_{\text{cool}}$. An individual heating or cooling rate is plotted when it reaches at least 15% of the total heating and cooling rate anywhere in the depicted vertical range.
Fig. A.1 continued. Vertical cuts at r = 3 au, 10 au, and 30 au
References
 Abraham, P., Juhász, A., Dullemond, C. P., et al. 2009, Nature, 459, 224 [NASA ADS] [CrossRef] [Google Scholar]
 Abraham, P., Chen, L., Kóspál, A., et al. 2019, ApJ, 887, 156 [NASA ADS] [CrossRef] [Google Scholar]
 Agúndez, M., Cernicharo, J., & Goicoechea, J. R. 2008, A & A, 483, 831 [Google Scholar]
 Akimkin, V., Zhukovska, S., Wiebe, D., et al. 2013, ApJ, 766, 8 [NASA ADS] [CrossRef] [Google Scholar]
 Alcalá, J. M., Manara, C. F., Natta, A., et al. 2017, A & A, 600, A20 [CrossRef] [EDP Sciences] [Google Scholar]
 Anderson, D. E., Blake, G. A., Cleeves, L. I., et al. 2021, ApJ, 909, 55 [NASA ADS] [CrossRef] [Google Scholar]
 Ansdell, M., Williams, J. P., Trapman, L., et al. 2018, ApJ, 859, 21 [NASA ADS] [CrossRef] [Google Scholar]
 Aresu, G., Kamp, I., Meijerink, R., et al. 2011, A & A, 526, A163 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Banzatti, A., Pontoppidan, K. M., Salyk, C., et al. 2017, ApJ, 834, 152 [NASA ADS] [CrossRef] [Google Scholar]
 Banzatti, A., Pascucci, I., Bosman, A. D., et al. 2020, ApJ, 903, 124 [NASA ADS] [CrossRef] [Google Scholar]
 Banzatti, A., Pontoppidan, K. M., Carr, J. S., et al. 2023, ApJ, 957, L22 [NASA ADS] [CrossRef] [Google Scholar]
 Bethell, T., & Bergin, E. 2009, Science, 326, 1675 [NASA ADS] [CrossRef] [Google Scholar]
 Black, J. H., & van Dishoeck, E. F. 1987, ApJ, 322, 412 [Google Scholar]
 Booth, R. A., & Ilee, J. D. 2019, MNRAS, 487, 3998 [CrossRef] [Google Scholar]
 Bosman, A. D., Bruderer, S., & van Dishoeck, E. F. 2017, A & A, 601, A36 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Bosman, A. D., Bergin, E. A., Calahan, J., & Duval, S. E. 2022a, ApJ, 930, L26 [NASA ADS] [CrossRef] [Google Scholar]
 Bosman, A. D., Bergin, E. A., Calahan, J. K., & Duval, S. E. 2022b, ApJ, 933, L40 [NASA ADS] [CrossRef] [Google Scholar]
 Bruderer, S., Harsono, D., & van Dishoeck, E. F. 2015, A & A, 575, A94 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Carr, J. S., & Najita, J. R. 2008, Science, 319, 1504 [Google Scholar]
 Carr, J. S., & Najita, J. R. 2011, ApJ, 733, 102 [NASA ADS] [CrossRef] [Google Scholar]
 Cazaux, S., & Tielens, A. G. G. M. 2002, ApJ, 577, L127 [NASA ADS] [CrossRef] [Google Scholar]
 Cazaux, S., & Tielens, A. G. G. M. 2004, ApJ, 604, 222 [NASA ADS] [CrossRef] [Google Scholar]
 Cazaux, S., & Spaans, M. 2009, A & A, 496, 365 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Cazaux, S., & Tielens, A. G. G. M. 2010, ApJ, 715, 698 [NASA ADS] [CrossRef] [Google Scholar]
 Ciesla, F. J., & Cuzzi, J. N. 2006, Icarus, 181, 178 [NASA ADS] [CrossRef] [Google Scholar]
 CruzSáenz de Miera, F., Kóspál, A., Abraham, P., et al. 2023, A & A, 678, A88 [CrossRef] [EDP Sciences] [Google Scholar]
 D'Alessio, P., Cantö, J., Calvet, N., & Lizano, S. 1998, ApJ, 500, 411 [Google Scholar]
 Draine, B. T., & Bertoldi, F. 1996, ApJ, 468, 269 [Google Scholar]
 Du, F., & Bergin, E. A. 2014, ApJ, 792, 2 [NASA ADS] [CrossRef] [Google Scholar]
 Dubrulle, B., Morfill, G., & Sterzik, M. 1995, Icarus, 114, 237 [Google Scholar]
 Dullemond, C. P., & Monnier, J. D. 2010, ARA & A, 48, 205 [NASA ADS] [CrossRef] [Google Scholar]
 Dullemond, C. P., Dominik, C., & Natta, A. 2001, ApJ, 560, 957 [NASA ADS] [CrossRef] [Google Scholar]
 Dzyurkevich, N., Flock, M., Turner, N. J., Klahr, H., & Henning, T. 2010, A & A, 515, A70 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Flock, M., Fromang, S., Turner, N. J., & Benisty, M. 2017, ApJ, 835, 230 [CrossRef] [Google Scholar]
 Furlan, E., Watson, D. M., McClure, M. K., et al. 2009, ApJ, 703, 1964 [Google Scholar]
 Glassgold, A. E. , & Najita, J. R. 2015, ApJ, 810, 125 [NASA ADS] [CrossRef] [Google Scholar]
 Glassgold, A. E., Meijerink, R., & Najita, J. R. 2009, ApJ, 701, 142 [NASA ADS] [CrossRef] [Google Scholar]
 Gordon, I. E., Rothman, L. S., Hargreaves, R. J., et al. 2022, J. Quant. Spec. Radiat. Transf., 277, 107949 [NASA ADS] [CrossRef] [Google Scholar]
 Grant, S. L., van Dishoeck, E. F., Tabone, B., et al. 2023, ApJ, 947, L6 [NASA ADS] [CrossRef] [Google Scholar]
 Greenwood, A. J., Kamp, I., Waters, L. B. F. M., Woitke, P., & Thi, W. F. 2019, A & A, 626, A6 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Gu, H., Cui, J., Niu, D. D., et al. 2020, AJ, 159, 39 [NASA ADS] [CrossRef] [Google Scholar]
 Hales, A. S., Pérez, S., Saito, M., et al. 2018, ApJ, 859, 111 [Google Scholar]
 Heays, A. N., Bosman, A. D., & van Dishoeck, E. F. 2017, A & A, 602, A105 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Hickson, K. M., Loison, J.C., NunezReyes, D., & Mereau, R. 2016, arXiv eprints [arXiv: 1608.08877] [Google Scholar]
 Hummer, D. G., & Rybicki, G. B. 1985, ApJ, 293, 258 [NASA ADS] [CrossRef] [Google Scholar]
 Husain, D., & Kirsch, L. J. 1971, Chem. Phys. Lett., 9, 412 [NASA ADS] [CrossRef] [Google Scholar]
 Isella, A., & Natta, A. 2005, A & A, 438, 899 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Juhász, A., Dullemond, C. P., van Boekel, R., et al. 2012, ApJ, 744, 118 [Google Scholar]
 Kadam, K., Vorobyov, E., Regály, Z., Kóspál, A., & Ábrahám, P. 2019, ApJ, 882, 96 [NASA ADS] [CrossRef] [Google Scholar]
 Kadam, K., Vorobyov, E., & Basu, S. 2022, MNRAS, 516, 4448 [NASA ADS] [CrossRef] [Google Scholar]
 Kama, M., Min, M., & Dominik, C. 2009, A & A, 506, 1199 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kamp, I., & Bertoldi, F. 2000, A & A, 353, 276 [NASA ADS] [Google Scholar]
 Kamp, I., Thi, W. F., Woitke, P., et al. 2017, A & A, 607, A41 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kanwar, J., Kamp, I., Woitke, P., et al. 2024, A & A, 681, A22 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kokoulina, E., Matter, A., Lopez, B., et al. 2021, A & A, 652, A61 [CrossRef] [EDP Sciences] [Google Scholar]
 Kóspál, Á., Ábrahám, P., Diehl, L., et al. 2023, ApJ, 945, L7 [CrossRef] [Google Scholar]
 Li, X., Heays, A. N., Visser, R., et al. 2013, A & A, 555, A14 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lommen, D. J. P., van Dishoeck, E. F., Wright, C. M., et al. 2010, A & A, 515, A77 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Masset, F. S., Morbidelli, A., Crida, A., & Ferreira, J. 2006, ApJ, 642, 478 [Google Scholar]
 McElroy, D., Walsh, C., Markwick, A. J., et al. 2013, A & A, 550, A36 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mulders, G. D., & Dominik, C. 2012, A & A, 539, A9 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Najita, J. R., Ádámkovics, M., & Glassgold, A. E. 2011, ApJ, 743, 147 [NASA ADS] [CrossRef] [Google Scholar]
 Najita, J. R., Carr, J. S., Pontoppidan, K. M., et al. 2013, ApJ, 766, 134 [Google Scholar]
 Natta, A., Prusti, T., Neri, R., et al. 2001, A & A, 371, 186 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Nazari, P., Tabone, B., van't Hoff, M. L. R., Jørgensen, J. K., & van Dishoeck, E. F. 2023, ApJ, 951, L38 [NASA ADS] [CrossRef] [Google Scholar]
 Nomura, H., Aikawa, Y., Tsujimoto, M., Nakagawa, Y., & Millar, T. J. 2007, ApJ, 661, 334 [NASA ADS] [CrossRef] [Google Scholar]
 Ormel, C. W., Spaans, M., & Tielens, A. G. G. M. 2007, A & A, 461, 215 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pascucci, I., Herczeg, G., Carr, J. S., & Bruderer, S. 2013, ApJ, 779, 178 [NASA ADS] [CrossRef] [Google Scholar]
 Perotti, G., Christiaens, V., Henning, T., et al. 2023, Nature, 620, 516 [NASA ADS] [CrossRef] [Google Scholar]
 Pontoppidan, K. M., Salyk, C., Blake, G. A., & Käufl, H. U. 2010, ApJ, 722, L173 [NASA ADS] [CrossRef] [Google Scholar]
 Pontoppidan, K. M., Salyk, C., Bergin, E. A., et al. 2014, in Protostars and PlanetsVI, eds. H. Beuther, R. S. Klessen, C. P. Dullemond, & T. Henning, 363 [Google Scholar]
 Rahmann, U., Kreutner, W., & KohseHöinghaus, K. 1999, Appl. Phys. B: Lasers Opt., 69, 61 [NASA ADS] [CrossRef] [Google Scholar]
 Rechenberg, I. 2000, Comput. Methods Appl. Mech. Eng., 186, 125 [NASA ADS] [CrossRef] [Google Scholar]
 Rigliaco, E., Gratton, R., Kóspál, Á., et al. 2020, A & A, 641, A33 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Riols, A., & Lesur, G. 2018, A & A, 617, A117 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Salyk, C., Pontoppidan, K. M., Blake, G. A., et al. 2008, ApJ, 676, L49 [NASA ADS] [CrossRef] [Google Scholar]
 Salyk, C., Pontoppidan, K. M., Blake, G. A., Najita, J. R., & Carr, J. S. 2011, ApJ, 731, 130 [Google Scholar]
 Schaaf, S. A. 1963, Handbuch Physik, 3, 591 [NASA ADS] [Google Scholar]
 Schräpler, R., & Henning, T. 2004, ApJ, 614, 960 [CrossRef] [Google Scholar]
 Shakura, N. I., & Sunyaev, R. A. 1973, A & A, 24, 337 [NASA ADS] [Google Scholar]
 SiciliaAguilar, A., Fang, M., Roccatagliata, V., et al. 2015, A & A, 580, A82 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Sipos, N., Àbrahàm, P., AcostaPulido, J., et al. 2009, A & A, 507, 881 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Tabone, B., van Hemert, M. C., van Dishoeck, E. F., & Black, J. H. 2021, A & A, 650, A192 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Tabone, B., Bettoni, G., van Dishoeck, E. F., et al. 2023, Nat. Astron., 7, 805 [NASA ADS] [CrossRef] [Google Scholar]
 Teets, W. K., Weintraub, D. A., Kastner, J. H., et al. 2012, ApJ, 760, 89 [NASA ADS] [CrossRef] [Google Scholar]
 Thi, W. F., & Bik, A. 2005, A & A, 438, 557 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Thi, W. F., Kamp, I., Woitke, P., et al. 2013, A & A, 551, A49 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Thi, W. F., Lesur, G., Woitke, P., et al. 2019, A & A, 632, A44 [CrossRef] [EDP Sciences] [Google Scholar]
 van ’t Hoff, M. L. R., Bergin, E. A., Jørgensen, J. K., & Blake, G. A. 2020, ApJ, 897, L38 [Google Scholar]
 Varga, J., Abraham, P., Chen, L., et al. 2018, A & A, 617, A83 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Visser, R., van Dishoeck, E. F., & Black, J. H. 2009, A & A, 503, 323 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Walsh, C., Nomura, H., & van Dishoeck, E. 2015, A & A, 582, A88 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Wang, M.T., Herczeg, G. J., Liu, H.G., et al. 2023, ApJ, 957, 113 [NASA ADS] [CrossRef] [Google Scholar]
 White, J. A., Kóspál, Á., Hughes, A. G., et al. 2020, ApJ, 904, 37 [CrossRef] [Google Scholar]
 Woitke, P., & Helling, C. 2003, A & A, 399, 297 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woitke, P., Kamp, I., & Thi, W. F. 2009, A & A, 501, 383 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woitke, P., Min, M., Pinte, C., et al. 2016, A & A, 586, A103 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woitke, P., Helling, C., Hunter, G. H., et al. 2018a, A & A, 614, A1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woitke, P., Min, M., Thi, W. F., et al. 2018b, A & A, 618, A57 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woitke, P., Kamp, I., Antonellini, S., et al. 2019, PASP, 131, 064301 [NASA ADS] [CrossRef] [Google Scholar]
 Woods, P. M., & Willacy, K. 2009, ApJ, 693, 1360 [Google Scholar]
 Youdin, A. N., & Lithwick, Y. 2007, Icarus, 192, 588 [NASA ADS] [CrossRef] [Google Scholar]
 Zhang, K., Pontoppidan, K. M., Salyk, C., & Blake, G. A. 2013, ApJ, 766, 82 [NASA ADS] [CrossRef] [Google Scholar]
The spectral resolution of the MIRI instrument depends on wavelength, see https://jwstdocs.stsci.edu/jwstmidinfraredinstrument/miriobservingmodes/mirimediumresolutionspectroscopy, varying between about 2000 and 3000, so our choice here is a simplification.
All Tables
Total line fluxes ΣF_{line} [W m^{−2}], fluxmean column densities 〈N_{col}〉 [cm^{−2}], fluxmean emission temperatures 〈T_{g}〉 [K], and fluxmean emission radius interval 〈r_{1} – r_{2}〉 of molecules, considering all lines emitted in two different spectral regions in the 2D disc model.
Total line fluxes ${\sum}_{\text{line}}{F}_{\text{mol}}^{\text{line}}}\text{\hspace{0.17em}}\left[{\text{Wm}}^{2}\right]$ [W m^{−2}], column densities 〈N_{col}〉 [cm^{−2}], emission temperatures 〈T_{g}〉 [K], and emitting radii 〈r_{1} − r_{2}〉 [au] of selected molecules, affected by stellar UV luminosity, Xray luminosity, and massaccretion rate, considering all lines between 13 and 17.7 µm.
All Figures
Fig. 1 Escape probability (${P}_{ul}^{\text{esc}}$, top) and continuum pumping probability (${P}_{ul}^{\text{pump}}$, bottom) of the [OI] 63 µm line in the PRODIMO standard T Tauri model. Left and right plots show the results from the previous and the new escape probability theory. The white dashed contours show the particle density of atomic oxygen log_{10} n_{OI}[ cm^{−3}] = {8, 6, 4, 2, 0, −2}.

In the text
Fig. 2 Change in heating and cooling balance with the new escape probability treatment and the new 2D concept to apply UV molecular shielding factors. The plots show the leading heating process (top) and the leading cooling process (bottom) in a zoomedin disc region responsible for the disc IR line emissions. Processes are only plotted when they fill at least 1% of the area in these plots. The dashed lines mark the visual disc surface A_{v,rad} = 1 and the vertical optical extinction A_{V} = 10. The model includes 103 heating and 95 cooling processes with 64910 spectral lines altogether.

In the text
Fig. 3 Effect of continuum emission on line flux. Case (a) shows an emission line on a cold continuum S_{C} = 0. Case (b) is an emission line on a warm continuum S_{L} > S_{C}, and case (c) is an absorption line where the continuum is hot S_{L} < S_{C}. The area A is the flux of photon energy [erg s^{−1} cm^{−2}] carried away by line photons escaping from the object (after continuum extinction and line selfabsorption) and is the same in cases (a), (b) and (c). However, the objective is to derive the area O, which is the line flux as measured by observers. For a warm continuum, clearly O < A, and for an absorption line O < 0 (although A > 0).

In the text
Fig. 4 Functions C_{1}(τ_{L}) and C_{2}(τ_{L}) as introduced in Eq. (36).

In the text
Fig. 5 Line fluxes predicted by the old escape probability treatment (blue) and new escape probability treatment (orange). All line fluxes are divided by the results from the full line RT for zero inclination (faceon).

In the text
Fig. 6 Change of molecular concentrations caused by introducing our new 2D concept to apply molecular shielding factors.

In the text
Fig. 7 PRODIMO model for the quiescent state of EX Lupi. The top plots show the assumed gas and dust column densities (left) and scale heights (right). The second row shows the corresponding gas densities (left) and gastodust mass ratio after settling (right). The third row shows the UV field strength χ (left), and the Xray ionisation rate ζ_{X} in comparison to the cosmicray ionisation rate (right). The bottom row shows the resulting dusttemperature (left) and gastemperature (right) structures. Additional contour lines show selected values for the vertical optical extinction A_{V} and the radial optical extinction A_{V,rad} as indicated.

In the text
Fig. 8 Fit of the SED of EX Lupi in the quiescent state. The orange and green data points in the upper plot are Herschel/SPIRE and ALMA measurements. The orange spectrum is the JWST/MIRI data. The lower plot shows a magnification of the MIR spectral region.

In the text
Fig. 9 Resulting chemical concentrations ϵ_{i} = n_{i}/n_{〈H〉} of selected molecules in the PRODIMO disc model for EX Lupi. Additional contour lines are plotted as boundaries, including the ionisation parameter χ/n_{〈H〉} (i.e. the UV field strength divided by the hydrogen nuclei particle density) and the ratios of the concentrations of the major molecules. For example, ‘H/H2=100’ means that H atoms are 100 times more abundant than H_{2} molecules.

In the text
Fig. 10 Continuumsubtracted JWST spectrum (black line) in comparison to the PRODIMOFLITS disc model for EX Lupi. The coloured areas show the contributions of the different molecules to the total model line spectrum. These are therefore cumulative; i.e. the CO_{2}spectrum is plotted on top of the C_{2}H_{2}spectrum, the HCNspectrum on top of the (C_{2}H_{2}+CO_{2})spectrum, and so on, such that the top of the water spectrum represents the total continuumsubtracted model spectrum. The model spectrum has been convolved to R = 2500. Furthermore, both the observational data and the model spectrum were slightly boxfiltered before plotting in order to increase clarity; see main text. The broad bumps in the observational data (e.g. those around 6.3 µm and in the region 15.5 – 17.7 µm) are likely due to problems with the early data reduction and continuum subtraction.

In the text
Fig. 11 Location and physical properties in the MIR lineemission regions of the EX Lupi disc model. Upper row: Lineemitting regions of different molecules in two different spectral bands in the bestfitting EX Lupi model. The left upper plot considers λ = 407 µm, and the right upper plot λ = 1317 µm. The white lines at the bottom of the plots mark the location where the vertical continuum optical depth is one, considering an average of the wavelengths of all water lines in the considered wavelength region. The bottom row shows the corresponding gas temperatures (left) and the carbontooxygen ratio C/O in the gas phase (right). C/O = 0.46 is constant by assumption, except for the region where water ice is found to be stable, where C/O instantly jumps to very large values of >1000.

In the text
Fig. 12 Continuumemitting regions responsible for about 50% of the flux at different wavelengths under faceon inclination. Contour lines for the vertical optical extinction A_{V} at 1 and 10 are added.

In the text
Fig. 13 Reaction pathways to form HCN and C_{2}H_{2} in the close midplane, where n_{〈H〉}> = 2 × 10^{11} cm^{−3}, T_{g} = 640 K, T_{d} = 630 K, A_{V,rad} = 7, and A_{V} = 0.7. The major species are marked with thick boxes. Red species are rare and created by Xray processes. The green numbers are the particle concentrations n_{mol}/n_{〈H〉}, and the blue numbers are the rates [cm^{−3}s^{−1}]. Wiggly arrows indicate photodissociation, and red arrows indicate Xray processes: XPHOT is the Xray primary ionisation of He, and XG and XI are the Xray secondary ionisations by fast electrons.

In the text
Fig. 14 Leading heating (left) and cooling processes (right) in the bestfitting EX Lupi model. The plots show a magnification of the inner disc relevant for the IR molecular line emissions. The dashed contour line marks the disc surface, where the radial optical extinction A_{V,rad} = 1.

In the text
Fig. A.1 Vertical cuts at r = 0.1 au, 0.3 au, and 1 au through the standard PRODIMO T Tauri disc model after the code modifcations described in Sect. refsec:CodeChanges. The xaxis is the hydrogen nuclei column density measured from the top, relevant line formation typically happens between about 10^{21} cm^{−2} and 10^{24} cm^{−2}. The left plots show the assumed hydrogen nuclei particle density n_{〈H〉} and the calculated gas and dust temperatures. The middle and left plots show the relevant heating and cooling rates, annotated below, where the thick grey line is the total heating and cooling rate. We note that ${{\displaystyle \sum}}^{\text{}}\text{\hspace{0.17em}}{Q}_{\text{heat}}={{\displaystyle \sum}}^{\text{}}\text{\hspace{0.17em}}{Q}_{\text{cool}}$. An individual heating or cooling rate is plotted when it reaches at least 15% of the total heating and cooling rate anywhere in the depicted vertical range.

In the text
Fig. A.1 continued. Vertical cuts at r = 3 au, 10 au, and 30 au

In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
