1. Introduction

Baryons in galaxies are engaged in a complex intertwining of mechanisms whose combined effects drive galaxy evolution. Key players of this game are gas, stars, and active galactic nuclei (AGN). Gas is the primary ingredient of both star formation and black hole accretion, and its properties are therefore crucial for shaping galaxies. Star formation and AGN activity can in turn heavily influence the physical, chemical, and kinematical conditions of gas within galaxies, thereby exerting a “feedback” on galaxy evolution. In a simplistic way, our current knowledge of the processes occurring in galaxies and involving gas and stars can be summarised as follows. The presence of gas within galaxies is a key prerequisite for star formation. In local galaxies, all known star formation takes place in dense molecular clouds, mostly in giant molecular clouds (GMCs, see review by Scoville 2013).

The star formation process can be either smooth and quiescent, probably fostered by cosmological inflows of cold gas into galaxies (e.g. Dekel et al. 2009; Bouché et al. 2010), or bursty, triggered by dynamical processes such as galaxy interactions (Scoville 2013). Recent studies have suggested that the latter mode of star formation does not contribute significantly to the cosmic star formation rate (SFR) density, accounting for only 10% of it even at z ~ 2, i.e. the peak of the cosmic SFR density (Rodighiero et al. 2011). Although we still lack conclusive observational evidence of cold accretion flows feeding galaxy halos (but see promising observations by Cantalupo et al. 2014; and Hennawi et al. 2015 at z ~ 2), the hypothesis that the building up of baryonic mass is a secular process has been suggested by observation of a tight correlation between stellar mass (M) and SFR in star-forming galaxies (Bouché et al. 2010; Lilly et al. 2013), dubbed star formation “main sequence” (MS). The MS is a well-established property of the star-forming galaxy population at z ~ 0 (Noeske et al. 2007; Peng et al. 2010) and is believed to persist at least up to z ~ 4 (Schreiber et al. 2015) with an intrinsic scatter of only ~0.3 dex.

Once star formation is activated, supernovae enrich the interstellar medium (ISM) with metals and, along with young and massive stars, inject energy and momentum into the ISM, thereby altering the physical conditions of the gas surrounding the sites of star formation and at the same time driving multi-phase galactic-scale outflows that propel part of the gas out of these regions. In some cases, they can even expel it from the galaxy. The investigation of stellar feedback has triggered a wealth of both theoretical and observational works. For theoretical work we refer to the early review by Chevalier (1977) for energy-driven outflows, to Murray et al. (2005) for momentum-driven outflows, and to Hopkins et al. (2014) for cosmological zoom-in simulations that explore the combined effect of multiple stellar feedback mechanisms on galaxy evolution. For observational work we refer to the reviews by Veilleux et al. (2005) and Erb (2015), the latter focussing on high redshifts.

Gas heating and removal resulting from intense episodes of star formation are believed to play a key role in galaxy evolution. For example, stellar feedback may be the main cause of (i) the low efficiency of star formation observed in both low- and high-mass galaxies (Behroozi et al. 2010; Papastergis et al. 2012), although for more massive galaxies, an additional feedback from AGNs is often invoked (e.g. reviews by Cattaneo et al. 2009 and Kormendy & Ho 2013); (ii) the lower gas-phase metal content of low-mass galaxies with respect to more massive galaxies (Davé et al. 2011a); and (iii) the consequent enrichment of the circumgalactic medium (CGM) with metals (Mac Low & Ferrara 1999). Moreover, it has been suggested that galactic outflows driven by star formation may have aided the reionisation of the early Universe, by creating gas-free paths around young star clusters, thus facilitating the leakage of ionising photons from the first galaxies (Heckman et al. 2011; Erb 2015).

Although blueshifted absorption lines at optical and UV wavelengths are probably the most direct and accessible tool for identifying outflows of ionised (and atomic) gas, especially in distant galaxies, nebular emission lines such as [OIII]λ5007, Hα, and [NII]λλ6548, 6584 are also widely employed to study galactic outflows, both in local star-forming galaxies (e.g. Heckman et al. 1990; Veilleux et al. 1995; Lehnert & Heckman 1996; Soto et al. 2012; Westmoquette et al. 2012; Rupke & Veilleux 2013; Rodríguez Zaurín et al. 2013; Bellocchi et al. 2013; Cazzoli et al. 2014; Arribas et al. 2014) and at higher redshifts (e.g. Shapiro et al. 2009; Newman et al. 2012; Harrison et al. 2012; Cano-Diaz et al. 2012; Genzel et al. 2014; Förster Schreiber et al. 2014; Carniani et al. 2015). However, despite the increasing number of observational studies targeting galactic outflows and the remarkable advances in the field, a systematic and unbiased investigation of star-formation-driven outflows in a large sample of galaxies is still missing. Indeed, since the outflow signature can be very faint and difficult to detect in individual normal galaxies, previous studies have focussed on rather small samples, mostly characterised by “extreme” properties (e.g. powerful and massive starbursts, ultra-luminous infrared galaxies – ULIRGs), hence not representative of the general galaxy population, although significant improvement has been recently made in this regard (e.g. Chen et al. 2010; Martin et al. 2012; Rubin et al. 2014; Chisholm et al. 2015).

In this paper we study star-formation-driven outflows of ionised gas as traced by faint broad wings of optical emission lines ([OIII]λ5007, Hα, and [NII]λλ6548, 6584) by using the largest and most unbiased spectroscopic sample of local galaxies currently available, the Sloan digital sky survey (SDSS). In conjunction with the catalogues provided by the MPA-JHU analysis, the SDSS constitutes a huge database, whose noteworthy potential in terms of studying the general properties of galaxies can be exploited further by stacking multiple spectra together to obtain very high signal-to-noise composite spectra (e.g. Chen et al. 2010; Andrews & Martini 2013). The stacking technique has numerous advantages, and it is particularly useful when searching for faint spectral features, such as those impressed by galactic outflows, which can be missed in the noise of single galaxy spectra.

We divide the MSFR parameter space into a fine grid of bins, each of which includes from several tens to thousands of sources. The spectra within each bin are then stacked together to produce a single, very high signal-to-noise composite spectrum that is representative of the spectrum of a “typical” galaxy in that bin, in which we can study the emergence of faint broad wings of optical emission lines that may trace ionised outflows. Moreover, since stellar mass and SFR are intrinsically correlated in most star-forming galaxies (because most of them follow the MS), we can investigate the trends between the outflow properties and these two parameters independently by stacking galaxies in bins of SFR and M, thus breaking the degeneracy resulting from the MS. The SDSS database and the use of the stacking technique allow us to explore the incidence and properties of ionised outflows over a wide dynamical range of galaxy properties, i.e. M ∈ [2 × 107,6 × 1011] M and SFR ∈ [2 × 10-3,2 × 102] M yr-1, which is unprecedented in outflow studies.

A rather controversial issue in studies of galactic outflows through emission line profiles is the definition of “broad component”, which is supposed to trace gas in outflow, and of “narrow component”, which instead traces virial motions in the galaxy. This has not been addressed in a systematic way by previous studies: most of them just rely on the χ2 improvement to establish the necessity of a broad component to fit the emission line profile (e.g. Harrison et al. 2012; Westmoquette et al. 2012; Bellocchi et al. 2013; Arribas et al. 2014). Moreover, even if a broad component is present, its association with galactic flows is not straightforward: a broad component in emission may trace the high-velocity tail of virialised motions within the galaxy or galaxy interactions. In this study we attempt to overcome this problem by adopting a novel strategy, consisting in directly comparing the line-of-sight velocity distribution (hereafter, LoSVD) of the ionised gas with the LoSVD of the stars, which is taken as a reference that traces virial motions. Accordingly, gaseous outflows are identified by deviations in the gas kinematics from the stellar kinematics and, in particular, by the presence of an excess of gas velocity with respect to the stars in the high-velocity tail of the LoSVD.

Summarising, the main goal of this work is to investigate the incidence and properties of galactic outflows of ionised gas as a function of a wide range of galaxy properties, breaking the degeneracy between SFR and M. Moreover, for the first time, we push outflow studies to stellar masses and SFRs as low as 2 × 107 M and 2 × 10-3 M yr-1, respectively, a regime that has not been probed before in this field.

A H0 = 70 km s-1 Mpc-1, ΩM = 0.27, ΩΛ = 0.73 cosmology is adopted throughout this paper.

2. Methods

In this section we present the SDSS sample of star-forming, inactive galaxies selected for this study (Sect. 2.1). We also describe in detail the stacking procedure (Sect. 2.2) and the fitting techniques applied to the stellar continuum and to the [OIII]λ5007 and Hα+[NII]λλ6548, 6583 nebular lines to obtain the line-of-sight velocity distributions of stars and ionised gas from the galaxy composite spectra (Sects. 2.32.6).

2.1. Sample selection

Our galaxy sample is drawn entirely from the spectroscopic sample of the Sloan digital sky survey, data release 7 (SDSS DR7, Abazajian et al. 2009). We made a first selection by including only those galaxies enclosed in the MPA-JHU catalogue1, which provides intrinsic and derived spectral parameters for each source, such as redshift, emission line fluxes, stellar mass, and SFR (Tremonti et al. 2004; Kauffmann et al. 2003; Brinchmann et al. 2004; Salim et al. 2007). The MPA-JHU analysis encompasses only SDSS DR7 sources at z< 0.7.

Among the MPA-JHU galaxies, we selected only sources classified as “star-forming” (or “HII”) according to their location on the log([OIII]/Hβ) vs. log([NII]/Hα) diagram (i.e. the “BPT” diagram, Baldwin et al. 1981), by adopting the same division criteria as Kauffmann et al. (2003). This selection is needed to avoid contamination from AGNs, which is of primary importance to constrain the star formation-driven feedback mechanisms in action in normal local galaxies.

We note that the BPT selection may introduce a potential bias in our sample of star-forming galaxies because purely star-forming galaxies may still exhibit extended areas where the optical line ratios are typical of low-ionisation emission line regions (LINERs). As a consequence, an “HII” galaxy may be erroneously classified as “Composite” or “LINER” when its optical emission is averaged over a large aperture (such as the SDSS spectroscopic fibre). Extended LINER-like gas excitation in purely star-forming galaxies can have different origins. In the vast majority of local isolated (inactive) galaxies, the most plausible source of extended LINER-type excitation are evolved (post-AGB) stars (Cid Fernandes et al. 2011; Yan & Blanton 2012; Singh et al. 2013; Belfiore et al. 2015). This is in general not the case for strongly star-forming galaxies such as (U)LIRGs, where there is evidence of extended LINER excitation associated with widespread shocks. Indeed, both theoretical models (Allen et al. 2008) and spatially resolved integral field spectroscopy (IFS) observations (Monreal-Ibero et al. 2006, 2010; Soto & Martin 2012; Rich et al. 2014, 2015) have shown that galaxy regions dominated by shock excitation exhibit optical line ratios typical of LINERs.

Extended shocks can be associated with strong outflows produced by vigorous star formation (e.g. Sharp & Bland-Hawthorn 2010). Therefore, by leaving out LINERs and Composite galaxies, our sample selection may be biased against (U)LIRGs experiencing strong feedback from star formation. Although this is certainly a caveat to keep in mind, the nature of the widespread shocks that may dominate the ionised gas excitation over extended regions in (U)LIRGs is most likely linked to the merger process. This argument is based on the lack of observational evidence in isolated (U)LIRGs for shock-like excitation that significantly affects the optical line fluxes (Monreal-Ibero et al. 2010; Rich et al. 2015). Indeed, the point made by resolved IFS studies (Soto & Martin 2012; Rich et al. 2014, 2015) about a possible misclassification of star-forming galaxies hosting widespread shocks, when aperture-integrated spectra are used, concerns only (U)LIRGs in a merger stage. In contrast, for isolated (U)LIRGs, the contribution from shocks to extended optical line emission is negligible (Monreal-Ibero et al. 2010; Rich et al. 2015). Therefore, the types of shocks that can affect integrated optical line fluxes to the point that an “HII” galaxy is classified as “Composite” or “LINER” are galaxy-wide shocks produced by a complex interplay of merger-driven processes and not just by star-formation-driven outflows.

thumbnail Fig. 1

SDSS sample of star-forming, inactive galaxies selected for this study, plotted in the MSFR parameter space. The grid of 50 bins used for the stacking is shown, with the bins colour-coded according to the number of spectra enclosed. The exact number of sources within each bin is indicated by the yellow text. The white dashed and dotted lines represent the MS relation of local star-forming galaxies with its ± 1σ scatter (=0.3 dex). The MS relation has been taken from Peng et al. (2010) and adapted to this dataset as explained in Sect. 2.2.

Open with DEXTER

For their sample of local ULIRGs, Monreal-Ibero et al. (2006) explicitly concluded that the LINER-type optical line ratios observed in the extranuclear regions, several kiloparsecs away from the circumnuclear starburst, are due to shocks associated with tidally-induced large-scale flows produced during the merger and not to star-formation-driven “superwinds” (which instead tend to dominate the gas kinematics in the inner regions of these ULIRGs that are characterised mostly by HII-type excitation). A similar conclusion was reached by Monreal-Ibero et al. (2010), who investigated the excitation source of ionised gas in a sample of 32 local LIRGs using IFS data, and found that the presence and relevance of shock-type excitation is more strongly correlated with the interaction class of the system than with the star formation activity (with isolated galaxies being largely dominated by HII-type excitation).

In summary, based on the observational evidence available from IFS studies, our BPT sample selection could lead to two possible biases: (i) a bias against ageing isolated galaxies dominated by old stellar populations and/or (ii) a bias against merger-driven shocks. The first bias would affect massive “retired” galaxies with stellar populations older than 1 Gyr and little ongoing star formation (e.g. Cid Fernandes et al. 2011; Singh et al. 2013), hence with very little or no star formation feedback at work. The second bias would affect mergers, which are only a minor fraction of the local galaxy population (Patton & Atfield 2008) and so unimportant in our sample2. Moreover, even if hypothesising that our analysis under-represents merging (U)LIRGs experiencing strong feedback, our conclusions (e.g. Sect. 4.2) would not be affected but would actually be even strengthened: in this case we would be under-representing galaxies with high SFRs/sSFRs (i.e. galaxies above the main sequence in the MSFR diagram, e.g. Combes et al. 2013; Kilerci Eser et al. 2014) with strong outflows; as a result, our investigation and the relevant results could be regarded as conservative.

In addition to the BPT selection of “HII” galaxies, we require a signal-to-noise ratio (S/N) greater than five in all four emission lines used in the BPT diagram (i.e. [OIII], Hβ, [NII], Hα). As a consequence, the most passive galaxies, which do not show prominent nebular lines, are under-represented in our sample. We note that, by imposing a threshold S/N on the [OIII] and [NII] line fluxes, we may introduce a bias with metallicity (). However, since local galaxies define a tight surface in the plane (i.e. the “fundamental metallicity relation”, e.g. Mannucci et al. 2010; Lara-López et al. 2010), we do not expect galaxies within a given bin in the MSFR parameter space to show significant variations in metallicity. Therefore, the main effect of imposing S/N constraints on the [OIII] and [NII] emission lines is that our sample selection does not allow us to populate certain regions of the MSFR parameter space, but we do not introduce differential biases within the galaxy bins that are included in our sample.

A general caveat for this study is that at the median redshift of our sample, zmed = 0.073, the 3 arcsec diameter of the SDSS spectroscopic fibre only samples the galaxy emission within r ≲ 2.1 kpc. Moreover, the spectroscopic fibre samples a wide range of different projected sizes within our galaxy sample. Aperture effects are an obvious limitation of our study that will need to be taken into account in future works and that can only be tackled properly by using spatially resolved observations. To be able to study outflows in “normal” galaxies (i.e. in galaxies that are neither extreme starbursts nor AGN hosts), we need to wait for the completion of ongoing large IFS surveys such as the CALIFA, SAMI, and MaNGA surveys, although these will still have statistics that are orders of magnitude smaller than provided by the SDSS. Another potential source of bias is given by galaxy inclination, which can have a strong effect on the detectability of outflows (e.g. Chen et al. 2010). However, in terms of outflow properties, we expect the stacking of thousands of spectra to average out the effects of inclination, so we do not expect our results to be affected much.

Our final selection consists of 157 639 galaxy spectra, whose distribution in the MSFR diagram is shown in Fig. 1. The stellar mass of each galaxy was derived from a fit to the observed spectral energy distribution (SED), obtained with SDSS broad-band photometry (Brinchmann et al. 2004; Salim et al. 2007), which therefore takes the total emission from the galaxy into account. The SFR estimate is instead based on the Hα intrinsic luminosity, following the procedure described by Brinchmann et al. (2004), without applying any aperture correction to the SDSS fibre-limited spectrum: the SFRs employed in this work are therefore the “fibre SFRs” provided in the MPA-JHU catalogue. Such a choice is justified by the fact that, in this study, we infer the properties of the gaseous and stellar kinematics by exclusively using the information provided by the fibre-limited SDSS spectroscopy, so we do not have information on the gas (and so on possible outflows) on scales larger than those sampled by the fibre. Therefore, we believe that, given the obvious limitations of SDSS spectroscopy (which can be overcome only with IFS studies), it is more sensible to look for possible correlations between the properties of ionised outflows (on the scales sampled by the SDSS fibre) and the fibre SFRs, rather than the aperture-corrected SFRs. For the stellar mass instead we have chosen to use the “total” M because galactic outflows are expected to feel the effect of the entire galaxy gravitational potential well, which is linked to the total stellar mass.

2.2. Stacking procedure

The MSFR parameter space sampled by our SDSS galaxy selection is divided into a fine grid of 50 bins, as shown in Fig. 1, and the spectra within each bin are stacked together to obtain very high S/N composite spectra. Each bin is required to include a minimum of 50 sources, but most bins contain over 100 galaxies, and the central ones up to ~20 000. Throughout this paper, we will code each stack by its average log(SFR) and log(M) (ID = log(SFR)_log (M)).

We also show the position of the main sequence of local star-forming galaxies and its ±0.3 dex scatter in Fig. 1 (Salim et al. 2007; Peng et al. 2010). Since we use fibre-limited SFRs, the reference MS for this study differs slightly from the MS relationship derived by Peng et al. (2010), who instead used aperture-corrected SFRs. The main effect of using SFRs that are not corrected for the SDSS aperture is a downward shift in the MS relation by Δlog (SFR) = −0.4 dex. This shift was estimated by selecting, in our sample, galaxies with 0.02 <z< 0.085 (to match the redshift range of Peng et al. 2010) and 9.0 < log (M [M] ) < 11.0 (i.e. the stellar mass range where the mean relationship between log(SFR) and log(M) is linear) and by fitting the mean trend between log(SFR) and log(M) with a linear relationship, whose slope was constrained to be the same as Peng et al. (2010). However, we stress that the aim of this work is not to provide a generally applicable fit to the local MS relation of star-forming galaxies and that the MS relationship shown in Fig. 1 should only be used as a reference for this galaxy sample. We refer to the works by Peng et al. (2010), Schreiber et al. (2015), and Gavazzi et al. (2015) for more detailed discussion about the MS of star-forming galaxies.

Prior to stacking, the galaxy spectra in each bin are de-reddened and normalised to their extinction-corrected Hβ line flux, which is related to the SFR in the galaxy. The reddening E(BV) is estimated from the observed Hα-to-Hβ flux ratio by using the Galactic extinction curve as described in Cardelli et al. (1989) and by assuming RV = AV/E(BV) = 3.1. The spectra are then shifted to the rest frame by using the redshifts provided by the Princeton-1D spectroscopic pipeline3 and contextually re-binned by using a technique based on “Drizzle”, the method for linear reconstruction of under-sampled images (Fruchter & Hook 2002). The drizzling consists in mapping the original redshifted SDSS spectrum into a rest-frame pixel grid (the output spectrum) by taking their different pixel sizes and relative shift into account, as sketched in Fig. 2. In practice, the flux contained in the input pixel is averaged into the output pixel with a weight that is proportional to the area of overlap between the two pixels. The resulting spectra have a wavelength separation of 0.8 Å pixel-1, i.e. slightly finer than the original SDSS spectra. The rest-frame galaxy spectra in each bin are finally averaged together to produce a single composite spectrum (the final stack), which is then normalised to its mean.

thumbnail Fig. 2

Sketch of the “Drizzle” method applied to the SDSS spectra.

Open with DEXTER

2.3. Stellar subtraction

thumbnail Fig. 3

Stellar continuum fit and subtraction over two wavelength ranges including the [OIII]λ5007 emission line (top panels) and the Hα+[NII] emission lines (bottom panels), performed for two galaxy stacks: ID = 2.0_8.5 (left) and ID=0.5_11.5 (right). In each plot, the upper panel shows the stacked spectrum (black) and the best fit to the stellar continuum (blue), while the lower panel shows the residual spectrum. The red-shaded regions mark the spectral windows that contain nebular features and are therefore masked from the stellar continuum fit.

Open with DEXTER

The subtraction of the stellar continuum emission from the stacked spectra is crucial for this study, which is aimed at detecting faint wings of nebular emission lines. For the purpose of stellar subtraction, we select as stellar templates a large set of synthetic spectra of single stellar populations (SSPs) computed with the PÉGASE-HR v3.0 code4 (Le Borgne et al. 2004), with both low metallicities (), and with solar metallicities (). The PÉGASE-HR spectral templates cover the wavelength range λ ∈ [4000,6800] Å with a spectral resolving power of R = 10 000 at λ = 5500 Å and are computed for a wide range of ages (from 10 Myr to 2 Gyr), by assuming a Salpeter initial mass function (IMF, Salpeter 1955).

We fit the PÉGASE-HR templates to the nebular line-free regions of the composite galaxy spectra by using the IDL implementation of the penalised pixel-fitting (pPXF) method developed by Cappellari & Emsellem (2004). The stellar continuum fitting and subtraction is performed in two wavelength ranges, i.e. λ ∈ [4800,5100] Å and λ ∈ [6200,6790] Å, selected to include the [OIII]λ5007 and the Hα +[NII]λλ6548, 6583 nebular emission lines, which are the targets of this study. The nebular emission lines and ISM absorption features are masked from the stellar fit to prevent it from being affected by non-stellar features. When the fit is provided with a large enough number of stellar features in the non-masked portion of the spectrum (which is always true in the spectral region we are interested in), this procedure can accurately determine the stellar contamination under the masked nebular lines. Figure 3 shows the stellar continuum fit and subtraction performed for two different stacks. We note that the pPXF procedure, together with the high-resolution PÉGASE-HR templates, produces an excellent fit to the stellar continuum underlying the nebular features in the galaxy stacks.

2.4. SDSS spectral instrumental profile

Our investigation of the kinematics of the ionised gas in local star-forming galaxies, as traced by the [OIII]λ5007 and Hα+[NII]λλ6548, 6583 nebular emission lines, aims at finding broad wings of the LoSVD of the ionised gas that may be the signature of outflows. This is done by comparing, in each galaxy stack, the LoSVD of the gas with the LoSVD of the stars. As explained in Sect. 2.5, the LoSVD of the stars is derived by fitting the stellar continuum around λ = 5500 Å, i.e. in a spectral region where the stellar fit produces the best results thanks to the large number of stellar absorption lines and the scarcity of nebular (ISM) features. However, to extract the real kinematics of stars and gas from the observed line profiles (either from the nebular emission lines, in the case of the gas, or from the stellar features seen in absorption, in the case of the stars), the LoSVDs of gas and stars must be deconvolved from the spectral instrumental profile. Therefore, it is of primary importance for our study to determine the instrumental profile of the SDSS spectrographs.

The presence of scattered light in the spectrometer may affect the spectral instrumental profile, resulting in extended wings. For the purpose of our investigation, we used the arc lamp calibration spectra to retrieve and analyse the spectral instrumental profile of the original SDSS spectrographs (adopted for SDSS-II). The average SDSS instrumental profile, shown in Fig. 4, is impressively clean with no wings down to 3/1000 of the peak, where some low-level instrumental wings start to appear. This effect is, however, negligible for our study, since it clearly cannot account for the much stronger broad (and asymmetric) line wings that we detect in our galaxy stacks, as shown in Sect. 3.

In their Fig. 35, Smee et al. (2013) analyse the spectral resolving power (R(λ) = λ/ (2.35 ∗ σλ)) of the original SDSS spectrographs as a function of wavelength. The resolving power of SDSS is quite difficult to constrain between λ = 5000 Å and λ = 6000 Å, because in this spectral region R does not depend monotonically on wavelength, owing to the transition from the blue to the red camera of the spectrographs (and some overlap between the two). In this study we have adopted R = 1850 (corresponding to σv = 69 km s-1), which is the average spectral resolving power inferred from the arc lamp images (Fig. 4) and is on the lower side of (but still well within) the nominal range quoted in the literature for the SDSS spectrographs (i.e. R ∈ [1800,2000]).

thumbnail Fig. 4

Instrumental profile of the SDSS spectrographs, estimated from bright, unblended emission lines in the arc lamp images, selected within the wavelength range of interest for this study: HgI λ5460.753 Å for the blue cameras and NeI λ6598.953 Å for the red cameras. For each camera (blue/red) of the two spectrographs (1/2), we overplotted ten representative profiles from as many different frames (corresponding to different plates) obtained by averaging the arc lamp spectra over all 320 fibres. The black solid line corresponds to the mean profile. The inset highlights the presence of low-level instrumental wings (corresponding to 3/1000 of the peak), which are more prominent for the red cameras.

Open with DEXTER

2.5. The LoSVD of the stars

thumbnail Fig. 5

Stellar continuum fit over the range λ ∈ [5250,5550] Å (left) and resulting stellar LoSVD (right) derived for two galaxy stacks, i.e. ID = −0.5_11.0 (panel a)) and ID = −1.5_9.5 (panel b)). In the left panels, the stacked spectrum is plotted in black, and the best fit to the stellar continuum is in blue. The red dashed regions indicate the spectral windows masked from the stellar continuum fit because of the presence of nebular features. In the right panels, the red dashed line indicates the LoSVD profile obtained by using, in the pPXF procedure, a simple Gaussian function to model the stellar features, while the blue solid line shows the stellar LoSVD profile obtained by allowing the use of Hermite polynomials to account for possible asymmetries of the stellar absorption features (Cappellari & Emsellem 2004). The stellar LoSVD obtained for the stack ID = −0.5_11.0 shows a clear blue asymmetry. The fit is excellent ( = 0.8) for both stacks.

Open with DEXTER

The pPXF method developed by Cappellari & Emsellem (2004) allows us not only to accurately fit the stellar continuum and subtract it from the stacked spectra of galaxies, but also to extract the stellar kinematics. The pPXF procedure adopts a Gauss-Hermite parametrisation for the stellar line-of-sight velocity distributions, which accounts for possible asymmetries in the stellar absorption-line profiles.

To infer the stellar LoSVDs, we first convolve the stellar templates (i.e. the PÉGASE-HR synthetic spectra) with the SDSS instrumental spectral profile obtained in Sect. 2.4. When performing the stellar continuum fit by using these stellar templates (i.e. the ones convolved with the instrumental profile), the pPXF procedure yields the “real” stellar LoSVD, i.e. the stellar LoSVD deconvolved from the instrumental profile. As already mentioned in Sect. 2.4, to extract the stellar kinematics, it is preferable to perform the continuum fitting around λ ~ 5500 Å, because this spectral region is abundant in stellar absorption features and relatively free of nebular emission lines. For this reason, to infer the stellar LoSVDs, we fit the stellar continuum in wavelength ranges selected between λ = 5100 Å and λ = 5850 Å or between λ = 6050 Å and λ = 6250 Å. The range λ ∈ [5850,6050] Å is avoided because of the presence of the NaID λλ5890, 5896 Å resonance absorption doublet, which is contaminated by the galaxy ISM.

An example of continuum fitting aimed at extracting the stellar kinematics is reported in Fig. 5 for two different galaxy stacks, i.e. ID = −0.5_11.0 and ID = −1.5_9.5. We note that the ID = −0.5_11.0 stack shows a significant asymmetry in its stellar LoSVD. The presence of asymmetries in the stellar LoSVDs has also been proved in other stacks and is discussed in Sect. 3.3.

2.6. The LoSVD of the ionised gas

thumbnail Fig. 6

Examples of spectral fits to the [OIII]λ5007 (left column) and Hα+[NII] (right column) emission line profiles for four representative galaxy bins with different SFR and M. From top to bottom: ID = 1.5_8.0 (low SFR and low M), ID = 1.0_10.5 (low SFR and high M), ID = 0.5_8.5 (high SFR and low M), and ID = 2.0_11.0 (high SFR and high M). In each plot, the left panel shows the fit to the data (solid curves, the total fit is in blue, the multiple Gaussian components in a lighter shade of blue). For comparison, we have overplotted to the data the average SDSS instrumental resolution profile (magenta dashed curve, from Fig. 4). In the right panel of each plot we show the final LoSVD of the ionised gas resulting from the fit, hence deconvolved from the SDSS instrumental profile (details in Sect. 2.6).

Open with DEXTER

thumbnail Fig. 7

Same as Fig. 6 but for a typical bin on the MS with intermediate SFR and M (ID = 0.0_10.5).

Open with DEXTER

To infer the LoSVD of the ionised gas we fit, for each stack, the [OIII]λ5007, Hα and [NII]λλ6548, 6583 emission lines with a function that results from the convolution of the SDSS instrumental profile, ℛ(v), with another function ℒ(v), which by definition corresponds to the “real” LoSVD of ionised gas. To account for potential broad wings of the LoSVD, possibly tracing outflows of ionised gas, ℒ(v) is parametrised by the sum of three Gaussians, lk(v) (k = 1,2,3), each centred at a velocity v0,k, with area ak and standard deviation σk, i.e. (1)where nk = 1/ is the normalisation factor. Therefore, the “observed” LoSVD, F(v), resulting from the convolution of the “real” LoSVD (ℒ(v)) and the SDSS spectral resolution profile (ℛ(v)), is given by (2)where we have used the distributive property of the convolution (indicated by the symbol ) and we defined fk(v) ≡ lk(v) ∗ ℛ(v). As a result, since both lk(v) and ℛ(v) are Gaussians, fk(v) has the form: (3)with .

An emission line centred at a velocity vi, corresponding to a central wavelength λi, is fitted with a final function of the form: (4)that is, the observed LoSVD, F(v), convolved with a Dirac delta function centred at the vacuum wavelength of the line λi and whose integral ϕi is proportional to the line flux. Following Eq. (4), the final function [OIII](λ) that we employ to fit the [OIII]λ5007 emission line profile in the composite spectra is (5)Similarly, we fit the Hα+[NII] emission lines with a function of the form: In this equation, [NII] indicates the bluest line of the [NII] doublet, i.e. the [NII]λ6548 line, and ϱ denotes the theoretical ratio between the rest-frame vacuum wavelengths of the [NII]λ6548 and [NII]λ6583 lines as reported in the NIST database.

The kinematics (velocity and widths) of all components fitting the Hα+[NII] complex is set to be equal for the three transitions. Such a constrained approach is necessary to separate the partially blended Hα and [NII] emission lines, and it improves the quality and reliability of the fit, as pointed out by Westmoquette et al. (2012). Moreover, this method is justified by the fact that in star-forming galaxies and in absence of strong shocks, the Hα and [NII] emission lines arise from adjacent regions.

The fit, whose input parameters are only the instrumental resolution (σR) and the (vacuum) central wavelengths of the different transitions (λi), provides us with the relative line fluxes ϕi and with other nine parameters, i.e. v0,k, σk, and ak (with the index k = 1,2,3 denoting the three Gaussian components used to model the observed LoSVD) from which, using Eq. (1), we retrieve ℒ(v), i.e. the real LoSVD of the ionised gas. Figures 6 and 7 show example fits to the [OIII]λ5007 and Hα+[NII] emission lines, as well as the resulting LoSVDs, for five representative galaxy stacks, having different SFR and M properties (in particular, low and high SFR, low and high M, and intermediate SFR and M). In Figs. 6 and 7 we also show for comparison, over-plotted to the observed spectral emission line profiles, the average SDSS instrumental profile (from Fig. 4), to show that the broad asymmetric wings we detected in a few of the stacks (e.g. ID = 2.0_11.0) are not instrumental.

3. Results

In this section we present the results of our analysis of the dynamical properties of ionised gas and stars based on stacked SDSS spectra of local star-forming galaxies, aimed at identifying the presence of galactic outflows. Throughout the remainder of the paper and in the figures, for the sake of simplicity, we replace “[OIII]λ5007” and “Hα+[NII]λλ6548, 6583” by “[OIII]” and “Hα”, respectively. The reader should, however, keep in mind that “Hα” actually refers to the Hα and [NII] line complex as a whole, since the LoSVDs were derived by fitting the Hα and [NII] lines simultaneously, as explained in Sect. 2.6. The adopted strategy is briefly summarised in Sect. 3.1. In Sect. 3.2 we analyse the general properties of the LoSVDs of gas and stars; in Sect. 3.3 we study the presence of asymmetric wings in the LoSVD profiles; and finally in Sect. 3.4 we discuss the outflow properties.

3.1. The novelty of our approach

Before presenting our results, we first briefly summarise what is new in our approach to the study of galactic outflows by emphasizing the advantages and strengths of this method. For the first time, we study galactic outflows by directly comparing the LoSVD of the ionised gas (as traced by the [OIII], Hα, and [NII] nebular emission lines) with the LoSVD of the stars. This has never been attempted before, primarily because previous studies could not reach the S/N needed to extract the stellar LoSVDs from the data, and (if any) they just relied on the comparison between the velocity dispersion of gas and stars.

Furthermore, this technique holds the potential of detecting the signature of outflows in sources that span a wide dynamic range of physical parameters as shown in Fig. 1, and in particular in faint, low-mass (i.e. M as low as ~2 × 107 M) and moderately star-forming (i.e. SFR as low as ~2 × 10-3 M yr-1) galaxies. The main limitations when probing outflows in galaxies with such low stellar masses and low SFRs with SDSS spectroscopy are both the low S/N and low spectral resolution of the associated spectra. In this study, however, we overcome both these limitations. Firstly, we used the stacking technique to significantly improve the S/N in the spectra (Sect. 2.2). Secondly, we minimised problems associated with the limited spectral resolution by deconvolving the “real” line-of-sight velocity distribution of gas and stars from the instrumental spectral profile in the observed resolution-limited composite spectra (as described in Sects. 2.42.6). This is made possible by the high S/N of the stacked spectra, especially for those galaxy bins in which the observed line profiles are narrow (i.e. line widths are close to the instrumental resolution). In particular, since in emission lines, outflows are traced by a broad component superimposed on a narrow component, our deconvolution technique allows us in principle to detect such a broad component (provided it is broad enough), even if the bulk of the (narrow) emission line is not resolved.

thumbnail Fig. 8

Line-of-sight velocity distribution of the ionised gas as traced by the [OIII]λ5007 emission line. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER

thumbnail Fig. 9

Line-of-sight velocity distribution of the ionised gas as traced by the Hα+[NII] emission lines. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER

thumbnail Fig. 10

Line-of-sight velocity distribution of the stars. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER

thumbnail Fig. 11

Line-of-sight velocity distribution of the ionised gas as traced by the [OIII]λ5007 emission line. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER

thumbnail Fig. 12

Line-of-sight velocity distribution of the ionised gas as traced by the Hα+[NII] emission lines. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER

thumbnail Fig. 13

Line-of-sight velocity distribution of the stars. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER

3.2. Properties of the kinematics of gas and stars

LoSVD profiles

In the following we analyse variations in the LoSVD profiles of (ionised) gas and stars as a function of M and SFR. We stress that, since the galaxy spectra have been stacked in bins of M and SFR, the trends with M and SFR can be investigated independently, thus breaking the degeneracy between SFR and M that holds for star-forming galaxies on the MS. For each stack, we adopt the velocity corresponding to the peak of the stellar LoSVD as a reference zero velocity for the LoSVD of both the stars and the gas.

Figures 810 show the variations in the LoSVD profiles of gas and stars as a function of M at a fixed SFR. The most obvious trend that emerges from these figures is the increasing width of the LoSVDs of both gas and stars with stellar mass at a given SFR. This is simply a consequence of the fact that, to first order, the velocity dispersion of both gas and stars primarily traces virial motions that are related to the dynamical mass of the galaxy. The dynamical mass of a galaxy is, to first order, proportional to its stellar mass, although gas and dust also contribute to it. Therefore, broader LoSVDs are expected at higher stellar masses, simply because higher stellar masses are generally associated with higher dynamical masses. A comparison between Figs. 8 and 9 shows that the [OIII] and the Hα LoSVD profiles are consistent overall.

The stellar LoSVDs in Fig. 10 show some interesting properties: they are generally quite broad, and they have wings that extend up to several hundred km s-1 in velocity, similar to the ionised gas traced by [OIII] and Hα, in particular for bins with −0.5 ≤ log (SFR [M yr-1] ) ≤ 1.5. This is in part a consequence of the velocity tail of the stellar distribution, but additional effects may be present, and these are discussed in detail later in this section.

Figures 1113 are complementary to Figs. 810 because they show the trends of LoSVD profiles of gas and stars as a function of SFR for fixed M. We first focus on Figs. 11 and 12: at a given stellar mass, the LoSVDs of [OIII]- and Hα-emitting gas broaden at higher SFRs. Such broadening is particularly evident for the “wings” of the line-of-sight velocity distributions, especially at stellar masses between 9.0 ≤ log (M [M] ) ≤ 11.0 for the [OIII] LoSVDs and between 9.0 ≤ log (M [M] ) ≤ 10.0 for the Hα LoSVDs. As we discuss later in this section, the overall broadening of the LoSVDs of ionised gas observed with increasing SFR at fixed M could trace various stellar feedback-related phenomena, such as turbulence in the disk gas and outflows.

A dependency of the width of the LoSVD on the SFR is also seen in the stars (Fig. 13), although in a smaller measure and especially at lower stellar masses (i.e. log (M [M] ) ≤ 10.5) than, for example, in the [OIII] LoSVDs (Figure 11). In the case of the stars, the LoSVD broadening with SFR (for constant M) may be associated with an increase in the total dynamical mass of the systems. In particular, the increase in width of the stellar LoSVDs is possibly tracing an increase in the total gas content in galaxies with higher SFRs, which is in turn a consequence of the Schmidt–Kennicutt relation between SFR and total gas mass surface density (Schmidt 1959; Kennicutt 1998). However, this trend might be affected by a potential observational bias: the average projected size of galaxies decreases for higher SFRs (higher SFRs correspond, on average, to more distant sources because of selection effects), and this may have an effect on the stellar velocity dispersion measured within the SDSS fibre.

The line-of-sight velocity distributions of [OIII] and Hα (Figs. 8, 9, 11, and 12) exhibit asymmetries between the blue and the red sides of the profiles. By eye inspection, such asymmetries appear to depend on the SFR, but a more quantitative analysis is presented in Sect. 3.3. We note that, quite surprisingly, the stellar LoSVDs in Figs. 10 and 13 also appear asymmetrical, although to a lesser extent; such an effect can be best appreciated in bins with log (SFR [M yr-1] ) = 0.5 and log (SFR [M yr-1] ) = 1.5 (Fig. 10). Asymmetries of the LoSVDs of gas and stars are investigated in Sect. 3.3.

LoSVD parameters: σ and percentile velocities

The next step is to extrapolate physically meaningful quantities from the LoSVDs of stars and gas and to investigate the relationships with galaxy properties. Errors on the LoSVD parameters are obtained using the bootstrap technique (Efron 1979). This method consists in randomly resampling (with replacements) our galaxy stacks, by generating, for each bin, resampled stacks with sample size (here indicated with S) equal to the original stack. More specifically, for each bin in the MSFR parameter space (Fig. 1), we produce N ≫ 1 resampled stacks, each of which is obtained by randomly selecting S galaxy spectra from the original sample of S spectra included in that bin and by co-adding them to produce a new “resampled” stack. The difference from the original stack is that, in the resampled stacks, the S spectra to be co-added together are extracted randomly from the parent sample of S galaxy spectra by allowing repetitions, therefore the spectrum of a given galaxy can be selected either once or more than once or never. After producing N resampled stacks for each bin, we perform the stellar continuum subtraction and the [OIII] and Hα+[NII] line fitting for each of them, exactly in the same way as for the original stacks (see Sects. 2.3, 2.5, and 2.6), in order to retrieve the LoSVDs of stars and gas. Therefore, for each bin and for a given LoSVD parameter of interest (pi), the bootstrap provides a distribution of N values. The variance of this distribution of N parameters (following on from the variance of the galaxy samples) is used to estimate the error on the measure of pi. The choice of the number N of resampled stacks for each bin is a compromise between statistics and computational effort. We set N = 10 for the most crowded bins (i.e. those including S ≥ 10 000 galaxy spectra), N = 50 for bins with 5000 ≤ S< 10 000, and N = 100 for the remaining ones, i.e. those with fewer than 5000 objects.

The simplest parameter to study is the line-of-sight velocity dispersion (σ), given by (6)where the line-of-sight velocity distribution described by ℒ(v) is normalised, such as , and vc is the centroid of the distribution, i.e. . The relationships between σ (of both the ionised gas, as traced by [OIII] and Hα and the stars), and galaxy properties such as SFR, M, and sSFR (sSFR = SFR/M, i.e. SFR per stellar mass unit) are shown in Fig. 14.

thumbnail Fig. 14

Line-of-sight velocity dispersion of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines and of the stars (bottom panel). The errors were obtained by applying the bootstrap method, as explained in the text. The grey dashed lines in the third column outline the sSFR range corresponding to the MS of local star-forming galaxies between 9.0 ≤ log (M [M] ) ≤ 11.0. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported in each plot, along with the corresponding two-sided p-value as given in parenthesis (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER

For each plot in Fig. 14, we calculated the non-parametric Spearman rank correlation parameter (ρ ∈ (0,1)5) to test the hypothesis of correlation between the line-of-sight velocity dispersion of gas and stars and the galaxy properties (SFR, M, sSFR). In our case, non-parametric tests such as the Spearman rank test are more appropriate than the standard Pearson correlation coefficient (r), since we are dealing with binned data and the relationship between σ and galaxy properties (if any) could be non-linear. A high value of ρ (e.g., ρ ≳ 0.5), combined with a low p-value (α, where α is the level of significance, which we set α = 0.05), indicates the presence of a statistically significant correlation. In the calculation of the p-value, we allow for both positive and negative correlations (“two-sided”). The results of the Spearman rank test are reported in Fig. 14.

As illustrated by the clean relationships in Fig. 14, our method is particularly effective at uncovering general trends between the dynamical properties of gas and stars and the galaxy properties. Moreover, Fig. 14 allows us to appreciate some differences between the dynamical behaviour of ionised gas and stars as a function of SFR and M. In absolute values, the velocity dispersions of gas and stars are roughly consistent, with the bulk of the galaxy bins showing values in the range 40 ≲ σ [km s-1] ≲ 150. However, for the highest stellar mass bins, i.e. log (M [M] ) ≳ 10.0, the velocity dispersions measured for the stars are slightly larger than the ones measured for the gas, especially when using Hα as a gas tracer. This weak effect can be explained by the contribution of stellar bulges in more massive galaxies. Gavazzi et al. (2015) have recently shown that >40% of isolated local star-forming galaxies with M> 109.5M host stellar bulges (without distinguishing between classical bulges and pseudo-bulges), whereas the fraction of stellar bulges at M< 109.5M is only ~5%. When a galaxy has a prominent stellar bulge, its stellar LoSVD probes both the galactic disk and the bulge, whereas the LoSVD of the ionised gas only traces the dynamics in the disk (and, possibly, a ionised outflow), which is more subject to projection effects than the bulge. In particular, disks viewed face-on contribute much less to the broadening of the LoSVD than edge-on disks. Therefore, it is possible that, by averaging many spectra of massive galaxies with stellar bulges together, observed from different viewing angles, the resulting line-of-sight velocity dispersions are slightly higher for the stars than for the gas, because of the additional contribution from the stellar bulge.

By inspecting the plots in the first column of Fig. 14, we note that σ[OIII] and σHα are tightly correlated (ρ> 0.9) with the SFR, and the correlation holds both at low and high stellar masses. The line-of-sight velocity dispersion of the stars is also correlated with the SFR, but more weakly than the gas (ρ = 0.795), and the σstarsSFR relationship flattens at log (M [M] ) ~ 10.5 (ρ = 0.029, p-value = 0.957).

The steady increase in gas velocity dispersion with SFR observed in Fig. 14 may trace a combination of various physical processes. Since feedback-related mechanisms should only affect the gas kinematics, leaving the motions of (evolved) stellar populations unperturbed, we can use the stellar velocity dispersion as a reference to identify trends that are not related to feedback. The positive correlation between σstars and SFR observed at low stellar masses may be due to the presence of gas contributing to the dynamical mass, the gas being traced by the SFR via the S–K relation, and therefore it may be related to an increase in gas fraction (at fixed stellar mass). However other mechanisms may produce a similar effect: in the first place, as already mentioned, a possible anti-correlation between the projected size and the SFR in galaxies, in conjunction with the limited SDSS fibre aperture, may affect the observed stellar LoSVD. Moreover, mergers and galaxy interactions, whose fraction is expected to increase at higher SFRs, can also have an impact on the observed LoSVDs, owing to the combined motions of overlapping disks or tidal motions of collision, as pointed out by Rupke & Veilleux (2013) in their study of ULIRGs. However, mergers are relatively unimportant in the local Universe: the local galaxy merger rate estimated using SDSS data is about 0.01 Gyr-1 (Patton & Atfield 2008). Assessing the relative importance of these different factors in producing the observed trend of increasing σstars with SFR (at a given M) goes beyond the scope of this paper and requires spatially resolved observations. For the concerns of the present study, these results suggest caution in interpreting the observed broadening of the ionised gas LoSVDs with SFR as entirely due to feedback-related processes, since the effects described above (and affecting both stars and gas) may be at work.

Moreover, as mentioned above, outflows of ionised gas are not the only feedback-related mechanisms that can affect the observed gas velocity dispersions. Higher σgas may also trace star formation-induced turbulence in galactic disks (Faucher-Giguère et al. 2013), such as turbulence injected in the gas by SNe explosions, which would naturally depend on the SFR (e.g. Shetty & Ostriker 2012; Hopkins et al. 2012). Indeed, observationally, vertical disk velocity dispersions in the gas (increased by turbulence) would be convolved with circular velocities due to inclination effects, thereby affecting the sightline-averaged gas velocity dispersions. Faucher-Giguère et al. (2013) suggest that turbulence resulting from stellar feedback regulates the the rate of formation of giant molecular clouds (GMCs), where most of star formation takes place, thereby playing an important role in regulating the global disk-averaged star formation efficiency in galaxies (Faucher-Giguère et al. 2013).

The tendency of galaxies with higher SFRs (as traced by their IR luminosity) to show larger optical emission line widths has already been shown by earlier observational studies (Veilleux et al. 1995; Lehnert & Heckman 1996). However, more recent results by Arribas et al. (2014) indicate that star-formation-driven turbulence may play only a marginal role in increasing the velocity dispersion of ionised gas in galaxy disks. These authors suggest that, at least in (U)LIRGs, galaxy interactions and AGNs may instead be the main responsible for the presence of dynamically hot gas disks.

Figure 14 also shows the line-of-sight velocity dispersion of gas and stars as a function of M (second column), with the bins colour-coded by their SFR, i.e. the diagram orthogonal to the one in the first column. As already pointed out, a positive correlation is expected since the stellar mass is a proxy for the total dynamical mass of a system, and higher dynamical masses result in higher velocity dispersions for gas and stars. The scatter is mostly ascribable to differences in SFR. For M> 1010M, where the relationship between σstars and SFR flattens (as shown in the first column plot), the correlation between σstars and M tightens.

For fixed stellar mass (indicated by the colour coding), the trends of σ vs. sSFR reported in the third column of Fig. 14 are identical to the trends vs. SFR, only shifted by −log (M). This is a natural consequence of binning galaxies in the MSFR parameter space. In these plots we show the range of sSFR corresponding to the MS of local star-forming galaxies (Fig. 1), calculated between 9.0 ≤ log (M) ≤ 11.06 following Peng et al. (2010) as detailed in Sect. 2.2. Such an sSFR range is very narrow, and this constitutes a fundamental property of the galaxy population: the sSFR, which is the ratio between ongoing star formation (i.e. SFR) and past-integrated star formation (i.e. M), is roughly constant in star-forming galaxies at a given epoch (Peng et al. 2010) (however, see also discussion in Gavazzi et al. (2015) and references therein according to which the MS relation changes slope above a turnover stellar mass, resulting in a decrease in sSFR with M in normal star-forming galaxies).

In conclusion, the widths of the [OIII] and Hα LoSVDs are not the most appropriate tools for investigating galactic outflows: although the correlations observed in Fig. 14 between σ and SFR (or sSFR) are likely to also be probing galactic outflows, there are other effects that may affect these trends, such as the previously discussed possible projection effects, star-formation-induced turbulence in the disk, and the effects of variations in the total dynamical mass on the virial motions of stars and gas. To reduce the influence of virial motions and to shed light on the effects of galactic outflows on the ionised gas dynamics, we need to focus our investigation on the high velocity tail of the LoSVDs.

thumbnail Fig. 15

(Modulus of the) 0.1th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 0.1th percentile velocity corresponds to 3 standard deviations (σ) from the mean velocity, and therefore it probes the high velocity blueshifted tail of the LoSVD. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER

To this purpose, we calculated the 0.1th, 2.3th,15.9th, 84.1th, 97.7th, and 99.9th percentile velocities of the LoSVDs of gas and stars. We chose these values because, in a Gaussian distribution, they respectively correspond to −3σ, −2σ, −1σ, 1σ, 2σ, and 3σ, where σ is the standard deviation of the Gaussian distribution. The Nth percentile velocity, vN, is defined as (7)where P(v<vN) is the probability of observing, with the given line-of-sight velocity distribution ℒ(v), velocities lower than vN, and .

Figure 15 shows the 0.1th percentile velocities of the [OIII], Hα, and stellar LoSVDs as a function of SFR, M, and sSFR. The corresponding plots obtained for the other percentile velocities are shown in the Appendix (Figs. A.1 to A.5). The results of the Spearman rank test performed on the relationships between the various LoSVD parameters (σ and percentile velocities) and galaxy parameters (SFR, M, and sSFR), for both gas and stars, are reported in Table 1 to facilitate the comparison between the different relationships shown in Figs. 14, 15, and A.1A.5.

Table 1

Spearman rank correlation parameters.

It is clear from Table 1 that the velocity dispersions and the percentile velocities show all significant correlations with SFR and M for both the gas and the stars. There are, however, important differences among the various LoSVD parameters, in particular between the 15.9th and the 0.1th percentile velocities. More specifically, by moving towards the high-velocity blueshifted tail of the LoSVD (i.e. from the 15.9th to the 0.1th percentile velocity), the correlation between gas velocity and SFR tightens (the Spearman correlation coefficient ρ increases), whereas the correlation between stellar velocity and SFR weakens slightly (ρ decreases). A similar trend is also shown for the redshifted tail of the LoSVD (i.e. from the 84.1th to the 99.9th percentile velocity). These results strengthen the hypothesis that the high-velocity tail of the ionised gas LoSVD traces mainly star formation-feedback related mechanisms and is affected very little by other mechanisms, which instead dominate the relationships between stellar velocity and SFR. The correlation between gas velocity and SFR is slightly tighter at blueshifted than at redshifted velocities (especially if using Hα as a tracer), probably because of dust extinction mostly affecting the receding (i.e. redshifted) side of the outflow. Furthermore, Table 1 shows that the correlation between ionised gas velocity and M weakens (and almost breaks down, as clearly shown in the corresponding plots in Fig. 15 and Figs. A.3A.5) towards the high-velocity tail of the LoSVD (ρ decreases), suggesting that gravity (as traced by M) does not play an important role in determining the dynamics of the high-velocity gas.

In summary, by exploring the relationships between the different percentile velocities of the LoSVDs of gas and stars and the galaxy parameters, we infer that the correlation with the SFR is tighter for the ionised gas at higher percentile velocities and, in particular, that the high velocity (blueshifted or redshifted) tails of the gaseous LoSVDs depend tightly on the SFR (correlation coefficient ρ ≳ 0.9) and more weakly (ρ< 0.7) on the M. This result supports the hypothesis that, in the high velocity regime, the gas kinematics progressively ceases to probe the dynamical mass of galaxies (which is in first approximation traced by the stellar mass), but it is instead intrinsically related to the rate at which stars are formed, most likely because of the presence of stellar feedback mechanisms.

However, regardless of the correlations observed between the various LoSVD parameters (σ and percentile velocities) and galaxy properties (SFR, M, sSFR) that have been discussed in this section (Table 1), in order to isolate the effects of outflows from other mechanisms we need to investigate the differences between the LoSVDs of gas and stars. Indeed, by looking at the galaxy stacks where the difference (vgasvstars) is significantly greater than zero, we can identify galaxies where the motions of gas and stars are clearly decoupled, and thus galaxies where outflows are most likely taking place. Differences between the gaseous and stellar kinematics and their dependency on galaxy properties are investigated in Sect. 3.4.

3.3. Asymmetries in the LoSVDs of gas and stars

Asymmetric wings of nebular emission lines usually trace perturbed gas, whose dynamics is not consistent with purely virial motions, but they can be instead explained with radial (outward or inward) motions in conjunction with dust extinction effects. The presence of a blue asymmetry is commonly interpreted in terms of outflows, because obscuration by dust in the galaxy disk primarily affects the backside receding gas (e.g. Lehnert & Heckman 1996; Villar-Martín et al. 2011; Soto et al. 2012).

thumbnail Fig. 16

Blue asymmetry of the [OIII] (top panel), Hα (middle panel), and stellar (bottom panel) LoSVDs, as measured by the difference between the (moduli of the) 2.3th and 97.7th percentile velocities (i.e. y = | v2.3 | − | v97.7 |). For display purposes, only the less noisy bins are plotted, i.e. bins with either σy< 50 km s-1 or | y | ≥ 2σy. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p-value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER

Visual inspection of the LoSVD profiles of gas and stars shown in Figs. 8 to 13 suggests that the line-of-sight velocity distributions of both gas and stars are not symmetrical. We further investigate this possibility in Fig. 16, where we plot, as a function of SFR, M, and sSFR, the difference between the (moduli of the) 2.3th and 97.7th percentile velocities, i.e. | v2.3 | − | v97.7 |, evaluated for [OIII], Hα, and stars. Figure 16 shows that almost all galaxy bins (a part form a few, noisier stacks) exhibit a clear blue asymmetry in the LoSVDs of [OIII] and Hα, with | v2.3 | − | v97.7 | values ranging between ~0 km s-1 and ~100 km s-1. Very surprisingly, the stellar LoSVDs are also affected by a blueward asymmetry, although it is less pronounced than in the gas. The velocity difference | v2.3 | − | v97.7 | measured for the stars is consistent with zero at low SFRs. However, in galaxy bins with SFR ≳ 0.1 M yr-1, | v2.3 | − | v97.7 | increases up to values of a few tens of km s-1, with large uncertainties, but still significantly larger than zero and therefore inconsistent with the absence of any asymmetry.

The presence of a blue asymmetry in the LoSVDs of [OIII] and Hα is suggestive of galactic outflows. The hypothesis of star-formation-driven outflows is corroborated by the correlation observed between the Hα blue asymmetry (as traced by | v2.3 | − | v97.7 |) and the SFR (ρ = 0.594), and by the hint of a correlation observed for [OIII] (ρ = 0.361). We note, however, that the dust properties of galaxies may also affect the trends observed for [OIII] and Hα in Fig. 16. Indeed, by using Herschel observations of local and intermediate-redshift (z ≲ 2.5) galaxies, Santini et al. (2014) found a tight correlation between dust mass and SFR, which they interpreted as a consequence of the Schmidt–Kennicutt law (since dust and gas mass are related). Therefore, the positive correlation between | v2.3 | − | v97.7 | and SFR observed for the ionised gas is likely the combined effect of star formation-driven outflows and MdustSFR proportionality, since dustier galaxy disks result in more pronounced line asymmetries. The evidence of a relationship between LoSVD blue asymmetry and M is instead more marginal (ρ = 0.362 and ρ = 0.279, respectively, for [OIII] and Hα, second column of Fig. 16). The absence of a clear correlation is consistent with the recent results by Santini et al. (2014), who show that the positive correlation between dust and M found by previous studies significantly flattens when separating galaxies according to their SFR.

Figure 16 shows that, in the stellar LoSVDs, blue asymmetries are also present but, owing to the large uncertainties, it is very difficult to investigate possible relationships with galaxy properties. However, we note that there is some evidence of a weak correlation between stellar blue asymmetry and SFR (ρ = 0.551) and an even more marginal one with stellar mass (ρ = 0.401), vaguely recalling the corresponding trends observed in ionised gas.

In Fig. 5 (Sect. 2.5) we showed a check on the stellar continuum fitting for two galaxy stacks: one exhibiting a blue asymmetry in the stellar LoSVD, and one with no asymmetry. These plots demonstrate that the detection of such a faint feature in the stellar kinematics of external galaxies is made possible thanks to the high signal-to-noise reached in the composite spectra, which allows us to fit the stellar continuum (and so extract the stellar kinematics) with unprecedented accuracy. To our knowledge, blue asymmetries in the stellar LoSVDs of external galaxies have never been observed before. Indeed, while an intrinsic kinematic asymmetry or “lopsidedness” in the stellar distribution is certainly possible for individual galaxies or at specific locations within galaxies, for example due to stellar bars, galaxy interactions, or even counter-rotating disks (e.g. Krajnović et al. 2015), such effects should average out when combining the integrated spectra of thousands of different galaxies. The observation of an asymmetry of the stellar LoSVD that is consistently blue (and never red) could be explained by the presence of stars in radial outward motions in galaxies, combined with obscuration by dust lanes in the galactic disk. Dust in the disk would mainly hamper the detection of stars moving away from the galaxy with a redshifted (line-of-sight) velocity component, hence skewing the average stellar LoSVD towards blueshifted velocities.

The blue asymmetries in the stellar LoSVDs suggest that high-velocity runaway stars, hypervelocity stars (HVS, Brown et al. 2005) and possibly high-velocity stellar clusters (Caldwell et al. 2014) in radial motions may be a rather common phenomenon in star-forming galaxies. High-velocity stars in radial trajectories are usually very difficult to detect even in our own galaxy. Palladino et al. (2014) discovered a sample of 20 candidate hypervelocity stars in the Milky Way, the bulk of which have velocities between 600 and 800 km s-1, and in at least half of the cases exceed the escape velocity from the Galaxy. These are G- and K-type dwarf stars, hence less massive and older than the typical massive B-type HVSs (Brown et al. 2012). Interestingly, the trajectories of the stars detected by Palladino et al. (2014) are not consistent with ejection via three-body interactions between a binary system and the SMBH of our Galaxy or of M 31, which is currently the most popular explanation for young B-type hypervelocity stars (Hills 1988; Yu & Tremaine 2003) and predicts that one component of the binary system remains in a bound orbit around the SMBH. On the contrary, the HVS candidates detected by Palladino et al. (2014) appear to come from all directions, suggesting that another mechanism must be capable of accelerating stars to high speeds, such as a supernova explosion in a close binary system (Blaauw 1961; Zubovas et al. 2013), which is currently the most likely origin of lower speed runaways ejected from the galactic disk (Brown et al. 2015). Notably, the fastest HVS ever detected, US 708, with a Galactic rest-frame velocity of 1200 km s-1, has been recently confirmed to be a solid candidate for an ejected Type Ia supernova donor remnant (Geier et al. 2015). The supernova binary ejection scenario may be a viable explanation for our observations, supported by the tentative correlation observed in Fig. 16 between the stellar blue asymmetry and the SFR.

However, although HVSs may provide a plausible explanation for the blue asymmetries observed in the stellar LoSVDs of local star-forming galaxies, the properties and origin of these features need further and in-depth investigation with high signal-to-noise data such as will be delivered by ongoing surveys (Gaia, MaNGA) and new facilities (MUSE, JWST, 30 m class telescopes).

3.4. Outflow properties

Overall, the presence and properties of the line-of-sight velocity distributions of ionised gas as derived from composite spectra of nearby inactive galaxies suggest the ubiquity of star-formation-driven galactic outflows. However, our analysis has also highlighted the presence of additional factors, other than outflows, that are likely to be affecting the kinematics of both the ionised gas and the stars, namely virial motions, projection effects, gas content, and dust extinction. The next step is to try to isolate the effects of gas outflows in the data, disentangling them from other mechanisms, in order to get a completely unbiased picture of their occurrence and properties in local galaxies.

The plots in Figs. 1416 provided important clues to the concomitant mechanisms that have an impact on the LoSVDs of gas and stars. In the following, we briefly summarise some logical deductions that will help us understand outflow properties:

  • 1.

    The effects of virial motions on gas kinematics can be reducedconsiderably by looking at the high-velocity tail of the LoSVD ofthe ionised gas. In particular, the correlation between theline-of-sight velocity of the ionised gas and M (which is related to the dynamical mass) is weaker for the 0.1th and 99.9th (ρ ~ 0.6) than for the 15.9th and 84.1th (ρ ~ 0.8) percentile velocities (Table 1). Moreover, the highest velocities show the tightest correlation with the SFR (ρ ≳ 0.9), indicating that the effects of star-formation-driven feedback is indeed predominant.

  • 2.

    The stellar LoSVDs appear quite broad with stellar velocity dispersions as high as ~170 km s-1, i.e. as high as the highest σ observed in the ionised gas and, for high stellar masses, even higher than the gas, probably because of the presence of stellar bulges in massive galaxies combined with projection effects, as explained in Sect. 3.2. As a consequence, only the excess of gas velocity with respect to the stars, i.e. vgasvstars, can reliably trace gas motions due to gaseous outflows.

  • 3.

    Because of dust attenuation, the blueshifted side of the LoSVD of the gas is a better probe of outflowing gas than the redshifted side. Therefore, following points (i) and (ii), gaseous outflows will be investigated through the 0.1th percentile velocity of the LoSVD of [OIII] and Hα, from which we subtract the corresponding stellar velocity.

  • 4.

    Another complication for the study of ionised outflows is given by the presence of (modest) blue asymmetries in the stellar LoSVDs, whose origin is not clear and may be related to non-virial motions of stars in galaxies. In the following analysis, we assume that this effect can be reduced (if not completely removed) by simply using the redshifted stellar velocities, i.e. by subtracting from the 0.1th percentile LoS velocity of the gas, the 99.9th (rather than the 0.1th) percentile LoS velocity of the stars.

By considering points 1 to 4, the most appropriate tracer of ionised outflows is then given by the velocity difference | v0.1 gas | − | v99.9 stars | 7: this quantity will be used to track “secure” outflows in galaxy stacks. Indeed, if (vgasvstars) > 0, then the kinematics of gas and stars are decoupled, and we are reliably tracing gaseous outflows. The only other mechanism that would explain such decoupling would be galaxy mergers, but the merger fraction is negligible in the local Universe (Patton & Atfield 2008), so gaseous outflows are the only viable explanation.

Figure 17 shows the relationships between the quantity | v0.1 gas | − | v99.9 stars |, evaluated for both [OIII]- and Hα-emitting gas, and the galaxy physical parameters (i.e. SFR, M, and sSFR). In Fig. 18 we show the stacking grid in the MSFR parameter space defined by the sample of local star-forming galaxies used in this study (i.e. the same grid as in Fig. 1), with each bin colour-coded according to the value of | v0.1 gas | − | v99.9 stars | (measured for [OIII] and Hα).

It is worth emphasising that the negative values of | v0.1 gas | − | v99.9 stars | estimated in some galaxy bins (especially at log (M [M] ) ≥ 10.0), are probably a consequence of the conjunction of projection effects and of the absence of detectable galactic outflows. More specifically, ignoring galactic outflows (which usually expand perpendicular to the galactic disk along its minor axis, as shown by observations, e.g. Lehnert & Heckman 1996; Heckman et al. 2000; Chen et al. 2010; Rubin et al. 2014; Cazzoli et al. 2014), the ionised gas is confined to the plane of the galactic disk, and the projection effects described in Sect. 3.2, affecting mostly observations of face-on galaxies with a prominent stellar bulge (which dominate the population of high-M galaxies, e.g. Gavazzi et al. 2015), can be even more accentuated. For this reason, negative values of | v0.1 gas | − | v99.9 stars | simply indicate galaxy bins in which outflows are not present or in which outflows are not prominent enough to be detected: as a consequence, this quantity can reliably trace outflows only when it is positive.

thumbnail Fig. 17

Excess of line-of-sight velocity of the ionised gas with respect to the stars (vgasvstars) as given by y = | v0.1 gas | − | v99.9 stars | for [OIII] (upper panel) and for Hα (bottom panel). For display purposes, only the less noisy bins are plotted, i.e. only bins with either σy< 50 km s-1 or | y | ≥ 2σy. As explained in Sect. 3.4, the quantity y is a reliable tracer of ionised outflows only when it is positive. The Spearman rank correlation coefficient (0 < | ρ | < 1, higher values of | ρ | indicate stronger correlation, ρ< 0 if there is an anti-correlation) is reported in each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER

Although many attempts have been made to establish fundamental “scaling” relationships linking outflows and galaxy properties (Martin 2005; Rupke et al. 2005; Chen et al. 2010; Westmoquette et al. 2012; Martin et al. 2012; Rubin et al. 2014; Arribas et al. 2014; Heckman et al. 2015), the general picture remains unclear and contradictory. The main reason for this impasse may be the absence of a study on galactic outflows of large statistical significance: most of previous studies relied on limited samples of objects, showing extreme characteristics and spanning only a narrow range of galaxy properties (e.g. SFR, M). As a consequence, previous results do not adequately represent the whole local population of galaxies. Our analysis instead capitalises on a large statistical and almost unbiased sample of local star-forming galaxies, particularly suitable for determining scaling relationships between galactic outflows and galaxy properties. Moreover, our method allows us to accurately identify and separate of the effects of star-formation driven outflows from the other mechanisms affecting the LoSVD of the gas.

The general picture emerging from Figs. 17 and 18 is the following8: the excess of gas velocity with respect to the stars (i.e. vgasvstars, as traced by | v0.1 gas | − | v99.9 stars |), which we use in this study to trace galactic outflows, depends weakly on the SFR (ρ = 0.602 for [OIII], but for Hα the correlation with SFR is much weaker, ρ = 0.311, and not statistically significant as indicated by the high p-value) and more tightly on the sSFR (ρ = 0.804 and ρ = 0.485 for [OIII] and Hα, respectively). However, we note that for galaxy bins identified by higher stellar masses, the correlation between | v0.1 gas | − | v99.9 stars | and SFR at a fixed M becomes significantly tighter for both [OIII] and Hα, i.e. ρ> 0.8 (with p-value 0.05) at M ≥ 109.5M and even more so at M ≥ 1010M, for which we measure ρ> 0.95.

thumbnail Fig. 18

Grid of galaxy bins in the MSFR parameter space used for the spectral stacking (see also Fig. 1). Each bin is colour-coded according to the line-of-sight velocity difference vgasvstars as given by | v0.1 gas | − | v99.9 stars | for [OIII] (upper panel) and for Hα (lower panel). The | v0.1 gas | − | v99.9 stars | values are also reported for each bin. The same bins as in Fig. 17 are plotted.

Open with DEXTER

In general, there is instead no relation between | v0.1 gas | − | v99.9 stars | and M (second column of Fig. 17): ρ = −0.054 for [OIII] and ρ = −0.242 for Hα, but with high p-values, implying that such a weak anti-correlation is not significant. For some galaxy bins, an anti-correlation appears between | v0.1 gas | − | v99.9 stars | and M at a fixed SFR. This effect is, however, highly significant (ρ< −0.9) for both [OIII] and Hα only at log (SFR [M yr-1] ) = −1.0 and log (SFR [M yr-1] ) = 0.5. Since the stellar mass traces the depth of the gravitational potential in galaxies, these observations would suggest that, on equal SFRs, it becomes increasingly difficult to launch gaseous outflows in larger gravitational potentials by means of star formation feedback alone. This qualitatively agrees with theoretical predictions (further discussed in Sect. 4.1), as well as with indirect observational evidence of a mass dependence of negative feedback provided by studies of the “mass-metallicity” relationship in galaxies (Tremonti et al. 2004; Maiolino et al. 2008). These studies show that the gas-phase metallicity increases steadily with stellar mass, at least up to log (M [M] ) ≃ 10.5, suggesting that low-mass galaxies are less able than massive galaxies to retain the metals provided by supernova explosions in their gas phase, probably because they are more vulnerable to galactic outflows.

In addition, Fig. 17 reveals some interesting differences between [OIII] and Hα as tracers of ionised outflows. In particular, Hα emission seems to be a worse tracer of galactic outflows than [OIII] emission: (i) The correlation between vgasvstars and SFR is considerably weaker and less significant for Hα than for [OIII], and the same holds for the correlation with sSFR; (ii) for bins with log (M [M] ) = 11.0, high values of | v0.1 gas | − | v99.9 stars | are inferred by using [OIII], whereas no velocity excess is detected when using Hα emission as a gas tracer. Qualitatively, a higher outflow ionisation in more massive galaxies could explain the differences that we show between [OIII] and Hα as outflow tracers. We note that it is unlikely that such a difference between the Hα and [OIII] LoSVDs is a consequence of residual stellar Hα absorption. Indeed, the Hα LoSVDs are obtained by fitting the Hα and [NII]λλ6548, 6583 lines simultaneously (see Sect. 2.6), by constraining the kinematics of all components employed in the fit to be the same for the three lines. Therefore, the resulting LoSVDs also reflect the kinematics traced by the [NII] lines, which are much less affected by possible residual stellar absorption.

Finally, we note that there is an intriguing property of galactic outflows that stands out immediately from Fig. 18: local non-active galaxies hosting powerful outflows are located above the main sequence of star-forming galaxies. The absence (or insignificance) of galactic outflows along and/or below the MS, which we show here for the first time in a clear way, probably constitutes a striking feature of the local galaxy population, and it may persist to higher redshifts, as marginally shown in outflow studies at z ~ 1 (Martin et al. 2012). The relationship between galactic outflows and the MS of star-forming galaxies will be discussed in Sect. 4.2.

4. Discussion

4.1. Implications of outflow properties for feedback models

Intense star formation activity conveys energy and momentum to its surroundings, which can then be transmitted by various physical mechanisms to larger scales, thus eventually impacting the entire host galaxy and affecting its capability of forming stars (negative feedback). Although negative feedback from star formation can manifest under various forms (such as multi-phase galactic outflows, shocks, hot bubbles, cavities, and metal enrichment of the IGM), its direct and unambiguous signature can be very difficult to detect in most galaxies. As a consequence, the detailed physics underlying this phenomenon is not yet completely understood, any more than its relevance for quenching star formation in galaxies. However, significant advances have been accomplished by theorists in this field, who by also exploiting the valuable information provided by observational studies, propose two main scenarios for star-formation-driven feedback to occur:

  • 1.

    According to the first, “canonical” scenario, thekinetic energy released by supernova explosionsand, especially in the very first stages of the starburst(Δt ≤ 107 yrs) and at high metallicities (), by stellar winds from OB and Wolf-Rayet stars, plays the most important role in counteracting and self-regulating star formation (“energy-driven” scenario, e.g. Chevalier 1977; Leitherer et al. 1992; Chevalier & Clegg 1985; Springel & Hernquist 2003; Veilleux et al. 2005). This feedback mechanism is subject to the thermalisation efficiency of the energy deposited into the ISM. This efficiency may vary, but it is believed to be around 110%; therefore, up to ~99% of the total kinetic energy injected by star formation may be dissipated radiatively in dense gas (Chevalier 1977; Murray et al. 2005; Thornton et al. 1998; Mac Low & Ferrara 1999). If the transfer from kinetic energy from SNe and stellar winds to cloud motions is efficient enough to unbind the gas in the galaxy, it can drive strong and large-scale outflows (Chevalier & Clegg 1985). A natural outcome of this model is that energy-driven outflows are more important at a given SFR (which is directly related to the kinetic energy injected by supernova ejecta and by stellar winds into the ISM) in low-mass galaxies residing in less massive dark matter halos, because it is easier for gas to escape from their shallower gravitational wells (Dekel & Silk 1986; Springel & Hernquist 2003; Davé et al. 2011b).

  • 2.

    In the second scenario, the momentum transferred by the UV radiation from young and massive stars to dust and the momentum injected by supernova explosions9 (“momentum-driven” scenario) dominate the feedback mechanism (Murray et al. 2005; Davé et al. 2011b). The advantage of momentum-driven outflows is that they can be effective even when radiative losses are high, because momentum cannot be radiated away (Murray et al. 2005). However, to be effective, this feedback mechanism requires ISM conditions that may not be satisfied in normal local star-forming galaxies, such as large optical depths to infrared radiation (Davé et al. 2011b; Hopkins et al. 2011), as well as collisional coupling of gas and dust in the outflow (Murray et al. 2005; Davé et al. 2011b). For these reasons, momentum-driven outflows may be most effective at launching cold and dense gas (which is likely hydrodynamically coupled to dust) in dusty star-forming galaxies and AGNs (Murray et al. 2005; Fabian 2012). We note that in this model, according to the original formulation by Murray et al. (2005), the condition that must be satisfied in order to launch gas outward via momentum injection is that the total momentum flux exceeds the gravitational force, which translates into a condition on the luminosity of the starburst LLM, where LM is an “Eddington-like” luminosity threshold. If LLM, a momentum-driven wind develops with velocity vout ≳ 2σ (where σ is the stellar velocity dispersion; Murray et al. 2005).

In Sect. 3.4 we have identified the galaxy stacks displaying the signature of galactic outflows such as those for which the excess of gas velocity with respect to the stellar velocity, as estimated from the high-velocity tail of the LoSVD, is significant. More specifically, we have considered values of | v0.1 gas | − | v99.9 stars | that are significantly greater than zero as a clear signature of outflows. The next step would be comparing the scaling relationships obtained for the observed outflows with the expectations of theoretical models. However, while being suitable for identifying outflows, the quantity | v0.1 gas | − | v99.9 stars | is not appropriate for the comparison with models, because it has no clear interpretation in terms of the physical quantities usually employed by theorists. Unfortunately, because of the information lost with the stacking, it is not possible to estimate the mass entrained in the observed outflows and therefore to calculate some important parameters such as mass-loss rate, kinetic power, and momentum rate of the outflows, which would help to distinguish different feedback models. Most importantly, spatially resolved spectroscopic information is needed to infer these quantities (Rupke & Veilleux 2013; Cazzoli et al. 2014; Arribas et al. 2014). However, we can obtain a proxy of the outflow velocity, and this can be exploited to shed light on the physical mechanism powering the ionised outflows.

The LoSVD of ionised gas traces a combination of dynamical motions of gas clouds within the gravitational potential of the galaxy and of perturbed motions due to star formation feeedback-related processes, such as outflows and turbulence in the disk. In the following analysis, since we consider only the high-velocity tail of the LoSVD, we assume that outflows dominate turbulence and so, simplistically, that any non-gravitational motions of the gas at such high velocities are due to outflows and not to turbulence. Therefore, the LoSVD of the gas may be regarded as the convolution of two line-of-sight velocity distributions, one tracing the virial motions, and the other one tracing the outflow: (8)We note that such an approximation reflects the fact that the typical outflows detected in our galaxy sample are rather modest, and most likely consist of localised bubbles and chimneys, emanating from star-forming regions spread across the stellar disk (see also the case of NGC 1569 discussed by Martin et al. 2002). In this scenario, the outflowing material participates, at least to some extent, also to the virial (rotational) motions in the galaxy. However, we stress that Eq. (8) is not universally applicable. In particular, Eq. (8) does not hold if the kinematics of the high velocity gas is largely dominated by a large-scale “bulk outflow” expanding perpendicular to the disk. This is the case of powerful starburst-driven superwinds (e.g. M 82, NGC 253) if they are probed on scales of at least a few kpc, i.e. sufficiently larger than the typical vertical scale height of the stellar disk, where the motions of the gas in outflow is clearly distinct from the disk motions. Indeed, even the strong “bulk outflows” that develop in powerful starbursts such as M 82 appear to originate as a collection of individual chimneys expanding out from the disk that subsequently merge to form the classical biconical outflows observed on kpc scales (Wills et al. 1999; Lehnert & Heckman 1996).

Following from Eq. (8), by (simplistically) approximating both virial(v) and outflow(v) with Gaussian distributions, the line-of-sight velocity dispersion of the gas corresponds to: (9)where σvirial can be approximated by the stellar line-of-sight velocity dispersion, i.e. σvirialσstars. As a result, the “outflow” line-of-sight velocity dispersion would be (10)We note that Eq. (10) can also be extended to the percentile velocities because, in the approximation of Gaussian distributions, they correspond to multiples of the velocity dispersion. According to this line of reasoning, the outflow velocity can therefore be approximated by the quantity , where vN indicates the Nth percentile velocity.

As we commented earlier, because of the observed blue asymmetries observed in the stellar LoSVDs of some galaxy stacks (Sect. 3.3), the percentile velocities on the blue side of the stellar LoSVD, i.e. the 15.9th, 2.3rd, and 0.1th, may be not appropriate for tracing virial motions in the galaxy. Therefore, in the following, we adopt the same strategy as in Sect. 3.4 and define the outflow velocity as (11)where the percentile velocity of the gas is chosen on the blue side of the LoSVD (because it is less affected by dust), i.e. N = 0.1, 2.3, or 15.9, and for the stars, we use 100−N, which gives the corresponding percentile velocity on the red side of the LoSVD. We note that vout can be inferred from Eq. (11) only in those cases for which vN,gas>v100−N,stars: this means that vout cannot be calculated for quite a few bins below the MS, as illustrated by Fig. 18.

Figures 19 and 20 show the outflow velocity (vout) as a function of galaxy properties (e.g. SFR, σ, and sSFR), for two different estimates of the outflow velocity, indicated as vout,low and vout,high, probing respectively the low and the high velocity gas within the ionised outflows, and defined as and . We note that in the middle panels of Figs. 19 and 20, the outflow velocity is shown as a function of the stellar velocity dispersion instead of the stellar mass, so that these trends can be readily compared to the predictions of models of star-formation-driven feedback. Figures 19 and 20 indicate that the outflow velocity scales with SFR and sSFR. In particular, vout,high shows a very tight (ρ> 0.8) correlation with the SFR. Previous studies found a similar increase in outflow speed with SFR (e.g. Martin 2005 using a sample of IR luminous galaxies at z ~ 010; Arribas et al. 2014 for outflows detected in z ~ 0 (U)LIRGs; Chisholm et al. 2015 in local star-forming and starburst galaxies; Heckman et al. 2011 and Heckman et al. 2015 using a a sample of UV-luminous starbursts and Lyman break analogues at z ~ 0, Bradshaw et al. 2013 and Weiner et al. 2009 by means of a stacking analysis of star-forming galaxies at the typical redshifts of z ~ 1.2 and z ~ 1.4, respectively) and with sSFR (Bradshaw et al. 2013; Heckman et al. 2015). However, the correlations found by previous studies are in most cases less significant than in our study and inevitably based on smaller number statistics. Furthermore, the literature also reports many cases in which observations failed to find a clear correlation between outflow velocity and SFR (e.g. Heckman et al. 2000; Rupke et al. 2005; Chen et al. 2010; and Westmoquette et al. 2012 at z ~ 011; Sato et al. 2009 at z ~ 0.4; Rubin et al. 2014 at z ~ 0.5; Kornei et al. 2012 and Martin et al. 2012 at z ~ 1; Erb et al. 2012 at z ~ 1.5). In most cases, the main issue appears to be the narrow dynamical range of host galaxy properties probed by such outflow studies, which is crucial to recovering scaling relations (Rupke et al. 2005; Westmoquette et al. 2012; Martin et al. 2012). Inspection of Figs. 19 and 20 suggests that a strong correlation between outflow velocity and SFR is characteristic of galaxies with log (SFR [M yr-1] ) ≳ 0; at log (SFR [M yr-1] ) < 0 the dependence of vout on SFR is nearly flat.

thumbnail Fig. 19

Outflow velocity as given by (see explanation in Sect. 4.1) inferred from [OIII] (upper panel) and Hα emission (bottom panel), plotted as a function of SFR, stellar velocity dispersion (as obtained from the fit to the stellar continuum), and sSFR. The same bins as Fig. 17 are plotted, excluding those for which . In the middle panels, the dashed lines indicate the locus of points where vout = σstars. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER

thumbnail Fig. 20

Outflow velocity as given by (see explanation in Sect. 4.1) inferred from [OIII] (upper panel) and Hα emission (bottom panel), plotted as a function of SFR, stellar velocity dispersion (as obtained from the fit to the stellar continuum), and sSFR. The same bins as Fig. 17 are plotted, excluding those for which . In the middle panels, the black dashed lines indicate the locus where vout = σstars, and the grey dot-dashed lines indicate the approximate upper envelopes of the distributions of values, given by the relationships: vout = 6σstars for [OIII], and vout = 6σstars for Hα. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER

Overall we find that the outflow velocity increases with the stellar velocity dispersion, as shown by Fig. 20 (a positive correlation between vout,high and σ is observed with ρ> 0.6 and p-value 0.05 for both [OIII] and Hα outflows) and, to some extent, also by Fig. 19. A weak correlation between vout,low and σ is found for [OIII], although not for Hα. While the existence of a correlation between gas velocity and SFR is a more or less established property of galactic outflows, the relationship with stellar mass (or with the dynamical mass, as probed by the galaxy rotation speed or by the stellar velocity dispersion) is more controversial. Lehnert & Heckman (1996), in their sample of local, edge-on IR luminous galaxies did not find any relationship between the kinematical properties (emission line widths, velocity shear) of the ionised gas, as measured along the minor axis of the disks (where outflows are found to dominate the gas kinematics) and galaxy rotation speeds. Similarly, Heckman et al. (2000) showed that the NaI outflow velocity is unrelated to the galaxy rotational velocity. On the contrary, Martin (2005) found an almost linear relation with galaxy rotation speed (although they could only test this relationship for a small fraction of the galaxy sample with available rotation curves). The positive correlation between maximum outflow velocity and galaxy circular velocity found by Rupke et al. (2005) is completely driven by the dwarf starburst sample of Schwartz & Martin (2004), highlighting once again the importance of probing a wide dynamical range in galaxy properties. In line with this hypothesis, Arribas et al. (2014) find that the distribution of ionised outflow velocity as a function of galaxy dynamical mass is quite scattered in the (U)LIRG regime, i.e. for massive and strongly star-forming galaxies. The results by Heckman et al. (2011), whose sample spans a wider range of galaxy properties, suggest that outflow velocity and stellar mass are instead related. Studies at higher redshifts seem to find more consistently a correlation between outflow velocity and M in star-forming galaxies (Weiner et al. 2009; Bradshaw et al. 2013; Rubin et al. 2014).

Higher stellar velocity dispersions trace deeper gravitational potentials. The positive correlation that we observe in Fig. 20 between vout,high and σ suggests that ionised outflows may still gain a velocity high enough for gas to escape also from massive galaxies and not only from lower-mass galaxies (as would be the case if the outflow velocity did not depend on M, in which case the escape of the gas from low-mass galaxies would be favoured). However, we note that our analysis may be biased towards higher velocity outflows. Indeed, our method probably selects only outflows with velocity close to or above the escape velocity from the galaxy, because we are selecting gas velocities in excess of the stellar velocity in order to avoid contamination by gas in virial motion. Figure 20 also shows that, for a fixed SFR, the outflow velocity (in the high velocity regime) decreases with σ. A possible explanation is that for a given SFR, i.e. for a given energy and momentum budget available to accelerate the gas, outflows are slowed down and re-captured by the gravitational potential in more massive galaxies, and therefore they become increasingly ineffective at higher masses.

The relationships between outflow velocity and stellar velocity dispersion (central panels of Figs. 19 and 20) suggest that the physical mechanisms powering the lower and the higher velocity clouds in the observed ionised outflows may be slightly different. Indeed, at lower velocities (vout, low), which trace the bulk of the gas in outflow12, the data points are placed just below the vout = σ locus, indicating that radiation pressure-driven (or “momentum-driven”) winds, which are characterised by vout ≳ 2σ (Murray et al. 2005; Davé et al. 2011b), are unlikely to dominate in this regime. Instead, these outflows may be generated by the kinetic energy injected into the ISM by supernovae and stellar winds, i.e. “energy-driven”. Similarly, Bouché et al. (2012), by using background quasars to trace MgII blueshifted absorption in z ~ 0 galaxies, estimated outflow speeds that are on average half the escape velocity, although these authors did not find any correlation with the SFR. On the other hand, the situation changes significantly in the high-velocity regime, as shown by Fig. 20, where the data mostly lie above the vout = σ relationship. In this case, momentum-driven winds may also be at play (see also findings by Martin 2005; Heckman et al. 2015 for what they define as “strong outflows” at z ~ 0, and by Weiner et al. 2009, at z ~ 1.4). Figure 20 also suggests that the asymptotic velocity of the observed ionised outflows is as high as 6−8 σstars, i.e. comparable to or higher than the escape velocity (vesc ≃ (5−6)σ, where σ is the line-of-sight stellar velocity dispersion, gives a conservative estimate of the escape velocity, e.g. Weiner et al. 2009).

thumbnail Fig. 21

Excess of line-of-sight velocity of the ionised gas with respect to the stars (vgasvstars) as given by y = | v0.1 gas | − | v99.9 stars |, plotted as a function of the offset from the local MS of star-forming galaxies. In the upper panel the outflow velocity is measured from [OIII] and in the lower panel from Hα. As in Fig. 17, only bins with either σy< 50 km s-1 or | y | ≥ 2σy are shown. The black stars indicate the mean trend, obtained by averaging the data points (weighted with their errors) over bins of Δlog (SFR/SFRMS) = 0.5.

Open with DEXTER

4.2. The connection between galactic outflows and the main sequence of star-forming galaxies

Galactic outflows and cosmic inflows are invoked as key moderators of the SFR (and sSFR) in galaxies through cosmic times. Specifically, powerful galactic-scale outflows driven by AGNs and/or by extreme starburst episodes (possibly merger-driven) are thought to constitute the observational evidence for the so-called “quenching” mechanism acting on galaxies at all cosmic times (or “mass-quenching”, distinct from the “environment-quenching”, Peng et al. 2010, 2012). Such a mechanism, through different physical processes that are still poorly understood, should eventually transform disky star-forming galaxies into passive spheroids, thus generating the observed dichotomy between blue star-forming and red passive galaxies (Baldry et al. 2004). Cosmic inflows are believed to feed galaxies through a smooth and continuous process, hence directly regulating the rate at which star formation occurs (Dekel et al. 2009; Bouché et al. 2010; Lilly et al. 2013). The tight correlation between stellar mass and SFR observed from z ~ 0 up to z ~ 4 (Schreiber et al. 2015) provides the major observational support to the hypothesis of a “cosmic feeding of star formation”, but direct observational evidence is still lacking.

In this scenario there is an effect that has been explored very little from an observational point of view: the possible role of galactic outflows in shaping the MS of star-forming galaxies and, in particular, its upper envelope. Figure 18 shows that ionised outflows are detected only in galaxies located above the MS on the MSFR diagram. This effect can be visualised even better in Fig. 21, where we plotted the excess of line-of-sight velocity of the ionised gas with respect to the stars, i.e. | v0.1 gas | − | v99.9 stars | (for both [OIII] and Hα), as a function of the offset from the local MS (as derived in Sect. 2.2). Figure 21 shows a sharp increase in outflows at SFR>SFRMS, where for a given stellar mass, SFRMS represents the SFR of a galaxy located on the MS. In other words, we empirically observe that for a given stellar mass, when the SFR exceeds SFRMS, the gas velocity increases significantly, with the effect of producing observable outflows. These outflows may eventually contribute to the suppression of the SFR by reducing gas available for star formation, therefore bringing the galaxy back onto the MS. Our observational result may reveal a self-adjusting mechanism that explains the tightness of the local MS (i.e. ± 0.3 dex). We note that this hypothesis is consistent with the scenario recently proposed by Tacchella et al. (2016), who used simulations of high-redshift star-forming galaxies to explore the mechanisms that confine galaxies into a narrow sequence in the MSFR plane.

The picture emerging from Figs. 18 and 21 is consistent with the abundant observational evidence for outflows in local starbursts and (U)LIRGs. Outflows of ionised, neutral, and molecular gas are a common feature of galaxies with intense star formation activity, as traced by their high infrared luminosities LIR(8−1000 μm) ≥ 1011L (Chung et al. 2011; Sturm et al. 2011; Westmoquette et al. 2012; Rupke & Veilleux 2013; Rodríguez Zaurín et al. 2013; Veilleux et al. 2013; Spoon et al. 2013; Bellocchi et al. 2013; Cazzoli et al. 2014; Arribas et al. 2014; Cicone et al. 2014). These galaxies have greater SFR and sSFR than local MS galaxies (i.e. SFR> 10 M yr-1 and sSFR typically higher than 10-9 yr-1, e.g. Combes et al. 2013) and populate the upper-right region of the MSFR diagram. Previous observations at z ~ 0 are therefore consistent with our findings, i.e. that star formation-driven galactic outflows are preferably hosted by galaxies located above the local MS in the MSFR diagram.

In contrast, except from Martin et al. (2012), outflow searches at higher redshifts revealed in general no dependency of galactic outflows on the galaxy position on the MSFR diagram with respect to the MS (Rubin et al. 2014; Genzel et al. 2014; Förster Schreiber et al. 2014), although in some of these cases the observed outflows are plausibly driven by AGNs (Genzel et al. 2014; Förster Schreiber et al. 2014). The majority of NaID outflows detected by Sato et al. (2009) are hosted by galaxies lying on the red sequence in the rest-frame (UB) colour vs. MB diagram and showing early-type morphologies. These authors, however, note that most of the red sequence galaxies with detectable outflows in their sample may have some residual star formation, as suggested by their still high IR luminosities, and/or show signs of recent star formation, as indicated by their NUVRAB colour. Furthermore, since AGNs are not excluded from their sample, an accreting super massive black hole may be responsible for driving the observed outflows, especially in those galaxies that do not show any significant star formation activity.

We note that there are secondary effects emerging from Fig. 21. On the one hand, outflows seem to “saturate” at log (SFR/SFRMS) > 1.5 when using [OIII] as a tracer, while the scatter on the corresponding plot derived using Hα does not allow us to assess whether a similar saturation is also present for this tracer or not. On the other hand, the minimum SFR/SFRMS required to launch observable outflows seems to be lower (i.e. closer to 1) for [OIII], while it is about a factor of 10 larger for Hα.

An indirect implication of Fig. 21 is that galaxies located on or just below the local MS do not host significant outflows, although we cannot exclude the presence of low-velocity outflows (“weak outflows”, e.g. Heckman et al. 2015) or of fewer galaxies with important outflow activity but where the outflow is seen edge-on. This implies that star formation-driven outflows are likely not to be responsible for the migration of blue star-forming galaxies into the “red sequence”, and so they are not responsible for what we generally refer to as “quenching”, consistent with what is found by simulations (Hopkins et al. 2012) and also consistent with recent observational evidence that, for most galaxies, quenching results from the cutoff of gas inflow (a process referred to as “strangulation” or “starvation”, Peng et al. 2015). However, our results clearly highlight a link between high sSFRs (i.e. sSFR in excess with respect to MS galaxies) and fast star formation-driven outflows.

5. Summary and conclusions

Galactic outflows, ejecting gas out of the galaxy, are a manifestation of feedback. Powerful outflows have been observed in galaxies for decades, however it is still not clear what their role is in galaxy evolution and whether they are actually responsible for reducing or, in the most extreme cases, shutting off star formation in galaxies. Some key questions that we have addressed in this work are: how can we reliably trace galactic outflows and estimate their properties? How do outflow properties relate to the properties of the host galaxy? How do outflow properties compare to the predictions of galaxy evolutionary models?

The most obvious source of feedback in galaxies is star formation itself, which, by conveying energy and momentum to the interstellar medium over prolonged timescales, can potentially affect future star formation and hence galaxy evolution. In this paper we have investigated the presence and properties of star formation-driven outflows of ionised gas in normal galaxies by using a large spectroscopic sample of ~160 000 local non-active galaxies drawn from the SDSS. The galaxy sample was divided into a fine grid of bins in the MSFR parameter space, for each of which we produced a composite spectrum by stacking together the SDSS spectra of the galaxies contained in that bin. We exploited the high signal-to-noise of the stacked spectra to study the emergence of faint features of optical emission lines that trace galactic outflows, which otherwise would be too faint to detect in individual galaxy spectra. Not only has the stacking technique allowed us to explore the presence of galactic outflows in a large and representative sample of normal galaxies, spanning a wide range of galaxy properties (M ∈ [2 × 107,6 × 1011] M and SFR ∈ [2 × 10-3,2 × 102] M yr-1), but also to break the degeneracy between SFR and M that affects the bulk of the local star-forming galaxy population (i.e. the MS galaxies).

Based on the assumption that feedback-related processes (outflows, turbulence) should only affect the gas kinematics, leaving the motions of stellar populations unperturbed, we traced the kinematical signature of feedback by adopting a novel approach that relies on the comparison between the LoSVD of the ionised gas (as traced by the [OIII] and Hα+[NII] emission lines) and the LoSVD of the stars, which were used as a reference tracing virial motions. More specifically, significant deviations in the ionised gas kinematics compared to the stellar kinematics in the high-velocity tails of the LoSVDs (to minimise the effects of virial motions and turbulence) were interpreted as a signature of outflows.

Our results suggest that the incidence of ionised outflows in local star-forming galaxies increases with SFR and sSFR. Moreover, at a given SFR, more massive galaxies are increasingly less efficient at launching powerful outflows. In galaxy stacks displaying the clearest signature of galactic outflows, the outflow velocity (vout) was found to correlate tightly with the SFR for SFR> 1 M yr-1, whereas at lower SFRs the dependence of vout on SFR appears nearly flat. Although with a much larger scatter, the outflow velocity also increases with the stellar velocity dispersion (σ) and in a few galaxy stacks reaches values as high as vout ~ (6−8)σ, indicating that both energy-driven and momentum-driven winds may be at play.

Strikingly, the kinematical signature of ionised outflows was detected only in galaxies located above the main sequence of star-forming galaxies in the MSFR diagram, and the incidence of high-velocity outflows increases sharply with the offset from the MS. On the one hand, this result clearly highlights a link between (specific) star formation rates in excess with respect to MS galaxies and fast star-formation-driven outflows, suggesting that such outflows may be responsible for shaping the upper envelope of the MS by providing a self-regulating mechanism for star formation. On the other hand, our findings suggest that the observed outflows may play little or no role in the quenching of star formation in galaxies, i.e. the migration of blue star-forming galaxies into the red sequence.

Finally, although our study focussed mainly on galactic outflows, a complementary analysis of the stellar kinematics revealed blue asymmetries (of a few 10 km s-1) in the stellar LoSVDs of galaxies with higher SFRs and M. The large uncertainties did not allow us to draw any firm conclusion about the origin of such asymmetries, but one possibility is that these trace the presence of a large number of runaway stars and hypervelocity stars in radial trajectories within local galaxies.

In this paper, besides demonstrating the advantages and limitations of applying the spectral stacking technique to optical emission lines for outflow studies, we proposed a new strategy for studying galactic outflows, which relies on the direct comparison between the LoSVD of the gas and the LoSVD of the stars. Such a new approach was tested with the SDSS spectroscopic sample that, although certainly valuable for its large statistics, is obviously limited in terms of spatial information. However, this methodology can reveal its full potential if applied to resolved (IFS) observations of large galaxy samples, which are becoming available thanks to the ongoing IFS surveys (MaNGA, CALIFA, and SAMI) and new powerful instruments such as MUSE.


2

Our sample is largely representative of the local star-forming galaxy population, in contrast to previous outflow studies that focus mostly on the local (U)LIRG population (for which the merger fraction is much higher).

3

These are heliocentric redshifts derived from a combination of stellar absorption lines and nebular emission lines. For additional information we refer the reader to D. Schlegel’s Princeton/MIT SDSS Spectroscopy webpage (http://spectro.princeton.edu) and to Bolton et al. (2012).

5

Calculated by using the IDL function R_CORRELATE.

6

Without including the MS scatter of ±0.3 dex in SFR.

7

We note that the velocity differences |v0.1 gas| − |v99.9 stars| and |v0.1 gas | − |v0.1 stars | used as outflow tracers produce results that are overall consistent. However, | v0.1 gas | − | v99.9 stars | is probably a better choice because it allows us to minimise the effects due the presence of a blue asymmetry in the stellar LoSVDs, whose main consequence is lowering our estimate of vgasvstars, especially when using Hα emission to trace the gas.

8

We stress that all results discussed in this section and in the subsequent analyses do not depend on the choice of using v99.9 stars instead of v0.1 stars to measure vstars.

9

The latter is thought to be important especially in later stages and in regions where the infrared optical depth is low, such as at large radii from the galactic centre.

10

Although the correlation in their Fig. 6 is mainly driven by the three dwarf starbursts with detected NaID outflows from Schwartz & Martin (2004).

11

By only using their data, neither Rupke et al. (2005) nor Westmoquette et al. (2012) found a significant correlation between outflow velocity and SFR, the correlation appears only when including the dwarf starbursts from Schwartz & Martin (2004).

12

By definition, vout,high probes only 0.1% of the LoSVD of ionised gas, i.e. the very high velocity tail of the outflow, which however only represents a small fraction of the total LoSVD of the gas.

Acknowledgments

We thank the anonymous referee for the thorough review of the manuscript that significantly helped us improve both the analysis and the presentation of the results. C.C. gratefully acknowledges support from the Isaac Newton Studentship (University of Cambridge) and from the Swiss National Science Foundation Professorship grant PP00P2_138979/1 (ETH Zurich). C.C. and R.M. acknowledge funding from the United Kingdom Science and Technology Facilities Council (STFC). This work is based on SDSS-DR7 data and makes use of the MPA-JHU release of spectral measurements. We thank David Schlegel and Christy Tremonti for providing crucial information on the SDSS arc lamp calibration spectra, which allowed us to estimate the SDSS spectral instrumental profile shown in Fig. 4. C.C. thanks Kevin Schawinski, Kurt Soto, Adriano Agnello, and George Privon for stimulating discussions.

References

Appendix A: The percentile velocities of the LoSVDs

Figures A.1A.5 show, respectively, the 15.9th (σ), 2.3rd (2σ), 84.1th (σ), 97.7th (2σ), and 99.9th (3σ) percentile velocities of the [OIII], Hα, and stellar LoSVDs as a function of SFR, M, and sSFR. The results of the Spearman rank test performed on these relationships are reported in Table 1. See further discussion in Sect. 3.2.

thumbnail Fig. A.1

(Modulus of the) 15.9th percentile velocity of LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 15.9th percentile velocity corresponds to 1 standard deviation (σ) from the mean velocity. Similarly to Fig. 14, we report for each plot the Spearman rank correlation coefficient ρ along with its associated two-sided p-value.

Open with DEXTER

thumbnail Fig. A.2

(Modulus of the) 2.3rd percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel), the Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 2.3rd percentile velocity corresponds to 2 standard deviations (−2σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot along with its associated two-sided p value.

Open with DEXTER

thumbnail Fig. A.3

84.1th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 84.1th percentile velocity corresponds to +1 standard deviation (σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER

thumbnail Fig. A.4

97.7th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 97.7th percentile velocity corresponds to +2 standard deviations (2σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER

thumbnail Fig. A.5

99.9th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 99.9th percentile velocity corresponds to +3 standard deviations (3σ) from the mean velocity. Similarly to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER

All Tables

Table 1

Spearman rank correlation parameters.

All Figures

thumbnail Fig. 1

SDSS sample of star-forming, inactive galaxies selected for this study, plotted in the MSFR parameter space. The grid of 50 bins used for the stacking is shown, with the bins colour-coded according to the number of spectra enclosed. The exact number of sources within each bin is indicated by the yellow text. The white dashed and dotted lines represent the MS relation of local star-forming galaxies with its ± 1σ scatter (=0.3 dex). The MS relation has been taken from Peng et al. (2010) and adapted to this dataset as explained in Sect. 2.2.

Open with DEXTER
In the text
thumbnail Fig. 2

Sketch of the “Drizzle” method applied to the SDSS spectra.

Open with DEXTER
In the text
thumbnail Fig. 3

Stellar continuum fit and subtraction over two wavelength ranges including the [OIII]λ5007 emission line (top panels) and the Hα+[NII] emission lines (bottom panels), performed for two galaxy stacks: ID = 2.0_8.5 (left) and ID=0.5_11.5 (right). In each plot, the upper panel shows the stacked spectrum (black) and the best fit to the stellar continuum (blue), while the lower panel shows the residual spectrum. The red-shaded regions mark the spectral windows that contain nebular features and are therefore masked from the stellar continuum fit.

Open with DEXTER
In the text
thumbnail Fig. 4

Instrumental profile of the SDSS spectrographs, estimated from bright, unblended emission lines in the arc lamp images, selected within the wavelength range of interest for this study: HgI λ5460.753 Å for the blue cameras and NeI λ6598.953 Å for the red cameras. For each camera (blue/red) of the two spectrographs (1/2), we overplotted ten representative profiles from as many different frames (corresponding to different plates) obtained by averaging the arc lamp spectra over all 320 fibres. The black solid line corresponds to the mean profile. The inset highlights the presence of low-level instrumental wings (corresponding to 3/1000 of the peak), which are more prominent for the red cameras.

Open with DEXTER
In the text
thumbnail Fig. 5

Stellar continuum fit over the range λ ∈ [5250,5550] Å (left) and resulting stellar LoSVD (right) derived for two galaxy stacks, i.e. ID = −0.5_11.0 (panel a)) and ID = −1.5_9.5 (panel b)). In the left panels, the stacked spectrum is plotted in black, and the best fit to the stellar continuum is in blue. The red dashed regions indicate the spectral windows masked from the stellar continuum fit because of the presence of nebular features. In the right panels, the red dashed line indicates the LoSVD profile obtained by using, in the pPXF procedure, a simple Gaussian function to model the stellar features, while the blue solid line shows the stellar LoSVD profile obtained by allowing the use of Hermite polynomials to account for possible asymmetries of the stellar absorption features (Cappellari & Emsellem 2004). The stellar LoSVD obtained for the stack ID = −0.5_11.0 shows a clear blue asymmetry. The fit is excellent ( = 0.8) for both stacks.

Open with DEXTER
In the text
thumbnail Fig. 6

Examples of spectral fits to the [OIII]λ5007 (left column) and Hα+[NII] (right column) emission line profiles for four representative galaxy bins with different SFR and M. From top to bottom: ID = 1.5_8.0 (low SFR and low M), ID = 1.0_10.5 (low SFR and high M), ID = 0.5_8.5 (high SFR and low M), and ID = 2.0_11.0 (high SFR and high M). In each plot, the left panel shows the fit to the data (solid curves, the total fit is in blue, the multiple Gaussian components in a lighter shade of blue). For comparison, we have overplotted to the data the average SDSS instrumental resolution profile (magenta dashed curve, from Fig. 4). In the right panel of each plot we show the final LoSVD of the ionised gas resulting from the fit, hence deconvolved from the SDSS instrumental profile (details in Sect. 2.6).

Open with DEXTER
In the text
thumbnail Fig. 7

Same as Fig. 6 but for a typical bin on the MS with intermediate SFR and M (ID = 0.0_10.5).

Open with DEXTER
In the text
thumbnail Fig. 8

Line-of-sight velocity distribution of the ionised gas as traced by the [OIII]λ5007 emission line. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER
In the text
thumbnail Fig. 9

Line-of-sight velocity distribution of the ionised gas as traced by the Hα+[NII] emission lines. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER
In the text
thumbnail Fig. 10

Line-of-sight velocity distribution of the stars. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) SFR and by different (average) stellar masses, colour-coded by their M.

Open with DEXTER
In the text
thumbnail Fig. 11

Line-of-sight velocity distribution of the ionised gas as traced by the [OIII]λ5007 emission line. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER
In the text
thumbnail Fig. 12

Line-of-sight velocity distribution of the ionised gas as traced by the Hα+[NII] emission lines. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER
In the text
thumbnail Fig. 13

Line-of-sight velocity distribution of the stars. In each panel we have over-plotted the LoSVDs of galaxy bins identified by the same (average) M and by different (average) SFRs, colour-coded by their SFR.

Open with DEXTER
In the text
thumbnail Fig. 14

Line-of-sight velocity dispersion of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines and of the stars (bottom panel). The errors were obtained by applying the bootstrap method, as explained in the text. The grey dashed lines in the third column outline the sSFR range corresponding to the MS of local star-forming galaxies between 9.0 ≤ log (M [M] ) ≤ 11.0. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported in each plot, along with the corresponding two-sided p-value as given in parenthesis (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER
In the text
thumbnail Fig. 15

(Modulus of the) 0.1th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 0.1th percentile velocity corresponds to 3 standard deviations (σ) from the mean velocity, and therefore it probes the high velocity blueshifted tail of the LoSVD. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER
In the text
thumbnail Fig. 16

Blue asymmetry of the [OIII] (top panel), Hα (middle panel), and stellar (bottom panel) LoSVDs, as measured by the difference between the (moduli of the) 2.3th and 97.7th percentile velocities (i.e. y = | v2.3 | − | v97.7 |). For display purposes, only the less noisy bins are plotted, i.e. bins with either σy< 50 km s-1 or | y | ≥ 2σy. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p-value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER
In the text
thumbnail Fig. 17

Excess of line-of-sight velocity of the ionised gas with respect to the stars (vgasvstars) as given by y = | v0.1 gas | − | v99.9 stars | for [OIII] (upper panel) and for Hα (bottom panel). For display purposes, only the less noisy bins are plotted, i.e. only bins with either σy< 50 km s-1 or | y | ≥ 2σy. As explained in Sect. 3.4, the quantity y is a reliable tracer of ionised outflows only when it is positive. The Spearman rank correlation coefficient (0 < | ρ | < 1, higher values of | ρ | indicate stronger correlation, ρ< 0 if there is an anti-correlation) is reported in each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER
In the text
thumbnail Fig. 18

Grid of galaxy bins in the MSFR parameter space used for the spectral stacking (see also Fig. 1). Each bin is colour-coded according to the line-of-sight velocity difference vgasvstars as given by | v0.1 gas | − | v99.9 stars | for [OIII] (upper panel) and for Hα (lower panel). The | v0.1 gas | − | v99.9 stars | values are also reported for each bin. The same bins as in Fig. 17 are plotted.

Open with DEXTER
In the text
thumbnail Fig. 19

Outflow velocity as given by (see explanation in Sect. 4.1) inferred from [OIII] (upper panel) and Hα emission (bottom panel), plotted as a function of SFR, stellar velocity dispersion (as obtained from the fit to the stellar continuum), and sSFR. The same bins as Fig. 17 are plotted, excluding those for which . In the middle panels, the dashed lines indicate the locus of points where vout = σstars. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER
In the text
thumbnail Fig. 20

Outflow velocity as given by (see explanation in Sect. 4.1) inferred from [OIII] (upper panel) and Hα emission (bottom panel), plotted as a function of SFR, stellar velocity dispersion (as obtained from the fit to the stellar continuum), and sSFR. The same bins as Fig. 17 are plotted, excluding those for which . In the middle panels, the black dashed lines indicate the locus where vout = σstars, and the grey dot-dashed lines indicate the approximate upper envelopes of the distributions of values, given by the relationships: vout = 6σstars for [OIII], and vout = 6σstars for Hα. The Spearman rank correlation coefficient (0 <ρ< 1, higher values of ρ indicate stronger correlation) is reported for each plot, along with the corresponding two-sided p value (if the p value is α, where α = 0.05 is the level of significance, the observed correlation is statistically significant).

Open with DEXTER
In the text
thumbnail Fig. 21

Excess of line-of-sight velocity of the ionised gas with respect to the stars (vgasvstars) as given by y = | v0.1 gas | − | v99.9 stars |, plotted as a function of the offset from the local MS of star-forming galaxies. In the upper panel the outflow velocity is measured from [OIII] and in the lower panel from Hα. As in Fig. 17, only bins with either σy< 50 km s-1 or | y | ≥ 2σy are shown. The black stars indicate the mean trend, obtained by averaging the data points (weighted with their errors) over bins of Δlog (SFR/SFRMS) = 0.5.

Open with DEXTER
In the text
thumbnail Fig. A.1

(Modulus of the) 15.9th percentile velocity of LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 15.9th percentile velocity corresponds to 1 standard deviation (σ) from the mean velocity. Similarly to Fig. 14, we report for each plot the Spearman rank correlation coefficient ρ along with its associated two-sided p-value.

Open with DEXTER
In the text
thumbnail Fig. A.2

(Modulus of the) 2.3rd percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel), the Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 2.3rd percentile velocity corresponds to 2 standard deviations (−2σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot along with its associated two-sided p value.

Open with DEXTER
In the text
thumbnail Fig. A.3

84.1th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 84.1th percentile velocity corresponds to +1 standard deviation (σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER
In the text
thumbnail Fig. A.4

97.7th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 97.7th percentile velocity corresponds to +2 standard deviations (2σ) from the mean velocity. Similar to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER
In the text
thumbnail Fig. A.5

99.9th percentile velocity of the LoSVD of the ionised gas as traced by the [OIII] (top panel) and Hα (middle panel) emission lines, and of the stars (bottom panel). For a Gaussian velocity distribution, the 99.9th percentile velocity corresponds to +3 standard deviations (3σ) from the mean velocity. Similarly to Fig. 14, we report the Spearman rank correlation coefficient ρ for each plot, along with its associated two-sided p value.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
