1. Introduction

The birth sites of high-mass star-forming regions (HMSFRs) are highly complex structures, consisting of different gas and dust cores, embedded in a less dense gas envelope. While the complexity of dynamic processes within these regions has been characterized well (e.g., Zinnecker & Yorke 2007; Beuther et al. 2007b; Tan et al. 2014), our knowledge of the chemical properties of these regions is still poor. Since specific molecules can act as tracers of physical processes (e.g., Schilke et al. 1997; Charnley et al. 1997; Bachiller et al. 2001; Viti et al. 2004; Garrod 2013), characterizing the chemistry of gas associated with the early stages of high-mass stars is crucial for understanding how these stars might form.

Line surveys of HMSFRs in mm/sub-mm atmospheric windows exhibit rich molecular emission spectra (see Herbst & van Dishoeck 2009 for a comprehensive review). The multitude of detected lines allow for an unbiased look at the chemical composition of a particular region, from which its physical properties can be inferred, including temperature and density. However, HMSFRs are typically distant (several kpc), so that spatially disentangling the physical and chemical substructures is challenging with the resolution of most facilities. This makes the Becklin-Neugebauer and Kleinmann-Low Nebula in Orion (Orion BN/KL), at a distance of 414 ± 7 pc (Sandstrom et al. 2007; Menten et al. 2007), ideal for studies of the physical and chemical properties of HMSFRs. As the nearest HMSFR, it has been extensively studied at both far-infrared to (sub) millimetre wavelengths accessible from space (e.g., Olofsson et al. 2007; Bergin et al. 2010; Crockett et al. 2014) and at radio, millimetre, and submillimetre wavelengths accessible from the ground. A broad range of studies on this source have been conducted either with single-dish telescopes (e.g., Johansson et al. 1984; Sutton et al. 1985; Blake et al. 1987; Turner 1989; Greaves & White 1991; Schilke et al. 1997, 2001; Lee & Cho 2002; Comito et al. 2005; Remijan et al. 2008; Tercero et al. 2010) or interferometers (e.g., Wright et al. 1996; Blake et al. 1996; Beuther et al. 2005, 2006; Friedel & Snyder 2008; Guélin et al. 2008). Strong emission lines in these observations have revealed complex dynamics (e.g., Sutton et al. 1985; Blake et al. 1987; Turner 1989; Beuther & Nissen 2008; Beuther et al. 2010) and chemistry (e.g., Wright et al. 1996; Blake et al. 1996; Beuther et al. 2005, 2006; Friedel & Snyder 2008; Guélin et al. 2008; Widicus Weaver & Friedel 2012; Friedel & Widicus Weaver 2012).

Both single-dish-only and interferometer-only observations, however, have limitations. Single-dish observations have low spatial resolution, making it difficult to detect spatial variations of chemistry on small scales. In contrast, interferometric observations can probe spatial variations on small scales, but suffer from filtering-out to large scale structures (the “missing short spacing” problem; Bajaja & van Albada 1979), making measurements of the chemistry of more extended features unreliable. In this paper, we aim to study the chemistry of Orion-KL by obtaining a combined dataset from an interferometer (Submillimetre Array, SMA) and a single-dish (IRAM 30 m) telescope. These combined data, which resolve small-scale substructures and are sensitive to more extended components, allow us to accurately map the distribution of molecular species, determine their abundances, and ultimately analyse spatial variations in the chemistry.

One unique feature of HMSFRs is hot molecular cores, which are compact objects (≤0.05 pc) that exhibit high temperatures (≳100 K) and densities (≳106 cm-3; Palau et al. 2011). Numerous spectral surveys (see, e.g., Turner 1989; Schilke et al. 2001; Belloche et al. 2009; Herbst & van Dishoeck 2009; Tercero et al. 2010) have revealed that hot molecular cores are characterized by a large abundance of simple organic molecules, including H2CO (formaldehyde), HCOOH (formic acid), and complex organic molecules (COMs, organics containing ≥6 atoms), such as CH3OH (methanol), HCOOCH3 (methyl formate), and CH3OCH3 (dimethyl ether). Although some larger COMs have low abundances in hot molecular cores, e.g., CH3CH2OH (ethanol; Rizzo et al. 2001), CH3COCH3 (acetone; Snyder et al. 2002), CH3CHO (acetaldehyde; Nummelin et al. 2000), (CH2OH)2 (ethylene glycol; Hollis et al. 2002), and CH2OHCHO (glycolaldehyde; Hollis et al. 2000, 2004), they have been previously detected towards the Galactic-centre hot molecular core source SgrB2 (N-LMH). Because of their high degree of chemical and structural complexity, the precise origins and formation mechanisms of these COMs is still a subject of debate. Nevertheless, understanding these topics is particularly important for understanding the chemical evolution of the interstellar medium (ISM; e.g., Herbst & van Dishoeck 2009). Recently, a number of interferometric observations of COMs in Orion-KL (e.g., Friedel et al. 2005; Friedel & Snyder 2008; Guélin et al. 2008; Favre et al. 2011a,b; Widicus Weaver & Friedel 2012) have shown spatial-related chemical differentiation. However, the relatively low sensitivity of these observations means that the lowest-abundance COMs (e.g., CH2OHCHO, CH3CH2OH, and CH3CHO) are below the 3σ detection limit or are blended by strong neighbouring lines.

In addition to the hot molecular core chemistry, the shock chemistry driven by outflows is another important aspect of chemistry in HMSFRs. The region in Orion-KL that is most affected by outflow and shock events is called the “plateau” (Blake et al. 1987; Wright et al. 1996; Lerate et al. 2008; Esplugues et al. 2013) and is characterized by spectral lines with broad line wings. Two roughly perpendicular outflows are seen in Orion-KL, traced by the proper motion of H2O masers at 22 GHz (Genzel et al. 1981). One is a high-velocity outflow (30–100 km s-1, along the north-west–south-east (NW−SE) axis); this outflow is also detected in OH (hydroxyl) masers (Norris 1984; Cohen et al. 2006), broad bipolar CO line wings (Zuckerman et al. 1976; Kwan & Scoville 1976; Erickson et al. 1982; Masson et al. 1987; Chernin & Wright 1996; Beuther & Nissen 2008; Zapata et al. 2009), and lobes of poorly collimated shock-excited H2 (Beckwith et al. 1978; Scoville et al. 1982; Taylor et al. 1984; Allen & Burton 1993; Sugai et al. 1994). Although the source responsible for driving the outflow is still uncertain, it has been suggested that the outflow is only about 500−700 years old (Lee & Burton 2000; Doi et al. 2002; Gómez et al. 2005, 2008; Nissen et al. 2007; Beuther & Nissen 2008; Bally et al. 2011; Goddi et al. 2011b; Nissen et al. 2012). The other is a low-velocity outflow (~18 km s-1, △ V ~ 35 km s-1, along the north-east–south-west (NE–SW) axis; Genzel et al. 1981; Gaume et al. 1998), which is also detected in SO (Plambeck et al. 1982), SiO masers (Wright & Plambeck 1983; Plambeck et al. 2009; Greenhill et al. 2013) and H2O maser (Greenhill et al. 2013). This outflow is believed to be closely associated with an expanding gas shell or torus around Source I, but whether its age is >3000 years (Menten & Reid 1995; Greenhill et al. 1998; Doeleman et al. 1999; Reid et al. 2007) or much younger (Plambeck et al. 2009; Greenhill et al. 2013) is still not clear. Another goal of this study is to look for additional chemical signposts of these outflows, apart from the known masers, in order to better understand their physical and chemical properties.

In this paper, we present the first combined single-dish and interferometric line survey at 1.3 mm towards Orion-KL and study the chemical properties of this region at a linear resolution of ~1200 AU (at a distance of ~414 pc). In Sect. 2, we describe the observations and their combination. In Sect. 3, we present a continuum map and maps of the distribution of different molecules, including simple molecules and COMs, where the presences of COMs are identified by synthetic spectrum fittings. The spatial distributions, column densities, and abundances for all the detected species are derived in Sect. 4. A discussion of the chemistry in the hot molecular core and outflows of Orion-KL can be found in Sect. 5.

2. Observations and data reduction

2.1. Submillimetre Array (SMA)

We carried out observations of Orion-KL with the SMA on Feb. 15, 2005 and Feb. 19, 2005. At 1.3 mm (220/230 GHz) in the compact configuration with seven antennas, the baselines ranged between 16 and 69 m. The short baseline cutoff causes source structures ≥20′′ to be filtered out. The primary beam is 52′′, and the phase centre of the observations is α2000 = 05h35m14.5s and δ2000 = −5°22′30.45′′ with Vlsr ~ 7 km s-1. Bandpass calibration was done withCallisto, and the flux calibration is estimated to be accurate within 15%, based on the SMA monitoring of quasars. Phase and amplitude calibration was performed via frequent observations of the quasar 0607-157. The zenith opacities, measured with the NRAO tipping radiometre located at the Caltech Submillimetre Observatory, were excellent during both tracks with τ(1.3 mm) ~ 0.03 − 0.04, allowing us to observe at both 1.3 mm and 440 μm simultaneously (Beuther et al. 2006). More technical descriptions of the SMA and its calibration schemes can be found in Ho et al. (2004). The receiver operated in a double-side band mode with an intermediate frequency of 4−6 GHz so that the upper and lower side bands were separated by 10 GHz. The correlator had a bandwidth of 2 GHz, and the channel separation was 0.8125 MHz, corresponding to a velocity resolution of ~1.2 km s-1. Double-sided band system temperatures corrected for the atmosphere were between 150 and 300 K (depending on the elevation of the source).

The initial flagging and calibration was done with the IDL superset MIR, which is originally developed for the Owens Valley Radio Observatory and adapted for the SMA1. The imaging and data analysis was conducted in MIRIAD (Sault et al. 1995) and CASA2. Between the observations on two nights, the frequency setups were shifted by 0.4 GHz, yielding a slightly larger total bandwidth for the combined dataset (218.870 − 221.234 GHz for the lower sideband, and 228.870 − 231.234 GHz for the upper sideband). The synthesised beams of the combined data are 3.49′′ × 2.57′′ for the lower sideband and 3.68′′ × 2.69′′ for the upper sideband.

2.2. Single-dish observations with the IRAM 30 m telescope

In addition to the high spatial resolution data from the SMA, we mapped an area of 1′ × 1′, with the IRAM 30 m telescope, to complement the short-spacing information missing from the interferometric observations. Observations were performed in the on-the-fly mode on Nov. 30, 2012, covering a broad bandpass (8 GHz bandwidth for each sideband) of EMIR at 220/230 GHz. Observations were conducted under good weather conditions (Tsys = 266 K, τ ~ 0.152 at 220 GHz). The focus was on Uranus, and pointing was checked on Uranus and 0420-014. Using a forward efficiency of 92% and a main beam efficiency of 58%, we converted the data from antenna temperature (K) to flux (Jy) by using an efficiency3 of 7.8. The beam of the 30 m telescope at 1.3 mm is ~11.3′′ in the upper sideband and ~11.8′′ in the lower sideband. The observations cover frequencies 213.370–221.150 GHz and 229.051–236.831, with a velocity resolution of 0.255 km s-1. We used the Gildas4 software for data reduction, and then converted the 30 m data to the MIRIAD data format.

2.3. Data merging

The 30 m single-dish spectral-line data were first converted to visibilities, and then combined with the SMA data using the MIRIAD package task UVMODEL5. To recover large-scale emission, while simultaneously maintaing high spatial resolutions for resolving small scale structure, we chose an intermediate weighting between natural and uniform (“robust” = − 0.5 value in MIRIAD). However, as continuum information is not available from the 30 m observations, only the spectral-line data can be corrected in this way.

The combined data have a field of view of 52′′ and a beam of 5.55′′ × 4.35′′ with position angle PA = + 8° in the lower sideband and 5.44′′ × 4.43′′ with PA = + 2° in the upper sideband. The frequency overlap between the SMA and 30 m data results in the combined data having a frequency range 218.870–221.150 GHz and 229.051–231.234 GHz. Figure 1 presents an amplitude-versus-projected uv distance plot, showing the good combination of the single-dish and interferometer data. Missing projected baselines shortwards of 10 kλ from the SMA have been complemented by using the 30 m data. After combination, the 1σ rms per 1.2 km s-1 channel is measured to be 80 mJy beam-1 for the lower sideband and 70 mJy beam-1 for the upper sideband.

thumbnail Fig. 1

Amplitude in Jy versus the projected baseline showing the combination of the interferometer and single-dish data, from the upper sideband (top) to lower sideband (bottom). Red and blue dots present data from the SMA on Feb. 15, 2005 and Feb. 19, 2005, respectively, showing the lack of baselines shorter than 10 kλ. Black dots are data converted from 30 m single-dish observations, which fill in the missing short spacing information.

thumbnail Fig. 2

Substructures resolved by SMA-only observations at a spatial resolution of ~1200 AU. White contours show the 1.3 mm continuum emission at −5σ, 5σ, 15σ, 25σ, 60σ rms levels with the σ = 0.04 Jy beam-1. The yellow circle denotes the primary beam of SMA at 1.3 mm. Red circles denote the peaks of hot core (HC), mm2, mm3a, mm3b, the southern region (SR), north-east clump (NE), the NW and SE parts of the high-velocity outflow (OF1N, OF1S). Yellow crosses denote the BN object and the compact ridge (CR). The beam in the bottom left corner is from the SMA-only data. Colourmap shows the brightness (in counts per 400 s) of shocked H2 emission (Nissen et al. 2007). Corresponding to the yellow square, the insert panel shows the HC continuum from the SMA at 1.3 mm in detail as colourmap, with black contours of the 865 μm continuum emission at a spatial resolution of ~300 AU from Beuther et al. (2004) overlaid.

Table 1

Properties of substructures, which are denoted on the continuum image obtained from SMA observations at 1.3 mm (Fig. 2).

3. Observational results

3.1. Continuum emission

Orion-KL has a rich spectrum of molecular emission lines, so extracting the continuum requires some care. To construct our continuum map, we averaged the line-free parts of the upper and lower sidebands from the SMA-only data. In Fig. 2, we present the resulting 1.3 mm continuum image as contours overlaid on a map of the outflow traced by shock-excited H2 (Nissen et al. 2007). We detected the previously known compact continuum substructures of this region and moreover, resolved some of these substructures into multiple distinct condensations. We list the following resolved condensations in Table 1:

Because of the limited UV coverage and field of view, the high-velocity outflow and the BN object are not detected above 5σ in the SMA-only continuum map. To study the chemistry in these regions from the combined data, we take the positions of the high-velocity plateau (Vlsr ~ 11 km s-1) and BN object from Beckwith et al. (1978) and denote them as OF1N, OF1S, and BN in Fig. 2.

Table 1 lists the nominal absolute positions of these substructures, as well as the peak specific intensity (Jy beam-1) for each continuum substructure, obtained from the SMA-only 1.3 mm continuum map (Fig. 2, for more detail about this table, see Sect. 4.2.2). The HC is the brightest condensation; mm2, mm3a, and mm3b are fainter; while NE, SR, OF1N, and OF1S are even weaker.

3.2. Spectral line emission

3.2.1. Line identification

After imaging the whole SMA-30 m combined data cube, we extracted the double sideband spectrum from each substructure denoted in Fig. 2 and show them in Fig. 3. The majority of lines are strongest towards the HC, so we use the spectrum from the HC to identify lines. However, line identification may be ambiguous in a region such as the Orion-KL HC, because of a high density of lines (that can have different line widths according the species), also because the ~1.2 km s-1 spectral resolution of the observations does not allow us to separate all the blending. For strong lines, we first compare their rest frequencies with an existing single-dish survey catalogue of Orion-KL by Sutton et al. (1985). Next, we cross-check their rest frequencies with the molecular database at “Splatalogue”6 (a compilation of the Jet Propulsion Laboratory (JPL7, Pickett et al. 1998), Cologne Database for Molecular Spectroscopy catalogues (CDMS8, Müller et al. 2005), and Lovas/NIST catalogues, Lovas 2004), and confirm the identification if the CDMS/JPL intensity is >10-6 nm2 MHz9.

thumbnail Fig. 3

Spectra taken towards selected positions (denoted by red circles in Fig. 2) after imaging the whole data cube. The spectral resolution is smoothed to 1.2 km s-1 after the combination of SMA and 30 m data, and strong emission lines are labelled. A blow-up figure of the spectrum in the HC is Fig. A.1.

Using the above method, the detection of strong lines are shown in Fig. A.1. In addition, we can also detect multiple transitions of low-abundance COMs in Orion-KL, owing to the high sensitivity and recovering the full intensity for spatially extended molecular emission from the combined dataset. We use a synthetic spectrum fitting program (Sanchez-Monge 2011; Palau et al. 2011) in conjunction with molecular data from the JPL/CDMS catalogues, to simultaneously fit multiple COM lines under the assumption that all transitions are optically thin, are in local thermodynamic equilibrium (LTE), and have the same line width10. Given these assumptions, the fitted flux densities are not always a perfect match to the observed spectra. However, in many cases we are able to robustly identify multiple transitions of a COM (Fig. A.2). We discuss the properties of the identified COM species further in Sect. 3.2.2.

With these two approaches, we identified more than 160 lines that we assigned to 20 molecules (including 25 isotopologues) over the entire band; we labelled the unblended strong emissions in Fig. 3, and list all the lines in Table A.1. This table includes the rest frequency, quantum number, symmetry label, and upper state energy for each transition. Lines marked with “†” are from molecules containing less than six atoms as shown in Fig. 4, and those marked with “‡” are from molecules we designated as COMs and carbon chains, which are shown in Fig. 5. Our observations have a frequency resolution of 0.8125 MHz (~1.2 km s-1 at 1.3 mm). Thus, some observed lines with broad linewidths can be attributed to multiple transitions, when compared to the laboratory-measured rest frequencies recorded in the “Splatalogue” database. If potentially blended transitions for one line are from different isotopologues but have similarly strong CDMS/JPL intensities, we compared the spatial distribution of this line to those of the known isotopologues. Then, we either confirm a match or indicate all possibilities with “*” in Table A.1. If there are multiple possible transitions from the same isotopologue at this rest frequency, they are also marked with “*”.

3.2.2. Line imaging

In general, all the identified species show different spatial distributions, velocity widths (FWHM ΔV), and velocity at line centre (Vpeak) in each substructure (see Fig. A.3, on average, Vpeak ~ 6–8 km s-1 in the HC; Vpeak ~ 8–10 km s-1 in mm2, mm3a, and mm3b; Vpeak ~ 10–12 km s-1 in NE). However, transitions from a single isotopologue have the same spatial distribution (except for CH3OH). In this paper, we have chosen one of the strongest unblended transitions from each isotopologue and produced their intensity distribution maps from the SMA-30 m combined data. In avoiding contamination from other strong lines, we integrate the intensity of each line through 40−60% of their profile range in Fig. A.311.

thumbnail Fig. 4

Intensity distribution maps of transitions from molecules containing <6 atoms, which are detected in the combined SMA-30 m data at 1.3 mm (corresponding quantum numbers are listed in Table A.1, with “†” marks). The intensities have been derived by integrating the line emission over the velocity range shown in Fig. A.3. The filled beam in the bottom left corner is from SMA-30 m data. White contours show the continuum from the SMA-only data (at −5σ, 5σ, 15σ, 25σ, and 60σ levels). Purple contours show ± 1σ levels of the molecular emission (solid contours indicate positive flux, and dashed contours indicate negative flux). Green lines in the SO and CO maps sketch the outflow directions. The white crosses denote the BN object and the CR, and the black crosses denote the positions of the hotcore, Source I, Source N, and SMA1, as in Fig. 2. All images have different colour scales (in Jy beam-1 km s-1), increasing from black to white, which are optimized to emphasize the features in the distribution of each molecules.

thumbnail Fig. 5

Intensity distribution maps of transitions from COMs and carbon chains detected in the combined SMA-30 m data at 1.3 mm (corresponding quantum numbers are list in Table A.1, with “‡” marks). The intensities have been derived by integrating the line emission over the velocity range shown in Fig. A.3. The filled beam in the bottom left corner is from SMA-30 m data. White contours show the continuum from the SMA-only data (at −5σ, 5σ, 15σ, 25σ, and 60σ levels). Purple contours show ± 1σ levels of the molecular emission (solid contours indicate positive flux, and dashed contours indicate negative flux). The white crosses denote the BN object and the CR, and the black crosses denote the positions of the hotcore, Source I, Source N, and SMA1, as in Fig. 2. All images have different colour scales (in Jy beam-1 kms-1), increasing from black to white, which are optimized to emphasize the features in the distribution of each molecules.

thumbnail Fig. 6

Lines that only have one transition with low specific intensity (≤10 Jy beam-1) in our data, fitted with synthetic spectrum from their emission peaks.

The combined data at 220/230 GHz covers a field of view of 52′′, which is greater than the extent of the source (not including the outflows), so our maps exhibit negligible artefacts caused by residual missing flux. The high quality of our data allows us to map molecules, such as 34SO2, O13CS, HNCO, H213CO\hbox{$\rm H_2^{13}CO$}, 13CO, and CH2CO for the first time with both high resolution and sensitivity to spatial information on all scales. After sorting by different groups, we present the intensity integration map for each identified molecule in Figs. 4 and 5. Compared to previous sub-mm and mm (especially interferometric) observations in Orion-KL (listed in the following paragraphs), the main features of our molecular distribution maps are:

  • 1.

    All the identified sulphur- (S-) bearing species in our dataset arediatomic/triatomic containing no hydrogen. Most of them haveextended distributions (except forSO2 and 34SO2), exhibiting a V-shaped morphology that extends from the emission peak at HC, through mm3a, mm3b to mm2. Their velocities at line centre also vary among substructures from ~6 km s-1 (HC) through 8−10 km s-1 (mm2, mm3a, mm3b, and SR) to 11–12 km s-1 (NE).

    • OCS and O13CS (carbonyl sulphide) peak at SMA1 and have emission that extend to the CR. In addition, OCS is also detected in NE and SR. Although only one line of O13CS is detected in our data (19 → 18, Fig, 6), other lines of this isotopologue have been previously confirmed and imaged by single-dish observations (e.g., Sutton et al. 1985; Ziurys & McGonagle 1993; Tercero et al. 2010). In addition to the detections by single-dish surveys (e.g., Sutton et al. 1985; Turner 1991; Schilke et al. 1997; Tercero et al. 2010), previous interferometric surveys of OCS also reproduce the same V-shaped widespread intensity distribution of this molecule, peaking at the HC (e.g., Wright et al. 1996; Friedel & Snyder 2008).

    • SO2 and 34SO2 (sulphur dioxide) peak at the hotcore and SMA1 and exhibit extended emission in the NE direction, with Vpeak ~ 9–11 km s-1. Unlike the other S-bearing species, no emission has been detected from these species in SR, and they do not display a clear V-shaped feature. However, there is a clear second velocity component in the line profile of 34SO2 (at ~22.7 km s-1, Fig. 7) and SO2 (at 22.1 km s-1, Fig. 7). In addition, red- and blue-shifted 34SO2 trace outflows in the NW–SE direction (Fig. A.4). Single-dish studies (e.g., SO2; Blake et al. 1987; Persson et al. 2007; Esplugues et al. 2013, 34SO2; Esplugues et al. 2013) conclude that this species is a good tracer not only for the warm dense gas, but also for regions affected by shocks. While based on the velocity around 22 km s-1, Esplugues et al. (2013)12 suggests that this velocity component may be associated with shocks caused by the explosive (NW–SE) outflow and/or the BN object, our data clearly show that this velocity component of SO2 is spatially offset from BN and seems to be associated much more with the main NE–SW outflow (Fig. A.5). On small scales, interferometric observations of Orion-KL also detect a compact SO2 emission peak (Wright et al. 1996; Zapata et al. 2011) and strong extended emission of 34SO2 to mm2 (Beuther et al. 2005).

    • SO (sulphur monoxide) has multiple strong emission peaks towards HC, NE, mm3a, and mm3b and exhibits strong self-absorption in mm2 (Fig. A.3). There is also significant emission extending along both the plateau of high- (Vpeak ~ 8–10 km s-1) and low-velocity (Vpeak ~ 7–8 km s-1) outflows. Similar to 34SO2, its line wings are broad (△ V ~ 23 km s-1), and a second velocity component is clear in the line profile at ~21 km s-1 (see Fig. A.3 mm3b), which may be associated with shock events13. These morphological features (elongated emission peak(s) and broad line wings of SO) have also been detected by both single-dish (Persson et al. 2007; Esplugues et al. 2013) and interferometric (Wright et al. 1996) line studies.

    • 13CS (carbon monosulphide) has only one transition in our dataset, but it is very strong, peaking at SMA1, with a similar distribution to O13CS – extended emission from NE through HC to the CR. Owing to its high dipole moment, this molecule is considered to be a dense gas tracer (e.g., Bronfman et al. 1996), and its detection in both CR and NE is confirmed by Persson et al. (2007) and Tercero et al. (2010).

The distribution of simple CxHyOz (x,z = 1,2...; y = 0,1,2...; x + y + z ≤ 5) molecules are co-spatially extended.

  • CO, C18O, and 13CO (carbon monoxide) have a common morphological peak at the HC (though the integrated intensity of CO peaks north of the HC due to its strong self-absorption in this source, see Fig. A.3). Velocity at line centre Vpeak ranges from 6 km s-1 (HC) through 8 km s-1 (mm2, mm3a, mm3b, and SR) to 10 km s-1 (NE, OF1N, and OF1S), with broad red- and blue-shifted line wings trace both high-velocity (CO, 13CO) and low-velocity (C18O) outflows (Fig. A.4). As the second most abundant species in the ISM, this species has been detected in numerous other observations of Orion-KL (C18O; Beuther & Nissen 2008; Plume et al. 2012, CO; Zuckerman et al. 1976; Kwan & Scoville 1976; Erickson et al. 1982; Blake et al. 1987, single-dish; Masson et al. 1987; Chernin & Wright 1996; Zapata et al. 2009; Peng et al. 2012b, interferometry, 13CO; Wilson et al. 2011, single-dish), showing the same morphology as we see: extended structure, with bipolar line wings covering from the NE through HC to the CR and tracing outflows.

  • CH2CO (ketene) has a single transition (111,11 → 101,10) detected (Fig. 6), peaking at mm3a and mm3b, with strong emission extending to the OF1S and the NE filament. With Vpeak ~ 8 km s-1 and △ V ~ 2.5 km s-1 in mm2, mm3a, and mm3b, this line has also been confirmed by Sutton et al. (1985). Some other lines of this species are also detected in Orion-KL by Lee & Cho (2002).

  • H 2 13 CO \hbox{$\rm H_2^{13}CO$} (formaldehyde) exhibits an elongated peak stretching from SMA1 towards mm3a. Similar to the simple organic CH2CO, it also shows extended structure along the SE lobe of the high-velocity outflow and NE. Single-dish detections (e.g., Persson et al. 2007) confirm that this molecule is present in both the CR and the outflows.

thumbnail Fig. 7

Gaussian fitting to the line profile of 13CO, C18O, HNCO, SO2, and 34SO2 extracted from NE. Outflow signatures are seen in the broad line wings and the second velocity component in the HNCO, SO2, and 34SO2 line profile.

HNCO (isocyanic acid) is the simplest organic molecule containing C, H, O, and N elements. Peaking at SMA1, it shows extended emission towards all the substructures, with Vpeak ranging from 6 km s-1 (HC) through 7−8 km s-1 (mm3a, mm3b, SR, and OF1S) to 9–10 km s-1 (mm2, NE, OF1N), and a second velocity component at ~19.8 km s-1 (Fig. 7). Although the formation pathway of HNCO is still not clear (Hasegawa & Herbst 1993; Turner et al. 1999; Garrod et al. 2008; Tideswell et al. 2010), its distribution is observed to be correlated with shock tracing molecules SiO (e.g., Zinchenko et al. 2000) and CH3OH (e.g., Meier & Turner 2005), suggesting that it is also produced in shocks.

In contrast, highly saturated COMs14 are the typical COMs detected in HMSFRs, and they exhibit a variety of morphological structures in Orion-KL. In general, N-bearing COMs have a similar peak to HNCO, at or near HC; while most of the O-bearing COMs are co-spatial with CH2CO peaking at mm3a and mm3b, and extending even to southern CR (e.g., HCOOCH3, CH3OCH3, and CH3CHO). This spatial segregation of the N- and O-bearing COM peaks has also been reported by other single-dish (Blake et al. 1987; Persson et al. 2007) and interferometric studies with high spatial resolution (e.g., Wright et al. 1996; Beuther et al. 2005; Favre et al. 2011a; Friedel & Widicus Weaver 2012). In addition, there are several other O-bearing COMs identified in this study, which have unique morphologies. To understand the spatial differentiation of COMs on small scales (Fig. 5), we compared the distributions of these molecules between our observations to other recent interferometric studies (Table 2).

  • CH3CN and C H 3 13 CN \hbox{$\rm CH_3^{13}CN$} (methyl cyanide) are two abundant N-bearing COMs. In our dataset, we detect the J = 12 → 11 ladder of both isotopologues around 220 GHz. Most of the C H 3 13 CN \hbox{$\rm CH_3^{13}CN$} lines are blended, but lines with K = 2,4,5,6 are clearly detected in the HC (Fig. 8). In particular, K = 2 line of C H 3 13 CN \hbox{$\rm CH_3^{13}CN$} and CH3CN are clearly co-spatial (Fig. A.3), peaking at SMA1 (Vpeak ~ 5–7 km s-1) and extending to mm2, mm3a, mm3b (Vpeak ~ 8–10 km s-1), with >3σ detection in NE (Vpeak ~ 10–13 km s-1), exhibiting a V-shaped morphology. CH3CN is detected in SR and OF1N (S), but not for C H 3 13 CN \hbox{$\rm CH_3^{13}CN$}. This V-shaped morphology of CH3CN has also been detected in e.g., Beuther et al. (2005), Zapata et al. (2011), Widicus Weaver & Friedel (2012), Bell et al. (2014), as well as the NE extension in Wright et al. (1996). This species is considered to be a warm and dense gas tracer (e.g., Kalenskii et al. 2000; Araya et al. 2005), with gas phase and grain surface chemical models predicting that it is only detected in an environment with elevated temperatures (e.g., Purcell et al. 2006). We use the CH3CN ladder and the C H 3 13 CN ( 12 2 → 11 2 ) \hbox{$\rm CH_3^{13}CN (12_2\rightarrow11_2)$} line to estimate the temperature of the substructures where these lines are detected (see Sect. 4.1.1).

  • CH2CHCN (vinyl cyanide) exhibits strong compact emission north of the hotcore, with Vpeak ~ 5 km s-1, and a slight extension towards mm2. The northern peak is also coincident with the one in higher resolution maps of this species from SMA at 865 μm (Beuther et al. 2005), CARMA at 1 mm (Friedel & Snyder 2008), and PdBI at 3 mm (Guélin et al. 2008).

  • CH3CH2CN (ethyl cyanide) emission also makes a V-shaped structure. Unlike the single-peaked structure of CH2CHCN, CH3CH2CN exhibits a dual-peaked structure, with a first emission peak at the hotcore (~6 km s-1), and a second peak at mm2 (~9 km s-1). Although there are two velocity components in both mm3a and mm3b (6 km s-1, 10 km s-1), there is no detection in southern CR, which is consistent with Blake et al. (1987). This observed morphology is consistent with other interferometric observations at high spatial resolution (Wright et al. 1996; Beuther et al. 2005; Friedel & Snyder 2008; Guélin et al. 2008; Widicus Weaver & Friedel 2012; Peng et al. 2013).

  • CH3OH (methanol) has multiple transitions in our data (Fig. A.2). We obtained the channel maps of all the unblended strong CH3OH transitions in our dataset and found two types of spatial distributions (Fig. A.6). One type of line clearly shows extended emission from mm2 and SR (7.2–8.4 km s-1, e.g., lines of 80,8 → 71,6E, 8− 1,8 → 70,7E, and 3− 2,2 → 4− 1,4E) towards the high-velocity outflow OF1N(S), exhibiting a similar SE tail to H 2 13 CO \hbox{$\rm H_2^{13}CO$} at 7–10 km s-1, which has not been detected before; whereas the other type of line (e.g., lines of 154,11 → 163,13E, 224,18 → 215,17E, and 195,14 → 204,17A − −) does not show such a SE tail. However, both of them show multiple velocity-dependent emission peaks: towards SMA1 at 5 km s-1, mm3a at 8 km s-1, and mm3b at 10 km s-1. The multiple-peak structure is different from the traditional segregated dichotomous distribution of COMs in Orion-KL (i.e., the main emission peak is either at HC or mm3a(b)), though it has also been observed in other interferometric surveys (Wright et al. 1996; Beuther et al. 2005; Friedel & Snyder 2008; Guélin et al. 2008; Friedel & Widicus Weaver 2012; Peng et al. 2012a). Methanol has previously been detected in the Orion outflow (Wang et al. 2011), and furthermore, line 8− 1,8 → 70,7 is known to be a potential Class I maser that traces shocks (Fish et al. 2011). As a result, the SE tail can be reasonably explained as a feature of the outflow. In addition, it is also suggested that the SMA1-Source N area is the launching point of the Orion-KL outflows (e.g., Menten & Reid 1995; Beuther & Nissen 2008), which may explain CH3OH and H 2 13 CO \hbox{$\rm H_2^{13}CO$} peaking in this area.

  • HCOOCH3 (methyl formate) has the largest number of detected lines in our data (Fig. A.2). There are two types of HCOOCH3 in the whole observational band, torsionally excited lines (ν = 1) and lines in ground state (ν = 0). Both of them have identical distributions (Fig. 5) that peak at both mm3a and mm3b, with a clear detection in the southern CR, which is similar to CH2CO. This morphology has also been reported by Wright et al. (1996), Beuther et al. (2005), Guélin et al. (2008), Friedel & Snyder (2008), Favre et al. (2011a), Widicus Weaver & Friedel (2012), indicating that this species arises in a cooler and less dense environment than the HC.

  • CH3OCH3 (dimethyl ether) peaks towards mm3a and mm3b and extends to the southern CR, similar to HCOOCH3. Unlike the other COMs, its emission in mm2 is considerably stronger than towards the HC. This morphology has also been imaged with other interferometric studies (Liu et al. 2002; Beuther et al. 2005; Guélin et al. 2008; Friedel & Snyder 2008; Favre et al. 2011b; Brouillet et al. 2013).

  • CH3CH2OH (ethanol), the functional isomer15 of CH3OCH3, exhibits extended emission from the vicinity of HC to mm2, mm3a, and mm3b, indicating the same distinctive V-shaped molecular emission as the N-bearing COMs. However, unlike CH3OCH3 and the other COMs, it peaks in between the hotcore and mm3a. The difference in the location of their peaks is exactly the same as reported by Guélin et al. (2008), Brouillet et al. (2013) from PdBI and Friedel & Snyder (2008) with the EVLA and CARMA at high spatial resolution. In the grain mantle chemistry models, both isomers are produced from two radicals involved in the synthesis of CH3OH ice (Garrod et al. 2008). Therefore, their spatial differentiation may result from the chemical differences between the CH2OH and CH3O radicals across Orion-KL, e.g., variations in production rates or chemical evolution (Brouillet et al. 2013).

  • CH3COCH3 (acetone) is an O-bearing COM, though, it has a similar distribution to CH3CH2CN, which peaks at SMA1, extends to mm2, and has no detection in the southern CR. Although its nature as a hot molecular core tracer has been confirmed by detections in both Orion-KL (Friedel et al. 2005; Friedel & Snyder 2008; Widicus Weaver & Friedel 2012; Peng et al. 2013) and Sagittarius B2 (N-LHM) (Snyder et al. 2002), whether this species mainly forms on dust grains or in the gas phase is still not clear.

  • CH3CHO (acetaldehyde) is tentatively detected, as all lines except one at 220.446 GHz (Table A.1) are blended with HCOOCH3. Morphologically, this line has a similar distribution to CH2CO, peaking at mm3a and mm3b, with extended emission to the NE and SE tail. Although its origin is still unclear (Charnley 2004), it has been detected in Orion-KL with single-dish telescopes (Turner 1989). Previous interferometric observations failed to detect it because of filtering out the extended structure (e.g., Friedel & Snyder 2008; Widicus Weaver & Friedel 2012). However, its detection has been reported by recent CARMA and ALMA observations (Loomis, priv. comm.), which shows the same distribution as our single-dish complemented interferometric observation result.

  • There are also several other organics, such as CH2OHCHO (glycolaldehyde), (CH2OH)2 (ethylene glycol), and HCOOH (formic acid), which we do not detect in Orion-KL at 1.3 mm in the SMA-30 m combined data. Of the first two, although there are some candidate detections from our synthetic fitting, they are blended with other nearby lines, and so cannot be confirmed. Although Liu et al. (2002) claimed to detect HCOOH in the CR, in their data the line at 1 mm is only a 2σ feature. Widicus Weaver & Friedel (2012) also did not detect any compact concentrations of HCOOH in our studied region either, and they conclude that the HCOOH emission must be extended on >1700 AU scales.

In brief, from our detections, N- and O-bearing COMs not only show two segregated peaks, but also exhibit more complicated spatial distributions. Most of the N-bearing species (except CH2CHCN) are co-spatial and peak at the hotcore. While some O-bearing species (HCOOCH3, CH3OCH3, and CH3CHO) peak at mm3a and mm3b, and others present more unusual features (i.e., CH3OH has velocity dependent peaks at both hotcore and mm3a/mm3b; CH3CH2OH peaks in between mm3a and hotcore; and CH3COCH3 peaks in a similar location to N-bearing COMs). This challenges the traditional hypothesis that all of these molecules are forming in the same chemical and physical conditions (Garrod et al. 2008; Laas et al. 2011).

Unlike the saturated COMs, long carbon chains (organics with carbon-carbon multiple bonds) are less likely to be detected in star-forming regions (Thorwirth 2001; Rice & Maier 2013).

  • C6H is the parent radical of C6H− (the first molecular anion identified in the gas phase interstellar and circumstellar media; McCarthy et al. 2006), after its presence was predicted by Herbst (1981). It had not been detected in Orion-KL before. In our dataset, there is one unblended line at 230.109 GHz with J = 165/2 → 163/2, although most transitions identified by the synthetic fitting of C6H are blended. Emission from this tentative detected species appears to be confined to the HC.

  • HC3N and HC7N are two cyanopolyynes (HC2n + 1N, n is an integer). We confirmed the detection of HC3N(ν7 = 1) to the north of the hotcore and also tentatively detect HC7N. Although only two out of four of the HC7N lines predicted by the synthetic fitting programme are detected in our observations16, these lines are unblended and peak at a similar location to HC3N. The excited-vibrational state (ν7 = 1) of HC3N shows a similar confined structure north-east of the HC in Wright et al. (1996); Beuther et al. (2005) and Zapata et al. (2011), where it is said to form a shell around the HC. HC3N is an especially useful dense gas tracer due to its relatively low optical depth transitions, large dipole moment, and simple linear structure (Bergin et al. 1996). The HC3N(ν7 = 1) lines are believed to be primarily excited by a strong mid-infrared radiation field (e.g., Goldsmith et al. 1982). A gas-phase chemical model of a hot molecular core with high but transitory abundances of cyanopolyynes has been presented in Chapman et al. (2009), where these species are formed from reactions between the precursor C2nH2 (e.g., C2H2, acetylene) and N-bearing species via gas phase chemistry (e.g., C2nH2 + CN → HC2n + 1N + H).

Table 2

Identification of saturated COMs and complex carbon chains in Orion-KL.

4. Rotational temperature and abundance estimates

The above qualitative comparison of the morphology of different species show the chemical variations in the above-mentioned substructures. A more precise approach to studying these variations is to measure the quantitative differentiations in chemical parameters towards individual substructures, i.e., the temperatures, molecular column densities, and abundances.

4.1. Temperature estimates

Temperature is commonly used as a benchmark for comparing model results and observations. Since N-, O-, and S-bearing species show different spatial distributions, we estimate their temperatures in each substructure separately.

4.1.1. CH3CN

A good tracer of temperature in high-density gas (n ≳ 105 cm-3) is CH3CN, which is a symmetric-top molecule with no dipole moment perpendicular to the molecular axis, and its K ladders in rotational levels are excited solely by collisions. Provided that the collision rate is sufficient to thermalize the rotational levels within each K ladder, the rotational excitation temperature of CH3CN is equal to the gas kinetic temperature (Boucher et al. 1980; Wright et al. 1995). Our observation band covers the J = 12 → 11 transitions of CH3CN around 220 GHz, with upper state energy levels from ~70 K to ~500 K, yielding a wide range for determining temperatures. If we assume that the emission from all of these transitions originate in the same parcels of gas along the line of sight in LTE, having the same size, velocity, and a single temperature, then rotational temperatures can be derived from the rotational diagrams (Hollis 1982; Loren & Mundy 1984; Olmi et al. 1993; Goldsmith & Langer 1999). Traditionally, in the optically thin limit, the level populations are then directly proportional to the line intensities of the K components. The parameters used to estimate the level populations of CH3CN transitions (i.e., the line strength Sulμ2 (Debye2) and the lower state energy EL (cm-1)) in our data are listed in Table A.2.

The K = 3, 6 lines are from ortho (o-) transitions, which have a statistical weight that is twice as strong as those of the other para (p-) lines. Radiative transitions between o-/p-types are usually prohibited, so we exclude these lines in the optically thin rotation diagram fitting (shown in black lines in Fig. 8, also see Andersson et al. 1984).

Panel 1 of Fig. 8 shows the synthesised fitting under the assumption of optically thin emission in LTE for the HC with the dashed lines. To reduce the number of free parameters, we also assume that all the K = 0 − 8 components17 have the same line width. A satisfactory fit is obtained to all lines except K = 0, 1, 2. Since all transitions were observed simultaneously, calibration errors due to poor pointing or amplitude scaling are not responsible, and the remaining explanations for the deviations are as follows: (1) the K = 0, 1 lines are so close in frequency that they are blended in our fitting by the uniform line width we assumed; (2) it is also likely that lines at K = 2 are more optically thick.

thumbnail Fig. 8

Panel 1): CH3CN spectrum towards the HC in black, LTE model fit in dashed purple, and fitting with optical depth correction in filled red. Panels 2)−6): rotation diagram of CH3CN derived for each substructure, with dots for p-CH3CN and triangles for o-CH3CN. Black fittings are only for the p-lines when assuming they are optically thin, and red fittings are for both o- and p-lines by optical depth correction. Panel 7): CH313CN\hbox{$\rm CH_3^{13}CN$} spectrum towards the HC in black and the LTE model fit in red. Panel 8): rotation diagram of CH313CN\hbox{$\rm CH_3^{13}CN$} in HC with black dots (p-) and triangles (o-) from observation, and fitting is o-lines excluded by assuming lines are optically thin. For lines without detection, an upper limit equal to the 3σ rms is shown as arrow. The estimated temperature and total column density from each fitting is indicated in each panel. Errors are derived from scatter in the data points.

Compared to CH3CN, lines of its rare isotopologue CH313CN\hbox{$\rm CH_3^{13}CN$} should be optically thin. However, CH313CN(122→112)\hbox{$\rm CH_3^{13}CN~ (12_2\rightarrow11_2)$} is the only transition that is not blended with the broad line wings of CH3CN in substructures other than HC. Even in the HC, only the K = 2, 6, and 7 lines are unblended (Panel 7 of Fig. 8). Excluding the o-type lines (K = 3, 6), the rotation temperatures in HC we derive from the main and rare isotopologues of CH3CN have large differences (black fittings in Panels 2 and 8 of Fig. 8). Optical depth seems to be the most likely reason for such inconsistency, so to investigate this hypothesis, we use the following iterative approach to correct the optical depth of CH3CN lines and derive the opacity-corrected rotation temperature Trot,p (p = HC, mm2, mm3a, mm3b, NE) of each substructure (red fittings in Panels 2−6 of Fig. 8):

  • (1)

    Obtain the rotation temperatureT1,p from weighted least squares fit to Boltzmann diagram, assuming that all the p-type CH3CN lines are optically thin (see fit to the black dots in Panels 2−6 of Fig. 8);

  • (2)

    Estimate the optical depth of CH3CN (122 → 112)τK,1 (K = 2) by comparing its main beam temperature with that of CH313CN(122→112)\hbox{$\rm CH_3^{13}CN~ (12_2\rightarrow11_2)$}, and calculate the column density of line 122 → 112 at T1,p with the optical depth correction. Then, estimate the total column density of CH3CN as N1,p assuming LTE (see Sect. 4.2 for more details about the correction);

  • (3)

    With T1,p and N1,p as trial input parameters, estimate the optical depth for the remaining transitions in the CH3CN ladder τK,1 (K = 0 − 8) with the RADEX code package18 (van der Tak et al. 2007), then correct their column densities line by line (dots and triangles in red in Fig. 8) and obtain a new rotation temperature T2,p;

  • (4)

    Repeat step (2)–(3) until (| Tn,p − Tn − 1,p | ) /Tn − 1,p ≤ 10% (n = 2, 3,...; see fittings in red in Fig. 8).

The above approach19 can be applied to sources HC, mm2 mm3a, mm3b, and NE, where the CH3CN ladders and CH313CN(122→112)\hbox{$\rm CH_3^{13}CN~(12_2\rightarrow11_2)$} can be clearly detected20. In SR and OF1N(S), the CH3CN lines are below the 3σ detection threshold, so we assume the rotation temperature in these positions to be the same as that in NE.

4.1.2. HCOOCH3, CH3OH, and 34SO2

HCOOCH3 has the largest number of lines detected in our dataset. From satisfactory synthetic fitting (especially for lines in the torsionally excited state ν = 1, Fig. A.2), we can reasonably assume that most of its lines are optically thin. Line emissions from this species are not contaminated by N-bearing species owing to their different spatial distributions, so we use them to derive a second set of temperatures.

On the other hand, CH3OH and H213CO\hbox{$\rm H_2^{13}CO$} have an unusual spatial distribution (dual peaks /extended emissions at both HC and mm3a(b), and tail towards the SE), which may be affected by their different temperatures. Since multiple transitions of CH3OH are available in our data, we can use them to derive a third temperature set.

For S-bearing species, their extended emission indicates they may be sensitive to the ambient shock environment, so their temperature in each substructure may be different from the other species. However, in our data, some of the S-bearing species have only a single transition (O13CS, 13CS), and other lines may not be optically thin (SO2, SO, and OCS). Because 34SO2 is the only S-bearing rare isotopologue that has multiple transitions in our observations, we applied temperatures derived from transitions of 34SO2 to the other S-bearing species.

Using the lines list in Table A.3, we derived the rotation temperatures in each substructure from HCOOCH3, CH3OH, and 34SO2 (Figs. 9I–III) and list these temperature sets in bold face in Table 3. Temperatures derived from HCOOCH3 lines in the ground and torsionally excited states separately have some differences, but they do not deviate significantly from temperatures derived from all of its lines. Therefore, we use the “mixed” temperatures in the end.

4.1.3. The other organics

In addition, since different organic molecules have specific spatial distributions, we also derive the rotation temperatures for the species that have multiple transitions with significantly different Eu/kB detected in our dataset (Figs. 9IV−VI, listed in Table A.3). In the condensations HC, mm2, mm3a, and mm3b, rotation temperatures of HNCO are similar to those derived from CH3CN within uncertainties; and rotation temperatures derived from CH3OCH3 and CH3CH2OH are close to HCOOCH3 (ν = 1) within uncertainties. Therefore, temperature sets from CH3CN and HCOOCH3 are applicable to the rest N- and O-bearing species (including simple molecules and COMs) in estimating their column densities.

Although temperatures derived from different species at the same substructure vary, HC is consistently the warmest substructure, while mm2, mm3a, and mm3b are slightly cooler. In the outflow regions, there are no sufficiently strong lines for species other than CH3CN to derive the temperature, which may suggest these regions are cooler, exhibiting similar chemical properties.

thumbnail Fig. 9

Rotation diagrams of the N-, O-, and S-bearing species with multiple unblended transitions detection in HC, mm2, mm3a, and mm3b. Panels in row I show two states of HCOOCH3 lines, with the blue and black dots from observation of ground state (ν = 0) and torsionally excited state (ν = 1) lines, respectively. With the optically thin assumption, fittings for each state are plotted in blue or black, respectively, and fittings for all the transitions are plotted in red. Non-detection of HCOOCH3 lines are not shown. Panels in rows II–VI show fittings with the optically thin assumption, with 3σ upper limits from non-detections plotted as arrows. Blue dashed lines in row III are fittings with upper limits included. The estimated temperature and total column density from each fitting is indicated in each panel. Errors are derived from scatters in the data points.

Table 3

Rotation temperature sets for each substructure derived from species, each of which has >4 transitions with significantly different Eu/kB detected in our data.

4.2. Column densities

4.2.1. Molecular column densities

For all the species we detected, we calculate their column densities (from both main and rare isotopologues) from the integrated spectral line intensities as below.

The optical depth τυ (in velocity) along the line of sight is (Zeng et al. 2006, Eq. (A.25)): τυ=c38πν3AulNu(ehνkBTrot−1)Φ(υ),\begin{equation} \tau_\upsilon=\frac{c^3}{8\pi \nu^3 } A_{\rm ul} N_{\rm u} \left({\rm e}^{\frac{h \nu}{k_{\rm B}T_{\rm rot}}}-1\right) \Phi(\upsilon), \end{equation}(1)where c is the speed of light, kB the Boltzmann constant, h the Planck constant, ν the line rest frequency, Φ(υ) the distribution function of the line shape in terms of velocity υ. Here, Aul is the average spontaneous emission rate from the upper state Eu into the lower state El, and it is calculated from line strength Sul and dipole moment μ as Aul=64π4ν33hc3Sulμ2gu·\begin{equation} A_{\rm ul}=\frac{64\pi^4\nu^3}{3hc^3}\frac{\it S_{\rm ul}\mu^2}{g_{\rm u}}\cdot \end{equation}(2)After integrating the optical depth over the observed linewidth, ∫Φ(υ)dυ = 1, and the column density Nu of the line at ν Hz is Nu=8πν3c3Aul1exp(hνkBTrot)−1∫τυdυ.(cm-2).\begin{equation} \label{up} N_{\rm u}=\frac{8 \pi \nu^3}{c^3 A_{\rm ul}}\frac{1}{\exp\left(\frac{h \nu}{k_{\rm B}T_{\rm rot}}\right)-1} \int \tau_\upsilon {\rm d}\upsilon. \rm~~~~~(cm^{-2}). \end{equation}(3)When assuming LTE, the total column density of all transitions for a molecule α is NT,α=NuguQ(Trot)eEukBTrot(cm-2)\begin{equation} \label{NT} N_{T,\alpha}=\frac{N_{\rm u}}{g_{\rm u}} Q(T_{\rm rot}) {\rm e}^{\frac{E_{\rm u}}{k_{\rm B}T_{\rm rot}}}\rm ~~~~~(cm^{-2}) \end{equation}(4)where Q(Trot) is the partition function for the given (rotational) excitation temperature of each sources, which is interpolated from a table of partition functions for fixed temperatures, obtained from CDMS/JPL.

Here, Sulμ2 can be calculated from CDMS/JPL line intensity ℓ(Trot) (Pickett et al. 1998), Sulμ2=3hc8π3νℓ(Trot)Q(Trot)(e−ElkBTrot−e−EukBTrot)-1=2.4025×1010[νHz]-1[ℓ(300 K)nm2MHz]Q(300K)\begin{eqnarray} S_{\rm ul}\mu^2&=& \frac{3hc}{8\pi^3\nu}\ell(T_{\rm rot})Q(T_{\rm rot})\left({\rm e}^{-\frac{E_{\rm l}}{k_{\rm B}T_{\rm rot}}} -{\rm e}^{-\frac{E_{\rm u}}{k_{\rm B}T_{\rm rot}}}\right)^{-1}\\ &=& 2.4025\times10^{10}\left[\frac{\nu}{\rm Hz}\right]^{-1}\rm \left[\frac{\ell(300\,K)}{nm^2~MHz}\right]{\it Q}(300~K) \nonumber\\ && \times\left[{\rm e}^{-\frac{E_{\rm l}}{k_{\rm B}\rm 300~K}}-{\rm e}^{-\frac{E_{\rm u}}{k_{\rm B}\rm 300~K}} \right]^{-1} \rm Debye^2.\label{sul} \end{eqnarray}For the emission lines, we assume the Rayleigh-Jeans approximation (hνkBTrot≪1\hbox{$\frac{h\nu}{k_{\rm B}T_{\rm rot}}\ll1$}) is valid, therefore Eqs. (3) and (4) can be simplified as (Zeng et al. 2006, Eq. (4.26); also see Wilson et al. 2009),

Nugu≅3kB8π3νSulμ2Trot∫τυdυ(cm-2)NT,α=kBhc(ehνkBTrot−1)ℓ(Trot)Trot∫τυdυ(cm-2).\begin{eqnarray} \label{emi} &\frac{N_{\rm u}}{g_{\rm u}}\cong \frac{3k_{\rm B}}{8\pi^3\nu \it S_{\rm ul}\mu^2} T_{\rm rot} \int \tau_\upsilon {\rm d}\upsilon ~~~~~~~~~~\rm(cm^{-2})\\ & N_{\rm T,\alpha}= \frac{k_{\rm B}}{h c} \frac{\left({\rm e}^\frac{h\nu}{k_{\rm B}T_{\rm rot}}-1\right)}{\ell(T_{\rm rot})}T_{\rm rot} \int \tau_\upsilon {\rm d}\upsilon ~~~~~~~~~~\rm(cm^{-2}). \end{eqnarray}Assuming that the observed emission in each substructure is homogeneous and fills the combined beam, the integration of measured main beam brightness temperature within the velocity range TB∫(υ)dυ\hbox{$\int T_{\rm B}(\upsilon) {\rm d}\upsilon$} can be substituted for the last term in the above equation: Trot∫τυdυ≅τα,01−e−τα,0∫TB(υ)dυ(Kcm s-1)\begin{equation} \label{eq:correc} T_{\rm rot} \int \tau_\upsilon {\rm d}\upsilon \cong \frac{\tau_{\alpha,0}}{1-{\rm e}^{-\tau_{\alpha,0}}}\int T_{\rm B}(\upsilon) {\rm d} \upsilon~~~~~~~~~~~~\rm (K~cm\,s^{-1}) \end{equation}(9)where τα,0 is the optical depth at line centre, and TB∫(υ)dυ\hbox{$\int T_{\rm B}(\upsilon) {\rm d}\upsilon$} is measured from Gaussian/hyperfine structure (HFS) fitting by using Gildas software package.

The column densities and related uncertainties of species listed in Table 3 (CH3CN (CH313CN\hbox{$\rm CH_3^{13}CN$}), HNCO, HCOOCH3, CH3OH, CH3OCH3, CH3CH2OH, and 34SO2) can be estimated directly from their rotation diagrams and the scatterings of the data points (Fig. 9). For the species whose transitions are not sufficient to derive the rotation diagrams, we estimate their column densities by assuming that transitions of related species have the same Trot:

  • N-bearing species have similar temperatures to those derivedfrom the opacity-corrected CH3CN,

  • S-bearing species have similar temperatures to 34SO2,

  • O-bearing species have similar temperatures to HCOOCH3,

  • given the similarly unusual spatial distribution between H213CO\hbox{$\rm H_2^{13}CO$} and CH3OH, we also estimate the column densities of H213CO\hbox{$\rm H_2^{13}CO$} at temperatures derived from CH3OH.

In general, we assume that the observed transitions are optically thin (τα,0≤1,τα,01−e−τα,0≈1\hbox{$\tau_{\alpha,0}\le1, \frac{\tau_{\alpha,0}}{1-{\rm e}^{-\tau_{\alpha,0}}} \approx1$}). However, for several molecules with large abundances, we observe the corresponding transitions of their main and rare isotopologues, e.g., OCS (J = 19 → 18) − O13CS (19 → 18), 13CO (2 → 1) − CO (2 → 1) − C18O (2 → 1) and CH313CN(122→112)−CH3CN(122→112)\hbox{$\rm CH_3^{13}CN ~(12_2\rightarrow11_2)-\rm CH_3CN ~(12_2\rightarrow11_2)$}. By measuring the ratio between main beam brightness temperature of the main line TB,α,0 and its rare isotopologue TB,β,0, we can estimate the optical depth at line centre of a given transition τα,0 (Myers et al. 1983): 1−exp(−τα,0/ℜα)1−exp(−τα,0)≈TB,β,0TB,α,0\begin{equation} \label{eq:tau} \rm \frac{1- exp(-\tau_{\alpha,0}/\Re^\alpha)}{1-exp(-\tau_{\alpha,0})}\approx \frac{{\it T}_{B, ~\beta,0}}{{\it T}_{B, ~\alpha,0}} \end{equation}(10)where ℜα is the intrinsic abundance of the main isotope (e.g., 12C) compared to its rare isotope (e.g., 13C) in the ISM (Table 4, e.g., Wilson & Rood 1994; Chin et al. 1996).

Using the above method, we calculate the column densities of 25 isotopologues (for both optically thin and thick cases) in each substructure, and present them in Tables A.5I−A.7I. In Table 4, we list the transitions for which we corrected their optical depths. We found that CO (2 → 1), OCS (19 → 18), and CH3CN (122 → 112) are significantly optically thick (τ = 6 − 117) in all substructures where they are detected. The validity of the assumption that the remaining molecular lines are optically thin is discussed in Sect. 4.4.

In addition, the main emission peak(s) of some COMs (CH3COCH3, CH3CH2OH, CH2CHCN, C6H, and HC7N) do not strictly coincide with either of the continuum peaks. In determining their column densities at their main emission peaks, we use their strongest transitions (shown in Fig. 5) and the temperature from an adjacent substructure. Lines are assumed to be optically thin, and molecular column densities could be underestimated if this assumption is incorrect, so the lower limits are given in Table 2.

4.2.2. H2 column densities

In Orion-KL, at 1.3 mm wavelength, the continuum emission is dominated by dust-neutral gas emission (Beuther et al. 2004). Assuming the dust emission at mm wavelengths is optically thin and coupled with the gas, which has a single excitation temperature, Tex ~ Trot = Tdust (Hildebrand 1983), we use the SMA-only data to calculate the H2 column densities for different substructures, according to Schuller et al. (2009) : NH2=IνRBν(Tdust)ΩaκνμmH(cm-2)\begin{equation} \label{gas} N_{ \rm H_2}=\frac{I_{\nu}R}{B_\nu(T_{\rm dust})\Omega_a \kappa_{\nu}\mu m_{\rm H}}~~~~~~~~~\rm (cm^{-2}) \\ \end{equation}(11)where Iν is the peak specific intensity for each substructure on the continuum (in Jy beam-1, taken to be the 3σ upper limit in the outflow regions); R is the isothermal gas to dust mass ratio (taken to be 150, from Draine 2011); Bν(Tdust) is the Planck function for a dust temperature Tdust; Ωa is the solid angle of the SMA beam (in rad2);κν = 1.0 cm2 g-1 is the dust absorption coefficient at 1.3 mm (assuming a model of agglomerated grains with thin ice mantles21 for densities107 cm-3 (Blake et al. 1987), extrapolated from Ossenkopf & Henning (1994); μ is the mean molecular weight of the ISM, which is assumed to be 2.33; and mH is the mass of an hydrogen atom (1.67 × 10-24 g). The results are reported in column NH2,1 of Table 1.

From the SMA-only observations, the total continuum flux at 1.3 mm is 22.6 Jy. However, extrapolating the flux Sν from existing SCUBA data (Di Francesco et al. 2008) at 450 μm (28 700 Jy) and 850 μm (2 090 Jy), the total flux should be closer to ~400 Jy at 1.3 mm (assuming Sν ∝ ν4, Johnstone & Bally 1999). The difference implies that >90% of the flux has been filtered out by the SMA observations. In contrast, C18O (2 → 1) from a combination of 30 m and SMA observations is detected towards all the substructures, and it should not suffer from the same spatial filtering as the SMA-only continuum data. As a result, it is a more reliable probe of the total column density of gas in the cloud at all spatial scales. Moreover, as a rare isotopologue line, it can be reasonably assumed to be optically thin, so we use it to make a second independent estimation of the H2 column density in all the substructures. By assuming a constant abundance in all substructures NC18ONH2=NC18ONCONCONH2~10-4560~1.79×10-7\hbox{$\frac{N_{\rm C^{18}\rm O}}{N_{\rm H_2}} =\frac{N_{\rm C^{18}O}}{N_{\rm CO}}\frac{N_{\rm CO}}{N_{\rm H_2}} \sim \frac{10^{-4}}{560}\sim1. 79\times10^{-7}$} (Wilson & Rood 1994), H2 column densities can be calculated from the column densities of optically thin C18O emission (reported in the column NH2,2 of Table 1).

4.3. Molecular abundances

Subsequently, to study the chemical properties on the small scale of Orion-KL, we derived the molecular abundances with respect to H2 (converted from C18O) in each substructure (Tables A.5II−A.7II).

Figure 10 presents the molecular column densitiy and the abundance of each species with respect to NH2,2. Generally, all the molecules have higher column densities in the central condensations (HC, mm2, mm3a, and mm3b) than the extended regions in the outflows (NE, SR, OF1N, and OF1S). While the abundances of some species have relatively small variations among the substructures (e.g., SO, CO, C18O, and 13CO), some vary substantially. Specifically, N-bearing species are significantly underabundant in the SR and the outflow regions; O-bearing organic molecules containing ≤6 atoms (e.g., H213CO\hbox{$\rm H_2^{13}CO$}, CH2CO, CH3OH) have more extended emission across all the substructures, with nearly constant large abundances in all the substructures except for NE. The S-bearing molecules are an intermediate case: most of them are not detected in the high-velocity outflow, but are clearly detected in NE (OCS, SO2, 34SO2, 13CS) and (or) the SR (SO), with lower abundance. Such abundance differentiation among species is consistent with the spatial differentiation shown in Fig. 4.

thumbnail Fig. 10

Molecular column densities (panels in the left column) and abundances (panels in the right column) towards 8 positions in Orion-KL. The molecular abundances of each species with respect to H2 are converted from C18O, assuming a constant NC18O/NH2 ~ 1.79 × 10-7 ratio. Column densities and abundances with the uncertainties are measured as mentioned in Sect. 4.4 and Tables A.5–A.7. Coloured solid lines show the differentiation for each isotopologue calculated from optically thin assumption (arrows highlight the upper limits), while dashed lines show the differentiation calculated with optical depth correction from Eq. (10). For abundant molecules (e.g., HNCO, SO, SO2, CH3OH) which we have not measured their line optical depths, their densities could be underestimated by a factor of 7−10.

4.4. Error budget

In this section, we consider the effect that the various assumptions that we made in our quantitative analysis have on the results presented in this paper.

  1. Trot (rotation temperature): the traditional rotation diagram method is subject to a number of uncertainties owing to various assumptions, e.g, line emission is assumed to be optically thin and LTE is assumed to apply (see discussion in Snyder et al. 2005; Herbst & van Dishoeck 2009). If these assumptions are valid, the points on the population diagram will be well-fit by a straight line, with the slope proportional to the negative reciprocal of the temperature. However, this is not the case (see Fig. 8). According to Table 2, the volumn density in each substructure is ~107 cm-3 (assuming a source size ~10 times of the beam size, see also Blake et al. 1987; Plume et al. 2012), so LTE can be a reasonable assumption (except for such extreme cases as masing and sub-/super thermal excited conditions), and the main reason for the fittings with uncertainties is the optical depth of the used lines.

    (1): In Sect. 4.1.1, we obtain the optical depth ofCH3CN (122 → 112) by comparing its observed main beam brightness temperature to that of CH313CN(122→112)\hbox{$\rm CH_3^{13}CN~(12_2\rightarrow11_2)$}. Then, we use this optical depth as a standard in non-LTE radiative transfer fitting and derive a lower Trot in each substructure. In the HC, the rotational temperatures derived from CH3CN (155 ± 16 K) and CH313CN(121±16K)\hbox{$\rm CH_3^{13}CN~ (121\pm16~ K)$} are slightly different, but they agree within the uncertainties, and column densities of N-bearing species are insensitive to temperature uncertainties of this magnitude (Table A.6I). On the other hand, temperatures derived from HNCO agree with the above Trot within the uncertainties, so our approach should be applicable.

    (2): In Sect. 4.1.2, Trot for most O-bearing species are assumed to be similar to those derived from HCOOCH3. In general, the temperatures derived from two different states of HCOOCH3 lines are consistent, while the torsionally excited HCOOCH3 (ν = 1) lines appear to trace lower temperatures than lines in the ground state (ν = 0), because LTE assumption may not be applied in sub-thermal conditions (see also Demyk et al. 2008). In addition, we derived a third temperature set from CH3OH, which is in general higher than those derived from HCOOCH3, CH3OCH3, and CH3CH2OH. Synthetic spectrum fitting (Fig. A.2) indicates that some lines of CH3OH may be optically thick, which may explain the higher measured Trot. On the other hand, CH3OH lines have broader line widths (~5 − 7 km s-1) than HCOOCH3 lines (~3 − 5 km s-1) in the central condensations, implying that they trace gas with different temperatures.

    (3): For S-bearing species, Trot derived from 34SO2 varies from HC through mm2 to mm3a and mm3b. However, detected lines in mm3a and mm3b are not sufficient to derive a reliable temperature, because we lose the constraint of fittings from the non-detection line with high Eu/kB at 229.987 GHz (Fig. 9III). Nevertheless, we estimate the temperature upper limits for both substructures by including the non-detected lines (dashed blue fittings), and find the differences for column densities derived at temperatures from 89−101 K (non-detection are excluded in fittings) to 176−193 K (upper limits, columns in italic font in Table A.7I) are by a factor of <3. The insensitivity of S-bearing column densities to this temperature regime may also explain the slightly higher Trot with large uncertainties in HC and mm2.

NT (molecular column density): in Sect. 4.2, we first assume that all the identified molecular lines are optically thin. Then, we use Eq. (10) to obtain the optical depth of those main isotopologue lines whose rare isotopologue lines with the same transition are detected. Finally, using Eq. (9), we correct the column density of the main isotopologue. In this approach, by assuming the rare isotopologue lines are optically thin, we list the optical depths and abundance ratios for 13CO (2 → 1), CO (2 → 1), OCS (19 → 18), and CH3CN (122 → 112) with respect to the corresponding rare isotopologue lines with and without optical depth correction in Table 4.

Table 4

Optical depth and abundance ratios for CO, 13CO, OCS, and CH3CN with respect to their rare isotopologues in each substructure of Orion KL.

However, Eq. (9) is based on the assumption that the main and rare isotopologue lines have the same excitation temperature, which is often not the case. Therefore, a more accurate calculation requires the large velocity gradient (LVG) approach and proper chemical modelling. Nevertheless, our analytic calculations suggest that, the optical depth is the main situation driving the error in the estimated molecular column density. For abundant molecules such as CH3OH, HNCO, SO, and SO2, where we do not observe a corresponding transition of their rare isotopologues, our assumption that their lines are optically thin may result in underestimating their column densities by a factor of 7−10 (coming from the average differences for OCS, CO, and CH3CN column density values before and after optical depth correction in Fig. 10).

Aside from the optical depth, the errors also come from our assumption of LTE. Assuming that the transitions of one species have ideal Boltzmann distributions at the same Trot, molecular total column density can be derived from one transition. However, as represented by points on their rotation diagrams, multiple transitions of certain species (e.g., 34SO2, HNCO, and CH3CH2OH, Fig. 9) show wide scatter, indicating that uncertainties in the estimation of Trot lead to the over-/under-estimation of the total column densities by a factor of 0.5−2 (bold face in Tables A.5I,−A.7I). For the species whose total column densities are not able to be estimated from rotation diagram fittings owing to the lack of sufficient transitions, our LTE assumption (using Eq. (4)) may also result in the under/over-estimation of their total column densities of the same magnitude.

In addition, TB∫(υ)dυ\hbox{$\int T_{\rm B}({\upsilon}) {\rm d}{\upsilon}$} measured from Gaussian/HFS fittings brings on average <10% uncertainties (Table A.4), which is negligible compared to the chemical differentiation amongst the substructures (written as the subscript in Tables A.5I−A.7I).

NH2 and molecular abundance: because no continuum information is available from the combined data, we used two methods to calculate the column density of H2 (Table 1): from SMA-only continuum (NH2,1) and from SMA-30 m C18O (NH2,2). The molecular abundances were derived with respect to H2,2. Comparing the column density of H2,1 and H2,2, we found NH2,2/NH2,1 is ~0.9 in mm2, ~0.5 in mm3a and mm3b, ~0.4 in HC22, ~0.2 in NE, but 0.1 in SR. Several reasons may lead to such difference: (1) the specific intensity (Jy beam-1) used to calculate the column density depends on the beam. The combined beam is larger than the SMA-only beam by a factor of ~2.5, so it is reasonable that for larger beam size, we obtain lower H2 column density (similar case in Beuther et al. 2007a). (2) In producing the continuum, we select the “line-free” part, but there are still lines with low emission (Fig. A.2), which may contaminate the continuum; (3) we simply assume that the gas-to-dust ratio and the volume densities in all substructures are similar within an order of magnitude (~150, ~107 cm-3), hence also the dust opacity. Since we do not know the size of each substructure, gas is possibly much denser in a warmer source (HC, mm2, mm3a, and mm3b) than in the other cooler substructures (NE, SR), so the homogeneous volume density assumption may not be accurate in the whole region.(4) Grain growth in the envelopes can also be a reason for difference in dust emissivity from centre to extended substructures at (sub-)mm (Miotello et al. 2014). (5) We also note that C18O column density in the central region is a factor of 30 higher than in the outflow. Judging that NH2,2 is derived with the assumption that NC18O/NH2 = const. in all the studied substructures, the variation of NC18O/NH2 ratio in different substructures can be another factor that leads to error in our estimation.

In addition, another simplification in our calculation is an assumed constant beam-filing factor. Determination of molecular abundances in Orion-KL substructures relies upon an accurate source structure model for each molecule. When the source is smaller than the beam size, the main beam brightness temperature is diluted, leading to an underestimated brightness temperature for more compact structures. To correct this, an appropriate correction factor needs to be applied. Since we do not know the accurate sizes of the substructures, we simply assume that the filling factor is unity in all the calculations.

5. Discussion

These observations comprise a large set of molecular lines (over 160 lines from 20 species, including 25 isotopologues) from combined SMA and IRAM 30 m data towards Orion-KL. Resolving Orion-KL into eight substructures and comparing S-, N-, and O-bearing molecules, we find complicated spatial morphologies for COMs and strong chemical differentiation over the observed substructures.

5.1. Comparison with the other results

Previous quantitative studies of Orion-KL mainly focused on the HC, CR (with mm3a and mm3b treated as a single substructure), and plateau (OF1N, OF1S), therefore comparison of our estimated molecular abundances with previous results is limited to these substructures.

  • 1.

    Since different molecules have different chemistry, the rotationtemperatures derived using different tracers in the samesubstructure vary. Comparing with the results of others studies,the variation in Trot for different species can be explained.

    • Our opacity-corrected temperature in HC derived from CH3CN is 120–160 K, which is a factor of 1.5 lower than reported by Goddi et al. (2011a) from NH3 at a higher angular resolution (~0.8″). Given that HNCO in our dataset probes the similar temperatures, our slightly lower temperatures for N-bearing molecules may trace the envelope region of the HC.

    • Our adopted temperatures from HCOOCH3 agree with the temperatures estimated by Favre et al. (2011a) from observations of this species at similar spatial resolution23. However, they are lower than those reported in Brouillet et al. (2013) owing to our spectral resolution. Multiplets of CH3OCH3 and CH3CH2OH are not resolved in this paper, so we treat each detected line of these species as a single component, and temperatures obtained from rotation diagrams are potentially underestimated24.

    • Temperatures probed by CH3OH (>200 K in HC, ~170 in mm2, and ~160 K in CR) are higher than those probed by the other molecules, probably because of the lack of optical depth corrections, or because they trace gas with different temperatures (discussed in Sect. 4.4 part 1 (2)). Nevertheless, these temperatures agree with those derived from the same species by Sutton et al. (1995) (13CH3OH) and Friedel & Widicus Weaver (2012) in HC and CR, and by Beuther et al. (2005) in HC and mm2.

    • We note that S-bearing species may be affected by shocks in the environment. Although they were not often derived previously, and the high Eu/kB transition leads to large uncertainties in the rotation temperatures derived from 34SO2, our estimated temperatures are within the uncertainty of those derived by Esplugues et al. (2013) from SO2 in HC (190 ± 60 K) and CR (80 ± 30 K).

Due to the compactness of the detected substructures, column densities of CO, 13CO, and C18O are ten times higher than those from lower resolution observations in single-dish observations of Wilson et al. (2011) (FWHP ~ 13″) and in Plume et al. (2012) (Herschel/HIFI beam ranges from 13′′ to 40″). If taking the beam ratio into account, our results are consistent with previous measurement.

In both HC and CR, the abundances of SO, SO2, HNCO, HC3N, CH3OH, CH2CHCN, CH3CH2CN, and CO are comparable to the values in Blake et al. (1987), Wright et al. (1996), and Esplugues et al. (2013), within our factor of 1.5−2 uncertainties. H213CO\hbox{$\rm H_2^{13}CO$} is lower than the value derived from H2CO in Blake et al. (1987), assuming a standard 12C /13C ratio, but is comparable to the value in Wright et al. (1996). After the optical depth corrections, our OCS and CH3CN abundances are ten times higher than those in Blake et al. (1987), because the latter estimation was made assuming lines of these species to be optically thin. However, our abundances of OCS and 13CS are comparable to those in Tercero et al. (2010), within our factor of 2 uncertainty.

Similar to the gradient in Sutton et al. (1995) and Wright et al. (1996), CO and SO have stronger emission and higher abundances in the plateau of both the high- and low-velocity outflows, which has been suggested to be due to shock enhancement in these regions. Although molecules in general have around 1−2 mag lower abundances in our low-velocity outflow than the values reported in the NE–SW plateau from previous interferometric study (Wright et al. 1996), their abundances in our high-velocity outflow are comparable to the single dish results in the NW–SE plateau (Sutton et al. 1995).

The estimated column densities of COMs (CH3CH2CN, CH3COCH3, CH3OCH3, and HCOOCH3) in HC are found to be lower than the values in Friedel & Snyder (2008) by a factor of 10, because their observations have a smaller synthetic beam. However, HCOOCH3 has comparable column densities to Favre et al. (2011a) in mm2 (MF4–5), mm3a (MF3), and mm3b (MF1), as does CH3OCH3 compared to Brouillet et al. (2013) at all the central condensations (HC, mm2, mm3a, and mm3b), and the abundance of CH3COCH3 compared to Peng et al. (2013) at HC and mm2 (Ace-3).

To sum up, the abundance of most species from our study are comparable to previous single-dish studies especially in the central condensations. Therefore, molecular abundance estimation from single-dish observations for the farther sources (e.g., ten times farther than Orion-KL) should be trustworthy at least in the source centre after optical depth correction.

5.2. Chemistry in the hot molecular core

At a spatial resolution of ~1200 AU, our data resolves Orion-KL into several condensations. The specific intensities (Jy beam-1) of the dust continuum peaks exhibit a gradient from the central condensations to the extended structures, and the gas temperatures exhibit the same gradient: The HC is the strongest continuum substructure, because it has both the highest gas temperature and column density; mm2, mm3a, and mm3b are slightly fainter and less dense; while NE and SR have weaker continuum and line emission than the former sources, but stronger emission than OF1N(S).

Differentiation in the spatial distribution of S-, N-, and O-bearing species clearly shows that chemistry in the central condensations of Orion-KL is not homogeneous. Simple N- and O-bearing molecules show the strongest emission towards the central condensations. However, unlike most of the N-bearing species (including N-bearing COMs) which are not detected in SR, NE, or the outflow, simple organic molecules (H213CO\hbox{$\rm H_2^{13}CO$}, CH2CO) and CO (13CO, C18O) have bright extended emission even towards the cooler and less dense regions (SR, OF1N, and OF1S). Compared to the above extreme cases, the S-bearing molecules are widely distributed over the central condensations, NE and (or) SR. A possible reason for this is that the S-bearing molecules are mainly formed via warm gas-phase chemistry or shock chemistry (e.g., Pineau des Forets et al. 1993; Charnley et al. 1997), and then coincide with both N- and O-bearing molecules in the plateau (NE) of BN/KL (e.g., Chandler & Wood 1997; Schreyer & Henning 1999, see discussion in Sect. 5.3).

For the COMs, it has been widely suggested that “N-/O- chemical differentiation” can be caused by lower or higher temperatures during the cold pre-hot molecular core phase and different paces of warm-up in these regions (Caselli et al. 1993; Garrod et al. 2008; Neill et al. 2011; Laas et al. 2011). Besides confirming the HC peak of N-bearing COMs (CH2CHCN, CH3CH2CN, CH3CN, and CH313CN\hbox{$\rm CH_3^{13}CN$}) and the mm3a (or/and mm3b) peak of several O-bearing COMs (e.g., HCOOCH3 and CH3OCH3), we found several other COMs which cannot be classified within these dichotomous emission peaks groups (also see Guélin et al. 2008; Friedel & Widicus Weaver 2012; Peng et al. 2013). For example, the peak of CH3OH is velocity dependent, shifting from the HC (3.6 km s-1) through mm3a (6 km s-1) to mm3b (7.2 km s-1); the peak of CH3CH2OH is in between the HC and mm3a. In contrast, CH3COCH3 shares a morphology with N-bearing molecules−peaking towards the HC with a V-shaped distribution. This similarity in morphologies may indicate a link between the HC-peaking N-bearing species and the mm3a (or/and mm3b)-peaking species, therefore their formation pathways likely involve NH3 (ammonia) or another major N-bearing molecule (e.g., Chen & Woon 2011), or need similar physical conditions appropriate to their production and/or sublimation, such as shocks (Peng et al. 2013). Moreover, although CH3CHO is only tentatively detected, it peaks in a similar location to HCOOCH3. Furthermore, like CH2CO, it exhibits extended emission from the NE to the SE tail, suggesting these three species may share a common or at least a related formation path.

The favoured model of hot molecular core chemistry so far is the gas-grain model, where frozen radicals, partly produced by photolysis, become mobile during the warm-up phase, and their reactions produce COMs (Markwick et al. 2000; Garrod et al. 2008). Three phases are usually modelled, the cold, warm-up, and hot molecular core stages. During these stages, different species are defined as zeroth-generation (e.g., CH3OH), first-generation (e.g., HCOOCH3), and second-generation organic molecules (see Herbst & van Dishoeck 2009). In such a scenario, since the critical densities are fairly similar for N- and O-bearing species, the distribution diversity of species in Orion-KL may also be explained by different initial compositions or different chemical “ages” (evolutionary stage, the time that the gas phase species has had to evolve from an initial composition after being released from ice mantles, Friedel & Snyder 2008). If that is the case, COMs like CH3OCH3/ CH3OH can act as chemical clocks, implying that the different substructures in BN/KL could have different chemical ages (e.g., Charnley et al. 1997; Wakelam et al. 2004).

In addition to grain-surface and gas-phase chemical processing, it is also possible that varying physical conditions, including temperature, density, and kinematics cause the differentiation in the spatial distributions of molecular line emission seen in the Orion-KL region. Probably due to the difference in the central protostars, the warm-up paces of different substructures vary. The modelling result from Garrod et al. (2008, especially their Fig. 8) is an example. In a particular substructure during the warm-up process (e.g., from 100 K to 200 K), the abundances of some molecules increase (e.g., HNCO, CH3CN, CH3OH) because of their evaporation from the grain surface to the gas phase,while the abundances of some large molecules cannot be synthesized on grains any longer because their precursor species have desorbed to the gas phase. They decrease (e.g., HCOOCH3, CH3OCH3) or start to decrease (CH3OH). Another possibility is that these species are destroyed by ion-molecule chemistry (e.g., by protonation via XH+ molecules), followed by dissociative recombination into multiple small fragments. In this scenario, the different emission peaks of different species can be explained by the higher temperature in HC (120−160 K) than in mm3a and mm3b (80−100 K), meaning that N-bearing species are still evaporating in HC but formation of molecules such as HCOOCH3 is stopped or it is dissociating there.

5.3. Chemistry in the outflow

Outflows from young stars can destroy grain material and/or liberate ices when they impact the surrounding cold matter, meaning that chemical reactions can be driven by the associated shocks even in cold gas (Herbst & van Dishoeck 2009). For years, the outflows in Orion-KL have been the main subject of chemical studies of this region (Wright et al. 1996 and references therein). Although COMs are less abundant or not detected in these outflows, the chemistry of simple molecules especially shock tracers can provide an alternative way to investigate the gas structure of the outflows.

Two outflows have been reported in Orion-KL, almost perpendicular to each other. In addition, along the NE–SW direction, a large-scale “integral-shaped” filament has been detected aligned with the low-velocity outflow (Wright et al. 1992; Lis et al. 1998; Di Francesco et al. 2008). To confirm whether the NE clump is associated with the filament or the outflow, we selected several widespread species, and use a Gaussian function to fit their line profile extracted from NE (Fig. 7). Broad line wings (C18O) and a second component (HNCO, SO2, and 34SO) with Vpeak ~ 20 − 23 km s-1 indicate that line emission in NE contains significant contribution from the outflow and is part of the plateau.

To study the chemistry in the outflows, we image the blue- and red-shifted gas of several shock-tracing molecules along the outflow direction (Fig. A.4). To avoid contamination from blending, we image as broad a velocity range as possible (labelled in each panel), though, −20 ~ + 30 km s-1 is the limit for most lines other than SO, CO, and 13CO. Because of the range limit and the limits of the 52′′ primary beam, the high-velocity outflow (30 − 100 km s-1) cannot be imaged in its entirety. However, the low-velocity outflow (~18 km s-1) with a NE−SW elongated structure is clearly detected, showing bipolar structure in the intensity-integrated map of H213CO\hbox{$\rm H_2^{13}CO$}. In addition, intensity-integrated maps of such molecules as OCS, 34SO2, SO, HNCO, CH2CO, CO, and 13CO all have a “butterfly” morphology, with blue-shifted radial velocities of the moving gas towards the NW and the red-shifted velocities in the SE. This morphology is exactly the same as found in SiO (Wright et al. 1995; Plambeck et al. 2009; Zapata et al. 2012; Niederhofer et al. 2012) and H2O maser observations (Greenhill et al. 2013) on scales of tens of AU. Whether this morphology is due to the bipolar lobes of the high-velocity outflow or to the expanding low-velocity outflow is still not clear. Possibilities are discussed (e.g., two bipolar outflows from a precessing binary, ballistic ejecta from a rotating disk, a single expanding wide-angle NE−SW outflow; Zapata et al. 2012). The asymmetry shape of the lobes (e.g., “U” shape blue-shifted and half “U” red-shifted lobes in the map of SO) is said to come from some density inhomogeneities in the surroundings (Zapata et al. 2012) or the interaction between outflow and the environment (Niederhofer et al. 2012).

Therefore, it can be suggested that a picture of explosive NW–SE outflow explains the excitation temperature gradient from the central condensations to the extended outflows in Orion-KL (Zapata et al. 2012): the decelerated bullets can be absorbed by the BN/KL cloud, and their kinetic energy can be transferred to thermal energy (Peng et al. 2012b); the closer a gas parcel is to the explosion centre (e.g., the closer encounter of BN, source I and maybe also source N, suggested by proper motion studies from Rodríguez et al. 2005; Gómez et al. 2005; 2008 and 3D modelling from Nissen et al. 2012), the higher the thermal energy available to affect the chemical properties of the gas in the HC and mm2.

Of all the shock-related molecules, S-bearing species are of special interest, not only because their abundance may be enhanced by shocks (Martin-Pintado et al. 1992; Pineau des Forets et al. 1993; Chernin et al. 1994; Bachiller & Pérez 1997; Schilke et al. 1997; Charnley et al. 1997; Bachiller et al. 2001; Viti et al. 2004; Garrod 2013), but also because they have been proposed as potential chemical clocks to date outflows (and hence their protostellar driving source; e.g., Charnley et al. 1997; Wakelam et al. 2004). The angular resolution of our study does not allow us to investigate the post/pre-shocked chemistry. In spite of that, we do find that some S-bearing molecules (e.g., SO2, 34SO2, and SO) have almost the same abundances in NE as in the central sources, which are higher than those in OF1N(S), even though we assume the temperatures in NE and OF1N(S) are equally low . The enhancement of their abundance may indicate stronger shocks in this direction than the rest of Orion-KL. On the other hand, although we cannot tell the precise ages of different substructures, we can compare the variations in abundance ratios SO2/ SO in our observations to the gas-grain modelling result. To simplify the case, we assume that the temperatures in all substructures are 100 K and that all substructures have the same density ~107 cm-3; and we estimate the value of SO2 (lines are possibly optically thick) by using 34SO2 and a ratio of 32S /34S = 22 (Wilson & Rood 1994). Comparing the observed SO2/ SO ratio to modelling of Wakelam et al. (2004)25 in all substructures (Fig. 11), we find that the HC has the highest SO2/ SO ratio, which suggests it is the most evolved substructure. Also, mm2, mm3a, and mm3b have lower ratios and are younger. The lowest ratios are in the outflows, which indicate the age of the low-velocity outflow should be ≪1 × 104 years, while the high-velocity outflow should be ≪1 × 103 years26.

thumbnail Fig. 11

Observed SO2/ SO ratio compared to the model prediction. The upper panel is adopted from Fig. 5 of Wakelam et al. (2004) (100 K, 107 cm-3), where different line types are from different grain component models. The lower panel is from our observed SO2/ SO ratio by assuming (1) all substructures have similar density 107 cm-3 and (2) NSO2/N34SO2 = 22 (Wilson & Rood 1994). The black solid line comes from the assumption that all substructures have a temperature close to 100 K, and the red dotted line comes from different temperatures derived in Sect. 4.1 (labelled in red).

The shocks could also be responsible for the observed chemical differentiation in COMs (e.g., by stripping ices from grains). The CR (together with mm3a and mm3b) is thought to be the place where icy grains are released into the gas phase by an outflow from the HC (Blake et al. 1987; Liu et al. 2002). Therefore, based on the reported association between the emissions of HCOOCH3 and the 2.12 μm vibrationally excited H2 (Lacombe et al. 2004), it has been suggested that shocks between the ISM and high-velocity gas “bullets” from the outflow (Zapata et al. 2009; Bally et al. 2011) explains the production of COMs, which has the same morphology as HCOOCH3 (Favre et al. 2011b). In a similar scenario, N-bearing COMs may be released to the gas phase north-east of the HC (e.g., HC3N, CH2CHCN), where the low-velocity outflow is impacting the ambient dusty material, and the weak emission /nondetection of these molecules along the high-velocity outflow may be due to lack of dusty material in the NW–SE direction (Friedel & Widicus Weaver 2012).

5.4. Search for COMs

The chemistry of Orion-KL is rich, not only in high-density tracers and shock tracers, but also with numerous transitions of COMs, which are less abundant than the other tracers and which have a less well understood formation mechanism.

Three possibilities have been discussed for the formation of the COMs: (1) ion-molecule chemistry involving large radicals (Ehrenfreund & Charnley 2000); (2) formation on dust grains and then released to the gas at higher temperatures in the later stages of star formation (Garrod et al. 2008; Herbst & van Dishoeck 2009); (3) a hybrid approach that COMs are ejected into the gas via efficient reactive desorption, after a sequence of gas-phase reactions between precursor species formed on grain surfaces (Vasyunin & Herbst 2013).In our dataset, we search for several COMs (Table 2) by using the synthetic fitting programme described in Sect. 3.2.2. HC7N, C6H, and CH3CHO are tentatively detected because of missing predicted lines. For the remaining species, if not taking the blending problem into account, all the predicted transitions are robustly detected. In addition, we find that saturated molecules are likely to be more abundant than unsaturated molecules (e.g., HC3N, C6H, HC7N). This indicates that these saturated species may be formed on dust grain surfaces by subsequent hydrogenation of their precursor species (such as CO, O, N or their more complex combinations).

Unfortunately, we lack the sensitivity to detect HCOOH (formic acid), which has been previously reported in Orion-KL by Liu et al. (2002). Line blending also prevents us from robustly detecting CH2OHCHO (glycolaldehyde) and (CH2OH)2 (ethylene glycol) in our data. We also fail to detect other prebiotic molecules, e.g., NH2CH2COOH (glycine; Garrod 2013), CH3COOH (acetic acid), NH2CH2CN (amino acetonitrile; Belloche et al. 2008), CH3CONH2 (acetamide; van Dishoeck 2009), and the ring molecules. More sensitive observations (e.g., with ALMA) are required to determine whether these molecules exist in the Orion-KL environment.

6. Conclusions

Based on the analysis of combined SMA and 30 m observations of Orion-KL, we have drawn the following conclusions:

  • 1.

    From interferometric observations with the SMA, Orion-KLhas been resolved into several continuum substructures withdifferent peak flux densities, at the angular resolutionof 3′′ (1200 AU at adistance of 414 pc). In addition to the previouswell-known compact continuum substructures like the HC andmm2, our data resolves the clump south-west of HC into twocores: mm3a and mm3b. In addition, we confirmed the detectionof strong continuum emissions (>5σ) from two resolved clumps (SR and NE), which lie along the axis of both the low-velocity outflow and the large-scale dusty filament.

  • 2.

    For the first time, we have combined interferometric and single-dish observations of Orion-KL, to correct missing short spacings, and achieved high sensitivity to all spatial scales. Covering a field of view of 52″, we mapped the distribution of all the identified species. In particular, we obtained the first maps of molecules such 34SO2, O13CS, HNCO, H213CO\hbox{$\rm H_2^{13}CO$}, 13CO, and CH2CO with both high resolution and sensitivity to spatial information on all scales. We also identified several transitions of low abundance (<10-8 with respect to H2) COMs, such as CH3COCH3 and CH3CH2OH, as well as made the tentative detection of CH3CHO and long carbon chains like C6H and HC7N.

  • 3.

    The Orion KL region exhibits clear chemical differentiation on the scales probed by the SMA-30 m observations. The emission from S-bearing molecules, CO isotopologues, and simple organic molecules are extended, covering not only the central condensations (HC, mm2, mm3a, and mm3b), but also the NE clump, the SR, and even the outflow regions. In comparison, the distributions of COMs are more concentrated and hard to group. The segregated emission peaks at either the HC (e.g., N-bearing) or CR (together with mm3a and mm3b, e.g., HCOOCH3, CH3OCH3) indicates different formation pathways for O-bearing and N-bearing molecules. However, some COMs peak in-between the HC and mm3a (CH3CH2OH), or have dual velocity dependent peaks (CH3OH), or share the same morphology as N-bearing species (CH3COCH3), which may indicate the linking of some formation pathways between O-bearing and N-bearing molecules. Moreover, line widths of the N-bearing, S-bearing species, HCOOCH3 and CH3OH vary, and so do the derived rotation temperatures, indicating they trace different gas.

  • 4.

    By studying the chemistry within outflows of Orion-KL, we found higher abundances of such shock tracers as 34SO2, SO2, and SO in the plateau of the low-velocity outflow (NE), indicating stronger shocks in this direction than the rest of Orion-KL.

  • 5.

    Molecular rotation temperatures and abundances show large gradience between central condensations and the outflow regions, indicating difference between hot molecular core and shock chemistry.

Online material

Appendix A

Table A.1

Identified emission lines from the SMA-30 m combined dataset.

Table A.2

Laboratory parameters of CH3CN and CH313CN\hbox{$\rm CH_3^{13}CN$} and the intensity integrated over the width of each line TB∫(υ)dυ\hbox{$\int T_{\rm B}({\upsilon})\rm d{\upsilon}$}, which is used for rotation diagrams in Fig. 8.

Table A.3

The laboratory parameters and the intensity integrated over the width of each line TB∫(υ)dυ\hbox{$\int T_{\rm B}({\upsilon}) {\rm d}{\upsilon}$}, which is used for rotation diagrams in Fig. 9.

Table A.4

Intensity integrated over the width of each line, corresponding to the transitions shown in Fig. A.3.

Table A.5

Column densities and abundances for O-bearing molecules and carbon chains from different substructures in Orion-KL denoted in Figs. 4 and 5.

Table A.6

Column densities and abundances for N-bearing molecules from different substructures in Orion-KL denoted in Figs. 4 and 5.

Table A.7

Column densities and abundances for S-bearing molecules from different substructures in Orion-KL denoted in Fig. 4.

thumbnail Fig. A.1

Spectrum from the HC, with identified strong lines marked. From 220.5 GHz to 220.8 GHz, CH3CN and CH313CN\hbox{$\rm CH_3^{13}CN$} are labelled in red and blue, respectively. COMs containing only C, H, O elements and other tentatively detections are labelled in Fig. A.2.

thumbnail Fig. A.2

Synthetic spectrum fitting of COMs towards their emission peaks (Vlsr of each species are corrected according to Vpeak from Fig. A.3). The black histograms are the observed spectra, overlaid with a best fit model spectrum for given uniform FWHM linewidth (△ V) (fit from Fig. A.3), Trot (assumed from an adjacent substructure), and Nmol (adjusted based on NT in Tables A.5I−A.7I) listed on top of each panel. Blue lines mark the central frequency of each transition. Uncertainties of the fitting to observations come from the assumption that under LTE, the candidate molecule lines are optically thin, and each species has the same line width at different transitions. Referenced molecular data are from CDMS/JPL (Sanchez-Monge 2011; Palau et al. 2011).

thumbnail Fig. A.2

continued.

thumbnail Fig. A.2

continued.

thumbnail Fig. A.2

continued.

thumbnail Fig. A.3

Line profiles of identified species from each continuum peak. In measuring the main Vpeak and ΔV of each line at each substructure, lines in green and notes in blue (in the form of “value(error)”) are given by the Gaussian fittings using Gildas software. Multi-Gaussian fittings are used to CH3CN, CH313CN\hbox{$\rm CH_3^{13}CN$}, HCOOCH3 (ν = 0), and CH3COCH3 due to blending, and to SO2, 34SO2, and SO due to the second velocity component (the second velocity component of HNCO measured from multi-Gaussian fittings are given in Fig. 7). Single Gaussian fittings are used to the rest lines, while lines whose Vpeak cannot be measured by Gaussian fittings owing to strong self-absorption are marked with “**”, and non-detections are not marked. Two red vertical lines in each panel mark the velocity range over which the emission from each species is integrated to make the distribution maps shown in Figs. 4 and 5.

thumbnail Fig. A.3

continued.

thumbnail Fig. A.3

continued.

thumbnail Fig. A.3

continued.

thumbnail Fig. A.3

continued.

thumbnail Fig. A.4

Line wing flux integration maps from the combined SMA-30 m data at 1.3 mm. The grey maps show the intensity integrated ranging through the main emission of their linewidth in Fig. A.3. Red and blue contours show the red-shifted and blue-shifted gas, with the intensity integrated as labelled. Yellow lines sketch the outflow directions. Black crosses denote the hotcore, SMA1, Source I, and Source N; white crosses denote the BN object and CR.

thumbnail Fig. A.5

Channel maps of the second velocity component (Vpeak ~ 22 km s-1) of the strongest unblended 34SO2 and SO2 line, as well as of SO(65 → 54).

thumbnail Fig. A.6

Channel maps of unblended CH3OH lines show multiple velocity-dependent emission peaks: 2.4 − 3.6 km s-1 towards SMA1, ~4.8 − 6 km s-1 towards HC, 7.2 − 9.6 km s-1 towards HC/mm3a/mm3b, 10.8 km s-1 towards mm3a/mm3b/mm2 and >12 km s-1 towards mm2. Green lines sketch the outflow directions. Black crosses denote the hotcore, SMA1, Source I, and Source N; white crosses denote the BN object and the CR.

9

This is a coarse cutoff for identifying the strong emission lines, corresponding to spontaneous emission rate Aul ~ 10−5.5 ~ −6. Taking the frequency resolution of our observations into consideration (~0.8 MHz), we found that 50% number possibility at certain rest frequency of a particular line has CDMS/JPL intensity >10-6.

10

The synthetic fitting program we use here is for line detection, but not for finding the best fit of column density or temperature to the observations. Since the synthetic fitting is performed with optically thin assumption, minor lines of a particular species which cannot fit as well as the majority may be optically thick.

11

The chosen velocity ranges are slightly larger than the FWHM of the lines, when accounting for the small variation in the peak velocity between different substructures.

12

Vpeak = 20.5 km s-1 in Esplugues et al. (2013).

13

The line wing of SO at ~7 km s-1 is broad, and its second velocity component is blended, so we cannot tell the origin of the shock precisely from our observations, Fig. A.5.

14

A COM that has a chain of carbon atoms linked together by single bonds and has rich hydrogen atoms filling the other bonding orbitals of the carbon atoms.

15

Two compounds with the same molecular formula but different functional groups (radicals) are called functional isomers.

16

Lines with J = 196 → 195 and J = 205 → 204 are detected, but neither J = 195 → 194 nor J = 204 → 203 are detected, so these potential detected lines are marked with “?” in Table A.1.

17

The K = 9 line is blended by strong 13CO (2 → 1) emission.

18

RADEX is a one-dimensional non-LTE radiative transfer code, providing an alternative to the widely used rotation diagram method. Without requiring the observation of many optically thin emission lines, it can be used to roughly constrain the excitation temperature in addition to the column density.

19

In reality, molecules do not distribute homogeneously in the clouds, and they are far from being homogeneous in density and temperature. The ultimate best-fit requires a sophisticated, fully 3D physico-chemo-LRT modelling, which is beyond the scope of our paper. Our iterative approach is between realism and feasibility of the modelling, which fits both o-/p- CH3CN well.

20

The detection of CH313CN(122→112)\hbox{$\rm CH_3^{13}CN~(12_2\rightarrow11_2)$} in NE is 4σ.

21

At around 100−150 K, water ice starts to be evaporated. However, in the line of sight, the envelope of the protostar may not have the same temperature at different radii, so ice may not be completely evaporated. Therefore, without knowing the real geometry of the source, we assume the dust absorption coefficient according to the “thin ice mantle” case. Moreover, this assumption is consistent with the modelling result in Gerner et al. (2014). In the extremely case, if we assume the ice is completely evaporated, the H2 column density derived from continuum will be 2−4 times lower than our current estimation.

22

In the extreme case, the ratio is 0.8−1, if assuming the ice mantle is completely evaporated.

23

MF1–5 are the HCOOCH3 emission peaks in Favre et al. (2011a), which coincide with mm3b (MF1), HC (MF2), mm3a (MF3), and mm2 (MF4–5) in our continuum.

24

Brouillet et al. (2013) resolves the CH3OCH3 multiplets and uses them to estimate temperatures as well as column densities. However, if each multiplet is treated as a single component, it would derive temperatures consistent with those we estimate.

25

In Wakelam et al. (2004), SO/H2 ratio is sensitive to the grain components. However, SO2/ SO ratios from different grain component models are similar at a particular time (yr), so we compare this ratio to the observations.

26

NE is part of the filamentary structure, so the age of the low-velocity outflow is implied from the upper limit ratio in SR. Due to the non-detection of SO2 (34SO2) in OF1N(S), the age of the high-velocity outflow is implied from the upper limit ratio in OF1N.

Acknowledgments

We would like to thank the SMA staff and IRAM 30 m staff for their helpful support during the reduction of the SMA data, the performance of the IRAM 30 m observations in service mode, Z. Y. Zhang and Y. Wang for helping with code development, for useful discussion, and the referee for constructive suggestions. This research made use of NASA’s Astrophysics Data System. The Submillimetre Array is a joint project between the Smithsonian Astrophysical Observatory and the Academia Sinica Institute of Astronomy and Astrophysics, and it is funded by the Smithsonian Institution and the Academia Sinica. S.F. acknowledges financial support by the European Community Seventh Framework Programme [FP7/2007-2013] under grant agreement No. 238258. D.S. acknowledges support by the Deutsche Forschungsgemeinschaft through SPP 1385: “The first ten million years of the solar system − a planetary materials approach” (SE 1962/1-2).

References

  1. Allen, D. A., & Burton, M. G. 1993, Nature, 363, 54 [NASA ADS] [CrossRef] [Google Scholar]
  2. Andersson, M., Askne, J., & Hjalmarson, A. 1984, A&A, 136, 243 [NASA ADS] [Google Scholar]
  3. Araya, E., Hofner, P., Kurtz, S., Bronfman, L., & DeDeo, S. 2005, ApJS, 157, 279 [NASA ADS] [CrossRef] [Google Scholar]
  4. Bachiller, R., & Pérez Gutiérrez, M. 1997, ApJ, 487, L93 [NASA ADS] [CrossRef] [Google Scholar]
  5. Bachiller, R., Pérez Gutiérrez, M., Kumar, M. S. N., & Tafalla, M. 2001, A&A, 372, 899 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  6. Bajaja, E., & van Albada, G. D. 1979, A&A, 75, 251 [NASA ADS] [Google Scholar]
  7. Bally, J., Cunningham, N. J., Moeckel, N., et al. 2011, ApJ, 727, 113 [NASA ADS] [CrossRef] [Google Scholar]
  8. Beckwith, S., Persson, S. E., Neugebauer, G., & Becklin, E. E. 1978, ApJ, 223, 464 [NASA ADS] [CrossRef] [Google Scholar]
  9. Bell, T. A., Cernicharo, J., Viti, S., et al. 2014, A&A, 564, A114 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  10. Belloche, A., Menten, K. M., Comito, C., et al. 2008, A&A, 482, 179 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  11. Belloche, A., Garrod, R. T., Müller, H. S. P., et al. 2009, A&A, 499, 215 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  12. Bergin, E. A., Snell, R. L., & Goldsmith, P. F. 1996, ApJ, 460, 343 [NASA ADS] [CrossRef] [Google Scholar]
  13. Bergin, E. A., Phillips, T. G., Comito, C., et al. 2010, A&A, 521, L20 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  14. Beuther, H., & Nissen, H. D. 2008, ApJ, 679, L121 [NASA ADS] [CrossRef] [Google Scholar]
  15. Beuther, H., Zhang, Q., Greenhill, L. J., et al. 2004, ApJ, 616, L31 [Google Scholar]
  16. Beuther, H., Zhang, Q., Greenhill, L. J., et al. 2005, ApJ, 632, 355 [NASA ADS] [CrossRef] [Google Scholar]
  17. Beuther, H., Zhang, Q., Reid, M. J., et al. 2006, ApJ, 636, 323 [NASA ADS] [CrossRef] [Google Scholar]
  18. Beuther, H., Churchwell, E. B., McKee, C. F., & Tan, J. C. 2007a, in Protostars and Planets V, eds. B. Reipurth, D. Jewitt & K. Keil, 165 [Google Scholar]
  19. Beuther, H., Leurini, S., Schilke, P., et al. 2007b, A&A, 466, 1065 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  20. Beuther, H., Linz, H., Bik, A., Goto, M., & Henning, T. 2010, A&A, 512, A29 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  21. Blake, G. A., Sutton, E. C., Masson, C. R., & Phillips, T. G. 1987, ApJ, 315, 621 [NASA ADS] [CrossRef] [Google Scholar]
  22. Blake, G. A., Mundy, L. G., Carlstrom, J. E., et al. 1996, ApJ, 472, L49 [NASA ADS] [CrossRef] [Google Scholar]
  23. Boucher, D., Burie, J., Bauer, A., Dubrulle, A., & Demaison, J. 1980, J. Phys. Chem. Ref. Data, 9, 659 [NASA ADS] [CrossRef] [Google Scholar]
  24. Bronfman, L., Nyman, L.-A., & May, J. 1996, A&AS, 115, 81 [NASA ADS] [Google Scholar]
  25. Brouillet, N., Despois, D., Baudry, A., et al. 2013, A&A, 550, A46 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  26. Caselli, P., Hasegawa, T. I., & Herbst, E. 1993, ApJ, 408, 548 [NASA ADS] [CrossRef] [Google Scholar]
  27. Chandler, C. J., & Wood, D. O. S. 1997, MNRAS, 287, 445 [NASA ADS] [Google Scholar]
  28. Chapman, J. F., Millar, T. J., Wardle, M., Burton, M. G., & Walsh, A. J. 2009, MNRAS, 394, 221 [NASA ADS] [CrossRef] [Google Scholar]
  29. Charnley, S. B. 2004, Adv. Space Res., 33, 23 [Google Scholar]
  30. Charnley, S. B., Tielens, A. G. G. M., & Rodgers, S. D. 1997, ApJ, 482, L203 [NASA ADS] [CrossRef] [Google Scholar]
  31. Chen, L., & Woon, D. E. 2011, J. Phys. Chem. A, 115, 5166 [CrossRef] [Google Scholar]
  32. Chernin, L. M., & Wright, M. C. H. 1996, ApJ, 467, 676 [NASA ADS] [CrossRef] [Google Scholar]
  33. Chernin, L. M., Masson, C. R., & Fuller, G. A. 1994, ApJ, 436, 741 [NASA ADS] [CrossRef] [Google Scholar]
  34. Chin, Y.-N., Henkel, C., Whiteoak, J. B., Langer, N., & Churchwell, E. B. 1996, A&A, 305, 960 [NASA ADS] [Google Scholar]
  35. Cohen, R. J., Gasiprong, N., Meaburn, J., & Graham, M. F. 2006, MNRAS, 367, 541 [NASA ADS] [CrossRef] [Google Scholar]
  36. Comito, C., Schilke, P., Phillips, T. G., et al. 2005, ApJS, 156, 127 [NASA ADS] [CrossRef] [Google Scholar]
  37. Crockett, N. R., Bergin, E. A., Neill, J. L., et al. 2014, ApJ, 787, 112 [NASA ADS] [CrossRef] [Google Scholar]
  38. Demyk, K., Wlodarczak, G., & Carvajal, M. 2008, A&A, 489, 589 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  39. Di Francesco, J., Johnstone, D., Kirk, H., MacKenzie, T., & Ledwosinska, E. 2008, ApJS, 175, 277 [NASA ADS] [CrossRef] [Google Scholar]
  40. Doeleman, S. S., Lonsdale, C. J., & Pelkey, S. 1999, ApJ, 510, L55 [NASA ADS] [CrossRef] [Google Scholar]
  41. Doi, T., O’Dell, C. R., & Hartigan, P. 2002, AJ, 124, 445 [NASA ADS] [CrossRef] [Google Scholar]
  42. Dougados, C., Lena, P., Ridgway, S. T., Christou, J. C., & Probst, R. G. 1993, ApJ, 406, 112 [NASA ADS] [CrossRef] [Google Scholar]
  43. Downes, D., Genzel, R., Becklin, E. E., & Wynn-Williams, C. G. 1981, ApJ, 244, 869 [NASA ADS] [CrossRef] [Google Scholar]
  44. Draine, B. T. 2011, Physics of the Interstellar and Intergalactic Medium (Princeton University Press) [Google Scholar]
  45. Ehrenfreund, P., & Charnley, S. B. 2000, ARA&A, 38, 427 [Google Scholar]
  46. Eisner, J. A., Plambeck, R. L., Carpenter, J. M., et al. 2008, ApJ, 683, 304 [NASA ADS] [CrossRef] [Google Scholar]
  47. Erickson, N. R., Goldsmith, P. F., Snell, R. L., et al. 1982, ApJ, 261, L103 [NASA ADS] [CrossRef] [Google Scholar]
  48. Esplugues, G. B., Tercero, B., Cernicharo, J., et al. 2013, A&A, 556, A143 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  49. Favre, C., Despois, D., Brouillet, N., et al. 2011a, A&A, 532, A32 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  50. Favre, C., Wootten, H. A., Remijan, A. J., et al. 2011b, ApJ, 739, L12 [NASA ADS] [CrossRef] [Google Scholar]
  51. Fish, V. L., Muehlbrad, T. C., Pratap, P., et al. 2011, ApJ, 729, 14 [NASA ADS] [CrossRef] [Google Scholar]
  52. Friedel, D. N., & Snyder, L. E. 2008, ApJ, 672, 962 [NASA ADS] [CrossRef] [Google Scholar]
  53. Friedel, D. N., & Widicus Weaver, S. L. 2011, ApJ, 742, 64 [NASA ADS] [CrossRef] [Google Scholar]
  54. Friedel, D. N., & Widicus Weaver, S. L. 2012, ApJS, 201, 17 [NASA ADS] [CrossRef] [Google Scholar]
  55. Friedel, D. N., Snyder, L. E., Remijan, A. J., & Turner, B. E. 2005, ApJ, 632, L95 [NASA ADS] [CrossRef] [Google Scholar]
  56. Garrod, R. T. 2013, ApJ, 765, 60 [Google Scholar]
  57. Garrod, R. T., Weaver, S. L. W., & Herbst, E. 2008, ApJ, 682, 283 [NASA ADS] [CrossRef] [Google Scholar]
  58. Gaume, R. A., Wilson, T. L., Vrba, F. J., Johnston, K. J., & Schmid-Burgk, J. 1998, ApJ, 493, 940 [NASA ADS] [CrossRef] [Google Scholar]
  59. Genzel, R., & Stutzki, J. 1989, ARA&A, 27, 41 [NASA ADS] [CrossRef] [Google Scholar]
  60. Genzel, R., Reid, M. J., Moran, J. M., & Downes, D. 1981, ApJ, 244, 884 [NASA ADS] [CrossRef] [Google Scholar]
  61. Gerner, T., Beuther, H., Semenov, D., et al. 2014, A&A, 563, A97 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  62. Goddi, C., Greenhill, L. J., Humphreys, E. M. L., Chandler, C. J., & Matthews, L. D. 2011a, ApJ, 739, L13 [NASA ADS] [CrossRef] [Google Scholar]
  63. Goddi, C., Humphreys, E. M. L., Greenhill, L. J., Chandler, C. J., & Matthews, L. D. 2011b, ApJ, 728, 15 [NASA ADS] [CrossRef] [Google Scholar]
  64. Goldsmith, P. F., & Langer, W. D. 1999, ApJ, 517, 209 [NASA ADS] [CrossRef] [Google Scholar]
  65. Goldsmith, P. F., Snell, R. L., Deguchi, S., Krotkov, R., & Linke, R. A. 1982, ApJ, 260, 147 [NASA ADS] [CrossRef] [Google Scholar]
  66. Gómez, L., Rodríguez, L. F., Loinard, L., et al. 2005, ApJ, 635, 1166 [NASA ADS] [CrossRef] [Google Scholar]
  67. Gómez, L., Rodríguez, L. F., Loinard, L., et al. 2008, ApJ, 685, 333 [NASA ADS] [CrossRef] [Google Scholar]
  68. Greaves, J. S., & White, G. J. 1991, A&AS, 91, 237 [NASA ADS] [Google Scholar]
  69. Greenhill, L. J., Gwinn, C. R., Schwartz, C., Moran, J. M., & Diamond, P. J. 1998, Nature, 396, 650 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  70. Greenhill, L. J., Gezari, D. Y., Danchi, W. C., et al. 2004, ApJ, 605, L57 [NASA ADS] [CrossRef] [Google Scholar]
  71. Greenhill, L. J., Goddi, C., Chandler, C. J., Matthews, L. D., & Humphreys, E. M. L. 2013, ApJ, 770, L32 [NASA ADS] [CrossRef] [Google Scholar]
  72. Guélin, M., Brouillet, N., Cernicharo, J., Combes, F., & Wootten, A. 2008, Ap&SS, 313, 45 [NASA ADS] [CrossRef] [Google Scholar]
  73. Hasegawa, T. I., & Herbst, E. 1993, MNRAS, 261, 83 [NASA ADS] [CrossRef] [Google Scholar]
  74. Herbst, E. 1981, Nature, 289, 656 [NASA ADS] [CrossRef] [Google Scholar]
  75. Herbst, E., & van Dishoeck, E. F. 2009, ARA&A, 47, 427 [NASA ADS] [CrossRef] [Google Scholar]
  76. Hildebrand, R. H. 1983, QJRAS, 24, 267 [NASA ADS] [Google Scholar]
  77. Ho, P. T. P., Moran, J. M., & Lo, K. Y. 2004, ApJ, 616, L1 [NASA ADS] [CrossRef] [Google Scholar]
  78. Hollis, J. M. 1982, ApJ, 260, 159 [NASA ADS] [CrossRef] [Google Scholar]
  79. Hollis, J. M., Lovas, F. J., & Jewell, P. R. 2000, ApJ, 540, L107 [NASA ADS] [CrossRef] [Google Scholar]
  80. Hollis, J. M., Lovas, F. J., Jewell, P. R., & Coudert, L. H. 2002, ApJ, 571, L59 [NASA ADS] [CrossRef] [Google Scholar]
  81. Hollis, J. M., Jewell, P. R., Lovas, F. J., & Remijan, A. 2004, ApJ, 613, L45 [NASA ADS] [CrossRef] [Google Scholar]
  82. Johansson, L. E. B., Andersson, C., Ellder, J., et al. 1984, A&A, 130, 227 [NASA ADS] [PubMed] [Google Scholar]
  83. Johnstone, D., & Bally, J. 1999, ApJ, 510, L49 [NASA ADS] [CrossRef] [Google Scholar]
  84. Kalenskii, S. V., Promislov, V. G., Alakoz, A., Winnberg, A. V., & Johansson, L. E. B. 2000, A&A, 354, 1036 [NASA ADS] [Google Scholar]
  85. Kwan, J., & Scoville, N. 1976, ApJ, 210, L39 [NASA ADS] [CrossRef] [Google Scholar]
  86. Laas, J. C., Garrod, R. T., Herbst, E., & Widicus Weaver, S. L. 2011, ApJ, 728, 71 [NASA ADS] [CrossRef] [Google Scholar]
  87. Lacombe, F., Gendron, E., Rouan, D., et al. 2004, A&A, 417, L5 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  88. Lee, J.-K., & Burton, M. G. 2000, MNRAS, 315, 11 [NASA ADS] [CrossRef] [Google Scholar]
  89. Lee, C. W., & Cho, S.-H. 2002, J. Kor. Astron. Soc., 35, 187 [Google Scholar]
  90. Lerate, M. R., Yates, J., Viti, S., et al. 2008, MNRAS, 387, 1660 [NASA ADS] [CrossRef] [Google Scholar]
  91. Lis, D. C., Serabyn, E., Keene, J., et al. 1998, ApJ, 509, 299 [Google Scholar]
  92. Liu, S.-Y., Girart, J. M., Remijan, A., & Snyder, L. E. 2002, ApJ, 576, 255 [NASA ADS] [CrossRef] [Google Scholar]
  93. Loren, R. B., & Mundy, L. G. 1984, ApJ, 286, 232 [NASA ADS] [CrossRef] [Google Scholar]
  94. Lovas, F. J. 2004, Phys. Chem. Ref., 33, 117 [Google Scholar]
  95. Markwick, A. J., Millar, T. J., & Charnley, S. B. 2000, ApJ, 535, 256 [NASA ADS] [CrossRef] [Google Scholar]
  96. Martin-Pintado, J., Bachiller, R., & Fuente, A. 1992, A&A, 254, 315 [NASA ADS] [Google Scholar]
  97. Masson, C. R., Claussen, M. J., Lo, K. Y., et al. 1985, ApJ, 295, L47 [NASA ADS] [CrossRef] [Google Scholar]
  98. Masson, C. R., Lo, K. Y., Phillips, T. G., et al. 1987, ApJ, 319, 446 [NASA ADS] [CrossRef] [Google Scholar]
  99. Matthews, L. D., Greenhill, L. J., Goddi, C., et al. 2010, ApJ, 708, 80 [NASA ADS] [CrossRef] [Google Scholar]
  100. McCarthy, M. C., Gottlieb, C. A., Gupta, H., & Thaddeus, P. 2006, ApJ, 652, L141 [NASA ADS] [CrossRef] [Google Scholar]
  101. Meier, D. S., & Turner, J. L. 2005, ApJ, 618, 259 [NASA ADS] [CrossRef] [Google Scholar]
  102. Menten, K. M., & Reid, M. J. 1995, ApJ, 445, L157 [NASA ADS] [CrossRef] [Google Scholar]
  103. Menten, K. M., Reid, M. J., Forbrich, J., & Brunthaler, A. 2007, A&A, 474, 515 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  104. Miotello, A., Testi, L., Lodato, G., et al. 2014, A&A, 567, A32 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  105. Müller, H. S. P., Schlöder, F., Stutzki, J., & Winnewisser, G. 2005, J. Mol. Struct., 742, 215 [NASA ADS] [CrossRef] [Google Scholar]
  106. Mundy, L. G., Scoville, N. Z., Baath, L. B., Masson, C. R., & Woody, D. P. 1986, ApJ, 304, L51 [NASA ADS] [CrossRef] [Google Scholar]
  107. Murata, Y., Kawabe, R., Ishiguro, M., et al. 1992, PASJ, 44, 381 [NASA ADS] [Google Scholar]
  108. Myers, P. C., Linke, R. A., & Benson, P. J. 1983, ApJ, 264, 517 [NASA ADS] [CrossRef] [Google Scholar]
  109. Neill, J. L., Steber, A. L., Muckle, M. T., et al. 2011, J. Phys. Chem. A, 115, 6472 [CrossRef] [Google Scholar]
  110. Niederhofer, F., Humphreys, E. M. L., & Goddi, C. 2012, A&A, 548, A69 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  111. Nissen, H. D., Gustafsson, M., Lemaire, J. L., et al. 2007, A&A, 466, 949 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  112. Nissen, H. D., Cunningham, N. J., Gustafsson, M., et al. 2012, A&A, 540, A119 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  113. Norris, R. P. 1984, MNRAS, 207, 127 [NASA ADS] [Google Scholar]
  114. Nummelin, A., Bergman, P., Hjalmarson, Å., et al. 2000, ApJS, 128, 213 [NASA ADS] [CrossRef] [Google Scholar]
  115. Olmi, L., Cesaroni, R., & Walmsley, C. M. 1993, BAAS, 25, 1315 [NASA ADS] [Google Scholar]
  116. Olofsson, A. O. H., Persson, C. M., Koning, N., et al. 2007, A&A, 476, 791 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  117. Ossenkopf, V., & Henning, T. 1994, A&A, 291, 943 [NASA ADS] [Google Scholar]
  118. Palau, A., Fuente, A., Girart, J. M., et al. 2011, ApJ, 743, L32 [NASA ADS] [CrossRef] [Google Scholar]
  119. Peng, T.-C., Despois, D., Brouillet, N., Parise, B., & Baudry, A. 2012a, A&A, 543, A152 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  120. Peng, T.-C., Zapata, L. A., Wyrowski, F., Güsten, R., & Menten, K. M. 2012b, A&A, 544, L19 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  121. Peng, T.-C., Despois, D., Brouillet, N., et al. 2013, A&A, 554, A78 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  122. Persson, C. M., Olofsson, A. O. H., Koning, N., et al. 2007, A&A, 476, 807 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  123. Pickett, H. M., Poynter, R. L., Cohen, E. A., et al. 1998, J. Quant. Spectr. Rad. Transf., 60, 883 [NASA ADS] [CrossRef] [Google Scholar]
  124. Pineau des Forets, G., Roueff, E., Schilke, P., & Flower, D. R. 1993, MNRAS, 262, 915 [NASA ADS] [CrossRef] [Google Scholar]
  125. Plambeck, R. L., Wright, M. C. H., Welch, W. J., et al. 1982, ApJ, 259, 617 [NASA ADS] [CrossRef] [Google Scholar]
  126. Plambeck, R. L., Wright, M. C. H., Friedel, D. N., et al. 2009, ApJ, 704, L25 [NASA ADS] [CrossRef] [Google Scholar]
  127. Plume, R., Bergin, E. A., Phillips, T. G., et al. 2012, ApJ, 744, 28 [NASA ADS] [CrossRef] [Google Scholar]
  128. Purcell, C. R., Balasubramanyam, R., Burton, M. G., et al. 2006, MNRAS, 367, 553 [NASA ADS] [CrossRef] [Google Scholar]
  129. Reid, M. J., Menten, K. M., Greenhill, L. J., & Chandler, C. J. 2007, ApJ, 664, 950 [NASA ADS] [CrossRef] [Google Scholar]
  130. Remijan, A. J., Leigh, D. P., Markwick-Kemper, A. J., & Turner, B. E. 2008, ArXiv e-prints [arXiv:0802.2273] [Google Scholar]
  131. Rice, C. A., & Maier, J. P. 2013, J. Phys. Chem. A, 117, 5559 [CrossRef] [Google Scholar]
  132. Rizzo, J. R., Martín-Pintado, J., & de Vicente, P. 2001, in Highlights of Spanish astrophysics II, eds. J. Zamorano, J. Gorgas, & J. Gallego, 397 [Google Scholar]
  133. Rodríguez, L. F., Poveda, A., Lizano, S., & Allen, C. 2005, ApJ, 627, L65 [NASA ADS] [CrossRef] [Google Scholar]
  134. Sanchez-Monge, A. 2011, Ph.D. Thesis, University of Barcelona [Google Scholar]
  135. Sandstrom, K. M., Peek, J. E. G., Bower, G. C., Bolatto, A. D., & Plambeck, R. L. 2007, ApJ, 667, 1161 [NASA ADS] [CrossRef] [Google Scholar]
  136. Sault, R. J., Teuben, P. J., & Wright, M. C. H. 1995, in Astronomical Data Analysis Software and Systems IV, eds. R. A. Shaw, H. E. Payne, & J. J. E. Hayes, ASP Conf. Ser., 77, 433 [Google Scholar]
  137. Schilke, P., Walmsley, C. M., Pineau des Forets, G., & Flower, D. R. 1997, A&A, 321, 293 [NASA ADS] [Google Scholar]
  138. Schilke, P., Benford, D. J., Hunter, T. R., Lis, D. C., & Phillips, T. G. 2001, ApJS, 132, 281 [NASA ADS] [CrossRef] [Google Scholar]
  139. Schreyer, K., & Henning, T. 1999, in The Orion Complex Revisited, ASP Conf. Ser., 99, 1999 [Google Scholar]
  140. Schuller, F., Menten, K. M., Contreras, Y., et al. 2009, A&A, 504, 415 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  141. Scoville, N. Z., Hall, D. N. B., Ridgway, S. T., & Kleinmann, S. G. 1982, ApJ, 253, 136 [NASA ADS] [CrossRef] [Google Scholar]
  142. Snyder, L. E., Lovas, F. J., Mehringer, D. M., et al. 2002, ApJ, 578, 245 [NASA ADS] [CrossRef] [Google Scholar]
  143. Snyder, L. E., Lovas, F. J., Hollis, J. M., et al. 2005, ApJ, 619, 914 [NASA ADS] [CrossRef] [Google Scholar]
  144. Sugai, H., Usuda, T., Kataza, H., et al. 1994, ApJ, 420, 746 [NASA ADS] [CrossRef] [Google Scholar]
  145. Sutton, E. C., Blake, G. A., Masson, C. R., & Phillips, T. G. 1985, ApJS, 58, 341 [NASA ADS] [CrossRef] [Google Scholar]
  146. Sutton, E. C., Peng, R., Danchi, W. C., et al. 1995, ApJS, 97, 455 [NASA ADS] [CrossRef] [Google Scholar]
  147. Tan, J. C., Beltran, M. T., Caselli, P., et al. 2014, in Protostars and Planets VI, eds. H. Beuther, R. S. Klessen, C. P. Dullemond, & T. Henning (Tucson: University of Arizona Press), 149 [Google Scholar]
  148. Tang, Y.-W., Ho, P. T. P., Koch, P. M., & Rao, R. 2010, ApJ, 717, 1262 [NASA ADS] [CrossRef] [Google Scholar]
  149. Taylor, K. N. R., Storey, J. W. V., Sandell, G., Williams, P. M., & Zealey, W. J. 1984, Nature, 311, 236 [NASA ADS] [CrossRef] [Google Scholar]
  150. Tercero, B., Cernicharo, J., Pardo, J. R., & Goicoechea, J. R. 2010, A&A, 517, A96 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  151. Thorwirth, S. 2001, Ph.D. Thesis, I. Physikalisches Institut Universität zu Köln, Germany [Google Scholar]
  152. Tideswell, D. M., Fuller, G. A., Millar, T. J., & Markwick, A. J. 2010, A&A, 510, A85 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  153. Turner, B. E. 1989, ApJS, 70, 539 [NASA ADS] [CrossRef] [Google Scholar]
  154. Turner, B. E. 1991, ApJS, 76, 617 [NASA ADS] [CrossRef] [Google Scholar]
  155. Turner, B. E., Terzieva, R., & Herbst, E. 1999, ApJ, 518, 699 [NASA ADS] [CrossRef] [Google Scholar]
  156. van der Tak, F. F. S., Black, J. H., Schöier, F. L., Jansen, D. J., & van Dishoeck, E. F. 2007, A&A, 468, 627 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  157. van Dishoeck, E. F. 2009, Astrochemistry of Dense Protostellar and Protoplanetary Environments, eds. H. A. Thronson, M. Stiavelli, & A. Tielens, 187 [Google Scholar]
  158. Vasyunin, A. I., & Herbst, E. 2013, ApJ, 769, 34 [Google Scholar]
  159. Viti, S., Codella, C., Benedettini, M., & Bachiller, R. 2004, MNRAS, 350, 1029 [NASA ADS] [CrossRef] [Google Scholar]
  160. Wakelam, V., Caselli, P., Ceccarelli, C., Herbst, E., & Castets, A. 2004, A&A, 422, 159 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  161. Wang, S., Bergin, E. A., Crockett, N. R., et al. 2011, A&A, 527, A95 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  162. Widicus Weaver, S. L., & Friedel, D. N. 2012, ApJS, 201, 16 [NASA ADS] [CrossRef] [Google Scholar]
  163. Wilner, D. J., Wright, M. C. H., & Plambeck, R. L. 1994, ApJ, 422, 642 [NASA ADS] [CrossRef] [Google Scholar]
  164. Wilson, T. L., & Rood, R. 1994, ARA&A, 32, 191 [NASA ADS] [CrossRef] [Google Scholar]
  165. Wilson, T. L., Gaume, R. A., Gensheimer, P., & Johnston, K. J. 2000, ApJ, 538, 665 [NASA ADS] [CrossRef] [Google Scholar]
  166. Wilson, T. L., Rohlfs, K., & Hüttemeister, S. 2009, Tools of Radio Astronomy (Springer-Verlag) [Google Scholar]
  167. Wilson, T. L., Muders, D., Dumke, M., Henkel, C., & Kawamura, J. H. 2011, ApJ, 728, 61 [NASA ADS] [CrossRef] [Google Scholar]
  168. Woody, D. P., Scott, S. L., Scoville, N. Z., et al. 1989, ApJ, 337, L41 [NASA ADS] [CrossRef] [Google Scholar]
  169. Wright, M. C. H., & Plambeck, R. L. 1983, ApJ, 267, L115 [NASA ADS] [CrossRef] [Google Scholar]
  170. Wright, M., Sandell, G., Wilner, D. J., & Plambeck, R. L. 1992, ApJ, 393, 225 [NASA ADS] [CrossRef] [Google Scholar]
  171. Wright, M. C. H., Plambeck, R. L., & Wilner, D. J. 1995, in NCSA Astronomy Data Image Library, 2 [Google Scholar]
  172. Wright, M. C. H., Plambeck, R. L., & Wilner, D. J. 1996, ApJ, 469, 216 [NASA ADS] [CrossRef] [Google Scholar]
  173. Wynn-Williams, C. G., Genzel, R., Becklin, E. E., & Downes, D. 1984, ApJ, 281, 172 [NASA ADS] [CrossRef] [Google Scholar]
  174. Zapata, L. A., Schmid-Burgk, J., Ho, P. T. P., Rodríguez, L. F., & Menten, K. M. 2009, ApJ, 704, L45 [NASA ADS] [CrossRef] [Google Scholar]
  175. Zapata, L. A., Schmid-Burgk, J., & Menten, K. M. 2011, A&A, 529, A24 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  176. Zapata, L. A., Rodríguez, L. F., Schmid-Burgk, J., et al. 2012, ApJ, 754, L17 [NASA ADS] [CrossRef] [Google Scholar]
  177. Zeng, Q., Mao, P. Q., & Pei, C. C. 2006, Microwave spectrum of astrophysics diagnosis (Chinese edition) [Google Scholar]
  178. Zinchenko, I., Henkel, C., & Mao, R. Q. 2000, A&A, 361, 1079 [NASA ADS] [Google Scholar]
  179. Zinnecker, H., & Yorke, H. W. 2007, ARA&A, 45, 481 [NASA ADS] [CrossRef] [Google Scholar]
  180. Ziurys, L. M., & McGonagle, D. 1993, ApJS, 89, 155 [NASA ADS] [CrossRef] [Google Scholar]
  181. Zuckerman, B., Kuiper, T. B. H., & Rodriguez Kuiper, E. N. 1976, ApJ, 209, L137 [NASA ADS] [CrossRef] [Google Scholar]

All Tables

Table 1

Properties of substructures, which are denoted on the continuum image obtained from SMA observations at 1.3 mm (Fig. 2).

In the text
Table 2

Identification of saturated COMs and complex carbon chains in Orion-KL.

In the text
Table 3

Rotation temperature sets for each substructure derived from species, each of which has >4 transitions with significantly different Eu/kB detected in our data.

In the text
Table 4

Optical depth and abundance ratios for CO, 13CO, OCS, and CH3CN with respect to their rare isotopologues in each substructure of Orion KL.

In the text
Table A.1

Identified emission lines from the SMA-30 m combined dataset.

In the text
Table A.2

Laboratory parameters of CH3CN and CH313CN\hbox{$\rm CH_3^{13}CN$} and the intensity integrated over the width of each line TB∫(υ)dυ\hbox{$\int T_{\rm B}({\upsilon})\rm d{\upsilon}$}, which is used for rotation diagrams in Fig. 8.

In the text
Table A.3

The laboratory parameters and the intensity integrated over the width of each line TB∫(υ)dυ\hbox{$\int T_{\rm B}({\upsilon}) {\rm d}{\upsilon}$}, which is used for rotation diagrams in Fig. 9.

In the text
Table A.4

Intensity integrated over the width of each line, corresponding to the transitions shown in Fig. A.3.

In the text
Table A.5

Column densities and abundances for O-bearing molecules and carbon chains from different substructures in Orion-KL denoted in Figs. 4 and 5.

In the text
Table A.6

Column densities and abundances for N-bearing molecules from different substructures in Orion-KL denoted in Figs. 4 and 5.

In the text
Table A.7

Column densities and abundances for S-bearing molecules from different substructures in Orion-KL denoted in Fig. 4.

In the text

All Figures

thumbnail Fig. 1

Amplitude in Jy versus the projected baseline showing the combination of the interferometer and single-dish data, from the upper sideband (top) to lower sideband (bottom). Red and blue dots present data from the SMA on Feb. 15, 2005 and Feb. 19, 2005, respectively, showing the lack of baselines shorter than 10 kλ. Black dots are data converted from 30 m single-dish observations, which fill in the missing short spacing information.

In the text
thumbnail Fig. 2

Substructures resolved by SMA-only observations at a spatial resolution of ~1200 AU. White contours show the 1.3 mm continuum emission at −5σ, 5σ, 15σ, 25σ, 60σ rms levels with the σ = 0.04 Jy beam-1. The yellow circle denotes the primary beam of SMA at 1.3 mm. Red circles denote the peaks of hot core (HC), mm2, mm3a, mm3b, the southern region (SR), north-east clump (NE), the NW and SE parts of the high-velocity outflow (OF1N, OF1S). Yellow crosses denote the BN object and the compact ridge (CR). The beam in the bottom left corner is from the SMA-only data. Colourmap shows the brightness (in counts per 400 s) of shocked H2 emission (Nissen et al. 2007). Corresponding to the yellow square, the insert panel shows the HC continuum from the SMA at 1.3 mm in detail as colourmap, with black contours of the 865 μm continuum emission at a spatial resolution of ~300 AU from Beuther et al. (2004) overlaid.
In the text
thumbnail Fig. 3

Spectra taken towards selected positions (denoted by red circles in Fig. 2) after imaging the whole data cube. The spectral resolution is smoothed to 1.2 km s-1 after the combination of SMA and 30 m data, and strong emission lines are labelled. A blow-up figure of the spectrum in the HC is Fig. A.1.

In the text
thumbnail Fig. 4

Intensity distribution maps of transitions from molecules containing <6 atoms, which are detected in the combined SMA-30 m data at 1.3 mm (corresponding quantum numbers are listed in Table A.1, with “†” marks). The intensities have been derived by integrating the line emission over the velocity range shown in Fig. A.3. The filled beam in the bottom left corner is from SMA-30 m data. White contours show the continuum from the SMA-only data (at −5σ, 5σ, 15σ, 25σ, and 60σ levels). Purple contours show ± 1σ levels of the molecular emission (solid contours indicate positive flux, and dashed contours indicate negative flux). Green lines in the SO and CO maps sketch the outflow directions. The white crosses denote the BN object and the CR, and the black crosses denote the positions of the hotcore, Source I, Source N, and SMA1, as in Fig. 2. All images have different colour scales (in Jy beam-1 km s-1), increasing from black to white, which are optimized to emphasize the features in the distribution of each molecules.

In the text
thumbnail Fig. 5

Intensity distribution maps of transitions from COMs and carbon chains detected in the combined SMA-30 m data at 1.3 mm (corresponding quantum numbers are list in Table A.1, with “‡” marks). The intensities have been derived by integrating the line emission over the velocity range shown in Fig. A.3. The filled beam in the bottom left corner is from SMA-30 m data. White contours show the continuum from the SMA-only data (at −5σ, 5σ, 15σ, 25σ, and 60σ levels). Purple contours show ± 1σ levels of the molecular emission (solid contours indicate positive flux, and dashed contours indicate negative flux). The white crosses denote the BN object and the CR, and the black crosses denote the positions of the hotcore, Source I, Source N, and SMA1, as in Fig. 2. All images have different colour scales (in Jy beam-1 kms-1), increasing from black to white, which are optimized to emphasize the features in the distribution of each molecules.

In the text
thumbnail Fig. 6

Lines that only have one transition with low specific intensity (≤10 Jy beam-1) in our data, fitted with synthetic spectrum from their emission peaks.

In the text
thumbnail Fig. 7

Gaussian fitting to the line profile of 13CO, C18O, HNCO, SO2, and 34SO2 extracted from NE. Outflow signatures are seen in the broad line wings and the second velocity component in the HNCO, SO2, and 34SO2 line profile.

In the text
thumbnail Fig. 8

Panel 1): CH3CN spectrum towards the HC in black, LTE model fit in dashed purple, and fitting with optical depth correction in filled red. Panels 2)−6): rotation diagram of CH3CN derived for each substructure, with dots for p-CH3CN and triangles for o-CH3CN. Black fittings are only for the p-lines when assuming they are optically thin, and red fittings are for both o- and p-lines by optical depth correction. Panel 7): CH313CN\hbox{$\rm CH_3^{13}CN$} spectrum towards the HC in black and the LTE model fit in red. Panel 8): rotation diagram of CH313CN\hbox{$\rm CH_3^{13}CN$} in HC with black dots (p-) and triangles (o-) from observation, and fitting is o-lines excluded by assuming lines are optically thin. For lines without detection, an upper limit equal to the 3σ rms is shown as arrow. The estimated temperature and total column density from each fitting is indicated in each panel. Errors are derived from scatter in the data points.

In the text
thumbnail Fig. 9

Rotation diagrams of the N-, O-, and S-bearing species with multiple unblended transitions detection in HC, mm2, mm3a, and mm3b. Panels in row I show two states of HCOOCH3 lines, with the blue and black dots from observation of ground state (ν = 0) and torsionally excited state (ν = 1) lines, respectively. With the optically thin assumption, fittings for each state are plotted in blue or black, respectively, and fittings for all the transitions are plotted in red. Non-detection of HCOOCH3 lines are not shown. Panels in rows II–VI show fittings with the optically thin assumption, with 3σ upper limits from non-detections plotted as arrows. Blue dashed lines in row III are fittings with upper limits included. The estimated temperature and total column density from each fitting is indicated in each panel. Errors are derived from scatters in the data points.

In the text
thumbnail Fig. 10

Molecular column densities (panels in the left column) and abundances (panels in the right column) towards 8 positions in Orion-KL. The molecular abundances of each species with respect to H2 are converted from C18O, assuming a constant NC18O/NH2 ~ 1.79 × 10-7 ratio. Column densities and abundances with the uncertainties are measured as mentioned in Sect. 4.4 and Tables A.5–A.7. Coloured solid lines show the differentiation for each isotopologue calculated from optically thin assumption (arrows highlight the upper limits), while dashed lines show the differentiation calculated with optical depth correction from Eq. (10). For abundant molecules (e.g., HNCO, SO, SO2, CH3OH) which we have not measured their line optical depths, their densities could be underestimated by a factor of 7−10.
In the text
thumbnail Fig. 11

Observed SO2/ SO ratio compared to the model prediction. The upper panel is adopted from Fig. 5 of Wakelam et al. (2004) (100 K, 107 cm-3), where different line types are from different grain component models. The lower panel is from our observed SO2/ SO ratio by assuming (1) all substructures have similar density 107 cm-3 and (2) NSO2/N34SO2 = 22 (Wilson & Rood 1994). The black solid line comes from the assumption that all substructures have a temperature close to 100 K, and the red dotted line comes from different temperatures derived in Sect. 4.1 (labelled in red).

In the text
thumbnail Fig. A.1

Spectrum from the HC, with identified strong lines marked. From 220.5 GHz to 220.8 GHz, CH3CN and CH313CN\hbox{$\rm CH_3^{13}CN$} are labelled in red and blue, respectively. COMs containing only C, H, O elements and other tentatively detections are labelled in Fig. A.2.
In the text
thumbnail Fig. A.2

Synthetic spectrum fitting of COMs towards their emission peaks (Vlsr of each species are corrected according to Vpeak from Fig. A.3). The black histograms are the observed spectra, overlaid with a best fit model spectrum for given uniform FWHM linewidth (△ V) (fit from Fig. A.3), Trot (assumed from an adjacent substructure), and Nmol (adjusted based on NT in Tables A.5I−A.7I) listed on top of each panel. Blue lines mark the central frequency of each transition. Uncertainties of the fitting to observations come from the assumption that under LTE, the candidate molecule lines are optically thin, and each species has the same line width at different transitions. Referenced molecular data are from CDMS/JPL (Sanchez-Monge 2011; Palau et al. 2011).

In the text
thumbnail Fig. A.2

continued.
In the text
thumbnail Fig. A.2

continued.
In the text
thumbnail Fig. A.2

continued.
In the text
thumbnail Fig. A.3

Line profiles of identified species from each continuum peak. In measuring the main Vpeak and ΔV of each line at each substructure, lines in green and notes in blue (in the form of “value(error)”) are given by the Gaussian fittings using Gildas software. Multi-Gaussian fittings are used to CH3CN, CH313CN\hbox{$\rm CH_3^{13}CN$}, HCOOCH3 (ν = 0), and CH3COCH3 due to blending, and to SO2, 34SO2, and SO due to the second velocity component (the second velocity component of HNCO measured from multi-Gaussian fittings are given in Fig. 7). Single Gaussian fittings are used to the rest lines, while lines whose Vpeak cannot be measured by Gaussian fittings owing to strong self-absorption are marked with “**”, and non-detections are not marked. Two red vertical lines in each panel mark the velocity range over which the emission from each species is integrated to make the distribution maps shown in Figs. 4 and 5.
In the text
thumbnail Fig. A.3

continued.
In the text
thumbnail Fig. A.3

continued.
In the text
thumbnail Fig. A.3

continued.
In the text
thumbnail Fig. A.3

continued.
In the text
thumbnail Fig. A.4

Line wing flux integration maps from the combined SMA-30 m data at 1.3 mm. The grey maps show the intensity integrated ranging through the main emission of their linewidth in Fig. A.3. Red and blue contours show the red-shifted and blue-shifted gas, with the intensity integrated as labelled. Yellow lines sketch the outflow directions. Black crosses denote the hotcore, SMA1, Source I, and Source N; white crosses denote the BN object and CR.
In the text
thumbnail Fig. A.5

Channel maps of the second velocity component (Vpeak ~ 22 km s-1) of the strongest unblended 34SO2 and SO2 line, as well as of SO(65 → 54).
In the text
thumbnail Fig. A.6

Channel maps of unblended CH3OH lines show multiple velocity-dependent emission peaks: 2.4 − 3.6 km s-1 towards SMA1, ~4.8 − 6 km s-1 towards HC, 7.2 − 9.6 km s-1 towards HC/mm3a/mm3b, 10.8 km s-1 towards mm3a/mm3b/mm2 and >12 km s-1 towards mm2. Green lines sketch the outflow directions. Black crosses denote the hotcore, SMA1, Source I, and Source N; white crosses denote the BN object and the CR.

In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
