1. Introduction

Primeval galaxies in the process of forming their first generation of stars were predicted to generate a diffuse extragalactic background light (EBL) in the optical and near-infrared (NIR; Partridge & Peebles 1967), later on extended to the far infrared (FIR; Low & Tucker 1968; Kaufman 1976). Puget et al. (1996) reported the first measurement of the cosmic IR background (CIRB), an isotropic IR signal appearing in the all-sky maps of the FIRAS experiment onboard COBE with an integrated intensity of ~30 ± 5 nWm-2sr-1 between 100 and 1000 μm. The CIRB represents about the half of the EBL (Dole et al. 2006; Lagache et al. 2005). Although it sums up only ~2.3% of the intensity of the cosmic microwave background (CMB), it is the strongest emission due to galaxies so that it represents the net energetic budget of galaxies. The cosmic UV-optical background and CIRB are expected to be generated by the energy produced through stellar nucleosynthesis and, for a minor fraction, by black-hole accretion and emission from the diffuse intergalactic medium (Hauser & Dwek 2001). The contribution of accretion in the form of active galactic nuclei emission is expected to represent a fraction of ~15% of the CIRB (Jauzac et al. 2011). Since the discovery of the CIRB, a major issue in observational cosmology has been to identify the individual sources responsible for this diffuse light which contains the net energetic budget of nucleosynthesis integrated over cosmic time, hence the detailed information on how and when stars formed in galaxies.

Several factors make the correct identification of sources a challenge when multi-wavelength data of extragalactic objects are combined. The resolution θ of a telescope having a collecting mirror of a diameter D is limited by diffraction, i.e. θ ~ λ/D, a problem particularly difficult to treat for FIR and submillimetre instrumentation (λ 100 μm). It is possible to attack this problem by constructing larger collecting surfaces for the telescopes (as well as instruments with smaller detection elements) until the desired angular resolution is reached. However, this increases substantially the associated costs that scale with the size of the telescope mirror to the 22.5 power (van Belle et al. 2004), as well as rocket limitations that prevent the launch of big telescopes into space. Poor spatial resolution plays a major role in confusion noise, which can be defined as the uncertainty in the measurement of the flux of a point source owing to the variance of the underlying background induced by extremely faint sources or by the contamination of nearby point sources. The origin of the background may be instrumental (caused by the thermal radiation of the telescope itself), intrinsically diffuse (caused by the interstellar medium, e.g. galactic cirrus, see Helou & Beichman 1990) or may be the result of the accumulated light of faint objects (the EBL).

The launch of the Herschel satellite (Pilbratt et al. 2010) has opened a new window on the FIR universe by allowing the detection of individual galaxies down to uniquely faint limits with deep extragalactic surveys (for a comprehensive review see Lutz 2014). Thanks to its 100500 μm coverage, Herschel provides the best insight into the sources responsible for the peak emission of the CIRB. Although it is the largest telescope ever sent into space, its 3.5 m-class observatory does suffer from the so-called confusion limit, and the depth of these extragalactic surveys is essentially limited by the fluctuations of the signal due to a sea of unresolved sources, together with the blending from bright neighbours (Berta et al. 2010; Oliver et al. 2010; Nguyen et al. 2010). Confusion is inherent to IR data, particularly in the 250–500 μm SPIRE bands, where the confusion limit is as high as ~20 mJy (Oliver et al. 2010; Nguyen et al. 2010), but in this work we attempt to develop a method to go beyond the nominal confusion limit. The confusion noise results from a combination of effects including the beam size, the instrumental noise, astrometric uncertainties, and the emission of faint, undetected sources. Isolating the effect of each of these contributions to the confusion is a challenging task (e.g. degeneracy between the position of the sources and the effect of the uncertainty in individual pixels produced by the instrumental noise, pixel sensitivity, and local fluctuations due to faint sources).

From this point, this paper is divided into the following sections. Section 2 explains the new method to incrementally correct the observed Herschel colours from shorter to longer wavelengths; Sect. 3 presents the ancillary dataset supporting this work; Sect. 4 analyses the role of clean galaxies, blending and clustering effects in the evolution of mid-IR (MIR) to FIR colours as a function of redshift; Sect. 5 presents the relations that best fit the colour-redshift relations, as well as the iterative corrections applied to correct blending effects; Sect. 6 describes how the realistic mock images were made; Sect. 7 provides an analysis of the confusion noise in the extracted sources from the simulated maps. Finally, Sect. 8 presents new values for the resolved CIRB and the typical redshifts and stellar masses of the galaxies responsible for its origin, and Sect. 9 summarises the main results of this work.

2. The method

This work relies on the combination of the information of Spitzer and Herschel from the shortest to the longest wavelengths thanks to the existence of universal mid-to-far infrared colours of galaxies as a function of redshift. The success of this propagation of the information from the shortest to the longest wavelengths relies on the recently found evidence of universality of the IR spectral energy distribution (SED) of galaxies (Elbaz et al. 2011), itself reflecting more general scaling laws now often referred to as a “main sequence of star-forming galaxies”. Recent evidence suggests that most galaxies grow in stellar mass at a steady-state rather than from episodic, merger-driven starbursts, and new scaling laws have emerged from this scenario of galaxy formation.

First, a tight correlation between the specific SFR (sSFR = SFR/M) and the stellar mass M at different redshifts: z ~ 0 (Brinchmann et al. 2004; Salim et al. 2007), z ~ 1 (Elbaz et al. 2007; Noeske et al. 2007), z ~ 2 (Daddi et al. 2007b; Pannella et al. 2009), z ~ 3 (Magdis et al. 2010; Elbaz et al. 2011), z ~ 4 (Daddi et al. 2009). In this scaling law, most galaxies fall on a main sequence (MS) with steady star formation, while a small fraction of outliers experience starburst (SB) episodes.

Second, there is a correlation between the total IR luminosity LIR and the luminosity at 8 μm, L8 μm. The LIR is mostly due to the FIR emission of big grains of dust, while the 8 μm emission is dominated by polycyclic aromatic hydrocarbon (PAH) molecules. Again, most galaxies fall on a main sequence with a median IR8 = LIR/L8 μm of ~4.9. Outliers to this sequence, i.e. LIR/L8 μm ≫ 4.9, are associated with mergers that show compact star-forming regions, where PAH molecules are more efficiently destroyed hence decreasing in L8 μm (Elbaz et al. 2011).

The third scaling law separating a dominant mode of star formation from a minor mode of starbursts is provided by the extension of the Schmidt-Kennicutt law (Schmidt 1959; Kennicutt 1998), the tight relation between projected densities of SFR and gas, to high redshifts (Daddi et al. 2010; Genzel et al. 2010).

As a result, the mode in which galaxies form their stars seems to follow a set of simple rules. The infrared SED of distant galaxies is on average very similar to the one of local galaxies and these simple scaling laws that have been found can be used to extrapolate total IR luminosities from single photometric measurements. In this work, considering the potential of extrapolating the IR fluxes from shorter wavelengths and taking advantage of the unique multi-wavelength data existing in the GOODS-North field, we present a method of digging below the standard global confusion limit (i.e. the statistical limit that does not account for the actual positions of individual sources) and reach a local confusion limit, accounting for these positions, to resolve most of the CIRB even in the SPIRE bands that are most affected by confusion.

We achieve this by building realistic simulated images of a cosmological deep field that is well-sampled in redshift and has a very complete multi-wavelength dataset. The robustness of the source extraction and the accuracy of the photometry are studied in the simulations, aiming to find a criterion that determines the reliability of fluxes by

  • quantifying the impact of confusion on the uncertainty in thedetermination of Herschel flux densities,

  • understanding the relative impact of the different sources of noise,

  • improving the selection of prior sets of target positions to improve the search for faint galaxies in the process of catalogue building.

The resulting criteria are designed to be applicable to other cosmological fields that may lack a complete and well-controlled redshift, and multi-wavelength ancillary datasets.

Consequently, we proceed according to the following steps

  • We exploit the fact that prior sources, seen at shorter wavelengthswith higher spatial resolution(e.g. 24 μm sources),are located at positions that are tightly correlated with thepresence of FIR sources.

  • Thus, instead of defining a global confusion noise (produced by a floor of faint sources percolating over the full image, and to limit detections above 3σ of this global noise) we use our simulations and the information at the shorter bands of each given Herschel band to attribute to each source a photometric accuracy index. This index measures a “local confusion noise”, i.e. the impact of confusion at the actual position of individual sources, by estimating the difference between the input and measured flux densities of every individual source used to produce the mock Herschel image.

  • We use this index to isolate a subsample of sources that are the least affected by confusion from neighbouring sources.

  • We define this revised detection limit for a subset of the sources as the local confusion noise.

  • We are then able to dig into the heavily confused deep FIR images, improve the Herschel detection limits, resolve a greater fraction of the CIRB, and determine what fraction of the CIRB can be resolved into individual sources. Since sources that are rejected for being affected by random projections of sources in the line of sight are not biased, the properties of the sources with clean photometry are expected to be representative of the whole sample.

3. The GOODS-North dataset

The full 10′ × 15′ Great Observatories Origins Deep Survey (GOODS) North field has been imaged with PACS (Poglitsch et al. 2010) at 100 and 160 μm, and SPIRE (Griffin et al. 2010) at 250, 350, and 500 μm as part of the GOODS-Herschel key project (Elbaz et al. 2011). By construction, the SPIRE images properly encompass the GOODS-N field but also cover a wider area that is included in the FITS images of the present data release but not in the catalogues due to the lack of ancillary data in the external parts, in particular deep 24 μm catalogues that are required to perform prior Herschel source extraction. The total observing time in GOODS-N is 124 h and 31.1 h for PACS and SPIRE, respectively.

The mosaics used in the present paper are the same ones as those described in Elbaz et al. (2011). In short, the data were reduced within the HIPE environment in the Herschel common science system (HCSS) with the official PACS Photometer pipeline (Wieprecht et al. 2009). Maps were created from the timelines of each AOR via the HCSS photProject algorithm, which is equivalent to the drizzle method (Fruchter & Hook 2002). Each individual AOR map was projected with the same world coordinate system (WCS). Since the SPIRE bolometers do not fill the field of view, scanning at a particular angle is necessary in order to provide relatively homogeneous coverage, hence the observations were executed as cross-linked scan maps. Each single SPIRE cross-linked map covers 22′ × 19′ with 3 repetitions for a total field of view of 900 arcmin2.

The pixel sizes are 1.2 arcsec and 2.4 arcsec for the PACS maps at 100μm and 160μm maps and 3.6, 4.8, and 7.2 arcsec for the SPIRE maps at 250, 350, and 500 μm, respectively. These significantly oversample the PSF full width at half-maximum (FWHM) by a factors of 5, corresponding to a sampling finer than Nyquist by a factor 2 (see Table 1 for a summary of the FWHM of Spitzer and Herschel.)

The present SPIRE data from the GOODS–Herschel project in GOODS-North are the deepest data ever obtained at 200600 μm, together with those similarly deep data obtained by the HerMES1 consortium (Oliver et al. 2010) in GOODS-South. We note that deeper data exist in the GOODS-South field for PACS for the central 8′ × 8′ region from GOODS–Herschel and extended over the whole GOODS-South field in the PEP2-GOODS–Herschel combination (Magnelli et al. 2013). The 3σ depth for the PACS data in GOODS-North are 1.1 mJy (100 μm), 2.7 mJy (160 μm) as compared to 0.6 mJy (100 μm), 2 mJy (160 μm) after combining the GOODS-Herschel data with the PEP ones (Magnelli et al. 2013)3. Due to the confusion limit, the data at 160 μm are mildly deeper, while the 100 μm data in the central region of GOODS-South are nearly twice deeper. However this deeper level is obtained at the centre only of the field and at the expense of a varying coverage on the outskirts of the field. Since the present paper presents a method to deal with confusion, and that this effect only starts to play a dominant role with Herschel above 160 μm, the following results would be comparable if done in one or the other field. Forthcoming papers will apply this method to all the CANDELS fields, i.e. the two GOODS fields, as well as the central part of COSMOS and the UDS field in the framework of the Astrodeep FP7 European project.

Table 1

Full width half maximum of the point spread function of the Spitzer IRAC and MIPS bands (upper part), and Herschel PACS and SPIRE bands (lower part).

3.1. Source extraction method

Source extraction on the real Herschel images, as well as on the mock images that will be later on described was performed, as described in Sect. 4.1 of Magnelli et al. (2013; see also Magnelli et al. 2009). A MIPS-24 μm catalogue (S24 μm ≥ 20 μJy) was built from a list of sources coming from a blind SExtractor (Bertin & Arnouts 1996) source extraction on an IRAC mosaic made from the weighted average of the 3.6 μm and 4.5 μm images, using a “Mexhat” convolution kernel to enhance deblending in crowded regions. Due to the pixel sizes of the IRAC camera, the spatial resolution of both IRAC bands is given by the same FWHM ~ 1.6′′.

As a result of this choice, the position uncertainty of the Herschel sources is the one of the IRAC priors but the accuracy of the separation of neighbouring sources is controlled by the actual FWHM of the PSF at the Herschel wavelengths (listed in Table 1). If we had a perfect knowledge of the pointing of the satellite, and in the absence of instrumental noise, sources could be deblended with a nearly infinite accuracy, which we actually tested. But in the presence of these two sources of uncertainty, even accurate prior positions are limited by the fact that we are not certain of the position in the Herschel maps and due to the instrumental noise, which introduces an extra uncertainty on the centroid of the PSF that is fitted. The resulting flux uncertainties are therefore very difficult to quantify, requiring the most accurate mock Herschel mosaics to reproduce these sources of uncertainties to quantify precisely the difference between input and measured flux densities for sources distributed with the actual source positions in the field. This is the key bottleneck of Herschel extragalactic surveys that we are addressing here. Note that stacking on a larger number of source positions does reduce the effect of blending, since only the central sources are repeated, while neighbouring sources are diluted in the stacks, but that this is at the expense of studying large galaxy populations with no insurance on the actual fraction of sources that are making the signal. We are here interested in digging deeper into the confusion regime but following individual sources that can later on be studied.

We used MIPS-24 μm priors from Magnelli et al. (2013) imposing a minimum flux density of 20 μJy (3σ limit, while for PACS-160 μm and SPIRE-250 μm we restricted the 24 μm priors to fluxes larger than 30 μJy (5σ limit) (reducing the number of priors by about 35%). For SPIRE-350 and 500 μm  we used the 24 μm prior positions for sources with a signal-to-noise ratio S/N ≥ 2 detected at 250 μm. These criteria were adopted from Monte Carlo simulations to avoid using too many priors that would result in subdividing flux densities artificially, while producing residual maps (after PSF subtracting the sources brighter than the detection limit) with no obvious sources remaining.

It is important to avoid using a too large number of prior positions since this would lead to an “over-deblending issue”, namely the flux density of a single Herschel source may be distributed between several priors with high uncertainty. Therefore, in the event where two 24 μm sources would turn out to be closer than 1.5 pixel (i.e. FWHM/3.5 or Nyquist/1.5), we only kept the brightest one for the source extraction. This choice does not impact the source extraction itself – it is only used to avoid overestimating the noise in the measurement by trying to deblend too nearby sources – but it means that we have favoured one out of the two candidates as counterpart. The implications of this choice will be the matter of a forthcoming paper where we show that in a minor fraction of the cases, this approach leads to the missing of distant SPIRE sources that are wrongly attributed to more nearby galaxies (Shu et al., in prep.)

The MIPS-24 μm data probe fainter IR galaxies thanks to a less intense k-correction resulting in a flatter redshift evolution of the minimum LIR that can be detected. The SpitzerMIPS 24 μm image reach deeper confusion levels (20 μJy for 3σ) up to z ~ 3 than Herschel data in the GOODS fields and most Herschel sources have a 24 μm counterpart (Elbaz et al. 2011). A minor number of Herschel objects (21 galaxies, <1%) have no 24 μm counterparts. Those sources have been identified as MIPS-dropouts, and show strong silicate features in absorption at 9.7 and 18 μm falling in the MIPS-24 μm band when the galaxies are at z ~ 1.3 and z ~ 0.4, respectively (Magdis et al. 2011). This means that source extraction based on 24 μm prior positions can recover most of the sources in the Herschel images. It is expected that above a redshift of z ~3, the SPIRE bands will be more sensitive to distant sources at the depth reached here in GOODS-Herschel than MIPS-24 μm. As we will show in Sect. 6.3, this will concern only a small fraction of the sources that will not play a dominant role in the confusion limit.

3.2. Flux uncertainties

Two methods have been classically used in previous studies (e.g. Magnelli et al. 2009, 2013; Elbaz et al. 2011) to determine measurement uncertainties on the Herschel flux densities. The first one consists in measuring the noise level in a “residual map” at the position of the source. To produce such residual map, a first source extraction is performed to determine the 3σ detection threshold, then sources brighter than 3σ are identified, and only those ones are kept in a second iteration of the source extraction code on the original images. This leads to the production of a residual map where only 3σ sources have been subtracted, thus avoiding subtracting highly uncertain sources that would produce noise artificially. Keeping this residual map as a noise map, a third source extraction is then performed using all prior positions as in the first iteration but keeping the previous residual map as a noise map. This noise measurement is our “local residual noise level”.

A second method consists in injecting a small number of sources with a given flux density in the real Herschel mosaic, extracting the sources using their all the prior positions, and including the ones of the extra sample, for which positions have been blurred in the input prior list by a random uncertainty mimicking the position uncertainty from the satellite. Reproducing this step many times for each flux density, we obtained an uncertainty on the measurement that we call “global simulated noise level”. This noise level can be compared to the local residual noise level for any of sources of similar flux densities. When this comparison was done, it was found that the two noise levels were equivalent for PACS, while for SPIRE the local residual noise level was underestimating the global simulated noise level by a factor 3/5, i.e. sources expected to be measured at the 5σ level, were in fact detected at 3σ. The inconvenient of this measurement is that it is not local, it is an average measurement over several positions on the map.

In the present paper, we will introduce a better determination of the noise level that will be defined from the use of realistic Herschel mosaics. First, these mosaics will be used to demonstrate that the previous two noise levels can be made consistent. We will show – in Figs. 12, 13 discussed in Sect. 7.3 – that the factor 3/5 is indeed reproduced in the realistic mock mosaics. Second, we will be able to determine a “local simulated noise level” by determining the noise that affects the measurement of a source at its real position but on the mock mosaic. This local simulated noise level will be determined by a “photometric accuracy index” (PAI) that will compare the measured and input flux densities of sources in our simulated images, where all sources are injected rather than a small sample randomly injected at positions that do not reproduce the actual local confusion noise level of sources.

3.3. Redshifts and stellar masses

Spectroscopic redshifts come from Barger et al. (2008) and Stern et al. (in prep.).

Photometric redshifts were obtained using EAZY4 adopting a linear combination of the seven standard EAZY galaxy templates as described in Pannella et al. (2014). When compared to the spectroscopic sample, the photometric redshifts present a relative accuracy of Δz = (zphotzspec)/(1 + zspec) ≤ 3% with less than 3% catastrophic outliers (i.e., objects with Δz> 0.2).

Stellar masses were determined with FAST5 (Kriek et al. 2009) on the U to 4.5 μm PSF-matched aperture photometry from Pannella et al. (2014), using Bruzual & Charlot (2003) delayed exponentially declining star-formation histories, which mimicks the trend observed with the redshift evolution of the SFR-M main sequence of star-forming galaxies (see Pannella et al. 2014, for more details). We use solar metallicities, a Salpeter initial mass function, and the Calzetti et al. (2000) reddening law with AV up to 4 mag.

4. Universal mid-to-far infrared colours of star-forming galaxies as a function of redshift

In order to incrementally take advantage of the better spatial resolution of shorter wavelengths from 24 to 500 μm, we start by comparing the flux density of individually detected Herschel sources to their 24 μm emission as a function of redshift. The existence of an IR main sequence regime followed by most galaxies, as opposed to a minor population of galaxies in a starburst mode, suggests that most distant galaxies do not depart by large factors from a typical FIR/24 μm ratio, at any given redshift, for each one of the Herschel bands. We therefore extend here the IR main sequence concept based on the IR8 = LIR/L8 μm colour index (Elbaz et al. 2011) to the more general relations LHerschel/L24 μm/(1 + z), where LHerschel is the luminosity in each one of the Herschel bands, i.e. L100 μm/(1 + z), L160 μm/(1 + z), ...

Our goals are to (i) find the best recipe to construct as realistic mock Herschel images as possible that we will use to test the robustness of source extraction against confusion; (ii) determine a methodology to benefit from the shorter wavelength Herschel bands to improve the source extraction in the longer bands on real images, mainly using PACS to deblend SPIRE; (iii) estimate the completeness of this source extraction approach, and correct the contribution of faint Herschel sources to the CIRB for incompleteness.

thumbnail Fig. 1

Redshift evolution of the mid-to-far infrared colours of Herschel galaxies. Each plot shows the ratio of the observed Herschel over MIPS-24 μm flux densities as a function of redshift. Figures on the left column show the colours from the observed Herschel measurements. Figures on the right column show the same dataset but after having corrected the 160 to 500 μm over 24 μm ratios of the individual galaxies by the offset observed in the 100 to 350 μm shorter wavelength bands. The points indicate the positions of individually detected sources separated in 3 populations, depending on the presence of bright 24 μm neighbours (i.e. with a S24 μm greater than half of the central source) in their close environment (at a distance of 12′′for PACS and 20′′for SPIRE). This number is the “clean index”, CI. Filled red dots: galaxies with no bright neighbours (CI = 0); filled green dots: galaxies with at most one bright neighbour (CI ≤ 1); open circles: remaining 3σ sources (CI ≥ 2). The sliding median of the CI = 0 galaxies is shown with a blue line and blue circles with central red dots. The trends for the mean stacking at the positions of the 24 μm prior sources brighter than 50 μJy are illustrated with orange lines. The yellow line corresponds to the best-fit relations described in Eq. (1) to (5) of Sect. 5 that fit the sliding median. The colours obtained for the IR spectral energy distributions of the library of Magdis et al. (2012, black dotted line) and the main sequence SED of Elbaz et al. (2011) are shown for comparison.

Open with DEXTER

4.1. Clean galaxies

The goal of this section is to determine the existence of universal trends in terms of FIR/MIR colours of galaxies as a function of redshift. In order to minimise the effects of bright neighbours on galaxies, which would artificially make such relations noisier, we have chosen to perform these measurements on a sub-population of “clean” galaxies. Clean galaxies are defined by exploiting the a priori knowledge of the underlying galaxy population on the projected density map, assuming that the local spatial distribution of the 24 μm sources also traces the local spatial distribution of sources at longer wavelengths. Here we define a clean index (CI) as the number of bright 24 μm neighbour sources (Sneighbour > 0.5Scentral) that are closer to the central source, Scentral, than 12′′ for PACS and 20′′ for SPIRE. It was found by Hwang et al. (2010) that sources with 2 or more “bright” 24 μm neighbours systematically exhibit non-physical jumps in the FIR SED, resulting from their Herschel fluxes, while sources with 0 or 1 neighbour did not. In its original definition, the CI was computed within a distance of 20′′ by reference to the SPIRE 250 μm band. This distance that corresponds to 1.1 × FWHM250 μm being too conservative for PACS, we have translated it to the PACS 160 μm band, i.e. 12′′ (equal to 1.1 × FWHM160 μm).

4.2. Redshift evolution of the far/mid-infrared colour of galaxies

Here we present a new empirical method based on the correlation of FIR/24 μm colours of individual galaxies as a function of redshift to extrapolate the Herschel fluxes to be used to produce realistic simulations. Libraries of SEDs are widely used to fit the FIR emission of galaxies and extrapolate their bolometric IR luminosity (Chary & Elbaz 2001; Dale & Helou 2002; da Cunha et al. 2008). However, uncertainties in our knowledge about the physics of galaxy evolution and not well-constrained measurements in the long wavelengths – due to detection and confusion limits – lead to large uncertainties when using such libraries, established for local galaxies, to extrapolate FIR fluxes of distant galaxies. After having used SED libraries, and found them unsatisfactory to predict the FIR fluxes based on 24 μm as compared to the actual Herschel measurements (in particular the SPIRE data for which extrapolations are more extreme in terms of the wavelength gap), we adopt here a more phenomenological approach to predict Herschel fluxes by fitting the observed evolution of the FIR/24 μm ratio as a function of redshift, and accounting for the departure of individual galaxies from this typical trend based on the closest shortest Herschel band. The resulting trends will afterwards be compared to standard SED libraries.

We found that the observed FIR/24 μm colours show well-defined trends for each Herschel band as a function of redshift. Part of the dispersion of these colours comes from the effect of source blending. To minimise this effect in the determination of the typical colour of individual galaxies, we have split our sources in three categories, depending on the presence of bright neighbours at 24 μm, within a distance depending on the Herschel band considered. This technique has been used to identify “clean” candidate sources (Hwang et al. 2010; Elbaz et al. 2010, 2011) as sources with the least probability to be affected by the confusion with a bright neighbour, where “bright” designates sources with a flux density of at least half that of the central source. The evolution of the observed SHerschel/S24 μm flux density ratios as a function of redshift are presented on the left panel of Fig. 1. In Fig. 1, sources defined as “clean” because they have zero or one bright 24 μm neighbour are shown with red and green dots, respectively. We find that “clean” Herschel sources follow a well-defined evolution of the FIR/24 μm colour with redshift with an average dispersion of only 0.23 ± 0.07 dex. The error bars in Fig. 1 represent the median absolute deviation, MAD, i.e. the interval in log 10 containing 68% of galaxies around the median Herschel/24 μm colour. The average of this dispersion over the full redshift range is 0.23 ± 0.07 dex, with values that vary with wavelength: MAD = [0.17, 0.16, 0.18, 0.21, 0.31] dex at [100, 160, 250, 350, 500] μm. Note that the MAD would have been larger without splitting sources in redshift, i.e. MAD around the median colour of all redshifts = [0.20, 0.18, 0.20, 0.33, 0.42].

The sliding median of the sources without bright neighbours is shown with a blue line joining blue dots with red centres. In order to obtain the purest relations, we used here the filled red dots, i.e. the galaxies fulfilling the condition of CI = 0 (that is to say sources having no bright neighbour), to define the best-fitting relations and the dispersion around these relations that are shown with the solid blue line in Fig. 1.

The green points with at most one bright neighbour are distributed symmetrically around this trend and we have tested that their sliding median does not present any major departure from the one seen with the cleanest sources, i.e. no bright neighbour. While the technique allowed us to minimise the impact of blending, we are limited to the sources that can be detected by Herschel. Therefore, in order to check whether this trend remains reliable to fainter levels, we have compared it to stacked measurements.

4.3. Comparison with stacking measurements

We have stacked postage stamp images on a selection of 24 μm prior positions in order to determine whether the colour trends seen for detected sources were also representative of a wider selection or more typical of the brightest sources. For each of the sources in our galaxy sample, we produced a cutout, centred on the nearest pixel to the sky position of the source, in the PACS and SPIRE images of 60 × 60 pixels, which corresponds to an angular scale of about 10 times the image beam. The cutouts were then stacked to create mean images in selected bins of redshift and stellar mass. The resulting measurements were corrected for flux boosting by clustering using the recipe described in the Appendix B2 in Schreiber et al. (2015).

We stacked only prior 24 μm positions of sources brighter than 50 μJy. The reason for this choice comes from the number of independent beams that can be used within 150 square arc minutes with the large SPIRE PSF FWHM. Within this area there are about 400, 870, and 1650 beams at 500, 350, and 250 μm, respectively. Using all 24 μm sources brighter than 20 μJy, meaning about 2400 sources, would imply that we would be stacking more positions than there are independent beams in the area. Obviously, we would not gain any information by doing this. Instead we decided to stop at 50 μJy in order to reduce the number of priors to nearly 1000. We note that the Herschel detections rapidly drop for 24 μm priors below 200 μJy. Between 200 and 50 μJy, they decrease by a factor 10 for PACS and 100 for SPIRE at the Elbaz et al. (2011) detection limits of 1.1 and 2.7 mJy at 100 and 160 μm 5.7, 7.2, and 9 mJy at 250, 350, and 500 μm (see Fig. 2).

Remarkably, the redshift evolution of the FIR/24 μm colours measured using stacking (orange line) follows closely the one of the sliding median (blue line and dots), showing that the detected sources do not present different SEDs than fainter undetected sources probed by stacking down to the limit probed here.

The narrow dispersion of the clean samples allowed us to define relations that best fit the median colours of individual sources as a function of redshift for each Herschel band (see Sect. 5 for more details). These best-fitting relations are shown with a yellow line in Fig. 1. The nodes of the yellow lines were chosen arbitrarily to reproduce the sliding median with a minimum of relations.

thumbnail Fig. 2

Histogram showing the number of 24 μm sources as a function of flux density in bins of 0.05 dex (black curve). The coloured lines show the number of 24 μm sources in the same flux density bins that are detected by Herschel at 100 to 500 μm.

Open with DEXTER

4.4. Blending and clustering effects

Sources located at prior positions close to two or more bright 24 μm neighbours (black open circles in Fig. 1) show FIR/24 μm ratios more dispersed and systematically higher than the best-fitting relations over the whole redshift range. This suggests that their colours are strongly affected by blending with nearby bright sources, hence are not characteristic of the colours of individual galaxies.

In general, the non-clean sources become confused just by the presence of a large projected density of sources at their position (by chance associations rather than physical association in most cases) and there is no reason for them to have a different nature than the clean ones.

A possible caveat though, would be the possibility that clean sources favour sources that are physically less clustered than the general population. Indeed, it is known that two effects are playing a role in the confusion of Herschel mosaics: a projected random association and a physical association linked to clustering. Clustering can boost flux densities by several percents as described in the Table B.3 of Schreiber et al. (2015). The CI would preferentially reject those sources and, possibly, bias the colours of the resulting galaxies if clustered sources were found to be, for example, warmer than non clustered ones. In order to test this effect, we have kept the same number of 24 μm sources and redistributed them randomly in the field. Physical clustering is therefore present only in the real source distribution and absent in the random one. We do find that the fraction of clean sources rises when distributing randomly the 24 μm sources. In the real catalogue, 38.8% of the sources are “clean”, i.e. present at most one bright neighbour with >50% of its 24 μm flux density within 20′′, while in comparison this fraction rises to 44.6% in the randomly distributed sample. Concequently, we would find 7% more clean sources in the absence of clustering. In other words, our CI has led us to reject 7% of the sources because they were physically associated with bright neighbour due to real physical associations. We do not know whether such sources are presenting different FIR colours, but their small fraction suggests that their presence in the sample would not have strongly modified the colour trends that are used here.

5. An incremental method to predict flux densities in the Herschel bands

We have shown in the previous section that the clean population is representative of the whole population, as well as of the detected sources since they follow the same trend as the staked sources. This also implies that we can use the colours of clean detections to constrain a proto-typical IR SED of galaxies or at least to extrapolate from 24 μm the flux densities of all prior sources in the Herschel bands used here to make the mock images. For comparison, in Fig. 1 we also show the main sequence SED from Magdis et al. (2012, black dotted line), where the correct SED is chosen as a function of redshift, and also the main sequence SED from Elbaz et al. (2011, black dashed line). These SEDs globally agree with the colour trends that we find here. Noticeable differences appear at z> 3, where the SEDs are not constrained but sources at such high redshifts make a negligible contribution to the confusion limit. We note though that these large differences are however useful for the identification of candidate z> 3 sources.

In the following, we will show that the dispersion of “clean” sources around the sliding median of the FIR/MIR relations is physical and not due to measurement uncertainties. To demonstrate this, we will determine the offset of sources with respect to the median trend at a given wavelength, e.g. 100 μm, then correct for this offset the following longer wavelength, i.e. 160 μm. If the dispersion is physical and dominated by FIR/MIR differences rather than changes in dust temperature, then the dispersion at 160 μm will be reduced by the same amount. We will make such corrections iteratively up to 500 μm. After having shown that this method does reduce by a substantial amount the dispersion of galaxies around the median trends, we will use these median trends and the offsets measured at “shorter wavelengths” to reversely predict the observed “longer wavelengths” flux densities of sources starting from 24 μm to 500 μm. This method will allow us to attribute realistic observed Herschel flux densities to all 24 μm priors and we will then produce mock Herschel images from these catalogues that we will compare to the real images to verify that they do contain the same amounts of confusion noise due to undetected sources.

thumbnail Fig. 3

Residuals of colour index Herschel band minus MIPS-24 μm. with respect to the best-fit relations as a function of redshift. Upper panel: residuals for the observed colour index. The 68% dispersion around the median is equal to [0.17, 0.16, 0.18, 0.21, 0.31] dex for the five Herschel bandpasses when accounting for redshift ranges in the best-fit equations, while it would have been [0.20, 0.18, 0.20, 0.33, 0.42] without separating galaxies in redshift slices. Lower panel: dispersion after accounting for the offset measured at shorter wavelengths, e.g. correcting S160 μm/S24 μm by the distance of S100 μm/S24 μm to the median, the dispersion in colour indices becomes as small as [0.14, 0.12, 0.13, 0.19] at [160, 250, 350, 500] μm, respectively (no correction can be applied to the 100 μm band obviously). The correction process reduces the dispersion of the colour distribution because that variation is physical and not due to noise in the measurements.

Open with DEXTER

5.1. Universal Herschel–24 μm colour evolution and dispersion

The observed dispersion of the colours of galaxies as a function of redshift results from the combination of noise in the measurements and physical differences such as PAH equivalent widths, distributions of grain sizes, nature (silicates, carbon), and temperature. The upper plot in Fig. 3 shows the colour residuals with respect to the best-fit relations given below in this section. If noise was the dominant cause of this dispersion, we would not expect the offset of a source observed at 100 μm to be correlated with the one observed at 160 μm. Flux boosting, due to a bright neighbour, would artificially induce such correlation but with a different effect as a function of FWHM and, as seen in Fig. 1, with a preferential effect of boosting the flux density. However, as we will show in the following sections, offsets to the best-fitting trends are correlated between the Herschel bands suggesting that they are due to physical differences. For example, Elbaz et al. (2011) showed that starbursts tend to exhibit stronger FIR/MIR ratios than normal star-forming galaxies, which result in a boost in all Herschel bands. The effect of dust temperature on this boost is a second-order effect.

Assuming that differences in the FIR/MIR colours of observed galaxies are physical and not dominantly due to noise, we can use the e.g. excess of FIR emission, as probed by the 100/24 flux density ratio, as an indication that the SPIRE/24 μm ratio will also exhibit an excess, hence use this information to better predict the longer wavelengths flux densities.

Since the presence of neighbours results mostly from projection effects of sources that are not physically connected, the selection of clean sources, i.e. sources selected to have at most one bright 24 μm neighbour, is not expected to bias our analysis. Since we allow at most one bright neighbour but reject sources with two or more neighbours, we do not expect our sample to be biased against interacting systems of close pairs.

The resulting best-fitting laws that describe how colours change as a function of (1 + z), as shown in Fig. 1, are the following: where and S24 μm are flux densities and were measured in the Herschel images using 24 μm prior positions as in Magnelli et al. (2009) using the sample of clean sources.

These best-fitting laws define the reference colours from which any excess or lack of flux of the real Herschel sources can be determined: in the former case, a departure from these laws can, in principle, mean that the source is gaining flux from a companion due to blending (boosting), a sign that sources are affected by confusion (alternatively, sources can also be experiencing a starburst phase that can resemble a boosted source) or, in the latter case, the source may be giving up part of its flux to boost others.

Based on these findings, we believe that we can use the SHerschel/S24 μm best-fit colours to extrapolate Herschel flux densities based on 24 μm measurements for objects below the nominal detection limit of Herschel.

To construct our list of best-fitted fluxes for all prior sources, we calculated the for ~2700 sources in the ancillary MIPS catalogue, adopting the spectroscopic redshift where available (48%) and otherwise the photometric redshift (37%). For the remaining 15% lacking a redshift, we assumed that they were faint, distant galaxies with colours following the behaviour observed in the high redshift domain in Eqs. (1) to (5).

5.2. Iterative correction

The second step to produce the final flux densities, which will be used in the realistic mock images, exploits the advantage of the multi-wavelength association of data and the observed colour deviations with respect to the best-fitting relations, to iteratively correct the colour of clean sources from shorter to larger wavelengths.

We begin by considering the shortest wavelengths that show very low or no confusion at all. That is the case for 24 μm and 100 μm sources, at least down to the flux density limit above which sources are detected in the 160 μm and SPIRE bands. Here we will test the hypothesis that the colour dispersion for clean sources around the median colour trend, found in the previous section, is physical and not artificially produced by noise and/or confusion. If this hypothesis is correct, then we can estimate the distance in colour of an individual galaxy to the median colour trend at the shortest wavelength, e.g. 100 μm, and use this information to predict the flux density at the longest wavelengths, e.g. 250 μm. In other words, we should be able to reduce the dispersion around the median in the SPIRE bands by using the colour distance measured in the shorter wavelength bands.

For any given source detected at 24 μm for which we have a redshift determination, we start by determining its from Eq. (1). Then, this extrapolated flux density is compared to the observed one and its excess (or deficit) is defined by C100 as: (6)where C100 contains the colour information, from a well sampled set of data, that will serve to correct any excess (or lack) of flux for that source also detected in a larger wavelength band. In the case that the source is not detected at 100 μm the constant is set to 1, i.e., we adopt the best fitted 100 μm flux as the flux density for that 24 μm prior in the simulations.

To determine whether offsets at 100 and 160 μm are correlated, we define a corrected 160 μm flux density as: (7)Figure 1 right presents the distribution of the corrected flux densities as a function of redshift. No correction was applied at 100 μm since there is no shorter Herschel band that can be used for a correction, hence the upper-left and upper-right panels are identical. Below, the 160 μm band shows a reduced dispersion which confirms that the dispersion seen at 100 and 160 μm are not only due to random noise but are correlated. Globally, the 68% dispersion around the median of the S160 μm/S24 μm ratio is equal to 0.16 dex when galaxies are compared to their median in redshift intervals, as in Fig. 1 left. It becomes as low as 0.12 dex in Fig. 1 right, when correcting for the offsets observed at 100 μm using C100. This implies that one can extrapolate a value for S160 μm with a 0.12 dex accuracy with the knowledge of the redshift of a source and of its flux densities at 24 and 100 μm.

To extend the process to the following wavelength, 250 μm  we define C160 as the residual offset between the corrected 160 μm flux density and the median best-fitting trend: (8)Using this new correction factor, one can correct the observed 250 μm flux density by combining both C100 and C160 as in Eq. (9) and then determine the dispersion of resulting flux density distribution around the best-fitting S250 μm/S24 μm ratio vs. redshift trend. The 68% dispersion around the median gets reduced from 0.18 dex to 0.13 dex. We apply a similar procedure to correct the 350 and 500 μm flux densities, so that: When no measurement of the source exists in the band k then we set the constant as Ck = 1.

When applying these iterative extrapolations, we observe that the original colour dispersion for clean sources (left panel of Fig. 1) is reduced in all Herschel bands (right panel in Fig. 1). This means that the colour dispersions are correlated from one band to the other, hence the knowledge of the shorter wavelengths can be used to improve the extrapolation to the longest wavelengths. We can consider those corrected flux densities as good approximations to the real emission of the 24 μm sources in the FIR bands. Figure 3 shows the dispersion of the observed and corrected colours for all Herschel bands.

We find that the use of this iterative offset correction for the colours at shorter wavelengths (as in Fig. 1 right) reduces the MAD of the dispersion of the FIR/24 μm colour with redshift to 0.15 ± 0.04 dex, i.e. [0.14, 0.12, 0.13, 0.19] dex at [160, 250, 350, 500] μm, respectively (no correction can be applied to the 100 μm band obviously), as compared to the initial value of 0.23 ± 0.07 dex (as in Fig. 1 left). Thus, the colour dispersion is typically divided by two with our technique, which implies that the prediction of the flux density in the most extreme band at 500 μm is known within 55% (within 32% at 250 μm), starting from the knowledge of the source redshift and flux density in the shorter bands.

To summarise the previous discussion, our aim here consists in demonstrating that we can robustly predict the flux density of an individual galaxy at wavelength “k + 1” (e.g. 500 μm) on the basis of a best-fitting Herschel/24 μm colour trend that depends on redshift and on a set of colours measured by the coefficients Ck (e.g. C100, C160, C250, C350) that mimic the variety of IR SEDs of individual galaxies. What do not claim to demonstrate that all galaxies share the exact same SED, but instead that the measurement of the Ck coefficients can be used to improve the prediction of the flux density of individual galaxies at wavelength k + 1, where blending is more problematic than in the shorter bands. If our assumption was incorrect, we would not observe a reduction of the dispersion as we do in Fig. 1 right and in Fig. 3 bottom. The residual dispersion combines the uncertain extrapolation from λk to λ = k with noise due to instrumental effects and the source extraction process. In the following section, we will use these colours to inject mock Herschel sources in a noise map to produce a fully consistent mock Herschel image by accounting for the measured Ck coefficients when building band k + 1.

thumbnail Fig. 4

Selected area of the real (left) and the simulated maps (right) for GOODS-North field in 250 μm. Each stamp is ~ 9′ × 9′ (see Sect. 6).

Open with DEXTER

6. Production of realistic mock Herschel images

6.1. Instrumental noise, PSF, and astrometric uncertainty

To produce mock images as realistic as possible, all characteristics of the actual GOODS-Herschel maps need to be reproduced such as the pixel scale, instrumental noise and point spread function (PSF) to convolve the input fluxes.

We start with a map only containing instrumental noise, with no source, which we build by dividing the individual scan maps of the real PACS and SPIRE observations in two equal sets and subtracting one half to the other. To avoid being affected by different shifts in the positions of the half-maps, we combined separately the odd and even individual scan maps, rather than taking the first half and the second half which would induce a time shift between the two mosaics. The resulting maps are devoid of sources, since those were subtracted in the process being equally present in both mosaics, but contain the instrumental noise. To reach the actual instrumental noise level present in the full mosaics, this noise map needs to be divided by a factor two6.

Individual sources were then injected by attributing to each one of the 2704 MIPS-24 μm priors a flux density in each one of the Herschel bands using the method described in Sect. 5, i.e. the Herschel over 24 μm colour at the redshift of the sources. Sources with no photometric nor spectroscopic redshift were attributed a universal Herschel over 24 μm colour as discussed in Sect. 5.

The mock images were built using the observed PSF of the asteroid Vesta for PACS and a Gaussian model for the SPIRE PSF, including a random astrometric error of 0.35″ to the source positions. If we had a perfect knowledge of the position of the sources and if there was no instrumental noise, the confusion noise would be highly reduced by the use of priors in the source extraction. This can be tested by generating mock images with these conditions and sources can then be deconvolved with exquisite accuracy. For that reason, even though it is said that the confusion comes from the Herschel beam, it is because the PSF is not perfectly sampled, its central position linked to the prior is uncertain, and that there is instrumental noise on top that produce a combined effect that forbids the clear deblending of nearby sources. In order to include a position uncertainty, we have performed a blind source extraction on the real images and compared the centroid of the extracted sources to the one of the prior positions. This comparison gave an offset of ~0.4′′ rms that we used to randomly offset our mock sources. This uncertainty results from the combination of the Herschel relative pointing error (0.2−0.3″) with the remaining absolute astrometric uncertainty and with the precision of the determination of the centres of sources in the Herschel maps. The absolute pointing accuracy of Herschel is 0.8″ but this was corrected by stacking positions of the brightest 24 μm sources on each individual scan maps before projecting them in the final mosaic. An offset was then computed by comparing the centroid of the detection in the stack to the centroid of the postage stamp images, i.e. the centre of the actual sources.

In the following two sections, we demonstrate that the mock Herschel images designed from 24 μm priors do contain the same amount of confusion noise than the real images and that they incorporate more than 95% of the SPIRE 250 to 500 μm sources at the depths reached in the present survey.

thumbnail Fig. 5

Histogram of the flux distribution of pixels for Herschel maps and simulated mock images: observed (black), best-fit (red), and iteratively corrected (blue) fluxes. The corresponding pixel distribution of the noise maps used in the simulations are also presented (dashed lines). The panels below each histogram show residuals coming from ratio of the iteratively corrected map to the observed Herschel map after subtracting the instrumental noise as a function of the flux density. The ratio varies around 1 along the flux bins. The similarity between the observed and mock images is remarkable in particular in the flux bins where most of galaxies contributing to the CIRB are present (see Sect. 8).

Open with DEXTER

thumbnail Fig. 6

Same as Fig. 5 but for 250 μm (upper panel); 350 μm (middle panel), and 500 μm (lower panel).

Open with DEXTER

6.2. Test of the realism of the mock images from their pixel distributions

A critical issue in the production of Herschel mock images is to make sure that mock sources reach faint enough flux limits to reproduce the confusion noise level due to the sea of faint undetected sources. Here we have assumed a priori that the list of 24 μm priors was large and deep enough to include such faint sources making the confusion noise level. In order to test this, one needs to compare the histogram of pixel distributions in the real and mock Herschel images.

The close similarity between the real and mock images can be seen in Fig. 4. Quantitatively, this similarity goes beyond significantly detected sources as shown by the comparison of the pixel distributions of the real and mock images. The upper panels in Figs. 5 and 6 show the pixel distribution for the observed Herschel (in black) and mock (red and blue) images. The mock images (in blue) were generated using the iteratively corrected flux densities as described in the previous section. Mock images using only the best-fitting relations between 24 μm and Herschel flux densities as a function of redshift were also built, and their resulting histograms are shown (in red). This implies that the simulations contain enough faint sources to mimick the effect of confusion. Therefore, it is not necessary to include additional prior sources from other catalogues in shorter wavelengths (e.g. optical or UV) to reproduce the background of faint sources responsible for the bulk of the confusion noise. The noise introduced in the simulation is also show as a Gaussian distribution of pixels (dashed lines). The residual of subtracting the instrumental noise to the observed and simulated maps corresponds to the light produced by the galaxies in all redshifts in the GOODS-North field and its sum is the integrated galaxy light. The lower panels in the same figures show the ratio between the noise-subtracted distributions of the iteratively corrected image and the observed Herschel map. The ratio fluctuates close to a value of 1 in all the flux bins. The recovery of the this fossil light in the simulated and in the real maps is very similar confirming the again the accuracy of the simulation making when the correct instrumental noise and sources with realistic flux densities are used.

Moreover, these faint sources are also the ones that make the CIRB, hence can be used as a reference to determine the fraction of the background that is actually detected as compared to the one present in the images (see Sect. 8). This confirms the results of Dole et al. (2006), who found that 24 μm selected sources contribute to more than 70% to the CIRB at 70 μm and 160 μm.

Once the set of realistic mock images are built, it is possible to extract their source fluxes and compare them with the input data to quantify the level of confusion in each source. Since we use the actual position of individual sources, the good quality of the mock images indicates that we can use them to not only to quantify statistically our source extraction method and the level of the confusion noise, but also determine the robustness of flux density measurements on individual positions in the images.

6.3. Are we missing a population of 24 μm-dropouts in our 24 μm-based mock Herschel images?

A pre-requisite to build the realistic mock Herschel images following the process, as described in Sect. 6, was to start with 24 μm seeds. The advantage of this choice is obvious since we start from a wavelength probing dust emission with the best spatial resolution, a resolution that is itself based on the IRAC one, i.e. at the sub-arcsec level. However, the number of seeds is limited to 2704 sources detected at 24 μm above the threshold of 20 μJy and, although in theory, it was shown that this threshold is enough to detect fainter objects (i.e. less star-forming galaxies) than the Herschel bands at the depths used in the GOODS-Herschel survey (see Elbaz et al. 2011), we now wish to confirm that a large population of Herschel, and more particularly SPIRE sources, are not absent from our simulated mosaics.

We already discussed in Sect. 3, the existence of <1% 24 μm-dropouts that are detected with PACS (Magdis et al. 2011). We wish here to address the remaining issue of the SPIRE sources. Two possibilities are offered to address this issue. As a first step, one can study the residual maps after having subtracted sources from the SPIRE images at the positions of the 24 μm priors. The Herschel residual maps are presented in Fig. 7. The area used for the catalogue production where the noise level is homogeneously and deepest in the PACS bands is identified with a blue rectangle in all images. We show for comparison the MIPS-24 μm image on the upper-left image. The black spots are sources in all images. Note that the SPIRE images cover a much larger area than the PACS ones, which explains the presence of a large number of sources outside of the blue rectangle. One can see that the PACS images contain no clear residual sources, while there remains 23 spots in the SPIRE residual maps. These spots are systematically found close to bright sources in the mosaics making it difficult to know for sure whether they are truly new sources that would be seen with SPIRE but be 24 μm-dropouts, or if they are just residual emission from badly subtracted sources due to the combined effects of noise and uncertain position accuracy of the priors. We therefore decided to generate another set of simulations to disentangle these two possibilities, i.e. true 24 μm-dropouts vs. noise artefacts.

thumbnail Fig. 7

Residual images in GOODS-North field after source extraction using 24 μm priors in each band. The maps show how efficient is the extraction process in the area covered by the prior catalogue (blue rectangle), showing only very few cases where the remnants of bright sources badly subtracted are still present in the SPIRE residual maps (black spots).

Open with DEXTER

We designed a more complete simulation that was made out of optical priors following the recipe described in Schreiber et al. (2015, see Appendix B) that we briefly summarise hereafter. A list of 23672 optical priors were used, an order of magnitude more than the 2704 MIPS priors, to generate these simulated mosaics. These sources were selected to have a 5σ detection in the NIR (KS< 24.5). Stellar masses were derived from the fit of their optical to NIR magnitudes, and then converted into a star-formation rate (SFR) using the SFR-M scaling law that has been observed from z = 0 to 3.5 with a 0.3 dex scatter in Schreiber et al. (2015). A small percentage of 2% of the sources were attributed a 0.6 dex higher SFR to account for starbursts. We note that we do not use the optical-NIR SEDs to derive SFR since this would imply having a perfect knowledge of the extinction and star-formation history of galaxies, and that the regions emitting in the optical-NIR are representative of the colours of the ones where star formation is taking place. This is far from clearly demonstrated and in particular the SFR of galaxies, which present an excess with respect to the main sequence one, are systematically underestimated. Consequently, in order to make sure to have both normal star forming galaxies, as well as a population of starbursts that are systematically missing from optical-NIR estimates, we decided to distribute SFR according to the observed distribution of SFR for each stellar mass bin. Then SFRs were converted into a total IR luminosity, LIR(8–1000 μm) using the Kennicutt (1998) relation SFR = 1.72 × 10-10 × LIR. The Chary & Elbaz (2001) IR SEDs that were best-fitting the stacking data were then used to distribute the LIR to each one of the Herschel bands in order to generate a catalogue of input fluxes.

Note that we validated that the sources produced following that recipe did also follow the colour trends shown in Fig. 1. The advantage of this other set of mock Herschel sources is that it goes much deeper than the present one. The inconvenient of this method is that it only statistically reproduces the Herschel sources, i.e. sources are given a SFR that reproduces the dispersion of the SFR-M “main sequence”, while here we try to stay as close as possible to the real Herschel fluxes. However this deeper simulation can be used to determine the fraction of SPIRE sources that are missed above our detection thresholds when we limit ourselves to 24 μm priors. This is illustrated in Fig. 8, where the number of SPIRE sources as a function of flux density for each one of the three SPIRE bands are shown (black line), as well as the sources that are also detected at 24 μm above the threshold of our prior list (red line). As one can see, above our detection thresholds of 2.5, 5, and 9 mJy at 250, 350, and 500 μm the fraction of sources missed when requiring a 24 μm prior is at the percent level.

thumbnail Fig. 8

Number (lower panels) and fraction (upper panels) of 24 μm sources having a SPIRE counterpart (red) and those with no associated SPIRE detection as a function of the flux density in 250 μm (left panel), 350 μm (central panel), and 500 μm bands (right panel). Vertical lines show the flux limits reached using the simulations found in the present work 2.5 mJy for 250 μm  5.0 mJy for 350 μm, and 9.0 mJy for 500 μm. (See Sect. 7.1 for more details of how these flux limits were obtained.) Consequently, the missing 24 μm population at the flux limits of the simulations is very marginal.

Open with DEXTER

7. The confusion noise

Ironically, there is a non negligible confusion around the definition of confusion noise. It is often defined as the limiting depth below which the number of sources gets so large that there is less than an arbitrary number of beams per sources. Using this definition, Oliver et al. (2010) obtain a confusion limit of ~20 mJy for the three SPIRE bands defined from the depth corresponding to 40 beams/source in the SPIRE deep surveys and BLAST data predicts confusion limits for SPIRE bands of 22, 22, and 18 mJy at 250, 350, and 500 μm also equivalent to 40 beams/source (Devlin et al. 2009).

Alternatively, one can estimate the variance of the sky map due to the presence of unresolved sources following the recipe of Condon (1974) and labelled as the photometric confusion noise in Dole et al. (2003). Nguyen et al. (2010) estimate this noise to be as large as 5.8, 6.3, and 6.8 mJy/beam at 250, 350, and 500 μm, hence leading to lower limits to the 3σ detection limit of 17.4, 18.9, and 20.4 mJy, respectively (lower limits since instrumental noise is not included here, but discussed in the paper). Interestingly, the 40 beams/source definition computed by Nguyen et al. (2010) decreases from 250 to 500 μm going from 19 mJy at 250 μm to 18 mJy at 350 μm, and 15 mJy at 500 μm.

One important caveat in the use of number of beams per source is that such systematic definition not only relies on an arbitrary number of 40 instead of, e.g., 20, but more importantly assumes that the impact of confusion is the same independently of the slope of galaxy counts below this detection threshold. It is obvious that if the depth considered is close to the plateau of the integral counts, then few sources will appear at fainter flux densities, while if the number of sources below this depth presents a steep increase with decreasing flux density, the impact on the fluctuations of the sky will be much stronger.

In practice, what one needs is not a systematic definition but rather a quantitative estimate of the photometric accuracy that can be reached on most of the extracted sources. This is particularly true when confusion can be due to very faint undetected sources, as well as relatively bright sources that are located at specific positions in the maps, introducing a spatial variation of confusion. If we consider the standard Gaussian value of a rms of 68%, we can set our limit to be the depth above which more than 68% of the sources (at the faintest flux limits) can be extracted with a photometric accuracy better than 32%, meaning a S/N> 3. This definition was introduced by Chary et al. (2004) and later used for both Spitzer and Herschel (Magnelli et al. 2009, 2013; Elbaz et al. 2011). The photometric accuracy on the extraction of Spitzer MIPS–24 μm sources was estimated by injecting mock sources on the real maps in small number, to avoid overcrowding the field, but a large number of times. The limiting condition above, which corresponds to | ΔS | /Sout= | (SoutSin) | /Sout ≤ 0.32 for >68% of the sources, was reached at ~20 μJy. At such limiting depth, the number of beams per source is as low as 7 beams/source, yet leading to reliable photometric measurements for most sources.

A potential drawback of the latter method is coming from the fact that sources are injected at some specific positions in the map and even though they can be randomly disposed, one cannot estimate the photometric uncertainty on positions in the map were bright sources are located. In ultra-deep images, bright sources are located all over the image, hence making it difficult to study variations of the confusion noise as a function of position. In order to account for the specific position of bright sources in the Herschel images, Hwang et al. (2010) and Elbaz et al. (2010) noted that there was a correlation between the presence of bright sources in the neighbourhood of a specific source in the Spitzer 24 μm and Herschel maps which led them to select sources using the CI defined in Sect. 4.2. Using the CI to reject such objects in the GOODS fields, Elbaz et al. (2011) were able to reduce the detection threshold accounting for confusion (corresponding to the 3σ limit) by a factor ~3 in the SPIRE bands reaching 5.7, 7.2, and 9 mJy at 250, 350, and 500 μm respectively.

In the following, we will test this method on our realistic mock Herschel mosaics, improve it by studying all positions on the mosaics and quantify the limiting depth reaching the “3σ accuracy for 68% of the sources” at the actual positions of the Herschel sources. We will show that one can reach a detection limit, that we will from now on call the local confusion limit (since it accounts for the local noise due to bright sources as determined from shorter wavelengths), 7 times deeper than the global confusion limit of ~20 mJy at 250 μm (4 times at 350 μm and 2.5 times at 500 μm).

7.1. The photometric accuracy index (PAI)

For a valid comparison between the confusion levels in the real and the simulated maps, not only the mock images have to be built as realistically as possible but also the extraction method applied must be identical to the method used to produce the GOODS-Herschel catalogues.

The photometric accuracy of the flux extraction in the mock images will allow us to quantify with high precision in what degree the extracted sources are affected by bright neighbours and by the confusion produced by faint sources. We will use that knowledge to explore deeper levels in the detection limits of the GOODS-Herschel images.

To quantify the confusion noise in the simulations, we define the PAI as in Magnelli et al. (2009): (13)In the following, we will consider that sources of a given flux density, Sin, can be accurately measured if the extracted flux density, Sout, of at least 68% of them can be extracted with an accuracy better than 32%. We wish to introduce here an important distinction between what we will call the “global confusion limit” and the “local confusion limit”. The global confusion limit is the minimum flux density that fulfills the requirement that PAI ≤ 0.32 for 68% of the sources. We have seen in the previous sections that we can use the information at shorter wavelengths to improve our knowledge at longer wavelengths. In particular, a source that is far from any 24 μm bright source has on average a Herschel flux density that is less affected by blending. Since our mock Herschel sources are located at the same positions as the real ones and with similar flux densities, we can use the simulations to reject a fraction of the sources that are more likely to be affected by the presence of bright neighbours than others. By doing so, we will reduce the effective area of the survey but with the advantage of decreasing the flux limit above which output fluxes are reliable. In the following, we will call such improved flux density limit the “local confusion limit”, local in the sense that we account for what happens at the location of sources.

Figures 9 and 10 show ΔS/Sout as a function of Sout for the simulations of the GOODS-North field. The plots show how the photometric uncertainty increases inversely with the flux densities. Positive values of ΔS/Sout above 0.32 indicate that the extracted fluxes in that flux bin are overestimated. There is a characteristic asymmetry in that direction in the SPIRE bands that is typical of what one would expect from the contamination of bright nearby sources. However, the behaviour of the clean sources in these plots will allow us to obtain new depths, presented below, based on the simulations.

thumbnail Fig. 9

Photometric accuracy index, ΔS/Sout= (SoutSin) /Sout, as a function of the output flux Sout. The median trend of | ΔS | /Sout is shown by the blue line and the red envelope lines contains the 68% of the clean galaxies, i.e. sources associated with a 24 μm source having a CI ≤ 1 (green dots). Dotted horizontal lines at | ΔS | /Sout 0.32 mark the limits that define sources having good photometry. The intersection between the 68% envelope line and the good photometry limit defines the depths for Herschel data based on the simulations (vertical dashed lines; 1.1 mJy, 2.2 mJy, 2.5 mJy, 5.0 mJy, and 9.0 mJy for the 100 μm, 160 μm, 250 μm, 350 μm, and 500 μm Herschel bands, respectively). The histograms on the bottom and right sides of each panel show the distribution of the whole sample of galaxies (dotted line), the clean galaxies (solid green line) and the complementary non-clean galaxies (solid black line) as a function of the flux density (horizontal histogram), and as a function of ΔS/Sout (vertical histogram). The comparison of the solid green and dotted lines shows that the proportion of clean sources remain identical in all flux density bins, i.e., there is no bias against faint or bright sources when dealing with clean sources alone.

Open with DEXTER

thumbnail Fig. 10

Same as Fig. 9 but for 250 μm (upper panel), 350 μm (middle pannel), and 500 μm (lower panel).

Open with DEXTER

7.2. Validating the clean index with the photometric accuracy index

In Figs. 9 and 10, all sources are shown with a filled black dot, while clean sources with at most one bright neighbour (CI ≤ 1, which is going to be our clean criterion) are represented by open green circles. Clean sources, as determined from the 24 μm CI (sources with at most one bright neighbour at 24 μm with 12 and 20′′ in the PACS and SPIRE bands, respectively), are shown with light green dots. Clean sources are nearly indistinguishable from the full set of sources in Fig. 9 showing the 100 and 160 μm PACS results. On the other hand, the clean sample tends to be centred on the | ΔS | /Sout = 0 line in the SPIRE bands (Fig. 10), while the rest of the sources, those which happen to fall close to a bright 24 μm neighbour, are systematically above the dotted | ΔS | /Sout = 0.32 line.

This shows that the CI is a robust method for rejecting sources that are heavily affected by confusion. At 250 μm  for example, one would need to consider a limiting depth of ~20 mJy to reach the requirement of 68% of the sources with | ΔS | /Sout 0.32, which would correspond to the global confusion limit. Instead, we can see that this requirement is reached at much fainter levels, down to a depth of 2.5 mJy after rejecting non clean sources (vertical dashed line). Using the CI, the local confusion limit is set by the intersection between the red envelopes that encompass 68% of the sources around the sliding median of the clean sample (blue line) and the horizontal dotted lines at | ΔS | /Sout = ± 0.32, which define our 3σ limit. In these mock Herschel images, we can see that one can expect to reach a local confusion limit of 1.1 mJy, 2.2 mJy, 2.5 mJy, 5.0 mJy, and 9.0 mJy for the 100 μm, 160 μm, 250 μm, 350 μm, and 500 μm Herschel bands, respectively (intersection of the vertical lines with the | ΔS | /Sout = ± 0.32 in Figs. 9 and 10). These limits are slightly deeper than the Elbaz et al. (2011) ones at 250 and 350 μm as discussed in the next section.

7.3. Comparison of the noise level in the real and mock Herschel images

The PAI can obviously only be determined in the mock Herschel images for which we know both Sin and Sout. However, we can check the consistency of the noise level present in the real and mock Herschel images by comparing the PAI = | ΔS | /Sout to the noise level attributed to individual detections in the real images as estimated from the residual maps (see Magnelli et al. 2013 for a more detailed description). Once detections are extracted from the real Herschel images, one can estimate the local noise at the position of a source by the fluctuations measured in the residual map. The robustness of the noise estimate obtained on residual images has been tested by injecting a limited number of mock sources on the real Herschel images, and extracting their flux density to derive their | ΔS | /Sout. As discussed in Elbaz et al. (2011) and Magnelli et al. (2013), while both noise estimators agree for PACS, there is a systematic offset for SPIRE. The noise obtained from the residual maps in the SPIRE bands is lower than the actual uncertainty in the measurements of the | ΔS | /Sout. Typically, the 5σ detection threshold estimated from the residual maps corresponds to an effective threshold of 3σ. In order to derive a local noise estimate, one needs to use the residual maps and correct the rms by this systematic offset.

thumbnail Fig. 11

Comparison of observed S250/S24 colours for sources with flux densities between 3 <S250< 5.7 mJy selected by their associated photometry accuracy from the simulations. The median colours of sources with a good photometric accuracy | ΔS | /Sout 0.32 (black line) follow the colour trend, of clean-selected sources CI 1 (blue line) and the stacked sources (orange line) while the median colours of sources having poor photometric accuracy | ΔS | /Sout> 0.32 (red line) are systematically displaced to brighter 250 μm fluxes, an indication of blending.

Open with DEXTER

After accounting for this systematic offset, we can perform a comparison of the noise estimated by the PAI in the mock images (solid red line in Figs. 12,13) with the noise estimated on the real Herschel images from the residual maps (solid blue line). We have here directly applied the strategy described above for the real images and, without adding any correction factor, one can see that the red and blue solid lines perfectly match, confirming again that the mock Herschel images are indeed close to the real ones. We reach very similar detection limits. In Elbaz et al. (2011), the detection limits were based on the blue solid line. The red dashed line shows the S/N obtained for the clean sources only in the mock Herschel images, we can see that at 250 and 350 μm the 3σ limits are slightly deeper (~2.2 and 5 mJy).

thumbnail Fig. 12

Signal-to-noise ratio as a function of flux for extracted sources in the Herschel/PACS maps (blue), the simulated images (solid red) and for the subset of clean sources in the simulation (dashed red line). The horizontal lines marks the 3σ level. The similarity in the trends demonstrates that the simulations reproduce well the sources of noise in the real image, i.e. the faint population of 24 μm prior sources, as well as the instrumental noise. Flux limits can also be defined for the Herschel data by the 3σ limits reached by clean sources (intersection between the dashed red line and the horizontal line).

Open with DEXTER

thumbnail Fig. 13

Same as Fig. 12 but for the SPIRE bands.

Open with DEXTER

thumbnail Fig. 14

Quality of the source extraction on the mock Herschel images from a “purity” (top) and “completeness” (bottom) criterion. We present here the example of the 250 μm band. Top: purity of the sources extracted in the mock images defined as the fraction of sources with accurate photometry, i.e. | ΔS | /Sout 0.32, among the sources selected using the clean index, CI. The different lines present the sources with no bright 24 μm neighbour, CI = 0 (solid line), at most one 24 μm neighbour, CI = 1 (dashed line), at most 2 neighbours, CI = 2 (dotted line), and the full sample of sources without any filtering (dash-dotted line). Bottom: completeness of the samples selected using the CI (same definition of the lines), defined as the ratio in percentage of the number of sources filtered by the CI over the total number of sources in each flux density bin (differential completeness). The red solid line shows the completeness of the sources with PAI = | ΔS | /Sout 0.32, which are by definition associated with a 100% purity.

Open with DEXTER

7.4. Representativity of “clean” sources

We have demonstrated that the CI offered a reliable way to pre-select prior positions for which Herschel flux density measurements are obtained with a photometric accuracy better than 32%. Imposing on the list of 24 μm priors the condition that they have at most one bright neighbour in that band is an efficient method to reject galaxies with poor photometry. However, one may wonder whether this result is conditioned by the fact that we used Herschel images based on 24 μm sources only. We showed that the histograms of pixel values of the mock and real images were comparable (Figs. 9, 10), and that the S/N as a function of flux density were also comparable (Figs. 12, 13). In this section, we wish to present a complementary test that reinforces already existing evidence that selecting sources by the CI does not bias their properties, in terms of FIR over MIR colour, and to compute the completeness of such selection.

The following test has been carried out for all Herschel bands but for brevity is shown here for the 250 μm band alone. We reproduce in Fig. 11 the 250/24 colour as a function of redshift as in Fig. 1. The measure of the average 250 μm flux density obtained by mean stacking images at the positions of all 24 μm sources is the same as in Fig. 1, and shown with an orange line. It provides a reference for the typical trend of this colour. We note that the 250/24 colour presents nearly no variation with redshift because, while the redshift increases, the 250 μm band goes across the ~100 μm bump due to the thermalised big dust grains, and in parallel the 24 μm band goes across the ~8 μm PAH bump. If we select the 24 μm prior positions for which we get a PAI = | ΔS | /Sout > 0.32 in the mock Herschel image and plot in Fig. 11 the 250/24 colour measured on the real Herschel image on those positions, we get a 250/24 ratio, which is typically twice as large than the typical one (red solid line in Fig. 11). For this test, we have selected the faintest flux density bin, where the photometry is more likely to be uncertain, i.e. 3 mJy < S250 < 5.7 mJy. Even at such faint flux density levels, we find that if we instead select sources that exhibit a PAI = | ΔS | /Sout 0.32 in the mock Herschel image the colour of these sources in the real Herschel image is very close to the one obtained from stacking as shown by the solid black line in Fig. 11. This shows that the simulations do provide an efficient way to identify sources with reliable photometry among the sources that are detected in the real images. The PAI = | ΔS | /Sout is a solid reference indicator for the local confusion noise but it requires to produce realistic Herschel images and one would like to test if a systematic criterion can provide a reliable selection mechanism as well. Clean sources, identified with the CI, are shown with a solid blue line with red dots in Fig. 11. They follow with a remarkable accuracy the trend seen for the PAI = | ΔS | /Sout 0.32 and stacked sources. Therefore, selecting sources with the CI does not induce a systematic bias in their IR SED.

The quality of the source extraction done in the mock Herschel images is described in the following using two criteria: completeness and purity. The purity defines the photometric reliability of the catalogue of sources. It is measured with the PAI, i.e. the relative difference between the input flux density and the measured one, and sources are considered as “pure” if their photometric accuracy is better than 32%. The dash-dotted line in Fig. 14 top shows the purity of the whole sample of sources, i.e. using as priors all the 24 μm positions, in the case of the 250 μm band. At flux densities lower than 4 mJy, less than 68% of the sample is pure. If instead we require that prior positions be limited to only 24 μm sources with at most 2 neighbours, then this limit is reached at 3 mJy. Sources with CI ≤ 1 (i.e., having at most one bright neighbour), are pure for 68% of them at 2.5 mJy. Asking CI = 0, does not improve this limit on the purity of the sample.

The second criteria, completeness, quantifies the fraction of sources detected in comparison with the total number of sources that have been injected in the mock Herschel images. The dotted line Fig. 14 bottom, which presents the CI ≤ 2 condition, is obviously the one with the largest completeness, but at the expense as discussed above of a worse purity. In other words, adding sources by allowing to go from CI = 1 (dashed line) to CI = 2 (dotted line) enhances the completeness by adding sources with a photometric accuracy worse than 32%, the limit that we have here defined as that of “pure galaxies”. The solid red line in Fig. 14 bottom shows the fraction of sources that are detected with a PAI ≤ 0.32, i.e., the fraction of pure sources among all measurements at the positions of the priors. If the mock Herschel images were exactly reproducing the amount of noise that each source suffers from then we could use the positions of these pure sources to obtain the best completeness in the catalogue of sources built out of the real Herschel image. However, we can also see that by requiring systematically CI ≤ 1 (dashed line), we get a completeness that is not so bad in comparison and which is much better than the CI = 0 request.

In conclusion, the best compromise to optimise the best purity for the largest completeness appears to be the requirement of CI ≤ 1. We note, however, that the completeness correction factors estimated from the simulations is only a lower limit, in the case of SPIRE particularly, since the mock Herschel images were built from a list of 24 μm priors hence miss a potential population of sources below the 24 μm detection limit.

8. Resolving the cosmic infrared background with GOODS-Herschel

The realistic mock Herschel images have helped us calibrate the robustness of the source extraction above a limiting depth, where more than 68% of the sources are detected with a photometric accuracy better than 32%. They also provide a way to estimate the completeness of the catalogues extracted above this depth as a function of flux density and thus to correct for incompleteness the contribution of Herschel sources to the CIRB down to the local confusion limit (~2 mJy), which is nearly ten times deeper than the global confusion limit (~20 mJy).

While statistical studies provide estimates of the amount of EBL due to galaxies (Patanchon et al. 2009; Dole et al. 2006; Marsden et al. 2009; Béthermin et al. 2010; Glenn et al. 2010; Béthermin & Dole 2011; Berta et al. 2011; Béthermin et al. 2012), they do not allow the study of the properties of the galaxies making this contribution. Using the method of the PAI and/or CI described above to identify sources at the faintest levels in the Herschel maps and correcting their contribution to the EBL from their incompleteness as estimated from simulations (as a lower limit), we can study a greater population of galaxies making a stronger contribution to the EBL than extraction methods relying on a single wavelength and at the same time have the possibility to study the nature of these individual galaxies.

Table 2

Summary of the resolved IGL, its contribution to the CIRB down to specific flux density limit Slim in each SPIRE band for the GOODS-North field.

thumbnail Fig. 15

Cumulative contribution to the CIRB of the IGL as function of the flux density limit in 100 μm (violet), 160 μm (blue), 250 μm (green), 350 μm (orange), and 500 μm (red) in the GOODS north field. Dashed lines show the cumulative flux density directly from the observed GOODS-Herschel sources and the solid lines are the same but corrected by completeness from the simulations in this work. Resolved (Berta et al. 2010; Oliver et al. 2010; Berta et al. 2011; Magnelli et al. 2013), stacked (Berta et al. 2010; Béthermin et al. 2012) and P(D) results (Berta et al. 2011) at different adopted Slim are also shown for comparison, as well as IGL predictions for Herschel based on a model of multi-wavelength galaxy counts (Le Borgne et al. 2009). Horizontal dashed bands show the total extrapolated CIRB in the SPIRE bands adopted from Béthermin et al. (2012) using the same colour coding than for the curves and their widths represent the limits of the errors. In the case of PACS total values, vertical thick bars mark the error in the extrapolations of the CIRB calculated by Berta et al. (2011).

Open with DEXTER

8.1. Integrated galaxy light: fraction of the CIRB resolved in individual detections

The combined contribution of individual sources to the CIRB is the integrated galaxy light (IGL), which can be expressed in its differential form as: (14)where dN(sr-1) is the surface density of sources with flux density Sband in mJy over a flux bin dS(mJy) and νband in Hz is the frequency in a given FIR bandpass. The constant 1020 appears after the conversion of 1 mJy = 10-20 nWm-2 Hz-1. Integrating Eq. (14) down to the Slim, we obtain the IGL in units of nWm-2 sr-1. Our IGL measurements correspond to high fractions of the CIRB down to very deep flux limits compared with other estimations.

We have compared the estimates of the amount of EBL produced by individual galaxies resolved by Herschel coming from the PAI and CI techniques and found that they were consistent within less than 5%. We present here the values obtained using the CI alone since it does not rely on the assumptions on redshifts and SEDs used to produce the simulations.

We first compute the cumulative contribution of all “clean” sources individually detected above the Herschel flux limits – numbers in italics on the second line at each wavelength in Table 2. Then, we correct these numbers for completeness using the correction factors derived from our realistic mock Herschel images and obtain the values listed in bold letters in the Table 2. For example, over a total of 971 sources injected in the mock Herschel image at 250 μm above a flux limit of mJy, the algorithm detects 398 sources above mJy that are classified as clean (i.e. have at most one bright neighbour at 24 μm). Therefore, the completeness of our clean list is Ncompl = 41 % in number of sources and IGLcompl = 61 % in the contribution to the IGL (higher than Ncompl since detect the brightest sources).

Table 3

Summary of the number of sources and beams involved in the simulations, as well as in the Herschel maps.

In comparison with the commonly used definition of the confusion limit (e.g. 40 beams/source in Nguyen et al. 2010), we have also computed the equivalent of our confusion limits in numbers of beams/source. Various papers have used different definitions of the beam size, here we use a definition of the beam area matching the ones used in Dole et al. (2003) and Oliver et al. (2010) for consistency in the comparison: Abeam = π × (0.73 × FWHM)2. The beam size at 250 μm is 0.154 arcmin2 and the number density of clean detections is equivalent to 3 beams/source, knowing that this level was reachable only by the use of the shorter bands to allow the identification of robustly determined photometric measurements. We list in Table 3 these numbers for all 5 Herschel bands.

The resulting background estimated in nW m-2 sr-1 are then compared to estimates of the EBL at these wavelengths, in order to determine the resolved fraction of the CIRB. Two options exist for this comparison that consists in using as reference values either the COBE measurements or statistical extrapolations of Herschel counts using stacking and P(D) analysis. Error bars on the COBE values are larger, especially at 100 μm, where the correction for zodiacal light is highly uncertain, hence we use here extrapolated values from (a)Berta et al. (2011) and by (b)Béthermin et al. (2012) (listed in the last column of Table 2) as a reference to compute fraction of the resolved CIRB.

In the PACS 100 and 160 μm bands, sources brighter than 1.1 and 2.2 mJy make around 5060% of the CIRB at these wavelengths as compared to the ~75% obtained by Magnelli et al. (2013) counting sources down to 0.6 and 1.3 mJy in GOODS-South. However, thanks to our Herschel mock image we are able to correct these values obtained for clean sources for incompleteness. After having applied this correction, we get fractions of the resolved CIRB of 54% and 60%, which are comparable to the ones obtained using stacking and P(D) analysis as shown in Fig. 15. This is also true for the SPIRE bands, since in both cases, PACS and SPIRE, our estimates shown with solid coloured lines (after completeness correction) can easily be extended by eye to the symbols showing the locus of statistical estimates using stacking and P(D) analysis.

Table 4

Summary of the median z and flux-weighted average redshift zf, as well as the median M and the flux-weighted stellar mass Mf of the galaxy population that produce the resolved IGL down to specific flux density limit Slim in each SPIRE band found based on the simulations of the GOODS-North field.

The most remarkable improvement of our method can be seen in the SPIRE bands, where we resolve 55, 33, and 13% of the background light at 250, 350, and 500 μm with individually detected sources thanks to the use of our estimate of the “local confusion noise” as compared to 15, 12, and 5% as measured by Oliver et al. (2010) and Béthermin et al. (2012) with the global confusion limit of ~20 mJy. Our approach has allowed us to resolve in individual galaxies 3.5 times more EBL at 250 μm and more than ~3 times at 350 and 500 μm.

thumbnail Fig. 16

Distributions in redshift (left) and stellar mass (right) of the sources responsible for 55% of the CIRB at 250 μm. Vertical dashed lines show the median of the distributions.

Open with DEXTER

We present in Fig. 15 our estimates of the IGL both before (dashed lines) and after (solid lines) correcting for completeness. Direct measurements from Berta et al. (2010, 2011), Magnelli et al. (2013) for PACS and (Oliver et al. 2010; Béthermin et al. 2012) for SPIRE are show for comparison with filled symbols, while extrapolations with stacking and P(D) analysis are shown with open symbols. We also present expectations of the IGL fractions predicted for Herschel based on a model of multi-wavelenth galaxy counts by Le Borgne et al. (2009).

We compared our resolved IGL fractions to the ones predicted by the backward evolution model of Béthermin et al. (2011), which reproduces galaxy counts in all Herschel bands. In this paper, the authors calculate the confusion limit expected for different telescope diameters in the FIR using the criterion defined in Dole et al. (2003) by requiring sources to be brighter than 5σphotometric, where σphotometric is the noise due to the fluctuations induced by the sources below this detection limit, and such that less than 10% of the sources have a neighbour closer than 0.8 × FWHM above that detection limit. The standard global confusion limit fits the predictions of the model for a 3.5 m class telescope, but our improved depths in the 250 μm band correspond to the standard confusion limit of a telescope with an aperture close to ~10 m (see Fig. 14 and Table 8 in Béthermin et al. 2011).

8.2. Nature of the sources making the CIRB

We present here the characteristic redshift and stellar mass of the galaxies that make the resolved fraction of the CIRB described in the previous section. We provide two methods to estimate these characteristic values, the median – z and M – and flux weighted average – zf and Mf computed following Eqs. (15), (16). where Si are the flux densities of the sources contributing to the CIRB for a Herschel band centred at λ.

The IGL in the PACS and SPIRE bands to the CIRB, as well as the typical redshifts and stellar mass of the galaxies contributing to the CIRB are summarised in Table 2. We see that the typical redshift of the galaxies responsible for a dominant contribution to the infrared background light increases with increasing wavelength. This is naturally expected as a result of k-correction, since the peak emission of the IR SED of individual galaxies, like e.g. the closest starburst galaxy M 82, lies around 80 μm (with a moderate Tdust variation). Thus, the peak of the IR background around 140160 μm is expectedly produced by galaxies around z ~ 0.9. Increasing the wavelength, sources at larger redshifts contribute a larger contribution with respect to this redshift, hence we observe the increasing redshift to z ~ 1.3 in the higher wavelength bands.

Our median redshifts in 100 and 160 μm are consistent with the results of Magnelli et al. (2013) using the PEP/GOODS-Herschel data who obtained z = 0.85 for sources S100 μm> 1.5 mJy, and for sources S160 μm> 2.5 mJy (see also Berta et al. 2010, 2011). In the case of the SPIRE bands (see Fig. 16 left), Béthermin et al. (2012) found that half of the CIRB is emitted at the typical redshifts of 1.04, 1.20, and 1.25 for 250, 350, and 500 μm, respectively, by staking data in COSMOS and GOODS-north as part of the HerMES. This increasing trend in redshift in the higher wavelengths band is also consistent with our results in the SPIRE bands, while we find larger median redshift in 500 μm.

Thanks to our method, it is now possible to study the individual galaxies responsible for the peak of the CIRB around 250 μm. The major difference and strength of our approach with respect to other methods (e.g. stacking) is the fact that we are identifying the contribution of each individual galaxy to the background instead of studying the average contribution of populations of galaxies. This is important for studies based on large galaxy samples. For example, Daddi et al. (2007b,a) reported that, based on stacking, z = 2 sources with a “MIR excess” were powered by AGNs in the MIR. However, this excess was coming only from a population of about 30% of the sources that were indeed powered by AGNs and numerous enough to make a strong signal in the stacking. It was impossible from the stacking alone to know if the characteristics found could be applied to 30% or 100% of the sources.

We present in Fig. 16 their redshift and stellar mass distributions. Both distributions are well peaked, and it is quite interesting to see that the stellar mass distribution peaks at a value of M ~ 9 × 1010M, close to the mass of the Milky Way with a narrow dispersion of only 0.3 dex in log10. Interestingly the same happens in the other bands, which present a similar characteristic mass. The redshift peak is at z ~ 0.95.

In consequence, most of the CIRB is due to the radiation of siblings of the Milky Way around 7.5 billion years ago. This finding is in agreement with the fact that the stellar mass function of star-forming galaxies does not seem to vary strongly with redshift up to z ~ 2 (Bell et al. 2003, 2007; Pozzetti et al. 2010; Ilbert et al. 2010) and with the statistical analysis done using stacking of galaxy populations by Viero et al. (2013).

9. Conclusions

The main conclusions of this work are summarised below:

  • We have developed a method to robustly predict FIR fluxes basedon the knowledge of their redshift and emission at shorterwavelengths starting from 24 μm.

  • Using those predicted FIR fluxes, we were able to build realistic simulated Herschel images of the GOODS-North that we showed to robustly reproduce the confusion noise present in the real Herschel maps.

  • We showed that the extrapolation of the FIR emission of 24 μm sources detected down to 20 μJy make up enough signal in the mock images to sharply reproduce the pixel distribution of the observed Herschel maps, suggesting that the bulk of the confusion noise, even fainter than the detection limits, is included in the mock images.

  • We used the difference between the extracted photometry of sources in the simulated images and the input fluxes used to make the mock images – the PAI – to determine the degree of local confusion in the GOODS-Herschel maps, i.e. the photometric uncertainty at each specific position on the mosaics.

  • We validate the CI approach (Hwang et al. 2010; Elbaz et al. 2010) that identifies clean and confusion dominated Herschel sources from the local environment of 24 μm sources clean sources in the GOODS-Herschel data based on the quantification of the number of contaminating close neighbours to a given source. We confirm that the optimal selection rule for clean sources is when CI ≤ 1. While the CI identifies sources that respect the PAI criterion (| ΔS | /Sout 0.32), the mock Herschel images combined with the PAI allow one to identify reliable sources with a stronger completeness and to set deeper flux density limits for the data in the SPIRE bands.

  • After correcting for incompleteness, the emission of sources detected with our approach in the GOODS-North field, we find that galaxies individually detected by Herschel down to 1.1 mJy at 100 μm and 2.2 mJy at 160 μm make up as much as 54% and 60% of the EBL, whereas down to 2.5, 5, and 9 mJy sources produce 55, 33, and 13.0% of the EBL at 250 μm, 350 μm, and 500 μm, respectively.

  • Interestingly we find that the dominant contributors to the CIRB in all Herschel bands appear to be galaxies analogous to the Milky Way in stellar mass with M ~ 9 × 1010M reinforcing the idea of a dominant dark matter halo mass in which stars formed over the Hubble time (Conroy & Wechsler 2009; Béthermin et al. 2013).


1

Herschel Multi-tiered Extragalactic Survey.

2

PACS Evolutionary Probe (PEP) guaranteed-time Survey.

3

As explained in Sect. 5 of Magnelli et al. (2013), although the 3σ detection limit is 1.3 mJy at 160 μm, sources below 2 mJy are affected by confusion, hence reliable individual detections are limited to a depth of 2 mJy rather than 1.3 mJy.

4

Publicly available at http://code.google.com/p/EAZY-photoz

6

This factor 2 combines two effects: (i) each half-map contains half of the exposure time, hence a noise level that is  larger than the real noise map; (ii) when we subtract the two half-maps, the noise is combined quadratically hence becomes larger by another factor . The two effects combine to make the resulting noise map twice noisier than the real map, consequently the signal in that map needs to be divided by two to mimic the real instrumental noise map.

Acknowledgments

The authors would like to thank the referee for their valuable comments, which helped to improve the manuscript. R.L. acknowledges the financial support from FONDECYT through grant 3130558 and CEA-Saclay. This research was supported by the French Agence Nationale de la Recherche (ANR) project ANR-09-BLAN-0224. D.E. acknowledges the contribution of the FP7 SPACE project ASTRODEEP (Ref. No. 312725), supported by the European Commission.

References

All Tables

Table 1

Full width half maximum of the point spread function of the Spitzer IRAC and MIPS bands (upper part), and Herschel PACS and SPIRE bands (lower part).

Table 2

Summary of the resolved IGL, its contribution to the CIRB down to specific flux density limit Slim in each SPIRE band for the GOODS-North field.

Table 3

Summary of the number of sources and beams involved in the simulations, as well as in the Herschel maps.

Table 4

Summary of the median z and flux-weighted average redshift zf, as well as the median M and the flux-weighted stellar mass Mf of the galaxy population that produce the resolved IGL down to specific flux density limit Slim in each SPIRE band found based on the simulations of the GOODS-North field.

All Figures

thumbnail Fig. 1

Redshift evolution of the mid-to-far infrared colours of Herschel galaxies. Each plot shows the ratio of the observed Herschel over MIPS-24 μm flux densities as a function of redshift. Figures on the left column show the colours from the observed Herschel measurements. Figures on the right column show the same dataset but after having corrected the 160 to 500 μm over 24 μm ratios of the individual galaxies by the offset observed in the 100 to 350 μm shorter wavelength bands. The points indicate the positions of individually detected sources separated in 3 populations, depending on the presence of bright 24 μm neighbours (i.e. with a S24 μm greater than half of the central source) in their close environment (at a distance of 12′′for PACS and 20′′for SPIRE). This number is the “clean index”, CI. Filled red dots: galaxies with no bright neighbours (CI = 0); filled green dots: galaxies with at most one bright neighbour (CI ≤ 1); open circles: remaining 3σ sources (CI ≥ 2). The sliding median of the CI = 0 galaxies is shown with a blue line and blue circles with central red dots. The trends for the mean stacking at the positions of the 24 μm prior sources brighter than 50 μJy are illustrated with orange lines. The yellow line corresponds to the best-fit relations described in Eq. (1) to (5) of Sect. 5 that fit the sliding median. The colours obtained for the IR spectral energy distributions of the library of Magdis et al. (2012, black dotted line) and the main sequence SED of Elbaz et al. (2011) are shown for comparison.

Open with DEXTER
In the text
thumbnail Fig. 2

Histogram showing the number of 24 μm sources as a function of flux density in bins of 0.05 dex (black curve). The coloured lines show the number of 24 μm sources in the same flux density bins that are detected by Herschel at 100 to 500 μm.

Open with DEXTER
In the text
thumbnail Fig. 3

Residuals of colour index Herschel band minus MIPS-24 μm. with respect to the best-fit relations as a function of redshift. Upper panel: residuals for the observed colour index. The 68% dispersion around the median is equal to [0.17, 0.16, 0.18, 0.21, 0.31] dex for the five Herschel bandpasses when accounting for redshift ranges in the best-fit equations, while it would have been [0.20, 0.18, 0.20, 0.33, 0.42] without separating galaxies in redshift slices. Lower panel: dispersion after accounting for the offset measured at shorter wavelengths, e.g. correcting S160 μm/S24 μm by the distance of S100 μm/S24 μm to the median, the dispersion in colour indices becomes as small as [0.14, 0.12, 0.13, 0.19] at [160, 250, 350, 500] μm, respectively (no correction can be applied to the 100 μm band obviously). The correction process reduces the dispersion of the colour distribution because that variation is physical and not due to noise in the measurements.

Open with DEXTER
In the text
thumbnail Fig. 4

Selected area of the real (left) and the simulated maps (right) for GOODS-North field in 250 μm. Each stamp is ~ 9′ × 9′ (see Sect. 6).

Open with DEXTER
In the text
thumbnail Fig. 5

Histogram of the flux distribution of pixels for Herschel maps and simulated mock images: observed (black), best-fit (red), and iteratively corrected (blue) fluxes. The corresponding pixel distribution of the noise maps used in the simulations are also presented (dashed lines). The panels below each histogram show residuals coming from ratio of the iteratively corrected map to the observed Herschel map after subtracting the instrumental noise as a function of the flux density. The ratio varies around 1 along the flux bins. The similarity between the observed and mock images is remarkable in particular in the flux bins where most of galaxies contributing to the CIRB are present (see Sect. 8).

Open with DEXTER
In the text
thumbnail Fig. 6

Same as Fig. 5 but for 250 μm (upper panel); 350 μm (middle panel), and 500 μm (lower panel).

Open with DEXTER
In the text
thumbnail Fig. 7

Residual images in GOODS-North field after source extraction using 24 μm priors in each band. The maps show how efficient is the extraction process in the area covered by the prior catalogue (blue rectangle), showing only very few cases where the remnants of bright sources badly subtracted are still present in the SPIRE residual maps (black spots).

Open with DEXTER
In the text
thumbnail Fig. 8

Number (lower panels) and fraction (upper panels) of 24 μm sources having a SPIRE counterpart (red) and those with no associated SPIRE detection as a function of the flux density in 250 μm (left panel), 350 μm (central panel), and 500 μm bands (right panel). Vertical lines show the flux limits reached using the simulations found in the present work 2.5 mJy for 250 μm  5.0 mJy for 350 μm, and 9.0 mJy for 500 μm. (See Sect. 7.1 for more details of how these flux limits were obtained.) Consequently, the missing 24 μm population at the flux limits of the simulations is very marginal.

Open with DEXTER
In the text
thumbnail Fig. 9

Photometric accuracy index, ΔS/Sout= (SoutSin) /Sout, as a function of the output flux Sout. The median trend of | ΔS | /Sout is shown by the blue line and the red envelope lines contains the 68% of the clean galaxies, i.e. sources associated with a 24 μm source having a CI ≤ 1 (green dots). Dotted horizontal lines at | ΔS | /Sout 0.32 mark the limits that define sources having good photometry. The intersection between the 68% envelope line and the good photometry limit defines the depths for Herschel data based on the simulations (vertical dashed lines; 1.1 mJy, 2.2 mJy, 2.5 mJy, 5.0 mJy, and 9.0 mJy for the 100 μm, 160 μm, 250 μm, 350 μm, and 500 μm Herschel bands, respectively). The histograms on the bottom and right sides of each panel show the distribution of the whole sample of galaxies (dotted line), the clean galaxies (solid green line) and the complementary non-clean galaxies (solid black line) as a function of the flux density (horizontal histogram), and as a function of ΔS/Sout (vertical histogram). The comparison of the solid green and dotted lines shows that the proportion of clean sources remain identical in all flux density bins, i.e., there is no bias against faint or bright sources when dealing with clean sources alone.

Open with DEXTER
In the text
thumbnail Fig. 10

Same as Fig. 9 but for 250 μm (upper panel), 350 μm (middle pannel), and 500 μm (lower panel).

Open with DEXTER
In the text
thumbnail Fig. 11

Comparison of observed S250/S24 colours for sources with flux densities between 3 <S250< 5.7 mJy selected by their associated photometry accuracy from the simulations. The median colours of sources with a good photometric accuracy | ΔS | /Sout 0.32 (black line) follow the colour trend, of clean-selected sources CI 1 (blue line) and the stacked sources (orange line) while the median colours of sources having poor photometric accuracy | ΔS | /Sout> 0.32 (red line) are systematically displaced to brighter 250 μm fluxes, an indication of blending.

Open with DEXTER
In the text
thumbnail Fig. 12

Signal-to-noise ratio as a function of flux for extracted sources in the Herschel/PACS maps (blue), the simulated images (solid red) and for the subset of clean sources in the simulation (dashed red line). The horizontal lines marks the 3σ level. The similarity in the trends demonstrates that the simulations reproduce well the sources of noise in the real image, i.e. the faint population of 24 μm prior sources, as well as the instrumental noise. Flux limits can also be defined for the Herschel data by the 3σ limits reached by clean sources (intersection between the dashed red line and the horizontal line).

Open with DEXTER
In the text
thumbnail Fig. 13

Same as Fig. 12 but for the SPIRE bands.

Open with DEXTER
In the text
thumbnail Fig. 14

Quality of the source extraction on the mock Herschel images from a “purity” (top) and “completeness” (bottom) criterion. We present here the example of the 250 μm band. Top: purity of the sources extracted in the mock images defined as the fraction of sources with accurate photometry, i.e. | ΔS | /Sout 0.32, among the sources selected using the clean index, CI. The different lines present the sources with no bright 24 μm neighbour, CI = 0 (solid line), at most one 24 μm neighbour, CI = 1 (dashed line), at most 2 neighbours, CI = 2 (dotted line), and the full sample of sources without any filtering (dash-dotted line). Bottom: completeness of the samples selected using the CI (same definition of the lines), defined as the ratio in percentage of the number of sources filtered by the CI over the total number of sources in each flux density bin (differential completeness). The red solid line shows the completeness of the sources with PAI = | ΔS | /Sout 0.32, which are by definition associated with a 100% purity.

Open with DEXTER
In the text
thumbnail Fig. 15

Cumulative contribution to the CIRB of the IGL as function of the flux density limit in 100 μm (violet), 160 μm (blue), 250 μm (green), 350 μm (orange), and 500 μm (red) in the GOODS north field. Dashed lines show the cumulative flux density directly from the observed GOODS-Herschel sources and the solid lines are the same but corrected by completeness from the simulations in this work. Resolved (Berta et al. 2010; Oliver et al. 2010; Berta et al. 2011; Magnelli et al. 2013), stacked (Berta et al. 2010; Béthermin et al. 2012) and P(D) results (Berta et al. 2011) at different adopted Slim are also shown for comparison, as well as IGL predictions for Herschel based on a model of multi-wavelength galaxy counts (Le Borgne et al. 2009). Horizontal dashed bands show the total extrapolated CIRB in the SPIRE bands adopted from Béthermin et al. (2012) using the same colour coding than for the curves and their widths represent the limits of the errors. In the case of PACS total values, vertical thick bars mark the error in the extrapolations of the CIRB calculated by Berta et al. (2011).

Open with DEXTER
In the text
thumbnail Fig. 16

Distributions in redshift (left) and stellar mass (right) of the sources responsible for 55% of the CIRB at 250 μm. Vertical dashed lines show the median of the distributions.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
