Sensitivity of gravitoinertial modes to differential rotation in intermediatemass mainsequence stars
^{1}
Institute of Astronomy, KU Leuven, Celestijnenlaan 200D, 3001 Leuven, Belgium
email: timothy.vanreeth@sydney.edu.au
^{2}
Kavli Institute for Theoretical Physics, University of California, Santa Barbara, CA, 93106
USA
^{3}
Sydney Institute for Astronomy (SIfA), School of Physics, University of Sydney, New South Wales, 2006 Australia
^{4}
Department of Astrophysics, IMAPP, Radboud University Nijmegen, PO Box 9010 6500 GL Nijmegen, The Netherlands
^{5}
Laboratoire AIM ParisSaclay, CEA/DRFUniversité Paris DiderotCNRS, IRFU/SAp Centre de Saclay, 91191 GifsurYvette, France
^{6}
TAPIR, Walter Burke Institute for Theoretical Physics, Mailcode 35017, Caltech, Pasadena, CA, 91125 USA
^{7}
LESIA, Observatoire de Paris, PSL Research University, CNRS, Sorbonne Universités, UPMC Univ.Paris 6, Univ. Paris Diderot, Sorbonne Paris Cité, France
^{8}
Department of Theoretical Physics and Cosmology, University of Granada (UGR), 18071 Granada, Spain
^{9}
Instituto de Astrofísica e Ciências do Espaço, Universidade do Porto, CAUP, Rua das Estrelas, 4150762 Porto, Portugal
^{10}
Department of Astronomy, University of WisconsinMadison, 475 Charter Street, Madison, WI, 53706 USA
Received:
26
January
2018
Accepted:
26
June
2018
Context. While rotation has a major impact on stellar structure and evolution, its effects are not well understood. Thanks to highquality and longtime base photometric observations obtained with recent space missions, we are now able to study stellar rotation more precisely.
Aims. We aim to constrain radial differential rotation profiles in γ Doradus (γ Dor) stars, and to develop new theoretical seismic diagnosis for such stars with rapid and potentially nonuniform rotation.
Methods. We have derived a new asymptotic description which accounts for the impact of weak differential nearcore rotation on gravitymode period spacings. The theoretical predictions are illustrated from pulsation computations with the code GYRE and compared with observations of γ Dor stars. When possible, we also derived the surface rotation rates in these stars by detecting and analysing signatures of rotational modulation, and computed the coretosurface rotation ratios.
Results. Stellar rotation must be strongly differential before its effects on period spacing patterns can be detected, unless multiple period spacing patterns can be compared. Six stars in our sample exhibit a single unexplained period spacing pattern of retrograde modes. We hypothesise that these are Yanai modes. Finally, we find signatures of rotational spot modulation in the photometric data of eight targets.
Conclusions. If only one period spacing pattern is detected and analysed for a star, it is difficult to detect differential rotation. A rigidly rotating model will often provide the best solution. Differential rotation can only be detected when multiple period spacing patterns have been found for a single star or its surface rotation rate is known as well. This is the case for eight of the stars in our sample, revealing surfacetocore rotation ratios between 0.95 and 1.05.
Key words: asteroseismology / methods: data analysis / stars: fundamental parameters / stars: variables: general / stars: oscillations / stars: rotation
© ESO 2018
1. Introduction
Rotation is a crucial element of stellar structure and evolution (e.g. Maeder 2009; and references therein). It induces and influences various types of angular momentum transport and chemical mixing processes inside the star, such as shear mixing (e.g. Heger et al. 2000; Mathis et al. 2004; Maeder et al. 2013), meridional circulation (e.g. Zahn 1992; Maeder & Zahn 1998; Mathis & Zahn 2004) and waves (e.g. Lee & Saio 1993; Talon & Charbonnel 1998, 2005; Mathis 2009; Rogers 2015). These lead to additional transport of fuel into the nuclear burning regions, influencing the nucleosynthesis and extending the life of the star (e.g. Zahn 1992; Pinsonneault 1997; Maeder & Meynet 2000). The mixing processes also have a potential impact on the element abundances at the stellar surface (e.g. Brott et al. 2011a,b). Furthermore, stellar rotation has a strong influence on stellar magnetism (e.g. Mestel 1999; Spruit 1999) and vice versa (e.g. Mestel et al. 1988; Spruit 1999; Mathis & Zahn 2005). The centrifugal acceleration distorts the shape of the star (e.g. Roxburgh 2004, 2006; Jackson et al. 2005; MacGregor et al. 2007; Espinosa Lara & Rieutord 2013), and the distribution of angular momentum influences the convective stability inside the star (e.g. Maeder et al. 2013).
The full impact of stellar rotation is far from understood (e.g. Aerts et al. 2014; Cazorla et al. 2017). While there have been considerable efforts to carry out multidimensional stellar modelling (e.g. Rieutord et al. 2016), these have often had a high computational cost. Hence, modern stellar evolution codes typically use onedimensional stellar models in which higher dimensional processes such as stellar rotation are averaged over isobars (e.g. Chaboyer et al. 1995; Heger et al. 2000; Eggenberger et al. 2008; Ekström et al. 2012; Chieffi & Limongi 2013; Paxton et al. 2013; Marques et al. 2013; Palacios et al. 2003; Charbonnel & Lagarde 2010; Amard et al. 2016). This approach is often incomplete, and potentially numerically unstable (e.g. Lau et al. 2014; Lattanzio et al. 2015; Rieutord et al. 2016; Edelmann et al. 2017).
Thanks to recent photometric space missions such as MOST (Walker et al. 2003), CoRoT (Auvergne et al. 2009), Kepler (Borucki et al. 2010; Koch et al. 2010), K2 (Howell et al. 2014), and BRITE (Weiss et al. 2014; Pablo et al. 2016), there has been significant progress in constraining stellar rotation using observations. These highquality highcadence and long time base data have led to major advances in asteroseismology, in other words, the study of the internal stellar structure, dynamics and evolution by analysing nonradial stellar pulsations. This has been particularly successful for lowmass mainsequence stars that have radiative cores and convective envelopes (e.g. Benomar et al. 2015; van Saders et al. 2016), subgiants (e.g. Deheuvels et al. 2014), and red giants (e.g. Beck et al. 2012; Deheuvels et al. 2012; Ceillier et al. 2017). However, asteroseismology is also a valuable tool to study intermediate to highmass mainsequence stars with convective cores and radiative envelopes.
Gamma Doradus (γ Dor) stars, with 1.4 M_{⊙} ≲ M_{*} ≲ 2.0 M_{⊙}, and slowlypulsating Btype (SPB) stars, with 2.5 M_{⊙} ≲ M_{*} ≲ 8 M_{⊙}, exhibit highorder gravitymode (gmode) pulsations, gravitoinertial pulsations (Van Reeth et al. 2016), and/or purely inertial pulsations, such as rmodes (Saio et al. 2018). The restoring forces for gravitymodes and purely inertial pulsation modes are buoyancy and the Coriolis force, respectively. In the case of gravitoinertial pulsation modes, both forces contribute. As predicted by asymptotic theory, the pulsation periods for γ Dor and SPB stars were observed to form period spacing patterns (e.g. Chapellier et al. 2012; Chapellier & Mathias 2013; Kurtz et al. 2014; Bedding et al. 2015; Saio et al. 2015; Van Reeth et al. 2015; Ouazzani et al. 2017). The pulsation periods are equidistant in the asymptotic regime (with radial order n ≫ spherical degree l) for a nonrotating chemically homogeneous star (Tassoul 1980). Chemical gradients in the deep stellar interior cause pulsation mode trapping, which introduces nonuniform variations in the spacings (Miglio et al. 2008). On the other hand, the stellar rotation leads to shifts in the observed pulsation mode frequencies (Bouabid et al. 2013; Salmon et al. 2014; Van Reeth et al. 2015; Moravveji et al. 2016). For slowly rotating stars, the observed pulsation modes are split into frequency multiplets that depend on the mode identification. For moderate to fast rotators, that is, with rotation in the order of or more than 20% of the critical rotation rate, the observed period spacing patterns have a clear slope (e.g. Van Reeth et al. 2016; Ouazzani et al. 2017). Prograde (azimuthal order m > 0) and zonal modes have a downward slope, that is, the spacing between consecutive pulsation periods decreases with increasing pulsation period, i.e. radial order n. The period spacing patterns of retrograde modes (with m < 0) mostly have an upward slope. For stars with detected period spacing patterns, this has been exploited to derive the nearcore stellar rotation (e.g. Kurtz et al. 2014; Saio et al. 2015, 2018; Triana et al. 2015; Murphy et al. 2016; Schmid & Aerts 2016; Van Reeth et al. 2016; Ouazzani et al. 2017).
It is often assumed that these stars are (quasi)rigidly rotating. Notable exceptions are (i) the analysis of the slowly rotating Btype star KIC 10526294 (Triana et al. 2015), whereby the impact of differential rotation on the pulsation mode splitting was studied, or (ii) the analysis of hybrid γ Dor/δ Sct pulsators that exhibit both gmode and pmode pulsations (e.g. Kurtz et al. 2014). If the pmode pulsation spectrum is sufficiently regular, it can be analysed to derive the surface rotation rate (e.g. Kurtz et al. 2014; Saio et al. 2015; Schmid & Aerts 2016; Paparó et al. 2016a,b).
In this work, we aim to constrain possible radial differential rotation in γ Dor stars. We have studied the problem using two different approaches. First, we took a closer look at the theoretically expected effects of differential rotation in the nearcore regions on the gmode pulsations (Sect. 2.1 and Appendix A), and used them to place a constraint on the differential rotation of observed γ Dor stars (Sect. 2.3). Second, we determined the coretosurface rotation ratio for stars in the same sample using rotational spot modulation (Sect. 3) to constrain the stellar surface rotation rate. Finally, we discuss these results, and draw our conclusions (Sect. 4).
2. Differential rotation in the nearcore regions
2.1. Theoretical description of the gmodes
Computing the complete impact of stellar rotation on pulsations is computationally expensive (Dintrans & Rieutord 2000; Ballot et al. 2010). A common method to reduce this computational cost for gmode pulsations is to use the traditional approximation of rotation (TAR), whereby (i) the horizontal component of the stellar rotation vector in the equation of motion is ignored, and (ii) the studied star is assumed to be spherically symmetric (e.g. Eckart 1960; Friedlander 1987; Lee & Saio 1987, 1997; Townsend 2005; Mathis 2009; and Appendix A). For slow to moderate rotators for which the stratification restoring force dominates the Coriolis acceleration along the radial direction, these assumptions are reasonable. The horizontal component of the pulsation displacement vector (and velocity) is dominant for gmodes, which are most sensitive to the nearcore regions in the star where the deformation of the stellar structure caused by the centrifugal force is minimal.
When the star is assumed to be rigidly rotating, the gmode pulsation periods in the corotating reference frame are given by(1)
as described by Bouabid et al. (2013). Here, N is the stable stratification BruntVäisälä frequency defined in Appendix A, λ_{νkm} is the eigenvalue of the Laplace tidal equation, and ν the corresponding spin parameter given by ν = 2f_{rot}P_{co}, with the rotation frequency (Ω being the rotation angular velocity). The integers k and m provide the pulsation mode identification as defined by Lee & Saio (1997), i.e. k = l − m for gmodes, whereby l is the spherical degree of the pulsation mode, and k < 0 for purely inertial modes; n is the integer corresponding to the quantification along the radial direction. α_{g} is a phase term dependent on the stellar structure at the boundaries of the pulsation mode cavity. For stars with a convective core and convective envelope, α_{g} ≃ 0.5. The turning points of the pulsation mode cavity are indicated by r_{1} and r_{2}.
Equation (1) can be generalised for purely radial differential rotation (the socalled shellular rotation), where the angular velocity is a function of r only. Using the asymptotic theory for the propagation of lowfrequency gravitoinertial modes in differentially rotating stars developed by Mathis (2009; see also Ogilvie & Lin 2004) and detailed in Appendix A, one can show that(3)
where f_{in} is the frequency of the pulsation with mode identification (n, k, m) as seen by the observer in the inertial reference frame. Here, both the eigenvalue λ_{νkm}(r) and the rotation profile f_{rot}(r) vary as a function of the radial coordinate r, and are included within the integral.
We see from Eq. (3) that small variations in the stellar rotation profile or in the BruntVäisälä frequency profile have a comparable effect on the pulsation frequencies. This can be illustrated by the case of a weak radial differential rotation defined as in Mathis et al. (2008) (4)
In this case, Eq. (3) becomes(5)
where , and ϵ(r)=m ^{⋆} δ f_{rot}(r)/f_{co}.
In addition, we can further explore the impact of differential rotation, by rewriting Eq. (3) using Taylor expansions for and (f_{in} − m f_{rot} (r))^{−1} at a radial coordinate r_{s}, where the sensitivity of the gmodes to the stellar structure is dominant. This leads to(6)
Here the quantity x_{s} denotes the value of the quantity x at the radial coordinate , and(7)
The pulsation frequency in the local corotating frame is given by(8)
Because the eigenvalue λ_{νkm} varies smoothly as a function of the spin parameter ν for a given pulsation mode identification (k, m), the derivatives in the righthand side of Eq. (6) can be rewritten using the chain rule. Hereby we consider the functions λ_{km}(ν), ν(f_{rot}) and f_{rot}(r) for a given pulsation. Taking into account that the pulsation period in the corotating frame , we find(9)
The coefficients a_{i} depend on the rotation profile, and are the same for all pulsations. The functions G_{i}(ν) depend on the pulsation mode identification, and describe how the influence of the differential rotation varies across the period spacing patterns. The full expressions for a_{i} and G_{i}(ν) are given in Appendix B. Because the functions G_{i}(ν) are continuous and smooth, we can conclude that differential rotation in the nearcore regions of a gmode pulsator also introduces an additional continuous change in the slope of the period spacing patterns.
2.2. MESA and GYRE models
We illustrate the theoretical results from Sect. 2.1 by computing pulsation periods for stellar evolution models including a differential rotation profile. The input models are computed with the onedimensional stellar evolution code MESA v10108 (Paxton et al. 2011, 2013, 2015, 2018), for a nonrotating 1.7 M_{⊙} star with solar metallicity, assuming the chemical mixture described by Asplund et al. (2009) and using OPAL opacity tables (Rogers & Nayfonov 2002). Convection is treated using the mixing length theory, with an α_{MLT} value of 1.8, exponential convective core overshooting of 0.015 H_{p}, and extra diffusive mixing in the radiative region of 1 cm^{2} s^{−1}. These values were chosen to match the ones used in studies of gmode pulsators observed with space photometry (e.g. Moravveji et al. 2015, 2016; Schmid & Aerts 2016; Zwintz et al. 2017). The differential rotation profile is added a posteriori to the model. It is defined as(10)
where r_{s} = ⟨r⟩, and f_{rot,s} and δ f are free parameters, providing the rotation frequency at radius r_{s} and the relative difference in rotation frequency between r = 0 and r = r_{s}, respectively. This prescription is based on the differential rotation profile derived by Rieutord (2006) and Hypolite & Rieutord (2014) for the thermal wind balance in rapidly rotating stars, taking into account the effects of rotation and stable stratification in the Boussinesq approximation.
We evaluated the asymptotic relation in Eq. (3) for different theoretical stellar models, and compared our results with full numerical pulsation frequencies computed for the same input models. For the evaluation of Eq. (3), we have relied on the numerical BruntVäisälä frequency profiles. The pulsations of the stellar models were calculated at multiple points during the mainsequence evolution (with a core mass hydrogen fraction X_{c} of 0.7, 0.5, 0.3, and 0.1, respectively), for several rotation rates (f_{rot,s} = 0.1 d^{−1}, 1 d^{−1}, 1.5 d^{−1}, and 2 d^{−1}) with varying degrees of differential rotation. The numerical pulsation frequencies of the stellar models were computed using the adiabatic version of the stellar pulsation code GYRE v5.1 (Townsend & Teitler 2013; Townsend et al. 2018), since stability or excitation rate computations (see, e.g. Bouabid et al. 2013) are beyond the scope of the present work. This version of the GYRE code adopts the TAR to model gravitoinertial and purely inertial modes. The implementation of the TAR in GYRE, which was undertaken independently of the present work, is similar to the approach described by Townsend (2005), with the allowance for differential rotation as derived by Mathis (2009).
In most cases, our test results were qualitatively similar. A representative case is shown in Fig. 1. While the asymptotic relation in Eq. (3) does not account for mode trapping, it describes the changes in the mean pulsation period and the slope of the period spacing patterns, caused by differential rotation. The results from Eq. (3) and those obtained numerically with the GYRE code are in agreement.
Fig. 1. 1.7 M_{⊙} stellar model at X_{c} = 0.7 with f_{rot,s} = 2 d^{−1} and δ f = 0.0 (light grey), 0.1 (grey), and 0.2 (black). Top left: the BruntVäisälä frequency profile. Top right: the considered stellar rotation profiles. Left panels: the corresponding gravitoinertial mode pulsations with (k, m)=(+0, +1), computed from Eq. (3) (middle) and with GYRE v5.1 (bottom). Right panels: the corresponding gravitoinertial mode pulsations with (k, m)=(−2, −1), computed from Eq. (3) (middle) and with GYRE v5.1 (bottom).

Open with DEXTER
The impact of the differential rotation on the pulsation modes depends on the pulsation mode identification. For retrograde gravitoinertial modes, such as rmodes with (k, m)=(−2, −1), the local pulsation frequency in the corotating frame is lower when the local rotation frequency is lower, and vice versa, as we can see from Eq. (8). For prograde modes, the local pulsation frequency in the corotating frame decreases when the local rotation frequency increases. The relative contribution of the Coriolis force to the total restoring force increases when the local pulsation frequency in the corotating reference frame decreases. Hence, retrograde (prograde) modes become more sensitive to the slower (faster) rotating layers in a differentially rotating star. Thus, if the stellar core rotates sufficiently faster than the outer layers, as illustrated in Fig. 1, the retrograde rmodes are more sensitive to the outer layers of the star, whereas the prograde gravitoinertial modes are more sensitive to the nearcore regions, as illustrated in Fig. 2. Finally, as we can see in Fig. 1, changes in the rotation profile cause the dips in the period spacing patterns to shift in period. This is also indicative of changes in the pulsation mode cavities. Other illustrative examples of the impact of differential rotation on gmode period spacing patterns can be found in Figs. C.1 and C.2.
Fig. 2. Pulsation mode cavities of the gravitoinertial mode pulsations with (n, k, m)=(−25, +0, +1) (black) and (n, k, m)=(−25, −2, −1) (grey) for the 1.7 M_{⊙} stellar model at X_{c} = 0.7 with f_{rot,s} = 2 d^{−1}, shown in Fig. 1. Both the integrand of Eq. (3) (left panels) and the rotation kernel K_{nl} (computed following Eq. (3.356) in Aerts et al. (2010); (right panels) are shown for differential rotation rates δf = 0.0 (top panels), 0.1 (middle panels), and 0.2 (bottom panels).

Open with DEXTER
2.3. Revisiting the γ Dor sample analysis
Next, we reanalysed the period spacing patterns of γ Dor stars reported by Van Reeth et al. (2015), and consider the possibility of radial differential rotation. These stars have been studied in an ensemble modelling analysis by Van Reeth et al. (2016), assuming rigid rotation. This was successful for 40 of the 50 stars with observed period spacings, and led to the identification of rmode pulsations in ten stars in the sample. These results were recently confirmed in further analyses by Saio et al. (2018).
In a first step, we fitted the observed period spacing patterns using Eq. (9), whereby we optimised the parameters Π_{0}, f_{rot}, and a_{i}. From this analysis we find that the observed period spacing patterns often do not allow to detect differential rotation. This is illustrated in Fig. 3 for the γ Dor star KIC 11721304, where we show the observed pattern, the best fitting model assuming rigid rotation, and a model that includes differential rotation. The quality of the fit is similar for both types of rotation profiles, but when differential rotation is included, the uncertainties on the derived nearcore rotation rate and the asymptotic spacing become larger. Hence, the model assuming rigid rotation is statistically favourable, but we cannot disprove differential rotation.
To properly establish the extent of this degeneracy, we simulated period spacing patterns for varying degrees of differential rotation, and analyse them using rigidly rotating models. The simulated period of the pulsation with mode identification (n, k, m) in the inertial reference frame, is given by(11)
Here, P_{th, nkm} is the theoretical pulsation period for the mode (n, k, m) in the asymptotic regime, computed with Eq. (3). We used the 1.7 M_{⊙} MESA model discussed in Sect. 2.2 at X_{c} = 0.5 as input, combined with rotation profiles that were constructed following Eq. (10) for increasing differential rotation rates (0 ≤ δ f ⋅ f_{rot,s} ≤ 0.3). The offsets δ P_{nkm} in Eq. (11) account for the effects of mode trapping and observational errors that were included in our simulated data. The latter were taken to be the residuals after modelling an observed period spacing pattern. These simulated period spacing patterns were subsequently fitted with a rigid rotation model, as described by Eq. (1), and the quality of the fits were evaluated using reduced χ ^{2}values.
Fig. 3. Observed period spacing pattern of KIC 11721304 (grey squares) with the best model assuming rigid rotation (red; f_{rot} = 0.46 ± 0.02 d^{−1}, Π_{0} = 4320 ± 230 s), and allowing for differential rotation (blue; f_{rot} = 0.51 d^{−1}, Π_{0} = 4430 s, a_{1} = − 0.04).

Open with DEXTER
The results of two selected simulations, with offsets δP_{nkm} based on the observations of the γ Dor star KIC 11721304, are shown in Fig. 4 and listed in Table 1. As the differential rotation δf in the simulated data increases, the quality of the rigidly rotating model fit decreases. However, this is hard to observe. Indeed, differences in the slope of the simulated pattern caused by the differential rotation are accounted for by slight changes in the nearcore rotation rate f_{rot,i} and asymptotic spacing Π_{0} of the rigidly rotating model. The changes in the model value of Π_{0} are related to the interaction between the differential rotation profile and the BruntVäisälä frequency profile, as we derived from Eq. (3) and illustrated in Fig. 2. For all simulated differential rotation profiles, the values for f_{rot,i} and Π_{0} of the best model are as typically detected for a γ Dor star. Any remaining differences between the differentially rotating simulation P_{th, nkm} and the bestfitting model are negligible compared to the offsets δP_{nkm}. As a result, we cannot properly detect the differential rotation in these simulated data, even for δf ≈ 0.9.
Fig. 4. Simulated period spacing patterns based on the observations for KIC 11721304 (black dots). The input parameters for the simulations (with nonrigid rotation) are shown in black, while the χ_{red} ^{2} of the best model with rigid rotation (full red line) is also given.

Open with DEXTER
The degeneracy between rigid and differential rotation is lifted when multiple period spacing patterns are observed for the same star. This is illustrated in Fig. 5. In this figure we show simulations of a prograde dipole mode series and a retrograde rmode series, with offsets δP_{nkm} based on the observations of the γ Dor star KIC 12066947. The parameter values of the simulated patterns and the best (rigidly rotating) models are again listed in Table 1. Because a differential rotation profile has a different effect on both patterns (as discussed in Sect. 2.2), its presence is revealed when models assuming uniform rotation are fitted simultaneously to the data. We can see that for the simulations in the bottom panels of Fig. 5, with δf = 0.15, the rigidly rotating model fails to match the slope of the patterns. Since we did not observe such significant shortcomings when modelling the real observed period spacing patterns for this star, we estimate that its differential rotation rate is δf ≲ 0.15. Similar modeldependent upper limits for δf have been estimated for the other stars with detected rmode patterns, and are listed in Table 3.
Fig. 5. Simulated period spacing patterns for different rotation profiles (top, middle, bottom) based on the observations for KIC 12066947 (black dots). The input parameters for the simulations (with nonrigid rotation) are shown in black on the right, while the of the best model with rigid rotation (full red line) is also given. Both the prograde dipole modes (with (k, m) = (0,1); left) and the rmodes (with (k, m) = (−2,−1); right) are shown.

Open with DEXTER
In addition, the simulations illustrate another property when dealing with nonrigid rotation. The uniformly rotating model provides a better fit to the simulated data with a differential rotation rate δf = 0.04, than to the simulated data for a rigid rotator (δf = 0.0), as evidenced by their respective values. For δ f = 0.04, the observational signatures of pulsation mode trapping by a chemical gradient and the differential rotation partially cancel each other. Modelling of the patterns in Fig. 5 individually confirms these results and is in line with the discussion in Sect. 2.2. As the differential rotation increases, the prograde gravitoinertial modes become more sensitive to the faster rotating nearcore regions, and the rmodes become more sensitive to the slower rotating outer layers of the star. At the differential rotation rate δ f = 0.15, the results from modelling both patterns individually no longer agree within their respective errors. In addition, the rmodes have become sufficiently sensitive to the outer layers of the star that the derived asymptotic spacing Π_{0} from the modelling, as computed in Eq. (2), is no longer reliable.
2.4. Discovery of Yanai modes
For ten stars in the sample, Van Reeth et al. (2016) could not find a unique pulsation mode identification for the detected period spacing patterns. For some, there were multiple mode identifications that yielded equally good results. However, for six of them, no suitable interpretation could be found at all. Interestingly, all of these stars have a few characteristics in common. They have low to moderate values for the spectroscopic rotation velocity v sin i (see Table 2). For each of them Van Reeth et al. (2015) detected a single period spacing pattern with an upward slope, i.e. of retrograde pulsation modes, with period spacing values typically ranging from a few hundred to a few thousand seconds. Qualitatively, these characteristics agree with what is expected for Yanai modes, a type of purely inertial pulsation modes with k = −1, otherwise known as odd rmodes (Townsend 2003b; Saio et al. 2018). The observed period spacing values are far larger than the spacings of rmodes with k = −2, while the spacings of normal retrograde gmodes with k ≥ 0 are not expected to be much smaller than the asymptotic spacing . However, Van Reeth et al. (2016) could not compute a satisfactory theoretical model for Yanai modes, and were limited to the asymptotic expressions given by Townsend (2003b).
In this work, we have been able to compute adequate theoretical models for Yanai modes, using GYRE v5.1. The period spacing pattern of the γ Dor star KIC 11668783 is shown in Fig. 6 as an example. The best fitting model, included in the figure, corresponds to Yanai modes with (k, m)=(−1, −1) in a rigidly rotating star. While we can obtain pulsation periods in the observed range, the slope of the model pattern differs from the slope of the observations, and the asymptotic spacing Π_{0} and nearcore rotation frequency f_{rot} of our best model have unrealistic values, i.e. s and respectively. The inclusion of radial differential rotation in the models was insufficient to resolve this issue.
However, the observations are qualitatively consistent with Yanai modes with (k, m)=(−1, −1). If we assume that the star is a solidbody rotator, we can use the mode identification to derive a lower limit for the stellar rotation frequency f_{rot}. As explained in detail by Saio et al. (2018), an rmode pulsation frequency in the inertial reference frame f_{in,s} < mf_{rot}, so that for m = −1, we have (mP_{min})^{−1} < f_{rot}, where P_{min} is the shortest pulsation period of the detected period spacing pattern. Combined with the spectroscopic values for the projected surface rotation velocity v sin i, we find that these are moderate to fast rotating stars seen close to poleon. These results, shown in Figs. 7 and 8, are generally consistent with the theoretical expectations for Yanai modes (Saio et al. 2018).
There are differences between the models and the observations for these six stars. These stars are fast rotators, seen close to poleon as indicated by the low v sin i values. Hence, the traditional approximation may not be applicable to Yanai modes in these stars. The behaviour of Yanai modes becomes similar to that of retrograde gravitymodes at high spin parameter values (Townsend 2003b; Saio et al. 2018). Recently, Ouazzani et al. (2017) compared the traditional approximation with a general twodimensional treatment of stellar pulsations and found that it is reasonably appropriate for gmode period spacing patterns with various mode identifications, except for retrograde gmodes in moderate to fast rotating stars. In this case, general twodimensional models are needed.
3. Rotational modulation
A common approach to observationally detect or disprove differential rotation is to determine the ratio between the rotation frequency in the nearcore regions and close to or at the stellar surface. While gmode pulsations are the only reliable way to probe the stellar properties near the convective core, the rotation rate in the outer stellar envelope can be determined by analysing pmode pulsations (e.g. Kurtz et al. 2014; Saio et al. 2015; Schmid & Aerts 2016) and/or rotational spot modulation (e.g. Degroote et al. 2011; Escorza et al. 2016; Saio et al. 2018) in the light curve, if either are present. In this section, we focus on detecting rotational modulation and distinguishing it from gmode pulsations. To avoid confusion, the rotation frequency in the deep stellar interior and in the outer layers are denoted by f_{rot,i} and f_{rot,o}, respectively.
When we look for observational signatures of rotational spot modulation in the Fourier spectrum of spacebased photometry of a star, we expect to find lowfrequency peaks for which the first harmonic frequency is also present. These frequencies are often part of a group of two or more closely spaced frequencies which are not always resolved. Such signal is common for lowmass stars with convective envelopes, but has been observed for A and Btype stars as well (e.g. Degroote et al. 2011; Escorza et al. 2016; Bowman 2017; Saio et al. 2018).
For nonradial gmode pulsators, the detection of rotational modulation signal is not straightforward. These pulsation modes are known to have combination frequencies in the observations, and, for mainsequence stars, they occur in the same frequency range as the stellar rotation frequency. Furthermore, we may expect similar amplitudes for rotational modulation and gmode pulsations in photometric data, and both types of signal are frequently nonsinusoidal. However, contrary to gmode pulsations, which have lifetimes longer than the total observation time of the Kepler space mission, rotational spot modulation can vary in amplitude on much shorter timescales. In addition, whereas gmode pulsations have very stable frequencies on long timescales, rotational spot modulation frequencies often exhibit small variations dependent on the latitude of the stellar spots. Consequently, rotational modulation signal ofttimes consists of isolated closely spaced frequency groups, clustered around harmonic frequencies.
Fig. 6. Top panel: log χ ^{2}distribution for the parameters of the model pattern evaluated for KIC 11668783. The red contour indicates the boundary of the 1σ confidence interval. Bottom panel: observed period spacing pattern of KIC 11668783 (black squares) reported by Van Reeth et al. (2015), with the best model (red line; , ).

Open with DEXTER
Fig. 7. Spectroscopic rotation velocities of the single stars in our sample, as a function of the derived nearcore rotation rate, assuming uniform rotation as the statistically favoured model. The symbol and colour indicate the derived pulsation mode identification. Contrary to the other stars in this figure, the stars with Yanai modes (with (k, m)=(−1, −1)) have not been successfully modelled. For these stars, the plotted rotation frequency is a lower limit, assuming the proposed mode identification is correct. The arrows indicate how the graph changes when f_{rot} is higher. This figure is an update of Fig. 14 by Van Reeth et al. (2016).

Open with DEXTER
Fig. 8. Inclination angle i of the observed stars, derived from the information shown in Fig. 7, assuming the stars are spherically symmetric with a stellar radius R_{*} = 2.0 ± 0.5 R_{⊙}, which is typical for a γ Dor star. The symbols and colours are the same as in Fig. 7. For the stars with Yanai modes (with (k, m)=(−1, −1)), the plotted rotation frequency is again a lower limit. The arrows indicate how the graph changes when f_{rot} is higher.

Open with DEXTER
Hence, we evaluated the frequencies extracted from the Kepler photometry by Van Reeth et al. (2015) to look for rotational modulation signal. To properly distinguish gmode pulsations from rotational modulation, we require that

the signaltonoise ratio S/N ≥ 4, and the value of the amplitude is at least five times as large as its error, to ensure that the detected signal is significant;

the first harmonic of the selected frequencies is detectable in the data, whereby we use the Rayleigh frequency resolution f_{res} as a limit to find harmonics;

the selected frequency is part of a closely spaced group of frequencies, whereby f_{i} − f_{j}< 1.5f_{res};

both the selected frequencies and their first harmonics are located outside of the frequency ranges of the gmode pulsation frequencies and their combinations;

the selected frequencies are larger than half the derived nearcore rotation frequency f_{rot,i} and any detected rmode frequencies;

the selected frequencies are smaller than oneandahalf times the derived nearcore rotation frequency f_{rot,i} and any detected prograde pulsation mode frequencies;
With these criteria, the main limitation is that stellar spots must have a shorter lifetime than the total observation time of the original Kepler space mission. This implies that we cannot detect rotational modulation in gmode pulsators with longlived stellar spots. A second limitation of our approach is that we require the surface rotation rate and the nearcore rotation rate to agree within 50%. This assumption would be unjustified in (very) slowly rotating stars, such as KIC 8197761 (Sowicka et al. 2017). However, the stars in our sample rotate significantly faster (Van Reeth et al. 2016).
Our analysis is illustrated in Fig. 9 for the γ Dor star KIC 11294808. The frequencies marked in red are the only peaks that fulfil the first three criteria, and any frequencies within the grey area fulfil the last two criteria. There is only one peak, at 0.788 ± 0.001 d^{−1}, that satisfies all of our criteria, and is reasonably isolated within the frequency spectrum. Thus, this signal is caused by rotational modulation, and its frequency is the surface rotation rate f_{rot,o}. Consequently, f_{rot,o} and f_{rot,i} are equal within 1σ, indicating that KIC 11294808 is a rigid rotator.
Fig. 9. Fourier spectrum of KIC 11294808. Frequencies that fulfil our detection criterion, are indicated in black, whereas frequencies marked in red fulfil the detection criterion, have the firstorder harmonic within the extracted frequency list, and are part of a closely spaced group of frequencies. The derived nearcore rotation frequency and its harmonic are indicated with the dashed and dotted lines, respectively. Signatures of rotational modulation occur within the shaded grey frequency range.

Open with DEXTER
To avoid false detections, the criteria we employed to detect rotational modulation are rather strict. However, when one of the criteria is not met for a star, it can still exhibit rotational modulation. As an example, we show the Fourier spectrum of the γ Dor star KIC 8375138 in Fig. 10. There is a smallamplitude peak in the spectrum at a frequency of 1.641 ± 0.001 d^{−1} that complies with all but one of our criteria, in other words, it is not part of a closely spaced group of frequencies, but an isolated frequency. Nevertheless, this is very likely also rotational modulation signal. Thanks to the detection of both prograde dipole modes and rmodes in this star, the nearcore rotation rate f_{rot,i} is exceptionally wellconstrained, and the detected frequency agrees with f_{rot,i} within a fraction of 1σ. The probability that this is a pulsation frequency, is very small. As shown in Fig. 10, we numerically calculated the cumulative distribution function of the detected significant frequencies of this star, that have a firstorder harmonic. By drawing random frequency values from the computed distribution function, taking into account the total number of such detected frequencies, we find that there is a 2.1% chance that a significant pulsation frequency with a firstorder harmonic in the data, is located within 1σ of f_{rot,i}. The probability of detecting a random significant pulsation frequency with a firstorder harmonic within 3σ of f_{rot,i}, is 7.1%. All stars with derived values for the surface rotation rate f_{rot,o} are listed in Table 3.
Fig. 10. Fourier spectrum of KIC 8375138. Frequencies that fulfil our detection criterion, are indicated in black, whereas frequencies marked in red fulfil the detection criterion, and have the firstorder harmonic within the extracted frequency list. The derived nearcore rotation frequency and its harmonic are indicated with the dashed and dotted lines, respectively, while the cumulative distribution function of the red frequency peaks is shown by the blue curve. Signatures of rotational modulation occur within the shaded grey frequency range. Inset: a closeup of the Fourier spectrum around the nearcore rotation rate f_{rot,i} (dashed line). The 1σ (dotted lines) and 3σ (grey area) uncertainties on f_{rot,i} are indicated. The ten highestamplitude pulsation frequencies have been prewhitened for clarity.

Open with DEXTER
The six stars with single retrograde period spacing patterns, which we suspect correspond to Yanai modes.
4. Discussion and conclusions
The aim of this work was to provide observational constraints of differential rotation in a sample of γ Dor stars. We approached this issue using two separate methodologies.
First, we considered the impact of differential rotation on the observational properties of gmode period spacing patterns. We used a theoretical formalism that allows us to study the properties of lowfrequency gravitoinertial modes propagating in differentially rotating stars developed in Mathis (2009) and an extended observation sample of γ Dor stars. In a uniformly rotating star, the slope of an observed period spacing pattern provides information on the stellar rotation rate, while the nonuniform structure of the pattern is a signature of the pulsation mode trapping caused by chemical gradients and discontinuities in the nearcore regions. Differential rotation modifies these diagnostics. It changes the sensitivity of pulsation modes to different depths within the interior structure, which in turn leads to changes in the pulsation mode trapping. This translates into changes of the morphology of the period spacing patterns. A high differential rotation rate will also change the slope of the observed period spacing pattern. Here, we have developed a new theoretical seismic diagnostic for the case of radial differential rotation.
In the case where only one period spacing pattern is detected for a star, it is difficult to detect the signature of differential rotation in the pattern. Indeed, other physical processes, such as the mode trapping by chemical gradients, can have similar observational characteristics in the pulsation period spectrum. On the other hand, a period spacing pattern of a differentially rotating star can often be fitted by a rigidly rotating model, where the uniform rotation rate and asymptotic period spacing parameters of the model are tweaked to compensate for the offset. In many cases the rigidly rotating model is statistically favourable over a model with differential rotation. We demonstrate this for the γ Dor star KIC 11721304, and were unable to detect differential rotation rates below δ f < 0.9.
When multiple period spacing patterns have been detected, the period spacing patterns can be compared to infer the presence of, or an upper limit for, differential rotation. We demonstrate this for the γ Dor star KIC 12066947, and found δ f ≲ 0.15. Similar modeldependent upper limits for δ f have been estimated for our other stars with detected rmode patterns, and are listed in Table 3.
Second, we determine surface rotation rates for eight stars in our sample, using detected signal of rotational modulation. From these, we then derived the surfacetocore rotation ratio. Such values have already been computed for other stars in the literature, albeit for more slowly rotating stars. An overview of these stars is shown in Fig. 11. As we can see, most stars are seemingly uniformly rotating within 1σ or 2σ error margins, and the differential rotation grows larger when (i) the nearcore rotation rate is low, or (ii) the star is in a binary system, and sensitive to tidal effects.
Fig. 11. Overview of BAFtype mainsequence stars with derived values for the nearcore rotation rate f_{rot,i} and the surface rotation rate f_{rot,o}. The bottom figure is a zoomin of the top figure. For most stars, the values are consistent with rigid rotation within 1σ. The observational signature of differential surfacetocore rotation becomes stronger when the star is slowly rotating, and/or in a binary system. The stars with values from the literature were taken from (Kurtz et al. 2014; Saio et al. 2015; Triana et al. 2015; Moravveji et al. 2016; Murphy et al. 2016; Schmid & Aerts 2016; Guo et al. 2017; Kallinger et al. 2017; Sowicka et al. 2017).

Open with DEXTER
When both methods for the detection and constraining of differential rotation in γ Dor stars are combined, we find that the observations are in agreement with (quasi)rigid rotation throughout most of the radiative region, but that we cannot exclude differential rotation in the nearcore regions. The precise location where such differential rotation may be present and the steepness of the gradient can strongly vary, and has to be considered for each studied star individually. When the stellar surface rotation rate is known as well, this can be included as a strong constraint in seismic modelling.
Finally, six of the stars in the sample exhibit a single retrograde period spacing pattern in qualitative agreement with Yanai modes, for (k, m)=(−1, −1) (Saio et al. 2018). Considering the high rotation frequencies and the associated low inclination angles that this mode identification implies, twodimensional models that do not assume the traditional approximation, are required to treat these pulsations properly.
This work provides us with a new observational window into the angular momentum transport that takes place in the interiors of intermediate and highmass stars with convective cores and radiative envelopes. We derived observational constraints for the rotation profiles in moderate to fast rotating stars, whereas available studies in the literature were mostly limited to slowly rotating stars. Consequently, the results of this work allow us to build a more complete picture of the stellar rotation. This is required to understand which angular momentum transport processes take place inside a star, resulting in the observed dramatic changes in stellar rotation rate during stellar evolution (Aerts et al. 2017; Ouazzani et al. 2018).
Overview of the stars with derived constraints on differential rotation.
In the case of differential rotation, the possible latitudinal trapping of waves obtained for subinertial gravitoinertial waves in uniformly rotating stars will become more complex. We refer the reader to Mathis (2009), Mirouh et al. (2016) and Prat et al. (2018) for a detailed discussion.
