1. Introduction

The intercombination lines from O iv and S iv around 1400 Å provide useful electron density (Ne) diagnostics in a variety of solar features and astrophysical plasmas (see, e.g. Flower & Nussbaumer 1975; Feldman & Doschek 1979; Bhatia et al. 1980). These transitions are particularly suitable for performing density measurements as their ratios are known to be largely independent of the electron temperature, and only weakly dependent on the electron distribution (Dudík et al. 2014). The other advantage is that these lines are close in wavelength, minimizing any instrumental calibration effects.

However, discrepancies between theoretical ratios and observed values have been reported in the past by several authors. For instance, Cook et al. (1995) calculated emission line ratios from different O iv and S iv line pairs by using solar observations from the High Resolution Telescope Spectrograph (HRTS) and the SO82B spectrograph on board Skylab as well as stellar observations from the Hubble Space Telescope (HST). They found that the observed ratios from O iv and S iv would imply electron densities which differed significantly with each other (by up to an order of magnitude). Some of the discrepancies were subsequently identified by Keenan et al. (2002) as due to line blends and low accuracy in the atomic data calculations. They obtained more consistent density diagnostics from O iv and S iv ratios by using updated atomic calculations together with observations from SOHO/SUMER. Nevertheless, some inconsistencies still remained (Del Zanna et al. 2002).

There is now renewed interest in the literature concerning these transitions, because some of the O iv and S iv intercombination lines, together with the Si iv resonance lines, are routinely observed with the Interface Region Imaging Spectrograph (IRIS; De Pontieu et al. 2014) at much higher spectral, spatial and temporal resolution than previously. For example, Peter et al. (2014) used the intensities of the O iv vs. Si iv lines to propose that very high densities, on the order of 1013 cm-3 or higher, are present in the so-called IRIS plasma “bombs”. Line ratios involving an O iv forbidden transition and a Si iv allowed transition have been used in the past to provide electron densities during solar flares and transient brightenings (e.g. Cheng et al. 1981; Hanssen 1981). However, the validity of using O iv to Si iv ratios has been hotly debated because these ratios gave very high densities compared to the more reliable ones obtained from the O iv ratios alone (see, e.g. Hayes & Shine 1987). In addition, Judge (2015) recalled several issues that should be taken into account when considering the Si iv/O iv density diagnostic. The main ones were: (1) O iv and Si iv ions are formed at quite different temperatures in equilibrium and hence a change in the O iv/Si iv ratio could imply a change in the temperature rather than in the plasma density (2) the chemical abundances of O and Si are not known with any great accuracy and could be varying during the observed events (3) density effects on the ion populations could increase the Si iv/O iv relative intensities by a factor of roughly three to four. Judge (2015) has also mentioned the well known problem of the “anomalous ions”, that is, the observed high intensities of the Li- and Na-like (as Si iv) ions (see also Del Zanna et al. 2002). Another important aspect to take into account is the effect of non-equilibrium conditions on the observed plasma diagnostics. It is well known that strong variations in the line intensities are obtained when non-equilibrium ionisation is included in the numerical calculations (see, e.g. Shen et al. 2013; Raymond & Dupree 1978; Mewe & Schrijver 1980; Bradshaw et al. 2004). In particular, Doyle et al. (2013) and Olluri et al. (2013) investigated the consequences of time-dependent ionization on the formation of the O iv and Si iv transition region lines observed by IRIS. In addition, Dudík et al. (2014) showed that non-Maxwellian electron distributions in the plasma can substantially affect the formation temperatures and intensity ratios of the IRIS Si iv and O iv lines. These authors also suggested that the observing window used by IRIS should be extended to include S iv. Recent IRIS observation sequences have indeed included the S iv line near 1406 Å. The S iv line ratios have a higher limit for density sensitivity than the O iv line ratios and are thus particularly useful for diagnosing high densities which might occur in flares. Previous flare studies have in fact reported line ratios involving O ions which lay above the density sensitivity range, indicating an electron density in the excess of 1012 cm-3 (e.g. Cook et al. 1995; Polito et al. 2016).

We present here the analysis of several IRIS observational datasets where Si iv, O iv, and S iv lines were observed. We focus on the diagnostics based on the O iv and S iv lines that we believe to be more reliable than those involving the Si iv to O iv line ratios, because of the issues described above.

The observations used in this work were obtained from a variety of solar features. Small spatial elements were selected, to reduce multi-thermal and multi-density effects. Discrepancies in density diagnostics can in fact also arise if regions of plasma at different temperature and density are observed along the line of sight (Doschek 1984; Almleaky et al. 1989). We discuss in some detail the various factors that affect the density measurements, and their uncertainties, as well as the different methods to obtain densities.

We start by describing in Sect. 2 the spectral lines and atomic data used in our analysis. We refer the reader to Appendix A for a detailed review of the issues related to the atomic data and wavelengths for these lines. In Sect. 3 we briefly discuss the diagnostic methods. In Sect. 4 we analyse a loop spectrum observed in Active Region (AR) NOAA 12356 on the 1 June 2015 and a spectrum acquired at the footpoints of the M 6.5 class flare on the 22 June 2015. The analysis of additional spectra observed in the AR can be found in Appendix B. Section 5 presents a discussion on some of the physical processes which can affect the formation temperature of the ions studied in this work. Finally, the results of our analysis are discussed and summarized in Sect. 6.

thumbnail Fig. 2

Theoretical ratios (continuous lines) of O iv 1399/1401 Å, 1401/1404 Å and S iv 1404/1406 Å obtained by using the atomic data described in the text. The dotted curves show a ±10% error for the theoretical ratios. The vertical lines indicate the high-density limit of 1012 cm-3 for the O iv ratios and 1013 cm-3 for the S iv ratios.

2. Transition-region lines observed by IRIS

Table 1 lists the O iv, S iv and Si iv transition region (hereafter, TR) lines observed by the IRIS FUV spectrograph which have been analysed in this study. We note that in this context, TR indicates an approximate temperature of formation for emission lines rather than a layer of the solar atmosphere. An example of an IRIS AR spectrum showing these lines is given in Fig. 1. It is important to note that the IRIS spectral window has recently been extended to include the 3s2 3p 2P3/2–3s 3p24P5/2 S iv transition at 1406.06 Å.

The O iv and S iv density-sensitive intensity ratios discussed in this work are: R1=R2=R3=\begin{eqnarray} R_{1}&=&\frac{I_\oiv(1399.78~\AA)}{I_\oiv(1401.16~\AA)}, \label{eq:R1} \\ R_{2}&=&\frac{I_\oiv(1401.16~\AA)}{I_\oiv(1404.81~\AA)}, \label{eq:R2}\\ R_{3}&=&\frac{I_\siv(1404.85~\AA)}{I_\siv(1406.06~\AA)}\cdot \label{eq:R3} \end{eqnarray}The above ratios are shown in Fig. 2 as a function of electron density. They have been obtained by using the atomic data described in Sect. 2. The ratios R1, R2 and R3 are useful density diagnostics in an intermediate density interval, between lower and higher densities (1010–1012 cm-3 for O iv and 1011–1013 cm-3 for S iv).

One limitation in the use of these lines is that they are normally observed to be extremely weak (the O iv 1399.779 Å line in particular). In addition, the variation of the R1 ratio over the density sensitivity range is not very large, and only spans around a factor of two in magnitude (top panel of Fig. 2), as already noted by Feldman & Doschek (1979). The ratio R2 involving the 2P3/24P3/2 O iv component at 1404.81 Å is in principle better, but unfortunately this line is blended with the S iv 3s23p 2P1/2–3s 3p24P1/2 transition at 1404.85 Å (see Table 1). Various methods have been considered to address this issue in the past. Feldman & Doschek (1979) discussed how the importance of the S iv to the O iv line in the blend varies with the plasma density and temperature. For instance, at the quiet Sun density of 1010 cm-3, the S iv transition only contributes by around 10% to the 1404.82 Å (bl) line. The ratio between the S iv and O iv blended lines is however significantly higher (50%) at densities of the order of 1012 cm-3.

In this work, we estimate the intensity of the O iv 1404.81 Å line by dividing the intensity of the unblended O iv 1401.16 Å line with the value of the theoretical R2 ratio at the density Ne which is determined by using the R1 ratio: IOiv(1404.81Å)=IOiv(1401.16Å)R2·\begin{equation} I_{\oiv} (1404.81~\AA)=\frac{I_\oiv(1401.16~\AA)}{R_2}\cdot \label{eq:Ioiv} \end{equation}(4)The intensity of the blended S iv line at 1404.85 Å is then simply obtained as the difference between the intensity of the 1404.82 Å blend and the estimated intensity of the O iv 1404.81 Å line: ISiv(1404.85Å)=IOiv+Siv(1404.82Å)IOiv(1404.81Å).\begin{equation} I_{\siv} (1404.85~\AA)=I_{\oiv + \siv}(1404.82~\AA)-I_{\oiv} (1404.81~\AA). \label{eq:Isiv} \end{equation}(5)Finally, we compare the results obtained by using R1R2, R3 and the Si iv / O iv ratio R4: R4=ISiiv(1402.77Å)IOiv(1401.16Å)·\begin{equation} R_\textrm{4}=\frac{I_\siiv(1402.77~\AA)}{I_\oiv(1401.16~\AA)}\cdot \label{eq:R4} \end{equation}(6)However, we bear in mind that this latter ratio is known to imply much higher densities than the R1,2,3 ratios because of the issues outlined in the introduction (see in particular Hayes & Shine 1987).

Table 1

O iv and S iv transitions observed by IRIS.

Atomic data, blends, and wavelengths.

Various inconsistencies in the electron densities obtained from the O iv and S iv have been reported in the literature (see Appendix A). The main ones are removed with improved atomic data (see Keenan et al. 2002); however, some still remain, especially regarding the 1404.8 Å blend (Del Zanna et al. 2002), which is about 30% stronger than predicted. This discrepancy prompted a new S iv calculation by the UK APAP network1, presented in Del Zanna & Badnell (2016). Here, we use these S iv new atomic data, but we note that these data differ from the previous ones, available within the CHIANTI v.8 database (Del Zanna et al. 2015), by only about 10%. In particular, the excitation rates that drive the level population of the 3s 3p24P levels are within a few percent of those calculated by Tayal (2000), while variations in the A-values as calculated by different authors vary by at most 10%. Therefore, we estimate an uncertainty in the intensity ratios of the S iv intercombination lines to be about 10%. This however means that the 30% discrepancy in the 1404.8 Å blend is still present even if the new atomic data of Del Zanna & Badnell (2016) are used.

For the O iv transitions, we use the UK APAP network data (Liang et al. 2012) as distributed within the CHIANTI v.8 database (Del Zanna et al. 2015). In Appendix A, we describe some of the earlier atomic data, and provide a table of A-values, where we can see that variations are well within 10%. Therefore, as in the S iv case, we estimate an overall uncertainty in the intensity ratios of the intercombination lines to be about 10%. Finally, for the Si iv transition at 1402.77 Å, we use the atomic data from CHIANTI v.8.

Another important issue is presented by possible blends in the emission lines under study. The O iv lines are sometimes observed to be blended with cooler emission lines, as described by Young (2015). Polito et al. (2016) noted that the O iv lines at 1399.78 Å and 1401.16 Å were blended with several photospheric lines, some of them unidentified, during the impulsive phase of an X class flare. Keenan et al. (2002) suggested that Fe ii lines are blended with the S iv 1406.06 Å transition. The presence of two Fe ii lines (at 1405.61 Å and 1405.80 Å) on the blue side of the S iv 1406 Å line is indeed confirmed in some of the observed spectra in this study, see Sect. 4.1 and Fig. 1. We also note that in some previous observations (e.g. SOHO/SUMER, see Keenan et al. 2002), some of the lines were blended with second-order lines, an issue not present in the IRIS data. To avoid any source of error in our analysis, we carefully investigated the possibility of line blends in the observed O iv and S iv spectra and included possible blends as an additional uncertainty in the line intensity measurement (see Sect. 4.1).

Finally, we note that there has been some confusion in the literature regarding the wavelengths of the O iv and S iv lines. For example, the wavelengths of the important O iv and S iv blended lines around 1404.08 Å have been inverted in some cases. We list in Table 1 our recommended wavelengths. The discussion on these wavelengths is quite involved and given in Appendix A.

3. Density diagnostic method

In this work, we estimate the electron density Ne of the emitting plasma by using an emissivity ratio method. This method is based on comparing the observed intensity Iobs and the calculated contribution function Gth(T,Ne) of a set of optically thin spectral lines as a function of Ne .

The function Gth, in units of phot cm3 s-1, is defined as: Gth(T,Ne)=N(Xj+m)N(X+m)N(X+m)N(X)Ab(X)N(H)NeAjiNe,\begin{equation} G_\textrm{th}(T,N_\textrm{e})=\frac{N(X^{+m}_j)}{N(X^{+m})}\frac{N(X^{+m})}{N(X)}A_\textrm{b}(X)\frac{N(H)}{N_\textrm{e}}\frac{A_{ji}}{N_\textrm{e}}, \label{eq:Ith} \end{equation}(7)where N(Xj+m)/N(X+m)\hbox{$N(X^{+m}_j) / N(X^{+m})$} is the population of the upper level j relative to the total number density of the ion X+m, calculated at a temperature T, and N(X+ m) /N(X) is the relative abundance of the ion X+ m in equilibrium. In addition, Aji is the spontaneous radiative transition probability, Ab(X) is the abundance of the element X relative to hydrogen, and N(H) /Ne is taken as 0.83 in a completely ionized plasma. The product AjiN(Xj+m)/N(X+m)\hbox{$A_{ji} N(X^{+m}_j) / N(X^{+m})$} is obtained by using the CHIANTI v8 IDL routine emiss_calc for a given temperature T and density Ne. We use photospheric chemical abundances Ab(X) from Asplund et al. (2009) and fractional ion abundances N(X+ m) /N(X) from CHIANTI v8 and the Atomic Data and Analysis Structure (ADAS)2 databases.

Considering that the observed intensity Iobs [phot s-1 arcsec-2 cm-2] of a spectral line λij along the line of sight dh can be expressed as: Iobs=hc4πλijhGth(T,Ne)Ne2dh,\begin{equation} I_\textrm{obs}=\frac{hc}{4\pi\lambda_{ij}}\int_{h}G_\textrm{th}(T,N_\textrm{e})N_\textrm{e}^2 \mathrm{d}h \, \label{eq:Iobs}, \end{equation}(8)the emissivity ratio ER(T,Ne) of the spectral line can be defined as: ER(T,Ne)=IobsGth(T,Ne)·C,\begin{equation} ER(T,N_\textrm{e}) = \frac{I_\textrm{obs}}{G_\textrm{th}(T,N_\textrm{e})} \cdot C, \label{eq:ratio} \end{equation}(9)where C is a scaling constant depending on the geometry of the source and on the units used. It is the same for all lines originating in the same plasma source. The emissivity ratio curves presented in Sects. 4.2 and 4.3 are normalized so that their y-axis ranges between zero and one.

For an almost iso-density plasma, the ratios ER(T,Ne) should then consistently intersect (within the errors) at the same value, giving the density Ne of the emitting plasma source. This method can be applied to spectral lines from the O iv and S iv ions, which are formed at close values of temperature and therefore, in a constant-pressure plasma, at similar densities. For instance, at formation temperatures of logT[K] 5.15 and 5.0 for O iv and S iv respectively (as calculated in CHIANTI v.8 in ionization equilibrium), we expect the densities of two ions to be close within a factor of 1.8. This factor is close to the uncertainty, considering that even a small error in the observed ratio would produce a spread in the estimated density value using the theoretical ratio curves shown in Fig. 2.

The method described above is similar to the L-function method suggested by Landi & Landini (1997), with the main difference that they used a Differential Emission Measure (DEM) weighted temperature T0 to calculate Gth. Given the lack of suitable spectral lines to perform a DEM analysis in our observations, we use an alternative approach to estimate the average plasma temperature T (see Sect. 4). Except for a density factor, the emissivity ratio method used here is similar to the method presented by Del Zanna et al. 2004; however, these authors applied it to spectral lines formed within a single ion (Fe x) only. Therefore, they could ignore the chemical and ion abundance factors in the definition of their emissivity ratio.

The advantage of using the emissivity ratio (Eq. (9)) compared to the individual intensity ratios R1, R2, R3 is that each line l is considered independently, thus allowing a better identification of the presence of possible discrepancies or anomalies in the intensity of a particular spectral line.

It is important to note that in Eq. (9), Iobs is also a function of T and Ne present in the emitting source (Eq. (8)). This is especially the case if we are considering the blend at 1404.82 Å. Here, the intensity of the individual O iv 1404.81 Å and S iv 1404.85 Å lines will depend on the density and temperature assumed to deblend them (Eqs. (4)–(5)).

In order to test the validity of our method, we first simulated several O iv and S iv synthetic spectra at known temperatures and densities using the atomic data described in Sect. 2. We then verified that by using the emissivity ratio method we were able to recover the same plasma temperature and density chosen for simulating the synthetic spectra.

Finally, various issues need to be considered when comparing line intensities from different ions. For example, chemical abundances which are outlined below (Sect. 3). Some other issues will be discussed in Sect. 5.

Chemical abundances.

It has long been observed that some solar TR and coronal features show variations in the chemical abundances, which are correlated with the first ionization potential (FIP) of the element (see, e.g. Laming 2015). The low-FIP (10 eV) elements are more abundant than the high-FIP ones, relative to the photospheric values (the FIP bias). Typical variations are of the order of three to four. In our analysis, we have adopted the photospheric abundances recommended by Asplund et al. (2009). However, we note that with coronal abundances the Si iv intensity would increase compared to the O iv intensity. S has an FIP of about 10, but it normally shows intensity variations in line with those of the high-FIP elements such as O, and therefore we do not expect large variations in the S/O abundance. It is interesting to note that closed long-lived structures such as the 3 MK core loops in active regions show consistently an FIP bias of about three (Del Zanna 2013; Del Zanna & Mason 2014), while newly emerged regions normally show photospheric abundances. Unfortunately, IRIS does not observe enough TR lines to measure chemical abundances accurately.

As we shall see in Sect. 4, there is a consistency in the relative intensities of the IRIS O and S lines, independent of the feature observed. In particular, we have also examined the emission in the sites of chromospheric evaporation during the impulsive phase of flares, where we would normally expect photospheric abundances. On the other hand, we find that the intensity of Si iv relative to O iv and S iv is always very large and even increases in the flare spectra, which is the opposite of what we would expect if the variations were due to an elemental abundance variation. Si iv in fact behaves as an “anomalous ion” (see Del Zanna et al. 2002, and references therein). Non-equilibrium effects such as non-equilibrium i non-thermal electron distributions (e.g. Dudík et al. 2014) might be responsible for this discrepancy (see also Sect. 5.2.).

thumbnail Fig. 3

Overview of the AR NOAA 12356 as observed by the IRIS SJI in the 1400 Å passband at around 19:00 UT. See also the movie that shows the evolution of the SJI 1400 images over time. The green box overplot to the SJI image indicates the field of view of the IRIS spectrograph images in Fig. 4.

thumbnail Fig. 4

Monochromatic images of the AR NOAA 12356 observed by IRIS showing the intensity of different transition region spectral lines. From left to right: Si iv 1402.77 Å , O iv 1399.78 Å and 1401.16 Å and S iv 1406.93 Å. The units are phot s-1 arcsec-2 cm-2. The yellow, light blue and red coloured boxes represent the regions where we acquired the plage, loop and bright point spectra respectively, which are shown in Fig. 5. The time halfway through the IRIS raster is indicated in each panel.

thumbnail Fig. 5

Spectra of the IRIS Si iv 1402.77 Å spectral window for a plage region (black), loop (light blue) and bright point (red). The spatial location where these spectra are acquired are shown by the coloured boxes in Fig. 4 respectively. The pink vertical lines indicate the at-rest wavelength position for each of the spectral lines. The spectral lines do not show any significant Doppler shift apart from the 5–8 km s-1 quiet-Sun systematic redshift.

4. IRIS observations of an active region and a flare

IRIS is a complex instrument with two major components. It acquires simultaneous spectra and images at very high temporal (up to 2s) and spatial (0.33–0.4) resolution. The IRIS spectrograph observes continua and emission lines over a very broad range of temperatures (logT[K] = 3.7–7), including the TR lines under study (Table 1). Simultaneously, the IRIS Slit Jaw Imager (SJI) provides high-resolution images in four different passbands (C ii 1330 Å , Si iv 1400 Å, Mg ii k 2796 Å and Mg ii wing 2830 Å).

In this study, we examine the spectra of O iv, S iv and Si iv lines observed by IRIS in the non-flaring AR NOAA 12356 on 1 June 2015 (see Fig. 3) and in AR 12371 during an M6.5 class flare on 22 June 2015. We use level 2 data downloaded from the IRIS website3, which are obtained from level 0 data after flat-field, geometry calibration and dark current subtraction, as detailed in the IRIS software notes4. In addition, we used the solarsoft routine despik.pro to remove the cosmic rays. The calibration of the wavelength scale was performed as described in Polito et al. (2015, 2016).

We use IRIS spectroscopic data to measure the intensity Iobs (expressed as data number (DN)) of the TR lines in different observed spectra. The intensities were then converted from DN to physical units (erg s-1 sr-1 cm-2) by using the radiometric calibration detailed in the IRIS technical note 263. In particular, the updated version of the SolarSoft routine iris_get_response.pro was used, which corrects the effective areas to take into account the instrumental degradation since launch. The errors associated to the intensities are derived as described in the following section.

4.1. Fitting the IRIS line profiles

The line profiles observed in the AR under study (Sect. 4.2) present a non-Gaussian shape with narrow core and broad wings (Fig. 5). Such profiles could be fitted well with two Gaussian components (see Fig. B.1). We used the SolarSoft routine xcfit to perform the fitting. The error estimated by the multi component fitting in the xcfit routine takes into account the errors (as standard deviations) associated to the parameters of each Gaussian. Given the high number of free parameters in the double Gaussian fit, this error can be quite large, even though the sum of the two Gaussians approximates the observed spectrum well, as shown in Fig. B.1. In order to have an alternative estimation of the errors associated to the observed intensities Iobs, we compare the calibrated intensities obtained by the fitting the line profiles with two Gaussians to the intensities obtained by summing the total intensity under the line profile. These errors are typically less than 10% (see Tables B.1 and B.2). In both method (fitting and sum) a background was subtracted by the spectral window before measuring the line intensities. This background can be estimated by averaging the counts over a spectral interval which is free of any emission lines.

We note that the spectral lines in the AR plage and loop regions (see Figs. 5 and B.1) present relatively narrow profiles which allows us to rule out the presence of significant blends, except the well-known blends of S i 1401.51 Å within the O iv 1401.16 Å line and O iv 1404.81 Å with S iv 1404.85 Å (see Sect. 2). In particular, in the plage spectrum (middle panel of Fig. B.1) we can clearly distinguish the two Fe ii lines (see Sect. 2) and the nearby the S iv 1406.06 Å line, ruling out any possible blending issue. For the plage and loop spectra, the difference between the summed and fitted intensities is very small (see Tables 2, B.1 and B.2); therefore we use the intensity values obtained by summing under the line profiles and assume a maximum error of 10%.

Table 2

Line intensities Iobs in the loop region.

thumbnail Fig. 6

Emissivity ratio curves as a function of density for the O iv and S iv spectral lines observed by IRIS in the “loop” region. Different colours for the curves indicate different spectral lines as described in the legend. In the top panel, we assume the typical temperatures of formation of logT[K] = 5.15 and 5 for the O iv and S iv ions, respectively. In the bottom panel, a temperature of logT[K] 5 is assumed instead for both ions. The error bars include the propagation of a 10% uncertainty in both the line intensity and the atomic data.

In contrast, the spectra acquired in the AR bright point (see Fig. 5 and bottom panel of Fig. B.1) show broader profiles resulting in a worse fit and an increased error in the intensity estimation. In particular, it is not clear if the enhancements of the blue and red wings observed in some lines (such as the S iv 1406.93 Å) might be due to a superposition of flows or to blending with other lines (such as Fe ii). In this case, we only fitted the main central component of the line profile and the difference between summed and fitted intensity is higher (Table B.2). Therefore, we assume an error of 20% for the intensity in the bright point spectrum. Similarly, a 20% error is associated to the line intensity values in the flare case study (Sect. 4.3), where the line profiles are often asymmetric and need to be fitted with two or more Gaussian components.

In Sects. 4.2 and 4.3 we present the analysis of the density diagnostics for the AR 12356 and the M 6.5 class flare on the 22 June 2015, respectively. We then discuss the results in Sects. 5 and 6.

4.2. Density diagnostics in the AR NOAA 12356

The AR NOAA 12356 was visible during its passage on disk from May 28 to June 10, 2015 and during this time it did not show any major flaring activity. Figure 3 presents an overview of the AR 12356 as observed by IRIS in the SJI 1400 Å filter. This band is dominated by TR emission from Si iv at around logT[K] = 4.9 and shows several loop structures and compact bright points. The movie shows the evolution of the AR over time, as observed in the SJI 1400 Å band. In particular, the movie shows that these loops and brightenings evolve very dynamically over time. The coloured box in Fig. 3 indicates the field of view of the IRIS spectrograph monochromatic images shown in Fig. 4. The IRIS spectrograph was running a single raster over the AR 12356 from 18:11 UT to 21:27 UT on the 1 June 2014. The dense 96-steps raster ran from east to west over a field of view of 33″ × 119″. Every slit position had a 0.33 step size and an exposure time of 60 s. Several CCD spectral windows were included in this study, but we focus our analysis on the FUV spectral window centred around the Si iv 1402.77 Å line.

The images in Fig. 4 show the intensity maps of the Si iv 1402.77 Å, O iv 1399.78 Å and 1401.16 Å, S iv 1406.06 Å spectral lines observed during the IRIS raster. For each slit exposure, the intensity at each detector pixel has been obtained by integrating the total counts (DN) over the line profiles and converting them to physical units (phot s-1 arcsec-2 cm-2).

We analyse three different features in the AR 12356 where the O iv and S iv lines were reasonably intense: a more steady region that we call “plage”, a “loop structure” and a brightening that we call “bright point”. These regions are indicated in Fig. 4 by the yellow, light blue and red coloured boxes respectively. The corresponding IRIS TR spectra (black, blue and red lines) are shown in Fig. 5. The individual spectra are plotted in Fig. B.1, which also shows the double Gaussian fit. We note that the line profiles are much broader in the bright point spectrum than in the loop and plage spectra, possibly due to a superposition of different flows along the line of sight or turbulent motion in the plasma. In addition, the relative intensity of the observed lines (in particular of the 1404.82 Å blend and the S iv 1406.06 Å) changes significantly between the three spectra. This is a consequence of the density variation between different regions. The movie shows these features over time at high spatial resolution with the IRIS SJI. In particular, the so-called “plage" region seems to be made by small unresolved arch-like structures.

In the following, we show detailed results for the loop region only and we refer the reader to the Appendix B for the AR plage and bright point analysis.

The top panel of Fig. 6 shows the emissivity ratios of each IRIS TR line observed in the loop spectrum as a function of density, given by Eq. (9) and described in Sect. 2. The intensity of the blended O iv 1404.81 Å and S iv 1404.85 Å lines was obtained as described in Eqs. (4) and (5). The temperature T used to calculate Gth(T,Ne) in Eq. (7) is initially taken to be the temperature of maximum abundance for each ion from the fractional ion abundances available in CHIANTI v.8; that is, logT[K] 5.15 and 5.0 for O iv and S iv respectively. It is important to note that these fractional ion abundances are calculated in CHIANTI assuming a low electron number density, below 108 cm-3. As we mentioned in Sect. 3, given the small difference in temperature of formation of the two ions, if we assume pressure equilibrium, we expect the O iv and S iv plasma to be formed at electron densities which differ by up to a factor of 1.8.

The two S iv and three O iv transitions in the top panel of Fig. 6 show two distinct crossing points which would indicate electron densities logNe [cm-3] of 10.70 and 11.34 respectively. The density values obtained by using the separate O iv and S iv ratios thus differ of a factor by around four, that is, much higher than expected assuming constant pressure. The error bars at the crossing points represent the propagation of a 10% error in both the line intensities and the Gth(T,Ne). We emphasize that estimating the density from the crossing points of the O iv and S iv lines separately is equivalent to applying the intensity ratio method (Eqs. (1)–(3)). We also note a significant discrepancy between the relative intensity of those ions taking into account the error bars. A discrepancy in the relative line intensity is also found in both the bright point and plage spectra (see Appendix B) as well as in the flare spectrum analysed in Sect. 4.3. We note that previous studies (e.g. Keenan et al. 2002) mainly focused on comparing density diagnostics using the O iv and S iv ratios individually but did not report any comparison on the relative intensity of spectral lines from the two ions.

We rule out that the discrepancy in the relative intensity and derived electron density values could be due to an underestimation of the errors associated to either the atomic data or observed intensities. In Appendix A we show that atomic calculations from different authors agree better than a 10%. Regarding the intensity values, we note that the intensity of the O iv 1404.81 Å and S iv 1404.85 Å lines might indeed be affected by a larger error than the other unblended lines. However, the discrepancy between the unblended O iv and S iv lines would still remain. In addition, we emphasize that possible blends of the O iv and S iv with the photospheric S i and Fe ii spectral lines do not represent a major issue as discussed in Sect. 4.1. Finally, the discrepancy is observed in all AR features studied as well as in the flare spectrum presented in Sect. 4.2, suggesting that differences in O and S chemical abundances are unlikely to be the main cause.

We recall that the emissivity ratio curves shown in the top panel of Fig. 6 are obtained assuming that the O iv and S iv ions are formed at the temperature of maximum ionization abundance for each ion. We relaxed this assumption and investigated whether we could find a combination of a single density and a single temperature values for the emitting plasma which could reproduce the intensity of all the O iv and S iv lines in the observed AR loop spectrum. Given the lack of suitable spectral lines to produce a DEM distribution, we start by assuming that the O iv and S iv plasma are nearly isothermal. This approximation can be justified by the fact that AR loops are often observed to show a very narrow distribution in their cross-section (Del Zanna 2003; Warren et al. 2008; Brooks et al. 2012; Schmelz et al. 2007). This seem to be particularly true for cooler loops which tend to have narrower DEM distributions than hotter loops (Schmelz et al. 2014, 2009). In Fig. 7 we show a 3D plot of the emissivity ratio ER(T,Ne) as a function of T and Ne for just the three unblended lines observed by IRIS: O iv 1339.77 Å and 1401.16 Å, and S iv 1406.06 Å. The 3D emissivity ratios consistently intersect at a temperature of logT[K] 5.0 and a density of logNe [cm-3] 10.6. Hence, we recalculate the Gth(T,Ne) function at this latter value of temperature for each of the observed IRIS TR lines. We note that the observed intensity Iobs of the blended O iv 1404.81 Å line (and consequently of the S iv 1404.85 Å line) also changes slightly because it is now obtained from Eq. (4) by taking R2 at the density logNe [cm-3] = 10.6 rather than at the density estimated by the R1 ratio as previously.

thumbnail Fig. 7

3D emissivity ratio as a function of logNe [cm-3] and logT[K] for the S iv 1406.93 Å, O iv 1399.78 Å and O iv 1401.16 Å lines observed by IRIS in the “loop” region. Different colours for the surfaces indicate different ions as described in the legend.

The bottom panel of Fig. 6 shows the new emissivity ratio curves obtained assuming the temperature and density values obtained from the 3D emissivity ratios in Fig. 7. We note that the discrepancy between the O iv and S iv intensities is now removed and that all the lines, including the O iv at 1404.81 Å and the S iv at 1404.85 Å, consistently indicate a near iso-thermal (logT[K] 5.0) and iso-density (logNe [cm-3] 10.6) plasma.

It is interesting to note that the analysis of the bright point and plage spectra (see plots in Appendix B) are also consistent with the emitting plasma being isothermal and in all cases formed at temperatures logT[K] 5.0.

In Table 3 (middle row) we compare the estimated density Ne for the loop region obtained from the intensity ratios R1, R3 and R4 (Cols. 2–4) and the ER method analysis presented above (Col. 5, indicated as “A”). Column 6 shows the density values obtained from the ER method after taking into account the Ne dependence in the fractional ion abundances of each ion (indicated as ER method “B”). This latter method will be described in detail in Sect. 5.1. Finally, Cols. 7 and 8 show the estimated values of plasma temperature obtained by using the ER method in the case A and B respectively. The same results for the plage and bright point regions are also reported in the top and bottom rows of Table 3.

In Sect. 4.3 we perform a similar density diagnostic analysis with spectra acquired during the impulsive phase of the 22 June 2015 flare.

thumbnail Fig. 8

Soft X-ray light curves as measured by the GOES satellite in the 0.5–4 Å and 1–8 Å chennels during the 22-June-2015 flare. The dotted green lines represent the times of the IRIS rasters that were selected for measuring the electron density, as indicated in Table 4.

Table 3

Electron number density and temperature for different features in the AR 12356.

4.3. High density measurements during the 22 June 2015 M-class flare

In this section, we focus on the M6.5 class flare that occurred in AR NOAA 12371 on 22 June 2015. The flare started at about 17:23 UT and reached the maximum of the X-ray flux at around 18:00 UT, as shown in the GOES light curves in Fig. 8. The peak phase was followed by a long gradual phase until about 20:53 UT.

On 22 June 2015, IRIS was running several 16-step sparse rasters observing the AR 12371 from 17:00 UT to 21:14 UT. Each raster had a FOV of 15× 119 and a cadence of 33 s, with a single slit exposure time of just 2 s.

The left panel of Fig. 9 shows that the IRIS slit (vertical line) intersected both northern and southern ribbons during the whole evolution of the flare. The right panel of Fig. 9 shows a spectrum of the Si iv 1402.77 Å window at the location where the slit was crossing the southern flare ribbon at around 17:54 UT, during raster No. 96 and at slit exposure No. 9. We note that the relative intensity of the S iv line at 1406.06 Å and the O iv + S iv blend at 1404.82 Å is significantly larger compared to the AR spectra presented in Sect. 4.2. This is a result of the increase in the electron density.

thumbnail Fig. 9

Left: IRIS Slit Jaw Image in the Si iv 1400 Å filter, showing the flare ribbons and the position of the IRIS spectrograph slit (vertical white line). The black pixels are due to dust contamination on the IRIS detector. Right: Si iv window observed by the IRIS spectrograph at the southern flare ribbon, at the location indicated by the arrow. The dotted red lines represent the wavelength limits which were assumed when summing the total counts for each line. See text for further details (Sect. 4.3).

We analyse four TR spectra at the same slit position No. 9, crossing the southern flare ribbon during the impulsive and peak phases of the flare, where the TR lines are strong. We only selected spectra where the line profiles were not strongly asymmetric or contaminated by a high FUV continuum. Table 4 summarizes the results of the density diagnostics by using the intensity ratios R1, R3 and R4 and emissivity ratio method “A” when applicable. In addition, the last two columns show the plasma density and temperature obtained by using the ER method “B”, that is, taking into account the ionization balances in high density regime (with ADAS), as described in Sect. 5.1.

The emissivity ratio methods (“A” or “B”) cannot be applied if R1 lies outside the density sensitivity limit of 1012 cm-3 (Fig. 2 top). In such cases however, the S iv ratio can still be used as it is sensitive to densities up to 1013 cm-3 (Fig. 2 bottom). It is important to note that the ratio R2 also reaches a statistical equilibrium above 1012 cm-3 and it remains constant at the value of around 6. Therefore, we can use this value to estimate the contribution of the O iv 1404.81 Å line to the blend at 1404.82 Å from Eq. (4) and thus obtain the intensity of the S iv line involved in the R3 ratio (from Eq. (5)).

Table 4

Electron number density and temperature at the flare ribbon over time.

It is important to note that at these high densities, the intensity of the O iv 1404.81 Å (and thus S iv 1404.85 Å) line obtained from R2 will not change with density as in the previous case of the AR loop presented in Sect. 4.2. The S iv ratio is therefore a more reliable density diagnostic in the high density regime (above 1012 cm-3).

The values of S iv ratios and corresponding densities over time are shown in Table 4 and in Fig. 10 for the four selected spectra. Figure 10 shows that the density reaches a peak of above 1013 cm-3 during the impulsive phase of the flare at about 17:59 UT. It then drops dramatically by more than one order of magnitude by around 18:02 UT, 2 min after the peak of the flare in the soft X-ray flux. The fourth column of Table 4 shows the density diagnostics obtained by using the Si iv/ O ivR4 ratio for the four spectra analysed, except the one at 17:57:57 UT where the Si iv line is saturated. Interestingly, the density diagnostics from the Si iv/O iv and the S iv (R3) ratios seem to show better agreement at two times (second and third row Table 4) during the impulsive phase of the flare compared to the lower density AR case (Sect. 4.2). However, we note that at those two times the intensity of the Si iv line is very large and only 5% below the saturation threshold, which might affect the intensity estimation. In addition, opacity effects may also cause a decrease in the Si iv intensity (see Sect. 6).

thumbnail Fig. 10

Ratio of S iv 1404/1406 lines (top panel) and derived electron density (bottom panel) as a function of time for the 22-June-2015 flare. The arrow indicates the high density limit (1013 cm-3) of the S ivR3 line ratio.

At 18:02 UT, the density is again within the sensitive interval of the O iv line ratios and we can thus apply the emissivity ratio method. The top panel of Fig. 11 shows the emissivity ratio curves for the O iv and S iv lines observed by IRIS during the raster No. 110 at 18:02:28 UT. A very large discrepancy between the relative intensities of these lines is evident. Hence, we use an approach similar to the one presented in Sect. 4.2 and try to determine whether the emitting plasma can be fitted with a different value of temperature, starting from a near-isothermal assumption for the two ions. Figure 12 shows a 3D emissivity ratio plot. We find that the flare spectrum at 18:02 UT is consistent with a plasma emission being isothermal at the temperature of logT[K] 4.98 and density logNe [cm-3] 11.70. We then re-calculated the Gth function at the newly estimated temperature and density, as explained in Sect. 4.2. The corresponding new emissivity curves are plotted in the bottom panel of Fig. 11, showing that the intensity of all the observed O iv and S iv lines, including also the O iv 1404.81 Å and S iv 1404.85 Å, are indeed consistent with a plasma being near iso-density and iso-thermal.

thumbnail Fig. 11

Emissivity ratio curves as a function of density for the O iv and S iv spectral lines observed by IRIS in the ribbon during the peak phase of the 22-June-2015 flare (at 18:02:28 UT). Different colours for the curves indicate different spectral lines as described in the legend. In the top panel, we assume the typical temperatures of formation of logT[K] = 5.15 and 5.0 for the O iv and S iv ions, respectively. In the bottom panel, a temperature of logT[K] 4.98 is assumed instead for both ions. The error bars include the propagation of a 10% uncertainty in both the line intensity and the atomic data.

5. Processes affecting the ion formation temperature

Sections 4.1 and 4.2 show that the observations of O iv and S iv transition lines are consistent with an isothermal assumption and temperatures of about logT[K]  5.0 This value is consistent with the temperature of the S iv maximum ion abundance but it is lower than the temperature at which most of O iv plasma is expected to emit in ionization equilibrium.

As we already mentioned in Sect. 4.2, cooler coronal loops often show a near-isothermal distribution, so it is not surprising to see this result for the TR loops. It is not obvious to us why we should find an isothermal temperature for the O iv and S iv plasma also at the flare ribbon, AR plage and bright point but this does indeed seem to fit the observed data well. As mentioned above, the movie shows that the so-called “plage” region is continuously filled with small and very fast loop-like structures. Hence, one possible explanation is that in all cases the plasma we observe either originates from loop structures (AR loop and possible the plage region) or loop footpoints (for the flare and bright point cases), which are both features where the plasma is often observed to be near isothermal.

However, the predicted formation temperature of the ions is uncertain. There are in fact several effects that can shift the temperature of formation of the ions, the most important ones being briefly summarised in Sects. 5.15.3.

5.1. Density effects on the ion abundance

The ion abundance can be obtained once the total effective ionisation and recombination rates are known. Most ion charge state distributions found in the literature are in the so-called low-density limit. Fractional ion abundances that take into account density effects were presented by Burgess & Summers (1969) and Jordan (1969). In particular, there are two main effects which become important at high densities, the suppression of the dielectronic recombination (DR), and the presence of metastable states.

As shown by Burgess (1964), DR is far more important that radiative recombination (RR). As first calculated in detail by Burgess & Summers (1969), DR becomes suppressed at high densities. To derive appropriately the effects of finite density on the emissivity and so in particular on DR, complex Collisional-Radiative (CR) modelling needs to be carried out. Results of this modelling were published in a series of papers and reports by H. Summers (see e.g. Summers 1974). However, approximate cross-sections were used. For example, for the DR, the Burgess approximate formula was used. Since then, more accurate DR calculations in the low-density limit (the DR project, see Badnell et al. 2003) have been carried out. In addition, Nikolić et al. (2013) have provided an approximate way to estimate the DR suppression by using the most recent DR rates and comparing the relative suppression with that which was calculated by H. Summers.

For several ions, significant population is present in the metastable states at high densities, hence ionisation and recombination from these states also needs to be taken into account. The role of metastable states and the effects of finite density on DR are considered within the generalised collisional-radiative (GCR) modelling in ADAS (Summers et al. 2006).

thumbnail Fig. 12

3D emissivity ratio as a function of logNe [cm-3] and logT[K] for the S iv 1406.93 Å, O iv 1399.78 Å and O iv 1401.16 Å lines observed by IRIS during the first peak of the 22-June-2015 flare (18:02:28 UT, indicated by the last dotted vertical line in Fig. 8). Different colours for the surfaces indicate different ions as described in the legend.

Figure 13 shows the fractional ion abundances for O iv, S iv and Si iv obtained by using the effective rate coefficients for ionisation and recombination available in the OPEN-ADAS database2 (for O iv, the GCR model was used; for S iv, the CR model was used). The continuous curves show the fractional ion abundances calculated at low density values (Ne = 108 cm-3) while the dotted lines show the results for higher densities (Ne = 1011−13 cm-3). As already shown by (e.g. Vernazza & Raymond 1979), including the effects of DR suppression and the presence of metastable levels results in a shift the formation temperature of TR ions towards lower values. In a stratified atmosphere, lower temperature plasma regions have a larger density which thus cause an increase in the line intensities. This increase is particularly large for allowed lines, whose intensity is proportional to Ne2\hbox{$N_\textrm{e}^{2}$}, and might explain the anomalously high intensity of some of such lines (such as the Si iv 1402.77 Å). In addition, Fig. 13 shows that the values of the peak fractional ion abundances for Si iv and S iv increase significantly with density, contributing to an additional increase in the intensity of those ions.

In order to estimate the effect on the density diagnostics, we applied the ER method to the AR loop and flare observations by including the density-dependent ADAS fractional ion abundances in Eq. (7). The results of density and temperature so obtained are given in Tables 3 and 4 (indicated as ER method “B”). In both cases, the estimated plasma temperature is lower than the temperatures that we obtained in Sect. 4 using fractional ion abundances from CHIANTI (calculated at low density). In contrast, the density values do not change significantly, showing that the high density effects on the ion abundances do not affect the density diagnostic results presented in Sect. 4, in the isothermal approximation.

thumbnail Fig. 13

Fractional ion abundances N(X+ m) /N(X) for O iv (blue lines), S iv (green lines) and Si iv (red lines) calculated as a function of different electron number densities using atomic data from the OPEN-ADAS database. The continuous, dotted, dashed and dot-dashed lines indicate a different value of electron number density used to calculate the fractional ion abundances for each ion, as described in the legend.

5.2. Non-equilibrium ionisation

We note that IRIS does not observe spectral lines of successive stages of ionisation of an element which would enable us to study non-equilibrium ionisation in detail. The effect of transient ionization on the intensity of the O iv and Si iv lines observed by IRIS at plasma densities of around 1010 cm-3 was recently investigated by Doyle et al. (2013) and Olluri et al. (2013). Those lines show a very different response to transient ionization because of their different formation process. In contrast, the S iv and O iv lines analysed in this work have similar atomic structure (see Table 1) and therefore we expect them to behave in a similar manner under non-equilibrium ionization.

In addition, the relatively high densities we expect and measure in the low TR where O iv is emitted in active regions (1011 cm-3) and in the flare under study (1013 cm-3), mean that strong departures from equilibrium ionisation are not expected (cf., Dzifčáková et al. 2016). At these densities, the typical ionisation/recombination timescales are in fact of the order of 1 s (e.g. Smith & Hughes 2010), which are comparable to or less than the IRIS exposure times. In particular, the exposure time of the AR observation presented in Sect. 4.2 is around 60 s, that is, much longer than the expected ionization/recombination timescales. The non-equilibrium ionization could however still be present if there are advective flows carrying plasma from regions with different temperature (e.g. Bradshaw & Mason 2003; Olluri et al. 2013). We however do not detect any strong Doppler shifts, apart from the systematic 5 km s-1 redshift in the quiet Sun TR (e.g. Brekke et al. 1997), in any of the observed O iv and S iv spectra in the AR loop and flare studies (see for example Fig. 5). The O iv and S iv plasma should therefore be close to the ionization equilibrium at the densities we observe in this work (above 1010 cm-3).

thumbnail Fig. 14

Left: density (x-axis) and temperature (y-axis) values at the 3D emissivity plot crossing points for the AR loop, obtained assuming non-Maxwellian distributions with different values of κ, except for κ = 2. The density and temperature values for the Maxwellian case in Sect. 4.2 are also shown for comparison. Right: 3D emissivity ratio for the κ = 2 case. We note that there is no crossing point in this case. Different colours for the surfaces indicate different ions as described in the legend.

5.3. Non-thermal distributions

The presence of non-Maxwellian distributions with high-energy tails, such as the κ-distribution, could significantly shift the formation temperatures of the TR lines towards lower temperatures (Dzifčáková & Kulinová 2011; Dzifčáková & Dudík 2013). For a DEM decreasing with temperature, the Si iv line will be strongly enhanced compared to the O iv and S iv ones (Dudík et al. 2014). This effect could easily explain the large intensities of the Si iv lines compared to the O iv ones reported in Sect. 4, except for some of the spectra in the flare case (although see discussion in Sect. 4.3).

However, unambiguous detection of such non-Maxwellian distributions from IRIS observations is not trivial. This is due to the fact that only a few lines are observed by IRIS, and that these lines are formed from energy levels close in wavelength. There are however indirect indications of the possible presence of non-Maxwellian distributions in the present observations. First, as already mentioned, the Si iv intensities are too large by a significant factor compared to the Maxwellian predictions at the values of T and Ne derived from the ER method applied to the AR loop in Sect. 4.2, leading to the densities diagnosed from the ratio R4 being much higher than using other methods (see Table 3 in Sect. 4.2). Second, the line profiles observed in the AR (Sect. 4.2, Fig. 5), especially in the loop, show narrow cores and broad wings, consistent with a velocity distribution for the ions given by a κ-distribution (generalized Lorentzian). Preliminary work on fitting the line profiles using the method of Jeffrey et al. (2016) suggests that at least some of the line profiles are well-fitted with a κ 2. Since a detailed analysis of multiple line profiles in different observed regions is beyond the scope of the present manuscript, in the following we only show the possible effect of the κ-distributions on the density diagnostics for the AR loop presented in Sect. 4.2. This can be done by calculating the contribution function Gth of the O iv and S iv lines assuming κ-distributions for the electrons, analogous to Dudík et al. (2014), but with the same atomic data as described in Sect. 2. Additionally, we have corrected a minor error in the collision strengths calculations performed by Dudík et al. (2014) as shown in Appendix C. The estimated values of temperature and density from the ER method for different κ values are shown in the left panel of Fig. 14. The isothermal crossing points exist at for κ ≧ 3 if temperatures of logT[K] 4 are considered. The isothermal and iso-density crossing points occur at progressively lower T and Ne (Fig. 14, Table 5). However, no crossing point exists for κ = 2 (right panel of Fig. 14), which is inconsistent with the line profiles, assuming that the electrons and ions have the same velocity distribution. The cause of this is unknown at present.

Table 5 and Fig. 14 show that a range of possible values of density and temperature diagnostics for the AR loop if non-thermal distributions at different κ values were present in the observed plasma.

Table 5

Density and temperature estimation from the ER method assuming non-Maxwellian electron distributions for different κ.

6. Discussion and summary

In this work we have investigated the use of the O iv and S iv emission lines near 1400 Å observed by IRIS as electron density diagnostics in the plasma from which they are emitted. These ions are formed at similar temperatures and therefore are expected to provide similar density diagnostics (within a factor of around two).

Density diagnostics are usually based on the use of the intensity ratio of two lines from the same ion. We have applied an emissivity ratio method to obtain a value of electron density which can reproduce the relative intensity of the all the O iv and S iv lines in the observed spectra.

In our analysis, we have selected different plasma regions within an AR (loop, bright point and a plage region) and at the ribbon of the 22 June 2015 flare, where the lines were observed to be more intense. The O iv and S iv lines (in particular the O iv line at 1399.77 Å) are usually very weak and cannot easily be detected in quiet Sun regions with IRIS.

In all the features we analysed, we find that the O iv and S iv lines give consistent density diagnostic results when we assume that the plasma has a near isothermal distribution rather than different temperatures of formation for the two ions. In all cases, the results are consistent with the plasma being at a temperature of about logT[K] = 5. This temperature is lower than the peak formation temperature of O iv calculated in CHIANTI v.8 assuming ionization equilibrium. However, a significant amount of O iv is still formed at a temperature of logT[K]  5.0, as shown in the fractional abundance plot in Fig. 13 (continuous lines), and even more so when the high density effects are taken into account (dotted lines). The hypothesis of iso-thermality for the O iv and S iv plasma could be explained by the fact that all the features we analysed are either cool loop structures or loop footpoints, which are often observed to be dominated by plasma with a very narrow thermal distribution (e.g. Del Zanna 2003; Warren et al. 2008; Schmelz et al. 2007, 2014). We also emphasize that we are estimating average values of temperature and density for the emitting plasma.

Using the emissivity ratio method, we find electron number densities ranging from logNe [cm-3] 10.6–11.0 in the AR loop and bright point respectively. The density variation in different plasma features in the AR under study can also qualitatively be estimated by comparing the spectra shown in the right panel of Fig. 5. For instance, in the bright point spectrum (red), formed in a higher density plasma, the intensity of the S iv 1406.1 Å spectral line is enhanced compared to the intensity of O iv+S iv blend at 1404.82 Å. In contrast, in the loop spectrum the S iv 1406.16 Å line is weaker, indicating that the plasma is at a lower density. In addition, we note that the densities obtained by using the Si iv/O iv line ratio R4 are much higher than the values obtained by using the O ivR1 and S ivR3 ratios, as shown in Table 3 and previously noted by Hayes & Shine (1987). This could be due to a number of issues, as outlined in Sects. 1 and 5.2, and in particular to the anomalous behaviour of the Na-like ions.

In the flare case presented in Sect. 4.2, the O iv line ratio indicates a very high electron number density above the high density limit of 1012 cm-3. The S iv line ratio is sensitive to higher electron densities and has been used to measure densities of 1013 cm-3 at the TR footpoints of the flare during the impulsive phase. Indications of high electron densities in the TR plasma during flares have been reported by some authors in the past. In particular, Keenan et al. (1995) obtained 1012 cm-3 using the O v line ratio, while Cook et al. (1994) reported density values of 1012.6 cm-3 using ratios of allowed and intersystem O iv lines. However, most of the other studies (e.g. Cook et al. 1995) were based on the use of line ratios, such the O iv ones used in this work, which are density-sensitive up to a high density limit of 1012 cm-3, and therefore could only provide lower estimates for the electron density. Other authors have investigated electron number densities in high temperature plasma during flares. For instance, Doschek et al. (1981) measured densities of 1012 cm-3 in the O vii coronal plasma at 2 MK. Of particular importance is the study of Phillips et al. (1996), who showed for the first time very high electron densities (up to 1013 cm-3) from ions formed at 10 MK. Those high densities were observed 1 min after the peak of a M-class flare. By using the ratio of the S iv lines observed by IRIS, we obtain an accurate electron density estimates for the TR plasma which are almost everywhere within the sensitivity range of the line ratio. Figure 10 shows that very high densities close to or above 1013 cm-3 are only reached over a short period of time during the peak of the flare, before dropping dramatically by more than an order of magnitude at the same footpoint position over 2 min. To the best of our knowledge, this is the first time we can directly diagnose such high electron number densities in the TR plasma during a flare. Density diagnostics based on the use of S iv line ratios with previous instruments in the past were complicated by the presence of line blends which could not be properly resolved and problems in the atomic data (Dufton et al. 1982; Cook et al. 1995), as also pointed out by Keenan et al. (2002). In this work we have shown that the S iv 1404.85 Å line can be accurately de-blended from the O iv 1404.85 Å line in the high density interval above 1012 cm-3. In this case in fact the ratio R2 remains constant, reducing the uncertainty associated with the estimation of the O iv 1404.85 Å contribution to blend by using the O iv 1401.16 Å line intensity (see middle panel of Fig. 2). One might think that at such high values of densities, the opacity effects may become important. This is not the case for the O iv and S iv intercombination lines, due to the low A-values of these transitions. The optical depth can in fact be easily estimated by using the classical formula given for instance in Buchlin & Vial (2009). We found that at a density of 1013 cm-3, the O iv lines reach an opacity of 1 over an emitting layer of the order of 105 km, which is much higher than the source size (size of the IRIS pixel, i.e. around 200 km). In contrast, the Si iv reaches an opacity of 1 over a considerably smaller layer, of the order of 20 km. This implies that opacity effects might be important for this line in the flare case study. In particular, a decrease in the Si iv intensity due to the opacity might result in wrong density estimates based on the Si iv/O iv ratio.

Moreover, we emphasize the importance of including the effect of high electron number densities (above 1010 cm-3) in the calculations of the fractional ion abundances. In Sect. 5.1 we show that including fractional ion abundances for O iv and S iv calculated at higher electron number density does not significantly affect the results of the density diagnostics from the emissivity ratio method. In contrast, the temperature formation of the ions, and therefore the temperature estimation from the emissivity ratio method, is shifted to lower values, as shown in Fig. 13.

Similarly, the presence of non-Maxwellian electron distribution in the plasma causes a shift of the temperature of formation of the ions to lower values. It is not possible to unambiguously detect signatures of non-thermal plasma conditions in the present study. A possible signature might arise from the analysis of the spectral line profiles. These profiles provide information regarding the velocity distribution of the ions, and it is reasonable to assume that this distribution is the same than the electron velocity distribution at these plasma densities and at the timescale of our observations. However, this analysis is quite involved and requires further investigation which is beyond the scope of this paper. In this work, we are interested in estimating how the possible presence of non-thermal electron distributions might affect our density diagnostics. We therefore provide a range of possible values of density and temperature diagnostics for the AR loop obtained by using the emissivity ratio method, assuming that κ-distributions at different κ values were present. The results are presented in Fig. 14 and Table 5, showing that the density and temperature diagnostics would indeed differ significantly from the values obtained in Sect. 4.2, where we assumed Maxwellian electron distributions.

We have shown that combining O iv and S iv observations from the recent IRIS satellite provide a useful tool to measure the electron number density in a variety of plasma environments. In particular, thanks to very high spatial resolution of IRIS (200 km) it is now possible to select small spatial elements, reducing the problem of observing emission from very different density and temperature plasma regions, as pointed out in the past by Doschek (1984).

In this work, we greatly emphasized the importance of including the S iv lines in the IRIS observational studies. Simultaneous, high-cadence observations of several spectral lines formed in the transition region can be used as direct density and temperature diagnostics of the emitting plasma. These diagnostics provide crucial information which can be compared with the predictions made by theoretical models of energetic events in the solar atmosphere.
