1. Introduction

Carbon is one of the most important species in the interstellar medium (ISM), both in terms of its relevance for the physical and chemical state of the ISM, as well as because of its diagnostic power (e.g., Henning & Salama 1998). Because of its high abundance, carbon is one of the major coolants of the ISM, in its atomic and ionized form for the low-extinction components and in its most abundant molecular form (CO) in high extinction and dense molecular clouds. There are two main pathways linking the sequence C+/C0/CO: During cloud formation, the originally diffuse and ionized medium recombines and becomes partly neutral (observable in lines of ionized C+ ([CII]) and neutral carbon C0 ([CI])), and then with increasing densities forms molecular H2 and CO (e.g., Bergin et al. 2004; Glover et al. 2010). In contrast, if exposed to strong UV radiation, CO can dissociate to form atomic and ionized carbon (e.g., Köster et al. 1994; Röllig et al. 2006).

As atomic hydrogen reacts to form H2 during cloud formation (e.g., Bergin et al. 2004; Heitsch et al. 2008), the carbon follows the C+C0CO route during the formation of infrared dark clouds (IRDCs). At early evolutionary stages, C+ is likely to be one of the best tracers for the so-called “dark H2” because due to self-shielding H2 forms earlier than CO (e.g., Langer et al. 2010; Glover & Mac Low 2011). During these processes, signatures of streaming motions may be imprinted on the different carbon lines, allowing us to investigate the cloud formation processes (e.g., Glover et al. 2010; Shetty et al. 2011; Clark et al. 2012).

At the center of IRDCs, massive stars form rapidly, exciting the surrounding gas and producing the different forms of carbon via the opposite COC0C+ route. Photon-dominated region (PDR) models give predictions about the line properties in this scenario (e.g., Tielens & Hollenbach 1985; Cubick et al. 2008). Furthermore, the youngest and most embedded protostars develop jets and outflows that form cavities that act as valves releasing UV radiation into the ambient gas (e.g., Kuiper et al. 2010; Cyganowski et al. 2008). Thus, feedback from the youngest protostars affects the relative abundances of molecular CO and atomic and ionized carbon also in the most deeply embedded regions.

Early work has shown that [CII] and [CI] emission is far more extended through molecular clouds than was initially anticipated with layered-structure cloud models. This implied that molecular clouds are clumpy and that the radiation can penetrate the clouds deeply (e.g., Stutzki et al. 1988; Herrmann et al. 1997; Kramer et al. 2004). However, because of the poor spatial resolution available at those times, in particular for C+, there was no chance to spatially resolve the substructures, and to disentangle the excitation mechanisms of the different gas components. For example, is the [CII] and [CI] emission deep inside the clouds mainly due to external radiation that penetrates deeply through the clumpy medium, or do internal heating sources from embedded stars contribute significantly to the formation of C+ and C0 (e.g., Ossenkopf et al. 2011)? Topics like that can be addressed particularly well for IRDCs because, while they are at early stages of cloud evolution, many already contain internal heating sources that excite the immediate environment (e.g., Rathborne et al. 2006; Beuther et al. 2010; Henning et al. 2010; Wang et al. 2014). This information is also necessary for the proper modeling of the structure and evolution of molecular clouds, since any interior warm gas provides thermal support and deep penetration of UV photons enhances the importance of magnetic support.

To disentangle the different carbon components, it is essential to map the respective regions at high spatial resolution, and to spectrally resolve the line emission. The detailed comparison of the line profiles and their small scale variation between [CII]/[CI]/CO allows us to separate clumps/filaments overlapping along the line of sight. While mapping is important to spatially differentiate the origin of the ionized/atomic/molecular carbon phases, spectral line shape information can be directly compared to cloud formation and PDR model predictions (e.g., Cubick et al. 2008; Glover et al. 2010), as well as to the impact of outflows from the embedded protostars. Mapping at high spectral resolution [CII]/[CI]/CO with Herschel/SOFIA/APEX/IRAM30 m (the Herschel satellite mission, the Stratospheric Observatory For Infrared Astronomy, The Atacama Pathfinder Experiment, and the 30 m telescope of the Institut de Radioastronomie Millimetrique), respectively, can result in spatial resolution elements between 11′′ and 15′′, corresponding to linear scales below 0.2 pc at typical distances of IRDCs of 3 kpc. This matches the physical processes of cloud formation, fragmentation and feedback extremely well, e.g., the Jeans fragmentation scale at typical densities (~ 103 cm-3) is on that order.

To address these aspects, we conducted a concerted effort to study the gas phase carbon budget in young molecular clouds by observing and analyzing a well selected sample of four IRDCs in [CII] at 158 μm with Herschel and SOFIA, in [CI] with APEX and in 13CO/C18O(2–1) with the IRAM 30 m telescope. This combined mapping approach is complementary to the Galactic Observations of Terahertz C+Herschel key project (GOTC+, Langer et al. 2010; Pineda et al. 2013) that focused on single pointings toward a large sample of Galactic sources. Now mapping the regions allows us to separate the different cloud components and their associated carbon constituents properly from low to high extinction. These data provide us with the column densities, the spatial structure and the kinematic/dynamic properties of the different states of carbon in the ISM. For all regions we have complementary PACS/SPIRE continuum data (EPOS Herschel GT project, Ragan et al. 2012) as well as APEX/LABOCA 870 μm continuum observations (Schuller et al. 2009).

2. The sample

We selected four IRDCs that exhibit a variety of environments. While G11.11 (also know as The Snake, e.g., Henning et al. 2010; Kainulainen et al. 2013) and G48.66 (e.g., Ossenkopf et al. 2011; Pitann et al. 2013) are rather isolated IRDCs (G48.66 shows slightly more star formation activity), IRDC 18223 is an infrared dark filament that has already formed a high-mass protostellar object with ~ 104L at one end (e.g., Beuther et al. 2010). Finally, IRDC 18454 is also a starless dark cloud, however in the very close environment of the Galactic mini-starburst W43 (Beuther et al. 2013). All these clouds are part of the Herschel key project EPOS with a wealth of complimentary data (Ragan et al. 2012). Table 1 presents the basic sample parameters.

Table 1

Sample.

3. Observations

Table 2

Observed spectral lines

The different spectral lines shown in Table 2 were observed with various instruments, the ionized carbon [CII] line with Herschel/HIFI (Pilbratt et al. 2010; de Graauw et al. 2010, for G11.11, G48.66, IRDC18454) and SOFIA/GREAT (Young et al. 2012; Heyminck et al. 2012, for IRDC 18223), the atomic carbon [CI](3P13P0) and 12CO(3–2) with APEX, and the C18O(2–1) and 13CO(2–1) with the IRAM 30 m telescope. All data are calibrated to Tmb in Kelvin. The final spectral resolution Δv, the 1σ rms in a line-free channel and the spatial resolution θ for all data can be found in Table 3.

Table 3

Observing parameters.

The Herschel/HIFI [CII] data for G11.11, G48.66 and IRDC18454 were observed in one guaranteed time (obids 1342250966, 1342250967) and one open time project (obsids 1342270620, 1342270621, 1342270624, 1342270625). The approximate map sizes were in all cases ~ 3′ × 3′, and each map was observed twice at scanning angles of 0 and 90 deg. Data reduction was conducted within HIPE version 10.3 and beam and forward efficiencies of 0.69 and 0.96 were applied (Roelfsema et al. 2012). The observations were taken against the internal cold load as reference and included the observation of an additional OFF position at an offset of RA + 5′ and Dec −5′ from the center of the map. As we found clear contamination of the OFF position, we only subtracted the load reference from the data, and removed the remaining standing wave pattern by the HifiFitFringe pipeline task which resulted in good baselines for our spectra. The spectra were then exported to GILDAS format for final processing and imaging. For G11.11 we used only the V-polarization because that had less standing wave problems. For the other two sources, we used both polarizations. To increase the signal-to-noise ratio, we degraded the native spatial resolution of ~ 12′′ to 20′′−25′′ (Table 3).

The corresponding [CII] data for IRDC 18223 were observed in fall 2013 with GREAT on SOFIA and a beam efficiency of 0.67 (Heyminck et al. 2012). These data were smoothed to 20′′ resolution to increase the signal-to-noise ratio as well.

The atomic carbon [CI] data were all obtained with the APEX observatory and the FLASH receiver. The maps have similar sizes as the [CII] maps and were observed in on-the-fly mode at a spatial resolution of ~ 13.5′′ and a native spectral resolution of 0.05 km s-1. We re-binned the spectra to improve the signal to noise, and the finally used effective spectral resolution Δv, 1σ and θ can be found in Table 3. The FLASH receiver observed simultaneously the 12CO(3–2) line, but we show that only for G11.11 as an example because our analysis relies on the C18O(2–1) data due to its lower optical depth.

thumbnail Fig. 1

G11.11: large-scale Herschel/PACS 70 μm image of the G11.11 region with 870 μm ATLASGAL contours starting at 200 and continuing in 300 mJy beam-1 steps (Henning et al. 2010). The white box outlines the region of our carbon observations shown in Fig. 2.

Open with DEXTER

thumbnail Fig. 2

G11.11: the color scale shows integrated intensity images of the transitions marked above each panel. Integration regimes are [27, 33] km s-1, [27, 33] km s-1, [29, 31] km s-1, [24, 38] km s-1 and [24, 36] km s-1 for C18O(21), [CI], [CII], 12CO(32) and 13CO(21), respectively. Except for [CII], the corresponding black contours start from 15% and continue in 10% steps of the peak emission in each map. The peak values are 7.8, 19.9, 37.1 and 21.2 K km s-1, respectively. The [CII] contours start at 3σ and continue in 1σ steps of 0.8 K km s-1. The white contours always show the ATLASGAL 870 μm continuum image starting at a 3σ level of 0.15 Jy beam-1 and continue in 4σ steps. The bottom-left of each panel shows the beam of the line data whereas the bottom-right shows the continuum beam size. The three markers in the [CII] panel show the positions of 70 μm sources, and the top-left panel also shows a linear scale-bar.

Open with DEXTER

thumbnail Fig. 3

G11.11: C18O(2–1), 13CO(2–1) and [CI] spectra averaged over the whole area of emission shown in Fig. 2.

Open with DEXTER

Finally, the C18O(21) spectra were all observed during different runs with the IRAM 30 m telescope. The maps were taken in the on-the-fly mode, and the spatial resolution is ~ 12′′. The data for G11.11, G48.66 and IRDC 18223 were observed as pooled observations in winter 2012. The observations for IRDC 18454 were part of an IRAM large program (PI F. Motte) and have already been published in Carlhoff et al. (2013). The IRAM 30 m telescope also observed simultaneously the 13CO(21) line, but we again only show it for G11.11 as an example and rely for the analysis on the C18O(21) data. The corresponding 870 μm continuum data were taken from the ATLASGAL survey (Schuller et al. 2009).

4. Results

4.1. Morphologies and structures

Since our data are the first maps in the different gas carbon phases, we start with a morphological and structural analysis of the data toward the four IRDCs.

4.1.1. G11.11 also know as The Snake

The IRDC G11.11 encompasses a much larger area shown in Fig. 1. Here we focus on the 3′ × 3′ region outlined by the white box. That subregion is a particularly quiescent part of the G11.11 region, hosting only very few weak mid-infrared sources as well as a dark core without any mid- or far-infrared counterpart (Henning et al. 2010; Ragan et al. 2012). Figure 2 presents the different carbon datasets we obtained for this project. The 870 μm submm continuum data tracing the cold dust emission are shown in contours as reference frame on all plots. The first and most obvious outcome for G11.11 is that the molecular C18O and atomic carbon emission do trace the high-column density gas probed by the 870 μm continuum emission well. While the C18O(2–1) emission follows closely the dust continuum, the atomic [CI] emission appears a bit more extended. In contrast to these two tracers, the ionized carbon [CII] emission remains a non-detection in our data. Towards the dust continuum, we do not detect any [CII] at all, but a few very weak features are tentatively identified at the cloud edges. However, none of these integrated emission edge features are above 6σ, and analyzing individual spectra at these position, we cannot confirm them either. Hence, at the given sensitivity, our [CII] observations toward G11.11 are a non-detection, even after averaging all spectra over the entire region.

Figure 2 also shows the 12CO(3–2) emission from APEX and the 13CO(2–1) emission from the IRAM30 m telescope. However, both trace the dense gas emission outlined by the dust continuum worse than the C18O(2–1). This is mainly due to the larger optical depth of these isotopologues. For the remainder of the analysis, we therefore focus on the C18O(2–1) data because of its low optical depth.

Figure 3 presents the averaged spectra over the entire region of emission in Fig. 2 for C18O(2–1), 13CO(2–1) and [CI]. While the line shape does vary significantly between the different species, the line width measured as full width half maximum is similar for [CI] and 13CO(2–1) (Δv = 4.0 and 3.8 km s-1, respectively), whereas it is narrower for C18O(2–1) (Δv = 2.4 km s-1). Since 13CO and [CI] trace larger volumes than C18O, this difference is approximately consistent with Larson’s line width-size relation (Larson 1981; Stahler & Palla 2005). Although the averaged line width over the whole cloud of [CI] and 13CO(2–1) are similar, their spatial structure varies considerably.

thumbnail Fig. 4

G11.11: the color scales show the 2nd moment maps (intensity weighted line widths) of [CI] and C18O(21) in the left and right panel, respectively. The contours present the ATLASGAL 870 μm emission with the same contours as in Fig. 2. The bottom-left of each panel shows the beam of the line data, and the left panel also presents a linear scale-bar. The five-pointed stars mark the positions toward which the spectra in Fig. 5 are extracted.

Open with DEXTER

For a closer comparison of the C18O(2–1) and [CI] line width distribution, Figure 4 presents 2nd moment maps (intensity-weighted line widths) of both lines. Interestingly, the [CI] line width peaks close to the main submm continuum sources and hence resembles the [CI] integrated intensity image in Fig. 2. Together with the non-Gaussian profiles, this is consistent with a macro-turbulent picture, where individual, partially optically thick clumps are distributed over some turbulent velocity interval. In contrast to that, the C18O(2–1) 2nd moment map shows a relatively smooth velocity distribution over most of the clump with only an increase in line width south of the main submm continuum peak. The same position shows also an increased line width in the [CI] emission. Figure 5 present the C18O(2–1) and [CI] spectra extracted toward the respective integrated intensity as well as line width peak positions, and the same trend is visible there. While the [CI] line widths between both positions does not vary much, for C18O(2–1) we find a unique line width increase toward that southern position at the edge of cloud. Interestingly, Ragan et al. (2014b) find toward the close-by submm continuum peak position (Fig. 4) multiple N2H+ velocity components in high-spatial-resolution Plateau de Bure Interferometer (PdBI) data. These multiple N2H+ spectral features are consistent with global collapse of massive gas clumps as modeled by Smith et al. (2013). Although the positions of our enhanced C18O and [CI] line width do not exactly coincide with the multiple N2H+ spectra (offset ~ 25′′), the close spatial association may indicate that both features could trace different parts of the same global collapse of this star-forming region.

4.1.2. G48.66

The IRDC G48.66 is a prominent massive dark cloud in the projected vicinity of W51 (distance ~ 5.4 kpc, Sato et al. 2010), however at closer distance of 2.6 kpc (e.g., Ormel et al. 2005; van der Wiel & Shipman 2008). A recent analysis of the Herschel far-infrared continuum data of that IRDC has been published by Pitann et al. (2013). Figure 6 shows the 70 μm Herschel/PACS image outlining the dark features but also several embedded protostars within the cloud (the area of our carbon spectral line observations is marked). Compared to the region within G11.11 discussed in the previous section, G48.66 appears slightly more evolved, yet still very young.

The integrated emission maps of the different carbon phases of this region are presented in Fig. 7. In G48.66 the C18O(21) and [CI] emission follows the dense gas in east-west direction traced by the ATLASGAL 870 μm emission, and it exhibits an additional extension toward the south of that east-west ridge. The [CI] map exhibits even larger differences with more emission in east-west extension in the southern part of the map. These spatial substructures could not be identified by the previous lower-spatial-resolution [CI] observations by Ossenkopf et al. (2011) but are consistent with the two peaks of emission seen there.

The biggest difference arises in the ionized carbon [CII] map. In contrast to G11.11, where we barely detect the line above the 3σ level, here [CII] is strong and shows even different velocity components. While C18O(2–1) and [CI] have single-peaked spectra around the vlsr of ~34 km s-1 with averaged full-width-half-maximum (FWHM) values of 1.7 and 2.2 km s-1, respectively (Fig. 8), the [CII] spectrum exhibits a very broad second component extending up to 45 km s-1 (Fig. 8, the FWHM of the main component at ~34 km s-1 is 3.3 km s-1). Analyzing the spatial structure of these two velocity components, we find that the one around the vlsr is similar to the [CI] emission. Although the [CII] peak position is a bit offset from the C18O and dust continuum peak, the large-scale structure of that component resembles that of the [CI] and C18O emission. In contrast to that, the high-velocity component is distinctively shifted to the north (the right two panels in Fig. 7). A different way to dissect the velocity structure of the ionized carbon emission is a 1st moment map (intensity-weighted peak velocity). The velocity pattern shown in Fig. 9 is dominated by a steep velocity gradient right across the dense cloud filament seen in the submm dust continuum emission as well as the infrared extinction. We will discuss that gradient in more detail in Sect. 5.2.

4.1.3. IRDC 18223

The IRDC 18223 has been studied in detail in recent years on scales of the filament (e.g., Beuther et al. 2002, 2010; Garay et al. 2004) as well as on smaller scales of individual substructures

thumbnail Fig. 5

G11.11: C18O(2–1) (top panel) and [CI] spectra (bottom panel) at selected positions as marked in the panel and in Fig. 4.

Open with DEXTER

thumbnail Fig. 6

G48.66: large-scale Herschel/PACS 70 μm image of the G48.66 region (Pitann et al. 2013) with 870 μm ATLASGAL contours in 3σ steps of 150 mJy beam-1. The white box outlines the region of our carbon observations shown in Fig. 7.

Open with DEXTER

(e.g., Beuther & Steinacker 2007; Fallscheer et al. 2009). This filamentary IRDC hosts several evolutionary stages from an already evolved high-mass protostellar object (HMPO) in the north to the dark filament with embedded very young protostars (Fig. 10). It is also part of a much larger filament extending more than 70 pc in the Milky Way plane (e.g., Tackenberg et al. 2013; Ragan et al. 2014a). For this carbon study we focus in particular on the infrared dark filament outlined in Fig. 10.

The spatial and spectral structure of the molecular C18O, atomic and ionized carbon in this region are presented in Figs. 11 and 12. Around the vlsr of ~45.5 km s-1, the main emission is seen in the molecular C18O(2–1) and the atomic [CI] emission, and both species exhibit a secondary strong peak around 51 km s-1. The averaged spectrum over the whole region in the ionized [CII] line shows emission peaks at similar velocities, however, the intensities of both peaks are almost the same. All three species exhibit a third spectral peak at slightly higher velocities of ~54.5 km s-1. The [CI] spectrum in Fig. 12 exhibits an additional weak emission component between approximately 35 and 41 km s-1. However, the images show that this component is only found at the south-eastern edge of our map and barely covered at all. Therefore, we do not show it here.

Figure 13 shows the spatial structure of these three velocity components for the atomic [CI] line. The main spectral component between 42 and 49 km s-1 is strongly correlated with the dense gas traced by the 1.2 mm dust continuum emission measured with MAMBO at the IRAM 30 m telescope (Beuther et al. 2002). However, already the high-velocity end of this component between 46.8 and 48 km s-1 exhibits a spatially distinct structure visible in the cyan contours in Fig. 13 (left panel). In contrast to this, the second component between 49 and 53 km s-1 which is also strong in the averaged spectrum (Fig. 12) appears spatially diffuse with barely any obvious peak emission (Fig. 13 middle panel). Going to even higher velocities, the spectral component between 53 and 56 km s-1 is spatially very localized with a small peak to the east of the filament (Fig. 13 right panel and Fig. 11 left panel). The spatial structure of the C18O(21) emission is similar to the [CI] line, whereas for the [CII] emission we do not find clear structures, but the ionized carbon appears to be distributed much more diffusely over the entire complex without any clear association with the infrared dark filament. Interestingly, two strong [CII] emission features lie southeast and northwest of the central peak in the filament in the direction of the two outflow lobes discussed in Fallscheer et al. (2009). While this is not conclusive, there is the possibility that these [CII] emission features could be partly related to the outflow from the embedded young protostar.

thumbnail Fig. 7

G48.66: the color scale shows from left to right the emission from C18O(2–1), [CI] and [CII], respectively. The integration ranges for C18O(2–1) and [CI] are [32.0; 35.0] and [32.0; 35.5] km s-1. The integration ranges for [CII] are marked in the 2 right panels. The contours always show the ATLASGAL 870 μm emission starting at 3σ level of 150 mJy beam-1 and continuing in 3σ steps. The white markers in the 3rd panel mark the positions of 70 μm sources.

Open with DEXTER

4.1.4. IRDC 18454

The fourth region in our sample, IRDC 18454, is in the direct vicinity of the Galactic mini-starburst W43. Figure 14 presents the 70 μm emission of the region, and while W43 at the western edge is very bright in the far-infrared, our regions of interest are either faint at 70 μm or they even show dark absorption patches.

Another intriguing aspect of this region at the interface of the Galactic bar with the inner spiral arm, is the velocity structure. Toward this region, all observed spectral lines exhibit 2 spectral components, one centered at approximately 100 km s-1 and the second at ~ 50 km s-1 (Fig. 16). This is not just observed in the carbon tracers shown here, but also in dense gas tracers like N2H+ or NH3 (e.g., Nguyen Luong et al. 2011; Beuther et al. 2012). Also Galactic surveys of radio recombination lines show a large fraction of multiple components in this part of the Galaxy (Anderson et al. 2011). These different components could be caused by two independent clouds in different spiral arms (e.g., Nguyen Luong et al. 2011), via colliding gas flows (e.g., Carlhoff et al. 2013), or by potential cloud-cloud interaction in the interface between the Galactic bar and the inner Scutum spiral arm (e.g., Beuther et al. 2012). For a detailed discussion about this IRDC, the influence of the neighboring W43 mini-starburst and the multiple velocity components see Beuther et al. (2012).

Independent of the interpretation of the different velocity components, the velocity spread of each individual component is very broad, for the high-velocity component it ranges from approximately 65 to 140 km s-1, and these velocities are all spatially connected (Nguyen Luong et al. 2011). Because of the complex structure of the spectra, we do not report FWHM values for this region. Figure 15 presents emission of the two components integrated over a broad part of their spectra. In Beuther et al. (2012), it is argued that the two velocity components appear spatially interacting. In the new carbon data, this is best visible in the atomic phase where the 50 km s-1 occupies the eastern part and the 100 km s-1 mainly the western part of the observed region. In the ionized carbon [CII], the 50 km s-1 emission is comparably very strong, however, the spatial separation of both components is less obvious. In contrast to that, the C18O(2–1) emission shows in general a similar structure as the atomic carbon [CI] with the main difference that the 50 km s-1 appears less extended in the molecular gas. This is consistent with the observations of the other sources where we also saw a general tendency that the molecular C18O(2–1) emission is the most compact.

4.2. Carbon phases versus hydrogen distributions

In order to quantitatively compare the distribution of the different carbon phases with the molecular gas of these regions, we constructed dust temperature and column density maps using the Herschel data obtained for the Earliest Phases of Star Formation key program (Ragan et al. 2012). We used PACS data at 100 and 160 μm and SPIRE data at 250, 350 and 500 μm. First all maps were convolved to the SPIRE 500 μm resolution then mapped to identical grids. The spectral energy distribution (SED) at each pixel was fit employing the hierarchical Bayesian-fitting algorithm described in Kelly et al. (2012), which makes the assumption that the SED is well-fit by a modified Planck function as follows: (1)where Ω is the solid angle of the observation, N is the column density, Bν(T) is the Planck function, which is evaluated at the dust temperature, Td, and κ0(ν/ν0)β is the dust opacity. We assumed a κ0 of 0.006 cm2 g-1 at 1.3 mm wavelengths (Ossenkopf & Henning 1994), which includes an assumed dust-to-gas ratio of 150 (Draine 2011). The algorithm fits for N, Td and β. For the plots, we also show the equivalent AV computed from the relation NH2 = 0.95 × 1021 cm-2 (AV/mag).

For the comparison, we used the integrated intensity maps of C18O(2–1), [CI] and [CII] for the four regions with the velocity regimes presented in Figs. 2, 7, 11 and 15. These images were smoothed to the spatial resolution of the SPIRE 500 μm data of 36.6′′.

Figure 17 presents the scatter plots of the three gas phases with respect to the molecular (H2) column density, and one sees distinct differences between the molecular, neutral atomic and ionized atomic phases. The C18O(2–1) emission strongly increases at low column densities, and then flattens of at column densities above 1022 cm-1. The latter flattening can likely be attributed to freeze-out of the carbon monoxide at the low temperatures in these IRDCs (toward the cloud centers we find temperatures below 20 K, see for comparison, e.g., Kramer et al. 1999).

The atomic carbon also shows a correlation with the hydrogen column density, however, in general the relation is flatter and no clear break is visible. This confirms the previous morphological assessment that the atomic carbon is related to the dense molecular gas, however, weaker than the molecular C18O. To compare our results with the recent cloud formation and [CI] emission models by Glover et al. (2014), we show as a dashed line in Fig. 17 the fit they conducted to their model data in their approximately linear regime below 10 mag extinction. The comparison with our data shows that below column densities of about 1022 cm-2 (or 10 mag extinction), the models and observations agree reasonably well. Toward higher column densities this linear relation between [CI] emission and molecular column density breaks down and the curves flatten. This is already indicated in the models by Glover et al. (2014), and even more prominent in our data since these observations go to higher column densities.

Finally, the ionized carbon emission exhibits almost no correlation with the general dense gas distribution. This confirms that ionized carbon is distributed in a much broader and widespread component than the molecular gas.

thumbnail Fig. 8

G48.66: C18O(2-1), [CI] and [CII] spectra (in K) averaged over the whole area of emission shown in Fig. 7. The FWHM of the main peak at 34 km s-1 are presented as well.

Open with DEXTER

thumbnail Fig. 9

G48.66: the color scale presents the 1st moment (intensity-weighted velocity) of the [CII] emission between 30 and 45 km s-1. The contours show the ATLASGAL 870 μm emission starting at 3σ level of 150 mJy beam-1 and continuing in 3σ steps.

Open with DEXTER

thumbnail Fig. 10

IRDC 18223: large-scale Herschel/PACS 70 μm image of the IRDC 18223 region with 870 μm ATLASGAL contours starting at 200 and continuing in 300 mJy beam-1 steps. The white box outlines the region of our carbon observations shown in Fig. 11.

Open with DEXTER

4.3. Masses of carbon components

In addition to the morphologic analysis, we can use the spectral line data of the three different carbon phases to estimate the mass contributions of the ionized and atomic carbon as well as molecular CO to the gas phase carbon budget of the ISM. For all three species, we calculate the corresponding column densities and masses assuming optically thin emission of the respective spectral lines.

For the molecular C18O, the column densities are calculated using classical expressions (e.g., Cabrit et al. 1988): Here, ν, μ, Tex, Eu/k, τ and Tmb are the frequency, dipole moment (0.112 Debye), the excitation temperature, the upper energy level of 15.8 K, the optical depth and the main beam brightness temperature of the line, respectively. Assuming τ ≪ 1 the term approaches 1.

The atomic carbon [CI] column densities are calculated following Frerking et al. (1989): and for the ionized carbon [CII], the column densities are calculated following Goldsmith et al. (2012), Eq. (26): with the kinetic gas temperature Tkin and the collision rate Cul = Ruln depending on the temperature, where Rul is collision rate coefficient with H2 and n the density.

Table 4

Masses of carbon phases.

The remaining unknown in the equations above is the temperature of the gas. Since we are dealing with IRDCs, hence the earliest evolutionary stages, for the molecular C18O and the atomic [CI] we assume 15 K for all sources following multiple NH3 studies of IRDCs (e.g., Sridharan et al. 2005; Pillai et al. 2006; Dunham et al. 2011; Ragan et al. 2011; Wienen et al. 2012; Chira et al. 2013). Regarding the temperatures for the ionized carbon, this is less well determined. Langer et al. (2010) assume temperatures largely between 100 and 150 K for the diffuse ionized carbon, although above the level temperature of Eu/k of 91 K, the emissivity is basically constant, independent of the assumed excitation temperature. However, at least in G48.66 and IRDC 18454 we see a clear spatial correlation between the ionized carbon emission and that of the dense molecular CO. This indicates that the temperatures of the ionized carbon could be lower as well. To estimate the uncertainties based on the temperature, we calculated the masses of the ionized carbon for temperatures between 20 and 250 K at an average density n ~ 1 × 103 cm-3. The corresponding collision rate coefficients with H2 are taken from the Leiden database for molecular spectroscopy1 (Schöier et al. 2005) where the para- and ortho rates are weighted following Le Bourlot (1991) and Gerlich (1990). While for IRDC 18454 in the vicinity of W43 collisions with other partners than H2 may be possible as well, the good spatial correspondence of the [CII] with the molecular line data indicates that H2 should be the most dominant collisional partner. Figure 18 presents the corresponding results. For temperatures above 100 K, the corresponding masses do not vary significantly, however, going to lower temperatures, the values can vary by more than a factor of a few (see also Table 4).

thumbnail Fig. 11

IRDC18223: the color scale shows in the left, middle and right panel the emission from C18O(2–1), [CI] and [CII], respectively. The integration regimes for the three color images are are [42; 49]. [43; 49] and [43; 55] km s-1. The white and cyan contours in the left panel correspond to the velocity components at [53.0; 56.0] and [46.9; 48.0] km s-1. The black contours always show the 1.2 mm continuum emission (Beuther et al. 2002) starting at 3σ level of 36 mJy beam-1 and continuing in 3σ steps. The arrows in the middle and right panel outline the direction of a bipolar outflow studied by Fallscheer et al. (2009).

Open with DEXTER

To calculate the masses of the different carbon phases, we integrated the emission of the different spectral lines over the areas of their respective emission. For IRDC 18454, we only use the spectral component around 100 km s-1 since only that is unambiguously associated with the neighboring W43 complex. Table 4 presents the derived masses of the CO (converting C18O to 12CO masses with a factor 500, Wilson & Rood 1994, applying the additional CO/H2 ratio of ~ 10-4 we have an estimate of the total gas mass), atomic and ionized carbon in our four target regions. We find that in all four regions, gas-phase carbon is most dominant in its molecular form, usually about 10 times more abundant than atomic carbon. Interestingly, the ratio between the ionized and the other two phases is less uniform. While ionized carbon is less abundant than atomic carbon in G11.11, we find more ionized than atomic carbon in the other three regions. One should keep in mind that these ratios depend on the covered areas since [CII] is usually found to be more extended than the other two phases. More details will be discussed in Sect. 5.1.

4.4. Estimates of bolometric luminosities and radiation fields

Further interesting parameters to characterize the emission of the different carbon phases is an evaluation of the bolometric luminosities in the regions as well as an estimation of the interstellar radiation field.

The bolometric luminosities are straightforward to estimate. We extract the total fluxes in our regions from the Herschel far-infrared data between 70 and 500 μm (Ragan et al. 2012) and fit spectral energy distributions (SEDs) to the data points. The resulting SEDs give us estimates of the bolometric luminosities of the regions. Table 5 presents the bolometric luminosities Lbol derived this way ranging from a few thousand for G48.66 to more than 105L for IRDC 18454. These bolometric luminosities can partly be due to internal sources, but they are also produced by the external radiation penetrating and heating these clouds. To approximate the contribution of internal source luminosity to the total, we use the Ragan et al. (2012) catalog of point sources, which uses modified blackbody fits to the Herschel point source SED at 70, 100 and 160 μm to compute the luminosities. We sum the luminosities of all point sources in the regions mapped in this work (Lpoint) and tabulate them in Table 5. These values represent lower limits, as some point sources that were not detected at all PACS wavelengths are excluded from the Ragan et al. (2012) catalog, though we expect this additional contribution to be negligible. Nevertheless, it is clear that the point source luminosity contribution is on the order of a few percent of the total bolometric luminosity of the IRDCs. Thus, we conclude that Lbol is dominated by external irradiation. These bolometric luminosities may to first order appear large, in particular since we are studying IRDCs. However, considering the large areas over which these bolometric luminosities are derived (between 9 and 31 pc2, Table 5), and taking into account that the dust emission is also due to external radiation, these values are plausible. We see a clear differentiation between the more isolated IRDCs G11.11, G48.66 and IRDC 18223 with bolometric luminosities in the 104L regime, and the very different IRDC 18454 that exceeds 105L. The latter high value is in agreement with IRDC 18454 being located in the direct environment of W43 with an estimated luminosity from the associated Wolf-Rayet cluster in excess of 106L (e.g., Blum et al. 1999; Beuther et al. 2012).

thumbnail Fig. 12

IRDC18223: C18O(21), [CI] and [CII] spectra (in K) averaged over the whole area of emission shown in Fig. 11. The fitted [CI] and C18O(2–1) FWHM of the main component around 45 km s-1 are presented as well (class did not converge to a reasonable fit result for the [CII] line).

Open with DEXTER

thumbnail Fig. 13

IRDC18223: the color scale shows in the left, middle and right panel the emission from atomic carbon [CI] in the three velocity regimes marked at the bottom of each panel. are [42; 49]. [43; 49] and [43; 55] km s-1. The cyan contours in the left panel correspond to [46.9; 48.0] km s-1. The black contours always show the 1.2 mm continuum emission (Beuther et al. 2002) starting at 3σ level of 36 mJy beam-1 and continuing in 3σ steps.

Open with DEXTER

thumbnail Fig. 14

IRDC 18454: large-scale Herschel/PACS 70 μm image of the IRDC 18223 region with 870 μm ATLASGAL contours in steps of 0.4 mJy beam-1. The white box outlines the region of our carbon observations shown in Fig. 15.

Open with DEXTER

It is more difficult to estimate the interstellar radiation field. However, one can indirectly get an estimate of the interstellar radiation field from the dust temperature. Here, we follow the approach outlined in Glover & Clark (2012). Assuming that the dust is in thermal equilibrium, the main process responsible for heating the dust is the absorption of photons from the interstellar radiation field. Cooling is dominated by thermal emission from the dust, which for the dust properties assumed in their study (dust properties of non-coagulated grains coated with thick ice mantles) scales . In thermal equilibrium, one can then derive a relation between the interstellar radiation field G0 (here we use the Draine field which is 1.7 times the Habing field, e.g., Tielens 2005) and the dust temperature as where χ(Av) is an attenuation factor depending on the extinction. Glover & Clark (2012) evaluated χ(Av) for the above-mentioned dust model, and we use χ(Av) ~ 0.1 corresponding to an average hydrogen column density NH of ~ 1022 cm-2.

The median dust temperatures were again derived from the SED fits to the Herschel far-infrared data (Ragan et al. 2012) also used in Sect. 4.2. The temperatures and corresponding G0 values are shown in Table 5. While the interstellar radiation field is on the order of a few 10 (in Draine units = 2.7 × 10-3 erg cm-2 s-1) for the three more quiescent IRDCs (G11.11, G48.66, IRDC18223), the estimated external radiation field exceeds 100 for IRDC 18454. The latter higher value is again no surprise since this region is in the direct neighborhood of the 3.5 × 106L mini-starburst W43 (e.g., Beuther et al. 2012). As obvious in the above equation for G0, the high sensitivity of the external radiation field on the dust temperature introduces considerable errors in these estimates. Since the four regions have four different temperatures, the values in Table 5 give also a rough estimate of the steep dependency of G0 on Td and hence the uncertainties associated with this approach. Although just ball-park estimates, the luminosities and radiation fields derived this way are in rough agreement with each other. The large external radiation field and luminosity derived for IRDC 18454 also explain the much stronger emission of [CI] and [CII] in this complex.

thumbnail Fig. 15

IRDC18454: the color scale shows in the left, middle and right panel the emission from C18O(2–1), [CI] and [CII], respectively. The integration regimes for the three color images are [47; 55] km s-1. The white contours in all three panels correspond to the emission from the same species only integrated from [80; 120] km s-1. The red contours always show the ATLASGAL 870 μm emission in levels of 0.4 Jy beam-1.

Open with DEXTER

Table 5

Luminosities and radiation fields.

5. Discussion

5.1. Carbon phases

As expected, the C18O(2–1) emission traces the dense gas observable in the dust continuum emission very well. Similarly the [CI] emission is a reasonable proxy of the dense gas (see also Glover et al. 2014), however, it appears somewhat more widespread on average. The [CII] emission shows a less uniform picture and varies from a non-detection (G11.11) to compact sources (G48.66 and IRDC 18454) as well as more diffuse components (G48.66, IRDC 18223, IRDC 18454). These differences are particularly prominent in the scatter plots in Fig. 17.

thumbnail Fig. 16

IRDC18454: C18O(21), [CI] and [CII] spectra (in K) averaged over the whole area of emission shown in Fig. 15.

Open with DEXTER

Ratios between atomic carbon and CO for typical molecular clouds have usually been reported in the 20% to 30% regime (e.g., Frerking et al. 1989; Beuther et al. 2000), and Tauber et al. (1995) infer a lower limit of 17% for the Orion Bar PDR. In contrast to that, the largest ratio of atomic carbon to CO we find is ~12% in IRDC 18454 whereas the ratio is lower in the other regions going down to values of ~7% in the most quiescent region G11.11 (Sect. 2). A similar value of 8% was also found in the lower-spatial-resolution [CI]/13CO study of the G48.66 region by Ossenkopf et al. (2011). Although our sample of four regions is too small to derive firm conclusions, we do see a trend of increasing atomic-to-molecular gas ratio from the earliest, most quiescent infrared dark and starless clouds to regions that are in a more evolved environments with radiation sources nearby, e.g.,the high-mass protostellar object IRAS 18223-1243 at the northern end of the IRDC 18223 or the W43 mini-starburst near IRDC 18454.

thumbnail Fig. 17

Scatter plots of the integrated C18O(2–1), [CI] and [CII] emission versus the molecular column density and extinction (in mag) derived from the Herschel far-infrared data. The color-coding separates between the different regions as marked in each panel. The integration regimes are the same as those mentioned in the previous corresponding figures (for G48.66 only the main spectral component and for IRDC 18454 only the 100 km s-1 component are used). The dashed line in the middle panel shows the fit to the modeled [CI] data from Glover et al. (2014) who fitted their data in their approximately linear regime below 10 mag extinction. For IRDC 18454, we only use the 100 km s-1 component that is clearly associated with the W43 complex.

Open with DEXTER

Regarding the ionized carbon, the situation is less conclusive. While we do not detect [CII] emission in our most quiescent region G11.11, it is strongly detected in the other regions with higher ionized than atomic carbon gas abundances. Since the temperatures are more uncertain for the ionized carbon, the ratios are also less well determined. For example the ionized-to-atomic gas ratio may vary between 4 and 9.3 for IRDC 18454 depending on the assumed temperature for the ionized carbon of 50 or 100 K, respectively. The highest ionized carbon abundances is again seen in the region IRDC 18454 that is exposed to the intense radiation field of the W43 mini-starburst.

The Herschel GOTC+ survey has revealed that a significant fraction of molecular H2 gas is not traced by CO but this sometimes dubbed “dark gas” may be traced by the [CII] emission (Langer et al. 2010; Velusamy et al. 2010; Pineda et al. 2010, 2013). While the ratio of CO-dark H2 gas depends on the density, Pineda et al. (2013) estimate for the whole GOTC+ survey that approximately 28% of the H2 gas can be missed by the CO emission, but these values can go even above 50% for the more diffuse lower extinction parts of the clouds (Velusamy et al. 2010). Although deriving CO-dark gas fractions is not the scope of our paper, we do see wherever we detect [CII] emission that it is spatially significantly more extended than the dense C18O and dust continuum emission, consistent with the GOTC+ results. While the C18O emission traces the dense gas associated with the star-forming regions, in particular the [CII] emission traces the environment and is much more sensitive to the external UV field. For [CII] emission associated with molecular clouds, Pineda et al. (2010) find that in many cases low far-UV fields and densities in the regime 103.5−105.5 cm-3 reproduce the data well, but they also find exception where strong far-UV fields and higher densities are required. While the latter situation resembles the IRDC 18454 complex, the former lower far-UV fields rather resemble the other three target regions of our mini-survey.

Extended [CII] emission is also regularly observed from strong PDRs, a recent prominent example being M17SW (Pérez-Beaupuits et al. 2012). They find that the [CII] emission on the one hand traces parts of the PDR that are not found by other tracers, and that on the other hand the [CII] emission is seen from deep in the cloud. The latter is interpreted as additional evidence of the clumpy nature of the dense ISM. In contrast to M17SW, we are dealing largely with much lower far-UV fields, however, again the IRDC 18454 region partly resembles the extended emission [CII] emission as well as the association with the dense gas and hence the clumpiness of star-forming regions.

5.2. Gas flows

Since the different carbon phases trace different parts of the forming and evolving clouds, the [CII], [CI] and C18O lines should harbor signatures of the cloud formation history or external UV illumination. In the framework of converging gas flows, kinematic signatures may be embedded in the more diffuse gas components (e.g., Vázquez-Semadeni et al. 2006; Heitsch et al. 2008; Glover & Clark 2012; Clark et al. 2012), and we investigate such potential signatures in our datasets.

For G11.11 and IRDC 18454 this turns out to be more difficult. While in the former source [CII] remains undetected and hence we do not have much information about the more diffuse parts of the cloud, it is interesting that we find a line width increase in the C18O and [CI] emission close to a position of multiple N2H+ spectral features in high-resolution PdBI data (Ragan et al. 2014b). Such an enhanced line width or multiple peaks can be interpreted as signatures of global collapse of high-mass star-forming regions (e.g., Smith et al. 2013). In comparison to that, in the IRDC 18454 region the [CII] emission is very strong and shows the multiple velocity components (Sect. 4.1.4). These multiple velocity components have already previously been reported in molecular and ionized gas emission (Anderson et al. 2011; Beuther et al. 2012), and the controversy stands whether these two velocity components at 50 and 100 km s-1 are signs of cloud-cloud interaction at the galactic-bar/inner-spiral-arm interface or whether they are simply chance alignments along the line of sight (Nguyen Luong et al. 2011; Beuther et al. 2012). This ambiguity may be resolved in the future when accurate parallax distances from maser sources at both velocities become available through the Bessel survey (Brunthaler et al. 2011).

thumbnail Fig. 18

Masses of ionized carbon in the three regions where the line is clearly detected. We calculated the masses assuming different temperatures at an average density of 103 cm-3 as outlined in Sect. 4.3.

Open with DEXTER

Investigating the other two regions, promising kinematic signatures can be found. For G48.66, in particular the [CII] emission turns out to be interesting. Although the averaged FWHM line width of the main gas component in the molecular, atomic and ionized gas does not exhibit large spreads between 1.7 and 3.3 km s-1, the additional high-velocity gas component visible in Fig. 8 is spatially clearly offset to the north from the main component around the vlsr (Fig. 7). Looking at the velocity structure, the first moment map in Fig. 9 exhibits a strong velocity gradient from north to south directly across the main infrared dark gas filament and site of active star formation. This steep velocity gradient at the location of the IRDC indicates a large velocity shear and by that enhanced Rayleigh-Taylor instability. Therefore, we suggest that the IRDC may at least partly be formed through that instability. Attempts to produce observational predictions of colliding flow signatures have focused mainly on CO transitions (e.g., Heitsch et al. 2008; Clark et al. 2012), but the diverse morphologies and dynamics that we observe in the [CII] line, such as the velocity gradients and correlations with other tracers described above, give us a promising avenue to potentially discern between various cloud assembly processes.

The other infrared dark filament IRDC 18223 does also show different velocity components, but the kinematic signatures are different. Comparing only the averaged spectral signatures, the ionized and atomic carbon as well as C18O appear similar with multiple velocity components (Fig. 12). However, spatially the ionized carbon is distinct from the atomic and molecular phase, and it is largely found in a diffuse distribution at the edge of the cloud. In contrast to that, the multiple velocity components of the atomic carbon and C18O exhibit clear spatial substructures and appear relatively similar between both phases (Figs. 11 and 13). The main spectral component around the vlsr of ~45.5 km s-1 is clearly associated with the dense filament traced by the dust continuum emission. But even within that main component, the more red-shifted part between 46.8 and 48 km s-1 is already offset from the filament to the south-east (Figs. 11 and 13). Going to higher velocities, the second spectral component between 49 and 54 km s-1 is more diffusely distributed (Fig. 13), middle panel), whereas at even higher velocities between 53 and 56 km s-1, we find again a compact gas component east of the filament (Fig. 13) right panel). As mentioned in Sect. 4.1.3, the spectrum in Fig. 12 shows an additional blue-shifted [CI] component, however, that is only found at the lowest edge of the mapped region and we cannot give more details about that. With blue- and red-shifted gas in diffuse as well as compact components found around the main dense gas filament, we again tentatively interprete these spectral and spatial structures as evidence that the main filament of active star formation has formed out of a kinematically active gas stream that likely converged in the region of the filament.

6. Conclusions

With the aim of studying the different carbon gas phases (ionized, atomic and molecular) during the early high-mass star formation stages, we observed four IRDCs at high spatial resolution in the spectral emission lines of ionized ([CII]) and atomic ([CI]) carbon as well as molecular carbon monoxide (C18O(21)) with Herschel, SOFIA, APEX, and the IRAM 30 m telescopes. Except for the ionized [CII] line in one region, we could map all gas components toward all four target regions.

  • While as expected the molecular gas is always closely associated with the dense gas filaments visible in infrared extinction as well as dust emission, the atomic carbon often has a similar appearance. It also traces the dense gas, however, the atomic gas distribution appears a bit more extended than the C18O maps. The averaged line widths within the different regions are slightly smaller for the C18O(21) line compared to the atomic [CI] emission.

  • In contrast to that, the ionized carbon [CII] emission exhibits a larger spread in morphologies over the different regions. While it remains undetected in the most quiescent region, it shows strong emission toward the IRDC in the environment of the W43 starburst. Furthermore, the spatial structure of the ionized carbon varies between rather diffuse emission at the cloud edges to structures that are clearly associated with the dense gas.

  • The data allow us to estimate the relative abundances of the different carbon phases within these IRDCs. The ratio between atomic carbon and molecular CO mass ranges between 7 and 12%, lower than values found in other molecular clouds, with the lowest values found in the most quiescent environment. Although with only four regions, the statistical basis is still poor, the data indicate that the ratio of atomic to molecular gas depends on the evolutionary stage of the region as well as the radiation field the regions are exposed to. In the three regions where [CII] is detected, its abundances is always higher by a factor of a few than that of [CI].

  • Similar to that, also the ionized carbon is most strongly detected in the environment of the W43 mini-starburst. However, for the dark clouds the signatures vary significantly. While [CII] remains undetected toward the most quiescent region G11.11, it is easily and strongly detected toward the G48.66 IRDC that is not much more evolved and that also does not have strong radiation sources in the environment. Hence, the [CII] emission does not only depend on external radiation sources but other factors must be important as well.

  • While still in a very young evolutionary stage, G48.66 exhibits the strongest kinematic signatures of gas flows in the [CII] emission. This indicates that kinematically active regions can exhibit stronger [CII] emission as well. Although model predictions about kinematic signatures of converging gas flows are scarce or non-existent, we interprete the strong [CII] velocity gradient across the G48.66 dark filament as suggestive evidence for filament formation within kinematically very active gas flows.

  • For the IRDC 18223, we see multiple red- and blue-shifted velocity components. While the spatial structure of the ionized carbon in this region is relatively diffuse, the atomic and molecular gas exhibits spatially distinct cloud components in the environment of the dense filament. Again, we interprete this complex spatial and spectral substructures as tentative evidence for gas flows that may form the active star formation sites at converging points. In addition to this, in IRDC 18223 we find enhanced [CII] emission in the direction of two bipolar outflow lobes. While not conclusive yet, it may indicate that [CII] emission can also be caused by the kinematic activity of jets and outflows.

In summary, mapping star-forming regions at comparable spatial scales in the ionized, atomic and molecular phases allows us to constrain the carbon budget as well as the gas kinematics in great detail. Since cloud and star formation takes place in diverse environments, often one line does not tell the same story for different regions, hence, mapping all the different gas phases together is an important mean to understand the cloud and star formation processes in a global sense. While this study targeted mainly IRDCs, it will be important to extend similar studies to more evolved evolutionary stages.

While maps of molecular and atomic gas can be obtained with ground-based facilities well, Herschel mainly did single-pointing studies of the ionized carbon, and not many spectral line maps were obtained with that space observatory. SOFIA has now proven as a very efficient observatory to map clouds in the [CII] and other far-infrared spectral lines, and we hope to get many more exciting data from this observatory in the future.


Acknowledgments

We would like to thank Rahul Shetty for helping to implement the dust temperature fitting algorithm. We also thank the anonymous referee for insightful comments improving the paper. S.E.R. acknowledges support from grant RA 2158/1-1 which is part of the DFG-SPP 1573 “The Physics of the Interstellar Medium”.
