1. Introduction

The hot Jupiter HD 209458b has been the source of many detections of atomic and molecular species over the years (see Vidal-Madjar et al. 2013 and references therein). Transit observations of this planet in the H i Lyman-α line led to the first detection of atmospheric escape (e.g., Vidal-Madjar et al. 2003, 2008; Ben-Jaffel 2007, 2008; Ehrenreich et al. 2008). Heavier elements were identified at high altitudes in the extended exosphere of the planet in the lines of O i, C ii, and Si iii (Vidal-Madjar et al. 2004; Linsky et al. 2010; Ben-Jaffel & Sona Hosseini 2010), Si iv (Schlawin et al. 2010) and more recently Mg i (Vidal-Madjar et al. 2013), supporting the idea that its atmosphere is in a state of “blow-off”.

A large range of models have been developed to characterize the structure of the upper atmosphere of close-in giant exoplanets and to explain the evaporation process, either from theory or from observations (see Bourrier & Lecavelier des Etangs 2013 and references therein). Here we use the 3D numerical model detailed in Bourrier & Lecavelier (2013), revised to interpret the observed escape of magnesium from the atmosphere of HD 209458b. Transit observations of the planet in the Mg i and Mg ii lines are described in Sect. 2. We present our new model in Sect. 3, notably the analytical modeling of the atmosphere below the exobase and the description of the ionization and recombination mechanisms. In Sect. 4, we analyze the dynamics of an escaping magnesium atom, and in Sect. 5, we describe the ionization state of the gas around HD 209458b. In Sect. 6, we compare simulated spectra with the observations and put constraints on the exobase properties as well as the physical conditions in the extended atmosphere of HD 209458b. Predictions of spectro-temporal variations in the absorption profile are presented in Sect. 7.

2. Observations in the Mg i and Mg ii lines

Three transits of HD 209458b were observed by Vidal-Madjar et al. (2013) in the Mg i line of neutral magnesium (2852.9641 Å) and in the Mg ii doublet of singly ionized magnesium (2796.3518 and 2803.5305 Å) in 2010 with the Space Telescope Imaging Spectrograph (STIS) instrument on board the Hubble Space Telescope (HST). Each visit consists of two observations before the planetary transit, two observations during the transit labeled transit-ingress and transit-center, and one observation after the end of the transit labeled post-transit. To get optimal signal-to-noise ratios Vidal-Madjar et al. (2013) cumulated the spectra of the three visits. The time windows of the cumulated observations are given in Table 1. They discarded the first observation of each visit because of systematic trends known to affect STIS observations (e.g., Brown et al. 2001 and Charbonneau et al. 2002). Here we will not use post-transit observations as a reference to calculate the absorption because of the possibility of an absorption signature related to the transit of a cometary tail after the planetary transit. In our study, we calculated all absorption depths in the same way by using only the second observation before the transit, labeled pre-transit, as reference, (1)with A(λ) the spectral absorption depth, F the flux measured during the transit-ingress, transit-center, or post-transit observation, and Fref measured during pre-transit observation. The corresponding absorption profiles are displayed in Fig. 1 for the Mg i line. Vidal-Madjar et al. (2013) found a transit absorption signature in the blue wing of the Mg i line, with a total depth of 8.8 ± 2.1% in the range 60 to 19 km s-1 if only the second observation before the transit is used as reference. A tentative detection of absorption was also reported in the post-transit observation with a depth of 4.0 ± 2.2% in the range 67 to 14 km s-1. No signal was found in excess of the planetary occultation depth in either line of the Mg ii doublet (Fig. 2). Hereafter, the reduced χ2 of the fits to the data are always found to be lower than 1 (e.g., Sect. 6.1). Therefore, error bars on the spectral fluxes are likely over-estimated and, in the following, all error bars on estimated values of the model parameters can be considered as conservative.

Table 1

Log of the observations of HD 209458b used in this work, cumulated over three visits in 2010.

thumbnail Fig. 1

Mg i line absorption profiles during the transit-ingress (top panel), transit-center (middle panel), and post-transit (lower panel) observations of HD 209458b. The resolution is 20 km s-1. The absorption signatures detected by Vidal-Madjar et al. (2013) are delimited by vertical dashed black lines.

Open with DEXTER

thumbnail Fig. 2

Absorption profiles in the doublet of singly ionized magnesium, calculated with the fluxes cumulated over the transit-ingress, transit-center, and post-transit observations. The resolution is 20 km s-1. No atmospheric absorption signature was detected in either the Mg ii-k line (top panel) or the Mg ii-h line (bottom panel).

Open with DEXTER

3. Model description

3.1. The case of magnesium

We used Monte-Carlo particle simulations to compute the dynamics of the populations of neutral and singly ionized magnesium in the extended atmosphere of HD 209458b, and to estimate the physical conditions needed to reproduce the absorption profiles obtained by Vidal-Madjar et al. (2013). The general functioning of the model is described in Bourrier & Lecavelier (2013), in which it was applied to the hydrogen escape from HD 189733b and HD 209458b. Improvements and modifications of the model needed to match the characteristics and specificities of magnesium are detailed hereafter. In the code, neutral and ionized magnesium atoms are represented by metaparticles made of the same number of atoms Nmeta. The total number of neutral magnesium particles launched every time step dt depends on the escape rate of neutral magnesium Mg0. The particles are released from the entire upper atmosphere of the planet at the altitude of the exobase Rexo (Sect. 3.3). Hereafter, all numerical values of altitude will be given with the origin at the planet center. The initial velocity distribution of the particles, relative to the planet, is the combination of the radial bulk velocity of the planetary wind vpl − wind and an additional thermal component from a Maxwell-Boltzman velocity distribution corresponding to the temperature at Rexo (Sect. 3.4). The modeling of the atmosphere below the exobase, characterized by its mean temperature , is described in Sect. 3.3.2.

The dynamics of neutral and ionized magnesium atoms above Rexo is constrained by the stellar radiation pressure (Sect. 3.2), the stellar gravity, and the planetary gravity. As the magnetic field of HD 209458b is unknown (observations at radio wavelengths provided only an upper limit; Lecavelier des Etangs et al. 2011), we neglected its influence on the charged particles’ dynamics. Ionized magnesium particles may recombine into neutral magnesium through dielectronic recombination, which depends on the density of electron ne surrounding the planet. Ionized magnesium atoms are created by the stellar UV photoionization of neutral magnesium, and possibly through impacts with electrons (Sect. 3.4).

Theoretical spectral absorption profiles are calculated in the Mg i line and in both lines of the Mg ii doublet via Eq. (1), with simulated fluxes averaged over the time window of a given observation (transit-ingress, transit-center, or post-transit). The χ2 for the entire observation is the sum of the χ2 yielded by the comparison of each of the nine absorption profiles (i.e., three per line, as shown in Fig. 1 for the Mg i line) with the corresponding theoretical spectrum, calculated in the velocity range 300 to 300 km s-1. Because of the relatively small velocity range of the observed absorption signature and the high resolution of the STIS Echelle E230M grating spectra, the simulations have the same spectral resolution Δv =10 km s-1 as the observations.

To sum up, the free parameters of the model are the escape rate of neutral magnesium (Mg0, in g s-1), the electron density at a reference altitude of 3 planetary radii (hereafter called the reference electron density ne(3Rp), in cm-3), the altitude of the exobase (Rexo, in Rp), and the velocity of the planetary wind at the exobase (vpl − wind, in km s-1). We also considered the influence of the main atmosphere temperature . We checked that simulations calculated with higher temporal and spectral resolutions produce the same theoretical absorption profiles. Physical parameters used in the model as well as numerical parameters with constant values are given in Table 2.

Table 2

Physical parameters for HD 209458b, and numerical parameters with fixed values for all simulations.

3.2. Radiation pressure

3.2.1. Radiation pressure from the Mg i line

A neutral magnesium atom in its ground state may be subjected to radiation pressure from Mg i stellar lines at several wavelengths (e.g., at λ = 2026.4768, 2852.9641, or 4572.3767 Å ). However, only the Mg i line at λ0 = 2852.9641 Å, characterized by a high oscillator strength (Table 3), has enough flux to generate a significant force on neutral magnesium atoms. We display the spectrum of this line in Fig. 3. All velocities herein are given in the reference frame of the star, which has a heliocentric radial velocity Vstar = −14.7 km s-1 (Kang et al. 2011; Vidal-Madjar et al. 2013). To obtain the radiation pressure applied to a neutral magnesium atom, we calculated the ratio β between radiation pressure and stellar gravity. This coefficient is proportional to the stellar Mg i line flux received by an escaping atom at its radial velocity (Lagrange et al. 1998; Fig. 3). In contrast to the H i Lyman-α line (e.g., Bourrier & Lecavelier 2013), whose central part absorbed by the interstellar medium and contaminated by geocoronal emission needs to be reconstructed, here observations can be used directly. As the flux in the Mg i resonance line increases away from the line center, radiation pressure may even surpass stellar gravity when the radial velocity exceeds ~10 km s-1 away from the star or ~15 km s-1 toward the star, in which case atoms are more accelerated as their absolute radial velocity increases. Because radiation pressure has little effect on neutral magnesium particles at low velocities, planetary gravity may have significant effect on the atmospheric escape (see Sect. 6.1.4 and Sect. 6.2.2).

thumbnail Fig. 3

Intrinsic Mg i stellar absorption line profile of HD 209458 as observed with HST/STIS at 2852.9641 Å (Vidal-Madjar et al. 2013). The ratio β between radiation pressure and stellar gravity (right axis) is proportional to the line flux. Note that β is larger than 1 (horizontal dotted line) for velocities outside the range 10 to 15 km s-1, and increases steeply farther away in the wings of the line.

Open with DEXTER

3.2.2. Radiation pressure from the Mg ii line

A singly ionized magnesium atom is subjected to radiation pressure from both lines of the Mg ii doublet at 2796.3518 Å  (Mg ii-k) and 2803.5305 Å  (Mg ii-h), displayed in Fig. 4. Observations can be used directly to calculate radiation pressure, except between about −55 and 55 km s-1 where stellar flux is absorbed by interstellar magnesium. In this range, a self-reversed chromospheric emission is observed, absorbed by the interstellar medium in a narrow band slightly redshifted with respect to the star velocity (Fig. 5). Using a similar procedure as in the case of the Lyman-α line (e.g., Ehrenreich et al. 2011), we fitted the line cores with two independent Gaussians centered on the star velocity, and modeled the interstellar medium (ISM) absorption with two Gaussians with different parameters except for a common center velocity. In the line shape, we did not consider the effect of the intrinsic self-reversal of the stellar lines, as they are shallow and limited to a narrow band in the line core (see the case of the Sun in Lemaire & Blamont 1967). In any case, this has no influence on our results as there is no significant amount of ionized magnesium at low altitudes in the atmosphere, where low-velocity particles are found (Sect. 6).

We replaced the doublet line cores in the observations by the reconstructed profiles. The radiation pressure coefficient from a given line is proportional to the flux received by a Mg+ atom at its radial velocity with respect to the line center. The total radiation pressure coefficient β+ is the sum of the coefficients from each line of the doublet (Fig. 6), with a stronger contribution from the Mg ii-k line because of its higher flux and oscillator strength (Table 3). Ionized magnesium atoms are strongly accelerated by radiation pressure at low absolute radial velocities below ~40 km s-1. Away from the chromospheric emission in the line core, the flux is lower and particles are decelerated until their velocity exceeds ~185 km s-1 away from the star.

thumbnail Fig. 4

Intrinsic Mg ii stellar absorption line profile of HD 209458 as observed with HST/STIS at 2796.3518 Å  (Mg ii-k line) and 2803.5305 Å  (Mg ii-h line). Velocities are relative to the Mg ii-k line. Similarly to the Mg i line, the Mg ii lines spectral region is V-shaped.

Open with DEXTER

thumbnail Fig. 5

Mg ii stellar absorption line profile of HD 209458 at 2796.3518 Å  (Mg ii-k line; top panel) and 2803.5305 Å  (Mg ii-h line; bottom panel). The blue line shows the theoretical self-reversed emission profile as seen by ionized magnesium atoms around the planet. The red line shows the line core profile after absorption by the interstellar Mg+, to be compared with the observations (black histogram). Outside of the line core, observations (black line) can be used directly to calculate radiation pressure.

Open with DEXTER

thumbnail Fig. 6

Radiation pressure coefficients associated with the Mg ii-k line (dotted red line) and the Mg ii-h line (dashed red line), as a function of the Mg+ ion radial velocity in the star reference frame. Their sum β+ characterizes the total radiation pressure on an ionized magnesium particle (solid red line). β+ is larger than 1 (horizontal dotted black line) in the line core and at high radial velocities in the wings of the line.

Open with DEXTER

3.3. Hydrodynamic and kinetic regimes

3.3.1. Exobase properties

In contrast to hydrogen escape from HD 209458b (Vidal-Madjar et al. 2004) and HD 189733b (Lecavelier des Etangs et al. 2012), magnesium atoms are detected in a smaller velocity range close to the line center. At low velocities, escaping particles are likely near the planet (Bourrier & Lecavelier 2013) and in the case of magnesium they can be significantly affected by planetary gravity. As a result, the initial launching conditions of magnesium particles (Rexo and vpl − wind) have a strong influence on the structure of the escaping cloud and the corresponding absorption profile.

Neutral magnesium particles are released at the exobase, i.e., the transition zone between the hydrodynamic regime and the kinetic regime. The different gases populating the atmosphere below the exobase (hereafter called the main atmosphere) arrive in the transition zone in a state of “blow-off”, as inferred from previous observations (Vidal-Madjar et al. 2004; Linsky et al. 2010 and references therein) and modeling of atmospheric escape from HD 209458b (e.g., Koskinen et al. 2013a; Guo 2013). The gases at the exobase are mixed in a global planetary wind with the velocity vpl − wind. By contrast the kinetic regime corresponds to a collisionless region in which the dynamics of the gases can be described independently for each species. The precise altitude of the exobase of HD 209458b is unknown, and we studied the impact of Rexo exploring values above 1.5 Rp. We also considered the influence of the planetary wind bulk velocity vpl − wind (Sect. 6.1.4). The additional thermal speed component defined in Sect. 3.1 is constrained by the temperature at the exobase level, given by the profile described in Sect. 3.4.

Table 3

Values of the constants used in the calculation of the radiation pressure exerted on Mg and Mg+ particles, and their optical depth.

3.3.2. The atmosphere below the exobase

Atmospheric absorption in the core of the Mg i line is partly due to the denser regions of the main atmosphere, which has to be modeled accurately. To calculate the optical depth and the self-shielding of the main atmosphere, we adopted an analytical depiction (as opposed to the particle modeling of the gas above the exobase) with a radial density profile corresponding to a hydrostatic equilibrium, (2)

This appears to be a good approximation of the density profile of the hydrodynamical atmosphere (e.g., Koskinen et al. 2013b). The main atmosphere extends up to Rexo and is characterized by its mean temperature  K (Koskinen et al. 2013a), its mean atomic weight (assuming a Solar-like hydrogen-helium composition), and its density of neutral magnesium nMg0(r) at the distance r from the planet center. In the numerical simulation, the density profile in the main atmosphere is reassessed by adjusting nMg0(Rexo) to match the magnesium density obtained at the exobase for the particle calculation of the upper atmosphere in the stationary regime. During the transit of the main atmosphere, its surface is discretized with a high-resolution square grid (101 × 101 cells). The column density of magnesium in front of each cell is given by (3)with rcell the distance between the planet center and its projection on the line of sight that goes through the cell.

We assumed the magnesium gas particles in the main atmosphere follow a Maxwellian velocity distribution. As a result, their absorption line profile is thermally broadened because of the gaussian component of the velocity distribution on the line of sight. It is characterized by its thermal width and its central velocity equal to the projection of the planet velocity on the line of sight. The profile width is further increased by natural Lorentzian broadening characterized by the damping constant Γ. The resulting absorption cross-section is thus a Voigt profile, which is multiplied by the column densities of the main atmosphere grid cells to obtain their optical depths. The addition of these values to the optical depth of the particles above the exobase yields the total optical depth of the neutral magnesium gas. The final absorption profile of the Mg i stellar flux is obtained by combining the planetary occultation depth with neutral magnesium absorption, using Eq. (12) in Bourrier & Lecavelier (2013). The absorption profile of the Mg ii stellar flux is obtained in the same way but with the optical depth of ionized magnesium gas above the exobase only. We did not model ionization inside the main atmospere because no absorption was observed at low velocities in the Mg ii line and observations are well reproduced with high electron densities, which ensure that magnesium remains neutral below the exobase (Sect. 6). See Table 3 for constant values used in these calculations.

3.4. Ionization and recombination mechanisms

Neutral magnesium was observed up to 60 km s-1 in the blue wing of the Mg i line. This velocity can be naturally explained by radiation pressure acceleration if the particles are accelerated over a sufficient period of time. However, magnesium atoms are exposed to UV photoionization from the star and at the short orbital distance of HD 209458b they are quickly ionized with a timescale of about 0.6 hours (Vidal-Madjar et al. 2013). This time is too short for the particles to reach the observed velocities (Sect. 4; Fig. 9).

We used a scenario observed in the ISM (Lallement et al. 1994), in which neutral magnesium lifetime is extended through dielectronic recombination, compensating for ionization. With appropriate conditions for the electron density and temperature, ionized magnesium can indeed recombine with electrons into neutral magnesium. To calculate the transition probability of a neutral magnesium atom into an ionized atom, dP0 +, we took into account the possibility that it is ionized sometime during dt and then recombined with an electron. The reverse transition probability for an ionized magnesium atom dP+ 0 is calculated in the same way, and after integration we obtained (4)with Γion the total ionization rate of neutral magnesium, and Γrec the total recombination rate of ionized magnesium. At the altitude r, Γrec depends on the recombination rate αrec(r) and the electron density ne(r)(5)\In turn, αrec(r) (in cm3 s-1) depends on the electron population temperature Te(r) (in K) and was evaluated by Aldrovandi & Pequignot (1973), (6)The parameter Γion depends on the constant photoionization rate ΓUV − ion and, at the altitude r, on the electron-impact ionization rate αcoll(r) and the electron density ne(r), (7)Without sufficient information about the densities of H+ and He+ in the atmosphere of HD 209458b, we neglected the processes of charge-exchange of these particles with neutral magnesium. The UV flux of HD 209458 was measured at the wavelengths below the ionization threshold (1621 Å ; Vidal-Madjar et al. 2004) and the photoionization rate is thus known to be ΓUV − ion = 4.6 s-1 (Vidal-Madjar et al. 2013). The ionization rate αcoll(r) (in cm3 s-1) was evaluated by Voronov (1997), (8)Because the electronic ionization rates calculated by Voronov (1997) are for temperatures significantly above 11 000 K (at the upper limit of the temperature domain), and there are very large uncertainties on rates below this temperature, we did not take into account this mechanism, and we discuss its influence on our results in Sect. 8. Hereafter, the ionization rate does not depend on the altitude and Γion(r) = ΓUV − ion.

Several theoretical models have explored the temperature and density profiles in the upper atmosphere of HD 209458b. We compared the works of García Muñoz (2007), Koskinen et al. (2013a), and Guo (2013) to infer an approximate radial temperature profile for the electron population (Fig. 7), (9)While the temperature in the atmosphere of HD 209458b can be directly constrained by the observations, it is not the case with the electron density. From Koskinen et al. (2013a) and Guo (2013) we estimated the shape of the radial density profile ne(r), with the density at r = 3 Rp as a free parameter (Fig. 8), (10)

thumbnail Fig. 7

Theoretical radial temperature profile Te(r) of the electron population surrounding the planet as a function of the distance from the planet center. Profile was constructed by comparing different theoretical models and is defined for altitudes above 1.5 Rp.

Open with DEXTER

thumbnail Fig. 8

Theoretical radial density profile ne(r) of the electron population surrounding the planet as a function of the distance from the planet center, for ne(3 Rp) = 1010 cm-3. Profile was constructed by comparing different theoretical models and is defined for altitudes above 1.5 Rp.

Open with DEXTER

4. Magnesium atoms dynamics

In a first approach to understanding the processes in play, we used a 2D toy model to estimate the velocity profiles of a neutral and an ionized magnesium atom escaping the planet atmosphere. The particle is launched with the planet orbital velocity in the stellar referential. Its trajectory in the orbital plane is then constrained only by stellar gravity and radiation pressure. Note that radiation pressure depends on the particle radial velocity relative to the star, which differs from its velocity as observed from the Earth (Bourrier & Lecavelier des Etangs 2013). Figure 9 displays the former as a function of the particle distance from HD 209458b. Because the particle initial velocity is that of the planet, its radial velocity is null. In the case of a neutral magnesium atom, β is thus lower than unity (Fig. 3), but the particle quickly separates from the planet orbit and gains enough radial velocity through the projection of the planet velocity on the star/particle axis to be accelerated away from the star by radiation pressure. The particle acceleration and velocity keep increasing as the stellar flux absorbed in the blue wing of the Mg i line increases away from the line center. On the contrary an ionized magnesium atom is strongly accelerated at low velocity because of the chromospheric emission in the Mg ii line core (Fig. 6). The particle radial velocity then keeps increasing, but at a much lower rate when β+ is below unity in the wings of the line (Fig. 9).

With a characteristic UV-photoionization lifetime of about 0.6 h, a magnesium atom has a low probability of remaining neutral until it is accelerated to the upper limit of the signature observed in the blue wing at 60 km s-1 (Fig. 9), unless its lifetime is extended through electron recombination. A complete 3D modeling is needed to fully simulate the dynamics of the escaping magnesium gas, as the magnesium atoms will alternate between ionized and neutral states and their trajectory may be significantly altered by planetary gravity and self-shielding effects.

thumbnail Fig. 9

Blueward radial velocity of a neutral (blue line) or ionized (red line) magnesium atom escaped from HD 209458b, as a function of the distance from the planet center. Diamond symbols show the time since the particle escape with a step of one hour (half-hours are indicated by cross symbols). A neutral particle reaches 60 km s-1 (horizontal dotted line) in about 4.25 h at 4 Rp and an ionized particle in about 5.2 h at 8 Rp.

Open with DEXTER

5. Mg-recombining layer of the exosphere

The amount of magnesium atoms in the neutral or the ionized state depends on the relative values of the UV-photoionization rate and the recombination rate. As will be confirmed by the detailed simulation (Sect. 6), in a first approach to describe the global picture of ionization/recombination processes we can neglect the particles’s dynamics and consider that in the stationary regime there are the same number of ionizations and recombinations at the altitude r, i.e., (11)Using Eq. (4), we obtained an approximation of the ratio between the ionized and neutral magnesium populations at the altitude r(12)For a given electron density profile, i.e., a given value of ne(3 Rp), this ratio is only dependent on the distance from the planet (Fig. 10). If the reference electron density is lower than about 105 cm-3 the UV photoionization mechanism is dominant at all altitudes above the exobase (Γrec/ ΓUV − ion ≤ 0.01; red striped zone in Fig. 10). Neutral magnesium are quickly ionized with a short lifetime of about 0.6 h and are unlikely to recombine (dP+ 0(r) ~ 0). With higher reference electrons densities, there are enough electrons in a shell above the exobase to significantly extend the lifetime of escaping neutral magnesium atoms through recombination. We define the recombination altitude Rrec (Γrec/ ΓUV − ion = 100), i.e., the critical altitude below which the probability that a magnesium atom remains neutral is close to unity (blue striped zone in Fig. 10). The recombination altitude is included in the Mg-recombining layer of the exosphere (hereafter called “Mg-rec layer”), which is defined as the layer where the recombination rate is always higher than the ionization rate. It extends from the exobase to the equilibrium altitude Req (Γrec = ΓUV − ion). Within the Mg-rec layer, magnesium atoms have spectroscopic signatures in the Mg i line, which also drives their radiation-pressure acceleration. Beyond the equilibrium altitude, ionized particles do not recombine efficiently and their dynamics and absorption signatures are driven by the Mg ii doublet. The upper limit of the absorption profile in the blue wing of the Mg i line thus increases with Req, i.e., with the reference electron density. For example, for magnesium atoms to absorb in the Mg i line up to 60 km s-1, they must remain mostly neutral up to about 4Rp (Fig. 9), which means this altitude is somewhere between the recombination altitude (ne(3 Rp) = 1011 cm-3) and the equilibrium altitude (ne(3 Rp) = 109 cm-3).

thumbnail Fig. 10

Ratio between the recombination rate Γrec and the ionization rate ΓUV − ion, as a function of the altitude counted from the planet center and the electron density at 3 Rp. Solid and dashed lines show isovalues of the ratio. In the striped red zone photoionization is dominant (ΓUV − ion ≥ 100Γrec) and the probability that an ionized particle recombines is close to zero. With altitudes below the equilibrium altitude (solid black line), the lifetime of a neutral magnesium atom is significantly extended, and in the blue striped zone below the recombination altitude (solid blue line) the probability that it is ionized is close to 0 (Γrec ≥ 100ΓUV − ion).

Open with DEXTER

6. Modeling magnesium escape from HD 209458b

6.1. General scenario

6.1.1. Best-fit parameters

We used our 3D model to estimate the exobase properties and the physical conditions in the exosphere of HD 209458b needed to reproduce the observations in the lines of neutral and singly ionized magnesium. In this general scenario (hereafter, G-scenario), all four parameters of the model were let free to vary. The best fit was obtained with a χ2 of 802.4 for 1067 degrees of freedom, when particles escape the atmosphere at Rexo = 3 Rp (exobase level) with a planetary wind velocity vpl − wind = 25 km s-1, the escape rate of neutral magnesium is Mg0 = 2.9 × 107 g s-1 and the reference electron density is ne(3Rp) = 6.4 × 1010 cm-3. We caution that with χ2 lower than the number of degrees of freedom, error bars on these parameters are conservative values. Absorption profiles from this global best-fit simulation are displayed in Fig. 11 for the Mg i line and in Fig. 12 for the Mg ii doublet. In the following sections, we study the structure of the escaping cloud in relation with the absorption it generates, and discuss the uncertainty on the derived values of the four model parameters.

thumbnail Fig. 11

Absorption profiles in the Mg i line calculated with the fluxes averaged over transit and post-transit observations of HD 209458b. The observed profile (Vidal-Madjar et al. 2013) is displayed as a blue histogram with a resolution of 20 km s-1, while the solid black line corresponds to the theoretical global best-fit profile. The associated with this absorption profile is 225.9 (357 data points), and the χ2 for all observations is 802.4 for 1067 degrees of freedom.

Open with DEXTER

thumbnail Fig. 12

Same as in Fig. 11 with absorption profiles in the Mg ii-k line (upper panel) and Mg ii-h line (lower panel) for the global best-fit simulation. They are obtained with (357 data points) and (357 data points), and a total χ2 = 802.4 for 1067 degrees of freedom for all observations.

Open with DEXTER

thumbnail Fig. 13

Distribution of neutral (light blue dots; left panel) and ionized (light red dots; right panel) magnesium atoms within ±0.5 Rp of the orbital plane for the best-fit simulation in the G-scenario. Magnesium atoms that escape at the exobase level (Rexo = 3 Rp; striped blue disk) are accelerated away from the star by radiation pressure (the star is along the vertical direction toward the top of the plot). They remain neutral up to the recombination altitude (Rrec = 3.9 Rp; dashed blue circle) and keep a high probability to stay in this state until they reach the equilibrium altitude (Req = 13.4 Rp; dashed black circle), beyond which ionized magnesium particles do not recombine efficiently anymore. Because of the planet shadow and shielding from the main atmosphere, the inner part of the cometary tail is empty of radiation-pressure accelerated particles.

Open with DEXTER

thumbnail Fig. 14

Mean radial density profiles of the neutral (blue dots) and singly ionized (red dots) magnesium populations in the cometary tail. Profiles correspond to the best-fit simulation in the G-scenario and are plotted from the exobase level (Rexo = 3 Rp). Electron-recombination compensates for ionization in the Mg-rec layer below Req = 13.4 Rp (dashed black line), with a very high efficiency below Rrec = 3.9 Rp (dashed blue line). Density of ionized magnesium below ~5 Rp must be taken with caution as ionized particles are few and far between at these altitudes.

Open with DEXTER

6.1.2. Magnesium cloud structure

The extended atmosphere of magnesium in the global best-fit simulation can be seen in Fig. 13, shaped into a cometary tail by radiation pressure. We measured the mean radial density profiles of neutral and ionized particles inside the cometary tail (Fig. 14) and found that despite their different dynamics the two populations follow Eq. (12). The magnesium gas is maintained in a nearly full neutral state by electron-recombination up to about 4Rp, as expected from the value of the recombination altitude (3.9Rp) associated with the electron density in the global best fit (Fig. 10). The constant high radial density below Rrec is responsible for the deep theoretical absorption in the core of the Mg i line. At higher altitudes, the density of neutral magnesium decreases until it is balanced by the density of ionized magnesium near the equilibrium altitude (13.4Rp). Above the Mg-rec layer there are not enough electrons to sustain the recombination mechanism efficiently and the cloud is mostly ionized. At all altitudes the ionized magnesium population is maintained at low-density levels which, in addition to the low oscillator strengths of the Mg ii-k and Mg ii-h lines, ensure that no significant absorption is generated in the Mg ii doublet (Vidal-Madjar et al. 2013). Note that because of the asymetry of the escaping cloud the density profiles displayed in Fig. 14 may vary on the starward side.

The density of neutral magnesium corresponds to typical hydrogen density in the order of ~106 cm-3 at the level of the Roche lobe, consistent with the results of Bourrier & Lecavelier des Etangs (2013). The resulting mean free path is significantly larger than the atmospheric scale height of HD 209458b (about 5 × 108 cm), and magnesium particles are unlikely to be subjected to collisions above 3Rp.

6.1.3. Influence of the escape rate and electron density

We set the exobase properties to the global best-fit values (Rexo=3 Rp; vpl − wind = 25 km s-1) and studied the goodness of fit as a function of the neutral magnesium escape rate and the reference electron density (Fig. 15). Observations are reproduced up to the 3σ level with ne(3Rp) ≥ 3.4 × 109 cm-3, which corresponds to Req ≥ 4.9 Rp. With these high electron densities, neutral magnesium particles escape the main atmosphere into the Mg-rec layer and have extended lifetimes that lead to absorption at higher velocities in the blue wing of the Mg i line (Fig. 16). In particular, simulations within 1σ from the best fit are obtained with reference electron densities in the range 2.7 × 1010 − 1011 cm-3 (Req = 8.9 − 16.5 Rp). In this case, the recombination altitude is also higher than the exobase and all escaping particles stay neutral up to Rrec = 3.4 − 4.1 Rp. An increase in the electron density above ~1.2 × 1013 cm-3 has no influence on the quality of the fit (Fig. 15) as it corresponds to Rrec ≳ 18 Rp, which is the distance between the star and the planet in the plane of sky at the end of the post-transit observation (Vidal-Madjar et al. 2013). All the regions of the magnesium cloud observed transiting the stellar disk are thus below Rrec and fully neutral. Alternatively, with lower values of ne(3Rp) ionization losses of neutral magnesium could be compensated for by higher escape rates. However, the subsequent increase in the ionized magnesium population and the resulting absorption in the Mg ii lines would not be consistent with the observations.

We also inferred 1σ error bars on the escape rate of neutral magnesium in the range 2 × 107 − 3.4 × 107 g s-1. In contrast to the reference electron density, the escape rate controls the depth of the absorption profile, but has little import on its velocity range (Fig. 17; see also discussion in Vidal-Madjar et al. 2013). Best-fit parameters in the G-scenario are similar to those obtained by Vidal-Madjar et al. (2013) with Mg0 = 3 × 107 g s-1 and an ionization cut-off radius of 7.5 Rp located between best-fit values Rrec = 3.9 Rp and Req = 13.4 Rp. If we assume a solar abundance (mass fraction Mg/H ~ 9.6 × 10-4; Asplund et al. 2009), escape rates of neutral magnesium within 3σ of our best fit correspond to escape rates of neutral hydrogen in the range 4.3 × 109 − 5.4 × 1010 g s-1, consistent with the values derived from Lyman-α observations (e.g., Ehrenreich et al. 2008; Bourrier & Lecavelier 2013) and theoretical models (e.g., Lecavelier des Etangs et al. 2004; Yelle 2004; Tian et al. 2005).

thumbnail Fig. 15

Error bars for the estimated neutral magnesium escape rate and electron density at 3 Rp, in the G-scenario. The exobase is fixed at Rexo = 3Rp with a planetary wind velocity vpl − wind = 25 km s-1. A black star indicates the global best fit to the observations with Mg0 = 2.9 × 107 g s-1 and ne(3Rp) = 6.4 × 1010 cm-3 (χ2 = 802.4 for 1067 degrees of freedom).

Open with DEXTER

thumbnail Fig. 16

Same as in Fig. 11, with two additional theoretical absorption profiles calculated with the same magnesium escape rate Mg0=2.9×107 g s-1 and electron densities corresponding to 3σ limits (χ2 = 811.4) from the global best fit with ne(3Rp) = 4.5 × 109cm-3 (long-dashed black line) and ne(3Rp) = 7.7 × 1011cm-3 (dashed black line). The electron density mostly impacts the width of the absorption profile in its blue wing.

Open with DEXTER

thumbnail Fig. 17

Same as in Fig. 11, with two additional theoretical absorption profiles calculated with the same reference electron density ne(3Rp)=6.4×1010 cm-3 and magnesium escape rates corresponding to 3σ limits (χ2 = 811.4) from the global best fit with Mg0=4.1×106 g s-1 (long-dashed black line) and Mg0=5.0×107 g s-1 (dashed black line). The increase in escape rate raises the depth of the absorption profile with little effect on its velocity range.

Open with DEXTER

6.1.4. Exobase properties

Here we studied the goodness of fit as a function of the exobase altitude and the planetary wind velocity at the exobase, when all four parameters of the model are let free to vary (Fig. 18). Remarkably, the global best-fit exobase altitude is found to be just above the Roche lobe (about 2.8 Rp for HD 209458b) with Rexo = 3 Rp and vpl − wind = 25 km s-1. We looked for the planetary wind velocities that best reproduce the observations for a given exobase altitude. For particles launched beyond the Roche lobe, the planet gravity is negligible compared to stellar gravity and radiation pressure. Consequently, their dynamics only depend on their initial velocity and observations remain best-fitted with vpl − wind = 25 km s-1. Alternatively, with exobase altitudes below the Roche lobe, planet gravity limits the expansion of the magnesium cloud and the best-fit velocity needs to be higher, up to 45 km s-1 at 1.5Rp. However, as it seems unlikely that the planetary wind is so fast, we fixed vpl − wind = 25 km s-1 and inferred 1σ limits on the exobase altitude between 2.1 and 4.3 Rp. Within this range, best fits are always obtained with Mg0 = 2.9 × 107 g s-1 and ne(3Rp) = 6.4 × 1010 cm-3 (see Sect. 7 for more details).

Because the atmosphere beyond the Roche lobe is outside of the gravitational influence of the planet it cannot be described accurately with a spherically symmetric hydrostatic profile when the exobase radius exceeds 2.8 Rp. Besides, gravitational equipotentials near the Roche lobe stray from the spherical approximation used in our model to describe the exobase (see the 3D plot of the shape of the exobase close to the Roche lobe in Fig. 2 of Lecavelier des Etangs et al. 2004). On the other hand, theoretical models with hydrodynamical escape (Yelle 2004; García Muñoz 2007; Koskinen et al. 2013a; Guo 2013) predict planetary wind velocities in the range 1 to 10 km s-1 at altitudes between 2 and 3 Rp, which is significantly lower than our global best-fit value of 25 km s-1. Therefore, in addition to the G-scenario we considered an alternative constrained scenario (hereafter called C-scenario) in agreement with theoretical predictions for Rexo and vpl − wind. In this C-scenario we fixed the exobase at an intermediate altitude of 2 Rp and constrained the planetary wind to 10 km s-1 (Fig. 18). We study the atmospheric escape in this scenario in the following section.

thumbnail Fig. 18

1σ error bars on the planetary wind velocity and the exobase altitude in the G-scenario. The other model parameters (escape rate and electron density) are also let free. The dashed line shows the fit to the planetary wind velocities that best reproduce the observations for a given exobase altitude. The global best-fit simulation (black star) is obtained with Rexo = 3Rp, vpl − wind = 25 km s-1, Mg0 = 2.9 × 107 g s-1 and ne(3Rp) = 6.4 × 1010 cm-3 (). A black diamond shows the best-fit simulation in the constrained scenario (vpl − wind = 10 km s-1; Rexo = 2 Rp; ).

Open with DEXTER

6.2. Constrained scenario

6.2.1. Physical conditions in HD 209458b exosphere

In the C-scenario (vpl − wind = 10 km s-1; Rexo = 2 Rp) the constrained best fit to the observations is found with a χ2 of 807.4 for 1069 degrees of freedom (Fig. 19), at little more than 2σ from the global best fit, and yields similar values for the magnesium escape rate and reference electron density (Mg0=6.3×107 g s-1; ne(3Rp) = 6.4 × 1010 cm-3) albeit with larger error bars, in particular at the 1σ level (1.4×1074.7×108 g s-1 and 1.2 × 109 − 9 × 1011cm-3). As in the G-scenario there is no change in the fit quality (here within 2σ from the best fit) with electron density above ~1.2 ×1013 cm-3. On the contrary, the fit becomes worse with escape rates in the range 5 × 107 − 5 × 108 g s-1 and ne(3Rp)109 cm-3 because the recombination altitude then falls below the exobase. A significant portion of the escaping gas is ionized and, as the atmosphere is denser in the C-scenario, Mg ii line absorption depths increase steeply with decreasing reference electron densities. Assuming electrons are mainly produced by the ionization of hydrogen most theoretical models of HD 209458b atmosphere predict electron densities in the range 106 − 107cm-3 at 3 Rp (e.g., Yelle 2004; Koskinen et al. 2013a; Guo 2013). In the C-scenario this situation corresponds to a regime with no recombination above the exobase and can only reproduce the observations within 3σ from the constrained best fit, with escape rates below ~2 × 106 g s-1. In this case, absorption profiles in the magnesium lines are shallow and not much influenced by variations of ne(3Rp) and Mg0 (Fig. 19).

thumbnail Fig. 19

Error bars for the estimated magnesium escape rate and electron density at 3 Rp, in the C-scenario. The exobase is fixed at Rexo=2Rp with a planetary wind velocity vpl − wind = 10 km s-1. A diamond indicates the constrained best fit to the observations with Mg0=6.3×107 g s-1 (χ2 = 807.4 for 1069 degrees of freedom), while a star shows the global best fit with Mg0 = 2.9 × 107 g s-1 (χ2 = 802.4 for 1067 degrees of freedom), in both cases obtained with ne(3Rp) = 6.4 × 1010cm-3.

Open with DEXTER

6.2.2. Radiation pressure and planetary gravity

In the case of the global best fit (Rexo = 3 Rp and vpl − wind = 25 km s-1), the gas cloud is mostly optically thin and spread over a large area. By contrast when particles are launched with lower velocities at altitudes below the Roche lobe, as for the constrained best fit (Rexo = 2 Rp and vpl − wind = 10 km s-1), densities of neutral magnesium are high enough for the bulk of the atmosphere to be self-shielded from stellar photons and particles escape more easily from the unshielded limbs of the atmosphere (Fig. 20). Besides, at the low altitude of the exobase in the constrained best fit, planetary gravity is the dominant force and it strongly influences the dynamics of escaping particles. Those escaping from shielded regions are so deflected that they move backward of the planet orbital motion until they emerge from the other side of the cometary tail to the rear of the planet (Fig. 20).

thumbnail Fig. 20

View of the neutral magnesium cloud from above of the orbital plane in the best-fit simulation (C-scenario). Because of the high density below the exobase (Rexo = 2 Rp; dashed orange circle) magnesium atoms escape more easily from the limbs of the atmosphere, unshielded from radiation pressure (the star is toward the top of the plot). The orange lines show the average trajectory of these flows. Gravitational effects and the lower velocity of the planetary wind prevent the cometary tail from dispersing as in the G-scenario (Fig. 13). The red line shows the average trajectory of the flow of particles emanating from shielded regions. Deviated by planetary gravity, the flow emerges from the cloud to the rear of the planet, where it becomes subjected to radiation pressure.

Open with DEXTER

6.3. Influence of the main atmosphere temperature

Here we tested the impact of the main atmosphere temperature on the theoretical Mg i line absorption profile and the fit to the data. We considered no change in the escape rate, the reference electron density and the exobase properties, with the same values that provided the best fit to the observations in either the G-scenario or the C-scenario. We found that an increase in the temperature of the main atmosphere has no influence on the quality of the fits (Fig. 21). On the other hand, the χ2 quickly increases as temperature decreases, and we put a 1σ lower limit on at about ~6100 K. If the temperature is lower than this value, densities in the main atmosphere are indeed much higher and result in higher absorption depths in the damped Mg i line wings, which are not observed (Fig. 22).

6.4. Discussion on the electron density

We obtained electron densities at 3 Rp significantly higher than the 106−107 cm-3 range expected from theoretical models (e.g., Guo 2013). It is possible that these values have a large uncertainty, as such models are by necessity based on many assumptions regarding the energy input, the atmospheric processes, and composition, and are furthermore simplified 1D representations of the sharp atmospheric transition between the day and night sides (i.e., along the terminator as observed during transits). If ions and electron densities are indeed similar, collisions of magnesium with ions should modify the dynamics of the escaping gas. However, the hydrogen escape rate, planetary wind velocity and exobase altitude derived from our best fits are consistent with values found in the literature, and are independent of the electron density in their effect on the theoretical absorption profile (see for example Figs. 16 and 17). This gives us confidence in our modeling and the assumption that the atmosphere beyond the Roche lobe is collisionless. As a first explanation it is conceivable that electrons may be more abundant than ions in the upper atmosphere. Alternatively, we may have overestimated the electron density. First, we would not detect an absorption signature in the Mg ii line if the ionized magnesium cloud produced by the atmospheric escape was extending far away from the planet to occult the stellar disk at all observed orbital phases, a scenario which was proposed for WASP-12 b by Haswell et al. (2012). In this case, the density of neutral magnesium needed to reproduce the observations would be obtained with much lower recombination rates and electron densities because of the large amount of ionized magnesium available for recombination. Second, depending on the heating efficiency and stellar irradiation, temperatures in the extended atmosphere of HD2 09458b could be significantly higher than the average temperature profile we used (e.g., Koskinen et al. 2013a). With temperatures of about 13 000 K, which would be consistent with the high heating efficiency expected in the atmosphere of HD 209458b (Ehrenreich & Désert 2011; Koskinen et al. 2013a), best-fit electron densities are in the order of 108 cm-3 because of the higher recombination rate. Third, the radiative and dielectronic recombination rates estimated by Aldrovandi & Pequignot (1973) may be inadequate in the hydrodynamic atmosphere of HD 209458b.

thumbnail Fig. 21

Plot of the χ2 difference between simulations obtained with the best-fit parameters of the G-scenario (black line) or the C-scenario (green line) as a function of the main atmosphere temperature. Horizontal dotted black lines are plotted at 1, 2, and 3σ from each best fit (; ), and in both cases the χ2 difference exceeds 1σ with temperatures below ~6100 K.

Open with DEXTER

thumbnail Fig. 22

Absorption profile observed in the Mg i line (blue histogram). Two absorption profiles are calculated for best-fit parameters (G-scenario) and a main atmosphere temperature of 5000 K (dashed black line) and 7000 K (solid black line). In both cases, the red line shows the part of the absorption profile generated by neutral magnesium in the main atmosphere. The decrease in temperature leads to higher densities in the main atmosphere, which increases absorption in the wings of the line through natural broadening.

Open with DEXTER

7. Spectro-temporal variability

We obtained variations with time in the velocity structure of the best-fit theoretical absorption profile, regardless of the considered scenario (Fig. 23). Radiation-pressure-accelerated neutral atoms free of the planet influence absorb in the blue wing of the Mg i line up to a velocity determined by their lifetime, i.e., by the reference electron density. By contrast radiation pressure from the Mg i line has little influence on particles close to the planet (which are neutral in the global and constrained best fits), as they have low velocities and are mostly shielded from stellar photons. These particles follow the planet orbital motion and their absorption in the Mg i line core shifts toward higher positive velocities during the transit, following the increase in the planet velocity on the line of sight between 15 to 15 km s-1 from ingress to egress (as observed in the line of carbon monoxide by Snellen et al. 2010). This variation is similar to the putative redward extension of the absorption signature reported by Vidal-Madjar et al. (2013) between the transit and post-transit observation, as can be seen in Fig. 1. The ratio between the populations generating absorption in either the core or the wing of the spectral Mg i line is constrained by the planetary wind velocity at the exobase, and the best-fit values described in Sect. 6.1.4 are those that balance the two populations and their respective absorptions in a way consistent with the observations (Fig. 23). Independent of the planetary wind velocity and the exobase altitude, the escape rate and reference electron density control the total amount of neutral magnesium particles in the cloud and their maximum velocities, i.e., the overall depth of the absorption profile and its width. As a result, observations are always best reproduced with ne(3 Rp) = 6.4 × 1010 cm-3 and Mg0 = 2.9 × 107 g s-1, regardless of the best couples (vpl − wind; Rexo) in Fig. 18.

The velocity range of the observed absorption signature also limits the size of the cometary tail of neutral magnesium. For both best-fit simulations it absorbs efficiently up to about 15 planetary radii (Fig. 13), and seen from the Earth, the projection of the cloud onto the stellar disk extends to only a few planetary radii. Absorption drops quickly after the end of the planetary transit (Fig. 24) and post-transit absorption depths are lower than the value measured by Vidal-Madjar et al. (2013).

thumbnail Fig. 23

Evolution of the theoretical absorption profile as a function of time during the transit of HD 209458b, for the best-fit simulation of the G-scenario. Absorption in the blue side is generated by radiation-pressure accelerated magnesium atoms and always drops at about 60 km s-1 (at mid-height). The central absorption peak comes from atoms close to the planet (dotted lines show the part of the absorption profile generated by the main atmosphere) and shifts redward of the line with the orbital motion. This is similar to the spectral extension of the observed absorption signature toward positive velocities during and after the transit (Fig. 1). The simulated planetary disk is the source for an absorption depth of ~1.4% at all wavelengths during the transit.

Open with DEXTER

thumbnail Fig. 24

Top panel: theoretical transit absorption depth over the range 60 to 0 km s-1 in the Mg i line (solid and dashed lines). Measurements for the transit-ingress, transit-center, and post-transit observations (Vidal-Madjar et al. 2013) are plotted as black dots with horizontal error bars showing their duration. Vertical dotted lines show the beginning and end of ingress and egress of the planetary transit. The theoretical absorption depth, determined by the stellar surface occulted by the magnesium cloud and its opacity, is displayed for the global best-fit simulation (solid line; Rexo = 3 Rp, vpl − wind = 25 km s-1, Mg = 2.9 × 107 g s-1) and the constrained best-fit simulation (dashed line; Rexo = 2 Rp, vpl − wind = 10 km s-1, Mg = 6.3 × 107 g s-1). Lower panels: views of the magnesium particles with velocities in the range 60 to 0 km s-1 along the star/Earth line of sight (light blue). HD 209458b is displayed as a deep blue disk. Although the cloud occults a larger area in the global best-fit simulation (middle panel), it is optically thinner than in the constrained best-fit simulation (bottom panel).

Open with DEXTER

8. Conclusion

We used a revised version of the 3D particle model described in Bourrier & Lecavelier (2013) to simulate the escape of magnesium from the atmosphere of HD 209458b and to calculate theoretical transmission spectra to be compared to transit and post-transit observations obtained in the Mg i and Mg ii lines in the UV by Vidal-Madjar et al. (2013). The main improvement to the previous model is a detailed analytical modeling of the atmosphere below the exobase which takes its shielding effect and its absorption in the core of the neutral magnesium line into account. We found that the mean temperature below the exobase must be higher than ~6100 K. The free parameters of the model are otherwise the escape rate of neutral magnesium, the electron density, the altitude of the exobase, and the velocity of the planetary wind at the exobase.

Observations are best explained if the exobase is close to the Roche lobe () and magnesium atoms escape the atmosphere at the exobase level with a radial velocity vpl − wind = 25 km s-1. Because of the V-shape of the stellar Mg i line, radiation pressure is not too efficient on low-velocity neutral magnesium atoms close to the planet but impart strong accelerations to atoms with high radial velocities, as they receive more UV flux far from the line core. The velocity range of the absorption signature, up to 60 km s-1 in the blue wing of the line, is thus well reproduced by a radiative blow-out, provided the quick stellar UV-photoionization of the escaping particles is compensated for by electron recombination up to an equilibrium altitude between the two mechanisms, which is estimated to be . Beyond this Mg-recombining layer of the exosphere the magnesium is mostly ionized and subjected to a low radiation pressure from the Mg ii line. The non-detection of excess absorption in this line is well-explained by low densities of ionized magnesium at all altitudes. The global best fit to the observations is obtained with an escape rate Mg = 2.9 × 107 g s-1 (2.0 × 107 − 3.4 × 107 g s-1). Assuming a solar abundance these results are consistent with standard values of hydrogen escape rates in the range 2.1 × 1010 − 3.5 × 1010 g s-1. Observations are best reproduced with electron density at 3Rp in the order of 1010cm-3. This value is possibly overestimated; or if the electron density is correct, it could mean that electrons are more abundant than ions in this collisionless part of the upper atmosphere. With the addition of electron-impact ionization to UV-photoionization, electron-recombination is dominated by ionization close to the planet (below 2.7Rp), but this has little influence on the quality of the best fit since particles are launched above the Roche lobe. In any case, the rates used by Voronov (1997) for electron-impact ionization may not be valid for temperatures below 11 000 K because they were calculated for plasmas with far higher temperatures.

Constraining the exobase radius and planetary wind velocity to lower values consistent with theoretical model predictions (Rexo = 2 Rp and vpl − wind = 10 km s-1) we found that the observations can still be explained with similar escape rates and electron densities, albeit with larger error bars: Mg = 6.3 × 107 g s-1 (1.4 × 107 − 4.7 × 108 g s-1). Although in this case the exobase radius was chosen arbitrarily, halfway between the planet surface and the Roche lobe, a different value in this range does not significantly change our conclusions.

Simulations show that the absorption profile results from complex interactions between radiation pressure, planetary gravity, and self-shielding. In a previous work, the analysis of transit observations in the Lyman-α line of neutral hydrogen allowed us to characterize atmospheric escape at high altitudes in the exosphere. Here the absorption signature in the line of neutral magnesium has been used to analyze the structure of the atmosphere at lower altitudes both in the escaping cloud and below the exobase. Simulations predict that the absorption profile should expand toward positive velocities during the transit because the atmosphere close to the planet follows its circular orbital motion. Observation of the magnesium lines thus appears to be a powerful tool to probe an exoplanet’s upper atmosphere in the thermosphere-exosphere transition region. We can anticipate that several host stars of transiting planets may be bright enough in the Mg i line for their atmosphere to be probed in such a way.

Acknowledgments

The authors wish to thank the referee, Tian Feng, for his perceptive comments, which greatly improved this paper and helped to put its results in perspective. Based on observations made with the NASA/ESA Hubble Space Telescope, obtained at the Space Telescope Science Institute, which is operated by the Association of Universities for Research in Astronomy, Inc., under NASA contract NAS 5-26555. The authors acknowledge financial support from the Centre National d’Études Spatiales (CNES). The authors acknowledge support from the French Agence Nationale de la Recherche (ANR), under program ANR-12-BS05-0012 “Exo-Atmos”. This work has also been supported by an award from the Fondation Simone et Cino Del Duca.

References
