1. Introduction

Photo-dissociation regions (PDRs) are interstellar neighbors of HII regions that are already shielded from extreme ultraviolet (EUV) photons with an energy sufficient to ionize atomic hydrogen, but where the physical and chemical conditions of the atomic and molecular interstellar medium (ISM) are still governed by the remaining far-ultraviolet (FUV) radiation of nearby massive stars (Hollenbach & Tielens 1999). Here, the transition from the atomic to the molecular ISM takes place, giving rise to a rich astrochemical environment. The combination of a chemically rich pool of species that includes a large reservoir of free electrons and strong energetic excitation conditions produces a wealth of spectroscopic emissions, carrying information on the internal chemical and physical structure of the PDR.

Comparing the results of theoretical and numerical calculations to the observed spectral line emission of PDRs is a frequently used method to infer their local physical conditions. Numerical models to describe the physical and chemical processes in molecular clouds have been successfully used for many years. They involve simultaneously solving the problem of a) radiative transfer for a cloud of gas and dust; b) the chemical structure by balancing formation and destruction processes for all included species; c) determining the thermal structure of the cloud by balancing all important heating and cooling processes.

Properly taking into account all relevant chemical and physical processes is extremely time-consuming in terms of computational power and usually leads to a large number of simplifying assumptions in the treatment of the physics and the chemistry. The exact choice of these simplifications depends on the field of application, on the expertise of the modeller, and on the available physical and chemical knowledge. Many processes are still not fully understood if not largely unknown. A prominent example is the description of interstellar dust (see Draine 2003a,for a review on interstellar dust). Many important physical and chemical processes require a good knowledge of the properties of interstellar dust grains (Abel et al. 2008). Chemical reactions on the surface of dust grains appear to be the only efficient formation route for a number of important astrochemical species (Garrod et al. 2008; Hall & Millar 2010). The specifics of their reaction kinematics depend to a large degree on the material properties and the structure of the dust grains. Porous, spongy grains provide a large surface for chemical reactions but might hinder the release of the newly formed species into the gas phase (Leger et al. 1985; Roberts et al. 2007; Taquet et al. 2012). Not only the material and shape, but also the size of the grains might be important. Very small grains and very large molecules, such as polycyclic aromatic hydrocarbons (PAHs), efficiently contribute to the gas heating by means of the photoelectric (PE) effect (Bakes & Tielens 1994; Weingartner & Draine 2001a) while larger grains are dominating the scattering and absorption of FUV photons. For a review on PAHs see Tielens (2008).

The rapid development in observational techniques over the last two decades left us with a vast amount of spectroscopic data that defies reproduction with simple numerical PDR models. We are far away from being able to really understand the conditions in any observed PDR (Röllig et al. 2007). In this paper we describe a number of steps that have been taken to increase the modeling power of the KOSMA-τ PDR model code. We tried to evolve the code toward a consistent treatment of dust physics and chemistry. By calculating the optical and energetic properties of a model cloud with a given dust composition we are now able to describe the full spectral emission characteristic of a model cloud including dust continuum and line emission1.

2. Code description

2.1. The KOSMA-τ PDR model code

The KOSMA-τ code (Röllig et al. 2006), a welltested and mature PDR model code (Röllig et al. 2007), applies spherical geometry to the problem of simultaneously solving the chemical and energy balance in an interstellar molecular cloud. KOSMA-τ is equipped with a modular chemical network, i.e., chemical species can easily be added or removed from the network and the network will rebuild dynamically, including isotopic chemistry of 13C and 18O. After obtaining the physical and chemical structure of the model cloud, a radiative transfer code is applied to calculate the resulting emissivities for the spectral line emission. Because of the spherical geometry of the model clump, radiation can reach a point inside the clump from any direction.

2.2. Multi-component dust radiative transfer model

The multi-component dust radiative transfer (MCDRT) code allows one to solve the frequency-dependent radiative transfer equations and the thermal balance equation in a dusty clump under the assumption of spherical symmetry (Yorke 1980). A detailed description of the code’s main features is given in Szczerba et al. (1997). The code includes isotropic scattering, which is important at high optical depths. Further modifications to that version of the code have been made. First, we have added the possibility to solve the radiative transfer simultaneously for a number of dust sorts (NDS) i that may or may not be co-spatial, and obey any dust size distribution. The grain size distribution is given by the general relation valid for grains with radius ai, −  ≤ a ≤ ai, + ; (1)where: ni(a) is the number density of grains with size  ≤ a and n is the number density of H nuclei (in both atoms and molecules: n = nH + 2nH2). The function fi(a) has a modular structure and can be changed easily to a different form. Second, because we adapted the code to the conditions typical for PDRs it was necessary to introduce an option for switching off the central source. In addition, because intense sources of an interstellar radiation field are ubiquitous in PDRs, we changed the spatial distribution of impact parameters (originally logarithmically spaced beginning from the inner shell of the clump) along which the ray equations are integrated. The end result of this code is the infrared radiation flux emitted by the clump, which can be compared to the radiation observed from real PDRs. However, as a byproduct, the code provides the mean intensity of the radiation field, Jλ(r) and the dust temperature, Td,i(r,a), which for now is computed from the assumed thermal equilibrium for each dust species and dust grain size at each radius r of the clump. These two quantities (mean radiation field and dust temperature) are now used in the KOSMA-τ PDR model code to obtain a self-consistent gas-dust model.

2.3. Dust models

For the purpose of this paper we selected three dust models of interstellar dust from Weingartner & Draine (2001b, hereafter WD01), and the MRN dust model (Mathis et al. 1977) for comparison. The MRN interstellar dust model was constructed by fitting a dust model to the Galactic mean extinction curve. It consists of two separate dust populations, one for “astronomical silicates” (sil) and one for graphite (gra). In the MRN model the grain size distribution is identical for both dust components and is given by (2)where i stands for sil and gra, Asil = 10-25.10, and Agra = 10-25.13 (WD01).

Recently gathered observational constraints led WD01 to construct new models for interstellar dust. The authors proposed that interstellar dust is composed of four main components: astronomical silicates, graphite, and populations of very small grains that consist of neutral (PAH0) and ionized (PAH+) particles. The grain size distributions for these dust components follow the general definition given by Eq. (1) and their functional forms (fi(a) in Eq. (1)) are given by Eqs. (2)–(6) of WD01. The authors employ a power-law form for the large grains and a log-normal distribution for the very small grain population. Free parameters of the fi(a) functions were determined by the best fit to the average extinction with RV = AV/E(B − V)) of 3.1, 4 and 5.5 (see WD01 for details). AV is the absolute visual extinction at V = 5500 Å and E(B − V) = AB − AV. The three dust models from WD01 correspond to lines 7, 21, and 25 from Table 1 in Weingartner & Draine (2001b) and are denoted WD01-7 (RV = 3.1), WD01-21 (RV = 4.0), and WD01-25 (RV = 5.5).

To compute the extinction efficiency Qext and albedo ω for each dust component, we assumed that grains are spherical and used the Mie theory (Bohren & Huffman 1983). For silicates and graphite we used the dielectric constants from Draine (2003b), while for very small grains we followed the approach given by Li & Draine (2001). The minimal and maximal grain size for the size distribution of each dust component are given in Table 4. For very small grains we used 17 grain sizes, while for bigger grains we divided each dex of grain sizes into ten sizes, keeping equal distance in log    (a). The wavelength coverage used in the MCDRT code extends from 10 Å to 3000 μm and is split into 333 wavelengths.

3. Impact on the PDR model

In the following we describe how the new, full radiative transfer (RT) computation compares to the old approximation used in the KOSMA-τ model. For this purpose we evaluated a reference model clump with varying FUV radiative transfer and different dust models. We kept the following model parameters constant for all models: the total clump mass M = 10 M, the total surface gas density n = 105 cm-3, and the total FUV field χ = 1000 in units of the Draine field (Draine 1978). We applied a power law density gradient with power index 1.5 with a constant central gas density for radii smaller than Rtot/5. This implies Rtot = 2.46 × 1017   cm = 0.08   pc. We assumed a total cosmic ray ionization rate of molecular hydrogen ζH2 = 5    ×    10-17 s-1. The chemistry is based on the UMIST 2006 database for astrochemistry UDfA2 (Woodall et al. 2007), using 47 chemical species and 490 reactions in total.

3.1. UV continuum radiative transfer

3.1.1. Dust extinction

For any given line of sight, the optical depth at FUV wavelengths τFUV = σd,FUVNH (Sternberg & Dalgarno 1989), with σd,FUV being the effective dust grain extinction cross section in the FUV, and the total hydrogen column density NH. In the previous version of the KOSMA-τ code, the local radiation field was calculated by computing the optical depth as a function of angle and then performing an angular averaging of the resulting intensity over the full solid angle. A detailed description of the FUV transfer in the spherical model has been given by Störzer et al. (1996).

For a constant dust-to-H ratio the total extinction cross section per H nucleus can be derived from (3)where is the extinction cross section of a single dust particle with size a at wavelength λ. Often the absolute extinction in magnitudes is used (4)By introducing the average mass extinction coefficient for each dust component, i.e., the mean extinction cross section per dust mass, (5)where ρb,i is the bulk dust grain density (i.e., the density of material of which dust of given sort is composed) and ρdust,i is volume density of the ith dust sort, the optical depth at any given point of the model clump can be written as (6)Relating this to the gas density provides (7)where n   mH    =    ρgas, and mH is mass of a single H atom. Using Ψ    =    ρdust/(n   mH) as the total dust-to-H mass ratio, and we can write (8)with (9)For a constant dust-to-H mass ratio the integration over r in Eq. (8) can be performed giving an H column density NH using (10)i.e., σext(λ) =  ⟨ Kext(λ) ⟩ mHΨ.

thumbnail Fig. 1

Extinction cross section per H nucleus for the WD01-7 dust model (dashed lines) and for the MRN model (solid lines). The total cross sections are represented by thick lines. The contribution from each dust component is shown by red lines for silicates, blue lines for graphite, and green lines for very small grains.

Open with DEXTER

3.1.2. Influence of the dust composition

Figure 1 shows the total extinction cross section per H nucleus computed for the WD01-7 (thick dashed line) and the MRN model (thick solid line) of interstellar dust. The other lines show contributions from each dust component incorporated into the WD01-7 model (silicates – dashed, red in the electronic version; graphite – dashed, blue in the electronic version; and PAH0+PAH+ – dashed green line in the electronic version), and the solid lines present contribution from silicates (red) and graphite (blue) in the MRN model. One can see that in the WD01 model populations of very small grains (PAH0 and PAH+) are responsible for a large part of the total extinction, especially for the 2200 Å band, while large grains dominate the total mean Galactic extinction in the MRN model.

thumbnail Fig. 2

Relative extinction for the dust models of MRN (solid) , WD01-7 (long-dashed; red in electronic version); WD01-21 (short-dashed; green in the electronic version) and WD01-25 (dot-dot-dashed; blue in the electronic version) of interstellar dust. The vertical dotted lines at wavelengths of 912 and 2066 Å, corresponding to 13.6 and 6 eV, show the range of averaging. The horizontal lines show kFUV for the considered models.

Open with DEXTER

Figure 2 shows Aλ/AV for the dust models tested in this paper: MRN (solid), WD01-7 (long-dashed; red in the electronic version), WD01-21 (short-dashed; green in the electronic version), and WD01-25 (dot-dot-dashed; blue in the electronic version). The FUV range relevant for photoelectric heating and photo-dissociation reactions extends between 13.6 and 6 eV3. Consequently, we define an FUV-to-V color as kFUV =  ⟨ A(λ)/A(V) ⟩ λ   ≡  ⟨ Aλ/AV ⟩ λ where the averaging is performed over an energy from 6 to 13.6 eV and AV is the visual extinction. The vertical dotted lines in Fig. 2 indicate this range of averaging and the horizontal lines show kFUV for the considered models. Note that the MRN and WD01-7 dust models have the same value of kFUV = 3.339. All values of the average relative dust extinction are collected in Table 4. From Fig. 2 it can be seen that kFUV is significantly decreased in the WD01-21 and WD01-25 dust models. This is consistent with the higher values of RV, i.e., a shallower gradient of A(λ)/AV toward shorter wavelengths causing a lower UV extinction for the same AV (see Fig. 2). This is the main source for the different UV attenuation properties of different dust types.

3.1.3. Influence of radiative transfer and scattering

As a result of the new radiative transfer computations we obtain the full, wavelength-dependent FUV radiation field at all clump radii, where Iλ is the specific intensity at wavelength λ. In Fig. 3 we plot Jλ(r) for radii in steps of Rtot/10 for the WD01-7 model. The effect of the prominent 2200 Å “bump” is plainly visible in the enhanced reduction of Jλ with decreasing radius.

The FUV optical depth (11)can be described by the effective dust extinction cross section (12)For adopted dust models, the obtained values of σD,FUV are collected in Table 4.

thumbnail Fig. 3

Mean intensity Jλ(r) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The lines show Jλ(r) for radii in steps of 10% of Rtot.

Open with DEXTER

The original KOSMA-τ code did not include any angular dependence of the dust scattering but implicitly assumed pure forward scattering (Sternberg & Dalgarno 1989) in terms of an extinction coefficient σD,FUV. As long as the models use the same value of σD,FUV, the radiative transfer should always give the same scaling of the UV intensity with exp( − NHσD,FUV) at high optical depths because the radiation from scattering at other angles is quickly damped because of the longer optical path, but the scattering will increase the intensity close to the surface (Flannery et al. 1980).

To study the influence of FUV scattering we performed a set of model calculations with different scattering properties but the same effective value of σD,FUV = 1.76 × 10-21 cm2:

  • 1.

    The old KOSMA-τ FUV calculations using pureforward scattering.

  • 2.

    The MCDRT result for a MRN dust distribution providing the same σD,FUV, but where the albedo ω is artificially set to zero.

  • 3.

    The MCDRT result for the MRN distribution with a full treatment of scattering and absorption.

In Appendix A we discuss how the assumption of isotropic scattering compares to more realistic scattering properties and demonstrate that it poses a clear improvement compared to the pure forward scattering case used in our previous model.

Figure 4 shows a comparison of the depth-dependant mean FUV intensity scaled by the unattenuated mean FUV intensity J(r)/χ0 for these three models. J(r) is the total mean intensity, i.e., averaged over the full solid angle and integrated over the full wavelength range: . χ0 is the corresponding total mean intensity of the FUV field in the absence of the molecular cloud, i.e., the full unattenuated photon flux coming from 4π solid angle. For r = Rtot, models 1) and 2) are slightly larger than 0.5, which would be the theoretical value for a fully opaque and very large clump. Higher values indicate the contribution from angles slightly larger than 90°. By contrast model 3 shows a value of 0.58, indicating significant contributions to J(r) by scattered photons. Consequently, the mean intensity is higher for model 3) throughout the whole clump because of a large amount of scattered photons. The small differences between models 1) and 2) result from the full wavelength treatment compared to the attenuation by an average τFUV only. For high optical depths models 2) and 3) converge to the same intensities as all sidewards scattered photons turn insignificant there because of the longer optical path (Flannery et al. 1980).

Equation (12) turns out to be a very good approximation when only forward-scaterring occurs, which is clearly reproduced by the detailed radiative transfer computations with the albedo set to zero. However, only the full radiative transfer treatment can produce the full spatial and spectral knowledge of the radiation field and the proper accounting for scattered photons.

thumbnail Fig. 4

Mean intensity of the UV radiation vs. cloud depth. The black line corresponds to the old KOSMA-τ result for pure absorption. The blue line corresponds to the MCDRT result for an MRN distribution with full treatment of scattering and absorption. The dashed line is the result for an MRN distribution with the albedo artificially set to zero.

Open with DEXTER

thumbnail Fig. 5

Mean intensity of the UV radiation J(r) scaled to the unshielded (empty space) Draine field χ0 vs. cloud depth. Different lines denote different dust compositions.

Open with DEXTER

The influence of dust composition on the resulting depth-dependent FUV intensity in the clump can be seen in Fig. 5. For the FUV intensity in the WD01 models, the following is true throughout the whole clump: WD01-7 < WD01-21 < WD01-25.

3.1.4. Influence on photo-reactions

The local UV intensity acts on the chemistry of the clump by heating the gas and dust and by inducing ionization and dissociation reactions. This photo-process j with a wavelength-dependent cross section σj(λ) proceeds at a rate (Roberge et al. 1991) (13)Jλ(r) is the mean intensity of radiation at radius r in photons cm-2s-1 nm-1. The integral runs from λH = 912 Å to the threshold wavelength λj for the process j4. Astrochemical databases often provide parametrized reaction rate coefficients to allow the calculation of these photo-reaction rates. For instance, UDfA gives the rate coefficients in the form (14)assuming an attenuation of the radiation provided by a standard MRN dust model in a plane-parallel configuration using the radiation transfer results from Flannery et al. (1980) parametrized in terms of the perpendicular visual extinction AV. χ0 is the FUV field strength at the edge of the cloud and the unshielded, free-space rate coefficient αj assumes a mean FUV intensity of unity (in units of the Draine field) and FUV photons coming from all directions. At the edge of an optically thick molecular cloud the rate coefficient is about half of this value, depending on the dust scattering properties.

The unshielded rate coefficient αj does not depend on the dust properties and we concentrated on the attenuation properties, parametrized in form of the . Changing either the dust properties, i.e., the wavelength-dependant FUV attenuation, or the spectral distribution of the FUV field leads to a different result for Γj and consequently to a different fit parameter γj. However, performing the wavelength-dependent integration of Eq. (13) for every reaction and every radial point is often beyond the scope of PDR models, e.g., because it is too time-consuming or because neither dust properties nor ionization cross sections σj(λ) are known accurately enough to justify the computational effort of a full integration of the wavelength-dependent radiative transfer. Furthermore, knowledge of the wavelength-dependent σj is not available for all astrophysically relevant species and models have to apply Eq. (14) even if they can perform the full integration in principle.

Here we derive a scaling relation between the γj values provided by a data base like UDfA and corresponding fit values for a particular dust model to calculate the rate coefficient for species j and dust sort D. For a direct comparison with UDfA values we started from a model cloud with a mass of 103 M and a radius of 1.71 pc, large enough to neglect the effects of the spherical symmetry close to the surface, isotropically illuminated and calculated the photo-dissociation and photo-ionization rates of 72 species provided by van Dishoeck et al. (2006); van Hemert & van Dishoeck (2008) for all 25 dust models D from Weingartner & Draine (2001b) according to Eq. (13).

thumbnail Fig. 6

Fit results for for HCO (black), CH2 (red), CN (green), and N2 (blue) for all dust models from Weingartner & Draine (2001b,their Table 1). The abscissa gives the number of the dust model. The large points show the original values of γj for the respective molecules.

Open with DEXTER

Table 1

Dust model parametrization of all WD01 dust models.

To this end, we performed least-squares fits to up to an AV = 10 to determine new coefficients for all D and j. Figure 6 shows the new for four example molecules, HCO, CH2, CN, and N2 for all 25 dust models.

The big dots on the left show the original value γj from UDfA5. The figure shows that the new show the same behavior along the abscissa for all four example species. There are also three branches of , visible as prominent quantitative steps in Fig. 6 that correspond to the respective RV values.

The next step is to identify what dust model property is best correlated with . An extensive analysis of the dust properties reveals that we can find a wavelength λ = 760   Å for which (15)shows a monotonic ordering for the of the 25 dust models. Consequently, we chose as the parameter describing the dust. Table 1 gives for all 25 WD01 dust models. Using this parameter, we can approximate the dependence of on γj and the dust model by (16)Equation (16) reproduces the explicitly calculated attenuation of the rate coefficients within an accuracy of σ = 0.05, and a maximum absolute residual of 0.22. This is comparable to the uncertainties of due to fitting Γj(AV)/Γj(0) up to a different maximum AV. Note that for the fitting we removed seven species (photo-dissociation of CH+, SH+, OH+, HCO+, CO, O, and SiO ) from the data set because their represent strong outliers with respect to the remainder of the data set. We discuss possible reasons for these deviations in Appendix B. To apply Eq. (16) to them, we had to use corrected coefficients instead of the UDfA vales when computing . The values are given in Table 3.

thumbnail Fig. 7

Comparison of explicitly fitted for HCO (black), CH2 (red), CN (green), and N2 (blue) for all dust models from Weingartner & Draine (2001b,their Table 1) with scaling relationship Eq. (16). The large points show the original values of γj from UDfA, the open diamonds show the values calculated using an MRN dust model, and the open squares denote the explicitly calculated values assuming .

Open with DEXTER

Table 2

Fit parameters in Eq. (16).

Table 3

Corrected for the outlying species.

It turns out that the original MRN distribution with does not exactly follow the parametrization of Eq. (16), based on the WD01 dust models, but that it can be easily used in the same function when adjusting the parameter . Figure 7 compares for HCO, CH2, CN, and N2 with the results of Eq. (16). In addition we show the MRN results in the plot: the original γj, the explicitly calculated , and the assuming using large points, open diamonds, and open squares, respectively (the arrows in the figure demonstrate the shifting of the rescaled closer to Eq. (16)).

It is unclear why the γj from UDfA, i.e., the MRN values, do not follow the parametrization of Eq. (16). There is a number of possible reasons for the deviation. Woodall et al. (2007) did not use a Draine FUV radiation field but assumed a 10 000 K black-body radiation field. The different spectral shape usually accounts for approximately 10% difference but can in a few special cases result in a significant difference. Secondly, different AV,max up to which the γj is fitted give different values of γj( see Appendix B for a more detailed discussion). The details of the radiation scattering is another possible reason for different results. Assuming different anisotropy factors g and dust albedo ω will change the radiation field and accordingly affect the γj (see Appendix A for a discussion on the effect of different values of g).

We conclude that the scaling relation Eq. (16) is able to rescale the tabulated γj from UDfA to the dust-specific (fitted to the fully calculated Γj(AV)/Γj(0)) with an accuracy of about 10%.

3.2. Dust temperatures

Dust temperatures are calculated independently for each dust component and size. Figures 810 show depth-dependent grain temperatures for a number of differently sized grains for three of the four components. The plot for the ionized PAHs is omitted because their temperature behaves like that of neutral PAHs. The general behavior is that smaller grains exhibit higher grain temperatures.

thumbnail Fig. 8

Dust temperatures of silicate grains for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different grain sizes.

Open with DEXTER

thumbnail Fig. 9

Dust temperatures of carbonaceous grains for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different grain sizes.

Open with DEXTER

thumbnail Fig. 10

Dust temperatures of neutral PAHs for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different PAH sizes.

Open with DEXTER

Figure 11 compares grain temperatures of the components of the MRN and WD01-07 dust model at the surface of a model clump as a function of grain radius ai. Graphites tend to have a higher temperature than silicate grains except for very large grain sizes. Small grains tend to be hotter than bigger grains. The PAHs are heated much more efficiently than the larger grains and have significantly higher grain temperatures. For simplicity, we deliberately neglected the non-equilibrium heating of very small grains and PAHs here and assumed equilibrium heating in this paper. In a subsequent paper, we will include the comparison with real observations accounting for the stochastic heating of the very small particles. The dependence on ai vanishes for sufficiently high extinctions i.e., once most of the remaining photons have wavelengths longer than the grains. The resulting equilibrium grain temperature then only depends on the absorption coefficient of the material.

thumbnail Fig. 11

Grain temperature for the components of the MRN and WD01-07 dust models as a function of the radius ai in nm. The grain temperatures are calculated at the surface of a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust components. Dashed lines show the MRN components and solid lines show the WD01-07 components.

Open with DEXTER

The detailed knowledge of the dust temperature as a function of radius, grain size, and grain type enables us to treat all dust-related processes separately for all grain sizes and types. However, since most relevant processes are grain surface reactions, e.g., formation of the H2 or photoelectric heating, it is usually sufficient to calculate surface-averaged quantities. For the ith dust component we can define the relevant mean dust temperature as (17)Averaging over all dust sorts is done according to (18)with the geometrical cross section of the ith sort σd,i and the total dust cross section σd. We will use the short-hand notation Td =  ⟨ Td ⟩ NDS and Td,i =  ⟨ Td,i ⟩ a from here on.

Figure 12 shows the mean dust temperature Td,i for the WD-7 dust model as a function of cloud depth for all four dust components. As at the surface (Fig. 11), silicates, indicated by the solid blue line, are cooler than graphite grains (solid, red line). Graphite and silicate grain temperatures are very close, but the mean silicate temperature drops slightly faster for increased cloud depths than the graphites. The PAHs have a much higher Td,i. Neutral PAHs tend to be marginally hotter than the ionized PAHs. The black line denotes the average dust temperature Td for the WD01-7 dust.

The influence of the different dust models can be seen from Fig. 13. The black line shows the old dust temperature calculation in KOSMA-τ following Hollenbach et al. (1991), which gives a central dust temperatures Td ≈ 22 K. Accounting for the full wavelength dependence and the detailed grain size distribution gives a significantly lower Td ≈ 13 K at the center of the model clump. On the other hand, it also leads to warmer dust at the surface of the cloud compared to Hollenbach et al. (1991).

The dust temperature for the WD01 models follow their corresponding FUV intensities (see Fig. 5). The MRN model has a much lower Td. Figure 11 shows that the Td,i for MRN and WD01-7 are very similar for equal grain sizes. However, the temperature of the PAHs in the WD01-7 model contributes significantly to the average dust temperatures in Eq. (18) and leads to higher Td in models with PAH content.

The lower central dust temperatures of models with WD01 dust types also influences the gas temperatures. Models with WD01 dust show significantly lower central gas temperatures because gas-grain collisions are becoming the dominant cooling process.

thumbnail Fig. 12

Mean dust temperature for the WD01-7 dust model for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote the average temperature of the individual dust components. The black line shows the overall mean dust temperature.

Open with DEXTER

thumbnail Fig. 13

Mean dust temperature as a function of Av for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust compositions.

Open with DEXTER

Table 4

Parameter of the WD01 and MRN dust models.

3.3. H2 formation

Molecular hydrogen is the most abundant molecule in the universe. The formation of H2 most effectively takes place on the surface of dust grains. The proper treatment of the H2 formation is crucial in any numerical PDR model (see e.g. Le Bourlot et al. 2012, for a recent update of the Meudon PDR code.). We updated the KOSMA-τ calculation of the H2 formation efficiency RH2 from the method described by SD89 to account for physisorption and chemisorption binding energies on silicate and graphite surfaces (Cazaux & Tielens 2002, 2004, 2010, hereafter CT).

This model is based on two main points: (1) H atoms can stick to the grain surface in two different binding sites, a physisorption site and a chemisorption site. Physisorption is a weak atom-surface binding resulting from a Van der Waals force (dipole-dipole interaction). Chemisorption is a strong atom-surface binding interaction involving the valence electrons, known as covalent bond. These interactions determine whether atoms move on the surface, and thus, how quickly they can meet a recombination partner. (2) The mobility of a surface H atom results from the combination of two physical processes: tunneling and thermal diffusion; tunneling dominates at the lowest temperatures while thermal diffusion is most important at the highest temperatures. The calculation of the transmission coefficients, to go from site to site, are given in Cazaux & Tielens (2004, 2010).

At low temperature (T ≤ 100 K), H2 formation involves the migration of physisorbed H atoms. At higher temperatures (T ≥ 100 K), H2 formation results from chemisorbed H recombination. The presence of these two types of binding sites allows H2 formation to proceed relatively efficiently at low and elevated temperatures.

For the dust component i, the formation rate can be written as (19)where nH and vH are the number density and thermal velocity of H atoms in the gas phase, nd,iσd,i is the total cross section of the grain component i, ϵH2,i is the formation efficiency (Cazaux & Tielens 2004) on surfaces of the ith component, and SH is the sticking coefficient of the H atoms (20)which depends on the gas and dust temperature, Tg and Td (Hollenbach & McKee 1979). The thermal velocity is 1.45 × 105(Tg/100)1/2 cm s-1. The ith dust cross section per H nucleus is given by (21)Table 4 lists σd,i for the different dust models. Cazaux & Tielens (2002) expressed the general expression for the ith H2 formation efficiency: (22)ϵH2,i is limited by three terms: the first term A prohibits the evaporation of the newly formed molecules at low temperatures. The second term, equal to unity, dominates at higher grain temperatures; all incoming H atoms leave the surface as H2. The third term B governs the high-temperature regime, where evaporation of physisorbed atoms removes H from the surface before it can recombine to H2. It competes with the hopping of atoms into chemisorbed binding sites where the atoms can remain on the surface to form H2 at significantly higher temperatures. The numerator ξi, describing the chemisorption, terminates the H2 formation at much higher temperatures, above several hundred Kelvin, when even chemisorbed atoms start to evaporate.

thumbnail Fig. 14

H2 formation efficiency for carbon and silicate surfaces. A and B denote the temperature regimes of the corresponding terms in Eq. (22). The dash-dotted line denotes the standard formation efficiency given by Hollenbach & McKee (1979).

Open with DEXTER

thumbnail Fig. 15

H2 formation rate RH2 as a function of dust temperature Td for different formation models and dust compositions. The gas temperature Tg is set to 50 K. The dashed lines indicate the-low temperature formation in the original CT formation rates with A ≠ 0. SD89 is the formation rate from Sternberg & Dalgarno (1989).

Open with DEXTER

Figure 14 shows ϵH2 as a function of Td for silicate (blue line) and graphite (red line) surfaces. The old formation efficiency from Hollenbach & McKee (1979) is shown as a dash-dotted line for comparison. When applying this formation in the framework of the PDR model, see Fig. 14, the term A turned out to be problematic because it shuts down the H2 release into the gas phase once T < 10 K, accumulating all molecules on the grain surfaces. We question this term because Eq. (22) does not account for the H2 binding energy of 4.48 eV that upon formation is available to allow release into the gas phase even at very low temperatures. As a remedy we set A = 0 to ensure efficient H2 formation even on cold dust surfaces (Cazaux 2011, priv. comm.)6. More details on how to calculate the H2 formation efficiency are given in Appendix C. The total H2 formation rate can then be written as (23)Figure 15 compares the new and old H2 formation rates. The formation efficiency given by SD89 follows the treatment of Hollenbach & McKee (1979), which adopted a critical dust temperature of Tcr ≈ 65 K above which the H2 formation efficiency drops below 0.5. H2 formation becomes inefficient above  ≈ 100 K. The H2 formation in the CT dust model remains efficient up to 1000 K. The model by Cazaux & Tielens allows a much more efficient H2 formation at higher temperatures. Additionally, the significantly larger dust surface in the MRN and WD01-7 model lead to a much higher H2 formation rate than SD89.

thumbnail Fig. 16

H2 formation rate RH2 as a function of dust temperature Td for different dust compositions. The gas temperature Tg is set to 50 K. The dashed lines show the formation rate with suppressed H2 formation on PAHs. The solid lines show the formation rate allowing for H2 formation on PAH surfaces.

Open with DEXTER

While accounting for chemisorbed H atoms significantly increases the H2 formation efficiency at higher surface temperatures, it is the total available grain cross section that distinguishes between different dust models. Table 4 also compares the total dust cross section per H nucleus for the different dust compositions. The PAH cross sections contribute the majority to the final H2 formation rate. The resulting H2 formation rate for one H atom cm-3 is shown in Fig. 16. Solid lines show the formation rate as a function of Td for a constant Tg = 50 K for the WD01-7, WD01-21, and WD01-25 models allowing for H2 formation on the surface of PAHs. The dashed lines show the formation rates if the PAH surfaces are excluded from the H2 formation calculation. Consequently, the dust model with the largest effective cross section, WD01-7 shows the highest formation rate in both cases.

thumbnail Fig. 17

H2 formation heating rate for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models have been computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

The strong increase in the total H2 formation rate has an important effect in addition to the easier H2 production. Each formed H2 molecule releases its binding energy of 4.48 eV. A common assumption (e.g., Habart et al. 2004) is that this energy is equally used to a) release the molecule into the gas phase, b) increase the kinetic energy of the molecule, and for c) internal rotational-vibrational excitation. If we assume a uniform distribution, 1.5 eV are available to heat the gas. Here we can measure the H2 formation rate across the cloud by equivalently looking at the H2 formation heating.

By including H2 formation according to Eq. (23) we also increase the formation rate significantly at low values of AV. This is shown in Fig. 17. All models in the plot were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating. The solid line shows the results for the formation rate from Sternberg & Dalgarno (1989). The result for the full H2 formation treatment from CT (with A = 0), suppressing and allowing H2 formation on PAH surfaces, are shown by the dotted and dashed line. The much larger surface area of the WD01-7 dust model leads to a significant increase of the formation rate. Particularly the large PAH surface in that dust model contributes dominantly to the total grain surface and consequently to the total H2 formation heating.

It is important to note that the H2 formation heating is extensive at cloud depths where most of the hydrogen is in the form of H. This leads to the curious situation of a strong H2 formation heating in the absence of H2 molecules. The gas temperatures at these depths can reach more than thousand Kelvin. Under these conditions two more H2 destruction reaction become important: Each destruction process requires 4.48 eV to break the binding, in contrast to the release of 4.48 eV during the formation. The much more efficient formation of molecular hydrogen by Cazaux & Tielens makes it necessary to adopt an additional cooling term in the chemical network, accounting for the 4.48 eV energy consumption during the kinetic dissociation (Lepp & Shull 1983). The cooling rate can be written as (24)where k(C   1) and k(C   2) are the temperature-dependent rate coefficients for reactions (C 1) and (C 2).

The role of interstellar dust in ISM physics and chemistry remains one of the key problems in modern astrophysics. In this section we demonstrate the strong effect of H2 formation on PAH surfaces on the chemistry and the thermal conditions in PDRs. However, it remains unknown whether PAHs really contribute to the formation of molecular hydrogen. Naturally, this is connected to the uncertainty about the detailed form and distribution of interstellar PAHs.

By assuming that H2 formation can take place on PAH surfaces the formation rate from Cazaux & Tielens predicts rates of a few times 10-16 s-1 when applied to the dust distributions presented by WD01. This is about a factor 10 higher than what has commonly been found for the diffuse medium (Jura 1974; Browning et al. 2003; Gry et al. 2002; Welty et al. 2003; Wolfire et al. 2008). However, the usual values of R ∽ 2−4 × 10-17 cm3 s-1 are mean values along the line of sight while our results are local values and a direct comparison is difficult. Recently, Le Bourlot et al. (2012) presented an update to the H2 formation formalism in the Meudon PDR code and also found a strong increase of the local H2 formation rates. If we prevent H2 formation on PAH surfaces, the total grain surface available to form molecular hydrogen is significantly reduced and we predict formation rates of the same order as found in the diffuse ISM. However, PDR models assuming diffuse gas formation rates are not able to reproduce the observed extent of H2 line excitation (Habart et al. 2011). H2 formation on PAHs has also been proposed by Habart et al. (2003) to explain the H2 emission in ρ Oph, and recently Mennella et al. (2012) concluded from experimental studies that hydrogenated neutral polycyclic aromatic hydrocarbon molecules act as catalysts for the formation of molecular hydrogen.

3.4. Photoelectric heating

Weingartner & Draine (2001a) presented the photoelectric heating rate for the WD01 grain size distributions in a parametrized form as a function of , where T is the gas temperature in Kelvin and ψ is in units of K1/2 cm3. To convert the FUV field from Habing G to Draine χ units use G = 1.71χ. These parametrizations are fairly accurate when 103   K ≤ T ≤ 104 K and 102   K1/2   cm3 ≤ ψ ≤ 106   K1/2   cm3. However, the parameter range in PDR models allows ψ to reach values as high as 109   K1/2   cm3 and as low as 10-2   K1/2   cm3. Weingartner (2009) provided updated calculations of Γpc and Λgr for the dust distributions WD01-7, WD01-21, and WD01-25 up to ψ = 109   K1/2   cm3. These rates are fairly well reproduced by the new analytic fits: (25)and (26)Numerical values for Ci and Di are tabulated in the appendix in Tables D.1 and D.2.

thumbnail Fig. 18

Photoelectric heating rate for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust compositions. Models with an MRN dust composition apply the PE heating efficiency as given by Bakes & Tielens (1994). Dotted lines indicate a shift from heating to cooling because of Λgr > Γpc.

Open with DEXTER

thumbnail Fig. 19

Gas temperature Tg for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. Left panel: the different lines denote different dust models that affect the FUV radiative transfer and the PE heating. All models in the left panel werecalculated using the SD89 H2 formation. Right panel: the different lines show the effect of different H2 formation treatment. All models in the right panel were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

Figure 18 shows the PE heating rates for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The solid lines show the photoelectric heating (PEH) rates using the method described by Bakes & Tielens (1994). The PEH rate obtained for an MRN dust composition when solving the full FUV radiative transfer problem is enhanced compared to the old KOSMA-τ values because of the stronger FUV intensities due to the scattering. The dashed lines in Fig. 18 show the heating rates using the updated parametrizations from Eqs. (25) and (26) for the different dust models. Dotted lines indicate negative values, i.e., a transition from heating to cooling because Λgr > Γpc. For AV > 1 the PEH rate of the WD01 dust models follow the FUV intensity of the respective models, i.e., the model with the highest mean FUV intensity, WD01-25, shows the strongest PEH rate while the model WD01-07 drops quickest. However, it is interesting to note that for AV < 0.1 the PEH rate for the WD01-07 dust produces the strongest PEH rate, leading to the highest gas temperature of all models (see Fig. 19).

4. Application of the single clump model

4.1. Impact on gas temperature

The changes in computing the PE heating and the H2 formation, which depend on the applied dust model, have a profound effect on the thermal structure of the model clump. Figure 19 shows the separate effects of the changed FUV and resulting PE heating (left panel) and different H2 formation treatment (right panel). Among the different dust models presented by Weingartner & Draine (2001b) the WD01-7 dust models shows the highest total PE heating rate because it contains the largest population of very small grains (Weingartner & Draine 2001a). Depending on ψ, the PE heating rate from Bakes & Tielens (1994) can become higher than in the WD01 models despite its smaller population of very small grains. This is because they assume a higher electron sticking coefficient. In the chemically very active zone of 0.1 < AV < 2, the new FUV treatment leads to systematically warmer gas temperatures. The net effect of the dust model on the PE heating strongly depends on the applied dust model, with the PE heating efficiency proportional to the size of the very small grain population. A second effect comes from the H2 formation heating. The right panel in Fig. 19 shows how the increase in the total available grain surface raises the gas temperature. However, this mostly affects the outer layers of a model clump where the high grain temperatures require accounting for chemisorbed H atoms to allow the formation of molecular hydrogen.

thumbnail Fig. 20

H and H2 abundances for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different treatments of the H2 formation. The solid line shows a model using the standard H2 formation rate as given by Sternberg & Dalgarno (1989). The dashed and dotted lines show model results for H2 formation according to CT where the formation on PAH surfaces is switched on and off, respectively. All three models assume a WD01-7 dust distribution. The green dash-dotted line assumes an MRN dust model and uses the CT H2 formation.

Open with DEXTER

Overall, we can distinguish two regions: For optical depths AV ≳ 0.5, the different attenuation of the FUV field by different dust distributions dominates the gas temperature. The model with the lowest reddening, i.e., the highest FUV intensity at those depths, shows the highest gas temperature. At lower optical depths, the FUV intensity is in all cases high enough that the total dust surface available for PE heating and H2 formation determines the gas temperature. Here, the models with PAHs and many small grains, which also produce a higher reddening, show the highest gas temperature.

4.2. Impact on gas chemistry

The described changes to the model have a significant effect on the chemical structure of the cloud. The influence of the assumed dust composition and dust size distribution affects the FUV radiative transfer and the improved treatment of dust scattering increases the FUV intensity throughout the clump compared to the original approximation. Chemical species that are dominantly formed or destroyed via photo-ionization or photo-dissociation processes are affected. Secondly, the stronger H2 formation efficiency leads to an increased H2 formation heating contribution, which in turn produces an increase in gas temperature at low AV. Consequently, the abundance of the species that are dominantly formed in the outer regions of the molecular clump is changed because the higher gas temperature accelerates their respective formation and destruction reactions in the gas phase.

thumbnail Fig. 21

CO and C+ abundances for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. Left panel: the different lines denote different dust models that affect the FUV radiative transfer and the PE heating. All models in the left panel have been calculated using the SD89 H2 formation. Right panel: the different lines show the effect of different H2 formation treatment. All models in the right panel have been computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

Both effects can go in opposite directions, but usually one effect dominates. In Fig. 20 we show the dependence of the H-H2 transition zone on the applied H2 formation rate. We compare three models assuming a WD01-7 dust model with full radiative transfer and photoelectric heating treatment. The only difference between the model calculations is the treatment of H2 formation. We apply (1) the standard H2 formation rate as given by Sternberg & Dalgarno (1989) (black, solid line); (2) the H2 formation given by CT with H2 formation taking place on the PAH surface (blue, dashed line); (3) and the H2 formation given by CT with H2 formation on PAHs suppressed (red, dotted line). H2 chemistry is unique in the sense that it only weakly depends on the gas temperature (see Eqs. (19), (20)). Figure 20 shows how the different treatment of the H2 formation influences the details of the H-H2 transition. In that particular model clump, the dust temperature is about 50 K and almost identical in all models, leading to a H2 formation efficiency of unity across the dust models shown. The only significant difference is the total dust surface of the various models. The SD89 approximation, case (1), has the smallest available surface (σd = 4.14 × 10-22 cm2) followed by CT without PAHs and CT including PAHs (see Table 4). This agrees with the H-H2 transition moving outwards with growing dust surface in Fig. 20. To emphasize this behavior, we added a fourth dust model to the plot, showing the results for the MRN model. The total surface in the MRN model is only slightly smaller than the WD01-7 model without PAHs and consequently, both models show a very similar behavior. Please note that the contribution of graphite and silicate to the total dust surface is still very different in the different dust models. The MRN model possesses about equal surfaces in both kinds, while the majority of the big grain surfaces in the WD01-7 model comes from silicates.

In contrast to H2 , all other chemical species in the gas phase are affected by variations of the local FUV intensity and the local gas temperature. This is apparent, for example, in the C+ to CO transition. Figure 21 shows the density profile of C+ and CO for different model calculations. In the left panel we show the influence of the different dust models in terms of radiative transfer and PE heating, while the right panel demonstrates how the different H2 formation treatment influences the chemistry. All models in the left panel were calculated using the SD89 H2 formation. The transition from C+ to CO occurs at different AV for all models. Consistent with the FUV intensities shown in Figs. 4 and 5, the models with the lowest FUV intensities show a C+ to CO transition at lowest AV, while models with a weak dust attenuation, e.g. WD01-25, exhibit the same transition deeper in the cloud. Additionally, we note an enhanced CO density at low AV in the WD01-7 model. This is a result of the higher gas temperature due to the stronger PE heating efficiencies of that dust model.

The right panel in Fig. 21 shows the isolated effect of the different H2 formation treatment. All models in the right panel were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating. The C+-CO transition is similar across all shown models, since the FUV intensity, which controlls the photo-dissociation of CO, is the same across all models. However, the CO abundance at lower AV shows very large differences. The models using the CT dust formation scheme produce more CO at the cloud edge compared to the SD89 H2 formation. The CT models provide a stronger H2 formation heating contribution. The additional heating term produces a significant population of hot CO in the outer layers of the model clump.

thumbnail Fig. 22

Total line integrated clump-averaged intensities of 12CO transitions for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

thumbnail Fig. 23

CH and CH+ abundances (left) and column densities (right) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

thumbnail Fig. 24

OH and OH+ abundances (left) and column densities (right) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER

The production of hot, i.e., strongly excited, CO is visible in the spectral line emission of the model clumps. In Fig. 22 we show the corresponding total CO line emission of the model clumps shown in the right panel in Fig. 21. For transitions higher than J = 8−7, the line-integrated intensities start to show significant differences for the three models. In this particular case, the strength of the high-J CO transitions is proportional to the total H2-forming grain surface. The outer layers of the model clumps contribute significantly to the total CO line emission of this model. As a consequence, any modeling with a large surface of the clouds, e.g., assuming a clumpy structure, will show much stronger high-J CO emission lines compared to non-clumpy model attempts.

As an additional example of chemical species that predominantly form in the outer regions of molecular clouds and thus are affected by the H2 formation treatment we show in Fig. 23 the CH and CH+ abundances and column densities and in Fig. 24 the OH and OH+ abundances and column densities. All these species are significantly affected by the strong H2 formation heating effect in the outer parts of the model clump. The column density effect is weakest for the CH because of the abundance peak at AV ≈ 1. The other three species show a stronger effect on the column density because of the weak formation in deeper clump regions. Recent Herschel observations show high column densities of these surface tracers (e.g. Qin et al. 2010; Falgarone et al. 2010), which were difficult to reproduce in existing PDR models. A more efficient H2 formation modeling with the accompanying formation heating effect may help to resolve the discrepancy between models and observations.

Table 5

Line emission Idv for the three models shown in Fig. 25.

4.2.1. Full model SED

In Fig. 25 we show the full continuum and spectral line flux (in units of Jy) emitted by a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The two panels show the results for different dust models. The top panel shows the result for the dust model with the largest effective surface contributing to the gas heating, the WD01-7 model, equivalent to a RV = 3.1. The strong gas heating is visible in the large population of intense high-J CO emission lines with J > 10 stemming from the outer layers of the cloud (see Table 5)7. In the bottom panel we show the result for a MRN dust model, visible through the lack of PAH emission features in the NIR.

thumbnail Fig. 25

Full continuum and spectral line flux emitted by a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The two panels show the results for different dust models. Top: WD01-7 dust model, equivalent to a RV = 3.1. This is the dust model with the largest grain surface contributing to the heating. Bottom: MRN dust mode. This is a dust model with a slightly smaller grain surface compared to WD01-7. The PE heating was calculated according to Bakes & Tielens (1994).

Open with DEXTER

In Table 5 we summarize the line emission of the WD01-7 and WD01-25 (with and without H2 formation on PAHs), as well as the MRN models quantitatively. The differences between the WD01-7 and WD01-25 models are limited to the line emission, the continuum emission is only marginally different. The WD01-25 models show weaker high-J CO emission because of the smaller grain surface and correspondingly a weaker H2 formation heating. The high-J CO emission of the MRN model falls between the WD01-7 and the WD01-25 dust models without H2 formation on PAHs. Allowing for H2 formation on PAHs will add a strong heating contribution from the formation processes on the large PAH surface, exciting the high-J CO transitions by a large factor.

5. Summary

We revised the treatment of the dust in the KOSMA-τ PDR model code to achieve a consistent description of the dust related physics in the code. The computation of dust properties in numerical models of photo-dissociation regions afflicts the chemical and physical structure of a model cloud via multiple effects. The major areas where dust properties play an important role are

  • 1.

    the optical dust properties, i.e., their influence on the radiativetransfer

  • 2.

    the dust temperature (neglecting non-equilibrium heating for the very small grains), which influences surface chemistry, most importantly the formation of molecular hydrogen

  • 3.

    the heating and cooling capabilities of dust grains via photoelectric heating and gas-grain collisional cooling.

The effect of changes in these areas on the physical and chemical structure of a model can be profound and we described their respective influence in detail.

We notice two opposite effects: Increasing the fraction of small grains steepens the slope of the extinction curve so that the FUV intensity drops faster when going into the cloud, which leads to a temperature decrease at high optical depths. However, it also provides more surface for PE heating and H2 formation, thus increasing the heating efficiency. As a consequence, the gas becomes hotter in the outer layers, but colder inside the cloud when the fraction of small grains and PAHs is increased. Only tracers of the outer layers are able to reliably measure the gas heating efficiency. In contrast to common wisdom, this is not even true for ionized carbon [CII], which traces both regimes.

The most influential modification of the code is the treatment of H2 formation on the surface of dust grains. Allowing for chemisorption, i.e., including the Eley-Rideal effect into the formulation of the H2 formation efficiency, significantly increases the overall formation rate of molecular hydrogen. If a significant fraction of the dust consists of very small grains and PAHs, their very large contribution to the total grain surface leads to an additional enhancement of the total H2 formation. If the molecule formation is enhanced, the formation heating is enhanced as well, providing a profound heating contribution in the outer layers of the model clumps, which significantly affects the local chemistry.


1

Other PDR model codes are also able to perform wavelength-dependent UV radiative transfer. Compare for example Le Petit et al. (2006); Abel et al. (2005).

3

H2 only absorbs FUV photons via Lyman and Werner electronic transitions in the 912−1100 Å range.

4

A database of photo-ionization and photo-dissociation cross sections for common astrophysical species can be found at http://home.strw.leidenuniv.nl/~ewine/photo/. For more details see van Dishoeck et al. (2006) and van Hemert & van Dishoeck (2008).

5

van Dishoeck et al. (2006) and van Hemert & van Dishoeck (2008) provide their own fitted values of γj,EvD (up to an maximum AV = 3) for all species for which they also give tables of σj(λ).

6

All model results accounting for CT H2 formation shown in this paper assume A = 0.

7

The level population of the CO energy levels was computed up to J = 50.

10

We ignore deviations for CO because photo-dissociation of CO is treated separately in any PDR code (van Dishoeck & Black 1988).

Acknowledgments

This work was supported by the German Deutsche Forschungsgemeinschaft, DFG project number Os 177/1–1. R.S. acknowledges support partly from the Polish NCN grant 2011/01/B/ST9/02229. We acknowledge the use of the UDfA (a.k.a. UMIST) chemical reaction databases8. Some kinetic data we used were downloaded from the online database KIDA (KInetic Database for Astrochemistry9. We thank the anonymous referee for many remarks that significantly improved this paper. We would like to thank J. Weingartner for the calculation of the photoelectric heating rates and collisional cooling rates for the extended parameter range and for the helpful remarks on the calculation of the total heating rate.

References

Appendix A: Isotropic vs. non-isotropic scattering

thumbnail Fig. A.1

Left panel: mean intensity versus optical depth τ normalized to the incident specific intensity I0. The solid black curve shows the depth dependence of the mean intensity assuming dust parameters ω = 0.4, g = 0.7, approximately describing the WD01-7 dust sort. The dashed and dotted curves denote mean intensities using the same albedo ω, but assuming isotropic and pure forward-scattering, respectively. Right panel: absolute error  | log (Ji/I0) − log (Jk/I0) |  of assuming isotropic g = 0 and pure forward-scattering g = 1 with respect to more realistic values ω = 0.4, g = 0.7 (dashed and dotted lines, respectively).

Open with DEXTER

The MCDRT code assumes isotropic scattering, i.e., a mean scattering angle g =  ⟨ cosΘ ⟩  = 0 when calculating the frequency-dependent FUV radiative transfer. However, taking into account the detailed material properties and size distribution of interstellar dust results in different values of g. Reasonable values for interstellar dust in the FUV range fall around g ≈ 0.7 and ω ≈ 0.4 (Li & Draine 2001). In the following we show that even in this case of strong forward-scattering the isotropic scattering treatment poses a clear improvement compared to the pure forward-scattering cased used in our previous model.

To quantify the error we used the spherical harmonics method, presented by Flannery et al. (1980) to calculate the penetration of UV radiation of a spherical cloud. Applying their method, we calculated the attenuation of the mean intensity as a function of optical depth for a given asymmetry factor g and albedo ω. For more details on the method see also Roberge (1983), Le Petit et al. (2006), Goicoechea & Le Bourlot (2007).

In Fig. A.1, left panel, we plot the solution of the mean intensity for ω = 0.4, g = 0.7 normalized to the incident radiation field for a homogeneous spherical cloud with an optical depth to the center τc = 20 (black curve). The dashed blue curve shows the solution for the same albedo, but for isotropic scattering. This represents the solution of the MCDRT code. The dotted red curve gives the result for pure forward-scattering, i.e., the case exp( − (1 − ω)τ). This is equivalent to the previous approximation in KOSMA-τ. The right panel shows the corresponding error when assuming isotropic or pure forward-scattering. It is apparent that the assumption of isotropic scattering is an improvement over our previous approach up to optical depths of about 16, only for very high τ the forward-scattering is the solution closer to the g = 0.7 case. However, the FUV influence at τ > 10 is negligible. Presently, we therefore sacrifice the dark cloud accuracy in favor of a more accurate description of the cloud surface, but in a future work we plan to update the MCDRT code to properly account for non-isotropic scattering.

Appendix B: Rescaling of photo-rates to account for different dust properties

thumbnail Fig. B.1

Wavelength dependence of the assumed UV illumination and the photo-dissociation cross sections. The thick black line shows the unshielded empty-space Draine FUV field, the dashed line shows an extension of the Draine field longward of 2000 Å suggested by van Dishoeck & Black (1982). The blue, green and red lines show the FUV radiation field inside the reference cloud at 95% Rtot for the WD01-7, WD01-21, and WD01-25 dust models, respectively. Left panel: the blue filled curve shows the continuum absorption cross section σcont of CH2 that leads to dissociation, the black dots with drop lines show the corresponding line absorption cross section σline. Right panel: same as left panel but for the SiH+ photo-dissociation cross sections.

Open with DEXTER

In the following we discuss the uncertainties of the proposed rescaling for different dust models D.

One important factor is the spectral shape of the assumed FUV radiation field. In Fig. B.1 we plot the photo-dissociation cross sections σ of two different molecules (CH2 in the left panel, SiH+ in the right panel) together with the FUV radiation field (thick black line: unshielded Draine field, colored lines: FUV field inside the clump at 95% of the total radius for the dust models WD01-7, 21, and 25). The total photo-dissociation cross section is calculated using Eq. (13). The different wavelength behavior of σ in the two panels demonstrates why the photo-dissociation rates of different species are attenuated differently when going deeper into the cloud. The right panel also emphasizes that the choice of the spectral shape of the illuminating FUV radiation field may influence the photo-dissociation rate of some species significantly; the choice between the two FUV fields results in an unshielded photo-dissociation rate difference of a factor two. However, differences in the attenuation behavior between different dust models will still be dominated by wavelengths shorter than 2000 Å because A(λ)/A(V) varies only weakly for λ > 3000   Å.

thumbnail Fig. B.2

Comparison of the explicitly integrated photo-dissociation rates of CH2 for the WD01-7, WD01-21, and WD01-25 dust models (circles, squares, triangles, respectively) and the corresponding fits to the rates according to Eq. (14). The different line styles denote fits up to different maximum visual extinctions (solid: AV,max = 3, dashed: AV,max = 10, dotted: AV,max = 15, and dot-dashed: AV,max = 20).

Open with DEXTER

Another uncertainty results from the choice of AV,max up to which the γj,fit from Eq. (14) is fitted to the values Γj(AV)/Γj(0). In Fig. B.2 we show the ΓCH2(AV)/ΓCH2(0) for three dust models: WD01-7, WD01-21, and WD01-25. The lines shows the corresponding fits for different AV,max. The range of is 1.92−2.24, 1.48−1.71, and 1.14−1.3 for the three dust models, equivalent to a 10−15% uncertainty. We calculated fits to for all available species and for all dust models to AV,max = 10.

The third source of uncertainties is the functional dependence used in the fit through Eq. (16). We performed least-squares fits to polynomials up to order 4 to derive a suitable scaling relation between the input parameters γj, describing the wavelength-dependent attenuation of the photo-dissociation rate of species j with AV, , describing the wavelength-dependent attenuation of the FUV radiation field depending on the dust model D, and the output parameter . Figure B.3 visualizes Eq. (16) (black grid) and the explicitly calculated fits (colored dots) for the 25 WD01 dust models for all species with available cross sections. The data points are colored according to their deviation from Eq. (16).

thumbnail Fig. B.3

Visualization of Eq. (16) (black grid) and the explicitly calculated fits (colored dots) for the 25 WD01 dust models for all species with available cross sections. The data points are colored according to their deviation from Eq. (16). Green and blue denotes deviations of less than 0.05 and 0.1. Red points signal deviations exceeding 0.1. All deviations are smaller than 0.22.

Open with DEXTER

Seven species, CH+, SH+, OH+, HCO+, CO, O2+, and SiO, deviate significantly from our Eq. (16) with residual  > 0.4. By shifting their γj to a corrected we are able to compensate for these deviations. Figure B.4 shows the fitted of the three strongest outliers and the corresponding from Eq. (16) using the original γj (dashed lines) and the corrected (solid lines).

The deviations of the seven outlying species are large compared to the rest of the 63 species that we calculated (compare Fig. B.3). In the following we will discuss the strongest outliers individually10.

HCO+

HCO+ showed the strongest maximum deviation of 1.12 from the plane defined by Eq. (16). UDfA gives γ = 2.0 referring to van Dishoeck et al. (2006) who give a value of γ = 3.32 in their Table 2. Unfortunately, all photo-dissociation rate coefficients from UDfA that refer to van Dishoeck et al. (2006) are inconsistent with their published numbers and should be replaced with more recent numbers. Their paper was still in preparation when Woodall et al. (2007) was published, so the mismatch is possibly due to pre-publication updates of the final values.

OH+

OH+ showed the second-strongest deviations of up to 0.8 from Eq. (16). It possesses a strong absorption continuum only for wavelengths shorter than 1100 Å so that extensions to the Draine FUV field at longer wavelengths should not affect the final photo-dissociation rate. However, computing the unshielded photo-dissociation rate coefficient α for a Draine field yields 1.27 × 10-11 s-1 , comparable to 1.1 × 10-11 s-1 from van Dishoeck et al. (2006), while UDfA lists 1 × 10-12 s-1. The reason for the mismatch is unclear, all sources refer to the same photo-dissociation cross section by Saxon & Liu (1986). We also find inconsistent values of γ published, between 1.8 and 3.5. We find a best fit to Eq. (16) with .

thumbnail Fig. B.4

Comparison of the for the three strongest outliers CH+, OH+, and HCO+ and the corresponding scaling behavior of Eq. (16) using the original γj (dashed line) and the corrected .

Open with DEXTER

CH+

For CH+ deviations from Eq. (16) of up to 0.6 were found. Woodall et al. (2007) give α = 2.5 × 10-10 s-1 and γ = 2.5 referring to Roberge et al. (1991), van Dishoeck et al. (2006) give α = 3.3 × 10-10 s-1 and γ = 2.94 using cross sections from Kirby et al. (1980). We find and . At AV these lower values of γ lead to photo-dissociation rates 3 − 6 orders of magnitude stronger compared to rates calculated with the higher γ from above. The reason for the γ offsets is unclear.

SH+

SH+ has comparable values of α, and γ in UDfA and in van Dishoeck et al. (2006). Small differences in α can be attributed to a strong absorption line at 3100 Å, which leads to a stronger unshielded photo-dissociation rate when applying a 10 000 K black-body radiation field as used by Woodall et al. (2007). We find and . Differences of γ from the literature and our calculations most likely result from different assumed dust properties and fits to lower maximum AV,max.

SiO and O

Both molecules show maximum deviations of 0.4 from Eq. (16). The unshielded SiO rate coefficients from UDfA and van Dishoeck et al. (2006) differ by a factor 16 (see comment on HCO+) while their γj are the same.

In Fig. B.5 we show a histogram of the residuals after removing the outlying species. The standard deviation is σ = 0.05, the maximum absolute residual is 0.22. Photo-dissociation cross sections are available for a number of species that are not yet included in UDfA (van Hemert & van Dishoeck 2008). In Table B.1 we give α and γ from http://home.strw.leidenuniv.nl/~ewine/photo as well as our .

thumbnail Fig. B.5

Histogram of the residuals after removing outliers.

Open with DEXTER

Table B.1

R ate coefficients and corrected for species not included in UDfA. PI and PD denotes photo-ionization and photo-dissociation.

Appendix C: H2 formation rate

We followed the model of H2 formation on interstellar dust grains via physisorption and chemisorption from Cazaux & Tielens (Cazaux & Tielens 2002, 2004, 2010).

For a given dust type, the total H2 formation rate is given by Eq. (19) (omitting the subscript index i in the following) where the formation efficiency is given by Eq. (22): (C.1)We set (μF)/(2βH2) to zero to make sure that newly formed H2 molecules are able to leave very cold dust surfaces, equivalent to Eq. (13) in Cazaux & Tielens (2002). We can approximate ξ and βHP/αPC by (C.2)(C.3)Equation (C.3) takes into account the corrections from Cazaux & Tielens (2010). Table C.1 gives the applied model parameters for silicate and graphite surfaces.

Table C.1

Model parameter for silicate and graphite surfaces.

Appendix D: Photoelectric heating rates

Weingartner & Draine (2001a) showed that the photoelectric heating rate for the WD01 grain size distributions is fairly well reproduced by the parametrization (D.1)with , where T is the gas temperature in Kelvins and ψ is in units of K1/2 cm3, and G = 1.71χ. Numerical values for the parameters Ci in Eq. (D.1) are given in Table 2 in Weingartner & Draine (2001a) for each dust distribution. The rate of cooling due to charged particle collisions can be approximated by (D.2)where . Values for the Di for all WD01 grain distributions are given in Table 3 in Weingartner & Draine (2001a).

thumbnail Fig. D.1

Fit results to the photoelectric heating rate, calculated for an extended range of . The different lines show results for gas temperatures 100 K, 1000 K, and 10 000 K. Γpc is given in units of 10-26   erg   s-1.

Open with DEXTER

thumbnail Fig. D.2

Fit result to the net cooling rate due to collisions with charged particles, calculated for an extended range of . The different lines show results for gas temperatures 100 K, 1000 K, and 10 000 K. Γpc is given in units of 10-26   erg   s-1.

Open with DEXTER

Table D.1

Photoelectric heating parameters (Eq. (25)).

Table D.2

Collisional cooling parameters (Eq. (26)).

Equations (D.1) and (D.2) are fairly accurate when 103   K ≤ T ≤ 104 K and 102   K1/2   cm3 ≤ ψ ≤ 106   K1/2   cm3. However, the parameter range in PDR models allows ψ to reach values as high as 109   K1/2   cm3 and as low as 10-2   K1/2   cm3. Weingartner (2009) provided updated calculations of Γpc and Λgr for the dust distributions WD01-7, WD01-21, and WD01-25 up to ψ = 109   K1/2   cm3.

We performed numerical fits to the updated photoelectric heating rates and to the cooling rate due to collisions with charged particles according to the parametrizations 25 and 26. The heating and cooling rates have been calculated by Weingartner (2009) with an extended parameter range of 10-2   K1/2   cm3 ≤ ψ ≤ 109   K1/2   cm3. The details of the computation are described in Weingartner & Draine (2001a). To achieve a good fit over the full extended parameter range it was necessary to modify the algebraic form of the parametrizations relative to its original form in Weingartner & Draine (2001a). The final form is given in Eqs. (25) and (26). In Figs. D.1 and D.2 we show the fits to calculations of Γpc and Λgr for gas temperatures of 100 K, 1000 K and 10 000 K to demonstrate the quality of the parametrization. The Ci and Di parameters are given in Tables D.1 and D.2 and will provide a fairly accurate reproduction of the total photoelectric heating rate Γtot between 10   K ≤ T ≤ 10   000 K and 10-2   K1/2   cm3 ≤ ψ ≤ 109   K1/2   cm3.

All Tables

Table 1

Dust model parametrization of all WD01 dust models.

Table 2

Fit parameters in Eq. (16).

Table 3

Corrected for the outlying species.

Table 4

Parameter of the WD01 and MRN dust models.

Table 5

Line emission Idv for the three models shown in Fig. 25.

Table B.1

R ate coefficients and corrected for species not included in UDfA. PI and PD denotes photo-ionization and photo-dissociation.

Table C.1

Model parameter for silicate and graphite surfaces.

Table D.1

Photoelectric heating parameters (Eq. (25)).

Table D.2

Collisional cooling parameters (Eq. (26)).

All Figures

thumbnail Fig. 1

Extinction cross section per H nucleus for the WD01-7 dust model (dashed lines) and for the MRN model (solid lines). The total cross sections are represented by thick lines. The contribution from each dust component is shown by red lines for silicates, blue lines for graphite, and green lines for very small grains.

Open with DEXTER
In the text
thumbnail Fig. 2

Relative extinction for the dust models of MRN (solid) , WD01-7 (long-dashed; red in electronic version); WD01-21 (short-dashed; green in the electronic version) and WD01-25 (dot-dot-dashed; blue in the electronic version) of interstellar dust. The vertical dotted lines at wavelengths of 912 and 2066 Å, corresponding to 13.6 and 6 eV, show the range of averaging. The horizontal lines show kFUV for the considered models.

Open with DEXTER
In the text
thumbnail Fig. 3

Mean intensity Jλ(r) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The lines show Jλ(r) for radii in steps of 10% of Rtot.

Open with DEXTER
In the text
thumbnail Fig. 4

Mean intensity of the UV radiation vs. cloud depth. The black line corresponds to the old KOSMA-τ result for pure absorption. The blue line corresponds to the MCDRT result for an MRN distribution with full treatment of scattering and absorption. The dashed line is the result for an MRN distribution with the albedo artificially set to zero.

Open with DEXTER
In the text
thumbnail Fig. 5

Mean intensity of the UV radiation J(r) scaled to the unshielded (empty space) Draine field χ0 vs. cloud depth. Different lines denote different dust compositions.

Open with DEXTER
In the text
thumbnail Fig. 6

Fit results for for HCO (black), CH2 (red), CN (green), and N2 (blue) for all dust models from Weingartner & Draine (2001b,their Table 1). The abscissa gives the number of the dust model. The large points show the original values of γj for the respective molecules.

Open with DEXTER
In the text
thumbnail Fig. 7

Comparison of explicitly fitted for HCO (black), CH2 (red), CN (green), and N2 (blue) for all dust models from Weingartner & Draine (2001b,their Table 1) with scaling relationship Eq. (16). The large points show the original values of γj from UDfA, the open diamonds show the values calculated using an MRN dust model, and the open squares denote the explicitly calculated values assuming .

Open with DEXTER
In the text
thumbnail Fig. 8

Dust temperatures of silicate grains for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different grain sizes.

Open with DEXTER
In the text
thumbnail Fig. 9

Dust temperatures of carbonaceous grains for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different grain sizes.

Open with DEXTER
In the text
thumbnail Fig. 10

Dust temperatures of neutral PAHs for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000 using the WD01-7 dust model. The different lines denote different PAH sizes.

Open with DEXTER
In the text
thumbnail Fig. 11

Grain temperature for the components of the MRN and WD01-07 dust models as a function of the radius ai in nm. The grain temperatures are calculated at the surface of a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust components. Dashed lines show the MRN components and solid lines show the WD01-07 components.

Open with DEXTER
In the text
thumbnail Fig. 12

Mean dust temperature for the WD01-7 dust model for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote the average temperature of the individual dust components. The black line shows the overall mean dust temperature.

Open with DEXTER
In the text
thumbnail Fig. 13

Mean dust temperature as a function of Av for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust compositions.

Open with DEXTER
In the text
thumbnail Fig. 14

H2 formation efficiency for carbon and silicate surfaces. A and B denote the temperature regimes of the corresponding terms in Eq. (22). The dash-dotted line denotes the standard formation efficiency given by Hollenbach & McKee (1979).

Open with DEXTER
In the text
thumbnail Fig. 15

H2 formation rate RH2 as a function of dust temperature Td for different formation models and dust compositions. The gas temperature Tg is set to 50 K. The dashed lines indicate the-low temperature formation in the original CT formation rates with A ≠ 0. SD89 is the formation rate from Sternberg & Dalgarno (1989).

Open with DEXTER
In the text
thumbnail Fig. 16

H2 formation rate RH2 as a function of dust temperature Td for different dust compositions. The gas temperature Tg is set to 50 K. The dashed lines show the formation rate with suppressed H2 formation on PAHs. The solid lines show the formation rate allowing for H2 formation on PAH surfaces.

Open with DEXTER
In the text
thumbnail Fig. 17

H2 formation heating rate for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models have been computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 18

Photoelectric heating rate for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different dust compositions. Models with an MRN dust composition apply the PE heating efficiency as given by Bakes & Tielens (1994). Dotted lines indicate a shift from heating to cooling because of Λgr > Γpc.

Open with DEXTER
In the text
thumbnail Fig. 19

Gas temperature Tg for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. Left panel: the different lines denote different dust models that affect the FUV radiative transfer and the PE heating. All models in the left panel werecalculated using the SD89 H2 formation. Right panel: the different lines show the effect of different H2 formation treatment. All models in the right panel were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 20

H and H2 abundances for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines denote different treatments of the H2 formation. The solid line shows a model using the standard H2 formation rate as given by Sternberg & Dalgarno (1989). The dashed and dotted lines show model results for H2 formation according to CT where the formation on PAH surfaces is switched on and off, respectively. All three models assume a WD01-7 dust distribution. The green dash-dotted line assumes an MRN dust model and uses the CT H2 formation.

Open with DEXTER
In the text
thumbnail Fig. 21

CO and C+ abundances for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. Left panel: the different lines denote different dust models that affect the FUV radiative transfer and the PE heating. All models in the left panel have been calculated using the SD89 H2 formation. Right panel: the different lines show the effect of different H2 formation treatment. All models in the right panel have been computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 22

Total line integrated clump-averaged intensities of 12CO transitions for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 23

CH and CH+ abundances (left) and column densities (right) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 24

OH and OH+ abundances (left) and column densities (right) for a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The different lines show the effect of different H2 formation treatment. All models were computed using the WD01-7 dust properties regarding the radiative transfer and the PE heating.

Open with DEXTER
In the text
thumbnail Fig. 25

Full continuum and spectral line flux emitted by a model clump of M = 10 M, n = 105 cm-3, and χ = 1000. The two panels show the results for different dust models. Top: WD01-7 dust model, equivalent to a RV = 3.1. This is the dust model with the largest grain surface contributing to the heating. Bottom: MRN dust mode. This is a dust model with a slightly smaller grain surface compared to WD01-7. The PE heating was calculated according to Bakes & Tielens (1994).

Open with DEXTER
In the text
thumbnail Fig. A.1

Left panel: mean intensity versus optical depth τ normalized to the incident specific intensity I0. The solid black curve shows the depth dependence of the mean intensity assuming dust parameters ω = 0.4, g = 0.7, approximately describing the WD01-7 dust sort. The dashed and dotted curves denote mean intensities using the same albedo ω, but assuming isotropic and pure forward-scattering, respectively. Right panel: absolute error  | log (Ji/I0) − log (Jk/I0) |  of assuming isotropic g = 0 and pure forward-scattering g = 1 with respect to more realistic values ω = 0.4, g = 0.7 (dashed and dotted lines, respectively).

Open with DEXTER
In the text
thumbnail Fig. B.1

Wavelength dependence of the assumed UV illumination and the photo-dissociation cross sections. The thick black line shows the unshielded empty-space Draine FUV field, the dashed line shows an extension of the Draine field longward of 2000 Å suggested by van Dishoeck & Black (1982). The blue, green and red lines show the FUV radiation field inside the reference cloud at 95% Rtot for the WD01-7, WD01-21, and WD01-25 dust models, respectively. Left panel: the blue filled curve shows the continuum absorption cross section σcont of CH2 that leads to dissociation, the black dots with drop lines show the corresponding line absorption cross section σline. Right panel: same as left panel but for the SiH+ photo-dissociation cross sections.

Open with DEXTER
In the text
thumbnail Fig. B.2

Comparison of the explicitly integrated photo-dissociation rates of CH2 for the WD01-7, WD01-21, and WD01-25 dust models (circles, squares, triangles, respectively) and the corresponding fits to the rates according to Eq. (14). The different line styles denote fits up to different maximum visual extinctions (solid: AV,max = 3, dashed: AV,max = 10, dotted: AV,max = 15, and dot-dashed: AV,max = 20).

Open with DEXTER
In the text
thumbnail Fig. B.3

Visualization of Eq. (16) (black grid) and the explicitly calculated fits (colored dots) for the 25 WD01 dust models for all species with available cross sections. The data points are colored according to their deviation from Eq. (16). Green and blue denotes deviations of less than 0.05 and 0.1. Red points signal deviations exceeding 0.1. All deviations are smaller than 0.22.

Open with DEXTER
In the text
thumbnail Fig. B.4

Comparison of the for the three strongest outliers CH+, OH+, and HCO+ and the corresponding scaling behavior of Eq. (16) using the original γj (dashed line) and the corrected .

Open with DEXTER
In the text
thumbnail Fig. B.5

Histogram of the residuals after removing outliers.

Open with DEXTER
In the text
thumbnail Fig. D.1

Fit results to the photoelectric heating rate, calculated for an extended range of . The different lines show results for gas temperatures 100 K, 1000 K, and 10 000 K. Γpc is given in units of 10-26   erg   s-1.

Open with DEXTER
In the text
thumbnail Fig. D.2

Fit result to the net cooling rate due to collisions with charged particles, calculated for an extended range of . The different lines show results for gas temperatures 100 K, 1000 K, and 10 000 K. Γpc is given in units of 10-26   erg   s-1.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
