The MUSE Hubble Ultra Deep Field Survey
Free Access
Issue
A&A
Volume 608, December 2017
The MUSE Hubble Ultra Deep Field Survey
Article Number A2
Number of page(s) 26
Section Extragalactic astronomy
DOI https://doi.org/10.1051/0004-6361/201731195
Published online 29 November 2017

© ESO, 2017

1. Introduction

The distance from an observer to a galaxy is nearly a prerequisite for any scientific study. Fundamental physical properties of galaxies (e.g., luminosity, star formation rate, and stellar masses) always include uncertainties from distance measurements. Ideally, precise redshifts are desired for all galaxies detected by imaging. Although the current technology cannot yet meet this demand, large efforts have been made to obtain spectroscopic data as efficiently as possible.

Large spectroscopic galaxy surveys have greatly enhanced our ability to explore the formation and evolution of galaxies by gathering a wealth of data sets of spectral features (emission lines, absorptions lines, and breaks), which in turn provide redshifts (e.g., York et al. 2000; Lilly et al. 2007; Newman et al. 2013; Le Fèvre et al. 2015). Multi-object spectroscopy (MOS) is the most widely used technique for simultaneously obtaining a large number of spectra over a wide area, but this technique requires preselection of the targets from imaging data and has difficulty with dense fields because of potential slit or fiber collisions (when only passing the field once). A magnitude cut is a typical selection method for a target sample. This process can exclude faint galaxies, including quiescent absorption line galaxies or dust attenuated red galaxies. Also, a relatively bright magnitude cut on the target sample and restrictions on slit positioning lead to sparse sky sampling and introduce low spectroscopic completeness, in particular toward higher density regions.

Another approach is photometric redshift (photo-z), which is derived by fitting multiple galaxy templates as a function of redshift to the observed photometry of a source. Although photo-z may be an alternative to redshifts from MOS observations, its error is typically Δz/ (1 + z) ~ 0.05 (e.g., Bonnett et al. 2016; Beck et al. 2017). This precision is inadequate for tasks such as finding (close) galaxy pairs, identifying overdensity regions, and studying (local) environmental effects.

An integral field unit (IFU) with a wide field of view (FoV), high sensitivity, wide wavelength coverage, and high spectral resolution can remedy some of these issues. The IFU yields spectroscopy for each individual pixel over the entire FoV, which means that every detected object in the field has a spectrum. However, earlier generation IFUs had FoV sizes that were too restrictive, insufficient spectral resolution, or spatial sampling that was too low for spectral surveys.

The Multi Unit Spectroscopic Explorer (MUSE; Bacon et al. 2010), is an IFU on the Very Large Telescope (VLT) Yepun (UT4) of the European Southern Observatory (ESO). It is unique in having a large FoV (1′ × 1′), wide simultaneous wavelength coverage (4650–9300 Å), relatively high spectral resolution (R ~ 3000), and high throughput (35% end-to-end). The MUSE instrument has a wide range of applications for observing objects such as H ii regions, globular clusters, nearby galaxies, lensing cluster fields, quasars, and cosmological deep fields. Despite its universality, MUSE was originally designed and optimized for deep spectroscopic observations. One of its advantages is that it can deal with dense fields without making any target preselection, achieving a spatially homogeneous spectroscopic completeness and reducing the uncertainty in assigning a measured redshift to a photometric object (cf. Bacon et al. 2015; Brinchmann et al. 2017).

We have conducted deep cosmological surveys in the Hubble Ultra Deep Field (HUDF; Beckwith et al. 2006) with MUSE. This field has some of the deepest multiwavelength observations on the sky, from X-ray to radio. However, the previously known secure spectroscopic redshifts (spec-z) in the HUDF are limited to about only 2% of the detected galaxies (169 out of 9927 galaxies; Rafelski et al. 2015). The three-dimensional data of MUSE also facilitate blind identifications of previously unknown sources by searching for emission lines directly in the data cube (cf. Bacon et al. 2015). In addition to increasing the spectroscopic completeness in the HUDF with MUSE, the unique capabilities of MUSE have permitted some of the first detailed investigations of photo-z calibration of faint objects up to 30th magnitude (Brinchmann et al. 2017, hereafter Paper III), properties of a statistical sample of C iii] emitters (Maseda et al. 2017), spatially resolved stellar kinematics of intermediate redshift galaxies (Guérou et al. 2017), constraints on the faint-end slope of Lyman-α (Lyα) luminosity functions and its evolution (Drake et al. 2017), spatial extents of a large number of Lyα haloes (Leclercq et al. 2017), redshift dependence of the Lyα equivalent width and the UV continuum slope (Hashimoto et al. 2017), galactic winds in star-forming galaxies (Finley et al. 2017), evolution of the galaxy merger rate (Ventou et al. 2017), and analyses of the cosmic web (Gallego et al. 2017). In this paper, we report on the first set of redshift determinations in the two layered MUSE UDF fields with ~ 10 h and ~ 30 h integration times used for all of the studies above.

The paper is organized as follows: in Sect. 2, we explain our deep surveys, observations, and data reduction in brief. Then we describe the source and spectral extraction methods, procedure of the redshift determination, detected emission line flux measurements, and continuum flux measurements in Sect. 3. The resulting redshift distributions and global properties are shown in Sect. 4, followed by Sect. 5 in which we discuss success rates of the redshift measurements, emission line detected objects, comparisons with previous spec-z and photo-z, and color selections of high-z galaxies. Finally, the summary and conclusion are given in Sect. 6. Along with this paper, we release the redshift catalogs (see Appendix A). The magnitudes are given in the AB system throughout the paper.

2. Observations and data reduction

The detailed survey strategy, data reduction, and data quality assessments are presented in Bacon et al. (2017, hereafter Paper I). Here we provide a brief outline. As part of the MUSE Guaranteed Time Observing (GTO) program, we carried out deep surveys in the HUDF. There are two layers of different depths in overlapping areas: the 3′ × 3′ medium deep and 1′ × 1′ ultra deep fields. The medium deep field was observed at a position angle (PA) of −42deg with a 3′ × 3′ mosaic (udf-01 to udf-09), and thus it is named the mosaic. The ultra deep region (named udf-10) is located inside the mosaic with a PA of 0deg. We selected this field to maximize the overlap region with the ASPECS1 project (Walter et al. 2016).

The observations were conducted between September 2014 and February 2016. during eight GTO runs under clear nights, good seeing, and photometric conditions. The average seeing measured with the obtained data has a full width at the half maximum (FWHM) of ≈ 0.6′′ at 7750Å. The total integration time for the mosaic is ≈ 10 h for the entire field (9.92 sq. arcmin). The udf-10 was observed for ≈ 21 h (at a PA of 0deg), but the final product was added together with the overlap region of the mosaic to achieve ≈ 31 h.

The data reduction begins with the MUSE standard pipeline (Weilbacher et al. 2012). For each exposure, it uses the corresponding calibration files (flats, bias, arc lamps) to generate a pixtable (pixel table), which stores information of wavelength, photon count, and its variance at each pixel location. After performing astrometric and flux calibrations on the pixtable, a data cube is built. Then we implemented the following calibrations beyond the standard pipeline. The remaining low-level flat fielding was removed by self-calibration, artifacts were masked, and the sky background was subtracted. Finally, we combined the 227 individual data cubes to create the final data cube for the mosaic. For udf-10, 51 of the PA 0deg data cubes and 105 overlapping mosaic data cubes were used to make the final product.

The MUSE data cubes used for this work are version 0.42 for both the udf-10 and mosaic. The estimated 1σ surface brightness limits are 2.8 and 5.5 × 10-20 erg s-1 cm− 2 Å-1 arcsec-2 in the wavelength range of 7000–8500 Å (excluding regions of OH sky emission) for udf-10 and the mosaic, respectively. The 3σ emission line flux limits for a point-like source are 1.5 and 3.1 × 10-19 erg s-1 cm− 2 , respectively, at ~ 7000Å, where has no OH sky emission line.

3. Analysis

3.1. Source and spectral extractions

We performed two different source extractions in the MUSE Ultra Deep Field (UDF). One uses the HST detected sources from the UVUDF catalog2 (Rafelski et al. 2015) as the priors to extract continuum selected objects. The other searches for emission lines blindly (without prior information) in the cube directly. The details of the source detections in the MUSE UDF are discussed in Paper I. Here we briefly summarize the methods of the source detection and spectral extraction of the detected sources.

3.1.1. Continuum selected objects

Among all of the 9969 galaxies in the UVUDF catalog, 1095 and 7904 of these serve as the priors to extract objects in the udf-10 and mosaic survey fields, respectively. We performed the extraction at all of the HST source positions regardless of whether they are detected in the MUSE data cube. When the HST-detected galaxies are located within 0.6′′, which cannot be spatially resolved by our observations, they were merged and treated as a single object. We computed the new coordinates for a merged object via the HST F775W flux-weighted center of all objects composing the new merged source. We neither used their photometric measurements in this work nor reported the photometric measurements in the catalogs (see note (e) of Table A.1). In total, we acquired 854 and 6288 MUSE objects3 for the udf-10 and mosaic fields, respectively. Then we made a 5″ × 5″ subcube (or larger for extended objects) for each of the extracted objects so that they are easy to handle. For each object, we convolved its HST segmentation map (provided by the UVUDF catalog) with the MUSE point spread function (PSF) to construct a mask image to mask out emission from nearby objects.

For the purpose of redshift determination, while we used all of the extracted objects in udf-10, we only inspected the objects with F775W ≤ 27 mag (1147 MUSE objects) in the mosaic. This magnitude cut was selected after we completed the redshift analysis in udf-10. We discuss in detail how we decided to make the cut at this magnitude in Sect. 4.2.1.

3.1.2. Emission line selected objects

We also searched for emission lines directly in the data cubes to identify objects. We adopted the software ORIGIN (detectiOn and extRactIon of Galaxy emIssion liNes; Mary et al., in prep.) to perform blind detections.

The ORIGIN software uses a matched filter in three-dimensional data to detect signals by correlating with a set of spectral templates. It first uses a principal component analysis (PCA) to remove continuum emission. A matched filter is then applied to the continuum removed data cube and the P-value test is used to assign a detection probability to each emission line candidate. When the test gives a high probability, a narrowband image is created using the raw data cube to further test the significance of the line. The line is only considered to be a real detected line when it survives the narrowband image test. Finally, the spatial position of each detected line is estimated by spatial deconvolution. For more details on the procedures and parameters used for the detections in udf-10 and the mosaic, we refer to Paper I. In udf-10 and the mosaic, 306 and 1251 emission line objects were detected with ORIGIN, respectively.

In addition to ORIGIN, we also used the MUSELET software4 to test our blind search for line emitters in the Mosaic field. The MUSELET software is a SExtractor-based detection tool, which identifies line emission sources in continuum-subtracted narrowband images of a cube. The narrowband images are produced by collapsing (weighted average) the closest 5 wavelength planes (6.25 Å) and subtracting a median continuum from the closest 20 wavelength planes (25 Å) on each of the blue and red sides of the narrowband regions. By comparing the UVUDF sources and ORIGIN detections with the raw MUSELET catalogs of emission line sources in the mosaic, MUSELET only detects 60% of the objects which ORIGIN detects, but it finds 16 additional sources. The lower detection rate and small number of additional detections of MUSELET strengthens our choice of ORIGIN as the primary line detection software for the analyses of these fields. All of the sources detected only by MUSELET are also included in the analyses of this work and the released catalogs.

3.1.3. Spectral extractions

We adopted three different methods for spatially integrating the data cube to create one-dimensional spectral extractions: unweighted sum, white-light weighted, and PSF weighted. The unweighted sum is a simple summation of all of the flux in each wavelength slice over the mask region (the MUSE PSF convolved HST segmentation map). The white-light weighted spectrum is computed by giving a weight based on the flux in each spatial element of the MUSE white-light image, which is made by collapsing the MUSE data in the wavelength direction. For the PSF-weighted spectrum, the estimated PSF (as a function of wavelength) is used as the weight for the spectral extraction. Local residual background emission is then subtracted from the extracted spectrum. The local background region is defined by the area outside of the combined resampled HST segmentation maps of all of the prior sources in the 5″ × 5″ subcube. The global sky background emission has already been removed during the data reduction.

thumbnail Fig. 1

Redshift tool MARZ with some modifications for our redshift analysis. This tool reports the most likely redshift and the quality (QOP) by cross-correlating with input spectral templates. The redshift identifiers verify the suggested redshift or manually find a better redshift and provide its quality (indicated as CONFID in the catalogs). We also implement a feature to show images in the panel on the right.

Open with DEXTER

The weighted optimal extractions offer the advantage of reducing contamination from neighboring objects that are not covered by the mask. Although in many cases the weighted extractions provide a higher signal-to-noise ratio (S/N) in the extracted spectrum, they can be disadvantageous for objects whose emission line features are spatially extended or offset from the position of the white-light emission or the PSF. This characteristic is often seen in Lyα emitters (e.g., Wisotzki et al. 2016; Leclercq et al. 2017).

As the default for the redshift determination process, because we preferentially require spectra with a good S/N, we primarily use white-light and PSF weighted spectra, depending on the galaxy size found by SExtractor (Bertin & Arnouts 1996) in the HST F775W image reported in the UVUDF catalog. When the FWHM of an object is extended more than the average seeing, 0.7′′, the primary spectrum to inspect is white-light weighted. For the galaxies with FWHM< 0.7′′, the PSF-weighted spectrum is used. However, when necessary, redshift investigators can use any of the extracted spectra or a user-defined spectrum to investigate spectral features in depth. For some cases, a simple extraction in a small circular aperture (≈ 0.8′′ in diameter) is useful to confirm observed features.

3.2. Redshift determination

We adopted a semi-automatic method for the redshift identification. For the continuum selected galaxies, we used the redshift fitting software MARZ (Hinton et al. 2016). The redshift determination of MARZ is based on a modified version of the AUTOZ cross-correlation algorithm (Baldry et al. 2014). From a user-defined input list of spectral templates, it automatically finds the best-fit template to the input spectrum and determines the redshift. If the resulting redshift is not ideal, then the user can also update it interactively in the same window. We used the peak position of the most significant detected feature to define redshift, including Lyα. The Lyα peak emission may not represent the systemic redshift due to radiation transfer effects of the resonant Lyα line in bulk motion of neutral hydrogen gas (Hashimoto et al. 2013).

In addition to its original capabilities, we customized MARZ to match our needs. We added a panel to display HST images along with the UVUDF ID numbers and MUSE white-light images. The original MARZ already has a button for confidence level implemented (called the quality operator, QOP, in MARZ) and, in addition, we integrated TYPE and DEFECT buttons (see below for the description of these parameters). Instead of only inputting a one-dimensional spectrum, we can feed the subcube such that it can create narrowband images simultaneously when a redshift is selected or when certain emission/absorption features are selected in the spectrum. A screenshot of the customized MARZ is presented in Fig. 1.

The input spectral templates for MARZ are listed and explained in Appendix B. Some of the templates (Nos. 6−19) are made using the MUSE data. During the redshift identification process, no photometric redshift information is provided to the inspectors to avoid biases when we compare MUSE determined redshift against photometric redshift (Paper III). Instead, we display all of the existing HST UV to near-infrared images as supplemental information to the MUSE spectra. Although it is not yet implemented in our modified MARZ, we found that HST color images also help constrain spectroscopic redshifts and identify the corresponding object that is associated with the determined redshift.

For each of the determined redshifts, a confidence level (CONFID) from 3 to 1 is assigned:

  • 3:

    secure redshift, determined by multiple features;

  • 2:

    secure redshift, determined by a single feature;

  • 1:

    possible redshift, determined by a single feature whose spectral identification remains uncertain.

Although we identified emission and absorption features in the one-dimensional spectra, we employed narrowband images of the features to confirm the significance of the detections. The CONFID is assigned only when the identified features are seen in its narrowband images. The redshifts with CONFID of 2 or 3 are reliable, but if one is interested in using the redshifts with CONFID of 1, it is highly recommended to double check the spectrum and use it with care.

While measuring redshifts, we kept records of which feature is mainly used for the identification. This parameter is saved as the integer, TYPE, corresponding to

  • 0:

    star;

  • 1:

    nearby emission line object;

  • 2:

    [O ii] emitter;

  • 3:

    absorption line galaxy;

  • 4:

    C iii] emitter;

  • 5:

    [O iii] emitter;

  • 6:

    Lyα emitter;

  • 7:

    other types.

In general, the most prominent feature is used to define the type. We distinguished nearby galaxies (1) and [O ii] emitters (2) by a detection of Hα. Thanks to the relatively high spectral resolution of MUSE, it is possible to distinguish the [O ii] λλ3726,3729 and C iii] λλ1907,1909 doublet features based on their intrinsic separations at a certain redshift. It also helps to resolve the distinctive asymmetric profile of Lyα. We discuss this further in Sect. 4, but the majority of redshifts are determined by identifying the most prominent feature, the [O ii] and Lyα emission at low redshift (z< 1.5), and high redshift (z> 3), respectively. Galaxies are only classified as [O iii] emitters when [O iii] is more prominent than [O ii] in cases both are detected.

We also kept the information of the data quality with the parameter DEFECT. The default is DEFECT = 0, meaning no problem is found in the data. When DEFECT = 1, it indicates that there are some issues with the data, but the data are still usable. This flag is raised often owing to the object lying at the edge of the survey area. This may indicate that line fluxes of these sources are underestimated because they are truncated in the data. As long as a spectral feature can be identified, we are able to determine a redshift, but we cannot recover the total line fluxes beyond the edge of the survey area.

For each continuum detected object, at least three investigators independently assessed the redshift. For udf-10, because it is our reference field, we had six investigators look at all of the objects. For the mosaic, 1147 objects (F775W ≤ 27 mag, see Sect. 3.1.1) are divided equally for two groups with three investigators each. In the case of the emission line detected objects, two investigators individually determined redshift for all of these objects for both udf-10 and the mosaic. For both continuum and emission line detected objects, among each of the groups, any disagreements in their determinations of redshift, CONFID, TYPE, and DEFECT were consolidated to provide a single set of redshift results. With the consolidated results, we had at least one more person, who is not in the group, check all of the determined redshifts and related parameters to finalize the redshift assessment.

Then we refined the redshift by simultaneously fitting all of the detected emission lines and measure line fluxes using a spectral fitting software. This process is discussed in the next subsection.

3.3. Line flux measurements

For the redshift determination, the spectra utilized were primarily extracted based on either the white-light or PSF weighted extraction in order to optimize S/N. For the purpose of cataloging line fluxes, we alternatively used the unweighted summed spectra for all of the sources within each segmentation map5. This avoids possible biases introduced by the weighting scheme. It is also better when the spatial distribution of the line emission is more extended than the white-light emission or PSF. This is especially relevant for Lyα emission (cf. Wisotzki et al. 2016; Leclercq et al. 2017). However, this results in an increased scatter for faint emission lines.

For the detected emission lines with S/N> 3, the line flux and its uncertainty are provided along with the measured redshift in the released catalog (Appendix A). We used the spectral line fitting software PLATEFIT (Tremonti et al. 2004; Brinchmann et al. 2008) to simultaneously fit all of the emission lines falling within the spectral range. This tool first uses a set of model template spectra from Bruzual & Charlot (2003) with stellar spectra from MILES (Sánchez-Blázquez et al. 2006) to fit the continuum of the observed spectrum at a predefined redshift with strong emission lines masked. After subtracting the fitted continuum from the observed spectrum, a single Gaussian profile is fitted to each expected emission line in velocity space. The velocity offset (the velocity shift relative to the redshift of the galaxy) and velocity dispersion of all of the emission lines are tied to be the same. See Tremonti et al. (2004) for a more detailed description of the software.

The velocity offset is limited to vary within ± 300 km s-1. For emission line galaxies, we used the velocity offset output from PLATEFIT to refine the original (input) redshift. The calculation of the velocity offset includes Lyα when it is detected. The typical velocity offset is about 10 km s-1 on average. When the original redshift is obtained directly from MARZ’s cross-correlation, we do not expect the offset to be significant, but it can be larger when the redshift identifiers manually estimate the redshift.

As described above, PLATEFIT fits single Gaussian functions to the emission lines. However, this is not suitable for Lyα because it is often observed to have an asymmetric profile. Thus, we added a feature to the software to fit the complicated profile of Lyα. Instead of fitting Lyα with a single Gaussian function, we used a combination of multiple Gaussian functions (up to 21, although typically much fewer are used) at fixed relative positions to fit the Lyα profile. We placed a central component Gaussian function at the position of Lyα as determined by the single Gaussian fitting carried out in the previous step. We placed an additional 10 components on either side of this, at a constant spacing of 120 km s-1 to be consistent with the spectral resolution of the data. As such the fitting covers a velocity range of ±1200 km s-1 from the expected position of the line.

We then performed the minimization via a nonlinear least squares method. During this process, the fluxes of each Gaussian component are allowed to vary independently (with most falling to 0 as they lie in the spectrum where Lyα has no emission) until the aggregate of all components best matches the observed spectrum. The separation between each component is kept constant (in velocity) but the wavelength of the central component is allowed to shift (±300 km s-1, consistent with fits for other lines). This allows for the fitting to correct for small discrepancies in the central position determined during the multiple Gaussian component fitting so that it produces a more accurate fit to Lyα. The widths of individual Gaussian components are forced to be the same but the width itself is a free parameter. The PLATEFIT tool places a limit of <500 km s-1 for each line width, but in general the Gaussian components only vary slightly from the initial guess of 70 km s-1 and fall between 60 and 120 km s-1. Allowing the widths of the components to vary in this way produces a better fit to the data in a few cases, compared to running the fitting with a single fixed width for all of the components. However, the improvement is much less significant than that obtained by allowing the central velocity of the components to shift.

After the fitting, we studied the output spectrum of the complex fitted regions and identified individual complex “lines” (a composite of multiple Gaussian components) by searching the fit spectrum for local maxima. The routine then scans out from each maxima on either side of the peak until it identifies a local minimum or the fitted spectrum returns to 0. The flux of each complex line is then calculated along with its associated error and fitted “lines” with a S/N of less than 3 are dropped. This S/N cut successfully avoids overfitting the noise and removes unphysical fits (such as more than two components or very broad components) in most cases. The properties of the remaining lines are then calculated directly from the fitted spectrum using a model independent approach. Errors are determined using a Monte Carlo method by modifying the input spectrum with random values within the associated errors at each point 100 times. Each line property is then re-extracted for each realization and the standard deviation of these values is given as the error. An example of the complex fitting is presented in Fig. 2.

thumbnail Fig. 2

Demonstration of the complex fitting for a Lyα emission line presenting blue and red bumps. The fitting is performed on a simulated spectrum (black line) to better illustrate the procedure (the flux is in arbitrarily units). In the real data, the final fit is usually comprised of fewer components. The dashed red lines are the individual Gaussian components and the solid blue line is the total of these components (the final fit). The vertical green dashed lines indicate the local minima. We use the Lyα peak position to measure the redshift (see Sect. 3.2).

Open with DEXTER

3.4. Continuum flux measurements

Throughout the paper, we used the continuum fluxes from the HST observations provided in the UVUDF catalog. In addition to that, we measured our own continuum fluxes for the objects that are not in the UVUDF catalog but are identified by directly detecting their emission line features with ORIGIN and MUSELET (see Sect. 3.1.2). For these objects, we performed our own photometric measurements on the HST images to obtain segmentation maps and continuum fluxes or upper limits. A full analysis of why these objects are not in the UVUDF catalog and our method of extracting their broadband properties are described in Paper I. Here we provide a brief summary.

Among 160 objects that are only found by ORIGIN/MUSELET, roughly one-quarter have very low or no continuum emission, and thus they are hardly detectable in any broadband images. The rest of the objects can be visually identified in the images, but they are not detected by SExtractor6 (Bertin & Arnouts 1996). In order to measure continuum fluxes (or upper limits) of these objects, we used NoiseChisel7, which is an image analysis software employing a noise-based detection concept (Akhlaghi & Ichikawa 2015). It is run independently on each of the HST images and the largest (from all the filters) object closer than 0.30″ to the position reported by ORIGIN/MUSELET is taken as representing the pixels associated with it to create a segmentation map for each object. We are able to associate a NoiseChisel segmentation map for 76% of the objects only found by ORIGIN/MUSELET. However, for the rest of the objects, no NoiseChisel segmentation map (in any of the HST broadband images) can be found within 0.30″. For these objects, a 0.50″ diameter circular aperture was placed on the position reported by ORIGIN/MUSELET.

The broadband magnitude is found by feeding the image of each filter and the final segmentation map into MakeCatalog, which takes output of NoiseChisel as input to directly create a catalog. The error in magnitude for each segment is derived from the S/N relation: σM = 2.5 / (S/N × ln(10)) (see Eq. (3) in Akhlaghi & Ichikawa 2015). MakeCatalog produces upper limit magnitudes for each object, by randomly positioning its segment in 200 different blank positions over each broadband image and using 3σ of the standard deviation of the resulting distribution. If the derived magnitude for an object in a filter is fainter than this upper limit, the upper limit magnitude is used instead.

4. Results

4.1. Redshift determination in the MUSE Ultra Deep Field (udf-10)

In this subsection, first we report the measured redshift and the parameters associated with it in our reference field, the MUSE Ultra Deep Field (udf-10). In addition to being the deepest spectroscopic field so far observed with MUSE, all of the extracted MUSE spectra in this field have been visually inspected. In the udf-10 field, as discussed in Sect. 3, we used two different procedures to extract the sources. Their redshifts were determined independently first, and then reconciled. Here we first present the basic properties of the objects associated with their redshift measurements for each extraction method independently. Based on our understanding of the differences and the relationship between the two source extraction methods and the redshift properties, we tried to find the best combination of these two methods to efficiently maximize the detection rate of redshifts in the even larger sample size of the MUSE Deep Field (the mosaic).

4.1.1. Redshifts of the continuum selected objects

Among 854 continuum selected objects in the MUSE Ultra Deep Field (udf-10), we successfully measured the redshifts of 282 objects in the redshift range from z = 0.21 to 6.64. The number of redshifts with confidence level 2 is 223.

thumbnail Fig. 3

MUSE redshift distributions of the objects extracted with the HST continuum-detected priors (filled bars) and the direct line emission searches (ORIGIN; filled and faded color bars on the right in each bin) in the MUSE Ultra Deep Field (udf-10). All of the extracted sources are shown without removing overlaps between the extraction methods. Left: redshift histogram in bins of Δz = 0.35. The red, blue, and gray represent the confidence levels 3, 2, and 1, respectively, for the determined redshifts. The filled dots show the percentage difference relative to the total of HST prior and ORIGIN MUSE-z distributions. Middle: same redshift distribution as the left panel, but color coded by the classified type of the objects. Right: histogram of the classified type of the objects color coded by the redshift confidence levels.

Open with DEXTER

In the left two panels of Fig. 3, we show the distributions of redshifts found with the MUSE data. Because most of the objects at 0 <z< 1.5 are usually identified by the [O ii] doublet, their CONFID is mostly 3 by definition when the double peaks are resolved and clearly seen. There are six cases in which CONFID is 2 in this redshift range, whose spectra in general have lower S/Ns but the features are obviously detected in narrowband images.

On the other hand, galaxies at z> 3 are often found by a single feature Lyα, which gives CONFID of 2. For the case of CONFID = 3 at z> 3, the C iii] emission or UV absorption features, and in some rare cases He ii, are also discerned. The number of determined redshifts drops significantly at 1.5 ≲ z ≲ 3.0. This is a well-known “redshift desert”, where [O ii] shifts out from the red end of the spectral coverage, although Lyα is still too blue to be detected. With the deep data, we are able to recover some of the redshifts in this range by detecting C iii] emission and some absorption features (e.g., Fe ii).

There are also 59 redshifts with CONFID = 1. Their redshifts are difficult to determine with confidence, because in most cases, it is ambiguous to use their line profile to specify the feature (e.g., [O ii] versus Lyα). For [O ii] emitter at 0.25 <z< 0.85, Hβ and [O iii] are in general also available, but they lie in a sky line crowded region, which can sometimes prevent further constraint on the measured redshift to give a higher CONFID.

4.1.2. Redshifts of the emission line selected objects

Of the 306 emission line selected objects (objects detected with ORIGIN regardless of whether they have UVUDF counterparts), 154 objects have secure redshift measurements with CONFID of 2 or 3 in the redshift range of 0.28–6.64. When we include the CONFID = 1 redshifts, the resulting number of measured redshifts is 160. Since we have to actually detect the emission features to select this sample, it is expected that the number fraction of CONFID = 1 redshifts is much smaller for the emission line selected objects compared with the continuum selected objects. A crucial difference between the continuum and line emission selected objects is that the former are extracted regardless of whether they are detected with MUSE or not, but the latter requires actual line detections.

The redshift distributions of the emission line objects are shown as the faded color bars (on the right in each bin) in Fig. 3. Similar to the continuum selected objects, the majority of the redshifts at z< 3 have CONFID = 3, while mostly CONFID = 2 at z> 3, because of the detectable spectral features. The main features that ORIGIN detects to facilitate the redshift identifications are [O ii], Lyα, and C iii]. The lack of redshifts in this range is more significant for the emission line selected objects because by nature ORIGIN does not have the ability to find any absorption galaxies.

4.1.3. Redshift comparisons between the continuum and emission line selected objects

When we only consider the secure redshifts (CONFID ≥ 2), the derived redshifts of both the continuum and emission line selected galaxies cover a similar range, from z = 0.2 to 6.7. A large difference is the numbers of identified redshifts between these two data sets. The continuum selected galaxies have 223 secure redshifts, while the emission line selected galaxies have 154. If we consider that of these 154 objects, 30 do not have a continuum detection (not in the prior list), the difference is even larger.

In the left panel of Fig. 3, the percentage difference of the numbers of determined MUSE redshifts between the two extraction methods (HST prior or ORIGIN) is shown with the filled dots. The ORIGIN method is optimized to detect compact emission line objects with faint continuum, such that it is more sensitive to the detection of high-z emission lines. This method misses 44% of the [O ii] emitters identified in the continuum selected galaxies. For the Lyα emitters, 38% of the continuum detected sample are not found by ORIGIN. There is no obvious trend of the fraction of missed [O ii] or Lyα with redshift (Fig. 4). There is no trend found with line surface brightness either.

At 1.5 <z< 3, the number of confirmed redshifts is smaller for the emission line selected galaxies because in this redshift range we mostly rely on galaxies with absorption features to find their redshifts in addition to C iii]. The ORIGIN method is not designed to detect absorption features, and thus it is not able to detect any of these objects. While the other feature, C iii], is in emission, it is fairly weak, which makes it harder for ORIGIN to detect. As shown in Fig. 4, line fluxes of the C iii] emission not detected by ORIGIN are at the low end of the line fluxes. Although it is possible to tune ORIGIN to detect fainter emission features in the cube, it also dramatically increases the number of spurious detections.

thumbnail Fig. 4

Line fluxes of [O ii] λλ3726,3729 (the red circles), C iii] λλ1907,1909 (the blue squares), and Lyα (the green diamonds) of the redshift-identified galaxies in udf-10 (CONFID ≥ 2). The open and filled symbols are the HST continuum and emission line selected objects, respectively. The filled symbols with the black edge indicate that they are detected only by ORIGIN.

Open with DEXTER

thumbnail Fig. 5

Full MUSE spectrum and a zoomed-in portion of the [O ii], C iii], and Lyα detected wavelength region at the top of each panel, and the HST F775W, MUSE white-light, and narrowband images of each emission line in the bottom of each panel. The yellow contours in the images are the boundary of the UVUDF catalog segmentation for the object, but those in the MUSE white-light image are convolved with the MUSE beam size. The white boundaries indicate masked objects excluded from local sky residual estimates. The green cross indicates the central position of the extracted object. The ID numbers and measured redshift are indicated at the top of each panel. All of these redshifts are secure (CONFID = 2 or 3).

Open with DEXTER

4.1.4. Final redshifts for the MUSE Ultra Deep Field (udf-10)

We combined and compared the results from the independent measurements of the continuum and emission line selected objects to obtain the final redshifts. All of the determined redshifts are provided in the catalog (Appendix A). We show some example spectra and narrowband images of [O ii], C iii], and Lyα emitters, and an absorption line galaxy in Figs. 5 and 6.

We successfully measured 313 and 253 redshifts with CONFID ≥ 1 and 2, respectively, for the unique objects selected with the continuum or line emission (i.e., overlapping objects are removed). The final MUSE redshift distribution in udf-10 is shown in Fig. 7 and summarized in Tables 1 and 2. The shape of the histogram does not change compared with the individual redshift assessments (Fig. 3): two peaks at z ≈ 1 and z ≈ 3. The number of CONFID = 2 redshifts at z ≤ 1.5 is 69, at 1.5 <z ≤ 3 (redshift desert) it is 29, and at 3 <z ≤ 6.7 it is 155.

Table 1

Counts of determined redshifts for different source extractions in the MUSE Ultra Deep (udf-10), Deep field (mosaic), and the unique objects of udf-10 + the mosaic.

Table 2

Census of the objects in the MUSE Ultra Deep (udf-10) and Deep field (the mosaic) sorted by categories.

In Fig. 7, it is also immediately noticeable that beyond z = 3, the fraction of confirmed redshifts of the objects detected only by ORIGIN (the faded color regions) increases. By z ≈ 6, it reaches ≈ 50%. According to Fig. 4, the ORIGIN detections do not seem to favor any specific redshift ranges or line fluxes (except of course when the line flux is below its detection limit). Two [OII] emitters (CONFID ≥ 2) were only detected by ORIGIN: MUSE ID 6314 and 6315. The disturbed morphology of ID 6314 in the HST imaging likely accounts for the no detection with SExtractor. The other object, ID 6315, is blended with a nearby bright source and are difficult to separate using solely imaging data. For the 28 Lyα emitters identified only by ORIGIN, most of these sources have surface brightness continuum emission that is too low to be detected with SExtractor (we measured ≈ 30 mag with NoiseChisel) or are not visible by eye (Fig. 8), but there are a small number of cases that are missed in the UVUDF catalog because of blending or because they are lying close to nearby bright sources (ID 6313) and disturbed/complex morphology in the HST images (ID 6324). We emphasize that these 28 objects represent ~ 20% of Lyα emitters found in this work and they are in a small 1′ × 1′ area of the entire sky where the deepest HST data exist.

4.2. Redshift determination in the MUSE Deep Field (the mosaic)

4.2.1. Strategy based on the results in udf-10

Based on the redshift analysis in our deepest survey field udf-10, we tried to find the best combination of the two extraction methods to maximize the efficiency of redshift identifications. As shown in Fig. 9, for the objects with redshift determined, 85 out of 98 objects at z< 3 (CONFID ≥ 2), mostly [O ii] emitters, have F775W ≤ 27 mag (see also Fig. 10). While the majority at z> 3 are fainter than 27 mag, 106 out of 155 objects (70%) in this redshift range are detected by line emission directly in the data cube with ORIGIN. In addition, all of the absorption galaxies, which ORIGIN cannot detect, are brighter than 26.1 mag.

thumbnail Fig. 6

Full MUSE spectrum and a zoomed-in portion of the SiIV, SiII and CIV, and FeII absorption features. The HST F775W and the MUSE white-light images are shown on the right. The yellow contours in the images are the boundary of the UVUDF catalog segmentation for the object, but those in the MUSE white-light image are convolved with the MUSE beam size. The white boundaries indicate masked objects excluded from local sky residual estimates. The green cross indicates the central position of the extracted object. The ID number and measured redshift are indicated at the top.

Open with DEXTER

thumbnail Fig. 7

Final MUSE redshift distribution of the unique objects (i.e., overlapping objects are removed) combine both the continuum and emission line detected sources in the MUSE Ultra Deep Field (udf-10). Left: redshift histogram in bins of Δz = 0.35. The red, blue, and gray colors represent the confidence levels 3, 2, and 1, respectively, for the determined redshift. The objects only found by ORIGIN are indicated by the faded colors, whereas in Fig. 3all of the ORIGIN detected objects are shown. Middle: same redshift distribution as the left planel, but color coded by classified type of the objects. Right: histogram of the classified type of the objects color coded by the redshift confidence levels.

Open with DEXTER

We simulated expected [O ii] line fluxes to investigate the sudden reduction of [O ii] emitters fainter than 27 mag visible in Fig. 10. With the spectral energy distribution (SED) fitting code FAST8 (Kriek et al. 2009), we used all of the galaxies in the mosaic with photo-z (BPZ) of 0–1.5 provided in the UVUDF catalog to predict their [O ii] fluxes. With the simple assumption that all of the [O ii] emission originates from star formation, we can directly translate the star formation rates obtained from SED fits of the HST photometry into expected [O ii] fluxes. Then we correct the [O ii] fluxes for dust extinction using the median dust correction factor, which is derived for the galaxies that are detected with MUSE using the Balmer decrement. The modeled [O ii] fluxes decrease with the F775W magnitude. From the 3σ line flux detection limit of the mosaic, ≈ 3 × 10-19 erg s-1 cm-2, the fraction of detectable [O ii] emitters drastically decreases at F775W ≳ 27 mag. At 27 mag, we expect ≈ 80% of the [O ii] emitters to be detected, but it abruptly decreases to ≈ 20–50% between 27–28 mag. These numbers are likely to be upper limits because, for simplicity of the model, all galaxies are assumed to be star forming.

thumbnail Fig. 8

Example of an object that is not detected by continumm emission but found by ORIGIN. The full MUSE spectrum and zoomed-in part of the Lyα detected wavelength region are presented at the top. The HST F775W, MUSE white-light, and Lyα narrowband images are at the bottom.

Open with DEXTER

thumbnail Fig. 9

Magnitudes of HST F775W plotted against determined redshift (CONFID ≥ 2) for udf-10. The open and filled symbols represent the continuum (HST prior) and emission line (ORIGIN or MUSELET) extracted objects. The filled squares are the objects detected only with ORIGIN or MUSELET, and thus their F775W mags are upper limits. The horizontal dashed line indicates 27 mag where we make the cut to the continuum selected galaxies to perform the redshift determination in the mosaic field (see Sect. 4.2.1).

Open with DEXTER

Thus, we make a cut at F775W ≤ 27 mag to limit the number of the continuum selected objects based on the HST priors for which we need to perform the visual inspection on redshift determination. This reduces the total number of 6288 continuum selected objects to 1147 to be inspected. For the emission line selected objects, we do not apply any preselection and examine all of the 1251 spectra of the emission line detected objects.

In the near future, we plan to extend the redshift determination toward galaxies with F775W> 27 mag. At present, we only release the redshift measured in the F775W ≤ 27 mag continuum selected sample and all of the emission line selected sample as the first version of the MUSE UDF redshift catalog (Appendix A).

4.2.2. Redshifts in the mosaic

The process of the redshift evaluation in the mosaic follows the same procedure as udf-10. We inspected the continuum detected and emission line detected objects individually, and then reconciled these two objects to obtain the final redshifts.

The summary and distributions of the determined redshifts are shown in Tables 1 and 2 and Fig. 11. Out of the 1147 continuum selected objects (F775W ≤ 27 mag), redshifts of 714 and 636 objects are determined with confidence levels of 1 and 2, respectively. When we include the emission line selected objects, these numbers increase to 1439 and 1247. Among these, 1295 and 1133 objects, respectively, have detectable UVUDF counterparts.

thumbnail Fig. 10

Cumulative counts of secure redshifts in udf-10. The colors indicate different types with the same scheme as in Fig. 3.

Open with DEXTER

The fractions of the identified redshifts below and above z = 3 are different compared with those in udf-10. Out of 1247 redshifts with CONFID ≥ 2 in the mosaic, 52% (650) are at z ≤ 3 and 48% (597) are at 3 <z ≤ 6.7. Whereas, in udf-10, there are 39% (98) and 61% (155), respectively, out of 253 redshifts with CONFID ≥ 2. A larger percentage of Lyα emitters are detected in the deeper data of udf-10 than in the mosaic, whose integration times are about three times different. This trend stays the same, even when we only account for the continuum detected objects (i.e., excluding the objects detected only by ORIGIN and MUSELET): 56% (631) at z ≤ 3 and 44% (502) at z> 3 for the mosaic, and 43% (96) and 57% (127), respectively, for udf-10. In addition, a smaller fraction of redshifts (10%) is found in the “redshift desert” at 1.5 <z ≤ 3.0 compared with udf-10 (13%). These differences between the mosaic and udf-10, due to the depth of the data, are also implied by the higher fraction of CONFID = 2 redshifts at z< 3 in the mosaic. Interestingly, the deeper data of the udf-10 increase the number fraction of CONFID = 1 redshifts in the [O ii] emitters compared to the mosaic. Among all of the determined [O ii] and Lyα emitters, the CONFID = 1 redshift is 11% and 16% of the CONFID ≥ 2 redshift, respectively, for the mosaic, while it is 44% and 16%, respectively, for udf-10. This is possibly because with higher S/N spectra, it is easier to find more features. The depth of the data also affects the detection rate of the ORIGIN/MUSELET-only objects at z> 3. We do not see the same tendency as in udf-10, where the fraction of the determined redshifts of the ORIGIN/MUSELET-only objects to the continuum extracted objects increases with redshift. One nearby galaxy, 14 [O ii] emitters, and 99 Lyα emitters are found only by ORIGIN/MUSELET with CONFID ≥ 2 in the mosaic.

Thanks to the larger survey area of the mosaic, we find more rare objects than in udf-10. As an example, the one-dimensional spectrum of a quasar at z = 1.22 (MUSE ID 872 or UVUDF ID 23796) with prominent Mg ii emission is shown in Fig. 129. This spectrum also exhibits Fe ii and Mg ii absorption features. These features only appear in the spectrum when it is extracted within the quasar PSF and are likely to be due to an intervening absorber at z = 0.98 (cf. Rigby et al. 2002).

thumbnail Fig. 11

Same histograms as Fig. 7 but for the MUSE Deep Field (the mosaic).

Open with DEXTER

4.3. Redshift comparisons between the overlap region in MUSE Ultra Deep (udf-10) and Deep Field (the mosaic)

The mosaic redshift determination is performed independently from udf-10. In this subsection, we show direct comparisons of the measured redshifts and the associated parameters in the overlap region of these two fields.

In the overlapping part of the mosaic and udf-10 fields, all of the redshifts (regardless of CONFID) identified in the mosaic are also identified in udf-10 with the same CONFID or higher, except MUSE ID 275 and four objects detected only by ORIGIN or MUSELET (MUSE IDs 6432, 6447, 6865, and 7396). The redshift of ID 275 is measured to be z = 2.9 in both udf-10 and the mosaic, but CONFID are 1 and 2, respectively. This is because the object lies at the edge of the udf-10 field, which gives less confidence. The four objects detected only by emission lines found in the mosaic data cube (with CONFID ≥ 2) are missed by the ORIGIN run in udf-10.

Among 313 redshifts identified in udf-10, there are 13 redshifts that disagree with the redshifts identified in the mosaic by | Δz | > 0.01. For the object discussed above, MUSE ID 275, the redshift is measured to be z = 2.899 and 2.931 in udf-10 and the mosaic, respectively. Apart from this object, one (MUSE ID 6684) has the same CONFID of 2 and four (MUSE IDs 44, 49, 90, 127) have the same CONFID of 1 in both udf-10 and the mosaic, but all of the rest (MUSE IDs 64, 103, 718, 6335, 6339, 6676, 6686) have the high CONFID of 2 or 3 in the udf-10 whereas CONFID of 1 in the mosaic. Below, we analyze why the obtained redshifts have differences (CONFID is given in the parentheses):

With the same CONFID

  • 6684zudf-10 = 4.740 (2), zmosaic = 0.871 (2).

    A clear emission feature is detected in both udf-10 and the mosaic, but it is identified as Lyα in udf-10 and as [O ii] in the mosaic. This is because the line profile in the mosaic spectrum shows double peaks (due to lower S/N) whose separation matches that of [O ii] at z = 0.871. However, because this object is not detected in the UV imaging, it is more likely at higher redshift. Thus, we conclude that the feature is Lyα and its redshift should be 4.740 as determined in udf-10.

    thumbnail Fig. 12

    Full MUSE spectrum of a quasar at z = 1.22 detected with a broad, prominent Mg ii emission feature. An intervening absorber (Fe ii and Mg ii) at z = 0.98 is also detected. The cutout (7.6″ × 7.6″) for this object is larger than the standard 5″ × 5″.

    Open with DEXTER

  • 44zudf-10 = 1.610 (1), zmosaic = 1.436 (1).

    Both of the redshifts are from absorption features, but a set of multiple Fe ii absorption features are found in different wavelength regions. The CONFID for both of these redshifts are low.

  • 49zudf-10 = 1.864 (1), zmosaic = 1.578 (1).

    The Al iii and Fe ii absorptions are identified in udf-10, but a different set of absorptions are possibly seen in the mosaic. Owing to low S/N in the continua, they are both not certain.

  • 90zudf-10 = 0.734 (1), zmosaic = 2.389 (1).

    The same emission feature detected at 6465Å in udf-10 and the mosaic is identified as [O ii] and C iii], respectively. With the low S/N data, it is difficult to confidently distinguish whether it is [O ii] or C iii].

  • 127zudf-10 = 0.616 (1), zmosaic = 4.035 (1).

    This is an interesting case in which different sets of emission features are spotted in the udf-10 and mosaic spectra. In udf-10, emission features at 6025Å, 7855Å, and 8090Å are identified as [O ii], Hβ, and [O iii] 5007 at z = 0.616. In contrast, none of these features are identified in the mosaic, but an emission line is identified at 6120Å. This feature is attributed to Lyα. Reviewing the udf-10 spectrum, this feature is clearly detected. Thus, we think that there are probably two objects at z = 0.616 and z = 4.035 lying along the sightline. In the combined udf-10 and mosaic catalog, we use z = 0.616 for ID 127 and add a new object with ID 7582 for the Lyα emitter at z = 4.035.

    thumbnail Fig. 13

    Same histograms as Figs. 7 and 11, but for the combined redshifts of the unique objects from the MUSE Ultra Deep Field (udf-10) and MUSE Deep Field (the mosaic).

    Open with DEXTER

Higher CONFID in udf-10

  • 64zudf-10 = 1.847 (2), zmosaic = 1.566 (1).

    The C iii] doublet is well detected at 5430Å in udf-10. The mosaic redshift was measured by tentative absorption features. However, with a closer look, the same C iii] seen in udf-10 is weakly detected in the mosaic. Thus, the redshift of this object is likely to be 1.847 as measured in udf-10.

  • 103zudf-10 = 3.002 (3), zmosaic = 2.986 (1).

    A clear Lyα absorption detected in both udf-10 and the mosaic spectra. In udf-10, there are also multiple UV absorption lines. Taking into account that the features used to determine the redshift are absorption and very broad, | Δz | of 0.016 is not a significant difference. We use the udf-10 redshift as the final redshift.

  • 718zudf-10 = 4.524 (2), zmosaic = 0.801 (1).

    Similar to ID 6684, the spectrum of the mosaic is noisier than udf-10, which causes spurious double peaks of the identified emission feature. In the udf-10 spectrum, the feature shows a clear asymmetric profile with a red wing, indicating Lyα. Thus, the redshift should be 4.524 as in udf-10.

  • 6335zudf-10 = 4.370 (2), zmosaic = 1.098 (1).

    A clear emission feature is detected in udf-10 at 6525Å whose profile indicates Lyα, while the identified feature ([O ii]) in the mosaic is unclear. We do not see any obvious features around 6525Å in the mosaic spectrum. This is not surprising because the line flux is ≈ 1 × 10-18 erg s-1 cm-2, just around the 3σ detection limit of the mosaic.

  • 6339zudf-10 = 5.131 (2), zmosaic = 5.121 (1).

    The same emission feature is recognized as Lyα. It looks as if the detected Lyα has a blue bump (which is likely to be sky residual) in the mosaic. The blue bump is used to determine redshift, causing a redshift difference of 0.01. However, this blue bump is not visible in the deeper data of udf-10. Using z = 5.131 from udf-10 is reasonable.

  • 6676zudf-10 = 3.723 (2), zmosaic = 0.541 (1).

    The emission line clearly looks like Lyα in the udf-10 spectrum and the UV continuum emission is not detected. However, in the mosaic spectrum, although the same feature is identified, it is classified as [O ii]. Thus, the udf-10 redshift should be the correct one.

  • 6686zudf-10 = 0.307 (2), zmosaic = 4.383 (1).

    In the udf-10 spectrum, two emission features at 4875 and 6545Å correspond to [O ii] and [O iii] 5007, which gives z = 0.307. The former feature, in addition to not being convincing in udf-10, is not seen in the mosaic. The latter feature in the mosaic is recognized as Lyα because of its distinctive profile. This object is not detected up to the F435W band, which indicates that this object is likely to be at high redshift. Thus, the correct redshift is probably z = 4.383 measured in the mosaic.

These results suggest that it is not necessary true that the success rate of CONFID in the shallower mosaic region is lower when comparing the same CONFID. We only found one case (ID 6684) in which the redshift in the mosaic field is not correct when both of the redshifts are CONFID = 2. When both redshifts are CONFID = 1 (IDs 44, 49 90, 127), their redshifts are too uncertain to make a judgement for the quality.

Because of the shallower depth of the mosaic, not all of the redshifts measured in udf-10 are found in the mosaic. Excluding the objects only found by ORIGIN/MUSELET, the mosaic misses 118 out of 282 redshifts with CONFID ≥ 1 and 64 out of 223 with CONFID ≥ 2 (night [O ii] emitters, six absorption line galaxies, six C iii] emitters, and 43 Lyα emitters). We only visually inspected the spectra of galaxies with F775W ≤ 27 mag and for the rest we relied on ORIGIN (and MUSELET). Thus, a subset of these missing redshifts may be recovered if we actually look at the spectra or change the tuning of ORIGIN (and MUSELET). If we include the objects that have no UVUDF counterpart (i.e., detected only by ORIGIN/MUSELET), then these numbers increase to 133 and 78 for CONFID ≥ 1 and 2, respectively. The smaller number of ORIGIN/MUSELET detections in the overlap region in the mosaic can also be attributed to the depth of the data.

Together with this paper, we release both the udf-10 and mosaic redshift catalogs (Appendix A). As explained above, the ID numbers of the objects in the overlapping region are the same in udf-10 and the mosaic. In addition, we compiled a final redshift catalog combining the udf-10 and mosaic results. For the objects that have measurements from both of the catalogs, the information is from udf-10, unless there is a disagreement with the mosaic. For those cases, we adopted the redshifts discussed above. For the discussion below, we used the redshifts and the associated parameters from this combined catalog.

4.4. Final redshifts in the entire MUSE UDF survey region

In the entire MUSE UDF survey region (udf-10 + the mosaic), there are 7904 UVUDF sources that we used as priors to extract the continuum selected objects. As shown in Table 1, for 1206 (15%) of them, we successfully obtained secure redshifts (CONFID ≥ 2). As discussed above, some of the objects were merged because of the lower spatial resolution of MUSE than HST and we did not investigate a subset (F775W ≤ 27 mag in the mosaic where not overlapping with udf-10) of their spectra to determine redshifts. The direct searches of emission line objects enabled us to find 132 more redshifts in addition. Thus, in total, we obtained 1338 unique redshifts with high confidence (CONFID ≥ 2). The final redshift distribution is presented in Fig. 13. As a simple test, we compared the broadband (F775W) luminosity against the measured MUSE redshifts (CONFID ≥ 2) to check whether there are any catastrophic measured redshifts. This test does not show any extreme outliers.

We used the redshifts determined in both udf-10 and the mosaic to derive the distribution of redshift differences between these two catalogs. The standard deviation of the Δz/ (1 + z) distribution is 0.00017. Assuming that the errors are similar for the udf-10 and mosaic redshifts (i.e., assuming that the depth of the data is not a dominant factor for redshift errors), then we obtain a global estimate of the redshift/velocity uncertainty to be σz = 0.00012(1 + z) or σv ≈ 40 km s-1.

5. Discussion

5.1. Redshift measurement success rates

Assuming all of the determined redshifts are correct for CONFID ≥ 2, we calculated the success rates of the redshift measurements. Here we define the success rate as the number fraction of the obtained secure redshifts over the sample size we inspected. We only used the sample extracted with the HST priors for this calculation (i.e., the objects detected only by ORIGIN/MUSELET are excluded). In the mosaic, all galaxies with F775W> 27 mag are extracted by ORIGIN/MUSELET (or due to splitting; see Sect. 5.3). In other words, the success rates at F775W> 27 mag for the mosaic should be considered as lower limits.

thumbnail Fig. 14

Success rates of obtained secure redshifts are shown in the top panel for udf-10 (red) and mosaic (blue). The horizontal dashed line indicates 50% completeness. We only use the objects with HST counterparts in the UVUDF catalog in this plot (i.e., the objects detected only by ORIGIN/MUSELET are excluded). The middle and bottom panels show the counts of the total number of the HST objects (solid bars) and the MUSE redshift determined objects (hatched bars). The vertical dashed line in the bottom panel indicates the magnitude cut where we perform the redshift investigation on the continuum detected objects.

Open with DEXTER

In Fig. 14, the success rates of udf-10 and mosaic are plotted against the HST F775W magnitude. In udf-10, we successfully measured secure redshifts (CONFID ≥ 2) for all of the galaxies brighter than 25 mag. At the same magnitude, the success rate for the mosaic is 87%. The 100% success rate for the mosaic is at <22.5 mag (or 23.5 mag if we ignore one object MUSE ID 6934 without MUSE redshift in the 22.5–23.0 mag bin). The 50% completeness with respect to the HST F775W magnitude is reached at 26.5 and 25.5 mag, in udf-10 and the mosaic, respectively. The success rates decrease with the F775W magnitudes, in particular there is a sudden drop at ≈ 25 mag for both of the fields. However, the success rate remains greater than ≈ 20% at <28–29 mag in udf-10 and 27 mag in the mosaic. Except in the 25.0–25.5 mag bin, at all magnitudes, the udf-10 success rate is higher than the mosaic.

Another MUSE deep survey in the Hubble Deep Field South (HDFS; Bacon et al. 2015), whose coverage is also a single MUSE field of view as our udf-10 and has a similar depth (27 h), reaches the 50% completeness at 26 mag in the HST F814W band. The achieved slightly higher completeness in udf-10 is a natural consequence of the better line flux detection limit, which results from the improved data reduction and analysis compared to the HDFS data cubes (Bacon et al. 2015).

The spectroscopic completeness and comparisons with photometric redshifts are discussed in Paper III.

5.2. Objects only detected by ORIGIN or MUSELET

Owing to its wide FoV IFU with high sensitivity, MUSE enables direct detection of emission line objects with very faint continuum emission, which are improbable to target with slit spectroscopy and inefficient to find with narrowband imaging. In the entire 3′ × 3′ survey area, we discovered 132 emission line detected objects with confident redshifts which are not on the HST prior list. In the deepest region (1′ × 1′ area of udf-10), this number is 30. Among these 132 emission line objects, the majority are Lyα emitters (117). The rest are [O ii] emitters (14) and a nearby galaxy (1). Some of these objects in fact can be visually identified in the images but are blended10 (see Sect. 4.1.4). However, especially for the Lyα emitters, even when they can be visually identified, they have very low surface brightness or are not detected in the continuum. As mentioned in Sect. 3.4, we performed our own flux or upper limit measurements for these galaxies, but here we look into the most recent HST catalogs in more detail to investigate their properties.

Our prior list is based on the UVUDF catalog created by running ColorPro (a wrapper of SExtractor; Coe et al. 2006) with the detection image obtained by averaging four optical (F435W; F606W, F775W, F850LP) and four near-infrared (F105W, F125W, F140W, F160W) images (Rafelski et al. 2015). Except for the blended galaxies, the continuum of the MUSE emission line objects was still too faint to be originally detected in the combination of this deepest detection image.

We also checked if any of the emission line only objects are in the CANDELS11 GOODS-S multiwavelength catalog (Guo et al. 2013), and identified 52 objects (one nearby object, eight [O ii] emitters, and 43 Lyα emitters) that have potential counterparts within 1′′. This does not immediately mean that they are the actual corresponding objects because some ORIGIN/MUSELET detected objects are completely blended with known objects or happen to lie on the same sightline. We inspected these objects one by one and found one nearby galaxy, seven [O ii] emitters, and one Lyα emitter that exist in the CANDELS catalog. For this Lyα emitter (MUSE ID 6343 or CANDELS ID 15913), based on the prospective Lyα in its MUSE spectrum, its redshift is determined to be 5.5. However, its U magnitude is 28.5 mag in the CANDELS catalog, which is not probable for a high-z galaxy because of the Lyman break at 912 Å. It is more likely that this Lyα emitter happens to lie on the same line of sight as this galaxy. The template-fitting technique, TFIT (Laidler et al. 2007), is utilized for the CANDELS catalog. The TFIT tool uses spatial positions and morphologies in a high-resolution image as the priors to fit objects in lower resolution images. Until objects cannot be resolved in the high-resolution image, it can further perform deblending in the lower resolution images even when object separations are 1.5 times the PSF FWHM, which is the limit for SExtractor. Thus, some of these closely separated objects could not be deblended in the UVUDF catalog but were in CANDELS. In fact, the one [O ii] emitter (MUSE ID 6315) that is not in the CANDELS catalog is not resolved even with HST, and the 42 Lyα emitters are barely detected or not at all.

5.3. Blend and split of merged objects

During the redshift evaluation process, we found some cases in which we were able to split the merged MUSE objects (see Sect. 3.1.1). Comparisons between a detected emission line narrowband image and the HST image provide the spatial information of the corresponding HST counterpart of the emission line object. An example is shown in Fig. 15. The object shown in the MUSE white image (the middle panel) is originally extracted as a merged object, which corresponds to two HST-detected objects with UVUDF IDs of 8147 and 8118. While these two objects are clearly resolved in the HST F775W image (the left panel), they are not resolved in the MUSE white image (the middle panel). We managed to associate the determined redshift (based on Lyα) with one of the HST objects, UVUDF ID 8147, by creating a narrowband image of the detected Lyα at z = 3.67 (the right panel). Although we cannot fully deblend the MUSE emission because of the limited spatial resolution, we can assign individual MUSE ID numbers for these objects using their UVUDF coordinates (“split”). This Lyα emitter is given MUSE ID 6290 and the other is 6749. This process does not increase or decrease the number of objects whose redshifts are successfully reported as identified in the earlier sections, unless both (or multiple) of the split objects show clear features that can be used to determine redshift.

thumbnail Fig. 15

Stamp image of 5″ × 5″ centered at RA = 53.169458 and Dec = −27.778191. The HST F775W image (white-light, left panel), the MUSE λ-collapsed image (middle), and the continuum subtracted narrowband image created at λ = 5676Å with a width of 10Å (right). While it is not possible to resolve the two nearby HST objects (UVUDF IDs of 8147 and 8118) with the MUSE white-light image, the combination of the HST image with the narrowband image of the detected emission line (Lyα in this case) makes it possible to identify the origin of the emission (UVUDF ID 8147 corresponds to MUSE ID 6290 with z = 3.67).

Open with DEXTER

Although small in number, there are also cases in which multiple redshifts are found in a single merged object. The MUSE IDs of 6877 and 6878 are originally merged and treated as a single MUSE extracted object. However, clear detections of the [O ii] doublet, [O iii] λλ4959,5007, and several Balmer lines at z = 0.734 for ID 6877 and Lyα at z = 3.609 for ID 6878 allow us to assign confident redshifts for both of the objects in addition to splitting them (Fig. 16).

thumbnail Fig. 16

Spectra (extracted by PSF weighting) of MUSE IDs 6877 (z = 0.734) and 6878 (z = 3.609) at the top. The images shown at the bottom are HST F775W, MUSE white-light, and narrowband images of [O ii] at z = 0.734 and Lyα at z = 3.609, from left to right. Because these two objects are barely resolved with MUSE, they were originally treated as a single “merged” object. However, their spectra and a comparison of the narrowband images with the HST image help to “split” and associate the MUSE redshifts with the corresponding HST counterparts.

Open with DEXTER

There are also some rare cases in which even though two or more of the merged objects have more than one redshift identified, they cannot be associated with any of the known objects owing to complex morphology, too close separation even for the HST, or no continuum detection. As shown in Fig. 17, in the one-dimensional spectrum of an absorption galaxy at z = 2.575, MUSE ID 942, multiple emission lines are visible at 7805Å, 8100Å, 8590Å, and 9090Å. These features do not correspond to any of the features that can be seen at z = 2.575 of ID 942, but are consistent with [O ii], [Ne iii] 3869, Hδ, and Hγ at z = 1.094 (MUSE ID 7382), respectively. We use the center of the [O ii] narrowband image as the coordinates of this object. This particular case was found by hand, but ORIGIN has played an important role in finding these kinds of blended objects that are hard to find by humans. For example, multiple pronounced emission features seen in MUSE ID 945 immediately reveal its redshift to be z = 0.605. It is very easy to neglect a weaker emission feature detected at 7230Å in the same spectrum, which is not associated with ID 945. ORIGIN successfully found this feature and we identify it as Lyα at z = 4.947 (MUSE ID 6470, no UVUDF counterpart).

thumbnail Fig. 17

Similar to Fig. 16, but for MUSE IDs 942 (z = 2.575) and 7382 (z = 1.094). The extracted spectra clearly show that there are at least two objects lying on the same sight line. A small offset is also seen between the narrowband images of the C iv absorption feature at z = 2.575 and [O ii] at z = 1.094. However, there is no obvious HST object to provide the counterpart for the [O ii] emitter.

Open with DEXTER

In the end, we split about 150 of the merged objects. Among 1574 objects with MUSE-z (CONFID ≥ 1), there are 79 that remain as merged objects. We stress that we do not use or provide the photometric measurements for the merged objects. When merged objects have been successfully split during the redshift determination, the split objects have been associated with the corresponding photometries from the UVUDF catalog. If we find multiple redshifts in an object that is not merged (the case of Fig. 17), only the object with the centroid in the narrowband images of the detected features closest to the UVUDF coordinates or the object with the reasonable HST color is assigned to have the UVUDF photometries.

5.4. Comparisons with previous spectroscopic redshifts

There has been a large effort to measure spectroscopic redshifts (spec-z) in the UDF and the surrounding regions, such as GOODS, VVDS, and VUDS. According to the list of spec-z compiled in the UVUDF catalog by Rafelski et al. (2015)12, there are 150 previously known secure spec-z in our survey region (3′ × 3′). The total number of published redshifts in the UVUDF catalog is 169 over the entire HUDF area. In addition, within a 0.5′′ search radius, we find that there are 11 MUSE objects13 that have previously known spec-z measured by VUDS with high reliability (redshift flags of 4, 3, or 2; Tasca et al. 2017). Thus, in total, we compile 161 previously known reliable spec-z in our survey field. It is noteworthy that MUSE delivers a drastic improvement not only in the number of spec-z, but also in the range of redshift and the limiting magnitude of the objects with confident spec-z (Fig. 18).

thumbnail Fig. 18

Magnitude vs. redshift space of secure MUSE-z (CONFID ≥ 2; red circles) and previous reliable spec-z for the unique objects in the entire MUSE deep survey region (udf-10 + mosaic). The previously known spec-z taken from the UVUDF and VUDS catalogs are indicated with blue and cyan squares, respectively. The horizontal dashed line indicates 27 mag where we make the cut to the continuum selected galaxies to perform the redshift determination in the mosaic field (see Sect. 4.2.1).

Open with DEXTER

The majority (all for udf-10) of the published spec-z are in the redshift range of 0 <z< 3 and F775W magnitude of <25. The three objects at z> 3.5 in the UVUDF catalog are from the spectroscopic observations of Lyman break galaxies (Vanzella et al. 2009)14.

A simple check of MUSE redshifts is to compare them with the published spectroscopic redshifts. In Fig. 19, our MUSE spectroscopic redshifts are compared to these previously known spectroscopic redshifts. When we only use the robust redshifts (CONFID 2), we find six objects with | Δz | > 0.01 (MUSE IDs 29, 949, 957, 997, and 1048 from UVUDF and MUSE ID 6891 from VUDS), but all except IDs 997 and 6891 have 0.01 < | Δz | < 0.02, which is expected to happen owing to observations with different spectroscopic resolutions. We investigate the two objects with catastrophic differences below (CONFID of MUSE-z is given in the parentheses):

  • 997zMUSE = 1.041 (3), zknown = 1.603 (Morris et al. 2015).

    The previous spec-z is measured from WFC3 grism (G141) data by identifying Hβ and [O iii] (with a good quality, 3 out of 4), while MUSE-z is determined by a well-detected [O ii] doublet, [Ne iii] 3869, Hδ, and Hγ (with CONFID of 3, the highest). Reinspecting the WFC3 grism spectrum verifies that z = 1.603 is not as convincing as originally determined. In addition, there is an extra complication in extracting the grism slitless spectrum due to multiple nearby objects. Thus, we conclude that our MUSE redshift is likely to be correct for MUSE ID 997 (UVUDF ID 8592).

  • 6891zMUSE = 0.227 (3), zknown = 3.647 (Tasca et al. 2017).

    Although the redshift of ID 6891 (UVUDF ID 4864) is identified by good detections of Hβ, [O iii], and Hα, its spectrum is blended with ID 6892 (UVUDF ID 4863), which shows a Lyα emission line at zMUSE = 3.648 (CONFID = 2). The separation of these two objects is 0.3′′. The previously measured spec-z corresponds to MUSE ID 6892, but the pointing coordinates are closer to MUSE ID 6891. Also, these two objects were not successfully deblended in the CANDELS catalog (CANDELS ID 13745 for both of the objects). Thus, we think that our MUSE redshift measurement for MUSE ID 6891 (and 6892) has no problem.

thumbnail Fig. 19

Comparisons of MUSE-z to the previous spectroscopic redshifts from the other ground- and space-based telescopes compiled in the UVUDF catalog. The high and low confidence MUSE-z are shown as red and gray symbols, respectively. MUSE ID 997 indicated in the figure is the only object with a catastrophic difference in the spec-z comparisons. See the text for more details.

Open with DEXTER

When including CONFID = 1 redshifts, one MUSE object (MUSE ID 1143) has previously known spectroscopic redshifts but disagrees with our MUSE redshifts (zMUSE = 1.262 and zknown = 1.332 from Morris et al. 2015). The previously known redshift 1.332 is measured in the near-infrared spectrum obtained with HST/WFC3 grism (G141) spectroscopy. Morris et al. (2015) identified Hβ and [O iii]. In our MUSE spectrum, we identified [O ii] λ3729 at 8435Å, which gives z = 1.262. Its CONFID is 1 because [O ii] λ3726 is not detected probably because it overlies a sky line. The difference in redshift is δz = 0.07, which cannot be explained by the low spectral resolution (R ~ 130) of the grism spectroscopy. We found that the 3D-HST survey (Brammer et al. 2012) also published a redshift for this object of z = 1.299 (by identifying Hα; Momcheva et al. 2016), which is consistent with our measurement. The slight discrepancy (| Δz | = 0.037) can be attributed to the fact that the object is spatially extended in the dispersion direction for the grism. Thus, we assessed that the MUSE redshift for this object is more feasible.

There are 10 objects whose spec-z are reported in the UVUDF (seven objects) and VUDS (three objects) catalogs but are missed by our redshift determination. These objects are listed below with MUSE ID, UVUDF ID in the parentheses, previously measured spec-z, and the reference:

  • 55 (24380): z = 1.39 ± 0.01 (Daddi et al. 2005).

    The spectrum was obtained with HST/ACS grism low-resolution spectroscopy (G800L, R ≈ 100 at 8000Å for a point source), which detected a broad Mg ii absorption line. This feature is not seen in our MUSE spectrum even with smoothing probably due to much higher noise level in the continuum. This object is located in the overlapping region of the mosaic and udf-10, but we cannot find a redshift from the spectrum extracted from the deeper udf-10 data.

  • 1199 (3482): z = 1.91 ± 0.01 (Daddi et al. 2005).

    Daddi et al. (2005) found a broad blended Mg ii λλ2796,2803 doublet absorption feature (and likely the Fe ii multiplet absorption) in their spectrum taken with HST/ACS grism spectroscopy. This feature can be identified in our MUSE spectrum too, but only after knowing the redshift or heavily smoothing the spectrum.

  • 1308 (10544): z = 1.313 (Morris et al. 2015).

    The known redshift was determined using the spectrum taken with HST/WFC3 grism spectroscopy (G141, R ≈ 130 at 1.1 ≤ λ [ μm ] ≤ 1.7). The emission features Hβ, [O iii], and Hα were identified to obtain z = 1.313. With this redshift, we confirm the [O ii] emission at 8630Å in our MUSE spectrum. It is located in the wavelength region where sky emission dominates, which made it easily missed during our redshift determination process. This redshift is added into the combined catalog by hand (zMUSE = 1.315 with CONFID = 3).

  • 1312 (21773): z = 1.76 ± 0.02 (Daddi et al. 2005).

    The HST/ACS grism spectrum detected a broad Mg ii absorption line. With the previously determined redshift, we can confirm the same feature in the MUSE data. However, it lies in a wavelength region crowded with sky lines, which makes it even harder to identify the feature without the a priori information.

  • 1351 (4562): z = 2.145 (Balestra et al. 2010).

    The spectrum was taken with VLT/VIMOS. The previously known redshift was determined based on the O i (1302.20Å) and C ii (1335.10Å) absorption features detected at 4095Å and 4200Å, respectively. These features are both outside the MUSE wavelength coverage, preventing us from recovering its redshift with MUSE. At this redshift, C iii] and some absorption features are covered by the MUSE wavelength range, but none of these features are visible.

  • 1364 (8292): z = 2.067 (Morris et al. 2015).

    The redshift was measured in the spectrum taken with the HST/WFC3 near-infrared grism. These authors detected Hβ and [O iii]. We can indeed recognize the Mg ii λλ2796,2803 absorption lines (and possibly Fe ii λ2344 and Fe ii λλ2374,2382) in the MUSE data with this redshift. It is difficult to notice these features in our data because at this redshift, the Mg ii features lie in the low S/N region due to many sky lines.

  • 1520 (21730): z = 1.98 ± 0.02 (Daddi et al. 2005).

    A broad Mg ii absorption feature (and possibly the Fe ii multiplet absorption) was detected in their HST/ACS grism spectrum. This feature might be visible in the MUSE data, but is not obvious because of crowded sky lines. It is difficult to use our MUSE data solely to determine this redshift.

  • 4070 (635): z = 4.498 (zflag = 3) (Tasca et al. 2017).

    The VUDS redshift (VUDS ID 532000222) may have been determined by a tentative Lyα emission at 6685 Å. In our MUSE spectrum we also discern an emission line at 6685 Å, but this is contamination from MUSE ID 1185 (Lyα at zMUSE = 4.50), which is 2.38′′ away. It is possible that the VUDS slit also covered the extended Lyα emission from ID 1185, which led to z = 4.498.

  • 5216 (8384): z = 2.095 (zflag = 2) (Tasca et al. 2017).

    It looks as though the VUDS redshift (VUDS ID 539990803) was derived from a good cross-correlation signal. However, our cross-correlation with MARZ does not provide a good signal and we are not able to find the expected absorption features at this redshift in our MUSE spectrum.

  • 5494 (7285,7374): z = 0.768 (zflag = 3) (Tasca et al. 2017).

    At the VUDS redshift (VUDS ID 532000256), we might expect to detect Fe ii, Mg ii, Hβ, and [O iii] in the MUSE spectrum, but none of these features are seen. The VUDS redshift is likely obtained through a good cross-correlation signal, but we are not able to do so with the MARZ cross-correlation.

Of these 10 redshifts that were missed by our redshift determination process, four were obtained via ground-based spectroscopy. However, for one of these redshifts (MUSE ID 1351), the detected features are not accessible with MUSE, and for the other three, we cannot confirm the previously measured redshifts in the MUSE spectra (IDs 4070, 5216, and 5494). The rest were taken with sky emission free space-based spectroscopy. The four optical spectra (HST/ACS) provide much higher sensitivity, especially in the continua, which facilitates detections of absorption features (Mg ii in this case). An extremely broad feature is also easily washed out in our higher resolution spectra without smoothing. The remaining two redshifts were measured with the near-infrared spectra from space (HST/WFC3). We can confirm the expected features in the MUSE spectra with the known redshift, although they are difficult to identify because their wavelengths are in the region of many strong sky emission lines.

5.5. Comparisons with photometric redshifts

We compared our MUSE determined spec-z against the published photometric redshifts (photo-z) from Rafelski et al. (2015) in Fig. 20. The merged objects (extracted with HST priors that cannot be resolved by MUSE) are not included in the plots. Rafelski et al. (2015) provide two sets of photo-z, based on the Bayesian photometric redshift (BPZ) estimation (Benítez 2000) and the EAZY software (Brammer et al. 2008).

thumbnail Fig. 20

Comparisons of redshifts measured from the MUSE data in udf-10 + mosaic compared with photometric redshifts, computed with BPZ (left) and EAZY (right). The redshifts with CONFID ≥ 2 and CONFID = 1 are plotted with the red and gray circles, respectively.

Open with DEXTER

Although MUSE spec-z and photo-z agree well with both BPZ and EAZY up to z ≈ 3, a systematic difference appears at z ≳ 3. Both of the photo-z measurements tend to underestimate the redshift. All of the MUSE redshifts at z > 3 are identified by Lyα, which is known to cause the apparent offset toward higher redshift (of a few hundred km s-1; Shapley et al. 2003; Steidel et al. 2010; Hashimoto et al. 2013) attributed to galactic-scale outflows or absorption by the intergalactic medium. However, this Lyα apparent offset is not the major cause of the photo-z offset because the median of the measured offsets (Δz) between MUSE-z (CONFID ≥ 2) and photo-z is significantly larger than the expected Lyα velocity offset (−0.13 and −0.32 for BPZ and EAZY, respectively). In Fig. 21, the redshift difference is plotted against the HST F775W magnitude. It is clear that the photo-z measurements are biased at the faint end.

Further analyses and discussions including the redshift completeness can be found in Paper III. In this paper, we checked the catastrophic redshift outliers and systematic biases. We found that changes in model of treatments of inter-galactic medium (IGM) absorption for Lyα-forest and Lyman continuum absorption can reduce the photo-z and MUSE-z discrepancy. We also adopted photometric redshifts from the BEAGLE software (Chevallard & Charlot 2016).

thumbnail Fig. 21

Difference in the photometric redshift and MUSE redshift (udf-10 + mosaic) against the F775W magnitude. The redshifts with CONFID = 1 are plotted with gray circles. The secure redshifts (CONFID ≥ 2) are separated into two groups: z < 3 (red circles) and z ≥ 3 (blue squares).

Open with DEXTER

5.6. Color selections of high-z galaxies

The presence of the 912 Å Lyman break enables selection of high-redshift galaxies using their colors. Here we compared MUSE-z to some commonly used color-color selection diagrams to discuss the fraction of successful color selections. The combination of the MUSE wavelength coverage and the HST filter sets observed in our deep field facilitates some tests on the color selection technique of 2 ≲ z ≲ 6 candidate galaxies. Known stars are excluded from all of these plots.

thumbnail Fig. 22

Left: color-color diagram of F336WF435W vs. F435WF606W to select z ~ 2.7 galaxies (F336W dropouts). Only the MUSE spectroscopic redshifts with CONFID ≥ 2 are plotted. The galaxies in the targeted redshift range (2.3 ≤ z ≤ 3.0) are shown with red open squares. The violet, blue, green, gold, orange, magenta, and red filled circles, with sizes from small to large, indicate galaxies in 0 ≤ z< 4 with steps of Δz = 1, respectively. The model tracks of the starburst template (SB1; Kinney et al. 1996) and the CWW templates (Scd and E, Coleman et al. 1980) are overlaid. The crosses on the model tracks indicate redshifts from z = 0 in increments of Δz = 1. Right: counts of galaxies in each redshift bin (only the galaxies detected in all of the F336W, F435W, and F606W bands are used here). The empty bars are all of the galaxies with MUSE redshifts and the filled bars are a subset of the MUSE redshifts lying within the F336W dropout selection boundary (the left panel). The percentages shown above each bar are the fractions of the galaxies within the color-color boundary for each bin. The vertical dashed blue lines indicate the targeted redshift range, 2.3 ≤ z ≤ 3.0. The percentage indicated in between these lines in blue is the fraction of the galaxies within the color-color boundary for the targeted redshift range.

Open with DEXTER

In Fig. 22 (left panel), we overplot all of the MUSE-z on the F336W dropout selection diagram (F336WF435W versus F435WF606W). The bandwidth of F336W favors Lyman break galaxies (LBGs) at 2.3 ≲ z ≲ 3.0. Although Hathi et al. (2010) and Teplitz et al. (2013) also show the F225W and F275W dropout selections, we exclude these from this paper because they preferentially select z ~ 1.7 and z ~ 2.1, respectively, which is a range in which MUSE does not recover a large number of redshifts. We follow the selection criteria of Hathi et al. (2010), i.e.,

F336W dropouts: The original selection conditions also apply a magnitude cut of F435W ≤ 26.5 mag and S/N limits of S/N(F435W) > 3, S/N(F336W) < 3, S/N(F275W) < 1, and S/N(F225W) < 1 to securely find high-z candidates. We do not adopt these limits because our purpose here is to demonstrate where our galaxies with measured redshift lie in the diagrams. However, we do require solid detections, and thus no limit is shown in the diagrams.

The fraction of galaxies that meet these selection criteria in each redshift bin is shown in the right panel of Fig. 22. This plot indeed identifies galaxies at 2.3 ≲ z ≲ 3.0 among the galaxies with secure redshift (81%). If we limit to 2.5 <z< 3.0, 93% of the galaxies in this redshift range are classified as F336W dropouts. Those missed (the filled green circles in the left panel of Fig. 22) lie very close to the selection boundary where lower-z galaxies start to get intermingled, in particular around 0.5 ≲ F336WF435W ≲ 0.8 and −0.2 ≲ F435WF606W ≲ 0.4. There is only one interloper from galaxies at 0 ≤ z< 1 at F336WF435W = 0.93 and F435WF606W = 0.27, almost on the borderline. This object is MUSE ID 2537 (z = 0.717) whose redshift is identified by Hδ and [O iii] λλ4959,5007.

For even higher redshifts, we utilize the F435W, F606W, and F775W dropout techniques to inspect z ~ 3.5, z ~ 5.0, and z ~ 6.0 galaxy selections, respectively (Stark et al. 2009, 2010), as shown in Fig. 23. The selection boundaries are listed below. Again, here we do not include any S/N cuts on the dropout conditions.

F435W dropouts:

F606W dropouts:

F775W dropouts: In all of these dropout selections, the targeted dropout galaxies are well captured. No low-z interloper is found in any of these selections. The fraction of galaxies that lie within the boundaries is much smaller compared the F336W selection (Fig. 24). This fraction also decreases from the lower-z to higher-z dropout selections (41%, 34%, and 22% for the F435W, F606, and F775W dropouts, respectively). If we limit the redshift bin to 3.5 <z< 4.0, which is the most sensitive redshift range for the F435W filter to detect the dropouts, then 81% of galaxies in this redshift bin meet the dropout criteria. Similarly, for selecting F606W and F775W dropouts, the fractions are highest (67% for both) in the redshift bins of 5.0 <z< 5.5 and 6.0 <z< 6.5. Although error bars are not shown in the diagrams (in order to make them readable), the errors of the objects outside of the selection boundaries are almost always smaller than those in the boundaries. Their positions are reliable in the color-color planes.

thumbnail Fig. 23

Similar to the left panel of Fig. 22 but selecting z ~ 3.5 (F435W dropouts), z ~ 5.0 (F606W dropouts), and z ~ 6.0 (F775W dropouts), shown in the left, middle, and right panels, respectively. For the F435W and F606W dropouts, we do not plot the objects at z> 5.0 and z> 6.0, respectively. The galaxies indicated with the red squares are not in the full targeted redshift range, but are restricted to narrower ranges (see also Fig. 24). The solid and dashed black lines are the boundaries of the selection criteria from Stark et al. (2009, 2010). The dashed black lines are shown because they are at the outside of the plotting regions in Stark et al. (2009, 2010). The solid red lines are our empirically redefined new selection boundaries to gain more galaxies in the targeted redshift ranges. The model tracks for the F850LP magnitude in the F775W dropout diagram is computed for an absolute magnitude of −22 mag. The 5σ limit of the F850LP magnitude is 28.9 mag (Rafelski et al. 2015).

Open with DEXTER

thumbnail Fig. 24

Similar to the right panel of Fig. 22 but for investigating the fractions of galaxies that meet the dropout conditions at z ~ 3.5, z ~ 5.0, and z ~ 6.0, shown in the left, middle, and right panels, respectively.

Open with DEXTER

From these results, we can empirically adjust the selection boundary to increase the fraction of the candidate galaxies at the targeted redshift ranges. Based on visual modifications, we relax the selection conditions based on our MUSE redshifts as follows:

Redefined F435W dropouts from MUSE-z:

Redefined F606W dropouts from MUSE-z:

Redefined F775W dropouts from MUSE-z: These updated boundaries are shown with the solid red lines in Fig. 23. The histograms of the selected galaxies with these new criteria are shown in Fig. 25. We are trying this experiment, but not all of our sample galaxies in the diagrams (in particular those lying between the original and new boundaries) necessarily show a clear Lyman break because we only use Lyα emission to determine their redshifts.

thumbnail Fig. 25

Same plots as Fig. 24, but for our empirically redefined new selection boundaries shown in Fig. 23 with the red lines.

Open with DEXTER

We allow a slightly bluer F435WF606W color for selecting z ~ 3 galaxies (F435W dropouts) because there is a crowd of 3 ≤ z< 4 galaxies lying right below the original boundary. The new boundary significantly improves the z ~ 3 galaxy selection without picking up contaminants. In particular, now it finds ≈ 40% more galaxies at 3.0 <z< 3.5.

For the F606W dropouts, the targeted z ~ 5 galaxies also extend toward bluer F606WF775W colors. Thus, we lower the color limit of F606WF775W. In addition, we remove the border at F775WF850LP = 1.3 because some of galaxies at 5.5 < z < 6.0 have redder colors. These new conditions successfully increase the fraction of z ~ 5 galaxies lying within the boundary from 34% to 59% and now capture 88% of the galaxies in the 5.0 < z < 5.5 bin and 66% in the 4.5 < z < 5.0 bin. This also adds one low-z interloper and two galaxies at 3.0 < z < 4.015.

It is more difficult to enhance the z ~ 6 galaxy selection. We double the number of galaxies at 5 ≲ z ≲ 6.5 to meet the new conditions, but this also increases the number of galaxies at lower redshifts. With the newly suggested criteria, we cover galaxies at 6.0 <z< 6.5 well (83%) and improve a lot for galaxies at 5.5 <z< 6.0 (from 29% to 63%). There are more galaxies below z = 5 in the new selection box, but only one is below z = 1 (MUSE ID 2478 z = 0.73). The remaining eight lower-z galaxies have redshifts between 3 and 5. In total, we successfully select 29 galaxies at 5.0 < z < 6.5. It is challenging to purely select galaxies at 5.0 < z< 5.5 with this color-magnitude diagram because galaxies at 3 < z < 5 have similar colors and magnitudes. We only collect two galaxies (5.3%) in this bin using the new diagram (0 in the original one).

thumbnail Fig. 26

Examples of the outliers in the F435W (top panel), F606W (two middle panels), and F775W (bottom panel) dropout selections. In each panel, a spectral energy distribution using the HST photometries is shown at the top left, a zoomed-in part of the Lyα detected wavelength region is presented at the top right, and thumbnail HST images of the object are shown at the bottom. The object ID, MUSE spec-z, and the colors of each galaxy can be found at the top of each panel.

Open with DEXTER

There are still significant numbers of high-z galaxies lying outside of the selection boxes. We have checked these galaxies individually to determine whether their bluer colors are due to blending or photometric issues. In the F435W dropout diagram, we find 10 objects with 3.5 ≤ z ≤ 4.0 for F435WF606W< 0.9. Among these objects, one may be blended with a nearby object, one is a dusty galaxy (ID 6672, see Fig. 26) and one may have an ambiguous Lyα feature. In the remaining seven objects, two have good photometries lying near the revised selection box, and five have S/N(F435W) < 5 but the error budgets of their photometries make them agree with the revised selection box. For the F606W dropout diagram, we checked 12 galaxies with 4.5 ≤ z ≤ 5.5 for 0 ≲ F606WF775W ≲ 0.4. There is one (ID 6324, Fig. 26) whose photometries may be contaminated by a neighboring object, but the rest of the objects have good photometries (seven with S/N(F606W) ≳ 5 and four with S/N(F606W) > 10; e.g., ID 2727, Fig. 26). However, we find that all of these objects have the Lyα emission line lying in the F606W coverage, which is likely to produce bluer F606WF775W colors. This effect is visible in the diagrams in Figs. 25 and 24. Allowing the boundary of F606WF775W to be bluer increases more lower-z selections in the targeted redshift range of 4.2 <z< 5.8. In fact, this trend is also seen in the 13 outlier galaxies with 5.5 ≤ z ≤ 6.5 for 0 ≲ F775WF850LP ≲ 0.5 in the F775W dropout diagram (e.g., ID 3238, Fig. 26). All of these galaxies have S/N(F775W) ≳ 5 and the detected Lyα line is lying in the F775W coverage; three of these galaxies are starting to enter the F850LP coverage, but at the wavelength where the F850LP filter throughput is still <50%. Similar to the outliers in the F606W dropout diagram, the enhanced blue F775WF850LP colors of these objects can be ascribed to Lyα emission contributing to the F775W flux. The newly defined selection boundaries help to increase the completeness of 3 ≲ z ≲ 7 galaxy selections. It is not surprising that we find outliers as color selection criteria are not designed for comprehensive detection. Although rest-frame UV spectra of high-z galaxies are affected by IGM transmission, the high equivalent width of Lyα emission also causes bluer colors, which makes the apparent Lyα break less significant (particularly in the F606W and F775W dropout selections). In addition, color selections are known to exclude some high-z passive and dust-obscured galaxies (e.g., Daddi et al. 2004; Reddy et al. 2005; van Dokkum et al. 2006). The outliers in the dropout diagrams are also found in the VVDS survey (Le Fèvre et al. 2005; Paltani et al. 2007).

Here we limit to the comparisons of measured redshifts against the dropout selections. The galaxy populations plotted here are likely to be different from the traditional dropout selected galaxies because the majority of the redshifts are determined with emission lines. However, candidate galaxies lying between the original and new selection conditions may be able to serve as second highest priority targets for multi-object spectroscopy to increase the efficiency in finding high-z galaxies. Also, we do not adopt any S/N or magnitude cuts here. For future work, we will discuss in more detail why some galaxies fail to meet the dropout conditions (with respect to their spectroscopic and photometric redshifts), the relationship between Lyα emitters and dropout galaxies and their physical properties, and the evolution of the fraction of Lyα emitters.

6. Summary and conclusions

We have conducted a deep spectroscopic survey in the HUDF with MUSE. The 3′ × 3′ deep survey (≈ 10 h depth, the mosaic) region almost covers the entire HUDF with the 1′ × 1′ ultra deep survey (≈ 30 h depth, udf-10) region enclosed. We used two different spectral extraction methods for the redshift identification: the HST prior continuum selected objects (based on the UVUDF catalog; Rafelski et al. 2015) and the emission line objects selected directly in the cubes without prior information. We visually inspected these spectra to determine redshifts via redshift analysis software. We also measured the line fluxes for the objects with redshifts determined. Along with this paper, we release the redshift and line flux catalogs. Here we summarize our findings in the redshift assessments:

  • 1.

    In udf-10, we obtained 253 secure redshifts (CONFID ≥ 2) in the redshift range 0.21 ≤ z ≤ 6.64. Among these, 30 are not in the HST UVUDF catalog that we used for the prior based source extraction. The majority of these redshifts (28) are Lyα emitters. When we only count HST prior extracted objects, we managed to retrieve 223 redshifts out of 854 continuum selected objects (26%). We reach a 50% completeness at 26.5 mag (F775W), and the completeness stays around 20% up to 28–29 mag.

  • 2.

    In the mosaic, in addition to investigating all of the emission line galaxies, we performed visual inspections for those with F775W ≤ 27 mag for the continuum selected galaxies. This arbitrary cut is made based on our findings for udf-10 that ≈ 90% of galaxies at z< 3 are brighter than this magnitude. At z> 3, although most of the galaxies are fainter than 27 mag, we are able to detect 70% of these galaxies with emission features directly in the data cube without any continuum information. Together with the direct search for emission line objects in the cube, this helps to increase the efficiency of redshift determination.

  • 3.

    Out of the 1147 continuum selected objects with F775W ≤ 27 mag in the mosaic field, we determined secure redshift of 636 objects. When we included the emission line detected objects (regardless of magnitude), we obtained 1247 unique redshifts with confidence. The 50% completeness with respect to F775W mag is at 25.5 mag.

  • 4.

    In the overlapping region of udf-10 and mosaic, all of the redshifts measured in mosaic were also measured in the udf-10 with at least the same confidence level or higher, except one object lying at the edge of the udf-10 field and four objects detected only through emission lines in the mosaic cube. On the other hand, 78 secure redshifts were missing in mosaic when compared with udf-10. There are a few discrepancies but the measurements in the udf-10, which has higher S/N spectra, are usually more convincing.

  • 5.

    Among 7904 unique continuum selected galaxies in the entire MUSE UDF survey region (udf-10 + the mosaic), we recovered redshifts for 1206 (15%) objects. We also found 132 objects only via emission line searches directly in the data cubes (no counterparts in the HST UVUDF catalog). Thus, in total, we obtained 1338 unique redshifts with high confidence.

  • 6.

    Compared with the HST beamsize, the MUSE data suffer from source confusion. However, we were able to partly solve this issue when an emission/absorption feature is identified. The location of the detected feature in its narrowband image can be associated with the location of the corresponding source in the HST images. There are also a few cases where two (or more) galaxies are completely blended even with the HST resolution, but we identified both (or all) of these cases with two (or more) different sets of emission lines at different redshifts. Finally, among 1574 objects with MUSE-z (CONFID ≥ 1), there are 79 that remain as merged objects.

  • 7.

    Of the previously known 161 spectroscopic redshifts in our survey field, we recovered all except 10 objects. Of these, four were measured in spectra taken with ground-based spectroscopy. However, for one of these redshifts, the detected features are at wavelengths shorter than the blue end of MUSE, and for the other three, we cannot confirm the previously measured redshifts based on the expected detectable features. The other six spectra were taken with HST grism spectroscopy. The features used for determining their redshifts either were a very broad absorption feature or lay on the red side of MUSE spectra where sky emission dominates.

  • 8.

    The comparison of MUSE-z and photometric redshifts revealed that they agree well up to z ≈ 3. At higher redshift, an offset appears. Although most of the z> 3 redshifts are determined with Lyα, the median offset between MUSE-z and photo-z is much larger than the expected Lyα velocity offset to the systematic redshift due to gas motion. We observed a trend that the photo-z offset increases with fainter continuum emission in HST/F775W.

  • 9.

    We investigated all of the galaxies with secure MUSE-z in some common color selection (dropout) diagrams of high-z galaxies. With the F336W dropout selection criteria, 81% of targeted z ~ 2.7 galaxies are captured. This fraction decreases for higher-z selections: 41% for F435W dropouts (z ~ 3), 34% for F606 dropouts (z ~ 5), and 22% for F775W dropouts (z ~ 6). We empirically redefined the selection boundaries to increase the fractions to 68%, 59%, and 45%, but our galaxy populations are likely to be different from the traditional dropout selected galaxies (continuum selected) because the majority of the redshifts were determined using emission lines.

With deep MUSE spectroscopic observations in HUDF, we dramatically improve the redshift completeness. The improvements are not only the increase in number from 161 to 1338, but also the coverage of the redshift range well beyond z> 3 and depths up to the 30th magnitude (F775W). Together with existing large telescopes and planned future observatories such as JWST and 30 m class telescopes, it opens new horizons for exploring the early Universe.

In the near future, we plan further advances in the analysis, such as investigating spectra extracted at the positions of continuum selected objects fainter than 27 mag in the mosaic, fine tuning ORIGIN (and MUSELET) to further improve the direct detection of emission lines without enhancing spurious sources, upgrading MARZ to increase the accuracy of automated redshift determinations with newly built spectral templates, and developing deblending techniques based on prior information.


1

The ALMA SPECtroscopic Survey in the Hubble Ultra Deep Field.

2

The ultraviolet UDF (UVUDF) catalog includes the photometries of 11 HST broadbands from F225W to F160W.

3

These numbers increase after the redshift analysis because we manage to “split” some of these objects based on their emission line narrowband images (see Sect. 4.1.1).

4

MUSELET is publicly available as a part of the MPDAF software (Piqueras et al. 2017). More details at http://mpdaf.readthedocs.io/en/latest/muselet.html

5

Line fluxes measured in the segment may be less than the total flux because of aperture effects.

6

In Sect. 7.3 of Paper I, we discuss why they were not detected by SExtractor.

8

Fitting and Assessment of Synthetic Templates. We assume the dust extinction curve of τλ-1.3 from Charlot & Fall (2000) together with the median value of the measured Balmer decrements of the MUSE sources that have two or more Balmer lines detected.

9

The optical spectrum of this object was taken before with HST/ACS slitless grism spectroscopy and Mg ii is detected (Straughn et al. 2008).

10

Object MUSE ID 6449 actually has UVUDF ID 4293 (CANDELS ID 18674) in the UVUDF segmentation map. However, UVUDF ID 4293 does not exist in the UVUDF catalog. Since the actual measurement is not provided in the UVUDF catalog, here we consider that it was not successfully extracted in UVUDF.

11

Cosmic Near-IR Deep Extragalactic Legacy Survey.

12

The spectroscopic redshifts provided in the UVUDF catalog are gathered from the following surveys: VVDS (Le Fèvre et al. 2004), Szokoly (Szokoly et al. 2004), K20 (Mignoli et al. 2005), GRAPES (Daddi et al. 2005), Vanzella GOODS Vanzella et al. (20052009), Popesso GOODS (Popesso et al. 2009), Balestra GOODS (Balestra et al. 2010), GMASS (Kurk et al. 2013), and 3D-HST (Morris et al. 2015).

13

MUSE ID 6945 has a previously known spec-z in both of the UVUDF and VUDS catalogs (1.098 and 1.096, respectively). These redshifts agree, and thus we do not count this as an additional spec-z and only use the spec-z from UVUDF.

14

Their object IDs are J033236.83-274558.0, J033240.01-274815.0, and J033239.06-274538.7.

15

The low-z interloper is MUSE ID 873 (z = 0.66). The other galaxies are MUSE IDs 493 (z = 3.18) and 7377 (z = 3.42).

Acknowledgments

The authors are grateful for useful suggestions by the referee that improved the manuscript. We thank Laure Piqueras for her support with analysis and observation software. This work is supported by the ERC advanced grant 339659-MUSICOS (R. Bacon). J.B. acknowledges support by Fundação para a Ciência e a Tecnologia (FCT) through national funds (UID/FIS/04434/2013) and by FEDER through COMPETE2020 (POCI-01-0145-FEDER-007672) and was in part supported by FCT through Investigador FCT contract IF/01654/2014/CP1215/CT0003. J.R. and B.C. acknowledge support from the ERC starting grant 336736-CALENDS. T.C. acknowledges support of the ANR FOGHAR (ANR-13-BS05-0010-02), the OCEVU Labex (ANR-11-LABX-0060), and the A*MIDEX project (ANR-11-IDEX-0001-02) funded by the “Investissements d’avenir” French government program managed by the ANR. J.S. acknowledges support of the ERC Grant agreement 278594-GasAroundGalaxies. LW acknowledges funding by the Competitive Fund of the Leibniz Association through grant SAW-2015-AIP-2. R.A.M. acknowledges support by the Swiss National Science Foundation.

References

Appendix A: MUSE UDF redshift catalogs

Along with this paper, we release the MUSE ultra deep field (udf-10) and deep field (mosaic) redshift and line flux catalogs. Because the udf-10 field is within the mosaic field, there is some overlap in the object entries. The combined catalog, which only includes a single set of redshift and the associated parameters (CONFID, TYPE, and DEFECT, and measurements in detected lines) for each unique galaxy, is also provided. For the cases with conflicting redshifts, we give the redshift discussed in Sect. 4.3, otherwise the udf-10 redshifts and the associated parameters are employed. In the Table A.1, we describe the contents in the catalogs.

The UVUDF ID numbers are stored as strings (CSV) instead of integer numbers because some of the UVUDF objects are unresolved with MUSE and are merged to be treated as a single object (see Sect. 3.1.1). In order to find an object with the object ID from the UVUDF catalog, users can use the following commands in both Python 2 and 3:

>>> from astropy.table import Table
>>> import numpy as np

# Read the catalog
>>> catalog = Table.read("udf10_mosaic_dr1.fits")

# Convert the catalog UVUDF_ID column to the string type
>>> UVUDF_IDs = catalog["UVUDF_ID"].astype(str)

# The UVUDF ID to search
>>> search_UVUDF_ID = "9525"


# Find the index number of the above UVUDF ID in the catalog
>>> indexes = np.where([search_UVUDF_ID in x for x in np.char.split(UVUDF_IDs, ",")])[0]


# Print the above UVUDF ID and
#   its corresponding MUSE ID and the index number in the catalog
>>> if  len(indexes) > 0:
>>>        idx = indexes[0]
>>>        print_format = "UVUDF ID={0} is MUSE ID={1} (UVUDF ID {2}) at index={3}"
>>>        print(print_format.format(search_UVUDF_ID, catalog["MUSE_ID"][idx], UVUDF_IDs[idx], idx))
>>> else:
>>>        print("UVUDF ID %s: No match found" % search_UVUDF_ID)
                             UVUDF ID=9525 is MUSE ID=70 (UVUDF ID 9525,9515) at index=61

Table A.1

Column description of the redshift catalogs for the MUSE Hubble Ultra Deep Field (udf-10, mosaic, and combined).

Appendix B: Spectral templates for MARZ

Table B.1

Input spectral templates for MARZ.

All Tables

Table 1

Counts of determined redshifts for different source extractions in the MUSE Ultra Deep (udf-10), Deep field (mosaic), and the unique objects of udf-10 + the mosaic.

Table 2

Census of the objects in the MUSE Ultra Deep (udf-10) and Deep field (the mosaic) sorted by categories.

Table A.1

Column description of the redshift catalogs for the MUSE Hubble Ultra Deep Field (udf-10, mosaic, and combined).

Table B.1

Input spectral templates for MARZ.

All Figures

thumbnail Fig. 1

Redshift tool MARZ with some modifications for our redshift analysis. This tool reports the most likely redshift and the quality (QOP) by cross-correlating with input spectral templates. The redshift identifiers verify the suggested redshift or manually find a better redshift and provide its quality (indicated as CONFID in the catalogs). We also implement a feature to show images in the panel on the right.

Open with DEXTER
In the text
thumbnail Fig. 2

Demonstration of the complex fitting for a Lyα emission line presenting blue and red bumps. The fitting is performed on a simulated spectrum (black line) to better illustrate the procedure (the flux is in arbitrarily units). In the real data, the final fit is usually comprised of fewer components. The dashed red lines are the individual Gaussian components and the solid blue line is the total of these components (the final fit). The vertical green dashed lines indicate the local minima. We use the Lyα peak position to measure the redshift (see Sect. 3.2).

Open with DEXTER
In the text
thumbnail Fig. 3

MUSE redshift distributions of the objects extracted with the HST continuum-detected priors (filled bars) and the direct line emission searches (ORIGIN; filled and faded color bars on the right in each bin) in the MUSE Ultra Deep Field (udf-10). All of the extracted sources are shown without removing overlaps between the extraction methods. Left: redshift histogram in bins of Δz = 0.35. The red, blue, and gray represent the confidence levels 3, 2, and 1, respectively, for the determined redshifts. The filled dots show the percentage difference relative to the total of HST prior and ORIGIN MUSE-z distributions. Middle: same redshift distribution as the left panel, but color coded by the classified type of the objects. Right: histogram of the classified type of the objects color coded by the redshift confidence levels.

Open with DEXTER
In the text
thumbnail Fig. 4

Line fluxes of [O ii] λλ3726,3729 (the red circles), C iii] λλ1907,1909 (the blue squares), and Lyα (the green diamonds) of the redshift-identified galaxies in udf-10 (CONFID ≥ 2). The open and filled symbols are the HST continuum and emission line selected objects, respectively. The filled symbols with the black edge indicate that they are detected only by ORIGIN.

Open with DEXTER
In the text
thumbnail Fig. 5

Full MUSE spectrum and a zoomed-in portion of the [O ii], C iii], and Lyα detected wavelength region at the top of each panel, and the HST F775W, MUSE white-light, and narrowband images of each emission line in the bottom of each panel. The yellow contours in the images are the boundary of the UVUDF catalog segmentation for the object, but those in the MUSE white-light image are convolved with the MUSE beam size. The white boundaries indicate masked objects excluded from local sky residual estimates. The green cross indicates the central position of the extracted object. The ID numbers and measured redshift are indicated at the top of each panel. All of these redshifts are secure (CONFID = 2 or 3).

Open with DEXTER
In the text
thumbnail Fig. 6

Full MUSE spectrum and a zoomed-in portion of the SiIV, SiII and CIV, and FeII absorption features. The HST F775W and the MUSE white-light images are shown on the right. The yellow contours in the images are the boundary of the UVUDF catalog segmentation for the object, but those in the MUSE white-light image are convolved with the MUSE beam size. The white boundaries indicate masked objects excluded from local sky residual estimates. The green cross indicates the central position of the extracted object. The ID number and measured redshift are indicated at the top.

Open with DEXTER
In the text
thumbnail Fig. 7

Final MUSE redshift distribution of the unique objects (i.e., overlapping objects are removed) combine both the continuum and emission line detected sources in the MUSE Ultra Deep Field (udf-10). Left: redshift histogram in bins of Δz = 0.35. The red, blue, and gray colors represent the confidence levels 3, 2, and 1, respectively, for the determined redshift. The objects only found by ORIGIN are indicated by the faded colors, whereas in Fig. 3all of the ORIGIN detected objects are shown. Middle: same redshift distribution as the left planel, but color coded by classified type of the objects. Right: histogram of the classified type of the objects color coded by the redshift confidence levels.

Open with DEXTER
In the text
thumbnail Fig. 8

Example of an object that is not detected by continumm emission but found by ORIGIN. The full MUSE spectrum and zoomed-in part of the Lyα detected wavelength region are presented at the top. The HST F775W, MUSE white-light, and Lyα narrowband images are at the bottom.

Open with DEXTER
In the text
thumbnail Fig. 9

Magnitudes of HST F775W plotted against determined redshift (CONFID ≥ 2) for udf-10. The open and filled symbols represent the continuum (HST prior) and emission line (ORIGIN or MUSELET) extracted objects. The filled squares are the objects detected only with ORIGIN or MUSELET, and thus their F775W mags are upper limits. The horizontal dashed line indicates 27 mag where we make the cut to the continuum selected galaxies to perform the redshift determination in the mosaic field (see Sect. 4.2.1).

Open with DEXTER
In the text
thumbnail Fig. 10

Cumulative counts of secure redshifts in udf-10. The colors indicate different types with the same scheme as in Fig. 3.

Open with DEXTER
In the text
thumbnail Fig. 11

Same histograms as Fig. 7 but for the MUSE Deep Field (the mosaic).

Open with DEXTER
In the text
thumbnail Fig. 12

Full MUSE spectrum of a quasar at z = 1.22 detected with a broad, prominent Mg ii emission feature. An intervening absorber (Fe ii and Mg ii) at z = 0.98 is also detected. The cutout (7.6″ × 7.6″) for this object is larger than the standard 5″ × 5″.

Open with DEXTER
In the text
thumbnail Fig. 13

Same histograms as Figs. 7 and 11, but for the combined redshifts of the unique objects from the MUSE Ultra Deep Field (udf-10) and MUSE Deep Field (the mosaic).

Open with DEXTER
In the text
thumbnail Fig. 14

Success rates of obtained secure redshifts are shown in the top panel for udf-10 (red) and mosaic (blue). The horizontal dashed line indicates 50% completeness. We only use the objects with HST counterparts in the UVUDF catalog in this plot (i.e., the objects detected only by ORIGIN/MUSELET are excluded). The middle and bottom panels show the counts of the total number of the HST objects (solid bars) and the MUSE redshift determined objects (hatched bars). The vertical dashed line in the bottom panel indicates the magnitude cut where we perform the redshift investigation on the continuum detected objects.

Open with DEXTER
In the text
thumbnail Fig. 15

Stamp image of 5″ × 5″ centered at RA = 53.169458 and Dec = −27.778191. The HST F775W image (white-light, left panel), the MUSE λ-collapsed image (middle), and the continuum subtracted narrowband image created at λ = 5676Å with a width of 10Å (right). While it is not possible to resolve the two nearby HST objects (UVUDF IDs of 8147 and 8118) with the MUSE white-light image, the combination of the HST image with the narrowband image of the detected emission line (Lyα in this case) makes it possible to identify the origin of the emission (UVUDF ID 8147 corresponds to MUSE ID 6290 with z = 3.67).

Open with DEXTER
In the text
thumbnail Fig. 16

Spectra (extracted by PSF weighting) of MUSE IDs 6877 (z = 0.734) and 6878 (z = 3.609) at the top. The images shown at the bottom are HST F775W, MUSE white-light, and narrowband images of [O ii] at z = 0.734 and Lyα at z = 3.609, from left to right. Because these two objects are barely resolved with MUSE, they were originally treated as a single “merged” object. However, their spectra and a comparison of the narrowband images with the HST image help to “split” and associate the MUSE redshifts with the corresponding HST counterparts.

Open with DEXTER
In the text
thumbnail Fig. 17

Similar to Fig. 16, but for MUSE IDs 942 (z = 2.575) and 7382 (z = 1.094). The extracted spectra clearly show that there are at least two objects lying on the same sight line. A small offset is also seen between the narrowband images of the C iv absorption feature at z = 2.575 and [O ii] at z = 1.094. However, there is no obvious HST object to provide the counterpart for the [O ii] emitter.

Open with DEXTER
In the text
thumbnail Fig. 18

Magnitude vs. redshift space of secure MUSE-z (CONFID ≥ 2; red circles) and previous reliable spec-z for the unique objects in the entire MUSE deep survey region (udf-10 + mosaic). The previously known spec-z taken from the UVUDF and VUDS catalogs are indicated with blue and cyan squares, respectively. The horizontal dashed line indicates 27 mag where we make the cut to the continuum selected galaxies to perform the redshift determination in the mosaic field (see Sect. 4.2.1).

Open with DEXTER
In the text
thumbnail Fig. 19

Comparisons of MUSE-z to the previous spectroscopic redshifts from the other ground- and space-based telescopes compiled in the UVUDF catalog. The high and low confidence MUSE-z are shown as red and gray symbols, respectively. MUSE ID 997 indicated in the figure is the only object with a catastrophic difference in the spec-z comparisons. See the text for more details.

Open with DEXTER
In the text
thumbnail Fig. 20

Comparisons of redshifts measured from the MUSE data in udf-10 + mosaic compared with photometric redshifts, computed with BPZ (left) and EAZY (right). The redshifts with CONFID ≥ 2 and CONFID = 1 are plotted with the red and gray circles, respectively.

Open with DEXTER
In the text
thumbnail Fig. 21

Difference in the photometric redshift and MUSE redshift (udf-10 + mosaic) against the F775W magnitude. The redshifts with CONFID = 1 are plotted with gray circles. The secure redshifts (CONFID ≥ 2) are separated into two groups: z < 3 (red circles) and z ≥ 3 (blue squares).

Open with DEXTER
In the text
thumbnail Fig. 22

Left: color-color diagram of F336WF435W vs. F435WF606W to select z ~ 2.7 galaxies (F336W dropouts). Only the MUSE spectroscopic redshifts with CONFID ≥ 2 are plotted. The galaxies in the targeted redshift range (2.3 ≤ z ≤ 3.0) are shown with red open squares. The violet, blue, green, gold, orange, magenta, and red filled circles, with sizes from small to large, indicate galaxies in 0 ≤ z< 4 with steps of Δz = 1, respectively. The model tracks of the starburst template (SB1; Kinney et al. 1996) and the CWW templates (Scd and E, Coleman et al. 1980) are overlaid. The crosses on the model tracks indicate redshifts from z = 0 in increments of Δz = 1. Right: counts of galaxies in each redshift bin (only the galaxies detected in all of the F336W, F435W, and F606W bands are used here). The empty bars are all of the galaxies with MUSE redshifts and the filled bars are a subset of the MUSE redshifts lying within the F336W dropout selection boundary (the left panel). The percentages shown above each bar are the fractions of the galaxies within the color-color boundary for each bin. The vertical dashed blue lines indicate the targeted redshift range, 2.3 ≤ z ≤ 3.0. The percentage indicated in between these lines in blue is the fraction of the galaxies within the color-color boundary for the targeted redshift range.

Open with DEXTER
In the text
thumbnail Fig. 23

Similar to the left panel of Fig. 22 but selecting z ~ 3.5 (F435W dropouts), z ~ 5.0 (F606W dropouts), and z ~ 6.0 (F775W dropouts), shown in the left, middle, and right panels, respectively. For the F435W and F606W dropouts, we do not plot the objects at z> 5.0 and z> 6.0, respectively. The galaxies indicated with the red squares are not in the full targeted redshift range, but are restricted to narrower ranges (see also Fig. 24). The solid and dashed black lines are the boundaries of the selection criteria from Stark et al. (2009, 2010). The dashed black lines are shown because they are at the outside of the plotting regions in Stark et al. (2009, 2010). The solid red lines are our empirically redefined new selection boundaries to gain more galaxies in the targeted redshift ranges. The model tracks for the F850LP magnitude in the F775W dropout diagram is computed for an absolute magnitude of −22 mag. The 5σ limit of the F850LP magnitude is 28.9 mag (Rafelski et al. 2015).

Open with DEXTER
In the text
thumbnail Fig. 24

Similar to the right panel of Fig. 22 but for investigating the fractions of galaxies that meet the dropout conditions at z ~ 3.5, z ~ 5.0, and z ~ 6.0, shown in the left, middle, and right panels, respectively.

Open with DEXTER
In the text
thumbnail Fig. 25

Same plots as Fig. 24, but for our empirically redefined new selection boundaries shown in Fig. 23 with the red lines.

Open with DEXTER
In the text
thumbnail Fig. 26

Examples of the outliers in the F435W (top panel), F606W (two middle panels), and F775W (bottom panel) dropout selections. In each panel, a spectral energy distribution using the HST photometries is shown at the top left, a zoomed-in part of the Lyα detected wavelength region is presented at the top right, and thumbnail HST images of the object are shown at the bottom. The object ID, MUSE spec-z, and the colors of each galaxy can be found at the top of each panel.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
