Appearance of dusty filaments at different viewing angles
^{1} European Southern Observatory, KarlSchwarzschildStr. 2, 85748 Garching, Germany
email: rox.chira@gmail.com
^{2} MaxPlanck Institute for Astronomy, MPIA, Königstuhl 17, 69117 Heidelberg, Germany
Received: 22 December 2015
Accepted: 18 May 2016
Context. In recent years, there have been many studies on the omnipresence and structures of filaments in starforming regions, as well as their role in the process of star formation. These filaments are normally identified as elongated fibres across the plane of the sky. But how would we detect filaments that are inclined?
Aims. We aim to learn more about whether, and how, total column density or dust temperature change with respect to the line of sight. These variations would enable observers to use dust observations to identify and study filaments at any inclination and gain more insight into the distribution and orientations of filaments within the Galactic plane.
Methods. As a first step, we perform numerical calculations on simple cylindrical models to evaluate the influence of filament geometry on the average flux density. After that, we apply our threedimensional Monte Carlo dustradiative transfer code on two models of starforming regions and derive maps of effective total column density and dust temperature at different viewing angles.
Results. We only see slight changes of average flux density for all cylinders we study. For our more complex models, we find that the effective dust temperature is not sensitive to viewing angle, while the total column density is strongly influenced, with differences exceeding an order of magnitude. The variations are not injective with the viewing angle and depend on the structure of the object.
Conclusions. We conclude that there is no single quantity in our analysis that can uniquely trace the inclination and threedimensional structure of a filament based on dust observations alone. However, observing wide variations in total column density at a given effective dust temperature is indicative of inclined filaments.
Key words: radiative transfer / dust, extinction / ISM: structure
© ESO, 2016
1. Introduction
Recently, studies molecular clouds have focused more and more on their filamentary structure (e.g., Men’shchikov et al. 2010; Arzoumanian et al. 2011; Peretto et al. 2012; André et al. 2014). These studies have revealed that filaments are omnipresent at all scales and regulate starforming activities by carrying gas from the clouds to the cores.
At all wavelengths, in both extinction and absorption, filaments are identified as elongated structures on the plane of the sky. In particular, interstellar dust is an excellent tool for tracing denser parts of the interstellar medium (ISM), as well as for determining the mass and temperature distributions of molecular clouds and filaments. For example, Ragan et al. (2014) and AbreuVicente et al. (2016) used the high extinction caused by dust grains to identify very long filaments as extended (>1°) dark features in Spitzer and UKIDSS observations. Similarly, Wang et al. (2015) found very elongated structures (meaning structures that are at least ten times longer than wide) with high contrasts and systematically lower temperatures than their surroundings using Herschel HIGAL data.
Filaments discovered by column density mapping data must be confirmed by line observations to ensure that they are coherent in velocity. Since dust emission lacks any dynamical information, the twodimensional structures we observe in column density do not necessarily trace real threedimensional (3D) filaments, but can also be a result of superpositions along the line of sight (Juvela et al. 2012a; Smith et al. 2014).
Besides, it still has to be verified whether dust extinction and emission observations reflect the same structures and whether those structures reveal all of the true filament. A way to disentangle this problem is to combine dust observations with radiative transfer (RT) calculations. Juvela et al. (2012a) and Smith et al. (2014) applied RT on filaments formed within their (magneto) hydrodynamical models and found that the column density profiles of resolved filaments obtained from their synthetic images were similar to observed ones, suggesting that RT effects are negligible. This is not the case when the filament is located further away and becomes poorlyresolved. Moreover, they project their filaments in such a way that their long axes are seen in the plane of the sky. Assuming that we can find all filaments by looking for elongated, highdensity structures implies that they have preferential locations and directions within the Galactic disk. This is not necessarily the case and may exclude a notable fraction of filaments.
To confirm the 3D coherence of a filament regardless of inclination, we still need line observations with highly resolved velocity spectra. However, dust observations by Spitzer (3.6−160 μm) and Herschel (70−500 μm) and groundbased surveys as ATLASGAL (870 μm) are available in high quantity and, hence, the starting point for identifying objects of interest. The questions we attempt to answer in this paper are: Would we recognise inclined filaments in dust observations? What are the signatures of inclined filaments in the far infrared (FIR) and submm observations? And are variations along different lines of sight significant enough to be detectable?
In Sect. 2, we examine simple, isothermal cylinders and show sight line effects based on different geometries. In Sect. 3 we introduce the RT code that we use to model dust temperature and emission of our more complex filamentary models in Sect. 4. The results and conclusions are summarised in Sect. 5.
2. Cylindrical filaments
Fig. 1
PDFs showing the 250 μm flux density, F_{250 μm}. From left to right, the plots show the PDFs of the homcyl, cyl, and cylsph models, all at (θ, ϕ) = (0°, 0°) and T_{iso} = 10 K. The black lines show the Rayleigh distributions fitted to the PDFs. The fitted mean values are marked with red lines. These plots illustrate how the flux density is concentrated towards the upper (homcyl) or lower range (cyl, cylsph) of the distributions.

Open with DEXTER
Fig. 2
Mean flux density, log _{10}(), of homcyl, cyl, and cylsph as function of temperature, inclination, and position angle. The error bars illustrate the errors of the mean value. We present the results for θ and ϕ at 0°, 45° and 90°. The lines are interpolations that represent the true values well. Note that the curves for ϕ = 45° and 90° may overlap in Figs. 2b and c.

Open with DEXTER
2.1. Model description
We start by analysing simple, isothermal models whose structure can be described analytically. These models are used to explore how the mean flux density varies as a function of the viewing angle. Since the dust is isothermal and optically thin at FIR and submm wavelengths (see Table 1), the mean column density is expected to vary similarly with the mean flux density. These simple models provide insight into the behaviour of the mean column density before we consider more complex models in Sect. 4.
We need to keep in mind that the flux density can only be observed relative to the fore and background emission and is influenced by many other parameters, like dust properties, observational noise or, essentially, by the way observational data are treated (as we will see and discuss at the end of Sect. 4.2). This is the reason why we focus on variations in mean flux densities relative to the initial sight line only instead of analysing absolute values.
We model filaments as cylinders (since it has been done before by, for example, Ostriker 1964) and consider three models: (a) a homogeneous, constant density cylinder (homcyl) that represents a coreless filament; (b) a cylinder with a powerlaw radial density profile (cyl) that reflects a more realistic filament without a core; and (c) a cylinder that includes a sphere with both having a powerlaw radial density profile (cylsph) that mimics a fragmented filament.
Our radial density profiles are based on Plummer functions (Plummer 1911; Nutter et al. 2008) and are given by (1)where ρ_{c} and ρ_{s} are the central gas densities and p_{c} and p_{s} the powerlaw exponents of the density profile of the cylinder and sphere component respectively, and R_{flat} defines the region where the density in the inner part of the cylinder is relatively constant. For our calculations, we assume a gastodust mass ratio R = 100 and compute the dust density = ρ_{i}/R. The quantity r_{0} represents the position vector of the central cell of the sphere. We note that the sphere component only contributes within its radius r_{s} ≥  r−r_{0} . We generate model cylinders with n_{x}, n_{y}, and n_{z} grid elements, each having the edge length l_{cell}, in x, y, and z direction, respectively. Table 1 provides the parameters we use for our calculations. These parameters are consistent with those Arzoumanian et al. (2011) find on average for nearby filaments.
The dust is set to be isothermal with temperature T_{iso}, which we vary between 10 K and 20 K. We rotate the models by 0°, 45°, and 90° in inclination, θ, and position angle, ϕ, to look at the structures from different line of sights (LoSs).
At each sight line and for each temperature, we produce flux density maps at λ = 250 μm analytically using (2)where B_{λ} is the Planck function at the wavelength λ, T_{d} is the dust temperature, κ_{λ} the dust opacity at λ, μ_{H2} = 2.33 the mean molecular weight per hydrogen molecule, m_{p} the proton mass, and N_{tot} the total column density along the LoS.
Interestingly, the scale we have chosen for R_{flat} is equal or smaller than l_{cell}, which means that the flattened region of the distributions cannot be resolved. We tested our results by varying the ratio of R_{flat}/l_{cell} and found that our results are not affected by resolution.
2.2. Flux density spectral energy distribution
Figure 1 shows the flux density PDFs of homcyl, cyl, and cylsph at T_{iso} = 10 K and (θ,ϕ) = (0°,0°). In case of homcyl, 90% of all pixels have values close to the peak flux density (see Fig. 1 left). Because of the homogeneous density distribution the flux density of homcyl is mostly peaked. In cyl and cylsph, only a small fraction of the models contain dust at higher density owing to the steep density gradient. This means that the flux density PDFs are dominated by the lowdensity regime (see Fig. 1 middle and right). The sphere within cylsph contributes to the flux density PDF (within 10^{2.2}−10^{2.8} Jy sr^{1}), but makes up only a small fraction of the whole volume.
To quantify the flux density PDFs, we fit Rayleigh distributions to them which are given by (3)where A is a scaling factor for the amplitude, x_{0} is a parameter shifting the distribution along x and σ is the standard deviation. The mean value , which is equivalent to the position of the distribution peak, is given by . Since the standard deviation is small compared to x_{0}, the mean value is dominated by x_{0}. We still use the distribution mean value for our analysis. In Fig. 2 we show the mean values of the flux density PDFs, , as function of dust temperature, inclination, and position angle.
We note that from now on we discuss only the behaviour of the mean values. The mean value is certainly the most favourable statistical parameter to compare with observational studies since it is commonly used, reflects the overall characteristics of the object, and is less affected by resolution effects.
Alternatively, we use the maximal flux density of the distribution or its standard deviation. The advantage of looking for the areas of maximal flux density is that it is the most straightforward way to identify the most dense or warmest regions within a filament (for instance, the maximal flux density would be the best parameter in differentiating between cyl and cylsph).
The standard deviation σ (see Eq. (3)) is more promising than the maximal flux value to describe the overall properties of the models. We find that there are variations in σ for sight lines along ϕ = 0° and ϕ > 0° (meaning both ϕ = 45° and 90°). These variations are less revealing since they are independent of the dust temperature. Thus, contrary to the mean value, we would miss insights in the evolution of the filament. Furthermore, the variations are not uniform. While σ increases from 0.01 Jy sr^{1} along ϕ = 0° to about 0.13 Jy sr^{1} along ϕ> 0° for homcyl, it decreases for cyl and cylsph from 0.13 Jy sr^{1} along ϕ = 0° to about 0.05 Jy sr^{1} along ϕ> 0°. This means that the changes are indeed significant in numbers, but they also depend on how the matter is distributed. Additionally, a sampling of σ requires the filament to be wellresolved, which might become a problem the fainter and further it is located from us.
For our test cases, we see that the mean flux increases with increasing temperature. For a given temperature, the average variations are on the order of 0.2 dex, which corresponds to a factor of about 1.58. This is in agreement with Arzoumanian et al. (2011) who predicted that their observed column densities are on average overestimated by a factor of ⟨ cos(θ)^{1} ⟩ = π/ 2 ≈ 1.57 owing to the unknown inclinations.
In homcyl, we see that the mean flux density is mostly constant, with small variations within 0.2 dex. In the case of cyl and cylsph (Figs. 2b and c), the variations are slightly larger, but not on the order of 0.3 dex (corresponding to a factor of 2.0). In general, the mean flux density decreases with increasing inclination. This is because the area within the flux density is amplified, due to larger amounts of dust along the LoS, because smaller and statistically less significant. Thus, the PDFs are even more dominated by the more diffuse dust, decreasing the value of .
When comparing the results of cyl and cylsph, we see no contribution of the sphere to . This means that the sphere is too small compared to the whole cylinder that dominates the total flux. We performed additional tests and found that increasing the density by several order of magnitude of the sphere alone does not have any impact. If we insert more spheres such that the spheres contain at least 10% of the total mass of the models, we see notable fluctuations in the mean flux density. This means that, as long as a core is small in size and mass compared to the filament, it can only be studied directly by removing the filamentary background. For example, Montier et al. (2010) filtered the local background from PlanckHFI maps to reduce the influence of largescale structures on the source detection and build up their Planck catalogue of cold cores. This is comparable to using the maximum flux density to identify objects of interest instead of the mean flux density.
In summary, we predict little to no variations in the mean flux density PDFs for elongated cylindrical structures based on their geometry. They are not significant enough to allow conclusions on viewing angles based on dust observations alone. We neither see significant changes in the PDF distributions when inserting a corelike sphere into our cylinder. This implies that as long as a single core does not contain a significant fraction of the mass compared to its surrounding filament it does not influence the average properties of the whole filament.
3. 3D Monte Carlo dust radiative transfer code
We use a threedimensional (3D) vectorised Monte Carlo (MC) code by Heymann & Siebenmorgen (2012), which is based on the original radiative transfer code of Krügel (2008) to model realistic filaments. The code is specialised for radiative transfer (RT) of dust and computes selfconsistently the temperatures of the dust species. The program keeps track of all scattering and absorption/reemission processes, and produces flux density maps at requested viewing angles.
The code includes different methods for optimising performance such as the iterationfree method by Bjorkman & Wood (2001). If a photon package is absorbed, this method ensures that the whole energy of this package is used to heat the dust with respect to previous absorption events. After the dust temperature of the cell is adjusted, the energy is reemitted as a new photon package (see Bjorkman & Wood 2001 for more details; as well as Baes et al. 2005; Krügel 2008).
We extend MC to utilise arbitrary density structures that are heated isotropically by an external radiation field (ERF) by photon packages that are launched from the outer walls. The launching points are computed for each photon package individually by setting them randomly onto the surface of the data cube. The initial direction of each photon package is calculated such that the resulting external radiation field is isotropic (see also Appendix A).
Contrary to point sources, the luminosity of an ERF depends on both the total flux density, (4)where represents the flux of the ERF at the frequency ν, and the surface area of the cube, A_{tot}, that emits the flux. For controlling the luminosity, we introduce the scaling factor w. The total luminosity, L_{ext}, is then given by: (5)In this way, any ERF can be used.
In Appendix B we provide a detailed description of the benchmark runs we have performed to verify the correctness of our implementations.
4. Filaments as seen at different viewing angles
Fig. 3
3D images of the dust density distribution of the ρ Ophiuchi (based on Kainulainen et al. 2009) and G11.11 models (based on Kainulainen et al. 2013). The models consist of a number of small, dense clumps that are surrounded by diffuse envelopes. Note that we only plot the most dense parts of the models and not the more diffuse envelopes since those would obscure the central clumps and cores. The real range of total column densities and dust temperatures are summarised in Table 3.

Open with DEXTER
Next, we study the sight line effects on models that are more complex in both their density and temperature structures and represent real filaments better than the cylinders in Sect. 2 do. We use MC to derive the dust temperature and emission in the FIR and submm selfconsistently (contrary to the isothermal models we studied in Sect. 2). We discuss two main questions: Firstly, how would we observe filamentary structures at different viewing angles? Secondly, are there observational criteria, such as the dust temperature and total column density, which enable us to reconstruct elongated structures along the LoS by dust observations alone?
Statistical summary of derived parameters based on the ρ Ophiuchi and the Snake models.
We use two 3D models of molecular clouds that estimate the volume density distributions by fitting a superposition of spheroids on observed column density maps. Figure 3 shows 3D images of our models, one based on the ρ Ophiuchi cloud (Fig. 3a, Kainulainen et al. 2009, 2014) and the other on the G11.11 Snake filament (Fig. 3b, Kainulainen et al. 2013, 2014). In both models, the xyplane is the plane of the sky and the zaxis represents the LoS. Table 2 lists the basic parameters we used for our simulations and Table 3 provides a summary of the volume and column density, dust temperature, and mean flux density statistics of both models.
We derive dust temperatures, assuming that the dust is only heated by an external, isotropic heating field. We use the model of interstellar radiation field (ISRF) by Mathis et al. (1983). Their ISRF consists of a combination of three diluted blackbody spectra, with effective temperatures of 7500 K, 4000 K, and 3000 K, and an additional UV excess (Mathis et al. 1983). We produce images by raytracing (see Heymann & Siebenmorgen 2012) at 881 wavelengths within a range from 0.43 Å to 1.2 cm. To reduce the MC noise we use 5 × 10^{4} and 10^{6} photon packages per frequency grid point for the ρ Ophiuchi and Snake model, respectively. Previous tests have demonstrated that this is sufficient to sample the temperature within all cells continuously, which is reflected by a noiseless spectrum.
Using only the ISRF as the heating source is a simplification. The ρ Ophiuchi cloud, for example, is a site of active star formation (Wilking et al. 2008) that heats the cloud internally, which leads to significant temperature gradients. Recognising this caveat, we focus on a simple external heating field only.
As a dust model we use a mixture of amorphous carbon (aC) and silicates (Si) dust grains. The grain sizes range between 16 to 128 nm and 32 to 256 nm for aC and Si grains, respectively, and follow the size distribution with number density ∝ a^{3.5} da (Mathis et al. 1977). The crosssections and opacities are based on the dust models of Siebenmorgen et al. (2014). We choose spherical grains and abundances relative to H_{2} of χ_{aC} = 2.5 × 10^{3} and χ_{Si} = 4.8 × 10^{3}, respectively. This ratio is consistent with typical values of dust in the interstellar medium in the solar neighbourhood (Dwek 2005).
We are aware that our dust grain model is a simplification, as well. Studies by, for example, Ossenkopf & Henning (1994), Stepnik et al. (2003), Steinacker et al. (2015), Lefèvre et al. (2016) indicate that dust grains in dense parts of the ISM grow to larger aggregates. In the future, we will extend the parameter space to study the influence of other grain models. For now, we keep our simplified setup and focus on analysing filaments at different viewing angles.
We consider 40 different directions by varying the inclination, θ, between 0° and 315° and position angle, ϕ, between 0° and 180°, both in steps of 45°. We focus our analysis on the FIR and submm part of the spectrum since this part is dominated by the thermal emission of dust. To mimic Herschel observations at the Herschel SPIRE bands (250, 350, and 500 μm) we smooth the flux density maps to the resolution of the SPIRE 500 μm data using Gaussian pointspread functions. For each pixel of the synthetic intensity maps, we fit a modified black body to the flux values at λ = 250, 350 and 500 μm, following the descriptions in Könyves et al. (2010, see Eq (2. We assume a mass absorption coefficient κ_{ν} = 0.1 cm^{2} g^{1}. For the dust emissivity index, β, we use 1.75 (Könyves et al. 2010; Wang et al. 2015). The results we discuss in the following sections are based on this value. We have performed the same analysis with β = 2.0 and recover similar results within the typical observational uncertainties.
We use the idl routine mpfitfun (Markwardt 2009) to perform the fittings, with the effective dust temperature and total column density as parameters. The resulting maps are shown in Appendix C. Figure 4 presents results based on the ρ Ophiuchi model, including flux density, effective column density, and effective dust temperature maps at (θ,ϕ) = (0°, 0°) and (45°, 45°).
We note that and are not direct results of the RT simulations, but derived by SED fitting of three data points and assuming a powerlaw opacity relation (κ ∝ ν^{β}). This method introduces some degree of degeneracy. For this reason both quantities are less accurate than the values that result from the RT procedure. We find a correlation between the real column density, which we computed directly from the input volume density distribution, and the effective column density derived by SED fitting which is lost by some scatter owing to the inaccuracies of fitting an entire SED to three points with only one single temperature.
However, and are equivalent to dust temperatures and column densities that are derived from observed fluxes.
4.1. ρ Ophiuchi model
Fig. 4
Results based on the ρ Ophiuchi cloud model at (θ, ϕ) = (0°, 0°) (top) and (θ, ϕ) = (45°, 45°) (bottom). From left to right the figures show the maps of synthetic intensity at 250 μm, maps of effective total column density with corresponding PDFs, and the maps of effective dust temperature with corresponding PDF. The contours in the maps are at {0.82,1.0,1.15,1.32,1.5}, {22.0,22.32,22.72,23.0}, and {10.5,11.0,11.5,12.0} K. The red lines in the PDFs indicate the arithmetic mean values of the distributions, the blue lines the median values.

Open with DEXTER
Fig. 5
ρ Ophiuchi cloud model. The plots show the mean values of the effective total column density PDFs, , as a function of the inclination, θ, and position angle, ϕ. The error bars illustrate 1σ errors. Note that we only show the values for inclinations θ ≤ 180° because the values for θ and θ+180° are identical. We see that the mean dust column density strongly depends on the viewing angle. The maximal difference compared to (θ, ϕ) = (0°, 0°) is on the order of 1.7 dex.

Open with DEXTER
Fig. 6
ρ Ophiuchi cloud model. Like Fig. 5 relating to the mean values of effective dust temperature PDFs. does not depend strongly on the viewing angle.

Open with DEXTER
Figures C.1 and C.2 show maps of effective dust temperature and total column density respectively, based on the ρ Ophiuchi model. We find similar results along a given LoS (front → back compared to back → front), just mirrorinverted (e.g., maps at (θ, ϕ) = (0°, 0°) and (180°, 0°)). As long as the dust is optically thin we see the same profiles both ways. For molecular lines, however, the sight line will make a significant difference (e.g., Chira et al. 2014).
Looking at our model along different LoSs, we see significant changes in the morphology. The more we incline the object the clumpier and more elliptic the morphology becomes. This is expected based on the structure of the input model.
We observe that the effective total column density of the central region becomes higher while its gradient becomes steeper the more we incline the model. The central effective dust temperatures, however, do not change significantly, whereas the profile becomes flatter. Figure 4 shows a detailed example in which we plot maps of synthetic 250 μm flux density, F_{250 μm}, the effective total column density, , and effective dust temperature, , as seen at (θ, ϕ) = (0°, 0°) and (θ, ϕ) = (45°, 45°), as well as the respective PDFs. We note that since the dust is optically thin in the FIR the flux and column densities behave in the same way. This is why we focus our discussion on .
The effective column density is concentrated towards the longest axis of the model at (θ, ϕ) = (45°, 45°) compared to (θ, ϕ) = (0°, 0°), leading to higher intensities at similar effective dust temperatures. If one compares the regions enclosed by the contours at both viewing angles one can identify the same structures at (θ, ϕ) = (45°, 45°) as in (θ, ϕ) = (0°, 0°) (considering the influence of to rotation), but at higher values in the case of the intensity and effective column density. In the case of effective dust temperature, the respective regions are indicated by the contours of the same values.
At (θ, ϕ) = (0°, 0°), the PDFs for both the effective total column density and dust temperature are lognormal with a peak at cm^{2} and K. The PDFs of (θ, ϕ) = (45°, 45°), however, have the shape of a lognormal distribution with a powerlaw tail towards lower column densities and higher dust temperatures, peaking at cm^{2} and K.
The main point that can be deduced from this result is that observing filaments along different sight lined do not fake typical signatures of star formation in column density PDFs (cf. Schneider et al. 2013; Stutz & Kainulainen 2015). The tails towards lower column densities in the PDFs are normally within the noise range and cut during the data reduction process. We discuss this in Sect. 4.2 in more detail.
In Figs. 5 and 6 we plot the values of and from fitting Rayleigh distributions to the PDFs (see Sect. 2) as a function of viewing angle. We find huge variations in compared to the noninclined sight line (θ, ϕ) = (0°, 0°). The maximal is detected at (θ, ϕ) = (45°, 135°) and (135°, 135°) at a factor of 50 higher than the (θ, ϕ) = (0°, 0°) case. These average column densities are clearly above the average range of mean total column density in the literature (5 × 10^{20}−3.16 × 10^{22} cm^{2}Könyves et al. 2010; Juvela et al. 2012b; Palmeirim et al. 2013; Roy et al. 2014).
In contrast, the variations of are below 0.5 K. These differences are on the same order as typical noise levels and would not be significant enough to make any profound statement about the viewing angle. For a fixed θ = 0°, the remains constant. All values for here are within a range that agrees with observational findings of prestellar cores and filaments (10−15 K, e.g. Juvela et al. 2012b).
Comparing the results of the ρ Ophiuchi model with those in Sect. 2, the closest model with respect to the density profiles would be cylsph. We argue that the differences in behaviour result from the fact that the ρ Ophiuchi model is dominated by its irregular, clumpy structure which makes it more sensitive to changes in the viewing angles than a smooth, regular structure. Furthermore, the total model of ρ Ophiuchi is not isothermal, unlike the individual spheroids. Since the individual spheroids are approximately homogeneous, the ρ Ophiuchi model can be described as a superposition of homcyllike elements which, however, has not shown significant variations along different sight lines as we observe them for the ρ Ophiuchi model.
Thus, more complicated structures are more significantly affected by changes in orientation and geometry. However, the column density alone is not enough to trace back the inclination of an observed filament. Only a significant increase in column density at a constant average dust temperature can give hints on how the matter is distributed along a given LoS.
Just inclining the model does not change the thermal processes (heating, cooling) within the object. If the density within the object increases (for example, by collapsing material) the dust is cooled more efficiently and decreases before the first protostar is formed. Thus, if and do not behave antiproportionally, this indicates that the object is elongated along the LoS. In this case, it is necessary to reconstruct the density distribution along the LoS by line observations.
4.2. G11.11 Snake model
Fig. 7
Like Fig. 5 but for the G11.11 Snake model. We see a strong dependence of the on the viewing angle. The differences compared to (θ, ϕ) = (0°, 0°) are on the order of ~1.2−2.5 dex.

Open with DEXTER
Fig. 8
Like Fig. 6 but for the G11.11 Snake model.

Open with DEXTER
Fig. 9
Comparison of (effective) total column density PDFs of Snake based on data of this work (left) and Wang et al. (2015, right. The black lines show the original data of the simulation and observation, respectively. The greyshaded area on the left plot indicates the range that would be below the detection limit of Herschel. The bluedotted line in both images indicates the cut limit which is used for noise reduction. The solid blue line in the right plot shows the total column density PDF based on the masked intensity maps.

Open with DEXTER
Fig. 10
Like Fig. 7 but based on the masked maps of the G11.11 Snake model. We see that the behaviour here is, in general, the same as before, just the values and differences are lower due to the intensity cut.

Open with DEXTER
Fig. 11
Like Fig. 8 but based on the masked maps of G11.11 Snake model. We see that the is approximately constant for all viewing angles, but variations between different sight lines are larger.

Open with DEXTER
We repeat the analysis for the Snake model and show the maps of effective dust temperature and total column density in Figs. C.3 and C.4, respectively. We note that we only print the maps within (0° ≤ θ ≤ 135°, 0° ≤ ϕ ≤ 180°) owing to the symmetries we have already discussed in Sect. 4.1.
We observe that rotations do not skew the projected morphology of Snake as much as it has done for ρ Ophiuchi. At all viewing angles (except θ = 90°), we can see the sinusoidal structure which is typical for the Snake, although its amplitude slightly changes. The distribution of effective dust temperature, however, remains approximately constant, as has been the case for ρ Ophiuchi. The values of the average effective dust temperature (see Fig. 8) vary within 0.8 K, which is insignificant in terms of observational uncertainties (e.g., Juvela et al. 2012b).
As with the ρ Ophiuchi model, we see significant variations in effective total column density with viewing angle. As plotted in Fig. 7, the values of at (θ, ϕ) = (0°, 0°) and (θ, ϕ) = (0°, 45°) change by almost two orders of magnitude. In general, we observe an increase in by factors of between 16 and 320 compared to (θ, ϕ) = (0°, 0°). The steepest rise is found when rotating the model between (θ, ϕ) = (0°, 0°) to positions with θ = 45° or ϕ = 45°. For steeper angles, the column densities do not change as significantly.
Thus, the distributions of effective total column density and dust temperature of the Snake model behave similarly to our ρ Ophiuchi model. The elongated structure of the model amplifies the variations of the small components in two ways; firstly, the rises higher along the LoS, which is parallel to its long axis than along other sight lines; secondly, the radial temperature gradient is larger since the filament is too thin and not dense enough to be isothermal.
Compared to the results in Sect. 4.1, we note that the errors of the mean values of the distributions are larger than before. We can explain that by having a closer look at the PDFs, for which Fig. 9 shows an example. In the left panel we plot the effective total column density PDF (black line) of our Snake model as observed at (θ, ϕ) = (0°, 0°). We see that the PDF splits into three peaks in total; two at higher column densities (~ 3.2−5 × 10^{21} cm^{2}), which are relatively close to each other and a third peak at low column densities (~5 × 10^{20} cm^{2}). A similar profile is seen with the effective dust temperature PDF. Since we only fit a single Rayleigh distribution to the PDF, this is a major source of the uncertainties.
Of course, we could reduce the errors by fitting a superposition of Rayleigh distributions for each component. However, in terms of physical interpretation that would mean that we assume that the model consists of at least three independent components. Furthermore, finding these peaks has already been unexpected since there is no hint in the literature that this structure has been observed for the real Snake cloud.
We conclude that this is due to observational limitations and reduction processes (Ke Wang, priv. comm.). On the right side of Fig. 9, we plot the total column density PDF derived by Wang et al. (2015). The black solid line shows the column density PDF derived from the unmasked (calibrated, but not noisereduced) intensity map, and with the blue solid line the PDF for the masked map. The blue dashed line indicates the level at which the originally observed intensity maps have been cut in the masking process.
For the Wang et al. study, fluxes corresponding to total column densities below 2.5 × 10^{21} cm^{2} are below the sensitivity limit of Herschel and would not be observed. We indicate this part with a grey box in our PDF (Fig. 9, left plot). This means that we could detect the two peaks at higher column densities with observations, but not the third one at low column densities. This is consistent with the fitting routine of Kainulainen et al. (2014), which weights the highest column density regimes more than the low column density parts. Thus, the lower peak belongs to the parts of the observations that lie within the noise and is cut off during the noise correction process. Applying all these factors, we end up with a singlepeak PDF which agrees with the observed findings.
We note that the peak positions in the PDFs of Wang et al. and this work are not the same. First, our model filaments were derived from extinction maps in the NIR, whereas Wang et al. (2015) used emission maps in the submm. Even though these techniques result in column densities that on average are in agreement (e.g., Kainulainen et al. 2013), regional differences may exist. On the one hand, extinction maps are limited at high column densities whereas emission maps are most sensitive there. On the other hand, emission maps are more temperaturedependent than extinction maps.
Second, our models are only heated externally. Both Henning et al. (2010) and Wang et al. (2015) show that this does not match reality. The Snake filament contains cores that are associated with protostars and ongoing star formation processes. While the results of cylsph in Sect. 2 suggest that missing individual cores does not affect the column density statistics of the filament, a larger population of cores would contribute to the incoming radiation field if they contain embedded sources and thus change the outputs of the RT code. Moreover, we do not consider the temperature gradient in cylsph, which would be expected for the Snake filament. The influence of different external heating fields and/or internal heating sources needs to be investigated in more detail in future studies.
We test the significance of noise by cutting the noise level from our flux maps and then repeat the analysis of the resulting PDFs. The results for the and are plotted in Figs. 10 and 11, respectively. We find that the effective total column density are lower than before, by about one order of magnitude, whereas the effective dust temperatures keep relatively constant although the variations become larger.
5. Conclusions
In this paper, we have investigated the dependence of effective total column density and dust temperature of filaments on the viewing angle.
As a first step, we have analysed the behaviour of flux density profiles of simple cylinders as a function of viewing angle and dust temperature. We have found that the mean flux density rises with increasing dust temperature, but it is not significantly influenced by changing the viewing angle.
Next, we have analysed 3D models of the ρ Ophiuchi cloud and the G11.11 Snake filament and performed radiative transfer calculations to compute images for 40 different viewing angles. We have focused our analysis on the frequencies that are within the Herschel SPIRE bands and derived the effective dust temperature, , and total column density, , for each pixel by SED fitting.
We have found that the is approximately constant, whereas changes significantly, especially when we rotate the models into the direction where their long axis is parallel to the LoS. Since the dust emission is optically thin, the column densities strongly depend on the viewing angle. The dust temperature is determined by the local heating and cooling processes, which is unchanged when we rotate the models.
We have briefly investigated how sensitivity limits and noise corrections influence our results. We have found that common data reduction processes reduce the level of variation in column density. The variations in effective dust temperature have increased, but have been still insignificant enough in the observational context.
We conclude that there is no quantity in our analysis related to dust emission that tracks the inclination of a filament uniquely. A notably high column density at a given dust temperature can indicate that an observed object is elongated along the LoS direction. For true inclinations and confirming masses, line observations are required. However, with all the data obtained by dust surveys and our findings, it is possible to identify candidates of filaments which may be elongated along the LoS. This is important to learn more about the distribution and orientation of filaments in the Galactic plane, which improves our understanding of the role of filaments within the star formation process.
