1. Introduction

The study of the star formation histories (SFH) of galaxies is an essential element in understanding their past evolution. How the baryonic component of a galaxy has formed and evolved should be reflected in its stellar populations. Because of observational constraints, different methodologies are applied to the study of the stellar content in galaxies (see Peletier 2013, and references therein). Intrinsically, these methodologies are very different and are affected by different sources of errors.

Deep colour-magnitude diagrams (CMD) reaching the oldest main-sequence turnoff (oMSTO) are generally regarded as the most direct and reliable observables that can be used to obtain a detailed SFH of a galaxy (Gallart et al. 2005). At magnitudes brighter1 than the oMSTO, stars along the main sequence are distributed in a sequence of age: short lived, young, massive stars are the bluest and brightest, and less massive and therefore longer lived stars are progressively fainter and redder. While there remains some age-metallicity degeneracy in the positions of the stars on the main sequence, it is significantly less than that seen in other stellar evolutionary phases such as the red giant branch (RGB) or the horizontal branch. In such features, the position of the stars are mainly determined by metallicity and there is very little age sensitivity. By combining the information of the position of the stars in the main sequence of a CMD reaching the oMSTO with the number counts across it, it is possible to minimize the remaining age-metallicity degeneracy and obtain accurate, detailed, and reliable SFHs, including information from the early times of the galaxy’s history (e.g. Gallart et al. 1999; Dolphin 2002; Cole et al. 2007; Noël et al. 2009; Monelli et al. 2010a,b; Hidalgo et al. 2011; de Boer et al. 2012; Meschin et al. 2014; Skillman et al. 2014). However, this kind of analysis has been limited to a few dozen nearby systems, those within a distance of 1–2 Mpc (see McConnachie et al. 2005, for an updated census of the Local Group, and the distance of its members to the Milky Way). The wide variety of morphologies and characteristics found in galaxies forces us to study systems at larger distances where the analysis of individual stars is unfeasible. In these systems, because of the limited spatial resolution, we need to derive the stellar content using colours or spectral information coming from integrated stellar populations (e.g. de Jong 1996; MacArthur et al. 2004; Pérez & Sánchez-Blázquez 2011; Sánchez-Blázquez et al. 2011, among many others).

In order to characterize the composite stellar populations of unresolved galaxies, and in particular of galaxies at high redshift, significant effort has been made since the early 1980s to interpret integrated stellar populations (e.g. Pickles 1985; Bica 1988). Broadband colours were first used to distinguish between old/young, metal poor/rich stellar populations (Searle et al. 1973; Tinsley & Gunn 1976; Peletier & Balcells 1996). However, this type of analysis is affected by the known age-metallicity degeneracy and the effect of dust (e.g. Worthey 1994; Ganda et al. 2009). Spectroscopic analysis can help to minimize that degeneracy. The very first spectroscopic approach was developed by de Vaucouleurs & de Vaucouleurs (1959), later followed by Spinrad (1962) and Alloin et al. (1971). The use of line equivalent widths or line-strength indices, taking into account their dependence on metallicity and age, became popular in the 1980s and 1990s (e.g. Rose 1984; Faber et al. 1985; Bica & Alloin 1986a,b; Bica 1988; Gorgas et al. 1993; Worthey 1994; Bica et al. 1994; Vazdekis et al. 1996; Worthey & Ottaviani 1997; Kauffmann et al. 2003). Indices have been used to obtain single stellar population (SSP) equivalent values (age and metallicity) or even to derive the whole SFH shape (e.g. Proctor et al. 2000). The use of indices has been relatively successful in the characterization of stellar populations in “simple” systems such as globular clusters or elliptical galaxies (e.g. Peletier et al. 2007; Kuntschner et al. 2010); however, these studies i) are still hampered by the age-metallicity degeneracy hindering the derivation of a reliable SFH; ii) are biased towards the youngest stellar populations that contribute much to the light while involving a small mass fraction; iii) make use of a limited part of the observed spectra; and iv) are quite limited when replicating the whole shape of the SFH. Combinations of different indices allow us to better constrain the stellar information, but this approach is still affected by the above limitations. Other approaches must be used to study the actual shape of the SFH in galaxies with complex stellar compositions.

With the goal of increasing the spectral coverage (and thereby maximizing the information used from the observed spectra) and of being able to reproduce the SFH of complex systems, spectral energy distribution (SED) fitting codes have been developed such as MOPED (Heavens et al. 2000; Reichardt et al. 2001), VESPA (Tojeiro et al. 2007), or STARLIGHT (Cid Fernandes et al. 2005) along with other approaches. In this approach, the overall shape of the observed spectrum is fitted through a combination of stellar population models. These codes are sensitive to problems in the data such as flux calibration or extinction errors because they also take into account the continuum in the fit. At the same time, the first so-called “full spectrum fitting codes” (e.g. Ocvirk et al. 2006b,a; Koleva et al. 2009, STECKMAP and ULySS) became available. These techniques avoid problems in the flux calibration and extinction in the spectra by fitting a polynomial to the shape of the continuum. Both SED and full spectrum fitting codes are better at reducing the impact of the age-metallicity degeneracy than line–strength indices analysis as they maximize the information used from the observed spectrum (Koleva et al. 2008; Sánchez-Blázquez et al. 2011; Beasley et al. 2015). Along with this evolution in the fitting codes, there has been huge progress in the modelling of stellar populations (e.g. Bruzual & Charlot 2003; Lee & Worthey 2005; Schiavon 2007; Conroy et al. 2009; Vazdekis et al. 2010) partly as a result of the improvement of stellar libraries (e.g. Prugniel & Soubiran 2001; Le Borgne et al. 2003; Valdes et al. 2004; Sánchez-Blázquez et al. 2006; Prugniel et al. 2007), isochrones and evolutionary tracks (e.g. Girardi et al. 2000; Pietrinferni et al. 2004, 2013; Bressan et al. 2012), and studies on the IMF (Salpeter 1955; Vazdekis et al. 1996; Kroupa 2001; Weidner et al. 2013b,a; Peacock et al. 2014).

Various works have tested the various SED and full spectrum fitting codes using artificial spectra (e.g. Cid Fernandes et al. 2005; Ocvirk et al. 2006a; Sánchez-Blázquez et al. 2011; Koleva et al. 2011). In particular, Koleva et al. (2011) test STARLIGHT, STECKMAP, and ULySS with 48 mock spectra with different known SFHs. A general result of these studies is that the final success in the recovery of the stellar population content lies in the quality of the spectrum: the better the S/N and the resolution of the observed spectra, the more reliable the stellar population determination will be.

thumbnail Fig. 1

Left panel: image of the LMC bar and its surroundings (Credit: John Gleason). The location in the centre of the bar of the field studied in this paper is indicated. Right panel: positions of the two WFPC2 fields (red shaded areas), and the 2.5′ × 5′ area covered by sweeping the slit in the east-west direction (blue shaded area), superimposed on a VIMOS B-band image.

Open with DEXTER

To further test the reliability of full spectrum fitting techniques, it is of crucial importance to thoroughly compare the (in principle) more reliable CMD results to those obtained using these codes with actual data. This exercise should reveal where they fail and where they succeed, and thus provide information about the spectral ranges and features that are more likely to improve these techniques. Such analysis is not straightforward. Not only do CMDs containing stars as faint as those on the oMSTO need to be studied, but also high resolution and high S/N integrated spectra must be obtained, which is made difficult by the often low surface brightness of nearby resolved systems. Although previous studies have tried to do something similar in star clusters (e.g. Gibson et al. 1999; Beasley et al. 2002; de Grijs & Anders 2006; Santos et al. 2006; González Delgado & Cid Fernandes 2010; Barber et al. 2014) and in dwarf galaxies (e.g. Makarova et al. 2010; García-Benito & Pérez-Montero 2012), it is necessary to improve those tests by applying them to more complex systems (i.e. systems with complex SFH) with available data of individual stars down to the oMSTO in the CMD.

We have performed such a test using one of the few fully resolved bright galaxies where this test can be carried out, the Large Magellanic Cloud (LMC). In particular, we study a region of the LMC bar as a guinea pig for which we can compare complex SFHs derived through integrated-light synthesis techniques and through the CMD of the resolved stellar population. We emphasize the fact that, in this paper, the SFH in the LMC bar region was derived from the CMD without knowing the results from the integrated spectrum analysis and vice versa, making this a blind test in order to avoid bias towards a common solution by adjusting the fitting parameters.

Throughout this paper we will consider the SFH is composed of three main functions: one is the star formation rate as a function of time, SFR (t); the second is the chemical enrichment history (age-metallicity relation, AMR); and the third is the initial mass function (IMF).

In this paper, we show the LMC bar SFH derived from full spectrum fitting techniques applied to its integrated spectrum and we compare it to the CMD results from Hubble Space Telescope (HST) data. We have focused our work on the STECKMAP results. This code gives a higher probability to smooth solutions (by means of a penalized χ2 fitting algorithm; see Ocvirk et al. 2006b,a, for further information). The smoothness of the recovered SFH makes the comparison with the CMD results easier and more sensible. However, we will also compare the results obtained using other spectral fitting codes such as ULySS and STARLIGHT. In Sect. 2 we explain our target choice, and describe the observations and data reduction procedure used to obtain the composite CMD and the integrated spectrum. In Sects. 3 and 4 we derive the SFH following both approaches and compare the similarities and differences found, with special emphasis on how the final solutions are affected by using different STECKMAP input parameters. Results coming from other codes (ULySS and STARLIGHT) are shown and analysed in Sect. 5. Some caveats, parallel analysis, implications, future work, and main conclusions are discussed in Sects. 6 and 7.

2. Observations and data reduction

To proceed with the comparison between integrated and resolved stellar population approaches in the case of a complex stellar population, we selected a field in the LMC bar (see Fig. 1). The centre of the LMC bar is bright enough to obtain a high quality integrated-light spectrum with high S/N, which we did from observations at the 3.6 m ESO telescope on La Silla using EFOSC2 (Alloin et al. 2002). It is also sufficiently close and resolved for a CMD reaching the oMSTO to be secured with the HST. Such a CMD has been already published by Smecker-Hane et al. (2002) and various SFHs have been derived by different groups, and published in Skillman & Gallart (2002). We present a newly derived SFH with more sophisticated analysis techniques here.

Table 1

Observing log of the photometric data.

When the spectroscopic observations were obtained (15 years ago) the only HST field available with sufficient surface brightness to carry out this project was the field observed with the Wide Field and Planetary Camera 2 (WFPC2). Unfortunately, the poor dynamic range of the camera limits our observations of the brightest stars. However, we can overcome this limitation with the methodology used to analyse the data (see Sect. 3.1).

2.1. Resolved stellar populations

The photometry and artificial star tests necessary to reconstruct the SFH of the LMC bar region were obtained from the HST Local Group Stellar Photometry Archive (Holtzman et al. 2006), maintained by J. Holtzmann2. In particular, we downloaded the data of two WFPC2 pointings, namely the u4b112 and u4b115 fields, located at the centre of the LMC bar (see Fig. 1) and originally observed within the GO programme 7382 (P.I. T. Smecker-Hane). Table 1 details the observing log, including the position of the two fields, the integration time in both the F555W and F814W filters, and the date of the observations.

The (MF814W, MF555WMF814W) CMD is presented in Fig. 2. The photometry reaches down to MF814W ~ 6, well below the oMSTO. A prominent bright main sequence is visible up to MF814W ~ −1, indicating that star formation continued until very recent epochs in this region. The red giant branch (RGB), comprising stars older than ~1 Gyr, is also highly populated up to MF814W ~ −2. Finally, we also highlight the presence of a prominent red clump of centrally He-burning stars (MF814W ~ −0.5), while the old horizontal branch is barely populated. We have indicated four regions in the figure that will be discussed in Sect. 3.1.

The lack of stars brighter than MF814W ~ −1 and MF814W ~ −2, along the main sequence and the RGB, respectively, is likely due to saturation. Visual inspection of the brightest sources in the field confirms that a number of bright stars (~200) are saturated in both filters. The region of the CMD affected by saturation will not be used in the SFH derivation. At the metallicity of the youngest LMC stars, our saturation magnitude of F814W ~ −1 on the main sequence corresponds to the turnoff of a ~0.3 Gyr stellar population. The bright massive stars younger than this age do not appear in the CMD, and this implies that we are not using all the possible information to derive the SFH for these ages. However, because lower mass stars of the same ages are present at fainter magnitudes, the SFH can be still obtained from them, under the assumption of a given IMF.

thumbnail Fig. 2

MF814W vs. MF555WMF814W CMD based on WFPC2 data. The four polygons show the regions used to derive the SFH using the IAC-star/MinnIAC/IAC-pop suite of routines (see text for details).

Open with DEXTER

2.2. Integrated spectrum

Integrated-light spectra of the LMC bar and a sky field were collected at the 3.6 m ESO telescope on La Silla, using EFOSC (Buzzoni et al. 1984), on 18-20 December 2000. The J2000 coordinates of the observed target field are α = 05:23:17 and δ = −69:45:42. We used a north-south 5 long and 1.5′′ wide slit, which was swept along the east-west direction; this allowed us to cover a full area of 2.5 by 5, which approximately matches the WFPC2 pointings (see Fig. 1). Four different grisms were used, spanning in total the wavelength range 3500–8745 Å (see Fig. 3). We smoothed the spectra from the four grisms to a common final dispersion of 1.9 ± 0.1 Å/pix (see Fig. 3). A mean exposure time of 5400 s divided into three separate exposures was adopted for each grism, both for the target field and also for the sky field. The sky-field spectrum was taken 6° north of the target-field position. The sky position was chosen as a compromise between the sky field being relatively close and thus representative of the foreground Milky Way (MW) contamination and sky light present in the LMC bar field, and to mimimize the contribution from LMC light. We note, however, that with a galactocentric radius of at least 16° (Majewski et al. 2009; Saha et al. 2010), even at 6° from its centre, the LMC still presents a highly populated CMD, with many intermediate-age stars (Gallart et al. 2008; Saha et al. 2010).

thumbnail Fig. 3

Composite spectrum of the LMC bar field used in the integrated stellar population analysis. Top row: the spectrum is divided according to the four different grisms used: Blue for grism # 7 (35005185 Å), green for grism # 9 (47256730 Å), red for grism # 10 (62758160 Å), and black for grism # 15 (75658745). For each grism the corresponding sky spectrum, i.e. the spectrum taken in the sky field, has been subtracted. Only the LMC bar contribution is shown here. Bottom row: fully reduced composite spectrum of the LMC bar (black) and fully reduced, emission-cleaned composite spectrum (red). For the stellar content analysis we use the wavelength range from 3800 to 6800 Å (dashed vertical red lines; see text for details). The shaded regions of the spectrum are the masked regions (not considered in the fit).

Open with DEXTER

The 2D spectra corresponding to the four grisms for both the target and the sky fields were reduced through standard techniques, using MIDAS and IRAF3 packages. A full 2D wavelength calibration was built up to correct for geometrical distortions. The spectra were flux calibrated using the spectrophotometric standard EG 21 and LTT 4816; the error in flux calibration is estimated to be around 10%. After this step, the 1D spectra of the four grisms were matched together and the quality of the match controlled through the overlapping wavelength regions.

To check whether small number statistics in the sampling of minority stellar populations in the target field (such as the insertion of a few young stars dominating the final spectrum but with little mass contribution) could lead to significant fluctuations in the SFH, we performed the following test. From the integrated-light, spatially resolved 2D spectra, we extracted two series of integrated-light 1D spectra, one for the target field and one for the sky field, with extraction windows of 5 and of 2.5. We ended up with four 1D spectra over the 3500–8745Å range (FWHM ~ 10 Å), two corresponding to the integrated light in the LMC bar field over spatial areas of respectively 2.5′ × 5′ (field 1) and 2.5′ × 2.5′ (field 2, included in field 1) and the other two corresponding to the integrated light in the sky field with the same extraction windows. At face value, the sky-subtracted spectra of the target field through the two different extraction windows exhibit very similar characteristics. In terms of the shape of their spectra, we scaled the field 2 spectrum to match the higher flux level of field 1 spectrum. The average difference of both spectra relative to the field 1 spectrum, over the whole spectral range, is 1.6% (i.e. the two scaled spectra are almost identical). We then derived the SFH of both spectra (field 1 spectrum and the scaled, field 2 spectrum) using STECKMAP (see Sect. 3.2). The residuals between both recovered SFR (t) are within our error values (see Sect. 3.2 for further information). This analysis indicates that we are properly sampling the stellar content in the analysed fields in spite of the very small fraction of the galaxy’s light present in them. Therefore, we decided to analyse in detail the composite stellar population corresponding to the spectrum covering the 2.5′ × 5′ area (40 pc × 80 pc), which has a better S/N ratio as a consequence of the wider range of spatial coverage of an area with intrinsically the same stellar content. The corresponding final sky-subtracted spectrum is shown in Fig. 3. The final signal-to-noise ratio of this spectrum is ~36.3 (per Å).

3. Determination of the star formation history

We have obtained the SFH using the data described in Sects. 2.1 and 2.2, following carefully developed and well-tested methodologies to study the stellar content via CMD (Aparicio & Gallart 2004; Monelli et al. 2010b) and spectroscopic analysis (Sánchez-Blázquez et al. 2011, 2014; Seidel et al. 2015; Ruiz-Lara, in prep.). This study is meant to be a blind test to compare the two approaches. Thus, all the results obtained and described in this section have been analysed and studied independently (without knowing the results from the other approach) in order to avoid any possible bias to a common solution.

3.1. CMD analysis

The SFH from the CMD was obtained using the IAC-star/ MinnIAC/IAC-pop (Aparicio & Gallart 2004; Aparicio & Hidalgo 2009; Hidalgo et al. 2011; Monelli et al. 2010b) suite of routines. This SFH derivation is based on the comparison, through a χ2 minimization, of the distribution of stars in the observed and in a model CMD. The model CMD was obtained from a synthetic CMD computed with IAC-star, after simulation of the observational errors. For the calculation of the synthetic CMD, which contains 9 × 106 stars, we assumed a constant star formation rate at all ages between 0 and 13.5 Gyr, and flat metallicity distribution between Z = 0.0002 and 0.02. For consistency with the analysis of the integrated spectrum, we used the Padova stellar evolution library (Girardi et al. 2000; Marigo et al. 2008). Finally, we assumed a Kroupa initial mass function (Kroupa 2001) and a binary fraction of 40% (Monelli et al. 2010b). The observational errors were simulated using the information from the artificial stars tests. These allow for the inclusion of the completeness of the photometry, and more importantly, how the photometric errors displace a star from its original position in the CMD. The model CMD was divided into simple stellar populations by adopting a basic set of age and metallicity bins, whose limits are age (Gyr) = [0, 0.25, 0.5, 1.0, 1.5 to 13.5 in steps of 1 Gyr] and Z = [0.0002, 0.0006, 0.001 to 0.01 in steps of 0.001, 0.015, 0.02]. We adopted a distance modulus (mM)0 = 18.5 mag and reddening E(BV) = 0.1 mag to shift the observed CMD to the absolute magnitude plane.

Following previous investigations of other dwarf galaxies (Hidalgo et al. 2009, 2011; Monelli et al. 2010b,a; Meschin et al. 2014), the SFH was derived using only the main sequence (MS) and subgiant branch (SGB) regions, avoiding the regions where the completeness is less than ~50%. Figure 2 presents the CMD with the regions adopted for SFH derivation (called bundles) highlighted. The star counts are performed in each bundle by dividing it into boxes of different sizes. The finest sampling was used in bundle 1 (0.01 mag and 0.2 mag for the colour and magnitude, respectively) and bundle 2 (0.02, 0.1). Bundle 3 was sampled in (0.2,0.5) boxes and bundle 4 was used as a single box. This strategy is the best one and takes into account that i) the physics of main-sequence stars is best understood; and ii) the largest number of stars in the CMD are located in the lower main sequence. Of the 69 209 observed stars, 27 556 are counted in the four bundles.

To take into account possible errors in the distance, reddening, and photometric or model calibration, a number of different solutions were derived introducing small shifts in colour and magnitude, in a grid of 25 positions within ±0.06 mag and ±0.15 mag in colour and magnitude, respectively. In order to minimize the effect of the sampling choice, in each position of the grid 24 solutions were calculated varying the assumed age and metallicity bins of the simple stellar populations, and moving the boxes inside the bundles. In each position of the grid, the 24 solutions are averaged and the corresponding is calculated as the average of the χ2 of the solutions. The minimum value of () indicates the position in the grid where the best solution is obtained, which turned out to be Δ [(MF555WMF814W),Δ(MF814W)] = [0.03,0].

Figure 4 shows the SFH derived from this analysis. This figure shows the SFR (t) and Z (t) projections of the SFH, as the average of the 24 individual solutions calculated at the position of the grid where was obtained (Hidalgo et al. 2011). We should note here that the averaging of the 24 solutions has the effect of smoothing the final SFH. Error intervals are calculated from the dispersion of these 24 solutions, plus any solution in the grid that differs in χ2 by less than 1σ. This provides errors equal to or in excess of the so-called several solutions criterion which was shown by Aparicio & Hidalgo (2009) to produce reliable estimates of total internal errors. Figure 4 shows that the SFR (t) is relatively smooth over the whole time interval, with a slight change at around 4.5 Gyr ago and increased SFR (t) at later times. This is reminiscent of the period of low star formation activity followed by a later increase found by other studies in LMC regions located at larger galactocentric distances (e.g. Meschin et al. 2014,and references therein). The intermediate-age SFR (t) in the LMC bar, however, seems to differ substantially from that of the disc at different galactocentric distances, in which the two main periods of star formation, separated by an epoch of lower star formation activity, are barely seen in the bar and are replaced by a much flatter SFR (t). The SFR (t) between 3.5 and 0.25 Gyr obtained here is rather flat followed by a decrease for stars younger than 0.25 Gyr. The AMR is similar to the one reported in previous studies (e.g. Olszewski et al. 1991; Dirsch et al. 2000; Grocholski et al. 2006), showing an exponential decline from Z ~ 0.0175 at young ages to Z ~ 0.0004 at old ages. The metallicity dispersion in the AMR is found to increase towards younger ages.

thumbnail Fig. 4

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP (test 24). The three panels show, from top to bottom, the normalized SFR (t), the age-metallicity relation, and the cumulative mass fraction with a zoom at young ages for the normalized SFR (t) and the AMR. We plot the envelope of the histograms in the main plots in the insets. In order to make a fair comparison a normalization is needed. We normalize the SFR (t) in such a way that the sum of the areas of the different rectangles (SFR [M/yr] ×Δt) is 1 (upper panel). The AMR plot shows the average metallicity at every age bin. Error bars are 1σ of the resulting distribution of solutions from a series of 25 Monte Carlo simulations in the case of STECKMAP and 600 different solutions by applying small shifts in the CMD for the CMD analysis (see text for details). The shaded regions correspond to the mean values and standard deviations of all the solutions using MILES and ages ranging from 0.063 to 13.5 Gyr (tests 3, 7, 17, 18, 19, 20, 21, 22, 23, and 24).

Open with DEXTER

3.2. Integrated spectrum analysis

We used the integrated spectrum of the LMC bar (see Sect. 2.2) to obtain its SFR (t) and AMR employing state-of-the-art techniques taking advantage of the wide spectral coverage of our data along with some of the most detailed stellar libraries and models.

3.2.1. Emission line cleaning (GANDALF)

When studying integrated stellar populations it is important to take into account any contributions from ionized gas (see Fig. 3). To obtain a reliable SFH we must remove this contribution in order to be able to use also those regions affected by emission (Hβ, [O iii] λ5007, Hα, etc.) in the stellar population analysis. To this end we used GANDALF (Gas AND Absorption Line Fitting, Sarzi et al. 2006) for the emission line removal. In this step we made use of the Vazdekis et al. (2010) models based on the MILES library4 (Sánchez-Blázquez et al. 2006; Cenarro et al. 2007) and computed using the scaled-solar isochrones of Girardi et al. (2000). The models are generated following a Kroupa Universal IMF (Kroupa 2001). GANDALF simultaneously fits the absorption and emission features present in the studied spectrum. It previously runs pPXF (penalized pixel fitting, Cappellari & Emsellem 2004) to obtain the stellar kinematics and a combination of spectral templates matching the observed spectrum. The stellar kinematics obtained here are used in Sect. 3.2.3. Once the absorption spectrum is taken into account, additional Gaussians are included in the fit to obtain the kinematics, shapes, and fluxes of the different emission lines.

3.2.2. Star formation history (STECKMAP)

The emission-cleaned integrated stellar spectrum was then analysed using full spectrum fitting techniques by means of STECKMAP 5 (STEllar Content and Kinematics via MAximum a Posteriori, Ocvirk et al. 2006b,a). The spectrum is fitted using a Bayesian minimization method (by means of a penalized χ2) to obtain the stellar combination that matches the observed spectrum via a maximum a posteriorialgorithm. The equation to minimize is (1)where s is the modelled spectrum that depends on the age distribution (x), the AMR (Z), and the broadening function accounting for the kinematics (g). STECKMAP has the advantage of being a non-parametric code, i.e. it does not assume an a priori shape for the solution (such as stellar age distribution, AMR, and the line-of-sight velocity distribution), but gives a higher probability of smoother solutions. This smoothness is accomplished through the penalization function (function Pμ in Eq. (1)) and the function P (a function that gives high values to high oscillating solutions while small values to smooth solutions of x, Z, or g). The penalization function Pμ is defined as (2)The parameters μx, μZ, and μv are the smoothing parameters for the stellar age distribution (SAD), the AMR, and the line-of-sight velocity distribution (LOSVD), respectively. The different values that these parameters can adopt allow us to change the smoothness of the accepted solutions. The function P can also adopt different shapes (for further information see Ocvirk et al. 2006b,a). This code accounts for the continuum shape of the spectrum using a polynomial fitting (avoiding sources of error such as flux calibration or extinction errors).

STECKMAP outputs allowed us to reconstruct the SFR (t) and the AMR that best fit the integrated spectrum (see Fig. 4). Errors were computed by means of a series of 25 Monte Carlo simulations. Once STECKMAP has determined the best combination of stellar populations to fit the observed spectrum (“best model”), we added noise to the best model spectrum and ran STECKMAP again. This procedure was repeated 25 times. We compute the error of the stellar mass fraction at each age and metallicity bin as the standard deviation of the 25 resulting values.

3.2.3. Robustness of the STECKMAP results

There are several input parameters to consider while running STECKMAP that might affect the SFH reconstruction (e.g. spectral templates, S/N, the smoothing parameters). In this section we check the effect of the various input parameters and probe the robustness of the STECKMAP results.

Table 2

Set of characteristics and parameters used in the different tests to examine the robustness of the STECKMAP solutions.

We explored the entire input parameter space in 24 different tests to choose the best combination of parameters for the STECKMAP run (see Sect. 3.2). All these tests can be interpreted as a way of testing the robustness and consistency of the STECKMAP results. The most important parameters that can affect the final results are i) the set of spectral templates (models and age range); ii) the smoothing parameters; iii) whether the stellar kinematics are fixed or fitted, although we prefer to fix the stellar kinematics in order to stabilize the solution and minimize well-known degeneracies (Sánchez-Blázquez et al. 2011), we will check how the processes of simultaneously fitting the stellar content and kinematics affects the final results.

Table 2 summarizes the main input parameters for each test and the corresponding rms. In the tests we explored the whole parameter space divided into three main blocks: i) we checked the effect of using different stellar models, the age range used during the fit, and the simultaneous recovery of the stellar kinematics (tests 1 to 8); ii) based on the previous block and our expertise (Sánchez-Blázquez et al. 2011, 2014; Seidel et al. 2015, Ruiz-Lara in prep.) we used the Vazdekis et al. (2010) models (age-range: 0.063 × 9 to 17.8 × 109 yr) and fixed the stellar kinematics (tests 9 to 16) while exploring the smoothing parameters (μx and μZ) with values ranging from 10-15 to 1015; and finally iii) in the third block (tests 17 to 24) we used the same ingredients as in the second block but limited the age range to 13.5 × 109 yr (to match the CMD analysis age range). In all the tests we use a square Laplacian smoothing kernel for the shape of the penalization function, P.

thumbnail Fig. 5

Comparison of the different SFHs from STECKMAP, paying special attention to the choice of models (Vazdekis et al. 2010; Vazdekis et al. 2010 + González Delgado et al. 2005, or Bruzual & Charlot 2003). A zoom at the younger ages for the SFR (t) and the AMR is applied. The rest of STECKMAP input parameters as in test 24 (see Table 2). See caption of Fig. 4 for a complete explanation.

Open with DEXTER

A visual inspection of the fits, and the quantitative value of their rms (~0.12 with little dispersion, see Table 2) for all the tests, led us to conclude that there is no easy way to choose the combination of input parameters that best suits our data. In terms of the reconstructed SFR (t) and AMR shapes, all of the tests show very similar results (compatible within errors), except for tests 5, 6, 7, and 8 (see Appendix B), which show the largest discrepancies (also in terms of their rms). These tests share the property that we fit simultaneously the stellar kinematics, which considerably hampers the correct SFH reconstruction. This behaviour highlights the overall stability of the STECKMAP solutions, since as the general shape (if not the precise details) of the solutions is quite similar among tests.

As there is no clear set of input parameters to favour over the others, we have decided to use the following reasonable set of input parameters: i) we fixed the stellar kinematics to the values found with pPXF following Sánchez-Blázquez et al. (2011); ii) we matched the age range used in the CMD analysis using SSP model templates with ages from 0.063 × 109 to 13.5 × 109 yr; and iii) we focused on the results using MILES. In Fig. 5 we show a comparison between the commonly used MILES models (Vazdekis et al. 2010), MILES with the extension towards younger stellar populations from González Delgado et al. (2005), and the Bruzual & Charlot (2003; hereafter BC03) models. We find small differences in the SFR (t) between the models. Larger differences are found in the recovered AMR, with discrepancies within the errors. In particular, the inclusion of the González Delgado et al. (2005) models (based on theoretical stellar libraries) with ages younger than 63 Myr might affect the SFH recovery depending on the real amount of young stars present in the observed field. If we do not include these models, in principle, the contribution of these stars would be included in older bins modifying the recovered SFH shape. Further investigation is needed to understand whether the impacts on the solutions make sense or not.

Bearing this in mind, we show test 24 as an example of the recovered SFH. We have used this test just for illustration purposes, but most of the considered tests could have been used without modifying the main conclusions. We can see in Fig. 4 that the LMC bar displays an almost constant SFR (t) from its formation until ~4 Gyr ago according to the analysis of the integrated spectrum. Afterwards, a progressive increase in the SFR (t) is found with a peak at ~1 Gyr ago followed by a drop in the SFR (t) to the present day. The AMR exhibits an exponential increase with old stellar populations showing the lowest metallicity ([M/H] ~ −0.6) and young stars the highest metallicities ([M/H] ~ 0.2). We note that this exponential behaviour in the AMR shape is mainly caused by our choice of smoothing parameters (μZ is 106 for test 24). The only difference in tests 17 to 24 is the choice of values of the smoothing parameters. As expected (see Appendix B), high values of μx give smooth SFR (t) shapes (tests 17, 21, and 22) and high values of μZ give smooth AMR shapes, (tests 17, 19, 21, 22, and 24) while low values give highly oscillating results. In order to easily compare this data with the rest of the solutions, we have plotted a shaded region corresponding to the average of all the solutions using MILES models and ages ranging from 0.063 to 13.5 Gyr. As can be seen, our chosen test is within that shaded region showing again the robustness of the STECKMAP results.

4. Comparison between CMD and integrated spectrum analysis

In Sect. 3 we derived the SFHs in a region of the LMC bar using two different techniques. In one technique we used the resolved stars in a deep CMD and compared them to theoretical CMDs based on theoretical isochrones and in the other we applied full spectral fitting techniques using stellar population synthesis models. These analyses were performed independently in a blind test. The comparison between the SFH from both approaches will then allow us to test how well modern spectral fitting techniques recover the characteristics of a complex stellar population.

4.1. Star formation rate, SFR (t)

The upper panel of Fig. 4 shows the SFR (t) in the LMC bar region obtained using CMD and STECKMAP typical analyses, as discussed in Sect. 3. The overall shape of SFR (t) is qualitatively similar in both derivations, with an almost continuous star formation since the earliest epochs until 4 Gyr ago, when small differences between the SFH obtained from both approaches appear. The CMD analysis reveals a rather flat SFR (t) between ~0.25 and ~3.5 Gyr with a clear drop in the star formation during the last 0.25 Gyr. The STECKMAP analysis shows a SFR (t) that can be described as a Gaussian skewed towards older ages with the peak around 1 Gyr. Although the youngest populations are better sampled in the case of the integrated analysis than in the case of the resolved analysis, the decline of SFR (t) at ages younger than 0.25 Gyr is consistent in both cases. The lower panel of Fig. 4 shows the cumulative mass fraction as a function of time obtained following both approaches. Small differences can be noted between the curves representing the mass build-up of this region of the galaxy. They are, however, consistent within the error bars and so are not significant.

4.2. Age-metallicity relation

In Fig. 4 (middle panel) we show the AMRs from the CMD and the STECKMAP study with a zoom at young ages. The overall shape and the metallicity range are consistent. Even though larger metallicities are systematically found in the STECKMAP analysis, they are consistent within the error bars for most of the time interval, except the last 0.25 Gyr. In the spectrum solution, there is an upturn from ~1.5 Gyr to now, which is not found in the CMD analysis, where the metallicity remains constant and always below the STECKMAP values. We find the main similarities in the age range between ~1.5 and ~3.5 Gyr. At ages older than ~3.5 Gyr the AMR from the integrated spectrum shows a very shallow negative gradient while the AMR from the analysis of the CMD shows a steeper negative gradient and lower metallicities. A plausible explanation might be found in the choice of the smoothing parameters. The best test uses a smoothness parameter in the AMR of 106, thus, very smooth solutions for the AMR shape, like the one found, are preferred. If we compare this solution (Fig. 4) with other solutions using different smoothing parameters (see Sect. 3.2.3 and Appendix B), we can see that this young, metal-rich component disappears for those tests with a low value of the AMR smoothness parameter. Thus, the main differences regarding the AMR shape (outlined above) might be an artefact from the high smoothing parameter imposed on the AMR. In fact, tests 17, 18, 20, and 23 (tests with a lower μZ) all show quite similar AMR shapes when compared to the CMD results. This is also true of the SFR (t) shapes.

5. Results from other available codes

For the sake of completeness, we have also used other available full spectrum and SED fitting codes (see Sect. 1). However, as this is not meant to be an exhaustive comparison between all the available codes for analysing stellar content from integrated spectra, here we analyse the results from the codes that we are more familiar with. The input parameters for these tests are as similar to the STECKMAP input parameters as possible.

5.1. ULySS

ULySS6 (Koleva et al. 2009) is a full spectrum fitting code that uses Levenberg-Marquardt minimization (from Markwardt 2009) to fit a linear combination of non-linear parameters. It parametrizes the inverse problem as (3)where FObs(λ) is the observed flux at every value of the wavelength (λ); Pn is the multiplicative polynomial and n its degree; LOSVD is the stellar line-of-sight velocity distribution that depends on kinematics parameters such as the systemic velocity (vsys), velocity dispersion (σ), and higher momenta (h3, h4); Cmpi are the different components or SSPs dependent on age (a1) and metallicity (a2) with different weights (Wi) computed during the fit.

thumbnail Fig. 6

Top panel: SFH using ULySS with the Vazdekis et al. (2010) models younger than 13.5 Gyr (“SSP” test). Bottom panel: age-metallicity relation from the ULySS results. SFH: We note that the representation of the SFH is different to the case of STECKMAP (see Fig. 4). In this case we use SSPs with no smoothing applied and thus, vertical lines are chosen to show the mass contribution of the different SSPs instead of a bar plot. However, for a fair comparison, a similar normalization has been applied. Horizontal lines represent the Δt used in this case (computed based on stellar population models used). For further information see Fig. 4. AMR: green points represent the age and metallicity of the different single stellar populations with a non-zero weight in the fit. The point size is proportional to the weight.

Open with DEXTER

thumbnail Fig. 7

Same as Fig. 6, but using as spectral templates a set of 35 spectra generated from a constant SFR (t) and single metallicity (see text for details). However, in this case we do not use SSPs as spectral templates, and so we use a similar representation to the one used with STECKMAP (see Fig. 4).

Open with DEXTER

We have carried out different tests with different input parameters using ULySS. In a first approach, our model was computed as a subset of i = 15 SSPs broadened by a LOSVD from a subset of the Vazdekis et al. (2010) models (as for the STECKMAP analysis). While the ages of the SSPs were fixed between 63 Myr and 13.5 Gyr (equally log-spaced) the metallicities were left free and they could vary between the limits of the models (–2.3 and 0.2 dex, the subset of models comprises 105 different SSPs). We used the emission-cleaned spectrum obtained in Sect. 3.2 and fixed the stellar kinematics. We will refer to this test as “SSP” as we use SSPs as spectral templates. The best fit SFR (t) and AMR are shown in Fig. 6. The overall shape of the SFR (t) is qualitatively similar to the STECKMAP and CMD reconstructions (see Fig. 6), although showing sporadic bursts of star formation, which is expected as we are using a combination of SSPs. ULySS is not able to replicate the AMR at ages younger than ~0.5 Gyr; the metallicities recovered are lower than those inferred from the CMD and the STECKMAP approaches. However, at intermediate and old ages (older than 0.25 Gyr) ULySS AMR results are in fair agreement with the CMD and STECKMAP values.

Although the SSP approach is widely used when recovering the stellar content from integrated spectra, we have also employed a more complex set of spectral templates, more similar to the ones used in the CMD analysis. We made use of the IAC MILES webtools7 to create spectral templates via user defined SFHs. We decided to use 35 spectra of populations with constant SFR (t) between 0.063–0.178, 0.178–0.501, 0.501–1.413, 1.413–3.981, and 3.981–13.49 Gyr (equally log-spaced in intervals of 0.45 dex) and fixed metallicities ranging from −2.32 to 0.22 dex [M/H]. These spectral templates may be a better representation of the continuous mode of star formation expected in real galaxies than discrete SSPs. We will name these new spectral templates “complex SPs” (complex stellar populations). Thus, we use these i = 35 complex SPs (Cmpi) following the same approach outlined above (input spectrum, wavelength range, fixed stellar kinematics, etc.). We will refer to this test as “constant SFR”. The results are shown in Fig. 7. The use of complex SPs considerably improves the recovery of the shape of the SFR (t). The main discrepancies are found at ages younger than 0.5 Gyr, with an absence of populations with ages between 0.178–0.501 Gyr and an excess contribution in the youngest bin (0.063–0.178 Gyr). The AMR shape is similar to the one we obtain using SSPs, with the youngest ages showing metallicities that are too low.

5.2. STARLIGHT

We have also used STARLIGHT (Cid Fernandes et al. 2005)8 to obtain the SFH from the observed integrated spectrum. STARLIGHT is a SED fitting code that tries to match the observed spectrum (continuum and spectral features) by means of a combination of stellar models. It also fits the reddening and stellar kinematics simultaneously.

The details of how STARLIGHT works are given in Cid Fernandes et al. (2004) and Cid Fernandes et al. (2005). STARLIGHT mainly requires as input an observed spectrum, a configuration file, a mask file, a set of N base spectra (templates), and a reddening law. Essentially, the code then tries to obtain the SFH, reddening, and stellar kinematics by the minimization of a χ2, (4)where Oλ is the observed flux, Mλ is the modelled flux, and wλ is the weight (0 for masked regions) at the wavelength λ. STARLIGHT normalizes the observed spectrum and the spectral templates at a given wavelength; in our case we use the window between 5590 and 5680 Å for the observed spectrum, and the flux at 5635 Å for the template normalization. The expression that this code uses for the modelled spectrum is (5)where Mλ0 is the synthetic flux at the normalization wavelength; Mλ is the modelled flux at λ; xj is the weight of the jth element of the set of base spectra; and bj,λrλ is the normalized reddened-spectrum for this jth component, where rλ = 10− 0.4(AλAλ0) is the extinction term. This first part of the expression accounting for the stellar content and the reddening is convolved () by the LOSVD of the stellar component (G(v,σ)). We made use of the LMC reddening law provided by the STARLIGHT package and presented in Gordon et al. (2003).

We have analysed the LMC bar integrated spectrum following a recipe similar to the one discussed in Sects. 3.2 and 5.1; this test will be called “SSP” as it will be based on SSPs as spectral templates. We used the same set of models9 (Vazdekis et al. 2010, up to 13.5 Gyr) as in previous cases, removed the emission line contribution using GANDALF, fixed the stellar kinematics to the pPXF values, and ran STARLIGHT to match every spectral feature in the wavelength range from 3800 to 6800 Å. We masked transition regions between grisms and sky features, but not the emission lines as they have meaningful information after applying GANDALF. We find that the results from STARLIGHT show some important differences when compared to the CMD and STECKMAP results (see Fig. 8). The recovered SFR (t) shows some episodic bumps of star formation younger than 2 Gyr and a predominant old stellar population (older than 10 Gyr), while an intermediate population between 2 and 10 Gyr is not found. The main discrepancies regarding the AMR are found at ages younger than 0.5 Gyr. As in the case of ULySS, the discontinuity in the recovered SFR (t) is a direct consequence of the use of SSPs as spectral templates.

These discrepancies encouraged us to carry out a set of 36 tests modifying different input parameters and procedures to check the reliability of the results: i) We tested the effect of changing the set of model templates and the age range; ii) to reduce the degrees of freedom in the fit we also inspected the effect of imposing an a priori AMR from Carrera et al. (2008), using a carefully selected set of spectral templates from the different models; iii) considering that STARLIGHT also fits the continuum shape of the spectrum, we have also tried to obtain stellar content with this code avoiding the emission line removal step with GANDALF, masking the emission lines instead in order to test if the discrepancies are caused by a bad emission line subtraction; and iv) we also allowed STARLIGHT to fix or fit the stellar kinematics.

We obtained a wide variety of solutions from these different tests. A clear bi-modality is found in the SFR (t) shape using the Vazdekis et al. (2010) plus González Delgado et al. (2005) models, with contributions from young and old populations (younger than 2 Gyr and older than 8 Gyr) and a lack of an intermediate component. However, the use of the BC03 models results in a more spread out or smoother SFR (t) with contributions at all ages. Imposing an observed AMR strongly restricts the number of templates used, and gives poor fits. Fixing the kinematics gives slightly better results than fitting for the kinematics. Using GANDALF or masking the emission lines plays a minor role in the recovery of the stellar content.

In addition, as we did with ULySS (see Sect. 5.1), we performed a further test where we used complex SPs, rather than SSPs, as spectral templates (see Sect. 5.1). We name this test “constant SFR” as previously done with ULySS. The results of this test are shown in Fig. 9. Using complex SPs we were able to obtain a closer approximation to the CMD results regarding the SFR (t) shape. However, we find a lack of stars with ages ranging from 0.501−1.413 Gyr and an excess of stars in the youngest age bin (0.063−0.178 Gyr). The obtained AMR is very similar to the one recovered using SSPs as spectral templates (again, similar to the ULySS results), displaying the same issues at the youngest ages.

thumbnail Fig. 8

Top panel: SFH from STARLIGHT with Vazdekis et al. (2010) models younger than 13.5 Gyr. Bottom panel: age-metallicity relation from the STARLIGHT results. SFH: we note that the representation of the SFH is different to the case of STECKMAP (see Fig. 4). In this case we use SSPs with no smoothing applied and thus, vertical lines are chosen to show the mass contribution of the different SSPs instead of a bar plot. However, for a fair comparison, a similar normalization has been applied. Horizontal lines represent the Δt used in this case (computed based on the base of stellar models used). For further information see Fig. 4. AMR: green points represent the age and metallicity of the different single stellar populations with a non-zero weight in the fit. The point size is proportional to the weights.

Open with DEXTER

thumbnail Fig. 9

Same as Fig. 8, but using as spectral templates a set of 35 spectra generated from a constant SFR (t) and single metallicity (see text for details). However, in this case we do not use SSPs as spectral templates, and so we use a similar representation to the one used with STECKMAP (see Fig. 4).

Open with DEXTER

6. Discussion

The LMC bar is an appropriate astronomical object with which to perform a comparison between the SFH obtained for a composite stellar population by means of the information from its resolved stars and from its integrated light. The reason is twofold: i) we can obtain a CMD reaching the oMSTO using HST data, and ii) its high surface brightness allows us to observe a high quality integrated spectrum. By analysing the CMD and integrated spectrum of the LMC bar we derived and compared its SFHs. In this work we mainly focused on the comparison between CMD analysis and full spectrum fitting analysis using STECKMAP (Ocvirk et al. 2006b,a). In principle, the stellar populations of the LMC bar represent a challenging case for inversion codes analysing integrated stellar spectra because of its complex nature and rich stellar diversity. However, the agreement in the SFR (t) and the AMR between the CMD and the integrated spectrum analysis strongly supports the use of state-of-the-art full spectrum fitting codes in deriving the SFH of complex stellar systems. Our blind tests show that the results of both approaches are consistent when trying to recover the SFH of the same object. However, during our analysis we identified several issues that should be further studied.

thumbnail Fig. 10

Top panels: comparison between the observed spectrum and the fit from STECKMAP (left), STARLIGHT (middle), and ULySS (right). For STARLIGHT and ULySS we use the “constant SFR” approach. Black: fully reduced, emission-cleaned composite spectrum of the LMC bar. Red: fit from the different codes. Bottom panels: residuals of those fits computed as observed – best model. For the stellar content analysis we use the wavelength range from 3800 to 6800 Å (dashed vertical red lines; see text for details). The shaded regions of the spectrum are the masked regions (not considered in the fits). The residuals are in units of 10-15 erg-1 cm-2 Å-1.

Open with DEXTER

The most striking difference between the STECKMAP and the CMD results appears in the derived AMRs. Both AMRs show a metallicity monotonically increasing with time, but the AMR derived from the CMD starts at lower metallicities (−1.2 dex) and does not reach solar metallicity at young ages. The AMR obtained with STECKMAP starts at [M/H] −0.75 dex at old ages, remains quite flat for most of the time range, and increases steeply in the last 2 Gyr, reaching metallicity slightly over solar at the present time. The overall SFR (t) shape also displays some differences for populations younger than 4.0 Gyr. The SFR (t) is almost flat between ~0.25 and ~3.5 Gyr from the CMD analysis, whereas from the STECKMAP analysis we see a skewed Gaussian towards older ages with the peak at ~ 1 Gyr. There are several possible explanations for these differences in SFR (t) obtained from the two methods:

  • a)

    The CMD analysis produces precise results when a deepCMD reaching to below the oMSTO is used (as in this case). Themethodology described in Sect. 3.1 has beenextensively tested by recovering SFHs using mock CMDswith known stellar content (e.g. Aparicio& Hidalgo 2009; Monelliet al. 2010a,b; Hidalgoet al. 2011). However, theseanalyses are not error-free. Differences in the solutionsare found owing to slight changes in the analysis method(e.g. way of dealing with errors, bundle definition, mini-mization algorithm). Also, tests with mock stellar popula-tions reveal that an age-dependent smoothing of the SFHfeatures is produced, with age resolution worsening at oldages, owing to the limitations in the age resolution intrin-sic to the method (see e.g. figure 8 in Hidalgoet al. 2011). Having a largenumber of stars in the CMD is important for a reliable solu-tion, and we cannot exclude the possibility that the shape of theSFR (t) at young ages is not well recovered because of the small data set. This may be aggravated by the fact that the brightest, youngest stars in the main sequence are saturated, and therefore do not appear in the CMD. Even though the SFR (t) at the corresponding ages may still be recovered from lower mass stars, which are fainter on the main sequence, some information is obviously lost. Thus, further investigation using a CMD taken over a larger area, and covering the whole magnitude range would be of interest.

  • b)

    There could be a lack of young stars in the field where the integrated spectrum was observed. This might produce a deficit of flux coming from the youngest populations, and therefore might result in the failure of STECKMAP to reproduce the AMR at such young ages. However, we note that STECKMAP, STARLIGHT, and ULySS all find some contribution at very young ages (see Fig. 4). In addition, a visual inspection of the observed spectrum shows some helium absorption lines (He iλ3819 and He iλ4922), which are signatures of the presence of young, hot stars. Therefore, it does not seem that a deficit of signal from young stars is the cause of the differences in the metallicity inferred for the very young population.

  • c)

    The AMR shape is especially affected by the smoothing penalty function in the AMR (μz). In particular, the shape of our recovered AMR using STECKMAP (see Fig. 4) is very smoothed as a consequence of imposing a large smoothing parameter (μz = 106). The discrepancies between this AMR and that from the CMD analysis in the younger and older edges of our age range could be due to the effect of this parameter. In fact, tests with μz above 102 currently present supersolar stars and primordial metallicities greater than [M/H] = −1.0. Other tests with different smoothing parameters for the AMR (see Appendix B) are better able to reproduce the AMR shape derived in the CMD analysis while still providing a good fit for the SFR (t).

  • d)

    As shown in Sect. 3.2.3, different input parameters give similar SFH results and very accurate fits (see Fig. 10 and Table 2) when STECKMAP is applied to a high quality spectrum. The overall shape of the recovered SFH is reasonably consistent for the different tests although slight differences do arise between them. Therefore, we conclude that the shape of the recovered SFH from high quality spectra is accurately reproduced regardless of the input parameters.

Despite these small discrepancies, the similarities between the CMD and the STECKMAP results are very reassuring. The manner in which STECKMAP deals with the intrinsically ill-posed inversion problem (regularization through a penalized χ2) has proven to be very powerful. The smoothed solutions from STECKMAP make sense physically; star formation in galaxies is a complex mechanism, and a consequence of continuous galaxy evolution. In STARLIGHT and ULySS no such smoothing is implemented, and thus, the use of SSPs as spectral templates naturally leads to a SFR (t) characterized by discrete bursts of star formation. Although the use of SSPs as a base for reconstructing the SFH of galaxies is a good first approximation, these SSPs are idealized realizations of bursts of star formation that are not necessarily expected in nature. The inclusion of some kind of smoothing techniques in these codes might eliminate these discontinuities.

Since the exact determination of the shape of the SFR (t) is difficult in STARLIGHT and ULySS if SSPs are employed, we used a set of spectral templates computed assuming populations with a range of ages (complex SPs). Although the shape of the AMR is very similar irrespective of whether we use SSPs or complex SPs, the shape of the SFR (t) obtained using this second approach is closer to the CMD and STECKMAP SFR (t) shapes. The use of complex SPs seems in some sense to mimic the effect of imposing a smoothing on the solution (see Figs. 7 and 9) and it is preferred to the use of SSPs as it allows us to obtain some intermediate contribution that otherwise is impossible to detect. This suggests that these kinds of spectral templates may be better in order to study the stellar content of external complex systems (e.g. galaxies, not star clusters).

Table 3

Percentages of the total stellar mass in three different stellar subpopulations: young (younger than 0.5 Gyr), intermediate (older than 0.5 Gyr and younger than 5.0 Gyr), and old (older than 5.0 Gyr).

We have also evaluated whether, although they do not always produce consistent SFR (t) shapes, the different methods are able to reproduce the relative contribution in mass of young, intermediate, and old components (the age intervals for this test are defined to match the Bica analysis; see Appendix A). Table 3 shows the contributions to the total stellar mass for different age ranges, as inferred using all the analysed approaches. The outcomes from the CMD, STECKMAP, STARLIGHT, and ULySS (“SSP” and “complex SSP” tests) display roughly similar percentages of stars in each age range, although slightly larger discrepancies are found in the STARLIGHT analysis.

thumbnail Fig. 11

Comparison between the STECKMAP and STARLIGHT (using spectral templates mimicking constant SFR) best models. Top panel: the STECKMAP best model is plotted in red. The STARLIGHT best model is plotted in blue. Bottom panel: residuals of both best models (STECKMAP – STARLIGHT). The shaded regions of the spectrum are the masked regions (not considered in the fits). Vertical, dashed red lines are located at the wavelengths of the main stellar absorption features. The residuals are in units of 10-15 erg-1 cm-2 Å-1.

Open with DEXTER

A common issue in the ULySS and STARLIGHT results is the excess of young stars (see Figs. 69). As discussed in Sect. 2.1, some bright stars (F814W ~ −1) are saturated, and thus, are not taken into account in the SFH recovery from the CMD. This saturation magnitude roughly corresponds to the main sequence turnoff of a ~0.3 Gyr old population. However, we consider in our calculation other stars with the same age that are not saturated (lower mass and, therefore, fainter stars), so we can still recover the information at the youngest ages. As this saturation affects the brightest (and youngest) stars which might be dominating in the light integrated spectrum, the excess of young stars found with ULySS and STARLIGHT may be a consequence of this limitation. We note that this issue is somehow observed in the STECKMAP results with low smoothing parameters. This should be further investigated with a comparison with other local group galaxies using a similar analysis to this work.

In Fig. 10 we analyse each spectral fit (STECKMAP, ULySS, and STARLIGHT) in order to assess where the observed discrepancies discussed above (SFH and age percentages) may come from. At first glance the three codes seem to properly fit the observed spectrum. The rms of the residuals is 0.12 for the STECKMAP fit, 0.21 for the STARLIGHT fit and 0.18 for the ULySS fit (both “SSP” and “constant SFR” tests). A careful inspection shows that STECKMAP and ULySS are able to better reproduce some individual spectral features than STARLIGHT as a consequence of the polynomial fitting. Figure 11 shows a more detailed comparison between the STECKMAP and STARLIGHT best models (“constant SFR”), i.e. the spectrum corresponding to the recovered stellar content. We note some important differences in the shape of the continuum (wave-like features in the residual plot) as well as differences in some specific absorption features. Among the features with larger discrepancies we can highlight Hϵ, Hβ, the Ca ii doublet (3933, 3969 Å), the magnesium feature at 5175 Å, and the sodium absorption line (5892 Å). Every stellar feature is deeper in the STECKMAP best model than in the case of the STARLIGHT fit except for the sodium feature. These differences considerably affect the recovered stellar content.

Although the techniques for the analysis of unresolved stellar populations give good results when compared to the CMD reconstruction, based on the work presented here we find that there is still room for improvement. For example, a wider range of spectral coverage might help to overcome the issues at young ages and to better constrain the recovered SFH. Few empirical stellar libraries are available in the ultraviolet (150 to 333 nm) and near-infrared (up to 2 microns) and thus, theoretical SSPs limited to the optical range are used (e.g. Riffel et al. 2009; Storchi-Bergmann et al. 2012; Martins et al. 2010, 2013). In addition, we find that a successful way of overcoming the ill-conditioned problem of the reconstruction of the stellar content from an observed spectrum is by imposing smoothed solutions (which have more physical meaning), or by using spectral templates composed of complex SPs. We suggest that this could be a basis for improvement in the next generation stellar population synthesis codes from integrated spectra.

7. Conclusions

In this paper we have studied the SFH and the AMR of the LMC bar using two distinct approaches. We compared the results from the reconstruction of an observed CMD reaching the oMSTO, obtained from WFPC2 data from the HST, with the results from the spectral fitting of an integrated spectrum taken at the 3.6 m ESO telescope on La Silla, using EFOSC2. Owing to the relatively high surface brightness of the LMC bar and its close proximity, the chosen field is a unique one in which both an accurate, deep CMD and a high quality spectrum can be obtained. We have applied state-of-the-art models, stellar libraries, isochrones, and codes following each approach in order to derive the SFR (t) and AMR of this bar field. Different codes (STECKMAP, ULySS, and STARLIGHT) have been used to recover the stellar content from the integrated spectrum and the results compared to the CMD analysis. The analysis of the integrated spectrum using each code has been performed in a consistent manner, and in an effort to avoid any biases in the solutions the CMD analysis was performed independently from the spectral analysis.

The best agreement between the integrated spectrum analysis and the CMD analysis was found using STECKMAP, the only full spectrum fitting code that we tested with a penalization implemented. STECKMAP produces SFR (t) and AMR in good agreement with those obtained from the CMD. All the spectral fitting codes used in this study are normally used with SSPs as spectral templates. ULySS and STARLIGHT do not use any penalization and, as a consequence, solutions dominated by episodic bursts are derived if SSPs are used as spectral templates. ULySS is able to reproduce the overall shape of the SFR (t) but with bursts of star formation. However, this code is not able to reproduce the AMR, especially at young ages. STARLIGHT is able to approximately reproduce the AMR (except at the youngest ages), but has problems with the shape of SFR (t), especially at intermediate ages where no equivalent contribution in the CMD is found. We have been able to improve these results (both with ULySS and STARLIGHT) by using a set of complex spectral templates constructed adopting a constant SFR (t) in bins of log-spaced ages instead of SSPs. This suggests that complex SP templates, rather than simple SP spectral templates should be preferred when analysing the stellar content of composite stellar systems.

This is the first time that the results of these two different approaches for studying stellar populations in galaxies have been compared for an object with a complex SFH, and for which a CMD reaching the oMSTO could be obtained. Such studies are of crucial importance in order to test recent advances in the field, especially in the analysis of the integrated stellar populations. Important ongoing and upcoming projects such as CALIFA (Sánchez et al. 2012), SAMI (Croom et al. 2012), or MANGA will make use of these techniques to study the formation and evolution of galaxies.

In future work we plan to expand our analysis to a sample of Local Group dwarf galaxies bracketing a range of properties. This will allow us to identify the impact that different factors (such as different SFHs, fractions of young vs old stars, the existence of a blue horizontal branch or blue straggler stars) may have on the results. Not only will this comparison identify where full spectrum fitting techniques may fail and where they succeed, but it will also provide information on the spectral ranges and features that are more likely to improve these techniques. Understanding the limits of the reliability of SFHs obtained from integrated spectra provides an important basis for the understanding of galaxies at low and high redshift.


1

Below the oMSTO there is basically no age information, but the luminosity function of the low main sequence can be used to obtain information on the initial mass function (IMF) of low mass stars (e.g. Kalirai et al. 2013).

3

IRAF is distributed by the National Optical Astronomy Observatory, which is operated by the Association of Universities for Research in Astronomy (AURA) under cooperative agreement with the National Science Foundation.

4

The models are publicly available at http://miles.iac.es

5

STECKMAP can be downloaded at http://astro.u-strasbg.fr/~ocvirk/

6

ULySS can be downloaded at http://ulyss.univ-lyon1.fr

8

STARLIGHT can be downloaded at http://astro.ufsc.br/starlight/

9

In the case of STARLIGHT, as well as for STECKMAP, we use the entire set of models, [ages (Gyr)] × [M/H] = [0.0631, 0.0708, 0.0794, 0.0891, 0.1000, 0.1122, 0.1259, 0.1413, 0.1585, 0.1778, 0.1995, 0.2239, 0.2512, 0.2818, 0.3162, 0.3548, 0.3981, 0.4467, 0.5012, 0.5623, 0.6310, 0.7079, 0.7943, 0.8913, 1.0000, 1.1220, 1.2589, 1.4125, 1.5849, 1.7783, 1.9953, 2.2387, 2.5119, 2.8184, 3.1623, 3.5481, 3.9811, 4.4668, 5.0119, 5.6234, 6.3096, 7.0795, 7.9433, 8.9125, 10.0000, 11.2202, 12.5893, 14.12] × [−2.32, −1.71, −1.31, −0.71, −0.4, 0.0, 0.22]

Acknowledgments

We thank the anonymous referee for very useful comments. We would like to thank Roberto Cid Fernandes and Brad Gibson for very helpful suggestions and discussions that have considerably improved this paper. It is a pleasure to thank the 3.6 m telescope team in La Silla for their support during the observing run, in particular R. Athreya and E. Wenderoth. This research has been partly supported by the Spanish Ministry of Science and Innovation (MICINN) under grants AYA2011-24728 and Consolider-Ingenio CSD2010-00064; and by the Junta de Andalucía (FQM-108). We also acknowledge financial support from the research projects under grants AYA2010-21887-C04-03, AYA2010-21322-C03-03. TRL thanks the support of the Spanish Ministerio de Educación, Cultura y Deporte by means of the FPU fellowship. D.A. acknowledges the support of the Haute Provence Observatory as well as the support of the IAC and ESO for visits during which this study was finalized. M.K. is a postdoctoral fellow of the Fund for Scientific Research- Flanders, Belgium (FWO 65052/12E4115N LV). P.S.-B. acknowledges support from the Ramón y Cajal program, grant ATA2010-21322-C03-02 from the Spanish Ministry of Economy and Competitiveness (MINECO).

References

Online material

Appendix A: Analysis using a base of integrated cluster spectra (Bica method)

Table A.1

Base elements in the age × metallicity plane for the Bica (1988) analysis. E(BV)i = 0.0.

Table A.2

Results for the Bica (1988) analysis.

To historically link previous methods to study the stellar content in galaxies with modern SED and full spectrum fitting techniques, we analyse the data via a spectral population synthesis technique originally developed by Bica (1988), and later updated by Schmitt et al. (1996). This method aims at reproducing the observed equivalent widths (Ws) and the continuum ratios (Cs) using the integrated-light spectra of an ensemble of star clusters with different ages and metallicities (e.g. Bica & Alloin 1986a,b, 1987; Bica et al. 1988, 1994). The W and C values from the cluster base are built in a grid parametrized by the age and the metallicity, and extrapolated in the case of high metallicities unreachable through observations. In the current analysis, we have used eight components to map the age-metallicity plane, with the constraint that their metallicities be solar and subsolar. Indeed, in a low mass galaxy such as the LMC, we do not expect to find stellar components with metallicity above solar (Pagel & Tautvaisiene 1998). The base elements used in the analysis are listed in Table A.1. The results are shown in Fig. A.1.

From the population analysis above it is clear that the 1 Gyr and 100 Myr components are very important in flux (see Fig. A.1, top panel). It is also important to compute how much they represent in terms of mass fractions. For such purposes we employed a flux-mass transformation method (Bica et al. 1988). This method uses different ratios of mass to V-light (M/LV) related to each age component. It also takes into account metallicity effects among old star clusters. We show in Fig. A.1 (bottom panel) the mass distributions for each component. We can see that the 1 Gyr and 100 Myr components are less than 10% and 5% in mass, respectively.

We can interpret those results as star formation along three different age ranges (less than 0.5 Gyr, 0.5–5 Gyr, and 5–14 Gyr;

see Table A.2). If we consider that the mass at every age range was formed uniformly and we compute a “pseudo-SFR” dividing the mass alive percentage by the age width for each population, which leads us to recent star formation of 4.4 Gyr-1, followed by a drop (2.2 Gyr-1) with a higher “pseudo-SFR” at older ages. These results differ from the STECKMAP and CMD results, essentially because of a lack of time resolution at old ages (see Table 3).

thumbnail Fig. A.1

Synthesis results using the Bica analysis. Top panel, flux fraction of the different base elements. Bottom panel, mass alive fraction of the different base elements.

Open with DEXTER

Appendix B: Recovered star formation histories for the STECKMAP tests

We include in this appendix the recovered SFH in the tests described in Sect. 3.2.3. We show the stellar content for the 24 tests in a similar way as in Fig. 4. As already outlined in the main body of the paper, we note the consistency between different tests except in some extreme cases.

thumbnail Fig. B.1

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 1; right: test 2. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.2

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 3; right: test 4. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.3

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 5; right: test 6. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.4

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 7; right: test 8. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.5

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 9; right: test 10. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.6

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 11; right: test 12. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.7

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 13; right: test 14. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.8

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 15; right: test 16. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.9

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 17; right: test 18. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.10

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 19; right: test 20. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.11

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 21; right: test 22. For further information see Fig. 4.

Open with DEXTER

thumbnail Fig. B.12

Comparison between the LMC bar SFH from the CMD and the integrated spectrum using STECKMAP. Left: test 23; right: test 24. For further information see Fig. 4.

Open with DEXTER
