Inequalities on stellar rotational splittings derived from assumptions on the rotation profile
^{1}
School of Physics and Astronomy, University of Birmingham,
Edgbaston,
Birmingham
B15 2TT,
UK
email:
dreese@bison.ph.bham.ac.uk
^{2}
Stellar Astrophysics Centre (SAC), Department of Physics and
Astronomy, Aarhus University, Ny
Munkegade 120, 8000
Aarhus C,
Denmark
Received: 15 July 2014
Accepted: 9 March 2015
Context. A number of pulsating stars with rotational splittings, in particular subgiants and giants, have been observed thanks to the CoRoT and Kepler missions. This has led various groups to investigate their rotation profiles via different methods.
Aims. We would like to set up some criteria that will help us to know whether a decreasing rotation profile, or one that satisfies Rayleigh’s stability criterion, is compatible with a set of observed rotational splittings for a given reference model.
Methods. We derive inequalities on the rotational splittings using a reformulated version of the equation that relates the splittings to the rotation profile and kernels.
Results. These inequalities are tested out on some simple examples. The first examples show how they are able to reveal when a rotation profile is increasing somewhere or inconsistent with Rayleigh’s criterion in a main sequence star, depending on the profile and the ℓ values of the splittings. The next example illustrates how a slight mismatch between an observed evolved star and a reference model can lead to erroneous conclusions about the rotation profile. We also show how frequency differences between the star and the model, which should normally reveal this mismatch, can be masked by frequency corrections for nearsurface effects.
Key words: stars: oscillations / stars: rotation / stars: interiors
© ESO, 2015
1. Introduction
The CoRoT and Kepler space missions have obtained exquisite pulsation data for many stars (Baglin et al. 2009; Borucki et al. 2009). This has enabled the detection of rotational splittings in a number of stars, including subgiants and giants (Beck et al. 2012; Deheuvels et al. 2012, 2014; Mosser et al. 2012), and a main sequence star (Kurtz et al. 2014). A number of prior studies have also used groundbased data to extract rotational splittings. Based on these splittings, the above authors have inverted or constrained the differential rotation profile, and hence constrained angular momentum transport within stars. In particular, the cores of red giants rotate much more slowly than expected based on theory, thereby pointing to unknown powerful angular transport mechanisms that operate throughout the stellar lifetime (Eggenberger et al. 2012; Marques et al. 2013; Ceillier et al. 2013).
There are several inverse methods used to probe the internal rotation profile of a star. One of these, the regularised leastsquares (RLS) method, searches for the best profile that reproduces the observed splittings. When carrying out such an inversion, it is necessary to introduce a priori information. Indeed, rotational splittings represent a finite number of measurements or constraints on the rotation profile, i.e. a function defined over the interval [0,R], where R is the stellar radius. As the method’s name suggests, this is typically done through a regularisation term that reduces the second order derivative of the resultant profile. Even then, the obtained solution is not always satisfactory. Indeed, as can be observed in Fig. 15 of Deheuvels et al. (2012), the resultant profile may change signs. Physically, this would correspond to a star with an onionlike structure with counterrotating shell(s), as pointed out in Deheuvels et al. (2014). A second, potentially problematic, situation is when the gradient of the rotation rate becomes positive (see e.g. Fig. 6 of Córsico et al. 2011). Although such a situation can occur and has been observed both at low latitudes in the Sun (Schou et al. 1998) and in a terminal age main sequence A star (Kurtz et al. 2014), it seems unlikely in many cases, especially in evolved stars that are undergoing core contraction and envelope expansion. Therefore, it is important to search for inversion methods which impose a positive rotation profile and, optionally, one that decreases outwards. Before developing such a method, however, it is useful to check beforehand whether such a profile is compatible with the observations for the chosen reference model.
In the present paper, we investigate under what conditions it is possible to obtain a decreasing rotation profile, or one that satisfies Rayleigh’s stability criterion, for a set of observed rotational splittings, and a given reference model. In Sect. 2, we show how these assumptions on the rotation profile lead to inequalities on the rotational splittings. Section 3 then contains several test cases. The first ones show how such inequalities can detect when the gradient of the rotation profile is positive somewhere in the star or when the rotation profile does not obey Rayleigh’s stability criterion. The last test case illustrates how they can be used to reveal a mismatch between the reference model and the star, provided one assumes a decreasing rotation profile. A short discussion concludes the paper.
2. Inequalities on rotational splittings
In spherically symmetric nonrotating stars, the pulsation modes are described by three quantum numbers: the radial order, n, which corresponds to the number of nodes in the radial direction, the harmonic degree, ℓ, which is the total number of nodal lines on the surface, and the azimuthal order, m, which gives the number of nodes around the equator. For each pair (n,ℓ) there are 2ℓ + 1 modes with the azimuthal order ranging from −ℓ to ℓ. These modes are degenerate, i.e. they all have the same frequency. If, however, the star is rotating, these modes will no longer be degenerate. Furthermore, if the rotation profile is slow and only depends on the radial coordinate, r, then, based on first order effects, these modes will be evenly spaced by a quantity known as the rotational splitting, s_{n,ℓ}. Using the variational principle, it is possible to derive a relation between the rotational splitting and the rotation profile, Ω (e.g. Aerts et al. 2010), (1)where ω is the pulsation frequency, C_{n,ℓ} the Ledoux constant, K_{n,ℓ} the rotation kernel, and R the stellar radius. In the above formula, we have assumed that the star is viewed from an inertial frame (as opposed to a corotating frame), and are making use of what could be called the prograde convention, i.e. modes with positive azimuthal orders are prograde. If the opposite convention is used, then the splitting is defined as s_{n,ℓ} ≡ (ω_{n,ℓ, − m} − ω_{n,ℓ,0}) /m.
The Ledoux constant takes on the expression (Ledoux 1951) (2)where ξ and η are the radial and horizontal Lagrangian displacements, respectively, and ρ the density profile of the star. Likewise, the rotation kernel can be expressed as (3)Bearing in mind that rotation kernels are only defined for nonradial modes (ℓ ≥ 1), it is straightforward to see that K_{n,ℓ}(r) is positive for all r values. Furthermore, K_{n,ℓ} is unimodular, i.e. .
2.1. Rotation profiles with a negative gradient
2.1.1. Inequalities for the full domain
At this point, we introduce two assumptions concerning the rotation profile:

1.
The gradient of the rotation profile is negative ). As mentioned in the introduction, there are stars where this is not the case (Schou et al. 1998; Kurtz et al. 2014), but we expect this to be true in many cases, especially in subgiants and giants.

2.
The surface rotation rate is positive. When combined with the previous assumption, this implies that the entire rotation profile is positive, which avoids oniontype structures with counterrotating shells.
We return to Eq. (1) and do an integration by parts of the righthand side: (4)where we have made use of the fact that K_{n,ℓ} is unimodular, cancelled out one of the terms, and used the index i as shorthand for (n,ℓ). If the rotation profile has a discontinuity at r_{d}, then the integration by parts can be carried out on the domains [0,r_{d}] and [r_{d},R] separately: (5)We note that to be consistent with our first assumption, it makes more sense if . Similar formulas can be obtained for multiple discontinuities. At this point, we introduce a first type of normalised rotational splitting: (6)A first, and rather trivial, inequality is immediately apparent from either Eqs. (4) or (5). Indeed, since , then the last term(s) on the righthand side is positive. Consequently, this leads to (7)Such an inequality is obvious: the lefthand side is a weighted measure of the internal rotation rate, and the righthand side the surface rotation rate. Given the assumption , the surface rotation rate is necessarily smaller than the internal rotation rate.
At this point, we introduce a first type of integrated rotation kernel: (8)Given that K_{i} is unimodular, we have I_{i}(R) = 1. Furthermore, since K_{i} is positive for all r and only zero in isolated points, the function I_{i} is strictly increasing. Given that I_{i}(0) = 0 by construction, I_{i}(r) is strictly positive for r> 0. A visual inspection of such functions for a set of modes, such as is illustrated in Fig. 1, shows that these functions tend to line up rather than cross each other. In other words, if I_{i}(r_{0}) ≤ I_{j}(r_{0}) for a given r_{0}, where i and j represent two modes, then I_{i}(r) ≤ I_{j}(r) for all r values. A similar behaviour certainly does not apply to the kernels themselves, hence the reason why we work with the integrated kernels. Now, it turns out that the integrated kernels do cross frequently (see Fig. 3), but the general trend still leads us in the right direction. Indeed, to make the argument more rigorous, one simply needs to find constants, a and b, such that the following inequalities hold: (9)The optimal values of a and b will then simply be (10)Figure 2 shows the ratios of integrated kernels for two pairs of modes from which we determine a and b. Already, it is straightforward to see that a ≤ 1 ≤ b by simply inserting r = R in Eq. (9). Furthermore, if a = 1 or b = 1, this implies that the integrated kernels do not cross (although we do note that by construction, they will have the same values at r = 0 and r = R, i.e. 0 and 1, respectively).
Fig. 1 Integrated normalised kernels of dipole modes for a 1 M_{⊙} red giant (Model 1, see Sect. 3). The lower curve corresponds to a more plike mode where as the top curves are for more glike modes. (Colour online.)

Open with DEXTER
Fig. 2 Ratios of integrated kernels for dipole modes. The top panel shows the ratio between the integrated kernels of a glike mode and a plike mode, whereas the bottom panel is for two glike modes. As can be seen in the lower panel, the ratio crosses the value 1, which means that the two integrated kernels have crossed.

Open with DEXTER
The behaviour in r = 0 is more complicated. Indeed, one needs to consider the limit of I_{i}(r) /I_{j}(r) in Eq. (10) when r → 0. Hence, it is useful to know the behaviour of the rotation kernels when r goes to 0. For ℓ ≥ 1, the vertical and horizontal displacement behave as . Therefore, the rotation kernels scale as r^{2ℓ} when r goes to 0 as can be seen from Eq. (3). However, there is one exception to this rule. Indeed, when r goes to 0, the vertical and horizontal displacements satisfy the relation: ξ ~ ℓη. If we replace ξ by ℓη in Eq. (3), then we obtain the following expression for the numerator: (11)This expression is zero when ℓ = 1. Hence, in dipole modes, the lowest order terms cancel out and one needs to consider higher order terms. If we return to expression (3) and substitute ℓ = 1, then the second part of the numerator drops out and we are left with (ξ − η)^{2}ρr^{2}. The next order term for (ξ − η) behaves as since only even powers of r intervene in the displacement functions of dipole modes. When squared and multiplied by ρr^{2}, this leads to an behaviour, rather than the behaviour initially expected. Finally, if we return to the general case, the integrated kernels will simply behave as , except for dipole modes, for which . Therefore, when considering the limit I_{i}(r) /I_{j}(r), the modes i and j need to have the same ℓ value or else one needs to have ℓ = 1 and and the other ℓ = 3. Otherwise, the limit will either be 0, thereby leading to a = 0, or infinite, thereby leading to b = ∞.
If we now multiply Eq. (9) by and integrate over [0,R], we obtain the inequalities (12)where we have made use of the assumption , and of Eq. (4), which assumes that Ω is continuous. Bearing in mind that aΩ(R) ≤ Ω(R) ≤ bΩ(R), one can simplify the terms proportional to the surface rotation rate, thereby leading us to our final set of inequalities: (13)Although simpler, this last equation is slightly less restrictive than the previous form. Hence, one should use Eq. (12) if the surface rotation rate is known. If the rotation profile, Ω, is discontinuous at r_{d}, it is still possible to obtain the inequalities given in Eq. (13), provided that , which is consistent with as pointed out earlier. As will be discussed in Sect. 2.1.5, observational error bars also need to be taken into account when applying the above inequalities.
We note, in passing, that the quantities R − r_{i} also obey the above inequalities, where . Indeed, an integration by part yields (14)Hence, integrating Eq. (9) over [0,R] leads to (15)If a or b is equal to 1 for a given pair of modes (i.e. if their integrated kernels I_{i} and I_{j} do not cross, as noted above), then the slope of line connecting to must be positive. However, it turns out that integrated kernels do cross fairly frequently (as shown in Fig. 3), so one cannot rely on the slope to decide whether a particular pair of modes obey the above inequalities. Instead, one needs to apply the inequalities systematically. We nonetheless expect there to be a general trend in an diagram, based on these considerations.
Fig. 3 Cumulative number of crossings between the I_{i}(r) integrated kernels as a function of position, r/R. These crossings were calculated using the ℓ = 1 modes from Model 1, which is introduced in Sect. 3.2.

Open with DEXTER
Bearing in mind that the original goal, as described in the Introduction, is to be able to find rotation profiles which are decreasing and which do not change signs, it is interesting to look at the above problem the other way around and see whether it is possible to construct such rotation profiles for given rotational splittings, assuming they obey the above inequalities. We begin by denoting . The quantity γ is between a and b since the rotational splittings satisfy the above inequalities. Furthermore, the function ranges from a to b, by definition of these constants. If this function is continuous, then there exists a point r_{γ} such that . It is then straightforward to see that the following rotation profile reproduces the rotational splittings and satisfies the above constraints: (16)If the function never takes on the value γ because of a discontinuity (for instance in a model with a discontinuous density profile), then one could define a rotation profile which is discontinuous at the points r_{1} and r_{2}, defined such that , and solve the relevant system of equations to find by what amount the rotation profile changes at each discontinuity. A more serious difficulty occurs if r_{γ} = 0 and no alternative r values could be used to construct a solution. In such a situation, one can only get arbitrarily close to the solution by setting a discontinuity at ϵ, finding the corresponding rotation profile, then decreasing ϵ. Hence, in summary, the above inequalities provide a necessary and nearly sufficient condition on the rotational splittings of two modes for the existence of a decreasing and positive rotation profile.
Had the above inequalities not provided a nearly sufficient condition for the existence of such profiles, then one would be left wondering if a more stringent set of criteria could be deduced. However, the above results suggest that these are the most restrictive conditions one could find for a given pair of modes. As we will, however, see in a later section, they do not provide the most restrictive conditions for a set of 3 or more modes, as they apply to 2 modes at a time. In addition, one must not forget that even if rotational splittings do obey the above inequalities, it does not guarantee that the true rotation profile is indeed decreasing everywhere. Indeed, for any set of rotational splittings, it is always possible to find rotation profiles which have a positive gradient somewhere in the star and/or a sign change.
2.1.2. Inequalities where the centre is excluded
If an upper bound on is known in the most central regions of the star, then it is possible to derive slightly different inequalities which exclude these regions and potentially lead to tighter constraints. We start by defining new constants, a^{⋆} and b^{⋆}, as (17)where r_{0} is the upper bound of the central region under consideration. Hence, (18)We then multiply this equation by and integrate over [r_{0},R]. Keeping in mind that (19)where k corresponds to i or j, we finally obtain, after some rearrangement and cancelling out the surface rotation terms: (20)At this point, we introduce ℬ, the upper bound on over the interval [0,r_{0}]. The first integral in the above expression can be bounded as (21)where we have also made use of the assumption over the interval [0,r_{0}]. We note that, if we substitute a for a^{⋆}, then max[0,aI_{j}(r) − I_{i}(r)] is always zero, thereby cancelling out the righthand side. The integral term would then drop out of Eq. (20). A similar manipulation with the second integral term leads to
(22)Once more, if we substitute b for b^{⋆}, the righthad side cancels out. When substituted into Eq. (20), these inequalities lead to (23)The advantage of this equation over Eq. (13) is that the constants a^{⋆} and b^{⋆} may be much more constraining than a and b, given that the latter may be overly affected by the very inner regions. In particular, this would allow comparisons between splittings for different ℓ values, for which the constants a or b could be 0 or infinite, respectively. The drawback is trying to find an appropriate value for ℬ. One can expect ℬ to become small in the central regions since .
In much the same way as was done above, one can check to see if the above inequalities provide a sufficient condition for obtaining a positive, decreasing rotation profile, subject to the supplementary condition over the interval 0 ≤ r<r_{0}. If is prescribed over the interval [0,r_{0}[, one could apply a similar approach to what was done above and attempt to define a radial coordinate r_{γ⋆} such that such that . If such a point exists, then it is possible to construct a rotation profile which is decreasing and satisfies the rotational splittings. However, Eq. (23) does not guarantee that γ^{⋆} is between a^{⋆} and b^{⋆}, and hence that r_{γ⋆} exists. Only Eq. (20) provides such a guarantee. One may try to adjust the function over the interval [0,r_{0}[, but would only succeed in enforcing either a^{⋆} ≤ γ^{⋆} or γ^{⋆} ≤ b^{⋆}. One could then take on a different approach, and define the points r_{a⋆} and r_{b⋆} such that and . As opposed to r_{γ⋆}, these points are guaranteed to exist. However, as described in Appendix A, if one defines a rotation profile with discontinuities at those points, and which reproduces the rotational splittings, only Eq. (20) guarantees that the rotation profile will decrease across these discontinuities. Hence, only Eq. (20) provides a necessary and sufficient condition for the rotation splittings to correspond to a positive decreasing rotation profile, provided it is decreasing over the interval [0,r_{0}[. Equation (23), in contrast, constitutes a necessary but insufficient condition on the rotational splittings.
2.1.3. Three or more modes
So far, we have only considered two modes in isolation. However, in typical stars, a larger number of rotational splittings are observed. Of course, one can always apply the above inequalities to every pair of rotational splittings. However, it is obvious that a more complicated strategy than what was described in the previous section is needed in order to construct a rotation profile which satisfies all of the rotational splittings simultaneously, and yet still has a negative gradient throughout the star. Indeed, certain properties of the rotation profile only emerge when a sufficient number of rotational splittings are used together. Hence, in what follows, we briefly explore a way of generalising the above inequalities to more than two modes. We consider an inequality of the form (24)where we are assuming that the a_{i} and b_{j} are positive. Then using the same methodology as above, we deduce the following inequalities on the corresponding rotational splittings: (25)We note that it was possible to remove the surface rotation rate because ∑ _{i}a_{i} ≤ ∑ _{j}b_{j} (as deduced from Eq. (24) for r = R). If one excludes the central region, [0,r_{0}], then the following inequality is obtained, (26)where ℬ is an upper bound on over the interval [0,r_{0}]. One can also obtain the following condition by making use of the inequalities , thereby allowing us to remove these terms altogether: (27)Although less restrictive than Eq. (26), this latter inequality has the advantage of being linear with respect to the coefficients a_{i} and b_{j}.
The main difficulty in the above inequalities is finding the constants a_{i} and b_{j} in such a way as to provide tight constraints. For instance, one could choose a set of b_{j} values, and search for a_{i} values which maximise the lefthand side of Eqs. (25) or (26) while respecting Eq. (24). Equation (24) could be applied at each mesh point, thereby providing a set of N linear inequalities on the coefficients a_{i}, where N is the number of mesh points. Maximising the lefthand side of Eq. (25) would then require methods from linear programming such as the simplex algorithm. A similar strategy can also be applied to Eq. (27). In contrast, maximising the lefthand side of Eq. (26) would require a method from mathematical optimisation, owing to its nonlinear form. In the next section, we carry out a comparison between these inequalities and inverse methods, thereby providing further insights into how to choose the coefficients a_{i} and b_{j}.
2.1.4. Link with inverse methods
In order to understand the link between the above inequalities and inverse methods, we start with Eq. (24) and subtract ∑ _{i}a_{i}I_{i}(r) from both sides: (28)The righthand side of this inequality is a linear combination of kernels that plays exactly the same role as an averaging kernel in inverse methods. There is, however, one crucial difference^{1}: needs to be positive everywhere, as indicated by the equation, in order for the inequality to carry through the integration onto the rotational splittings. In contrast, the averaging kernels from inverse methods are not obtained with such a goal in mind, and therefore frequently take on negative values.
This condition can be relaxed if one excludes the centre, or some other region(s) in the star. Indeed, in such a situation, the combined kernel, , only needs to be positive in those regions which have not been excluded. The upper bound on can then be used to constrain the supplementary terms which arise from the excluded regions, as is done, for instance, in Eq. (26). Hence, one could, in principle, take a set of inversion coefficients, exclude the regions where the averaging kernel is negative, and deduce inequalities on the rotational splittings for a given upper bound, ℬ. Conversely, one could search for the limiting value of ℬ beyond which the inequalities break down. If the averaging kernel is well localised, one will have primarily tested whether the rotation gradient is negative in that particular region. This approach could also be combined with a simplex method, as described above, in order to find tighter constraints on the splittings.
2.1.5. Error bars
In practice, it will be necessary to take into account error bars on observed rotational splittings. As will be described in this section, this introduces complications when interpreting the above inequalities. Indeed, if one of the inequalities is not satisfied, one can only deduce that the rotation profile has a positive gradient with some probability that needs to be determined. In order to illustrate this, we start with Eq. (25) as a generic form for the inequalities, group the nonzero terms together on the lefthand side, and introduce error terms, (29)where is the error realisation on a given normalised splitting, s′ represents the combined splittings, and ε′ the combined errors. For a true violation of the inequality, one needs s′> 0. However, since only the measurement s′ + ε′ is available, one has to evaluate the probability that s′ + ε′>ε′. An obvious approach is to compare the 1σ error bar on ε′, which we will denote σ′, with the measurement. This can be obtained as a quadratic sum of the individual 1σ error bars, (30)where the are the 1σ error bars on the individual normalised splittings. Hence, if s′ + ε′ is equal to 3σ′, and ε′ follows a normal distribution, the probability that the inequality is violated is 99.87% (where we have taken into account that there is violation in only one of wings of the distribution for ε′). It would be tempting to conclude that this is the probability that the rotation profile has a positive gradient. However, one will typically test a large number of inequalities which increases the chances of finding large deviations on one of the ε′ values and hence of having a false alarm. Given the correlations between the different inequalities, it is not straightforward how to calculate the probability of a false alarm. As will be described in Sect. 3, we will carry out MonteCarlo simulations to estimate such a probability.
2.2. Rotation profiles subject to Rayleigh’s stability criterion
2.2.1. Inequalities for the full domain
A different set of inequalities can be obtained from Rayleigh’s stability criterion. According to this criterion, the angular momentum must increase with the distance to the rotation axis: otherwise, the fluid will be dynamically unstable and can free up energy by redistributing its angular momentum (e.g. Rieutord 1997). Mathematically, this is expressed by the condition (31)where ϖ is the distance to the rotation axis. If we furthermore assume that the rotation profile only depends on r, this criterion then becomes (32)Hence, this criterion gives the maximum rate at which a rotation profile can decrease before the fluid becomes unstable. We note that such a criterion is incompatible with a sign change in the rotation profile, except at discontinuities. However, in realistic stars, viscosity, even though it is small, would remove true discontinuities, thereby suppressing sign changes. If a discontinuity were present in the rotation profile, it would be stable only if the absolute value of the rotation rate increases outwards across the discontinuity, which is the opposite from what was considered in the previous section (if we ignore sign changes). Finally, in real stars, this criterion is only one of the terms in the more general SolbergHoiland criterion for convective stability (e.g. Maeder 2009). Hence there could be situations where an unstable rotation profile is stabilised by, say, a μ gradient.
At this point, we will assume that the rotation profile does not change signs. Accordingly, we will see the consequences of the inequality rather than those of Eq. (32). In order to derive inequalities on the rotational splittings, we start from Eq. (1), do an integration by part, and divide both sides by : (33)If a discontinuity is present, for instance at r = r_{d}, one would obtain the following formula: (34)Of course, the difference would have to be negative, in keeping with Rayleigh’s criterion. We note, in passing, that the rotation kernels, K_{i}, behave as r^{n} in the centre, where n ≥ 4. Hence the ratio, K_{i}(r) /r^{2} always goes to zero in the centre. From now on, we will use the following notation to designate a second type of normalised rotational splitting: (35)A first inequality can be found straight away, in much the same way as was done above. The second term on the righthand side of Eq. (33) is negative, given the assumption . This leads to the following inequality: (36)This inequality sets a lower limit on the surface rotation rate based on the internal rotation rate, as measured by the rotational splitting. This is consistent with Rayleigh’s criterion which gives the maximum rate at which the rotation profile can decrease.
We then introduce a second type of integrated kernel: (37)Examples of this type of integrated kernel are shown in Fig. 4.
Fig. 4 Second type of integrated normalised kernels for the same modes as in Fig. 1 (the same colour scheme is used in both figures). These integrated kernels are very similar, so it is difficult to distinguish them, even though there is a mixture of plike and glike modes. (Colour online.)

Open with DEXTER
As was done above, we find, for a given pair of modes (i,j), inequalities of the following form, (38)where (39)Figure 5 illustrates ratios of the second type of integrated kernels, from which we can determine and . Once more, we obtain the relations by inserting r = 1 into Eq. (38). In order to avoid having or , the integrated kernels J_{i} and J_{j} need to have the same behaviour in the centre. Hence, the ℓ values of modes i and j, should be the same or should be 1 and 3.
Fig. 5 Ratios of second type of integrated kernels for the same pairs of modes as in Fig. 2.

Open with DEXTER
We then multiply Eq. (38) by and integrate over the interval [0,R]. This yields, taking into account the sign change, (40)where we have made use of Eq. (33). This time, given the inverted inequalities, the surface terms cannot simply be cancelled out and must therefore be kept. Furthermore, because of the inequality given in Eq. (36), the terms in Eq. (40) are negative. Hence, we rearrange this inequality so as to make positive terms appear, thereby leading us to our final form, (41)where is the error bar on the normalised splitting, . Had we worked with a discontinuous profile, the same inequalities would be obtained, as long as the rotation rate increases across the discontinuities (which is the opposite to what we assumed in the previous section). Otherwise, supplementary terms for each discontinuity where the rotation rate decreases would need to be included, but again we emphasise that such discontinuities would not satisfy Rayleigh’s stability criterion.
In analogy with what was done above, we introduce the quantity , defined as (42)Carrying out an integration by parts leads to the following equality: (43)Combining Eq. (43) with the inequalities in Eq. (38) then yields (44)Hence, the quantities obey the opposite inequalities to the normalised splittings . Accordingly, if or (i.e. if the integrated kernels J_{i}(r) and J_{j}(r) do not cross), then the slope of the line connecting to is negative. However, the integrated kernels do cross frequently, as illustrated in Fig. 6, so one should instead look at the general trend in an diagram. Only a systematic application of the inequalities will yield conclusive results.
Fig. 6 Cumulative number of crossings of between the J_{i}(r) integrated kernels as a function of position, r/R. These crossings were calculated using the ℓ = 1 modes from Model 1, which is introduced in Sect. 3.2.

Open with DEXTER
One can then try to see if the above conditions are sufficient for the existence of a rotation profile which satisfies Rayleigh’s criterion. This time, in keeping with the inequalities, we must assume the surface rotation rate is imposed. As was done previously, we introduce the ratio and its corresponding radial coordinate, , defined such that . This radial coordinate is guaranteed to exist provided the function is continuous. We then define a rotation profile which is discontinuous at and where everywhere else: (45)The constants μ and λ are obtained by imposing the correct surface rotation rate and rotational splittings. This leads to (46)It is straightforward to show that λ is positive, using Eq. (36). However, it is not clear whether μ is positive or not, meaning the above rotation profile might be negative in the centre. In addition, we were not able to show that  μ  <  μ + λ  which is needed to ensure that the absolute value of Ω increases across the discontinuity, and hence that Rayleigh’s criterion is verified. Instead, the above rotation profile only satisfies the criterion , which is slightly less restrictive than the condition we obtained when we assumed the rotation profile does not change signs in addition to Rayleigh’s criterion. Accordingly, if μ is positive, then  μ  ≤  μ + λ  and Rayleigh’s criterion is nearly satisfied (i.e. ). Hence, this simple strategy is unable to produce a foolproof solution solely based on the above inequalities and seems to indicate that these do not provide a sufficient, or nearly sufficient, condition for the existence of a rotation profile which satisfies Rayleigh’s criterion.
2.2.2. Inequalities where the centre is excluded
If an upper bound on in the central regions is known, then it is possible to derive some slightly different inequalities, much like in the previous section. We begin by introducing the quantities and : (47)Then, following a similar reasoning as in the previous section, we finally obtain (48)where denotes the upper bound on over the interval [0,r_{0}]. We do note that to first order, behaves as 2rΩ in the centre.
3. Applications
3.1. Direct application of the inequalities
A natural and straightforward application of the above inequalities is to see whether the rotation profile of a given star has a positive gradient and/or fails to respect Rayleigh’s criterion. In what follows, we will therefore test these inequalities in artificial situations to see how effective they are.
We start by using Model S (ChristensenDalsgaard et al. 1996) and impose the following rotation profile, (49)where A = B = 1.25, C = 1.5, x_{0} = 0.220, x_{1} = 0.432, and d = 0.05. This rotation profile and its derivatives are shown in the upper panel of Fig. 7. As can be seen, it has a positive gradient in the first 33% of the star, and does not satisfy Rayleigh’s criterion over a narrow region around 0.45 R. We then considered a set of 44 modes with harmonic degrees ℓ = 1–3 from which we calculated observed rotational splittings. We assumed these splittings follow a normal distribution, and their 1σ error bars are 0.0067 μHz, which is somewhat smaller than what is achieved with the Kepler satellite.
Fig. 7 Upper panel: rotation profile and associated derivatives used in first test case on Model S. Middle panel: combined kernel from simplex method which led to a detection of a positive gradient. Bottom panel: SOLA inversion results on along with 1σ error bars. (Colour online.)

Open with DEXTER
A systematic application of the inequalities (13) and (23) to all pairs of modes with degrees ℓ = 1 to 3 did not reveal a negative gradient. However, using Eq. (25), we were able to place tighter constraints on the splittings. We systematically applied this equation, in which each splitting was isolated to one side, then the other, of the inequality, and a simplex algorithm^{2} used to optimise the coefficients of the remaining splittings. This approach allowed us to deduce lower and upper bounds on each splitting, and to show that the rotational splitting of the ℓ = 3 mode with the lowest radial order (n = 13) is approximately 4.99σ beyond the bound predicted by Eq. (25), i.e. we showed that s′/σ′ = 4.99. A naive interpretation of this would lead to the conclusion that the probability of a false alarm is 3.0 × 10^{7}. However, as discussed in Sect. 2.1.5, this does not take into account that we are testing multiple inequalities, which increases the probability of having a large deviation on one of them. We therefore carried out a Monte Carlo test with 10^{6} realisations of the splittings. We calculated the maximal value of ε′/σ′ for each realisation, using the coefficients from the inequalities based on the mode pairs and based on the simplex approach, and counted the number of times the threshold 4.99 was exceeded. This occurred in 166 cases, thereby implying a probability of 1.7 × 10^{4} for a false alarm, i.e. substantially larger than the above value. A similar test, using splittings from a decreasing profile, yielded a probability of 1.5 × 10^{4}, thereby showing the result is robust. Even then, this new value is likely to be an underestimate because the Monte Carlo simulation was carried out for fixed coefficients. Ideally, one would want to repeat the simplex calculation for each realisation of the splittings, since the results are optimised for the given set of splittings. However, the numerical cost of such an approach is too high to obtain a result in a reasonable amount of time.
Fig. 8 Rotational splittings and 1σ error bars (solid red lines), constraints deduced from inequalities on pairs of modes (dotted blue lines), and constraints from multiple modes using simplex method (dashed green lines). The lighter lines denote the 1σ error bars. Right panel: zoom on ℓ = 3 mode where an inequality breaks down by 4.99σ (as indicated by the arrow). (Colour online.)

Open with DEXTER
The reason why the inequality failed for the ℓ = 3 mode is straightforward to understand. The middle panel of Fig. 7 shows the resultant combined kernel, . This kernel has a maximum amplitude where the rotation profile increases sharply and a low amplitude near the sharp decrease. Hence, the integral of the product is negative which leads to a breakdown of the inequalities for sufficiently small error bars. The lower panel of Fig. 7 shows the results obtained from a SOLA inversion of . Given that only the ℓ = 1 to 3 modes were used, the averaging kernels are poorly localised and the resultant inverted profile a poor match to , which inspires little confidence in the inversion. Nonetheless, the inversion does detect a positive gradient with a 2.87σ margin. Hence, the above inequalities, in conjunction with the simplex method, have yielded firmer results than the inversion.
In contrast to the tests based on finding a positive gradient, those based on Rayleigh’s criterion failed to detect a decrease in the angular momentum. Possible explanations for this failure is that the region with this decrease is either too narrow, or poorly located, given the set of modes we considered.
We also considered a second rotation profile with model S, (50)where x = r/R, A = 1 μHz, B = 0.5 μHz, C = 0.3, D = 0.4, and E = 0.2. This rotation profile has been designed to have a positive gradient in a localised region, fail Rayleigh’s criterion in another region, and have a zero derivative in the centre, as expected from regularity conditions. Figure 9 illustrates this rotation profile, as well as dΩ / dx and d(x^{2}Ω) / dx.
Fig. 9 The rotation profile, as based on Eq. (50), and its derivatives. (Colour online.)

Open with DEXTER
A set of 282 modes with ℓ ranging from 1 to 20 were calculated using the ADIPLS pulsation code (ChristensenDalsgaard 2008). Such an extensive set is naturally out of reach for stars other than the sun, given cancellation effects, but is what is needed to carry out a sufficiently detailed inversion of the rotation profile. Rotational splittings were calculated using the above profile, and their 1σ bars were set to 0.0033 μHz, which is smaller than what is currently achieved with the Kepler mission.
Figure 10 shows the result of a SOLA inversion (Pijpers & Thompson 1992, 1994) of the gradient of the rotation profile^{3}. The 1σ error bars are shown in this plot. The positive gradient shows up clearly.
Fig. 10 Inverted rotation profile gradient. The continuous line shows the actual rotation profile gradient, whereas the blue crosses indicate inversion results and associated 1σ error bars. (Colour online.)

Open with DEXTER
In contrast to the inversions, a systematic application of the inequalities (13) and (23) to all pairs of modes did not reveal a positive gradient. The same also applied to tests based on multiple modes, as described above (we limited ourselves to modes with ℓ = 1 to 10, given the numerical cost of the simplex algorithm). We also applied a heuristic approach which consisted in recuperating the inversion coefficients and adjusting them so as to have a positive combined kernel everywhere. This strategy was to no avail even if the error bars were set to nearly 0. A possible explanation for these failures is that the rotation profile decreases only over a very narrow region.
One may also see whether it is possible to show that the underlying profile does not satisfy Rayleigh’s criterion. Figure 11 shows inversion^{4} results for the gradient of the angular momentum, using the integrated kernels defined in Eq. (37). As can be seen for the full set of modes (upper panel), the inversion is able to detect the region which does not satisfy Rayleigh’s criterion.
Fig. 11 Inverted profile for the gradient of the angular momentum, using ℓ = 1 to 20 modes (upper panel) and only ℓ = 8 modes (lower panel). The continuous line shows the actual gradient, whereas the blue crosses indicate inversion results and associated 1σ error bars. For the sake of clarity, the horizontal error bars (obtained from the averaging kernels) have been omitted in the lower panel. (Colour online.)

Open with DEXTER
We then systematically applied the inequalities (41) for each pair of modes. Figure 12 shows the maximum values of ε′/σ′ as a function of the harmonic degree. Three different cases are investigated. The solid line shows what happens if we use the exact surface rotation rate, Ω(R) = 0.0836 μHz. Deviations larger than 4σ start to appear at ℓ = 8. The false alarm probability based on a Monte Carlo simulation is below 10^{5} (i.e. none of the 10^{5} realisations produced a large enough value of ε′/σ′). The dotted line corresponds to the case where the overestimate Ω(R) = 0.5 μHz is used. This time, the deviations exceeded 4σ for ℓ ≥ 17. The false alarm probability is 1.4 × 10^{3}. Finally, the dashed line shows what happens when the centre is excluded, using r_{0} = 0.01 and Hz (which is nearly 50 times too large), and still keeping Ω(R) = 0.5 μHz. Deviations greater than 4σ appear at ℓ = 9. The false alarm probability turned out to be 1.3 × 10^{3}. We also carried out a Monte Carlo test with 10^{6} realisations in the first case (i.e. with the exact surface rotation rate, over the whole domain) using only ℓ = 8 modes. This yielded a false alarm probability of 2.1 × 10^{4} (we note that the maximum value of ε′/σ′ is 4.61 in this case). In contrast, an inversion based on just these modes yields rather poor and inconclusive results due to poorly localised averaging kernels as illustrated in the lower panel of Fig. 11 (we do note that one of the points in the inversion does suggest a decrease in the angular momentum, but even the 1σ error bar allows for a positive gradient).
Fig. 12 Maximum values of ε′/σ′ as a function of ℓ for inequalities based on Rayleigh’s criterion. Three different test cases are investigated (see text for details).

Open with DEXTER
Fig. 13 Rotation profiles which give the similar splittings (to within 0.01 μHz) in Model 1 (from Sect. 3.2). Profile 1 is also used to calculate the observed rotational splittings (using Model 2) in Sect. 3.2. (Colour online.)

Open with DEXTER
One can also investigate the use of these inequalities in red giant stars. However, these seem to be less effective for such stars, since the rotation kernels are mainly sensitive to the core or surface regions and hardly in between. Accordingly, it is not too difficult to construct pairs of rotation profiles, one of which is decreasing the other not, and which produce essentially the same rotational splittings (i.e. to within some error bar). Figure 13 shows such a pair – the corresponding rotational splittings, when calculated in Model 1 (or Model 2 – these models are introduced in the following section), are within 0.01 μHz. Indeed, as explained in Goupil et al. (2013), the rotational splittings of red giants are primarily sensitive to the average core and surface rotation rates. Obviously, the above inequalities will not detect a positive gradient in such a situation, since there exists at least one decreasing rotation profile which reproduces the splittings within the error bars. Including higher ℓ modes does not seem like a viable solution, as these are harder to detect and will experience a stronger trapping, either in the p or gmode cavities. In order to cause one of the inequalities to break down, one needs to have a rotation profile which is increasing throughout most of the star. However, this will probably cause the splittings of the plike modes to be comparable or larger than those of the glike modes – already a very strong indication of an increasing rotation rate prior to any tests or inversions. In the following section, we nonetheless show how the above inequalities can be useful when studying red giants.
3.2. The effects of a mismatch between an observed star and the reference model
At this point a natural question arises: if the above inequalities break down is this necessarily caused by a positive gradient in the rotation profile, or can there be other causes? In what follows, we will show a situation where a slight mismatch between an observed star and a reference model leads to one of the inequalities breaking down, in spite of having a rotation profile where the gradient is negative everywhere. To do so, we start off with two very close 1 M_{⊙} models of redgiant stars. The second model is the same as the first, except for an adhoc 50% decrease of the density near the surface. This is achieved by multiplying the density profile by the function (51)where r_{d} = 0.995 R, λ = 2 × 10^{3}, and A = − 0.5. Table 1 gives the characteristics of these two models. We note in passing that the mass difference between these two models corresponds to 73% of Mercury’s mass. Figure 14 shows the inertia of their ℓ = 0 and 1 modes as a function of frequency, where .
Characteristics of the two models.
Fig. 14 Inertias of ℓ = 0 and 1 modes in models 1 and 2 as a function of frequency. (Colour online.)

Open with DEXTER
In what follows, the frequencies of Model 2 will be treated as the observations, and Model 1 will be used as a reference model. Furthermore, the observed frequency spectrum will include all of the ℓ = 0 modes over a given frequency range, and only a subset of the ℓ = 1 modes. Indeed, only the most plike dipole modes are expected to be visible in observed stars. We therefore selected the dipole modes at local minima of the inertia curve as well as the adjacent 2 modes on either side. Figure 15 shows an echelle diagram with the frequencies from both models. We assume 1σ error bars of 0.01 μHz on the frequencies, which is typical for the Kepler mission. Table 2 gives the value of where M is the number of frequencies. This quantity characterises the departure of the frequency spectrum of Model 1 from that of Model 2.
Fig. 15 Echelle diagram comparing the frequencies of Model 1 (with and without the KBCD surface corrections) and Model 2. (Colour online.)

Open with DEXTER
Seismic values for Model 1, with and without the Kjeldsen et al. (2008; KBCD, hereafter) surface corrections.
As can be seen from Table 2, the pulsation spectrum of Model 1 is a poor fit to the observations. Our observational error bars would therefore exclude Model 1 immediately. However, surface corrections based on KBCD are frequently included in seismic studies of observed stars. We therefore applied such corrections to the frequencies of Model 1, using the formula (52)where ν_{n,ℓ} are the original frequencies, the corrected frequencies, ν_{0} a reference frequency, a_{KBCD} a multiplicative constant, b_{KBCD} the exponent used in the KBCD power law, and Q_{n,ℓ} the mode’s inertia, divided by the inertia of an ℓ = 0 mode interpolated to the same frequency (e.g. Aerts et al. 2010, p. 470). We choose the values ν_{0} = 125 μHz, which is in the middle of the frequency range, a_{KBCD} = 0.40315 in order to reproduce as accurately as possible the frequency deviations in Model 2, and b_{KBCD} = 4.9, the value obtained in KBCD after calibrating Model S to the sun. The division by Q_{n,ℓ} is a later addition to the formula, which proved to be necessary in the case of red giants because of the large variations of the inertia of nonradial modes (e.g. Deheuvels et al. 2012). The second line of Table 2 shows the impact of including this surface correction. Although the is still above 1 and is worse than the best fitting models in Deheuvels et al. (2012), it is better than any of the best fits found in Deheuvels et al. (2014). Hence, such a model would probably be retained as a viable reference model with which to study the observed star (i.e. Model 2).
We calculate rotational splittings in Model 2, using the rotation profile (53)where A = 0.1μHz, B = 0.9μHz and C = 9 × 10^{3}. We note that this rotation profile decreases with r, but still satisfies Rayleigh’s stability criterion. This rotation profile is illustrated in Fig. 13 (see Profile 1). The resultant rotational splittings for model 2 are shown in Fig. 16, and these will serve as our observations. We assume 1σ error bars of 0.007 μHz on these splittings, which is approximately times smaller than the error bars on the frequencies, which is what you would expect from generalised ℓ = 1 splittings.
Fig. 16 Rotational splittings in model 2. The diamonds correspond to the splittings which were used in this study, whereas the crosses represent those which were discarded.

Open with DEXTER
Then, we systematically apply Eq. (13) to every pair of dipole modes. For each mode, we end up with N − 1 upper and lower bounds, where N is the number of rotational splittings. Figure 17 (upper panel) shows the bounds which are obtained for one of the plike modes in Model 1. According to this approach, this splitting is compatible with the lower and upper bounds from the other modes to within the 1.22σ. However, if the centre is excluded, as explained in Sect. 2.1.2, then it is possible to find an inequality which breaks down by 5.87σ. The middle panel of Fig. 17 shows the bounds obtained for the same mode, but using Eq. (23) with r_{0} = 2 × 10^{4}R and Rℬ = 5 × 10^{5}μHz. We note that the actual upper bound over the interval [0,r_{0}] is Rℬ = 3.270 μHz, i.e. more than 5 orders of magnitude smaller. A MonteCarlo simulation based on the coefficients deduced from inequalities on mode pairs found three cases where ε′/σ′> 5.87 in 10^{6} realisations, thereby indicating a false alarm probability of 3 × 10^{6}. The lower panel shows what happens when applying the same tests using Model 2 as a reference model. This time we set Rℬ = 3.270 μHz to be as restrictive as possible. Even then, none of the inequalities breaks down, which is consistent with the fact that we are using the true model and the rotation profile is decreasing.
Fig. 17 Upper and lower bounds on a given splitting, deduced from the N − 1 other rotational splittings, assuming that the rotation profile decreases. In the upper and middle panels, Model 1 has been used as the reference model, whereas in the lower panel, Model 2 is the reference model. In the lower two panels, a more restrictive set of inequalities is obtained by excluding the centre, as described in Sect. 2.1.2. The frequency of the original mode is shown by the red vertical dotted line, whereas the blue horizontal dotted and solid lines indicate its rotational splitting plus or minus the error bar. The dark blue solid vertical segments indicate the upper and lower bounds deduced from the other modes, and the 1σ error bars are indicated by the light blue extensions. (Colour online.)

Open with DEXTER
It is relatively straightforward to understand why Model 1 leads to a break down of one of the inequalities. Indeed, as can be seen in Fig. 14, the mode inertias of Models 1 and 2 do not match very well, especially for the high frequency plike dipole modes. This modification of mode inertias stems from the fact that surface effects act differently on p and gmodes and will therefore shift the former with respect to the latter. This, in turn, modifies the avoided crossings which occur between them, and hence, the inertias of the resultant modes. Such an effect is likely to be strongest in red giant stars where the spacing between consecutive gmodes can be comparable to the frequency shifts caused by surface effects. In contrast, applying a surface correction recipe like the one described in KBCD merely corrects the frequencies and not the inertias. This leads to inconsistencies between the mode inertias and period spacings, as illustrated in Fig. 18, and could mask mismatches between observations and what seems to be the bestfitting model(s).
Fig. 18 Normalised mode inertias as a function of averaged periods spacings (defined as π_{n} = (1 /ν_{n − 1} − 1 /ν_{n + 1}) / 2, where n is the radial order). The lower panel corresponds to Model 1 with a 90% decrease in density near the surface, whereas the upper panel uses Model 1 with KBCD surface corrections, adjusted so as to match (as best as possible) the frequencies of the modified model. The increased scatter at low inertias in the upper panel illustrates the mismatch between period spacings and mode inertias.

Open with DEXTER
One can also apply the tests based on Rayleigh’s criterion. We therefore systematically applied Eq. (41) using the exact surface rotation rate, to every pair of modes. However, this set of inequalities turns out to be far less stringent than the first set of inequalities. Accordingly, none of them break down, even when the centre is excluded, as described in Sect. 2.2.2, using the most restrictive value of possible. Figure 19 shows lower and upper bounds for the rotational splitting of the dipole mode (n,ℓ) = ( − 61,1) with r_{0}/R = 2 × 10^{4} and Hz.
Fig. 19 Same as Fig. 17 but using the inequalities based on Rayleigh’s criterion. The centre has also been excluded, as described in the text, thereby leading to more stringent conditions. The horizontal red dotted line near the top of the figure is an upper limit deduced from the surface rotation rate. The error bars which extend off the bottom of the plot go to negative values. (Colour online.)

Open with DEXTER
One could then turn the inequalities based on Rayleigh’s criterion the other way around and search for a lower bound on the surface rotation rate. Equation (36) already provides a first condition. Applying this condition using Model 1 as the reference model leads to Ω(R) > 6.54 × 10^{7}μHz whereas Model 2 (the true model) leads to Ω(R) > 6.04 × 10^{7}μHz. The true surface rotation rate is more than 5 orders of magnitude larger, with Ω(R) = 0.10010 μHz. However, one can also rearrange Eq. (48) to obtain more restrictive conditions: Applying these conditions using r_{0} = 2 × 10^{4} and Hz yields Ω(R) ≥ 4.89 × 10^{4}μHz for Model 1 and Ω(R) ≥ 1.52 × 10^{5}μHz for Model 2, which is still 3 to 4 orders of magnitude below the true value, and furthermore, very model dependant. Hence, even this way around, the inequalities based on Rayleigh’s criterion only provide very weak constraints and one would probably be better off either trying to measure the rotation rate through photometric modulation induced by spots (if present) or through spectroscopy. Alternatively, one could apply the relation derived by Goupil et al. (2013) which relates the ratio between the average surface and core rotation rates of red giants to the slope of the rotational splittings as a function of ζ, the ratio of the kinetic energy of the mode in the gmode cavity to the total kinetic energy. Such a relation has already been tested on 6 subgiants observed by Kepler and shown to agree, in most cases, with results based on inversions (Deheuvels et al. 2014).
4. Discussion
In this article, we have derived various inequalities which can be used to check whether a rotation profile has a negative gradient or satisfies Rayleigh’s stability criterion, for a given reference model. We explored how these inequalities may be used in practical situations by investigating various test cases. In the first test case, a rotation profile which satisfies neither the assumption everywhere nor Rayleigh’s criterion was imposed on Model S (ChristensenDalsgaard et al. 1996). A set of 44 splittings for modes with ℓ = 1 to 3 were used in the various tests. The above inequalities were able to detect the presence of a positive gradient, but were unable to show a violation of Rayleigh’s criterion. Although an inversion also suggested the presence of a positive gradient, the resultant conclusions remained less firm than those derived by the inequalities. A second test case, also based upon Model S, used a different profile which also contained a region positive gradient on the rotation profile and one where the angular momentum is decreasing. This second case used a set of 282 modes (with ℓ = 1 to 20), thereby enabling a clear detection of both of these regions using inversions. In contrast, the above inequalities failed to detect the positive gradient in the rotation profile, probably as a result of the narrowness of this region. However, these were able to detect a violation of Rayleigh’s criterion, even in situations where inversions yielded poor results, provided modes with ℓ ≥ 8 were included. We expect that this lower limit on the ℓ value is dependant on both the way in which the rotation profile violates Rayleigh’s criterion and on the size of the error bars on the rotational splittings.
We also looked at other ways in which the inequalities may break down. For this purpose, we considered two models of red giants which were identical except for an adhoc nearsurface modification of the density profile in the second model. The first model was then used as a reference model in trying to interpret the rotational splittings of the second model, which were based on a rotation profile which has a negative gradient everywhere and which obeys Rayleigh’s criterion. It turned out that one of the inequalities based on the rotation profile’s gradient was violated, whereas all of the inequalities based on Rayleigh’s criterion were satisfied. The reason for this is that the mode inertias differ in the two models, especially at high frequencies. This may come as a surprise since only the outer 0.5% or so is different between the two models. However, as argued above, nearsurface effects shifts the frequencies of plike modes relative to those of the glike modes, thereby modifying the avoided crossings which occur between the two, and hence the resultant inertias. Frequency correction recipes for nearsurface effects, such as the one presented in Kjeldsen et al. (2008), are able to mask the frequency differences between the two models, but they do not correct the mode inertias, thereby leading to erroneous conclusions on the rotation profile as shown in this test case.
This leads to the natural question as to what to do if one or several inequalities are violated by a set of observed rotational splittings. In answer to this question, one needs to consider the following options. First, a different, more suitable, reference model needs to be found. We expect that in the case of red giants, the above inequalities could be quite constraining owing to very different mode trappings, and may therefore provide an indirect way of testing the structure of the reference model. Furthermore, such stars are the most likely candidates to having a rotation profile which decreases outwards because of the spinup of the core as it contracts and the slowing down of the envelope as it expands. Of course, a direct comparison of the nonradial mode frequencies will very likely provide tighter constraints, but so far, no one has yet fitted a redgiant model to within 1σ of a set of observed frequencies. Hence, if one adopts less stringent constraints on the selection of the model, and/or if frequency surfacecorrections are included, the above criteria will be useful in determining beforehand whether or not the chosen reference model is compatible with a decreasing rotation profile. The second option, is to consider that the rotation profile does not have a negative gradient throughout the star and/or violates Rayleigh’s stability criterion (depending on which inequalities are not satisfied). As was already stated in the introduction, there is convincing evidence of stars where the gradient of the rotation profile is positive, at least in localised regions (Schou et al. 1998; Kurtz et al. 2014). This raises the open questions as to how often such a situation occurs, and whether even a red giant could not have a localised region with a positive rotation gradient, for example, in the outer convective envelope. However, one must not forget that the above criteria are not necessarily the most effective at detecting a rotation profile with a positive gradient. Accordingly, a mismatch between the reference model and the observed star may be a more likely explanation, which brings us back to the first option. A last option would be to consider that the rotation profile is too rapid to be described by first order effects, thereby violating the assumptions in this work. In such a situation, it would no longer be possible to apply linear inversion theory, except perhaps on generalised rotational splittings (defined as the frequency difference between prograde modes and their retrograde counterparts) of acoustic modes in stars with nearly uniform rotation profiles (Reese et al. 2009). Recent works (Reese et al. 2006; Ballot et al. 2010; Ouazzani et al. 2013) have, however, shown up to what point a first order description of the effects of rotation are valid, and can therefore be used to decide whether or not the criteria described in this paper are applicable.
The simplex algorithm was downloaded from http://algs4.cs.princeton.edu/65reductions/Simplex.java.html and is described in Sedgewick & Wayne (2011).
Acknowledgments
D.R.R. thanks the referee for very constructive comments which have substantially improved the manuscript. D.R.R. thanks A. Miglio for helping him come up with some of the ideas in this article and for providing red giant models. D.R.R. is currently funded by the European Community’s Seventh Framework Programme (FP7/20072013) under grant agreement No. 312844 (SPACEINN), which is gratefully acknowledged. This article made use of InversionKit, an inversion software developed in the context of the HELAS and SPACEINN networks, funded by the European Commission’s Sixth and Seventh Framework Programmes.
References
 Aerts, C., ChristensenDalsgaard, J., & Kurtz, D. W. 2010, Asteroseismology, Astronomy and Astrophysics Library (SpringerVerlag) [Google Scholar]
 Baglin, A., Auvergne, M., Barge, P., et al. 2009, IAU Symp., 253, 71 [NASA ADS] [CrossRef] [Google Scholar]
 Ballot, J., Lignières, F., Reese, D. R., & Rieutord, M. 2010, A&A, 518, A30 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Beck, P. G., Montalban, J., Kallinger, T., et al. 2012, Nature, 481, 55 [NASA ADS] [CrossRef] [Google Scholar]
 Borucki, W., Koch, D., Batalha, N., et al. 2009, IAU Symp., 253, 289 [NASA ADS] [Google Scholar]
 Ceillier, T., Eggenberger, P., García, R. A., & Mathis, S. 2013, A&A, 555, A54 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 ChristensenDalsgaard, J. 2008, Ap&SS, 316, 113 [NASA ADS] [CrossRef] [Google Scholar]
 ChristensenDalsgaard, J., Dappen, W., Ajukov, S. V., et al. 1996, Science, 272, 1286 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Córsico, A. H., Althaus, L. G., Kawaler, S. D., et al. 2011, MNRAS, 418, 2519 [NASA ADS] [CrossRef] [Google Scholar]
 Deheuvels, S., García, R. A., Chaplin, W. J., et al. 2012, ApJ, 756, 19 [NASA ADS] [CrossRef] [Google Scholar]
 Deheuvels, S., Doğan, G., Goupil, M. J., et al. 2014, A&A, 564, A27 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Eggenberger, P., Montalbán, J., & Miglio, A. 2012, A&A, 544, L4 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Goupil, M. J., Mosser, B., Marques, J. P., et al. 2013, A&A, 549, A75 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kjeldsen, H., Bedding, T. R., & ChristensenDalsgaard, J. 2008, ApJ, 683, L175 [NASA ADS] [CrossRef] [Google Scholar]
 Kurtz, D. W., Saio, H., Takata, M., et al. 2014, MNRAS, 444, 102 [NASA ADS] [CrossRef] [Google Scholar]
 Ledoux, P. 1951, ApJ, 114, 373 [NASA ADS] [CrossRef] [Google Scholar]
 Maeder, A. 2009, Physics, Formation and Evolution of Rotating Stars, Astronomy and Astrophysics Library (SpringerVerlag) [Google Scholar]
 Marques, J. P., Goupil, M. J., Lebreton, Y., et al. 2013, A&A, 549, A74 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mosser, B., Goupil, M. J., Belkacem, K., et al. 2012, A&A, 548, A10 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Ouazzani, R.M., Goupil, M. J., Dupret, M.A., & Marques, J. P. 2013, A&A, 554, A80 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pijpers, F. P., & Thompson, M. J. 1992, A&A, 262, L33 [NASA ADS] [Google Scholar]
 Pijpers, F. P., & Thompson, M. J. 1994, A&A, 281, 231 [NASA ADS] [Google Scholar]
 Reese, D., Lignières, F., & Rieutord, M. 2006, A&A, 455, 621 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Reese, D. R., MacGregor, K. B., Jackson, S., Skumanich, A., & Metcalfe, T. S. 2009, A&A, 506, 189 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Rieutord, M. 1997, Une introduction à la dynamique des fluides (Paris: Masson) [Google Scholar]
 Schou, J., Antia, H. M., Basu, S., et al. 1998, ApJ, 505, 390 [NASA ADS] [CrossRef] [Google Scholar]
 Sedgewick, R., & Wayne, K. 2011, Algorithms, 4th edn. (Upper Saddle River, New Jersey: Pearson Education, Inc.) [Google Scholar]
Appendix A: Attempting to construct a decreasing rotation profile when Eq. (23) is satisfied
We start by introducing the following radial coordinates: (A.1)and define a profile as follows (where we have assumed r_{a⋆}<r_{b⋆}): (A.2)A similar solution can be obtained if r_{b⋆}<r_{a⋆}. In this definition, we have deliberately postponed defining the rotation profile over the interval [0,r_{0}[, except that we will impose its continuity at r_{0} (except if r_{0} = r_{a⋆}). Inserting this expression into Eq. (19) then yields the following system: the solution of which is: From this we deduce that Eq. (20) is a sufficient condition to ensure that λ and μ are positive, and hence that Ω is decreasing. In contrast, Eq. (23), does not ensure that λ and μ are positive. To see this, we reexpress the numerator of Eq. (A.5) as follows: In order to ensure that the term I is positive according to Eq. (23), one needs to set to −ℬ over the interval where I_{i}(r) − b^{⋆}I_{j}(r) is positive. Term II is necessarily smaller or equal to zero. In order to cancel it out, needs to be zero over the interval where I_{i}(r) − b^{⋆}I_{j}(r) is negative. Likewise, in order to ensure that μ is positive, one would need to make sure when a^{⋆}I_{i}(r) − I_{j}(r) is positive, and otherwise. However, there is no guarantee that these two sets of conditions are compatible.
