1. Introduction

Planck1 (Tauber et al. 2010; Planck Collaboration 2011a) is the third-generation space mission to measure the anisotropy of the cosmic microwave background (CMB). It observes the sky in nine frequency bands covering 30–857GHz with high sensitivity and angular resolution from 33arcmin to 4.2arcmin (Table 1). The Low Frequency Instrument (LFI; Mandolesi et al. 2010; Bersanelli et al. 2010; Mennella et al. 2011) covers the 30, 44, and 70GHz bands with amplifiers cooled to 20K. The High Frequency Instrument (HFI; Lamarre et al. 2010; Planck HFI Core Team 2011a) covers the 100, 143, 217, 353, 545, and 857GHz bands with bolometers cooled to 0.1K. Polarisation is measured in all but the highest two bands (Leahy et al. 2010; Rosset et al. 2010). A combination of radiative cooling and three mechanical coolers produces the temperatures needed for the detectors and optics (Planck Collaboration 2011b). Two data processing centres (DPCs) check and calibrate the data and make maps of the sky (Planck HFI Core Team 2011b; Zacchei et al. 2011). Planck’s sensitivity, angular resolution, and frequency coverage make it a powerful instrument for Galactic and extragalactic astrophysics as well as cosmology.

Planck spins around its axis at a rate of one rotation per minute. The focal plane is oriented at an angle of 85° to the satellite spin axis, which tracks the direction of the Sun at ≈ 1° per day. The effective Planck scan strategy described in Dupac & Tauber (2005) results in areas near the ecliptic poles being observed several times more frequently than regions of sky near the ecliptic plane. This implies that there is a range of almost 50 in instrumental noise between the most- and least-frequently observed areas of the sky (Fig. 1). This scan strategy achieved greater than 99.9% coverage of the full sky on 1 April 2010 with gaps predominantly resulting from planet crossings and the masking of associated artefacts. A comparison between the all sky imaging capabilities of Planck, Wilkinson Microwave Anisotropy Probe (WMAP), COsmic Background Explorer/Differential Microwave Radiometer (COBE/DMR), AKARI, InfraRed Astronomy Satellite (IRAS) and Wide-field Infrared Survey Explorer (WISE) is shown in Table 1. Planck straddles the wavelength range between WMAP (Bennett et al. 2003) at one end and AKARI (Murakami et al. 2007) at the other end. At its lowest frequencies Planck improves upon the imaging resolution of WMAP. Although Planck does not have the high resolution of AKARI or WISE (Wright et al. 2010) at higher frequencies, it matches the capabilities of IRAS at frequencies which are more than a factor of three lower than IRAS. The consequence of this unprecedented spatial resolution and wavelength coverage is a unique simultaneous, multiwavelength view of the sky, enabling the study of a broad class of sources, and facilitating improved separation between Galactic and extragalactic foregrounds and the CMB.

The Early Release Compact Source Catalogue is a catalogue of all high-reliability sources, both Galactic and extragalactic, detected over the entire sky, in the first Planck all-sky survey. This includes a sample of clusters detected through the Sunyaev-Zeldovich (SZ) effect and a catalogue of cold, molecular cloud cores with far-infrared colour temperatures cooler than the ambient T ~ 18 K dust in our Galaxy. No polarisation information is provided for the sources at this time. One of the primary goals of the ERCSC is to provide an early catalogue of sources for follow-up observations with existing facilities, in particular Herschel, while they are still in their cryogenic operational phase. The need for a rapid turnaround (less than nine months) from the end of the first sky coverage to a community-wide release of source lists is the motivating factor behind the reliability and flux-density accuracy requirements as well as the choice of algorithms that were adopted for the ERCSC.

Table 1

Comparison between all sky surveys with similar frequencies aligned in rows.

The sources of noise vary significantly as a function of location on the sky as well as a function of frequency. Apart from the instrumental noise and the Galaxy, at the lowest frequencies the dominant astrophysical source of noise is the CMB itself. At the highest frequencies, zodiacal dust and emission from the interstellar medium dominate. As a result, the flux density limits corresponding to the same reliability vary widely across the sky (Fig. 1), with the sensitivity typically improving with increasing ecliptic latitude. The areas of deepest coverage are centred on the ecliptic pole regions due to the scan strategy and individual sources in that vicinity may be observed several times by Planck in the course of a single sky survey.

The data obtained from the scans of the sky between 2009 August 13 and 2010 June 6, corresponding to Planck operational days 91–389, have been processed and converted into all-sky maps at the HFI and LFI Data Processing Centres (DPCs). The data extend beyond a single sky coverage with 60% of the second sky coverage included in the maps. A description of the processing can be found in Zacchei et al. (2011); Planck HFI Core Team (2011b). Four different implementations of source detection algorithms were run on these maps. The performance of these algorithms was compared and the single implementation which provides superior source statistics at each frequency was selected for the final catalogue at that frequency. For the Early SZ (ESZ) and Early Cold Cores (ECC) catalogues, multifrequency algorithms described in Melin et al. (2006) and Planck Collaboration (2011s) respectively, have been run to provide a candidate source list, which has then been culled to maintain the high reliability required for the ERCSC. This paper describes the methodology through which the ERCSC pipeline generates a high reliability source catalogue as well as presents the contents and characteristics of the Planck ERCSC data release.

thumbnail Fig.1

The variance in units of Kelvin2 across the entire sky, with the left panel showing the variance for the LFI frequencies and the right panel showing the variance for the HFI frequencies. At any single frequency, the variance in the all-sky maps span almost a factor of 50 over the entire sky.

Open with DEXTER

2. The ERCSC pipeline

This section summarises the steps involved in progressing from the initial Planck all-sky maps to the final catalogue. A full description of the entire process can be found in Planck Collaboration (2011v), which has been released with the ERCSC.

The intensity maps on which the ERCSC pipeline is run are in HEALPix format (Górski et al. 2005) in units of KRJ (Kelvin Rayleigh-Jeans, a measure of brightness temperature) in the Galactic coordinate system. Thermodynamic temperature (TCMB) is related to the Rayleigh-Jeans brightness temperature by: where h is the Planck constant, k is the Boltzmann constant and ν is the frequency. The pixel size is 3.4arcmin for the LFI bands (30–70GHz) and 1.7arcmin for the HFI bands (100–857GHz) which corresponds to NSIDE values of 1024 and 2048 in the HEALPix format. In addition to the intensity map, there is a corresponding covariance map at each frequency, which is a measure of the noise in that pixel measured as the standard deviation of all scans that have gone through that pixel, after removal of an offset from each ring of observations. The covariance maps are in units of KRJ2. A full description of the map-making process can be found in Planck HFI Core Team (2011b).

The three core processing steps within the ERCSC pipeline are source detection, source extraction, and in the case of 857GHz, measuring the flux densities of each source at the three lower frequencies, 217, 353, and 545GHz, which is sometimes referred to as band-filling. These three steps are first run on the intensity maps to obtain catalogues of sources. The process is then repeated on maps which have a population of artificial point sources of varying flux densities injected directly into the maps. The performance of the algorithms are evaluated based on the positions and extracted flux densities of the artificial sources whose real flux density and positions are precisely known. Based on the properties of the extracted artificial sources, signal-to-noise ratio (SNR) cuts are defined such that the properties of the extracted artificial sources are robust both in terms of position and flux density. The same signal-to-noise cut is then applied to the real catalogue of sources generated from the intensity maps to obtain a high reliability catalogues. Secondary quality assessment cuts are applied to the catalogue to eliminate sources associated with known artefacts in the maps. Additional properties of the reliable sources such as the dates they were observed, their presence in CMB subtracted maps, their flux density estimated from point source fitting, and the potential contribution of Galactic cirrus emission are evaluated in the final stages of the pipeline.

We note that the maps used for the ERCSC are affected by uncorrected pointing errors of at least two types. The first is due to time-dependent, thermally-driven misalignment between the star tracker and the boresight of the telescope (Planck Collaboration 2011a). The second is due to uncorrected stellar aberration across the focal plane. Since 70% of the sky is observed at least twice with different orientations, the effect of stellar aberration for the majority of sources is negligible. However, for the remaining 30% of the sky, the effect would result in an offset ranging from 21″ near the ecliptic poles to a value close to 0″ in the ecliptic plane. We do not see this effect clearly in the centroids of sources in the ERCSC, likely because the intrinsic uncertainty in the positions is comparable to the maximum offset induced by these pointing errors. Furthermore, since these pointing errors are not factored into the injection of the artificial sources into the maps, the positional uncertainty from the Monte-Carlo analysis is an underestimate. The effect on the flux density of the catalogue sources is negligibly small, ≲ 2%. Both types of pointing error will be corrected in the maps used for future Planck catalogues.

2.1. Source detection algorithms

Four specific implementations of source detection algorithms were run as part of the ERCSC pipeline. These are the Paris matched filter (PMF; Melin et al. 2006), IFCA Mexican hat wavelet filter (IFCAMex; López-Caniego et al. 2007), PowellSnakes (PwS; Carvalho et al. in prep.; Carvalho et al. 2009) and SExtractor (Bertin & Arnouts 1996). Some of the algorithms are still in development and the results depended on version of algorithms used and their implementation methodology in the ERCSC pipeline. Of these, only two were selected to generate the final catalogues. The two algorithms were selected to provide the largest numbers of high reliability sources at high Galactic latitude in the Planck maps. These are PwS v2.0 for frequencies 30–143GHz, and SExtractor for frequencies 217–857GHz.

2.1.1. PowellSnakes

PowellSnakes is a fast Bayesian method for the detection of discrete objects immersed in a diffuse background. The application of Bayesian model selection and the Bayesian information criterion to source detection and extraction have been reviewed by Hobson & McLachlan (2003) and Savage & Oliver (2007). PwS builds on these ideas and incorporates them in a fast implementation.

The all-sky map is resampled onto a set of overlapping flat patches using a gnomonic (tangent plane) projection. Each patch is modelled as a set of discrete objects, of known shape, embedded in a stochastic background, with added instrumental noise. The object shape is chosen to be a circular Gaussian approximation to the effective point spread function (PSF), and the background and instrumental noise are modelled as a Gaussian random field with power spectrum to be estimated from the data. Because both the PSF and background vary with sky position, the analysis is performed on overlapping sky patches within which the properties are assumed to be uniform. At high latitudes and low frequencies the background is dominated by the CMB, so the Gaussian assumption is a good one; near the Galactic plane, however, the background is dominated by emission from the ISM and the assumption breaks down. In practice, however, PwS gives good results in these cases. At the highest frequencies SExtractor was found to perform better than PwS, probably because the model of the background statistics is poor, and also because many of the sources are diffuse peaks in the ISM emission and are not well represented by the PSF model.

Given these assumptions, PwS estimates source parameters by maximising the posterior probability (i.e., the product of the likelihood and an assumed prior), using a simultaneous multiple maximisation code based on Powell’s direction set algorithm (hence the name) to rapidly locate local maxima in the posterior. This novel feature makes PwS substantially faster than Monte-Carlo Markov chain methods used by Hobson & McLachlan (2003). Whether or not a posterior peak corresponds to a source is determined by Bayesian model selection using an approximate evidence value based on a local Gaussian approximation to the peak. In this step, PwS minimises the average loss matrix rather than maximising either reliability or completeness: that is, it treats spurious detections and missing detections as equally undesirable.

For detection of sources with high signal-to-noise ratio, PwS is fairly insensitive to the choice of priors. For the version of the algorithm which was used for ERCSC, a flat distribution of priors was adopted with the distribution of priors on the intrinsic source radius being uniform between 0 and for all frequencies. Since this is smaller than Planck’s spatial resolution at any frequency, the effect of the priors is to favour point sources.

After merging the results from each patch, the output of PwS is a set of source positions with estimated flux densities. The ERCSC pipeline photometry algorithms are then applied at each position to obtain other measures of flux density and size, taking into account the instrumental noise in each pixel.

Table 2

ERCSC catalogue columns.

2.1.2. SExtractor

SExtractor (Bertin & Arnouts 1996), as for PwS, requires local flat patches created from gnomonic projections. Each map is pre-filtered with a Gaussian kernel the same size as the beam at each frequency (the built-in filtering step within SExtractor is not used as it uses a digitised filtering grid). Typically, a Mexican hat filter gives slightly more reliable detections of point sources in the presence of noise and background, although bright extended sources are often missed. However, a Gaussian filter is adopted because simulations show that it performed almost as well as the Mexican hat for high-latitude compact sources and is still sensitive to sources that are extended. The algorithm then finds objects by isolating connected groups of pixels above a certain n-sigma threshold. Sources which are extremely close to each other are deblended if a saddle point is found in the intensity distribution. Spurious detections due to neighbouring bright objects are cleaned, and finally the algorithm determines the centroids of each source and performs photometry in an elliptical Kron aperture (Bertin & Arnouts 1996; Kron 1980).

The performance of SExtractor’s own adaptive aperture photometry (MAG_AUTO) is good at high latitudes for all Planck frequencies, providing flux densities to within 10% accuracy, and errors typically 1–5%. Nevertheless, at low Galactic latitudes, particularly at the highest frequencies, the photometric accuracy is significantly degraded. This is because it uses a variable Kron radius, which becomes unstable in crowded fields with strong residual background fluctuations. To ensure homogeneous flux density estimates, the primary flux density estimate is obtained from an external source extraction code, as was done for PwS.

2.1.3. Flux density estimation

Each source that is extracted has four different measures of flux density associated with it. These are based on aperture photometry, PSF fitting, Gaussian fitting and a measure native to the source detection algorithm (Table 2). Each of these flux density estimates has a local background subtracted but they have not been colour corrected. Colour corrections are available in Planck Collaboration (2011v).

  • 1.

    The FLUX and FLUX_ERR columns in the ERCSC FITS filesgive the flux densities measured in a circular aperture of radiusgiven by the nominal sky-averaged FWHM. Appropriatecorrections have been applied for the flux density outside theaperture, assuming that the source profile is a point source.

  • 2.

    The PSFFLUX and PSFFLUX_ERR columns give flux densities estimated by fitting the source with the Planck point spread function at the location of the source (Mitra et al. 2011). The Planck point spread function is estimated at each point on the sky by combining the individual horn beams with the scan strategy, where the individual beams are derived from when the scans cross planet positions. A 2D Gaussian is fit to the PSF and the derived parameters of the Gaussian are used to perform a constrained Gaussian fit to the source.

  • 3.

    The GAUFLUX and GAUFLUX_ERR columns give flux densities estimated by fitting the source with an elliptical Gaussian model whose parameters are free.

  • 4.

    The FLUXDET and FLUXDET_ERR columns gives the flux densities estimated by the native detection algorithm. For the frequencies at which PwS is used, this is estimated by utilising the mean of the posterior distribution of all parameters, while for frequencies at which SExtractor is used, it is the flux density in an elliptical Kron aperture, i.e., FLUX_AUTO. The FLUXDET values at the frequencies where PwS is used have been corrected for an average bias that was seen in the difference between the extracted and input flux density of Monte-Carlo sources that were injected into the maps. This is most likely due to an inaccurate representation of the true beam inside the PwS detection algorithm. For faint extended sources in the upper HFI frequencies, the SExtractor FLUXDET values might be useful.

Once the initial pass of the algorithm generates the list of all sources in the map, the next step is to identify the ones which are highly reliable, i.e., those that have accurate positions as well as flux density uncertainties which are less than 30%2. In the absence of a “truth” catalogue for the sky, it is not possible to definitively identify reliable sources. The significant frequency difference between AKARI, IRAS and Planck at submillimetre frequencies implies that uncertain extrapolations of the thermal dust spectral energy distribution (SED) need to be made to force associations between far-infrared sources and Planck sources. At radio frequencies, deeper surveys such as those with the Green Bank Telescope, Parkes and ATCA have been undertaken (e.g. Gregory et al. 1996; Griffith et al. 1995). However, the flat-spectrum radio sources that dominate the source population vary significantly even on short time scales. In addition, the high source density of those surveys requires assumptions about the thermal and non-thermal spectral indices in order to identify possible associations between the Planck sources and the radio sources. Although these ancillary external catalogues are used for cross-validation of the final ERCSC, the primary measure of reliability for the sources uses a Monte-Carlo quality assessment (MCQA) analysis that is described in the next section. This is the first application of a Monte-Carlo source characterisation algorithm at these frequencies, although the practise is fairly commonplace at higher frequencies (Chary et al. 2004,and references therein). The process is described below.

2.2. Primary reliability selection: Monte-Carlo analysis

Quality assessment (QA) is an integral step in the validation of a catalogue. It helps quantify flux-density biases and flux-density uncertainties, positional errors, completeness and reliability in a catalogue. QA metrics based on external (“truth”) catalogues suffer at the brightest flux densities since source numbers are sparse and resultant QA metrics are dominated by Poisson noise. In addition, generating such a truth catalogue for the sky from past observational priors, requires uncertain assumptions about the behaviour of sources across a wide range of frequencies. As a result, the Monte-Carlo QA approach is adopted as the primary criterion for selecting high reliability sources.

The goals of the Monte-Carlo QA system are:

  • 1.

    to quantify flux-density biases and flux-density uncertaintiesas a function of background;

  • 2.

    to quantify completeness in extracted sources as a function of flux density;

  • 3.

    to quantify contamination or “spurious sources” as a function of flux density;

  • 4.

    to assess positional offsets between extracted and input sources;

  • 5.

    to assess systematic uncertainties associated with beam shape, gaps in coverage, scan strategy, etc.

The first step of the MC QA analysis is to run the ERCSC pipeline on the input maps to generate a source catalogue for the true sky. Unresolved point sources, convolved with a circularly symmetric Gaussian with full-width at half maximum identical to that of the derived effective beam, are injected into the maps at random positions and with random flux densities (Sν) and re-run the main ERCSC pipeline. The typical run parameters are 1000 sources per iteration, uniformly distributed across the sky. In order to minimise Poisson variation in our estimates of QA parameters, while keeping confusion low, we execute 10 iterations. The present set of runs uses a flat dN/dlog S distribution at all flux densities ranging from 100 mJy to 100 Jy. We have previously tested Monte-Carlo runs where the injected sources follow a flux-density distribution that is similar to the Planck sky model. No significant differences due to the choice of flux density distribution have been found, particularly because source extraction in the Planck maps are not significantly affected by source confusion.

We note that to precisely assess the performance of the pipeline, including systematic effects associated with the generation of the all-sky maps, the artificial sources should be injected into the time-ordered data stream and processed through each each of the data-processing steps outlined in Zacchei et al. (2011); Planck HFI Core Team (2011b). This however, is prohibitively expensive in terms of computational resources and cannot be accomplished at the present time given the rapid turnaround required for the ERCSC.

At the end of the Monte-Carlo runs, we have one catalogue which only comprises the sources detected in the original map and 10 catalogues which have the original sources in addition to the detected fraction of the fake sources that were injected into the maps. We first match the sources in the original map to each of the remaining 10 catalogues with a matching threshold of twice the FWHM. This leaves only the artificial and spurious sources in the catalogues, whose properties can then be compared to the known flux densities and positions of the injected sources.

Reliability specifies the fraction of extracted sources that differ from their input flux densities to within 30%. This is based on the flux density accuracy requirement for the ERCSC. Imposing the requirement implies that the catalogue is equivalent to a catalogue with a >5σ cut if the noise were Gaussian. That is, a typical 5σ source would have a flux density error that is smaller than 20%, 68% of the time, which translates to a flux density error of <30% for 90% of the sources, for a Gaussian distribution of errors. It is well known that the contribution from the Galaxy and the CMB results in a non-Gaussian distribution for the background RMS, at least on large spatial scales. Future work will attempt to build upon our increased knowledge of the foregrounds from the Planck maps and undertake a more precise characterization of the noise.

thumbnail Fig.2

Plots showing the results of the Monte-Carlo analysis at 30GHz with the PwS algorithm. The upper two rows shows the results when the flux density of sources is from FLUXDET while the lower two rows shows the results when the flux density of sources is from FLUX. The set of 3 plots in the top-left and bottom-left corner show the all-sky flux-density uncertainty, differential reliability and differential completeness of the Monte-Carlo sources as a function of SNR where signal may be FLUX or FLUXDET and the noise is the background RMS. The set of four plots at the top right and bottom right show (left to right, top to bottom) the fractional flux density uncertainty, (Sin − Sout)/Sin (see Sect. 5.1), the distribution of the absolute positional offset, differential positional offset, as well as completeness and contamination (1-reliability converted to a percentage) as a function of flux density for the half of the sky with the lowest sky background RMS. The range of sky background RMS converted to a point source flux density uncertainty, is shown in the inset in mJy. The primary source selections in the catalogues are based on the reliability vs output flux density/background RMS plots such that the cumulative reliability (integral of the differential reliability) is greater than 90%.

Open with DEXTER

The reliability is measured as a function of root-mean-square (RMS) signal-to-background where the signal is a measure of the flux density of the source and therefore either FLUX or FLUXDET. The background RMS is derived from the RMS measured in a 2° radius annulus on the maps after individual detected sources are masked. The choice of 2° was made empirically. It was found that if the outer radius were too small, i.e., tens of minutes of arc, the RMS was similar to the RMS returned by the detection algorithms which detect sources as peaks above the local RMS. These RMS returned by the codes are typically lower than the RMS measured in the larger annulus used here. If the outer radius were too large (several degrees), background structure gets smoothed out. A radius of 2° represents a trade-off between these two extremes and yields a background RMS which is a combination of substructure in the background and the instrumental noise in the maps. The RMS is converted to a 1σ background RMS for a point source, by integrating over the Planck beam.

Figure 2 shows the flux-density accuracy, the positional accuracy and the differential reliability as a function of SNR at 30GHz based on the artificially injected Monte-Carlo sources. The differential reliability is simply the reliability in each bin of SNR while the cumulative reliability is the integral of the differential reliability above a particular SNR value. Also shown in Fig. 2 is the flux density accuracy, positional uncertainty, completeness and reliability as a function of flux density for the half of the sky with the lowest sky background RMS. Due to the differences between how FLUX and FLUXDET are estimated, the top panels and lower panels are not the same. First, FLUXDET flux densities have a larger scatter at almost all SNR ratios compared to FLUX. This is partly due to the prior assumptions on the source profile that are made in the estimation of FLUXDET. Deviations from this assumed source profile result in errors in the derived flux density.

Second, the FLUXDET reliabilities appear to be higher at low SNR compared to the FLUX based reliability values. At low values, the aperture flux-density based FLUX estimates tend to become increasingly affected by sky noise and even the background estimation becomes more uncertain. FLUXDET values are derived assuming a fixed source shape and a flat background. As a result, for point sources, the scatter in FLUXDET values at low SNR is smaller. When the error in the flux density estimate exceeds 30%, the reliability decreases. We note that the uncertainty on the reliability estimate is dominated by the Poisson statistics of the number of sources in the corresponding SNR bins. That is, if the completeness in a particular SNR bin is low, the uncertainty on the reliability is high. The typical uncertainty on the reliability estimate in a particular SNR bin is about 5%.

Also shown in Fig. 2 is the histogram of separations between the injected and extracted positions. The 1σ positional offset is approximately 230arcsec in low background regions, which is almost FWHM/10 at 30GHz.

The completeness plots for the Monte-Carlo point sources are shown for illustrative purposes for the half of the sky with the lowest background RMS. Without factoring in the source size distribution and flux density distribution of the real source populations, as well as the fraction of sky observed with a particular amount of exposure time, the completeness plot cannot be used to directly infer the actual completeness of the ERCSC.

Figures 3 and 4 show similar plots for the Monte-Carlo sources at 143 and 857GHz. Interesting trends can be observed by comparing these plots. The obvious one is an improvement in positional accuracy with increasing frequency due to the spatial resolution of Planck improving with increasing frequency. Another interesting trend is the evolution in the range of background RMS values for the cleanest half of the sky, which is provided in mJy in the numbers following “RMS:”. The numbers indicate that the background RMS is the largest at 857GHz due to the enhanced contribution of ISM emission.

The SNR values of the real sources are then estimated from the ratio of FLUX/Background RMS or FLUXDET/Background RMS. The reliability of the Monte-Carlo sources shown in these Figures is applied to the real sources using the SNR value as the comparison metric. These reliability values are between 0 and 1 although the minimum over all frequencies after the cumulative reliability cuts are applied is 0.74. If an arbitrary source has a reliability of 0.74, it implies that 74% of the time, a source lying in a patch of sky with similar sky noise will have an estimated flux density that is accurate to within 30%.

thumbnail Fig.3

As in Fig. 2 but at 143GHz with the PwS algorithm.

Open with DEXTER

Once the differential reliability of each source in the original map has been estimated, the sources are sorted in decreasing order of SNR. The differential reliability is converted to a cumulative reliability by integrating the differential reliability over increasing SNR values. We imposed a cumulative reliability threshold of 90% and a maximum standard deviation in the reliability of 10% for the ERCSC. This is the primary criterion used to select high reliability sources. The reliability cut is applied to both the FLUX/Background RMS as well as the FLUXDET/Background RMS, since these are two distinct measures of flux density and the resultant catalogue is the union of the two reliability cuts. The union is selected to maximise source counts since different measures of flux density tend to be more accurate in different regimes as described in Sect. 5.1.

The technique that is chosen at each frequency is the one that returns the maximum number of |b| > 30° sources above a cumulative reliability of 90%. These happen to be our particular implementation of PwS between 30 and 143GHz and SExtractor between 217 and 857GHz.

thumbnail Fig.4

As in Fig. 2 but at 857GHz with the SExtractor algorithm.

Open with DEXTER

2.3. Secondary cuts in selection of sources

The primary selection criteria described above have been augmented by a set of secondary cuts which take into account known source artefacts in the maps.

First, the transit of bright sources (especially planets) across the beam results in a pattern of bright and dark patches that is repeated every 36arcmin along the scan pattern, in the upper HFI bands (Planck HFI Core Team 2011b). These are due to the imprecise removal of an instrumental artefact (the 4 K cooler spectral line). A subset of these patterns have been visually identified in the maps and masks have been generated for those patches of sky. These masks are reflected in the incomplete sky coverage in Table 3. If more than 5% of the pixels within one FWHM from the source fall on the mask, the source is rejected.

Second, there are known gaps in the maps associated with the masking of planets and asteroids3. If sources have any of their pixels within one FWHM falling on such a gap, the source is rejected. This prevents edge effects due to the side lobes of bright planets from being classified as sources and also prevents the introduction of large errors in the photometry of sources.

Third, sources are also required to have either an aperture-photometry SNR ≥ 5 () or a detection method photometry SNR ≥ 5 (). The distinction is important, due to the fact that the photometry from the PowellSnakes implementation consistently underestimates the flux density for even marginally extended sources at the lower frequencies.

Fourth, due to the requirements on the flux-density accuracy in the ERCSC, the standard deviation in the photometric error for the artificial sources with the same SNR as the real source is required to be less than 30%.

thumbnail Fig.5

The Planck ERCSC flux density limit quantified as the faintest ERCSC source at |b| < 10° (dashed black line) and at |b| > 30° (solid black line) is shown relative to other wide area surveys. Also shown are the spectra of known sources of foreground emission as red lines; these include a Sν ~ ν-0.7 synchrotron component, ν-0.1 free-free component, a Rayleigh-Jeans component and a ν2 emissivity blackbody of temperature 18K. The ERCSC sensitivity is worse in the Galactic plane due to the strong contribution of ISM emission especially at submillimetre wavelengths. In the radio regime, the effect is smaller. The faintest WMAP 7 year 5σ sources are derived from the catalogue of Gold et al. (2011); Wright et al. (2009). Although the flux density limits of WMAP and Planck appear to be comparable at the lowest frequencies, the Planck ERCSC is more complete as discussed in Sect. 4. The GB6 sensitivity value is from Gregory et al. (1996), AT20G flux limit from Murphy et al. (2010), SCUBA-2 All Sky Survey (SASSy) limit from the Joint Astronomy Center website while the IRAS flux density limits are from the IRAS explanatory supplement (Beichman et al. 1988).

Open with DEXTER

Fifth, in order to remove extended sources associated with substructure in the Galactic ISM, we eliminate non-circular sources (ELONGATION ≤ 3) in the upper HFI bands. These are sources whose ratio of major to minor axis is greater than three.

As a sixth criterion, we also insist that the aperture flux density is positive (APERFLUX ≥ 0), which alleviates problems due to sources whose sky background estimate is biased high by the presence of bright sources in the sky annulus. These sources will have uncertain photometry and are therefore rejected.

The final ERCSC compilation is the list of sources which have satisfied the primary Monte-Carlo based reliability criterion as well as all the aforementioned secondary QA criteria. These cuts imply that about half the sources in the uncut lower frequency catalogues and about a third of the sources in the upper frequency catalogues are classified as high reliability sources.

As mentioned earlier, each source has four different measures of flux density associated with it. These flux density values have not been colour corrected. Users should identify appropriate colour corrections from Planck Collaboration (2011v) and apply them to the flux densities. The absolute calibration uncertainty of the HFI and LFI instruments is better than 7% at all frequencies (Zacchei et al. 2011; Planck HFI Core Team 2011b). However, the requirements on the ERCSC are a photometric accuracy of 30%.

3. Characteristics of the ERCSC

3.1. Sky coverage and sensitivity

Table 3 shows the fraction of sky coverage, the beam FWHM and the sensitivity of the ERCSC after all cuts have been applied. Although the 10σ values are quoted, sources which are up to a factor of ~2 fainter and located in regions of low sky background are included in the ERCSC since they meet the high reliability criterion described in the previous section. As an illustration, Fig. 5 shows the flux density limit of Planck both in the Galactic plane (|b| < 10°) and at high Galactic latitude (|b| > 30°) relative to other wide area surveys at comparable frequencies. Also shown are the spectrum of typical sources of foreground emission. Figures 6 show the all sky distribution of sources colour coded by flux density.

thumbnail Fig.6

Sky distribution of sources in Galactic coordinates at all nine Planck frequencies. Sources are colour coded by flux density. In the Galactic plane, due to strong emission from the ISM, there is a paucity of faint sources. The higher density of sources in the LMC region is also noticeable.

Open with DEXTER

thumbnail Fig.7

The distribution of spectral indices (α where Sν ∝ να) for sources within 10° of the Galactic plane. Each panel shows the spectral index distribution for ERCSC sources at the corresponding Planck band.

Open with DEXTER

Table 3

Planck ERCSC characteristics.

3.2. Statistical nature of sources

In this section, we characterise the sources detected by Planck at each frequency. A source, called source one, at frequency one is associated with a source, called source two, at frequency two, if it lies within , if source two is the closest source at frequency two to source one, and vice versa. The results are summarised in Table 4. Naturally, at the lowest frequency, 30GHz, it is impossible to find associations at a lower frequency and hence columns B & C are blank. Similarly, at the highest frequency, 857GHz, it is impossible to find associations at a higher frequency and hence columns B & D are blank.

We find that at 30GHz, where the radio spectrum might have a significant optically thin synchrotron emission component (which implies decreasing flux density with increasing frequency), the number of sources seen in the adjacent passband is 54%. Similarly, at the highest frequency where the thermal dust emission has a steep spectrum of the form Sν ~ ν3 + β, the fraction of 857GHz sources seen at 545GHz is predictably low due to the relative sensitivities of the two bands. However, at the intermediate frequencies, the fraction of sources which are associated with sources in the adjacent bandpasses is high. Although the fraction of associations is not 100%, we can use the spectral information from these associations to characterise the nature of sources at each frequency.

thumbnail Fig.8

The distribution of spectral indices for sources above 30° of the Galactic plane, likely to be dominated by extragalactic sources.

Open with DEXTER

Table 4

ERCSC source characterisation.

The spectral index is calculated by fitting a single power law (Sν ∝ να) to the flux density of sources in adjacent bands. For 30GHz sources, only the 30 and 44GHz flux densities of sources are considered. Similarly, at 857GHz, only the 545 and 857GHz flux densities of sources are fit. For all the intermediate bands, the frequencies just below and just above are included in the fit, if the source is detected in the ERCSC.

Figure 7 shows the distribution of spectral indices for the sources within |b| < 10° which are likely to be sources within our Galaxy. At low frequencies, the median SED of sources in the Galactic plane is an Sν ∝ ν-0.5 spectrum. The distribution of α values significantly broaden between 30 and 100GHz, likely due to varying amounts of free-free emission along different sightlines. At 100GHz, the spectrum becomes noticeably flatter with a median α =  − 0.25, partly due to the increasing contribution of thermal dust emission and partly due to the large contribution from the CO line to the 100GHz flux density. At 143GHz, the spectral index distribution shows the presence of both radio sources as well as the dominant contribution from sources with thermal dust emission. Expectedly, at higher frequencies, the distribution of spectral indices is narrow and is centred between α = 2 and α = 3, tracing the Rayleigh-Jeans component of dust emission. The reason the median α is almost 3 at 217 GHz but evolves to 2 at 857 GHz is a selection effect. As can be seen in Fig. 5, thermal dust emission with emissivity >0 would increase faster with increasing frequency compared to a Rayleigh-Jeans spectrum, relative to the Planck sensitivity. As a result, sources at the intermediate frequencies can span a broader range of spectral indices than a faint source at 857 GHz which would have an estimated spectral index only if it were detected at 545 GHz, and thereby preferentially have a spectrum that is less steep.

Figure 8 shows the distribution of spectral indices for the sources at |b| > 30° which are likely to be extragalactic. At the lower frequencies, the distribution of spectral indices is centred at α = 0. However, unlike the Galactic sources where the distribution broadens with increasing frequency, among the extragalactic sources, the spectral index distribution narrows between 30 − 100GHz. There are two possible origins for this. One is that the CO contribution is generally negligible for the extragalactic sources and that the larger distribution of spectral indices around 100 GHz for the Galactic sources is simply a tracer of variation of the CO contribution to the broadband photometry. A second possibility is that the spectral index distribution of Galactic sources is intrinsically broader while the extragalactic sources at 100 GHz are dominated by a power-law distribution of electrons produced in relativistic shocks, which tend to display a more uniform power-law index. At 143 and 217GHz, the radio source population continues to dominate although the dusty sources start to become significant. This is in contrast to the Galactic population where the infrared luminous sources are the dominant contributor. It is also striking that even at 353GHz, the radio source population continues to make a significant contribution. At the highest frequencies, both the Galactic and extragalactic source populations show similar behaviour expected from the Rayleigh-Jeans tail of dust emission.

A comparison with the statistical properties of sources found in the South Pole Telescope 1.4 mm and 2 mm surveys (Vieira et al. 2010) is warranted. The SPT surveys found that ~30% of the 1.4 mm sources are dusty while the majority are synchrotron dominated. This is similar to the results for the high Galactic latitude ERCSC sources; ~25% of the ERCSC 217 GHz sources show an SED consistent with thermal dust emission. The difference however is that the dusty sources observed by the SPT dominate at fainter flux densities (<15 mJy). In contrast, the dusty population in the ERCSC appears to be at brighter flux densities with a median FLUX of 2.4Jy, while the synchrotron sources have a median FLUX of 0.8Jy. This difference is because the ERCSC 217 GHz dusty sources are associated with the Large Magellanic Cloud and are thereby brighter than the typical dusty sources that the SPT has observed.

3.3. Individual case studies

The SED of representative sources of different classes that can be found in the ERCSC are presented in this sub-section. The selected sources are a pre-stellar core L1544 (Ward-Thompson et al. 2002), an extragalactic radio source Centaurus A, a synchrotron dominated radio galaxy Pictor A, IRC+10216 which is the prototype of stars with dust shells, the starbursting ultraluminous infrared galaxy Arp 220 and the cold stellar core ECC G176.52-09.80. The sensitivity and wavelength coverage of Planck enables synchrotron emission, thermal bremsstrahlung emission, thermal dust emission as well as the transition frequencies between the emission processes to be studied. Figure 9 shows the SED of these representative sources.

Since some of these sources are extended at the Planck angular resolution, the ERCSC Gaussian fit flux densities (i.e. “GAUFLUX”) are shown, except in the cases where the fit failed in the low signal-to-noise regime. In those cases the aperture photometry values (i.e. “FLUX” in the ERCSC) are plotted. Uncertainties include the Monte-Carlo estimate of flux density uncertainties. The plotted SED also show IRAS and/or ISO flux densities at far-infrared wavelengths. Planck can clearly reveal the contribution of cold dust at wavelengths longward of IRAS/ISO and observe the transition from thermal dust emission to synchrotron/free-free radio emission.

4. Validation of the ERCSC

At the three lowest frequencies of Planck, it is possible to validate ERCSC source identifications, reliability, positional accuracy and flux density accuracy using external data sets, particularly large-area radio surveys. This external validation was undertaken using the following catalogues and surveys: (1) full sky surveys and catalogues: WMAP 5-year catalogue (Wright et al. 2009) and the NEWPS catalogue, based on earlier WMAP results (Massardi et al. 2009); (2) in the southern hemisphere the AT20G survey at 20GHz (Murphy et al. 2010); (3) in the northern hemisphere, where no large-area, high-frequency survey like AT20G is available, we used CRATES (Healey et al. 2007).

thumbnail Fig.9

The SED of representative source classes in the ERCSC. The plot shows a pre-stellar core L1544, an extragalactic radio source Centaurus A, a synchrotron dominated radio galaxy Pictor A, IRC+10216 which is the prototype of stars with dust shells, the starbursting ultraluminous infrared galaxy Arp 220 and the cold stellar core ECC G176.52-09.80. IRAS or ISO flux densities are shown as solid squares while the Planck flux densities are shown as stars. The Planck ERCSC enables a diverse class of sources to be studied over a broad range of frequencies and flux densities.

Open with DEXTER

An ERCSC source was considered reliably identified if it falls within a circle of radius one half the Planck beam FWHM which is centered on a source at the corresponding frequency in one of the above catalogs. This means of identification was employed at |b| > 5° where confusion was less of a problem and the majority of the sources were extragalactic. Very few such sources were spatially resolved by Planck. Table 5 shows the percentage of sources thus identified. For the three lowest Planck frequencies and for |b| > 5°, the ERCSC clearly meets its 90% reliability specification as measured by this external validation. Table 5 also displays results of an attempt to assess reliability of ERCSC sources in the Galactic plane at |b| < 5°. Here, an ERCSC source was considered reliably identified if it falls within 5arcmin from Galactic objects like planetary nebulae, supernova remnants, HII regions (or in a few cases, extragalactic sources that happen to be found at low Galactic latitude). The percentage of identifications in the Galactic plane is lower, but still leaves the overall reliability figures at greater than 90%, meeting the ERCSC specification for reliability.

Table 5

ERCSC source validation.

We also examine the positional accuracy of ERCSC sources by comparing positions taken from the ERCSC with those determined quasi-simultaneously using the Very Large Array (VLA) of the US National Radio Astronomy Observatory. ERCSC positions were also compared to the positions of several hundred bright quasars (Fig. 10) at frequencies of 353GHz and below where a significant fraction are detected. The median scatter in offset for frequencies 30–217GHz was 2.0, 1.7, 1.1, 0.8, 0.7, 0.3 and 0.35arcmin. The results of these two tests are consistent, and suggest that the ERCSC clearly meets its specification of RMS scatter in positions being less than FWHM/5.

A comparison between the ERCSC flux densities with VLA measurements of the same source has also been made (Fig. 11) and is discussed in Planck Collaboration (2011j). At both 30 and 44GHz the two flux density scales appear to be in good overall agreement with any difference attributable partly to noise in the Planck measurements and partly due to variability in the radio sources, since the Planck and VLA measurements were not exactly simultaneous. At 70GHz however, the comparison is challenging since the VLA measurements are made at 43GHz and an extrapolation needs to be made assuming some spectral index for the source. If a simple extrapolation to a 70GHz flux density is made based on the VLA 22–43GHz spectral index, the extrapolated VLA values are either too high or the flux density scale of Planck is too low. The most likely interpretation of this discrepancy is that the spectral index of radio sources detected by Planck steepens at frequencies above 44 or 70GHz. If, for instance, a spectral index change of α =  − 0.5 is allowed at frequencies above 43GHz, the agreement between the extrapolated and measured 70GHz fluxes would be entirely acceptable (Planck Collaboration 2011j).

A comparison between the ERCSC sources and the WMAP point source catalogue was also undertaken. The WMAP seven-year catalogue (Gold et al. 2011) contains a total of 471 sources in the five WMAP bands. We have compared the WMAP 5σ sources at 33, 41, 61, 94 GHz with the sources in the ERCSC at 30, 44, 70 and 100 GHz, respectively. A search radius corresponding to the FWHM of the WMAP beam at each frequency (0.66°, 0.51°, 0.35°, 0.22° at 33 to 94 GHz channels) is used to find a match of WMAP sources in the ERCSC. Figure 12 shows the histogram distribution of WMAP flux densities; the WMAP 5σ sources are shown in gray, and the ones with an ERCSC match are in red. The ERCSC include 88%, 62%, 81% and 95% of the WMAP 5σ sources at the four bands, individually. Figure 13 is a similar plot, but shows the histogram distribution of the ERCSC flux densities: the ERCSC sources are shown in gray, and the ones with a WMAP match are in red. The WMAP seven-year point source catalogue mask which excludes the Galactic plane and the LMC/SMC region has been applied to the ERCSC beforehand to ensure the same sky coverage. It is evident that the ERCSC is a much deeper and more complete catalogue than the WMAP 7 year catalog, especially at the 100 GHz channel.

The WMAP 5σ detections that are missed in the ERCSC at 30, 70 and 100 GHz are further investigated. The 44 GHz channel is skipped since it is known to have lower sensitivity compared to the WMAP 7-year data. It is found that at 100 GHz, all the missed WMAP sources can be explained by either the WMAP source not having a 5 GHz counterpart or only being weakly associated with a 5 GHz source suggesting that the WMAP source might be spurious. At 70 GHz, ~41% of the unmatched sources are variable (this is a lower limit as the variability info was obtained from the WMAP five-year catalog, which is a subset of the WMAP seven-year catalog), ~13% of the unmatched sources have no 5 GHz ID or are only loosely associated with a 5 GHz source, ~38% are recovered after the CMB subtraction. At 30 GHz, ~17% of the unmatched sources are variable (again, this is only a lower limit), ~34% of the unmatched sources have no solid identification, ~54% are recovered after the CMB subtraction. This analysis suggests that the reason these sources are not detected in Planck is a combination of source variability, map sensitivity (different scanning strategy of WMAP and Planck result in a difference in the local background noise; also the ERCSC is based on 1.6 sky surveys whereas the WMAP catalogue is based on 14 sky surveys), and incompleteness of the ERCSC.

thumbnail Fig.10

Matches to quasars as a measure of positional offsets in the ERCSC 30 to 353GHz catalogues. The top row shows 30 and 44, the second row 70 and 100, the third row 143 and 217, and the final row 353GHz. There are insufficient numbers of detected quasars at the upper HFI frequencies.

Open with DEXTER

The similarity between the WMAP frequencies and Planck bands also motivates a comparison between their flux densities which is shown in Fig. 14. Overall we find there is no systematic difference between the WMAP and ERCSC flux densities at the corresponding bands. The significant scatter in Fig. 14 again indicates that variability is an issue. There is no variability analysis of the WMAP seven-year point sources, but an analysis of the variability on the five-year WMAP point sources mentioned above, shows that a high fraction of the sources are variable at greater than 99% confidence, and these are in general the brighter sources (Wright et al. 2009).

thumbnail Fig.11

The flux density of a subset of ERCSC sources at 30 and 44 GHz, with color corrections, compared to the flux density obtained from VLA 22 and 43 GHz observations of the same sources translated to the Planck effective frequency (Planck Collaboration 2011j). The over-plotted lines are the first order polynomial resulting from an uncertainty weighted fit to the VLA and ERCSC flux densities which partially takes into account Eddington bias. The slope of the fit is 1.08 at 30 GHz and 1.02 at 44 GHz indicating that both measurements are in good agreement. The median ratio of the ERCSC flux density to the VLA flux density is 1.15 at both frequencies. The difference is most likely attributable to a combination of effects including cross-calibration uncertainties, contribution from fainter sources within the Planck beam, variability and the fact that the smaller beam VLA measurements would be less sensitive to low surface brightness emission beyond the 2−4″ primary VLA beam although care has been taken to use mainly unresolved sources.

Open with DEXTER

thumbnail Fig.12

Histogram distribution of WMAP flux densities for all WMAP 5σ sources in each band (gray region). The sources that are detected in the ERCSC are shown as the red histogram. Some of the WMAP sources have been missed because of source variability.

Open with DEXTER

thumbnail Fig.13

Histogram distribution of ERCSC flux densities at each band in gray. ERCSC sources that are matched with WMAP 5σ sources in a similar band are shown as the red histogram. The WMAP 7 year point source catalogue mask (see text) has been applied to the ERCSC to ensure the same sky coverage.

Open with DEXTER

thumbnail Fig.14

Fractional difference between the ERCSC flux densities and WMAP flux densities at 30, 44, 70 and 100 GHz. The unit of the abcissa is Jy while the ordinate shows the fractional difference. No correction has been applied to the WMAP flux densities to account for the difference in bandpass compared to Planck. The agreement is good but the significant scatter that can be seen is most likely due to source variability.

Open with DEXTER

5. The ERCSC: access, contents and usage

The ERCSC is available from both the ESA Planck Legacy Archive4 and the NASA Infrared Science Archive5 (IRSA).

The source lists contain 35 columns per source at the LFI bands and 36 columns at the HFI bands. The 857GHz source list has six additional columns which consist of the band-filled flux densities and flux uncertainties at the three adjacent lower frequencies, 217, 353 and 545GHz for each source detected at 857GHz. The locations of sources are provided in Galactic coordinates. In addition, we also provide for each detected source, a postage-stamp cutout of the source from the all sky map of the corresponding frequency after the CMB has been subtracted. The size of the cutout is a square of side 4 × FWHM at the corresponding frequency. The primary purpose of these cutouts is to aid in the visual validation of sources. We also provide notes in a text file, one per frequency, for particular sources in the catalogues which state associations of the ERCSC source with sources in ancillary catalogues (e.g. IRAS, GB6, WMAP) as well as potential variability information.

Including the ECC and ESZ, the entire data release thus consists of 11 source list files, 11 all-sky source distribution maps, 11 notes files and postage-stamp cutouts in JPEG format of all the sources detected at the nine individual frequencies as well as in the ECC list. No postage stamp cutouts are provided for the ESZ.

5.1. Catalogue contents and usage

The key columns in the catalogues are:

  • 1.

    source identification: NAME (string);

  • 2.

    position: GLON, GLAT, POS_ERR which gives the Galactic coordinates in degrees and the estimated 1σ positional uncertainty in arcminutes;

  • 3.

    flux density: FLUX, FLUX_ERR in mJy measured in a circular aperture with radius equal to the nominal FWHM of the beam.

The one additional column for the HFI bands compared to the LFI bands is due to the inclusion of a cirrus estimate, described below.

Individual sources can be searched for in the list either by Galactic coordinates (GLON, GLAT), or by the equivalent J2000 equatorial coordinates (RA, DEC). The 1σ positional uncertainty for a source, given by POS_ERR in arcminutes, depends on the local background RMS and SNR. This uncertainty is only a measure of the uncertainty for fitting the location of the source in the maps and does not take into account any astrometric offset in the maps. Furthermore, POS_ERR is measured from the positional uncertainty of artificial point sources injected into the maps. As a result, sources might have larger positional uncertainties which are not reflected in this value (see Sect. 2).

When a source is classified as extended, we set EXTENDED = 1. This implies that the square root of the product of the major and minor axis of the source is 1.5 times larger than the square root of the major and minor axis of the estimated Planck point spread function at the location of the source, i.e., (3)In the upper HFI bands, sources which are extended tend to be associated with structure in the Galactic interstellar medium although individual nearby galaxies are also extended sources as seen by Planck (see Planck Collaboration 2011l). The choice of the threshold being set at 1.5 times the beam is motivated by the accuracy with which source profiles can be measured from maps where the point spread function is critically sampled (1.7′ pixel scale for a ~4′ FWHM). Naturally, faint sources for which the Gaussian profile fit might have failed do not have the EXTENDED tag set.

As described in Sect. 2.1.3, four measures of flux density are provided in mJy. For extended sources, both FLUX and PSFFLUX will likely be significant underestimates of the true source flux density. Furthermore, at faint flux densities corresponding to low signal-to-noise ratios (less than 20), the PSF fit might have failed. This would be represented either by a negative flux density or by a significant difference between the PSFFLUX and FLUX values. In general, for bright extended sources, we recommend using the GAUFLUX and GAUFLUX_ERR values although even these might be biased high if the source is located in a region of complex, diffuse foreground emission.

Uncertainties in the flux density measured by each technique are reflected in the corresponding “_ERR” column. The flux uncertainties derived from the artificial point sources injected into the maps are available in MCQA_FLUX_ERR. MCQA_FLUX_ERR is the standard deviation of the dimensionless (Sinput − Soutput)/Sinput for input and output flux densities S based on the aperture flux density (i.e., FLUX) at the signal-to-noise ratio of the source. We believe that the most conservative flux uncertainty is the quadrature sum of the Monte-Carlo flux uncertainty and the “_ERR” value relevant for the appropriate flux density (FLUX, PSFFLUX, GAUFLUX or FLUXDET).

MCQA_FLUX_BIAS provides the median in the difference between the injected flux and extracted aperture flux of the artificial point sources. In principle, the bias should be close to zero if the aperture corrections are precisely known, the aperture is perfectly centred on each source, and the background can be precisely estimated. In practice, there is an offset of a few percent, which can become large at the lowest signal-to-noise ratios or in high-background regions. This is a median offset estimated as a function of SNR from the artificial point sources, and has already been applied to the FLUX value of all sources. The bias correction has been applied such that the FLUX in the catalogue is the measured flux density divided by (1-MCQA_FLUX_BIAS) and increases the flux density values by about 5%.

The 1σ point source flux uncertainty due to structure in the background is given in BACKGROUND_RMS in units of mJy. At the lowest frequencies this is a combination of CMB noise and instrumental noise, with the latter dominating. At 143GHz, the noise is dominated by the CMB. At higher frequencies, it is dominated by Galactic ISM. The ratio of source flux density to BACKGROUND_RMS is the primary parameter which is used to calibrate the RELIABILITY of sources.

The dates on which the source was observed are included in DATESOBS (UTC) in the yyyymmdd format. This will be useful in the analysis of time-variable sources. The flux-density value in the ERCSC is an average over all the dates of observations.

Sources in the HFI bands each have a CIRRUS number which is based on the number of sources (both low and high reliability) within a 2° radius of the source, in raw 857GHz catalogues derived from the maps. The number has been normalised to a peak value of one. The normalisation factor is in practice, derived from the number density of sources in the Large Magellanic Cloud region where the maximum number of 857GHz sources is located.

Finally, each source has a CMBSUBTRACT flag. This flag has values of 0, 1 or 2. The value is 0 if the source is detected in the CMB-subtracted maps and has an aperture flux difference |Sintensity − Snocmb|/Sintensity < 0.30. CMBSUBTRACT = 1 if the source is detected in the CMB subtracted maps but has a flux difference of greater than 30%. CMBSUBTRACT = 2 if the source is not detected in the CMB subtracted maps. CMB subtraction results in artefacts in the maps which might remove real sources. It is recommended that a conservative user who wants a guarantee of source detection in follow-up observations neglect sources with CMBSUBTRACT = 2.

5.2. Cautionary notes in usage of catalogues

In this section, we list some cautionary notes associated with usage of the ERCSC list.

  • Statistical character: the ERCSC list is an early list of highlyreliable sources from the first Planck all skysurvey. It is not a flux density limited sample or even a completesample of sources and therefore care should be taken beforeundertaking statistical studies such as source counts. This ispartly due to the fact that the scan strategy results in significantvariation in instrumental sensitivity as a function of positionon the sky. In addition, the relative contribution of astrophys-ical sources of “noise” such as the CMB and the emissionfrom the Galactic interstellar medium (ISM) vary across thePlanck frequencies. The CMB contributionpeaks between 100 and 143 GHz while the ISMcontribution peaks above 857 GHz. In conjunc-tion with the varying spatial resolution, this results in varyinglimits to the sensitivity of sources that can be detected both as afunction of position on the sky and as a function of frequency. TheMonte-Carlo analysis presented does quantify this variation insensitivity for the overall catalogue. However, the estimates forthe fraction of sky area above a particular completeness limit,have not been factored into the catalogue.

  • Variability: at radio frequencies, many of the extragalactic sources are highly variable. A small fraction of them vary even on time scales of a few hours based on the brightness of the same source as it passes through the different Planck horns. Follow-up observations of these sources might show significant differences in flux density compared to the values in the data products. Although the maps used for the ERCSC are based on 1.6 sky coverages, the ERCSC provides only a single average flux density estimate over all Planck data samples that were included in the all sky maps and does not contain any measure of the variability of the sources. The Planck Quick Detection System (QDS; Aatrokoski et al. 2010) attempts to quantify the variability of sources seen by Planck. The information from the QDS has been included in the notes for certain sources.

    thumbnail Fig.15

    Bandpasses of HFI with the location of bright CO rotational lines (J = 1 → 0, 2 → 1, 3 → 2, 4 → 3, and 5 → 4 from left to right) shown as a horizontal black line with tick marks. The CO lines can introduce a significant positive bias in the flux density of the sources, particularly those associated with Galactic star-forming regions. The effect is the most significant at 100GHz where the flux density may be boosted by more than 50%. See Planck HFI Core Team (2011b) for details.

    Open with DEXTER

  • Contamination from CO: at infrared/submillimetre frequencies (100GHz and above), the Planck bandpasses straddle energetically significant CO lines (Fig. 15). The effect is the most significant at 100GHz, where the line might contribute more than 50% of the measured flux density. Follow-up observations of these sources, especially those associated with Galactic star-forming regions, at a similar frequency but different bandpass, should correct for the potential contribution of line emission to the continuum flux density of the source. See Planck HFI Core Team (2011b) for details.

  • Photometry: each source has multiple measures of photometry FLUX, GAUFLUX, PSFFLUX and FLUXDET as defined above. The appropriate photometry to be used depends on the nature of the source. For sources which are unresolved at the spatial resolution of Planck, FLUX and PSFFLUX are most appropriate. Even in this regime, PSF fits of faint sources fail and consequently these have a PSFFLUX value of “NaN” (“Not a Number”). For bright resolved sources, GAUFLUX might be most appropriate although GAUFLUX appears to overestimate the flux of sources close to the Galactic plane due to an inability to fit for the contribution of the Galactic background at the spatial resolution of the data. For faint resolved sources in the upper HFI bands, FLUXDET, which is the flux density in an elliptical Kron aperture provided by SExtractor, might give the most accurate numbers. The user should also note that the absolute calibration of flux-density values are required to be accurate to within about 30% although the signal-to-noise of the sources are much higher.

  • Cirrus/ISM: a significant fraction of the sources detected in the upper HFI bands could be associated with Galactic interstellar medium features or cirrus. The IRAS 100μm surface brightness in MJysr-1 for each of the sources, which is commonly used as a proxy for cirrus, is available through a search of the ERCSC with IRSA. Candidate ISM features can also be selected by choosing objects with EXTENDED = 1 although nearby Galactic and extragalactic sources which are extended at Planck spatial resolution will meet this criterion. Alternately, the value of CIRRUS in the catalogue can be utilised to flag sources which might be clustered together and thereby associated with ISM structure.

6. Astrophysical source classes identified by their multifrequency signature

In addition to the single frequency catalogs described in the previous sections, there are two other source catalogs that are provided as part of the ERCSC. These two additional catalogs leverage the spectral signature of two specific classes of astrophysical sources through the Planck bands and are generated using specialized multifrequency algorithms which have been developed within the Planck Collaboration. These are a list of galaxy clusters detected through the Sunyaev-Zeldovich effect and cold pre-stellar cores identified by the derived far-infrared color temperature in fits to the Planck photometry.

Table 6

ESZ catalogue columns.

6.1. The Early Sunyaev-Zeldovich cluster catalogue

The Planck Early Release Sunyaev-Zeldovich (ESZ) cluster sample (described in more detail in Planck Collaboration 2011d) is a list of 189 SZ cluster candidates which are detected by their multi-frequency signature in the Planck bands. The thermal SZ effect is the result of energetic electrons in the hot intra-cluster medium inverse-Compton scattering off the CMB photons. The net result is a distortion in the shape of the CMB spectrum, which results in a deficit of flux density below ~220GHz and an increment in flux density at higher frequencies (Sunyaev & Zel’dovich 1972; Carlstrom et al. 2002). By utilising a matched multi-frequency filter, the spectral signature of this distortion can be detected and measured in the Planck all-sky maps, which enables cluster candidates to be detected.

The ESZ sample generated as part of the Planck early data release is the result of a blind multi-frequency search in the all sky maps, i.e., no prior positional information on clusters detected in any existing catalogues was used as input to the detection algorithm. The ESZ sample is produced using one of the four matched multi-frequency filter (MMF) algorithms available within the Planck Collaboration (hereafter MMF3; see Melin et al. (2010) for details of the comparison of the cluster extraction algorithms available within the collaboration). MMF3 is an all-sky extension of the algorithm described in Melin et al. (2006) and is run blindly over the six HFI frequency maps. The technique first divides the all-sky maps into a set of overlapping square patches. The matched multi-frequency filter then optimally combines the six frequencies of each patch, assuming the SZ frequency spectrum and using the Arnaud et al. (2010) pressure profile as the cluster profile. Auto- and cross-power spectra used by the MMF are directly estimated from the data. They are thus adapted to the local instrumental noise and astrophysical contamination such as ISM emission. For each patch, the scale radius of the cluster profile is varied to maximise the signal-to-noise ratio of each detection. The algorithm thus assigns to each detected source an estimated size and an integrated flux. The detected sources extracted from individual patches are finally merged into an all-sky cluster list. Non-SZ sources captured by the MMF algorithm can contaminate the list and an additional step of validation of the detection is needed.

thumbnail Fig.16

Plot showing the all sky distribution of the ESZ cluster candidates colour coded by signal-to-noise ratio. Sources close to the Galactic plane have been excluded since the spurious fraction is high.

Open with DEXTER

Unlike the individual frequency source list or the ECC list, which are validated through a Monte-Carlo technique, the reliability of the ESZ list has been estimated through a validation process based on internal checks and on cross-checks with ancillary optical/near-infrared and X-ray cluster catalogues or images. Cross-matches with the Meta-Catalogue of X-ray detected Clusters of galaxies (MCXC hereafter; Piffaretti et al. 2011), Abell and Zwicky catalogues, SDSS-based catalogues, MAXBCG and Wen et al. (2009) and a compilation of SZ observed clusters were undertaken. For each known X-ray cluster, several entries are available among which the identifiers, redshift, coordinates, total mass M500, and radius R500 were used during the external validation process. R500 is the radius that encompasses a mean matter density which is 500 times the critical density at the corresponding redshift. R500 is less than the virial radius of the cluster. M500 is the mass within R500. Further searches in Virtual Observatory (VO) and in logs of observatories were performed. The goal of this search was to identify cluster candidates which might already have ancillary data available for community access. Of the 189 cluster candidates, 169 are associated with known X-ray or optical clusters and the Planck data provides the first measure of the SZ signature for the majority of them. In addition to the cross-check with ancillary data, follow-up observations with XMM confirmed an additional 11 new clusters which are described in Planck Collaboration (2011e). 9 other new clusters have not been confirmed in the X-ray as yet.

thumbnail Fig.17

Redshift distribution of ESZ cluster candidates. ESZ clusters which do not have a redshift are shown as the hatched region at z = 0.01.

Open with DEXTER

A full description of the validation effort is in Planck Collaboration (2011d). Figure 16 shows the all sky distribution of the clusters and cluster candidates while Fig. 17 shows their redshift distribution. Table 6 gives the list of columns in the ESZ catalogue.

All clusters have a Planck name which is given in the column NAME. This name is constructed from GLON and GLAT, the best estimated Galactic coordinates of the SZ signal. SNR gives the detection’s signal-to-noise ratio as defined by the matched multi-filter method MMF3.

When a Planck SZ cluster candidate is identified as an X-ray cluster in the MCXC the coordinates of the X-ray counterpart (i.e., the X-ray centroid) is given. The same positional information is given for the Planck cluster candidates confirmed by XMM-Newton observation (apart from one candidate identified with a double cluster, see ESZ notes). For those clusters with an X-ray counterpart, the Compton-Y parameter, which is the integral of the Compton-y over the cluster area, is re-extracted from the Planck maps using the X-ray centroid coordinates and X-ray size THETA_X as priors, yielding the value Y_PSX and its error Y_PSX_ERR. The Compton-Y parameter measured using the X-ray position and size priors is known to be more robust than the blind value estimated without priors (Planck Collaboration 2011d).

For cluster candidates without available estimates of X-ray position or size, the derived SZ parameters THETA, Y, and the associated errors THETA_ERR and Y_ERR are the values returned directly by the matched filter. These are likely to be more uncertain than cases where the cluster has been confirmed in the X-ray data. THETA and THETA_X are the estimated angular size of the cluster at 5 times R500.

Notes on individual clusters can be found in Planck Collaboration (2011v). These notes include cross-matches with ERCSC sources as well as the origin of the redshift.

Table 7

ECC catalogue columns

6.2. The Early Cold Cores Catalogue

Pre-stellar cloud cores represent the transition from turbulence dominated large scales to the gravitation dominated protostellar scales and are therefore a crucial step in the process of star formation. Imprinted in their structure and statistics is information of the properties of the parental clouds and the core formation processes where interstellar turbulence, magnetic fields, self-gravity, and external triggering all play a role.

The Planckall-sky submillimetre/millimetre survey has both the very high sensitivity and spatial resolution required for the detection of compact cores. The highest frequency channels at 857, 545 and 353GHz cover the frequencies around and longwards of the intensity maximum of the cold dust emission: Bν(T = 10K)ν2 peaks at a wavelength close to 300 μm while, with a temperature of T ~ 6K, the coldest dust inside the cores has its maximum close to 500 μm. When Planck data are combined with far-infrared data like the IRAS survey, the observations enable accurate determination of both the dust temperatures and its emissivity index. For historical reasons, we use “Cold Cores” to designate the entries in the ECC, since pre-stellar cores were a major scientific goal of this product. However, as two companion papers (Planck Collaboration 2011r,s) demonstrate, most of these entries are more correctly described as “cold clumps”, intermediate in their structure and physical scale between a true pre-stellar core and a molecular cloud. This is of course to be expected as the Planck effective beam dictates a preferred angular scale for ECC detection, and the selection process places their emission peak in the submm range.

In order to detect the cold cores, a warm background determined by the scaled IRAS 100 μm emission is subtracted from the Planck maps at 217, 353 and 545GHz (Montier et al. 2010; Planck Collaboration 2011s). The scaling factor is determined by measuring the sky background in a disk of 15arcmin outer radius. We search for the presence of a source in the residual emission, and perform photometry at the location of detected sources. The band-merging process positionally matches objects in the 353GHz detection list, which contains the least number of entries, against both the 545 and 857GHz catalogues using a 5′ matching radius. Sources only detected in one or two bands are discarded. The SNR and position of the detection having the greatest SNR are assigned to the band-merged entry.

Aperture photometry is performed on the IRAS 100μm and 353, 545, and 857GHz maps using a source radius of five arcminute and a background annulus spanning radii from five to ten arcminutes. An unconstrained three-parameter (T, β, and S857) greybody is fit to the four-band aperture photometry with the fitted temperatures used in the source selection process.

As for the ERCSC, a Monte-Carlo process is used to define signal-to-noise thresholds where the derived temperatures are consistent with being < 14K. A full description of the process can be found both in Planck Collaboration (2011v). The delivered ECC catalogue consists of 915 objects (Fig. 18) meeting the ECC selection criteria of SNR ≥ 15 and T ≤ 14K., after removal of selected sources having obviously discrepant SEDs or are closely positionally matched to bright AGN, e.g., 3C 273. The columns in the ECC catalogue are shown in Table 7.

thumbnail Fig.18

Sky distribution of ECC detections having SNR ≥ 15 and T ≤ 14K is shown. The symbols are colour-coded by temperature using the scale shown on the right.

Open with DEXTER

It should be noted that the derived temperatures of the Cold Cores are degenerate with the derived emissivity due to the absence of more than one flux-density estimate at wavelengths shortward of the peak in the blackbody spectrum. This issue is discussed in detail in Planck Collaboration (2011s).

Further information on the ECC is given in Planck Collaboration (2011v,s). Additional remarks on individual sources, including cross-matches with ERCSC sources are provided in the notes file that accompany the individual catalogs (see Sect. 5).

7. Concluding remarks

Planck is the third generation space based CMB experiment with more than an order of magnitude higher spatial resolution than COBE and with a broader range of frequency coverage than WMAP. The completion of the first sky survey in April 2010 yields a unique opportunity to study the classes of astrophysical sources that are foreground contributors to the CMB. The ERCSC is a catalogue with >90% reliability and is based on 1.6 sky coverages by Planck. It has been produced with a very rapid turnaround time to facilitate follow up observations with existing and future telescope facilities. The Planck Collaboration expects that the diversity of sources present in the ERCSC, ranging from protostellar cores to SZ selected clusters, radio galaxies and luminous star-forming galaxies, will provide a rich opportunity for follow-up studies of interesting astrophysical phenomena.


1

Planck (http://www.esa.int/Planck) is a project of the European Space Agency (ESA) with instruments provided by two scientific consortia funded by ESA member states (in particular the lead countries France and Italy), with contributions from NASA (USA) and telescope reflectors provided in a collaboration between ESA and a scientific consortium led and funded by Denmark.

2

Spurious sources can be classified as those which have an intrinsic flux density of zero but with some arbitrary extracted flux density, corresponding to a flux density error of 100%. The presence of such sources would decrease the reliability at the corresponding extracted flux density.

3

The following objects have been masked in the map making. Asteroids: 10 Hygiea, 11 Parthenope, 128 Nemesis, 12 Victoria, 13 Egeria, 14 Irene, 15 Eunomia, 16 Psyche, 18 Melpomene, 19 Fortuna, 1 Ceres, 20 Massalia, 29 Amphitrite, 2 Pallas, 324 Bamberga, 3 Juno, 41 Daphne, 45 Eugenia, 4 Vesta, 511 Davida, 52 Europa, 704 Interamnia, 7 Iris, 88 Thisbe, 8 Flora, 9 Metis. Comets: Broughton, Cardinal, Christensen, d’Arrest, Encke, Garradd, Gunn, Hartley 2, Holmes, Howell, Kopff, Kushida, LINEAR, Lulin, McNaught, NEAT, Shoemaker-Levy 4, SidingSpring, Tempel 2, Wild 2.

Acknowledgments

The production of the Planck Early Release Compact Source Catalogue was funded by NASA and carried out at the US Planck Data Center at the Infrared Processing and Analysis Center (IPAC), California Institute of Technology, on behalf of and in collaboration with the LFI and HFI Data Processing Centers and with many contributions by members of the Planck Collaboration. The Planck Collaboration acknowledges the support of: ESA; CNES and CNRS/INSU-IN2P3-INP (France); ASI, CNR, and INAF (Italy); NASA and DoE (USA); STFC and UKSA (UK); CSIC, MICINN and JA (Spain); Tekes, AoF and CSC (Finland); DLR and MPG (Germany); CSA (Canada); DTU Space (Denmark); SER/SSO (Switzerland); RCN (Norway); SFI (Ireland); FCT/MCTES (Portugal); and DEISA (EU). A description of the Planck Collaboration and a list of its members with the technical or scientific activities they have been involved into, can be found at http://www.rssd.esa.int/index.php?project=PLANCK&page=Planck_Collaboration

References

  1. Aatrokoski, J., Lähteenmäki, A., Tornikoski, M., et al. 2010, MNRAS, 401, 597 [NASA ADS] [CrossRef] [Google Scholar]
  2. Arnaud, M., Pratt, G. W., Piffaretti, R., et al. 2010, A&A, 517, A92 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  3. Beichman, C. A., Neugebauer, G., Habing, H. J., Clegg, P. E., & Chester, T. J. 1988, Infrared astronomical satellite (IRAS) catalogs and atlases, Vol. 1: Explanatory supplement, 1 [Google Scholar]
  4. Bennett, C. L., Halpern, M., Hinshaw, G., et al. 2003, ApJS, 148, 1 [NASA ADS] [CrossRef] [Google Scholar]
  5. Bersanelli, M., Mandolesi, N., Butler, R. C., et al. 2010, A&A, 520, A4 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  6. Bertin, E., & Arnouts, S. 1996, A&AS, 117, 393 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  7. Carlstrom, J. E., Holder, G. P., & Reese, E. D. 2002, ARA&A, 40, 643 [NASA ADS] [CrossRef] [Google Scholar]
  8. Carvalho, P., Rocha, G., & Hobson, M. P. 2009, MNRAS, 393, 681 [NASA ADS] [CrossRef] [Google Scholar]
  9. Chary, R., Casertano, S., Dickinson, M. E., et al., 2004, ApJ, 154, 80 [NASA ADS] [CrossRef] [Google Scholar]
  10. Dupac, X., & Tauber, J. 2005, A&A, 430, 363 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  11. Gold, B., Odegard, N., Weiland, J. L., et al. 2011, ApJS, 192, 15 [NASA ADS] [CrossRef] [Google Scholar]
  12. Górski, K. M., Hivon, E., Banday, A. J., et al. 2005, ApJ, 622, 759 [NASA ADS] [CrossRef] [Google Scholar]
  13. Gregory, P. C., Scott, W. K., Douglas, K., & Condon, J. J. 1996, ApJS, 103, 427 [NASA ADS] [CrossRef] [Google Scholar]
  14. Griffith, M. R., Wright, A. E., Burke, B. F., & Ekers, R. D. 1995, ApJS, 97, 347 [NASA ADS] [CrossRef] [Google Scholar]
  15. Healey, S. E., Romani, R. W., Taylor, G. B., et al. 2007, ApJS, 171, 61 [NASA ADS] [CrossRef] [Google Scholar]
  16. Hobson, M. P., & McLachlan, C. 2003, MNRAS, 338, 765 [NASA ADS] [CrossRef] [Google Scholar]
  17. Kron, R. G. 1980, ApJS, 43, 305 [NASA ADS] [CrossRef] [Google Scholar]
  18. Lamarre, J., Puget, J., Ade, P. A. R., et al. 2010, A&A, 520, A9 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  19. Leahy, J. P., Bersanelli, M., D’Arcangelo, O., et al. 2010, A&A, 520, A8 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  20. López-Caniego, M., González-Nuevo, J., Herranz, D., et al. 2007, ApJS, 170, 108 [NASA ADS] [CrossRef] [Google Scholar]
  21. Mandolesi, N., Bersanelli, M., Butler, R. C., et al. 2010, A&A, 520, A3 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  22. Massardi, M., López-Caniego, M., González-Nuevo, et al. 2009, MNRAS, 392, 733 [NASA ADS] [CrossRef] [Google Scholar]
  23. Melin, J., Bartlett, J. G., & Delabrouille, J. 2006, A&A, 459, 341 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  24. Melin, J.-B., Aghanim, N., Bartelman, M., et al. 2010, A&A, submitted [Google Scholar]
  25. Mennella, A., Bersanelli, M., Butler, R. C., et al. 2011, A&A, 536, A3 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  26. Mitra, S., Rocha, G., Górski, K. M., et al. 2011, ApJS, 193, 5 [NASA ADS] [CrossRef] [Google Scholar]
  27. Montier, L. A., Pelkonen, V.-M., Juvela, M., Ristorcelli, I., & Marshall, D. J. 2010, A&A, 522, A83 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  28. Murakami, H., Baba, H., Barthel, P., et al. 2007, PASJ, 59, 369 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
  29. Murphy, T., Sadler, E. M., Ekers, R. D., et al. 2010, MNRAS, 402, 2403 [NASA ADS] [CrossRef] [Google Scholar]
  30. Piffaretti, R., Arnaud, M., Pratt, G. W., Pointecouteau, E., & Melin, J.-B. 2011, A&A, 534, A109 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  31. Planck Collaboration 2011a, A&A, 536, A1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  32. Planck Collaboration 2011b, A&A, 536, A2 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  33. Planck Collaboration 2011c, A&A, 536, A7 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  34. Planck Collaboration 2011d, A&A, 536, A8 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  35. Planck Collaboration 2011e, A&A, 536, A9 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  36. Planck Collaboration 2011f, A&A, 536, A10 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  37. Planck Collaboration 2011g, A&A, 536, A11 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  38. Planck Collaboration 2011h, A&A, 536, A12 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  39. Planck Collaboration 2011i, A&A, 536, A13 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  40. Planck Collaboration 2011j, A&A, 536, A14 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  41. Planck Collaboration 2011k, A&A, 536, A15 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  42. Planck Collaboration 2011l, A&A, 536, A16 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  43. Planck Collaboration 2011m, A&A, 536, A17 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  44. Planck Collaboration 2011n, A&A, 536, A18 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  45. Planck Collaboration 2011o, A&A, 536, A19 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  46. Planck Collaboration 2011p, A&A, 536, A20 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  47. Planck Collaboration 2011q, A&A, 536, A21 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  48. Planck Collaboration 2011r, A&A, 536, A22 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  49. Planck Collaboration 2011s, A&A, 536, A23 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  50. Planck Collaboration 2011t, A&A, 536, A24 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  51. Planck Collaboration 2011u, A&A, 536, A25 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  52. Planck Collaboration 2011v, The Explanatory Supplement to the Planck Early Release Compact Source Catalogue (ESA) [Google Scholar]
  53. Planck Collaboration 2011w, A&A, 536, A26 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  54. Planck HFI Core Team 2011a, A&A, 536, A4 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  55. Planck HFI Core Team 2011b, A&A, 536, A6 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  56. Rosset, C., Tristram, M., Ponthieu, N., et al. 2010, A&A, 520, A13 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  57. Savage, R. S., & Oliver, S. 2007, ApJ, 661, 1339 [NASA ADS] [CrossRef] [Google Scholar]
  58. Sunyaev, R., & Zeldovich, Ya. 1972, A&A, 20, 189 [NASA ADS] [Google Scholar]
  59. Tauber, J. A., Mandolesi, N., Puget, J., et al. 2010, A&A, 520, A1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  60. Vieira, J. D., Crawford, T. M., Switzer, E. R., et al. 2010, ApJ, 719, 763 [NASA ADS] [CrossRef] [Google Scholar]
  61. Ward-Thompson, D., André, P., & Kirk, J. M. 2002, MNRAS, 329, 257 [NASA ADS] [CrossRef] [Google Scholar]
  62. Wright, E. L., Chen, X., Odegard, N., et al. 2009, ApJS, 180, 283 [NASA ADS] [CrossRef] [Google Scholar]
  63. Wright, E. L., et al. 2010, AJ, 140, 1868 [NASA ADS] [CrossRef] [Google Scholar]
  64. Zacchei, A., Maino, D., Baccigalupi, C., et al. 2011, A&A, 536, A5 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]

All Tables

Table 1

Comparison between all sky surveys with similar frequencies aligned in rows.

Table 2

ERCSC catalogue columns.

Table 3

Planck ERCSC characteristics.

Table 4

ERCSC source characterisation.

Table 5

ERCSC source validation.

Table 6

ESZ catalogue columns.

Table 7

ECC catalogue columns

All Figures

thumbnail Fig.1

The variance in units of Kelvin2 across the entire sky, with the left panel showing the variance for the LFI frequencies and the right panel showing the variance for the HFI frequencies. At any single frequency, the variance in the all-sky maps span almost a factor of 50 over the entire sky.

Open with DEXTER
In the text
thumbnail Fig.2

Plots showing the results of the Monte-Carlo analysis at 30GHz with the PwS algorithm. The upper two rows shows the results when the flux density of sources is from FLUXDET while the lower two rows shows the results when the flux density of sources is from FLUX. The set of 3 plots in the top-left and bottom-left corner show the all-sky flux-density uncertainty, differential reliability and differential completeness of the Monte-Carlo sources as a function of SNR where signal may be FLUX or FLUXDET and the noise is the background RMS. The set of four plots at the top right and bottom right show (left to right, top to bottom) the fractional flux density uncertainty, (Sin − Sout)/Sin (see Sect. 5.1), the distribution of the absolute positional offset, differential positional offset, as well as completeness and contamination (1-reliability converted to a percentage) as a function of flux density for the half of the sky with the lowest sky background RMS. The range of sky background RMS converted to a point source flux density uncertainty, is shown in the inset in mJy. The primary source selections in the catalogues are based on the reliability vs output flux density/background RMS plots such that the cumulative reliability (integral of the differential reliability) is greater than 90%.

Open with DEXTER
In the text
thumbnail Fig.3

As in Fig. 2 but at 143GHz with the PwS algorithm.

Open with DEXTER
In the text
thumbnail Fig.4

As in Fig. 2 but at 857GHz with the SExtractor algorithm.

Open with DEXTER
In the text
thumbnail Fig.5

The Planck ERCSC flux density limit quantified as the faintest ERCSC source at |b| < 10° (dashed black line) and at |b| > 30° (solid black line) is shown relative to other wide area surveys. Also shown are the spectra of known sources of foreground emission as red lines; these include a Sν ~ ν-0.7 synchrotron component, ν-0.1 free-free component, a Rayleigh-Jeans component and a ν2 emissivity blackbody of temperature 18K. The ERCSC sensitivity is worse in the Galactic plane due to the strong contribution of ISM emission especially at submillimetre wavelengths. In the radio regime, the effect is smaller. The faintest WMAP 7 year 5σ sources are derived from the catalogue of Gold et al. (2011); Wright et al. (2009). Although the flux density limits of WMAP and Planck appear to be comparable at the lowest frequencies, the Planck ERCSC is more complete as discussed in Sect. 4. The GB6 sensitivity value is from Gregory et al. (1996), AT20G flux limit from Murphy et al. (2010), SCUBA-2 All Sky Survey (SASSy) limit from the Joint Astronomy Center website while the IRAS flux density limits are from the IRAS explanatory supplement (Beichman et al. 1988).

Open with DEXTER
In the text
thumbnail Fig.6

Sky distribution of sources in Galactic coordinates at all nine Planck frequencies. Sources are colour coded by flux density. In the Galactic plane, due to strong emission from the ISM, there is a paucity of faint sources. The higher density of sources in the LMC region is also noticeable.

Open with DEXTER
In the text
thumbnail Fig.7

The distribution of spectral indices (α where Sν ∝ να) for sources within 10° of the Galactic plane. Each panel shows the spectral index distribution for ERCSC sources at the corresponding Planck band.

Open with DEXTER
In the text
thumbnail Fig.8

The distribution of spectral indices for sources above 30° of the Galactic plane, likely to be dominated by extragalactic sources.

Open with DEXTER
In the text
thumbnail Fig.9

The SED of representative source classes in the ERCSC. The plot shows a pre-stellar core L1544, an extragalactic radio source Centaurus A, a synchrotron dominated radio galaxy Pictor A, IRC+10216 which is the prototype of stars with dust shells, the starbursting ultraluminous infrared galaxy Arp 220 and the cold stellar core ECC G176.52-09.80. IRAS or ISO flux densities are shown as solid squares while the Planck flux densities are shown as stars. The Planck ERCSC enables a diverse class of sources to be studied over a broad range of frequencies and flux densities.

Open with DEXTER
In the text
thumbnail Fig.10

Matches to quasars as a measure of positional offsets in the ERCSC 30 to 353GHz catalogues. The top row shows 30 and 44, the second row 70 and 100, the third row 143 and 217, and the final row 353GHz. There are insufficient numbers of detected quasars at the upper HFI frequencies.

Open with DEXTER
In the text
thumbnail Fig.11

The flux density of a subset of ERCSC sources at 30 and 44 GHz, with color corrections, compared to the flux density obtained from VLA 22 and 43 GHz observations of the same sources translated to the Planck effective frequency (Planck Collaboration 2011j). The over-plotted lines are the first order polynomial resulting from an uncertainty weighted fit to the VLA and ERCSC flux densities which partially takes into account Eddington bias. The slope of the fit is 1.08 at 30 GHz and 1.02 at 44 GHz indicating that both measurements are in good agreement. The median ratio of the ERCSC flux density to the VLA flux density is 1.15 at both frequencies. The difference is most likely attributable to a combination of effects including cross-calibration uncertainties, contribution from fainter sources within the Planck beam, variability and the fact that the smaller beam VLA measurements would be less sensitive to low surface brightness emission beyond the 2−4″ primary VLA beam although care has been taken to use mainly unresolved sources.

Open with DEXTER
In the text
thumbnail Fig.12

Histogram distribution of WMAP flux densities for all WMAP 5σ sources in each band (gray region). The sources that are detected in the ERCSC are shown as the red histogram. Some of the WMAP sources have been missed because of source variability.

Open with DEXTER
In the text
thumbnail Fig.13

Histogram distribution of ERCSC flux densities at each band in gray. ERCSC sources that are matched with WMAP 5σ sources in a similar band are shown as the red histogram. The WMAP 7 year point source catalogue mask (see text) has been applied to the ERCSC to ensure the same sky coverage.

Open with DEXTER
In the text
thumbnail Fig.14

Fractional difference between the ERCSC flux densities and WMAP flux densities at 30, 44, 70 and 100 GHz. The unit of the abcissa is Jy while the ordinate shows the fractional difference. No correction has been applied to the WMAP flux densities to account for the difference in bandpass compared to Planck. The agreement is good but the significant scatter that can be seen is most likely due to source variability.

Open with DEXTER
In the text
thumbnail Fig.15

Bandpasses of HFI with the location of bright CO rotational lines (J = 1 → 0, 2 → 1, 3 → 2, 4 → 3, and 5 → 4 from left to right) shown as a horizontal black line with tick marks. The CO lines can introduce a significant positive bias in the flux density of the sources, particularly those associated with Galactic star-forming regions. The effect is the most significant at 100GHz where the flux density may be boosted by more than 50%. See Planck HFI Core Team (2011b) for details.

Open with DEXTER
In the text
thumbnail Fig.16

Plot showing the all sky distribution of the ESZ cluster candidates colour coded by signal-to-noise ratio. Sources close to the Galactic plane have been excluded since the spurious fraction is high.

Open with DEXTER
In the text
thumbnail Fig.17

Redshift distribution of ESZ cluster candidates. ESZ clusters which do not have a redshift are shown as the hatched region at z = 0.01.

Open with DEXTER
In the text
thumbnail Fig.18

Sky distribution of ECC detections having SNR ≥ 15 and T ≤ 14K is shown. The symbols are colour-coded by temperature using the scale shown on the right.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
