1 Introduction

Classical Be stars are rapid B-type rotators of luminosity class V to III that have, or had at some time, emission lines of hydrogen (at least in Hα) and single ionized metals (Jaschek et al. 1981; Collins 1987). The formation of these emission lines is attributed to the presence of a circumstellar disk-like envelope surrounding the star.

Observations suggest the presence of two different regions in the circumstellar envelope of Be stars: a dense equatorial disk in quasi-Keplerian rotation (responsible for most of the emission lines and the IR-excess; Rivinius et al. 2013) and a more diluted polar wind (responsible for the highly broadened UV lines; Prinja 1989).

The mass density distribution of Be star disks is often modeled with a simple power law of the form ρ(r) = ρ0 rn, where ρ0 is a base density and n is the exponent of the radial coordinate r (Waters 1986; Jones et al. 2008). Typically ρ0 values are 10−9−10−12 g cm−3 and the n power is about 1.5−3.5 (Cote & Waters 1987; Waters et al. 1987; Silaj et al. 2010; Arcos et al. 2017; Vieira et al. 2017).

There is a general consensus about the importance of stellar rotation on the mass ejection process necessary to form a circumstellar disk. Frémat et al. (2005) derived a mean value for the average rotational velocity of Be stars on the order of 88% of break-up (or critical) velocity, Vc 1. Cranmer (2005) showed that the hottest Be stars have a uniform spread of intrinsic rotation speed between 40 and 100% of their Vc values, while the coolest Be stars are all quasi-critical rotators. Meilland et al. (2012) found a mean velocity ratio of that corresponds to a rotation rate of 2. This means that only a small amount of energy would be needed to eject matter from the stellar surface, otherwise, the importance of other mechanisms (e.g., radiation pressure, pulsation, binarity) that could contribute to form the disk should be discussed.

Zorec et al. (2016) studied a set of 233 stars and transformed the distribution of observed projected rotational velocities into another distribution of true rotational velocities. Since the VVc values become globally larger as stars evolve from the main sequence (MS) to later evolutionary phases, the distribution of true rotational velocities depends on the evolutionary state of the stellar sample. These authors concluded that once the mode of ratios of the true velocities of Be stars attains the value VVc = 0.77 in the MS evolutionary phase, it remains unchanged up to the end of the MS lifespan. The statistical corrections for overestimations of V sin i, caused by macroturbulent motions and binarity, produce a shift of this distribution toward lower values when all MS evolutionary stages are considered together. Finally, the obtained final distribution has a mode at VVc = 0.65 with a nearly symmetric distribution, showing that the Be phenomenon is present in a wide range of true rotational velocities (0.3 < VVc < 0.95). With this result, the probability that Be stars are critical rotators is very low.

Meilland et al. (2012) proposed that an efficient way to test mass-ejection processes is to constrain the geometry and kinematics of Be stars’ circumstellar environments. This can only be performed using long-baseline interferometry with high spectral resolution. First detections of rotational signatures in the envelope of Be stars were carried out by Mourard et al. (1989). Later, Meilland et al. (2007b) obtained clear evidence of Keplerian rotation in the disk of α Ara. Contemporaneous interferometric observations also provided information on the disk sizes (Tycner et al. 2005; Meilland et al. 2009; Sigut et al. 2015) and flattenings (Quirrenbach et al. 1997; Tycner et al. 2005), whilst a clear signature of polar wind was detected in Achernar by Kervella & Domiciano de Souza (2006). The presence of small-scale structures was found in κ CMa (Meilland et al. 2007a) and ζ Tau (Carciofi et al. 2009) that were interpreted with the one-arm density-wave oscillation model proposed by Okazaki (1997).

In a few cases, the stellar photosphere was resolved by interferometry, allowing the determination of physical stellar parameters, as for Achernar (Domiciano de Souza et al. 2003). Long-baseline interferometry has also been a powerful tool for detecting companions and deducing physical parameters of binary systems and circumbinary disks; for example, δ Sco (Meilland et al. 2011), 48 Per and ϕ Per (Delaa et al. 2011), δ Cen (Meilland et al. 2008), HD 87643 (Millour et al. 2009) and Achernar (Kanaan et al. 2008).

To progress in the understanding of the physical processes responsible for the mass ejection and to test the hypothesis that they depend on stellar parameters, Meilland et al. (2012) initiated a survey of the circumstellar environments of eight bright Be stars: α Col, κ CMa, ω Car, p Car, δ Cen, μ Cen, α Ara, and o Aqr. They observed the Brγ emission line to study the kinematics within the circumstellar disk. They determined the disk extension in the line and the nearby continuum for most of the targets and constrained the disk kinematics, showing that the disk rotation law is close to a Keplerian one. However, as they did not detect any correlation between the stellar parameters and the structure of the circumstellar environments they suggested that a larger sample of Be stars was needed to obtain conclusive results.

In this work, we present spectro-interferometric observations of a new set of 26 Be stars obtained using the Very Large Telescope Interferometer(VLTI)/Astronomical Multi-Beam Recombiner(AMBER) instrument described in Sect. 2. The results derived from our sample together with those obtained by Meilland et al. (2012) are discussed, with the aim being to understand the physical properties and origin of their circumstellar disks.

This paper is organized as follows: in Sect. 2 we present the observations. In Sect. 3 we describe the adopted model and stellar parameters used to fit interferometric data. In Sect. 4 we introduce the selected sample to study and provide a qualitative analysis of AMBER data of each object together with the best-fitting model parameters. We discuss our results in Sect. 5 and give our conclusions in Sect. 6.

2 Observations

Near-infrared (NIR) spectro-interferometric observations were carried out with the AMBER instrument (Petrov et al. 2007) installed on the VLTI at the Paranal Observatory, Cerro Paranal, Chile.

AMBER operates in the NIR part of the spectrum between 1.0 and 2.4 μm. It was designed to coherently combine three telescope beams that can either be 8.2 m unit telescopes (UTs) or 1.8 m auxiliary telescopes (ATs). These three output beams are merged in a common Airy disk containing Young’s fringes, which are dispersed by a standard long-slit spectrograph on a two-dimensional (2D) detector. Per observation, AMBER delivers the visibilities and differential phases of the science target at three different spatial frequencies and one closure phase. The fringe contrast and phase are related to the Fourier transform of the source brightness distribution on sky at the observed spatial frequency f = Bλ, where B is the baseline distance of a telescope pair within the UT or AT configuration. The stabilisation of the fringes could be enhanced with the external fringe tracker FINITO (Fringe-tracking Instrument of NIce and TOrino), allowing longer DITs (detector integration time) up to 10 s and leading to a better S/N on the spectrally dispersed fringes. Quite often, AMBER programs include the observation of calibrator objects to obtain not only differential but also absolute visibilities, using an estimation of the sizes of the calibrators and their visibilities. However, the drawback of using AMBER in high-resolution mode (HR, with R ≃ 12 000) with FINITO is the difficulty in determining a stable transfer function using calibrators that usually lead to poor data calibration.

We observed 26 Be stars using the AMBER instrument in conjunction with FINITO, from October 28 to 31, 2014. Our survey does not include the observation of calibrators. The observations were performed using the ATs, and the AMBER spectrograph was setup in the HR mode and centered on the Brγ 2.16 μm emission line. This allows us to study the circumstellar gas kinematics through the Doppler effect. The lack of a calibrator is not an issue since the differential visibility, the differential phase, and the closure phase are independent of the effects that modify the absolute visibility.

The interference pattern is related to the source brightness via a 2D Fourier transformation of the complex visibility V (u, v) and for modeling purposes fairly good coverage of the (u, v) plane is required.

Table 1 presents the log of observations: HD number, date and time, telescope baseline configuration, baselines length and position angles, and integration time of our 26 Be stars AMBER dataset. The projected baselines, (u, v) plane, in meters for each object of the selected sample (see Sect. 4.1) is shown in Figs. 1 and A.1A.17. Each observation in the (u, v) plane, that is, three baseline measurements, is plotted with different colors and symbols, as is explained in the caption of Fig. 1.

Data were reduced using the VLTI/AMBER data-reduction software (amdlib v3.0.9, see Tatulli et al. 2007; Chelli et al. 2009, for detailed information on the AMBER data reduction).

Table 1

VLTI/AMBER observing log.

thumbnail Fig. 1

HD 23630: (u, v) plan coverage, differential visibilities (δV), differential phases (δϕ) and closure phases (CP) from our HR measurements. Each observation in the (u, v) plane, i.e., three baseline measurements, is plotted with a different color and symbol: blue circles correspond to the baselines B1–B3; green squares to baselines B4–B6; red triangles to baselines B7–B9; purple diamonds to baselines B10–B12; pink hexagons to baselines B13–B15; cyan pentagons to baselines B16–B18; orange thin diamonds to baselines B19–B21. See description in Sect. 4.

Open with DEXTER

3 Metodology

3.1 Disk model

Interferometric data are often analyzed using a 2D kinematic model of a rotating and/or expanding equatorial disk. This simple “toy model” has been used to describe circumstellar disks of classical Be stars (Delaa et al. 2011; Meilland et al. 2012, 2011); see Delaa et al. (2011) for a detailed description of the model.

This model includes a central star described by a uniform disk of constant brightness I (x, y), where x and y are the spatial Cartesian coordinates on the sky plane, surrounded by a circumstellar envelope. The envelope emission in the line, Il (x, y), and continuum, Ic (x, y), are described by two elliptical Gaussian distributions of different FWHMs, named al and ac, but with the same flattening f due to a projection effect on the sky of a geometrically thin equatorial disk that depends on the inclination angle i, being f = amaxamin = 1∕cos(i), where amax is the major axis and amin is the minor axis.

The emission maps were combined with a 2D projected velocity map, Vproj(x, y), of the geometrically thin equatorial disk, (1)

where Vϕ and Vr are the rotational and radial velocity laws for the disk with the radial distance given by Hutchings (1970) and Castor et al. (1975), respectively,

where R is the stellar radius, Vrot the rotational velocity at the disk inner radius, V0 the expansion velocity at the photosphere, V the terminal velocity, β the exponent of the expansion velocity law and j the exponent of the rotational velocity law.

For each wavelength λ and within a narrow spectral band δλ, an iso-velocity map projected along the line of sight, R(x, y, λ, δλ), was calculated and multiplied by the whole emission map in the line. The whole emission map for each wavelength is the weighted sum of the stellar map, the disk continuum map and the emission line map: (4)

where F(λ) and are, respectively, the contributions of the total continuum flux from the star and the disk, while EW is the line equivalent width.

The model parameters can be classified into different categories:

  • Stellar parameters: R, distance (d), inclination angle (i), disk major-axis position angle (PA).

  • Kinematic parameters: Vrot, V0, V, β and j.

  • Disk continuum parameters: disk FWHM in the continuum (ac), disk continuum flux normalized by the total continuum flux ().

  • Disk emission line parameters: disk FWHM in the line (al), and line equivalent width (EW).

We know how each parameter affects the visibility and phase variations (Meilland et al. 2012), and most parameters are unambiguously constrained using a few baselines with various orientations and lengths. Therefore, we decided to perform the model-fitting manually (instead of an automatic fit of the models). For all targets we set the expansion velocity to zero, since usually the radial velocity in the disk is assumed negligible (Miroshnichenko et al. 2003; Vinicius et al. 2006; Meilland et al. 2007a,b). For the other parameters (especially PA, i, ac, al and EW, which strongly affect the interferometric observables and, therefore, are easily and unambiguously constrained), we started with rough value estimates from a preliminary fit to our interferometric data and, then, we explored the parameter space by decreasing steps to minimize χ2 (see details below). We also explored the full range of possible model parameters using larger steps to make sure there are no other minima. Once we had obtained the best-fitting model, we changed the parameters one by one to find the uncertainty of each one. We consider the limit of uncertainty when the model is no longer a good fit for the observations. In what follows, we briefly describe each parameter.

  • PA (major axis position angle) modifies the amplitude of phase variations and the drop of the visibility (Meilland et al. 2011). For a nonfully resolved disk, the amplitude of the “S” shape variation is proportional to the baseline length and depends on its orientation. When the baseline is aligned with the major axis of the circumstellar envelope, the amplitude of the “S” shape is maximum and the visibility variation is “W” shaped, as shown in the B1 baseline of Fig. 1. At the same time, when the baseline is aligned with the minor axis the amplitude of the “S” shape is null and the shape of the drop of the visibility changes from “W” to “V” shaped, as shown in the B5 baseline of Fig. 1. We started the fit with 10° steps in the 0–360° range, and refined the grid using a final step of 1°.

  • EW is measured from the Brγ line profile. To derive the model sensitivity to the EW, this value was varied up to 30% using steps between 1 and 0.1 Å.

  • al (disk FWHM in the emission line in stellar diameters, D) has a huge influence on the drop of the visibility along all baselines and on the amplitudes of the “S” shapes of the differential phases. Phase variation loses its “S” shape for those baselines that fully resolved the disk, because of secondary effects due to inhomogeneities of the disk or, as in most of our observations, because of a mathematical effect due to the over-resolution of the disk as shown in the B9 baseline of Fig. 1. This mathematical effect is due to a property of the Fourier transform, by which the visibility goes through zero when a simple object is fully resolved, and beyond that, its phase is inverted. This effect is more complex in the case of a multicomponent object, that is, the rotating disk around a Be star, and it generates the loss of the “S” shape of the phase variations in a fully resolved disk. The parameter al also affects the double-peak separation (the larger the disk, the smaller the separation). We calculated models with values in the 1–20D range, with steps of between 0.5 and 0.1D.

  • ac (disk FWHM in the continuum in stellar diameters, D) is mainly derived from visibility measurements in the continuum. This parameter sets the relative flux of the disk in the continuum. As the disk emission in the continuum is larger than the stellar photosphere, this parameter affects the level of the absolute visibility in the continuum, that is, the absolute visibility in the continuum decreases when ac increases. Therefore, it can modify the amplitude of the phase variations. The more resolved an object is in the continuum, the smaller the phase variations are. We explored the values in the 1–20D range, with steps of between 1and 0.1D.

  • i (inclination angle) also has a significant effect on the drop of the visibility for baselines close to the polar orientation; it also has influence on the line-peak separation since it is related to the projected rotational velocity. The space parameter for i is the range 0–90°, and we explored steps of between 5° and 1°.

  • Vrot (rotational velocity) and j (exponent of the rotational velocity law) influence the double-peak separation and line width. The faster the disk rotates, the larger the peaks separate. On the other hand, as j increases, the rotational velocity drops faster with distance, the line double-peak separation becomes smaller, and the line wings wider. It is quite hard to set both Vrot and j unambiguously. The only way to do that is to study the disk kinematics using multiple lines formed in different parts of the disk. As Vrot and j describe the global disk kinematics, they should not depend on the observed line. This has been done only once, on the Be star δ Sco (Meilland et al. 2011), using the Hα line from the VEGA instrument, and Brγ and the 2.06 μm He I lines from AMBER. It is worth mentioning emission line wings can also be affected by nonkinematic broadening caused by noncoherentscattering (Delaa et al. 2011). Unfortunately, we do not have measurements in other lines to solve the ambiguity, therefore we explored the space parameter of Vrot and j to derive rough values. For Vrot, the space parameter was limited by V (obtained from i and V sin i) and Vc, and we explored this interval using initial steps of 10 km s−1 and decreasing them to minimal steps of 2 km s−1. For j, we inspected the 0.3 0.65 range, with initial steps of 0.05 and final steps of 0.01.

3.2 Stellar parameters from SED fittings

In order to derive R and for the selected sample, we performed fittings to the spectral energy distributions (SEDs). For each target, we reconstructed its SED using data available from the VIZIER database. We fitted a Kurucz (1979) model to the photometric data (Ochsenbein et al. 2000) using a minimization method implemented in the library IDL routine “mpfit” (details about the algorithm used can be found in Sect. 3.1 of Arcos et al. 2018). The input parameters are Teff, log g, and the reddening Rv. The Teff and log g values were taken from Frémat et al. (2005). The value of Rv was set in 3.1, using the interstellar extinction law from Cardelli et al. (1989).

For three of the sample stars (HD 32991, HD 37202 and HD 66194) Teff values are not available in the literature. Therefore, we also obtained Teff from the SED fitting.

To avoid contamination from the disk flux, the SED was fitted in the ultraviolet and optical wavelength ranges (Meilland et al. 2009). We fixed the stellar parameter from Table 2, except for R and , which are left free (and Teff in the cases commented before). From the best-fitting model we constrained R and for all the targets, and also the effective temperature, Teff, for HD 32991, HD 37202, and HD 66194.

In Fig. 2 we present an example of an SED fitting model. Red triangles represent the photometric data from the VIZIER database, the solid blue line represents the best-fitting Kurucz model, and the dashed green line shows the IR excess.

Table 2

Adopted and calculated parameters for the sample of Be stars with emission in the Brγ line.

thumbnail Fig. 2

Example of the SED fitting model for HD 41335. Red triangles represent the photometric data from VIZIER database, the solid blue line represents the best-fitting Kurucz model and the dashed green line shows the IR excess.

Open with DEXTER

4 Results

4.1 The selected sample and stellar parameters

Our sample consists of 26 Be stars observed with the VLTI/AMBER instrument. As shown in Fig. 3, the majority of the stars show a double-peaked emission profile. Shell line profiles are observed in HD 23862 (28 Tau) and HD 37202 (ζ Tau). The Brγ line is weak in HD 212571 (π Aqr) while eight stars (HD 23302, HD 23338, HD 23408, HD 23480, HD 33328, HD 75311, HD 219688, and HD 224686) display an absorption line profile. These last eight stars are excluded from the present study because we want to model the circumstellar disk emission. Therefore, our final sample contains 18 Be stars with mK  ≤ 6, spectral types between B1 and B8, and luminosity classes between V and III, distributed according to the histogram displayed in Fig. 4. Around 55% of our star sample have spectral types B1-B2, and the others are distributed almost uniformly between B3-B4 and B7-B8. The sample does not have stars with spectral types B5-B6. Around 60% of the star sample are in luminosity class V. Stars with luminosity classes IV and III are a few more than 20 and 15% of the total sample, respectively. Luminosity classes IV and III are mostly present in spectral types B1-B2 and B7-B8, while luminosity class V is spread over all the spectral subtypes sampled.

Table 2 lists known and calculated parameters for stars with the Brγ line in emission: the HD number and star name are given in the first two columns; Cols. 3 and 4 list the K-band magnitude (mK) and spectraltype (ST), respectively, taken from the CDS database. Column 5 lists the distance to the star in pc (d) which was taken from van Leeuwen (2007) and Astraatmadja & Bailer-Jones (2016). Columns 6–8 give the effective temperature (Teff), projected rotational velocity (V sin i), and break-up velocity (Vc) taken from Frémat et al. (2005), with the exception of the stellar parameters for HD 32991, HD 37490, and HD 66194, which we estimated from fittings to the SEDs using Kurucz (1979) atmospheric models (see Sect. 3.2). For HD 32991, the V sin i was taken from Abt et al. (2002), and for HD 37490 and HD 66194 from Chauville et al. (2001). Columns 9–11 list the polarization angle (P), disk continuous flux contribution relative to the total flux in the K-band (), and the stellar radius (R). The polarization angle, P was taken from Yudin (2001). R and were also derived from the SED by fitting a Kurucz (1979) model as is explained in Sect. 3.2.

thumbnail Fig. 3

Brγ line profile of Be stars observed with VLTI/AMBER instrument during our observing campaign.

Open with DEXTER
thumbnail Fig. 4

Histogram showing the distribution of the star sample as a function of the spectral subtype and luminosity class.

Open with DEXTER

4.2 Disk parameters and properties

For the 18 stars that show the Brγ emission line, Figs. 1 and A.1A.17 present the (u, v) plane coverages, differential visibilities, differential phases and closure phases as a function of wavelength, together with the best-fitting model. Differential visibilities, differential phases and closure phases from our observations are plotted in blue, and the best-fitting kinematic model is overplotted in red.

In almost all cases, the data show a drop of visibility in the emission line caused by variations in either the disk extension or the relative flux between the line and the continuum (Meilland et al. 2007b). In these cases, the visibility drop is “W” shaped and the differential phase is “S” (or more complex) shaped. Both characteristics bring out a rotating equatorial disk (Meilland et al. 2011).

For the stars with the Brγ line in absorption, Fig. 5 shows, as an example, the differential visibility, differential phase, and the closure phase as a function of wavelength for the unresolved disk of HD 23408.

The upper rows of Table 3 summarize the parameters of the best-fitting model obtained from our axisymmetric kinematic model for each starwith the Brγ line in emission. Column 1 gives the HD number of each star; Cols. 2 and 3 list global parameters of the disk (inclination angle i and the position angle PA); Cols. 4 and 5 give the kinematical parameters of the disk (Vrot and j); Cols. 6 and7 provide values for the major axis of the disk in the continuum (ac) and in the line (al), respectively; Cols. 8 and 9 give Brγ EW and V/R ratio; and Col. 10 lists the reduced χ2 of the fit.

To derive ac we modeled the differential visibility normalized to the continuum, and the uncertainties (see Table 3) were obtained following the procedure described in Sect. 3. In some cases, the uncertainties are not listed because the ac values were not properly constrained. Therefore, only a rough value (marked with * in Table 3) is given, which corresponds to the parameter obtained from a fitting model that minimizes the χ2 value. Despite the large uncertainty on the parameter ac, the parameters of the disk at the line frequency are still quite accurate, since they are determined independently of the ac values (i.e., using the drop of visibility in the line).

thumbnail Fig. 5

Differential visibility, differential phase and closure phase corresponding to the interferometric observations of HD 23408, with the Brγ line in absorption.

Open with DEXTER
Table 3

Best-fitting parameters, with their respective errors, obtained from our axisymmetric kinematic model.

4.3 Comments on individual objects

– HD 23630 (η Tau) is a Be star of spectral type B7 III that belongs to the Pleiades cluster. It exhibits a Hα line profile without significant changes on long timescales (Tycner et al. 2005). Using interferometric observations and a Gaussian fit for the Hα emission, Tycner et al. (2005) found an angular diameter of 2.08 ± 0.18 mas for the major axis of an elliptical Gaussian model. Grundstrom & Gies (2006) obtained, using Tycner et al. (2005) data, an inclination angle i = 44°, and an interferometric ratio between the disk radius in the continuum Rd and the stellar radius R of RdR = 2.9 ± 0.3, while the disk extension is 5.4 ± 0.7 derived from the Hα line EW.

Silaj et al. (2010) fitted the observed Hα double-peaked emission line using a central star of B8 spectral type and a power-law mass density distribution for the disk, n = 3.5. These authors also derived the following parameters: inclination angle i = 20° and base density at the stellar equator ρ0 = 10−11 g cm−3.

Touhami et al. (2013) made a K-band continuum survey using the CHARA Array long-baseline interferometer and found that the circumstellar disk of η Tau was unresolved.

For this object we performed three interferometric measurements with very high S/Ns using the VLTI/AMBER interferometer (see Fig. 1). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 110°, i = 53°, Vrot = 270 km s−1, j = −0.45, ac = 1.3D, and al = 7D. We noted that although the baselines were not oriented along the measured PA, the differential phase lose the “S” shape for those baselines that fully resolved the disk. The derived inclination from the interferometric data is in agreement with the expected shape for the Brγ double-peaked line profile (shown in Fig. 3) that suggests a disk seen at intermediate inclination angle.

– HD 23862 (28 Tau) is a Be star of spectral type B8 V, member of the Pleiades cluster. It is a single-lined spectroscopic binary with a low-mass companion (Nemravová et al. 2010). It has an orbital period of 218 days, a semi-amplitude of 5.9 km s−1, and a large orbital eccentricity e = 0.60 (Katahira et al. 1996a,b). The orbital solution proposed by Nemravová et al. (2010) has a semimajor axis between 223.5 R and 225.5 R, and a periastron separation between 53.0 R and 53.4 R, depending on the orbital inclination of the system.

The star underwent several B, Be, and Be shell transition phases with a period of 34 yr (Sadakane et al. 2005). From the analysis of the long-term polarimetric observations, Hirata (2007) interpreted the variation of the polarization angle in terms of the precession of the disk caused by the companion.

The star disk was marginally resolved with the CHARA array. Touhami et al. (2013) derived a disk-to-star radius ratio of 1.879, adopting a PA = 159° and axial ratio r = 0.438. Fitting the Hα line profile, Silaj et al. (2014) obtained a model with an inclination angle i = 76°, a disk base density of 6.2 × 10−12 g cm−3, and a power-law index of 2.5.

For thisobject we obtained two interferometric measurements with a good S/N (see Fig. A.1). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 333°, i = 85°, Vrot = 410 km s−1, j = −0.47, ac = 4D, and al = 11D. The Brγ line profile exhibits a double-peaked emission with a shell absorption line at its center (Fig. 3), typically seen in Be stars at a high inclination angle.

– HD 28497 (228 Eri) is a Be star of spectral type B2. This star has shown variable emission and shell episodes. Andrillat et al. (1990) derived a size for the Hα region between 1.79 and 4.79 stellar radii. Silaj et al. (2010) fitted the Hα double-peaked emission using as a best-fitting model a central star with spectral type B0 and the following disk parameters i = 45°, ρ0 = 10−10 g cm−3, and n = 4, while Vieira et al. (2017) obtained log ρ0 = −10.7 ± 0.3, and n = 3.4 ± 0.1 from the IR continuum radiation.

We obtained one interferometric measurement with a high S/N (see Fig. A.2). The “W” and “S” shapes fromthe differential visibility and differential phases were very asymmetrical, being the amplitude smaller in the red than the blue part of the spectrum. Both features were impossible to fit with a simple model. The Brγ line was also clearly asymmetrical, with a VR ~ 1.29 (see Fig. 3). To improve the fit of our data we considered a disk model with one-arm over-density, like the one developed by Okazaki (1997). We considered an antisymmetric spiral-like intensity distribution similar to the one given by Stee et al. (2013, in their Eq. (5)). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 30°, i = 44°, Vrot = 600 km s−1, j = −0.35, ac = 6.0 D, and al = 11 D. The arm was oriented with an angle ϕ = 50° from the major axis of the envelope.

– HD 30076 (56 Eri) is a B2 V Be star. Andrillat et al. (1990) derived a size for the Hα region between 1.37 and 6.0 stellar radii. Silaj et al. (2010) fitted the Hα double-peaked emission line using a central star of spectral type B2 and disk parameters with i = 20°, ρ0 = 5 × 10−10 g cm−3, and n = 3.5. From a statistical study, Jones et al. (2011) found that this star is variable with a confidence level of 95%.

We performed one interferometric measurement (see Fig. A.3). The disk parameters for the best-fitting model are: PA = 73°, i = 38°, Vrot = 400 km s−1, j = −0.45, ac = 6.0D, and al = 10D. The position angle of the B1 baseline (PA1 = 65.4°) was oriented close to the measured PA of the disk, thus the “W” and “S” shaped features in the visibility drop and differential phase were clearly present. The observed double-peaked Brγ line profile (Fig. 3) is consistent with the line-of-sight inclination angle obtained from the interferometric model.

– HD 32991 (105 Tau) is an early-type Be shell star (B2 V). The star exhibits photometric variability as γ Cas type variables (Lefèvre et al. 2009). The best-fitting model parameters derived by Silaj et al. (2010) from the Hα emission line are: a central B2 type starplus a disk with i = 20°, ρ0 = 5 × 10−10 g cm−3, and n = 3.5. This object has not previous disk size determinations.

We obtained one interferometric measurement (see Fig. A.4). The best-fitting model provides the following set of disk parameters: PA = 157°, i = 40°, Vrot = 500 km s−1, j = −0.5, ac = 2.0 D, and al = 13 D. As the observed baseline B2 (with PA = −18.7°), oriented along the major axis of the disk, was the shortest one, the “W” and “S” shaped features in differential visibility and differential phase are very weak. The Brγ line single-peaked profile (Fig. 3) is consistent with the small inclination angle obtained using our interferometric model.

– HD 35439 (ψ01 Ori) is a variable star of spectral type B1 V, passing from Be → B → Be phases. Andrillat et al. (1990) derived a size for the Hα region of between 1.31 and 3.66 stellar radii. Silaj et al. (2010) fitted a double-peaked Hα line profile using a B0-type central star with the following disk parameters i = 45°, ρ0 = 5 × 10−11 g cm−3, and n =3.5. The value of ρ0 is greater than the one derived by Vieira et al. (2017) from the WISE SED (log ρ0 = −11 and n = 3.4). On the other hand, Arcos et al. (2017) found two different set of parameters: i = 50°, ρ0 = 2.5 × 10−11 g cm−3, n = 2.5 by modeling observations of the Hα line taken in 2012 and i = 50°, ρ0 = 5 × 10−12 g cm−3, and n = 2 from data taken in 2015.

We performed one interferometric measurement (see Fig. A.5). The best-fitting disk model parameters are: PA = 45°, i = 55°, Vrot = 397 km s−1, j = −0.5, ac = 1.75 D, and al = 4.5 D. The B3 baseline had an orientation close to the PA of the major axis of the disk, therefore pronounced “W” and “S” shaped features were observed in the differential visibility and differential phase. The double-peaked Brγ line profile shown in Fig. 3 is consistent with the shape expected from a disk with inclination angle derived from the interferometric model.

– HD 36576 (120 Tau) is a B2 IV-V Be star. This star presents multiperiodicity consistent with multimodal nonradial pulsations (Bossi et al. 1989). The size of the Hα line forming region was estimated to be between 1.28 and 3.59 stellar radii by Andrillat et al. (1990). Silaj et al. (2010) modeled the single-peaked Hα line emission using a power-law density distribution for a central B2 type star plus a disk with parameters: i = 45°, ρ0 = 5 × 10−10 g cm−3, and n = 3.5. However, from the SED model, Vieira et al. (2017) obtained log ρ0 = −11.4, and n = 2.36.

We performed one measurement using the VLTI/AMBER interferometer (see Fig. A.6). The best-fitting model for the disk provides the following geometrical and kinematical parameters: PA = 198°, i = 60°, Vrot = 380 km s−1, j = −0.4, ac = 2.0 D, and al = 13.0 D. Although the baselines were not oriented close to the measured PA of the disk, the “W” shape in differential visibility and “S” shape in the differential phase are clearly seen in the largest baseline. The double peaked Brγ line profile is consistent with the shape expected from a disk with an intermediate angle orientation.

– HD 37202 (ζ Tau) is one of the most observed Be stars. It has a spectral type B1 IV. It has been known as a spectroscopic binary for decades. Harmanec (1984) derived an orbital period of 132.9735 days and an eccentricity e ≈ 0.15.

Complex variations in the Hα shell spectrum and long-term V/R variations were observed (Ballereau et al. 1987; Tycner et al. 2005). As the star is close enough (d = 136 ± 16 pc, van Leeuwen 2007), the circumstellar disk can be resolved with the actual instruments, and spectro-interferometry extends this resolution to the disk dynamics. The limb-darkened photospheric diameter was estimated at 0.4 mas (Tycner et al. 2004; Gies et al. 2007), and this corresponds to a radius of 5.5–6 R at the HIPPARCOS distance.

Using interferometric observations and fitting Gaussians from the Hα emission disks, Tycner et al. (2005) found a value for the major axis of 3.14 ± 0.21 mas. Based on Tycner et al. (2005) data, Grundstrom & Gies (2006) derived an inclination angle i = 75°, and interferometric radius of RdR = 7.3 ± 0.5, while from the Hα line EW they calculated a disk extension of RdR = 8.7 ± 1.5. Touhami et al. (2011) presented an analysis of K-band observations of the continuum emission from the circumstellar gas disk obtained with CHARA Array. Using a radiative transfer code for a parameterized version of the viscous decretion disk model they derived the following parameters: ρ0 = 1.4 × 10−10 g cm−3, n = 2.9, i = 87°, and disk temperature Td = 2∕3 Teff.

Gies et al. (2007), using CHARA in the K-band, measured the semi-major axis of the disk to 1.79 mas or 4.5 R. This value is lower than the estimated Roche-lobe radius for the primary star of the system, which Tycner et al. (2004) computed as 144 ± 12 R (5.3 mas), at a binary separation of 254 ± 20 R (9.2 mas). Considering this separation between both components the secondary star would be out of the circumstellar disk, in agreement with other models (Castle 1977). Štefl et al. (2009) studied three V/R cycles between 1997 and 2008. They found that after each minimum inV/R, the shell absorption weakens and splits into two components, leading to three emission peaks. Also, the phasing of the Brγ emission showed that the photocenter of the line-emitting region lied within the plane of the disk but was offset from the continuum source. The plane of the disk remained stable throughout the observed V/R cycles. Schaefer et al. (2010) resolved the circumstellar disk between 2007 and 2009 with the MIRC beam combiner at the CHARA array. They fit a nearly edge-on disk, with a FWHM major axis ~1.8 mas at the H-band. In addition, they found a correlation between the position angle of the disk and the spectroscopic V/R ratio, suggesting that the disk is precessing.

For this object, we obtained three interferometric measurements, two with a quite high S/N and one with a lower S/N (see Fig. A.7). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 127°, i = 67°, Vrot = 400 km s−1, j = −0.45, ac = 4.7 D, and al = 4.8 D. The line profile is typical for a Be star seen at high inclination angle (double-peaked with a shell absorption line at its center), in agreement with its Be shell classification. For the observations with good S/N, the “W” shape in the drop of the differential visibility and “S” shape of the differential phase are clear.

– HD 37490 (ω Ori) is a classical B3 V emission line star, which has been studied over many years. It presents short (1 day) and mid-term (11 months) photometric variability (Balona et al. 1987, 1992; Bergin et al. 1989). These variations were associated to nonradial pulsations, and the increase or decrease of the disk size. Andrillat et al. (1990) estimated a size for the Hα region of between 1.07 and 2.27 stellar radii. Neiner et al. (2002) determined the stellar parameters employing two methods: astrophysical formulae and the Barbier-Chalonge-Divan (BCD) spectrophotometric system. With the stellar parameters derived from the BCD system, logTeff = 4.306 ± 0.016 and logg = 3.48 ± 0.03, they determined Ω = 0.83Ωc, i = 32 ± 15°, R = 6.84 ± 0.25R, and M = 8.02 ± 0.25M using evolutionary tracks from Schaller et al. (1992).

Balona et al. (2002) found a V sin i = 173 ± 2 km s−1 from nonemission helium lines, and V sin i = 226 ± 7 km s−1 from the metal lines. They suggested that even the helium lines with weak emission are likely contaminated by the emission from the gas disk. Neiner et al. (2003) found evidence for the presence of a weak magnetic field, sinusoidally varying with a period of 1.29 days. However, new observations were unable to confirm the presence of this magnetic field (Neiner et al. 2012). Silaj et al. (2010) fitted the double-peaked Hα emission line using a central star of spectral type B2, i = 20°, ρ0 = 10−11 g cm−3, and n = 3.5. van Belle (2012) suggested that this object is a possible target for interferometric observations, with an estimated angular size of 0.5 mas and flattening RbRa − 1 = 0.13.

For this star we obtained one interferometric measurement (see Fig. A.8) and derived the following parameters for the disk: PA = 305°, i = 49°, Vrot = 308 km s−1, j = −0.5, ac = 1.0 D, and al = 2.5 D. The shape of the double-peaked line profile indicates that the object is seen from an intermediate inclination angle, consistent with the value we derived and a more precise determination of i = 42 ± 7° obtained by Neiner et al. (2003).

– HD 41335 (V696 Mon) is an interacting binary system (Peters 1972). Peters (1983) measured the radial velocity andobtained an orbital period of 80.86 days. The system consists of a primary star B1.5IV-V of 8− 11 M and a secondary of 1 M. They measured a separation between the components of 0.84 UA (~180 R). Studying the system SED, Waters et al. (1991) showed that the companion could be a hot subdwarf (Sd) star but not a cool giant star. Based on UV and Hα observations, Peters et al. (2016) was able to detect the weak signal of the spectral lines corresponding to a hot Sd star, and proposed a primary star with 9 M and a secondary with 0.7 M. They proposed that this Sb star creates a one-armed spiral feature, a tidal wake in the disk of the Be star (Thaller et al. 1995, named Be+SdO binary system or ϕ Per type). Andrillat et al. (1990) derived a size for the Hα circumstellar envelope of between 1.66 and 3.43 stellar radii. From the SED, Vieira et al. (2017) obtained log ρ0 = −10.3 ± 0.3, and n =3.0 ± 0.1. Furthermore, Arcos et al. (2017) derived ρ0 = 5 × 10−12 g cm−3, n =2.0, and i = 80°.

We performed one interferometric measurement for this object (Fig. A.9). The best-fitting model provides the following geometrical and kinematical parameters of the disk: PA = 55°, i = 68.5°, Vrot = 400 km s−1, j = −0.6, ac = 2.0 D, and al = 5.0 D. The double-peaked line profile, the drop of the differential visibility and phase variations present small asymmetries. The largest baselines (B1 and B3) were oriented with an angle close to the disk PA. Therefore, the “W” shape in the drop of differential visibility and the “S” shape of the differential phase are clear. The double-peaked line profile is consistent with the line shape seen at an intermediate inclination angle. Although Peters et al. (2016) proposed the presence of a one-armed spiral structure, we have not needed to consider an overdensity to fit our data.

– HD 45725 (β01 Mon) is a Be-shell star of spectral type B4 V. This object has been catalogued as a triple star by Struve (1925). Abt & Cardona (1984) measured separations of 7.1′′, 2.8′′, and 25.9′′ between the system components. Assuming that these separations were the semimajor axis of the orbits, they estimated periods of 10 000, 2600, and 100 000 yr, respectively. Oudmaijer & Parr (2010) catalogued the system as a binary and fit bidimensional Gaussians to the spatial profiles, finding a separation between the components of 7.14 arcsec and a position angle of 133°. Andrillat et al. (1990) derived a size for the Hα region of between 1.86 and 3.64 stellar radii.

van Belle (2012) suggested that HD 45725 is a good candidate for interferometric observations, with estimations for the projected rotational velocity of V sin i = 325 km s−1, an angular size of 0.70 mas, and a flattening of RbRa − 1 = 0.17. Arcos et al. (2017) obtained the following disk parameters ρ0 = 5 × 10−12 g cm−3, n = 2, and i = 70°.

We obtained two interferometric measurements, one with a relatively high S/N and the other with a low value (see Fig. A.10). The best-fitting disk model provides the following geometrical and kinematical parameters: PA = 101°, i = 72°, Vrot = 440 km s−1, j = −0.5, ac = 1.2 D, and al = 12.0 D. We note that the Brγ line does not present the shell absorption profile expected for our high value of the inclination angle. The baselines B1 and B4 were very similar and were oriented close to the PA. The baselines B2 and B6 had almost the same orientation, but different lengths, and therefore the shape of the differential visibility and differential phase are more evident in the B6 base.

– HD 60606 (OW Pup) is a B2V Be star. Lefèvre et al. (2009) catalogued this object as a γ Cas-type variable. The SED was modeled by Vieira et al. (2017) who derived log ρ0 = −11.7 ± 0.1, and n =2.5 ± 0.1, while from the Hα line Arcos et al. (2017) obtained the following disk parameters: ρ0 = 1 × 10−10 g cm−3, n = 3, and i = 70°. There are no disk size determinations available for this object.

Based on one interferometric measurement (Fig. A.11), the best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 240°, i = 70°, Vrot = 390 km s−1, j = −0.5, ac = 2.0 D, and al = 7.5 D. The longest baseline was also the closest to the modeled PA, and therefore the “W” shape of the differential visibility and the “S” shape of the differential phase are well defined.

– HD 66194 (V374 Car) is a Be star of spectral type B3V and is a member of the open cluster NGC 2516. It has been identified as a blue straggler star by Ahumada & Lapasset (2007). González & Lapasset (2000) reported some variability in the measured radial velocities and suggested that this object could be a spectroscopic binary with mass transfer in a close system. The star exhibits photometric variability as γ Cas-type variables (Lefèvre et al. 2009). This object has not previous disk size determinations.

We performed two interferometric observations with a low S/N (Fig. A.12). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 220°, i = 55°, Vrot = 350 km s−1, j = −0.4, ac = 3.0 D, and al = 9.0 D. Both observations were carried out with a very similar instrumental configuration. Therefore, none of them show clear signs of either a drop in the differential visibilities or the typical “S” shape in the differential phase. The Brγ line profile is consistent with the intermediate inclination angle obtained from our interferometric model (see Fig. 3).

– HD 68980 (MX Pup) is a spectroscopic binary of spectral type B1.5 IVe (Slettebak 1982) with a period of 5.1526 days and a very excentric orbit (Carrier et al. 2002). Its light curve also shows long-term variability with a time scale of about 9 yr accompanied by V/R variations (Hanuschik et al. 1995; Mennickent et al. 1997). Silaj et al. (2010) used a simple power-law model to fit the one-peaked emission Hα line profile, using a central star of B2 spectral type with the following disk parameters: i = 20°, ρ0 = 2 × 10−10 g cm−3, and n = 3.5. Arcos et al. (2017) obtained two set of independent parameters for the disk, ρ0 = 5 × 10−12 g cm−3, n = 2, and i = 50° using observations taken in 2013, and ρ0 = 2.5 × 10−11, n =2.5, and i = 50° with data acquired in 2015. Whilst Vieira et al. (2017) derived from the SED a log ρ0 = −11.5, and n =2.8. There are no disk size determinations available for this object.

We obtained one interferometric measurement (Fig. A.13). The best-fitting model provides the following geometrical and kinematical parameters for the disk: PA = 310°, i = 22°, Vrot = 410 km s−1, j = −0.5, ac = 1.5 D, and al = 3.0 D. The longest B3 baseline was oriented almost perpendicular to the PA of the disk. The differential visibility has a “V” shape and the differential phase has a small amplitude “S” shape. The Brγ line profile is in emission with a small asymmetry (see Fig. 3). Its shape is consistent with a line profile seen at the small inclination angle found.

– HD 209409 (o Aqr) is a rapidly rotating Be shell star classified as a B7 IV. The star has a stable Hα emission and does not show V/R variations (Rivinius et al. 2006). The star has been fully resolved by interferometry in many studies. Touhami et al. (2013) derived a disk-to-star radius ratio RdRs = 5.776, and PA = 107.5°, while Cyr et al. (2015) found an axis ratioof 0.25 in the K-band. Sigut et al. (2015) combined Hα and interferometric data covering a period of 7 yr and concluded that all the observations were consistent with a circumstellar disk seen at an inclination of 75° and PA = 110° with ρ0 = 6.6 × 10−11 g cm−3, and n = 2.7. Meilland et al. (2012) obtained the following parameters for the disk: PA = 120°, i = 70°, Vrot = 400 km s−1, j = −0.5, ac < 10 D, and al = 14 D. Alternatively, Yudin (2001) found PA = 177° for the observed polarization. From line profile fittings, Silaj et al. (2010) modeled the double-peaked Hα line profile with a central B8 type star and disk parameters with i = 45°, ρ0 = 5 × 10−11 g cm−3, and n = 3.5, while Arcos et al. (2017) obtained a lower base density and index power (ρ0 = 5 × 10−10 g cm−3, and n = 2.0), and two different inclinations: i = 25° (in 2013), and i = 50° (in 2015).

For this target we obtained seven interferometric measurements with high S/Ns (Fig. A.14). From the best-fitting disk model we derived: PA = 290°, i = 70°, Vrot = 355 km s−1, j = −0.45, ac = 3.0 D, and al = 8.0 D. The baselines B1, B4, and B7 were oriented close to the PA of the disk, and therefore the “W” shape of the drop of the differential visibility and the “S” shape of the differential phase are well defined. The B11 baseline wasone of the largest and was oriented almost perpendicularly to the measured PA, so the drop of the differential visibility has a “V” shaped structure and the “S” shaped feature of the differential phase has a small amplitude. The double-peaked Brγ line profile, the “W” shaped feature in the drop of the differential visibility and the “S” shaped feature of the differential phase are quasi-symmetric. This indicates that the object is seen from a high inclination angle and it does not present major inhomogeneity in the disk.

– HD 212076 (31 Peg) is a Be star with a spectral type B2 IV-V. The star disk was marginally resolved with the CHARA array. To derive a disk-to-star radius ratio of 1.852, Touhami et al. (2013) should adopt a PA = 148° and axial ratio r = 0.955. Silaj et al. (2010) fitted the Hα emission line assuming a circumstellar disk surrounding a B2 type-star with i = 20°, ρ0 = 10−11 g cm−3, and n = 2.5. These disk parameters differ from those found by Arcos et al. (2017, n = 2, i = 30°, ρ0 = 2.5 × 10−11 g cm−3 in 2012, and ρ0 = 2.5  × 10−12 g cm−3 in 2015) andby Vieira et al. (2017, log ρ0 = −11.7, and n = 2.13.).

We obtained five interferometric observations, three with high S/N and two with low S/Ns. The best-fitting model corresponds to an equatorial disk with PA = 202°, i = 22°, Vrot = 400 km s−1, j = −0.5, ac = 3.0 D, and al = 4.0 D. The shapes of “W” in the visibility drop and “S” in the differential phase are seen in a few baselines (generally the largest), as shown in Fig. A.15.

– HD 212571 (π Aqr) is a Be star of spectral type B1 III-IV. From the analysis of the Hα line profile, Bjorkman et al. (2002) suggested that HD 212571 may be a binary system with an orbital period of 84.1 days, consisting of stars with masses of M1 sin3 i = 12.4 M, and M2 sin3 i = 2.0 M. They also suggested that photometric, spectroscopic, and polarimetric variations observed during the second half of the twentieth century might be due to variable mass transfer between the binary components. Wisniewski et al. (2010) found that the timescale of disk-loss events corresponds to almost 29 complete orbits of the binary companion. They also found that the position angle of the intrinsic polarization is P = 166.7°, indicating that the disk is oriented on the sky at a position angle of PA = 76.7°.

Silaj et al. (2010) modeled the Hα double-peaked emission line using a B0-type central star and an equatorial disk with ρ0 = 10−11 g cm−3, and n = 3.5, seen with an inclination angle i = 45°. Arcos et al. (2017) derived three different sets of parameters, using spectra taken at different epochs: ρ0 = 2.5 × 10−11 g cm−3, i = 60°, and n = 2.5 for the epochs 2012 and 2015, and ρ0 = 7.5 × 10−12 g cm−3, i = 60°, and n = 2.5 for 2013, while Vieira et al. (2017) obtained log ρ0 = −12.1 and n = 3.5 from the SED. The disk size has not been determined for this object.

We performed two interferometric measurements with good S/N (Fig. A.16) and derived the following geometrical and kinematical parameters for the disk: PA = 87°, i = 34°, Vrot = 440 km s−1, j = −0.5, ac = 1.5 D, and al = 2.0 D. The “W” shape in the drop of the differential visibility is barely perceptible in the B3 and B4 baselines. The “S” shape of the differential phase is present only in a few baselines. The double-peaked Brγ line profile is very weak, as shown in Fig. 3.

– HD 214748 (ϵ PsA) is a fast-rotating B-type star with a stellar classification B8 Ve. Arcos et al. (2017) modeled the Hα line emission using a power-law density distribution with ρ0 = 2.5 × 10−10 g cm−3, n =3.5, and i = 50°. This disk base density is higher than the one calculated by Vieira et al. (2017; log ρ0 = −11.9, and n =2.7) based on a pseudo-photosphere model for the disk continuum emission.

We performed five interferometric measurements with a high S/N (see Fig. A.17). The best-fitting model provides the following geometrical and kinematical parameters for the equatorial disk: PA = 67°, i = 73°, Vrot = 244 km s−1, j = −0.46, ac = 2.0 D, and al = 3.9 D. The B10 baseline was oriented close to the observed PAof the disk. The Brγ line is in emission and exhibits a strong asymmetry (see Fig. 3).

4.4 Polarization angle

The polarization position angle in an optically thin axisymmetric disk is usually perpendicular to the plane of the disk since it mainly comes from electron scattering (Brown & McLean 1977). However, Delaa et al. (2011) reported that for 48 Per the major axis is oriented parallel to the polarization angle, and proposed that this might be due to the disk optical thickness. In almost all cases the disk major axes of our star sample seem to be roughly perpendicular to the polarization measurement, as shown in Fig. 6. Exceptions are HD 32991, and HD 212076. Both objects have small inclination angles that make the determination of the interferometric position angles more uncertain, especially when the observations have a bad S/N, as in HD 32991, or reveal the presence of a small disk, like in HD 212076.

For HD 23862, the PA is almost perpendicular to the polarization angle measured by Yudin (2001), but different from previous reported values. This difference could be explained by disk precession caused by a companion (Hirata 2007).

thumbnail Fig. 6

Position angle of the disk PA vs. polarization angle P. The solid black line corresponds to the case where PA is perpendicular to the polarization measurement (PA = P ± 90). The solid red line corresponds to the situation when PA is parallel to the polarization measurement (PA = P ± 180). The dotted lines correspond to an uncertainty of 15°.

Open with DEXTER

4.5 Global properties

In most cases, our simple kinematic model reproduced our measurements. However, in one case (HD 28497) we needed to add a “one-armed”over-density structure to improve the fit process of our data. The disk kinematics is dominated by rotation, with a law close to a Keplerian rotation in almost all targets. The largest discrepancies are found in HD 36576 (j = −0.4), HD 41335 (j = −0.4), HD 66194 (j = −0.6), and HD 28497 (j = −0.35). The last one corresponds to the object with the “one-armed” over-density.

Using the V sin i and Vc values taken from the literature and our own i values, we obtained the VVc ratios presented in Table 4. We found a mean ratio of .

The rotational rate is defined in Frémat et al. (2005) by the ratio of the stellar angular velocity to its critical one, , where Reqc and Req are the equatorial radii (in polar radii) for stars rotating at Vc and V, respectively. Values of Ω∕Ωc are listed inTable 4. The mean rotational rate from our sample of Be stars is Ω∕Ωc = 0.86 ± 0.04.

Table 4

VVc ratio and rotational rate Ω∕Ωc of our Be stars.

4.6 Statistical analysis of the combined sample

With the aim of studying a larger and more representative sample of Be stars and gaining a better understanding of the physical properties and origin of the circumstellar envelopes, we combine our results with those obtained by Meilland et al. (2012). The star HD 209409 was excluded from the Meilland et al. (2012) sample, and disk parameters were derived from our new observation, which has a higher S/N, improving the model fitting. The disk parameters obtained by Meilland et al. (2012) are listed in the lower rows of Table 3. Therefore, the combined star sample contains 25 Be stars, with spectral types between B1 and B8, and luminosity classes between V and III, distributed according to the histogram displayed in Fig. 7.

To search for the optimal bin number and bin size in each histogram, we adopted a bin-width optimization method that minimizes the integrated squared error (Shimazaki & Shinomoto 2007).

The distribution of the disk extension in the line per spectral type and luminosity class is presented in Fig. 8. This distribution is bimodal, with maxima at 3.6−5.1 D and 9.9−11.4 D. About a third of the star sample shows small disks, with al between 2 and 5.1 D. The largest measured for the disk size is 13 D. Stars with luminosity class V present disks with different sizes, whilst stars with luminosity class III only present disks smaller than 8.3 D.

In Fig. 9 we present the distribution of the observed inclination per spectraltype and luminosity class. The distribution presents a peak at the interval 67–76°. A few late B-type stars were observed near equator-on (5%). Stars seen at small angles (lower than 40°) are mostly of spectral type B1-B2, and all luminosity classes are seen. For intermediate values, the distribution is almost uniform for the different spectral types. Our sample does not have stars of luminosity class III seen at high inclination angles.

In Fig. 10 we present the distribution of the rotational velocity at the disk inner radius (Vrot) per spectraltype and luminosity class. This distribution has a peak in the bin 397−447 km s−1. The peak contains stars of all spectral types and luminosity classes. Early spectral-type stars have disks with high rotational velocities, whilst late B-type stars show disks with low rotational velocities. As regards the luminosity class, all stars exhibit more or less the same distribution, with a maximum at Vrot ~ 400 km s−1. Only one star (HD 28497) has an extremely high value of Vrot, that reaches ~ 600 km s−1.

The distribution of VVc ratio per spectral type and luminosity class is presented in the Fig. 11. Between 0.62 and 0.81, the distribution is almost constant and includes~80% of the sample. The ~20% left is distributed between 0.81 and 0.99. We do not see any correlation with the spectral type or the luminosity class. In Fig. 12 we present the distribution of Ω∕Ωc, which showsvalues between 0.82 and 0.99. The distribution is similar for stars with different spectral types and luminosity classes.

Although, there is no clear correlation between the disk extension in the line and Vrot, we observe that disk extensions larger than 10 D are only present when Vrot > 400 km s−1. This outcome is discussed in a broader context in Sect. 5.

Using the obtained values for R and Vc, we estimated the stellar masses from the expression , where G is the gravitational constant. At first glance, no correlation was found between the stellar mass and the disk size.

thumbnail Fig. 7

Distribution of Be stars per spectral type and luminosity class for the combined sample.

Open with DEXTER
thumbnail Fig. 8

Distribution of the disk extension in the line per spectral type and luminosity class for the combined sample.

Open with DEXTER
thumbnail Fig. 9

Distribution of inclinations along the line-of-sight per spectral type and luminosity class for the combined sample.

Open with DEXTER
thumbnail Fig. 10

Distribution of Vrot per spectral type and luminosity class for the combined sample.

Open with DEXTER
thumbnail Fig. 11

Distribution of VVc per spectral type and luminosity class for the combined sample.

Open with DEXTER
thumbnail Fig. 12

Distribution of Ω∕Ωc per spectral type and luminosity class for the combined sample.

Open with DEXTER

5 Discussion

5.1 Rotational rate

Consideringthe combined sample, we found a mean ratio and a mean rotational rate . These values agree with the ones determined by Frémat et al. (2005) from a sample of 130 stars, that is, and , and by Zorec et al. (2016, ). However, when this ratio is corrected by the effects of gravitational darkening, macroturbulence, and binarity, its value drops to , according to Zorec et al. (2016). As our sample contains seven binary stars, our value, which is not corrected for the mentioned effects, should be an upper limit. On the bases of this result, we conclude that the Be stars of our sample, on average, do not rotate at their critical velocity.

Cranmer (2005) proposed that the rotational rates have different limits depending on the effective temperature. To test his hypothesis, we plotted the values of the rotational rates against Teff (see Fig. 13) but found no relationship.

thumbnail Fig. 13

Distributions of VVc and Ω∕Ωc with the effective temperature. There is a lack of correlation.

Open with DEXTER

5.2 Stellar rotation axes

To see if therotational axes are randomly distributed, we compared the distribution of projected angles from our data with a theoretical distribution (see, e.g., Curé et al. 2014).

Let us define the 3D vector v, and s = sin i, the projection of v to the plane normal to the line of sight, with i being the angle between v and the line of sight. If we assume that v is uniformlydistributed over the sphere, then the probability distribution function (PDF) verifies that (Curé et al. 2014).

In Fig. 14 we present, in black solid line, the kernel density estimation (KDE) of the observed sin i values and the theoretical PDF f(s). Furthermore, we performed a Bootstrap study, generating 2000 random samples of our sin i values, each with a sample length of 25 data. The resulting confidence interval using the 0.025 and 0.975 quantiles is also plotted in the figure (shaded gray region), showing that the theoretical PDF lies almost entirely inside the confidence interval. In view of this finding, we performed Kolmorogov-Smirnov and Anderson-Darling tests to verify if the observed data are distributed according to the expected PDF − f(s). We obtained a p-value of 0.0686 and 0.0997, respectively. Both tests do not reject the null hypotesis, meaning that the sample might come from a random orientation of stellar rotational axes, but in view of the small p-values, a detailed study with a larger data sample is necessary to elucidate the underlying distribution.

thumbnail Fig. 14

PDF (solid black line) generated from our N = 25 data sample. It was calculated using a standard KDE algorithm with a Gaussian kernel and a Silverman’s bandwidth of 0.1029. The 95% confidence interval is shown in the shaded gray region and was calculated using the quantiles from 2000 bootstrap samples of length N = 25. The theoretical PDF f(s) function is shown as a dashed line.

Open with DEXTER

5.3 Correlation between al and Vrot

The disk size in the Brγ line ranges between 2 D and 13 D, and is independent of the effective temperature of the stars.

To discuss the origin of the circumstellar envelope and the role of the stellar rotation, we search for a relation between the disk extension in the Brγ line and Vrot. Figure 15 shows the whole sample of stars and highlights that there are no Be stars with low values for Vrot and large disk size. Furthermore, we observe that all the stars are located below the blue dashed line. This could mean that there is an upper limit for the disk size according to a given rotational velocity.

Considering the spectral variability of Be stars, we look for a criterion to determine which stars have stable disks. To this purpose, we compared the strength and spectral appearance of the Hα line for each star using observations published by Doazan et al. (1991), Silaj et al. (2010, 2014), Arcos et al. (2017, and in prep.). Thus, we differentiate the objects that present a stable intensity in the Hα line from objects that present variations. Based on the Hα criterion, the objects that we consider as stable are: HD 23630, HD 32991, HD 36576, HD 37795, HD 89080, HD 209409, and HD 214748. These objects are identified as “without variability” in Fig. 16, and the blue dashed line could state an upper limit for the disk size of these stars.

Another criterion was based on the results found by Vieira et al. (2017) who analyzed the evolution of the disks using the viscous decretion disk (VDD) model, and found that the timescale for disk growth is shorter than the timescale for disk dissipation. Also, they found a correlation between ρ0 and n values and determined distinct regions in the n −logρ0 plane. In this diagram, the n ≲3 region is associated with dissipating disks; the strip between n ≃ 3 and n ≃3.5 corresponds to the steady-state zone, and the region where n ≳ 3.5 is related to disks in formation. Based on this new criterion, Vieira et al. (2017) found that HD 23630, HD 28497, HD 35439, HD 41335, HD 50013, HD 89080, HD 91465, HD 105435 and HD 212571 have steady disks. In Fig. 16 these objects are identified as “3 ≤ n ≤ 3.5”. Some of these stars fall in the linear relationship found before, but others seem to outline a second linear regression, below the previous one. This second linear relationship is plotted with an orange dotted line and could be related with another stability condition for the disk extension for stars of a given spectral type or stellar mass.

Figure 17 presents our findings for disk size versus VrotVc. We observe that the stars with the largest disks present values of VrotVc ≳ 0.9, however no correlation with the stellar type was observed, as shown in Fig. 13.

Since it has often been observed that late-type Be stars are less variable than early-type ones (Hubert & Floquet 1998; Jones et al. 2011; Barnsley & Steele 2013; Labadie-Bartz et al. 2017), it would be possible that the relations for stable disks are connected to the mass of the star. Nevertheless, it is interesting to highlight that, for a given Vrot, the least massive B-type stars are close to the upper size limit while the most massive stars are near the lower limit, as is illustrated in Fig. 18. This result points out that Be stars with high stellar masses have denser and more compact disks than their low-mass counterparts. As the former are more luminous, compact and dense disks would be brighter in the Brγ line. This could explain why the peak of the Be phenomenon is around the B1-B3 spectral types. Evidence supporting a scenario where disks of early Be stars are more massive and smaller than those of late-Be types was previously reported by Arcos et al. (2017), who used a large sample of Hα observations.

Here, it is worth mentioning that HD 212571 is a binary star that is located below the orange linear regression, and, according to Vieira et al. (2017), has a steady disk. For this object, the timescale of the disk-loss events could be important, since the observationsused by Vieira et al. (2017) were performed from January to November 2010 and our interferometric observations were carriedout in October 2014. Arcos et al. (2017) observed the same object one year later, and found an n value that locates it in the dissipation region. Therefore, it is possible that the disk size we found does not correspond to the disk size on a steady phase.

thumbnail Fig. 15

Relation between Vrot and the disk extension in the Brγ line for the star sample of this work and those collected from Meilland et al. (2012). For a given Vrot, the blue dashed line could be an upper limit for the disk extension.

Open with DEXTER
thumbnail Fig. 16

Relation between Vrot and the diskextension in the line for the star sample (black dots) included in this work and Meilland et al. (2012). The colored linessymbols are given in the top left of the figure. The blue dashed line from Fig. 15 could state an upper limit for the disk size of the stars indicated as “without variability”. The orange dotted line seems to oultine a second linear regretion from stars with stable disks.

Open with DEXTER
thumbnail Fig. 17

Relation between VrotVc and the disk extension in the Brγ line for the combined sample. Stars with the largest sizes have Vrot close to its critical rotation velocity.

Open with DEXTER
thumbnail Fig. 18

Relation between Vrot and disk extension in the line for the star sample studied in this work and in Meilland et al. (2012). For a given Vrot, the blue dashed line traces the location of low-mass Be stars with stable disks and the orange dotted line identifies the location of high-mass Be stars with stable disks.

Open with DEXTER

5.4 Comparison of disk sizes in the Hα line and the Brγ line

Disk sizes observed in the Brγ line are systematically larger than those obtained from the K-band with the CHARA interferometer (Gies et al. 2007; Touhami et al. 2013). However, we do not find any clear correlation between the sizes of the disk in the Brγ and Hα lines. Using 48 northern Be stars, Catanzaro (2013) found that the radii of the disks measured in the Hα line have values between 2 R and 14 R, with a maximum concentration in the interval of 6–8 R. The values are similar to the disk size we measured in the Brγ line.

Measurements of disk size in Hα are available for thirteen of the stars in our sample (Hanuschik et al. 1988; Andrillat et al. 1990; Grundstrom & Gies 2006). The Brγ size measured from HD 23630 is larger than the Hα size obtained by Grundstrom & Gies (2006) but smaller than the one obtained by Hanuschik et al. (1988), even though this star has a stable Hα profile. For HD 37202, HD 158427, and HD 214748, the Brγ sizes are smaller than the ones measured in Hα, as was found in δ Sco by Meilland et al. (2011). For HD 37490, the Brγ and Hα (Andrillat et al. 1990; Hanuschik et al. 1988) lines lead to similar measurements for the disk size, contrary to HD 28497, HD 30076, HD 35439, HD 36576, HD 41335 and HD 45725, for which the Brγ line presents larger disk sizes than the ones obtained from Hα. It should be noted that all these objects have variable Hα profiles, possibly indicating that their disk sizes have increased.

Considering the variability of the Be stars, and the different methods used to derive the sizes of their circumstellar disks, it would be useful to perform simultaneous multiwavelength observations.

6 Conclusions

We analyzed a sample of 26 Be stars observed with the VLTI/AMBER instrument. We were able to obtain geometrical and kinematic disk parameters for 18 of these that present the Brγ line in emission, by fitting interferometric data with a 2D kinematic model for a rotating equatorial disk. For 5 stars of our sample the kinematical properties of the disks have been obtained for the first time.

Disk sizes measured in the Brγ line are similar to the ones obtained from the Hα line, and they range between 2 D and 13 D. We do not observe any correlation between disk size and Teff (or spectral type) of the central star. One third of the stars in our sample have sizes lower than 6 D and stars with luminosity class III tend to present the smallest disks. Nevertheless, using a combined sample of Be stars (our 18 Be star sample plus 7 stars studied by Meilland et al. 2012) we found an upper limit for the disk extension in the Brγ line that correlates with the rotational velocity in the inner part of the disk and the stellar mass. For a given Vrot, high-mass Be stars have more compact and dense disks than their low-mass counterparts. In almost all cases, the star disks rotate in Keplerian fashion, with the exception of HD 28497, which required a one-arm over-density model.

The distribution of stellar rotational velocities was found to be relatively symmetrical and has a maximum at Vrot ~ 365 km s−1. Stars with early spectral types tend to have high rotational velocities, whilst late B-type stars have low rotational velocities. We derived a mean ratio and a mean rotational rate , in agreement with those authors that propose that, on average, Be stars do not rotate at their critical velocity (Cranmer 2005; Frémat et al. 2005; Zorec et al. 2016). On the other hand, we did not observe any correlation between VVc values and spectral types, as was previously suggested by Cranmer (2005).

It is interesting to remark that the rotational axes seem to be uniformly distributed in the sky. However, this last result is not conclusive due to the low quantile value obtained. Therefore, more observations should be carried out to confirm this tendency.

It would be interesting to follow up the evolution of disk size in variable Be stars to better understand disk formation and dissipation processes of their circumstellar disks. To this aim simultaneous observations at different wavelengths are necessary. Furthermore, it would be interesting to improve radiative transfer models with various density laws in order to decipher whether or not the maximum disk size found (about 13 D) in the Brγ emission line has a physical meaning in terms of density and ionization structure of a “fully” built Be disk.

Acknowledgements

We would like to thank our anonymous referee for his/her valuable comments and suggestions, which helped to improve our manuscript. We thank M. L. Arias for her careful reading and comments. C.A. thanks becas de doctorado nacional de CONICYT 2016-2017. M.C. and C.A. acknowledge support from Centro de Astrofísica de Valparaíso. L.C. acknowledges financial support from CONICET (PIP 0177), the Agencia Nacional de Promoción Científica y Tecnológica (PICT 2016-1971) and the Programa de Incentivos (G11/137) of the Universidad Nacional de La Plata (UNLP), Argentina. L.C. and M.C. thank support from the project CONICYT + PAI/Atracción de capital humano avanzado del extranjero (folio PAI80160057).

Appendix A Additional figures

For each target, we present the (u, v) plan coverage, with the AMBER HR measurements. The best-fitting kinematics models are overplotted.

thumbnail Fig. A.1

As in Fig. 1, but for HD 23862.

Open with DEXTER
thumbnail Fig. A.2

As in Fig. 1, but for HD 28497.

Open with DEXTER
thumbnail Fig. A.3

As in Fig. 1, but for HD 30076.

Open with DEXTER
thumbnail Fig. A.4

As in Fig. 1, but for HD 32991.

Open with DEXTER
thumbnail Fig. A.5

As in Fig. 1, but for HD 35439.

Open with DEXTER
thumbnail Fig. A.6

As in Fig. 1, but for HD 36576.

Open with DEXTER
thumbnail Fig. A.7

As in Fig. 1, but for HD 37202.

Open with DEXTER
thumbnail Fig. A.8

As in Fig. 1, but for HD 37490.

Open with DEXTER
thumbnail Fig. A.9

As in Fig. 1, but for HD 41335.

Open with DEXTER
thumbnail Fig. A.10

Asin Fig. 1, but for HD 45725.

Open with DEXTER
thumbnail Fig. A.11

Asin Fig. 1, but for HD 60606.

Open with DEXTER
thumbnail Fig. A.12

Asin Fig. 1, but for HD 66194.

Open with DEXTER
thumbnail Fig. A.13

Asin Fig. 1, but for HD 68980.

Open with DEXTER
thumbnail Fig. A.14

Asin Fig. 1, but for HD 209409.

Open with DEXTER
thumbnail Fig. A.15

Asin Fig. 1, but for HD 212076.

Open with DEXTER
thumbnail Fig. A.16

Asin Fig. 1, but for HD 212571.

Open with DEXTER
thumbnail Fig. A.17

Asin Fig. 1, but for HD 214748.

Open with DEXTER

References

  1. Abt, H. A., & Cardona, O. 1984, ApJ, 285, 190 [NASA ADS] [CrossRef] [Google Scholar]
  2. Abt, H. A., Levato, H., & Grosso, M. 2002, ApJ, 573, 359 [NASA ADS] [CrossRef] [Google Scholar]
  3. Ahumada, J. A., & Lapasset, E. 2007, A&A, 463, 789 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  4. Andrillat, A., Jaschek, M., & Jaschek, C. 1990, A&AS, 84, 11 [NASA ADS] [Google Scholar]
  5. Arcos, C., Jones, C. E., Sigut, T. A. A., Kanaan, S., & Curé, M. 2017, ApJ, 842, 48 [NASA ADS] [CrossRef] [Google Scholar]
  6. Arcos, C., Kanaan, S., Chávez, J., et al. 2018, MNRAS, 474, 5287 [NASA ADS] [CrossRef] [Google Scholar]
  7. Astraatmadja, T. L., & Bailer-Jones, C. A. L. 2016, ApJ, 833, 119 [NASA ADS] [CrossRef] [Google Scholar]
  8. Ballereau, D., Alvarez, M., Chauville, J., & Michel, R. 1987, Rev. Mex. Astron. Astrofis., 15, 29 [NASA ADS] [Google Scholar]
  9. Balona, L. A., Marang, F., Monderen, P., Reitermann, A., & Zickgraf, F.-J. 1987, A&AS, 71, 11 [NASA ADS] [Google Scholar]
  10. Balona, L. A., Cuypers, J., & Marang, F. 1992, A&AS, 92, 533 [NASA ADS] [CrossRef] [Google Scholar]
  11. Balona, L. A., Handler, G., Aerts, C., et al. 2002, in Observational Aspects of Pulsating B- and A Stars, eds. C. Sterken & D. W. Kurtz, ASP Conf. Ser., 256, 9 [NASA ADS] [Google Scholar]
  12. Barnsley, R. M., & Steele, I. A. 2013, A&A, 556, A81 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  13. Bergin, E. A., Burns, J. F., Guinan, E. F., & McCook, G. P. 1989, IBVS, 3358, 1 [NASA ADS] [Google Scholar]
  14. Bjorkman, K. S., Miroshnichenko, A. S., McDavid, D., & Pogrosheva, T. M. 2002, ApJ, 573, 812 [NASA ADS] [CrossRef] [Google Scholar]
  15. Bossi, M., Guerrero, G., & Bianchini, G. 1989, IBVS Stars, 3348, 1 [NASA ADS] [Google Scholar]
  16. Brown, J. C., & McLean, I. S. 1977, A&A, 57, 141 [NASA ADS] [Google Scholar]
  17. Carciofi, A. C., Okazaki, A. T., Le Bouquin, J.-B., et al. 2009, A&A, 504, 915 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  18. Cardelli, J. A., Clayton, G. C., & Mathis, J. S. 1989, ApJ, 345, 245 [NASA ADS] [CrossRef] [Google Scholar]
  19. Carrier, F., Burki, G., & Burnet, M. 2002, A&A, 385, 488 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  20. Castle, K. G. 1977, PASP, 89, 862 [NASA ADS] [CrossRef] [Google Scholar]
  21. Castor, J. I., Abbott, D. C., & Klein, R. I. 1975, ApJ, 195, 157 [NASA ADS] [CrossRef] [Google Scholar]
  22. Catanzaro, G. 2013, A&A, 550, A79 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  23. Chauville, J., Zorec, J., Ballereau, D., et al. 2001, A&A, 378, 861 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  24. Chelli, A., Utrera, O. H., & Duvert, G. 2009, A&A, 502, 705 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  25. Collins, II, G. W. 1987, in IAU Colloq. 92: Physics of Be Stars, eds. A. Slettebak & T. P. Snow, 3 [Google Scholar]
  26. Cote, J., & Waters, L. B. F. M. 1987, A&A, 176, 93 [NASA ADS] [Google Scholar]
  27. Cranmer, S. R. 2005, ApJ, 634, 585 [NASA ADS] [CrossRef] [Google Scholar]
  28. Curé, M., Rial, D. F., Christen, A., & Cassetti, J. 2014, A&A, 565, A85 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  29. Cyr, R. P., Jones, C. E., & Tycner, C. 2015, ApJ, 799, 33 [NASA ADS] [CrossRef] [Google Scholar]
  30. Delaa, O., Stee, P., Meilland, A., et al. 2011, A&A, 529, A87 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  31. Doazan, V., Sedmak, G., Barylak, M., Rusconi, L., & Battrick, B. 1991, A Be star atlas of far UV and optical high-resolution spectra, ESA SP, 1147 [Google Scholar]
  32. Domiciano de Souza, A., Kervella, P., Jankov, S., et al. 2003, A&A, 407, L47 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  33. Frémat, Y., Zorec, J., Hubert, A.-M., & Floquet, M. 2005, A&A, 440, 305 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  34. Gies, D. R., Bagnuolo, Jr. W. G., Baines, E. K., et al. 2007, ApJ, 654, 527 [NASA ADS] [CrossRef] [Google Scholar]
  35. González, J. F., & Lapasset, E. 2000, AJ, 119, 2296 [NASA ADS] [CrossRef] [Google Scholar]
  36. Grundstrom, E. D., & Gies, D. R. 2006, ApJ, 651, L53 [NASA ADS] [CrossRef] [Google Scholar]
  37. Hanuschik, R. W., Kozok, J. R., & Kaiser, D. 1988, A&A, 189, 147 [NASA ADS] [Google Scholar]
  38. Hanuschik, R. W., Hummel, W., Dietle, O., & Sutorius, E. 1995, A&A, 300, 163 [NASA ADS] [Google Scholar]
  39. Harmanec, P. 1984, Bull. astr. Inst. Czechosl., 35, 164 [NASA ADS] [Google Scholar]
  40. Hirata, R. 2007, in Active OB-Stars: Laboratories for Stellare and Circumstellar Physics, eds. A. T. Okazaki, S. P. Owocki, & S. Stefl, ASP Conf. Ser., 361, 267 [NASA ADS] [Google Scholar]
  41. Hubert, A. M., & Floquet, M. 1998, A&A, 335, 565 [NASA ADS] [Google Scholar]
  42. Hutchings, J. B. 1970, MNRAS, 150, 55 [NASA ADS] [Google Scholar]
  43. Jaschek, M., Slettebak, A., & Jaschek, C. 1981, Be Star Terminology, Be Star Newsletter, 4, 9 [NASA ADS] [Google Scholar]
  44. Jones, C. E., Sigut, T. A. A., & Porter, J. M. 2008, MNRAS, 386, 1922 [NASA ADS] [CrossRef] [Google Scholar]
  45. Jones, C. E., Tycner, C., & Smith, A. D. 2011, AJ, 141, 150 [NASA ADS] [CrossRef] [Google Scholar]
  46. Kanaan, S., Meilland, A., Stee, P., et al. 2008, A&A, 486, 785 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  47. Katahira, J.-I., Hirata, R., Ito, M., et al. 1996a, Rev. Mex. Astron. Astrofis. Conf. Ser., 5, 114 [NASA ADS] [Google Scholar]
  48. Katahira, J.-I., Hirata, R., Ito, M., et al. 1996b, PASJ, 48, 317 [NASA ADS] [CrossRef] [Google Scholar]
  49. Kervella, P., & Domiciano de Souza, A. 2006, A&A, 453, 1059 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  50. Kurucz, R. L. 1979, ApJS, 40, 1 [NASA ADS] [CrossRef] [Google Scholar]
  51. Labadie-Bartz, J., Pepper, J., McSwain, M. V., et al. 2017, AJ, 153, 252 [NASA ADS] [CrossRef] [Google Scholar]
  52. Lefèvre, L., Marchenko, S. V., Moffat, A. F. J., & Acker, A. 2009, A&A, 507, 1141 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  53. Meilland, A., Millour, F., Stee, P., et al. 2007a, A&A, 464, 73 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  54. Meilland, A., Stee, P., Vannier, M., et al. 2007b, A&A, 464, 59 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  55. Meilland, A., Millour, F., Stee, P., et al. 2008, A&A, 488, L67 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  56. Meilland, A., Stee, P., Chesneau, O., & Jones, C. 2009, A&A, 505, 687 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  57. Meilland, A., Delaa, O., Stee, P., et al. 2011, A&A, 532, A80 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  58. Meilland, A., Millour, F., Kanaan, S., et al. 2012, A&A, 538, A110 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  59. Mennickent, R. E., Sterken, C., & Vogt, N. 1997, A&A, 326, 1167 [NASA ADS] [Google Scholar]
  60. Millour, F., Chesneau, O., Borges Fernandes, M., et al. 2009, A&A, 507, 317 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  61. Miroshnichenko, A. S., Bjorkman, K. S., Morrison, N. D., et al. 2003, A&A, 408, 305 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  62. Mourard, D., Bosc, I., Labeyrie, A., Koechlin, L., & Saha, S. 1989, Nature, 342, 520 [NASA ADS] [CrossRef] [Google Scholar]
  63. Neiner, C., Hubert, A.-M., Floquet, M., et al. 2002, A&A, 388, 899 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  64. Neiner, C., Hubert, A.-M., Frémat, Y., et al. 2003, A&A, 409, 275 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  65. Neiner, C., Grunhut, J. H., Petit, V., et al. 2012, MNRAS, 426, 2738 [NASA ADS] [CrossRef] [Google Scholar]
  66. Nemravová, J., Harmanec, P., Kubát, J., et al. 2010, A&A, 516, A80 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  67. Ochsenbein, F., Bauer, P., & Marcout, J. 2000, A&AS, 143, 23 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  68. Okazaki, A. T. 1997, A&A, 318, 548 [NASA ADS] [Google Scholar]
  69. Oudmaijer, R. D., & Parr, A. M. 2010, MNRAS, 405, 2439 [NASA ADS] [Google Scholar]
  70. Peters, G. J. 1972, PASP, 84, 334 [NASA ADS] [CrossRef] [Google Scholar]
  71. Peters, G. J. 1983, PASP, 95, 311 [NASA ADS] [CrossRef] [Google Scholar]
  72. Peters, G. J., Wang, L., Gies, D. R., & Grundstrom, E. D. 2016, ApJ, 828, 47 [NASA ADS] [CrossRef] [Google Scholar]
  73. Petrov, R. G., Malbet, F., Weigelt, G., et al. 2007, A&A, 464, 1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  74. Prinja, R. K. 1989, MNRAS, 241, 721 [NASA ADS] [CrossRef] [Google Scholar]
  75. Quirrenbach, A., Bjorkman, K. S., Bjorkman, J. E., et al. 1997, ApJ, 479, 477 [NASA ADS] [CrossRef] [Google Scholar]
  76. Rivinius, T., Štefl, S., & Baade, D. 2006, A&A, 459, 137 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  77. Rivinius, T., Carciofi, A. C., & Martayan, C. 2013, A&ARv, 21, 69 [NASA ADS] [CrossRef] [Google Scholar]
  78. Sadakane, K., Hirata, R., & Tsuji, T. 2005, PASJ, 57, 1 [NASA ADS] [CrossRef] [Google Scholar]
  79. Schaefer, G. H., Gies, D. R., Monnier, J. D., et al. 2010, AJ, 140, 1838 [NASA ADS] [CrossRef] [Google Scholar]
  80. Schaller, G., Schaerer, D., Meynet, G., & Maeder, A. 1992, A&AS, 96, 269 [Google Scholar]
  81. Shimazaki, H.,& Shinomoto, S. 2007, Neural Comput., 19, 1503 [CrossRef] [Google Scholar]
  82. Sigut, T. A. A., Tycner, C., Jansen, B., & Zavala, R. T. 2015, ApJ, 814, 159 [NASA ADS] [CrossRef] [Google Scholar]
  83. Silaj, J., Jones, C. E., Tycner, C., Sigut, T. A. A., & Smith, A. D. 2010, ApJS, 187, 228 [NASA ADS] [CrossRef] [Google Scholar]
  84. Silaj, J., Jones, C. E., Sigut, T. A. A., & Tycner, C. 2014, ApJ, 795, 82 [NASA ADS] [CrossRef] [Google Scholar]
  85. Slettebak, A. 1982, ApJS, 50, 55 [NASA ADS] [CrossRef] [Google Scholar]
  86. Stee, P., Meilland, A., Bendjoya, P., et al. 2013, A&A, 550, A65 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  87. Struve, O. 1925, ApJ, 62 [Google Scholar]
  88. Tatulli, E., Millour, F., Chelli, A., et al. 2007, A&A, 464, 29 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  89. Thaller, M. L., Bagnuolo, Jr. W. G., Gies, D. R., & Penny, L. R. 1995, ApJ, 448, 878 [NASA ADS] [CrossRef] [Google Scholar]
  90. Touhami, Y., Gies, D. R., & Schaefer, G. H. 2011, ApJ, 729, 17 [NASA ADS] [CrossRef] [Google Scholar]
  91. Touhami, Y., Gies, D. R., Schaefer, G. H., et al. 2013, ApJ, 768, 128 [NASA ADS] [CrossRef] [Google Scholar]
  92. Tycner, C., Hajian, A. R., Armstrong, J. T., et al. 2004, AJ, 127, 1194 [NASA ADS] [CrossRef] [Google Scholar]
  93. Tycner, C., Lester, J. B., Hajian, A. R., et al. 2005, ApJ, 624, 359 [NASA ADS] [CrossRef] [Google Scholar]
  94. Štefl, S., Rivinius, T., Carciofi, A. C., et al. 2009, A&A, 504, 929 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  95. van Belle G. T. 2012, A&ARv, 20, 51 [NASA ADS] [CrossRef] [Google Scholar]
  96. van Leeuwen F., ed. 2007, Astrophys. Space Sci. Lib., 350 [CrossRef] [Google Scholar]
  97. Vieira, R. G., Carciofi, A. C., Bjorkman, J. E., et al. 2017, MNRAS, 464, 3071 [NASA ADS] [CrossRef] [Google Scholar]
  98. Vinicius, M. M. F., Zorec, J., Leister, N. V., & Levenhagen, R. S. 2006, A&A, 446, 643 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  99. Waters, L. B. F. M. 1986, A&A, 162, 121 [NASA ADS] [Google Scholar]
  100. Waters, L. B. F. M., Cote, J., & Lamers, H. J. G. L. M. 1987, A&A, 185, 206 [NASA ADS] [Google Scholar]
  101. Waters, L. B. F. M., Cote, J., & Pols, O. R. 1991, A&A, 250, 437 [NASA ADS] [Google Scholar]
  102. Wisniewski, J. P., Draper, Z. H., Bjorkman, K. S., et al. 2010, ApJ, 709, 1306 [NASA ADS] [CrossRef] [Google Scholar]
  103. Yudin, R. V. 2001, A&A, 368, 912 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  104. Zorec, J., Frémat, Y., Domiciano de Souza, A., et al. 2016, A&A, 595, A132 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]

1

Rotational velocity of a star at which the centrifugal force equals the gravitational force at the equator.

2

The rotational rate, , is the ratio of the stellar angular velocity to its critical one.

All Tables

Table 1

VLTI/AMBER observing log.

Table 2

Adopted and calculated parameters for the sample of Be stars with emission in the Brγ line.

Table 3

Best-fitting parameters, with their respective errors, obtained from our axisymmetric kinematic model.

Table 4

VVc ratio and rotational rate Ω∕Ωc of our Be stars.

All Figures

thumbnail Fig. 1

HD 23630: (u, v) plan coverage, differential visibilities (δV), differential phases (δϕ) and closure phases (CP) from our HR measurements. Each observation in the (u, v) plane, i.e., three baseline measurements, is plotted with a different color and symbol: blue circles correspond to the baselines B1–B3; green squares to baselines B4–B6; red triangles to baselines B7–B9; purple diamonds to baselines B10–B12; pink hexagons to baselines B13–B15; cyan pentagons to baselines B16–B18; orange thin diamonds to baselines B19–B21. See description in Sect. 4.

Open with DEXTER
In the text
thumbnail Fig. 2

Example of the SED fitting model for HD 41335. Red triangles represent the photometric data from VIZIER database, the solid blue line represents the best-fitting Kurucz model and the dashed green line shows the IR excess.

Open with DEXTER
In the text
thumbnail Fig. 3

Brγ line profile of Be stars observed with VLTI/AMBER instrument during our observing campaign.

Open with DEXTER
In the text
thumbnail Fig. 4

Histogram showing the distribution of the star sample as a function of the spectral subtype and luminosity class.

Open with DEXTER
In the text
thumbnail Fig. 5

Differential visibility, differential phase and closure phase corresponding to the interferometric observations of HD 23408, with the Brγ line in absorption.

Open with DEXTER
In the text
thumbnail Fig. 6

Position angle of the disk PA vs. polarization angle P. The solid black line corresponds to the case where PA is perpendicular to the polarization measurement (PA = P ± 90). The solid red line corresponds to the situation when PA is parallel to the polarization measurement (PA = P ± 180). The dotted lines correspond to an uncertainty of 15°.

Open with DEXTER
In the text
thumbnail Fig. 7

Distribution of Be stars per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 8

Distribution of the disk extension in the line per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 9

Distribution of inclinations along the line-of-sight per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 10

Distribution of Vrot per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 11

Distribution of VVc per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 12

Distribution of Ω∕Ωc per spectral type and luminosity class for the combined sample.

Open with DEXTER
In the text
thumbnail Fig. 13

Distributions of VVc and Ω∕Ωc with the effective temperature. There is a lack of correlation.

Open with DEXTER
In the text
thumbnail Fig. 14

PDF (solid black line) generated from our N = 25 data sample. It was calculated using a standard KDE algorithm with a Gaussian kernel and a Silverman’s bandwidth of 0.1029. The 95% confidence interval is shown in the shaded gray region and was calculated using the quantiles from 2000 bootstrap samples of length N = 25. The theoretical PDF f(s) function is shown as a dashed line.

Open with DEXTER
In the text
thumbnail Fig. 15

Relation between Vrot and the disk extension in the Brγ line for the star sample of this work and those collected from Meilland et al. (2012). For a given Vrot, the blue dashed line could be an upper limit for the disk extension.

Open with DEXTER
In the text
thumbnail Fig. 16

Relation between Vrot and the diskextension in the line for the star sample (black dots) included in this work and Meilland et al. (2012). The colored linessymbols are given in the top left of the figure. The blue dashed line from Fig. 15 could state an upper limit for the disk size of the stars indicated as “without variability”. The orange dotted line seems to oultine a second linear regretion from stars with stable disks.

Open with DEXTER
In the text
thumbnail Fig. 17

Relation between VrotVc and the disk extension in the Brγ line for the combined sample. Stars with the largest sizes have Vrot close to its critical rotation velocity.

Open with DEXTER
In the text
thumbnail Fig. 18

Relation between Vrot and disk extension in the line for the star sample studied in this work and in Meilland et al. (2012). For a given Vrot, the blue dashed line traces the location of low-mass Be stars with stable disks and the orange dotted line identifies the location of high-mass Be stars with stable disks.

Open with DEXTER
In the text
thumbnail Fig. A.1

As in Fig. 1, but for HD 23862.

Open with DEXTER
In the text
thumbnail Fig. A.2

As in Fig. 1, but for HD 28497.

Open with DEXTER
In the text
thumbnail Fig. A.3

As in Fig. 1, but for HD 30076.

Open with DEXTER
In the text
thumbnail Fig. A.4

As in Fig. 1, but for HD 32991.

Open with DEXTER
In the text
thumbnail Fig. A.5

As in Fig. 1, but for HD 35439.

Open with DEXTER
In the text
thumbnail Fig. A.6

As in Fig. 1, but for HD 36576.

Open with DEXTER
In the text
thumbnail Fig. A.7

As in Fig. 1, but for HD 37202.

Open with DEXTER
In the text
thumbnail Fig. A.8

As in Fig. 1, but for HD 37490.

Open with DEXTER
In the text
thumbnail Fig. A.9

As in Fig. 1, but for HD 41335.

Open with DEXTER
In the text
thumbnail Fig. A.10

Asin Fig. 1, but for HD 45725.

Open with DEXTER
In the text
thumbnail Fig. A.11

Asin Fig. 1, but for HD 60606.

Open with DEXTER
In the text
thumbnail Fig. A.12

Asin Fig. 1, but for HD 66194.

Open with DEXTER
In the text
thumbnail Fig. A.13

Asin Fig. 1, but for HD 68980.

Open with DEXTER
In the text
thumbnail Fig. A.14

Asin Fig. 1, but for HD 209409.

Open with DEXTER
In the text
thumbnail Fig. A.15

Asin Fig. 1, but for HD 212076.

Open with DEXTER
In the text
thumbnail Fig. A.16

Asin Fig. 1, but for HD 212571.

Open with DEXTER
In the text
thumbnail Fig. A.17

Asin Fig. 1, but for HD 214748.

Open with DEXTER
In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
