Laboratory verification of Fast & Furious phase diversity: Towards controlling the low wind effect in the SPHERE instrument
^{1}
Leiden Observatory, Leiden University,
PO Box 9513,
2300 RA
Leiden, The Netherlands
email: wilby@strw.leidenuniv.nl
^{2}
AixMarseille Université, CNRS, LAM, Laboratoire d’Astrophysique de Marseille,
Marseille, France
^{3}
ONERA,
29 Avenue de la Division Leclerc,
92320
Châtillon, France
^{4}
Université GrenobleAlpes, CNRS, IPAG,
38000
Grenoble, France
Received:
15
September
2017
Accepted:
4
March
2018
Context. The low wind effect (LWE) refers to a characteristic set of quasistatic wavefront aberrations seen consistently by the SPHERE instrument when domelevel wind speeds drop below 3 ms^{−1}. The LWE produces bright loworder speckles in the stellar pointspread function (PSF), which severely limit the contrast performance of SPHERE under otherwise optimal observing conditions.
Aims. In this paper we propose the Fast & Furious (F&F) phase diversity algorithm as a viable softwareonly solution for realtime LWE compensation, which would utilise image sequences from the SPHERE differential tiptilt sensor (DTTS) and apply corrections via reference slope offsets on the AO system’s ShackHartmann wavefront sensor.
Methods. We evaluated the closedloop performance of F&F on the MITHIC highcontrast testbench, under conditions emulating LWEaffected DTTS images. These results were contrasted with predictive simulations for a variety of convergence tests, in order to assess the expected performance of an onsky implementation of F&F in SPHERE.
Results. The algorithm was found to be capable of returning LWEaffected images to Strehl ratios of greater than 90% within five iterations, for all appropriate laboratory test cases. These results are highly representative of predictive simulations, and demonstrate stability of the algorithm against a wide range of factors including low image signaltonoise ratio (S/N), small image field of view, and amplitude errors. It was also found in simulation that closedloop stability can be preserved down to image S/N as low as five while still improving overall wavefront quality, allowing for reliable operation even on faint targets.
Conclusions. The Fast & Furious algorithm is an extremely promising solution for realtime compensation of the LWE, which can operate simultaneously with science observations and may be implemented in SPHERE without requiring additional hardware. The robustness and relatively large effective dynamic range of F&F also make it suitable for general wavefront optimisation applications, including the cophasing of segmented ELTclass telescopes.
Key words: instrumentation: adaptive optics / instrumentation: high angular resolution / techniques: high angular resolution / atmospheric effects / telescopes
© ESO 2018
1 Introduction
The SpectroPolarimetric HighContrast Exoplanet REsearch instrument (SPHERE; Beuzit et al. 2008), is a secondgeneration highcontrast imaging instrument for the Very Large Telescope (VLT), which finished its commissioning phase in 2014. Since then it has been routinely delivering unprecedented science results in the fields of dualband imaging, differential polarimetry, and integral field spectroscopy of directlyimaged protoplanetary disks and young exoplanets (e.g. Vigan et al. 2016a; Maire et al. 2016; Zurlo et al. 2016; Bonnefoy et al. 2016; de Boer et al. 2016; Ginski et al. 2016). The extreme adaptive optics (XAO) system of SPHERE, SAXO (Sauvage et al. 2016b; Fusco et al. 2014, 2016), is capable of routinely achieving Strehl ratios of 90% in the Hband. When this performance is combined with coronagraphic observation modes and optimised reduction pipelines, it is possible to achieve 5σ planetstar companion detectability ratios of better than 10^{−6} beyond angular separations of 375 mas (Zurlo et al. 2016).
However, the instrument performance and ultimately the science yield of SPHERE is currently limited under the best observing conditions by the socalled low wind effect (LWE). This effect refers to a systematic degradation of the image quality of all three SPHERE detector arms (IRDIS, IFS, and ZIMPOL), which occurs when the wind speed at the altitude of the VLT dome drops below approximately 3 ms^{−1} (Sauvage et al. 2016a). The characteristic LWE wavefronts consist of independent pistontiptilt (PTT) phase errors across one or more of the VLT pupil segments, and have been observed to reach up to 800 nm peaktovalley error (PVE) onsky as measured by a prototype of the Zernike wavefront sensor ZELDA (N’Diaye et al. 2014, 2016). As shown in Fig. 1, this leads to a significant degradation of the imaging pointspread function (PSF) by creating multiple bright sidelobes at the location of the first Airy ring and increasing the amount of diffraction structure around the secondary mirror (M2) support spiders. This is an issue for both the coronagraphic and noncoronagraphic highcontrast observing modes of SPHERE, due firstly to increased photon noise and a lower Strehl ratio of offaxis companion sources. In reality the LWE is also a quasistatic phenomenon, and generates significant additional speckle noise on timescales and angular separations particularly detrimental to reference PSF subtraction and other highcontrast data reduction techniques, such as the angular differential imaging (ADI) and principal component analysis (PCA) classes of algorithm (e.g. Marois et al. 2006; Lafrenière et al. 2007; Soummer et al. 2012; Amara & Quanz 2012).
This highamplitude, quasistatic LWE may be considered a specific example of a more general “island effect” (N’Diaye et al. 2018), which encompasses all differential PTT aberrations associated with pupil segmentation irrespective of underlying cause or temporal behaviour. Since examples of island effect behaviour are now also being reported intermittently at the SCExAO (Jovanovic et al. 2015) and GPI instruments (Macintosh et al. 2008; V. Bailey 2016, priv. comm.), solutions developed for the LWE in SPHERE may well be applicable to similar issues faced by other instruments. This is expected to be especially important for the upcoming extremely large telescopes (ELTs), which will feature significantly more complex pupil geometries and may be correspondingly prone to these effects.
Figure 2 illustrates the degradation of raw contrast performance for the SPHERE apodised pupil Lyot coronagraph(APLC) for two example LWE cases drawn from the SPHERE user manual (ESO 2016), using a Fourier propagation model of the threeplane coronagraph system described in Guerri et al. (2011). It can be seen that diffractionlimited simulations (black curve, main panel) predict a raw contrast ratio of significantly better than 10^{−4} between 2–4 λ∕D, however this is not representative of real systems containing sources of noncommon path error (NCPE). In order to provide a more realistic performance estimate, each PSF in Fig. 2 (and the corresponding green, blue, and red curves in the lower panel) includes the incoherent average of 100 random realisations of loworder, lowamplitude wavefront aberrations. These loworder wavefronts are created by drawing random Zernike mode coefficients, with the resulting phase maps then spatially filtered in the Fourier domain to have a 1∕f^{2} decreasing spatial power spectrum often used to model NCPEs (Sauvage et al. 2007; Lamb et al. 2016). These are then scaled to have a 30 nm rootmeansquare (RMS) error, representative of the calibration accuracy achieved in SPHERE after baseline NCPE calibration routines (Fusco et al. 2014). From this it can be seen that for a typical LWE amplitude of 600 nm PVE there is an increase in offaxis transmission of the central source of an order of magnitude with respect to the NCPElimited case between 2–4 λ∕D. This alone would result in a factor of three increase in photon noise in the final reduced image at these angular separations, notwithstanding the inevitable impact of speckle variability due to a quasistatic LWE on the ultimate achievable contrast.
The current working hypothesis is that the LWE is caused by slow laminar airflow across the deep but narrow VLT M2 support spiders, which allows time for significant thermal exchange to occur (Sauvage et al. 2015). This results in sharp temperaturechanges and hence variations in the optical path depth of the air column across the width of each spider, thus generatingdiscontinuities in phase such as that illustrated in Fig. 1 (left). This optical path depth hypothesis is supported by ESO simulations (Sauvage et al. 2016a), which can reproduce the strength and overall morphology of the various wavefronts associated with the effect under realistic dome conditions. These characteristic wavefronts are however not seen in either SAXO ShackHartmann wavefront sensor (SHWFS) data or in the deformable mirror (DM) actuator voltages during onsky operation when the effect is present. This implies that the AO system is at best blind to this class of wavefront error, and at worst may be partially responsible for creating the effect due to unreliable sensing of phase discontinuities near the spiders. For this reason a complete understanding of the LWE, and other instances of the island effect, remains an active area of investigation with potentially significant implications for the design of future highcontrast imaging instruments.
Attempts to eliminate the LWE phenomenon via dynamic control of telescope dome conditions (including increased ventilation, temperature control, and telescope pointing with respect to the prevailing wind direction) or manipulation of the AO closedloop parameters have so far proved unsuccessful in reducing the strength or occurrence rates of the effect. Current efforts are ongoing to improve the thermal properties of the spiders by directly applying coatings with improved nearinfrared (NIR) emissivity (M. Kasper 2016, priv. comm.), which if successful would allow the structure to better remain in thermal equilibrium with the surrounding air and thereby prevent phase discontinuities from arising. Another approach is to directly sense and compensate the LWE wavefront in realtime by introducing an additional wavefront correction loop into the SPHERE instrument: the ZELDA wavefront sensor has been shown to be an accurate truth sensor for the LWE during trials at the VLT in 2016, however until an upgrade to the SPHERE instrument can be performed ZELDA must convert the IRDIS focal plane into a pupilplane sensor, preventing it from being used simultaneously with NIR science observations.
This paper proposes an immediately implementable solution to directly sense and compensate the LWE, by using phase diversity techniques to turn the existing differential tiptilt sensor (DTTS) camera, used for centring the stellar PSF on the NIR coronagraph (Baudoz et al. 2010), into a focalplane wavefront sensor. This is an attractive solution as it requires no additional hardware or modification to the operation of existing SPHERE subsystems, as the correction commands may be applied as reference slope offsets to the main SAXO SHWFS and therefore should be able to operate in parallel with the atmospheric XAO loop without conflict. For this task we propose the Fast & Furious (F&F) modified sequential phase diversity algorithm (Keller et al. 2012; Korkiakoski et al. 2014), so named because it uses a simplified model of the imaging system to obtain an analytical, computationally efficient phase reconstruction procedure (see Sect. 2.1 for details). F&F is also capable of using its own phase correction update cycle to provide the necessary phase diversity for complete focalplane wavefront retrieval. This is in contrast to the majority of phase diversity approaches (Gonsalves 2001; Sauvage et al. 2007; Lamb et al. 2016), which require the periodic application of large controlled probe phases in order to reconstruct the aberrating wavefront. By eliminating this requirement, F&F has the major advantage of being able to run continuously in closedloop without degrading or interrupting science observations, enabling continuous realtime wavefront control.
Fast & Furious has been successfully tested in proofofconcept simulations under imaging conditions emulating the SPHERE DTTS (Wilby et al. 2016) and in a general laboratory environment not specific to the LWE (Korkiakoski et al. 2012, 2014). While these preliminary simulations indicated that the algorithm should be robust against operating with the DTTS camera, before this solution may be implemented onsky it is essential to verify that this performance is reflected in an appropriate laboratory environment. In this paper we therefore present the results of LWEspecific lab testing using the Marseille Imaging Testbed for HIgh Contrast (MITHIC; Vigan et al. 2016b), located at the Laboratoire d’Astrophysique de Marseille (LAM), the results of which are combined with improved closedloop simulations to evaluate the potential performance of F&F onsky in SPHERE at the VLT.
This paper is divided into the following sections: Sect. 2 outlines the principle of the F&F algorithm and presents details of both the MITHIC testbench environment and supporting simulation tools. Section 3 presents the main laboratory closedloop results and compares these to simulated performance predictions, and investigates the stability of F&F at extremely low image signaltonoise ratio (S/N). The limiting factors and lessons learned from this investigation are discussed in Sect. 4, and final conclusions are drawn in Sect. 5.
Fig. 1
Typical example of the LWE phenomenon, based on onsky measurements made with the ZELDA wavefront sensor. Left: parametrised PTT wavefront model based on a single ZELDA phase measurement. Right: the aberrated PSF corresponding to this LWE wavefront map, simulated at a wavelength of 1.536 μ m. The PSF displays three notable sidelobes at the location of the first Airy ring (2.5 λ∕D), which correspond to the differential tiptilt components seen across individual pupil segments in the aberrating phase map.

Open with DEXTER
Fig. 2
Simulated performance of the SPHERE APLC in the presence of various LWE models and loworder wavefront error, for an observing wavelength of 1.536 μ m. Left image column: LWEfree PSFs containing only 30 nm RMS of loworder aberrations with a 1∕f^{2} spatial power spectrum, incoherently averaged over 100 random realisations. Centre column: a typical threelobed LWE model (600 nm PVE) identical to Fig. 1. Right column: an extreme LWE with wavefront similar to a fourquadrant phase mask pattern (600 nm piston on two opposite VLT pupil quadrants). Top image row: noncoronagraphic PSFs, including image Strehl ratio with respect to the diffractionlimited case. Bottom image row: corresponding onaxis coronagraphic PSFs. Main figure panel: Radial average contrast curves of each postAPLC PSF, with shading denoting the 1σ upper and lower bounds on azimuthal variation. Diffractionlimited performance in the absence of all aberration is shown by the blackcurve for comparison purposes.

Open with DEXTER
2 Methodology
2.1 The Fast & Furious algorithm
The F&F algorithm refers to a sequential phase diversity technique based on Gonsalves (2002), which has been extended to improve dynamic range and stability. It is capable of performing realtime wavefront phase retrieval when provided with a timeseries of noncoronagraphic, narrowband focalplane images and knowledge of the frametoframe phase commands applied by deformable elements in the system. Wavefront reconstruction is achieved by solving an analytical approximation to the stellar PSF in terms of the even and odd focalplane intensity distributions, corresponding to the Fourier symmetries of the wavefront to be sensed. Phase diversity information is used only to break a sign ambiguity associated with calculating the even wavefront, which is most effectively provided by the phase correction command from the preceding iteration of F&F. This has the major advantage that the sequential phase diversity process continually improves wavefront quality, allowing it to operate in parallel with continuous science observations. The algorithm is also highly computationally efficient, requiring only a single complex Fourier transform per iteration plus a small number of linear operations on image data. The correction cadence of F&F will therefore be limited by the imaging camera readout frequency in most practical applications, whereas other phase diversity approaches are limited by the (significantly lower) frequency of phase probeinjection. Unlike classical phase diversity however, F&F is not capable of performing oneshot phase retrieval and must be operated in closedloop for full wavefront compensation. Despite this it is always possible to reconstruct the odd wavefront component from any single PSF image, and with an appropriate choice of initial conditions it is almost always possible to achieve a systematic improvement in wavefront quality even on the first iteration.
A full derivation and analysis of the numerical properties of the F&F algorithm can be found in Keller et al. (2012) and Korkiakoski et al. (2014); a summary of the key equations necessary to implement the algorithm is presented here for reference. In the following description capitalised variables are used to denote twodimensional pupilplane quantities and lowercase variables denote twodimensional focalplane quantities, unless otherwise noted. The PSF of an aberrated stellar image may be Taylor expanded to second order as a function of the even and odd focalplane electric fields as (1)
where is the complex Fourier transform of the telescope aperture function A, which is assumed to be real and symmetric, while and are the complex Fourier transforms of the odd and even components of the wavefront phase map Φ, with and , such that Φ = Φ_{o} + Φ_{e}. The scalar normalisation factor is approximately equal to the Strehl ratio of the most recent image, where is the total wavefront variance: this is effectively the firstorder Taylor expansion of the Maréchal approximation (Roberts et al. 2004). Here is the Fourier transform operator, and * is the convolution operator. This formulation takes advantage of the enforced symmetry properties of all pupilplane quantities to simplify the expressions, and to remain consistent with the symmetry properties of the complex Fourier transform.
The expression above may be more conveniently expressed by defining the odd and even focalplane fields as the two real quantities
leading to analytical solutions for the complete odd field and the absolute value of the even field, by separating Eq. (1) according to symmetry and solving. This yields
where p_{o} and p_{e} are the odd and even components of p by direct analogy with Φ_{o} and Φ_{e}. Here the scalar ϵ parameter is introduced as a method of regularisation for pixels where a tends towards zero, which is typically set to a factor of ten above the noise threshold in the image sequence.
In order to estimate the signs of the even focalplane field, it is necessary to introduce a second PSF image which differs from the first by a known phase offset Φ_{d}, such that
where v_{d} and y_{d} correspond to this additional phase diversity between frames by analogy with Eqs. (2) and (3). Solving for v yields an independent expression in terms of the even components of each PSF, p_{1e} and p_{2e}, however this solution is extremely prone to noise due to the subtraction of two similar PSFs. It is therefore significantly more robust to take only the signs of this estimate, (8)
and combinethese with the magnitude v computed from Eq. (5).
The final estimate of the wavefront phase may then be reconstructed via a single complex inverse Fourier transform, by taking into accountthe symmetries of the odd and even focalplane fields to give (9)
This estimate may then be applied using a wavefront correcting element, which in turn becomes the new phase diversity Φ _{d} for the next iteration. Since sign(v) is undefined on the first iteration where phase diversity information is not available, it is optimal in the case of small wavefront aberrations to choose .
Key assumptions made implicitly by F&F include the use of a symmetric telescope pupil function, the presence of phaseonly aberrations and a monochromatic light source. An improved version of the algorithm dubbed FFGS, which includes GerchbergSaxton style iterative steps, has been developed (Korkiakoski et al. 2014) which can overcome these first two limitations by also enabling amplitude retrieval. It was not however found to be necessary to implement FFGS in this work, due to the nearsymmetric SPHERE pupil generating only small systematic reconstruction errors which may be removed by spatial filtering, therefore not warranting the increased complexity and lower stability of FFGS compared to F&F alone.
2.2 Implementing F&F in SPHERElike simulations
The first step towards using F&F as a LWEcompensator for SPHERE is to simulate as closely as possible the observing conditions of the DTTS camera, and verify that the algorithm is both efficient at eliminating LWE wavefronts and stable during continuous operation in the absence of the effect. The DTTS Hawaii I camera is capable of operating at high framerates (1 Hz–1 kHz) with only a 32 × 32 pixel field of view at 3.5 pixels per λ∕D sampling, with images stacked to provide tiptilt correction at a cadence of 1 Hz. This is operated at a wavelength of 1.536 μm (Hband) with a 3% bandwidth and is situated behind a 2% beamsplitter to avoid unnecessary science throughput losses, hence DTTS images normally have low S/N. F&F must therefore first and foremost be robust against dominant detector noises sources and a limited image size. Other considerations include the presence of amplitude variations, most notably the presence of the SPHERE NIR coronagraph amplitude apodiser (located upstream of the DTTS beamsplitter) and pupil rotation, but also errors in representing wavefront control commands due to fitting errors associated with a finite DM resolution, as well as systematic errors in applying reference offsets on an existing AO loop.
A dedicated python simulation package has been developed for the purpose of validating F&F under SPHERElike conditions, which is also used throughout this work. This code is capable of generating realistic DTTSlike image sequences using an XAOcorrected turbulence phasescreen simulator and quasistatic NCPE model with appropriate coherence timescale and spatial power spectrum, with photon and detector noise sources added to achieve the desired S/N. A comprehensive overview of the main code features is provided in Wilby et al. (2016), which also reported initial simulation results demonstrating that F&F should be capable of providing significant and robust improvements in wavefront quality for the case of the LWE. The key steps used in this implementation F&F are described below, which also apply to the code used for MITHIC laboratory testing (see Sect. 2.3).
As part of the preliminary data reduction step, a windowing function was applied to images in order to suppress pixeltopixel noise by removingthe high spatial frequencies containing no retrievable wavefront information. This took the form of a radial sigmoid lowpass spatial filter, with a radial cutoff determined by image S/N: this step is described further in Sect. 3.2. Two consecutive images p_{1} and p_{2} were then used along with the appropriate phase diversity command Φ _{d} to calculate the F&F phase reconstruction AΦ, as describedby Eqs. (4), (5), (8) and (9). The maximum spatial frequency which can be controlled by F&F is ultimately set by the fieldofview (FOV) of the input images, and the Fourier transform operation must be constructed so as to ensure that the reference field a has both the same focalplane sampling as the input images and at least the same FOV. This may be achieved by using a discrete fast Fourier transform (FFT) operation with an appropriately zeropadded aperture function A, but to fully optimise the algorithm a nonFFT based method such as the semianalytical approach described in Soummer et al. (2007) should be used. This allows for an arbitrary focalplane sampling and FOV whilst computing AΦ at an appropriate resolution for the deformable element being used, thereby maximising computational speed.
In order to further suppress pixeltopixel noise and systematic artefacts associated with asymmetric pupil features (such as spiders), the raw F&F wavefront estimates were projected onto a loworder modal correction basis, which can also be customised to constrain the degrees of freedom that F&F is able to control. The most appropriate modal correction basis to use given the current model of LWE wavefront morphology is a segmented basis consisting of independent PTT components for each VLT pupil quadrant, although Zernike or disk harmonic modes are less sensitive to specific pupil orientation and would also allow F&F to correct additional errors including NCPEs. Finally, the resulting phase maps were spatially filtered with a Gaussian kernel to approximate the limited spatial frequency response of the 41 × 41 actuator SPHERE DM. For simplicity it was assumed that these final filtered wavefront estimates could be applied accurately on the DM via reference offsets to the zero points of the main SAXO AO loop. Wavefront corrections were therefore directly applied on the (simulated) deformable element throughout this work. This assumption is encouraged by successful preliminary testing of the SPHERE DM response to piston offset commands (Sauvage et al. 2016a), but an endtoend simulation involving the SPHERE filtered SHWFS and DM interaction matrix is beyond the scope of this paper.
More detailed and diagrammatic explanations of F&F wavefront correction loop architectures can be found in Korkiakoski et al. (2014) and Wilby et al. (2016). The code implementation described in the latter paper has since been enhanced to explore additional considerations for SPHERE performance, with the capability to apply both systematic and random temporal variations in the gain of individual DM actuators (and hence imperfect reproduction of F&F phase estimates), the capacity to add additional amplitude aberrations and pupil rotation, a more realistic spatial filtering window function for atmospheric phasescreen generation, and a 1∕f^{2} filtered spatial power spectrum of injected NCPEs. This allows an extension of the already published simulation results, especially for addressing the impact of factors such as amplitude aberrations or reconstruction errors when applying F&F update commands through a real AO system.
2.3 Laboratory verification of F&F on the MITHIC bench
In order to verify whether the simulation package discussed above is accurate in its implementation of F&F and in its treatment of the most important factors for onsky observation, we performed closedloop tests with the MITHIC highcontrast testbench at LAM (Vigan et al. 2016b). The F&F code package was implemented on the bench as described in the previous subsection and executed fora number of controlled convergence tests, with variable parameters including the amplitude and type of wavefront error, imageFOV, pupil apodisation, and image S/N. Each set of laboratory conditions was also run through an equivalent closedloop simulation to provide a direct means of comparison between the two approaches. The various parameters and results of these tests are listed in Table 1, and are discussed in detail in Sect. 3.1.
The MITHIC bench operates at visible wavelengths (677 nm) and is optimised for highcontrast coronagraphic imaging using the Roddier and Roddier phase mask coronagraph (Roddier & Roddier 1997; N’Diaye et al. 2011), with the capability for pupilplane wavefront measurement provided by ShackHartmann and ZELDA wavefront sensors, in addition to the COFFEE coronagraphic phase diversity estimator (Paul et al. 2014) for focalplane NCPE control. Figure 3 illustrates the optical layout of the bench as was used for this investigation, which is similar to that described in Paul et al. (2014). A newlyinstalled phasescreen turbulence simulator (Vigan et al. 2016b) can be used to inject either single layer dynamic turbulence or a variety of static wavefront error patterns into the beam, including a LWE aberration with the same morphology as in Fig. 1 and an estimated amplitude of 98 nm PVE. Wavefront control was achieved using a Hamamatsu liquidcrystalonsilicon spatial light modulator (LCOSSLM), which is situated behind a beamsplitter in a faceon reflective configuration and samples the reimaged pupil with 273 pixels across the diameter. The CoolSnap HQ2 1392 × 1040 pixel interline CCD camera was used for final focalplane imaging, sampling the final PSF at 9.6 pixels per λ∕D. For this work the camera was used in noncoronagraphic imaging mode, with the images numerically binned to a resolution of 3.3 pixels per λ∕D and cropped to a 32 × 32 pixel FOV, matching the default imaging parameters of the DTTS. The PSF S/N was adjusted by varying the laser input power for a fixed exposure time of 1 ms, and was calculated based on the central image pixel with respect to the background noise floor.
In the absence of artificially injected sources of wavefront error, the MITHIC bench was measured by the HASO3 SHWFS to contain 96 nm RMS of astigmatismdominated loworder static error, due to optical misalignments. After wavefront flattening using the SLM it was estimated that residual aberrations were reduced to the level of 10 nm RMS, with the imaging camera PSF displaying four consecutive unbroken Airy rings. This phase correction was then manually applied as a flat wavefront command using the SLM during this investigation, ensuring that injected aberrations comprised the vast majority of total wavefront error in the system for closedloop tests.
A weak amplitude apodiser was included in the setup for a small subset of tests, inserted in the pupil shortly after the SLM in both an onaxis and offaxis position as shown in Fig. 4 in order to test the response of F&F to amplitude effects. During most SPHERE coronagraphic observations the DTTS imaging path also includes the strong APLC apodiser shown in black in Fig. 4, but a similar apodiser was not available in MITHIC forthese tests. This is not in itself a concern for F&F performance: the radial amplitude function of the APLC apodiser is completely symmetric, allowing it to be included when calculating the reference focal plane field a which defines the zero point for F&F wavefront reconstruction, without violating any of the assumptions on pupil geometry made in Sect. 2.1. The important consideration which is investigated here is whether the stability of F&F is limited by unknown amplitude errors, for example due to optical misalignments or errors in the pupil model used for F&F. The MITHIC apodiser pupil functions were therefore not provided to F&F when generating the reference field a for these tests, which instead used a uniform circular aperture matched to the MITHIC beam.
Due to the practicalities of using separate GUI interfaces for imaging and SLM control, coupled with the nonnetworked computing architecture currently implemented in MITHIC, wavefront correction could only be achieved by manually closing the loop. This limited the number of iterations which could reasonably be performed to a maximum of 25, due to time restrictions and risk of human error. As simulations and previous laboratory tests of F&F indicated that stable convergence is typically achieved in 5–6 iterations, this approach was deemed sufficient to characterise the initial convergence behaviour and place limits on the shortterm postconvergence stability.
The limited number of closedloop iterations, combined with the slow and irregular wavefront update frequency of manual control, alsomade it impractical to properly apply wavefront dynamics representative of SPHERE onsky observations. All injected LWE and loworder aberrations in this investigation were therefore static, whether applied on the SLM or via static patterns on the turbulence phase screen. Most importantly, this means that MITHIC images did not include a simulation of atmosphericturbulence, quasistatic NCPEs or variability of the LWE itself. However, none of these dynamical factors were found to limit F&F performance when studied in the prior closedloop simulations of Wilby et al. (2016), provided that the wavefront correction loop can run sufficiently fast compared to the LWE coherence timescale: this point is discussed further in Sect. 3.2. The lack of an incoherent atmospheric speckle background does mean that the Strehl ratios quoted in this paper are close to the diffraction limit, and must be scaled down by the typical Hband performanceof SAXO in order to make a comparison with expected onsky performance.
In future it would be advantageous to fully automate the MITHIC wavefront correction loop, which would eliminate user error and allow more thorough investigation into the longterm closedloop stability of focalplane sensors, and their correction cadence requirements under variable conditions more closely resembling onsky observations.
Fig. 3
Schematic of the MITHIC bench configuration used for this investigation. The spatial light modulator (SLM) is placed in a faceon reflective configuration via a double pass through a beamsplitter. Images taken via the CoolSnap camera GUIwere manually transferred from the imaging PC to the SLM control PC via a separate LAM server, before performing F&F wavefront reconstruction as described in Sect. 2.2 and applying the new wavefront commands on the SLM via a custom GUI. Each closedloop iteration of F&F typically took between 30 s and a minute to complete, of which the F&F code runtime was a negligible fraction. The HASO SHWFS was used only for the precompensation of MITHIC bench alignment errors and was not operated during F&F closedloop tests. The turbulence phase screen was aligned either on the static LWE pattern or a clear aperture, and was not used to simulate dynamical turbulence.

Open with DEXTER
Fig. 4
Throughput images (top panels) and radial transmission profiles (lower panel) of the amplitude apodisers relevant to this investigation. Top row, from left: SPHERE APLC apodiser model of Guerri et al. (2011), and pupilimaging measurements of the onaxis and offaxis transmission (respectively) of the weak MITHIC bench apodiser. Lower panel: Dark lines denote the mean radial throughput curve of each transmission profile, with shading illustrating the maximum and minimum bounds in the azimuthal direction.

Open with DEXTER
3 Results
3.1 Comparison of MITHIC bench and simulation results
Figure 5 shows the results of the most important convergence test performed on MITHIC, the details of which are listed in the first row of Table 1. This test applied a static 319 nm PVE LWE wavefront phase pattern on the SLM, which was chosen to provide half a wave of error at the 677 nm MITHIC laser wavelength. For the purposes of F&F this is directly equivalent to solving a 724 nm PVE LWE in the Hband, which is close to the strongest LWE amplitudes regularly seen onsky with SPHERE. The setup did not contain a SPHERE aperture mask but used a clear circular pupil: regions of LWE wavefront phase corresponding to the VLT M2 obscuration and support spiders were therefore set to zero phase. In addition to the LWE, 39 nm RMS of loworder aberrations were also applied on the SLM, with coefficients randomly drawn from the first 19 Zernike modes. The image S/N and 32 × 32 pixel FOV were chosen to be representative of DTTS images, and a weak onaxis apodiser was included in the beam. Corrections were made on the SLM by first projecting the output of F&F onto a combination of the segmented PTT mode basis and a 50mode loworder Zernike basis, and then spatially filtering to mimic the finite actuator influence function of the 41 × 41 actuator SAXO DM. This was achieved by convolving the resulting phase map with a Gaussian of fullwidth halfmaximum equal to two thirds of the SAXO actuator spacing, which is qualitatively representative of the resolution seen in reference slope control tests by Sauvage et al. (2016a). By not applying phase corrections at the full 273 × 273 pixel resolution ofthe Hamamatsu SLM with which the aberrating phase was initially implemented, we mimicked the interplay between a finite resolution DM and nondiscrete upstream aberrating wavefront, thereby providing a better estimate of the correcting power of the SPHERE DM.
The topleft image row shows initial and final PSFs taken at high S/N, showing the clear improvement in Strehl ratio from 68% to 93% associated with the elimination of LWE and the majority of the loworder wavefront within five closedloop iterations. The residual wavefront error maps show that the uncorrected wavefront error was dominated by highfrequency components along the edges of the spiders and along one edge of the pupil. This was a result of the DMlike spatial filtering of the correction wavefront, and is representative of the capabilities of such an implementation onsky.
In the righthand panel, the image Strehl ratio is directly compared for each iteration between MITHIC data and an average of ten simulations matching the laboratory conditions. Multiple simulations were run in order to place a limit on the reproducibility of convergence under noisy conditions, with only the individual pixeltopixel noise allowed to vary between realisations. This plot shows that there is an extremely close match between predicted and obtained performance in this scenario, with very similar final Strehl ratios achieved and laboratory convergence only very slightly lagging behind the simulated curve. It was also estimated from SHWFS measurements during this convergence process that there existed approximately 10 nm RMS of residual NCPE in the system, for which F&F is in principle also capable of correcting. This means that the laboratory implementation was dealing with additional wavefront error when compared to the simulated case, which may explain this small decrease in convergence efficiency.
All Strehl ratios for MITHIC bench images quoted in this paper were estimated according to a modified encircled energy metric described by
is the ratio of encircled energies between the Airy core and first Airy ring of the given PSF p, which provides an estimate of image quality using the regions visible above the noise floor. As the encircled energy metric systematically overestimates the true Strehl ratio of MITHIC images p_{MITHIC} by ignoring highfrequency aberrations, the second term in Eq. (10) used to account for this bias using the known true Strehl ratio S_{sim} and encircled energy of the simulated PSF p_{sim} of matched simulations. Such a correction was possible due to the close consistency between laboratory and simulation results, such that the correction factors could be expected to be very similar for the two cases. This metric was chosen over more readily available metrics such as using the SLM residual wavefront map or a reference image PSF from the MITHIC bench, as these can be biased by factors such as residual NCPEs or intensity variations in the system, and in practice were seen to occasionally predict Strehl ratios of greater than one.
Table 1 also summarises the laboratory performance obtained with F&F in MITHIC for a range of additional key tests, which illustrate the behaviour of the algorithm under variable conditions. It can be seen that for all but the final three test cases F&F returned the image Strehl ratio to over 90%, a gain of typically greater than 20% on the starting value. The rightmost column quotes the postconvergence RMS wavefront error, which was in most cases estimated directly from the last phase command applied on the SLM after closedloop convergence. These RMS residuals were found to be typically on the same order as the 10 nm RMS MITHIC bench alignment residual after HASO precompensation, and agree well with the quoted Strehl ratios through the use of the Maréchal approximation. In cases where the target wavefront error was not injected with the SLM, such as when using the turbulence screen LWE aberration or removing the MITHIC bench wavefront flat command, this approach is inherently biased. For these tests the estimate of the final RMS residual was then simply made using the Maréchal approximation with the final image Strehl ratio. For the final three test cases, the aim was not to correct all wavefront error present in the system but to leave specific aberrations uncorrected, in a manner which would allow F&F to solve only LWElike wavefronts without impacting the system NCPE budget. These cases are discussed in more detail in bullet point 8 below, and in Sect. 4.
The following specific observations can be made about the performance of F&F by comparing the various scenarios presented in Table 1:
 1.
Fieldofview: shrinking the square FOV available to F&F from 100 to 32 pixels had only a few percent impact on final PSF quality (rows 9 & 10); this was likely due to the removal of highorder wavefront information from the PSF supplied to F&F.
 2.
Signaltonoise: lowering the image S/N by a factor of 16, from 6380 to 382 (rows 2 & 7), had a negligible impact on final performance in the highS/N regime (see Sect. 3.2 for a simulated treatment of lowS/N performance).
 3.
Choice of mode basis: comparing the use of segmented PTT (row 9) and 50mode Zernike (row 8) bases shows that, as expected, Zernikes were less able to replicate the highfrequency LWE wavefront. There is negligible difference between a PTTonly basis and the full PTT + Zernike basis (row 7), although the latter is expected to perform better in the presence of additional nonLWE aberrations, or for erroneous pupil rotation angles where the PTT basis is no longer a good description of the LWE wavefront.
 4.
Using no mode basis: comparing the 100 × 100 pixel FOV PTT basis test (row 10) with a comparable test applying only Gaussianfiltered (i.e. DMresolution) F&F outputs without mode basis projection (row 13) shows that using the PTT basis actually resulted in a three percent increase in final Strehl ratio. This can be attributed to the effective removal of unwanted highfrequency noise propagation and pupil asymmetry systematics from the F&F output estimates by the tailored mode basis.
 5.
Wavefront corrector resolution: disabling the DMlike Gaussian spatial filtering and applying corrections at the full resolution of the SLM had negligible impact on the final correction performance (rows 10 & 11). In this case the maximum correctable spatial frequency was effectively set by the FOV of DTTS images. Residual wavefront error maps show highfrequency residuals around the locations of the spiders for filtered wavefront tests as in Fig. 5, however these result in only a small amount of additional diffraction along the spiders and hence have a low impact on Strehl ratio.
 6.
Pupil apodisation: a weak, onaxis pupil apodiser (row 5, and topcentre panel of Fig. 4) in fact resulted in marginally better performance than the equivalent unapodised case (row 7) despite F&F calculations still assuming a uniform pupil; this is attributed to the suppression of highorder aberrations. F&F was still stable in the presence of a stronger, asymmetric apodisation of the pupil which even exhibited some vignetting (row 4, and topright of Fig. 4) when the algorithm was still not provided with the modified pupil function, showing only a few percent loss in Strehl compared to the above cases. This indicates that F&F is extremely stable against unknown amplitude aberrations, and even severe pupil misalignments which violate the evenpupil assumption implicit in F&F. For this particular application it is therefore unnecessary to implement additional amplitude retrieval steps (such as the FFGS extension to F&F mentioned in Sect. 2.1) to ensure robust performance in SPHERE.
 7.
Source of phase aberrations: F&F was equally capable of correcting strong aberrations from external (nonSLM) sources (row 3) as it was for SLMinduced aberrations (row 1), returning both to a final estimated Strehl ratio above 90%. This indicates a sufficiently accurate orientation, alignment, and phasetovoltage calibration of SLM commands was achieved for closedloop correction.
 8.
Applying reference offsets: attempting to make F&F insensitive to PSF centre by removing global tiptilt components in the output wavefront (row 14) or attempting to induce specific wavefront reference offsets by manually subtracting them from the F&F output on each iteration (row 15) resulted in unstable convergence and were not viable methods for this implementation of F&F (see below and Sect. 4 for details). Using the natural lack of sensitivity of a PTTonly basis to loworder Zernike modes to try and correct only the LWE component of an aberrated wavefront (row 16) resulted in a stable convergence, however the final correction may have included some unwanted partial compensation of nonLWE errors, as the final residual RMS error of 64 nm was smaller than the 77 nm of loworder (i.e. nonLWE) aberrations initially applied on the SLM.
As with the main results presented in Fig. 5, the various test cases presented in Table 1 were found to be highly representative of closedloop simulations directly emulating the conditions of each test case, indicating that F&F was performing very close to the expected level in this MITHIC implementation. The predictive power of these simulations extends to the identification of the two key limitations so far identified for F&F; a sensitivity to the centroid zeropoint of the PSF in the image (row 14), and difficulty effectively converging to a nonflat wavefront via direct reference phase map subtraction (row 15). In both cases divergent behaviour was seen to set in within ten iterations after an initial improvement in wavefront quality, and therefore it is important to evaluate the underlying causes and potential solutions; this analysis is presented in Sect. 4.
Fig. 5
Comparison of F&F convergence behaviour between MITHIC laboratory data and equivalent simulations (see Table 1, row 1 for details). Left: highresolution, highS/N MITHIC focalplane images (top) andcorresponding residual wavefront error maps (bottom), before and after F&F correction (first and second columns respectively). Highfrequency residuals visible in the final wavefront error map are dominated by fitting error enforced by the DMlike filtering of wavefront corrections. Right: plot of estimated image Strehl ratio as a function of closedloop iteration number, showing close agreement between a single convergence of MITHIC data (red) and an average of ten simulations (blue), with shading denoting the 1σ limit. The two inset images show the N = 0 and N = 25 DTTSlike input focalplane images provided for F&F for wavefront reconstruction.

Open with DEXTER
Summary of the key parameters of all laboratory F&F convergence tests performed on the MITHIC bench.
3.2 Simulated lowS/N performance of F&F
One of the most important concerns with using the SPHERE DTTS as a focalplane wavefront sensor is that the low throughput to the DTTS camera results in low S/N images, especially for faint targets. The DTTS control loop is typically operated at a cadence of 1 Hz and is designed to function down to a S/N of approximately ten, and so F&F should also be stable under these conditions. However, any attempt to sense LWElike wavefronts from focalplane images will ultimately be limited by the S/N of the first Airy ring, which corresponds to the dominant spatial frequencies present in this type of wavefront. This forms a significantly stronger S/N constraint than that required for simple tiptilt correction using the PSF core, and will by necessity limit the efficiency of LWE correction at low S/N.
Figure 6 illustrates the simulated performance of F&F as a function of input image S/N, at the laboratory wavelength of 677 nm for comparison with MITHIC results. This was performed in the absence of atmospheric residuals or NCPEs, with only the 319 nm PVE LWE phase aberration (identical to that used for MITHIC bench tests) present. Each data point shows the average final Strehl ratio and wavefront error of ten independent simulations each of 25 iterations, such that the error bars provide an estimate of the postconvergence frametoframe stability of F&F. Here all S/N values are quoted for the central pixel of the PSF, and in all simulations a constant value of ϵ = 10^{−3} was used for wavefront reconstruction. It can be seen from the red (upper) data points that the algorithm is stable over the entire range of S/N values, and still makes some statistical improvement to the wavefront quality even at the minimum S/N of five. Above this the residual wavefront error declines logarithmically, and Strehl ratios of greater than 95% are achieved for S/N greater than 100. The blue (lower) residual RMS wavefront error data points also provide a useful estimate of the S/Nlimited sensitivity of this implementation of F&F to lowamplitude aberrations. This curve is consistent with the equivalent MITHIC test result (row 2 of Table 1), which for an image S/N of 382 achieved 20 nm of residual RMS error. This is equivalent to a sensitivity limit of 45 nm RMS in the Hband, since F&F operates in radians and so performance can be expected to scale linearly with wavelength.
Such robust performance at low S/N was only possible with the use of an adaptive focalplane spatial filter to attenuate pixeltopixel noise. This filter modifies the input DTTS PSF p by smoothly replacing noisedominated pixels with the reference (diffractionlimited) PSF , such that F&F sees the higher spatial frequencies as perfect and so provides zero correction on these scales. The resulting filtered PSF p_{filt} is defined by
is a radial sigmoid windowing function with a critical cutoff radius of r_{c}. This critical radius is defined to be the point at which the local maxima of the diffractionlimited PSF first drop below a critical S/N of 2.5, which in this instance was found to be an acceptable balance between rejecting noise and preserving wavefront information in the image. It may be possible to further improve the performance of this filter by optimising the functional form for w(r), for instance by using the generalised logistic function. A detailed investigation is however beyond the scope of this paper.
For comparison, the red shaded curve shows the natural behaviour of F&F in the absence of an appropriate spatial filter, using the full noisy 32 × 32 pixel FOV as the input. In this case the pixeltopixel noise at high spatial frequencies is directly propagated into strong modal noise in the final correction, resulting in a rapid divergence in wavefront quality below a S/N of 20. With spatial filtering applied it can be seen that the algorithm instead “fails gracefully”, simply correcting less of the aberrating wavefront as the corresponding spatial frequencies fall below the image noise threshold. This improved approach also achieves a final postconvergence wavefront quality of better than 40 nm RMS and stability of better than 20 nm RMS 1σ jitter for all but the lowest S/N values, which can most likely still be improved by more careful optimisation of the adaptive spatial filter profile and cutoff radii as a function of S/N.
For any given observing conditions it should also be possible to further improve F&F performance by stacking individual 1 s DTTS frames for a longer effective exposure and hence higher S/N, provided that the correction cadence remains significantly shorter than the variability timescale of the LWE. A recent study of the morphology and temporal evolution of the LWE as seen by the SPHEREIRDIS subsystem (J.F. Sauvage 2017, priv. comm.) concluded that under typical conditions (1 m s^{−1} wind speed, average LWE of 600 nm PVE, 10 Hz imaging cadence) the majority of the LWErelated structures were coherent on timescales of longer than 10 s, although some small amount of shortterm variability was also observed. Frame stacking up to this 10 s threshold would facilitate an additional S/N boost of a factor of three, which even for a faint target with a 1 s exposure image S/N of ten would return image S/N to the regime in Fig. 6 where we can expect final corrected Strehl ratios of 90% or greater, corresponding to the removal of the majority of lowfrequency LWE error and a significant reduction of spider diffraction effects. In general however, it is advantageous to sense and correct at least ten times faster than the shortest wavefront coherence timescale of interest. This means that F&F will most likely perform better when operated at the fastest cadence (i.e. with the lowest image S/N) which can be expected from Fig. 6 to provide sufficiently good correction for any given application.
Fig. 6
Simulated convergence quality of F&F as a function of image S/N, for halfwave (319 nm) PVE LWE at awavelength of 677 nm. Top image row: Initial DTTS images at specific S/N, showing increasing visibility of the aberrated first Airy ring. Bottom image row: Final noiseless images after 25 F&F iterations, showing acorresponding improvement in final PSF quality. Main panel: Plot of final Strehl ratio (red) and residual RMS wavefront error (blue) as a function of initial S/N. Each point is the average of ten simulations. The black horizontal line denotes both the starting Strehl ratio and wavefront error RMS, of 74% and 59 nm respectively. The shaded red line shows the Strehl ratio behaviour for F&F using the full 32 × 32 pixel DTTS image as input (i.e. without an adaptive spatial filter), with the shaded region below S∕N = 20 denoting the region where this implementation diverges.

Open with DEXTER
4 Discussion
It is important to discuss the two key limiting factors identified in F&F, which are found both in simulations and MITHIC lab tests as mentioned in Sect. 3.1. The first of these is sensitivity to the centroid location of the image PSF: the tiptilt zeropoint to which F&F will try to converge is set by the centroid location of the reference PSF , and so the algorithm naturally attempts to apply global tiptilt corrections if the image centroid differs from this reference. While this tiptilt correction was observed to be robust up to a dynamic range of approximately 1 radian, it raises the potential for loop conflict if the F&F zeropoint differs from that of the main tiptilt sensing loop for which the DTTS is primarily used, or if frametoframe DTTS tiptilt correction residuals approach 1 radian. It is therefore desirable to make F&F completely insensitive to tiptilt error, for which the naïve approach is to directly subtract any measured global tiptilt components from the output wavefront estimate. However, this approach only results in the buildup of differential tiptilt between individual VLT pupil segments and a slow divergence of wavefront quality over time. This is because F&F is not a perfect oneshot phase reconstructor: the exact tilts measured across each pupil segment tend to differ slightly from the global gradient, with the residual between the two still included in the wavefront correction command. As F&F is still sensitive to the subtracted global tiptilt error on each subsequent iteration, this residual differential tiptilt map is reapplied on each iteration and thus builds up steadily over over time. The DTTS image can always be recentred to pixel precision by shifting the image array (in this case corresponding to a precision of 0.3 λ∕D) to somewhat limit the extent of this centroiding issue, however the best approach is instead to ensure that the reference PSF p_{0} is constructed to exactly match the zero point of the DTTS to subpixel accuracy, thereby ensuring that there are no conflicts between the two correction loops.
The other outstanding issue associated with tiptilt control is whether a stable, converged F&F control loop adds any additional positional jitter to the PSF, and whether this remains within the specifications of the SPHERE design requirements for coronagraph centring. This was investigated on the MITHIC bench for the main 25iteration convergence test, previously presented in Fig. 5 and row 1 in Table 1. The absolute deviation of the PSF centroid from its mean location at 3.3 pixels per λ∕D focalplane sampling is shown for all frames in Fig. 7, comparing F&F control with a short reference image sequence at the same cadence, containing only the natural bench image jitter without an active control loop. This shows that F&F achieved subDTTS pixel stability with an RMS of one tenth of a pixel, equivalent to 0.03 λ∕D and hence 1.2 mas onsky for SPHERE, only slightly higher the natural bench jitter of 0.02 λ∕D (0.8 mas). It is likely that this result was dominated by normal thermal and mechanical fluctuations in the MITHIC optical path, given the low temporal bandwidth of the manual F&F control loop and the lack of any other form of active PSF centring control. The onsky positional stability of SPHERE on the other hand is dominated by the telescope highfrequency vibration environment, with a target of 3 mas (0.07 λ∕D) RMS required for baseline coronagraph operation (Fusco et al. 2016). If it may be assumed that F&F would add the same amount of additional jitter as was seen in MITHIC, this would constitute only a few percent of the total error budget. Due however to the fact that F&F would contribute at frequencies between 0.1–10 Hz depending on correction cadence (which is significantly slower than the 10–100 Hz vibrations limiting SPHERE stability), a more detailed investigation would be needed to determine its exact impact on the SPHERE vibrational error budget.
The second known limitation is in attempting to force F&F to converge to a specific nonflat wavefront, which is in general a useful feature enabling the application of controlled reference wavefront offsets. In this case, the differential optical pathbetween the DTTS and IRDIS focal planes is known to contain 20 nm of static focus error plus some additional higher order NCPEs, which ideally should not be introduced into the science beam by a DTTSbased WFS. While it was found in simulations that the most straightforward approach of subtracting the fixed reference offset from the F&F output wavefront on each iteration is stable in the noiseless case, under realistic conditions the ϵ regularisation parameter in Eq. (5) (which is typically chosen to be comparable to the image noise floor) results in a systematic underestimation of the even wavefront. As for the case of the global tiptilt drift phenomenon described above, this results in the injection of the residual between the sensed and true offset phase map on each iteration, resulting in the divergent behaviour seen in row 14 of Table 1. While it is possible to systematically ignore specific modes entirely (for example focus or astigmatism) by subtracting the measured coefficient of that mode from the raw F&F output wavefront before final mode basis projection, it is unclear how this would affect the efficiency of LWE correction: the segmented PTT basis is not fully orthogonal to such Zernike modes, and astigmatism in particular is typically present in the LWE wavefronts we wish to correct.
Attempts to modify the F&F algorithm itself to properly treat reference offsets are ongoing, however this is made challenging by the fact that the simplifying assumption of a real, even pupil function necessary for an analytical solution also prevents direct modification of the target PSF to include reference phase aberrations, i.e. . This is because a number of terms in the original Taylor expansion of the PSF which correspond to noneven and complex aperture terms are deliberately neglected from the derivation before arriving at Eq. (1) in order to obtain an analytical solution for the focal plane fields. Because these neglected terms now become significant, such a substitution for a is no longer valid. A generalised version of F&F capable of arbitrary wavefront reference offsets would also be of great interest for operation with coronagraphic images, especially the apodising phase plate (APP) coronagraph (Kenworthy et al. 2010; Snik et al. 2012; Otten et al. 2017). However, given the low level of NCPEs in the SPHERE case of interest there would be a minimal impact on science image Strehl ratio associated with allowing free convergence to the DTTS focalplane: the small degradation in image quality is expected to be vastly outweighed by the gain in raw contrast performance from controlling the LWE. In highS/N environments, it would also be expected that using F&F to stabilise NCPEs up to the NIR coronagraph with a general Zernike mode basis would also provide an improvement in final highcontrast imaging performance despite inducing 20 nm of static focus error into the science beam.
The results presented in this paper are somewhat idealistic in that they assume the XAO system is composed of the sole DM component to which the output phase commands from F&F can be accurately implemented via phase conjugation. In reality, correction must be achieved by modifying reference slope offsets on the SAXO SHWFS during operation of the main XAO sensing and correction loop. In addition to the potential for control loop conflicts, it is currently unknown how this approach will filter the high spatial frequencies present in the LWE wavefront, and at what point the finite dynamic range of the SHWFS will limit the correction of highamplitude LWE cases. The remaining stroke on the SAXO DM during closedloop operation will also determine how effectively the highest amplitude LWE cases can be corrected. For example, an 800 nm PVE LWE would constitute 11% of the total ± 3.5 μm SPHERE DM stroke and 26% of the ± 1.2 μm interactuator stroke (Fusco et al. 2006). Since the LWE occurs under good seeing conditions where there is less strain on the AO system, it is likely that almost all LWE cases would see significant improvement before being limited by DM saturation. Due to the complicating factors listed here, applying any form of focalplane wavefront control using the SPHERE DM and SHWFS is clearly still an important area to be addressed, and may require the development of a dedicated control scheme. However, initial tests have been encouraging in showing that the DM can accurately reconstruct a strong differential piston via the reference offset approach in both open and closed loop, with the width of the phase discontinuity boundary at pupil segment edges consistent with the influence function of the DM actuators (Sauvage et al. 2016a).
Altogether it is expected that with appropriate calibration the current implementation of F&F is capable of providing at least an order of magnitude of raw contrast improvement in SPHERE coronagraphic imaging performance at 2–4λ∕D in typical LWEaffected cases for S/N greater than 20, by returning the distorted first Airy ring to neardiffractionlimited performance(see Fig. 2). Additional gains may also be made in postprocessing if F&F has sufficient image S/N to stabilise quasistatic speckle structure, allowing for more effective reference PSF subtraction or removal via ADI or PCAbased PSF subtraction techniques. By running in continuous closedloop mode, onsky performance can also be expected to be superior to that presented in Fig. 6 and Wilby et al. (2016), since both this work and the previous study are concerned with compensating an established LWE wavefront error. Provided that F&F is operated above the critical cadence of ten times the variability timescale of PTT wavefront errors as they arise. In lowS/N cases a pistononly correction loop can still be expected to reduce the impact of many LWE wavefronts on the coronagraphic PSF, and is also less likely to conflict with the main AO loop as the SHWFS is in principle insensitive to differential piston aberrations.
Fig. 7
Impact of closedloop F&F correction on the tiptilt stability of the MITHIC bench. Main panel: measured radial offsets from the mean PSF centroid location as a function of iteration number, for the headline MITHIC F&F convergence test of Fig. 5 (blue) and a set of reference images containing only natural MITHIC bench image jitter (red). F&F convergence is taken to be achieved after five iterations. Inset panels: the central 0.3 λ/D pixels of the mean reference image (left) and the F&Fcorrected image (right) respectively, each overplotted with the centroid data used to compute jitter estimates. Dashed crosshairs show the mean PSF centroid for each dataset, showing that F&F applies a systematic subpixel offset to align the PSF with its internal reference zeropoint.

Open with DEXTER
5 Conclusions
We have demonstrated that the Fast & Furious sequential phase diversity algorithm is capable of robustly eliminating strong LWE wavefronts in the MITHIC highcontrast laboratory testbench environment, where it reliably returned image Strehl ratios to better than 90% within five closedloop iterations. This was achieved in the presence of strong static loworder aberrations, low S/N, and small FOV images representative of the SPHERE DTTS, but in the absence of incoherent atmospheric speckle residuals or an active primary XAO loop, and assumed an idealised SPHERE DM response for correction. We find no significant discrepancies between these MITHIC laboratory results and the predictions of dedicated LWE simulation code (Wilby et al. 2016) designed to emulate focalplane wavefront sensing with the DTTS sensor. Therefore, further work carried out using this code is expected to be representative of performance achievable with F&F onsky with the SPHERE instrument.
Supporting simulations showed that this implementation of F&F is also stable over the full working S/N range of the DTTS sensor down to at least S∕N = 5, and is capable of efficiently removing the dominant structures of the LWE for S∕N ≥ 20. For targets where this condition can be satisfied for correction cadences faster than the dominant LWE variability timescale (estimated from IRDIS observations to be longer than 10 s) an onsky implementation of F&F should be capable of effectively maintaining a neardiffractionlimited PSF core under the strongest LWE conditions routinely seen by SPHERE. Such an improvement is expected to provide at least an order of magnitude gain in raw contrast over typical LWEaffected PSFs close to the coronagraphic innerworking angle, greatly improving the ultimate contrast performance of the SPHERE instrument under the best seeing conditions.
Further efforts will focus on understanding the interplay between F&F and a realistic AO environment, including the spatial filtering properties of WFS reference slope offset based control, and the potential for conflicts in a multicontrol loop system. It is also of great interest to develop a generalised version of the algorithm which is capable of converging to arbitrary nonflat reference wavefronts: in addition to providing greater flexibility for closedloop control, this would also allow F&F to operate directly with many types of coronagraphic science image.
In addition to this specific application for controlling the LWE in SPHERE, the stability and versatility of F&F makes the algorithm highly suitable for other realtime focalplane wavefront control tasks, such as NCPE correction or mirror cophasing of segmented telescopes, provided that narrowband image data is available at a sufficiently fast cadence. With instances of the more general “island effect” now being repeatedly seen in highcontrast instruments beyond the VLT, it is clear that focalplane wavefront control methods such as F&F could become increasingly essential for the field. This will be especially important for the upcoming ELTclass telescopes, which will feature highly segmented pupils and a large amount of obscuring support structure. It can be expected that these telescopes will be more prone to island effect and LWE phenomena than simple fourquadrant pupil geometries, and without appropriate mitigation strategies these effects may severely limit the performance of their XAOfed highcontrast instruments. The computational simplicity of F&F allows it to scale efficiently to work with highresolution deformable elements, and in principle makes it sufficiently fast for highspeed (kHz) wavefront control applications: this makes it an attractive focalplane phase control solution for both current and future instruments.
Acknowledgements
The authors would like to thank the anonymous referee, whose helpful comments have significantly improved the contents of this paper. We would also like to acknowledge the contribution of A. Vigan for the development of the MITHIC testbench and turbulence simulation module used in this work, which is supported by the ASOREX project grant, Région ProvenceAlpesCôte d’Azur, 201402976. This work is funded by the NederlandseOnderzoekschool Voor Astronomie (NOVA), via the NOVA4 EPICS R&D support grant, and is also supported by a grant from the French Labex OSUG@2020 (Investissements d’avenir − ANR10 LABX56). SPHERE is an instrument designed and built by a consortium consisting of IPAG (Grenoble, France), MPIA (Heidelberg, Germany), LAM (Marseille, France), LESIA (Paris, France), Laboratoire Lagrange (Nice, France), INAF − Osservatorio di Padova (Italy), Observatoire astronomique de l’Université de Genéve (Switzerland), ETH Zurich (Switzerland), NOVA (Netherlands), ONERA (France) and ASTRON (Netherlands) in collaboration with ESO. SPHERE was funded by ESO, with additional contributions from CNRS (France), MPIA (Germany), INAF (Italy), FINES (Switzerland), and NOVA (Netherlands). SPHERE also received funding from the European CommissionSixth and Seventh Framework Programmes as part of the Optical Infrared Coordination Network for Astronomy (OPTICON) under grant number RII3Ct2004001566 for FP6 (20042008), grant number 226604 for FP7 (20092012), and grant number 312430 for FP7 (20132016).
References
 Amara, A., & Quanz, S. P. 2012, MNRAS, 427, 948 [NASA ADS] [CrossRef] [Google Scholar]
 Baudoz, P., Dorn, R. J., Lizon, J.L., et al. 2010, in Groundbased and Airborne Instrumentation for Astronomy III, Proc. SPIE, 7735, 77355B [CrossRef] [Google Scholar]
 Beuzit, J.L., Feldt, M., Dohlen, K., et al. 2008, in Groundbased and Airborne Instrumentation for Astronomy II, Proc. SPIE, 7014, 701418 [CrossRef] [Google Scholar]
 Bonnefoy, M., Zurlo, A., Baudino, J. L., et al. 2016, A&A, 587, A58 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 de Boer, J., Salter, G., Benisty, M., et al. 2016, A&A, 595, A114 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 ESO. 2016, SPHERE user manual, Period 99, Phase 1 (6th release), https://www.eso.org/sci/facilities/paranal/instruments/sphere/doc.html, accessed 20170206 [Google Scholar]
 Fusco, T., Petit, C., Rousset, G., et al. 2006, in Society of PhotoOptical Instrumentation Engineers, Proc. SPIE, 6272, 62720K [Google Scholar]
 Fusco, T., Sauvage, J.F., Petit, C., et al. 2014, in Adaptive Optics Systems IV, Proc. SPIE, 9148, 91481U [CrossRef] [Google Scholar]
 Fusco, T., Sauvage, J.F., Mouillet, D., et al. 2016, in Proc. SPIE, 9909, 99090U [Google Scholar]
 Ginski, C., Stolker, T., Pinilla, P., et al. 2016, A&A, 595, A112 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Gonsalves, R. A. 2001, Opt. Lett., 26, 684 [NASA ADS] [CrossRef] [Google Scholar]
 Gonsalves, R. A. 2002, in European Southern Observatory Conference and Workshop Proceedings, eds. E. Vernet, R. Ragazzoni, S. Esposito, & N. Hubin, 58, 121 [Google Scholar]
 Guerri, G., Daban, J.B., RobbeDubois, S., et al. 2011, Exp. Astron., 30, 59 [NASA ADS] [CrossRef] [Google Scholar]
 Jovanovic, N., Martinache, F., Guyon, O., et al. 2015, PASP, 127, 890 [NASA ADS] [CrossRef] [Google Scholar]
 Keller, C. U., Korkiakoski, V., Doelman, N., et al. 2012, in Adaptive Optics Systems III, Proc. SPIE, 8447, 844721 [CrossRef] [Google Scholar]
 Kenworthy, M. A., Quanz, S. P., Meyer, M. R., et al. 2010, in Groundbased and Airborne Instrumentation for Astronomy III, Proc. SPIE, 7735, 773532 [CrossRef] [Google Scholar]
 Korkiakoski, V., Keller, C. U., Doelman, N., et al. 2012, in Adaptive Optics Systems III, Proc. SPIE, 8447, 84475Z [CrossRef] [Google Scholar]
 Korkiakoski, V., Keller, C. U., Doelman, N., et al. 2014, Appl. Opt., 53, 4565 [NASA ADS] [CrossRef] [Google Scholar]
 Lafrenière, D., Marois, C., Doyon, R., Nadeau, D., & Artigau, É. 2007, ApJ, 660, 770 [NASA ADS] [CrossRef] [Google Scholar]
 Lamb, M., Correia, C., Sauvage, J.F., et al. 2016, in Adaptive Optics Systems V, Proc. SPIE, 9909, 99096D [Google Scholar]
 Macintosh, B. A., Graham, J. R., Palmer, D. W., et al. 2008, in Adaptive Optics Systems, Proc. SPIE, 7015, 701518 [CrossRef] [Google Scholar]
 Maire, A.L., Bonnefoy, M., Ginski, C., et al. 2016, A&A, 587, A56 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Marois, C., Lafrenière, D., Doyon, R., Macintosh, B., & Nadeau, D. 2006, ApJ, 641, 556 [NASA ADS] [CrossRef] [Google Scholar]
 N’Diaye, M., Dohlen, K., Tisserand, S., et al. 2011, in Optical Fabrication, Testing, and Metrology IV, Proc. SPIE, 8169, 81690G [CrossRef] [Google Scholar]
 N’Diaye, M., Dohlen, K., Caillat, A., et al. 2014, in Adaptive Optics Systems IV, Proc. SPIE, 9148, 91485H [Google Scholar]
 N’Diaye, M., Vigan, A., Dohlen, K., et al. 2016, A&A, 592, A79 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 N’Diaye, M., Martinache, F., Jovanovic, N., et al. 2018, A&A, 610, A18 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Otten, G. P. P. L., Snik, F., Kenworthy, M. A., et al. 2017, ApJ, 834, 175 [NASA ADS] [CrossRef] [Google Scholar]
 Paul, B., Sauvage, J.F., Mugnier, L. M., et al. 2014, in Groundbased and Airborne Instrumentation for Astronomy V, Proc. SPIE, 9147, 91479O [Google Scholar]
 Roberts, Jr. L. C., Perrin, M. D., Marchis, F., et al. 2004, in Advancements in Adaptive Optics, ed. D. Bonaccini Calia, B. L. Ellerbroek, & R. Ragazzoni, Proc. SPIE, 5490, 504 [NASA ADS] [CrossRef] [Google Scholar]
 Roddier, F., & Roddier, C. 1997, PASP, 109, 815 [NASA ADS] [CrossRef] [Google Scholar]
 Sauvage, J.F., Fusco, T., Rousset, G., & Petit, C. 2007, J. Opt. Soc. Am. A, 24, 2334 [NASA ADS] [CrossRef] [Google Scholar]
 Sauvage, J.F., Fusco, T., Guesalaga, A., et al. 2015, in Adaptive Optics for Extremely Large Telescopes IV (AO4ELT4), E9 [Google Scholar]
 Sauvage, J.F., Fusco, T., Lamb, M., et al. 2016a, in SPIE Conf. Ser., Proc. SPIE, 9909, 990916 [Google Scholar]
 Sauvage, J.F., Fusco, T., Petit, C., et al. 2016b, J. Astron. Telesc. Instrum. Syst., 2, 025003 [NASA ADS] [CrossRef] [Google Scholar]
 Snik, F., Otten, G., Kenworthy, M., et al. 2012, in Modern Technologies in Space and Groundbased Telescopes and Instrumentation II, Proc. SPIE, 8450,84500M [CrossRef] [Google Scholar]
 Soummer, R., Pueyo, L., Sivaramakrishnan, A., & Vanderbei, R. J. 2007, Opt. Exp., 15, 15935 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Soummer, R., Pueyo, L., & Larkin, J. 2012, ApJ, 755, L28 [NASA ADS] [CrossRef] [Google Scholar]
 Vigan, A., Bonnefoy, M., Ginski, C., et al. 2016a, A&A, 587, A55 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Vigan, A., Postnikova, M., Caillat, A., et al. 2016b, in SPIE Conf. Ser., Proc. SPIE, 9909, 99093F [Google Scholar]
 Wilby, M. J., Keller, C. U., Sauvage, J.F., et al. 2016, in SPIE Conf. Ser., Proc. SPIE, 9909, 99096C [Google Scholar]
 Zurlo, A., Vigan, A., Galicher, R., et al. 2016, A&A, 587, A57 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
