Nonparametric determination of H and He interstellar fluxes from cosmicray data
^{1}
LPSC, Université GrenobleAlpes, CNRS/IN2P3,
53 avenue des Martyrs,
38026
Grenoble,
France
email:
alexandre.ghelfi@lpsc.in2p3.fr; david.maurin@lpsc.in2p3.fr
^{2}
LIP, 1000
Lisboa,
Portugal
Received:
27
November
2015
Accepted:
26
March
2016
Context. Topofatmosphere (TOA) cosmicray (CR) fluxes from satellites and balloonborne experiments are snapshots of the solar activity imprinted on the interstellar (IS) fluxes. Given a series of snapshots, the unknown IS flux shape and the level of modulation (for each snapshot) can be recovered.
Aims. We wish (i) to provide the most accurate determination of the IS H and He fluxes from TOA data alone; (ii) to obtain the associated modulation levels (and uncertainties) while fully accounting for the correlations with the IS flux uncertainties; and (iii) to inspect whether the minimal forcefield approximation is sufficient to explain all the data at hand.
Methods. Using H and He TOA measurements, including the recent highprecision AMS, BESSPolar, and PAMELA data, we performed a nonparametric fit of the IS fluxes J^{IS}_{H,~He} and modulation level φ_{i} for each datataking period. We relied on a Markov chain Monte Carlo (MCMC) engine to extract the probability density function and correlations (hence the credible intervals) of the sought parameters.
Results. Although H and He are the most abundant and best measured CR species, several datasets had to be excluded from the analysis because of inconsistencies with other measurements. From the subset of data passing our consistency cut, we provide readytouse bestfit and credible intervals for the H and He IS fluxes from MeV/n to PeV/n energy (with a relative precision in the range [ 2−10% ] at 1σ). Given the strong correlation between J^{IS} and φ_{i} parameters, the uncertainties on J^{IS} translate into Δφ ≈ ± 30 MV (at 1σ) for all experiments. We also find that the presence of ^{3}He in He data biases φ towards higher φ values by ~30 MV. The forcefield approximation, despite its limitation, gives an excellent (χ^{2}/d.o.f. = 1.02) description of the recent highprecision TOA H and He fluxes.
Conclusions. The analysis must be extended to different charge species and more realistic modulation models. It would benefit from the AMS02 unique capability of providing frequent highprecision snapshots of the TOA fluxes over a full solar cycle.
Key words: astroparticle physics / Sun: activity / cosmic rays
© ESO, 2016
1. Introduction
H and He interstellar (IS) fluxes are the most abundant species in the cosmic radiation. The lowenergy part of their spectrum (MeV/n to GeV/n) is responsible for ionising the interstellar medium (ISM; Webber 1987; Nath & Biermann 1994; Webber 1998; Nath et al. 2012) and molecular clouds (e.g. Padovani et al. 2009). They also interact with the ISM to produce light LiBeB isotopes (Reeves 1970; Meneguzzi et al. 1971; VangioniFlam et al. 2000; Prantzos 2012) and nuclear γrays (Meneguzzi & Reeves 1975; Lingenfelter & Ramaty 1977; Ramaty et al. 1979; Kozlovsky et al. 2002; Tatischeff & Kiener 2004). Uncertainties on the lowenergy IS flux shape affect all these quantities (Indriolo et al. 2009). The highenergy part of the IS flux (from GeV/n to PeV/n) is involved in the secondary production of γrays, neutrinos, antiprotons, and positrons (Strong et al. 2007). In particular, the hint at an energy break at hundreds of GeV energy (Ahn et al. 2010; Adriani et al. 2011; Ackermann et al. 2014), now confirmed by the AMS02 collaboration (Aguilar et al. 2015a,b), must be accounted for as it affects the number of secondaries created (Donato & Serpico 2011; Lavalle 2011). All these observables underline the necessity of a description as accurate as possible of the H and He IS fluxes over a wide energy range.
A standard approach is to rely on topofatmosphere (TOA) data and simultaneously fit the IS flux parameters and solar modulation parameters (GarciaMunoz et al. 1975; Casadei & Bindi 2004; O’Neill 2006; Shikaze et al. 2007)^{1}. At the crossroad of cosmicray and solar physics, these data give a unique perspective on the IS fluxes and the 22year modulation cycle related to solar activity. The difficulty is that we do not know which solar modulation model (and parameters) to apply, but these models can be tested with highstatistics TOA data. We restrict ourselves in the present work to the simple forcefield approximation (Gleeson & Axford 1967, 1968; Perko 1987; Boella et al. 1998), which, despite some limitations (e.g. CaballeroLopez & Moraal 2004), is still widely used in the literature owing to its simplicity; it depends on a single free parameter φ(t).
Uncertainties on the IS fluxes translate into uncertainties on the solar modulation parameters. For instance, dark matter interpretations of the antiprotons and positrons fluxes are sensitive to φ uncertainties (e.g. Lavalle et al. 2014; Giesen et al. 2015). In general, there is no consensus on the required modulation level for a given data set and no consistency (of method and assumptions) between the various evaluations of φ provided by different experimental teams (see the discussion in Maurin et al. 2014), which is problematic. Also directly related to the correlation between the IS flux and modulation level is the difficulty of establishing reliable and consistent modulation timeseries from groundbased detector count rates (Usoskin et al. 2011) and/or from the concentration of cosmogenic radionuclides in ice cores (Webber & Higbie 2003; Herbst et al. 2010). As underlined in several studies, the use of several IS flux parametrisations (GarciaMunoz et al. 1975; Burger et al. 2000; Langner et al. 2003; Webber & Higbie 2003, 2009; O’Neill 2006; Shikaze et al. 2007) leads to shifts of these time series up to Δφ ~ ± 200 MV (e.g. Maurin et al. 2015). This motivates us even more to find a better characterisation of the IS flux, modulation level, and of the correlations between these parameters. The recent publication of highprecision data from PAMELA (Adriani et al. 2014), BESSPolar (Abe et al. 2016), and AMS02 (Aguilar et al. 2015a,b) is also a strong incentive to repeat and improve on the procedure of extracting these quantities from TOA CR data.
In Sect. 2 we describe the use of spline fit functions (in lieu of less flexible parametrisations previously used in the literature) to achieve a nonparametric determination of the H and He fluxes^{2}. A simple χ^{2} analysis is then used to select the subset of CR TOA data passing a consistency criterion. In Sect. 3 we replace the χ^{2} analysis by a Markov chain Monte Carlo (MCMC) exploration of the parameter space to obtain the credible intervals (CIs) and correlations between IS flux and modulation parameters. We also compare our results to the recent lowenergy Voyager data, which are considered to be a direct probe of the local IS fluxes (Stone et al. 2013; Webber & Higbie 2013; Webber et al. 2013a,b), and to the indirect observation of IS fluxes in the direction of molecular complexes from FermiLAT γray data (Neronov et al. 2012; Kachelrieß & Ostapchenko 2012; Yang et al. 2014; Strong 2015), before concluding in Sect. 4. The short Appendix A investigates possible systematic effects on the φ determination that are due to deuteron and ^{3}He contamination in H and He fluxes (Appendix A.1), or when using TOA data obtained from long datataking periods (Appendix A.2).
2. Methodology
To perform the analysis, the modulation model, the parametrisation of the IS flux, and the set of CR TOA data used for the minimisation must be specified. In this section, we present our setup, emphasising on the improvements made with respect to previous studies.
2.1. Modulation: forcefield approximation
The simplest modulation model to link unmodulated (IS) to modulated (TOA) quantities is the forcefield approximation (Gleeson & Axford 1967, 1968): (1)where E is the total energy, p the momentum, and J ≡ dJ/ dE_{k/n} is the differential flux per kinetic energy per nucleon E_{k/n}. This model has a single free parameter φ(t), whose dimension is rigidity.
2.2. Analysis and χ^{2}
The approach to break the degeneracy between J^{IS} and φ is to simultaneously fit s different snapshots { t_{1}...,t_{s} } of the same CR species N_{j} and/or n different CR species { N_{1}...,N_{n} } at the same t_{i}. In the former approach, we benefit from sampling the same IS flux at the cost of one additional modulation parameter per snapshot: depending on the data precision and the periods used, ideally both high and low solar activity periods, the degeneracy is mostly lifted, although some significant uncertainties can remain (e.g. Maurin et al. 2015). In the second approach, the modulation level φ(t_{i}) is now the quantity sampled several times by different species, each new species requiring several additional shape parameters: the benefit is that species with different Z/A (e.g. proton and helium) are differently modulated, even in the simple forcefield approximation (see Eq. (1)). More generally, species with different charges (e.g. electrons and positrons) can probe different modulation models as a dependence on Z is expected for example in drift modulation models (see Potgieter 2013, for a review).
The χ^{2} for a simultaneous fit over the TOA flux snapshots t_{i}, with several possibly measured species N_{j}(i) at this t_{i}, and over all E_{k}(i,j) energy bins measured, is given by (2)where the free parameters are the IS flux parameters for each species and the modulation parameters per TOA flux snapshot. The three cases considered in this study all involve fits over different snapshots { t_{1}...,t_{s} } for

p data only,

He data only, and

p and He data simultaneously.
The last option enables checking the consistency of the modulation levels derived with the values obtained from the separate species analysis (see Sect. 3).
2.3. Nonparametric IS flux: splines
Fits of the IS fluxes in the literature are mostly based on simple power laws in total energy (e.g. O’Neill 2006; Yang et al. 2014) or rigidity (e.g. Shikaze et al. 2007; Maurin et al. 2014). Recently, to account for the highenergy break, broken powerlaws were proposed (Donato & Serpico 2011; Lavalle 2011; Aguilar et al. 2015a). Whereas these parametrisations are flexible enough to describe the smooth behaviour above tens of GeV/n energies, the lowenergy behaviour governed by a β^{a} term (in front of the powerlaw) does not offer enough freedom to fit the logparabolashaped TOA flux. We find that pure and broken power laws in rigidity, kinetic energy, and total energy (i) give poor fits to the data for all parametrisations (χ^{2}/d.o.f. ~ 1.6−1.8); (ii) do not allow assessing the relative merit of the different parametrisations, which complicates the task of providing a statistically meaningful description of the IS fluxes and their uncertainties.
To solve these problems, we used a spline function, which gives an excellent fit of the TOA data (χ^{2}/d.o.f. ≲ 1, see below) and also encompasses all the above parametrisations. A spline is a piecewise function defined by polynomials connecting at knots. The order of the spline is related to the highest order n of the polynomial used, and smoothness is guaranteed by the fact that continuity of the spline and its n − 1 derivatives are imposed. Here, we used a cubic spline (n = 3) in x = log (R) and y = log (J^{IS}), with R = pc/Ze the rigidity in GV. The yvalues (flux) are the free parameters of the fit, while the number of knots N and their xposition (rigidity) have to be set carefully to describe the shape of the data correctly. No structures are expected at low energy in the IS fluxes, therefore a small number of knots is enough to reproduce the smooth shape. Several knots are needed at and around the highenergy break position (Aguilar et al. 2015a) to be able to match the structure. We find that at least six knots from 1 GV to 800 GV are necessary to provide a good description of the IS fluxes. The positions of the knots are the same for both H and He and are taken to be (3)As a sanity check, we added at random xpositions additional knots and repeated the fitting analysis (described below). No difference in the bestfit spectrum being observed, we conclude that the sixknot thirdorder spline function provides a nonparametric determination of the IS fluxes.
2.4. Data selection
We retrieved TOA CR data for H and He from the cosmicray data base CRDB^{3}(Maurin et al. 2014). In principle, all the data should be used in the analysis. However, inconsistencies between different measurements are common, especially for the oldest datasets. To identify and then reject these inconsistent datasets, we performed a χ^{2} minimisation on all p data, see Eq. (1), for which we relied on the Minuit minimisation package (James 1994) from the Root CERN libraries^{4}(Brun & Rademakers 1997). For each dataset, we then calculated an a posteriori distance between the data and the globally determined bestfit TOA flux for this set: (4)We then excluded all data with . Strictly speaking, this quantity is just a distance and has no statistical bearing, but it nevertheless gives a good estimate of the goodness of fit of each dataset (see the values obtained in Table 1). This procedure accounts for modulation effects, hence allows checking the TOA data consistency over their full energy range.
List of proton and helium data tested and rejected (italics) for the analysis.
In practice, the procedure must be repeated several times because values are modified each time noncompatible datasets are removed, as shown in Table 1. Surprisingly, the AMS01 and PAMELA (2006−2008) He data do not pass the cut. This is illustrated in Fig. 1, which represents (symbols) the ratio between the bestfit model ( modulated by the associated φ_{best}) to TOA data. For good data, this ratio is mostly contained in the data error bars (solid and dashed lines for p and He, respectively). AMS01 He data (empty red circles in topleft panel) are an illustration of rejected data. We note that inconsistencies in the data at low energy may be indicative of a failure of the simple forcefield approximation we used and not of underestimated systematics in the data, for instance. More realistic modulation models will be investigated in a forthcoming study. However, Fig. 1 shows for the very case of AMS01 He data that the inconsistency with other datasets is not related to solar modulation as differences are at high energy.
From comparing the results from one experiment to another, we see no clear trend for a systematic bias towards lower or higher values of the fluxes. The only case for which a pattern in the energy dependence is observed is for the various PAMELA data because they come from the same experimental setup and same analyses. This is not seen for BESS experiments, the configuration of which slightly changes between different flights.
Fig. 1 Ratio of the bestfit model for p (filled black circles) and He (empty red circles) to data for the experiments passing our selection (see Table 1). The solid blue (dashed red) lines correspond to the uncertainties (statistical and systematics combined) on the p (He) measurements. We note that the AMS01 (top left panel) and PAMELA (2006−2008) He data (red empty circles; left panel, third row) are excluded based on their χ^{2} value (see Table 1) and are shown for illustration only.

Open with DEXTER
We underline that neither Table 1 nor Fig. 1 show all the data rejected by the analysis. Moreover, some data were not considered for the MCMC analysis of Sect. 3 for the following reasons:

At low energy (≲GeV/n): several lowenergy datasets passed the cut (several sets for ISEEMEH, Kroeger 1986, and Voyager, Webber & Yushak 1983), but as they have no effect on the result (as checked from the χ^{2} minimisation analysis), we discarded them to avoid increasing the number of parameters (and runtime) in the MCMC analysis.

At intermediate energy: several datasets have a limited energy range with large error bars, hence no effect on the fit. For the same reason as above, they were not considered in the MCMC analysis.

At high energy (≳10 TeV/n): we recall that these data are not sensitive to solar modulation, but they determine the highenergy IS flux shape. We discarded them as the data are mostly inconsistent with one another (especially for He, see Fig. 5).
3. Markov chain Monte Carlo analysis
On these data we used a Markov chain Monte Carlo (MCMC) algorithm as implemented in the GreAT package (Putze & Derome 2014) to determine the probability density functions (PDF), correlations, and CIs for φ and IS flux parameters.
3.1. MCMC algorithm
The MCMC algorithm is based on the Bayes theorem that links the multidimensional PDF of the parameters to the likelihood function of the model and the prior on each parameter: (5)with θ corresponding to all IS flux and solar modulation parameters, and data the selected subset of experiments (see Sect. 2.4). In the Bayesian interpretation of statistics, the function describes our prior knowledge on each parameter, and we took here a flat prior for all parameters. For the likelihood, with χ^{2} defined in Eq. (2), we used
The algorithm, based on random numbers, generates a chain θ_{i = 1...N} of N elements based on the following iterative process (see e.g. Putze et al. 2009):

1.
Randomly pick θ_{0} in the parameter space as the starting point of the chain; the current point is defined as θ_{current} = θ_{0}.

2.
Propose a new point θ_{proposed} from a proposition function, here a multidimensional Gaussian, centred on θ_{current}.

3.
Compute the probability of θ_{proposed}and apply the MetropolisHastings criterion (Neal 1993; MacKay 2003): θ_{proposed} is added to the chain and becomes the new current point θ_{current} with a probability If θ_{proposed} does not pass this criterion, θ_{current} is added instead.

4.
Repeat 2 until the chain has N elements.
The chain is Markovian, meaning that the sampling of θ_{i + 1} only depends on the value θ_{i}. This implies a correlation between the consecutive values of θ in the chain. This correlation is corrected for by calculating the correlation length to select independent samples of θ^{i}. A burning length is computed to estimate the number of steps needed to forget about the starting point, and these points are removed; for more details, see Putze et al. (2009) and Putze & Derome (2014). This procedure ensures that the multidimensional PDF of the parameters is correctly sampled. The outputs of the MCMC algorithm are

a natural marginalisation of the multidimensional PDF PDF(θ  data) to access the 1D and 2D PDFs of the parameters, and

a vector of the model parameters that can be straightforwardly used to calculate CIs on quantities derived from the parameters (e.g. the IS fluxes for p and He).
Fig. 2 PDF (diagonal) and 2D correlations (offdiagonal) plots for three selected knots y = log J^{IS}(R) at position { R_{0},R_{1},R_{3} } = { 1 ,7 ,100 } GV and φ for three highstatistics datasets AMS02, BESSPOLARII, and PAMELA (2006−2008): positive correlations are observed for all lowenergy knots and datasets; knots above 100 GV show no correlation with any other parameter (the parameter distribution only depends then on the data uncertainties).

Open with DEXTER
3.2. Results of the MCMC analysis
The marginalised PDFs for a selected subset of the IS flux and modulation parameters are presented in Fig. 2. The PDFs for and φ are close to Gaussian. The 2D PDFs show strong and expected correlations between the lowenergy proton IS flux and the solar modulation levels: an increase of the IS flux must be balanced by an increase of the modulation level to recover the same TOA flux. The typical ≲10% uncertainty on (or dispersion between) the data at GeV/n energies (see Fig. 1) translates into a similar uncertainty on φ values (see Fig. 3) and on at GV rigidities (see Fig. 4). At high enough energy, as shown for the knot at R = 100 GV (third parameter in Fig. 2), the IS flux is no longer correlated to φ. This reflects that solar modulation changes become irrelevant compared to data uncertainties (or dispersion between datasets).
Fig. 3 PDF of the solar modulation level φ for the three most recent datasets with the highest statistics. We show the results for a fit on all selected data from Table 1, for p data alone (blue solid line), He data alone (red dashed line), and p and He data simultaneously (black dashdotted line).

Open with DEXTER
As underlined in Sect. 2.2, the analysis can be performed separatley for proton and helium data or for both simultaneously (to probe the consistency of the derived φ values). The TOA data uncertainties propagate to the IS flux parameters, and then to φ values because of the correlations seen in Fig. 2. Figure 3 shows the PDF of φ_{AMS−02} (top), φ_{BESS−POLARII} (middle), and φ_{PAMELA} (bottom)^{5}. The widths of the PDFs obtained in these three examples are representative of the width obtained for less accurate or lowerstatistics experiments, indicating that the TOA data dispersion (between different experiments) dominates the TOA data uncertainties. We observe (at 1σ) typically Δφ_{p} ≈ ± 10 MV for the ponly analysis and Δφ_{He} ≈ ± 30 MV for both the Heonly and p and He simultaneous analyses. The larger uncertainty for He is the result of a larger scatter in He data than in p data (He data uncertainties are similar to proton uncertainties, see in Fig. 1), which is explained by the fact that He is less abundant and more difficult to measure. The central value for the φ_{p + He} analysis is in between φ_{p} and φ_{He}. We note that for the dataset where only p data are available (e.g. PAMELA, bottom panel), the PDF obtained for the p and He simultaneous analysis is also wider than for the ponly analysis because of the correlations between the parameters. Table 2 gathers the median and 68% CI on the modulation level φ for the experiments selected in this analysis.
More important from Fig. 3 is the fact that the φ_{p} and φ_{He} values are not compatible at the 3σ level. This could be an indication that the forcefield approximation is rejected by the data. However, first, the best d.o.f. values for the bestfit models found in the MCMC chains are 0.26 and 0.71 for these two analyses, possibly indicating an underestimation of the data uncertainties. For comparison, the p and He simultaneous analysis gives a very good fit with d.o.f. = 1.02. Second, as shown in Appendix A.1 on simulated data, the isotopic contamination of ^{2}H and ^{3}He leads to biased φ values, with an overshoot larger by typically ~50 MV for φ_{He} than for φ_{p}. This allows us to reconcile the results of the ponly and Heonly analyses. To reduce and eventually eliminate this bias, highprecision data (e.g. from AMS02) are desired.
φ values obtained with the MCMC analysis for each experiment.
Fig. 4 Proton (blue) and helium (red) IS fluxes obtained from the various MCMC analyses. Top panel a): 68%, 95%, and 99% CIs (from darker to lighter shade) from the p+He analysis. The fluxes are multiplied by for illustration purposes. Middle panel b): 68% CI uncertainties for the p+He fluxes. Bottom panel c): comparison of the ponly and Heonly analyses to the p+He analysis. The solid lines correspond to the ratio of the median fluxes, the dashdotted and dashed lines are for the 68% CIs.

Open with DEXTER
3.3. Credible intervals (CI) on J^{IS}
For each point θ in the MCMC chain, we can compute the associated p and He IS fluxes at any energy. For each of these energies, we thus have a distribution of values from which we can calculate the PDF and CI; for rigidity values corresponding to the spline knots, the IS flux PDF at that point is directly the PDF from the MCMC analysis (see Fig. 2). In Fig. 4 the top panel shows in various shades of blue (p) and red (He) the 68%, 95%, and 99% CI on the IS flux (from the p+He simultaneous analysis). The middle panel shows the 68% contours divided by the median flux to emphasise the uncertainties: we have ΔJ/J ≲ 10% at GeV/n, ΔJ/J ≲ 5% above 1 TeV/n, and ΔJ/J ≲ 2% in between. The uncertainties for p and He are of the same order of magnitude. The bottom panel shows a comparison of the ponly and Heonly analyses to the p+He simultaneous analysis (ratio of the median and 68% contour to the median p+He flux). The median flux for p is unchanged, and the ponly analysis leads to smaller uncertainties (compare the blue curves in panels b and c). The He fluxes are more sensitive to the analysis chosen, but they are compatible within their 95% CIs (not shown). This last panel illustrates the fact that the fit is driven by p data, so that the p+He combined analysis only affects He. As for the modulation parameters (see Sect. 3.2), it also illustrates the effect of correlations in the determination of the IS flux parameters because the p+He simultaneous analysis enlarges the uncertainties on the proton IS flux.
Fig. 5 Same as Fig. 4, but compared to other direct or indirect IS flux determinations. Top panel a): green (Orion A) and grey (Perseus OB2) dashed areas are γray derived limits from local giant molecular clouds using FermiLAT data (Yang et al. 2014); symbols are for lowenergy Voyager 1 measurements (Stone et al. 2013) and highenergy data. Bottom panel b): thick lines are from the 68% CI of this analysis; shaded areas correspond to the 68%CI from a likelihood analysis of FermiLAT γray emissivity, and PAMELA (2006−2008) plus AMS01 (1998) p+He+e^{+}+e^{−} analysis (Casandjian 2015); chained lines are from a χ^{2}minimisation analysis of BESS data (Shikaze et al. 2007).

Open with DEXTER
3.4. Comparison with other determinations
The top panel of Fig. 5 shows comparisons with

a proton flux estimate from nearby giant molecular clouds in the Gould Belt. These fluxes are derived from γray data, assuming that the interactions of CR with the ambient gas are fully responsible for the FermiLATobserved fluxes (Yang et al. 2014). We find a very good match for the highestemitting clouds (Orion A and Perseus OB2). Yang and collaborators compared their fluxes to the modulated PAMELA data (their Figs. 5 and 6) and found an excess below 10 GeV/n, which might be interpreted as CR that are locally accelerated inside the cloud; when we compare this to our IS flux instead, this turns into a deficit for most of the clouds that might be explained by increased energy losses and destruction of CRs in the clouds.

For the sake of completeness, we also compared our highenergy extrapolation (above the vertical arrow) to highenergy data that were not included in the fit: ATIC (Panov et al. 2009), CREAMI (Yoon et al. 2011), JACEE (Asakimori et al. 1998), MUBEE (Zatsepin et al. 1993), PAMELACALO (Adriani et al. 2013c), RICHII (Diehl et al. 2003), RUNJOB (Derbina et al. 2005), and SOKOL (Ivanenko et al. 1993). Given the discrepancies between the datasets, our extrapolation is a fair estimate of the IS flux at these high energies.
The bottom panel of Fig. 5 shows the ratio of various parametrisations of IS fluxes to our bestfit result, compared to the 68% CIs on our IS fluxes (dashed and dashdotted lines):

the bestfit and (shaded) contours of Casandjian (2015) were derived with a likelihood analysis based on PAMELA (2006−2008) and AMS01 (1998) data (considering p, He, but also e^{+} and e^{−}), plus the use of FermiLAT data on γray emissivities. Overall, using more recent and more data yields smaller CIs. At high energies, the two results are not consistent within their 68% CIs. At low energy, our smaller error bars may result from the use of a more flexible parametrisation (spline) than is the pure powerlaw used in Casandjian (2015).

The bestfit fluxes (solid lines) of Shikaze et al. (2007) result from a fit to all BESS data in which the authors relied on a pure powerlaw. The highenergy feature is caused by the break in our parametrisation. In the energy range where both their fit and ours are not extrapolated, the largest difference between the two p parametrisations is ~30% at 100 GeV/n, with their He flux systematically lower than ours.
3.5. IS flux parametrisation with and without Voyager data
It is also interesting to compare our flux derived from TOAonly data to the Voyager 1 data (Stone et al. 2013). The latter are believed to provide a direct measurement of the local IS (LIS) flux outside the solar cavity. However, the possibility of a small radial gradient in the outer heliosheath over hundreds of AU remains (Scherer et al. 2011; Kóta & Jokipii 2014). This must be balanced by indirect arguments (Lallement et al. 2014) and simulation of this region (Guo & Florinski 2014; Luo et al. 2015; Zhang et al. 2015) that support the hypothesis that Voyager has indeed reached the LIS.
To test the consequences of the two above alternatives, we added Voyager data (open circles in Fig. 5) to the analysis. We then compared the results for the modulation values and IS fluxes obtained with and without Voyager data, either letting φ_{Voyager} be a free parameter or enforcing it to be zero. In the former case, the bestfit with Voyager data is φ_{Voyager} = 65 MV, without a modification of the IS fluxes. Conversely, if Voyager data are interstellar, we must enforce φ_{Voyager} = 0: in that case, we observe (i) a decrease of ~62 MV on φ values for all other experiments; (ii) a worsened χ^{2}/d.o.f. = 1.27; and (iii) a lower bestfit IS flux at low energy (see longdashed curves in Fig. 5). We did not repeat the MCMC analysis because the (very small) Voyager uncertainties (Stone et al. 2013) certainly do not include all the systematics.
Given the important role played by the H and He IS fluxes, we provide a simple implementation of our IS fluxes as a mixture of a logpolynomial and powerlaw extrapolation (spectral index ): (6)Table 3 provides all theses coefficients for two cases (both obtained from the p+He simultaneous analysis):

the first five columns provide coefficients for the median and CIsfrom the MCMC analysis (without Voyager data), to beconsidered as a high estimate of the H and He IS fluxes (not validbelow 400 MeV/n), and

the last column provides the bestfit including Voyager data (with φ_{Voyager} = 0), to be considered as a low estimate of the IS H and He fluxes.
Coefficients for H (top) and He (bottom) IS fluxes as parametrised by Eq. (6).
4. Conclusion
We have revisited the determination of IS fluxes and solar modulation parameters from TOA data alone. We took advantage of recent highstatistics experiments (AMS02, BESSPolar, PAMELA), we relied on a nonparametric fit of the IS fluxes (based on spline functions), and we used an MCMC to extract the PDF, CIs, and the correlation between the sought parameters. A preliminary step of the analysis was a consistency check that allowed rejecting some of the data. With the remaining data, we obtained reliable constraints on the p and He IS fluxes in the region of GeV/n to several hundreds of TeV/n. These fluxes are very important for many applications in the literature (ISM ionisation, CR secondary production, etc.), therefore we provide in Table 3 readyto use parametrisations based on our bestfit and IS flux contours with and without Voyager data.
Correlations between IS flux parameters and solar modulation parameters were found to be important to estimate all the CIs properly. We studied p and He separately or simultaneously to check the consistency of the modulation (most experiments measured p and He data during the same period). Although the preferred φ values are slightly different in the separate analyses, the simultaneous p+He analysis gives a very good fit (χ^{2}/d.o.f. =1.02) to all the data, with a 1σ uncertainty of 30 MV. As in many previous studies, H and He data are assimilated to pure ^{1}H and ^{4}He. However, we have shown that the presence of ^{2}H and ^{3}He leads to a ~30 MV positive bias in the p+He analysis, which is already similar to the systematic uncertainty. The bias is dominated by the presence of ^{3}He in He (~50 MV bias in the Heonly analysis), therefore this contamination needs to be accounted for in future studies.
From the data we conclude that the simple forcefield approximation is effective in providing a good description (within the uncertainties) of the modulated p and He fluxes at Earth. The situation may change because AMS02 data have the capability and the statistics to provide monthly, weekly, or even daily average fluxes. This could be used to check the limitation of the forcefield (or more evolved models, e.g. Corti et al. 2015 and Cholis et al. 2016) over a full solar modulation cycle, in particular during a solar polarity change. Adding more species to the analysis, for example, e^{+} and e^{−}(Casadei & Bindi 2004), or even antiprotons, is the obvious next step to proceed with characterising IS CR fluxes and the solar modulation.
Note added in proof. During the completion of this work, we became aware of a related study by Corti, Bindi, Consolandi and Whitman (Corti et al. 2015). It focuses on the IS proton flux and explores a modulation model beyond the forcefield approximation. The data sets and methods both differ from those of our study, making the two analyses complementary. A comparison of their proton IS flux (obtained with the energydependent solar modulation parameter) and ours (obtained in the forcefield approximation) shows a very good agreement in the range 4 GV−1 TeV, but with different uncertainties.
Variations on this approach are to use IS fluxes obtained from cosmicray propagation codes (e.g. Putze et al. 2011), and/or the sparser radialdependent CR data (Burger et al. 2000; Langner et al. 2003; Webber & Higbie 2009) in the context of more realistic modulation models.
Throughout the paper, we refer indifferently to p or H to denote the proton flux; see discussion in Appendix A.1.
Acknowledgments
We thank J.M. Casandjian for providing the values of his IS flux determination, and C. Combet for a careful reading of the manuscript. This work has been supported by the “Investissements d’avenir, Labex ENIGMASS” and by the French ANR, Project DMAstroLHC, ANR12BS050006. This study used the CCIN2P3 computation center of Lyon.
