1. Introduction

Solar irradiance is the main external energy source of the Earth’s climate system and, therefore, measurements of its variation are crucial to disentangle the influence of the Sun on climate from other sources. The available measurements (for recent reviews see Ermolli et al. 2013; Kopp 2014; Yeo et al. 2014a) are accurate enough to clearly show a relative change in the total solar irradiance (TSI) of up to ~0.3% and ~0.1% on timescales of the solar rotation and the 11-yr solar cycle, respectively. This relative variation is wavelength-dependent, increasing strongly towards shorter wavelengths. Although wavelengths above 400 nm (i.e. in the visible and infrared) contribute more than 90% to the TSI, the relative variability at these spectral ranges over the solar cycle is only of the order of 0.1%. In contrast, between 200 and 300 nm the relative variability over the solar cycle is 1–10%, and reaches 50% or more at wavelengths below 200 nm (Floyd et al. 2003a; Krivova et al. 2006).

While direct measurements of the total and spectral solar irradiance cover the past four decades almost continuously, climate studies require even longer time series to investigate, for example, the effects of irradiance changes in the Ocean-Atmosphere coupling (see Haigh 2001; Solanki et al. 2013, and references therein). Additionally, instrumental degradation, sensitivity changes and differences in the absolute values of the various radiometers introduce uncertainties in the observed trends of the irradiance variation on timescales longer than the solar cycle (e.g. Ermolli et al. 2013). In such cases when longer and continuous time series of irradiance are needed, models are crucial to extend irradiance records into the past.

Most successful models of solar irradiance assume that its variation on timescales longer than a day is due to the evolution of the magnetic fields on the solar surface (e.g. Foukal & Lean 1988; Fligge et al. 2000; Krivova et al. 2003; Wang et al. 2005; Crouch et al. 2008). The Spectral and Total Irradiance REconstructions (SATIRE) set of models (Krivova et al. 2011) are based on this assumption. The SATIRE-S (S for Satellite era) model in particular supports this idea since it is based on direct and detailed measurements of the solar surface magnetic fields (magnetograms) and has been able to reproduce more than 90% of the measured variation of TSI (Krivova et al. 2003; Wenzler et al. 2006; Ball et al. 2012; Yeo et al. 2014b). The recording of daily full-disc magnetograms started in 1974, and therefore, proxies of the photospheric magnetic fields are needed to extend the models further into the past.

SATIRE-T (for Telescope era; Krivova et al. 2007, 2010) employs a physical model to calculate the time-varying photospheric magnetic flux integrated over the whole solar surface, from the sunspot number (Solanki et al. 2002; Vieira & Solanki 2010). This model can thus reconstruct irradiance back to the Maunder minimum. The next step towards realism was taken by Dasi-Espuig et al. (2014), who presented the SATIRE-T2 model (for the Telescope era, version 2) that uses magnetograms simulated with a surface flux transport model (SFTM) based on sunspot group areas and positions (Cameron et al. 2010; Jiang et al. 2010, 2011b). This model allowed a reconstruction of the TSI starting in 1878. Employing the simulated magnetograms improved the agreement between the modeled and measured TSI on rotational timescales, since the SFTM uses the information on the spatial distribution of the magnetic features and thus allows a more realistic representation of the evolution of magnetic fields on the solar surface. It also accounts for the centre-to-limb variation of the contrast of magnetic features.

Here we present an extension of the SATIRE-T2 model to reconstruct the total and spectral solar irradiance between 115 nm and 160 μm starting in 1700. Since the sunspot group area record starts in 1874, to extend the reconstructions back to 1700 we used the same SFTM as in Dasi-Espuig et al. (2014), but this time fed with the semi-synthetic sunspot group records following Jiang et al. (2011a,b). These records obey the statistical relationships between the properties of sunspot group emergence seen in the Royal Greenwich Observatory (RGO) data set (such as the mean latitude, latitude distribution, areas, and tilt angles, e.g., Solanki et al. 2008; Dasi-Espuig et al. 2010, 2013), and the cycle strength and phase obtained from the sunspot group number.

The paper is structured as follows. The SFTM and the semi-synthetic sunspot group records are introduced in Sect. 2. In Sect. 3 we briefly describe the SATIRE-T2 model, validate it against available observations of the total magnetic flux and TSI, and explain the extension going back to 1700. Section 4 presents the results of the total and spectral irradiance reconstructions since the end of the Maunder minimum and compares them to previous studies. Finally, in Sect. 5 we summarise our results.

2. The photospheric magnetic flux

2.1. Active region flux

The SFTM describes the transport of the large-scale magnetic fields in the photosphere under the effects of large-scale surface flows: differential rotation, meridional flow, and turbulent diffusivity (for a review of the model see Jiang et al. 2014b). The sources of magnetic flux in the SFTM are the active regions, which are composed of sunspots and faculae. For sunspot areas and positions we used semi-synthetic records of sunspot groups derived from the sunspot group number (Hoyt & Schatten 1998), Rg, starting in the year 1700. The facular areas and positions were then computed based on the sunspot group areas and positions as described below. The model parameters used here are taken from observations and are the same as in Jiang et al. (2011b) and Dasi-Espuig et al. (2014).

The semi-synthetic sunspot group records are based on the statistical relationships between the properties of sunspot group emergence and cycle strength and phase derived by Jiang et al. (2011a). These records include area, position, and tilt angle of sunspot groups at the time when each group reaches its maximum area. Jiang et al. (2011a) used data from the RGO, the sunspot number and the tilt angle data from Mount Wilson and Kodaikanal Observatories (e.g Howard et al. 1984; Sivaraman et al. 1993). From the RGO record the authors selected groups only once, at the time they reached the maximum area; from the sunspot number they obtained the strength and phase of a cycle; and from the tilt angle data they obtained the mean tilt angle of sunspot groups emerging in each cycle. They then derived statistical relationships that describe the dependence of the mean latitude, the width of the latitude distribution, the mean tilt angle, and the area distribution of the observed sunspot groups at the time they reach maximum area, with the strength and phase of a cycle. This was done for the time when there is an overlap between the time series, i.e. 1874 to 1976 (cycles 12–20) for the RGO data and 1913 to 1986 (cycles 15–21) for the tilt angle data. Finally, the total number of groups emerging in a month (NSG) was normalised to match the number of groups emerging in a month as recorded in the RGO data set (NSG = Rg/2.1). The sunspot groups were then distributed randomly in time throughout the days of a month.

We extrapolated the statistical relationships described above to extend the RGO record back to 1700. We thereby implicitly assume that the dynamo has operated in a similar way over the past three centuries. Note that during the Maunder minimum, i.e. before 1700, the dynamo might have operated in a different manner (Usoskin et al. 2001, 2015; Owens et al. 2012).

An individual semi-synthetic record containing the time of maximum area, latitude, area and tilt angle was drawn from a population that obeys the observed statistical relationships. The longitude positions were obtained by distributing groups randomly within ±70° of the central meridian for each day. Although we used the same SFTM as in Jiang et al. (2011b), here we did not consider active longitudes when constructing the semi-synthetic records. Thus the open flux during cycle maxima is weaker than computed by Jiang et al. (2011b) and reconstructed from geomagnetic data by Lockwood et al. (2009, 2014) that focused on the evolution of the open flux. The difference is within 20% at these times for each cycle (cf. Fig. 6 of Jiang et al. 2011b). The active longitudes are an important ingredient in the evolution of the solar open flux during cycle maxima, but have no significant effect on the total magnetic flux (Wang & Sheeley 2002) and therefore we do not expect significant changes in irradiance either.

For each active region, the sunspot group area, As, is provided by the semi-synthetic records, and the facular area, Af, was computed using the empirical relationship taken from Chapman et al. (1997) between sunspot and facular areas. We assume that the ratio of facular to sunspot areas has not changed from cycle to cycle over the past ~3 centuries. The total area of the emerging active region, AR, was thus obtained as AR = As + Af.

The SFTM produces a daily map of the magnetic field on the photosphere for the whole Sun (i.e. a cylindrical map) which we convert into simulated magnetograms by projecting the portion of the solar surface facing the Earth each day (within ±90° of the central meridian) onto a disc (for details see Dasi-Espuig et al. 2014).

2.2. Ephemeral region flux

The SFTM does not include magnetic flux emerging in ephemeral regions and therefore the ephemeral region magnetic flux (ΦER) was modeled separately in the same manner as in Dasi-Espuig et al. (2014) following Krivova et al. (2007, 2010) and Vieira & Solanki (2010). Detailed studies of ephemeral regions in cycles 19–23 have shown that the number of such regions varies cyclically over time in phase with the solar cycle, but their duration is longer, starting before and ending after the corresponding sunspot cycle (Harvey 1992, 2000). Therefore, we linked the amplitude and length of the ephemeral region cycles to those of the corresponding sunspot cycles based on the Rg record. The relationships that provide the link contain two free parameters: the amplitude, X, and the time extension, cx, of the ephemeral region cycles (for more details see Dasi-Espuig et al. 2014).

The values of X and cx were kept constant over the whole period considered in this study, and therefore we assume that the dynamo has behaved in the same way since 1700. Between about 1650 to 1700, the Sun was in a state of a grand minimum (Maunder minimum), when extremely few sunspots were observed (Eddy 1976; Hoyt & Schatten 1998; Usoskin et al. 2016). Our model, therefore, does not produce ephemeral regions at this time as they are linked to the sunspot cycle. 10Be cosmogenic isotope data have indicated that the solar cycle continued throughout the Maunder minimum, albeit in too weak a manner to produce sunspots, and thus producing only faculae and ephemeral regions (Beer et al. 1998; Usoskin et al. 2016). If true, the relationships used here may not be valid during times of grand minima, and would mean that the reconstructed irradiance is too low between about 1700 and 1715, i.e. the change in the TSI since the Maunder minimum obtained with this model would be an upper limit. On the other hand, we have assumed that for a given magnetic flux, network elements (including ephemeral active regions) have the same brightness contrast to the quiet Sun as active region faculae. If the network elements turn out to be brighter (e.g. Solanki 1986; Ortiz et al. 2002; Yeo et al. 2013), then the change in TSI since the Maunder minimum would be larger than the value obtained here.

Note that the monthly smoothed sunspot number during cycle 24 reached a maximum of 81.9 in April 20141. We have updated the present study (with respect to Dasi-Espuig et al. 2014) to obtain the magnetic flux from ephemeral regions corresponding to cycle 24, that are present during the end of cycle 23.

3. Irradiance

The SATIRE-T2 model classifies the photospheric magnetic features into 4 main classes: sunspot umbra (u), sunspot penumbra (p), active region faculae (f), and network produced in the ephemeral regions (e). Regions free of magnetic fields correspond to the quiet Sun (q). The irradiance of each component is given by its corresponding intensity spectrum and the fraction of the solar surface it covers.

The intensities are time-independent, but depend on the wavelength and the heliocentric angle θ (where μ = cosθ). We employed the intensities I(μ,λ) computed by Unruh et al. (1999), who used the spectral synthesis code ATLAS9 of Kurucz (1992). The sunspot umbrae and penumbrae are described by radiative equilibrium models (Kurucz 1991) with effective temperatures of 4500 K and 5450 K, respectively; the quiet Sun is represented by the standard solar model atmosphere of Kurucz (1992), and the faculae by a modified version of FAL-P (Fontenla et al. 1993).

The fraction of the solar surface covered by each component varies with time as the photospheric magnetic field evolves. The area coverage of sunspots and faculae is obtained from the semi-synthetic records (see Sect. 3.1) and the simulated magnetograms, respectively, and is given by spatially-resolved filling factors. These filling factors refer to the fraction of all pixels within limb intervals of [μ − Δμ/ 2,μ + Δμ/ 2] (Δμ is typically 0.01) that are filled by a particular magnetic feature. They are denoted by α(μ,t). For the ephemeral regions we used the (disc-integrated) area coverage, fe(t), since their magnetic flux in our model was provided separately from the SFTM, for the whole disc (see Sect. 2.2).

We calculated the spectral irradiance as follows: S(t,λ)=∑μ[αu(μ,t)Iu(μ,λ)+αp(μ,t)Ip(μ,λ)+αf(μ,t)If(μ,λ)+αq(μ,t)Iq(μ,λ)]+fe(t)Ff(λ)−fe(t)Fq(λ),\begin{eqnarray} S(t,\lambda)&=&\sum_{\mu} \bigg[\alpha^{\rm u}(\mu,t) I^{\rm u}(\mu,\lambda) + \alpha^{\rm p}(\mu,t) I^{\rm p}(\mu,\lambda) \nonumber \\ && + \alpha^{\rm f}(\mu,t) I^{\rm f}(\mu,\lambda) + \alpha^{\rm q}(\mu,t) I^{\rm q}(\mu,\lambda) \bigg] \\ &&+ f^{\rm e}(t) F^{\rm f}(\lambda) - f^{\rm e}(t)F^{\rm q}(\lambda) \nonumber, \end{eqnarray}(1)where Ff(λ) and Fq(λ) correspond to the disc-integrated intensities of faculae and the quiet Sun, respectively (see Sect. 3.1), and ∑ μ indicates the sum over all pixels on the solar disc.

3.1. The filling factors

The semi-synthetic records contain the position, area, and tilt angle of sunspot groups only on the day of maximum area. This information is enough to model the photospheric magnetic flux with the SFTM (e.g. Cameron et al. 2010; Jiang et al. 2011b). However, to reconstruct irradiance we also need the area and position of each group on all days in which they are visible on the solar disc. To compute sunspot filling factors, i.e. the darkening caused by sunspots, we therefore extend the semi-synthetic records to include the days before and after a group reaches its maximum area by using empirical relationships, as described below. Note that we assume that the brightness of sunspot umbrae and penumbrae does not change in the course of their evolution.

To obtain the latitude and longitude of the sunspot groups on the days before and after the time of maximum area we used the observed profiles of meridional circulation from van Ballegooijen et al. (1998) and differential rotation from Snodgrass (1983), consistent with the SFTM.

Since the exact form of the decay law of sunspot groups is uncertain, we tested different decay laws and rates. In the literature we found studies that support both linear and parabolic decay laws, as well as different values of the decay rates (Moreno-Insertis & Vazquez 1988; Martinez Pillet et al. 1997; Petrovay & van Driel-Gesztelyi 1997; Baumann & Solanki 2005; Hathaway & Choudhary 2008). We selected the studies that dealt with the decay of total (umbral plus penumbral) sunspot group area instead of individual spots as the semi-synthetic records list total sunspot group area.

Hathaway & Choudhary (2008) used the combined RGO and Solar Optical Observing Network (SOON) data sets covering the periods 1974 to 1976, and 1977 to the present, respectively, to obtain an instantaneous decay rate as a function of group area, As, Γ(As)=(24MSH+0.116As)/day,\begin{eqnarray} {\it \Gamma}(A_{\rm s}) = (24 \; {\rm MSH} + 0.116 A_{\rm s}) \; {\rm /day}, \end{eqnarray}(2)where the area is measured in millionths of the solar hemisphere (MSH). The function Γ is defined as the average of the difference in area between three consecutive days: Γ(As,i) = [As, i − 1 − As,i + 1] /2, where i denotes the day number. In contrast, Baumann & Solanki (2005) modeled the distribution of sunspot group areas employing a linear and a parabolic decay law for different constant decay rates. Given that the difference between the areas predicted by the instantaneous decay rate as a function of area of Hathaway & Choudhary (2008) and the parabolic decay law of Baumann & Solanki (2005) is minimal, we computed areas with Eq. (2). The correlation coefficient between the observed and predicted daily sunspot areas smoothed over a year for the decay phase of sunspot groups is r = 0.98.

For the growth phase of sunspot groups we used the RGO-SOON record2 to derive instantaneous growth rates as a function of maximum area. We calculated the growth rate as g = (As,max − As,0)/(tmax − t0), where As,max and tmax denote the maximum area and the time of maximum area respectively, and As,0 and t0 denote the area and date at the time of first observation respectively. A linear fit of the growth rate versus As,max gave a slope of 0.163/day. This value was used to obtain the corresponding growth rate for each sunspot group in the semi-synthetic record (according to its given maximum area). The correlation coefficient between the observed and predicted daily sunspot areas smoothed over a year for the growth phase of sunspot groups is r = 0.96.

We extended the semi-synthetic sunspot group record (SGR) by including the growth and decay phases of each sunspot group before and after the day each group reaches maximum area, respectively.

Since the semi-synthetic sunspot records are of statistical nature, we constructed two different ones (hereafter referred to as SGR300 and SGR301) that fulfil the statistical relationships found by Jiang et al. (2011a) in order to test the sensitivity of our reconstructions to the choice of the semi-synthetic record. The differences between the two data sets result from the different random numbers in the generation of the sunspot group emergences based on the relationship between the statistical properties of sunspot emergence and the cycle phase and strength (Jiang et al. 2011a).

Figure 1 shows the daily sunspot area smoothed over a year from the SGR300 (red) and the RGO-SOON (black) records. The correlation coefficient between the observed and predicted daily sunspot areas smoothed over a year for the full data set is r = 0.98. Although not shown in Fig. 1, the daily sunspot group area obtained from SGR301 is very similar to SGR300, with a correlation coefficient between the observed and predicted yearly smoothed areas of r = 0.98. To demonstrate the good match with the decay and growth phases (i.e. not only with the full data set), we added in Fig. 1 the daily sunspot area corresponding to the decay phase of groups from observations (blue) and SGR300 (magenta).

thumbnail Fig. 1

Daily sunspot group area on the visible side of the Sun as recorded in the RGO-SOON data set (black), and that obtained from the synthetic record SGR300 within ± 70° from the central meridian (red). The same is plotted but taking only the decay phase of sunspot groups in the RGO-SOON data set (blue) and SGR300 (magenta).

We retrieved the location and area of the sunspot groups from the extended semi-synthetic records and masked the corresponding pixels in the simulated magnetograms. The remaining pixels in the simulated magnetograms were used to compute the filling factors of faculae and the quiet Sun following the method described in Dasi-Espuig et al. (2014).

We identified the pixels filled by sunspots and computed the corresponding filling factors, αs(μ,t), for every μ bin. The corresponding filling factors of sunspot umbra, αu(μ,t), and penumbra, αp(μ,t), were obtained assuming the empirical ratio of umbral to total area, Au/ (Au + Ap) = 0.2 (Brandt et al. 1990; Wenzler et al. 2005).

The pixels that are not covered with sunspots were considered to be covered by faculae and quiet Sun atmospheres. To obtain the facular filling factor we first computed histograms of the total fraction of such pixels within [μ − Δμ/ 2,μ + Δμ/ 2] and [B − ΔB/ 2,B + ΔB/ 2] (ΔB ~ 2G), and then multiplied each B bin by the fraction B/Bsatf\hbox{$B/B_{\rm sat}^{\rm f}$} until the saturation value Bsatf\hbox{$B^{\rm f}_{\rm sat}$} is reached. Summation over all B bins produces the facular filling factor for every μ, αf(μ,t). For B bins below the saturation value we still have a portion of the μ bin that corresponds to the quiet Sun and is equal to αq(μ,t) = N(μ) − αu(μ,t) − αp(μ,t) − αf(μ,t), where N(μ) is the number of pixels in each μ bin.

For ephemeral regions we employed the disc-integrated magnetic fluxes. The filling factors of ephemeral regions, fe(t), are also considered to be proportional to their corresponding magnetic flux density (Ber(t)) as Ber(t)/Bsater\hbox{$B^{\rm er}(t)/B^{\rm er}_{\rm sat}$}.

3.2. Parameters and model validation

The SATIRE-T2 model presented in Dasi-Espuig et al. (2014) has 5 free parameters. These are the scaling factor of the total simulated magnetic flux in active regions, a; the amplitude, X, and time extension, cx, of the ephemeral region cycle with respect to the active region cycle; the saturation value for the faculae Bsatf\hbox{$B^{\rm f}_{\rm sat}$} and ephemeral regions, Bsater\hbox{$B^{\rm er}_{\rm sat}$}. The factor a ∈ (0,1) was introduced in Dasi-Espuig et al. (2014) to re-scale the free parameter Bmax in the SFTM. Bmax is the peak field strength of each active region at the time of emergence and is fixed in the SFTM such that the absolute values of the simulated total magnetic flux match the measurements from the Mount Wilson (MWO) and Wilcox Solar (WSO) observatories (see also Cameron et al. 2010; Jiang et al. 2011b). The measured total magnetic flux consists of magnetic flux emerging within active and ephemeral regions, but the SFTM does not include the latter mainly due to the lack of direct and continuous observations of ephemeral regions. Therefore, the scaling factor a is needed when combining the magnetic flux from the SFTM and that of the ephemeral regions as described in Sect. 2.2.

As in Dasi-Espuig et al. (2014), we fixed the values of the free parameters using the optimisation routine PIKAIA3 (Charbonneau 1995) to minimise the reduced chi-square between the observed and modeled TSI and total magnetic flux (χr2=χr,TF2+χr,TSI2\hbox{$\chi_r^2 = \chi^2_{r,{\rm TF}}+\chi^2_{r,{\rm TSI}}$}), over cycles 21–23. The modeled data are based on the RGO-SOON sunspot group data set. The main difference to our previous approach is that we now include the growth phase of sunspot groups to compute daily filling factors, rather than just their decay phase. This improves the irradiance reconstructions on daily and monthly timescales and provides filling factors that are more consistent with the SATIRE-S model based on measured magnetograms (Yeo et al. 2014b), which is key to obtaining the correct spectral response (see Sect. 4.2).

The computed TSI was fitted to the PMOD (Physikalisch-Meteorologisches Observatorium Davos)4 composite of observations. For the magnetic flux, since we are using two different records (MWO and WSO), we fitted to the average of the two. We took into account that the measurements of the total magnetic flux miss a significant part of the magnetic flux in ephemeral regions (due to the limited spatial resolution of the magnetograms; Krivova & Solanki 2004) by reducing the modeled ephemeral region magnetic flux by a factor of 0.4 (Krivova et al. 2007, 2010). The total magnetic flux that we use to compare to the observations is aΦAR+0.4ΦER, where ΦAR and ΦER represent the modeled magnetic flux from active and ephemeral regions respectively.

Here we employed 27-day averages to compute the reduced chi-square values (χr2\hbox{$\chi^2_r$}) for the TSI and the total magnetic flux. None of the data sets provide errors for individual data points and thus we took the standard deviation of the measured time series as an estimate of the errors (see also Krivova et al. 2007, 2010; Vieira & Solanki 2010).

The resulting values of a, X, cx, and Bsat that optimise the TSI and the average total magnetic flux are listed in Table 1. Note that we adopted a single saturation value, Bsat, as the best-fit values for Bsatf\hbox{$B^{\rm f}_{\rm sat}$} and Bsate\hbox{$B^{\rm e}_{\rm sat}$} agree to within 20 G.

Table 1

Free parameters of the model that provide the best fit to the measured total photospheric magnetic flux and the TSI.

thumbnail Fig. 2

Comparison of the total magnetic flux measured by the Mount Wilson (filled circles) and Wilcox Solar (open squares) observatories, and modeled (red) as aΦAR + 0.4ΦER (with a = 0.74; see Table 1) using SATIRE-T2 with the RGO-SOON sunspot group record.

The best-fit and observed total magnetic flux are presented in Fig. 2. The modeled total magnetic flux based on RGO-SOON sunspot group data is represented by the thick red line, whereas the measurements taken by the Mount Wilson (MWO) and Wilcox Solar (WSO) observatories (Arge et al. 2002; Wang & Sheeley 2002; Wang et al. 2006) are indicated, respectively, by the filled circles and open squares. The measurements are provided for each Carrington rotation, which corresponds to a period of approximately 27 days. The correlation coefficient (r), slope (s), and reduced chi-square (χr,TF2\hbox{$\chi_{r, {\rm TF}}^{2}$}) of a linear fit between the average of the measurements from the two observatories, and the modeled total magnetic flux are, respectively, r = 0.95, s = 1.01, and χr,TF2=0.093\hbox{$\chi_{r,{\rm TF}}^{2} = 0.093$} for the 27-day averages (see Table 2). For the fit we only considered the period when the measurements from both observatories overlap, i.e. after 1976. We nevertheless plotted the data from the MWO from 1967 on, i.e. from when they became available, to show the good correspondence of the model to these.

Table 2

Slope, correlation coefficient (r), and reduced chi-square (χr2\hbox{$\chi_{r}^{2}$}) between the modeled and observed total magnetic flux (TMF) and TSI, and between the modeled UV (220–240 nm) irradiance with SATIRE-S and SATIRE-T2, for different averaging periods.

The comparison between the modeled and observed TSI is displayed in Fig. 3 between November 1978 and the end of 2008. Figure 3a shows the TSI reconstructed with SATIRE-T2 based on the RGO-SOON record in blue, with SATIRE-S in red, and the PMOD composite in black. The rms deviation, Δrms, between the monthly averages of our reconstruction and that of the SATIRE-S is smaller (Δrms = 0.31 Wm-2) than that between the SATIRE-S and the ACRIM (Δrms = 0.40 Wm-2; Willson & Mordvinov 2003) and IRMB (Δrms = 0.41 Wm-2; Dewitte et al. 2004) composites (Yeo et al. 2014b, not plotted). Both the PMOD composite and the SATIRE-T2 reconstruction have been shifted to the average TSI in 2008 measured by SORCE/TIM (Kopp & Lawrence 2005; Kopp et al. 2005a,b). In Fig. 3b we plot the difference between the SATIRE-T2 reconstruction and the observations. According to Fröhlich (2009), the typical error of the PMOD composite during the three minima can be up to 0.3 Wm-2.

The fit parameters between our reconstruction and the PMOD composite, i.e. the slope, correlation coefficient, and reduced chi-square, for the 27-day averages are s = 0.87, r = 0.87, and χr,TSI2=0.257\hbox{$\chi_{r, {\rm TSI}}^{2} = 0.257$}. In Table 2 we also listed the fit parameters for daily and 3-month timescales. The penultimate column provides the reduced chi-square weighted by a function that reduces the influence of outliers (for details see Vieira & Solanki 2010), in order to compare our fits to those obtained by Krivova et al. (2010) with the SATIRE-T model (see last column).

As discussed in Dasi-Espuig et al. (2014), the SATIRE-T2 model reproduces the total magnetic flux and the TSI on monthly timescales more accurately than SATIRE-T due to (1) a more realistic description of the evolution of the facular field and; (2) the use of spatially resolved magnetograms. We also note that, thanks to the incorporation of the growth phase of sunspot groups, the correlation coefficient and the reduced chi-square value of the TSI on daily timescales have improved significantly compared to those quoted by Dasi-Espuig et al. (2014), who had r = 0.78 and χr,TSI2=0.413\hbox{$\chi_{r, {\rm TSI}}^{2} = 0.413$}.

Figure 4 shows the spectral irradiance integrated over the wavelength range 220–240 nm, reconstructed using the SATIRE-T2 (blue) and SATIRE-S (red) models, as well as measured by UARS/SUSIM (Brueckner et al. 1993; Floyd et al. 2003b). For comparison, the UARS/SUSIM observations have been offset to match the SATIRE-S minimum levels in the year 1996. The good match between our reconstruction and the UARS/SUSIM measurements, as well as with the SATIRE-S model, at this wavelength range is encouraging, given the fact that our model is optimised to fit only the observations of TSI and total magnetic flux.

thumbnail Fig. 3

a) TSI reconstructed with SATIRE-T2 based on RGO-SOON data (blue), with SATIRE-S (red), and observed (PMOD composite, black). b) The difference between the TSI observed and reconstructed with SATIRE-T2. Each dot corresponds to a daily value, and the thick curves are three month running means.

thumbnail Fig. 4

Spectral irradiance between 220 nm and 240 nm reconstructed with SATIRE-T2 based on RGO-SOON data (blue), with SATIRE-S (red), and measured (SUSIM, black). Each dot corresponds to a daily value, and the thick curves are three month running means.

The low values of χr,TF2=0.093\hbox{$\chi_{r, {\rm TF}}^{2} = 0.093$} and χr,TSI2=0.257\hbox{$\chi_{r, {\rm TSI}}^{2} = 0.257$} for the total magnetic flux and the TSI respectively, suggest that we overestimated the errors associated with the measurements. Rescaling the errors for the total magnetic flux so as to force the reduced chi-square value to be of the order of 1 implies σ≈ 2 × 1014 Wb. This is significantly below the typical discrepancy between the MWO and WSO measurements of 5–10 × 1014 Wb, especially during the 4 yr centred around solar maximum. We thus refrained from rescaling, but compared the reconstructions that result when fitting each record separately (see Sect. 3.3).

In principle it is possible to use constant chi-square boundaries to estimate confidence limits on the parameters (Press et al. 1992). For 4 free parameters Δχ2 = 16.3 corresponds to a 3σ confidence limit, where Δχ2=χ2−χmin2\hbox{$\Delta\chi^2 = \chi^2 - \chi_{\min}^2$} and χmin2\hbox{$\chi_{\min}^2$} is the minimum chi-square. We warn, however, that due to our crude error estimates and our low reduced chi-square values, the true confidence interval is likely to be lower (a rough scaling suggests it to be more representative of 1σ).

To gauge the effect of uncertainties in the parameter fitting, we calculated Δχ2 on a grid of parameters within the allowed ranges: we vary a between 0.5–1.0 in steps of 0.05, X between 0.45–1.2 in steps of 0.05, cx between 5–7.5 yr in steps of 0.5 yr, and Bsat between 200–700 G in steps of 50 G (for more detail on the allowed ranges see Dasi-Espuig et al. 2014). All sets of parameters that fall within Δχ2 ≤ 16.3 (see Table 1 for the ranges) are used to reconstruct the TSI back in time and used to provide an estimate of the uncertainty resulting from the parameter fitting (see Sect. 3.3 for further discussion).

thumbnail Fig. 5

Comparison between the 1-yr smoothed total magnetic flux (left) and TSI (right) reconstructions based on the RGO-SOON sunspot group record (red), and the semi-synthetic sunspot group record (blue). The thickness of the blue line indicates the range of values between two reconstructions based on the semi-synthetic records SGR300 and SGR301.

3.3. SATIRE-T2 extension back to 1700

In Sect. 2.1 we extended the RGO-SOON sunspot group record back to 1700 employing the semi-synthetic data sets of Jiang et al. (2011a). We computed daily simulated magnetograms using the semi-synthetic data sets as input into the SFTM, and daily sunspot filling factors using SGR300 and SGR301 (as described Sect. 3.1), to reconstruct the spectral solar irradiance over the past 300 yr. For this we used the values of the free parameters listed in Table 1. Note that the choice of the initial field strength in the SFTM may affect the first ~20 yr of the modeled active region flux. In our case we set it to zero since the average value of Rg between 1700 and 1710 is below 5 (Jiang et al. 2011b).

This extension of the SATIRE-T2 model is suitable for irradiance reconstructions on timescales of a few solar rotations or longer since the semi-synthetic sunspot group records are built to keep the emergence rate of sunspot groups in a month proportional to the monthly sunspot group number Rg (see Sect. 3.1). For this reason we focus on comparing the SATIRE-T2 irradiance based on RGO-SOON, SGR300 and SGR301 data sets on yearly timescales or longer.

Figure 5 shows the yearly smoothed reconstructions of the total magnetic flux (left) and TSI (right) since 1878 based on the RGO-SOON record (red) and the semi-synthetic sunspot group records SGR300 and SGR301 (blue) using the same values for the free parameters. The thickness of the blue curves indicates the range of values between the two independent reconstructions based on SGR300 and SGR301. The rms deviation between the yearly smoothed reconstructions based on RGO and SGR300 on the one hand, and RGO and SGR301 on the other hand, is, respectively, 4.1 and 4.2 × 1014 Wb for the total magnetic flux, and 0.094 and 0.097 Wm-2 for the TSI. This indicates that reconstructions based on synthetic sunspot records agree well with the one based on the RGO data set without the need to re-fit the free parameters.

We also tested the sensitivity of our reconstructions to the choice of the total magnetic flux data set. If we use MWO or WSO separately to fit the free parameters in the model both the cycle amplitude and the secular increase since 1700 show differences. However, this difference is only slightly larger to that between the reconstructions using the two different semi-synthetic records SGR300 and SGR301. The cycle amplitude in the TSI varies up to 0.05 Wm-2, while the increase between the end of the Maunder minimum (1700) and the average over the last 3 cycles varies by 0.01 Wm-2.

As discussed in Sect. 3.2, we estimated the uncertainty associated with the parameter fitting by reconstructing the TSI back to 1700 for all sets of parameters with Δχ2 ≤ 16.3. All of these reconstructions lie within the range shown by the grey shading in Fig. 6. The blue line shows the “best-fit” reconstruction, smoothed over one year. All of the curves have been normalised by the minimum after cycle 23 (i.e. 2007 to 2008). The overall trend is very similar for all reconstructions. Typically, the difference in cycle amplitude remains below 0.2 Wm-2. The uncertainty in the increase in TSI between 1700 and the average over the last three cycles is roughly 0.5 Wm-2.

Lastly, we considered differences between our reconstructions based on Rg and on the Zurich sunspot number, Rz. Thus, we constructed a semi-synthetic sunspot group data set employing Rz (as described in Sect. 3.1 and in Jiang et al. 2011a) and repeated the steps explained in Sects. 2 and 3 to reconstruct the irradiance back to 1700 (Fig. 7). Between the years 1700 and 1800, the cycle amplitude is 0.2–0.3 Wm-2 larger for the TSI reconstruction based on Rz. This is because the Rz is larger than the Rg between 1700 and 1874.

The calibration of the sunspot numbers is currently in a state of flux. Clette et al. (2014) recently published a revised Rz and Rg record. Lockwood et al. (2014) compared the Rz to several other data sets to examine a possible calibration discontinuity around 1945, while additional independently corrected sunspot number series have been submitted (Usoskin et al. 2016; Svalgaard & Schatten 2015; Lockwood et al. 2016). For this reason we decided to use in this paper the older and widely used data sets of Rz and Rg. Once a consensus is reached as to which record is the most reliable, we will update our reconstructions.

4. Reconstructions back to 1700

thumbnail Fig. 6

TSI reconstruction based on Rg smoothed over 1 yr (blue) and the uncertainty range (grey) based on the uncertainty in the parameter fitting (see Sect. 3.2). The grey bars at the bottom indicate the times when the statistical relationships have been extrapolated beyond the range of observations on which they are based.

thumbnail Fig. 7

Comparison between the yearly-smoothed TSI reconstructions from SATIRE-T2 based on Rg (dark blue) and Rz (light blue). The grey bars at the bottom indicate the times when the statistical relationships have been extrapolated beyond the range of observations on which they are based.

In Sect. 3.2 we validated the SATIRE-T2 model by comparing the reconstructed total magnetic flux and TSI against observations over solar cycles 21–23. We also showed a good correspondence between SATIRE-T2 reconstructions of the total magnetic flux and the TSI starting in 1878 that are based on RGO-SOON data and those based on the semi-synthetic records. In this section we discuss the total and spectral irradiance reconstructions since 1700.

4.1. Total solar irradiance

The top panel of Fig. 8 shows the change in TSI relative to the quiet Sun value (obtained from integrating the quiet Sun model atmosphere over all wavelengths and μ values) smoothed over a year, ΔTSI (blue), since 1700. The contribution of each component (spots, faculae, and ephemeral regions) is also plotted on a daily basis. As described by Dasi-Espuig et al. (2014), the main contributor to changes from minimum to minimum, in the SATIRE-T2 irradiance reconstructions are the ephemeral regions (see dot-dashed curve in Fig. 8a), in agreement with previous models of the photospheric magnetic flux (Solanki et al. 2002) and the SATIRE-T model (Krivova et al. 2007, 2010).

We compared our TSI reconstructions with those from SATIRE-T Krivova et al. (2010) and Wang et al. (2005, hereafter WLS05). The bottom panel of Fig. 8 displays our yearly smoothed TSI reconstruction in blue, where the thickness of the curve represents the range of values between the two reconstructions based on the two semi-synthetic sunspot records SGR300 and SGR301. The SATIRE-T reconstruction smoothed over one year is indicated in red. Between 1750 and 1800 the reconstruction has periods with extensive gaps (due to gaps in the Rg) and therefore we omitted these values in the plot. WLS05’s reconstruction (orange) is available only on a yearly basis, while SATIRE-T2 and SATIRE-T have a temporal resolution of one day. To facilitate a comparison, the plotted SATIRE-T and SATIRE-T2 curves have been smoothed by a 1-yr running mean. The three reconstructions have been shifted to the average value of the PMOD composite of observations during the minimum between cycles 21 and 22, when the three reconstructions and the composite are available.

WLS05 also used a SFTM to compute the photospheric magnetic flux in active regions and their decay products from the Rg, and added the contribution of ephemeral regions separately. They, however, did not consider the extended cycles of ephemeral regions. Instead, their ephemeral region flux was taken to be constant throughout a cycle, with a value proportional to the amplitude of the corresponding sunspot cycle. Their SFTM has also several differences to that of Jiang et al. (2011b). Firstly, they assumed a cycle-to-cycle variable meridional flow, roughly proportional to the cycle amplitude, to maintain the polarity reversals of the polar field, whereas in our case this is achieved by including the observed cycle-to-cycle variation of the sunspot group mean latitudes (Li et al. 2003; Solanki et al. 2008; Jiang et al. 2011a) and tilt angles (Dasi-Espuig et al. 2010, 2013; Ivanov 2012; McClintock & Norton 2013). Note that using the statistical relationship between the tilt angles and the strength of a cycle is equivalent to taking into account the inflows towards the activity belts, i.e. variations related to the meridional flow (Howard & Labonte 1980; Zhao & Kosovichev 2004; Gizon 2004; Gizon & Birch 2005; Cameron & Schüssler 2012). Secondly, the profile of the meridional circulation used here is in close agreement to the recent measurements of Hathaway & Rightmire (2011), while WLS05 used a profile with a sharp gradient near the equator (Wang & Sheeley 1989; Wang et al. 2009). Thirdly, WLS05 constructed their source function based on two synthetic records different to ours: in case S1 they scaled the number of emerging active regions to the yearly Rg and fixed the strength of all regions to 5 × 1022 Mx, while in case S2 they fixed the number of emerging active regions in all cycles to 600 and scaled the strength of the active regions within a cycle to the maximum Rg of the same cycle. In both cases the active regions were distributed randomly in longitude over the solar surface, and were placed in latitude positions consistent with the migration of the mean latitude with cycle phase. However, they did not consider the dependence of the mean latitude with cycle strength (Li et al. 2003; Solanki et al. 2008; Jiang et al. 2011a).

The bottom panel of Fig. 8b shows the TSI reconstruction by WLS05 based on the average of two reconstructions (S1 and S2) of the total magnetic flux using a SFTM. The reconstruction follows the empirical model from Lean (2000), who used linear regressions between TSI measurements and different proxies of sunspot and facular brightness variations. Thus the sunspot darkening was derived from the yearly Rg before 1882 and the sunspot areas after that date. The facular brightening was obtained from the photospheric flux simulated with their SFTM before 1976, and the MgII index after 1976. In contrast, SATIRE-T2 uses one single homogeneous proxy for all magnetic features, the sunspot group number, Rg, to reconstruct the TSI over the past ~300 yr and semi-empirical model atmospheres to describe the brightness of each magnetic feature.

thumbnail Fig. 8

Top: change in TSI relative to the quiet Sun value, ΔTSI, smoothed over a year (blue) based on the semi-synthetic sunspot group record SGR300. The contribution of spots, faculae, and ephemeral regions are also shown on a daily basis as grey dots, black dots and the dot-dashed black curve, respectively. Bottom: comparison between the TSI reconstructions from SATIRE-T2 using SGR300 and SGR301 (both based on Rg as input (blue), and SATIRE-T (red) smoothed over 1 yr, and the yearly values of the reconstruction from Wang et al. (2005, orange). The grey bars at the bottom indicate the times when the statistical relationships of SATIRE-T2 have been extrapolated beyond the range of observations on which they are based.

As in all SATIRE models, SATIRE-T (Krivova et al. 2010) also employs brightness spectra computed from semi-empirical model atmospheres and weights them by the corresponding disc area coverage. The disc area coverage of spots are extracted from the daily Rg before 1874 and sunspot group areas after 1874. To derive the filling factors of faculae and the network, the evolution of the photospheric magnetic flux is first reconstructed with the physical model of Solanki et al. (2000, 2002) and Vieira & Solanki (2010). This model solves a set of ordinary differential equations with the sunspot number as input to provide daily disc-integrated values of the magnetic flux in active and ephemeral regions as well as the open flux.

To compare the TSI increase since 1700 in the three reconstructions we calculated the difference between the year 1700 and the average over the years 1976–1996. We stopped in 1996 since the reconstruction from WLS05 ends at this time. The three reconstructions show a very similar increase of the TSI during this period. SATIRE-T and WLS05 show an increase of 1.3+0.2-0.4\hbox{$^{+0.2}_{-0.4}$} Wm-2 and 1.2 Wm-2, respectively, while the increase in SATIRE-T2 (based on Rg) is 1.2+0.2-0.3\hbox{$^{+0.2}_{-0.3}$} Wm-2. Both SATIRE models are in agreement during the period 1700 and 1710 because (1) between 1700 and 1710 the Sun was barely active (the average value of Rg during this time was below 5; Hoyt & Schatten 1998) and therefore the irradiance in both models is dominated by the quiet Sun; and (2) we employed the same model atmospheres.

Figure 8 also reveals differences in the amplitude of the TSI cycles between the three reconstructions. On the one hand, the weakest cycles (between the years 1700 and roughly 1890) have on average a slightly larger amplitude in our reconstruction than in SATIRE-T and WLS05. On the other hand, the amplitude of the strongest cycles (1940–1960, and 1975–2009) in WLS05 and our reconstructions are comparable, but lower than in SATIRE-T.

The differences could partly be due to differences in how the input data are treated, and partly due to the different photospheric magnetic flux models. One of the reasons for the lower amplitude of the strong cycles is the following non-linear effect present in the SFTM used here and in WLS05. The diffusive magnetic flux transport in both SFTMs is dependent on cycle strength. During strong cycles, the number of sunspot groups on the solar surface at each time increases, and thus the groups are closer to each other, causing more flux in neighbouring active regions to cancel between each other (e.g Baumann et al. 2004). This means that strong cycles have shorter-lived facular fields, causing both the total flux and the TSI to saturate.

Following the behaviour of the real Sun, there are also other non-linearities in the source parameters of the SFTM used here; these are a consequence of the dependence of the mean latitude and tilt angle of sunspot groups on the strength of a cycle (for a comprehensive review see Jiang et al. 2014b). During cycle maxima the TSI is dominated by the active region magnetic flux. By model construction, weak cycles have on average sunspot groups emerging at lower latitudes and with larger tilt angles. Jiang et al. (2014a) showed that active regions emerging at lower latitudes (close to the equator) and with large tilt angles cause a significant effect on the axial dipole field (and thus in the amount of net flux that is advected to the poles), so that magnetic fields live longer due to reduced cancellation between the two polarities of each active region before they are transported to the polar regions. For irradiance this means that longer-lived faculae, which raise TSI for longer spells, are generated during weak cycles. In contrast, the magnetic flux from the ephemeral regions plays a key role in the TSI during the minima of weak cycles (see the top panel of Fig. 8). Since weak cycles tend to have stronger following cycles (which is related to the Gnevyshev-Ohl rule or Odd-Even rule; Gnevyshev & Ohl 1948), the magnetic flux from ephemeral regions after weak cycles is higher than after strong cycles due to the extended ephemeral region cycles in our model (see Sect. 2.2).

thumbnail Fig. 9

Lyman-α irradiance smoothed over 3 months. The red and blue curves correspond to the SATIRE-T2 model using as input the RGO-SOON and the semi-synthetic sunspot group records (based on the Rg), respectively. The grey bars at the bottom indicate the times when the statistical relationships have been extrapolated beyond the range of observations on which they are based. In black we also show the LASP Lyman-α composite.

4.2. Spectral solar irradiance

The semi-empirical model atmospheres used by the SATIRE family of models (see Sect. 3 and Krivova et al. 2011) were constructed using the ATLAS9 radiative transfer code (Unruh et al. 1999; Kurucz 1992), which assumes local thermodynamical equilibrium (LTE).

To correct for non-LTE effects in the UV (Krivova et al. 2006, 2009) we followed the approach by Yeo et al. (2014b). Firstly, they offset the quiet Sun UV irradiance to match the observed Whole Heliospheric Interval (WHI) reference solar spectra (Woods et al. 2009). Note that the variability is absolutely untouched by this measure. Secondly, below 180 nm Yeo et al. (2014b) offset and rescaled the UV variability employing the empirical relationships based on SORCE/SOLSTICE (McClintock et al. 2005; Snow et al. 2005) observations (see Yeo et al. 2014b, for more details).

The Hydrogen Lyman-α solar flux (121.5 nm) is of particular interest for its impact on the photochemistry and heating in the middle atmosphere (e.g. Wang et al. 2013). In Fig. 9 we compare the reconstructed Lyman-α flux (red and blue) to the LASP composite5. The composite is based on various measurements, while proxy models were used to fill in the gaps and extrapolate the time series back to 1947 (Woods et al. 2000). The correlation coefficient is 0.96 between the 3-month smoothed SATIRE-T2 reconstructions and the LASP composite over the entire period of overlap. The reconstruction suggests that the Lyman-α irradiance has increased by about 50% between the end of the Maunder minimum (1700) and the average over the last three cycles.

Figure 10 shows the reconstructed solar irradiance in various spectral bands relevant for climate studies, such as the Schumann-Runge oxygen continuum and absorption bands, the Herzberg oxygen continuum, the Hartley-Huggins ozone absorption bands, and two water vapor absorption bands. The reconstructions employing SATIRE-S (Yeo et al. 2014b), SATIRE-T2 based on the RGO-SOON data set, and SATIRE-T2 based on the semi-synthetic data sets are coloured, respectively, black, red, and blue.

As expected, the 11-yr cycle variability, as well as the irradiance increase since the end of the Maunder minimum, is weaker at longer wavelengths. The reversed variability with respect to the solar cycle between 1500–2500 nm had already been noticed in observations and previous model results (e.g. Krivova et al. 2006; Harder et al. 2009; Ermolli et al. 2013). This effect can be attributed to the decrease of the facular contrast at these wavelengths (Unruh et al. 2008) such that the spot darkening exceeds the overall facular brightening.

In Sect. 3.5 we compared the TSI and the TF using SATIRE-T2 based on RGO-SOON with these quantities obtained with SATIRE-T2 based on the semi-synthetic records. Figure 10 demonstrates that the correspondence between the two reconstruction approaches is very good also at different wavelength ranges (note that above 180 nm the spectral irradiance is only offset and not rescaled). Since all SATIRE models use the same set of model atmospheres to represent the brightness of the magnetic features, the filling factors are the only variables that may produce a different spectral response in each of the SATIRE models. Therefore, any deviations between the SSI based on RGO-SOON or the semi-synthetic record, result mainly from differences in the amount of spot darkening and faculae/network brightening. For this reason differences with respect to the SATIRE-T and -S models are also expected, as both the SFTM (from which we extract the facular contribution) and the sunspot group record (from which we extract the spot darkening) are now based on statistical relationships related to the sunspot number, rather than based on direct observations.

thumbnail Fig. 10

Reconstructed solar irradiance in various spectral bands smoothed over 1 yr with SATIRE-S (black; Yeo et al. 2014b), SATIRE-T2 based on RGO data (red) and based on the synthetic data (blue): a) Schumann-Runge oxygen continuum; b) Schumann-Runge oxygen bands; c) Herzberg oxygen continuum; d) Hartley-Huggins ozone bands; (e) and f)) water vapour infrared bands.

The good match with the SATIRE-S SSI is also very encouraging, given that SATIRE-S uses the most accurate observations (magnetograms and continuum images) to compute the filling factors for each magnetic component (Yeo et al. 2014b). The correlation coefficient and slope of a linear fit between the daily SATIRE-S spot/facular filling factors and those of SATIRE-T2 based on RGO-SOON data (see Sect. 3) are, respectively, r = 0.97/0.92 and s = 1.05/0.82. Note that the facular filling factors in SATIRE-S refer to all bright features, and thus include both faculae and ephemeral regions. Here we compared the filling factors of all of the bright components in each model, i.e. SATIRE-T2 facular plus ephemeral region filling factors with SATIRE-S facular filling factors.

Various studies (e.g. Krivova et al. 2006; Ermolli et al. 2013; Thuillier et al. 2014; Ball et al. 2014; Yeo et al. 2014b, 2015) have pointed out that the solar cycle variability in the UV reconstructed by SATIRE-S is much stronger than that in NRLSSI (Lean 1997, 2000). Specifically, between 300 and 400 nm, the variation over the solar cycle in SATIRE-S is about twice that in NRLSSI (Yeo et al. 2015). The reconstruction presented here, being consistent with SATIRE-S, shows the same disparity to NRLSSI.

Solar cycle variability in the UV in NRLSSI is determined by matching the rotational variability in the Mg II index and the Photometric Sunspot Index, PSI, (Hudson et al. 1982; Fröhlich 1994) to that in the UARS/SOLSTICE record (Rottman et al. 2001) and assuming the index-to-SSI relationship so derived to apply at solar cycle timescales. In the recent review of UV SSI records and reconstructions by Yeo et al. (2015), the authors noted that measured SSI rotational variability is increasingly dominated by noise towards longer wavelengths. As a direct consequence, the regression of the rotational variability in the Mg II index and PSI to observed SSI rotational variability is poor longward of 300 nm, raising doubt on the validity of the index-to-SSI relationship from such an analysis. From mimicking the NRLSSI approach on various records and reconstructions and comparing the recovered solar cycle variability to that in the original data, Yeo et al. (2015) demonstrated that solar cycle variability is likely underestimated in NRLSSI longwards of 300 nm due to measurement noise in the UARS/SOLSTICE record. Consequently, the SSI variability obtained since the end of the Maunder minimum in this study (as well as that of Krivova et al. 2010) is expected to be more reliable than the SSI variability provided by the NRLSSI.

5. Summary

We have reconstructed the spectral and TSI since 1700 by improving and extending the model presented by Dasi-Espuig et al. (2014). They used a SATIRE-type model together with daily magnetograms simulated with a SFTM (SFTM). The simulated magnetograms supply the evolution of the magnetic flux in active regions and their decay products. The magnetic flux that emerges within the ephemeral regions forming the network was added separately based on the concept of extended cycles, whose amplitude and length are related to those of the corresponding sunspot cycles (Solanki et al. 2000, 2002; Krivova et al. 2007, 2010; Vieira & Solanki 2010). A future improvement to SATIRE-T2 would be to include ephemeral regions in the SFTM.

In Dasi-Espuig et al. (2014) the source of magnetic flux in the SFTM was based on the RGO-SOON sunspot group data set, available since 1874. To extend the model back to 1700, we constructed semi-synthetic sunspot group records based on the sunspot number (Rg and Rz) and statistical properties of sunspot group emergence measured by the RGO (Jiang et al. 2011a).

The magnetic flux in each individual active region (sunspots and faculae) is injected into the SFTM only once – on the day of maximum area – since the SFTM describes the passive transport of the photospheric flux due to the effects of differential rotation, meridional flow, and turbulent surface diffusivity. To calculate daily irradiances, we additionally need the position and area of the sunspot groups on the days before and after the maximum area is reached. We obtained the areas employing an empirically determined growth rate, and the observed instantaneous decay rate by Hathaway & Choudhary (2008).

Our model has four free parameters that are fixed using observations of the TSI and the total photospheric flux during cycles 21 to 23. We tested the sensitivity of our reconstructions to uncertainties in the parameter fits as well as to the choice of a particular semi-synthetic sunspot record, and find very little change in the long-term trends of the reconstructions.

We compared our TSI reconstructions since 1700 with those from the SATIRE-T (Krivova et al. 2010) and Wang et al. (2005, WLS05). We calculated the magnitude of the secular increase in TSI between the end of the Maunder minimum and recent cycles (here taken as the average between 1976 and 1996, when all three reconstructions are available) and found that the increase is 1.2+0.2-0.3\hbox{$^{+0.2}_{-0.3}$} Wm-2, in agreement with the reconstructions from WLS05 and the SATIRE-T model. The amplitudes of the TSI cycles show some differences. In particular, the amplitude of the stronger cycles (1940–1960, and 1975–2009) are lower in both our reconstructions and in that of WLS05, while the amplitude of the weak cycles (1700–1890) are on average slightly larger in our reconstructions. These differences are mainly due to non-linearities in the SFTMs used here and in WLS05 (e.g. Jiang et al. 2014b), which reflect complex processes acting in the real Sun.

Our SSI reconstructions are in good agreement with the UARS/SUSIM measurements (Brueckner et al. 1993; Floyd et al. 2003b) as well as the Lyman-α composite of observations (Woods et al. 2000). We stress that no free parameters were adjusted to fit the UV irradiance. We find that the spectral variability obtained with SATIRE-T2 matches that of SATIRE-S without any further parameter adjustments. This is despite their very different input data: SATIRE-S is based on detailed solar disc images and magnetograms, while SATIRE-T2 relies either on sunspot numbers (before 1878) or sunspot area records. The good match is an example of the internal consistency between the different models of the SATIRE family. Together with their foundation in physics, this makes the SATIRE family of irradiance models particularly robust and versatile, allowing the reconstructed irradiance obtained for different timescales to be stitched together easily to obtain a seamless and internally consistent record of SSI and TSI over very long periods of time, with the quality determined only by the quality of the underlying data available for a particular period. In particular, according to the analysis of Yeo et al. (2015), the SSI provided by the SATIRE family of models should be more reliable than that obtained by NRLSSI (Lean 1997, 2000).

4
