1. Introduction

A significant fraction of interstellar carbon (up to 20%, Joblin et al. 1992; Tielens 2005) is tied up in the carriers of the aromatic infrared bands (AIBs). The most intense AIBs are observed at 3.3, 6.2, 7.7, 8.6, 11.3, and 12.7 μm and are generally attributed to stochastically heated polycyclic aromatic hydrocarbons (PAHs, Léger & Puget 1984; Allamandola et al. 1985). This set of emission bands shows systematic variations in the relative intensity and central wavelength of the bands (Peeters et al. 2002), reflecting variations in the local physical conditions and a chemical evolution of their carriers. From the analysis of spectro-imagery data on several Galactic photon-dominated regions (PDRs), the variations of the mid-IR (5.5−15 μm) bands were attributed to the emission of three different populations: PAH cations and neutrals (PAH+ and PAH0) and evaporating very small grains (eVSGs, Rapacioli et al. 2005; Berné et al. 2007; Pilleri et al. 2012). A chemical scenario has been proposed according to which eVSGs evaporate under UV irradiation, producing free-flying PAHs. Candidates such as PAH clusters (Rapacioli et al. 2006; Montillaud & Joblin 2014) or Fe-PAH complexes (Simon & Joblin 2009) have been proposed as models for these eVSGs. Jones (2012) recently proposed a model for the evolution of carbonaceous dust in the interstellar medium in which the smallest particles are aromatized, whereas the largest ones remain H-rich and predominantly aliphatic. Such a scenario would reconcile the observation of both the aromatic emission bands in UV-irradiated regions and the 3.4 μm CH aliphatic absorption feature as a main feature of interstellar dust in galaxies (Dartois et al. 2004). To develop this evolutionary scenario further, we report here a study of the 3.4 μm emission band, which is observed as a minor band at the side of the main AIB at 3.3 μm. Characteristic of aliphatic CH bonds, this band has been attributed to methyl sidegroups attached to PAHs (Jourdain de Muizon et al. 1990) or to superhydrogenated PAHs (Bernstein et al. 1996). The observed 3.4/3.3 μm intensity ratio (I3.4/I3.3) is found to decrease for an increasing intensity of the UV field (Geballe et al. 1989; Joblin et al. 1996; Sloan et al. 1997; Mori et al. 2014), reflecting the photo-destruction of the more fragile bonds linked to the 3.4 μm band.

thumbnail Fig. 1

In color scale, the Spitzer IRAC 8 μm image of the NGC 7023 NW PDR (Werner et al. 2004). The dark lines demarcate the region in which AKARI-IRC data were obtained, the white rectangle represents the Spitzer-IRS field of view. The star represents the position of HD 200775. The insets represent the AKARI and IRS beam sizes. AKARI spectra between 2.8 and 3.9 μm are shown to the right. They correspond to the positions P1-P4 that are marked as black dots on the map.

Open with DEXTER

In this paper we present 2D spectroscopy of the PDR associated with the reflection nebula NGC 7023 NW obtained with the AKARI and Spitzer space telescopes. The combination of these datasets allows us to study the spatial variations of the 3.3 and 3.4 μm emissions due to aromatic and aliphatic bonds with those of the PAH0 and eVSG emissions. In Sect. 2 we present the observations and the data reduction. In Sect. 3 we describe the data analysis tools and present the observational results. We discuss these results in Sect. 4. Finally, the conclusions are presented in Sect. 5.

2. Observations

2.1. NGC 7023 NW

NGC 7023 is a reflection nebula in the Cepheus constellation illuminated by the B2-5Ve binary star HD 200775 (Alecian et al. 2008). The distance of HD 200775 to the Sun measured by Hipparcos is 430 pc, but a recent analysis revised the distance to 320 ± 51 pc (Benisty et al. 2013). The nebula has been shaped by the star formation process, which led to the formation of a cavity (Fuente et al. 1993). The interaction of the UV photons with the walls of the parent molecular cloud has produced several PDRs to the northwest, south, and east of the star. The brightest PDR is found about 45′′  NW from the binary star (hereafter the NW PDR, or NGC 7023 NW). Pilleri et al. (2012) estimated the intensity of the radiation field at the PDR front to be G0 ~ 2600 in units of the Habing field (Habing 1968). Previous observations of different gas lines have shown that this region hosts structures at different gas densities: nH ~ 100 cm-3 in the cavity (Berné & Tielens 2012), 105−106 cm-3 in the filaments that are observed in the mm (Fuente et al. 1996) and near-IR (Lemaire et al. 1996; Martini et al. 1997), and ~104 cm-3 in the molecular cloud (Gerin et al. 1998).

thumbnail Fig. 2

Summary of the observations and spectral analysis for positions P1 to P4 (top to bottom row). First column: the observed spectrum (black) and its fit (red) for the AKARI observations. The fit of the 3.29 and 3.40 μm features are displayed in blue, and the 3.45 μm plateau is shown in green. Second column: observed Spitzer-IRS spectrum (crosses), its fit (black) and the decomposition obtained with PAHTAT (red: eVSG, green: PAH0, blue: PAH+).

Open with DEXTER

2.2. Near- and mid-IR observations with Spitzer and AKARI

The infrared camera (IRC, Onaka et al. 2007) onboard the AKARI space telescope (Murakami et al. 2007) was used to obtain near-IR (2.55 μm) spectro-imagery of NGC 7023 NW. The observations were performed as part of the open-time program NESID of the AKARI post-helium phase between October 2008 and January 2010. They were carried out using the grism spectroscopy mode with the narrow Nh slit, which provides a spectral resolution of about 0.02 μm and a spatial resolution of ~3″ (Onaka et al. 2007). The slit position was slightly shifted for the different runs to make dithering observations. In each pointed observation, eight to nine exposure cycles in spectroscopy were obtained together with one exposure in imaging in the N3 (3.2 μm) band, which gives the accurate position information. The on-source integration time for each observation is typically 360 s. The data were processed with the latest version of the spectroscopic toolkit (version 20110301) for the phase 3 observation1. The NGC 7023 NW observations consisted of 20 stripes of length ~50″, each with a slightly different position and orientation. The stripes were then combined in a mosaic using the software montage2. The field of view of the final mosaic results from the overlap of the slit coverages of all the stripes and is displayed in Fig. 1. The near-IR features vary smoothly between nearby positions but are significantly different with distance to the star, as shown by the four representative spectra in Fig. 1 that correspond to offsets of P1 [−29″, 24′′]; P2 [−36″, 35′′], P3 [−39″, 38′′], P4 [−43″, 41′′] relative to the position of HD 200775.

We compare this dataset with the Spitzer-IRS observations of NGC 7023, which provides spectral imagery in the wavelength range [5.514] μm and covers the whole filamentary region of the NW PDR with a spatial resolution of 3.6′′ (see Fig. 1). This dataset has been described in detail in previous studies, for example, Werner et al. (2004), Berné et al. (2007), and Pilleri et al. (2012).

3. Spectral analysis and spatial distributions

3.1. Near-infrared

The first column of Fig. 2 shows the AKARI-IRC spectra observed at the positions P1-P4. The spectra are dominated by the two emission bands that peak at 3.29 and 3.40 μm, in addition to an underlying plateau. To fit these spectra we used two narrow Gaussians for the 3.29 and 3.40 μm features and a broader Gaussian centered at 3.45 μm to account for the plateau. We let the central wavelength of the Gaussians vary by 0.01 μm to account for small shifts and treated the band widths and intensities as free parameters. We simultaneously fit the observed spectrum using a linear combination of these features and a linear continuum. The resulting full widths at half maximum of the bands were found to be ~0.03 μm for the 3.29 and 3.40 μm bands and ~0.1 μm for the 3.45 μm plateau. As shown in Fig. 2, this yields very good fits of the spectra, even in cases with a strong plateau and faint superposed 3.40 μm band.

thumbnail Fig. 3

Pixel-to-pixel correlations of the integrated intensity of the 3.3 μm band (I3.3), 3.4 μm band (I3.4), and the 3.45 μm plateau (Ipla). The correlation coefficient R and the slope m of the linear fit to the points are also given. Ipla correlates better with the intensity of the aromatic 3.3 μm band than with the aliphatic 3.4 μm band. This indicates that the plateau is dominated by emission from aromatic bonds.

Open with DEXTER

The 3.29 μm band is commonly attributed to the CH in-plane stretching mode in PAHs, whereas the 3.40 μm band and the plateau are more difficult to attribute unequivocally. Steglich et al. (2013) concluded that it is difficult from a spectroscopic point of view to favor the attribution of the 3.4 μm band either to methyl side groups attached to PAHs or to superhydrogenated PAHs. Still, Joblin et al. (1996) showed that the evolution of the 3.4/3.3 μm band ratio with the UV field can be explained by methylated PAHs. The 3.45 μm plateau is most likely the superposition of a number of faint features including other aliphatic modes, hot band emission of aromatic CH (Barker et al. 1987) and combination bands of CC and CH aromatic modes (Allamandola et al. 1989). In Fig. 3 we show the pixel-to-pixel correlation of the integrated intensity of the 3.45 μm plateau (Ipla) with that of the 3.29 μm (I3.3) and 3.40 μm (I3.4) bands. Ipla correlates better with I3.3 (correlation coefficient R = 0.95) than with I3.4 (R = 0.77). This suggests that the plateau is dominated by the emission from aromatics (hot bands and combination bands). Since our goal is to study the behavior of the aromatic vs. aliphatic evolution, we exclude the plateau from the analysis in the following.

3.2. Mid-infrared

To extract the emission of the different AIB carriers, we used the results of the PAHTAT procedure (Pilleri et al. 2012). Figure 2 shows the mid-IR spectra and the corresponding fits for the four positions P1-P4. PAHTAT also allows estimating the value of AV along the line of sight assuming that the AIB carriers and other dust populations are well mixed. From these AV values, we reconstructed the deredenned mid-IR and near-IR spectra by using the extinction curve from Weingartner & Draine (2001) for an RV value of 5.6 (Witt et al. 2006). These unreddened spectra are used in the following analysis. The 3.3 and 3.4 μm bands are sufficiently close in wavelength for their ratio is to be not significantly affected by the extinction correction.

Table 1 shows the relevant results of the fit for the positions P1-P4, that is, the integrated intensity of the near-IR bands, of the PAH+, PAH0, eVSG, and of the total AIBs, as well as the fraction of carbon locked in eVSGs (feVSG). In Pilleri et al. (2012), we have shown that feVSG can be derived from every pixel and then used as a probe for G0 in the region of the PDR with significant eVSG emission. For NGC 7023 NW, this region starts at a distance of ~45″ from HD 200775, corresponding to G0 = 2600. In the more exposed layers of the PDR, we obtain an estimate of the UV field intensity by assuming geometrical dilution of the stellar radiation field, a stellar temperature of Teff = 15 000 K (Finkenzeller 1985), and a local extinction of AV = 1.5 (Pilleri et al. 2012). The total map of G0 we obtain is shown in Fig. 4.

Table 1

Results of the fit of the mid- and near-IR observations.

thumbnail Fig. 4

Map of G0 in NGC 7023 NW (color scale). The H2 S(3) integrated intensity is shown for reference (linear steps of 1.7 × 10-7 W m-2 sr-1). The values of G0 between the star and the PDR were obtained assuming geometrical dilution of the stellar radiation field and a local extinction value of AV = 1.5. Inside the PDR, we used the fraction of carbon locked in eVSG as a probe for G0 (Pilleri et al. 2012).

Open with DEXTER

thumbnail Fig. 5

Top: spatial distribution of the 3.3 μma) and 3.4 μmb) integrated intensity as observed by the IRC instrument (color scale). The contours represent the integrated intensity of the H2 S(3) line at 9.7 μm (linear steps of 1.7 × 10-7 W m-2 sr-1), and the star indicates the position of HD 200775. Middle: comparison of the integrated intensity of the bands at 3.3 and 3.4 μm (color scale) with the spatial distribution of the PAH0 and eVSG intensity, respectively (contours steps of 1.7 × 10-5 W m2 sr-1, starting at 1.7 × 10-5 W m2 sr-1). Bottom: comparison of the integrated intensity of the 3.3 μm band with that of PAH+ and with the ratio IPAH+/IPAH0. In f) the contours are shown in steps of 0.3, with increasing values while approaching the star from the PDR.

Open with DEXTER

3.3. Spatial distributions

Applied to the full IRS data cube, PAHTAT allows deriving the spatial distribution of the intensity of PAH+, PAH0, and eVSGs (top panel in Fig. 5). These results have been described in detail in Pilleri et al. (2012) and can be summarized as follows: PAH+ dominate the mid-IR emission between the illuminating star and the PDR front; PAH0 are the most abundant species at the PDR front as traced by the emission of the H2 rotational lines; eVSGs dominate the emission slightly deeper inside the cloud; the transition between PAH0 and eVSGs corresponds to the peak of the H2 S(3) line, which is found at a magnitude of visual extinction, AV ~ 1 (Pilleri et al. 2012).

Figures 5a, b show the integrated intensity maps of the 3.3 μm and 3.4 μm bands. Both maps peak toward the H2 S(3) filament that delineates the PDR front. The 3.3 μm band is also detected in the cavity between the star and the PDR, whereas the 3.4 μm band is detected only toward the PDR. Neither the 3.3 μm nor the 3.4 μm bands is detected in the more shielded layers of the PDR, farther away from HD 200775 than the H2 filaments.

In Figs. 5c, d we compare these maps with the spatial distribution of PAH0 and eVSGs intensities obtained with PAHTAT. A very good spatial correlation is found between I3.3 and IPAH0 (Fig. 5c). In contrast, the 3.4 μm band is more localized on the dense PDR with a good spatial correlation between I3.4 and IeVSG (Fig. 5d). Still, the 3.3 μm band is observed inside the cavity, which indicates that there is a contribution from PAH+ to its emission, and/or that a fraction of PAH0 is present in the cavity (Fig. 5e). The intensity at 3.3 μm decreases by a factor >5 (from 3 × 10-6 to 6 × 10-7 W m-2 sr-1) in regions where IPAH+/IPAH0 ≳ 3 (Fig. 5f). Since we are interested in the evolution of the 3.4 μm band relative to the 3.3 μm band, we restrain our analysis below to the PDR front and mask the pixels that have IPAH+/IPAH0> 1 and those where the 3.4 μm band is not detected.

thumbnail Fig. 6

First column: correlation between the observed I3.3/IPAH0 and I3.4/IPAH0 as a function of G0. Second column: same plots for model maps of I3.3/IPAH0 and I3.4/IPAH0 computed using Eqs. (6) and (8) and the obtained values for IPAH+/IPAH0 (see text for details). Third column: semi-empirical model that in addition includes the dependency with G0 on the intensity at 3.3 and 3.4 μm relative to all PAH0 bands (see text). In all panels, the linear fit to the data points (red line) is shown as well as its slope m.

Open with DEXTER

4. Discussion

4.1. Variation of I3.3 with G0

The dependence of the 3.3 μm band intensity on G0 results from three effects: change in the abundance of its carriers, PAH ionization since the 3.3 μm band is expected to be smaller for PAH+ relative to PAH0 (see a review on quantum-chemical calculations by Pauzat 2011), and excitation effects. We discuss these effects here by considering the I3.3/IPAH0 ratio. As shown in Fig. 6a, this ratio presents some dispersion, but with an overall increase with G0.

The observed intensity of the 3.3 μm band can be written as a function of the column density N3.3 of its carriers and G0: (1)where ϵ3.3 is the average emissivity at 3.3 μm per aromatic CH bond in PAHs along the line of sight, which depends on the molecular properties of their carriers and the excitation conditions, and N3.3 is the column density of aromatic CH bonds.

The intensity of the 3.3 μm band is the sum of the contribution of the neutral and cationic PAHs. Thus, the ratio I3.3/IPAH0 can be written as (2)where , are the emitted intensity and average emissivity of the 3.3 μm band due to PAH0 and PAH+, and is the column density of aromatic CH bonds of neutral and ionized species. We assume that the ionization fraction is the same for the carriers of the 3.3 μm band and for the whole PAH population, that is, (Montillaud et al. 2013, see discussion below). From this we obtain (3)where we have defined k3.3 represents the fraction of the bolometric PAH emission in the 3.3 μm band for the PAH0 population and is therefore an indicator of the PAH size distribution. Pech et al. (2002) have modeled the IR emission spectrum of a distribution of PAHs under irradiation by UV photons and derived values for k3.3 of about 0.01−0.02 depending on the assumed size distribution. The p3.3 parameter represents the emissivity ratio for PAH cations and neutrals. It is expected to depend on the excitation conditions since PAH cations (open-shell species) have more electronic bands at low energy. However, in a relatively hard UV field, the excitation will be dominated by the strong UV ππ and σσ type bands, which are present in all charge states and are almost equal across them (Mulas et al. 2006). The p3.3 parameter will then depend mainly on the relative IR absorption cross-section at 3.3 μm of PAH cations relative to neutrals. Values in the range 0.20.5 have been calculated for PAH sizes between 20 and 60 C atoms (Malloci et al. 2007).

The total emissivity for a neutral and a cation with similar size is approximately the same because of conservation of energy and the fact that their UV absorption cross-sections are in first approximation similar, as explained above. Therefore, we can use the ratio of the observed intensity IPAH+/IPAH0 as a probe for the column density ratio of ionized to neutral PAHs, and rewrite Eq. (3) using only the observed intensities and the molecular parameters k3.3 and p3.3: (6)The term in parenthesis is related to the contribution of the ionization fraction of PAHs along the line of sight to the observed I3.3/IPAH0 ratio. Using the maps we obtained with PAHTAT, we derived the values of G0 and IPAH+/IPAH0 for each pixel (Figs. 4 and 5f, respectively). Then, we used these values to compute a model map of I3.3/IPAH0 using Eq. (6) with constant values of k3.3 and p3.3. This semi-empirical model (hereafter model 1, Fig. 6b) cannot reproduce the observed trend in I3.3/IPAH0. As an example, Fig. 6b shows the results for model 1 using k3.3 = 0.2 and p3.3 = 0.5. These values give the best fit to the data within the physically meaningful range for k3.3 and p3.3. This shows that the observed variations of I3.3/IPAH0 cannot be accounted for by a variation in the mean charge of PAHs alone.

To obtain a better fit of the observed increase of I3.3/IPAH0 with G0, we assumed that k3.3 depends on G0 with a linear relationship: . We fit the slope of this correlation by varying . The best fit is obtained using (hereafter model 2, Fig. 6c). The dependency of k3.3 on G0 could be due to an increase of the abundance of the 3.3 μm carrier relative to all neutral PAHs, or to an increase of the emissivity at 3.3 μm relative to the total emissivity of PAH0. As discussed below, the first effect is likely to involve a chemical evolution of the PAH population, whereas the second is related to excitation conditions.

Analyzing infrared observations obtained by Spitzer and Herschel, Berné & Tielens (2012) showed that there is no global variation of the PAH abundance in the region covered by our observations. Montillaud et al. (2013) modeled the chemical evolution of PAHs in NGC 7023 NW. They showed that PAHs of small sizes (with a number of carbon atoms NC ≲ 50) are fully dehydrogenated, whereas larger PAHs are normally hydrogenated and possibly superhydrogenated for the largest sizes (NC ≳ 90). The ionization fraction is found to be rather similar from one size to the other. It is interesting to note that across the PDR, intermediate-sized PAHs (NC ~ 60−70) can experience strong variations in their hydrogenation state because of the competition between photodissociation by UV photons and recombination with H atoms. For instance, C66H20 is predicted to be fully hydrogenated at the border of the PDR, but fully dehydrogenated deeper inside the cloud at a distance from 5 to 10′′ from the PDR front. Here, the abundance of H relative to H2 decreases faster than the attenuation of UV photons, resulting in fully dehydrogenated species. This effect could explain the increase in the 3.3 μm band intensity with increasing G0. Another possibility is that the emissivity at 3.3 μm increases with G0 as a result of the higher average internal temperatures of PAHs with higher UV field. Two effects may be invoked: in the most exposed layers of the PDR, the UV radiation field is becoming harder because of decreased extinction by dust (Rapacioli et al. 2006). Secondly, when the UV flux increases, the probability for multiple photon events increases. A PAH that has absorbed a UV photon can only relax part of its internal energy before absorbing another photon, and it is therefore heated to higher temperatures. However, whereas multiple photon events are important for studying photo-dissociation (Montillaud et al. 2013), they remain rare events in NGC 7023 NW and do not contribute significantly to the mid-IR emission. In addition, Witt et al. (2006) showed that in the first layers of the PDR there is a significant contribution of high-energy UV-photons ( ≳ 10.3 eV) that are suppressed in the more protected layers (AV ≳ 2). The variation of the hardness of the UV field across the PDR provides another explanation for the increase of the intensity of the 3.3 μm band with G0. Quantifying the importance of this process compared to the hydrogenation effect described above would require a full chemical and photo-physical model, which is not the purpose of this paper. We conclude that the increase of I3.3/IPAH0 with G0 is due to a change in the hardness of the UV field combined with an increased abundance of aromatic CH bonds at the border of the PDR, both effects being relatively moderate.

thumbnail Fig. 7

Map of the 3.4/3.3 μm ratio (color scale) with the contours of the H2 S(3) line a), and of the ratio IeVSG/IPAH = IeVSG/ (IPAH0 + IPAH+)b). The density plot of the I3.4/I3.3 band ratios vs. G0 is also shown c). In red, we report the linear regression of the data points. Only the pixels for which I3.3> 1.0 × 10-7 W m-2 sr-1 have been used to build in the analysis of the 3.4/3.3 μm ratio.

Open with DEXTER

4.2. Photo-destruction of aliphatics

Similar to the 3.3 μm band, the intensity of the 3.4 μm band relative to the total intensity of the PAH0 bands (I3.4/IPAH0) also presents some dispersion. However, it shows an overall decrease with G0 (Fig. 6d). In analogy with the 3.3 μm case, the observed intensity of the 3.4 μm band can be written as (7)where ϵ3.4 and N3.4 are the average emissivity and column density per aliphatic CH bond along the line of sight. Equation (6) can be rewritten for the 3.4 μm band as (8)where we have defined To obtain an estimate of the typical values for p3.4, we used the NASA-Ames PAH IR Spectroscopic database3 (hereafter the NASA-Ames PAH database, Boersma et al. 2014) and obtained p3.4 ≳ 1, depending on the size of the PAH being considered. Since p3.4>p3.3, the term in parenthesis is larger for the 3.4 μm than for the 3.3 μm band, implying that the charge state of PAHs modifies the ratio I3.4/IPAH0 more significantly than does I3.3/IPAH0.

Assuming p3.4 = 1, the best fit to the data using our model 1 is obtained using k3.4 = 0.002, which allows us to reproduce the average values of I3.4/IPAH0 (Fig. 6e). k3.4 is found to be a factor of 10 lower than k3.3 because of the lower abundance of aliphatic CH groups compared to the aromatic CH groups. The relative abundance of aliphatic vs. aromatic groups we derive agrees with previous studies, including the recent work of Li & Draine (2012). The observed negative slope of the I3.4/IPAH0 vs. G0 correlation (Fig. 6d) is not reproduced by our model 1 (Eq. (8) and Fig. 6e). As for the 3.3 μm band, we assume a dependency of k3.4 with G0: . The observations can be best reproduced by (Fig. 6e). This negative term mainly reflects the destruction of the carriers of the 3.4 μm band with increasing G0. This is an effective value that reflects both the increase in intensity and hardness of the UV field while reaching the edge of the PDR.

4.3. Variation of I3.4/I3.3 with G0

The ratio I3.4/I3.3 can be used as a tracer of the aliphatic to aromatic content in PAHs if we assume that both bands arise from the same carriers. This ratio is low in the cavity (~0.03 at P1) and increases monotonically toward the PDR, reaching its highest value (~0.15) slightly behind the H2 S(3) and the PAH0 emission (Fig. 7a). The highest gradient is found at the PDR front where in only ~10″ the ratio increases by a factor of ~3. This shows that photo-chemical processing of the carriers of the 3.4 μm band is taking place in this region. We note that 10″ corresponds to the angular width of the filament traced by the H2 rotational emission. Interestingly, this is also the evaporation zone of eVSGs into gas-phase PAHs. We have used the IeVSG/IPAH = IeVSG/ (IPAH0 + IPAH+) ratio as an indicator of the destruction of eVSGs into PAHs by UV photons. The relative spatial distributions suggest that the destruction of eVSGs is then followed by that of the 3.4 μm carriers. This suggests that the evaporation of eVSGs leads to the production of PAHs with aliphatic groups.

Figure 7c shows the pixel-to-pixel correlation between I3.4/I3.3 and log (G0). Dividing each side of Eq. (8) by Eq. (6), we obtain

where Dion is the ratio of the terms in parenthesis in each equation and represents the variation of I3.4/I3.3 due to ionization. Because the intensity of PAH+ relative to that of PAH0 is 0.4, Dion is very close to 1. More specifically, Dion is about 10% higher in the more exposed regions in which IPAH+/IPAH0 = 0.4 compared to the region with no PAH+ emission, thus it cannot explain the trend shown in Fig. 7c. For PAH sizes larger than ~50 carbon atoms, can be also considered constant (cf. NASA-Ames PAH database), and therefore the observed trend can be mainly attributed to a decrease in the abundance of the aliphatic CH bonds relative to aromatic CH bonds.

The trend we observe is similar to that reported in Joblin et al. (1996) and analyzed by the authors using a simple photo-chemical model that describes the evolution of methylated PAHs. The authors showed that the decrease of the 3.4 μm band occurs because the reactions that could reconstruct the aliphatic side-groups in the gas-phase are highly improbable.

5. Conclusions

Thanks to the high spatial resolution of observations made in the near- and mid-IR, we probed the evolution of aliphatic and aromatic CH groups in the spatially resolved PDR NGC 7023 NW. We showed that the intensity of the 3.3 μm band relative to the total PAH emission increases with G0, while the relative contribution of the 3.4 μm band decreases with G0. In the most exposed layers of the PDR, the UV radiation field is harder and high-energy UV photons can excite PAHs to higher temperatures, leading thus to an increase of the fraction of energy emitted at 3.3 μm. The higher abundance of H atoms in this region can also increase the abundance of CH aromatic bonds. On the other hand, the higher flux of UV photons leads to efficient destruction of the more fragile aliphatic CH bonds attached to PAHs, which cannot be efficiently reformed in these regions. In addition, we showed that the observed 3.45 μm plateau is dominated by the emission from aromatic bonds.

We find that the change in the aliphatic vs. aromatic composition is particularly important along the filament that delineates the PDR. In particular, the I3.4/I3.3 ratio peaks close to the region where eVSGs are photo-evaporated into PAHs. This suggests that the processing of eVSGs leads to PAHs with attached aliphatic sidegroups, which provides further insights into the formation and evolution of these species in astrophysical environments. (Very) small grains of mixed aromatic and aliphatic composition are known to be present in circumstellar environments (Kwok et al. 2001; Goto et al. 2003; Sloan et al. 2007), and they have been considered to be a major component in the dust model by Jones (2012). We provided here the first observational insights for the presence of such grains in interstellar clouds.


Acknowledgments

We thank the anonymous referee for useful comments. This work was supported by the French National Program, Physique et Chimie du Milieu Interstellaire, which is gratefully acknowledged. P. Pilleri acknowledges financial support from the Centre National d’Études Spatiales (CNES). The research leading to these results has also received funding from the European Research Council under the European Union’s Seventh Framework Programme (FP/20072013) ERC-2013-SyG, Grant Agreement No. 610256 NANOCOSMOS.
