The Staggergrid: A grid of 3D stellar atmosphere models
II. Horizontal and temporal averaging and spectral line formation^{⋆,}^{⋆⋆}
^{1} MaxPlanckInstitut für Astrophysik, KarlSchwarzschildStr. 1, 85741 Garching, Germany
email: magic@mpagarching.mpg.de
^{2} Research School of Astronomy & Astrophysics, Cotter Road, ACT 2611 Weston, Australia
Received: 10 July 2013
Accepted: 18 September 2013
Aims. We study the implications of averaging methods with different reference depth scales for 3D hydrodynamical model atmospheres computed with the Staggercode. The temporally and spatially averaged (hereafter denoted as ⟨3D⟩) models are explored in the light of local thermodynamic equilibrium (LTE) spectral line formation by comparing spectrum calculations using full 3D atmosphere structures with those from ⟨3D⟩ averages.
Methods. We explored methods for computing mean ⟨3D⟩ stratifications from the Staggergrid timedependent 3D radiative hydrodynamical atmosphere models by considering four different reference depth scales (geometrical depth, columnmass density, and two optical depth scales). Furthermore, we investigated the influence of alternative averages (logarithmic, enforced hydrostatic equilibrium, fluxweighted temperatures). For the line formation we computed curves of growth for Fe i and Fe ii lines in LTE.
Results. The resulting ⟨3D⟩ stratifications for the four reference depth scales can be very different. We typically find that in the upper atmosphere and in the superadiabatic region just below the optical surface, where the temperature and density fluctuations are highest, the differences become considerable and increase for higher T_{eff}, lower log g, and lower [Fe / H]. The differential comparison of spectral line formation shows distinctive differences depending on which ⟨3D⟩ model is applied. The averages over layers of constant columnmass density yield the best mean ⟨3D⟩ representation of the full 3D models for LTE line formation, while the averages on layers at constant geometrical height are the least appropriate. Unexpectedly, the usually preferred averages over layers of constant optical depth are prone to increasing interference by reversed granulation towards higher effective temperature, in particular at low metallicity.
Key words: convection / hydrodynamics / radiative transfer / line: formation / stars: abundances / stars: atmospheres
Appendix A is available in electronic form at http://www.aanda.org
Mean ⟨3D⟩ models are available at the CDS via anonymous ftp to cdsarc.ustrasbg.fr (130.79.128.5) or via http://cdsarc.ustrasbg.fr/vizbin/qcat?J/A+A/560/A8 as well as at www.staggerstars.net
© ESO, 2013
1. Introduction
Theoretical model atmospheres are needed in order to interpret stellar fluxes and derive individual characteristics of stars, like stellar parameters and chemical abundances. In recent decades, successive improvements of the often used onedimensional (1D) hydrostatic atmosphere models have confirmed their predictive capabilities (see, e.g., Gustafsson et al. 2008) but also highlighted their limitations. In fact, these 1D models make use of several simplifications in favor of computational ease, the most prominent one being the treatment of convection with the mixinglength theory (MLT, BöhmVitense 1958; Henyey et al. 1965). The latter entails several free parameters, in particular the free mixinglength parameter, α_{MLT}, which is a priori unknown, hence normally calibrated for the Sun by observations and assumed constant for all stars. Moreover, the calculation of synthetic spectral absorption lines in 1D requires the additional calibration of micro and macroturbulence parameters (ξ_{turb} and χ_{turb}, respectively) in order to properly account for the contribution of nonthermal convective and turbulent motions to the broadening of spectral line profiles.
Most of the limitations of 1D modeling of convection can be overcome only by performing timedependent, three dimensional (3D), radiativehydrodynamical (RHD) calculations (see Nordlund et al. 2009, and references therein). The goal of 3D simulations is to provide realistic ab initio models where stellar surface convection emerges selfconsistently from first principles. Compared to 1D models, such 3D RHD models are able, for the Sun in particular, to predict additional observable features of stars associated with stellar surface velocity fields and temperature and density inhomogeneities, such as surface granulation pattern, line asymmetries, and centertolimb variation (CLV; e.g., Asplund et al. 2000b; Pereira et al. 2013). To systematically study such properties of stars with a realistic approach, we computed a large grid of 3D models using the Staggercode, covering a wide range in stellar parameters^{1} (T_{eff}, log g, and [Fe / H]) for latetype (spectral type FGK) stars (see Magic et al. 2013, hereafter Paper I).
It is advantageous to reduce the relatively large amount of data from the full 3D atmospheric models to temporally and spatially averaged (hereafter ⟨3D⟩) representations. However, this reduction comes at the expense of physical selfconsistency (see Atroshchenko & Gadun 1994). Nonetheless, in this way one can deal with more manageable atmospheric data structures compared to the otherwise enormous amount of information associated with the full 3D models. These mean ⟨3D⟩ stratifications are usually compared with classical 1D hydrostatic atmosphere models. Nordlund & Stein (2001) point out that the largeamplitude fluctuations in the superadiabatic region^{2} (SAR) leads to deviations from the hydrostatic equilibrium. Furthermore, the 3D data sets incorporate quantities emerging from the hydrodynamics and associated with convection itself, such as selfconsistent velocity fields and turbulent pressure, for which there are no physically consistent counterparts in the case of 1D hydrostatic models.
The definition of the ⟨3D⟩ stratifications is neither unambiguous nor unique, but depends largely on the choice of reference depth scale. When dealing with the analysis of the atmospheric layers above the optical surface, monochromatic or Rosseland optical depth scales are usually considered the appropriate choice since these are the natural reference depth scales that are used to describe radiative transfer processes in the photosphere. On the other hand, the optical depth loses its usefulness somewhat in the very deep optically thick layers below the optical surface, since here the mean free path of photons becomes very short and the radiative transfer insignificant. Therefore, other reference scales are best suited to describing the main properties of the stellar stratification. Also, the bimodal and highly asymmetric distribution of bulk upflows and of downflows in the convective zone complicates the definition of a meaningful unique average value, particularly near the surface, at the transition between convectively unstable and stable regions.
Uitenbroek & Criscuoli (2011) investigated the application of ⟨3D⟩ models to spectral line formation. They computed and compared continuum and atomic line intensities and their respective CLV from ⟨3D⟩ and 3D models. They conclude that a mean ⟨3D⟩ stratification is insufficient to represent the full 3D atmosphere model in the light of spectral analysis. As reasons for the latter they list the nonlinearity of the Planck function, formation of molecules, and the asymmetry of convective motions.
The present work constitutes the second paper in the Staggergrid series. Here, we want to explore the following key question: which averaging method leads to the closest ⟨3D⟩ representation of a full 3D data set in the light of spectral line formation calculations? Therefore, we investigate spectral line absorption features by probing the latter with fictitious Fe i and Fe ii lines with different strengths and excitation potentials for different stellar parameters.
2. Averaging 3D models
The 3D models that form the basis of the present work were computed with the Staggercode. For a general description of our grid of 3D models, we refer the reader to Paper I. In short, the Staggercode solves the timedependent, 3D hydrodynamical equations coupled with realistic nongray radiative transfer. We utilize an updated version of the realistic stateoftheart equation of state (EOS) by Mihalas et al. (1988). Continuum and sampled line opacity are taken primarily from the MARCS package (Gustafsson et al. 2008, see also references in Paper I). The radiative transfer is solved for nine angles along long characteristics with a slightly modified version of the Feautrier (1964) method. The opacitybinning method with 12 opacity bins is applied to all Staggergrid models to reduce the computational burden while still accounting for nongray radiative transfer under the assumption of local thermodynamic equilibrium (LTE); in particular, the effects of scattering are neglected (see Nordlund 1982; Skartlien 2000; Collet et al. 2011). Our simulations are of the socalled boxinastar type, and they cover only a small representative volume of stellar surface that typically includes about ten granules horizontally and spans about 14 pressure scale heights vertically. The numerical resolution of the Cartesian grid is 240^{3}. It features a nonequidistant vertical axis in order to enhance resolution in the layers with the steepest temperature gradients. The vertical boundaries are open, while the horizontal ones are periodic.
2.1. Computing temporal and horizontal averages
We computed various temporal and horizontal averages for a large number of physical quantities of interest. For the spatial (horizontal) averages, we computed ⟨3D⟩ stratifications by considering four different reference depth scales and averaging the various physical quantities on layers of constant

geometrical height, z;

column mass density, m = ∫ρ dz;

Rosseland optical depth, τ_{Ross} = ∫(ρκ_{Ross}) dz;

optical depth at 500 nm, τ_{500} = ∫(ρκ_{500}) dz,
(hereafter denoted by ⟨3D⟩_{z}, ⟨3D⟩_{m}, ⟨3D⟩_{Ross}, and ⟨3D⟩_{500}, respectively), where ρ is the gas density, and κ_{Ross} and κ_{500} are the Rosseland mean opacity^{3} and opacity at 500 nm, respectively, both defined as crosssections per unit mass.
The geometrical averages ⟨3D⟩_{z} are easily taken directly from the output of the Staggercode, since the numerical mesh of this code is Eulerian in nature. For the three other (Lagrangianlike) averages, the original data sets have to be remapped to their respective new reference depth scale by individually interpolating each column of each 3D simulation snapshot (see 2.3). Furthermore, we also considered four additional averages:

fluxweighted average temperature, ⟨T^{4}⟩;
average brightness temperature at 500nm, ⟨T_{rad}⟩;
logarithmic average, ⟨3D⟩_{log }; and
enforcedhydrostaticequilibrium average, ⟨3D⟩_{HSE}.
We determine the fluxweighted temperature stratification ⟨T^{4}⟩ by evaluating the spatial averages of T^{4}, motivated by the StefanBoltzmann law for wavelengthintegrated radiative flux. The brightness temperature average T_{rad} is computed using the expression , where B_{500} and denote the Planck function at 500 nm and its inverse, respectively (see also Sect. 3.1). The depthdependent ⟨T_{rad}⟩ thus needs to be interpreted as the equivalent brightness temperature corresponding to the average blackbody emission at 500 nm from each layer. For ⟨3D⟩_{log } we define spatial averages of a given 3D variable X as exp(⟨log X⟩). Finally, since the ⟨3D⟩ models do not in general fulfill the hydrostatic equilibrium condition (see Appendix A.2), for the ⟨3D⟩_{HSE} averages we enforce hydrostatic equilibrium by adjusting the density and adjusting the thermodynamic pressure p_{th} consistently with the EOS, until hydrostatic equilibrium is attained. We emphasize that the proper enforcement of hydrostatic equilibrium requires that one considers both the thermodynamic p_{th} and turbulent p_{turb} contributions to total pressure p_{tot}: the gas pressure in the atmosphere is in fact significantly reduced because of the structural support provided by turbulent pressure. Then, a new geometrical depth z is computed (see Eq. (A.2)).
Classical hydrostatic 1D models of stellar atmospheres are often defined and computed on an optical depth scale, since this allows the numerical resolution to be easily adjusted where it is most needed to achieve the highest accuracy in the solution of the radiative transfer equation in the atmospheric layers, both during the modeling itself and during lineformation calculations. Therefore, especially for radiative transferoriented applications, these 1D models can be compared most naturally with averages of corresponding 3D models on constant optical depth, ⟨3D⟩_{Ross} or ⟨3D⟩_{500}. In Paper I, in particular, we adopted ⟨3D⟩_{Ross} as our standard averaging choice. One of the main reasons we chose ⟨3D⟩_{Ross} over ⟨3D⟩_{500} is that during the scaling of the simulations and the construction of the initial snapshots, the top physical boundary of essentially all models reached up to ⟨log τ_{Ross}⟩_{top} ≈ − 6.0 (see Paper I). In contrast, the vertical extent of the simulations in terms of optical depth at 500 nm varies depending on stellar parameters (log g in particular) owing to the concomitant variations in opacity at 500 nm as a function of temperature and density. Therefore, the ⟨3D⟩_{500} models in general require a careful extrapolation at the top to be extended up to log τ_{500} ≈ − 6.0 (see Sect. 2.4).
While ⟨3D⟩_{Ross} or ⟨3D⟩_{500} represent natural reference depth scales for the mean photospheric stratification, ⟨3D⟩_{z} or ⟨3D⟩_{m} is better suited to describing the average physical conditions below the stellar surface; e.g., only the geometrical averages fulfill conservation of momentum and energy (see Appendix A.2).
In latetype stellar atmospheres, the continuum opacity κ_{λ} in the optical is dominated by the H^{−} boundfree absorption that is sensitive to temperature (~ T^{10}). Therefore, even small fluctuations in T will result in large variations in κ_{λ}, which in turn will lead to a high degree of spatial corrugation of layers at constant optical depth (see Stein & Nordlund 1998). Furthermore, owing to such highly nonlinear behavior of the H^{−} opacity, temperature fluctuations around the average will be reduced by interpolation to layers of constant optical depth (see Sect. 4.1).
We note briefly that only the geometrical averages ⟨3D⟩_{z}, sampled over a sufficient time length, preserve the conservation properties of the hydrodynamical equations, such as hydrostatic equilibrium and conservation of energy. Furthermore, depending on the intended particular application of ⟨3D⟩ models, it is very important to use these carefully, since the different types of ⟨3D⟩ models vary significantly among the different averaging methods.
2.2. Basic averaging procedure
We proceeded with the following steps in order to obtain the ⟨3D⟩ models:

1.
retrieval of 3D variables of interest;

2.
interpolation to new reference depth scale;

3.
computation of horizontal averages and statistics;

4.
extrapolation of horizontal averages, if necessary;

5.
computation of temporal averages.
In case of the geometrical averages ⟨3D⟩_{z}, steps 2 and 4 are unnecessary and are therefore skipped. Owing to the generally nonlinear response of the various physical quantities as a function of basic independent variables and the EOS, the interpolation to a new reference depth scale should be performed after retrieving the variables. In particular, because of these nonlinearities, we caution against the derivation of thermodynamic variables via the EOS by utilizing averaged independent variables interpolated to the new reference depth scale, since the spatial averaging will inevitably break the physical selfconsistency present in the full original 3D data (see Sect. 2.3 and Appendix A.3).
At the vertical boundaries of our simulation box are socalled ghost zones, each consisting of five layers at the top and bottom. Their sole purpose is to numerically define the boundary conditions at both vertical ends. They do not contain physically meaningful values, so we excluded them before the averaging procedure.
To speed up the calculations without noticeably degrading the statistical properties, when computing the averages we considered only every fourth column of the 3D data cubes in both horizontal directions (x and y), which means that the initial N_{x}N_{y} = 240^{2} columns are reduced down to 60^{2}. The vertical extent of the columns is unchanged with N_{z} = 230 (geometrical) or 101 (all other reference depth scales). Tests ensured that this horizontal reduction does not influence the horizontal averages owing to the still large sample of vertical columns considered and the multiple snapshots included in the temporal averaging.
For step 3, we used an arithmetic mean to compute the average values of variable X for snapshot t at each horizontal layer z: (1)with N_{x} and N_{y} the number of horizontal elements. For exponentially varying variables like density and pressure, we computed also logarithmic averages, i.e., replacing X_{xyz} with log X_{xyz} in Eq. (1), denoting the models with ⟨3D⟩_{log }. In the final step 5, temporal averages are evaluated with (2)with N_{t} ≈ 100 − 150 being the total number of snapshots considered for each simulation, which corresponds typically to about two turnover times. In the present work, the combined temporal and spatial averages of variable X are always denoted with , where is the considered reference depth scale.
Since the 3D structures display a great plethora of details, for each relevant 3D variable we also determine a number of additional statistical properties (standard deviation σ, root mean square, minimummaximum range, and histograms of the distribution of values) at each horizontal layer, which are presented and discussed in Sect. 4. As for the spatial averages, the standard deviation and the root mean square are evaluated in step 3 for each layer z using the same basic expression as in Eq. (1) and, if necessary, doubly extrapolated at the top as in steps 2 and 4 (see Sect. 2.4). Finally, their temporal averages are computed in step 5.
Histograms of the distribution of values we determined separately, and we use temporal averages of the depthdependent extrema of variable X, ⟨minX⟩_{z} and ⟨maxX⟩_{z} to define a depthdependent range r_{z} = [⟨minX⟩_{z},⟨maxX⟩_{z}] for the histograms. For the 3D variable X at time t, we determined a set of 1D histograms, , for each individual layer z. The depthdependent range r_{z} is resolved with N_{r} = 200 equidistant points; temporal averages of the histograms are computed using a subset of N_{t} = 20 equidistant snapshots (see Sect. 4.3 for details).
Finally, we also computed averages and associated statistical properties separately for up and downflows, which we differentiate based on the sign of the vertical component of the velocity. Of course, when computing such averages and statistics, one has to account for the correct filling factor in either case, i.e. for the number of elements N_{x,y} belonging to up or downflows, respectively (Sect. 4.2).
2.3. Interpolation to the new reference depth scale
To interpolate to the new reference depth scale (hereafter denoted as ) in step 2, we defined a new equidistant logarithmic reference optical depth scale, , from − 5.0,..., + 5.0 in steps of 0.1 for both optical depth scales τ_{Ross} and τ_{500}. In the case of averaging based on the columnmass density scale m, we used the columnmass density normalized to the mean value of m at the optical surface, i.e. for the new reference depth scale, where ⟨m⟩_{surf} was determined at ⟨τ_{Ross} = 0⟩ and considered a fixed range from − 3.0,..., + 2.0 in steps of 0.05 for all simulations. All variables, X, we remapped columnwise from the original geometrical depth scale to the new reference depth scale, namely . We use linear interpolation, since quadratic interpolation introduced numerical artifacts in some ⟨3D⟩ models.
We note that owing to the remapping to a new reference depth scale, points at a constant optical depth or columnmass density will end up probing and spanning a range of geometrical depths, implying that the averages (and statistical properties) with respect to the new reference depth scale will be qualitatively and quantitatively different from plain horizontal averages on constant geometrical depth (see Appendix A).
2.4. Extrapolation at the top
The vast majority of Staggergrid models are sufficiently extended vertically, in particular at the top, to embrace the full range of with [− 5.0, + 5.0]. The condition ⟨log τ_{Ross}⟩_{top} ≤ − 6.0, is usually fulfilled for all but a few models. More specifically, surfaces of constant optical depth can become quite corrugated at the top for some giant models and fall outside the physical domain of the simulations; that is, one can occasionally have for a limited number of columns. These particular columns are therefore linearly extrapolated to log τ_{Ross} = −5.0 to allow calculating of average quantities in the desired range of optical depths. Exponentially varying values like density, pressure opacities are extrapolated by considering their logarithmic values. The extrapolation is needed only for a few giant models (log g ≤ 2.5), and the concerned columns are usually only a small fraction (≲0.3%). Therefore, we regard these extrapolations as negligible in the case of the optical depth scale τ_{Ross}.
For the optical depth scale τ_{500}, the situation is slightly different. The mean optical depth at 500 nm at the top ⟨log τ_{500}⟩_{top} deviates increasingly towards giant models from ⟨log τ_{Ross}⟩_{top}, so that ⟨log τ_{500}⟩_{top} > − 5.0. Therefore, the necessary extrapolation at the top is considerable, in particular for giant models.
We notice that careless columnwise extrapolation at the top can lead to a largely uncertain and erroneous stratification, which would have a negative impact on spectral line formation. For instance, a wrong density stratification at the top can dramatically affect the ionization balance. To limit these extrapolation errors, we first restrict the columnwise extrapolation to the region where the value is chosen so that no more than 20% of the columns would require extrapolation up to that level. We then compute the horizontal averages (step 3) and, after that, linearly extrapolate the ⟨3D⟩ models a second time to the original for each time snapshot. This particular extrapolation procedure produces more plausible stratifications since the horizontal ⟨3D⟩ averages exhibit a smooth and monotonic behavior with depth at the top compared to individual columns of the 3D data set.
Test calculations of data sets from the solar simulation, which were truncated at the top, revealed the reliability of this double extrapolation approach, since for the temperature stratifications we find the maximum error around 1% at the top (). Nonetheless, we favor the use of averages on mean Rosseland optical depth, i.e. ⟨3D⟩_{Ross} rather than ⟨3D⟩_{500}, since these averages are not plagued by such extrapolation uncertainties. For the extrapolated models on τ_{500}, we kept track of the extent of the applied extrapolation; in fact, only a few models with the lowest gravities (log g = 1.5 / 2.0) exhibit a noteworthy extrapolation (, respectively). The ⟨3D⟩_{500} averages can therefore be reduced to the extrapolationfree regime at the top afterwards.
3. Comparison of the averaging methods
In the following, we systematically compare the different types of averaging procedures explained in Sect. 2 over a broad range of stellar parameters relative to Rosseland optical depth, i.e. . For the sake of clarity, we illustrate the properties of average stratifications only for a representative selection of Staggergrid models comprising dwarfs and giants (log g = 4.5 and 2.0) at solar and subsolar metallicity ([Fe / H] = 0.0 and − 3.0). Besides the most important thermodynamic state variables, temperature and density, we also investigate averages of electron number density, an important quantity for, say, calculations of ionization balance and spectral line formation.
Owing to the lack of a unique common global depth scale that is invariant between different averaging methods, we display their results jointly on the averaged Rosseland optical depth scale, ⟨τ_{Ross}⟩, in order to enable a direct comparison.
Fig. 1
Relative differences in the temperature (left) and density (right panel) stratification vs. the (averaged) Rosseland optical depth for various stellar parameters. The differences are relative to the Rosseland optical depth, i.e. . Orange/brown dashed lines: averages on layers of constant geometrical height ⟨3D⟩_{z}; orange/brown dotted lines: averages on layers of constant column mass density ⟨3D⟩_{m}; orange/brown solid lines: 1D MLT models. Blue solid lines: fluxweighted T^{4}stratifications; blue dashed lines: brightness temperatures T_{rad} averaged on surfaces of constant Rosseland optical depth (left panel). Green solid lines: logarithmic density averages ; green dashed lines: hydrostatic averages (right panel). We compare always cooler and hotter effective temperatures, which are distinguished by dark and bright colors respectively. We note that the cool metalpoor dwarfs exhibit very small differences, and are therefore indistinguishable. Note the differences in the yaxes.
3.1. Temperature
We find that the temperature stratifications of the two optical reference depth scales, ⟨3D⟩_{Ross} and ⟨3D⟩_{500}, are similar, therefore we refrain from showing these. Only at the top of the metalpoor stars do the ⟨3D⟩_{500}averages appear cooler (~ 5%, i.e by ≳250 K at T_{eff} = 6000 K). On the other hand, the geometrical ⟨3D⟩_{z} and column mass density ⟨3D⟩_{m} averages deviate distinctively from the ⟨3D⟩_{Ross}stratification (see Fig. 1). In the regime 1.0 < log τ_{Ross} < 3.0, both ⟨3D⟩_{z} and ⟨3D⟩_{m} are cooler by ~ 5 − 10%. At the surface (τ_{Ross} = 0), the geometrical averages deviate considerably, while the ⟨3D⟩_{m}averages are closer to the optical depth scale (see Fig. 1). In the deeper layers below the superadiabatic regime (SAR), the various averaging methods are practically indistinguishable. In the upper atmosphere the differences are smaller at higher [Fe / H] due to relatively low horizontal contrast, but, these increase significantly for lower metallicity. The averages ⟨3D⟩_{z} and ⟨3D⟩_{m} are marginally cooler than ⟨3D⟩_{Ross} by ~ 1 − 2% at solar metallicity. In the metalpoor case [Fe / H] = −3.0, the temperature stratifications are distinctively cooler, which will certainly influence the line formation calculations with ⟨3D⟩ stratifications. Furthermore, the differences increase with higher T_{eff} and lower log g.
As mentioned earlier, in the atmospheres of latetype stars, minor temperature fluctuations are amplified disproportionally into large variations in the line and continuum opacity κ_{λ} owing to the strong Tsensitivity of the H^{−}opacity (κ_{λ} ∝ T^{10}, see Stein & Nordlund 1998). Therefore, surfaces of constant optical depth appear strongly corrugated in terms of the range of geometrical heights that they span. The transformation to layers of constant optical depth will naturally even out these corrugated surfaces and, at the same time, smooth the temperature fluctuations, since the latter are the source of the former (see Appendix A.1). Therefore, these are noticeably smaller on layers of constant optical depth compared to layers of constant geometrical depth, which is portrayed in the temperature contrast and histogram (see also Figs. 3 and 6). The SAR exhibits largeamplitude fluctuations as a result of the release of thermal and ionization energy at the photospheric transition, which are the reason for the observed enhanced differences between the averaging methods (see Sect. 4.1).
Steffen & Holweger (2002) found a beneficial mean ⟨T⟩representation for the Sun in the fluxweighted temperature averages, T^{4}, taken on constant Rosseland optical depth from their 2D simulations. The idea behind this approach is that the T^{4}averages render radiationoriented Tstratifications, therefore resulting in 1D line profiles that are closer to the multidimensional ones (see also Steffen et al. 1995). To allow for a similar comparison for our models, we computed such average T^{4}stratifications. In Fig. 1, the stratifications generally appear hotter at the top and in the SAR compared to the simple Tstratification. Averages taken at the fourth power will weight higher values more, which leads to hotter average temperatures. This could lead to pronounced differences for molecular lines that form high up in the atmosphere. At solar metallicity, the T^{4}stratifications at the top are fairly similar to the plain Taverages (~ 1 − 2%) in agreement with the findings of Steffen & Holweger (2002). This is different at lower metallicity ([Fe / H] = −3.0), namely the T^{4}averages are clearly higher by ~ 5 − 10%. At higher T_{eff} and lower log g, the temperature differences are greater, in particular for the metalpoor giants, owing to the enhanced temperature fluctuations (see Sect. 4.1).
Under the assumption of LTE and neglecting the effects of scattering, the source function is given by the Planck function, . Within this approximation, we can thus consider the brightness temperature average T_{rad} defined earlier in Sect. 2.1 as a good representation of the mean temperature stratification from the point of view of the radiative emission properties: brighter parts in each depth layer are given more weight with this averaging method. The differences between the average T_{rad} at 500 nm and average Tstratifications are displayed in Fig. 1. Their variations with stellar parameters are very similar to those of T^{4}averages, however, slightly more pronounced, in particular the metalpoor giants exhibit hotter stratifications by up to ~ 20% at the top.
Fig. 2
Root mean square (rms) of the vertical velocity v_{z,rms} (left) and mean electron number density n_{el} vs. optical depth (right panel). Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.
3.2. Density
In Fig. 1, we also illustrate the results of averaging in the case of the density stratifications. In the deeper interior, the different ⟨3D⟩ models converge toward the same density stratification. In the SAR, below the optical surface at log τ_{Ross} ≳ 0.0, the geometrical averages ⟨3D⟩_{z} are smaller than the ⟨3D⟩_{Ross} averages by up to ~ 30%, while at the top these are much denser by up to ~ 40%. The differences increase towards higher T_{eff} and lower log g. We find a different behavior in the metalpoor dwarfs, which turn lower towards the top after the initial increase (~ 10%). The density stratifications averaged on column mass density ⟨3D⟩_{m} are larger in the SAR and in the upper layers closer to ⟨3D⟩_{Ross}. However, we find that at lower metallicity ⟨ρ⟩_{m} they are smaller by up to ~ 30%. We note that thermal pressure qualitatively shows the same characteristics as the density.
The shape of the density distribution is symmetric and narrow on layers of constant column mass density, thanks to the exponential stratification of the atmosphere and to the additional damping of density fluctuations on the column mass scale (see Fig. 6). As a result, the ⟨3D⟩_{m} averages feature the narrowest contrast and density ranges, which, on the contrary, are usually greatest for geometrical averages ⟨3D⟩_{z}; for the ⟨3D⟩_{Ross} averages, these are noticeably reduced due to the mapping onto the optical reference depth scale (Fig. 3). Overall, the density fluctuations at the top of the ⟨3D⟩_{Ross} stratifications are similarly as small as those by ⟨3D⟩_{m} and ~ 20%; however, for metalpoor dwarfs they reach up to ~ 80% (see Fig. 3). As shown in Sect. 4.3, we find that the corrugation of the layers of constant optical depth in the upper part of 3D model stellar atmospheres at lower metallicity increases considerably towards higher T_{eff} because of an enhanced Tcontrast by the socalled reversed granulation (see Rutten et al. 2004). This in turn broadens the density distribution during the remapping to the optical depth scale, shifting the mean density value and leading to the observed deviations between ⟨ρ⟩_{Ross} and ⟨ρ⟩_{m} at lower metallicity (see Appendix A.1), which will affect the ⟨3D⟩ line formation calculations.
The highly stratified structure of stellar atmospheres features an exponential decrease with height. Linear density averages will therefore tend to give more weight to higher density values, leading to a systematic overestimation of the mean densities. For this reason we consider the logarithmic averages ⟨ρ⟩_{log }, which we compare to the linear ones in Fig. 1. As expected, we find the logarithmic ρaverages are smaller than the linear ones, with the difference between the two increasing with higher T_{eff} and lower log g by up to ~ 30%. The mean densities in the upper layers are lower by ~ 10% and ~ 40% at solar and low metallicity, respectively. For quantities that vary more moderately (e.g., temperature) the differences between logarithmic and linear averaging are rather small.
The transformation to constant optical depth and the subsequent averaging will change the physical selfconsistency as shown in Appendix A.2. To rectify this, we followed the recommendation of Uitenbroek & Criscuoli (2011) and also computed ρstratifications, which are enforced to be in hydrostatic equilibrium, ⟨ρ⟩_{HSE} (Fig. 1). These deviate significantly from the plain ⟨ρ⟩stratifications, in particular at the top. Incidentally, we note however that their dynamic nature and the effects of convective flows and turbulent pressure mean that the 3D models themselves are not strictly speaking in hydrostatic equilibrium at any one time.
In Fig. 1 (both panels), we also compare the 1D MLT models with the ⟨3D⟩_{Ross} stratifications. The 1D models in general show qualitatively similar behavior as the geometrical averages. The metalpoor 1D models are distinctively hotter, since these enforce radiative equilibrium in the upper layers.
3.3. Electron number density
We find large differences among the various averages of the electron number density, n_{el}, which we show in Fig. 2 (right panel). In the SAR the geometrical averages ⟨n_{el}⟩_{z} are distinctively larger than the averages on surfaces of constant Rosseland optical depth ⟨n_{el}⟩_{Ross}, while the column mass density averages ⟨n_{el}⟩_{m} are found in between the two. The deviations increase for higher T_{eff} and lower log g considerably, while at lower T_{eff} the differences are significantly smaller. We show in Appendix A.1 that the interpolation to a new reference depth scale changes the statistical properties by redistributing properties from different heights, so the resulting mean horizontal average will look different depending on the reference depth scale. This effect seems to be most pronounced in the case of electron density.
To determine the ionization fraction in spectral line calculations, the electron number density is either already provided by the model atmosphere or looked up from an EOS using the independent thermodynamic variables (typically (T,p) or (T,ρ)). The latter has to be done carefully in the case of the ⟨3D⟩ models, since, besides potential differences in the EOS compared to the one used for calculating the model atmosphere, electron densities derived from the EOS based on averaged independent variables, , can deviate significantly from the more physically consistent averaged ⟨n_{el}⟩ (see Appendix A.3).
3.4. Vertical velocity
It is worthwhile to compare how the vertical velocity, v_{z,rms}, changes with the respective averaging methods. For comparison, we show in Fig. 2 (left panel) the rms of the vertical velocity. In the upper layers, we find the v_{z,rms} on geometrical averages to be higher compared to other averages, while it is lower in the deeper layers. On optical depth the peak in v_{z,rms} below the surface is somewhat symmetric and slightly higher, while for averages on geometrical height and column mass density their peaks are flatter and more skewed towards higher layers, and the peak location is realized in slightly upper layers. For lower T_{eff} and higher log g, the differences diminish more and more, so that for the coolest models, the difference are small. The differences in the velocity arise as well due to the redistribution of velocity during the mapping to the new reference depth scale (see Appendix A.1).
4. Statistical properties
To explore the origins of the differences among the various average ⟨3D⟩ structures and the resulting ramifications for line formation calculations, we discuss here the statistical properties of the temperature, density, and velocity stratifications. Since the statistical properties of ⟨3D⟩_{500} and ⟨3D⟩_{Ross} are fairly similar, we focus only on the latter.
4.1. Contrast
The 3D RHD models usually exhibit a broad range of values at a given height thanks to the fluctuations arising from the convective motions. The amplitude of these fluctuations can be quantified using the rootmeansquare of the relative deviation from the mean, (3)which we refer to as the contrast ( is the mean value of X). It is equal to the normalized standard deviation; i.e., .
The translation to another reference depth scale changes the statistical properties as variables are remapped, which in turn is reflected in changes in contrast. Among the various averaging methods, geometric averages ⟨3D⟩_{z} typically feature the highest contrast. We also find that the level of fluctuations generally increases with increasing T_{eff} and decreasing log g. The highest contrast typically prevails in simulations with the highest T_{eff} and located in the vicinity of the maximum superadiabatic gradient, , and maximum rmsvelocity, . These arise from the photospheric transition from convective to radiative energy transport, and the resulting overturning of the entropydepleted plasma. At the top of the convection zone, the fluctuations reach a minimum, and they decrease towards the bottom of the model atmosphere.
Fig. 3
Temperature (top) and density (bottom) contrasts vs. averaged Rosseland optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.
In top and bottom panels of Fig. 3, we show the temperature and density contrasts, δT_{rms} and δρ_{rms}, respectively. In the case of the optical depth ⟨3D⟩_{Ross}, the temperature contrast is significantly reduced compared to the other reference depth scales ( reduced by a factor of ~ 3), while the density contrast is slightly enhanced ( compared to 10 − 50%). For averages on column mass density ⟨3D⟩_{m}, δρ_{rms} is lower, in particular in the upper layers, and δT_{rms} is slightly smaller compared to the ⟨3D⟩_{z} case. Fluctuations of variables that correlate with the new reference depth scale will be reduced during the transformation. As the translation to layers of constant optical depth partly evens out the corrugated τisosurface, fluctuations of the opacity κ_{λ} will be reduced, since the dominant H^{−}opacity is very sensitive to temperature. Therefore, the temperature fluctuations are also smoothed out. Layers of constant column mass density will similarly suppress density variations (see Appendix A.1). At the top, δρ_{rms} is almost similar between ⟨3D⟩_{m} and ⟨3D⟩_{Ross} in the case of the solar metallicity ); however, at lower metallicity, [Fe / H] = −3.0, we find considerable disparity with .
The thermal stratification in the upper atmosphere is determined by adiabatic cooling thanks to mechanical expansion and radiative heating because of spectral line reabsorption (Asplund et al. 1999; Collet et al. 2007). In metalpoor stars, radiative reheating in upper layers is significantly reduced owing to the weakness of spectral line features, while the mechanical expansion cooling term is virtually unaffected. The reversed granulation takes place at increasingly lower geometrical height with higher T_{eff} and lower log g, causing the distribution of the thermodynamic variables to become increasingly broader and more skewed (see Sect. 4.3). This is the reason for the enhancement in δT_{rms} and δρ_{rms} towards the top boundary in metalpoor simulations in Fig. 3. Replicating the results of full 3D line formation calculations in lowmetallicity stars with ⟨3D⟩ models is therefore challenging, since the averages have to correctly account for such temperature and density fluctuations. Interestingly, the temperature contrast saturates at 6500 K, similar to the saturation of the intensity contrast shown in our previous work (see Fig. 10 in Paper I).
The strength of spectral lines is sensitive to temperature, and the remapping to constant optical depth decreases δT_{rms}, making ⟨T⟩ closer to ⟨T⟩_{rad}. However, the transformation to layers of constant optical depth exhibits the side effect of redistributing the other variables, too, in particular the gas density; δρ_{rms} is thus much higher than averages on column mass density, due to the additional influence of opacity on the depth scale (see Sect. 2.1). This in turn will likely affect the line formation calculations with the different ⟨3D⟩ models.
The strong contrast in the upper part of the convection zone (log τ_{Ross} ≥ 0) is induced by the large amplitude fluctuations owing to the radiative energy losses at the photosphere and the asymmetry of the up and downflows, which we discuss further in Sect. 4.2. An interesting aspect is that the contrast in thermodynamic variables is very similar to the rms of the vertical velocity (Fig. 2), which is indicative of the correlation between the mass flux and the fluctuations in the thermodynamic variables. Namely, vertical velocity is generated by density contrast δρ via to the buoyancy force, f_{B} = −gδρ, which results from an imbalance of pressure and gravity terms in the hydrodynamical equation for conservation of momentum (see Paper I) in the highly stratified atmosphere. Lighter fluid elements (δρ < 0) experience positive buoyancy and thus upward acceleration, while denser elements (δρ > 0) experience negative buoyancy and are pulled downward. Buoyancy forces will vanish eventually, when the density of the up or downflowing element levels with the surrounding gas.
The entropy contrast δs_{rms} (not shown here), qualitatively depicts a very similar dependence on stellar parameter and reference depth scale as δT_{rms}. Both are very similar in optical depth, while for the averages ⟨3D⟩_{z} and ⟨3D⟩_{m} the overall amplitude is a factor ~ 2 smaller. In Paper I, we showed that the convective energy flux depends on the entropy jump, density, and vertical velocity. Interestingly, here we also find additional scaling relations concerning the peak contrast in entropy, , and density, , with the vertical peak velocity . This can be interpreted as convective driving, where the radiative losses generate large fluctuations in the entropy, temperature, and density.
For the different averaging methods, the variations in the minimummaximum range for the temperature and density are qualitatively very similar to the contrast (even though with larger amplitudes ~ 5 − 8), therefore, we refrain from discussing these explicitly.
Fig. 4
Similar as Fig. 3 but showing the relative difference between averages in up and downflows, δT_{up,dn} and δρ_{up,dn}.
4.2. Upflows and downflows
The properties of the convective motions in stellar atmospheres are highly asymmetric in up and downflows. The upflows overshoot into the photosphere leading to nonthermal Doppler shifts imprinted on spectral line features. We first compute the mean values of various variables separately for up and downflows based on the sign of the velocity at a given height. We then determine the relative difference between up and downflows with (Fig. 4). As expected, the buoyant upflows are hotter and lighter compared to the subsiding downflows. Furthermore, the asymmetries are especially pronounced in the convection zone below the optical surface. Above the photosphere, the convective motions decay quickly, and the asymmetries in δT_{up,dn} and δρ_{up,dn} are distinctively smaller. The remaining asymmetries at the top stem from reverse granulation.
The convective flows in granules, slow and almost laminar, radiate away their energy and overturn into the intergranular lanes characterized by cool, dense, narrow turbulent downdrafts. The subsequent largeamplitude fluctuations in the thermodynamical properties are caused by the turbulent mixing of the downflows with the upflows, typically located in the intergranular lane below the optical surface in the SAR. These regions are arranged in tubelike structures around the granules, and can be identified with their excessive vorticity. It is remarkable that, across all stellar parameters, the filling factor of the up and downflow in the convection zone remains almost constant, with f_{up} ~ 2 / 3 and f_{dn} ~ 1 / 3, respectively (see Paper I).
The variable δT_{up,dn} is reduced, and δρ_{up,dn} is enhanced on the optical reference depth scale ⟨3D⟩_{Ross} compared to the other averages. The column mass density shows a smaller asymmetry in density. This behavior, similar to what we discussed earlier for the temperature and density contrasts, is not entirely surprising, since the fluctuations are caused by the presence of the up and downflows (see also Appendix A.1).
Fig. 5
Histogram of the temperature (top) and density (bottom) vs. optical depth for the TO simulation (T_{eff} = 6500 K / log g = 4.0) with solar and subsolar metallicity ([Fe / H] = −3.0). Additionally, the histogram of a single layer (log τ_{Ross} = −4.0) is indicated for the whole layer (black) and separated in up and downflows (blue and red, respectively). Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}; blue solid lines: 1D MLT models.
4.3. Histograms
In Fig. 5, we illustrate temporally averaged histograms of the temperature, , and density distributions, p(ρ) for the TO simulation with two different [Fe / H] evaluated on layers of constant Rosseland optical depth, in order to illustrate the differences in the statistical properties. The histogram of the metalpoor case differs substantially in upper layers from the solar one. Furthermore, in Fig. 6, we show and p(ρ) in the upper layers (⟨log τ_{Ross}⟩ = −4.0) for dwarf models with different T_{eff} and [Fe / H]. In both cases we compare the distributions on constant geometrical height z, constant column mass density m and constant Rosseland optical depth τ_{Ross}.
At solar metallicity (Fig. 6), the temperature distributions are very narrow and symmetric. With increasing T_{eff}, the average T is as expected higher and the width of the distribution broadens slightly. The mean values are very similar between the different ⟨3D⟩ methods and in principle indistinguishable, which also agrees with Fig. 1. Furthermore, the mean values are located very close to the mode.
At [Fe / H] = −3.0, the temperature distributions change considerably. While at cooler T_{eff} the shape is vey narrow and symmetric, for T_{eff} ≥ 5500 K we find a distinct broadening of the Tdistribution on geometrical reference depth scale ⟨3D⟩_{z}, which is given by a long tail at high T and a decreasing peak at lower T (see Figs. 5 and 6). In the column mass density averages ⟨3D⟩_{m} the temperature peak is slightly more pronounced at higher T_{eff}, while the highT tail is slightly reduced. The situation is pretty different for the averages on Rosseland optical depth ⟨3D⟩_{Ross}, where we find that the temperature peak drops faster towards higher T_{eff}, and at 7000 K the Tdistribution shows an almost unimodal distribution. The mean values disagree at higher T_{eff} between the different reference depth scales.
The density distributions behave differently depending on the reference depth scale. On ⟨3D⟩_{z} the histograms are in general slightly skewed with a fat tail towards lower ρ for all metallicities (Figs. 5 and 6). The density distributions for the averages on column mass density are very symmetric and narrow for both solar and low metallicities. At solar metallicity, the density histograms on constant optical depth are narrower and higher than the geometrical analogs, but skewed in contrast to ⟨3D⟩_{m}. In the metalpoor case, ⟨p(ρ)⟩_{Ross} becomes very narrow and symmetric at lower T_{eff}, but towards higher T_{eff} we find the ρdistribution to also be broader. The mean density stratification varies considerably among the different averaging methods.
As mentioned above, adiabatic cooling due to mechanical expansion and radiative reheating are competing with each other in the upper photosphere and contribute to the phenomenon of reversed granulation. At lower metallicity, the reversed granulation is enhanced, so that the optical depth is increasingly strongly corrugated towards higher T_{eff}, which in turn will amplify the differences in statistical properties during the translation to the optical depth scale from the geometrical depth scale. This leads to the systematical broadening in the statistical distribution that we encounter at lower metallicity.
Fig. 6
Histograms of the temperature (left) and density (right panel) distributions taken at ⟨log τ_{Ross}⟩ = −4.0. We show the histograms averaged on constant geometrical height (top), column mass density (middle), and Rosseland optical depth (bottom). The surface gravity of displayed models is log g = 4.5 and the metallicity is solar (dashed lines) and subsolar with [Fe / H] = −3.0 (solid lines). The mean values are indicated by filled and open circles for [Fe / H] = −3.0 and 0.0, respectively.
5. Spectral line formation: ⟨3D⟩ and 3D LTE calculations
To explore the differences between the line formation based on ⟨3D⟩ and full 3D models, we have chosen a set of representative models consisting of a mainsequence (MS) star (T_{eff} / log g = 5777 K/4.44), a turnoff (TO) star (6500/4.0), a redgiant (RG) star (4500/2.0), and a dwarf (4500 / 5.0). For all these models, we considered metalpoor analogs with [Fe / H] = −3.0 besides the solar metallicity.
5.1. 3D line formation calculations
We used the 3D radiative transfer code Scate (Hayek et al. 2011) to calculate full 3D synthetic spectral line diskcenter intensity and flux profiles with 3D Stagger model atmospheres. Scate assumes LTE. Furthermore, in the present work, we also neglected the effects of scattering; i.e. we approximated the source function with the Planck function, S_{λ} = B_{λ}. We caution that LTE is in general a poor approximation, especially for Fe i spectral line formation calculations at low [Fe / H] (e.g. Bergemann et al. 2012), which should be kept in mind for analyzing the LTEbased abundance corrections presented here. For the sake of consistency, we used the same EOS (Mihalas et al. 1988) and continuum opacity data (from the MARCS package; see Gustafsson et al. 2008) as in the 3D Stagger simulations.
To reduce the computational costs for line formation calculations, we consider a subset of N_{t} = 20 temporally equidistant snapshots – the same as used for the temporal ⟨3D⟩ averages – sampling the entire time spans of the individual 3D simulation sequences. Additionally, we reduce the horizontal spatial resolution from N_{x}N_{y} = 240^{2} to 60^{2} by considering only every fourth column in each horizontal direction. Test calculations carried out at full resolution show that differences are negligible for all practical purposes (see Asplund et al. 2000a). Concerning the vertical direction, while we did not subsample the number of depth points, we considered only those layers with min(log τ_{Ross}) ≤ 3.0. The resulting diskcenter intensity and flux profiles are spatially and temporally averaged, and then normalized with the respective continuum intensity or flux.
To systematically illustrate the differences between ⟨3D⟩ and 3D line formation, we computed fictitious atomic lines for neutral and singly ionized iron, Fe i and Fe ii, for the selected Staggergrid models and metallicities. All lines are defined at the same wavelength, λ = 500 nm, and we considered two lowerlevel excitation potentials, χ_{exc} = 1.0 and 4.0 eV. Furthermore, we varied the oscillator strength, log gf, in order to cover a range of line strengths, from weak to partly saturated lines, with equivalent widths from W_{λ} = 5 to . We assumed an iron abundance of log ϵ_{Fe} = 7.51 (Asplund et al. 2009) and log ϵ_{Fe} = 4.51, for the solar metallicity and [Fe / H] = −3.0 case, respectively.
The spectral line calculations with ⟨3D⟩ models were also performed with Scate, to guarantee a consistent comparison. Scate employs atmospheric structures on geometrical height and computes the optical depth, τ_{λ}, for the individual line. Therefore, we provide the geometrical height by integrating dz = d⟨τ_{λ}⟩ / ⟨κ_{λ}⟩, which is of course unnecessary for ⟨3D⟩_{z}. Furthermore, tests revealed that including just an averaged velocity, e.g. v / 3, is insufficient to reproduce the influence of the 3D velocity field on the line shape. Analyzing the influence of the velocity field on the line formation surpasses the scope of the present work; therefore, we will explore this aspect in a separate study. In this paper, for the calculations with ⟨3D⟩ models we neglected the information about the actual velocity field and instead assumed a fixed microturbulence of ξ_{turb} = 1.0 km s^{1} for all considered stellar parameters.
Since the line formation calculations with ⟨3D⟩ models are obviously much faster, we use the ⟨3D⟩_{Ross} averages first to estimate the log gf range, which would result in the designated range in W_{λ}. We then consider ten equidistant log gf values within that range for the ⟨3D⟩ and full 3D models. Finally, we interpolate the curves of growth (log gf vs. W_{λ}) using a spline interpolation and retrieve the Δlog gf difference between ⟨3D⟩ and 3D synthetic lines at a given equivalent width; i.e., Δlog gf = ⟨3D⟩ − 3D. For trace elements, changes in line strength due to Δlog gf are equivalent to changes due to abundance variations Δlog ε; hence, the Δlog gf differences can be interpreted as ⟨3D⟩ − 3D abundance corrections. With four fictitious lines and four representative models with two metallicities, we covered 32 cases in total.
Full 3D line profiles are marked by line shifts and asymmetries owing to the nonthermal Doppler broadening introduced by the up and downflows of the convective motions, which are present in the photosphere due to overshooting (Asplund et al. 2000a). In 3D RHD modeling, the velocity field emerges naturally from first principles. The buoyant hot rising plasma in the granules blueshifts the line, while the fast downdrafts introduce a redshift. Besides the convective motions, another source of line broadening are the inhomogeneities in the thermodynamic independent variables, ρ and T. The ascending granules are hotter and less dense than the downdrafts (see Fig. 4). The velocities and inhomogeneities prevailing at formation height of the individual lines will lead to line shifts and asymmetries. The ⟨3D⟩based lines are symmetric without any shifts, however, we can compare the equivalent widths of lines from calculations based on full 3D models and on the different average stratifications.
Fig. 7
Overview of the ⟨3D⟩ − 3D line formation differences given in abundances displacement Δlog ε vs. equivalent width W_{λ} for the Fe i and Fe ii fictitious spectral lines with the excitation potentials χ_{exc} = 1.0 and 4.0 eV including the Sun, TO, RG and dwarf simulation (from top to bottom). The averages on layers of constant geometric height ⟨3D⟩_{z} (black dashed), constant column mass density ⟨3D⟩_{m} (black dotted), constant Rosseland optical depth ⟨3D⟩_{Ross} (black solid) and at 500 nm ⟨3D⟩_{500} (orange dashed tripledotted lines) are indicated. Furthermore, we show 1D models (red solid), averages (blue dashed) and (green dashed lines). The microturbulence of ξ_{turb} = 1.0 km s^{1} has been used throughout. Notice the different ordinates.
Fig. 8
Similar to Fig. 7 but showing overview of the abundance corrections for metalpoor models, with larger ranges for the yscales.
Fig. 9
In the left panel the mean Δlog ε (evaluated between 5 − 20 mÅ) is illustrated against Fe i and Fe ii given at χ_{exc} = 1.0 and 4.0 eV for the different selected models. In the right panel, the relative difference with ⟨3D⟩ − 3D of the continuum intensity, δI_{μ}, vs. μ angle is displayed. Both Figures include the solar metallicity (top) and the metalpoor (bottom) case, and the averages ⟨3D⟩_{z} (black dashed), ⟨3D⟩_{m} (black dotted), ⟨3D⟩_{Ross} (black solid), ⟨3D⟩_{500} (orange dashed tripledotted), averages (blue dashed), and 1D models (red solid lines).
We probed different formation heights with the parameters of our fictitious lines. The Fe ii lines form deeper in the atmosphere, closer to the continuum forming layers, while the Fe i lines are more sensitive to the intermediate heights of the atmosphere. Spectral lines with lower (higher) excitation potential form at smaller (larger) optical depths. We showed in Sect. 3 that the metalpoor model stellar atmospheres exhibit rather different temperature stratification at the top depending on the averaging method, consequently the latter should show the largest differences between the ⟨3D⟩ models.
5.2. Comparison of ⟨3D⟩ and 3D line formation
We show an overview of the differences between the ⟨3D⟩ and the full 3D calculations in Figs. 7 and 8. The first noticeable observations are the systematic trends in form of a slope towards higher line strength, which are due to the fixed value of the microturbulence, ξ_{turb}, with 1 km s^{1} in the ⟨3D⟩ models. An increasing slope with line strength indicates an underestimation of ξ_{turb}, in particular for the TO and RG (see panels 5 to 12 in Figs. 7 and 21 to 28 in Fig. 8). By contrast, in cool dwarfs, the adopted ξ_{turb} seem to be overestimated. These findings agree with comparisons of 1D models with observations (e.g., Edvardsson et al. 1993; Bensby et al. 2009). We tested this by applying a number of ξ_{turb} values^{4}, which showed that a finetuning can rectify the present slope. However, for the sake of clarity, we prefer to limit the already large number of stellar and line parameters to just a single ξ_{turb}. The calibration of the microturbulence will be the subject of a separate study.
Weak lines are insensitive to ξ_{turb}, yet they show variations in strength, which can be attributed to differences in the mean ⟨3D⟩ stratifications of temperature and density. Interestingly, when one compares this regime between the different averages in Fig. 7, the averages on column mass density are often the closest to the full 3D spectral lines and perform in this respect often better than the averages on constant Rosseland optical depth. The stratification on constant optical depth at 500 nm always shows spectral line features slightly closer to the full 3D case compared to the Rosseland optical depth. However, this is because we chose our fictitious iron lines at 500 nm, which leads to an inherent advantage of ⟨3D⟩_{500} over ⟨3D⟩_{Ross}. The geometrical averages show large deviations in the case of the TO and RG star at solar metallicity (see panels 5 to 12).
The differences in the metalpoor case (Fig. 8) are clearly greater than in the solar metallicity models (Fig. 7). It is obvious that ⟨3D⟩ models at low [Fe / H] struggle to reproduce the 3D case properly, in particular Fe i lines with small excitation potential, and the differences are particularly pronounced for the hotter metalpoor TO stars (panel 21). This is in accordance with our findings from Sects. 3 and 4: at low metallicity and high T_{eff}. The differences in the statistical properties among the various ⟨3D⟩ averages increases at low [Fe / H]. In particular, the widths of the temperature and density distributions become broader at lower metallicity (Fig. 6), and their mean values become increasingly less welldefined in its statistical representation. The reason for the broadening is the enhanced contrast of the reversed granulation due to the reduced radiative reheating with weak spectral line features at low metallicity (see Appendix A.1).
To facilitate an overall comparison between the different averages with respect to line formation, we show in Fig. 9 (left) the mean abundance deviations for weak lines that are determined between W_{λ} = 5 − 20 mÅ. For the model representing the Sun, the differences between ⟨3D⟩ and 3D are in general small: ≲0.1 dex. For the TO stars at solar [Fe / H], the differences are considerably larger: ≲0.2 dex. We find the largest deviations for Fe i lines with small excitation potential χ_{exc} = 1.0 eV, which are the most temperature sensitive; in particular the geometrical averages exhibit strong differences. At lower metallicity, the differences increase in particular for the TO and RG model with ≲0.4 dex, and the ⟨3D⟩ on optical depth shows the largest deviation for metalpoor TO star. In general the deviations become smaller at higher χ_{exc} and for Fe ii lines. The dwarfs show very small differences compared to the full 3D case. These models exhibit the lowest velocities and temperature contrast with the mean stratifications closely resembling the 1D models based on same EOS and opacities.
The averages on column mass density ⟨3D⟩_{m} typically exhibit the best agreement with the predictions of the full 3D model, in particular at low metallicity. The geometrical averages ⟨3D⟩_{z} exhibit large deviations (in agreement with Uitenbroek & Criscuoli 2011), especially for the TO stars. When one considers the comparison of the temperature and density in Fig. 1, then one can deduce that the models with cooler stratifications are closer to the full 3D line strength. Both models averaged on constant optical depth, ⟨3D⟩_{Ross} and ⟨3D⟩_{500}, lead to systematically larger deviations from the full 3D line formation calculations than those obtained with ⟨3D⟩_{m} models, in particular for low excitation Fe i for the metalpoor TO star.
The resulting spectral line features with the logarithmic averages ⟨3D⟩_{log } are similar to plain ⟨3D⟩_{Ross} (therefore we refrain from showing the latter), while averages enforcing hydrostatic equilibrium, ⟨3D⟩_{HSE}, clearly fail to closely reproduce the results from 3D line formation (similar to Uitenbroek & Criscuoli 2011) and lead to rather large errors in the line formation, in particular for the metalpoor TO model (Fig. 8). Furthermore, both the fluxweighted and brightnesstemperature averages, T^{4} and T_{rad}, are in general very close to the plain average, but often slightly less accurate, which is a somewhat surprising result (see T_{rad} in Fig. 9).
Another meaningful way to test the performance of the different averages can be accomplished by comparing the deviation of the CLV of the continuum intensity. In Fig. 9, we show the differences of the continuum intensity, , i.e. between the ⟨3D⟩ and full 3D models. We find in general that the ⟨3D⟩ models overestimate the continuum intensity at disk center (μ = 1), while towards the limb (μ = 0.2) the ⟨3D⟩ often underestimate the intensity. The deviations of the different averages are similar to the above findings with the comparison of the curve of growth. The diskcenter intensities of the 3D RHD models are matched best by the averages on column mass density ⟨3D⟩_{m}, whereas the geometrical averages ⟨3D⟩_{z} display the largest discrepancies, in particular for the RG model at solar metallicity with an overestimation by ~ 60%. The results for the averages on optical depth are once again midway between the two other kinds of averages. An interesting aspect is that the brightnesstemperature averages T_{rad} fail to render the continuum intensities exactly, which has to be interpreted as a consequence of the nonlinearity of the Planck function. Our findings are qualitatively similar to those by Uitenbroek & Criscuoli (2011).
5.3. Cautionary remarks
We remind the reader that LTE is often a very poor assumption at low [Fe / H] (e.g. Asplund 2005) and thus that the abundance differences presented in Figs. 7 and 8 should not be added indiscriminately to results from standard 1D LTE abundance analyses. In LTE, the difference between 3D and 1D models can be very substantial for metalpoor stars for especially low excitation and minority species like Fe i (e.g., Asplund et al. 1999; Collet et al. 2007), but those same lines also tend to be sensitive to departures from LTE (e.g., Bergemann et al. 2012; Lind et al. 2012) in 1D and ⟨3D⟩ models, mainly due to overionization and overexcitation in the presence of a hotter radiation field than the local kinetic temperature (i.e., J_{λ} > B_{λ}). Although not explored for more than Li, one would expect that the very cool upper atmospheric layers, hence steep temperature gradients in metalpoor 3D models compared with classical 1D models, are even more prone to substantial nonLTE effects (e.g., Asplund et al. 2003; Sbordone et al. 2010). In particular, neutral species of relatively low ionization energy, such as Fe i, typically suffer from significant positive NLTE abundance corrections due to overionization (e.g., Asplund 2005; Bergemann et al. 2012; Lind et al. 2012) with low excitation lines are especially prone. For lowexcitation Fe i lines, one would therefore expect the 3D NLTE line strengths to be more similar to the 1D case than the 3D LTE results due to the positive NLTE corrections, partly compensating for the negative 3D LTE corrections. We therefore caution the reader that the 3D LTE abundance corrections presented here (3D LTE – 1D LTE) for Fe i lines are likely to be too negative compared to the NLTE case (3D NLTE – 1D NLTE). As a corollary, it is inappropriate to apply a 1D NLTE abundance correction to a 3D LTEinferred abundance when the latter is very significant, as is often the case at low [Fe / H].
5.4. Comparison with 1D models
In Paper I we compared the ⟨3D⟩_{Ross} stratifications with 1D models computed with the same EOS and opacity as used in the Staggercode, in order to quantify the differences arising solely from 1D modeling based on MLT. The line formation calculations with 1D models perform quite well at solar metallicity, with the exception of the cool dwarf models (Fig. 7). However, in the metalpoor case, the lines based on the 1D models obviously do not correctly reproduce the full 3D lines by overestimating the Tstratifications due to the enforcement of radiative equilibrium in the upper atmosphere (Fig. 8). This is, in particular, distinctive for lowexcitation neutral iron lines as previously found by Asplund et al. (1999) and Collet et al. (2007). Kučinskas et al. (2013) present similar findings for a solarmetallicity RG simulation as well, namely that neutral iron lines based on 1D MLT models are slightly closer to the full 3D lines compared to the ⟨3D⟩ lines.
We note that in our 1D models the turbulent pressure is neglected, and the mixing length is fixed with α_{MLT} = 1.5, both choices that will influence the stratification significantly. Since their effect is strongest in convective zone below the optical surface and the line formation region, the influence in terms of abundance is likely small; in fact, Kučinskas et al. (2013) only found a very small effect <0.02 dex for the reduction in α_{MLT} from 1.5 to 1.2. However, for metalpoor giants the influence can be greater for lines with very high excitation potential.
6. Conclusions
We have investigated the properties of different methods in detail for computing temporal and horizontal average stratifications from 3D RHD Staggergrid simulations of stellar surface convection. The choice of the reference depth is critical, as comparisons of the various ⟨3D⟩ demonstrated. We find in general that the temperature stratifications of the ⟨3D⟩_{z} and ⟨3D⟩_{m} are hotter close to the continuum forming layers and cooler in the upper layers compared to averages on surfaces of constant optical ⟨3D⟩_{Ross} and ⟨3D⟩_{500}, while the density shows differences in the opposite sense. The fluxweighted temperature average and brightness temperature average are distinctively hotter than the plain averages, both close to the optical surface and in the upper atmosphere, since the Planck function and the fourth powers weights the larger temperatures higher. Averages obtained from the logarithmic values lead to lower temperature and density distributions by giving more weight the lower values in the distribution. These characteristics increase with higher T_{eff}, lower log g and especially with lower [Fe / H].
The statistical properties change depending on the reference depth scale, since the transformation to the new depth scale will inevitably imply a remapping of the values from different heights. The translation to layers of constant optical depth will smooth out temperature fluctuations as a byproduct: the temperature is in fact the main source of spatial corrugation of the surfaces of constant optical depth due to the strong temperature sensitivity of the dominant H^{−} continuum opacity source. Therefore, the temperature contrast and extrema are distinctively reduced, in particular in the superadiabatic region. However, this has also the side effect of enhancing both contrast and minimummaximum range of the density. The concomitant remapping of properties from deeper or higher layers during the transformation to the new reference depth scale will in turn change the average values.
Furthermore, we examined the effects of reversed granulation in the upper layers of metalpoor stars, namely the lowering of temperatures above the granules in metalpoor 3D models compared to classical 1D models. We found that the contribution of radiative reheating due to weak spectral line absorption features relative to cooling due to mechanical expansion in the upper atmospheric layers is reduced towards higher T_{eff}. On the other hand, the temperature in the regions immediately above the intergranular lanes are primarily controlled by mechanical expansion or compression and do not appear to be affected by the reduced metallicity. The two combined effects result in an enhanced contrast in the reversed granulation. This in turn leads to an increase in the corrugation of the surfaces of constant optical depth, which implies that the averages on constant optical depth are sampling values from a very wide range in geometrical height, thereby affecting the statistical properties such as mean value and contrast.
The comparison of Fe i and Fe ii calculated in full 3D and different ⟨3D⟩ atmosphere models reveals the surprising result that the averages on column mass density ⟨3D⟩_{m} typically provide the best representation of the 3D model with respect to the line formation. The commonly preferred averages on layers of constant optical depth ⟨3D⟩_{Ross} or ⟨3D⟩_{500} in general perform worse. We located the reason for the underperformance in the predictions of 3D RHD by the ⟨3D⟩_{τ} models being due to the optical depth, dτ_{λ} = ρκ_{λ}dz, which contains the additional nonlinearity of opacity κ_{λ}, in contrast to the column mass density, dm = ρdz; therefore, the statistical properties, in particular, the mean value, are more prone to distinctive temperature fluctuations present in the superadiabatic region and the upper layers, where the reversed granulation takes place. The differences between the lines calculated with the ⟨3D⟩_{τ} models and the full 3D RHD models are significant, in particular, for metalpoor simulations due to the enhanced reversed granulation in the upper layers. We find that the neutral Fe i lines with low excitation potential feature the largest differences between the mean ⟨3D⟩ and full 3D line calculations. The 1D MLT models perform quite well at solar metallicity; however, for metalpoor models the mismatch is evident. Therefore, we caution against using 1D models for metalpoor stars, which will lead to systematic errors in the spectral analysis.
For spectral line formation calculations with ⟨3D⟩ models from the Staggergrid, we recommend using averages obtained on layers of constant column mass density, ⟨3D⟩_{m}, since these provide the closest match to the spectral line strengths obtained with the full 3D RHD models. Furthermore, we advise strongly against using geometrical averages ⟨3D⟩_{z} for spectral line formation calculations. For purposes of improving stellar structures
and asteroseismology, the ⟨3D⟩_{z} models are, however, useful, since these averages alone fulfill the hydrostatic equilibrium, and therefore, comparisons with helioseismological observations are in better agreement.
It is obvious that the temporally and spatially averaged models are incapable of substituting the full 3D atmospheric structure. The reduction due to the averaging will unavoidably lead to sacrificing required information. A promising intermediate approach could be the socalled “1.5D” approximation. This approach emulates atmospheric inhomogeneities, which are probed by the traversing radiation, by considering a series of perturbed 1D stratifications for spectral synthesis (e.g., see Ayres et al. 2006). In the spirit of the latter, one could utilize the temporal averaged histograms for an improved spectral line synthesis, since these contain additional information on the statistical distribution of the 3D simulations.
Acknowledgments
We acknowledge access to computing facilities at the Rechenzentrum Garching (RZG) of the Max Planck Society and at the Australian National Computational Infrastructure (NCI) where the simulations were carried out. Remo Collet is the recipient of an Australian Research Council Discovery Early Career Researcher Award (project number DE120102940). We thank Tiago Pereira for his contribution.
References
 Asplund, M. 2005, ARA&A, 43, 481 [NASA ADS] [CrossRef] [Google Scholar]
 Asplund, M., Nordlund, Å., Trampedach, R., & Stein, R. F. 1999, A&A, 346, L17 [NASA ADS] [Google Scholar]
 Asplund, M., Nordlund, Å., Trampedach, R., Allen de Prieto, C., & Stein, R. F. 2000a, A&A, 359, 729 [NASA ADS] [Google Scholar]
 Asplund, M., Nordlund, Å., Trampedach, R., & Stein, R. F. 2000b, A&A, 359, 743 [NASA ADS] [Google Scholar]
 Asplund, M., Carlsson, M., & Botnen, A. V. 2003, A&A, 399, L31 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Asplund, M., Grevesse, N., Sauval, A. J., & Scott, P. 2009, ARA&A, 47, 481 [NASA ADS] [CrossRef] [Google Scholar]
 Atroshchenko, I. N., & Gadun, A. S. 1994, A&A, 291, 635 [NASA ADS] [Google Scholar]
 Ayres, T. R., Plymate, C., & Keller, C. U. 2006, ApJS, 165, 618 [NASA ADS] [CrossRef] [Google Scholar]
 Bensby, T., Johnson, J. A., Cohen, J., et al. 2009, A&A, 499, 737 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Bergemann, M., Lind, K., Collet, R., Magic, Z., & Asplund, M. 2012, MNRAS, 427, 27 [NASA ADS] [CrossRef] [Google Scholar]
 BöhmVitense, E. 1958, ZAp, 46, 108 [NASA ADS] [Google Scholar]
 Cheung, M. C. M., Schüssler, M., & MorenoInsertis, F. 2007, A&A, 461, 1163 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Collet, R., Asplund, M., & Trampedach, R. 2007, A&A, 469, 687 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Collet, R., Hayek, W., Asplund, M., et al. 2011, A&A, 528, A32 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Edvardsson, B., Andersen, J., Gustafsson, B., et al. 1993, A&A, 275, 101 [NASA ADS] [Google Scholar]
 Feautrier, P. 1964, Comptes Rendus Académie des Sciences, 258, 3189 [NASA ADS] [Google Scholar]
 Gustafsson, B., Edvardsson, B., Eriksson, K., et al. 2008, A&A, 486, 951 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Hayek, W., Asplund, M., Collet, R., & Nordlund, Å. 2011, A&A, 529, A158 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Henyey, L., Vardya, M. S., & Bodenheimer, P. 1965, ApJ, 142, 841 [NASA ADS] [CrossRef] [Google Scholar]
 Kučinskas, A., Steffen, M., Ludwig, H.G., et al. 2013, A&A, 549, A14 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lind, K., Bergemann, M., & Asplund, M. 2012, MNRAS, 427, 50 [NASA ADS] [CrossRef] [Google Scholar]
 Magic, Z., Collet, R., Asplund, M., et al. 2013, A&A, 557, A26 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mihalas, D., Dappen, W., & Hummer, D. G. 1988, ApJ, 331, 815 [NASA ADS] [CrossRef] [Google Scholar]
 Nordlund, A. 1982, A&A, 107, 1 [NASA ADS] [Google Scholar]
 Nordlund, Å., & Stein, R. F. 2001, ApJ, 546, 576 [Google Scholar]
 Nordlund, Å., Stein, R. F., & Asplund, M. 2009, Liv. Rev. Sol. Phys., 6, 2 [Google Scholar]
 Pereira, T. M. D., Asplund, M., Collet, R., et al. 2013, A&A, 554, A118 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Rutten, R. J., de Wijn, A. G., & Sütterlin, P. 2004, A&A, 416, 333 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Sbordone, L., Bonifacio, P., Caffau, E., et al. 2010, A&A, 522, A26 [Google Scholar]
 Skartlien, R. 2000, ApJ, 536, 465 [NASA ADS] [CrossRef] [Google Scholar]
 Steffen, M., & Holweger, H. 2002, A&A, 387, 258 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Steffen, M., Ludwig, H.G., & Freytag, B. 1995, A&A, 300, 473 [Google Scholar]
 Stein, R. F., & Nordlund, A. 1998, ApJ, 499, 914 [Google Scholar]
 Uitenbroek, H., & Criscuoli, S. 2011, ApJ, 736, 69 [NASA ADS] [CrossRef] [Google Scholar]
Online material
Appendix A: Addendum to averaged models
Appendix A.1: Reversed granulation
To illustrate the effects of the remapping of the 3D atmospheric structures on new reference depth scales, we show slices of temperature contours from our TOsimulation in Fig. A.1.
Fig. A.1
Temperature contours from our model with T_{eff} = 6500 K and log g = 4.5 with [Fe / H] = 0.0 (left) and − 3.0 (right). The top panels display horizontal slices with the reversed granulation pattern imprinted in the temperature map (from 3 to 7 × 10^{3} K) taken at ~ 230 km above the surface, which is also indicated in the second panel (dashed lines). The panels below show vertical slices (Tcontours from 2 to 17 × 10^{3} K) ranging from − 5.0 ≤ log τ_{Ross} ≤ 5.0 on layers of constant geometrical height (second), column mass density (third) and Rosseland optical depth (last panel). These panels include isocontours of the temperature (5, 10 and 12 × 10^{3} K; yellow lines) and density (0.1, 1.0 and 2.5 × 10^{7}g / cm^{3}; blue lines) and both increase with decreasing vertical depth. We show also lines of constant optical depth (second) and geometrical depth (third and last) indicated with white lines.
We show horizontal temperature maps taken in the upper atmosphere (top panel) and three vertical slices with different reference depth scales, which include geometrical z (second panel), column mass density m (third panel), and Rosseland optical depth (bottom panel). Furthermore, we indicate three different isocontours of the temperature (yellow) and density (blue lines) in Fig. A.1, and we also show lines of constant optical depth τ_{Ross} (white lines in top panel) or geometrical depth z (middle and bottom panels).
The downdrafts just below the optical surface, which are denser and cooler than the lighter and hotter surrounding granules, are easily identified (by the prominent changes in T,ρ and τ_{Ross} above the downflows, e.g. x ≈ 1.8 Mm). Owing to the lower temperatures in the downdrafts compared with the granules, the same optical depth value is reached at lower geometrical depths, meaning that the emergent radiation in the intergranular lanes originate in much deeper geometrical heights. The corrugation of the optical depth on geometrical depth scale is therefore most pronounced in the downdrafts (see isocontour of log τ_{Ross} = 2.0 in second panel of Fig. A.1).
The opposite is true for the upper atmospheric layers because of the phenomenon of reversed granulation (Rutten et al. 2004; Cheung et al. 2007), namely, above the granules, cooling by adiabatic expansion is dominant, while above the inter granular lanes the radiative reheating and mechanical compression are more important for the energy balance. At lower metallicity and higher T_{eff}, the radiative heating above granules is reduced by the weakening of spectral line features. The resulting reduction in radiative reheating leads to significantly cooler temperatures (see top panel in A.1) and a lower pressure support, and as a consequence the atmospheric layers at a given constant optical depth subside toward lower geometrical heights, closer to the optical surface. Therefore, the temperature contrast is enhanced in the upper atmosphere. The subsiding of the atmosphere is similar to what we found earlier, namely that the density range spanned in the atmosphere is significantly reduced at lower metallicity (see Fig. 16 in Paper I). Finally, the enhancement of the reversed granulation and the temperature contrast results in strongly corrugated surfaces of constant optical depth at the top of metalpoor simulations. We note that we also found an enhanced intensitycontrast for metalpoor stars (see Paper I).
The remapping of the individual columns of the 3D structure from geometrical depth to optical depth entails a change of perspective between the old and the new scales in terms of the distribution of values of a particular physical variable at a given constant reference depth. This is again most obvious in the downdrafts in the convection zone (see line of constant geometrical depth at z = 0.2 Mm in bottom panel of Fig. A.1). Properties from deeper geometrical heights are mapped onto layers at lower optical depth, and the temperature differences between upflowing and downflowing regions are reduced, which results in a less of a temperature contrast and in minimummaximum ranges (see Sect. 4.1). On the other hand, the deviations in the density are significantly enhanced, which will clearly alter the statistical properties, in particular the mean values.
In the upper atmospheric layers of the solar metallicity case, the optical depth is corrugated only a small amount, therefore the transformation does not affect the temperature and density much (compare the upper flat blue line with the two lower corrugated ones in the bottom panel of Fig. A.1). However, the corrugation of the optical depth in the upper atmosphere is rather large for hotter metalpoor stars owing to the enhanced reversed granulation. As a result, the effects of remapping on the optical depth scale for the temperature and density is fairly substantial in these simulations. And the distribution of the thermodynamic properties is broadened, such that the meaning of the horizontal average is weakened (see Fig. 6).
In a similar way, the translation to column mass density naturally reduces the variations in density thanks to its definition of the reference depth scale, which is the depthintegrated density. Therefore, the resulting density fluctuations are rather small in layers at constant column mass density. The variation in temperature is slightly lower than in the averages on geometrical depth, but larger than in the averages on optical depth, as one would expect.
We stress once again that the different reference depth scales are equivalent to each other in terms of the spatial remapping of the 3D atmospheric structures. What differs of course is the statistical properties of physical variables on layers of constant depth, which vary depending on the choice of reference depth scale. One has to consider two important aspects concerning the horizontal averaging, the first being what kind of quantity is considered, and the second which reference depth scale is accounted for. Therefore, the statistical properties of the density and temperature are relatively distinctive depending on which reference depth scale is considered (see Sect. 4).
Appendix A.2: Hydrostatic equilibrium
The Staggercode directly solves the discretized timedependent, RHD equations (see Paper I) for the conservation of mass, momentum, and energy. The conservation properties are reflected in the mean ⟨3D⟩_{z} stratifications of relaxed, quasistationary 3D hydrodynamical models averaged on layers of constant geometrical depth. In particular, the geometrical averages appear over time to be close to hydrostatic equilibrium^{5}. To elucidate this further, we analyze the horizontal and timeaverage of the momentum equation (A.1)with p_{th} being the thermodynamic pressure, v the velocity field, and the viscosity stress tensor. Due to the averaging, the only remaining spatial dependence is the vertical one. Divergence terms thus reduce to vertical derivatives, i.e., ∇·⟨X⟩ = ∂_{z}⟨X⟩. The time derivative ⟨∂_{t}ρv⟩ vanishes on time average as our model atmospheres are relaxed, hence quasistationary. The inertial term reduces to turbulent pressure , so we obtain ⟨∇·(ρvv)⟩ = ∂_{z}⟨p_{turb}⟩. The divergence of the viscous stress tensor, , vanishes on average. The last two terms yield ∂_{z}⟨p_{th}⟩ and ⟨ρg⟩, and we retrieve the equation for hydrostatic equilibrium with (A.2)In Fig. A.2 we show the hydrostatic equilibrium in the form of ρgdz / dp_{tot} = 1 for the temporal and geometrical averaged ⟨3D⟩_{z} stratifications, which are very close to hydrostatic equilibrium. We emphasize that the hydrostatic equilibrium is only fulfilled by considering the total pressure p_{tot}, as given in Eq. (A.2), which includes the nonthermal turbulent pressure that occupies a significant fraction of p_{tot} at the top and in the SAR (see Fig. 21 in Paper I).
Fig. A.2
Deviations from the hydrostatic equilibrium vs. optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.
Furthermore, one can find in Fig. A.2 that the averages on a new reference depth scales feature distinctive deviations from hydrostatic equilibrium (see ⟨3D⟩_{Ross} and ⟨3D⟩_{m}). The transformation of to a new reference depth scale maps all three components of Eq. (A.2) – geometrical depth z, density ρ, and total pressure p_{tot} – away from its hydrostatic equilibrium state. Also, the geometrical depth z loses its strict physical meaning through such a transformation as a mean value. The mean stratifications on constant Rosseland optical depth ⟨3D⟩_{Ross} deviate slightly at the top and significantly in the SAR from the hydrostatic equilibrium (⟨3D⟩_{500} is very similar). The largest departures can be found in the SAR. Furthermore, the amplitude of the discrepancy from hydrostatic equilibrium increases for higher T_{eff} and lower log g.
Fig. A.3
Deviations between the spatially and temporally averaged pressure (top) and opacity (bottom) and the values derived from the EOS, i.e. X(⟨ρ⟩,⟨ε⟩), vs. optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.
Appendix A.3: Deviations from the EOS
In 3D RHD simulations, the thermodynamic state of a simulation is selfconsistently determined by the EOS. This means in particular that any thermodynamic variable depends on only two independent variables (namely the gas density ρ and the internal energy ε) in a welldefined way. However, the internal selfconsistency is broken by reductions like temporal or spatial averaging.
This can be easily understood by investigating the behavior of a function f(X) on a 3D cube of quantity X. For small fluctuations X′ = X − ⟨X⟩ around the horizontal average at a given depth in the model atmosphere, a Taylorexpansion of f up to second order yields The horizontal average of this expression evaluates to where the definition of the contrast δX_{rms} was used in the last equation (see Eq. (3) in Sect. 4.1). The linear term in Eq. (A.5) vanishes as ⟨X′⟩ = 0 by definition. It is immediately clear that holds for linear functions. It is thus the nonlinearity of f that causes a departure of from f(⟨X⟩), because the departure scales with the square of the contrast δX_{rms}.
The discussion can be easily expanded to functions of two variables f(X,Y), since they are found in the EOS.
As a consequence, deriving thermodynamic quantities from averaged independent variables, ⟨ρ⟩ and ⟨ε⟩, will lead to inconsistent outcomes. The mean pressure in a given layer of the 3D cube will deviate from the pressure calculated with the EOS from mean density and mean internal energy, ⟨p_{th}⟩ ≠ p_{th}(⟨ρ⟩,⟨ε⟩). Therefore, with ⟨3D⟩ we face another level of complexity.
To quantify the deviations, we compute the temperature T, pressure p_{th}, opacity κ_{Ross}, and electron number density n_{el} from the EOS by employing the mean independent variables ⟨ρ⟩ and ⟨ε⟩. Then, we determine the relative disagreement as In Fig. A.3, we display the deviations of thermal pressure and opacity . As suggested by Eq. (A.6), we find the maximal deviations typically below the optical surface in the SAR, where the large fluctuations take place due to the overturning and to the presence of convective motions with their highly asymmetric up and downflows. The mean value thus toddles between the bimodal distribution. Furthermore, we find a strong variation in the δX_{EOS} with stellar parameter, which increases for higher T_{eff} and lower log g. Depending on which reference depth scale is applied, the disagreement δX_{EOS} are distinct.
This loss of consistency caused by dimensional reduction means that mean ⟨3D⟩ models can never entirely substitute full 3D models, especially for spectral line formation applications (Uitenbroek & Criscuoli 2011). The mean stratifications are nothing more than statistically meaningful representations of stellar atmospheres, while only the complete 3D data set describes their physical state completely. In 1D model atmospheres, such internal consistency is maintained at all times, since no spatial averaging of nonlinear variables is involved in the construction of 1D models.
All Figures
Fig. 1
Relative differences in the temperature (left) and density (right panel) stratification vs. the (averaged) Rosseland optical depth for various stellar parameters. The differences are relative to the Rosseland optical depth, i.e. . Orange/brown dashed lines: averages on layers of constant geometrical height ⟨3D⟩_{z}; orange/brown dotted lines: averages on layers of constant column mass density ⟨3D⟩_{m}; orange/brown solid lines: 1D MLT models. Blue solid lines: fluxweighted T^{4}stratifications; blue dashed lines: brightness temperatures T_{rad} averaged on surfaces of constant Rosseland optical depth (left panel). Green solid lines: logarithmic density averages ; green dashed lines: hydrostatic averages (right panel). We compare always cooler and hotter effective temperatures, which are distinguished by dark and bright colors respectively. We note that the cool metalpoor dwarfs exhibit very small differences, and are therefore indistinguishable. Note the differences in the yaxes.

In the text
Fig. 2
Root mean square (rms) of the vertical velocity v_{z,rms} (left) and mean electron number density n_{el} vs. optical depth (right panel). Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.

In the text
Fig. 3
Temperature (top) and density (bottom) contrasts vs. averaged Rosseland optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.

In the text
Fig. 4
Similar as Fig. 3 but showing the relative difference between averages in up and downflows, δT_{up,dn} and δρ_{up,dn}.

In the text
Fig. 5
Histogram of the temperature (top) and density (bottom) vs. optical depth for the TO simulation (T_{eff} = 6500 K / log g = 4.0) with solar and subsolar metallicity ([Fe / H] = −3.0). Additionally, the histogram of a single layer (log τ_{Ross} = −4.0) is indicated for the whole layer (black) and separated in up and downflows (blue and red, respectively). Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}; blue solid lines: 1D MLT models.

In the text
Fig. 6
Histograms of the temperature (left) and density (right panel) distributions taken at ⟨log τ_{Ross}⟩ = −4.0. We show the histograms averaged on constant geometrical height (top), column mass density (middle), and Rosseland optical depth (bottom). The surface gravity of displayed models is log g = 4.5 and the metallicity is solar (dashed lines) and subsolar with [Fe / H] = −3.0 (solid lines). The mean values are indicated by filled and open circles for [Fe / H] = −3.0 and 0.0, respectively.

In the text
Fig. 7
Overview of the ⟨3D⟩ − 3D line formation differences given in abundances displacement Δlog ε vs. equivalent width W_{λ} for the Fe i and Fe ii fictitious spectral lines with the excitation potentials χ_{exc} = 1.0 and 4.0 eV including the Sun, TO, RG and dwarf simulation (from top to bottom). The averages on layers of constant geometric height ⟨3D⟩_{z} (black dashed), constant column mass density ⟨3D⟩_{m} (black dotted), constant Rosseland optical depth ⟨3D⟩_{Ross} (black solid) and at 500 nm ⟨3D⟩_{500} (orange dashed tripledotted lines) are indicated. Furthermore, we show 1D models (red solid), averages (blue dashed) and (green dashed lines). The microturbulence of ξ_{turb} = 1.0 km s^{1} has been used throughout. Notice the different ordinates.

In the text
Fig. 8
Similar to Fig. 7 but showing overview of the abundance corrections for metalpoor models, with larger ranges for the yscales.

In the text
Fig. 9
In the left panel the mean Δlog ε (evaluated between 5 − 20 mÅ) is illustrated against Fe i and Fe ii given at χ_{exc} = 1.0 and 4.0 eV for the different selected models. In the right panel, the relative difference with ⟨3D⟩ − 3D of the continuum intensity, δI_{μ}, vs. μ angle is displayed. Both Figures include the solar metallicity (top) and the metalpoor (bottom) case, and the averages ⟨3D⟩_{z} (black dashed), ⟨3D⟩_{m} (black dotted), ⟨3D⟩_{Ross} (black solid), ⟨3D⟩_{500} (orange dashed tripledotted), averages (blue dashed), and 1D models (red solid lines).

In the text
Fig. A.1
Temperature contours from our model with T_{eff} = 6500 K and log g = 4.5 with [Fe / H] = 0.0 (left) and − 3.0 (right). The top panels display horizontal slices with the reversed granulation pattern imprinted in the temperature map (from 3 to 7 × 10^{3} K) taken at ~ 230 km above the surface, which is also indicated in the second panel (dashed lines). The panels below show vertical slices (Tcontours from 2 to 17 × 10^{3} K) ranging from − 5.0 ≤ log τ_{Ross} ≤ 5.0 on layers of constant geometrical height (second), column mass density (third) and Rosseland optical depth (last panel). These panels include isocontours of the temperature (5, 10 and 12 × 10^{3} K; yellow lines) and density (0.1, 1.0 and 2.5 × 10^{7}g / cm^{3}; blue lines) and both increase with decreasing vertical depth. We show also lines of constant optical depth (second) and geometrical depth (third and last) indicated with white lines.

In the text
Fig. A.2
Deviations from the hydrostatic equilibrium vs. optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.

In the text
Fig. A.3
Deviations between the spatially and temporally averaged pressure (top) and opacity (bottom) and the values derived from the EOS, i.e. X(⟨ρ⟩,⟨ε⟩), vs. optical depth. Dashed lines: ⟨3D⟩_{z} averages; dotted lines: ⟨3D⟩_{m}; solid lines: ⟨3D⟩_{Ross}.

In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
