Assessment of stochastic and deterministic models of 6304 quasar lightcurves from SDSS Stripe 82
MaxPlanckInstitut für Astronomie,
Königstuhl 17,
69117
Heidelberg,
Germany
email:
andrae@mpiahd.mpg.de
Received:
21
February
2013
Accepted:
2
April
2013
The optical lightcurves of many quasars show variations of tenths of a magnitude or more on timescales of months to years. This variation often cannot be described well by a simple deterministic model. We perform a Bayesian comparison of over 20 deterministic and stochastic models on 6304 quasisteller object (QSO) lightcurves in SDSS Stripe 82. We include the damped random walk (or OrnsteinUhlenbeck [OU] process), a particular type of stochastic model, which recent studies have focused on. Further models we consider are single and double sinusoids, multiple OU processes, higher order continuous autoregressive processes, and composite models. We find that only 29 out of 6304 QSO lightcurves are described significantly better by a deterministic model than a stochastic one. The OU process is an adequate description of the vast majority of cases (6023). Indeed, the OU process is the best single model for 3462 lightcurves, with the composite OU process/sinusoid model being the best in 1706 cases. The latter model is the dominant one for brighter/bluer QSOs. Furthermore, a nonnegligible fraction of QSO lightcurves show evidence that not only the mean is stochastic but the variance is stochastic, too. Our results confirm earlier work that QSO lightcurves can be described with a stochastic model, but place this on a firmer footing, and further show that the OU process is preferred over several other stochastic and deterministic models. Of course, there may well exist yet better (deterministic or stochastic) models, which have not been considered here.
Key words: galaxies: active / quasars: general / methods: data analysis / methods: statistical
© ESO, 2013
1. Introduction
The study of quasar lightcurves has prospered in the last years with the advent of multiepoch observations such as SDSS Stripe 82 or MACHO. Sesar et al. (2007) have shown that more than 90% of quasisteller objects (QSO) in SDSS Stripe 82 exhibit time variations of 0.03 mag in the optical on timescales of a few years. This time variation is one of the most important characteristics of QSOs and is widely believed to be associated with accreting material falling into the central black holes of QSOs (Rees 1984; Kawaguchi et al. 1998). Many authors (Kozłowski et al. 2010; MacLeod et al. 2010; Schmidt et al. 2010; Butler & Bloom 2011; Kim et al. 2011, 2012; Pichara et al. 2012) have shown that QSO variability can be used to discriminate QSOs from other sources. Some of these works also showed possible correlations between the time variation and physical characteristics of QSOs, such as black hole mass, using a stochastic model (Kelly et al. 2009). This suggests that modelling QSO lightcurves will help us to understand the cause of QSO variability. Thus analysing QSO lightcurves is critical not only for efficient QSO selection but also for a better understanding of the QSO variability mechanism.
In this article, we model quasar lightcurves that have been observed in SDSS Stripe 82 (Ivezić et al. 2007). Previous investigations (primarily Kelly et al. 2009) have successfully employed a “damped random walk” as a stochastic model for QSO lightcurves from MACHO data. This model was motivated by earlier results that showed that QSO lightcurves typically exhibit power spectra that are power laws with slopes ≈2 (Giveon et al. 1999; Collier & Peterson 2001), a behaviour that can be achieved with a damped random walk in certain domains, too. Kozłowski et al. (2010) and MacLeod et al. (2010) confirmed that the dampedrandomwalk model of Kelly et al. (2009) indeed provides a good description of QSO lightcurves. Zu et al. (2013) performed a model comparison of power spectra of 55 OGLE quasars but could not detect any significant deviations from the damped random walk using frequentist hypothesis testing. However, no rigorous Bayesian model comparison based on the lightcurves’ photometry itself has been undertaken to date.
The principal objective of this article is to conduct a Bayesian model assessment on a set of 6304 QSO lightcurves of Ivezić et al. (2007). We try to assess whether the damped random walk is indeed a reliable model for QSO lightcurves, in comparison to numerous other models. Kelly et al. (2009) speculated whether extensions of this process may lead to even better models. Therefore, we also compare the dampedrandomwalk model to several of its extensions. On a more fundamental level, we want to assess whether QSO variability is deterministic or stochastic.
We present various deterministic and stochastic models for QSO lightcurves in Sect. 2. We discuss the data and its properties in Sect. 3 and present our results in Sect. 4. Finally, we conclude in Sect. 5.
2. Models and model comparison
In this section, we discuss the method for model comparison and briefly summarise the models we are considering.
2.1. Bayes factors
We perform the model comparison by means of Bayes factors. We explicitly decide against using pvalues in orthodox hypothesis tests (reduced χ^{2}/χ^{2}test, KStest, Ftest, etc.) because they are known to favour increasingly complex models as the amount of observational data increases (e.g. Berger & Sellke 1987; Kass & Raftery 1995; Berger 2003; Christensen 2005). In particular, as more data becomes available, pvalues generally do not converge to favour the “true” model. Therefore, if a model is rejected by a pvalue, we can never be certain whether the model is indeed inappropriate, or whether it is this inherent failure of the pvalue itself at work. Bayes factors do not suffer from this problem (e.g. Kass & Raftery 1995).
Let D denote the observed data and let M_{0} and M_{1} denote two models with model parameters θ_{0} and θ_{1}, respectively. The Bayes factor is then defined as the ratio of Bayesian evidences, (1)where p(θM) denotes the prior distribution of the model parameters θ of model M. In words, the Bayesian evidence p(DM) of the data D given a model M is the probability that the observed data D could have been generated from model M, irrespective of the parameter values of model M.
Bayes factors penalise model complexity in a very intuitive way. As the Bayesian evidence is a priorweighted mean of the likelihood function, an additional model parameter has to lead to an increase in average likelihood. Therefore, an additional model parameter has to provide a “net increase” in likelihood in order to be “plausible”.
Estimation of the Bayes factor is nontrivial due to the marginalisation integrals of the Bayesian evidences in Eq. (1). Therefore, we estimate the Bayesian evidence by Monte Carlo integration: we draw random samples from the prior distribution, evaluate the likelihood function for the sampled parameter values, and compute the mean value of all likelihoods.
2.2. Interpretation of Bayes factors
Given two models, M_{0} and M_{1}, and estimates of their Bayesian evidences, p(DM_{0}) and p(DM_{1}), we use the logarithmic Bayes factor, (2)Throughout this work, we use the terminology of Kass & Raftery (1995), where Δ_{1−0} > 2 is interpreted as “decisive evidence against M_{0}”. In words, this means the observed data is a factor >100 more likely to have been generated by model M_{1} than by model M_{0}, irrespective of those models’ parameter values.
A (logarithmic) Bayes factor of Δ_{1−0} > 2 can only be interpreted as decisive evidence against M_{0}, since we have found at least one other model (namely M_{1}) that outperforms M_{0}. However, we cannot conclude from Δ_{1−0} > 2 that we have found decisive evidence in favour of M_{1}. There might be other models that we have not tested that would outperform M_{1}. In order to provide evidence in favour of some model, we would have to test all reasonable alternatives. In practice, the set of reasonable alternatives is infinitely large and cannot be covered.
2.3. Prior distributions and Bayes factors
The choice of prior distributions on model parameters obviously has a large impact on the Bayesian evidence and any Bayes factor computed from it. Prior distributions therefore need to be chosen carefully^{1}. As we have no intuition for most of the models we are considering, we decided to randomly select 100 QSO lightcurves from our data sample and to perform a maximumlikelihood parameter estimation. The resulting distribution of bestfit parameters over this subset is then fitted by an appropriate model, e.g., a Gaussian, a lognormal, or a uniform distribution. These distributions are then employed as prior distributions on all QSO lightcurves. This procedure provides us with a coherent choice of prior distributions, based on the characteristics of the ensemble of lightcurves. We emphasise that we do not use the parameter values reported by Kelly et al. (2009) to infer prior distributions for the dampedrandomwalk model.
2.4. Deterministic vs. stochastic models
We broadly distinguish between “deterministic” and “stochastic” models. For a deterministic model, e.g., a sinusoid, we can predict the model’s (not the data’s) time evolution without uncertainty. Conversely, for a stochastic model, e.g., a random walk, this prediction is only probabilistic, even when we know the true model parameters.
2.5. Deterministic models
As alternatives to stochastic processes in general, we are considering a few simple deterministic models for QSO lightcurves.
2.5.1. Constant model
The simplest possible model of a QSO lightcurve m(t) is a constant model, (3)This model assumes that there is no intrinsic time variability in the QSO lightcurve itself and any fluctuation is attributed to the measurement error. Given the results from Sesar et al. (2007), it is obvious that this model may not be a very useful description of QSO lightcurves. However, it is the simplest model and should thus be taken into consideration.
2.5.2. Constant model plus additional noise
This model is an extension of the constant model that adds an additional noise term, which is independent of the measurement error. This additional free parameter can be interpreted either as intrinsic to the QSO lightcurve itself or as correction for a potentially underestimated measurement error, or both. We have no possibility of differentiating between these two interpretations, without having additional information.
2.5.3. Sinusoidal models
The sinusoidal model assumes that the QSO lightcurve is periodic around a mean value, a_{0}, (4)We use this model with flat priors in period and in logarithmic period for periods between 1 and 10 000 days, i.e., this model appears twice. Furthermore, we consider the sinusoid with a periodogram prior. Note that by using a frequentist periodogram (Horne & Baliunas 1986) as prior distribution, we already make excessive use of the available data. Therefore, this prior distribution is highly favourable for this model^{2}. This is acceptable because we are going to find this model to have low evidence later, such that this prior in favour of this model is a conservative choice. We also consider the model comprised of a double sinusoid, where the prior is uniform over period for both components.
2.5.4. Sinusoidal model plus additional noise
This model is an extension of the singlesinusoid model that adds an additional noise term, which is independent of the measurement error. Again, this additional free parameter can be interpreted either as intrinsic to the QSO lightcurve itself or as correction for a potentially underestimated measurement error, or both.
2.6. Stochastic models
We consider various different stochastic models. Evidently, we cannot lay out the details of all these processes here. Instead, the interested reader may refer to Brockwell & Davis (2002) for more details.
2.6.1. Dampedrandomwalk model (OU process)
The chief character in this work is the “damped random walk”. This model is actually called the OrnsteinUhlenbeck process (Uhlenbeck & Ornstein 1930; Gillespie 1996, hereafter OU process) and we adopt this name for the rest of this work. The OU process is the only stochastic process that is Markov, Gaussian and stationary. It is a special kind of continuoustime firstorder autoregressive process, which is abbreviated as CAR(1). These are defined by the recursion formula (5)where Y_{n} is the observed value at time t_{n}, φ(t_{n},t_{n − 1}) is a deterministic function, and Z is a random variate “driving” the stochastic process. Such a process is called “autoregressive”, because Y_{n} can be predicted from the previous observation Y_{n − 1}. It is first order, because Y_{n} is predicted from Y_{n − 1} only, while Y_{n − 2} etc. have no influence once Y_{n − 1} is given. It is continuous time, because the observation times t_{n} are nonuniformly spaced. For the OU process, Z is a Gaussian random variate and a special choice for φ is made, (6)where τ is the relaxation timescale. More mathematical details on the OU process, its likelihood function and parameter estimation, can be found, e.g., in Kelly et al. (2009) and, in more detail, in BailerJones (2012). We compute likelihoods of the OU process as described in Sect. 3.1 of Kelly et al. (2009).
2.6.2. Extending the OU process
Kelly et al. (2009) speculate that extensions of the OU process could provide improved descriptions of QSO lightcurves. However, there are various different “dimensions” along which we can extend the OU process. Since the OU process is a Gaussian CAR(1) process with a special choice of φ, possible extensions are:

Wiener process, which is the Gaussian CAR(1) process with φ = 1. This is the classical random walk.

Linear combinations of multiple OU processes. Likelihoods are evaluated using the Kalman recursion as described in Kelly et al. (2011). In particular, the component OU processes have identical driving amplitudes and vary only in their individual timescales, as in Kelly et al. (2011)^{3}.

Gaussian CAR(2) processes with two free deterministic functions, φ_{1}(t_{i},t_{j}) and φ_{2}(t_{i},t_{j}) for which we consider three different parameterisations. This is a secondorder extension of the OU process, in which Eq. (5) is extended by another predecessor. First, we choose constant φ_{1} = φ_{2} = 0.1, which we found to yield relative high likelihood values. Second, we choose a parametrisation as in Eq. (6), where the two relaxation timescales τ_{1} ≠ τ_{2} are allowed to be different. Third, we choose two relaxation timescales that are identical, i.e., τ_{1} = τ_{2}.

Gaussian CARMA(1, 1) process, which extends the OU process by a firstorder moving average. This introduces a smoothing of random fluctuations and thus corresponds to another kind of “damping”.

NonGaussian CAR(1) processes with φ = 1 (“nonGaussian random walk”). We consider only αstable distributions, namely the Cauchy distribution, the symmetric stable distribution, and the (generally asymmetric) stable distribution. Appendix A provides a brief overview of stable distributions.

Gaussian ARCH(1) (Engle 1982) and GARCH(1,1) processes (Bollerslev 1986), where there is stochasticity in the variance instead of the mean. These stochastic processes are also combined with aforementioned processes, providing models such as CARMAGARCH with stochasticity in both mean and variance.
Fig. 1 Examples of stochastic processes. We can see qualitative differences by eye: The Wiener process in panel a) drifts away, whereas the OU process in panel b) reverts to the mean. The Cauchy process in panel c) has “steps” due to the heavy tails of the Cauchy distribution. The GARCH(1,1) process in panel d) exhibits episodes of low and high variation.

Open with DEXTER
3. The data
3.1. QSO lightcurves from SDSS Stripe 82
Ivezić et al. (2007) compiled a database of lightcurves of variable objects from the SDSS Stripe 82 data. From these data, we extract quasars using the spectroscopic redshift estimate. Any variable object with redshift z ≥ 0.08 is considered as a quasar. This provides us with a sample of 6304 QSOs, the redshift distribution of which is shown in the top panel of Fig. 2. From these data, we select only the gband lightcurves, since this is one of the deepest bands and has reliable magnitude estimates. We do not conduct a multivariate timeseries analysis, first, since such models are considerably more complex and thus harder to constrain from the available data, and second, since the different bands exhibit strongly correlated variability (Schmidt et al. 2012). Consequently, studying multiband variability is unlikely to provide considerably more insight than a singleband analysis. The bottom panel of Fig. 2 shows that the majority of gband lightcurves has between 40 and 80 observations. The minimum number of observations is 11 and the maximum number is 140.
Fig. 2 Sample distributions of spectroscopic redshift estimates (top panel) and number of observations in the gband lightcurve (bottom panel).

Open with DEXTER
3.2. Accounting for measurement errors
We neglect measurement errors on the time domain t_{n} because they are very small. However, we cannot neglect measurement errors on the observed magnitudes g_{n}. We assume that these errors are Gaussian standard deviations, σ_{n}.
Accounting for such measurement errors for deterministic models leads to a likelihood function. However, in the case of stochastic models, data and model are both probability distributions. Consequently, the likelihood of a single observed magnitude g_{n} is given by a convolution of model and error distribution, (7)where denotes the normal distribution and p(xθ) is the stochastic model of x with parameter values θ (e.g., see BailerJones 2012).
If we consider Gaussian processes, the convolution integral of Eq. (7) is analytic. However, in the case of a stable process – Cauchy, symmetric, or general – this convolution is not analytic. In our implementation, the integral is then estimated by drawing 100 Monte Carlo samples from the Gaussian error distribution and evaluating the likelihood of the stable process.
3.3. Outlier measurements
Outliers in the measured lightcurves pose a severe problem to any analysis. As stable distributions have heavier tails than the Gaussian distribution, we could not tell apriori whether such outliers were measurement flukes or real observations. Handling such outliers would be nontrivial because excluding them from the data analysis would possibly deprive us of our most valuable data if QSO lightcurves were stable processes. It would be necessary to add an outlier distribution to the Gaussian stochastic process, though it is unclear how such an outlier distribution should be constructed. Therefore, we only conduct a coarse outlier removal on the data, excluding any measurement with extreme g measurement or extreme measurement error. We consider all remaining data from SDSS Stripe 82 as valid measurements, i.e., we take the remaining data at face value and assume that there are no outliers. Consequently, if we find the Cauchy process not to be a good description despite of taking all data at face value, this will be a conservative result.
4. Results
4.1. Decisive evidence with confidence levels
We normally consider a model M_{1} to provide decisive evidence against model M_{0}, if the logarithmic Bayes factor Δ_{1−0} is larger than 2 (Sect. 2.2). However, by estimating the Bayesian evidence through Monte Carlo integration, we introduce a random error into the estimate of Δ_{1−0}, which we denote by σ_{Δ}. If σ_{0} and σ_{1} denote the statistical errors of the Monte Carlo estimates of Bayesian evidences, we estimate σ_{Δ} through error propagation, (8)Typically, σ_{Δ} is of the order of 0.5 or less, such that the criterion Δ > 2 may not be as confident as we expect. In order to account for the uncertainty in our estimate of the Bayes factor, we modify our criterion: We consider a model M_{1} to provide “decisive evidence against M_{0} with 3σ confidence”, if (9)We likewise define decisive evidence with 5σ, 7σ, and 10σ confidence.
Results of evidencebased model comparison.
4.2. Overview
Table 1 summarises the results of comparing the models we are considering. Inspecting the last column of maximum evidences, two things are immediately obvious: first, the OU process is clearly superior to all other models considered here, providing the best model for 5047 out of 6304 QSO lightcurves. Second, the deterministic models considered here do a rather poor job in describing those QSO lightcurves.
Let us now study Table 1 in more detail. First, we consider the deterministic models. For all QSO lightcurves, there is decisive evidence against the model of a constant lightcurve at 10σ confidence. Adding an additional noise term to the constant model improves the results considerably but still provides a good description only for a handful of QSO lightcurves. Sinusoidal models are similarly poor descriptions. In particular, we observe that the periodogram prior does not perform any better than the other priors on period. Given the limits on period (1 to 10 000 days), the flat prior in P seems to outperform the flat prior in log P, which may indicate that if QSO lightcurves were single sinusoids, they would prefer large periods, since the flat prior in P favours large values of P compare to a prior flat in log P. Adding yet another sinusoidal component also does not improve the model performance considerably.
Now let us consider Table 1 with respect to the stochastic models. For a significant fraction of QSO lightcurves, there is no decisive evidence against the Wiener process with confidence, though only few QSOs are best fit by this model. Nevertheless, the OU process clearly outperforms the Wiener process. This is astrophysically sensible because the (marginal) variance diverges with time for the Wiener process, yet the QSO only has finite energy supply. For 6 023 lightcurves, no model can provide decisive evidence against the OU process at any relevant confidence level. Next, Gaussian CAR(2) processes apparently do not improve the results obtained by the OU process. Stable CAR(1) processes generally seem to provide very poor descriptions, though the Cauchy CAR(1) process is favoured by some lightcurves which may indicate the presence of outlier measurements in these lightcurves. However, there is decisive evidence against general stable CAR(1) processes for all lightcurves. Similarly, the CARMA(1, 1) process is outperformed by the OU process. Last but not least, we note that adding stochastic variance (ARCH and GARCH) does improve the modelling outcome. In particular, extending the OU process by a GARCH(1, 1) component, we obtain a model that is almost as good as the OU process alone. This suggests that some QSOs exhibit stochasticity also on the variance not only on the mean.
Given the infinite (marginal) variance of the Wiener process and the heavy tails of the Cauchy CAR(1) process, respectively, we tested whether the preference for any of these two models shows any dependence on outlier measurements. In particular, we find that preference for these two models does not appear to be connected with maxmium gband measurement errors or maximum absolute measurementerrorweighted difference to the median magnitude of the lightcurve. However, we do find a clear tendency that preference for the Wiener process or the Cauchy CAR(1) process is more likely for QSO lightcurves with fewer observations and at lower redshfits.
As an additional sanity check, we repeated the analysis of the OU process, in which the prior distributions were twice and half as broad as before. In both cases, we find no noteworthy changes in Table 1. This suggests that the choice of prior distributions only has a minor impact on the preference for the OU process.
Fig. 3 Example lightcurves with maximum evidence for constant model with additional noise (first row), for sinusoid with flat prior in period (second row), for two sinusoids (third row), for Wiener process (fourth row), for OU process (fifth row), and for Cauchy CAR(1) process (sixth row). In order to facilitate comparison for this figure, all lightcurves have been standardised by subtracting the mean and dividing by the standard devition. Numbers in the top right corners of each panel provide this QSO’s ID from Ivezić et al. (2007).

Open with DEXTER
Figure 3 shows example lightcurves of four QSOs that favour certain models. We note that lightcurves in the top three rows exhibit strong variation in magnitude over short timescales. Lightcurves in the bottom panels also may exhibit large variations in magnitude, but over longer timescales. There are no obvious periodicities in any of these lightcurves. Lightcurves in the last row exhibit a few outlier observations, which may explain why they favour a Cauchy CAR(1) process with heavy tails.
4.3. Assessing stochasticity
Table 1 clearly shows that the OU process is by far the best model for QSO lightcurves of those models considered so far. We now want to generally assess the stochasticity of QSO lightcurves by comparing the combined deterministic vs. the combined stochastic models. For this purpose, we compute the number of QSOs where there is at least one deterministic model where no stochastic model can provide decisive evidence against it, and viceversa. Table 2 shows the results. Although there are 171 out of 6304 QSO lightcurves that are best described by a determinisitc model, there are only 29 QSO lightcurves where no stochastic models can provide decisive evidence against it at all relevant confidence levels. Conversely, there are 5353 QSO lightcurves where a stochastic model provides decisive evidence against all deterministic models at 10σ confidence. This provides a strong indication that QSO lightcurves are of stochastic nature.
Assessment of deterministic vs. stochastic models.
4.4. Linear combinations of OU processes
Kelly et al. (2011) suggest to use linear combinations of multiple OU processes. They find that typically a mixture of ≳30 OU processes is necessary to fit the observed power spectra of their QSO lightcurves. However, both methods for estimating the number of OU processes outlined in Kelly et al. (2011, Sect. 4.2 therein) do not correctly penalise model complexity (see Sect. 2.1 and discussions in Berger & Sellke 1987; Kass & Raftery 1995; Berger 2003; Christensen 2005). Consequently, using a linear combination of 30 OU processes or more is very likely to be an “overfit”^{4}.
Using the 6304 QSO lightcurves from SDSS Stripe 82, we want to assess how many OU processes can be superposed without overfitting the data. Table 3 shows that for the vast majority of QSO lightcurves, there is no decisive evidence against the single OU process. There are only very few lightcurves that favour two or more OU processes. Again, as a sanity check, we repeated the analysis with prior distributions half and twice as broad. We do not find any noteworthy change in our results, which implies that we are not overly sensitive to the choice of prior distributions. Unfortunately, our results are not directly comparable to Kelly et al. (2011), since our lightcurves do not contain as many observations (cf. Fig. 2).
Fig. 4 Five randomly selected example lightcurves where the OU process has highest evidence of all models. The bestfit model prediction is probabilistic. The black dashed line is the timeevolution of the mean. The three different grey shadings are the 1, 2, and 3σ intervals, respectively.

Open with DEXTER
Estimating the optimal number of linear combinations of OU processes.
4.5. Parameters of OU process
As we found the OU process to be by far the best model for QSO lightcurves, let us consider this model in more detail. We first show some example lightcurves with their bestfit OU process, and then investigate the distribution of bestfit parameter values.
So far, in order to evaluate Bayesian evidences, there was no need to actually maximise the likelihood function. However, now this becomes necessary. Starting out from the 20 000 Monte Carlo samples drawn from the prior PDF, we select the parameter combination that achieved the highest likelihood. We then initialise a Simplex algorithm (Nelder & Mead 1965) at this parameter combination and let it further maximise the likelihood function.
Fig. 5 Same as Fig. 4 but now zoomed into the time interval from 53 611 to 53 711 days.

Open with DEXTER
Fig. 6 Maximumlikelihood restframe parameters τ_{0} and of the OU process for all 6304 Stripe 82 QSO lightcurves. Black dots represent QSO lightcurves that are best described by an OU process, whereas red triangles represent those where the OU process is not the best description. Orange squares represent 100 MACHO QSO lightcurves from Kelly et al. (2009).

Open with DEXTER
Figure 4 shows five randomly selected QSO lightcurves and their bestfit OU processes. We can nicely see the time evolution of mean and standard deviation of the probabilistic model prediction^{5}. Note that the variance does not diverge with time because the OU process is stationary (0 < φ_{OU} < 1)^{6}. Similarly, note that for high observed values, the mean evolves downwards, whereas for low observed values the mean evolves upwards. This behaviour is called “mean reversion” and is also due to 0 < φ_{OU} < 1. We can see from Fig. 4 that the bestfit OU processes provide good models over long time separations between observations. Figure 5 shows the same but now resolving one of the time frames with many observations. Evidently, the bestfit OU processes are also excellent descriptions in that case. Note that the evolution of standard deviation of the model prediction does not start from 0 but from the error of the last observation.
Let us now repeat the analysis of OUprocess parameters that Kelly et al. (2009) conducted for 100 MACHO lightcurves. Our data sample is considerably larger and independent, such that this is also an independent test. Figure 6 shows the distribution of bestfit restframe parameters (10)and (11)for the OU process for a QSO lightcurve at redshift z. The distributions of τ_{0} and for our 6304 QSO lightcurves appear to be consistent with the distribution of the same parameters for the 100 MACHO QSO lightcurves as inferred by Kelly et al. (2009). We too find the majority of relaxation timescales between 100 and 1000 days, while values of σ_{0} are of the order of 0.01 as well. We note that there is a peculiar tail in parameter space, where QSO lightcurves have low relaxation timescales and large variation. These objects are lightcurves that prefer not being fit by the OU process. Figure 7 shows the distributions of bestfit parameters for the OU process. In detail, we obtain, Note that the agreement between our results and those obtained by Kelly et al. (2009) provide an important consistency check, as our method and data are completely different and we did not use results from Kelly et al. (2009) as prior distributions.
Fig. 7 Distribution of maximumlikelihood restframe parameters μ, and τ_{0} of the OU process for 5047 QSO lightcurves that are best described by an OU process.

Open with DEXTER
The typical values of relaxation timescales, τ, of a few hundred days could be related to the typical estimated size of QSO accretion discs which are a few hundred lightdays. As larger discs are brighter, this suggests a possible correlation of τ and brightness. However, we do not see noteworthy evidence of such a correlation in our data.
4.6. Composite models
In another attempt to construct better models of QSO lightcurves than the OU process, we combine a deterministic model with a stochastic process. In our opinion, the most reasonable choice is to combine a sinusoidal model with a stochastic process. When combining the sinusoid with a stochastic process, we can drop the offset parameter of the sinusoid and let the stochastic process take care of it. Furthermore, we no longer employ the periodogram prior on the sinusoid’s period, since, first, the model has now two components generating variability, and, second, we no longer aim for conservative evidence against this model. Instead, we adopt a prior distribution that is flat in P, ranging from periods of 1 day to 10 000 days.
Table 4 shows how the model assessment changes, if we take such composite models into consideration. There are two interesting conclusions: First, adding a sinusoid to the Wiener process decreases the model performance drastically. Apparently, adding the sinusoid component does not improve the description of QSO lightcurves and the additional model parameters are penalised accordingly. Second, adding a sinusoidal component to the OU process creates a composite model that is highly competitive to the OU process alone, despite increasing the number of model parameters from 3 to 6. For 6028 QSO lightcurves, no other model can provide decisive evidence against this model at any relevant confidence level, while even 1706 of all lightcurves (27%) are best described by this model. Nevertheless, twice as many QSO lightcurves are still best described by an OU process without sinusoidal modulation.
Fig. 8 Distribution of bestfit sinusoidal periods for those 1 724 QSO lightcurves that are best described by a combination of sinusoid and OU process. We quote restframe periods that have been corrected for redshift.

Open with DEXTER
Figure 8 shows the distribution of bestfit periods of QSO lightcurves favouring a combination of sinusoid and OU process. Typically, periods appear to be of the order of 1000 days, while approximately 90% of periods are between 500 and 5000 days. This corresponds to longterm variations over several years and additional data are necessary to investigate this in more detail. For instance, continued observations of these targets by PanSTARRS may confirm the longterm variation of these sources.
Fig. 9 Preference of OU process plus sinusoid over OU process alone as a function of spectroscopic redshift. The bestfit linear trend has a negative slope but it is only of 2.4σ confidence.

Open with DEXTER
Fig. 10 Preference of OU process plus sinusoid over OU process alone as a function of number of observations. The bestfit linear trend has a negative slope with 5.2σ confidence.

Open with DEXTER
Let us test whether the preference for an additional sinusoidal component correlates with the available astrophysical information about these QSOs. Figure 9 shows that there is no indication that preference for an additional sinusoid depends on spectroscopic redshift. Figure 10 shows that there is a weak dependence on the number of observations. QSO lightcurves with more observations slightly tend to favour the OU process alone, without an additional sinusoid. This trend is very weak but could indicate that we do not have enough data to rule out the composite model.
Testing the preference for an additional sinusoid for a dependence on the QSO’s brightness or colour is complicated by the large range of redshifts of the QSOs (cf. Fig. 2) and the required K correction. Due to this large redshift range, absolute magnitudes computed from the apparaent g would correspond to very different restframe wavelengths and would thus not be comparable. A similar argument applies to colours. However, we do not want to make a K correction because we do not want to make any assumption on QSO spectra. Instead, we bin the data into narrow redshift slices of width Δz = 0.025. QSOs with z < 0.3 or z > 3.3 are not considered here, as they are too sparse to allow a populated slicing. We then fit a linear relation to all redshift bins, where each redshift bin may have its own offset parameter accounting for the appropriate K correction at that redshift, but all bins are simultaneously fit by an identical slope parameter, b. For the gband magnitude, we obtain a slope of (15)and for g − r colour, we obtain a slope of (16)These numbers provide circumstantial evidence that QSOs lightcurves which prefer an OU process with an additional sinusoid tend to be brighter and bluer than other lightcurves which prefer the OU process alone. Given the fact that bluer QSOs tend to be brighter due to the thermal origin of their radiation (e.g. Giveon et al. 1999; Trèvese et al. 2001; Geha et al. 2003; Schmidt et al. 2012), this could be interpreted as an indication that the preference of periodic oscillations may correlate with an increase in “temperature” of the emission region.
5. Conclusions and discussion
Given the results of Table 1, we conclude that the overwhelming majority of QSO lightcurves are certainly not just due to Gaussian variations about a constant magnitude, in agreement with results of Sesar et al. (2007). Furthermore, the overwhelming majority of QSO lightcurves do not exhibit any indication of sinusoidal variability. Indeed, our results (Table 2) suggest that QSO lightcurves are not well described by simple deterministic models but instead are of stochastic nature, since we only find 29 out of 6304 QSO lightcurves where there is decisive evidence against all stochastic models. Furthermore, a substantial fraction of QSO lightcurves appear to exhibit stochasticity not only on the timeevolution of the mean value but also on the timeevolution of the variance itself (cf. evidence for models with ARCH or GARCH component in Tables 1 and 4).
What is causing the stochasticity? Kelly et al. (2009) provide an argument that this stochastic nature could arise through thermal fluctuations in the accretion disc of the quasar, namely magnetic turbulence. There could also be flares in the accretion disc, caused by inhomogeneous infall of matter. Last but not least, there is also the possibility that QSO variability is governed by complex, nonlinear processes, which are actually predictable but cannot be well described by our simple deterministic models.
Kelly et al. (2009) found the OU process to be a good description of 100 QSO lightcurves from the MACHO data. This result has been confirmed for other data by other authors (e.g. Kozłowski et al. 2010; MacLeod et al. 2010). Furthermore, Kelly et al. (2009) speculated whether extensions of the OU process could lead to better models. We have tested both these hypotheses in the Bayesian framework. We have considered several possible extensions of the OU process and several alternative models. However, there is decisive evidence against almost all of these extensions for the majority of QSO lightcurves. We find only one extension that is competitive with the OU process, and that is the OU process combined with a sinusoidal oscillation. 1706 out of 6304 QSO lightcurves favoured this model, while most of the rest favoured the simple OU process. These QSOs seem to be brighter and bluer, which may indicate a relation with increasing temperature and thermal activity. Furthermore, for the vast majority of QSO lightcurves in our sample there is no evidence that multiple OU processes (Kelly et al. 2011) provide better descriptions than a single OU process (Table 3). Comparing the bestfit OU parameters with results of Kelly et al. (2009), we find consistent results obtained from independent methods and different data, which provides an important sanity check.
Possible reasons why the OU process appears to be such a good description of QSO lightcurves have already been offered in the literature:

1.
The OU process approximates the shape of the observed power spectrum of QSO lightcurves (Kelly et al. 2009, 2011).

2.
The OU process is a solution to the linear stochastic diffusion equation, which may account for the astrophysical processes taking place in the QSO accretion disc (Kelly et al. 2011).
We of course cannot claim that QSO lightcurves are generated by OU processes. There may be more complicated extensions of the OU process or entirely different (deterministic or stochastic) models that could provide even better descriptions. Moreover, QSO variability data probing different domains, e.g., in brightness, redshift, or time sampling, may lead to different results. In fact, results of Zu et al. (2013) suggest that there may be deviations from the OU process on very short timescales. However, we may conclude that from those models that we have considered here the OU process is by far the best model for QSO lightcurves from SDSS Stripe 82.
BailerJones (2012) introduces a formalism for Bayesian model comparison based on Kfold cross validation that is less sensitive to the choice of prior distributions. However, we decided not to use this approach because it would be numerically too expensive for our application.
Mathematical details of the time evolution of mean and variance can be found in BailerJones (2012).
These three assumptions – linear superposition, finite variance, and statistical independence – enable us to invoke the Central Limit Theorem (see also Appendix A.1).
At first glance, the notion of infinite mean/variance may appear odd. Evidently, any finite data sample must have finite samplemean and samplevariance. On second thought, however, one should realise that distributions with infinite mean or variance are quite common in astronomy (e.g., powerlaw distributions, Schechter functions).
Acknowledgments
We thank Gordon Richards, JörgUwe Pott, Nina Hernitschek, Knud Jahnke, and Christian Fendt for discussions and helpful comments on the interpretation of our results.
References
 BailerJones, C. A. L. 2012, A&A, 546, A89 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Berger, J. 2003, Stat. Sci., 18, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Berger, J., & Sellke, T. 1987, J. Am. Stat. Ass., 82, 112 [Google Scholar]
 Bollerslev, T. 1986, J. Econom., 31, 307 [CrossRef] [MathSciNet] [Google Scholar]
 Brockwell, P., & Davis, R. 2002, Introduction to Time Series and Forecasting, 2nd edn. (New York: Springer) [Google Scholar]
 Butler, N. R., & Bloom, J. S. 2011, AJ, 141, 93 [NASA ADS] [CrossRef] [Google Scholar]
 Christensen, R. 2005, Am. Stat., 59, 121 [CrossRef] [Google Scholar]
 Collier, S., & Peterson, B. M. 2001, ApJ, 555, 775 [NASA ADS] [CrossRef] [Google Scholar]
 Engle, R. F. 1982, Econometrica, 50, 987 [CrossRef] [MathSciNet] [Google Scholar]
 Geha, M., Alcock, C., Allsman, R. A., et al. 2003, AJ, 125, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Gillespie, D. 1996, Am. J. Phys., 64, 225 [NASA ADS] [CrossRef] [Google Scholar]
 Giveon, U., Maoz, D., Kaspi, S., Netzer, H., & Smith, P. S. 1999, MNRAS, 306, 637 [NASA ADS] [CrossRef] [Google Scholar]
 Gnedenko, B. V., & Kolmogorov, A. N. 1954, Limit distributions for sums of independent random variables (Reading, Mass.LondonDon Mills., Ont.: AddisonWesley Publishing Co.) [Google Scholar]
 Horne, J. H., & Baliunas, S. L. 1986, ApJ, 302, 757 [NASA ADS] [CrossRef] [Google Scholar]
 Ivezić, Ž., Smith, J. A., Miknaitis, G., et al. 2007, AJ, 134, 973 [NASA ADS] [CrossRef] [Google Scholar]
 Kass, R. E., & Raftery, A. E. 1995, J. Am. Stat. Ass., 90, 773 [CrossRef] [MathSciNet] [Google Scholar]
 Kawaguchi, T., Mineshige, S., Umemura, M., & Turner, E. L. 1998, ApJ, 504, 671 [NASA ADS] [CrossRef] [Google Scholar]
 Kelly, B. C., Bechtold, J., & Siemiginowska, A. 2009, ApJ, 698, 895 [NASA ADS] [CrossRef] [Google Scholar]
 Kelly, B. C., Sobolewska, M., & Siemiginowska, A. 2011, ApJ, 730, 52 [NASA ADS] [CrossRef] [Google Scholar]
 Kim, D.W., Protopapas, P., Byun, Y.I., et al. 2011, ApJ, 735, 68 [NASA ADS] [CrossRef] [Google Scholar]
 Kim, D.W., Protopapas, P., Trichas, M., et al. 2012, ApJ, 747, 107 [NASA ADS] [CrossRef] [Google Scholar]
 Kozłowski, S., Kochanek, C. S., Udalski, A., et al. 2010, ApJ, 708, 927 [NASA ADS] [CrossRef] [Google Scholar]
 MacLeod, C. L., Ivezić, Ž., Kochanek, C. S., et al. 2010, ApJ, 721, 1014 [NASA ADS] [CrossRef] [Google Scholar]
 Nelder, J. A., & Mead, R. 1965, Comp. J., 7, 308 [CrossRef] [Google Scholar]
 Pichara, K., Protopapas, P., Kim, D.W., Marquette, J.B., & Tisserand, P. 2012, MNRAS, 427, 1284 [NASA ADS] [CrossRef] [Google Scholar]
 Rees, M. J. 1984, ARA&A, 22, 471 [NASA ADS] [CrossRef] [Google Scholar]
 Schmidt, K. B., Marshall, P. J., Rix, H.W., et al. 2010, ApJ, 714, 1194 [NASA ADS] [CrossRef] [Google Scholar]
 Schmidt, K. B., Rix, H.W., Shields, J. C., et al. 2012, ApJ, 744, 147 [NASA ADS] [CrossRef] [Google Scholar]
 Sesar, B., Ivezić, Ž., Lupton, R. H., et al. 2007, AJ, 134, 2236 [NASA ADS] [CrossRef] [Google Scholar]
 Trèvese, D., Kron, R. G., & Bunone, A. 2001, ApJ, 551, 103 [NASA ADS] [CrossRef] [Google Scholar]
 Uhlenbeck, G. E., & Ornstein, L. S. 1930, Phys. Rev., 36, 823 [NASA ADS] [CrossRef] [Google Scholar]
 Zu, Y., Kochanek, C. S., Kozłowski, S., & Udalski, A. 2013, ApJ, 765, 106 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Stable distributions in a nutshell
This section provides a brief introduction to the familiy of stable distributions. These distributions play an important role, e.g., in the field of financial math.
Appendix A.1: Generalised centrallimit theorem
Considering a realvalued random variate Y, which is the sum of N realvalued random variates X_{n}, (A.1)the centrallimit theorem states that the probability density function of Y, p(y), converges to a Gaussian in the limit of N → ∞, if and only if two conditions are satisfied:

1.
All random variates X_{n} are statistically independent of each other.

2.
All random variates X_{n} are drawn from distributions p_{n}(x) which have finite mean and variance.
The centrallimit theorem is one of the primary reasons why the Gaussian distribution is so popular – the other reason being the Gaussian’s mathematical simplicity.
Gnedenko & Kolmogorov (1954) investigated what happens if we drop the second condition of finite mean and variance of the X_{n}. They showed that in this case, p(y) no longer approaches a Gaussian but rather a stable distribution. This is called the “generalised centrallimit theorem”. If one accepts the “normal” centrallimit theorem as an argument in favour of the Gaussian distribution, one also has to accept the generalised centrallimit theorem as an argument in favour of stable distributions. Which form of the centrallimit theorem applies in practice, depends on the specific situation under consideration.
Fig. A.1 Examples of stable probability density functions that have been evaluated through numerical integration. In all cases, δ and γ are identical, β = 0, and the dashed curve always shows a Gaussian for comparison’s sake. Solid lines from top to bottom have values of α that are 1.5, 1, and 0.5. As α decreases, the tails become heavier and the peak becomes sharper when compared to the Gaussian.

Open with DEXTER
Appendix A.2: Properties of stable distributions
Here we give a brief overview over the most important properties of stable distributions. This overview is by no means exhaustive or complete, we only mention those properties that are relevant to this article.

1.
Parametrisation: stable distributions are fully described by four quantities:

α ∈ (0,2] , regulating the heavyness of the tails and the sharpness of the peak,

β ∈ [−1,1] , regulating the asymmetry (β = 0 is symmetric),

γ ∈ (0,∞), regulating the width of the distribution,

δ ∈ (−∞,∞), regulating the location (if β = 0, δ is the location of the peak).


2.
Infinite moments: as soon as α < 2, the second moment (variance) is infinite. As soon as α < 1, also the first moment (mean) is infinite. Only the zeroth moment (normalisation) is finite for all stable distributions^{9}.

3.
Characteristic function: in order to fit a distribution to observed data, one needs to evaluate the probability density function (PDF) in order to compute the data’s likelihood. Unfortunately, stable distributions usually do not have an analytic PDF. Only the characteristic function ϕ(t) is given analytically, (A.2) where (A.3) from which the PDF must be evaluated by Fourier transformation. Figure A.1 shows examples of stable PDFs. In practice, this makes likelihood evaluations computationally expensive. There are only four special cases, where the PDF exists analytically:

Gaussian distribution (α = 2, β = 0),

Cauchy distribution (α = 1, β = 0),

Lévy distribution (, β = 1),

inverse Lévy distribution.


4.
Sampling: although evaluating the PDF is numerically expensive, drawing random samples from a stable distribution is simple and has very low computational cost.

5.
αstability: let X and Y be two stable random variates with identical α. Then, also the random variate Z = X + Y is stable with identical α and the other parameters of the stable distribution of Z are: The Gaussian distribution (α = 2, β = 0) is a wellknown example.
All Tables
All Figures
Fig. 1 Examples of stochastic processes. We can see qualitative differences by eye: The Wiener process in panel a) drifts away, whereas the OU process in panel b) reverts to the mean. The Cauchy process in panel c) has “steps” due to the heavy tails of the Cauchy distribution. The GARCH(1,1) process in panel d) exhibits episodes of low and high variation.

Open with DEXTER
In the text
Fig. 2 Sample distributions of spectroscopic redshift estimates (top panel) and number of observations in the gband lightcurve (bottom panel).

Open with DEXTER
In the text
Fig. 3 Example lightcurves with maximum evidence for constant model with additional noise (first row), for sinusoid with flat prior in period (second row), for two sinusoids (third row), for Wiener process (fourth row), for OU process (fifth row), and for Cauchy CAR(1) process (sixth row). In order to facilitate comparison for this figure, all lightcurves have been standardised by subtracting the mean and dividing by the standard devition. Numbers in the top right corners of each panel provide this QSO’s ID from Ivezić et al. (2007).

Open with DEXTER
In the text
Fig. 4 Five randomly selected example lightcurves where the OU process has highest evidence of all models. The bestfit model prediction is probabilistic. The black dashed line is the timeevolution of the mean. The three different grey shadings are the 1, 2, and 3σ intervals, respectively.

Open with DEXTER
In the text
Fig. 5 Same as Fig. 4 but now zoomed into the time interval from 53 611 to 53 711 days.

Open with DEXTER
In the text
Fig. 6 Maximumlikelihood restframe parameters τ_{0} and of the OU process for all 6304 Stripe 82 QSO lightcurves. Black dots represent QSO lightcurves that are best described by an OU process, whereas red triangles represent those where the OU process is not the best description. Orange squares represent 100 MACHO QSO lightcurves from Kelly et al. (2009).

Open with DEXTER
In the text
Fig. 7 Distribution of maximumlikelihood restframe parameters μ, and τ_{0} of the OU process for 5047 QSO lightcurves that are best described by an OU process.

Open with DEXTER
In the text
Fig. 8 Distribution of bestfit sinusoidal periods for those 1 724 QSO lightcurves that are best described by a combination of sinusoid and OU process. We quote restframe periods that have been corrected for redshift.

Open with DEXTER
In the text
Fig. 9 Preference of OU process plus sinusoid over OU process alone as a function of spectroscopic redshift. The bestfit linear trend has a negative slope but it is only of 2.4σ confidence.

Open with DEXTER
In the text
Fig. 10 Preference of OU process plus sinusoid over OU process alone as a function of number of observations. The bestfit linear trend has a negative slope with 5.2σ confidence.

Open with DEXTER
In the text
Fig. A.1 Examples of stable probability density functions that have been evaluated through numerical integration. In all cases, δ and γ are identical, β = 0, and the dashed curve always shows a Gaussian for comparison’s sake. Solid lines from top to bottom have values of α that are 1.5, 1, and 0.5. As α decreases, the tails become heavier and the peak becomes sharper when compared to the Gaussian.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
