The universal shape of the Xray variability power spectrum of AGN up to z ∼ 3
^{1}
Dipartimento di Fisica “Ettore Pancini”, Università di Napoli Federico II, Via Cintia 80126, Italy
^{2}
INAF – Osservatorio Astronomico di Capodimonte, Via Moiariello 16, 80131 Naples, Italy
^{3}
INFN – Unità di Napoli, Via Cintia 9, 80126 Napoli, Italy
email: paolillo@na.infn.it
^{4}
Department of Physics and Institute of Theoretical and Computational Physics, University of Crete, Voutes University Campus, 71003 Heraklion, Greece
^{5}
Institute of Astrophysics–FORTH, N. Plastira 100, 70013 Vassilika Vouton, Greece
^{6}
Department of Astronomy and Astrophysics, 525 Davey Lab., The Pennsylvania State University, University Park, PA 16802, USA
^{7}
Institute for Gravitation and the Cosmos, The Pennsylvania State University, University Park, PA 16802, USA
^{8}
Department of Physics, The Pennsylvania State University, University Park, PA 16802, USA
^{9}
Instituto de Astrofísica and Centro de Astroingeniería, Facultad de Física, Pontificia Universidad Católica de Chile, Casilla 306, Santiago 22, Chile
^{10}
Millennium Institute of Astrophysics, Nuncio Monseñor Sótero Sanz 100, Of 104, Providencia Santiago, Chile
^{11}
Space Science Institute, 4750 Walnut Street, Suite 205, Boulder, CO 80301, USA
^{12}
INAF – Osservatorio di Astrofisica e Scienza dello Spazio di Bologna, Via Gobetti 93/3, 40129 Bologna, Italy
^{13}
Scuola Normale Superiore, Piazza dei Cavalieri 7, 56126 Pisa, Italy
^{14}
Department of Physics, University of North Texas, Denton, TX 76203, USA
^{15}
Leiden Observatory, Leiden University, PO Box 9513 2300 RA Leiden, The Netherlands
^{16}
School of Astronomy and Space Science, Nanjing University, Nanjing, Jiangsu 210093, PR China
^{17}
Key Laboratory of Modern Astronomy and Astrophysics (Nanjing University), Ministry of Education, Nanjing 210093, PR China
^{18}
INAF – Osservatorio Astrofisico di Arcetri, Largo Enrico Fermi 5, Firenze, Italy
^{19}
CAS Key Laboratory for Research in Galaxies and Cosmology, Department of Astronomy, University of Science and Technology of China, Hefei 230026, PR China
^{20}
School of Astronomy and Space Sciences, University of Science and Technology of China, Hefei 230026, PR China
Received:
25
October
2022
Accepted:
15
February
2023
Aims. We study the ensemble Xray variability properties of active galactic nuclei (AGN) over large ranges of timescale (20 ks ≤ T ≤ 14 yr), redshift (0 ≤ z ≲ 3), luminosity (10^{40} erg s^{−1} ≤ L_{X} ≤ 10^{46} erg s^{−1}), and black hole (BH) mass (10^{6} ≤ M_{⊙} ≤ 10^{9}).
Methods. We propose the use of the variancefrequency diagram as a viable alternative to the study of the power spectral density (PSD), which is not yet accessible for distant, faint, and/or sparsely sampled AGN.
Results. We show that the data collected from archival observations and previous literature studies are fully consistent with a universal PSD form, which does not show any evidence for systematic evolution of shape or amplitude with redshift or luminosity, even if there may be differences between individual AGN at a given redshift or luminosity. We find new evidence that the PSD bend frequency depends on BH mass and possibly on accretion rate. We finally discuss the implications for current and future AGN population and cosmological studies.
Key words: galaxies: active / black hole physics / quasars: supermassive black holes / Xrays: galaxies / surveys / methods: statistical
© The Authors 2023
Open Access article, published by EDP Sciences, under the terms of the Creative Commons Attribution License (https://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
This article is published in open access under the Subscribe to Open model. Subscribe to A&A to support open access publication.
1. Introduction
Flux variability is a defining characteristic of active galactic nuclei (AGN) and has been observed in these objects on all timescales, and across the whole electromagnetic spectrum. The fastest variations, as well as those of the greatest amplitude, are observed at the highest energies (Xrays and γrays), strongly suggesting that such radiation is mainly generated in relatively small regions, close to the central engine.
One of the most frequently used tools to study the observed variations is the power spectral density (PSD) function (or power spectrum for simplicity). Early studies of the Xray variability of AGN with EXOSAT showed that the PSD has a powerlaw shape with a slope of ∼ − 1.5, and an amplitude that scales with the source luminosity (Green et al. 1993; Lawrence & Papadakis 1993). Long observing campaigns with the Rossi Xray Timing Explorer (RXTE) over many years, combined with shorter XMMNewton observations (mainly) have allowed the detailed study of AGN Xray PSDs over a large frequency range, revealing at least one – and in some cases two – breaks in the PSD of nearby AGN (e.g., Uttley et al. 2002; Papadakis et al. 2002; Markowitz et al. 2003; McHardy et al. 2004; GonzálezMartín & Vaughan 2012). These should represent characteristic timescales linked to the physical process producing the observed emission.
Most of our knowledge about AGN power spectra in the Xray band is derived from extensive observations of relatively nearby and mostly lowluminosity AGN. It is not yet possible to estimate the PSD of AGN at larger redshifts because the available light curves have few points and are sparsely sampled. For this reason, our knowledge of the variability properties of the overall AGN population is mainly based on studies of the excess variance as a function of redshift and luminosity, using light curves from large samples of Xraydetected AGN in various surveys (e.g., Paolillo et al. 2004; Papadakis et al. 2008; Young et al. 2012; Shemmer et al. 2014; Lanzuisi et al. 2014; Yang et al. 2016; Middei et al. 2017; Zheng et al. 2017; Ding et al. 2018; Thomas et al. 2021).
Recently, Paolillo et al. (2017, P17 hereafter) studied the Xrayvariability properties of distant AGN in the Chandra Deep FieldSouth region (CDFS) over 17 years. These authors used the normalised excess variance (i.e., the average lightcurve variance corrected for noise; see Eq. (1) in P17) as a measure of the amplitude of the Xray variability of the sources, and they studied the dependence of on Xray luminosity in various redshift bins. P17 assumed powerspectrum models based on PSD analysis of relatively nearby, bright Xray Seyferts, and found that the variability properties of highz AGN are consistent with a PSD described by a bending power law, where the bend frequency (and perhaps also the PSD amplitude) depends on the accretion rate expressed in terms of the Eddington ratio λ_{E} = Ṁ/Ṁ_{Edd}, where Ṁ is the mass accretion rate and Ṁ_{Edd} is the Eddington accretion rate.
In this work, we expand this study, collecting several complementary AGN samples with available excessvariance measurements, including the CDFS (P17), COSMOS (Lanzuisi et al. 2014), CAIXA (Ponti et al. 2012), TARTARUS (O’Neill et al. 2005), and RXTE (Zhang 2011), in order to cover a wide range of timescales, redshifts, luminosities, and blackhole (BH) masses. We also estimated the excess variance of numerous additional local AGN using Swift/XRT and RXTE light curves in order to cover timescales in between the shortest and the longest ones probed by the data from the literature.
Our objective is to study the PSD itself using excessvariance measurements. In most previous works, was used to investigate the dependence of AGN variability amplitude on Xray luminosity, BH mass, and redshift. However, the dependence of on total lightcurve duration T itself is also important, because the excess variance is (approximately) equal to the integral of the intrinsic power spectrum in the range of frequencies 1/T ≤ ν ≤ 1/(2Δt_{min}), where Δt_{min} is the minimum time difference between successive points in the light curve^{1} (see Sect. 2). Due to the close relation between the PSD and , we can compute from light curves with different duration T, and then plot as a function of ν_{T} (≡1/T)^{2}. This variance–frequency plot (VFP) provides information closely related to the PSD, with the advantage that it can be directly derived for large samples of faint and/or distant AGN, and can therefore be studied with the aim of constraining the intrinsic PSD properties.
Although is easy to compute, so that we can create a VFP even from sparsely sampled light curves (which are not sufficient to measure the PSD), the use of the VFP is difficult on an individual AGN basis. In fact, given the statistical properties of the , in the case of a single object we would need many light curves in order to reliably estimate the intrinsic variance on various timescales (see Allevato et al. 2013, and references therein).
On the other hand, we could consider samples of AGN that have been monitored in the same way (i.e., where T and Δt_{min} are the same for all sources) in order to compute the mean excess variance, and use it to create the VFP. However, in the case where we use light curves of many AGN, one has to consider the dependence of on BH mass (M_{BH}) as well: for a given lightcurve duration, the variance decreases with increasing BH mass (e.g., Papadakis 2004; O’Neill et al. 2005; Ponti et al. 2012). Therefore, assuming we know the BH masses for all AGN in the sample, we must first model the dependence of the excess variance on M_{BH} to create VFP for AGN at a fixed mass.
Following this approach, we aim to investigate whether or not the measured VFP is consistent with the hypothesis that the Xray PSD has the same form in all AGN, implying that the Xray variability mechanism is the same in all of them and, if this is indeed found to be the case, we intend to identify the characteristics of this ‘universal’ Xray PSD of AGN.
The paper is organized as follows. In Sect. 2 we explain the relation between the VFP and the PSD, and how we can measure the VFP for sparsely sampled, lowS/N AGN. In Sect. 3 we present the BH mass and variability measurements for highredshift sources in CDFS and COSMOS samples, and the bestfit results to their –M_{BH} relations. In Sect. 4 we present the bestfit results for lowredshift sources from literature or archival data. In Sects. 5 and 6 we present the VFP of AGN up to redshift ∼3, the method we use to fit the observed VFP, and the bestfit results. Finally, in Sect. 7, we summarise our work and discuss the implications of our study. Throughout the paper, we adopt values of H_{0} = 70 km s^{−1} Mpc^{−1}, Ω_{M} = 0.3, and Ω_{Λ} = 0.7.
2. The variance–frequency plot: a substitute for the PSD
2.1. The PSD versus the VFP
Let us assume that the AGN Xray PSD follows a relation of the form:
where A is the PSD normalisation (A = PSD(ν_{b})×2ν_{b}), and ν_{b} is the bend frequency^{3}. The PSD defined in this way has a logarithmic slope of −1 at low frequencies (ν ≪ ν_{b}), which steepens to −(1 + s) at higher frequencies (ν ≫ ν_{b}). This model PSD is based on the results from PSD studies of relatively nearby, lowluminosity (but Xray bright) AGN (e.g., McHardy et al. 2004). Let us also assume that ν_{b} depends on the BH mass as follows (e.g., McHardy et al. 2006; GonzálezMartín & Vaughan 2012):
where B is a constant. According to Eq. (4) in Allevato et al. 2013, the excess variance of a light curve of duration T will be a measure of the normalised ‘band’ variance, defined as follows^{4}:
where ν_{T} = 1/T_{max} and ν_{max} = 1/(2Δt_{min}). In the case of equally sampled light curves with a few missing points (as in the RXTE, Swift, ASCA, and XMMNewton light curves we use; see below) the shortest frequency sampled by the data is well defined, with Δt_{min} = 2Δt, where Δt is the bin size of the light curves. However, in the case of the unevenly sampled light curves (like CDFS and COSMOS), the choice of Δt_{min} is not as clear (see e.g., the discussion in Appendix D in Scargle 1982). For these light curves, we decided to take Δt_{min} to be the shortest time difference between successive observations. For a fixed Δt_{min}, we expect a negative correlation between σ^{2} and ν_{T}, that is, the variability amplitude should increase with increasing light curve duration in AGN (due to the rednoise nature of the AGN PSD).
Equation (3) shows that σ^{2}(ν_{T}, ν_{max}) depends on the shape (and normalisation) of the PSD. Consequently, a plot of σ^{2} as a function of ν_{T} holds similar information to the PSD. As mentioned in Sect. 1, we refer to the plot of σ^{2}(ν_{T}, ν_{max}) versus ν_{T} as the VFP of an AGN^{5}.
Figure 1 shows the PSD and the VFP plot (upper and lower panels, respectively) for an AGN with a BH mass of 10^{8} M_{⊙}. The PSD is computed using Eq. (1), while σ^{2}(ν_{T}, ν_{max}) is computed using Eq. (3), for various PSD parameters. The variance plotted in this figure should be equal to the (intrinsic) variance of lightcurve segments with a duration of T = 1/ν and Δt = 250 s, so that ν_{max} = 4 × 10^{−3} Hz.
Fig. 1. PSD and VFP (upper and lower panels, respectively) of an AGN with a BH mass of 10^{8} M_{⊙}. The PSD model parameters are: A = 0.02 Hz^{−1}, s = 1, and ν_{b} = 3 ⋅ 10^{−6} Hz (black solid lines). Black dashed lines indicate the PSD and VFP when we increase the PSD amplitude by a factor of 2. Red lines show the PSD and VFP when we increase the bend frequency (by a factor of 10), while the blue lines show the changes when we increase the highfrequency PSD slope from −2 to −3 (all the other parameters in this case are like those of the red lines). For the computation of the variance, we assumed ν_{max} = (1/250 s).
The figure shows that all the major features of the PSD are apparent in the VFP plot as well. For example, both the PSD and VFP have a powerlawlike shape at high frequencies, with the VFP being flatter than the PSD (we highlight the different scale of the yaxis of the two panels in Fig. 1). At frequencies lower than ν_{b}, both the PSD and VFP flatten to a slope of −1 in the case of the PSD, while σ^{2} ∝ −ln(ν_{T}) below ν_{b}. The various lines in the same figure also show that when varying the PSD parameters, the PSD and the VFP shapes also vary in similar ways.
It is always better to estimate the power spectrum itself, even from a statistical point of view. The statistical properties of the periodogram (the estimator of the PSD) are far superior to the statistical properties of the excess variance as a measure of the intrinsic variance of a single source (see Allevato et al. 2013 for the statistical properties of the latter). However, as we already mentioned in Sect. 1, we cannot use the available light curves of the highz AGN to estimate their PSD. On the other hand, we can measure their excess variance on different timescales (i.e., different ν_{T}), and therefore we can compute the VFP and, as Fig. 1 shows, infer the intrinsic PSD of the sources.
2.2. Measuring the VFP of active galaxies
Ideally, we would need long and short, wellsampled light curves of an AGN to reliably measure variance on a large range of timescales and construct the VFP. However, this is not possible with the currently available data, especially for highz sources. The available light curves are insufficient (because they are too sparse and/or their signaltonoise ratio is too low) to measure the VFP of a single AGN. For this reason, we follow a different approach to construct the VFP of active galaxies, as we describe below.
We can consider samples of AGN with known BH mass, and light curves with the same duration (T_{obs}) and bin size (Δt) for all AGN in each sample. We can use the light curves to measure the excess variance for each AGN in the sample. One way to study the VFP would be to choose objects with the same BH mass in each sample, and then plot versus 1/T_{obs} for all of them. However, as the excess variance measurements do not follow a Gaussian distribution and their error is unknown (see Allevato et al. 2013), we cannot fit the resulting VFP and compare it with model predictions. In order to overcome this serious problem, we have to average the measured excess variances in some way.
On the other hand, we cannot simply compute the mean excess variance of all the objects in the sample if they host BHs of different masses, because the excess variance will depend on the BH mass. However, we can take advantage of this property, and produce a –M_{BH} plot for all sources in each sample. The excess variance is a measure of the band variance, σ^{2}(ν_{T}, ν_{max}), defined by Eq. (3). This equation, together with Eq. (2), shows how should depend on BH mass, depending on the sampled frequencies: if neither ν_{max} nor ν_{T} are much smaller than ν_{b}, should decrease with increasing BH mass in a roughly linear way in log–log space; if instead ν_{max} and ν_{T} ≪ ν_{b}, will not depend on BH mass (it will depend on ν_{T} and ν_{max} only; see Eq. (3)) and the vs. M_{BH} plot will be flat. This behaviour is illustrated by the models plotted as dotted lines, in all the figures of Sects. 3 and 4..
We can fit the vs. M_{BH} plot with a linear function of the form:
where is the mean BH mass of the sample, and α(T_{obs}) is the variance of an AGN with a mass of , computed using a light curve of duration T_{obs}. The key point here is that, as α(T_{obs}) is computed by fitting all the data in the vs. M_{BH} plot, its distribution will be much closer to the Gaussian distribution, and its error will be known (from the fitting procedure).
We can therefore consider AGN (with known BH mass) that have been observed by various satellites, over different timescales, T_{obs}, in order to compute , plot vs. M_{BH}, and fit the data with Eq. (4). If is the same for all samples, then the plot of α(T_{obs}) vs. 1/T_{obs} will be representative of the VFP plot for the AGN with a mass of . In this way, we can also take advantage of the study of the β(T_{obs}) vs. 1/T_{obs} plot as well. As shown in Sect. 2, for a given M_{BH} (and hence ν_{b}), the VFP shape, and therefore β(T_{obs}), should vary with T_{obs}. The way the VFP shape varies depends on the relation between ν_{b} and M_{BH}. In other words, the study of the β(T_{obs}) vs. 1/T_{obs} plot will constrain the parameter B in Eq. (2).
We plan to follow the approach we outline above in order to study the VFP of AGN, as we describe in detail in the following sections. We use data from various Xray surveys for highz objects and light curves from pointed observations of relatively nearby objects in order to construct the VFP of AGN, both at high and low redshift. In this way, we are able to directly compare the low and highz objects, and investigate whether or not their PSDs are the same.
3. The variance–BH mass relation of highredshift AGN
3.1. Blackhole mass measurements for the CDFS sources
The first AGN sample we considered is derived from the CDFS Xray catalog of Luo et al. (2017), and the CDFS variability measurements used in this work are described in P17; we refer to those works for specific details. Black hole mass measurements for CDFS sources are primarily based on the measurements published by Suh et al. (2015). These are derived from optical/nearinfrared spectroscopic measurements of Hα, Hβ, and MgII line widths of Xray sources in the ECDFS region. Black hole masses were obtained from scaling relations of M_{BH} with the FWHM and the luminosity of the broadline components in the spectra. We refer to the original paper for details of the method and the assessment of the reliability of the masses. The authors claim a median uncertainty of ∼0.1 dex with an additional 0.3 dex due to calibration uncertainties in the scaling relations. This data set was integrated with Hα BH mass measurements from Schulze et al. (2018), after recalibrating the scaling relation to that adopted in Suh et al. (2015, their Eq. (1)), and with MgII BH mass measurements from Schramm & Silverman (2013). In total, we collected masses for 40 sources: 35 from Suh et al. (2015), 3 from Schulze et al. (2018), and 2 from Schramm & Silverman (2013). In the case of multiple BH mass measurements for the same source, we used the average value; however, our results do not change if we adopt individual BH mass measurements instead (giving priority to Hα measurements). For the subsequent analysis, we define a ‘robust sample’ of 15 sources with available M_{BH} measurements, an average S/N > 0.8 per point, and more than 90 points in their Xray light curves in order to have reliable measurements. In fact, we verified that including more sources with lower quality light curves does not yield significant improvements in the final analysis and increases the uncertainties on the measured variability (see P17 for further details).
In Fig. 2, we plot the luminosity–redshift distribution of CDFS sources with available M_{BH} measurements and those in the robust samples. The sources in the robust sample are within the following ranges: ∼0.5–1.7 in redshift, ∼5 × 10^{42}–2 × 10^{44} erg s^{−1} in (2–8 keV restframe) Xray luminosity, and 10^{7}–10^{9} M_{⊙} in BH mass, and have low absorption N_{H} < 2 × 10^{22} cm^{−2} as expected from their type 1 spectra.
Fig. 2. Luminosity–redshift distribution of CDFS and COSMOS sources. Solid symbols represent sources with available BH mass measurements, while empty ones highlight the final samples used in this work (see text for details).
3.2. The CDFS –M_{BH} relation
We created –M_{BH} plots for the CDFS data using the excess variance measurements of P17 and the BH mass measurements for the sources in the ‘robust sample’ discussed in the previous section. P17 calculated the excess variance of the CDFS AGN using light curves with T_{obs} = 45, 128, 654, and 6005 days (observer’s frame; see the discussion in their Sect. 4.2). Here we used only their excess variance measurements from the 128 and 654 day lightcurve segments; that is, the segments plotted in the two rightmost panels in Fig. 1 of P17. These are separated by almost 5 years, and the excessvariance measurements based on them should be uncorrelated. On the contrary, the measurements from the longest and shortest timescales use lightcurve parts that overlap with each other (see Fig. 1 in P17), and therefore the resulting will be correlated. We note that, given that the AGN PSD is known to depend on the energy (e.g., McHardy et al. 2004), and to minimise the effect of absorption, the light curves are extracted in the 2–8 keV restframe band.
The panels in Fig. 3 show the –M_{BH} plots for the two different timescales. A weak anticorrelation between and M_{BH} can be observed, although the scatter is considerable. This is due to several reasons. First, the error on M_{BH} and, more importantly, on the individual measurements (Allevato et al. 2013) will introduce considerable scatter around the intrinsic relation. In addition, although T_{obs} is the same for all objects, the lightcurve variance depends on the duration in restframe, T_{rest}, which is not the same for all objects, as their redshifts differ.
Fig. 3. vs. M_{BH} for the CDFS ‘robust’ sample (filled circles) for the two different timescales discussed in the text. The solid lines show the linear fit to the data. Open diamonds show the bestfit modelpredicted variance computed by taking into account the restframe T_{rest}, and Δt_{min, rest} of each source. The dashed lines mark the best fit to the model predictions (see Sect. 6 for details). The dotted curves represent the model trends for the sources at z = 0.5 (top one) and z = 2.0 (bottom one), which is the approximate redshift range of the CDFS sample (see Fig. 2).
We note that, as we explained in Sect. 2, if both the duration and bin size of the light curve are much longer than the bend timescale, then the –M_{BH} relation will be flat (unless the PSD amplitude depends on M_{BH}). In other words, a lack of correlation between excess variance and BH mass provides important information regarding the intrinsic shape of the VFP and the PSD at low frequencies.
We cannot use χ^{2} to fit the data plotted in Fig. 3 (as well as in all figures which show –M_{BH} relations) and then test whether or not the model fits the data well because the excessvariance measurements are not Gaussian (and in any case their error is unknown). For that reason, we assumed that a straight line provides a good fit to the data, and we used the ordinary leastsquares regression of Y on X (OLS(YX)) method of Isobe et al. (1990) to fit the data in Fig. 3 (in log–log space), with the linear model defined by Eq. (4), with , which is similar to the average M_{BH} in the CDFS sample. As such, the line normalisation will be best determined at this mass. In this case, α(T_{obs}) corresponds to the intrinsic variance of an AGN with M_{BH} = 10^{8} M_{⊙}, when measured from a light curve of duration T_{obs}.
Bestfit results are listed in Table 1 and black solid lines in Fig. 3 show the bestfit linear models. Unsurprisingly, given the large scatter of the points around the bestfit lines, the error on the slope is large; however, the error on the normalisation is small. This is due to the fact that, given the rather flat bestfit slope, α(T_{obs}) is representative of the mean excess variance of all the points in each plot, which is reasonably well determined from the 15 measurements at each timescale.
Results of the linear fits to the –M_{BH} relation (in log–log space), for the different datasets used in this work.
3.3. The COSMOS –M_{BH} relation
Lanzuisi et al. (2014) used XMM observations in the COSMOS field over a period of ∼3.5 years to study the longterm Xray variability of a large sample of AGN. We used the data plotted in their Fig. 5 to fit the –M_{BH} relation. To improve the accuracy of the measured variances, we selected only objects with at least three points in their light curves and with a total restframe duration between 100 and 560 days (see their Fig. 1). As the final sample spans a wide range in T_{obs}, we further divided it into two bins based on the restframe lightcurve length: 100 days ≤ T_{rest} < 330 days and 330 days ≤ T_{rest} < 560 days, with a median duration of 240 and 413 days, respectively. There are 82 AGN in both groups, with a median redshift of 1.5 and 1.0 in the first and second group, respectively (see Fig. 2). Their Xray luminosity ranges from 6 × 10^{42} to 3 × 10^{45} erg s^{−1} in the 2–10 keV band. We fitted both –M_{BH} plots with the model defined by Eq. (4), and the same OLS(YX) routine as above (Fig. 4). The timescales and bestfit results for the COSMOS data are listed in Table 1.
Fig. 4. vs. M_{BH} for COSMOS sources from Lanzuisi et al. (2014). Symbols have the same meaning as in Fig. 3.
4. The variance–BH mass relation of lowredshift AGN
4.1. Compilation of –M_{BH} relations from literature
In order to sample shorter and longer timescales, which are not accessible for highredshift AGN, we used both published and archival data. We first considered the –M_{BH} data from the CAIXA sample (Ponti et al. 2012). These authors presented the results from a systematic study of the excess variance of a large sample of AGN using XMMNewton light curves. We used their measurements (2–10 keV) from the light curves with T_{obs} = 80 ks. Ponti et al. (2012) measured the excess variance on three shorter time timescales as well, but the use of the same light curves when measuring on different timescales would imply that their measurements would be heavily correlated (for the same source). We constructed the respective –M_{BH} plot (see the bottom panel of Fig. 5) using the data from their ‘Rev’ AGN sample^{6}. In doing so, we updated their BH mass estimates with the measurements listed in the AGN BH mass database (Bentz & Katz 2015). There are 11 radioquiet AGN in this sample with excess variance measurements based on light curves of 80 ks in duration. For consistency, we fitted the CAIXA –M_{BH} plot using Eq. (4), with , and the same OLS(YX) routine that we used to fit the respective CDFS plots. The bestfit results are listed in Table 1, and the black solid line in the lower panel of Fig. 5 shows the bestfit line.
Fig. 5. vs. M_{BH} for CAIXA+TARTARUS sources with T_{obs} = 40 ks (top panel), and for CAIXA sources with T_{obs} = 80 ks (bottom panel). Data are from Ponti et al. (2012) and O’Neill et al. (2005). Symbols have the same meaning as in Fig. 3.
In order to get information on shorter timescales, we considered the excessvariance measurements from the TARTARUS sample of O’Neill et al. (2005). These latter authors used ASCA light curves of 40 ks in duration, and measured the excess variance of nearby Xraybright Seyferts (in the 2–10 keV band). We chose 16 (radioquiet) AGN from their sample with BH mass measurements based on the reverberation mapping technique, as listed in the database of Bentz & Katz (2015). We added six sources from the CAIXA sample for which Ponti et al. (2012) provide 40 ks measurements (namely NGC 4151, Mrk 110, Mrk 279, Mrk 590, NGC 4593, and PG 1211+143); these are not part of the 80 ks sample and have BH mass estimates based on reverberation mapping. The respective –M_{BH} plot is shown in the top panel of Fig. 5. As above, we fitted the data using Eq. (4) and the same OLS(YX) routine that we used to fit the respective CDFS plots. Bestfit results are listed in Table 1, and the solid line in the upper panel of Fig. 5 indicates the bestfit line.
We also considered the –M_{BH} data from the RXTE light curves of Zhang (2011) in order to obtain information on longer timescales. These authors used data from the ASM on board RXTE to study the Xray variability amplitude of 27 AGN over a period of T_{obs} = 14 years. Using their and M_{BH} measurements, we fitted the resulting variability–M_{BH} relation with the same model and fitting routine as above. The –M_{BH} relation is shown in Fig. 6 together with the bestfit line, while the bestfit results are listed in Table 1. The AGN in the O’Neill et al. (2005), Ponti et al. (2012), and the Zhang (2011) samples are all relatively nearby, and their Xray luminosity span the range 10^{40} − 10^{46} erg s^{−1}.
Fig. 6. vs. M_{BH} for RXTE sources (filled circles) from Zhang (2011). Symbols have the same meaning as in Fig. 3.
4.2. Mediumterm measurements from archival observations
There is a considerable gap between the duration of the shortest CDFS light curves (128 days) and the CAIXA light curves, which have a duration of ∼1 day. In order to measure the excess variance on intermediate timescales, we used RXTE/PCA and Swift/XRT data for relatively nearby AGN, and we computed their excess variance using light curves that are 9.45 days in duration (restframe). This timescale is ten times longer than the CAIXA light curves and about ten times shorter than the CDFS. The sources are listed in Table 2, together with information on the light curves we used and the resulting excess variance.
RXTE and Swift light curves used in the present study to measure the excess variance of AGN on timescales of ∼10 days.
Columns (2) and (3) list the starting/ending time of the light curves we used (in MJD), and the (minimum) light curve bin size Δt_{min} in days. We did not reduce the Swift data ourselves; instead we used the light curves from Edelson et al. (2019) for all sources and from Cackett et al. (2020) for Mrk 142. The Swift light curves are in the 1.5–10 keV band, except for Mrk 142, where the published light curve is in the 0.3–10 keV band. All the other light curves were taken from the RXTE AGN Timing and Spectral Database^{7} (Rivers et al. 2013) and are in the 2–10 keV band. BH mass estimates (from Bentz & Katz 2015) are listed in Col. (3).
We divided the light curves into segments with a (restframe) duration of 9.45 days (as determined by the shortest light curve in the sample). We computed the excess variance of each segment in the usual way (i.e., using Eq. (1) in P17). We then computed the mean of the individual measurements for each source, which is listed in the last column of Table 2. As for all the other samples, we fitted the –M_{BH} relation using Eq. (4) and the OLS(YX) routine. The result is shown in Fig. 7, together with the bestfit model, while the bestfit results are listed in Table 1.
5. The observed VFP of AGN
As explained above, the bestfit α(T) values listed in Table 1 are representative of the variance of a 10^{8} M_{⊙} AGN on the timescales that are listed in the second column of the same table. We therefore used the α(T) values listed in this table and constructed the VFP for the 10^{8} M_{⊙} AGN.
Figure 8 shows the bestfit α(T) and β(T) values plotted as a function of ν_{T} (top and bottom panels, respectively). The two timescales probed by the CAIXA+TARTARUS data (filled squares) constrain the highfrequency part of the VFP, and the Swift+RXTE data (filled stars) allow us to sample intermediate timescales. The results from CDFS (filled circles) provide information on long timescales, while the COSMOS and the RXTE points (filled diamonds and filled triangle, respectively) further improve the accuracy of the VFP at low frequencies.
Fig. 8. Variance– and slope–frequency plots of our AGN sample. Upper panel: observed VFP of a 10^{8} M_{⊙} AGN as a function of the restframe frequency ν_{T} using our measurements from Table 1 (filled symbols). The red empty symbols indicate the bestfit model values (α(T_{max}) in Eq. (4)). For reference, we also show the theoretically expected trends for a 10^{8} M_{⊙} BH monitored with an average Δt_{min} = 250 s (dashed line) and Δt_{min} = 300 days (dotted line), but we stress that the comparison should be made between the filled and empty points. Lower panel: measured and bestfit model slope of the –M_{BH} relations (β(T_{max}) in Eq. (4)); symbols have the same meaning as those in the upper panel.
The limits of the PSD integral in Eq. (3) depend on restframe T_{max} and Δt_{min}. All AGN in the CAIXA, TARTARUS, RXTE, and Swift samples are at lowredshift and all light curves are of the same duration, which means T_{obs} = T_{rest} (and Δt_{min, obs} = Δt_{min, rest}). The situation is more complicated in the CDFS and COSMOS samples. T_{obs} is the same for all AGN in the CDFS; however, T_{rest} is not, because they do not have the same redshift. In the case of the COSMOS AGN, even T_{obs} differ for different sources because of the survey strategy (see Lanzuisi et al. 2014). Given the differences in T_{rest} in these samples, in Fig. 8 we plot all quantities as a function of ν_{T} = , where is the median lightcurve duration in the AGN restframe ( values are listed in the fourth column of Table 1). We note that this choice is for visualisation purposes only, because in the fitting procedure we properly take into account the actual restframe timescales sampled for each individual source (see Sect. 6).
The overall VFP (upper panel in Fig. 8) appears to be very well described by a single function, from the lowest to the highest sampled frequencies. We can see the logarithmic rise of the variance with decreasing frequency (i.e. increasing timescale), with a slope roughly equal to −1 from the CAIXA+TARTARUS to the highfrequency CDFS point. This implies a PSD slope of ∼ − 2 at high frequencies. The variance–frequency slope flattens at lower frequencies, indicating the presence of a bend frequency analogous to that of the PSD, ν_{b}, that is, somewhere between 1 and 20 days^{−1}. The low and highfrequency parts of the observed VFP are determined by the highz and lowz AGN samples, respectively, but the important observational result is that the lowfrequency VFP appears to be the continuation of the highfrequency VFP, without any hints of a normalisation mismatch between the two parts.
At low frequencies, the RXTE variance may appear to underestimate the value expected from a simple extrapolation of the CDFS and the COSMOS measurements in the VFP, although T_{rest} of the RXTE light curves is longer than the restframe duration of the longest CDFS light curves. In principle, this could suggest that the PSD normalisation at low frequencies is not the same in the distant and local AGN. However, Δt_{min} in the RXTE light curves is also significantly larger than the (restframe) minimum timescale in all other light curves. Indeed, it is almost certainly much longer than the PSD bend frequency of a 10^{8} M_{⊙} AGN. This implies that we are missing a significant part of the intrinsic variance in the RXTE light curves, hence the smaller α(T) value.
The bottom panel of Fig. 8 shows how the slope of the –M_{BH} relation varies with frequency. Similar to the case for the VFP plot, the bestfit slopes at high frequencies appear to connect smoothly, without any normalisation discontinuities, with the bestfit β(T) values at lower frequencies. The slope of the –M_{BH} plots at low frequencies (long timescales) approaches zero, that is, the bending frequency of the 10^{8} M_{⊙} AGN is probably higher than both the mean bin size and the duration of the available light curves in the RXTE sample and, to some extent, also those in the CDFS and the COSMOS sample.
6. Model fitting procedure and bestfit results
We considered a grid of A, B, and s values, and for each (A, B, s) combination we used Eqs. (2) and (3) to compute the variance σ^{2} for the AGN in the CDFS, COSMOS, CAIXA+TARTARUS, RXTE, and Swift+RXTE samples. To this end, we derived ν_{T}, ν_{max}, and ν_{b} using the M_{BH} and z values of each source, and the timescales T_{obs} and Δt_{min, obs} in Table 1 (we assumed z = 0 for the AGN in the CAIXA+TARTARUS, RXTE, and the Swift+RXTE samples, which only contain relatively nearby AGN).
In order to properly fit the data, we must take into account the biases due to a sparse and/or irregular sampling of the light curves. To this end, we used Eq. (11) in Allevato et al. (2013) to compute the bias affecting the measured and we include the same factor in the model variance σ^{2}. The bias correction depends on the PSD slope itself, and so we used the ‘average’ slope (from Eq. (1)) over the range of sampled restframe timescales for each source. Furthermore, we assumed a sparse sampling for the COSMOS sources, and a continuous sampling pattern for the remaining samples.
For each modelparameter combination, we therefore ended up with a pair of model (σ^{2}, M_{BH}) values for each source and timescale in the CDFS, COSMOS, CAIXA+TARTARUS, and Swift+RXTE samples. If the observed measurements were Gaussian variables with known errors, then we would be able to use χ^{2} statistics to fit all the observed vs. M_{BH} data plotted in Figs. 3–7 with the model (σ^{2}, M_{BH}) curves. However, this is not the case, and so we cannot directly fit the model to the observed –M_{BH} plots. Instead, we used a different approach to fit the model to the data.
For each parameter combination, we fit the resulting σ^{2}–M_{BH} points with Eq. (4), with , using the same OLS(YX) routine that we used to fit the data. In the end, each set of model parameters (A, B, s) would result in two bestfit values, α_{mod}(A, B, s, T_{obs}) and β_{mod}(A, B, s, T_{obs}), for each σ^{2}–M_{BH} relation.
The overall model fit: Based on the discussion above, each set of model parameters (A, B, s) would result in eight α_{mod}(A, s, B, T_{obs}) and β_{mod}(A, s, B, T_{obs}) values, that is, one for each of the observed –M_{BH} relations plotted in Figs. 3–7. To get the bestfit model, we minimised the χ^{2}, which is defined as follows:
where δ[α(T_{obs, i})] and δ[β(T_{obs, i})] are the errors on the bestfit normalisation and slope values, α(T_{obs}) and β(T_{obs}), listed in Table 1. Defined in this way, the bestfit model is the one that minimises the differences between the model and the observed VFP (i.e., the points plotted in the upper panel of Fig. 8), as well as the model and the observed slope of the –M_{BH} relations (bottom panel of Fig. 8).
The bestfit results are: for μ = 13 degrees of freedom, corresponding to P(< χ^{2}, μ) = 0.6, at Hz^{−1}, Hz, and . Here, the errors are the 90% uncertainties for two interesting parameters. The errors of the bestfit parameter values are both asymmetric and correlated as shown in Fig. 9. Open diamonds in Figs. 3–7 show the bestfit model (σ^{2}, M_{BH}) predictions for each source in these plots. The dashed red lines show the best linear fit to the model points. In some cases (e.g., Figs. 5 and 7), the model clearly predicts a curved –M_{BH} relation (dotted curve), which may indeed be closer to the observed one. However, even in these cases, a straight line can provide a reasonably good fit to the data (and the model predictions). As we fit a straight line to both the observed and the model relations, we can compare the bestfit line parameters, and search for the values that provide the best agreement between the data and the model predictions. The open symbols in Fig. 8 show the normalisation and slope of the bestfit lines to the model –M_{BH} relations that are closest to the data.
Fig. 9. Bestfit values (crosses) and 68%, 90%, and 99% uncertainty contours for each combination of two of the fitted interesting parameters A (i.e., the PSD normalisation), B (i.e., ν_{b} for a 10^{8} M_{⊙} BH) and s (the highfrequency PSD slope).
Strictly speaking, the VFP plotted in the upper panel of Fig. 8 is representative of the average VFP of an AGN with a mass of 10^{8} M_{⊙}. The bestfit parameters also refer to such an object. For example, if we had normalised the vs. M_{BH} relation at a different M_{BH}, then the expected VFP would be different (see the black and red lines in Fig. 1) and the bestfit bending frequency would be different if ν_{b} depended on BH mass. However, the fact that we consider the VFP of an AGN at 10^{8} M_{⊙} is merely a ‘technicality’ as this mass is close to the mean BH mass of the sources in the samples we considered. In reality, the bestfit α_{mod}(A, B, s, T_{obs}) and β_{mod}(A, B, s, T_{obs}) model parameters are computed by fitting a straight line to all the model points (i.e., open red points in Figs. 3–7). Therefore, the bestfit model VFP plotted in Fig. 8 holds information about the PSD of all AGN in each sample, and the same would be true if we had normalised the bestfit lines to another BH mass.
We find it impressive that a single PSD model can fit the observed VFP so well, given that we constructed –M_{BH} plots using light curves of 160 AGN, both nearby and distant, observed with different satellites, and with different sampling and light curve duration. This result strongly suggests that, on average, the Xray PSD over five orders of magnitude in frequency (i.e., from timescales of ∼40 ks up to ∼10 − 15 years) is described by the same form for all AGN at z ≤ 2 − 3. If there were significant differences in amplitude, bend frequency, or highfrequency slope between the highz and lowz PSDs, then the low and highfrequency parts of the VFP plotted in the top panel of Fig. 8, which are determined by the highz and lowz AGN, respectively, would differ significantly (see e.g., the various curves in Fig. 1).
7. Summary and discussion
We used excessvariance measurements computed using light curves of short (CAIXA+TARTARUS, Ponti et al. 2012; O’Neill et al. 2005), intermediate (Swift+RXTE, this work), and long (RXTE, Zhang 2011) duration, as well as light curves from the COSMOS and the CDFS surveys (Lanzuisi et al. 2014, P17), to construct –M_{BH} plots on various timescales. We fitted them with a simple linear model (in the log–log space), and studied the resulting VFP, together with the slope of the variance–BH mass relations as a function of frequency. Our main result is that the hypothesis of a common Xray PSD form in all AGN, which remains the same irrespective of redshift or luminosity, is fully consistent with the observed VFP.
The variance versus timescale relation of the CDFS sources was used in P17 as well (see their Fig. 7) to show that the excessvariance measurements were indeed consistent with the assumption of a bending powerlaw PSD, and in Zheng et al. (2017) to study the lowfrequency PSD slope. In the present work, we consider a much larger data set to create a more detailed VFP, and we use it together with the slope of the variance–BH mass plots to constrain the Xray PSD.
Indeed, detailed PSDs have only been determined (and fitted with models) for nearby AGN. We used excessvariance measurements from over 100 AGN with a wide range of BH mass (∼10^{6} − 10^{9} M_{⊙}) and Xray luminosity (∼10^{40} − 10^{46} erg s^{−1}) to determine the VFP over timescales from a few hours up to 5–14 years. Based on the fact that the VFP and the PSD hold the same information, we were able to determine the average PSD of the AGN in our sample. To the best of our knowledge, this is the first time that the average Xray PSD of a representative sample of (Xray selected) AGN has been accurately determined up to a redshift of ∼3.
The fact that the observed VFP is well fitted by a single function is remarkable. We measured the average variance, α(T), using light curves of different objects and obtained from different instruments, at different times, and over entirely different timescales. Our results therefore strongly suggest that the shape of the average PSD (defined by Eq. (1)) is the same in all AGN, irrespective of luminosity and/or redshift, and is consistent with almost all relatively nearby AGN. We note that the PSD shape of least one nearby AGN, namely Ark 564, is different. It has a powerlaw shape and shows two breaks, at high and low frequency, respectively (Papadakis et al. 2002; McHardy et al. 2007). This shape implies that Ark 564 may be in a state equivalent to the socalled ‘high/intermediate’ state in BH Xray binaries. Our results suggest that such a state should be rare among AGN.
We assumed a fixed value for the lowfrequency slope. If we consider a more general extension of Eq. (1), that is, , this means fixing l = −1. On the other hand, Zheng et al. (2017) suggested that a steeper lowfrequency slope l ≃ −1.2 is more appropriate to fit the CDFS data. In order to test this possibility, we repeated all our fits using the more general expression above; we find that our data are better fit by the canonical slope of −1, and while we cannot rule out a marginally steeper lowfrequency slope, a value as steep as −1.2 is excluded at the 99% significance level.
Our results are not meant to imply that all AGN should have the same highfrequency slope and PSD amplitude. Most likely, both the PSD amplitude and highfrequency slope will be distributed over a range of values, and the bestfit values we report should be indicative of the means of these distributions. For example, GonzálezMartín & Vaughan (2012) studied the Xray PSD in Xray bright, local AGN in detail and their results do show a rather broad range of highfrequency slopes (between 1.8 and 4.6; see their Table 4). Similarly, their bestfit PSD amplitude values (also listed in their Table 4) span a broad range, from 0.001 to 0.04. What is interesting is that the means of these distributions are the same as our results.
Indeed, the bestfit highfrequency PSD slope from the modelling of the mean VFP is (90% confidence limits). Although the PSD slope may depend on the energy band (e.g., McHardy et al. 2004), we point out that in our case we used the hard Xray band (i.e., E ≳ 2 keV) whenever possible and even in the COSMOS sample the large median redshift of the sources implies that we tend to sample energies ≳1 keV. The median of the highfrequency PSD slopes reported by GonzálezMartín & Vaughan (2012) in their Table 4 is −2.57 for sources where a bend frequency has been detected^{8}. This is consistent with our results.
In addition, our bestfit PSD normalisation of Hz^{−1} is also consistent with the mean PSD normalisation as determined by the PSD modeling of local AGN. According to Eq. (1), the PSD amplitude at the bend frequency, in terms of ν_{b} × PSD(ν_{b}), is equal to A/2. Based on our bestfit results, this is 0.008 ± 0.001, which is fully consistent with the mean PSD amplitude of ∼0.009 reported by GonzálezMartín & Vaughan (2012)^{9}.
The broadband VFP plotted in the upper panel of Fig. 8 shows a clear flattening below ∼10^{−6} Hz, which implies (from our bestfit result) a lowfrequency bend in the PSD at Hz. This corresponds to a bend timescale of (1.8 − 5.8) days (90% confidence). According to GonzálezMartín & Vaughan (2012), log(T_{b})≃log(M_{BH})−1.7, where T_{b} is in days and M_{BH} is the BH mass in units of 10^{6} M_{⊙}^{10}. For a 10^{8} M_{⊙} AGN, this relation predicts T_{b} = 2 days, which is consistent with our results. On the other hand, according to McHardy et al. (2006), the bend timescale should also depend on the source luminosity. These authors find that log(T_{b}) = 2 × log(M_{BH})−log(L_{bol})−2.33, where T_{b} is in days, M_{BH} is the BH mass in units of 10^{6} M_{⊙}, and L_{bol} is the bolometric luminosity in units of 10^{44} erg s^{−1}^{11}. We assumed that the constants A and B in the McHardy et al. (2006) equation are equal to 2 and 1, respectively, which means that the bend timescale is proportional to the BH mass and inversely proportional to accretion rate (in units of the Eddington limit). For T_{b} = 3.5 days, as derived in this work, and M_{BH} = 10^{8} M_{⊙}, then L_{bol} = 1.3 × 10^{45} erg s^{−1}, which is 10% of L_{Edd}. The VFP analysis therefore allows for a dependence of the PSD bend frequency on the AGN accretion rate as well.
We note that our results suggest that the average bend frequency and PSD amplitude are the same for the high and lowz sources. This implies that either these two PSD parameters do not depend on accretion rate, or the accretion rate is the same for both the nearby and the distant AGN in our sample. P17 found that the average accretion rate of the CDFS sources is ∼0.05 − 0.1 of the Eddington limit. Regarding the lowz objects, if we use the data listed in Table 1 of Zhang (2011) for the RXTE sample (which are representative of all our lowz AGN) we find an average accretion rate of ∼0.06 of the Eddington limit, which is comparable with the accretion rate of the CDFS sources. We will need to study the VFP of AGN with significantly different accretion rates in order to investigate the dependence of the PSD amplitude and bending frequency on the accretion rate.
Our results should be useful in future variability studies of large AGN samples using Xray light curves from the eROSITA allsky survey for example, and future surveys that may be conducted with the eXTP (in’t Zand et al. 2019), Einstein probe Yuan et al. (2018, 2022), and StarX (Saha et al. 2017) proposed missions, as well as Athena (Nandra et al. 2013), Lynx (Gaskin et al. 2018), or AXIS (Mushotzky 2018), provided that deep surveys are properly planned to probe the time domain as well (see e.g., Paolillo et al. 2012). In previous studies, such as P17, it was assumed that the shape of the Xray PSD is the same in both nearby and distant luminous AGN. We show in this work that this is indeed the case. Therefore, our result can be useful to any study that involves the modelling of the ensemble Xray variability of AGN in order to, for example, use them as cosmological probes (La Franca et al. 2014; Lusso et al. 2019, 2020; Demianski et al. 2020), or to constrain the AGN demographics through their ensemble Xray variability properties (Sartori et al. 2019; Georgakakis et al. 2021). From a more physical point of view, a common Xray PSD shape implies that the same variability mechanism operates in all luminous AGN, and that the mechanism does not evolve with time until up to at least z ∼ 2 − 3. This result is also in agreement with the lack of evolution observed in the spectral features of AGN, such as the UV vs. L_{X} ratio α_{ox} (e.g., Lusso et al. 2010, 2020) or the Xray spectral slope Γ (e.g., Young et al. 2009), and indicates that it is the underlying Xray emission mechanism in general that does not evolve with time. Although we do not have a welldeveloped physical model for the Xray emission or variability in AGN, the present findings provide further observational constraints for any future attempts.
Although the excess variance is a biased estimate of the PSD integral, in the case of rednoise PSDs and sparsely sampled light curves, it is possible to correct for this effect, as discussed in Sect. 5 of Allevato et al. (2013).
We note that, for simplicity, here we use σ^{2} instead of as in Allevato et al. (2013).
In case of multiple entries, we adopted the bestfit results of GonzálezMartín & Vaughan (2012), except from Ark 564 and PKS0558504. We adopted the results of McHardy et al. (2007) and Papadakis et al. (2010) for these sources, because these authors used more data sets and on various timescales, to compute the PSDs.
We note that the amplitude reported in GonzálezMartín & Vaughan (2012) is 0.009 ± 0.011 where the uncertainty represents the standard deviation of their sample; using the proper error on the mean their measurements yield 0.009 ± 0.003 which is still consistent with our result. Even removing from their sample the three NLSy1 with very high normalisation, they would obtain 0.0044 ± 0.0013, consistent within 2σ with our value.
