1 Introduction

Supernova remnants (SNRs) are diffuse expanding nebulae that result from a supernova (SN) explosion in which a star ejects violently most of its mass. The ejected material expands from the explosion, interacting with the circumstellar and interstellar medium (CSM-ISM), resulting in a rather complex morphology that reflects the interaction of the SN with the CSM-ISM, but also the asymmetries developed during the SN explosion and the nature of the progenitor star. The SNR IC 443 is one of the best examples of a SNR interacting with a very complex environment, which is made up of molecular and atomic clouds (Cornett et al. 1977; Burton et al. 1988; Rho et al. 2001; Su et al. 2014).

IC 443 belongs to the class of mixed-morphology SNR (MM SNR, Rho & Petre 1998), exhibiting a shell-like morphology in the radio band and centrally filled thermal X-ray emission. The majority of MM SNRs are interacting with dense molecular clouds and nearly half of them have been observed in γ-rays (Slane et al. 2015). The physical origin of the peculiar morphology of MM SNRs is still an open issue. Petruk (2001) stated that this morphology could be due to the nonuniform ambient medium where the SN exploded. Traditional models invoke the effects of thermal conduction which induce the evaporation of the dense clouds shocked by the SNRs and the cooling of the ejecta interacting with the clouds (e.g., White & Long 1991; Cox et al. 1999; Shelton et al. 1999; Zhou et al. 2011; Okon et al. 2020), although they typically do not consider the role of the ejecta X-ray emission, which is important in many cases (Lazendic & Slane 2006; Bocchino et al. 2009). On the other hand, alternative cooling processes suggest that the overionization of the ejecta is due to their rapid free expansion following their early heating in the case of an interaction with dense clouds (e.g. Miceli et al. 2010; Zhou et al. 2011; Yamaguchi et al. 2018; Greco et al. 2018). It is, therefore, important to carefully model the evolution of MM SNRs by describing in detail their interaction with the complex environment.

IC 443 (G189.1+3.0) has a diameter of ~50 arcmin and belongs to the GEM OB1 association at a distance of 1.5 kpc (Petre et al. 1988; Welsh & Sallmen 2003). It appears to consist of two interconnected quasi-spherical subshells of different radii and centroids that define the usually assumed boundaries of IC 443 (Braun & Strom 1986). The remnant age is still uncertain: the proposed age for SNR IC 443 varies from ~ 3 kyr (Troja et al. 2008) to ~20−30 kyr (Chevalier 1999; Bykov et al. 2008).

Several works have investigated the physical and chemical properties of IC 443 via radio (Leahy 2004; Lee et al. 2008, 2012), infrared (Rho et al. 2001; Su et al. 2014), X-ray (Troja et al. 2006, 2008; Greco et al. 2018) and γ-ray (Tavani et al. 2010; Abdo et al. 2010) observations. IC 443 is interacting with a molecular cloud in the northwestern (NW) and southeastern (SE) areas and with an atomic cloud in the northeast (NE). The dense molecular cloud was first identified by Cornett et al. (1977) and it lies in the foreground of IC 443 forming a semi-toroidal structure (Burton et al. 1988; Troja et al. 2006; Su et al. 2014). In the NE, the remnant is confined by the atomic H I cloud, discovered by Denoyer (1978), which is well traced by optical, infrared, and very soft X-ray emission (see Troja et al. 2006). The X-ray emission from IC 443 is composed of extended thermal X-ray emission and a number of isolated hard X-ray sources whose emission includes both thermal and non-thermal components (e.g., Petre et al. 1988; Bocchino & Bykov 2000, 2003; Bocchino et al. 2008). The latter could be a product of the SNR ejecta (or the pulsar wind nebula; PWN) and the surrounding shocked molecular clumps (see Zhang et al. 2018, and references therein). The gamma-ray emission from IC 443 seems to be associated with the interaction of cosmic rays accelerated at the shock front and the nearby molecular clouds (Tavani et al. 2010; Abdo et al. 2010). The remnant shows a great diversity and superposition of shocks which may be a natural result of the shock-cloud interactions in a clumpy interstellar medium (Snell et al. 2005; Shinn et al. 2011). Indications for the presence of overionized plasma have also been found (Yamaguchi et al. 2009; Matsumura et al. 2017; Greco et al. 2018), with their origin still under debate.

The available evidence implies that the SNR shock has encountered a pre-existing high density shell. Troja et al. (2008) suggested that SNR IC 443 has evolved inside a preexisting wind blown bubble, which likely originated from the massive progenitor star of the remnant (probably related to the PWN CXOU J061705.3+222127). The plerion nebula, discovered by Chandra (Olbert et al. 2001) and previously studied by several authors (e.g., Bocchino et al. 2001; Gaensler et al. 2006; Swartz et al. 2015), is situated in the southern part of the remnant, but its association with IC 443 is still debated considering its off-center position. Recently, Greco et al. (2018) detected a Mg-rich jet-like structure in the NW area of IC 443 close to the molecular cloud. Interestingly, the jet emission is mainly due to overionized plasma and its projection towards the remnant interior crosses the position of the neutron star at the time of the explosion of the progenitor star. This strongly suggests that the PWN belongs to IC 443 and that the collimated jet has been produced by the exploding star.

Here, we investigate the origin of the complex structure and of the multi-thermal X-ray emission of SNR IC 443 as well as the effects of the inhomogeneous medium in shaping the observed morphology. To this end, we modeled the expansion of the SNR and its interaction with the surrounding environment, parametrized in agreement with the results of the multi-wavelength data analysis. From the simulations, we synthesized the thermal X-ray emission and compared it with observations.

The paper is organized as follows. In Sect. 2, we describe the model, the numerical setup, and the synthesis of the thermal X-ray emission. In Sect. 3, we discuss the results and in Sect. 4, we draw our conclusions.

2 Hydrodynamic model

We developed a three-dimensional (3D) hydrodynamic (HD) model for SNR IC 443, which describes the expansion of the SNR and its interaction with the surrounding CSM-ISM. We followed the evolution of the SNR for t ≈ 10 000 yr by numerically solving the full time-dependent HD equations in a 3D Cartesian coordinate system (x, y, z), including the effects of the radiative losses from optically thin plasma. The HD equations were solved using the conservative form: ∂ρ∂t+∇⋅(ρu)=0,∂(ρu)∂t+∇⋅(ρuu)+∇P=0,∂(ρE)∂t+∇⋅[u(ρE+P)]=−nenHΛ(T), \begin{eqnarray*} \frac{\partial \rho}{\partial t} + \nabla \cdot (\rho \boldsymbol{u}) &=& 0,\\[5pt] \frac{\partial (\rho \boldsymbol{u}) }{\partial t} + \nabla \cdot (\rho\boldsymbol{u}\boldsymbol{u}) + \nabla P &=& 0,\\[5pt] \frac{\partial (\rho E) }{\partial t} + \nabla \cdot [\boldsymbol{u} (\rho E+P)] &=& - n_{\mathrm{e}} n_{\mathrm{H}} \Lambda (T),\end{eqnarray*}

where E = ϵ + u2∕2 is the total gas energy (internal energy ϵ, and kinetic energy) per unit mass, t is the time, ρ = μmHnH is the mass density, μ = 1.29 is the mean atomic mass of positive ions (assuming cosmic abundances), mH is the mass of the hydrogen atom, nH is the hydrogen number density, u is the gas velocity, T is the temperature, and Λ(T) represents the optically thin radiative losses per unit emission measure derived with the PINTofALE spectral code (Kashyap & Drake 2000) and with the APED V1.3 atomic line database (Smith et al. 2001), assuming solar abundances. We used the ideal gas law, P = (γ − 1)ρϵ, where γ = 5∕3 is the adiabatic index.

We performed the calculations using PLUTO (Mignone et al. 2007), a modular Godunov-type code for astrophysical plasmas. The code provides a multiphysics, multialgorithm modular environment particularly oriented towards the treatment of astrophysical high Mach number flows in multiple spatial dimensions. The code was designed to make efficient use of massive parallel computers using the message-passing interface (MPI) library for interprocessor communications. The HD equations are solved using the HD module available in PLUTO; the integration is performed using the original Piecewise Parabolic Method (PPM) reconstruction by Colella & Woodward (1984, see also Miller & Colella 2002) with a Roe Riemann solver. The adopted scheme is particularly appropriate for describing the shocks formed during the interaction of the remnant with the surrounding inhomogeneous medium, as in our case. We used a monotonized central difference limiter (the least diffusive limiter available in PLUTO) for the primitive variables. PLUTO includes optically thin radiative losses in a fractional step formalism (Mignone et al. 2007), which preserves the second time accuracy, as the advection and source steps are at least second-order accurate; the radiative losses (Λ values) are computed at the temperature of interest using a table lookup and interpolation method. The code was extended by additional computational modules to evaluate the deviations from equilibrium of ionization of the most abundant ions (via the computation of the maximum ionization age in each cell of the spatial domain, as described in Orlando et al. 2015) and the deviations from temperature-equilibration between electrons and ions. For the latter, we included the almost instantaneous heating of electrons at shock fronts up to kT ~ 0.3 keV by lower hybrid waves (see Ghavamian et al. 2007) and the effects of Coulomb collisions for the calculation of ion and electron temperatures in the post-shock plasma (see Orlando et al. 2015, for further details).

thumbnail Fig. 1

Schematic view of the environment adopted as initial conditions. The toroidal red structure and the spherical blue cap represent the molecular and the atomic clouds respectively. The black cross indicates the position of the PWN.

2.1 Numerical setup

The initial conditions consist of a spherically symmetric distribution of ejecta, representing the remnant of the SN explosion at the age of ≈ 122 yr, which expands through a highly inhomogeneous ISM. At this stage, the energy of the SNR is almost entirely kinetic, with the internal energy making up only a small percentage of the total energy. Given the lack of knowledge about the progenitor of SNR IC 443, we explored values in the ranges of 4− 10 M⊙ for the mass of the ejecta and 1−2.5 × 1051 erg for the energy of the explosion. The radial density profile of the ejecta is described by two power law segments (ρ ∝ r−m on the inside and ρ ∝ r−b on the outside), following the density distribution in a core-collapse SN as described by Chevalier (2005). For our favorite model, we use m = 1.5 and b = 11.31 (see Chevalier 2005) leading to an explosion energy of ~ 1 × 1051 erg and an ejecta mass of ~7 M⊙. The initial pressure of the ejecta is uniform, while the temperature is the lowest at the center of the initial remnant (T ≈20 K) and the highest in the outermost layers (T ≈ 105 K), following the inverse of the radial profile of density. The initial velocity of the ejecta increases linearly with the radial distance from zero, at the center of the remnant, up to 8 × 108 cm s−1 at 1 pc, namely the initial radius of the remnant.

The initial remnant is immersed in a highly inhomogeneous ambient environment. We follow the two-shell model proposed by Troja et al. (2006) to explain the IC 443 morphology (see Fig. 9, Troja et al. 2006). The medium consists of a toroidal molecular cloud and an spherical cap on the top representing the atomic cloud. In Fig. 1, we present a schematic view of the environment adopted as initial conditions.

The toroidal molecular cloud is azimuthally symmetric about the z-axis, centered at the origin of the 3D Cartesian coordinate system (x0, y0, z0) = (0, 0, 0). The dimensions of the clouds were chosen following the results of multi-wavelength data analysis (Rho et al. 2001; Troja et al. 2006, 2008; Lee et al. 2012; Su et al. 2014; Greco et al. 2018). The radius of the torus (i.e., the distance from the origin to the center of the tube) is 10 pc, while the radius of the tube is 2.6 pc. The atomic cloud is described as a spherical cap of radius 8 pc centered on the origin, confining the remnant to the positive direction of the z-axis.

The clouds play a central role in modifying the expansion of the forward shock and in driving a reverse shock through the ejecta. Since the geometry and density distribution adopted in the paper are idealized, this may introduce some artifacts in the remnant structure if the clouds are assumed to be uniform. On the other hand, a clumpy structure of the clouds is expected and often originates from highly compressible turbulence. Thus, we adopted a simplistic approach to the treatment of small-scale inhomogeneities in the clouds since we are not interested in studying in detail the effect of turbulence (as done by Zhang & Chevalier 2019). In order to get a non-uniform morphology and density distribution for the clouds, the material is modeled as a set of spherical clumps with radius ≈0.9 pc randomly distributed, filled with spherical sub-clumps of radius ≈0.3 pc. For the sakeof simplicity, the clouds were defined without considering any velocity fluctuations (which would still be much smaller than the shock velocity at the time when the remnant starts to interact with the clouds) and assuming pressure equilibrium among the clumps. For the average density, we explored values in the ranges of 10 < na < 103 cm−3 and 103 < nm < 104 cm−3 for the atomic and molecular clouds respectively, which is in good agreement with the values derived by Rho et al. (2001) from observations, namely 10 < n ≲ 1000 cm−3 in the northeastern rim and n ≈ 104 cm−3 in the southern molecular ridge. The density of the plasma in the spheres follows a normal distribution for both the atomic and the molecular clouds; in our preferred model, the mean density is ≈ 300 and ≈ 3000 cm−3, respectively. The intercloud medium is assumed to be uniform, with a density of 0.2 cm−3 and temperature of 103 K. The temperatures of the molecular and atomic clouds are set in order to be in pressure equilibrium with the intercloud component. The clouds and the intercloud medium are defined without considering any bulk velocity, which would still be much smaller than the velocity of the forward shock.

We explored different positions for the explosion (ranging between the geometric center of the cavity formed by the clouds and the very off-centered position of PWN CXOU J061705.3+222127, which is suspected to be the compact remnant of the SN) to derive the case that best reproduces the observations. We considered an offset along the x-axis, that is, the origin of the explosion is (dx, 0, 0), with dx varying in the range of [−5, 0] pc. The case dx = 0 corresponds to an explosion centered in the cavity formed by the surrounding clouds (see Fig. 1). Our preferred model, namely the case that best reproduces the observations, is based on dx = −5 pc, which corresponds to the position of PWN CXOU J061705.3+222127 at the time of the explosion (as inferred by Greco et al. 2018, taking into account the proper motion of the neutron star).

Table 1 summarizes the parameter space with the corresponding range of values explored, selected according to the values reported in the literature. Given the large number of parameters to be explored, we adopted an educated exploration of the parameter space by starting from a set of initial parameters (e.g., the SN explosion located at the geometric center of the clouds) and by performing an iterative process of trial and error to converge on a set of model parameters that reproduces the main features of X-ray observations of IC 443. The values of the model which best reproduce the data are outlined in the last column of Table 1.

The simulations include passive tracers to follow the evolution of the different plasma components (ejecta - ej - and atomic and molecular clouds; see Fig. 1), and to store information on the shocked plasma (time, shock velocity, and shock position, i.e., Lagrangian coordinates, when a cell of the mesh is shocked by either the forward or the reverse shock) required to synthesize the thermal X-ray emission (see Sect. 2.2). The continuity equations of the tracers are solved in addition to our set of HD equations. In the case of tracers associated with the different plasma components, each material is initialized with Ci = 1, while Ci = 0 elsewhere, where the index i refers to thematerial in the ejecta, in the atomic cloud and in the molecular cloud. All the other tracers are initialized to zero everywhere.

The computational domain is a Cartesian box extending for ≈ 34 pc in the x and y directions, and for ≈ 30 pc in the z direction. The box is covered by a uniform gridof 622 × 622 × 548 zones, leading to a spatial resolution of ≈0.055 pc. In this way, the initial remnant is covered by ~18 grid zones. We imposed outflow boundary conditions at all the boundaries.

Table 1

Summary of the initial physical parameters explored.

2.2 Synthesis of X-ray emission

We synthesized thermal X-ray emission from the model results, following the approach outlined in Orlando et al. (2015). Here, we summarize the main steps of this approach (see Sect. 2.3 in Orlando et al. 2015 for more details; see also Orlando et al. 2009; Drake & Orlando 2010).

First, we rotated the system 10° about the z-axis, 60° about the y-axis, and 28° about the x-axis to fit the orientation of the toroidal structure with respect to the line of sight (LoS) found from the analysis of observational data (Troja et al. 2006, 2008). For each cell of the 3D domain we derived the following: (a) the emission measure as EM = nH2V$EM\,{=}\,n_{\mathrm{H}}^2 V$ (where nH is the hydrogen density and V is the volume of the emitting plasma; we assume fully ionized plasma); (b) the ionization age τ = nejΔt where Δt is the time since the plasma in the domain cell was shocked; and (c) the electron temperature Te, calculated from the ion temperature, plasma density, and Δt, by assuming Coulomb collisions and starting from an electron temperature at the shock front kT = 0.3 keV, which is assumed to be the same at any time as a result of instantaneous heating by lower hybrid waves (Ghavamian et al. 2007;see also Orlando et al. 2015, for further details). In calculations of the electron heating and ionization timescale, the forward and reverse shocks are treated in the same way. From the values of emission measure, maximum ionization age, and electron temperature derived, we synthesized the X-ray emission in the soft [0.5− 1.4] keV and hard [1.4−5] keV bands using the non-equilibrium of ionization (NEI) emission model VPSHOCK available in the XSPEC package along with the NEI atomic data from ATOMDB 3.0 (Smith et al. 2001).

We assumed a distance of 1.5 kpc to the source (Welsh & Sallmen 2003) and an interstellar column density, NH = 7 × 1021 cm−2 (Troja et al. 2006). We assumed solar abundances for the ISM-CSM. As for the ejecta, we synthesized the X-ray emission by assuming the following set of abundances: O/O⊙ = 6, Ne/Ne⊙ = 7.5, Mg/Mg⊙ = 7.5, Si/Si⊙ = 8, S/S⊙ = 8, Fe/Fe⊙ = 2.5, and with solar abundances elsewhere. It is typically difficult to get reliable estimates of the absolute abundances from the analysis of X-ray spectra (see Greco et al. 2020, and references therein), while relative abundances are much more robust. Our relative abundances are in agreement with those derived by Troja et al. (2006, 2008) from the analysis of XMM-Newton observations (absolute abundances are a factor ~5 higher, see “region 6” in Troja et al. 2006 and “region IN” in Troja et al. 2008). We calculated the total X-ray emission in each cell and integrated along the LoS, and in selected spatial regions for the synthetic spectra. We then folded the resulting emission through the instrumental response of XMM-Newton/EPIC MOS2 camera.

We also derived the distribution of emission measure versus temperature, EM(T), in the temperature range of [104−108] K. The EM(T) distribution is an important source of information on the plasma components with different temperature contributing to the emission and is very useful in order to compare model results with observations. From the 3D spatial distributions of T and EM, we derive the EM(T) for the computational domain as a whole or for part of it: we consider the temperature range of [104 −108] K divided into 80 equidistant bins in log T; the total EM in each temperature bin is obtained by summing the emission measure of all the fluid elements corresponding to the same temperature bin.

3 Results

3.1 Hydrodynamic evolution

We followed the evolution of the SNR for approximately 10 000 yr, starting ≈ 100 yr after the explosion. We described the initial blast wave and the environment by performing a wide exploration of the parameter space, including the mass of the ejecta, the energy and origin of the explosion, and the density of the clouds (see Table 1). Here, we present in detail the results for our best model, namely, the case that best reproduces the observations of SNR IC 443, and we discuss the exploration of the parameter space.

The evolution of our preferred model is shown in Fig. 2, which reports the density (first row; third row, only the ejecta) and temperature (second row; fourth row, only the ejecta) distributions in the [x, z] plane, in logarithmic scale, at different epochs (increasing from left to right). The complete temporal evolution is available as online movie (Movie 1). The ejecta, described with a spherically symmetric distribution at the age of ~ 100 yr, initially propagate through a homogeneous medium in all the directions powered by their high kinetic energy. About ~ 300 yr after the SNevent, the forward shock starts to interact with the closer part of the toroidal molecular cloud (red clumpy structure in the left top panel in Fig. 2). The interaction determines a strong slowdown of the forward shock hitting the cloud and, consequently, a strengthening of the reverse shock traveling through the ejecta. Meanwhile, the portion of the remnant not interacting with the cloud continues to expand through the uniform intercloud medium. As a result, the initially spherically symmetric remnant progressively becomes asymmetric in the subsequent evolution (see second column in Fig. 2). The asymmetry is even enhanced when the blast wave starts to interact also with the atomic cloud to the north (orange clumpy structure in the top panels in Fig. 2). The strong reverse shock powered by the interaction with the molecular and atomic clouds (on the left side of the domain) rapidly expands through the ejecta and crosses the position of the neutron star immediately after the explosion (as also suggested by Greco et al. 2018) at an age of ≈ 3000 yr (see the magenta cross in the second column in Fig. 2). Given the large asymmetry caused by the interaction with the clouds on the left side,the reverse shock does not refocus in the center of the explosion, but proceeds expanding to the right (see third column in Fig. 2). At the same time, the forward shock continues to expand, reaching the farthest part of the toroidal cloud at t ≈ 4600 yr (see third column in Fig. 2). Conversely, the portion of the blast wave traveling southward is free to expand through the uniform intercloud medium. Most of the ejecta remain confined by the dense clouds in the northern part of the domain, to the right with respect to the center of the explosion (see the densest part of the ejecta in the third row in Fig. 2), while a fraction of them expand freely to the south (see third and fourth rows in Fig. 2).

The mass of the ejecta determines the density at the blast wave and, together with the velocity, regulates the energy of the explosion. The mass of the ejecta in our preferred model is ~ 7 M⊙ and the energy is ~1051 erg. The higher is the mass of the ejecta the higher is the density and the contribution of the ejecta to the X-ray emission (see Sect. 3.2). Moreover, if we consider models with the same energy, the higher is the ejecta mass the longer takes the blast wave to expand and the reverse shock to refocus; for instance, the model with ejecta mass 10 M⊙ takes ~ 1000 yr longer than the model with 4 M⊙ to arrive at an analogous final evolution state. When we consider models with higher energy instead (and same ejecta mass), the blast wave expands faster due to the higher velocity of the ejecta and the stronger interaction with the clouds leads to a larger contribution to the X-ray emission (see Sect. 3.2). For instance, the model with an explosion energy of 2.5 × 1051 erg takes ~ 3000 yr shorter than the model with 1 × 1051 erg to arrive to an analogous final evolution state. In the best model, we consider an offset of 5 pc from the center of the cavity for the progenitor (see Sect. 2.1), corresponding to the position inferred by Greco et al. (2018) for the nearby PWN at the instant of the explosion. A more centered position for the origin of the explosion (see Appendix A) yields a quite symmetric distribution of material in the SNR that does not agree at all with the multi-wavelength observations (Rho et al. 2001; Troja et al. 2006, 2008; Lee et al. 2012; Su et al. 2014; Greco et al. 2018).

In Fig. 3, we show a 3D volume rendering of the ejecta in our favorite model for IC 443 at t ≈ 8400 yr, from two different points of view: on the left, the assumed LoS (see Sect. 2.2, and Troja et al. 2006, 2008); on the right, same representation rotated by 90° about the z-axis. The ejecta distribution considers cells with density at more than 1% (upper panels) and 5% (lower panels) of the peak density. For a full-view distributions, see the online animations (Movie 2 and Movie 3). We also compare the modeled distribution of the ejecta and the blast wave with the observed morphology of the remnant in the optical band in the online Movie 4 (the wide field optical image was provided by Bob Franke - Focal Pointe Observatory) and in a navigable 3D graphic2. The ejecta are confined by the toroidal molecular (purple semi-transparent structure) and atomic clouds in the NE area, while the forward shock (transparent surface) travels freely in the opposite direction. The range of values explored for the atomic cloud is [10, 103] cm−3, according to the values discussed in the literature (e.g., Rho et al. 2001); for models with na < 300 cm−3 the forward shock sweeps up part of the material of the cloud and produces higher X-ray emission (see Sect. 3.2 for more details). In general, models with cloud densities n ≳300 cm−3 show similardistributions of ejecta and X-ray emission (see Sect. 3.2), as due to the high density, the cloud acts as a wall where the forward shock reflects. Thus, for our best model, we selected the minimum density producing results consistent with the observations, namely ~ 300 cm−3. We interpreted this as a lower limit to the density of the atomic cloud, thus better constraining the values of density quoted in the literature (namely, 10 < na < 103 cm−3; e.g. Rho et al. 2001). As for the molecular cloud, we explored values in the range of [103, 104] cm−3; for all of them, we found that neither the ejecta nor the X-ray distributions show relevant differences. So, we decided to consider a density of the molecular cloud which is an order of magnitude higher than that of the atomic cloud, namely ~ 3000 cm−3.

We observe a very irregular and asymmetric distribution of the ejecta (see Fig. 3) mainly due to the highly inhomogeneous medium where the SNR evolve and to the off-centered position selected for the origin of the explosion; the denser material is in the central part of the remnant to the right of the center of the explosion inside the cavity formed by the clouds (see 3rd and 4th rows in Fig. 2). This is due to the fact that the forward shock first reflects on the NE clouds, then is driven rapidly in the opposite direction, shocking the ejecta expanding to the right, and finally, it interacts with the reverse shock developed by the interaction of the blast wave with the NW clouds (we note the color scale in Fig. 3 and Movie 2, indicating the velocity distribution of the ejecta; see also Fig. 2). As a result, the reverse shock converges on a region located to the right of the center of explosion where the ejecta are compressed, reaching the highest values of density.

Since the SN explosion occurs close to the SE side of the molecular cloud, the ejecta are heated several times by multiple shocks reflected on the surrounding clouds in the very early stages of the remnant evolution, while they are still dense enough to approach rapidly the collisional ionization equilibrium. After this early heating, which occurs close to the explosion site, ejecta expand freely in the NW direction (see Fig. 2 and Movie 1) and cool down adiabatically, possibly leading to overionized plasma. This supports the scenario proposed by Greco et al. (2018) to explain the presence of overionized plasma and the component in strong non-equilibrium of ionization (NEI) found in the jet-like feature of IC 443.

In Fig. 4, we plot the density-weighted average electronic temperature along the LoS (see Sect. 2.2) for our preferred model at t ≈ 8400 yr. The temperature in the northern area close to the atomic cloud is ≈ 2 × 106 K, while in the SW region, it is higher and reaches values of ≈107 K in the central part of the remnant (close to the molecular cloud). Thus, the figure reveals a rather complex temperature structure of the plasma that is expected to be reflected in the X-ray emission arising from the remnant and a morphology which shows a striking resemblance with that of IC 443.

Figure 5 shows the distribution of emission measure as a function of the electronic temperature, EM(Te), for our preferred model (black line) and the ideal case without considering the effect of radiative losses from optically thin plasma (red line). The two models show completely different distributions for Te < 3 × 106 K (indicating an important role played by the radiative cooling), while they appear to be very similar for higher temperatures. Thus, the density-weighted temperature and the emission maps in the X-rays are similar for both the ideal and the best case; the differences in the EM(Te) distributions for Te < 3 × 106 K are reflectedmainly in the contribution to the X-ray emission coming from the plasma interacting with the clouds, which is higher in the ideal case. For a detailed description of the X-ray emission see Sect. 3.2.

thumbnail Fig. 2

Density (first row; third row, only the ejecta) and ionic temperature (second row; fourth row, only the ejecta) distributions in logarithmic scale in the (x, 0, z) plane at different evolution times (increasing from left to right). The magenta cross indicates the position of the explosion. See online Movie 1 for the complete temporal evolution.
thumbnail Fig. 3

Isosurfaces of the distribution of density at t ≈ 8400 yr for the ejecta of the favorite model for SNR IC 443 for different viewing angles: along the LoS (left panels), and rotated by 90° about the z-axis of the image (right panels). The opaque irregular isosurfaces correspond to a value of density that is at 1% (upper panels) and 5% (lower panels) of the peak density; their colors give the radial velocity in units of 1000 km s−1 on the isosurface. The semi-transparent surface marks the position of the forward shock; the toroidal semi-transparent structure in purple represents the molecular cloud. See online Movie 2 and Movie 3 for an animation of these data; a navigable 3D graphic is available at https://skfb.ly/6W9oM.
thumbnail Fig. 4

Map of the density-weighted average electronic temperature integrated along the LoS at ≈ 8400 yr.
thumbnail Fig. 5

Distribution of emission measure, EM, as a functionof the electronic temperature, Te, at ≈ 8400 yr. We compareour favourite model (black line) with the same model without radiative cooling (red line).

3.2 X-ray emission

In this section, we analyze the distribution of the X-ray emission in our best model and compare the X-ray emission synthesized from the model (see Sect. 2.2 for a detailed description) with XMM-Newton observations of SNR IC 443 (see Appendix B and Greco et al. 2018 for more details).

In Fig. 6, we present X-ray count rate maps synthesized from the model at different evolution times (increasing from left to right, corresponding to the evolution times shown in Fig. 2), considering the LoS as in left panels in Fig. 3 and integrating the emission along the LoS (see Sect. 2.2). The complete temporal evolution is available as online movie (Movie 5). The upper and lower panels at each epoch show the soft ([0.5−1.4] keV), and hard ([1.4−5] keV) X-ray emission, respectively. When the expanding ejecta reach the molecular cloud at t ≈ 300 yr since the SN event, the interaction of the forward shock with the dense cloud produces bright X-ray emission in both soft and hard bands (see left panels in Fig. 6). The impact on the cloud produces a reflected shock that powers the reverse shock, heating the ejecta material (see Fig. 2); indeed, the second column panels in Fig. 6 displays a large area with strong X-ray emission, especially in the soft band, due to the interaction of the ejecta with the dense cloud and the poweredreverse shock. The forward shock continues to interact with the atomic cloud to the north while expanding and producing bright X-ray emission that moves clock-wise from east to the north during the evolution (see Fig. 6, from leftto right, and Movie 5). The free propagation of the forward shock to the SW heats the ambient interclump material producing soft, and faint hard, X-ray emission (see third and fourth columns, in Fig. 6). We findthe brightest X-ray emission in the north area of the remnant where the clouds keep the plasma confined.

We followed the evolution and calculated the X-ray emission of the different plasma components (namely ISM and ejecta) by adopting the procedure explained in Sect. 2.2. In Figs. 7 and 8, we show synthetic X-ray count rate maps in the soft and the hard bands, respectively (noting the different scales), for the best model at t ≈ 8400 yr. Similarly to the density distributions presented in Figs. 2 and 3, the X-ray emission maps show a very asymmetric shape due to the highly inhomogeneous medium where the SNR evolve and to the off-centered position selected for the origin of the explosion; due to the morphology of the surrounding clouds, a model with a more centered position in the cavity for the originating SN exhibits a more symmetric X-ray distribution (see Fig. A.2 and Appendix A), which does not agree with the results from earlier X-ray studies (Troja et al. 2006, 2008; Bocchino et al. 2009; Greco et al. 2018). The ejecta show a centrally peaked distribution (see Figs. 7 and 8, middle panels) in both the soft and hard bands. From the exploration of the parameter space, we find that the higher is the initial mass of the ejecta, the brighter is its X-ray distribution.

The ejecta and the interstellar material are confined in the NE area (see Fig. 3) and interact with the clouds emitting in X-rays, mainly in the soft band, from the limb close to the atomic cloud (see left panels in Figs. 7 and 8). We verified that by changing the cloud density, we induce variations of the intensity of the X-ray emission in the northeastern bright limb. In particular, a lower cloud density leads to a higher contribution of X-ray emission from the interaction with the clouds. In fact, in lower density (na < 300 cm−3) models, the forward shock impacts into the cloud and drags part of the material; this interaction produces higher X-ray emission than the one shown in right panels in Figs. 7 and 8. On the other hand, for na > 300 cm−3 and for the range of values explored here for the density of the molecular cloud, namely, [103, 104] cm−3, the X-ray distributions do not show relevant differences. In any case, models with E > 1 × 1051 erg, that is, the energy of the best case, show higher X-ray emission in both the soft and the hard bands for all the density values of the clouds explored in this paper (see Table 1) due to the higher velocity of the blast wave, which leads to a stronger shock while interacting with the clouds and the ejecta.

SNR IC 443 has been classified in the category of MM SNRs, which show thermal peaked X-ray emission in the inner part and a shell morphology in radio (Rho & Petre 1998). The origin of this peculiar distribution, observed in left panels of Fig. 9, is not well understood. The X-ray emission synthesized from our favorite model has a centrally peaked component coming mainly from the ejecta in both the soft and hard bands (see right panels in Fig. 9). By carefullyderiving the explosion site (associated with CXOU J061705.3+222127) and the evolutionary stage (~ 8000 yr) of IC 443, we can naturally reproduce the broadband shape of the remnant. Moreover, we can understand the physical origin of the two different morphologies observed in soft (0.5−1.4 keV) and hard (1.4−5 keV) X-rays. In particular, we can pinpoint the role of ejecta and ISM in shaping the X-ray emission. While the interaction with the clouds produce mainly soft X-rays, concentrated in the upper part of the remnant (at t ~ 8000 yr), the hard X-ray emission is more centrally peaked (as in real data) and includes a larger contribution from the shocked ejecta heated by a reflected shock generated by the impact with the surrounding molecular ring. This is in agreement with the spectral analysis performed by Troja et al. (2006, 2008), where the authors associated the soft X-ray emission with shocked ISM and the harder X-ray emission with ejecta. The peculiar V-shaped northern border of the remnant and the faint, diffuse central and southern emission are also reproduced by our simulation as a result of the topology of the circumstellar environment.

We point out that the synthetic count rate is rather similar to that which is actually observed (without the need to add any ad-hoc renormalization), as shown in Fig. 9. We simply note that synthetic maps show an excess of soft X-ray emission in the northern limb due to the strong component originating in the interaction of the SNR with the atomic cloud (see Fig. 6 and Movie 5, and right panels in Figs. 7, 8, and 9). This excess is a result of the idealized morphology considered for the atomic cloud. Indeed, we considered a spherical cap connected with the toroidal molecular cloud that keeps the plasma confined and causes several reflections that, in turn, heat the material trapped inside. The X-ray emission from SNR IC 443 is higher in the soft band (see Fig. 9)3 due to the strong interaction of the remnant with the CSM and ISM.

In order to achieve a deeper level of diagnostics, we compared synthetic and actual spectra in the northern and central part of the remnant. To this end, we synthesized X-ray spectra from the two regions shown in right panels of Fig. 9: the northern region of the image being mainly composed by X-ray emission originating from the SNR-cloud interaction (black), and the central region being dominated by the ejecta component (red). We then analyzed actual spectra extracted from corresponding regions in the real XMM-Newton data, shown in left panels of Fig. 9, following the method outlined in Greco et al. (2018) (see also Appendix B). We selected regions with similar observed and synthetic total count rate, in order to compare the shape and the main features of the spectra. In Fig. 10, we plot the spectra corresponding to the northern (left panel) and the central (right panel) regions; in both cases, the spectra derived from the best model (black) remarkably reproduce the main features of the spectra extracted from the observed data (red). In particular, the equivalent widths of emission lines are much more pronounced in the central region than in the north. Moreover, the overall slope of the continuum is steeper at the north than in the central region, as in the real spectra. Details of line emission differ between models and observations (see Fig. 10, right panel). This is because we do not include tracers to follow the different chemical elements in the model, but instead we simply impose a uniform metallicity for all the ejecta in post-processing, according to the relative abundances of the main elements derived by Troja et al. (2006, 2008).

thumbnail Fig. 6

Synthetic X-ray count rate maps in the [0.5−1.4] keV band (upper panels) and [1.4−5] keV band (bottom panels) in logarithmic scale, at different evolution times (increasing from left to right). See online Movie 5 for the complete temporal evolution.
thumbnail Fig. 7

Synthetic X-ray count rate maps in the [0.5−1.4] keV band (in square root scale) at t ≈ 8400 yr, derived from the best model, as explained in Sect. 2.2 for the different components of the plasma: the whole distribution (left panel), solely the ejecta (middle panel), and the atomic and molecular clouds (right panel).
thumbnail Fig. 8

Synthetic X-ray count rate maps in the [1.4−5] keV band (in square root scale) at t ≈ 8400 yr, derived from the best model, as explained in Sect. 2.2, for the different components of the plasma: the whole distribution (left panel), solely the ejecta (middle panel), and the atomic and molecular clouds (right panel).

4 Summary and conclusions

In this work, we investigate the origin of the complex X-ray emission observed in the mixed-morphology SNR IC 443. For this purpose, we developed a 3D HD model describing the interaction of the SNR with the environment, parametrized in agreement with the results of the multiwavelength data analysis (Rho et al. 2001; Troja et al. 2006, 2008; Lee et al. 2012; Su et al. 2014; Greco et al. 2018). We performed a wide exploration of the parameter space describing the initial blast wave and the environment, including the mass of the ejecta, the energy and origin of the explosion, and the density of the clouds (see Table 1 for a summary of the parameter space explored and the values that best reproduce the observations). From the simulations, we synthesized the X-ray emission and compared it with XMM-Newton observations (see Appendix B).

Our model explains the complex X-ray morphology of SNR IC 443 in a natural way and is able to reproduce most of the features observed and identifying the strong effect of the inhomogeneous ISM on the remnant. The centrally-peaked X-ray morphology is best reproduced when considering the explosion site at the position of the PWN CXOU J061705.3+222127 at the time of the explosion (inferred taking into account the proper motion of the neutron star as estimated by Greco et al. 2018). This fact, together with the jet-like structure detected by Greco et al. (2018), supports the association between the PWN and IC 443, strongly indicating that the PWN belongs to IC 443 and that the collimated jet-like structure has been produced by the exploding star.

Our model results in a very irregular and asymmetric distribution of the ejecta, with a centrally-peaked X-ray emission due to the highly inhomogeneous medium where the SNR evolve and the off-centered position selected for the origin of the explosion. The surrounding clouds form a cavity where multiple shocks reflect, repeatedly heating the ejecta trapped inside. Before the expansion, the ejecta are heated and ionized by the interaction with the reflected shock due to the impact of the forward shock front with the SE cloud (which is very close to the explosion site, indicated by the position of the PWN at that time). Afterwards, the ejecta may cool down via adiabatic expansion to the NW, which could explain the overionized plasma in the jet-like structure discovered by Greco et al. (2018).

In our model, the atomic and the molecular clouds confine the remnant to the NE and SE, while it expands freely to the SW (see Fig. 3 and Movie 2 for a 3D view). From the exploration of the parameter space and the comparison of the X-ray emission observed with the X-ray synthesized images, we find that the density of the atomic cloud should be na > 300 cm−3, thus better constraining the values of density quoted in the literature (namely, 10 < na < 103 cm−3; e.g., Rho et al. 2001). In models with na < 300 cm−3, the forward shock sweeps up part of the material of the cloud and produces higher X-ray emission. For the molecular cloud, instead, neither of the values explored, namely [103, 104] cm−3, show significant differences in the X-ray emission. In our best model, the mass of the ejecta and the energy of the explosion are ~ 7 M⊙ and ~ 1 × 1051 erg, respectively, indicating that the parent SN was characterized by a low explosion energy. The higher is the mass of the ejecta and the energy of the model, the brighter the X-ray emission that is synthesized. From the evolution of the best model, we found that the peak of the X-ray emission move with time clockwise from east to the north and the time that best reproduces the X-ray observations of the remnant is ≈ 8400 yr. Considering all the cases explored, we find that the age of SNR IC 443 is ~ 8000 yr, indicating that IC 443 could be much younger than previous studies estimated (e.g., Chevalier 1999; Bykov et al. 2008).

The X-ray emission from SNR IC 443 is mostly dominated by the soft band, with a centrally-peaked distribution from the ejecta and a bright X-ray component from the northern limb close to the atomic cloud (see upper panels in Fig. 9). The X-ray emission in the [1.4−5] keV band is dominated by the ejecta component and presents a more pronounced centrally peaked morphology, as in the actual data. The synthetic spectra derived from the model adequately reproduce the main features of the spectra extracted from the observed data.

It is also worth noting that our simulations do not treat the molecular and atomic dissociation and ionization in the dense clouds because these processes are negligible with regard to the energy balance of the model. Considering a composition of 90% H and 10% He for the clouds, we estimated that the total energy necessary to dissociate and ionize all the shocked atoms and molecules of the clouds at the age of ~ 8400 yr is ~ 1048 erg. This value is one order of magnitude lower than the total internal energy of the shocked cloud material at the same epoch (which is ~ 1049 erg). Thus, we do not expect that the inclusion of these effects could change the main conclusions of this work. We also note that the internal structure of the remnant is mainly determined by the reverse shock that heats the ejecta, leading to the centrally-peaked morphology that emerges in the X-rays (see Fig. 9). Eventually, the main effect of dissociation and ionization of H and He would be to slightly reduce the temperature of the shocked clouds material, thus slightly lowering the contribution to the X-ray flux from the clouds in the [0.5−1.4] keV soft band (see right panel in Fig. 7). This reduction would improve even more the agreement between the X-ray emission maps synthesized from our model and those observed (see Fig. 9).

The radiative losses included in the model cool down the plasma, even though, in every case, the synthesized X-ray emission produced from the interaction with the atomic cloud is brighter than that observed in X-ray data. The excess of X-ray emission produced in the interaction of the SNR with the clouds in our model is a result of the morphology considered for the atomic cloud. Indeed, we considered a spherical cap, connected with the toroidal molecular cloud, which keeps the plasma confined and produces several reflections that heat the material trapped inside. The morphology described here is an idealization of the environment that we expect in SNR IC 443; a small fraction of the material could escape from the bubble along the LoS without leaving clear evidence in the observations.

It is worth noting that we neglected the effects of the thermal conduction in our simulations, although it may play a role in modifying the temperature structure of the shocked cloud and ejecta. In fact, a crucial effect that should be taken into account when including the thermal conduction is the ambient magnetic field which makes the thermal conduction highly anisotropic. However, we do not have any hints on the configuration and strength of the pre-SN interstellar magnetic field in IC 443. Any exploration of different field configurations and strengths in the simulations would be hopeless without imposing some constraints from observations. Nevertheless, even if we did have a satisfactory knowledge of the field configuration, we believe that the effects of thermal conduction may be negligible. For example, in the case of an ordered magnetic field, the thermal conduction can be highly suppressed in the direction perpendicular to the magnetic field (e.g., Orlando et al. 2008) and this could be the case if the blast wave squeezed the interstellar magnetic field along the clouds border (e.g., Orlando et al. 2019). In this case, the results would be comparable to those presented inthis paper. In the case of a randomly oriented magnetic field (possibly due to local turbulence), the thermal conduction can be reduced by up to a factor of 5 (Narayan & Medvedev 2001), thus making the effects of thermal conduction less relevant. Considering this reduction factor and the spatial resolution of the simulations as the lowest temperature length-scale, we estimated the characteristic time-scale for the thermal conduction in our model following Eq. (10) in Orlando et al. (2005). We obtained a conduction time-scale of ~ 5 × 105 yr, which is much larger than the evolution time of our model (~9000 yr). Thus, rather than prescribing an arbitrary magnetic field, for the purposes of the paper, we preferred to neglect the effects of thermal conduction in our simulations. This choice is analogous to assume a randomly oriented ambient magnetic field which is capable to strongly limit the effects of the thermal conduction. This assumption may affect some of the details of the shock-cloud interaction especially in regions where the effects of thermal conduction can be relevant. However we do not expect that our assumption affects the large-scale structure of the remnant and the ejecta distribution and, therefore, that it changes the main conclusions of the paper.

The morphology and the distribution of material observed in SNRs reflect the interaction of the SN blast wave with the ambient environment as well as the physical processes associated to the SN explosion and the internal structure of the progenitor star. Here, we consider a symmetric explosion for the initial conditions, which means that all the features observed in our model arise from the interaction of the remnant with the CSM and ISM. Thus, a correct description of the environment where the progenitor exploded has allowed us to explain the physical origin of the puzzling and multi-thermal X-ray emission of IC 443. The centrally peaked morphology (characteristic of MM SNRs) is a natural result of the interaction with the complex environment of IC 443. A combination of high resolution X-ray observations and accurate 3D HD modeling is necessary to confirm if this scenario is applicable to other MM SNRs. Our model also provided tight constraints on the explosion energy and the remnant age, and supported the association of IC 443 with PWN CXOU J061705.3+222127. A more detailed description of the SN explosion in IC 443 could add new information on the distribution of chemical abundances within the ejecta and on intrinsic inhomogeneities such as the overionized jet-like structure, as described by Greco et al. (2018).

thumbnail Fig. 9

Smoothed X-ray count rate maps in the [0.5−1.4] keV (upper panels) and [1.4−5] keV (lower panels) bands with a pixel size of 11′′. Left panels:2010 observations resampled as explained in the Appendix B. Right panels: synthetic images derived from the model, as explained in Sect. 2.2. The black and red shapes indicate the regions selected for the spectra shown in Fig. 10.
thumbnail Fig. 10

XMM-Newton EPIC MOS spectra extracted from the northern (left panel) and central (right panel) regions represented in Fig. 9. In black, the synthetic spectra derived from the model; in red, the spectra extracted from the observations. Error bars are at 1σ.

Movie

Movie 1 associated with Fig. 2. Access here

Movie 2 associated with Fig. 3. Access here

Movie 3 associated with Fig. 3. Access here

Movie 4 associated with Fig. 3. Access here

Movie 5 associated with Fig. 6. Access here

Acknowledgements

We thank the referee for useful comments and suggestions that allowed us to improve the manuscript. We acknowledge the CINECA ISCRA initiative (Award HP10CET086), the MoU INAF-CINECA initiative (Grant INA17_C5A43) and the HPC facility (SCAN) of the INAF - Osservatorio Astronomico di Palermo for the availability of high performance computing resources and support. The PLUTO code, used in this work, was developed at the Turin Astronomical Observatory in collaboration with the Department of General Physics of Turin University and the SCAI Department of CINECA. S.O., M.M., F.B. acknowledge financial contribution from the INAF mainstream program and from the agreement ASI-INAF n.2017-14-H.O. We are grateful to Bob Franke, Focal Pointe Observatory, for sharing the optical image of SNR IC 443 used in the online movie and the 3D interactive graphic.

Appendix A SN explosion at the geometrical center of the atomic and molecular clouds

In this section, we present the case with dx = 0, which corresponds to an explosion centered in the cavity formed by the surrounding clouds (see Fig. 1 and Sect. 2.1). The rest of the parameters are the same as in our preferred model (see Table 1).

thumbnail Fig. A.1

Density (first row; third row, only the ejecta) and ionic temperature (second row; fourth row, only the ejecta) distributions in logarithmic scale in the (x, 0, z) plane at different evolution times (increasing from left to right). The magenta cross indicates the position of the explosion.

The evolution of the model is shown in Fig. A.1 which, similarly to Fig. 2, reports the density and temperature distributions in the [x, z] plane, using same scales and evolution times for comparison with the best model described in Sect. 3. The ejecta expanding through the uniform intercloud medium start to interact with the atomic and molecular clouds ~ 2000 yr after the SNevent, much later than in the best case (see Figs. 2 and A.1) and the forward shock hits the clouds at the same time in all directions. As a consequence, the reverse shock (powered by the interaction with the clouds) travels through the ejecta when it is already expanded and is partially refocused slightly south of the origin of the explosion, which is indicated with a magenta cross (see second and third columns in Fig. A.1). As a result of this evolution, the remnant becomes symmetric respect to the z-axis (see last column in Fig. A.1).

In Fig. A.2, we present X-ray count rate maps synthesized (see Sect. 2.2) from the model at the same evolution times as in Fig. A.1 (increasing from left to right), considering the LoS as in our best model (see Fig. 3, left panels). The X-ray emission maps of the remnant show a symmetric distribution respect to the axis of the toroidal structure (see Figs. 1 and 3) due to the symmetric interaction with the clouds (see Fig. A.2). This distribution does not agree with the X-ray observations (Troja et al. 2006, 2008; Bocchino et al. 2009; Greco et al. 2018) and does not reproduce the X-ray morphology of IC 443 (see left panels in Fig. 9).

thumbnail Fig. A.2

Synthetic X-ray count rate maps in the [0.5−1.4] keV band (upper panels) and [1.4−5] keV band (bottom panels) in a logarithmic scale at different evolution times (increasing from left to right).

Appendix B XMM-Newton observations of IC 443

The source IC 443 has been observed several times with the European Photon Imaging Camera (EPIC) on board of XMM-Newton. We carried out spectral analysis of the observation performed in March 2010 (Obs-ID = 0600110101, PI: E. Troja) by considering only the MOS2 data. For the aim of this work, only one camera is needed and, out of the three available, we chose MOS2 since it is the one that is least degraded. We built count-rate images in two different energy bands following the same approach described in Sect. 2 in Greco et al. (2018), considering a bin size of 11′′. We used the Science Analysis System (SAS), version 16.1.0, to perform the whole data analysis. In particular, we used the SAS tool evigweight to correct vignetting effect in the spectra; we applied the SAS tasks rmfgen and arfgen obtaining response and ancillary matrices; and we binned spectra to obtain at least 25 counts per bin. The spectral analysis has been performed with XSPEC (version 12.10.0c, Arnaud 1996).

Appendix C Online material

  • Movie 1: Temporal evolution of the density (first column) and the ionic temperature (second column) distributions in logarithmic scale in the (x, 0, z) plane. The second row shows the distributions considering only the ejecta. The magenta cross indicates the position of the explosion.

  • Movie 2: Isosurface of the distribution of density at t ≈ 8400 yr for the ejecta of the preferred model for SNR IC 443. The opaque irregular isosurface corresponds to a value of density which is at 1% of the peak density; their colors give the radial velocity in units of 1000 km s−1 on the isosurface. The semi-transparent surface marks the position of the forward shock; the toroidal semi-transparent structure in purple represents the molecular cloud. A navigable 3D graphic is available4.

  • Movie 3: Isosurface of the distribution of density at t ≈ 8400 yr for the ejecta of the favorite model for SNR IC 443. The opaque irregular isosurface corresponds to a value of density which is at 5% of the peak density; their colors give the radial velocity in units of 1000 km s−1 on the isosurface. The semi-transparent surface marks the position of the forward shock; the toroidal semi-transparent structure in purple represents the molecular cloud.

  • Movie 4: Same as Movie 2, compared with an optical observation of SNR IC 443. The transparent image passing through the center of the remnant is a wide field optical observation of SNR IC 443. A navigable 3D graphic is available5. Image credit: Wide Field Optical: Bob Franke (Focal Pointe Observatory).

  • Movie 5: Temporal evolution of the synthetic X-ray count rate maps in the [0.5−1.4] keV band (left panel) and [1.4−5] keV band (right panel) in logarithmic scale.
