Volumetric star formation laws of disc galaxies
^{1}
Dipartimento di Fisica e Astronomia, Università di Bologna, via Gobetti 93/2, 40129 Bologna, Italy
email: cecilia.bacchini@unibo.it
^{2}
Kapteyn Astronomical Institute, University of Groningen, Landleven 12, 9747 AD Groningen, The Netherlands
^{3}
INAF – Osservatorio Astronomico di Bologna, via Gobetti 93/3, 40129 Bologna, Italy
^{4}
Institute of Astronomy, University of Cambridge, Madingley Road, Cambridge CB3 0HA, UK
^{5}
Department of Physics, ETH Zurich, WolfgangPauliStrasse 27, 8093 Zurich, Switzerland
Received:
4
October
2018
Accepted:
28
November
2018
Star formation (SF) laws are fundamental relations between the gas content of a galaxy and its star formation rate (SFR) and play key roles in galaxy evolution models. In this paper, we present new empirical SF laws of disc galaxies based on volume densities. Following the assumption of hydrostatic equilibrium, we calculated the radial growth of the thickness of the gaseous discs in the combined gravitational potential of dark matter, stars, and gas for 12 nearby starforming galaxies. This allowed us to convert the observed surface densities of gas and SFR into the deprojected volume densities. We found a tight correlation with slope in the range 1.3–1.9 between the volume densities of gas (HI+H_{2}) and the SFR with a significantly smaller scatter than the surfacebased (Kennicutt) law and no change in the slope over five orders of magnitude. This indicates that taking into account the radial increase of the thickness of galaxy discs is crucial to reconstruct their threedimensional density profiles, in particular in their outskirts. Moreover, our result suggests that the break in the slope seen in the Kennicutt law is due to disc flaring rather than to a drop of the SF efficiency at low surface densities. Surprisingly, we discovered an unexpected correlation between the volume densities of HI and SFR, indicating that the atomic gas is a good tracer of the cold starforming gas, especially in low density HIdominated environments.
Key words: stars: formation / ISM: kinematics and dynamics / ISM: structure / galaxies: kinematics and dynamics / galaxies: star formation / galaxies: structure
© ESO 2019
1. Introduction
The first formulation of an empirical star formation (SF) law was proposed by Schmidt (1959) in the shape of a power law
where ρ_{SFR} is the star formation rate (SFR) per unit volume and ρ_{HI} is the HI volume density; at that time, it was not possible to observe molecular gas emission. Using the distribution of young stars in the Milky Way (MW), he suggested that the index n of this power law is between 2 and 3. Unfortunately, if we focus on galaxies outside the MW, we can directly observe only the projected quantities, for example the surface densities, so Schmidt’s approach is less suitable.
The works of Kennicutt (1989, 1998) set the current standard method to investigate SF law. Using a sample of nearby starforming galaxies, Kennicutt (1989) derived a relation involving the radial profiles of the gas and the SFR surface densities (see also Kennicutt et al. 2007; Martin & Kennicutt 2001). The socalled Kennicutt (or Schmidt–Kennicutt) law is
where Σ_{SFR} and Σ_{gas} are the surface densities of SFR and total gas (HI+H_{2}). However, this surfacebased power law showed a break at densities below a threshold value. Later, Kennicutt (1998) collected a sample of spiral galaxies and starbursts to study the SF law over a range of seven orders of magnitude. Using surface densities integrated over the entire disc, he found a single powerlaw correlation with an index of N = 1.4 ± 0.15. In the next two decades, there was much work on two main issues of the SF law: the first issue refers to the gas phase that better correlates with SF and the second concerns the possibility that the powerlaw index changes in particular environments, producing a break in the relation.
About the first issue, several observational studies claimed that the vital fuel of SF is molecular gas. Indeed, a gas cloud can gravitationally collapse only if its temperature is low enough, and molecules are very efficient coolants. Bigiel et al. (2008) studied the SFRH_{2} relation in 18 nearby galaxies through pixeltopixel analysis and radial profiles extraction. These authors found, on a subkiloparsec scale, a linear correlation between SFR and molecular gas surface densities (see also Wong & Blitz 2002; Kennicutt et al. 2007; Bolatto et al. 2011; Schruba et al. 2011; Marasco et al. 2012; Leroy et al. 2013). Similarly, Lada et al. (2010) found a linear relation linking the mass of Galactic molecular clouds and the number of hosted young stellar objects.
However, molecular clouds form from atomic gas and, after the SF has occurred, they are destroyed by stellar feedback. Hence, we would expect the atomic or total gas to correlate with SFR, as originally found by Schmidt (1959). On the contrary, Leroy et al. (2008) found no correlation on subkiloparsec scale between HI and SFR in nearby starforming galaxies (see also Kennicutt et al. 2007). The picture changes in HIdominated environments such as the outskirts of spiral galaxies and dwarf galaxies, where the SFR seems to correlate also with atomic gas, but the efficiency of SF drammatically drops at these low surface densities (e.g. Ferguson et al. 1998; Bigiel et al. 2010; Bolatto et al. 2011; Schruba et al. 2011; Yim & van der Hulst 2016).
The second issue about the Kennicutt law concerns the shape of the classical relation involving the total gas and the SFR. Bigiel et al. (2008) found that the Kennicutt law index changes at Σ_{gas} ≈ 9 M_{⊙} pc^{−2}, which approximately corresponds to the transition to low density and HIdominanted environments (see also Bolatto et al. 2011; Schruba et al. 2011; DessaugesZavadsky et al. 2014). As a consequence, a surfacebased, double powerlaw relation was proposed and its break was explained as an abrupt change in the efficiency of SF at a specific threshold density (see also Schaye 2004). Similarly, Roychowdhury et al. (2015) studied the Kennicutt law in HIdominanted regions of nearby spirals and dwarf irregulars, and found a powerlaw relation with slope 1.5 for both kind of galaxies. Their relation showed however an offset of one order of magnitude with respect to the SF law for more central regions, where the gas surface density is higher. Despite that the existence of the break is not firmly confirmed as several authors recovered the classical single power law, sometimes with a different index. For example, Boissier et al. (2003) and Barnes et al. (2012) estimated N ≈ 2 and N = 2.8 ± 0.3, respectively, in nearby starforming galaxies, Heyer et al. (2004) found N ≈ 3.3 for M33, and Sofue (2017) measured N = 1.12 ± 0.37 in the MW.
From a theoretical point of view, it is possible to predict the powerlaw index assuming that a given physical process regulates the birth of stars. The simplest model involves the gravitational collapse and the SF timescale is set by the freefall time (Madore 1977). As a result, the SFR is given by the fraction of gas converted into stars per freefall time, so . This corresponds to if the disc thickness is constant with the galactocentric radius. This basic model has been proposed to explain the observed Kennicutt law with index N ≈ 1.4. Another possible SF timescale is the orbital time in the disc, which is related to the rotation velocity of the galaxy (e.g. Kennicutt 1998; Kennicutt et al. 2007; Boissier et al. 2003; Bolatto et al. 2017). Alternatively, if the balance between turbulent motions and gravity is assumed to regulate SF, the predicted slope is N ≈ 2 (e.g. Larson 1981; Elmegreen 2015). Another class of models aims to predict the critical density for the broken power law. For example, Toomre (1964) formalism allows us to estimate the critical density above which a gas disc is gravitationally unstable and the shear is low enough to have SF (e.g. Kennicutt 1989; Romeo 1990, 1992; Hunter et al. 1998; Martin & Kennicutt 2001). These are only a few examples among the plenty of possible models that have been proposed to explain or predict observations (see Krumholz 2014 and references within).
Overall, the picture is very complex and the shape of the relation between gas and SF remains unknown. Moreover, it is unclear which gas phase matters most for SF, whether molecular or atomic or both. Having a robust recipe for SF is very important, as the SF law is a key ingredient of numerical simulations and theoretical models of galaxies formation and evolution (e.g. chemical evolution of discs). All the SF laws mentioned so far (except Schmidt 1959) are based on surface densities because they are easy to observe, but the volume densities are likely more physically meaningful quantities than surface densities. In addition, gas discs in galaxies are expected to be nearly in hydrostatic equilibrium, so their thickness grows going from the inner radii to the outskirts and the resulting projection effects are not negligible (e.g. van der Kruit & Searle 1981a; Abramova & Zasov 2008; Banerjee et al. 2011; Elmegreen 2015). The purpose of this paper is to build a volumetric star formation (VSF) law through a method to convert surface densities to volume densities in local disc galaxies. The general model is described in Sect. 2, then Sect. 3 explains how we selected the sample of galaxies to test this model. The thickness of the gas disc for each galaxy is calculated in Sect. 4 and the resultting volumetric correlations are shown in Sect. 5. In Sect. 6, our results are discussed and compared to other works. Finally, we provide summary and conclusions in Sect. 7.
2. Volume densities from hydrostatic equilibrium
In order to build the VSF law, we need the volume densities of atomic gas (ρ_{HI}), molecular gas (ρ_{H2}), and SFR (ρ_{SFR}). In the following, we show how the simple assumption of the vertical hydrostatic equilibrium allows us to estimate these quantities and the ingredients that are needed to calculate them.
2.1. Hydrostatic equilibrium
Let us consider a rotating disc of gas in hydrostatic equilibrium in the gravitational potential Φ of a galaxy, which is assumed to be symmetric with respect to the rotation axis (axisymmetry) and the plane z = 0 (midplane). The vertical distribution of the gas density ρ(R, z) can be described by the stationary Euler equation in the z direction as follows:
where P(R, z) is the gas pressure due to the combination of thermal and turbulent motions, the latter being the dominant component. At a given galactocentric radius R, we take the three components of the velocity dispersion of the gas to have the same value in all directions σ_{x}(R) = σ_{y}(R) = σ_{z}(R) = σ(R) (isotropy). Then, we assume that the velocity dispersion σ is constant along z (vertically isothermal gas). Therefore, on galactic scales, the global profile of σ depends only on R and the gas pressure can be written as (e.g. Olling 1995)
and Eq. (3) can be solved for the density profile
where ρ(R, 0) and Φ(R, 0) are the radial profiles of the gas volume density and the total gravitational potential evaluated in the midplane of the galaxy.
2.2. Gravitational potential
The gravitational potential of a galaxy can be obtained through the Poisson equation for gravity once its mass distribution is known. The main mass components of starforming galaxies are dark matter (DM), stars in the form of a disc and a bulge (if present), and gas.
2.2.1. Dark matter halo
The DM distribution can be modelled as a pseudoisothermal halo (van Albada et al. 1985) or a Navarro–Frenk–White (NFW) halo (Navarro et al. 1996). For simplicity, the DM halo distribution is assumed spherical. The pseudoisothermal density profile is
where ρ_{DM, 0} is the central volume density and r_{c} the core radius. The NFW profile is
where c = r_{200}/r_{s} is the concentration parameter; r_{200} is the radius within which the average density contrast with respect to the critical density of the Universe equals 200. The spherical radius is in cylindrical coordinates.
2.2.2. Stellar disc
The stellar disc mass distribution is modelled with an exponential radial profile and a sech^{2} vertical profile (van der Kruit & Searle 1981b),
where ρ_{⋆, 0} is the central density, R_{⋆} is the stellar scale length, and z_{⋆} the scale height, which is assumed to be z_{⋆} = R_{⋆}/5 (see van der Kruit & Freeman 2011 and references within).
2.2.3. Stellar bulge
The bulge mass distribution is modelled using a sphere with exponential profile,
where ρ_{b, 0} and r_{b} are central density and scale radius. The justification for the choice of Eq. (9) is discussed in Sect. 3.2.
2.2.4. Gas surface density
In order to model the variety of gas distributions in galaxies (both for the atomic and molecular phases), we need a flexible model. Hence, we combined a polynomial and an exponential function
where Σ_{0} is the central surface density, R_{Σ} is the scale radius, and C_{i} are the polynomial coefficients.
2.3. Velocity dispersion
In previous works (e.g. Abramova & Zasov 2008; Leroy et al. 2008; Elmegreen 2015), the gas velocity dispersion was assumed to be constant with radius. On the contrary, several measurements of the velocity dispersion in nearby galaxies and in the MW show that it decreases with increasing galactocentric radius, following an exponential or linear trend (e.g. Fraternali et al. 2002; Boomsma et al. 2008; Tamburro et al. 2009; Mogotsi et al. 2016; Marasco et al. 2017). Hence, we derived the profile of σ(R) from the observations (Sect. 4.1.2) and modelled it, for the atomic and molecular phases, with the exponential function
where σ_{0} is the velocity dispersion at the galaxy centre and R_{σ} is a scale radius. This function can also adequately model a linear decline for large R_{σ} compared to the galaxy size.
2.4. Scale height definition
By means of a second order Taylor expansion of Φ (see e.g. Olling 1995; Koyama & Ostriker 2009), Eq. (5) can be approximated near the midplane by a Gaussian profile,
where the radial profile of the vertical scale height h(R) is
The roles of the gravitational potential and the velocity dispersion are opposite, as the first drags the gas towards the midplane, while the second gives rise to a force directed upward. As shown in Sect. 4, in real galaxies both terms decrease with radius, but the global result is an increase of the scale height with radius.
Equation (13) is an analytical approximation for the scale height and it is valid if the vertical gradient of the gravitational potential is null within small heights above the midplane. In addition, Eq. (13) does not take into account the selfgravity of the gas, which could become significant at large radii. As a consequence, we do not calculate the scale height analytically with Eq. (13), but we use a numerical method to estimate the scale height from Eq. (5). In Appendix A, we however show that this approximation is not as coarse as it may seem, but it gives results that are compatible with the numerical scale heights.
2.5. From surface densities to volume densities
Let us now look at the gas disc from the perspective of an external observer who measures the radial profile of the gas density; we are assuming a faceon disc for simplicity. The observed profile of the surface density is the projection along the line of sight of the corresponding volume density profile as follows:
Substituting Eq. (12) in Eq. (14) and solving the integral, we obtain the volume density in the midplane
Hence, Eq. (15) gives us the volume density from the observed surface density and the scale height. This is valid for any component, in particular HI, H_{2} and SFR. The gaseous and the SFR components require separate brief discussions.
2.5.1. Gas volume densities
As mentioned in Sect. 2.4, the scale height of a gas disc depends on the velocity dispersion of the gas. The molecular and the atomic phase are characterised by different values for the velocity dispersion (e.g. Mogotsi et al. 2016; Marasco et al. 2017). Hence, we must consider these components as distributed into two separate discs both in hydrostatic equilibrium and each one with its own scale height (h_{HI} and h_{H2}). Therefore, Eq. (15) can be written both for HI and H_{2} and the volume density of the total gas (HI+H_{2}) in the midplane becomes
In this way we defined three quantities (ρ_{HI}, ρ_{H2} and ρ_{gas}) that we compare to the SFR volume density.
2.5.2. Star formation rate volume density
The SFR vertical distribution is not known a priori but, as stars form from gas, it is reasonable to assume that an equation analogous to Eq. (15) applies to newborn stars as well, given some suitable definition of the SFR scale height (h_{SFR}). For this latter, we decided to make two extreme assumptions. The first consists in supposing that h_{SFR} is a function of the scale heights of the two gas phases. Thus, we assumed it to be the mean of the scale heights of both gas phases weighted for the respective gas fractions,
where f_{HI}(R)=Σ_{HI}(R)/Σ_{gas}(R) and f_{H2}(R)=Σ_{H2}(R)/Σ_{gas}(R) are the fraction of HI and H_{2} with respect to the total gas. With this choice, if the atomic gas is fully dominant with respect to the molecular phase (as in the outskirts of spirals and in dwarfs), h_{SFR}(R) coincides with h_{HI} and viceversa with h_{H2}. If both gas phases are present in a comparable amount, then h_{SFR}(R) is simply a weighted mean of h_{H2} and h_{HI}. For the second choice, we assumed a constant h_{SFR}, we took h_{SFR} = 100 pc as a fiducial value (Barnes et al. 2012). We note that choosing a different constant would change only the normalisation factor for the SFR volume density. It is reasonable to expect that the true SFR scale height lies between these two extreme choices. We could also consider h_{HI} or h_{H2} as alternative definitions of h_{SFR}(R). We explore these cases in Sects. 5.2 and 5.3.
3. Sample description
In order to estimate the volumetric densities, we need a sample of starforming galaxies with known gravitational potential and their observed surface densities of gas and SFR as a function of galactocentric radius R. We selected the galaxies starting from the sample of The HI Nearby Galaxy Survey (THINGS; Walter et al. 2008), which includes 34 objects.
3.1. Surface densities
Among the THINGS sample, we selected all the 23 galaxies in the sample of Leroy et al. (2008), who provide the surface densities radial profiles for HI and SFR. Leroy et al. (2008) derived the atomic gas distribution from the THINGS 21 cm emission maps. The SFR distribution was obtained combining the farultraviolet (unobscured SF) emission maps from the Galaxy Evolution Explorer (GALEX; de Gil Paz et al. 2007) and the 24 μm (obscured SF) emission maps from the Spitzer Infrared Nearby Galaxy Survey (SINGS; Kennicutt et al. 2003). These authors divided each galaxy in rings and calculated the surface densities at a certain radius as azimuthal averages inside that ring. This method is supposed to smooth the distributions and cancel azimuthal variations due to over or underdense regions as holes or spiral arms. Leroy et al. (2008) used the CO(21) transition maps from the HERA COLine Extragalactic Survey (HERACLES; Leroy et al. 2005) and the CO(10) transition maps from the BerkeleyIllinoisMaryland Association Survey Of Nearby Galaxies (BIMA SONG; Helfer et al. 2003) to calculate the H_{2} surface densities for about half of the galaxies in their sample. These authors also used the MW α_{CO} to convert the integrated CO intensity to H_{2} surface density. However, as shown by Narayanan et al. (2012), the choice of α_{CO} is crucial as it influences the shape of SF laws, in particular at high surface density regimes. Hence, we took the profiles for molecular gas from Frank et al. (2016), who used the same data as Leroy et al. (2008) but adopted the α_{CO} factor reported by Sandstrom et al. (2013). These authors took account of the dusttogas ratio and the metallicity gradient to obtain an accurate estimate of the α_{CO} radial variation in 26 nearby galaxies. They found that the radial profile of α_{CO} is nearly constant for all the galaxies, except in the central regions, where it tends to decrease and becomes 5–10 times smaller than the MW value in the most extreme cases. For example, the inner H_{2} surface densities in NGC 4736 and NGC 5055 that were calculated by Sandstrom et al. (2013) differ from Leroy et al. (2008) results by one order of magnitude. For NGC 2403, Frank et al. (2016) used the MW α_{CO} as this galaxy was not included in Sandstrom et al. (2013) study.
3.2. Selection based on mass models
Among Leroy et al. (2008) sample, we selected the galaxies with parametric mass models in de Blok et al. (2008) or Frank et al. (2016). In particular, de Blok et al. (2008) decomposed high quality HI rotation curves for a sample of 19 THINGS galaxies to obtain mass models using a DM halo, a stellar disc, a bulge (if present), and an atomic gas disc. Concerning the DM component, the authors adopted either an isothermal (Eq. (6)) or a NFW profile (Eq. (7)): in the first case they provide the bestfit central volume density ρ_{DM, 0} and core radius r_{c}, while in the second case the parameters are the concentration c and V_{200}, which is the circular velocity at r_{200}. For the stellar disc component, de Blok et al. (2008) fitted the 3.6 μm intensity profile with Eq. (8) leaving R_{⋆} and the masstolight ratio M/L as free parameters. In a small number of galaxies, they found an additional central component in the 3.6 μm surface brightness distribution, which is related to the stellar bulge. These authors fitted the light profile using the same profiles of the stellar disc (Eq. (8)) instead of a more generic Sersic profile R^{1/n} (Sérsic 1963). The main reason for this choice was the limited radial range over which the bulge profile dominated the total emission and this avoided the need for the determination of the index n. They checked that assuming a different functional form did not significantly impact on their final mass models. Concerning the atomic gas component, de Blok et al. (2008) assumed that it is distributed in an infinitely thin disc. Later, Frank et al. (2016) repeated the de Blok et al. (2008) analysis including the molecular gas contribution for 12 galaxies; the molecular gas disc was also assumed to be infinitely thin in the modelling. Frank et al. found a good agreement with de Blok et al. (2008) results and improved the DM halo parametric mass model for some galaxies.
Crossmatching de Blok et al. (2008) and Leroy et al. (2008) samples, we ended up with a sample of 12^{1} nearby starforming galaxies with surface densities of gas and SFR, and parametric mass models. In our sample, there are six normal spirals and six lowmass galaxies, whose circular velocity do not exceed 150 km s^{−1} (DDO 154 is a dwarf galaxy). DDO 154^{2}, IC 2574, and NGC 7793 were not included in Frank et al. (2016) sample as no CO emission was detected, for these we used the mass models reported in de Blok et al. (2008). The main properties of the galaxies and the parameters of their mass models are summarised in Tables 1 and 2, respectively.
Properties of the sample galaxies.
Parametric mass models for DM and stellar components of the sample galaxies.
For the sake of accuracy, we checked that the distances reported by de Blok et al. (2008) and Frank et al. (2016) are compatible with those reported in Lelli et al. (2016), who carefully selected the most reliable measurements in literature (except for NGC 0925 and NGC 4736, which are not included in the Lelli et al. 2016 sample). For some galaxies (DDO 154, IC 2574, NGC 5055, NGC 6946, and NGC 7793), the difference between the two distances is not negligible and could slightly influence the rotation curve. Hence, we decided to adopt Lelli et al. (2016) distances and correct the surface densities of Leroy et al. (2008) accordingly.
3.3. Galaxies with bulge
As mentioned above, de Blok et al. (2008) modelled the mass distribution of the bulges using Eq. (8), i.e. as they were exponential discs. This is not convenient for our purpose as the vertical pull near the midplane in the potential of this flattened component is stronger than the same force in the potential of a more realistic spheroidal distribution with the same mass. Therefore, the scale height would be significantly smaller, at least for the innermost regions where the bulge is likely the dominant component of the total gravitational potential. To alleviate this problem, we built the alternative bulge model described in Sect. 2.2.3 using an exponential sphere (Eq. (9)). In this way, the observed exponential light distributions are preserved, but the mass distributions are no more flattened across the midplane.
We want our model of the exponential sphere to have the same circular velocity as the (bulge) model of exponential disc of de Blok et al. (2008) for each galaxy with significant contribution from the bulge (NGC 2841, NGC 4736, NGC 5055, NGC 6946, and NGC 7331). To this purpose, we fitted the circular velocity of the exponential sphere
to the circular velocity of de Blok et al. (2008) flat bulge, leaving ρ_{b, 0} and r_{b} as free parameters. In the end, our models for the bulges are given by Eq. (9) with the bestfit ρ_{b, 0} and r_{b} reported in Table 2.
4. Gas disc thickness
In this section, we calculate the scale height of HI, H_{2}, and SFR distributions. As mentioned in Sect. 2, the vertical distribution of the gas (Eq. (5)) is regulated by the total gravitational potential of the galaxy and the gas velocity dispersion, which have opposite roles. The main obstacle to the scale height calculation is accounting for the gas selfgravity. Indeed, the total gravitational potential of a galaxy Φ must include also the gas contribution, which depends on the gas distribution itself and thus on the scale height.
In order to include the selfgravity, we used the publicly available software GALPYNAMICS^{3} (Iorio 2018) to compute the gas potential and scale height through an iterative algorithm (see also Abramova & Zasov 2008; Banerjee et al. 2011), which we explain in this section in a broad outline. In order to choose a simple example, let us consider a galaxy composed of DM, stars and atomic gas (including He).

As a preliminary stage, the software calculates the potential of DM and stars, which is defined as the external and fixed potential Φ_{ext}.

In the zeroorder step, GALPYNAMICS assumes a razorthin (h_{HI} = 0) mass distribution for the HI disc and calculates its gravitational potential Φ_{HI}. The total gravitational potential of the galaxy is then set to Φ = Φ_{ext} + Φ_{HI}.

The first iteration begins. The HI vertical profile is given by Eq. (5), where the velocity dispersion is given by Eq. (11), and it is fitted with a Gaussian function (Eq. (12)) to infer the new scale height . The next evaluation of the HI gravitational potential Φ′_{HI} is done for a disc with thickness h′_{HI}. Then, we are able to update the total potential to Φ′=Φ_{ext} + Φ′_{HI}.

Using Φ′ in Eq. (5), we find more accurate vertical distribution and scale height h″_{HI} for the atomic gas, which allow us to better estimate Φ″_{HI} and then Φ″.
This procedure is iterated until two successive computations of the scale height differ by less than a tolerance factor, chosen by the user. This software was extensively tested using mock data (see Iorio 2018).
Most of the galaxies in our sample have both the atomic and molecular gas components. We first calculate the HI scale height in the gravitational potential of stars and DM, and then the scale height for H_{2} but including also the HI gravitational potential. This choice implies that the HI distribution is not influenced by the H_{2} distribution and that we obtain two different scale heights for each gas phase, h_{HI} and h_{H2}. We expect that including the molecular gas distribution to the potential does not affect the HI scale height, as the total mass of molecular gas is about one order of magnitude smaller than the total amount of atomic gas (see Leroy et al. 2008). Moreover, the molecular phase is concentrated in the inner regions of galaxies, where stars are the dominant mass component, and becomes negligible in the outskirts. On the other hand, the atomic gas is distributed out to larger radii, so its contribution to the total gravitational potential there could become truly significant.
4.1. Flaring HI disc
In order to calculate the HI scale height, GALPYNAMICS needs, in addition to the external potential Φ_{ext}, the HI radial profiles of the surface density Σ_{HI}(R) and velocity dispersion σ_{HI}(R).
4.1.1. HI surface density
As mentioned in Sect. 2.2.4, we modelled the atomic gas distribution using a combination of an exponential and a polynomial (Eq. (10)), which was fitted on the observed azimuthally averaged radial profiles of Leroy et al. (2008) leaving Σ_{HI, 0}, R_{Σ}, and C_{i} as free parameters (the helium correction of 1.36 is included). In Fig. 1, the observed Σ_{HI}(R) for each galaxy is shown by the blue points and the corresponding bestfit model is represented by the light blue curve. It is clear that the best fits reproduce well the observed radial profiles save negligible and small differences, which do not affect the computation of the scale height.
Fig. 1. HI (Leroy et al. 2008, blue points) and H_{2} (Frank et al. 2016, red points) observed surface densities radial profiles. The light blue and coral curves show the models used to compute the scale heights and are obtained by fitting Eq. (10) to the observed profiles. Only the ranges where the SFR is measured are shown.

Open with DEXTER
4.1.2. HI velocity dispersion
As shown by Eq. (5), we expect the scale height to linearly depend on the velocity dispersion, so an accurate modelling of σ_{HI}(R) radial profile is fundamental. To this aim, we derived the radial profiles of the velocity dispersion in our galaxies using the publicly available software ^{3D} BAROLO^{4} (Di Teodoro & Fraternali 2015), hereafter 3DB, on THINGS data cubes (Walter et al. 2008). The 3DB software performs a tiltedring model fitting directly on the data cube, allowing us to correct for the beam smearing, which can significantly modify the resulting velocity dispersion and rotation curve (e.g. Swaters 1999). Moreover, the rotation velocity and velocity dispersion are fitted simultaneously rather than as separate components, as done in the classical 2D approach based on velocity dispersion maps (e.g. Tamburro et al. 2009; Romeo & Mogotsi 2017). We chose 400 pc as a common spatial resolution for the data cubes of our galaxies, which is a compromise between negligible gas streaming motions within our beam and sufficient signaltonoise ratio (S/N) in low column density areas. Details on the properties of the data cubes and the 3DB input parameters are found in Appendix B. Figure 2 shows the velocity dispersion measured by 3DB for all the galaxies in the sample. Our results are in agreement with previous works showing that the velocity dispersion decreases with the radius from 12 to 20 km s^{−1} in the inner parts of local spirals and dwarfs down to 5–7 km s^{−1} in the outskirts (e.g. Narayan & Jog 2002; Boomsma et al. 2008; Tamburro et al. 2009).
Fig. 2. HI velocity dispersion measured using ^{3D}BAROLO (filled and empty circles) for our galaxies with a common sampling of about 400 pc (for NGC 2841 we show one data point every two). The bestfit models (Eq. (11)) are shown by the light blue curves, whose parameters (σ_{HI, 0} and R_{σ}) are reported in a box in the lower left corner of each panel. The points indicated by empty circles are excluded from the fit.

Open with DEXTER
The velocity dispersion of NGC 7331 galaxy is probably overestimated. Indeed, if we compare this profile to that of the other galaxies, we see that it is systematically higher. This increase likely originates from projection effects due to the galaxy inclination angle and the HI disc thickness or noncircular motions along the line of sight, which bias the velocity dispersion towards high values. NGC 7331 is indeed the most inclined galaxy in our sample (i≈ 76°), so the line of sight intercepts regions with different rotation velocity, broadening the line profile. Such effects may be present in two further profiles of very inclined galaxies, NGC 2841 and NGC 3198, but they seem to be less affected. NGC 2841 velocity dispersion shows a peculiar sharp increase of 10 km s^{−1} extending from 15 kpc to 30 kpc, whose origin we discuss in Appendix D.
Having measured σ_{HI}(R), the model for the velocity dispersion (Eq. (11)) was fitted to the data points leaving σ_{HI, 0} and R_{σ} as free parameters. The model must reproduce the radial decrease of the velocity dispersion, leaving aside the most peculiar features differing from the global trend, which could be due to low S/N regions or some residual beam smearing effect in the very innermost radii. Therefore, we excluded the innermost point of NGC 0925, NGC 2841, NGC 2976, NGC 3198, NGC 4736, NGC 5055, and NGC 7331. For NGC 6946, we rejected the inner five velocity dispersion measurements after a comparison with the velocity dispersion profile of Boomsma et al. (2008), who found that σ_{HI} ≈ 12 − 15 km s^{−1} for the central radii. Thus, the drop that we observe is likely an artefact due to low S/N of our data, which have higher angular resolution with respect to Boomsma et al. (2008). In Fig. 2, the excluded points are shown as empty circles, while the measurements used for the fit are shown as the filled circles.
4.1.3. HI scale height
We calculated h_{HI}(R) for our galaxies using their gravitational potential and the surface density and velocity dispersion of the atomic gas. Before describing the full sample, it is useful to focus on a single galaxy in order to understand which mass component drives the trend of the scale height with radius. In Fig. 3, we show three different HI scale heights out to R = 20 kpc for NGC 2403: each of these scale heights is obtained with a different gravitational potential but the same velocity dispersion radial profile σ_{HI}(R). In the presence of the stellar disc only (dashed orange line), the scale height increases exponentially out to about R = 7 kpc, then the growth becomes milder and h_{HI} reaches 1.8 kpc at R = 20 kpc. This is because the disc mass distribution fades within a short length, so the gravitational pull towards the midplane quickly weakens. As a consequence, the HI disc becomes thicker and thicker with radius, despite the decrease of the velocity dispersion; if the velocity dispersion were constant, then the flaring would be more prominent. For the DM only potential (dashed grey line), the pull towards the midplane is still significant in the outskirts, as the radial decrease of the DM density is significantly slower with respect to an exponential profile. In the combined potential of stars and DM (solid blue), the scale height is mainly driven by the stellar disc in the inner regions and by the DM halo in the outskirts (see also Sarkar & Jog 2018). At the end, h_{HI} increases by a factor of about 8 within 20 kpc in radius. We note that the scale height in the single component potentials is always larger with respect to the combined potential, so neglecting one or the other component causes an overestimate of the scale height.
Fig. 3. HI scale height radial profiles in the presence of three different gravitational potentials (including the HI selfgravity) but with the same velocity dispersion. The orange and grey dashed curves, respectively, show h_{HI}(R) for the stellar disc only and DM halo only potentials taken from NGC 2403 mass model. The total potential of NGC 2403 gives the blue solid curve.

Open with DEXTER
The radial profiles of the HI scale height for the all galaxies in our sample are shown by the blue curves in Fig. 4, and the associated uncertainties are represented by the faded blue area. In Appendix E, we provide details about the estimates of the uncertainties, which include the errors on Σ_{HI} and σ_{HI}. We note the global trend of the flaring is similar for all the galaxies. We emphasise that the HI disc flaring is significant, regardless of the galaxy type, so assuming a thin gaseous disc or a constant thickness is never a good approximation. The presence of the bulge (NGC 2841, NGC 4736, NGC 5055, NGC 6946, and NGC 7331) reduces the scale height in the innermost regions. However, the mass model for the bulge is more uncertain (see Sect. 2.2.3) and the velocity dispersion in the centre of galaxies has large errors, so it is likely that the scale height in the innermost radii of these galaxies is underestimated or at least uncertain. The projection effects are particularly significant in the outskirts, therefore we expect that the intrinsic volume densities distribution with radius will differ from the observed surface densities distribution. Therefore, we anticipate that the VSF law will have different shape than the law based on surface densities.
Fig. 4. Scale height radial profiles: h_{HI}(R) (solid blue) and h_{H2}(R) (solid red) are calculated by GALPYNAMICS, while h_{SFR}(R) (dashed black) is estimated using Eq. (17). We note that h_{H2}(R) is shown out to the radius where CO emission is detected. The faded regions indicate the uncertainties on the gas scale heights, while the black dashed regions are the uncertainties on h_{SFR}(R).

Open with DEXTER
4.2. Flaring H_{2} disc
The molecular gas scale height was estimated using the gravitational potential of stars, DM, and the HI disc with flaring thickness. Moreover, we needed the surface density and velocity dispersion of the molecular gas.
4.2.1. H_{2} surface density
As in Sect. 4.1.1, the model for the H_{2} distribution (Eq. (10)) was fitted to the radial profile of the observed surface density (including the correction for Helium), leaving Σ_{H2, 0}, R_{Σ}, and C_{i} as free parameters. In Fig. 1, the observed Σ_{H2} from Frank et al. (2016) are shown by the red points and the corresponding bestfit models are represented by the coral curves. The error bars include the uncertainties on α_{CO} as reported in Sandstrom et al. (2013).
4.2.2. H_{2} velocity dispersion
As for σ_{HI} (Sect. 4.1.2), we modelled σ_{H2} using an exponential profile, which should be fitted to the observed velocity dispersion radial profiles. The spatial and spectral resolution are crucial in measuring the molecular gas velocity dispersion, as they could artificially broaden the observed emission line. The first typically affects the velocity dispersion in the central parts of the galaxies and the second acts as an additional broadening component.
There are scarce high resolution observations of the molecular gas emission in our sample galaxies. In the literature, three studies measured the CO velocity dispersion radial profile using the HERACLES data cubes of the CO(21) emission line with spatial resolution of 13″. In particular, CaldúPrimo et al. (2013) used the data cubes with spectral resolution of 2.6 km s^{−1} and stacked the CO (and also HI) line profiles over kiloparsecsized regions to improve the S/N. They used the HI velocity fields as a guide to align the profile centroids and measured the velocity dispersions by fitting a Gaussian function to the stacked profiles. They estimated the ratio of the HI to H_{2} velocity dispersion to be σ_{HI}/σ_{H2} ≈ 1. However, the staking method easily introduces an artificial broadening if the profiles are not perfectly aligned, so their result could be overestimated. Later, Mogotsi et al. (2016) (see also Romeo & Mogotsi 2017) used Hanning smoothed data cubes with spectral resolution of 5.2 km s^{−1} and fitted a Gaussian function to the line profiles in each pixel with S/N > 4, finding σ_{HI}/σ_{H2} ≈ 1.4. Unfortunately, their resolution (≈5 km s^{−1}) is probably too low to measure the molecular gas velocity dispersion in the galaxy outskirts, where it can easily drop below 5 km s^{−1} as shown by Marasco et al. (2017). These latter authors used the LeidenArgentineBonn (LAB) allsky 21 cm survey (Kalberla et al. 2005) and the CO(21) survey (Dame et al. 2001) to measure the distribution and kinematics of atomic and molecular gas with spectral resolution of about 2 km s^{−1}. They reproduced the observed emission building a model of the Galactic disc made of concentric and coplanar rings defined by rotation velocity, velocity dispersion, midplane volume density, and scale height. Marasco et al. (2017) showed that the radial trends of σ_{HI} and σ_{H2} are approximetely the same (see also Mogotsi et al. 2016), while their mean values are 8.9 ± 1.5 km s^{−1} and 4.4 ± 1.5 km s^{−1}, respectively.
Hence, we decided to assume σ_{HI}/σ_{H2} ≈ 2 and estimated the radial profile of σ_{H2} from the σ_{HI} radial profiles. In practice, the model for the molecular gas velocity dispersion is given by Eq. (11) with σ_{H2, 0} = 0.5σ_{HI, 0} and the same R_{σ} reported in Fig. 2. However, we tested that assuming 1.4 for σ_{HI}/σ_{H2} does not significantly affect our results. For completeness, we also compared our σ_{H2} radial profile for NGC 2403, NGC 4736, and NGC 5055 with those reported by Wilson et al. (2011). They measured σ_{H2} using CO(3–2) emission data cubes with spectral resolution of 0.43 km s^{−1} and spatial resolution of 14.5″. Our profiles are compatible within the uncertainties with Wilson et al. results save for the very central regions (< 1 − 2 kpc), where the beam smearing likely acts as an additional broadening component on their profiles.
4.2.3. H_{2} scale height
In Fig. 4, we show the H_{2} scale heights with their associated uncertainty for all the galaxies in our sample. In Appendix E, we explain how the errors on h_{H2} were estimated to take account of the uncertainties on σ_{H2} and Σ_{H2}, which include the error on α_{CO}. We note that h_{H2} ≈ 0.5h_{HI}, save for negligible discrepancies, as the main driver of the difference in the flaring of HI and H_{2} discs is the velocity dispersion.
4.3. Star formation rate scale height
Knowing the scale heights of the HI and H_{2}, we estimated the scale height of the SFR vertical distribution using Eq. (17). In Fig. 4, we show h_{SFR}(R) (black dashed curve) as a function of radius and its uncertainties (see Appendix E for details). Clearly, in the case of DDO 154, IC 2574, and NGC 7793, h_{SFR}(R) coincides with h_{HI} as CO emission is not detected.
5. Volumetric star formation laws
Having all the scale heights, we converted surface densities to volume densities through Eq. (15). In Appendix E, we describe the calculation of the uncertainties on the volume densities, which include the errors on the observed surface densities and on the scale heights.
Figure 5a illustrates the effect of the conversion to volume densities on the correlation between gas and SFR for the galaxy NGC 5055. The left panel shows the classical surfacebased correlation with each point coloured according to the radius. As can be seen from the central panel, the conversion of gas surface densities to volume densities using the constant h_{SFR} stretches the points along the xaxis. Indeed, low density points typically belong to the outskirts, therefore they undergo the most significant leftward shift. In this case, the SFR surface density profile is divided by a constant value, so its trend is not modified. In the right panel, the gas volume densities are the same as in the central panel, but the flaring h_{SFR}(R) (Fig. 4) is assumed, so the points are also stretched along the yaxis.
Fig. 5. Upper row: correlations between gas and SFR surface densities (left) and volume (centre and right) densities for NGC 5055; h_{SFR} is assumed to be constant and flaring (Eq. (17)) in the central and right panels, respectively. Each point is obtained as an azimuthal average and coloured according to its galactocentric radius. The slope of the VSF law is much shallower than for the surfacebased law. This is a consequence of taking the flaring of the gas (and the SFR) into account. Lower row: same as the upper row but for all the galaxies in our sample. Each galaxy has its own colour as shown by the colour bar. The VSF law has considerably less scatter than the surface based version. Each panel shows similiar ranges in x and y. No obvious break in the SF efficiencies is found at low densities after correcting for disc thickness.

Open with DEXTER
5.1. Relation between total gas and star formation rate
We now consider the full sample of galaxies. Figure 5 compares the surfacebased (left) and the volumebased (centre and right) correlations between gas and SFR with the points colourcoded according to the galaxy of origin. Byeye, it is clear that the surfacebased correlation is more scattered than any of the volumebased correlations. The change in the SF efficiency seen by Leroy et al. (2008) and Bigiel et al. (2010) is partially reduced in the left panel thanks to the improvement in the α_{CO} measurement by Sandstrom et al. (2013) included in this study. However, some galaxies in the left panel (e.g. NGC 5055 and NGC 7793) seem to follow a steeper SF law with respect to the others (e.g. NGC 4736 and NGC 7331). Indeed, the observed surface density corresponds to the integral of the column of gas along the line of sight and the height of this gas column increases with radius. Hence, high surface densities can be present not only in the central parts of galaxies, but also in the external regions, where the volume density is instead low and a few stars form. On the other hand, using the volume densities, we found a tight correlation between SFR and gas over 4–5 orders of magnitude. Even by eye, it is clear that the scatter reduces as the galaxies tend to align on the top of each other.
Figure 6a is the same as Fig. 5b but the points are coloured according to the HI fraction, f_{HI}(R)=Σ_{HI}(R)/Σ_{gas}(R); the blue and red points are HIdominated and H_{2}dominated, respectively. Going from left to right along the xaxis of all panels, the molecular phase becomes more and more important, but the low density gas is mainly atomic. We note how the scatter in the HIdominated regime is much reduced by the conversion from surface to volume densities.
Fig. 6. Upper row: same as Fig. 5b but the points are colourcoded according to the HI fraction; blue and red points come from HI and H_{2} dominated regions, respectively. The VSF law appears tight and straight even if only HIdominated regions are considered. Lower row: VSF law between total gas and SFR. The solid black line is the bestfit relation with slope α and orthogonal intrinsic scatter σ_{⊥} (dashed lines). The grey bands show 1σ and 2σ uncertainties on the fit. In the left panel, ρ_{SFR} is calculated with the constant h_{SFR}, while in the right panel h_{SFR}(R) flares with radius (Eq. (17)). The volume densities radial profiles are shown as contours containing 95% (yellow), 75% (orange), 50% (red), and 25% (dark red) of the data points.

Open with DEXTER
We then looked for a correlation between gas and SFR volume densities in the form of a power law as follows:
The relation is univocally described by the normalisation A and the index α. We sampled the parameters space through the Monte Carlo  Marchov Chain (MCMC) method implemented in the Python package emcee (ForemanMackey et al. 2013). In logarithmic scale, the model is a simple linear relation with slope α and yintercept log A,
We also included an intrinsic scatter, σ_{⊥}, which is orthogonal to the linear relation. We left slope, yintercept, and scatter as free parameters in the Bayesian fit (see Appendix F for details). The case with constant h_{SFR} and that with flaring h_{SFR}(R) were studied separately. The bestfit parameters are reported in Table 3; we found a slope of about 1.3 with h_{SFR} = 100 pc and about 1.9 with the flaring h_{SFR}(R). This means that the slope of the VSF law cannot be univocally determined. However, if the true SFR scale height is between the two extreme choices, it is reasonable to think that also the true slope is between 1.3 and 1.9. The bestfit intrinsic scatter is very small in both cases (σ_{⊥} ≈ 0.1 dex). In Fig. 6b, volume densities appear as contours and the panels show ρ_{SFR} in the constant (left) and the flaring h_{SFR}(R) (right) case. The bestfit relation is represented by the solid black line with the dashed lines showing ±σ_{⊥}. In order to test the robustness of our results, we tried alternative formulations for h_{SFR}(R) as a function of the gas scale heights (e.g. harmonic mean) but the bestfit relations were compatible with those reported in Table 3 within the scatter of the VSF law.
MCMC bestfit parameters of VSF laws.
The high volume density regime above 0.1 M_{⊙} pc^{−3} is the less sampled part of the plot and the scatter seems to increase there. Indeed, these points come from the innermost and H_{2}dominanted regions of massive galaxies, where the α_{CO} factor probably acts as an additional source of uncertainty on the surface density measurement. In particular, Sandstrom et al. (2013) discussed the reliability of their estimate of the α_{CO} in the inner regions of galaxies, as they found that it is lower than the MW value and also well below the galaxy average. Out of a total of about 400 volume densities for our 12 galaxies, the H_{2} fraction of only 25 points at most may be underestimated, so it is unlikely that our results would be influenced. As further test of the effect of α_{CO} on the best fit, we repeated the whole procedure, including the scale heights calculation, using the H_{2} surface densities of Leroy et al. (2008), which were obtained assuming the MW α_{CO} for all the galaxies. We found α = 1.03 ± 0.03 and σ_{⊥} = 0.21 ± 0.01 in the case with the constant h_{SFR} and α = 1.56 ± 0.03 and σ_{⊥} = 0.28 ± 0.01 with h_{SFR}(R), which is compatible with the relation in Fig. 6b.
5.2. Atomic gas versus star formation rate
We then investigated if some correlation exists between SFR and gas in the atomic phase. In Sect. 2.5.2, the flaring h_{SFR}(R) is defined as the weighted mean between h_{HI} and h_{H2} according to the gas fractions. Given that only the atomic gas is considered in this case, the SFR flaring scale height is assumed equal to the HI scale height, while the constant h_{SFR} remains 100 pc as in Sect. 5.1. Figure 7a compares the correlations between HI and SFR based on surface or volume densities, the points are colourcoded according to the HI fraction with respect to the total amount of gas (as in Fig. 6a). As expected, we found no correlation in the surfacebased panel (left), as one order of magnitude in range of HI surface density corresponds to almost four orders of magnitude in range of SFR surface densities. On the other hand, a tight correlation emerges using the volume densities. The implications of this remarkable result are discussed in Sect. 6.
Fig. 7. Upper row: same as Fig. 6a but with the xaxis showing the HI alone surface and volume densities. Lower row: VSF law between SFR and HI volume densities. See Fig. 6b for description.

Open with DEXTER
To determine the HI VSF law parameters, we followed the same procedure as in Sect. 5.1, but we defined the model in the MCMC fitting (see Appendix F for details) as
We found the slope and the intrinsic scatter, respectively, between 2.1 and 2.8 and 0.15 dex and 0.13 dex, depending on the choice of h_{SFR}. This result indicates a strong link between SF and the atomic gas, in particular in low density environments, where the HI disc is considerably thick. Figure 7b shows the volume density data points as contours and the bestfit relation ±σ_{⊥} is represented by the solid black line. For completeness, we compared this correlation with that obtained with the h_{SFR}(R) for the case with total gas (instead of h_{SFR}(R) = h_{HI}(R)), finding no significant difference between the results in the two cases.
5.3. Molecular gas versus star formation rate
Let us now focus on the correlation between the SFR and the molecular gas phase. In this case the flaring SFR scale height is equal to h_{H2}. Figure 8a compares the correlations between H_{2} and SFR surface and volume densities with the points coloured according to the HI fraction with respect to the total amount of gas. As expected, there is a clear sign of some H_{2}SFR correlation in all the three panels, but the volumetric relations appear to be more scattered than both the total gasSFR and the HISFR VSF laws. In addition, it seems that the molecular correlation is no more valid in the low density regime or that it is not a single power law. Indeed, there are hints of a bend both in the surface and volume density plots located at about 1 M_{⊙} pc^{−2} and 0.01 M_{⊙} pc^{−3}, respectively, where the environment is no more H_{2}dominated (see Sect. 6 for discussion).
Fig. 8. Upper row: same as Fig. 6a but with the xaxis showing the H_{2} alone surface and volume densities. Lower row: VSF law between SFR and H_{2} volume densities. See Fig. 6b for description.

Open with DEXTER
Again, we performed an MCMC fitting to determine the parameters of the H_{2}SFR VSF law, which was modelled as
We found that the slope is between 0.5 and 0.7 but, in this case, the intrinsic scatter is 0.3–0.4 dex, so two times larger than the previous cases with the total and atomic gas. Figure 8b shows the volume density data points as contours and the bestfit relation as the solid black line. As in Sect. 5.2, we tested the case with the h_{SFR}(R) for total gas (instead of h_{SFR}(R)=h_{H2}(R)) and found no significant difference between the results.
We could argue that the molecular gas VSF law may be sensitive to the possible underestimate of the α_{CO} factor (see Sandstrom et al. 2013), as there are fewer ρ_{H2} points than those of ρ_{gas}. However, given the scatter of the relation in Fig. 8b, it is unlikely that shifting rightward 25 points out of a total of 249 could affect the bestfit parameters significantly. As further test of the influence of α_{CO} on the VSF laws parameters, we repeated the entire procedure and the MCMC fit using the molecular gas surface densities of Leroy et al. (2008). We found γ = 0.60 ± 0.03 and γ = 0.95 ± 0.03 with the constant h_{SFR} and h_{SFR}(R), respectively, and σ_{⊥} = 0.60 ± 0.03 in both cases, which is fully compatible within the uncertainties with the relation shown in Fig. 8b.
To quantitatively compare the molecular VSF law with its surfacebased version (e.g. Bigiel et al. 2008), we used an MCMC fitting on the H_{2} surface densities leaving the slope, the yintercept and σ_{⊥} free. The resulting bestfit relation is flatter than a linear correlation; indeed the slope is 0.62. However σ_{⊥} is 0.3, so the molecular surfacebased relation is more scattered than both the total gas and the HI VSF laws. Probably, the reason why we find a different slope with respect to the unitary value estimated by some authors (e.g. Bigiel et al. 2008) is the α_{CO} factor, as the linear relation is usually obtained using the MW α_{CO} factor for all the galaxies. If we fix the slope to 1 and repeat the fit, the resulting scatter is even larger, about 0.4 dex. The latter is compatible with the intrinsic scatter of the molecular VSF law (0.25–0.37 dex), thus the volumebased approach does not improve the scatter significantly with respect to the surfacebased relation. Indeed, the molecular gas distribution typically extends to smaller radii with respect to the atomic gas distribution (Fig. 4). This means that the scale height at the outermost radius where the H_{2} is measured is only slightly higher than that at the innermost radii. Hence, the conversion to volume densities through the scale height has typically a much milder effect on the molecular gas distribution with respect to the atomic gas. Moreover, the α_{CO} factor is a further source of scatter in the H_{2}SFR relation which cannot be reduced by our method.
6. Discussion
6.1. Comparison with other works on gas and star scale heights
The thickness of gaseous and stellar discs in galaxies has been studied for years using both theoretical and observational approaches. For example, our method is very similar to that implemented by Banerjee et al. (2011). They calculated the atomic gas scale heights for DDO 154 and IC 2574 through an iterative algorithm based on the hydrostatic equilibrium. The parametric mass models of DDO 154 and IC 2574 were taken from de Blok et al. (2008) and Oh et al. (2008), thus the first is equal to the model in Table 2 and the second does not differ significantly. These works adopted the velocity dispersion measured by Tamburro et al. (2009) using the 2D method on THINGS data cubes. In order to directly compare the scale heights, we must verify that Banerjee et al. (2011) velocity dispersion is the same as we measured. For DDO 154, they assumed σ_{HI} = 8 km s^{−1} and constant with radius, so that their outermost scale height (R≈ 6 kpc) is about 1 kpc. Within uncertainties, their result is compatible with our scale height at 6 kpc, which is 1.4 kpc as our velocity dispersion is about 10 km s^{−1} (25%) higher. For IC 2574, the declining radial profile of the velocity dispersion assumed by Banerjee et al. (2011) is 20% lower everywhere than that shown in Fig. 2. The resulting scale height profiles are perfectly compatible within the errors.
Recently, Patra (2018) estimated the scale heights of the HI and H_{2} discs in hydrostatic equilibrium for NGC 7331. The gravitational potential model was taken from de Blok et al. (2008), therefore it is similar to that reported in Table 2. There are two differences from our method. The first is that the Patra (2018) stellar disc was assumed to be in “hydrostatic equilibrium”, so the stellar scale height was derived iteratively as for the gas components. The second difference is that the author assumed the velocity dispersion to be constant with radius. As a consequence, the comparison is not straightforward but, for σ_{HI} = 10 km s^{−1}, Patra (2018) found h_{HI} ≈ 230 pc at R = 10 kpc, which is compatible with our result of about 400 pc at same radius but with σ_{HI} = 20 km s^{−1}.
None of the galaxies in our sample are edgeon, so an accurate direct measurement of the gas disc thickness is not possible. However, there are several observational clues that gas discs flares with radius; we give just two recent examples. Yim et al. (2011, 2014) adopted the method proposed by Olling (1996) to measure simultaneously the inclination of the galaxy and the thickness of stellar and gaseous discs. For four starforming nearby galaxies, they found that both the thicknesses of the atomic gas disc (see also Peters et al. 2017) and stellar disc flare with radius. They also derived the thickness of the CO disc finding clear signs of the flaring for NGC 891, while the CO flare was not clearly visible for the other galaxies, given the larger uncertainties.
In the MW, Marasco et al. (2017) measured the scale height of HI and H_{2} vertical distributions and found that the HI scale height increases of a factor 2 from about 100 pc at R ≈ 2.5 kpc to about 200 pc in the solar neighbourhood. The molecular gas scale height was instead found to be nearly constant with radius, given the large associated uncertainties.
Concerning the SFR scale height, if our assumption is correct and the scale height of SFR flares with radius, we should observe that the thickeness of the disc of young stellar populations in galaxies increases with radius, at least in the outskirts. Mackereth et al. (2017) used SDSSAPOGEE survey data to decompose the MW stellar disc according to age, metallicity, and [α/Fe], and analysed the radial and vertical distributions the different populations. They found that the scale height of young populations, which have mainly high metallicity and low [α/Fe], flares with radius (see also Xiang et al. 2018). On the other hand, the scale height of old stars, which tend to have high [α/Fe] and low metallicity, is higher but radially flatter than that of the young populations.
6.2. Comparison with other works on volumebased SF laws
Other authors investigated the existence of a volumetric relation. The first VSF law was proposed by Schmidt (1959), who linked the HI and SFR through a single power law with slope between 2 and 3. Hence, we should compare his result with our VSF law with HI alone. Interestingly, the bestfit slope found in Sect. 5.2 is perfectly compatible with Schmidt’s estimate, suggesting the existence of a universal correlation involving the atomic phase of gas.
Abramova & Zasov (2008) is probably the work most similar to ours. For a sample of seven galaxies (including the MW), they calculated the HI and the H_{2} scale heights assuming hydrostatic equilibrium (see also Narayan & Jog 2002) and then converted the azimuthally averaged surface density radial profiles to volume densities. For the SFR scale height, they tried two approaches: one assumed a constant scale height and the other used the stellar disc thickness. However, they neglected the radial decrease of the velocity dispersion for the gas components, which is the most significant difference with our approach. They found that the gas and SFR volume densities are better correlated with respect to the surface densities, but the slope of the volumetric relation for their galaxies has large variations between 0.8 and 2.4, which are on average close to 1.5. They drew the same result for the molecular gas alone with average slope was close to 1. Given the significant difference between the slope of SF laws for single galaxies, they concluded there was an absence of a universal relation. This is probably due to the assumption of radially constant velocity dispersion profiles; our result is however in agreement within the uncertainties with their average slope of 1.5.
More recently, Barnes et al. (2012) studied the link between gas and SFR in the outer disc of seven nearby starforming galaxies. They found a very steep surfacebased SF law in the form of a single power law with index 2.8 ± 0.3. Then, they estimated the HI disc thickness through the full width at half maximum (FWHM) of the gas vertical profile (Eq. (20) in van der Kruit & Freeman 2011), finding that this thickness flares with radius. They used this proxy to convert the total gas surface densities radial profiles to volume densities and assumed 100 pc as fiducial value for the SFR scale height. They found a volumebased correlation with index 1.5 ± 0.1 between gas and SFR, which is in agreement with our result (see Tenjes & Haud 1991 for a similar study on M31).
Concerning Galactic studies, Sofue (2017) used 3D maps of HI from the LAB survey (Kalberla et al. 2005) and H_{2} from the CO survey (Dame et al. 2001) to estimate the gas volume densities out to 20 kpc. Sofue (2017) measured the SFR volume density from the HII region catalogue and investigated the existence of volumetric correlations with total gas, HI only, and H_{2} only. The author used two approaches: the first consists in dividing the data in radial bins, while the second considers the whole radial range (0–20 kpc). In the first case, they found that any VSF law showed radial variations both in the index and the normalisation. On the other hand, the second method revealed a correlation with index of 2.01 ± 0.02 for the VSF law with total gas, while the relations involving the molecular and the atomic gas only were found to have a slope of 0.70 ± 0.07 and of 2.29 ± 0.03, respectively. These results are in excellent agreement with our findings.
Krumholz et al. (2012) formulated a theory involving a molecular and volumetric SF law and compared it to the observed correlations. They gathered a collection of the correlations between gas and SFR using both resolved observations of MW molecular clouds and Local galaxies, and unresolved observations of local discs and high redshift starbursts. These authors explained the diversity of the observed gasSFR correlations as the result of the variety of threedimentional sizes and internal clumpiness, as the volume of the observed region can be very different at fixed surface density. Hence, they removed these projection effects by calculating the freefall time specifically for each different regime, from molecular clouds to high redshift galaxies, and found that all the data fall on a single powerlaw relation. In other words, they did not convert the surface densities to volume densities, but they instead built the freefall timescale using a different prescription for molecular clouds, disc galaxies, and starbursts, obtaining a correlation between Σ_{SFR} and Σ_{gas}/t_{ff}. However, the approach of Krumholz et al. (2012) differs from ours in many aspects. For example, they assumed that the starforming gas is exclusively molecular, so the freefall time is always calculated for the molecular phase. In addition, they did not take into account the vertical hydrostatic equilibrium for the gas and neglected the scale height flaring with radius.
6.3. Physical interpretation
We conclude by discussing some potential physical interpretations of our findings, starting from the most straightforward. In order to form stars, the gas must be cold and dynamically unstable, therefore the SF timescale is given by the longest between the dynamical and cooling timescales (see e.g. Ciotti & Ostriker 2007). A key result of our investigation is the superlinear correlation between the SFR and total gas volume densities in the form of a single power law. If we believe that the true SFR scale height is bracketed between the constant and the flaring profiles, the index of the VSF law with total gas should reasonably be between the bestfits slopes of 1.3 and 1.9. If the index is 1.5, then the physical explanation of the correlation may come from the gravitational instability of the gas, indicating that the cooling timescale is shorter than the dynamical timescale. Hence, (e.g. Madore 1977; Li et al. 2006). On the other hand, it is well known that the interstellar medium is not a continuous fluid, but it is mostly in gas clouds and filaments, therefore this interpretation of the global correlation may be not suitable to describe SF on the scales of single clouds. However, our results appear to indicate that the average SFR density at different locations in a galaxy disc is rather precisely regulated by the total volume density of the locally available gas.
Moreover, the fact that the observed break in the Kennicutt law disappears after the conversion to volume densities indicates that it is probably caused by the flaring of the gas disc. This was also suggested by Elmegreen (2015), who aimed to explain the change in the index of the surfacebased SF laws. He showed that the classical Kennicutt law between total gas and SFR surface densities is valid in the main regions of spiral galaxies, where he assumed that the scale height is almost constant. In the outskirts instead, he found a steeper index of 2 for the surfacebased law, as the gas disc thickness increases with radius. However, the DM contribution was not included in the model of the galactic gravitational potential, thus the gas is completely selfgravitating in the outer regions and the resulting gas scale height is overestimated.
The tight correlation between the atomic gas and the SFR is the most surprising result of our work. In this case, the interpretation is more difficult and uncertain. If the molecular gas is the prerequisite for SF, why should we observe a correlation between HI and SFR? It is well known that the molecular gas forms from atomic gas, so the possible explanation for the HI VSF law is that the atomic gas is a good tracer of the cold (and molecular) starforming gas both in low density and, to some extent, high density regions. Indeed, the outskirts of spiral galaxies and dwarf galaxies are often metal poor and low density environments, hence the amount of CO is probably too low to be detected. This scenario could explain the observed extended UV discs (XUV; Thilker et al. 2007a,b), showing that SF can occur also in the outermost and HIdominated regions of disc galaxies (see also Ferguson et al. 1998), where the metallicity is expected to be very low.
Taken to extremes, the HI VSF law could also mean that molecular gas is not always a prerequisite for SF and the atomic gas plays a key role in the process. Krumholz (2012) showed that SF can occur in cold atomic gas (at extremely low metallicity) rather than in molecular gas, thanks to the efficient cooling by C^{+}. In such peculiar conditions, the timescale to convert HI to H_{2} is longer than the timescales to reach the thermal equilibrium (cooling time) and gravitational collapse (freefall time). Hence, atomic gas can efficiently cool and form stars, but it does not have enough time to turn into a significant amount of H_{2}. Similarly, Glover & Clark (2012) investigated whether or not the molecular gas is essential for SF. They performed a set of numerical simulations of dense clouds using different chemical prescriptions: one in which the gas remains atomic for the whole cloud evolution, a second including H_{2} formation, and a third following both H_{2} and CO formation. They found that the SF process is very similar in all the simulations and concluded that the molecular gas is not a prerequisite for SF, as the gas can efficiently cool thanks to C^{+} line emission at low density and by energy transfer from gas to dust at high density. On the contrary, they found that including or not the dust shielding is fundamental, as it allows the gas to cool below 100 K and form stars. In other words, the ability of clouds to shield themselves from the interstellar radiation field is the key to SF. Moreover, the authors concluded that the observed correlation between the molecular gas and SFR surface densities originates from the fact that both the terms correlate with a third factor, which is the clouds ability to selfshield (see also Krumholz & Thompson 2007).
Concerning the H_{2} VSF law, the interpretation is even more difficult, as the estimate of the molecular gas volume density is problematic. This correlation seems to hold for the central parts of galaxies, despite the large uncertainties associated with the α_{CO} factor, velocity dispersion, and bulge potential. Probably, the interplay of these factors causes the large scatter of the molecular VSF law. However the surface density law has a similar scatter. The molecular gas is mostly in giant molecular clouds, but we are not including any clouds filling factor in our study. Thus, the volume density that we calculate is simply a mean value in a region of Δz ≈ h_{H2} perpendicular to the midplane, so our estimate of the volume density is very different from the volume density inside a cloud. This could explain why the molecular gas volume densities reach values lower than 10^{−3} M_{⊙} pc^{−3}, which corresponds to about 10^{−2} H_{2} particles per cm^{3}.
It is interesting to compare our results with the recent work by Catinella et al. (2018). They presented the extended GALEX Arecibo SDSS Survey (xGASS), a census of 1179 galaxies selected by stellar mass (10^{9} M_{⊙} < M_{⋆} < 10^{11.5} M_{⊙}) and redshift (0.01 < z < 0.05). They measured stellar masses, SFRs, and HI masses for all the galaxies and H_{2} masses for 532 galaxies. They found that the gas reservoir in galaxies is on average HIdominated, while the ratio of the HI to H_{2} masses slightly increases with increasing stellar mass. Moreover, for the whole mass range, the HI mass tightly correlates with the dustunobscured SFR traced by nearultraviolet – r colour. In light of these results, our correlation between HI and SFR volume densities is not surprising.
The tight VSF law between total gas and SFR corroborates the idea that the whole gas, including the atomic phase, traces SF in galaxies. Then, the HI and H_{2} VSF laws could help in understanding the mechanism of the conversion of atomic gas to molecular gas and how important this is in the whole SF process.
7. Summary and conclusions
We investigated the existence of a fundamental SF law based on volume densities of gas and SFR. We built VSF laws using the volume densities radial profiles calculated from the surface densities profiles of 12 nearby galaxies. To make the conversion to volume densities possible, we assumed the hydrostatic equilibrium and calculated the HI, H_{2}, and SFR scale heights, which required two preliminary steps: the first to calculate the total gravitational potential and the second to measure the gas velocity dispersion. Using volume densities, we found a correlation between the total gas (HI+H_{2}) and the SFR, which is less scattered than the classical surfacebased law. Moreover, an unexpected and tight relation between HI and SFR volume densities was discovered, suggesting a profound link between the atomic phase of gas in galaxies and SF. The H_{2}only version of the VSF law was found to have a larger scatter with respect to the HIonly and total gas relations, it seems to break down in low density and HIdominated environments.
Hence, our conclusions are the following.

The thickness of gas discs in hydrostatic equilibrium shows a significant flaring with radius, regardless of the galaxy type. This means that assuming a constant scale height for gaseous discs is not a good approximation.

The total gas and the SFR volume densities are linked by a tight and single power law with index between 1.3 and 1.9, depending on whether a flare in the SFR scale height itself is taken into account or not.

The break observed in the Kennicutt law may not be indicative of a low SF efficiency of atomic gas at low surface density, but rather be a consequence of the radial flaring of the gas discs.

The SFR volume density also correlates with the HI alone volume density through a single power law with small scatter and index between 2.1 and 2.8.
The VSF law is likely more fundamental and general than surfacebased laws, as it takes into account the threedimensional distribution of gas and SFR. The unexpected and tight correlation between HI and SFR volume densities may be important to unveil the mechanisms that regulate the conversion of gas into stars, in particular in low density and HIdominated environments as dwarf galaxies and the outskirts of spiral galaxies.
In dwarf galaxies, the asymmetricdrift correction should be included in the determination of the rotation curve. However, Iorio et al. (2017) showed that its contribution is negligible in the case of DDO 154, which is the least massive galaxy in our sample.
Acknowledgments
C.B. is grateful to A. Marasco, L. Posti, M. Nori, V. Ghirardini, and E. di Teodoro for inspiring conversations and advice, and to Bradley Frank for sharing the surfaced density profiles of molecular gas. G.I. is supported by the Royal Society Newton International Fellowship. G.P. acknowledges support by the Swiss National Science Foundation, grant PP00P2_163824.
References
 Abramova, O. V., & Zasov, A. V. 2008, Astron. Rep., 52, 257 [NASA ADS] [CrossRef] [Google Scholar]
 Bahcall, J. N. 1984, ApJ, 276, 156 [NASA ADS] [CrossRef] [Google Scholar]
 Bahcall, J. N., & Casertano, S. 1984, ApJ, 284, L35 [NASA ADS] [CrossRef] [Google Scholar]
 Banerjee, A., Jog, C. J., Brinks, E., & Bagetakos, I. 2011, MNRAS, 415, 687 [NASA ADS] [CrossRef] [Google Scholar]
 Barnes, K. L., van Zee, L., Côté, S., & Schade, D. 2012, ApJ, 757, 64 [NASA ADS] [CrossRef] [Google Scholar]
 Bigiel, F., Leroy, A., Walter, F., et al. 2008, AJ, 136, 2846 [NASA ADS] [CrossRef] [Google Scholar]
 Bigiel, F., Leroy, A., Walter, F., et al. 2010, AJ, 140, 1194 [NASA ADS] [CrossRef] [Google Scholar]
 Binney, J., & Tremaine, S. 2008, Galactic Dynamics, 2nd edn. (Princeton: Princeton University Press) [Google Scholar]
 Boissier, S., Prantzos, N., Boselli, A., & Gavazzi, G. 2003, MNRAS, 346, 1215 [NASA ADS] [CrossRef] [Google Scholar]
 Bolatto, A. D., Leroy, A. K., Jameson, K., et al. 2011, ApJ, 741, 12 [NASA ADS] [CrossRef] [Google Scholar]
 Bolatto, A. D., Wong, T., Utomo, D., et al. 2017, ApJ, 846, 159 [NASA ADS] [CrossRef] [Google Scholar]
 Boomsma, R., Oosterloo, T. A., Fraternali, F., van der Hulst, J. M., & Sancisi, R. 2008, A&A, 490, 555 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 CaldúPrimo, A., Schruba, A., Walter, F., et al. 2013, AJ, 146, 150 [NASA ADS] [CrossRef] [Google Scholar]
 Catinella, B., Saintonge, A., Janowiecki, S., et al. 2018, MNRAS, 476, 875 [NASA ADS] [CrossRef] [Google Scholar]
 Ciotti, L., & Ostriker, J. P. 2007, ApJ, 665, 1038 [NASA ADS] [CrossRef] [Google Scholar]
 Dame, T. M., Hartmann, D., & Thaddeus, P. 2001, ApJ, 547, 792 [NASA ADS] [CrossRef] [Google Scholar]
 de Blok, W. J. G., Walter, F., Brinks, E., et al. 2008, AJ, 136, 2648 [NASA ADS] [CrossRef] [Google Scholar]
 DessaugesZavadsky, M., Verdugo, C., Combes, F., & Pfenniger, D. 2014, A&A, 566, A147 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Di Teodoro, E. M., & Fraternali, F. 2015, MNRAS, 451, 3021 [NASA ADS] [CrossRef] [Google Scholar]
 Elmegreen, B. G. 2015, ApJ, 814, L30 [NASA ADS] [CrossRef] [Google Scholar]
 Ferguson, A. M. N., Wyse, R. F. G., Gallagher, J. S., & Hunter, D. A. 1998, ApJ, 506, L19 [NASA ADS] [CrossRef] [Google Scholar]
 ForemanMackey, D., Hogg, D. W., Lang, D., & Goodman, J. 2013, PASP, 125, 306 [NASA ADS] [CrossRef] [Google Scholar]
 Frank, B. S., de Blok, W. J. G., Walter, F., Leroy, A., & Carignan, C. 2016, AJ, 151, 94 [NASA ADS] [CrossRef] [Google Scholar]
 Fraternali, F., van Moorsel, G., Sancisi, R., & Oosterloo, T. 2002, AJ, 123, 3124 [NASA ADS] [CrossRef] [Google Scholar]
 Gentile, G., Fraternali, F., Klein, U., & Salucci, P. 2003, A&A, 405, 969 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 de Gil Paz, A., Boissier, S., & Madore, B. F. 2007, ApJS, 173, 185 [NASA ADS] [CrossRef] [Google Scholar]
 Glover, S. C. O., & Clark, P. C. 2012, MNRAS, 421, 9 [NASA ADS] [Google Scholar]
 Helfer, T. T., Thornley, M. D., Regan, M. W., et al. 2003, ApJS, 145, 259 [NASA ADS] [CrossRef] [Google Scholar]
 Heyer, M. H., Corbelli, E., Schneider, S. E., & Young, J. S. 2004, ApJ, 602, 723 [NASA ADS] [CrossRef] [Google Scholar]
 Hunter, D. A., Elmegreen, B. G., & Baker, A. L. 1998, ApJ, 493, 595 [NASA ADS] [CrossRef] [Google Scholar]
 Ianjamasimanana, R., de Blok, W. J. G., & Heald, G. H. 2017, AJ, 153, 213 [NASA ADS] [CrossRef] [Google Scholar]
 Iorio, G. 2018, PhD Thesis, University of Bologna, Italy [Google Scholar]
 Iorio, G., Fraternali, F., Nipoti, C., et al. 2017, MNRAS, 466, 4159 [NASA ADS] [Google Scholar]
 Kalberla, P. M. W., Burton, W. B., Hartmann, D., et al. 2005, A&A, 440, 775 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kennicutt, Jr., R. C. 1989, ApJ, 344, 685 [NASA ADS] [CrossRef] [Google Scholar]
 Kennicutt, Jr., R. C. 1998, ApJ, 498, 541 [NASA ADS] [CrossRef] [Google Scholar]
 Kennicutt, Jr., R. C., Armus, L., Bendo, G., et al. 2003, PASP, 115, 928 [NASA ADS] [CrossRef] [Google Scholar]
 Kennicutt, Jr., R. C., Calzetti, D., Walter, F., et al. 2007, ApJ, 671, 333 [NASA ADS] [CrossRef] [Google Scholar]
 Koda, J. 2008, ASP Conf. Ser., 396, 97 [NASA ADS] [Google Scholar]
 Koyama, H., & Ostriker, E. C. 2009, ApJ, 693, 1346 [NASA ADS] [CrossRef] [Google Scholar]
 Krumholz, M. R. 2012, ApJ, 759, 9 [NASA ADS] [CrossRef] [Google Scholar]
 Krumholz, M. R. 2014, Phys. Rep., 539, 49 [NASA ADS] [CrossRef] [Google Scholar]
 Krumholz, M. R., & Thompson, T. A. 2007, ApJ, 669, 289 [NASA ADS] [CrossRef] [Google Scholar]
 Krumholz, M. R., Dekel, A., & McKee, C. F. 2012, ApJ, 745, 69 [NASA ADS] [CrossRef] [Google Scholar]
 Lada, C. J., Lombardi, M., & Alves, J. F. 2010, ApJ, 724, 687 [NASA ADS] [CrossRef] [Google Scholar]
 Larson, R. B. 1981, MNRAS, 194, 809 [NASA ADS] [CrossRef] [Google Scholar]
 Lelli, F., McGaugh, S. S., & Schombert, J. M. 2016, AJ, 152, 157 [NASA ADS] [CrossRef] [Google Scholar]
 Leroy, A., Bolatto, A. D., Simon, J. D., & Blitz, L. 2005, ApJ, 625, 763 [NASA ADS] [CrossRef] [Google Scholar]
 Leroy, A. K., Walter, F., Brinks, E., et al. 2008, AJ, 136, 2782 [NASA ADS] [CrossRef] [Google Scholar]
 Leroy, A. K., Walter, F., Sandstrom, K., et al. 2013, AJ, 146, 19 [NASA ADS] [CrossRef] [Google Scholar]
 Li, Y., Mac Low, M.M., & Klessen, R. S. 2006, ApJ, 639, 879 [NASA ADS] [CrossRef] [Google Scholar]
 Mackereth, J. T., Bovy, J., Schiavon, R. P., et al. 2017, MNRAS, 471, 3057 [NASA ADS] [CrossRef] [Google Scholar]
 Madore, B. F. 1977, MNRAS, 178, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Marasco, A., Fraternali, F., & Binney, J. J. 2012, MNRAS, 419, 1107 [NASA ADS] [CrossRef] [Google Scholar]
 Marasco, A., Fraternali, F., van der Hulst, J. M., & Oosterloo, T. 2017, A&A, 607, A106 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Martin, C. L., & Kennicutt, Jr., R. C. 2001, ApJ, 555, 301 [NASA ADS] [CrossRef] [Google Scholar]
 Mogotsi, K. M., de Blok, W. J. G., CaldúPrimo, A., et al. 2016, AJ, 151, 15 [NASA ADS] [CrossRef] [Google Scholar]
 Narayan, C. A., & Jog, C. J. 2002, A&A, 394, 89 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Narayanan, D., Krumholz, M. R., Ostriker, E. C., & Hernquist, L. 2012, MNRAS, 421, 3127 [NASA ADS] [CrossRef] [Google Scholar]
 Navarro, J. F., Frenk, C. S., & White, S. D. M. 1996, ApJ, 462, 563 [NASA ADS] [CrossRef] [Google Scholar]
 Oh, S.H., de Blok, W. J. G., Walter, F., Brinks, E., & Kennicutt, Jr., R. C. 2008, AJ, 136, 2761 [NASA ADS] [CrossRef] [Google Scholar]
 Olling, R. P. 1995, AJ, 110, 591 [NASA ADS] [CrossRef] [Google Scholar]
 Olling, R. P. 1996, AJ, 112, 457 [NASA ADS] [CrossRef] [Google Scholar]
 Patra, N. N. 2018, MNRAS, 478, 4931 [NASA ADS] [CrossRef] [Google Scholar]
 Peters, S. P. C., van der Kruit, P. C., Allen, R. J., & Freeman, K. C. 2017, MNRAS, 464, 32 [NASA ADS] [CrossRef] [Google Scholar]
 Ponomareva, A. A., Verheijen, M. A. W., Peletier, R. F., & Bosma, A. 2017, MNRAS, 469, 2387 [NASA ADS] [CrossRef] [Google Scholar]
 Posti, L., Fraternali, F., Di Teodoro, E. M., & Pezzulli, G. 2018, A&A, 612, L6 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Romeo, A. B. 1990, PhD Thesis, SISSA, Trieste, Italy [Google Scholar]
 Romeo, A. B. 1992, MNRAS, 256, 307 [NASA ADS] [CrossRef] [Google Scholar]
 Romeo, A. B., & Mogotsi, K. M. 2017, MNRAS, 469, 286 [NASA ADS] [CrossRef] [Google Scholar]
 Roychowdhury, S., Huang, M.L., Kauffmann, G., Wang, J., & Chengalur, J. N. 2015, MNRAS, 449, 3700 [NASA ADS] [CrossRef] [Google Scholar]
 Sandstrom, K. M., Leroy, A. K., Walter, F., et al. 2013, ApJ, 777, 5 [NASA ADS] [CrossRef] [Google Scholar]
 Sarkar, S., & Jog, C. J. 2018, A&A, 617, A142 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Schaye, J. 2004, ApJ, 609, 667 [NASA ADS] [CrossRef] [Google Scholar]
 Schmidt, M. 1959, ApJ, 129, 243 [NASA ADS] [CrossRef] [Google Scholar]
 Schruba, A., Leroy, A. K., Walter, F., et al. 2011, AJ, 142, 37 [NASA ADS] [CrossRef] [Google Scholar]
 Sérsic, J. L. 1963, BAAA, 6, 41 [NASA ADS] [Google Scholar]
 Sicking, F. J. 1997, PhD Thesis, University of Groningen, The Netherlands [Google Scholar]
 Sofue, Y. 2017, MNRAS, 469, 1647 [NASA ADS] [CrossRef] [Google Scholar]
 Swaters, R. A. 1999, PhD Thesis, Rijksuniversiteit Groningen, The Netherlands [Google Scholar]
 Tamburro, D., Rix, H.W., Leroy, A. K., et al. 2009, AJ, 137, 4424 [NASA ADS] [CrossRef] [Google Scholar]
 Tenjes, P., & Haud, U. 1991, A&A, 251, 11 [NASA ADS] [Google Scholar]
 Thilker, D. A., Bianchi, L., Meurer, G., et al. 2007a, ApJS, 173, 538 [NASA ADS] [CrossRef] [Google Scholar]
 Thilker, D. A., Boissier, S., Bianchi, L., et al. 2007b, ApJS, 173, 572 [NASA ADS] [CrossRef] [Google Scholar]
 Toomre, A. 1964, ApJ, 139, 1217 [NASA ADS] [CrossRef] [Google Scholar]
 van Albada, T. S., Bahcall, J. N., Begeman, K., & Sancisi, R. 1985, ApJ, 295, 305 [NASA ADS] [CrossRef] [Google Scholar]
 van der Kruit, P. C., & Freeman, K. C. 2011, ARA&A, 49, 301 [NASA ADS] [CrossRef] [Google Scholar]
 van der Kruit, P. C., & Searle, L. 1981a, A&A, 95, 105 [NASA ADS] [Google Scholar]
 van der Kruit, P. C., & Searle, L. 1981b, A&A, 95, 105 [NASA ADS] [Google Scholar]
 Walter, F., Brinks, E., de Blok, W. J. G., et al. 2008, AJ, 136, 2563 [NASA ADS] [CrossRef] [Google Scholar]
 Wilson, C. D., Warren, B. E., Irwin, J., et al. 2011, MNRAS, 410, 1409 [NASA ADS] [Google Scholar]
 Wong, T., & Blitz, L. 2002, ApJ, 569, 157 [NASA ADS] [CrossRef] [Google Scholar]
 Xiang, M., Shi, J., & Liu, X. 2018, ApJS, 237, 33 [NASA ADS] [CrossRef] [Google Scholar]
 Yim, K., & van der Hulst, J. M. 2016, MNRAS, 463, 2092 [NASA ADS] [CrossRef] [Google Scholar]
 Yim, K., Wong, T., Howk, J. C., & van der Hulst, J. M. 2011, AJ, 141, 48 [NASA ADS] [CrossRef] [Google Scholar]
 Yim, K., Wong, T., Xue, R., et al. 2014, AJ, 148, 127 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: VSF law using the analytical approximation for the scale height
In Sect. 2.4, we reported an analytic approximation (Eq. (13)) for the scale height of the vertical distribution of a gas disc in hydrostatic equilibrium (see Romeo 1990, 1992 for a rigorous analytic study of the vertical structure of galactic discs). We now show that the results obtained through this definition are compatible with what we have found using the numerical (and more accurate) method. Through the Poisson equation of gravity in the z direction, we know that
In the midplane, , where V_{c} is the galaxy circular velocity. Hence, the r.h.s. of Eq. (A.1) is
where the rotational density ρ_{rot} is (see Bahcall 1984; Bahcall & Casertano 1984; Olling 1995)
Substituting Eq. (A.2) in Eq. (13), we find the following simple and generic analytical formulation for the scale height that can be used once the mass distribution of the galaxy components are known:
We note that, with this approximation, the gas selfgravity is not included and we are assuming a cylindrical mass distribution which, at fixed R, does not vary with z with respect to its value in the midplane.
For the galaxies in our sample, we assumed that the main mass components are the spherical DM halo and the stellar disc, which are modelled by Eqs. (6) or (7) and 8, respectively. The rotational density for the NFW halo is (with x = R/R_{s})
For the isothermal halo, we have (with )
The exponential disc circular velocity is given by Eq. (2.165) in Binney & Tremaine (2008), so the rotational density is
where k = R/R_{⋆}, A(k/2)=3K_{0}I_{1} + K_{2}I_{1} − 3K_{1}I_{0} − I_{2}K_{1} and B = I_{0}K_{0} − I_{1}K_{1} being K_{0}, K_{1}, I_{0}, and I_{1} the modified Bessel functions. The stellar bulge is modelled as an exponential sphere (Eq. (9)) with circular velocity given by Eq. (18), so
Table 2 provides all the parameters to calculate the mass distributions and rotational densities. Figure A.1 compares h_{HI} and h_{H2} calculated through Eq. (A.4) and with GALPYNAMICS, the velocity dispersion is modelled as explained in Sects. 4.1.2 and 4.2.2. For the majority of the galaxies in our sample, the analytical estimate is compatible with the numerical scale height within the uncertainties. Hence, the SFR scale height calculated through Eq. (17) but using the approximated h_{HI} and h_{H2} is approximately equivalent to that shown in Fig. 4.
Then, we use the analytical scale heights to convert the observed surface densities (see Sect. 3.1) to volume densities through Eq. (15). We have therefore all the elements to build the VSF laws and perform an MCMC fitting to derive slope, yintercept and scatter of the VSF laws with total gas, HI only, and H_{2} only. The results are reported in Table A.1 and are compatible within the uncertainties with those in Table 3.
MCMC bestfit parameters for the VSF laws in the analytical approximation for the scale heights.
Fig. A.1. Comparison of the scale heights calculated by Eq. (A.4) (dashed line) and by GALPYNAMICS (solid line). The HI and H_{2} scale heights are in blue and red, respectively.

Open with DEXTER
Appendix B: ^{3D}Barolo setup
As mentioned in Sect. 4.1.2, we derived the HI velocity dispersion using 3DB on publicly available 21 cm data cubes from the survey THINGS. In a broad outline, the tiltedring modelling consists in decomposing the rotating disc of a galaxy into a series of circular rings with radius R and characterised by kinematic and geometrical parameters. For each sampling radius, 3DB first builds a ring model described by inclination, position angle, and rotation velocity, then the model is compared to real data and the parameters of the ring are updated until the residuals between the model and observations are minimised. Before the comparison, the model is convolved with the point spread function (PSF) by degrading it to the same spatial resolution of observations. This step is fundamental to account for the beam smearing, which can affect the determination of the velocity dispersion. Each ring is fully described by the following parameters: the spatial coordinates of the centre (x_{0}, y_{0}), systemic velocity V_{sys}, inclination i, position angle ϕ, rotation velocity V_{rot}, velocity dispersion σ_{HI}, faceon HI column density Σ_{HI}, and scale height of the gas layer z_{0}.
3DB input parameters and characteristics of data cubes.
We used the robust weighted data cubes to ensure a reliable measurement of the line broadening due to the gas turbulence. Indeed, Ianjamasimanana et al. (2017) showed that the shape of the beam of natural weighted data cubes significantly differs from a Gaussian, causing an overestimate of the velocity
dispersion, while the robust weighted data cubes are less affected by this bias. Leroy et al. (2008) measured the surface densities of gas and SFR at resolutions of 400 pc and 800 pc for dwarf galaxies and normal spirals, respectively. For all the galaxies, we aimed to have a common spatial resolution that is not only compatible with their surface density measurements, but also as high as possible to preserve a good sampling of the velocity dispersion radial trend. The most distant galaxy, NGC 2841, was observed at about 400 pc of spatial resolution, and consequently this is our upper limit for homogeneous resolution. Hence, we smoothed all data cubes to the same spatial resolution of about 400 pc to improve the S/N in the data cubes (see Table B.1 for corresponding beam size). Secondarily, this resolution is compatible with the drift scale, which is the displacement between a young star and its parent cloud (see Koda 2008).
In order to set 3DB initial parameters, we made the following assumptions.

HI column density. Σ_{HI} was removed from the list of free parameters choosing one of the two 3DB normalisation methods. It is possible to normalise the model flux to the observed intensity map by a pixelbypixel (local) or azimuthal comparison. The local normalisation better represents the nonaxisymmetric features and prevents underdense or overdense regions from influencing the residuals minimisation. However, the weakness of this choice is that, in some cases, the algorithm is not able to reliably estimate the radial variation of the inclination and thus the output profile for the inclination varies unrealistically. Therefore, it is advisable to set the inclination to a fixed value when using the local normalisation. For this reason, when the S/N in the 400 pc resolution data cube is low (as for the most distant galaxies, NGC 2841, NGC 3198, and NGC 7331), we choose the azimuthal normalisation. The normalisation for each galaxy is reported in Table B.1 (L=local, A=azimuthal). In the vast majority of cases, the assumption on the normalisation does not affected the fit nor the dispersion velocity measurements.

Scale height. 3DB is insensitive to the scale height as the tilted ring fitting procedure is done ringbyring, while for thick discs one line of sight can intersect emission from different annuli because of the projection effects of inclination. Iorio et al. (2017) found that assuming a constant scale height does not significantly affect the estimate of the kinematical parameters in their sample of dwarf galaxies or, at least, these differences are compatible with the errors. The galaxies in our sample are more massive than Iorio et al. (2017) dwarfs, so the thickness bias is expected to be even milder for our galaxies. Following Iorio et al. (2017), we adopted z_{0} = 100 pc, which is smaller than the spatial resolution and constant for each ring.

Systemic velocity. Before fixing V_{sys}, we compared the values reported in de Blok et al. (2008) with the systemic velocity obtained from the global line profile by , where and are the velocities corresponding to the 20% of flux peak for the approaching and receding sides of the galaxy. The results are compatible for all the galaxies except IC 2574. In this case, we found V_{sys} = 44.9 km s^{−1}, which is lower than the 53.1 km s^{−1} estimate by de Blok et al. (2008) but compatible with the measurement with 3DB, so we chose the former.

Galaxy centre. (x_{0}, y_{0}) is fixed to the optical centre coordinates from the NASA/IPAC Extragalactic Database (NED).
Appendix C: Revisited mass model for NGC 7793
Fig. C.1. HI rotation curve of NGC 7793 assuming a flat rotation curve (red points), the errors are of the order of 4–5 km s^{−1}. The solid lines show our mass model: the stellar disc with M/L = 0.5 and the DM contributions are shown in orange and grey, while the resulting total rotation curve is in blue. The green points show the rotation curve measured by de Blok et al. (2008).

Open with DEXTER
The observed HI rotation curve of NGC 7793 has a declining profile in de Blok et al. (2008; green points in Fig. C.1). The authors interpreted this shape as a signature of a maximum stellar disc, but they found relatively low bestfit M/L values of 0.22 or 0.31 depending on the assumed initial mass function. In order to find a reliable mass model, we decided to interpret the declining rotation curve as the result of a small warp in inclination beyond 4 kpc. In practice, we first performed the tiltedring fitting using 3DB to determine a first guess of the rotation curve. Then, we repeated the fit using this rotation curve for the rings at R < 4 kpc but fixing V_{rot} at its peak (121.8 km s^{−1}) for the rings beyond 4 kpc. The resulting bestfit inclination starts to decrease at 4 kpc from about 44° to about 40°. In Fig. C.1, the difference between our rotation curve and that of de Blok et al. (2008) is due to the radial variation of the inclination. Our bestfit inclination is systematically lower than that of de Blok et al. (2008), so our rotation curve tends to be higher. We note that both rotation curves are realistic, but removing the decreasing part allows us to find a parametric mass model for the DM halo that reproduces the observed rotation much better. However, lineofsight warps are notoriously difficult to trace with fitting algorithms (Gentile et al. 2003). To set the mass model parameters, we fixed the M/L ratio of the stellar disc to 0.5 (Lelli et al. 2016) and repeated the isothermal halo fit on the flat rotation curve, leaving ρ_{DM, 0} and r_{c} as free parameters. In Fig. C.1, we show that our model can reproduce the whole rotation curve. For completeness, we checked if the measurement of the velocity dispersion profile is influenced by the assumption of the flat rotation curve beyond 4 kpc. We found a slight offset between the σ_{HI} radial profiles with the flat and declining V_{rot}(R), but the two are fully compatible within the uncertainties.
Appendix D: NGC 2841, an example of the scale height imprint on the velocity dispersion field
Fig. D.1. HI velocity dispersion map of NGC 2841. We note the Xshaped region where σ_{HI} > 15 km s^{−1}; the white ellipses correspond to the R = 15 kpc and R = 30 kpc annuli. The red cross indicates the centre and the red ellipse delimits the gas depleted region. The black dot (lower right) shows the beam size.

Open with DEXTER
In Fig. 2, the velocity dispersion profile of NGC 2841 shows a sudden increase by 10 km s^{−1} between 15 kpc to 30 kpc in radius. An inspection of the velocity dispersion map can help us understand the origin of this feature. In Fig. D.1, the galaxy is coloured according to the velocity dispersion value in each pixel. The red cross shows the centre of the galaxy (Table B.1) and it is surrounded by an HI hole delimited by the red ellipse, which corresponds to an annulus of radius of 3 kpc. The centre of the galaxy is deficient in both HI and H_{2}, as also pointed out by Frank et al. (2016). However, we want to focus on the most prominent feature of the map, which is the yellow Xshaped region with σ_{HI} > 15 km s^{−1} approximately delimited by the white ellipses. This Xshaped feature is typical of thick discs (Sicking 1997; Iorio 2018) and warped galaxies, as it is due to different lineofsight velocities being mixed in projections along selected directions. Therefore, the azimuthal average in these regions is biased towards high values, which is exactly what happens between the annuli with R = 15 kpc and R = 30 kpc. We conclude that the high velocity dispersion measured in this region is spurious and can be safely ignored in our modelling.
The more the galaxy is inclined with respect to the line of sight, the more important is the effect of increasing the velocity dispersion. NGC 2841, NGC 3198, and NGC 7331 are the galaxies in the sample with i > 70°. The effect of inclination on σ_{HI} profile of NGC 3198 is less prominent with respect to NGC 2841, as the former galaxy is less inclined. On the other hand, the whole velocity dispersion profile of NGC 7331 is likely overestimated, but the associated uncertainties are large enough to account for this effect.
Appendix E: Uncertainties on scale heights and volume densities
In this section, we explain how the uncertainties on scale heights (Δh) and volume densities (Δρ) are estimated. Let us first focus on the gas component and then on the SFR.
For a gas disc in hydrostatic equilibrium, the scale height can be calculated using the approximated Eq. (12). Applying the rules of the propagation of uncertainty, we find
where Δσ and are the uncertainties on the velocity dispersion and the second derivative of the gravitational potential. In our case, Δσ coincides with the error on the velocity dispersion measured by 3DB, but finding would be much more problematic. The uncertainty on is linked to the uncertainty on the total volume density of DM and stars through the Poisson equation, so we should use the uncertainties on the mass decomposition. However, we expect that the parametric mass models of stars and DM do not significantly change within the errors on the fit and the observed rotation curve in de Blok et al. (2008). For simplicity, we assume that , therefore
Then, the general equation for the uncertainties on the volume densities is derived from Eq. (15):
where ΔΣ is the uncertainty on the observed surface densities. Therefore, the errors on HI, H_{2}, and total gas volume densities are
We neglect the covariance between the error on Σ_{HI} and on h_{HI} as the scale height depends on the dominant mass components (the stellar disc and DM halo), so these two quantities can be considered independent; the same is valid for the molecular gas.
Concerning the constant SFR scale height, the uncertainty is null by construction (Δh_{SFR} = 0), so the error on the SFR volume density derived from Eq. (E.2) is
In the case of the flaring SFR scale height, the error is derived from Eq. (17)
Therefore, the uncertainty on the volume density is
When we build the HISFR and H_{2}SFR relations, we are implicitly assuming that h_{SFR} = h_{HI} and h_{SFR} = h_{H2}, so Δh_{SFR} = Δh_{HI} and Δh_{SFR} = Δh_{H2}. As a consequence, Eq. (E.8) becomes
Appendix F: Likelihood and posterior distributions of Bayesian fittings
In order to include both the orthogonal intrinsic scatter and the x and y errors on the volume densities, the logarithmic likelihood is written as (Ponomareva et al. 2017; Posti et al. 2018)
In this equation, N is the number of data points, d_{i} is the distance between a given data point (x_{i}, y_{i}) and the model (e.g. Eq. (20)), being x_{i} = logρ_{gas} and y_{i} = logρ_{SFR}. Then, , where σ_{⊥} is the orthogonal intrinsic scatter and σ_{xi, ⊥} = σ_{xi}cosθ and σ_{yi, ⊥} = σ_{yi}sinθ are the projections of the x and y uncertainties on data points σ_{xi} and σ_{yi} using the angle θ, which is the arctangent of the slope of the relation. The prior distribution of the free parameters is uniform and spans from −∞ to +∞ for the slope and yintercept, and from 0 to +∞ for the intrinsic scatter. Before the fitting, the origin of the data points coordinate system is shifted to the median of ρ_{gas} and ρ_{SFR} (x_{m} and y_{m} in logarithmic scale) to reduce the covariance between α and log A. In practice, the axes of the new coordinate system x′−y′ are defined as y′=y − y_{m} and x′=x − x_{m}, therefore the bestfit log A in the x − y system becomes log A = y_{m} − αx_{m} + log A′, where log A′ is the bestfit intercept in the x′−y′ system. Clearly, when we consider only the atomic (molecular) gas phase in Sect. 5.3 (Sect. 5.2), we use the same method but with x_{i} = logρ_{HI} (x_{i} = logρ_{H2}) and the slope and normalisation are defined as β and log B (γ and logΓ). In the case with total gas, x_{m} = −1.94 and y_{m} = −2.30 (y_{m} = −2.74) with the constant (flaring) h_{SFR}. In the case with atomic gas, x_{m} = −2.02 and y_{m} = −2.30 (y_{m} = −2.76) with the constant (flaring) h_{SFR}. In the case with molecular gas, x_{m} = −2.05 and y_{m} = −1.86.
Fig. F.1. Marginalised posterior distributions of free parameters in the Bayesian fittings of VSF laws with total gas (left column), HI only (central column), and H_{2} only (right column). In the first row h_{SFR} is constant at 100 pc, while in the second row it flares with radius (Eq. (17)). The contours of the 2D posteriors (corners) encompass the 68.3%, 86.6%, and 95.4% probability and the red squares and lines indicate the bestfit parameters. In the 1D posteriors (diagonals), the bestfit parameters are indicated by the red line and the 16th and 84th percentiles are indicated by the black dashed lines.

Open with DEXTER
Figure F.1 shows the marginalised posterior distributions of free parameters for the VSF laws MCMC fittings. The first column refers to the VSF law between the SFR and total gas (Eq. (20)). Despite the axes shifting, there is still a small covariance between α and log A′ but all the parameters are well constrained and clearly indicate the existence of a correlation between the volume densities of gas and SFR. Unfortunately, we are not able to find an unambiguous bestfit slope, as it depends on the choice of h_{SFR}, but the intrinsic scatter is small (0.12–0.13 dex) in both cases. The second and third columns are the same as the first but for the VSF laws with HI (Eq. (21)) and H_{2} (Eq. (22)). The relation with HI is steeper and has a small scatter compared to the relation with H_{2}.
All Tables
MCMC bestfit parameters for the VSF laws in the analytical approximation for the scale heights.
All Figures
Fig. 1. HI (Leroy et al. 2008, blue points) and H_{2} (Frank et al. 2016, red points) observed surface densities radial profiles. The light blue and coral curves show the models used to compute the scale heights and are obtained by fitting Eq. (10) to the observed profiles. Only the ranges where the SFR is measured are shown.

Open with DEXTER
In the text
Fig. 2. HI velocity dispersion measured using ^{3D}BAROLO (filled and empty circles) for our galaxies with a common sampling of about 400 pc (for NGC 2841 we show one data point every two). The bestfit models (Eq. (11)) are shown by the light blue curves, whose parameters (σ_{HI, 0} and R_{σ}) are reported in a box in the lower left corner of each panel. The points indicated by empty circles are excluded from the fit.

Open with DEXTER
In the text
Fig. 3. HI scale height radial profiles in the presence of three different gravitational potentials (including the HI selfgravity) but with the same velocity dispersion. The orange and grey dashed curves, respectively, show h_{HI}(R) for the stellar disc only and DM halo only potentials taken from NGC 2403 mass model. The total potential of NGC 2403 gives the blue solid curve.

Open with DEXTER
In the text
Fig. 4. Scale height radial profiles: h_{HI}(R) (solid blue) and h_{H2}(R) (solid red) are calculated by GALPYNAMICS, while h_{SFR}(R) (dashed black) is estimated using Eq. (17). We note that h_{H2}(R) is shown out to the radius where CO emission is detected. The faded regions indicate the uncertainties on the gas scale heights, while the black dashed regions are the uncertainties on h_{SFR}(R).

Open with DEXTER
In the text
Fig. 5. Upper row: correlations between gas and SFR surface densities (left) and volume (centre and right) densities for NGC 5055; h_{SFR} is assumed to be constant and flaring (Eq. (17)) in the central and right panels, respectively. Each point is obtained as an azimuthal average and coloured according to its galactocentric radius. The slope of the VSF law is much shallower than for the surfacebased law. This is a consequence of taking the flaring of the gas (and the SFR) into account. Lower row: same as the upper row but for all the galaxies in our sample. Each galaxy has its own colour as shown by the colour bar. The VSF law has considerably less scatter than the surface based version. Each panel shows similiar ranges in x and y. No obvious break in the SF efficiencies is found at low densities after correcting for disc thickness.

Open with DEXTER
In the text
Fig. 6. Upper row: same as Fig. 5b but the points are colourcoded according to the HI fraction; blue and red points come from HI and H_{2} dominated regions, respectively. The VSF law appears tight and straight even if only HIdominated regions are considered. Lower row: VSF law between total gas and SFR. The solid black line is the bestfit relation with slope α and orthogonal intrinsic scatter σ_{⊥} (dashed lines). The grey bands show 1σ and 2σ uncertainties on the fit. In the left panel, ρ_{SFR} is calculated with the constant h_{SFR}, while in the right panel h_{SFR}(R) flares with radius (Eq. (17)). The volume densities radial profiles are shown as contours containing 95% (yellow), 75% (orange), 50% (red), and 25% (dark red) of the data points.

Open with DEXTER
In the text
Fig. 7. Upper row: same as Fig. 6a but with the xaxis showing the HI alone surface and volume densities. Lower row: VSF law between SFR and HI volume densities. See Fig. 6b for description.

Open with DEXTER
In the text
Fig. 8. Upper row: same as Fig. 6a but with the xaxis showing the H_{2} alone surface and volume densities. Lower row: VSF law between SFR and H_{2} volume densities. See Fig. 6b for description.

Open with DEXTER
In the text
Fig. A.1. Comparison of the scale heights calculated by Eq. (A.4) (dashed line) and by GALPYNAMICS (solid line). The HI and H_{2} scale heights are in blue and red, respectively.

Open with DEXTER
In the text
Fig. C.1. HI rotation curve of NGC 7793 assuming a flat rotation curve (red points), the errors are of the order of 4–5 km s^{−1}. The solid lines show our mass model: the stellar disc with M/L = 0.5 and the DM contributions are shown in orange and grey, while the resulting total rotation curve is in blue. The green points show the rotation curve measured by de Blok et al. (2008).

Open with DEXTER
In the text
Fig. D.1. HI velocity dispersion map of NGC 2841. We note the Xshaped region where σ_{HI} > 15 km s^{−1}; the white ellipses correspond to the R = 15 kpc and R = 30 kpc annuli. The red cross indicates the centre and the red ellipse delimits the gas depleted region. The black dot (lower right) shows the beam size.

Open with DEXTER
In the text
Fig. F.1. Marginalised posterior distributions of free parameters in the Bayesian fittings of VSF laws with total gas (left column), HI only (central column), and H_{2} only (right column). In the first row h_{SFR} is constant at 100 pc, while in the second row it flares with radius (Eq. (17)). The contours of the 2D posteriors (corners) encompass the 68.3%, 86.6%, and 95.4% probability and the red squares and lines indicate the bestfit parameters. In the 1D posteriors (diagonals), the bestfit parameters are indicated by the red line and the 16th and 84th percentiles are indicated by the black dashed lines.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
