1. Introduction

Groups and clusters of galaxies are powerful probes to test and constrain cosmological models, independent of and complementary to other methods (e.g., Allen et al. 2011), such as Type Ia supernovae (Kowalski et al. 2008) and the cosmic microwave background (CMB; Dunkley et al. 2009). These systems have undergone gravitational relaxation and therefore are the largest objects whose masses can be measured with several independent methods. These measurements allow us to use the total matter content of clusters, and cluster counts at different epochs, to constrain the amount of dark matter in the universe. Moreover, the rate of gravitationally driven structure formation, as traced by the evolution of the cluster population, provides independent constraints on the amount and properties of dark energy in the universe.

Most cosmological studies that use galaxy groups and clusters require well-defined, large cluster samples. To this purpose, cluster samples have to be carefully treated by understanding their underlying cluster populations as well as their cluster mass determination and calibration. This has become clear again in the recently identified tension between primary CMB and cluster count constraints on cosmological parameters encountered by the Planck collaboration (Planck Collaboration XX 2014; Planck Collaboration XXIV 2016b). Observational bias and the survey strategy must be carefully accounted for in order to provide a sufficiently accurate description of the observed cluster sample (e.g., Mantz et al. 2010; Pacaud et al. 2016; Schellenberger & Reiprich 2017).

Early on, some tension was found between the values for σ8, parameterizing the matter fluctuation amplitude, and Ωm, the mean normalized matter density. Cluster studies preferred σ8 ∼ 0.7 (e.g., Borgani et al. 2001; Reiprich & Böhringer 2002; Seljak 2002; Viana et al. 2002) while CMB studies showed σ8 ∼ 0.9 (e.g., Spergel et al. 2003) for a given Ωm ∼ 0.3. After some oscillations (e.g., Spergel et al. 2007; Henry et al. 2009), now both probes seem to have settled around σ8 ∼ 0.8 (e.g., Mantz et al. 2010; Hinshaw et al. 2013; de Haan et al. 2016; Planck Collaboration XXIV 2016b; Schellenberger & Reiprich 2017). Still, cluster constraints tend to be on the lower σ8 side compared to primary CMB constraints while the statistical uncertainties shrink. This slightoffset may simply reflect statistical uncertainty but could also be due to interesting systematic, physical, or cosmological effects (e.g., Schellenberger & Reiprich 2017; McCarthy et al. 2018). Another probe at low redshift, that is, cosmic shear, also appears to result in lower σ8 estimations (e.g., Abbott et al. 2016; Hildebrandt et al. 2017).

Among the observational techniques for detection and analysis of galaxy groups and clusters, X-ray imaging is one of the most sensitive and reliable. The presence of the hot intra-cluster gas ensures that only genuine gravitationally bound structures are included, leading to highly pure and well-understood cluster samples in X-ray surveys.

The ROentgen SATellit (ROSAT) observatory has been the first and the only imaging telescope to perform an X-ray All-Sky Survey (RASS, Truemper 1992, 1993). The ROSAT mission was able to detect ∼125 000 X-ray sources (Voges et al. 1999, 2000; Boller et al. 2016), providing an ideal basis for the construction of a large X-ray cluster sample for cosmological studies. In the northern hemisphere the largest and most representative galaxy cluster compilations from contiguous areas of RASS include the Bright Cluster Sample (BCS; Ebeling et al. 1998), which is a flux-limited sample (flux ≥4.4 × 10−12 erg s−1 cm−2 in the 0.1 − 2.4 keV energy band), the extended BCS, which is a low-flux extension of BCS (eBCS, flux ≥2.8 × 10−12 erg s−1 cm−2 in the 0.1 − 2.4 keV energy band, Ebeling et al. 2000), the Northern ROSAT All-Sky Survey (NORAS; Böhringer et al. 2000), which is not flux-limited and its selection is based on a minimum count rates (0.06 cnts s−1 in the 0.1 − 2.4 keV energy band, roughly corresponding to a flux 1.2 × 10−12 erg s−1 cm−2 in the same band, see their Fig. 8a), and a source extent likelihood. The southern hemisphere has the ROSAT-ESO Flux Limited X-ray Galaxy Cluster Survey (REFLEX I - Böhringer et al. 2001), which is a flux-limited sample (flux ≥3 × 10−12 erg s−1 cm−2 in the 0.1 − 2.4 keV energy band).

However, these galaxy cluster samples obtained from the RASS data could be incomplete, because the sliding cell algorithm (Harnden et al. 1984), the detection method for most of such cluster samples, works most efficiently at finding point-like sources, instead of very extended sources with low-surface-brightness, such as galaxy groups and clusters at low redshift (e.g., Valtchanov et al. 2001). In addition, the inhomogeneous sky coverage of RASS might make the detection more difficult in regions with low or heavily varied exposure time. If the true incompleteness is higher than the estimated one, biased constraints on cosmological parameters may result. For studies of cluster mass function, this would tend to lower the inferred values of Ωm and/or σ8; see, for example, the tests carried out in Schellenberger & Reiprich (2017), shown in Fig. 10 therein.

The main goal of this work is to look for possible missing extended galaxy groups or clusters and assess the completeness of the RASS-based cluster catalogs. For this purpose we reanalyze the RASS images1 in the 0.5 − 2.0 keV energy band, with a wavelet-based source-detection algorithm combined with a maximum-likelihood fitting method to detect and characterize X-ray sources. This procedure is chosen based on its successful performance in finding extended X-ray sources with low surface-brightness, that is, galaxy groups and clusters at low redshift, in various X-ray surveys (e.g., Rosati et al. 1995; Vikhlinin et al. 1998; Pacaud et al. 2006, Lloyd-Davies et al. 2011). In this initial paper, we discuss the general X-ray characteristics of the possible missing groups and clusters in ROSAT catalogs, and show the properties of a pilot sample of confirmed detections. We refer to our extended detections as cluster candidates until we present the measured masses and can determine if they are galaxy groups or clusters. Subsequently, we refer to groups with M500 < 1014 M⊙ as galaxy groups and those with larger masses as galaxy clusters.

Throughout this paper, a Hubble constant H0 = 70 km s−1 Mpc−1, matter density parameter Ωm = 0.3, and dark energy density parameter ΩΛ = 0.7 are assumed unless stated otherwise. Moreover, the images used in this paper as well as the count rates are in the 0.5 − 2.0 keV energy band, while the fluxes are expressed in the 0.1 − 2.4 keV energy band unless stated otherwise.

2. Cluster-detection method

As stated in Rosati et al. (1995), wavelet transformation is capable of detecting faint X-ray sources with a variety of sizes and surface-brightnesses. Vikhlinin et al. (1998) showed that a further implementation of a maximum-likelihood method enhances the characterization of extended sources from the wavelet-detected sources. The combination of these methods has resulted in successful galaxy cluster catalogs using XMM-Newton data in recent years (e.g., Pacaud et al. 2006; Lloyd-Davies et al. 2011). Given that our main goal is to find possible missing extended groups and clusters with low surface-brightness in the RASS data, we follow the general scheme and implement a detection pipeline similar to the one used in Pacaud et al. (2006; hereafter P06), proceeding in three main steps:

  • 1.

    The Poisson noise is first removed from the images with a multiresolution filtering procedure.

  • 2.

    The filtered images are scanned by a source-detection algorithm, resulting in a preliminary source list.

  • 3.

    Each detected source is fitted and characterized by a maximum-likelihood procedure.

These steps are first applied to the simulations described in Sect. 3, with the aim to assess the reliability of this method in finding extended clusters with low surface-brightness; this approach is then applied to the RASS observations. In the following, a brief description of each step is presented.

The simulated images are first filtered using a wavelet algorithm designed to handle Poisson data. It is a completely new implementation of the wavelet task used in P06, MR_FILTER 2. Like its predecessor, it relies on a “à trous” (“with holes”) transform with a cubic B-spline wavelet (also known as starlet transform) and filters the noise by imposing hard thresholds on the wavelet coefficients, estimated from autoconvolution histograms (see Starck & Pierre 1998, for a detailed description). A smoothed and denoised image is then reconstructed iteratively from the significant coefficients. A key feature of the new implementation is the ability to account for varying exposure time not only in the reconstruction, but also for the determination of the significance thresholds. More details on the software are provided in Faccioli et al. (2018).

The source detection on the filtered images is performed by the SEXTRACTOR 3 software (Bertin & Arnouts 1996). Originally, SEXTRACTOR was developed to detect objects from optical data, but it can also be applied to the multiresolution filtered X-ray images, since the filtering removes most of the noise from it to produce a smooth background. This step proceeds exactly as in P06 and the most relevant SEXTRACTOR parameters are given in their Table 1. The only difference is the pixel size, which we set to 45 arcsec.

Table 1.

Summary of the extended source simulations in the ROSAT-like images.

In the final step of the detection procedure, the sources identified by SEXTRACTOR are characterized by a maximum-likelihood profile-fitting algorithm (also a new implementation compared to P06). Starting from the SEXTRACTOR measurements as a guess for the source properties, it maximizes the Poisson likelihood (C-statistic, Cash 1979) for each source individually, masking surrounding detections based on the SEXTRACTOR segmentation map. The best fit model parameters are derived using the simplex minimization method AMOEBA (Press et al. 1992). The significance of each detection (hereafter detection likelihood) is then quantified using a relation based on the best-fit likelihood as:

(1)

where ℒbgd and ℒext are respectively the Poisson likelihoods of the best background (flat distribution) and extended source model. The extended source model is given by a β profile, with a β value of two thirds (see Eq. (4)). A significance of the source extension (the extension likelihood) is also provided as:

(2)

where ℒpnt is the likelihood of the point-source model. It is worth mentioning that the point-like and the extended source models are convolved with the averaged ROSAT PSF. Aside from the instrument specifics, the two main differences compared to P06 lie in the definition of the extension / detection likelihoods (which included an analytical correction for the number of fitted parameters in P06) and the background treatment. Indeed, our model includes a constant sky background to be fitted, whereas it was set in P06 through an analytical maximization of the likelihood with respect to the model normalization.

3. Image simulations

We first assess our cluster-detection analysis on image simulations. For this, we perform extensive and dedicated Monte Carlo simulations of ROSAT images. Our procedure creates images with point-like and extended sources, which represent active galactic nuclei (AGNs) and galaxy clusters, respectively. It also takes into account the main ROSAT instrumental characteristics (such as point spread function (PSF), background, and Poisson noise). In this section, we describe the setup of our simulations.

3.1. General parameters

We simulate images with the same size as the publicly available RASS tiles, that is, 6.40 × 6.40 deg2, with a pixel size of 45 arcsec.

The input sources are convolved with the survey averaged PSF at 1.0 keV (as appropriate for the 0.5 − 2.0 keV energy band that we are simulating). The PSF itself is obtained from the Gaussian model of Boese (2000). This model describes the width of the PSF (in units of arcsec) as a function of energy and off-axis:

(3)

where E is the energy expressed in keV and ϵ is the off-axis angle in arcmin. For the field averaged PSF, applicable to survey observation, we generate Gaussian PSF at different off-axis angles and weight them according to the telescope vignetting and detector area. The resulting PSF has a full width at half maximum (FWHM) of ∼45 arcsec and, despite originating from a sum of Gaussian functions, has much broader wings than a single Gaussian.

The ROSAT survey exposure distribution is not uniform. It varies from 100 to 40 000 s at the ecliptic equator and poles, respectively (Voges et al. 1999). Given that the purpose of this work is to characterize the average potential of our extended source-detection algorithm and to provide insights into the properties of new clusters, we adopt a flat exposure time of 450 s for the simulations. This value is the average obtained over all exposure maps of the ROSAT all-sky survey. In a following paper, the limitations of this approach will be fully discussed.

We also include a flat X-ray background with a value of 0.08 cnts pixel−1. This value is calculated by averaging the background maps of the ROSAT all-sky survey. These maps are created by the SEXTRACTOR software (see Sect. 2 for further details).

3.2. Galaxy clusters and AGNs

The surface-brightness, SX, of galaxy clusters is described by the spherically symmetric β model (Cavaliere & Fusco-Femiano 1976); it is given by

(4)

where rc is the core radius of the cluster, and β determines the slope of the brightness profile. Different values for β, rc, and flux (see Table 1) are used in order to cover a wide range of possible cluster morphologies. For each set of parameters, 100 clusters are simulated with controlled positions. In order to reduce the overlap of X-ray emission from the simulated clusters, the distances between them are larger than 2 × r500. Moreover, the cluster distances to the nearest image edge are always larger than r500. The value of r500 is taken as 7 × rc.

Since AGNs represent the majority of extragalactic X-ray sources, a population of them are included in the image simulations. The surface-brightness of AGNs is described by the ROSAT PSF. The AGN flux distribution and source density are obtained using the logN − logS from Moretti et al. (2003) down to a flux of 2.29 × 10−14 erg s−1 cm−2. The spatial distribution of AGNs is assumed to be random.

To convert the flux of clusters and AGNs into photon count, PIMMS4 is used. The energy conversion factor used for clusters is 1.12 × 10−11 (erg s−1 cm−2)/(cnts s−1), which is obtained by assuming an absorbed APEC model with nH = 5.95 × 1020 cm−2, an abundance of 0.4 times solar abundance, a temperature of 2.73 keV (107.5 K), and z = 0.10. The galactic neutral hydrogen column density value, nH, is taken from the average of all observations, excluding only a ±20 deg area around the Galactic plane. The values of the temperature and redshift are chosen based on our objective of detecting relatively low-temperature and nearby clusters that were previously missed. We note that the energy conversion factor changes by less than 3% for 0.02 < z < 0.18 and T = 2.73 keV. The energy conversion factor for AGNs is 1.15 × 10−11 (erg s−1 cm−2)/(cnts s−1). We obtain this factor by assuming an absorbed power-law model with photon index equal to 1.85, which is roughly the peak of the observed distribution for X-ray AGNs (Ueda et al. 2014), and with the same nH value as before.

3.3. Source classification using simulations

All simulated images were processed with the pipeline described in Sect. 2. The positions of the detected sources were cross-identified with the simulation inputs using a correlation radius of 6 arcmin for point-like sources and 3.5 × rc for extended sources. We use a variable matching radius for extended sources because their positional accuracy is size dependent.

Following P06, we explore the parameter space of the maximum-likelihood fitting method to place source classification criteria. The most relevant parameters are: detection likelihood, extension likelihood, source extent (i.e., core radius), and source position.

The wavelet image reconstruction creates artifacts near the image edges, which result in false detections. Therefore, we exclude all detected sources located close to the image edges (< 15 pixels to image sides). Moreover, our analysis shows that a threshold value of 20 in the detection likelihood removes 95.4% of the false detections, that is, sources that are not simulated but are found by the detection algorithm. Although this threshold removes 50.8% of the detected AGNs, it preserves 96.7% of the detected clusters. We obtain an average of ∼1.5 false detections per simulated image. The number of 1.5 false detections is a global value of the number of false detections regardless of the origin of the simulated source (point-like or extended). However, as discussed in the following, this number is mainly generated by false point-like detections.

By scanning the extension likelihood - extent parameter space, we look for a location where the majority of our simulated extended sources are recovered while maintaining the contamination from point-like sources at a low level. The left-hand panel of Fig. 1 shows the main selection criteria for extended sources with β = 2/3 in this plane. This is given by values of extension likelihood > 25 and extent > 0.67 arcmin. The discrete distribution in the extent values reflects the different input core radius values used in the simulations (see Table. 1). Using these extended selection criteria we obtain ∼4.2 × 10−3 extended false detections per simulated image, and ∼0.1 misclassified AGNs per simulated image, that is, simulated AGN with values of extension likelihood > 25 and extent > 0.67 arcmin.

thumbnail Fig. 1.

Selection criteria for extended sources. The selection is performed in the extension likelihood - extent plane. The red-solid lines define the optimal parameters obtained from simulations to characterize extended sources. Left: simulation results. Gray dots represent simulated AGNs, and blue triangles, false detections. Colored stars represent clusters with different input fluxes. Right: results from reprocessing RASS data. Gray dots stand for point-like detections and the star symbols for the cluster candidates. Green and pink stars show the candidates with identified counterparts in the MCXC and PSZ2 catalogs, respectively. The black stars represent the 13 groups of our pilot sample described in Table 3.

The minimum extent value chosen for extended source characterization, 0.67 arcmin, is slightly lower than the minimum value of core radius used in the simulations (0.75 arcmin). We have tested the impact of this minimum extent value, by simulating clusters with rc = 0.5 arcmin. We found that these clusters are characterized by our algorithm with low values of extension likelihood, < 25. Therefore, they are not characterized as extended sources. This does not represent an issue in the present work since our goal is to look for very extended galaxy clusters that might have been missed in previous studies.

Fig. 2 shows that the selection criteria are very similar for extended sources simulated with β values different from two thirds. In contrast with the left-hand panel of Fig. 1, this plot displays only two values of input cluster fluxes, 1 × 10−12 erg s−1 cm−2 and 1 × 10−11 erg s−1 cm−2. In general, clusters simulated with small β values tend to have lower extension-likelihood values and larger extent values.

thumbnail Fig. 2.

Similar plot as the left-hand panel of Fig. 1 showing the selection criteria for extended sources in the extension likelihood - extent plane. Gray dots represent simulated AGNs, and blue triangles, false detections. Colored symbols represent clusters with different input β values. Filled stars show clusters with input flux 1 × 10−12 erg s−1 cm−2, while filled squares are clusters with input flux 1 × 10−11 erg s−1 cm−2.

The detection and characterization efficiency of the total number of simulated clusters can be summarized as follows. Approximately 34% of simulated clusters with β = 0.40, flux equal to 1 × 10−12 erg s−1 cm−2, and rc > 5′ are detected and characterized as extended sources. This percentage increases to ∼97% for clusters with flux equal to 3 × 10−12 erg s−1 cm−2. About 69% of simulated clusters with β = 0.55, flux equal to 1 × 10−12 erg s−1 cm−2, and rc > 5′ are detected and characterized as extended sources. Broadly speaking, simulated clusters with fluxes ≥5 × 10−12 erg s−1 cm−2, β ≥ 0.55, and rc ≥ 5′ have 100% probability of being detected and characterized as extended sources. The full analysis of the completeness of our sample will be presented in a subsequent publication.

4. Results

4.1. Performance on real data

Having calibrated the cluster candidate selection criteria on simulations, we proceed to run the detection algorithm on the real RASS data. The RASS data consist of 1378 image tiles, with varying exposure time (see Sect. 3). We exclude the data close to the plane of the Milky Way, the Magellanic Clouds, and the Virgo cluster regions (see Table 2 of Reiprich & Böhringer 2002).

Table 2.

Overview of the publications used to cross-check if cluster candidates have previously been detected.

The right-hand panel of Fig. 1 shows the results of processing the RASS data. Applying the same criteria for extended sources as in Sect. 3.3, we find 1308 cluster candidates. In order to validate the authenticity of these cluster candidates, we first cross-identify them with well-known cluster catalogs.

Using a correlation radius of 10 arcmin, we match our cluster candidates with the Meta-Catalog of X-Ray Detected Clusters of Galaxies (MCXC; Piffaretti et al. 2011) and the second Planck catalog of Sunyaev-Zeldovich sources (PSZ2; Planck Collaboration XXVII 2016a), excluding clusters in the regions where we do not process the RASS data. The size of the correlation radius is determined from the distribution of the positional difference between our cluster candidates and the MCXC and PSZ2 clusters. Within 10 arcmin, the differential number of matched clusters decreases rapidly. Beyond this value, the positional difference distribution starts to rise, meaning that random matches start to appear due to the increasing area.

First, we correlate all our detections (i.e., regardless of their extent, detection likelihood, and extension likelihood values) with clusters of the MCXC and PSZ2 catalogs. We are able to detect 86.5% of the MCXC clusters. This percentage increases to 99.7% if we only select RASS-based MCXC clusters. Fig. 3 shows the redshift and r500 (taken from Piffaretti et al. 2011) distributions of the matched and unmatched RASS-based MCXC clusters with our detected sources. From Fig. 3 we can see that we do not detect three RASS-based MCXC clusters. Two of such clusters are located in regions with exposure time < 70 s, while the third one is positioned close to the ROSAT North Ecliptic Pole where the large gradient of exposure time may affect the positional accuracy of the detected sources in the region (our nearest detection is 12 arcmin away). We also observe a high total detection rate of 97% of PSZ2 clusters with z < 0.2. This percentage decreases to 93% when correlating our detections with all PSZ2 clusters.

thumbnail Fig. 3.

Distribution of redshift and r500 of matched and unmatched RASS-based MCXC clusters with our detected sources. The y-axis is a log scale.

Using the whole MCXC and PSZ2 catalogs and imposing our extended source criteria, out of the 1308 cluster candidates, 540 have a counterpart in MCXC, while 323 have a correspondence in PSZ2 (Fig. 4). These numbers overlap in 285 clusters, therefore we remain with 730 cluster candidates without counterparts in MCXC or PSZ2. The extent distribution of the cluster candidates is displayed in Fig. 4. We find that ∼67% of our cluster candidates with extent ≲5 arcmin have a counterpart in the MCXC or PSZ2 catalogs, showing the reliability of our extended source finder. The gray histogram in Fig. 4 shows the distribution of the cluster candidates with no counterpart in MCXC or PSZ2. Approximately 60% of these candidates have an extent ≳5 arcmin, leaving very extended sources as possible candidates for missed clusters in the RASS-based cluster catalogs.

4.2. Looking for new galaxy clusters and groups

As mentioned previously, the purpose of this paper is not to describe a new cluster catalog obtained by reprocessing the RASS data, but to show a pilot sample of promising cluster and group discoveries.

We further investigate the cluster candidates that have not previously been detected in the MCXC or PSZ2 catalogs. We use a correlation radius of 5 arcmin to match our 730 cluster candidates with the First ROSAT all-sky survey source catalog (1RXS, which includes the ROSAT All-Sky Survey Bright Source Catalog - BSC - Voges et al. 1999 and the ROSAT All-Sky Survey Faint Source Catalog - FSC - Voges et al. 2000), and the Second ROSAT all-sky survey source catalog (2RXS; Boller et al. 2016). We find 219 candidates with no detections in 1RXS or 2RXS. The distribution of these cluster candidates is shown in the orange histogram of Fig. 4, which shows larger values of extent than the candidates matched in the 1RXS or 2RXS catalogs. We concentrate from now on only on these cluster candidates.

thumbnail Fig. 4.

Extent value distribution for the 1308 cluster candidates. Out of these 1308 candidates, 578 have a MCXC or PSZ2 counterpart (filled pattern histogram) and 730 do not have a counterpart in these catalogs (gray histogram). Out of the 730 candidates, 219 do not possess a counterpart in the 1RXS or 2RXS catalogs (orange histogram). The green histogram shows the extent distribution of the 13 group candidates discussed in detail in this work (see Sect. 4.3). The y-axis is a log scale.

To further validate the 219 cluster candidates we perform an exhaustive visual inspection and literature search. For the visual inspection, we used the ROSAT photon images, and their counterparts in infrared, optical, and microwave bands (2MASS5, SDSS6, DSS7, ATLAS8 and Planck 9) overlaid with X-ray contours obtained from the wavelet-filtered images. The ROSAT exposure maps are also checked to make sure that the most extended detections are not artificially created by large exposure gradients. We also use images of the HI 4π survey (HI4PI; HI4PI Collaboration 2016) to ensure that the cluster candidates are also not due to inhomogeneities in the HI sky distribution. We checked whether or not our cluster candidates have already been discovered by means of other X-ray, optical, or SZ surveys, and whether our source candidates are nearby galaxies given their extension. Table 2 shows the catalogs used to cross-check our candidates. Furthermore, we include spectroscopic redshift distributions obtained from SDSS DR1410 or the NASA Extragalactic Database11 (NED) to assess the reliability of the cluster candidates. We do not restrict the redshift values when constructing these distributions.

Using the above information we subjectively rated each of the 219 cluster candidates with different grades: 1 for cluster candidates that are already known from the cluster catalogs shown in Table 2, 2 for cluster candidates that show a clear galaxy over-density in the infrared and/or optical images, 3 for cluster candidates for which it is not clear that a galaxy over-density exists due to lack of optical and/or infrared data, and 4 for cluster candidates that we consider as noise; for example, X-ray detections created by strong gradients of exposure in the RASS data or by low density value of HI in small regions of the sky. Our final grades show that 20% of the 219 cluster candidates are rated with 1, 16% with 2, 20% with 3, and 44% with 4. The number of cluster candidates rated as noise corresponds to 0.1 false extended detections per image. This rate is consistent with the number of misclassified AGNs and false extended sources per image in our simulations (see Sect. 3.3).

In this paper, we present a detailed analysis of a pilot sample of 13 cluster candidates selected out of those rated as grade 2. In optical, these cluster candidates coincide with clear over-densities of bright elliptical galaxies (see Fig. A.1) distributed over extended areas (≳30 arcmin) and NED shows that 11 out of the 13 cluster candidates have previously been reported in optical group and cluster catalogs. Furthermore, for all the candidates we are able to determine a reliable redshift estimation from existing galaxy catalogs (see Sect. 4.3.1). In the following section, we describe the methods used to characterize each individual cluster.

4.3. Pilot sample of cluster candidates

In this section, we describe the methods used to characterize the properties of 13 cluster candidates. Table 3 shows the sky coordinates of each system. The locations of these candidates in the extension likelihood - extent plane are shown with the black star symbols in the right-hand panel of Fig. 1.

4.3.1. Redshift estimation

We use NED to determine the redshift of each cluster candidate. We select all galaxies with spectroscopic redshift and within a box of size 1 × 1 deg2 centered on the cluster candidate position. For most of the cluster candidates, there are no or very few galaxies with redshift above 0.1. The final redshift depends on the number of available redshifts and their distribution. We fit iteratively a Gaussian function to the redshift distribution in z < 0.1 range, and apply 3σ clipping to remove outliers. The redshift of candidate is derived from its peak (see right-hand panels Fig. A.1). For the cases with two peaks in the redshift distribution, we choose the closest redshift peak to the redshifts of the optical groups/clusters found in NED. Table 3 displays the total number of galaxies used for the redshift determination and the right-hand panels of Fig. A.1 shows their redshift distribution for each cluster candidate. We find that our 13 cluster candidates are in the redshift range 0.013 − 0.072, with a median value of 0.036. 11 of them are below z < 0.05.

According to NED, 11 out of our 13 group candidates have at least one published counterpart within 15 arcmin (see Sect. 5 for details). We look into these catalogs to corroborate our redshift estimation. The red lines in the right-hand panels of Fig. A.1 represent the redshifts of these matched groups or clusters showing a good agreement with our estimation.

Table 3.

Galaxy groups in this pilot study.

4.3.2. Flux, luminosity, and mass determination

Finally, we ran a more involved photometric analysis using the growth curve analysis method (hereafter GCA; Böhringer et al. 2000, 2001), which computes the ROSAT hard band, 0.5 − 2 keV, integrated count rates as a function of aperture around the estimated cluster center. For this, a local background is first estimated in a large annulus, then the background subtracted count rates is estimated at lower radii in bins of 0.5′ and summed within increasing apertures. Contamination by surrounding sources is corrected for by a deblending procedure that separates the signal in a number of angular sectors and excludes those falling outside 2.3σ above/below the median value. The error on aperture count rates relies on Poisson statistics and is combined with the uncertainty on the background count rate. By default, the GCA method over ROSAT data uses a background annulus of 20 − 41.3′, but given the large size of our cluster candidates, we had to increase these values manually for most sources, reaching up to 85 − 110′ for the most extended source.

At this point, we obtain a full radial profile of the source and a decision is needed as to the aperture within which the source flux should be measured. We closely follow the methods and assumptions laid out in Böhringer et al. (2013) for the REFLEX-II cluster sample so that our flux measurements are comparable to this reference catalog. At first, a significance radius, rsig, is determined for which the 1σ uncertainty interval encompasses all count rates integrated in larger apertures. Then, the count rate within this aperture, CRsig, is estimated by fitting a constant value to the plateau outside rsig. Since this aperture holds no physical meaning for the general cluster population, we convert it to a more meaningful value within the fixed spherical overdensity r500 based on a few assumptions on the appearance of galaxy clusters.

For a given galaxy cluster mass, M500, the integrated 0.1 − 2.4 keV luminosity, L500, and average spectroscopic temperature, TX, are estimated from the Reichert et al. (2011) scaling relations. The corresponding flux and count rates within r500, which we refer to as F500 and CR500, are derived from the ROSAT PSPC response using appropriate corrections for spectral redshifting, flux dilution, and absorption. Then a β model with β = 2/3 and core radius rc = r500/7 is assumed to convert CR500 to an expected count rates in the significance radius. This mapping enables us to iterate over cluster mass until the right count rate is obtained within rsig. This provides us with a set of estimated cluster parameters derived from the model (r500, F500, TX, L500, and M500).

The third panel of each row in Fig. A.1 shows the growth curves estimated following the REFLEX-II procedure described above. As clearly seen from these plots, the observed growth curves (solid lines) are much flatter than the surface-brightness distribution predicted by the assumed β model (dotted lines). This confirms that our detection algorithm permits us to identify very extended low-surface-brightness sources that may be missing from previous catalogs. A downside, however, is that the assumed cluster profiles are not suitable to reliably convert fluxes from one radius to the other. Fortunately, the significance radius of the cluster emission exceeds the estimated value of r500 for all of our detections. This permits to by-pass the use of a fixed surface-brightness model by comparing directly the count rates predicted by our scaling relation model for a given M500 with the observed value within the corresponding r500. A revised estimate of the count rate, , is thus obtained by interpolating over the growth curve such that CR(r500)/CR500(M500)=1. We note, however, that this new estimate of still includes a correction based on the default β model, since we use it to estimate the dilution resulting from the ROSAT PSF, but it only makes a tiny difference for such extended systems. In addition, given the peculiar properties of our sources, they may not follow the average scaling relations used in the model. Consequently, although our quoted masses and fluxes always rely on the interpolated measurements, we preferred to list in Table 4 both values of CR500 and as an illustration of systematic uncertainties. The differences between the two estimates are strongly variable (see Fig. 5), but the values of CR500 are always overestimated by a factor of 2.05 on average.

Table 4.

Photometry and mass determination for the new galaxy group candidats.

thumbnail Fig. 5.

Distribution of the normalized difference between CR500 and (see Sect. 4.3.2 for details on the estimation of these quantities).

The main characteristics of this pilot sample can be summarized as follows. The 13 cluster candidates have r500 ≳ 8 arcmin, reaching values up to ∼30 arcmin. Five of the 13 systems have flux measurements larger than the flux limit values of previous RASS cluster catalogs (≳3 × 10−12 erg s−1 cm−2, see Sect. 1). All 13 cluster candidates have M500 ≲ 1014 M⊙, placing them in the group regime, rather than in the cluster scale. Therefore, from now on we refer to our 13 cluster candidates as galaxy groups.

4.3.3. Dynamical mass estimation

For the galaxy groups with more than 20 galaxy members with spectroscopic information (groups 3, 8, 9, 10, 12), we also calculated dynamical masses from their velocity dispersion. First, the velocity dispersion is obtained from the fit of the Gaussian function with a 3σ clipping to the redshift distribution. Then, using Eq. 1 from Munari et al. (2013), which provides the relation between velocity dispersion and M200, a range estimation of is derived. We further assume a Navarro-Frenk and White (NFW; Navarro et al. 1997) profile with concentration parameter c = r200/rs = 4 to determine a range of by using r500 ≈ 0.65 r200 (Reiprich et al. 2013). The last column of Table 4 shows the range of values of the dynamical mass estimations. Figure 6 shows that the dynamical masses are in general agreement with the masses derived from the LX − M relation (see Sect. 4.3.2). Only group 8 (see Table 3) shows a significant difference between these two mass estimations; this is further discussed in Sect. 5.8.

thumbnail Fig. 6.

Comparison of the derived dynamical masses with the masses derived from the LX − M relation (see Sect. 4.3.3 for details).

5. Notes on individual groups

In this paper, we focus on 13 new X-ray-selected galaxy groups that show very extended (rsig > 10 arcmin) emission in the RASS. Here we discuss each of them in detail.

Figure A.1 shows each of these systems through the RASS photon images and optical images from ATLAS, SDSS, or DSS, depending on the availability, and in that order of importance. These images have 1 × 1 deg2 size, except for the ATLAS images, which are 0.30 × 0.30 deg2. The red cross shows the determined position of the detected group from the maximum-likelihood fitting method, while the magenta plus symbols show the positions of X-ray sources in the 1RXS and 2RXS catalogs. The green contours are obtained from the respective wavelet-filtered images, and the blue circle shows the core radius determined from the maximum-likelihood fitting method (see Sect. 2). The cyan diamonds represent the positions of the individual galaxies with spectroscopic redshift information in NED and are used to determine the final redshift of the group (see Sect. 4.3.1).

As previously explained, the right-hand panels of Fig. A.1 show the redshift determination and Table 4 shows a summary of the parameters estimated for the 13 systems (see Sect. 4.2). We refer the reader to the right-hand panels of Fig. A.1 and Table 3 while reading the notes on the individual groups.

5.1. Group 1

NASA/IPAC Extragalactic Database provides redshift information for only six galaxies in this group at z ∼ 0.07. The SDSS image (see Fig. A.1a) shows two clear and prominent brightest cluster galaxies (BCGs) at the center of our X-ray detection, for which there is no spectroscopic information in NED. From SDSS DR14, we found photometric redshifts of 0.059 and 0.068 for these central galaxies, which are consistent with our redshift estimation for this group (z = 0.069). This system is the most compact group in our pilot sample (r500 ∼ 8 arcmin).

5.2. Group 2

According to NED, group 2 was previously identified as a galaxy group. Within 10 arcmin of the group position, two of these previous detections are: USGC s110, located 2.17 arcmin from the group center at z = 0.012 (Ramella et al. 2002), and source 425 of Díaz-Giménez & Zandivarez 2015, positioned ∼8.37 arcmin away at z = 0.013. These redshifts are consistent with our estimation for this group (z = 0.013 from 10 galaxies). The ATLAS image shows two main dominating galaxies at the center of the group (see Fig. A.1b). This object is the most extended (r500 ∼ 30 arcmin) and nearest group in our pilot sample. It has the largest flux of all groups in the sample ( ), which is 2.6 times larger than the flux limit of the REFLEX catalog (3 × 10−12 erg s−1 cm−2 in the 0.1 − 2.4 keV energy band, Böhringer et al. 2001).

5.3. Group 3

This group has previously been identified in several publications; for example, as SDSS-C4 1156 at z = 0.039 by von der Linden et al. (2007), and as PM2GC GR1204 at z = 0.040 by Calvi et al. (2011). These works provided several spectroscopic redshifts (for 42 galaxies), which allow us to obtain a redshift estimation of z = 0.039. Moreover, this group has several elliptical galaxies easily spotted by eye (see Fig. A.1c).

5.4. Group 4

Group 4 presents a similar situation to group 1 (see Sect. 5.1). NED provides redshift information for only seven galaxies, obtaining an estimated redshift z = 0.072 for this system. From the 2MASS Photometric Redshift catalog (2MPZ; Bilicki et al. 2014), we found photometric redshifts of 22 galaxies. These redshift values are consistent with the final redshift estimation of this galaxy group. The spatial distribution of these galaxies coincides with the X-ray contours of this system. This group has the highest redshift value in our pilot sample. Although this object is located near a bright point-like source and surrounded by another two weak RXS point-like sources, our detection algorithm is capable of disentangling all this information and still finds this extended source. The DSS image shows a bright galaxy near the X-ray peak emission of the group (see Fig. A.1d). This system is the most massive ( ) and most luminous ( ) group in our pilot sample.

5.5. Group 5

Similar to group 2 (see Sect. 5.2), this system has been identified in different works: Colless et al. (2001; identified as CID 15 at z = 0.036 and located 5.04 arcmin away from the group center), and Ramella et al. (2002; labeled as USGC U118 at z = 0.035 and located 8.64 arcmin away). Both optical detections have similar redshifts to the one determined from 17 galaxy members (z = 0.036). The DSS image (see Fig. A.1e) clearly shows elliptical galaxies in this field.

5.6. Group 6

This group has also been identified as a galaxy triplet system, APMUKS(BJ) B013430.06-14130 (Maddox et al. 1990), located 2.89 arcmin away from the group center, as a galaxy group USGC s061 at z = 0.039, 6.70 arcmin away (Ramella et al. 2002), and as a galaxy group named [DZ2015] 396 at z = 0.039 located 7.26 arcmin away (Díaz-Giménez & Zandivarez 2015). Although NED only provides redshifts for 14 galaxies, the estimated redshift (z = 0.040) of the group is consistent with the ones of the identified close groups. The ATLAS image (Fig. A.1f) clearly shows a dominant galaxy in the system with z = 0.040 (Huchra et al. 1993).

5.7. Group 7

In a similar situation as group 5 (see Sect. 5.5), NED shows an identified optical cluster counterpart 1.92 arcmin away from this group. This matching group is called WBL 704 at z = 0.024 (White et al. 1999). This redshift is consistent with our estimation for this group (z = 0.023 from 8 galaxies). The SDSS image shows a dominant BCG (see Fig. A.1g).

5.8. Group 8

For this system, there are 123 galaxies with redshifts measured from NED, giving z = 0.040 as the final result. It has been previously reported by Smith et al. (2012) as MSPM 00022 located 1.94 arcmin away from the group center at z = 0.039, which is consistent with our redshift determination. The SDSS image shows many elliptical galaxies gathering around a prominent BCG (Fig. A.1h). This group is located 47.96 arcmin away from cluster Abell 2152 at z = 0.041 (Struble & Rood 1999) with r500 = 12.99 arcmin (Piffaretti et al. 2011). Given that our group presents a similar redshift, we might consider it as a potential infalling group into Abell 2152. This might be reflected by the large discrepancy between its and values. However, further investigation is needed.

5.9. Group 9

Similar to group 5 (see Sect. 5.5), this system has an optical counterpart, MSPM 00069 (Smith et al. 2012), located 5.50 arcmin away at z = 0.035, which is consistent with our redshift estimation for this group (z = 0.036 from 52 galaxies). ROSAT catalogs and images (Fig. A.1i) show that this group is surrounded by point-like sources, but our detection algorithm is able to disentangle the X-ray emission and detect them individually. This group is the least massive ( ), the least luminous () and has the smallest flux () of all groups in the sample.

5.10. Group 10

This system has been reported in previous works as HCG 067 (Hickson 1982) and as LDCE 1002 (Crook et al. 2008), at redshifts of 0.025 and 0.024, respectively. These redshifts are consistent with the one we have estimated for this group (z = 0.025 from 22 galaxies). Although this group is surrounded by three bright RXS sources (Fig. A.1j), our detection algorithm is able to disentangle the individual emission. The ATLAS image clearly shows several elliptical galaxies in this system.

5.11. Group 11

Within 10 arcmin of the position of this group, we found two Abell clusters: Abell S0924 at z = 0.016 and Abell 3742 at z = 0.016 (Abell et al. 1989). These redshifts are fairly consistent with our redshift estimation of z = 0.017 for this group, which was obtained from ten galaxies. Given that this group displays two prominent BCGs (Fig. A.1k), it has been identified in other works as a galaxy group at a redshift similar to our estimation (e.g., Chow-Martínez et al. 2014a).

5.12. Group 12

From 38 galaxy redshifts, we determined z = 0.033 for this system. The DSS image (see Fig. A.1l) shows several elliptical galaxies in the area of this group. It coincides with several known optical counterparts. The most representative are groups 266 of Díaz-Giménez & Zandivarez (2015) and 77 of Ragone et al. (2006), both with a redshift of z = 0.034 and located 5.44 and ∼8 arcmin from our detection, respectively. In a similar situation as for group 8, it is located only 27.00 arcmin away from galaxy cluster Abell S0736, also at z = 0.033 (Chow-Martínez et al. 2014b), and 58.95 arcmin from galaxy cluster Abell 1736 at z = 0.046 (Planck Collaboration XXVII 2016a). This group is actually a member of the Front-Eastern-Wall of the Shapley supercluster. According to the groups identified in the area by Ragone et al. (2006), it most likely resides in a filamentary structure starting from Abell S0736 (z = 0.033), going through our source (z = 0.033), then Abell 1736 NED01 (z = 0.035), Abell 1736 NED02 (z = 0.041), and ending at Abell 1736 (z = 0.0453), all nicely aligned also in the plane of the sky. This is further supported by their location in the outskirts of the Shapley supercluster (they have some of the lowest redshifts among the identified supercluster members).

5.13. Group 13

Based on 14 redshifts found in NED, we determine z = 0.021 for this group. It has three optical counterparts at similar redshift within 5 arcmin: galaxy pair NGC 1044 (Falco et al. 1999), galaxy triple HDCE 0161 (Crook et al. 2008), and galaxy group USGC U142 (Ramella et al. 2002). Croston et al. (2008) observed NGC 1044 with XMM-Newton to follow up an extended radio source, detecting extended X-ray emission from a group environment. The DSS image (see Fig. A.1m) shows a galaxy pair dominating the system.

6. Discussion

The 13 groups in our pilot sample have extent values (i.e., core radius) larger than 5 arcmin. Of these 13 groups, 11 have a redshift lower than 0.05. For all of them, significant emission can be traced out to rsig > 10 arcmin (see Table 3). These facts show that indeed some local, very extended galaxy groups have been missed in previous works and that our methodology used to look for them works fine.

The flux measurements of our groups show that these 13 systems are above the flux limit of the 1RXS and 2RXS catalogs (∼10−13 erg s−1 cm−2 for 2RXS catalog, Boller et al. 2016). Since most RASS galaxy cluster catalogs rely on 1RXS/2RXS as initial source sample, it is not surprising that the galaxy groups are also not included in any published RASS cluster catalog, despite their fluxes often being larger than the flux limits of those.

Our growth curve analysis method shows that our groups have a relatively flat ( β < 2/3) surface-brightness distribution (see the third panel of each row in Fig. A.1), making this pilot sample a perfect representation of sources that do not have the expected or usual characteristics and therefore are missed in catalogs. This is supported by the locations of the 13 groups in the extension likelihood - extent plane (see right-hand panel of Fig. 1), which are consistent with detected clusters of low β values in our simulations (low values of extension likelihood and large values of extent, see Fig. 2).

All these features make our 13 groups perfect candidates to be missed by the sliding-cell algorithm used to construct the RASS catalogs. This source finder performs best when detecting point-like sources (Rosati et al. 2002).

The fact that most of our secure group candidates lie below z = 0.05 raises the question of whether there is a significant fraction of such systems that have been missed. Around 14% of the MCXC clusters, that is, 251, have a redshift no larger than z = 0.05. A similar number, 219 objects, constitutes our sample of group candidates with no 1RXS/2RXS detections. If further analysis shows that at least 50% of these systems are indeed galaxy groups we will increase the number of known X-ray galaxy groups at z < 0.05 by at least 40%. Schellenberger & Reiprich (2017) have shown the impact on the values of Ωm and σ8 by the incompleteness of the mass function in the galaxy group regime. Generally, if there is an uncorrected incompleteness of 25%−50% at low masses, the best-fit Ωm values are biased low.

7. Conclusions

In this work, we have reprocessed the ROSAT All-Sky Survey (RASS) data with the aim to look for very extended, low-surface-brightness galaxy groups and clusters that might have been missed in previous works. Our approach consisted of a wavelet-based source-detection algorithm and a maximum-likelihood fitting method to characterize the source properties. We tested our methodology on extensive Monte-Carlo simulations and determined the selection criteria for significant and extended sources.

We found 1308 cluster candidates in the RASS data. Approximately 44% of those systems have a cluster counterpart in either MCXC or PSZ2 catalogs. This makes our methodology a reliable procedure. From the ∼56% remaining, 70% of them have a counterpart in either 1RXS or 2RXS catalogs. In this paper, we focus on and perform an extensive visual inspection and literature search of the other 30% of the systems. Of these objects, we describe in detail the analysis and characterization of a pilot sample of 13 candidates.

We determined a spectroscopic redshift for each cluster candidate finding that most of them are local systems (z ≲ 0.05), and are very extended (significant X-ray emission traced out to more than 10 arcmin radius). Moreover, all these objects have fluxes above the limit of the 1RXS and 2RXS catalogs. We argue that they might have been missed because of the source finder used in previous works, that is, the sliding-cell algorithm, which is not optimal for finding such low-flux, very extended objects. Our pilot sample also reveals that the surface-brightness distribution of the systems is flatter than the usual profile, that is β < 2/3, and that the missed systems are located in the group regime given the determined masses from galaxy velocity dispersions or a LX − M scaling relation (M500 ≲ 1014 M⊙).

In a subsequent paper, we will present and discuss in detail the remaining cluster candidates that we have found.
