Global simulations of protoplanetary disks with net magnetic flux
I. Nonideal MHD case
Univ. Grenoble Alpes, CNRS, IPAG, 38000 Grenoble, France
email: william.bethune@univgrenoblealpes.fr
Received: 14 November 2016
Accepted: 24 January 2017
Context. The planetforming region of protoplanetary disks is cold, dense, and therefore weakly ionized. For this reason, magnetohydrodynamic (MHD) turbulence is thought to be mostly absent, and another mechanism has to be found to explain gas accretion. It has been proposed that magnetized winds, launched from the ionized disk surface, could drive accretion in the presence of a largescale magnetic field.
Aims. The efficiency and the impact of these surface winds on the disk structure is still highly uncertain. We present the first global simulations of a weakly ionized disk that exhibits largescale magnetized winds. We also study the impact of selforganization, which was previously demonstrated only in nonstratified models.
Methods. We perform numerical simulations of stratified disks with the PLUTO code. We compute the ionization fraction dynamically, and account for all three nonideal MHD effects: ohmic and ambipolar diffusions, and the Hall drift. Simplified heating and cooling due to nonthermal radiation is also taken into account in the disk atmosphere.
Results. We find that disks can be accreting or not, depending on the configuration of the largescale magnetic field. Magnetothermal winds, driven both by magnetic acceleration and heating of the atmosphere, are obtained in the accreting case. In some cases, these winds are asymmetric, ejecting predominantly on one side of the disk. The wind mass loss rate depends primarily on the average ratio of magnetic to thermal pressure in the disk midplane. The nonaccreting case is characterized by a meridional circulation, with accretion layers at the disk surface and decretion in the midplane. Finally, we observe selforganization, resulting in axisymmetric rings of density and associated pressure “bumps”. The underlying mechanism and its impact on observable structures are discussed.
Key words: accretion, accretion disks / magnetohydrodynamics (MHD) / protoplanetary disks / stars: formation / turbulence
© ESO, 2017
1. Introduction
Protoplanetary disks are commonly observed around young stellar objects, linking the young star to its protostellar envelope. Optical and nearinfrared images show disks with strong extinctions near the midplane (Padgett et al. 1999). They also reveal bipolar outflows, normal to the disk plane, with inner jets collimated on large scales (Burrows et al. 1996). The structure of these disks can be probed by infrared and radio wavelengths. These images have unveiled a number of features, such as spiral arms (Muto et al. 2012; Benisty et al. 2015), asymmetric dust concentrations (van der Marel et al. 2013; Fukagawa et al. 2013), or axisymmetric rings (Brogan et al. 2015; Nomura et al. 2016).
The diversity of processes occurring in protoplanetary disks is ultimately constrained by the disk lifetime (Haisch et al. 2001; Cieza et al. 2007). On the one hand, any viable planetary formation scenario must be able to build planetesimals out of submicronsized dust grains in a few million years. On the other hand, the rapid disk dispersal calls for efficient transport mechanisms. Part of the gas is accreted onto the central star, as deduced from their excess continuum emission and redshifted absorption lines (Edwards et al. 1994; Hartigan et al. 1995). The rest of it must be evacuated in the form of an outflow. What drives accretion and ejection remains a central research topic.
Hydrodynamic models fail to account for the observed jets’ collimation and ejection efficiency (Cabrit 2007). Including magnetic fields opens a number of promising perspectives. Magnetized Keplerian disks are prone to the magnetorotational instability (MRI, Balbus & Hawley 1991), which could drive accretion by turbulent angular momentum transport (Hawley et al. 1995). Largescale magnetic fields could also extract angular momentum by the launching of a magnetohydrodynamic (MHD) wind (Blandford & Payne 1982; Ferreira & Pelletier 1995). In this ideal MHD picture, accretion and ejection are codependent aspects of one global process (Pudritz 1985). Thermodynamical effects, and in particular heating, are also important in order to characterize outflow properties. Heating at the disk surface has been shown to increase the outflow mass (Casse & Ferreira 2000), a result recently recovered by Bai et al. (2016), albeit with a prescribed magnetic topology and without solving the disk dynamics.
This ideal MHD picture is compromised when realizing that, due to their optical thickness and low temperatures, protoplanetary disks should be weakly ionized beyond 0.1–1au (Gammie 1996). The concept of a magnetic dead zone emerged, wherein the gas would be weakly coupled to the magnetic field. In principle, such a plasma should be described using a multifluid approach (e.g., O’Sullivan & Downes 2006). However, the recombination time in protoplanetary disks is in general much shorter than the orbital time (Bai 2011; RodgersLee et al. 2016, but see Ilgner & Nelson 2008), making the singlefluid approximation perfectly valid and actually preferable to reduce computational costs. In the singlefluid approximation, the reduced ionization fraction is taken into account by incorporating three nonideal MHD effects: ohmic diffusion, ambipolar diffusion, and the Hall drift (Nakano & Umebayashi 1986; Wardle & Ng 1999). Both diffusive effects can damp magnetic structures, and potentially quench the MRI (Jin 1996; Kunz & Balbus 2004), as supported by numerous nonlinear simulations (e.g., Hawley & Stone 1998; Fleming et al. 2000; Bai & Stone 2011).
The Hall drift leads to qualitatively new behavior, due to its dispersive nature. In particular, it induces new branches of instability, and a polarity dependence on the largescale magnetic field (Wardle 1999; Balbus & Terquem 2001; Sano & Stone 2002; O’Keeffe & Downes 2014). Local simulations, using the shearingsheet approximation (Goldreich & LyndenBell 1965), found the emergence of organized structures from HallMHD turbulence. In nonstratified simulations, produces zonal flows (Kunz & Lesur 2013) and magnetized vortices (Béthune et al. 2016). These structures were not observed in the vertically stratified simulations of Lesur et al. (2014) and Bai (2015). Instead, the magnetic field was laminar and filled the disk midplane. As these authors point out, the results were influenced by their vertical boundary conditions.
The only way to ascertain whether these features are caused by boundary effects is to perform global models. Most of the properties of global, stratified and magnetized disks has been studied in the framework of ideal MHD (Fromang & Nelson 2006; Flock et al. 2011), albeit without any global poloidal field, preventing magnetized outflows. The inclusion of an global poloidal field in numerical simulations is notoriously difficult. Inner boundary conditions easily produce numerical artifacts, and high Alfvén speeds in the atmosphere can lead to dramatically small numerical time steps. For these reasons, relativistic simulations of disks around black holes (e.g., Beckwith et al. 2008) are technically easier to achieve. In the context of protoplanetary disks, initial attempts were either severely limited in computational time (Steinacker & Henning 2001) or did not resolve the smallscale dynamics of the disk (Murphy et al. 2010). The more recent models of Suzuki & Inutsuka (2014) improved the situation, but they could not access the outflow acceleration and collimation regimes due to their limited vertical extent. Global simulations including both ohmic and ambipolar diffusion were carried out by Gressel et al. (2015), using realistic estimates for the ionization state of the disk. However, the vertical extent of these simulations was again somewhat limited, casting doubts on the asymptotic properties of the wind. Moreover, they left open the question of Halldriven selforganization, as this effect was not included in their simulations.
This paper presents a series of global simulations of protoplanetary disks, including all three nonideal MHD effects in a domain suitable to study disk winds and integrated over many orbital periods. Our primary objective is the characterization of accretion and ejection in a weakly magnetized disk, freed from the limitations of local simulations, and resolving the internal dynamics of the disk. A second goal is to ascertain the role of the Hall drift in producing largescale, organized structures. The physical framework, including our assumptions, conventions and definitions, are given in Sect. 2. The specific method of resolution is described in Sect. 3, and our results are presented in Sect. 4. A discussion of our results is made in Sect. 5 before summarizing of our main findings in Sect. 6.
2. Framework
2.1. Physical model
We wish to model the dynamics of a protoplanetary disk orbiting a young stellar object. We do not include the star in our model, but rather look at the outer regions of the disk, down to one astronomical unit (au). We will consider the portion of a disk contained in a spherical shell, with an inner radius r_{0}, and covering the largest possible polar extent. We enumerate the main features of our disk model:

1.
the disk is geometrically thin;

2.
the disk is made of weakly ionized gas;

3.
the disk is threaded by a weak magnetic field;

4.
the disk is embedded in a warm corona.
We use the nonideal MHD framework, and thus describe neutral and charged particles as one fluid with internal currents (cf. Sect. 2.3). The disk chemistry is evolved in a very simplified way, always assuming chemical equilibrium (cf. Sect. 2.4). This is made possible by the short time scale of chemical processes in comparison with the local orbital period (Bai 2011). The surrounding radiation field is not solved for; instead, we prescribe the temperature distribution via a cooling/heating function (see Appendix C). We use two coordinate systems:

a cylindrical system (r,ϕ,z), with the vertical coordinate z along the cylindrical axis of the disk;

a spherical system (R,θ,ϕ), with the polar angle θ ∈ [ 0,π ] increasing from the northern to the southern hemisphere.
The disk will be denoted by the letter , while the symbols and will stand for the northern and southern coronal regions respectively.
2.1.1. Disk
Let c_{s} be the midplane sound speed and Ω the local orbital frequency. Under the influence of gravity and thermal pressure alone, a disk in hydrostatic equilibrium must be vertically stratified, its density varying on a characteristic vertical scale h ≡ c_{s}/ Ω. Protoplanetary disks are geometrically thin in the sense that the ratio h/r is typically within 0.03 to 0.2, increasing with cylindrical radius r (Bitsch et al. 2013). We set a constant ratio h/r = 5% at all radii by imposing a constant ratio of sound over Keplerian velocity c_{s}/v_{K} = 5% within the disk.
We only consider disks with a radial profile of surface density Σ(r) ∝ 1 /r. This is flatter than the r^{− 3/2} often found in the literature since Hayashi (1981), but seems to better fit recent observations (D’Alessio et al. 2001; Williams & Cieza 2011).
The ionization fraction controls the coupling of the magnetic field with the gas. We are not interested in the detailed chemical composition of the medium: the computation of nonideal MHD effects already comes with computational overhead, and the selfconsistent resolution of a full chemical network is prohibitively demanding in CPU hours^{1}. We reduce the disk chemistry to a local ionization fraction, computed dynamically with the evolution of the density distribution, and following the prescriptions of previous dedicated studies (cf. Sect. 2.4).
Largescale magnetic fields are observed in the vicinity of protoplanetary disks, hosted by the parent molecular cloud and presumably concentrated near the young stellar object (Rao et al. 2014; SeguraCox et al. 2015; Yang et al. 2016). Their global topology is still not well constrained, but their intensity is always weak in the sense that the midplane ratio of thermal over magnetic pressure β ≡ 2P/B^{2} ≳ 1 (Donati et al. 2005). Assuming that the global magnetic field has a nonzero vertical component, we will consider disks with initial average (midplane) β ≫ 1, constant with radius. Given our radial density profile, a constant β means that the average (midplane) Alfvén velocity is a constant fraction of the local Keplerian velocity.
2.1.2. Corona
To study the global dynamics of protoplanetary disks via direct numerical simulations, previous studies used locally isothermal disk models, where the temperature decreases as a function of the cylindrical radius (Fromang & Nelson 2006; Suzuki & Inutsuka 2014; Gressel et al. 2015). These solutions have their density decreasing exponentially fast with height, ρ/ρ_{0} ~ exp^{(}−z^{2}/ 2h^{2}^{)}. The Alfvén velocity increases exponentially with height; this is particularly appreciable in our case for we want a midplane β ≲ 10^{6} and over ten scale heights of vertical extent. Resolving the dynamics of these Alfvén waves over Keplerian time scales is numerically impractical, so we cannot rely on such cold disk equilibria alone^{2}.
Convertion from code to physical units.
It is known that protoplanetary disks are surrounded by a warm environment of optically thin and well ionized gas (Aresu et al. 2011; Bitsch et al. 2013; Woitke et al. 2016). Assuming hydrostatic equilibrium, the predicted coronal temperatures can go as high as ten thousand degrees at 1 au, above a disk at about 300 K. The corresponding ratios of corona to midplane sound speed range typically from 3 to 6.
To mimic this structure, we make the gas warmer above a certain height H(r). We take a constant corona to midplane temperature ratio at all radii for the sake of selfsimilarity (Contopoulos & Lovelace 1994; Casse & Ferreira 2000). This ratio is set to 6 in most simulations in order to avoid excessively low densities, so that the maximal Alfvén velocity remains comparable to the maximal Keplerian velocity (see Appendix C).
We set the transition height H based on the expected chemistry at the disk surface. Our ionization model, essentially the same as in Lesur et al. (2014), predicts a high ionization degree for z ≳ 3.6h (cf. their Fig. 1). More complete radiative transfer models also find a diskcorona transition at z ≈ 3h for r ∈ [1,10] au (Aresu et al. 2011). For these reasons, we heat the gas smoothly from H ≡ 3.7h to 4.7h (cf. Fig. 2 and Appendix A). The ratio H/h is held constant for simplicity. A selfconsistent treatment of the thermodynamics and radiative transfer in the corona is beyond the scope of the present paper.
2.2. Units and conventions
Unless otherwise stated, all quantities will be evaluated in our code unit system. We use the inner radius r_{0} and the Keplerian velocity v_{0} at the inner radius as our distance and velocity units. We use both the orbital frequency Ω_{0} ≡ v_{0}/r_{0} and period T_{0} ≡ 2π/ Ω_{0} to measure time. Densities are measured in comparison to the initial density ρ_{0} in the midplane and at the inner radius. The intensity of the magnetic field is measured by the corresponding Alfvén velocity .
The estimation of the ionization fraction introduces dimensional constants in the problem. We give in Table 1 the conversion from code to physical units in the fiducial case of a disk around a 1 M_{⊙} star, with a surface density of Σ(r) = 500 (r/ 1 au)^{1} g cm^{2}, and for the two considered simulation inner radii r_{0} = 1 au and r_{0} = 10 au.
We use the pressure scale height h(r) = 0.05r to normalize curvilinear abscissa in most figures; if the cylindrical radius r varies along the profile (for example along a streamline), then h(r) varies as well.
2.3. Dynamical equations
We consider the equations of inviscid, nonideal MHD. We denote by ρ the bulk mass density, P the gas pressure, v the bulk velocity, B =  B  e_{b} the magnetic field, J ≡ ∇ × B the electric current, Φ the gravitational potential. The three nonideal MHD effects, namely ohmic diffusion, ambipolar diffusion and the Hall effet, can be characterized by their effective diffusivities η_{O}, η_{A} and η_{H} respectively (Wardle 2007). It will be useful to rewrite the last two as where the Hall length ℓ_{H} and the ionneutral coupling time τ_{in} primarily depend on the ionization fraction and the nature of the charge carriers, but not on the magnetic field amplitude. In a singly charged ionelectron plasma, these coefficients read: where ⟨ σv ⟩ _{e,i} are respectively the electronneutral and ionneutral collision rates, ρ_{i} is the ion mass density, n is the neutral number density, n_{e} is the electron neutral density, m_{n,i,e} are the neutral, ion and electron masses and e is the elementary charge.
The evolution of mass density, momentum and magnetic field are governed by the following equations: The pressure distribution is locally isothermal, i.e., the isothermal sound speed is prescribed beforehand. The detailed treatment of the gas energetics is given in Appendix C.
2.4. Ionization fraction
The intensity of the nonideal MHD effects involves the local ionization fraction. We compute it via the same model as Lesur et al. (2014). This model includes stellar Xrays and far ultraviolet (FUV) photons, cosmic rays and radioactive decay. The ionization rates and penetration depths are taken from previous studies (Umebayashi & Nakano 1981, 2009; Bai & Goodman 2009; PerezBecker & Chiang 2011). The ionization rates from cosmic rays and radioactive decay are respectively ζ_{CR} = 10^{17} s^{1} and ζ_{RAD} = 10^{19} s^{1}. The Xray ionization rate is given by Eq. (21) of Bai & Goodman (2009), with a luminosity L_{X} = 10^{30} erg s^{1}. The total ionization rate is balanced by dissociative recombination, without dust grains nor metals (Fromang et al. 2002).
By soaking up electrons, dust grains can become one of the main charge carriers of the gas. Numerical simulations have not shown a drastic qualitative change when including “large” (micronsized) grains (Lesur et al. 2014; Gressel et al. 2015). However, submicronsized grains can increase the diffusivities by several orders of magnitude when they are sufficiently abundant (Salmeron & Wardle 2008; Xu & Bai 2016). The impact of small grains on the dynamics is therefore controlled by the dust size distribution, which is largely unconstrained. For this reason, our reaction network does not include grains.
Unlike in the local simulations of Lesur et al. (2014), we compute the ionization fraction every 1/8 inner orbit, consistently with the global evolution of the density distribution. Because we do not track the propagation of ionizing radiation, we simply use the gas column density integrated along the density gradient. The integration is thus performed in the polar direction instead of the vertical one. Both yield similar ionization profiles, because the regions of interest are located near the midplane.
Regarding the X and FUV radiations, they should originate from the central star before being scattered and absorbed in the disk’s upper layers. However, with h/r constant and ρ ~ R^{2}, the integration of density along spherical radius strongly depends on the lower integration bound. In addition, shadowing effects of the disk by the inner regions, which are excluded from the computational domain, could have an important dynamical impact (Bans & Königl 2012). We however ignore this additional degree of complexity in our model. We therefore use the polar column density to compute the X and FUV ionizing rates, affecting only the surface layers of the disk and mimicking a global flaring (Woitke et al. 2016; Aresu et al. 2011).
It is important to note that our ionization model is unable to model thermal ionization in the hot corona. For this reason, we assume the gas is fully ionized in the hot corona region by setting the diffusion coefficients to zero (see Sect. 3.3).
2.5. Main diagnostics and definitions
The averaging of a quantity X over the azimuthal angle is: (6)where Δϕ is the total azimuthal extent of the considered disk. Multiple indices denote consecutive averagings. Radial profiles are produced by integration in the disk region only: (7)The brackets and indices will be omitted when obvious from the context. Let ⟨X⟩_{ρ} ≡ ⟨ρX⟩_{ϕ,z}/ ⟨ρ⟩_{ϕ,z} be the density weighted average of X. We define the fluctuating Reynolds stress tensor by , where . The Maxwell stress tensor is defined as ℳ ≡ −B ⊗ B, and we define the sum . We normalize these quantities by the local, vertically averaged pressure; although the flow might not be turbulent, we use the same notation as Shakura & Sunyaev (1973): (8)and similarly for α^{ℳ} and separately. The average radial mass flux can be deduced from the conservation of angular momentum (Balbus & Papaloizou 1999): (9)where Σ(r) ≡ 2H(r)⟨ρ⟩_{ϕ,z} is the mass surface density, τ_{r} is the mass accretion rate due to to the radial transport of angular momentum, and τ_{z} the mass accretion rate due to angular momentum extracted by a wind through the surfaces z = ± H(r). We compute the wind mass loss rates through spherical shells at the outer simulation radius R_{out} in both hemispheres separately: (10)and the total mass lost in the wind per unit time is . We quantify the net toroidal magnetic flux through the disk with (11)so that ι_{ϕ} = ± 1 when a poloidal section of the disk is threaded by positive/negative toroidal field only, and zero when both polarities occupy the same area over this plane. We define (12)such that σ_{ϕ}> 0 when the angular momentum flux is directed from the disk to the corona in both hemispheres. The symmetry coefficients ι_{ϕ} and σ_{ϕ} are analogous to the zeroth and first Fourier coefficients of B_{ϕ}(z), respectively related to the net flux , and to the phase of the largescale fluctuations of B_{ϕ}(z).
Fig. 1 Northern half of the computational grid; from the midplane to the pole: deep disk region (dark blue), disk surface region (cyan), diskcorona transition layer (yellow) and corona (red).

Open with DEXTER
3. Method
3.1. Numerical scheme
We use the finitevolume code PLUTO (Mignone et al. 2007) to integrate Eqs. (3)to (5)in time. The simulations are either threedimensional or axisymmetric twodimensional. The conservative variables are evolved via an explicit second order RungeKutta scheme. Parabolic terms are also included explicitly; this and the dispersive Hall whistler waves introduce strong constraints on the admissible timesteps satisfying the Courant–Friedrichs–Lewy (CFL) criterion. The CFL constraint due to the Keplerian velocity field is weak in comparison, so we do not activate the FARGO orbital advection scheme (Mignone et al. 2012). Intercell fluxes are computed with a modified HLL Riemann solver, including the Hall drift in a conservative manner (Lesur et al. 2014). We use a piecewise linear space reconstruction to estimate the Godunov fluxes at cell interfaces, with the Van Leer slope limiter. The solenoidal condition ∇·B = 0 for the magnetic field is maintained to machine precision by the constrained transport method (Evans & Hawley 1988).
3.2. Computational domain and grid
The computational domain is defined in spherical geometry by (R,θ) ∈ [1,10] × [π/ 2−θ_{0},π/ 2 + θ_{0}], with the extremal polar angle θ_{0} ≡ 20 (h/r) ≈ π/ 3. We found no significant benefit from increasing this polar range toward the poles but additional numerical difficulties. The hydrostatic equilibrium has an excessively low density in this region, and is numerically unstable. The equilibrium velocity field is also very slow; with very little inertia, spurious radial in/outflows develop, with high velocities and associated shear ∂_{θ}v_{R}, disturbing the rest of the corona.
Fig. 2 Vertical profiles in runs R1–P4 (from 1 au to 10 au, with weak B_{z}> 0) at r = 5r_{0} = 5 au: initial (solid blue) and final (dashed green at 300T_{0}) ionization fractions and , and final sound speed (red dots) in units of the midplane orbital velocity.

Open with DEXTER
The polar interval is split into several ranges, as illustrated in Fig. 1. The deepest 4h are meshed with 64 uniform grid cells (dark blue region). The remaining range, from two to twenty scale heights (cyan + yellow + red), is meshed with 64 “stretched” cells, increasingly larger as we go to the polar boundary. This separation allows us to properly resolve the smallscale dynamics of the disk while not overresolving the large volume of the corona.
The radial interval is meshed with a logarithmic grid of 512 cells, i.e., the increment δr is proportional to the local radius r. This grid gets coarser as we go from the inner to the outer radial boundary, keeping a constant aspect ratio of grid cells at a given polar angle, and thus a constant numerical resolution per scale height. With this radial range, the initial mass in the disk region is always in code units.
Threedimensional runs have an azimuthal extension ϕ ∈ [0,π/ 2] to reduce computational cost compared to a full 2π disk. They are meshed with 128 uniformly distributed azimuthal cells.
3.3. Initial, boundary and internal conditions
We present here only the qualitative features of our numerical setup, and refer the reader to Appendices A to D for the details.
We initialize a cold disk plus warm corona hydrodynamic equilibrium. This thermodynamical configuration is held fixed during the simulation. A proper treatment of the thermodynamics would imply coupling the dynamics to radiative heating due to nonthermal radiation (typically Xrays and extreme UV) which is beyond the scope of this paper. We however motivate our temperature structure from fullblown radiative transfer calculations (e.g. Aresu et al. 2011). The temperature transition is smoothed at the disk surface (yellow transition layer in Fig. 1). The vertical profiles of temperature and ionization fraction at r = 5 au in a typical run are shown in Fig. 2. The overall ionization fraction does not evolve considerably over the duration of a simulation, but it is generally reduced at the disk surface due to the screening by the outflow. The transition from x_{e}< 10^{9} to x_{e}> 10^{5} is steep, but as desired, it is properly matched by our prescribed temperature increase. The initial magnetic field is vertical everywhere; its intensity decreases with cylindrical radius, so that the midplane β is constant with radius. The sign of the initial magnetic field is given with respect to the rotation axis; it can be either positive (Ω·B> 0) or negative (Ω·B< 0). We take Ω along + e_{z}.
We impose a minimal outflow velocity through the polar and outer radial boundaries. Because the global wind tends to flow radially outward, outflow conditions at the inner radial boundary are inappropriate; we thus allow matter to flow into the computational domain from this side. Buffer zones are added in the vicinity of the radial boundaries to avoid spurious wave reflections and reduce the influence of the boundaries on the flow.
We limit the Alfvén velocity to the Keplerian velocity at the inner disk radius, v_{A} ≤ v_{0} by artificially increasing the density in the concerned cells. This cap occasionally affects a few percent of the corona region. We relax the temperature toward its initial distribution over a characteristic time of 1/10Ω, so that the flow is locally isothermal to a good approximation.
Fig. 3 Vertical profiles of dimensionless numbers characterizing nonideal effects in the initial conditions at r = 5 au (left panel) and r = 50 au (right panel): inverse of the ambipolar Elsasser number (solid blue), inverse of the ohmic Reynolds number (dashed blue, multiplied by 10^{3} for visibility, both at 5 and 50 au), and ratio of the Hall length to the local pressure scale height ℓ_{H}/h (green dots).

Open with DEXTER
We draw in Fig. 3 the initial profiles of dimensionless numbers characterizing nonideal effects. The ambipolar Elsasser number Λ_{A} and ohmic Reynolds number ℛ_{O} are defined by (13)These numbers do not depend on the magnetic field. Their radial distribution are comparable to those derived by Simon et al. (2015; see their Fig. 1). Two procedures are applied to nonideal coefficients deduced from the ionization fraction, as described in Appendix D:

1.
We reduce diffusivity coefficients in the corona, progressivelyfrom z ≳ 3h to z ≲ 8h to account for the fact that the gas should become fully ionized in the corona.

2.
We restrict the intensity of ohmic diffusion, the Hall effect and ambipolar diffusion to avoid extremely small time steps. This restriction effectively affects the Hall effect below 2.3r_{0}, and ambipolar diffusion only in runs with the highest magnetization β = 5 × 10^{2}.
4. Results
We list in Table 2 the parameters of the runs presented in this paper. Runs are labeled according to their inner radius (R1 at r_{0} = 1 au, R10 at r_{0} = 10 au) and initial magnetic field (P for Ω·B> 0, M in the opposite case, followed by the magnitude of the midplane beta). Three dimensional runs are listed at the bottom, the rest being twodimensional axisymmetric simulations. All axisymmetric runs are integrated over 1000T_{0}, corresponding to approximately 32 orbits at the outer radius. Run 3DR1P4 is evolved for 300T_{0}, and the two other 3D runs for 200T_{0} only. It should be pointed out that each simulation shows a longterm (secular) evolution, where the largescale configuration evolves over hundreds of local orbits.
The main scalar diagnostics are gathered in Table 3, averaged over representative time intervals. We describe the properties of our reference simulation in Sect. 4.1. This run is not generic in every aspect, so we characterize a variety of other processes in the following sections. In Sect. 4.2, we examine the magnetic polarity dependence introduced by the Hall drift. The properties of the wind in a warm corona are described in Sect. 4.3. In Sect. 4.4, we presents disks in which the vertical flux of angular momentum causes a largescale meridional circulation, with no net mass accretion. Section 4.5 describes a vertical symmetry breaking, leading to a onesided magnetic ejection. Section 4.6 is dedicated to a selforganization process leading to the formation of zonal flows. Finally, our set of simulations is considered as a whole for discussion in Sect. 5.
Global parameters for the runs presented in this paper.
Results for the runs presented in this paper.
4.1. Fiducial case
4.1.1. Overview of the disk dynamics
We show in Fig. 4 the instantaneous state of run R10M3C2 after 200 inner orbits of integration time (6 outer orbits). The toroidal magnetic field B_{ϕ} changes sign at the midplane, and decreases smoothly with height in the corona. It also changes sign with radius near r ≈ 2.5r_{0}. This change of sign occurs near the inner radial boundary, where the magnetic field follows an inwardpointing wind. This inward orientation of the wind is likely influenced by our outflow polar boundary conditions.
To this magnetic field is associated a flux of angular momentum ℳ·e_{ϕ} = −B_{ϕ}B (purple arrows in the disk of Fig. 4). In the outer half of the disk, this flux is oriented from the midplane toward the corona. The velocity field is organized, with magnitudes reaching four times the local sound speed. In the inner half of the disk, the flux of angular momentum is directed from the disk surface toward its midplane. In this half, the corona is turbulent, with no signature of organized ejection.
Fig. 4 Snapshot of run R10M3C2 (fiducial) at t = 200T_{0}, showing the toroidal magnetic field in color background (blue to red), the poloidal velocity field in units of local sound speed (green arrows in the corona), and the orientation of the angular momentum flux caused by magnetic stress (purple arrows in the disk); ⟨B_{z}⟩ < 0 in this case.

Open with DEXTER
The length scale of magnetic field variations is comparable to the disk extent, both in the vertical and radial direction. Its characteristic dynamical time is counted in hundreds of local orbits, while the fluid may be streaming at near sonic velocities. The evolution of the magnetic field in the disk may therefore be considered as secular with respect to accretion and ejection. Given a time window, we can decompose the magnetic field in a time and azimuthally averaged component ⟨B⟩_{ϕ,t} plus a fluctuating component . Under this decomposition, the average magnetic stress is split into two terms: (14)representing a laminar plus a fluctuating contribution to ℳ. We compute the ratio of laminar to total magnetic stress over 30T_{0} (≈one outer orbit), average it over the poloidal surface of the disk, and find that it exceeds ℳ_{laminar}/ ⟨ℳ⟩ > 90% for every run. Therefore, the magnetic stress in the disk is not due to a turbulent component, but is rather a quasisteady (laminar) stress. The variability near the inner radius is likely caused by the outflow polar boundary conditions.
4.1.2. Disk vertical structure
We show in Fig. 5 a series of vertical profiles in the outer region of the fiducial run R10M3C2. In the top panel, we see that the deviations from Keplerian velocity become significant above z ≳ 2h. The radial velocity is the dominant component, with v_{R}/v_{K} ≈ 10%, corresponding to v_{R}/c_{s} ≈ 1 at z = 5h. The polar velocity v_{θ} is second in magnitude, reaching v_{θ}/v_{K} ≈ 5%. The azimuthal velocity decreases by 5% in the corona, compared to the disk midplane value at the same radius. This last trend could be due to the outflow itself, or to the thermal pressure support against gravity in the corona.
The second panel shows that the horizontal magnetic field has an odd symmetry about the midplane. The initial vertical component is negative in this case, and it is the weakest component during the evolution of the simulation. The toroidal component is anticorrelated to the radial one, with a magnitude twenty to a hundred times higher in the disk. The location where B_{ϕ} = B_{r} = 0 corresponds to a thin current sheet.
The third panel shows the horizontal and vertical magnetic stresses. The horizontal magnetic stress ℳ_{rϕ} is positive everywhere. It is maximal at the disk surface, where is ten times higher than in the midplane. The vertical stress ℳ_{zϕ} changes sign at the midplane, transporting angular momentum downward in the southern hemisphere and upward in the northern one. The largescale magnetic field thus extracts angular momentum from the disk, and transports it toward the corona.
In the fourth panel of Fig. 5, the radial mass flux displays a negative peak at the current sheet (i.e., the midplane is accreting), and becomes positive at the base of the wind z ≳ 2h. The accretion stream is very narrow, and accurately fits the profile of radial electric current. We show instead the relative ionelectron radial velocity, v_{i}−v_{e} ≡ J/n_{e}, which drives the Hall drift. Because this disk sees a net vertical magnetic field B_{z}< 0, the Lorentz force F_{ϕ} ≃ −J_{r}B_{z}< 0 is extremal at the current sheet, thereby slowing matter and causing it to fall inward.
Fig. 5 Vertical profiles in run R10M3C2 (fiducial), averaged in time from 200T_{0} to 600T_{0}, and in spherical radius from 5r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of the vertical field B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses ℳ_{rϕ} and ℳ_{zϕ}, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and ion minus electron radial velocity, normalized by the local Keplerian velocity and the vertically averaged density. Fifth panel: ambipolar diffusivity η_{A} (solid blue), ohmic diffusivity η_{O} (dashed blue, increased by a factor 10^{4} for visibility), and Hall length ℓ_{H} (green dots).

Open with DEXTER
The profile of radial electric current can be linked to the ambipolar diffusivity η_{A}, drawn in the bottom panel of Fig. 5. The magnetic energy dissipation rate due to ambipolar diffusion is , where J_{⊥} is the electric current perpendicular to the local magnetic field. To minimize energy dissipation, this current must flow along the circuit with the smallest resistivity. Low density and strong field regions are poorly conducting due to ambipolar diffusion (cf. Eq. (2)). This enforces the current layer to be localized near the midplane and near the current sheet, where η_{A} takes its smallest value. Ohmic resistivity is unimportant in this region, making ambipolar diffusion the dominant dissipation process. The presence of dust grains should not alter this ordering in the outer regions of protoplanetary disks (see Fig. 1 of Simon et al. 2015). With the present values of ℓ_{H} and B_{0}, the region below z ≲ 2h is stable with respect to the HallShear instability (HSI, Balbus & Terquem 2001; Kunz 2008).
4.1.3. Mass and momentum fluxes
We draw in Fig. 6 the radial profiles of stress in our fiducial run R10M3C2. The horizontal Maxwell stress ℳ_{rϕ} is positive at all radii, transporting angular momentum radially outward, with increasing from 10^{2} to 10^{1} from 10 au to 100 au. The vertical component ℳ_{zϕ} is positive beyond 2.5r_{0}, transporting angular momentum from the disk to the corona. The fact that ℳ_{ϕz} < 0 in the inner region is possibly related to our polar outflow boundary conditions. The Reynolds stress is negative for r ≳ 4.6r_{0}. This is because above z> 1h, the velocity fluctuations display and . Because  ℳ_{rϕ}  > 10  ℛ_{rϕ} , we will focus on the Maxwell stress for transportrelated processes.
Fig. 6 Radial profiles of normalized stress in R10M3C2 (fiducial), averaged in time between 200T_{0} and 600T_{0}. The radial components of Maxwell (red dots) and Reynolds (dashed blue) are averaged over the disk height, whereas the vertical Maxwell stress (solid green) is measured at the disk surface z = ± H.

Open with DEXTER
The absence of correlation , so as the fact that ⟨ℛ⟩_{ϕ,z}< 0, are discrepant with a state of MRI turbulence (Pessah et al. 2006). It was mentioned in Sect. 4.1.1 that the flow cannot be considered as turbulent, and that there is no clear spatial scale separation between the magnetic structures and the entire disk. For these reasons, the α viscosity prescription should not be applied in this context (Balbus & Papaloizou 1999). However, conservation of angular momentum still applies and we can use Eq. (9) to compute the accretion rate separately caused by radial and vertical angular momentum fluxes; this decomposition is represented in Fig. 7. We find that the vertical transport of angular momentum τ_{z} is the main driver of accretion. Conversely, the radial contribution τ_{r} oscillates about zero and causes no accretion on average. We recall that it does not contradict the presence of a significant radial stress (cf. Fig. 6) since accretion is controlled by the stress divergence. Finally, we find the average mass flux in this box is Σ⟨v_{r}⟩_{ρ} ≈ −4 × 10^{6} in code units, corresponding to an average accretion rate ṁ_{r} ≡  2πrΣ⟨v_{r}⟩_{ρ}  ≈ 1.1 × 10^{7}M_{⊙} yr^{1} at 50 au around a solarmass star.
We find that τ_{r} ≈ 0 in all our simulations, meaning that the radial flux of angular momentum is divergencefree. This is a fortuitous consequence of our initial Σ(r), β(r), etc. We will therefore focus on the vertical transport of angular momentum.
Fig. 7 Accretion in the disk region of run R10M3C2 (fiducial), between r ∈ [3,8]r_{0}; the actual mass flux (solid black) is decomposed into radial (dashed blue) and vertical (red dots) torques as explicited in Eq. (9); the sum is drawn (dashed cyan) to validate this decomposition.

Open with DEXTER
4.1.4. Cold, magnetized wind
We have shown that a wind is launched by the outer half of the disk, where the Maxwell stress transports angular momentum from the disk to the corona. We qualify these winds as “cold” since the ratio of sound speeds between the disk and the corona is set to k = 2 (which corresponds to a factor 4 in temperature).
To characterize these winds, we first look at the dynamics of a fluid element. We average every quantity in azimuth and time, and compute the characteristic velocities along a streamline in the poloidal plane. We recall the definition of the slow (minus sign) and fast (plus sign) magnetosonic waves velocity: (15)where the index p stands for the poloidal component of a vector. These velocities are relevant only in the ideal MHD regime.
As apparent in Fig. 8, the fluid poloidal velocity monotonically increases, and crosses all characteristic MHD velocities. Surprisingly, the fastmagnetosonic point is located right before the domain boundary. The same is true in several, but not all runs (see for example Fig. 13). This fact was already observed in stratified, shearingbox simulations (Fromang et al. 2013). It indicates that our boundary conditions are still, somehow, constraining the flow structure down to the disk in this run.
Fig. 8 Velocities projected on a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, and normalized by the Keplerian velocity at the launching radius v_{K0}; flow velocity v (solid black), sound speed c_{s} (dashed orange), Alfvén velocity v_{A} (dashed green), slow magnetosonic speed v_{−} (dashed blue) and fast magnetosonic speed v_{+} (red dots).

Open with DEXTER
The mass transported by the wind is computed via Eq. (10). We estimate its average value ṁ_{W} ≈ 2.6 × 10^{4} in code units, corresponding to approximately 2.3 × 10^{7}M_{⊙} yr^{1} for this run.
We compute separately the acceleration a_{p} ≡ v_{p}∂_{p}v_{p}, and the acceleration caused by the forces F along the streamline. These include the thermal pressure gradient, the Lorentz force, and the inertial force due to gravitational and centrifugal accelerations: (16)We present the resulting accelerations F/ρ in Fig. 9, normalized by the Keplerian value at the streamline base. The sum of the forces decently reproduces the true acceleration in spite of the variability of the flow. The thermal pressure gradient helps accelerating the flow, but it is significantly weak than the Lorentz force. The latter barely compensates the inertial term, resulting in an overall small wind acceleration a_{p}/a_{K0} ≲ 2%.
Fig. 9 Acceleration along a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, normalized by the Keplerian acceleration a_{K0} at the streamline base. The sum of the different forces (dashed cyan) is shown to validate this decomposition.

Open with DEXTER
We split the specific angular momentum of a fluid element into its matter and magnetic contributions: (17)where κ ≡ ρv_{p}/B_{p} is the ratio of mass over magnetic flux along the streamline. Both j and κ should be invariant along streamlines for stationary, axisymmetric, ideal MHD flows (Chandrasekhar 1956; Pelletier & Pudritz 1992). We show in Fig. 10 that the total specific angular momentum j is approximately constant above z ≳ 5h. The magnetic torque transfers angular momentum back to the outflowing plasma, leading to an increase of the kinetic content up to the domain boundary. This demonstrates that the wind is magnetocentrifugally accelerated. Below 5h, the variations of j indicate that the average flow does not behave as an ideally conducting plasma. This is caused by ambipolar diffusion above the disk surface. It should be noted that the outflow is already superAlfvénic when entering the ideal MHD regime z ≳ 5h (cf. Fig. 8). As a consequence, only the sonic and fastmagnetosonic critical points can impose regularity conditions on the outflow (Ferreira & Pelletier 1995).
The magnetic contribution to j is only 0.4j_{0}, corresponding to a magnetic lever arm λ ≈ 1.4, much smaller than expected from strongly magnetized jets (see Fig. 4 of Ferreira 1997). For a magnetic lever arm smaller than 3/2, the Bernoulli invariant of a cold flow should be negative (Casse & Ferreira 2000); this is indeed the case in this simulation. It follows that the outflow cannot escape the gravitational field on its own energy content when it reaches the domain boundary. The outflow can have ℬ < 0, and still be both stationary and super fastmagnetosonic. Effectively, ℬ < 0 corresponds to an outflow which is gravitationally bound when z → ∞, but it is not necessarily bound for the gravitational potential restricted to the computation box.
Fig. 10 Angular momentum along a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, normalized to its value at the streamline base; the total angular momentum (solid black) is decomposed into matter (dashed blue) and magnetic (red dots) components as explicited in Eq. (17).

Open with DEXTER
4.2. Hall and magnetic field polarity
It is known that the Hall drift discriminates between the two polarities of the vertical magnetic field (Balbus & Terquem 2001). When Ω·B> 0, the Hall drift acts to enhance angular momentum transport; in the opposite case Ω·B< 0, the Hall drift tends to stabilize the flow, and greatly reduce angular momentum transport (Lesur et al. 2014).
We draw in Fig. 11 the vertical profiles of horizontal stress ℳ_{rϕ} for the two orientations of the initial magnetic field. When B_{z}> 0 (run 3DR1P4), there are three regions of important magnetic stress: the midplane and the two diskcorona interfaces. The midplane stress reaches and decreases exponentially fast with height. Near z ≈ 2.7h, the surface stress becomes dominant, and increases up to z ≈ H, where it reaches . This profile is similar to what was found in local shearingbox simulations (see Fig. 13 of Lesur et al. 2014). In the opposite case B_{z}< 0 (run 3DR1M4), the surface stress is essentially the same, but the midplane stress is now .
The vertical distribution of ℓ_{H} is overlaid in Fig. 11. It reaches ℓ_{H}/h ~ 1 deep in the disk, and decreases rapidly with height. In run 3DR1M4, below z ≲ 2h, the combination of a strong Hall length and a negative vertical magnetic field stabilizes the disk with respect to the HSI. At z ≳ 3h, the Hall drift becomes negligible regarding the linear stability of the flow, and we retrieve a polarityindependent system.
Fig. 11 Vertical profiles of horizontal magnetic stress, normalized by the vertically averaged pressure in the disk ℳ_{rϕ}/ ⟨P⟩_{z} in runs 3DR1P4 (solid blue, Ω·B> 0) and 3DR1M4 (dashed red, Ω·B< 0), averaged in time over 50T_{0} and radially from 3r_{0} to 6r_{0}; the green dots show the average ratio ℓ_{H}/h in this same region.

Open with DEXTER
The volumeaveraged values of differ only by a factor two between run R1P3 (R10P3), and the equivalent run with a reversed field R1M3 (resp. R10M3, cf. Table 3). This estimated includes the disk up to z ≤ H, so part of it is due to the polarityindependent surface stress. Also, the midplane is not magnetically dead when B_{z}< 0 and the initial magnetization β ≤ 5 × 10^{3} (see third panel of Fig. 5). As the intensity of the net magnetic flux increases, so does the magnetic stress at the disk surface, and the ambipolar diffusivity. The magnetic field can then diffuse, from the surface to the midplane, over a few tens of local orbits (cf. Sect. 5.1). The surface over midplane stress contrast is smaller at larger radii, where the Hall drift is weaker (see fifth panel of Fig. 5).
We conclude that ℳ_{rϕ} ≈ 0 in the midplane only when the midplane is Hallshear stable, and the intensity of the background field is sufficiently weak. For stronger magnetic fields, the surfacedriven torque can reach the midplane (see for example Wardle & Koenigl 1993; Salmeron et al. 2011).
4.3. Warm winds
We described the launching and acceleration of a cold, magnetized wind in our reference simulation with k = 2. In this section, we investigate the role of thermal pressure with a warmer corona. We consider a corona over disk temperature ratio of 36, i.e., a ratio of k = 6 in isothermal sound speed.
4.3.1. Overview
We show in Fig. 12 the average flow morphology in run R10M3, initially threaded by a negative B_{z}< 0. The density in the disk has homogeneously decreased by 10%, maintaining its radial and vertical stratification profiles. Magnetic field lines are straight in the disk, as one can expect in a diffusiondominated regime. In the inner regions of the corona, the field lines remain vertical or bend inward. Because the magnetic field is the weakest in these regions, it exerts no constraints on the fluid. The velocity field in the innermost region appears to be affected by our outflow polar boundary conditions.
The initial magnetic field has been substantially reduced for radii as far as 3r_{0}, where positive magnetic flux has entered the domain from the inner radial boundary. Although this phenomenon is artificially caused by our boundary conditions, it calls for a dedicated study of the Halldriven transport of magnetic flux in protoplanetary disks (Bai & Stone 2016). The outer corona displays a laminar structure. Field lines bend outward, with an inclination greater than 60° at the disk surface, favorable to magnetocentrifugal acceleration. The poloidal velocity and magnetic field lines are aligned in this region, consistently with a quasisteady and ideal MHD wind. The average wind mass loss rate is ṁ_{W} ≈ 2.7 × 10^{5} in code units. This corresponds to approximately 1.7 × 10^{7}M_{⊙} yr^{1} at 100 au, comparable to our fiducial case despite the temperature difference.
Fig. 12 Averaged flow poloidal map for run R10M3 (from 10 au to 100 au, with B_{z}< 0) from 400T_{0} to 700T_{0}; magnetic field lines are regularly sampled along the midplane, and the velocity field is indicated with green arrows over the background density field.

Open with DEXTER
We select a streamline in the poloidal plane, passing through (r = 7r_{0},z = 5h). The flow and the characteristic MHD velocities are projected on this streamline in Fig. 13. The increase in sound speed, from z = 3.7h to 4.7h, marks the diskcorona temperature transition. As for the fiducial, cold corona case (cf. Fig. 8), the slowmagnetosonic and Alfvén critical points are crossed at z ≈ 4h. The fastmagnetosonic critical point is now clearly within the computational domain. It is crossed by the outflow way before reaching the outer radial boundary, so the base of the wind should be causally disconnected from the boundary.
Fig. 13 Same as Fig. 8 for a streamline passing through (r = 7r_{0},z = 5h) in run R10M3, averaged from 400T_{0} to 700T_{0}. The fastmagnetosonic point is clearly crossed within the computational domain.

Open with DEXTER
The magnetic field again contributes to 0.4j_{0} in the specific angular momentum along this streamline. According to steadystate MHD jet theory, a small magnetic lever arm λ ≈ 1.4 corresponds to an ejection efficiency ξ ≡ ∂log ṁ_{W}/∂log r ~ 1 (Ferreira & Pelletier 1993; Ferreira 1997). This is consistent with the high ratio of mass outflow over mass accretion rates observed in our simulation. In this case, there would be too much matter loaded into the wind to obtain a steady and transAlfvénic outflow without coronal heating (cf. Eq. (40) of Ferreira 1997).
4.3.2. Energy budget
We examine the energetics of the outflow by means of the Bernoulli invariant. Following Suzuki & Inutsuka (2009), we decompose the ideal MHD Poynting flux as: (18)The first term can be thought of as the advection of magnetic energy by the flow; the second term gives the wavelike transport of energy. Given a streamline, we can decompose the integral (19)respectively an enthalpy contribution minus a heating term. The first corresponds to the adiabatic work exerted by the fluid, whereas the second measures its variation of specific entropy s. By dotting Eq (4)with v, we can construct a quantity constant along stationary streamlines, the Bernoulli invariant: (20)Because Q keeps an integral form, the value of ℬ′ along a streamline depends on the choice of integration bounds. We choose to subtract from ℬ′ the heat input evaluated at the domain boundary: ℬ ≡ ℬ′ + Q_{end}. With this definition, a fluid element having ℬ > 0 is able to escape the gravitational potential on its own energetic content, without additional heating past the domain boundary.
We draw the various contributions to ℬ along the streamline in Fig. 14. The poloidal component keeps increasing, as already apparent in Fig. 13. The toroidal component is initially the main energy reservoir against gravity, and slowly decreases. This is because the fluid specific angular momentum rv_{ϕ} is approximately constant above z ≳ 5h, so v_{ϕ} decreases as 1 /r along the streamline. The wavelike Poynting flux is strong at the disk surface z ≈ 3.2h, and most of it has been consumed at the end of the streamline. However, it is efficiently converted into kinetic energy only in the idealMHD region z ≳ 5h. The thermal contributions to the Bernoulli invariant, namely ℋ and , both increase at the diskcorona transition. Beyond z ≳ 5.5h, the enthalpy ℋ decreases, while the heating keeps increasing. The decrease in enthalpy corresponds to the adiabatic cooling of the fluid, exerting a mechanical work and thus contributing to the outflow acceleration. The increase in means that the fluid keeps receiving heat, because it is always colder than the prescribed temperature at a given location.
Fig. 14 Contributions to the Bernoulli invariant ℬ (solid black) as explicited in Eq. (20), along a streamline passing through (r = 7r_{0},z = 5h) in run R10M3, averaged from 400T_{0} to 700T_{0}; the gravitational contribution is not shown.

Open with DEXTER
The final value of is positive in this case, so the outflow has the potential to escape from the gravitational field. We note that the heating is necessary to make ℬ > 0. The quantity increases along the streamline, and it becomes positive at z ≈ 5.1h. In principle, we could stop heating above this height, and keep a potentially released flow.
The analysis of the Bernoulli invariant suggests that magnetic acceleration is important only at the wind basis, whereas most of the remaining acceleration along the streamline is due to coronal heating. This association constitutes the key mechanism at the origin of the magnetothermal winds we observe in these simulations. This is an extension of the situation described by Casse & Ferreira (2000), with the important difference that the flow becomes superAlfvénic in the nonideal MHD zone.
4.3.3. Ejection mechanism
We examine the role of coronal heating in the lifting and acceleration of material along a streamline in run R10M3. The acceleration of a fluid element and its decomposition into pressure, Lorentz and inertial forces are drawn in Fig. 15. The true acceleration a_{p} is about 15% stronger than the sum reconstructed from the averaged forces. This bias may be due to the correlated fluctuations of density with the Lorentz force, or between velocity components in the inertial term. We verified that it is entirely removed in runs showing better stationarity properties.
At the surface of the disk z ≲ H, the streamline is nearly vertical. In this direction, the inertial potential precisely cancels the vertical pressure gradient, as required from the initial, hydrostatic equilibrium. In the transition region z/h ∈ [3.7,4.7], matter from the disk is being pushed down toward the midplane by the hot gas at the base of the corona. The inertial acceleration is negligible in this region, and it is the Lorentz force that provides the kick lifting matter up into the hotter wind region.
Because the streamlines strongly bend outward at z> 4.7h, the radial pressure gradient becomes favorable to the outflow, whereas the Lorentz force is negligible in this region. For z> 6h, the acceleration produced by thermal pressure gradients decreases, whereas magnetic acceleration increases again. This is generic to all magneticallyejecting runs with a warm corona.
Fig. 15 Same as Fig. 9 in run R10M3, averaged in time between 400T_{0} and 700T_{0}, with a streamline passing through (r = 7r_{0},z = 5h).

Open with DEXTER
We conclude that in our warm corona simulations, mass is still loaded into the wind by the Lorentz force. The vertical temperature gradient acts against the launching of a wind. The radial temperature gradient bends the magnetic field lines, and causes the outward acceleration of the flow along these lines.
4.4. Nonaccreting disks
Some of our simulations do not exhibit accretion streams in the midplane. In this section, we describe the opposite configurations, where the radial mass flux is directed outward in the midplane and inward at the disk surface, resulting in a largescale meridional circulation (Fromang et al. 2011). We focus on run R1P4C4, which adopted this configuration over the entire duration of the simulation. Although R1P4C4 differs from our fiducial case R10M3C2 by four control parameters, only the orientation of the net magnetic field seems to affect this outcome in our simulations (cf. Sect. 5.1).
4.4.1. Overview
We show in Fig. 16 the morphology of the flow in run R1P4C4. We note several differences with our fiducial case (cf. Fig. 4). First, the entire corona exhibits a disorganized velocity structure. There are no signatures of acceleration above the disk, and the flow reaches moderate velocities. Second, the toroidal magnetic field does not expand to the corona, but remains confined within the disk instead. Finally, the largescale magnetic field transport angular momentum from the disk surface to its midplane.
Fig. 16 Snapshot of run R1P4C4 (from 1 au to 10 au, with weak B_{z}> 0) at t = 1000T_{0}, showing the toroidal magnetic field in color background (blue to red), the poloidal velocity field in units of local sound speed (green arrows in the corona), and the orientation of the angular momentum flux caused by magnetic stress (purple arrows in the disk). The orientation of the angular momentum flux is reversed compared to the fiducial, accreting case.

Open with DEXTER
As mentioned in Sect. 4.1.1, studying this configuration isolately makes sense because magnetic structures evolve over long time scales. However, the accreting property can vary in space (cf. Sect. 4.4.4), and in time for a given simulation.
4.4.2. Vertical structure
We show in Fig. 17 the vertical structure of the flow in run R1P4C4. In the first panel, the radial velocity is negative at the disk surface, where it reaches v_{R}/c_{s} ≈ −0.4. It becomes positive above z ≈ 4.3h, with v_{R}/v_{K} ≈ 5%, two times smaller than the fiducial case. The azimuthal velocity drops at z ≈ H, where the gas is heated. The polar velocity v_{θ} is negligible up to z ≈ 4.3h, beyond which it increases to 2% of v_{K}, again small compared to the fiducial case (cf. Fig. 5). This outflow is launched twice higher than in the fiducial case, near the temperature transition at z ≈ H, suggesting a predominantly thermal wind launching.
The second panel shows that the toroidal magnetic field is dominant in the disk, twenty to eighty times greater than the radial one. Unlike the fiducial accreting case, the toroidal field B_{ϕ} vanishes at z ≈ 4.7h, and does not expand to the corona.
The resulting vertical stress ℳ_{zϕ} is negligible in the corona. The disk thus receives no angular momentum from the corona, and a fortiori from our polar boundary conditions. Within the disk, the Maxwell stress ℳ_{zϕ} is positive in the southern hemisphere, and negative in the northern one. This induces a flux of angular momentum from the disk surface toward its midplane.
The fourth panel shows that mass is now streaming outward in the midplane, and inward at the surface. This is consistent with the idea that angular momentum is extracted from the surface, and provided to the midplane by magnetic stress. We emphasize that the net radial mass flux is approximately zero through this meridional circulation. The disk does not receive angular momentum from the corona, and mass accretion is solely caused by the radial flux of angular momentum, τ_{r} ≈ 0, as shown in Fig. 7.
Fig. 17 Vertical profiles in run R1P4C4, averaged in time from 400T_{0} to 1000T_{0}, and in spherical radius from 5r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of the vertical field B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and electron minus ion radial velocity, normalized by the local Keplerian velocity and the vertically averaged density.

Open with DEXTER
The property of being accreting or not essentially depends on the sign of ℳ_{zϕ} ≡ −B_{z}B_{ϕ}. Because the disk is threaded by a net vertical magnetic field, and because the flow is laminar, the orientation of the angular momentum flux is given by the sign of B_{ϕ} in both hemispheres. We will refer to this as the vertical phase of the toroidal field. When B_{ϕ} has a nonaccreting phase, the radial velocity is oriented outward in the midplane, and inward at the disk surface. The radial pressure gradient is negative in the corona, so it opposes the launching of a wind directed inward. This imposes a meridional circulation within the disk.
The pressure gradient forces the radial velocity to change sign above z ≳ H. The resulting outflow is thermally driven. It reaches moderate velocities, and it is not organized on large scales. We were not able to reconstruct streamlines leaving the disk surface, because of the timevariability of the flow in the corona. We presume that the outflow mass loading results from turbulence above the accretion layers. Forcing an outflow velocity at the domain boundaries greatly improved the numerical stability of our setup in such configurations.
We measured the phase of B_{ϕ} in every run via σ_{ϕ}, as defined by Eq. (12). Runs having σ_{ϕ}> 0 should be accreting, whereas σ_{ϕ}< 0 corresponds to predominantly nonaccreting configurations. Runs with σ_{ϕ} ≈ 0 are the object of Sect. 4.5. Timeaveraged values of σ_{ϕ} for every runs are given in Table 3.
4.4.3. Magnetic equilibrium
We raise two questions regarding the magnetic equilibrium of the nonaccreting configuration. First, if there is no outflow to remove toroidal magnetic flux, another process must be responsible for the saturation of the MRI. Second, because the corona rotates slower than the disk, the net vertical field should always exert a global torque on the disk, favoring the accreting configuration. To address these issues, we split the induction Eq. (5)into several terms, labeled by the associated physical process: where the electromotive field ℰ_{O,H,A} contains the three nonideal effects, as developped in Eq (21).
We represent in Fig. 18 these contributions to the induction of toroidal magnetic field ∂_{t}B_{ϕ}. The ohmic and Hall induction terms are not shown for they are negligible in this case.
The sum of the outflow plus advection terms has a minor effect, located at z ≈ H. Deep in the disk, the shearing of B_{R} is only balanced by ambipolar diffusion. At z ≈ 3.4h, where the toroidal Alfvén velocity is maximal, ambipolar diffusion transports the toroidal field toward the surface, and not toward the midplane. In the surface layers z ≈ H, we find a competition between the stretching of B_{z} and the shearing of B_{R}. Since the stretching term favors an accreting phase for B_{ϕ}, the nonaccreting configuration sustains a counteracting B_{R} at the surface.
Fig. 18 Contributions to the induction of toroidal magnetic field in run R1P4C4, as explicited in Eq. (22), averaged in time from 400T_{0} to 1000T_{0} and in spherical radius from 5r_{0} to 8r_{0}, normalized by the local Keplerian frequency and the local initial magnetic field.

Open with DEXTER
Fig. 19 Same as Fig. 18 for the radial magnetic field B_{R}; see Eq. (21).

Open with DEXTER
The same decomposition is performed for the radial component B_{R} in Fig. 19. The ohmic contribution is negligible again, so we do not plot it. The Hall term is effective below z ≲ 2h, balanced by ambipolar diffusion. At the surface z ≳ 3h, the outflow term has a moderate amplitude, and we find a competition between ambipolar diffusion and the stretching of B_{θ}.
The region z< 2h is separated from the disk surface. Near the midplane, it is the HSI that causes the growth of horizontal magnetic field. Near the surface, the feedback loop corresponds to the MRI: the accretion layers stretch B_{z} into B_{r}, which is sheared into B_{ϕ}; the resulting stress ℳ_{zϕ} removes angular momentum from the surface, thereby enhancing the accretion layers. Ambipolar diffusion is responsible for the saturation of the HSI in the midplane, and of the MRI at the disk surface.
4.4.4. Coexistence of accreting and nonaccreting regions
All the cases presented so far were relatively symmetric with respect to the disk midplane. In particular, the inward or outward mass streams were located near the midplane. Yet we have disks exhibiting both accreting and nonaccreting behaviors at the same time. We show the radial transition between two different portions of the same disk in Fig. 20.
Fig. 20 Same as Fig. 16 for run R1P4 at t = 1000T_{0}. The disk exhibits both an accreting (inner) and a nonaccreting (outer) region.

Open with DEXTER
As mentionned in Sect. 4.1.2, the mass flux actually follows the B_{ϕ} = 0 layer, where the electric current is extremal. The transition from an accreting to a nonaccreting disk region necessarily comes with the current sheet reaching the surface of the disk. In a region where B_{ϕ} has a nonaccreting phase, there is no magnetized outflow, and B_{ϕ} ≈ 0 above the disk. In this case, the mass flux follows closed circulation loops along the current sheet, inward at the surface and outward in the midplane. At the intersection with an accreting region, part of this mass flux is reoriented into the wind, and part of it goes to the midplane.
4.5. Vertical symmetry breaking
This section describes a spontaneous breaking of the up/down symmetry identified in our simulations. It is related to the emergence of a favored magnetic polarity over long time scales.
4.5.1. Overview
Within our stratified setup, the horizontal magnetic flux is free to leave the disk in the vertical direction. One polarity can be removed or amplified faster than the other, leaving the disk with only one sign of B_{ϕ}. This was observed in stratified shearingbox simulations (Lesur et al. 2014; Bai 2015), but considered unlikely to be directly connected to a global flow geometry. Focusing on the horizontal magnetic field, we will refer to these as even configurations with respect to the disk midplane in opposition to states showing an odd symmetry.
Such a configuration is illustrated in Fig. 21 for run R1M3. The entire disk sees B_{ϕ}< 0; the Keplerian and Hall shears ensure that B_{r}> 0 is also even about the midplane. In the inner half of the northern corona, the magnetic field lines do not guide the velocity field. Because the corona obeys ideal MHD, this implies that this part of the flow is turbulent, resulting in an effective “turbulent diffusion” for the timeaveraged flow. On the contrary, the outflow in the southern corona is very laminar and stationary. A magnetic collimation effect is observed in this hemisphere.
Fig. 21 Averaged flow poloidal map for run R1M3 (from 1 au to 10 au, with moderate B_{z}< 0) from 800T_{0} to 1000T_{0}; magnetic field lines are sampled along the midplane, and the velocity field is indicated with green arrows over the background toroidal field. The polar asymmetry and the absence of B_{ϕ} sign reversal within the disk are obvious.

Open with DEXTER
4.5.2. Vertical structure
The vertical structure of run R1M3 is represented in Fig. 22. A strong outflow is launched in the southern hemisphere, with v_{θ}/v_{K} ≈ 20% at z ≈ −8h. The toroidal velocity is higher than the local Keplerian value, down to z ≈ −6h. The outflow receives angular momentum via the Maxwell stress ℳ_{zϕ}, and transports mass at a rate . Picking a streamline passing through (r = 6r_{0},z = −5h), its total angular momentum is 1.5 times larger than the Keplerian value at the wind base, it crosses the fastmagnetosonic velocity before reaching the domain boundary, and its Bernoulli invariant .
On the other side, the northern hemisphere displays the properties of a nonaccreting disk (cf. Fig. 17). The radial velocity is oriented inward at the disk surface, and the outflow has a moderate velocity. The toroidal field B_{ϕ} = 0 at z ≈ 4h, beyond which the vertical flux of angular momentum is essentially zero.
Because B_{z} and B_{ϕ} keep the same sign within the disk, the vertical flux of angular momentum ℳ_{zϕ} is unidirectional. We find ℳ_{zϕ} ≈ 0 for z ≳ + 4h, and ℳ_{zϕ}< 0 below. The gradient ∂_{z}ℳ_{zϕ} thus takes angular momentum from the disk northern surface, and transports it toward the southern hemisphere. This causes both the radial flows at the disk surface, and the magnetic wind launching in the southern hemisphere. Since ℳ_{zϕ} ≈ 0 in the northern corona, the disk is not pumping angular momentum from the northern domain boundaries.
Fig. 22 Vertical profiles in run R1M3, averaged in time from 800T_{0} to 1000T_{0}, and in spherical radius from 6r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and ion minus electron radial velocity, normalized by the local Keplerian velocity and average density.

Open with DEXTER
The fourth panel of Fig. 22 shows an accretion layer at the northern surface, and a decreting layer at the southern one. On average, the net mass flux is slowly accreting, with τ_{z} = (−4 ± 5) × 10^{7}. We have separated the southern and northern wind mass loss rates and (cf. Eq. (10)). Table 3 confirms that when ι_{ϕ} × sign(B_{z}) > 0, i.e., the magnetically ejecting side transports more mass.
4.5.3. Secular evolution of vertical symmetries
We examine the onset of an even configuration in run R1P2, which did not immediately choose a favored polarity. We draw in Fig. 23 the symmetry coefficients ι_{ϕ} and σ_{ϕ} over time, respectively defined by Eqs. (11)and (12). ι_{ϕ} defines the average polarity of B_{ϕ} in the disk, whereas σ_{ϕ} characterizes B_{ϕ} symmetry across the midplane, the ejecting configurations with accretion in the disk midplane corresponding to σ_{ϕ} > 0.
During the first 100 T_{0}, ι_{ϕ} ≈ 0 indicates that both polarities of B_{ϕ} are equally present in the disk. The average phase of B_{ϕ} evolves from an accreting configuration σ_{ϕ} > 0 to a nonaccreting one σ_{ϕ} < 0 in this interval. From 100T_{0} to 200T_{0}, the increase in ι_{ϕ} means that the positive B_{ϕ} > 0 polarity is filling the disk. The fact that σ_{ϕ} goes to zero confirms that the disk is adopting an even B_{ϕ} symmetry.
Fig. 23 Evolution of the symmetry coefficients ι_{ϕ} and σ_{ϕ} in run R1P2; data have been averaged over bins of 10T_{0}.

Open with DEXTER
We consider a spacetime window in which the transition from an odd to an even B_{ϕ} symmetry is taking place (between t = 120 T_{0} and t = 130 T_{0}), and look at vertical transport of the horizontal magnetic field. We decompose the induction of radial field B_{R} in Fig. 24. In the upper panel, we see that the electric current layer is displaced of z ≈ −1.5h from the midplane, coinciding with the current sheet where B_{r} = 0. This current layer keeps drifting downward in time, and eventually leaves the disk (fourth panel of Fig. 22).
Fig. 24 Vertical profiles in run R1P2, averaged in time between 120T_{0} and 130T_{0}, and in spherical radius between 5.5r_{0} and 6r_{0}; upper panel: sonic Mach number for the radial Alfvén velocity (solid blue) and electron minus ion velocity, normalized by the Keplerian velocity (dashed red); lower panel: induction of radial magnetic field.

Open with DEXTER
In the lower panel of Fig. 24, we show that the transport of negative B_{R} < 0, from the midplane toward the southern surface, is mainly driven by ambipolar diffusion. The outflow and Hall contributions have a negligible impact on this process. Similar symmetrybreaking solutions have been observed in shearing box simulations (Lesur et al. 2014; Bai 2015). The cause of this phenomenon is yet unknown, but it appears to be robust.
4.6. Selforganization: zonal flows
This section describes the emergence of zonal flows in our simulations, characterized by axisymmetric density rings, together with magnetic field accumulations.
4.6.1. Overview
We illustrate in Fig. 25 the morphology of the flow in run R1P2. We see a series of density bumps in the disk, radially separated by approximately the local disk thickness 2H. The magnetic flux is concentrated in low density regions, and this foliation is maintained in both coronae. Some magnetic flux accumulations can momentarily be as narrow as eight grid cells in the disk. However, with a magnetic Reynolds number ℛ_{A} ≈ 3, we believe that this width is primarily attributed to physical diffusivity and not numerical diffusion. This run also displays an even B_{ϕ} symmetry, causing the tilting of magnetic field lines through the disk. As in run R1M3 (cf. Fig. 21), ejection is thermally driven in the northern corona, and magnetically enhanced in the southern one.
Fig. 25 Averaged flow poloidal map for run R1P2 (from 1 au to 10 au, with strong B_{z} > 0), from 500T_{0} to 700T_{0}; magnetic field lines are sampled along the midplane, and the velocity field is indicated with green arrows over the background density field. Magnetic field lines are accumulated in low density rings.

Open with DEXTER
Density and magnetic field fluctuations are anticorrelated. Table 3 shows that runs with B_{z} < 0 or β > 5 × 10^{3} do not exhibit such structures. These are the runs in which the disk midplane is Hallshear stable, or has linear growth rates smaller than 0.01Ω. Because our 3D simulations were integrated over shorter time intervals, the indicated number of zonal flows cannot directly be compared between equivalent 2D and 3D runs.
4.6.2. Selforganization mechanism
The induction of B_{z} is governed by the toroidal electromotive force (EMF), the same as in Eq. (21): (23)so the average B_{z} increases in time where ℰ_{ϕ} decreases with radius. The ideal, Hall and ambipolar EMFs can be expressed as: The first panel of Fig. 26 shows the anticorrelated fluctuations of density and magnetic field. In the second panel, we plot the averaged EMFs. The ohmic contribution has been omitted for it is negligible and cannot confine magnetic flux. The ideal term ℰ_{Iϕ} increases with radius at the location of each magnetic field concentration. The velocity field thus acts as a turbulent diffusion. The ambipolar term precisely balances the ideal one, so it decreases with radius at the location of each band. This was already noted by Bai & Stone (2014; see their Fig. 8). Ambipolar diffusion is therefore responsible for the accumulation of B_{z}. Apart from being negligible by a factor 50, the Hall term acts against the accumulation of magnetic flux. Halldriven selforganization requires the magnetic stress and flux to be anticorrelated (Kunz & Lesur 2013). This is possible in nonstratified simulations, when the net magnetic flux becomes strong enough to stabilize the HSI. In stratified simulations, the winddriven stress − B_{ϕ}B_{p} is known to correlate with the net magnetic flux for β ≫ 1 (Lesur et al. 2014). Selforganization can thus be inhibited if the wind drives the magnetic stress in Hallshear stable (i.e., strong field) regions.
Fig. 26 Radial profiles in run R1P2, vertically averaged through the disk from 500T_{0} to 700T_{0}; first panel: density (solid blue) and vertical magnetic field (dashed red), normalized by their initial profiles; second panel: ideal (solid blue) ambipolar (dashed red) and Hall (black dots, multiplied by 50 for visibility) electromotive forces, given by Eq. (24); third panel: toroidal component of the electric current J_{ϕ} (solid blue), and of its projection J_{⊥ ϕ} normal to the magnetic field; the vertical lines mark the location of magnetic field maxima.

Open with DEXTER
Fig. 27 Ambipolardriven selforganization mechanism: the electric current J is mainly radial, and the magnetic field B is mainly toroidal; as a result, the signs of J_{ϕ} and J_{⊥ ϕ} are opposed; this is equivalent to a negative diffusivity for B_{z} (cf. Eq. (24)).

Open with DEXTER
The direction of the ambipolar EMF is given by the electric current projected perpendicularly to the local magnetic field. Upon projection, the sign of the toroidal component J_{⊥ ϕ} can become opposed to the sign of J_{ϕ}. This is what happens in our simulations featuring zonal flows, as shown in the bottom panel of Fig. 26. In this case, the toroidal component of ℰ_{A} yields a negative effective resistivity (cf. Eq. (24)).
Fig. 28 Radial profiles of normalized stress in R1P2, averaged in time between 500T_{0} and 700T_{0}.

Open with DEXTER
The typical configuration occurring in such simulations is sketched in Fig. 27. The magnetic field is mainly toroidal in the disk, and the dominant component of J is the radial one. The signs of J_{ϕ} and J_{⊥ ϕ} are opposed, and they remain opposed when flipping the orientation of J and/or B. Ambipolar diffusion remains a dissipative process when considering all three spatial directions. With J_{⊥} ≃ J_{r} and ∂_{ϕ} ≃ 0, the diffusion occurs primarily on B_{ϕ} in the vertical direction. We verified that the same sign inversion occurred in the ambipolar run ABS presented by Béthune et al. (2016), which also featured magnetic flux concentrations without Hall drift.
We show in Fig. 28 the radial profiles of magnetic stress in the saturated state containing zonal flows. The radial stress ℳ_{rϕ} is maximal in regions of magnetic field accumulation. The resulting stress divergence pushes mass away from stress maxima, causing the observed anticorrelation between B_{z} and ρ.
4.6.3. Hydrodynamic properties and saturation mechanism
Zonal flows refer to quasisteady deviations from the Keplerian rotation profile of the disk. We characterize these by the fluctuations of angular velocity Ω relative to the Keplerian one Ω_{K}, and by the dimensionless shear q ≡ ∂log Ω /∂log r. The radial profiles of these two diagnostics are drawn in Fig. 29 for run R1P2, showing five distinct oscillations. Since β ≫ 1, magnetic pressure gradients do not provide a significant support against gravity. Given the density fluctuations, the deviations from a Keplerian profile follow the condition of geostrophic equilibrium: (26)One important issue regarding zonal flows is their ability to trap dust particles (Weidenschilling 1977). Several objects have now revealed axisymmetric structures in their dust distribution, such as rings and gaps (Brogan et al. 2015; Nomura et al. 2016). One possible scenario involves zonal flows. Dust particles undergo a drag force from the gas as they orbit the star at the local Keplerian velocity, whereas the gas can rotate slower or faster depending on its radial pressure gradient. If the gas rotates faster, it will transfer angular momentum to the dust and make it migrate outward, or inward if it rotates slower. Dust grains are thus accumulated in pressure maxima. We prove in Fig. 29 that the zonal flows produced in our simulations are actually able to cause transitions from sub to superKeplerian rotation. These zonal flows would therefore act as dust traps.
Fig. 29 Radial profiles in run R1P2, vertically averaged through the disk from 500T_{0} to 700T_{0}, of the variations of angular velocity Ω relative to Keplerian Ω_{K} (solid blue), and dimensionless radial shear ∂log ρ/∂log r (dashed red).

Open with DEXTER
The profile of dimensionless shear is superimposed to the rotation profile in Fig. 29, and tells us about the saturation of this process. In the limit q → −2, the distribution of specific angular momentum is flat and the flow is marginally stable with respect to Rayleigh’s criterion. This criterion appears to set the lower bound for the shear, as if any deviation q< −2 would instantly reorganize the flow to prevent hydrodynamic instability. However, we do not observe any evidence of purely hydrodynamic turbulence in these simulations. The disk therefore never crosses the Rayleigh line.
4.6.4. Threedimensional simulations
We now ascertain that these structures are not restricted to twodimensional simulations. The formation of axisymmetric rings in run R1P3 and in its threedimensional equivalent run 3DR1P3 are shown in Fig. 30. We observe the emergence of zonal flows on the same timescale at about the same location, and with the same radial separation. The structures form very early in the simulation (50T_{0} at 4r_{0}, i.e., five local orbits), the contrast in increases in time up to two orders of magnitude. They evolve over hundreds of local orbits, but we still count seven bands in run R1P3 after 1000T_{0}.
Fig. 30 Spacetime diagram of vertically and azimuthally averaged β_{z} in runs R1P3 (upper panel) and 3DR1P3 (lower panel); only the first 300T_{0} of the twodimensional run are shown.

Open with DEXTER
The present selforganization phenomenon is thus not inhibited in threedimensional simulations. Regarding the nonaxisymmetric stability of these structures, they could be Rossby wave unstable for the criterion given by Lovelace et al. (1999). Nevertheless, run 3DR1P3 proves that they are stable over 20 local orbits to all modes fitting in a quarter disk. Threedimensional simulations of a full disk with an increased resolution and/or a less diffusive numerical scheme will be required to confirm their stability over long time scales.
5. Discussion
5.1. Largescale configuration of the magnetic field
We gather the symmetry coefficients σ_{ϕ} and ι_{ϕ} from Table 3, and plot them in Fig. 31. We distinguish three populations in this area. Runs with B_{z}< 0 are the only ones on the right half of the figure (σ_{ϕ}> 0), i.e., overall loosing angular momentum in the wind and therefore accreting. The blue square associated with run R10M3 is close to the origin, because its outer half is accreting while the inner half is nonaccreting. On the left side σ_{ϕ}< 0, we find runs with a positive and weak magnetic field. The third population is located near (σ_{ϕ},ι_{ϕ}) ≈ (0, ± 1), i.e., only one sign of B_{ϕ} in the disk, accreting in one hemisphere and nonaccreting on the other. These runs mostly have B_{z}> 0 and a strong magnetization β ≤ 5 × 10^{3}.
Fig. 31 Symmetry coefficients σ_{ϕ} and ι_{ϕ} in our set of 2D simulations, averaged over representative time intervals; colors indicate the initial midplane magnetization β, blue corresponding to B_{z}< 0; runs in [ 1,10 ] au are plotted with circles, runs in [ 10,100 ] au are plotted with squares; different background colors correspond to different diskcorona temperature contrast k; the error bars correspond to standard deviations over time.

Open with DEXTER
It is tempting to see a correlation between the sign of B_{z} and the presence of magnetized outflows. However, we believe that this correlation is fortuitous. Indeed, the vertical phase of B_{ϕ} seems to be set at least partially by the noise injected in our initial conditions. This is illustrated in Fig. 32 showing the evolution of B_{ϕ} as a function of time. From 10T_{0} to 40T_{0}, the MRI amplifies B_{ϕ} at z ≈ 3h, causing σ_{ϕ} to alternate from positive to negative as the instability saturates and eventually settles with σ_{ϕ}> 0. In this example, σ_{ϕ}> 0 is clearly set by the initial phase and saturation mechanism of the most unstable MRI mode, which itself depends on how the MRI was initially seeded.
Fig. 32 Evolution of the toroidal magnetic field B_{ϕ} along a vertical cut at r = 5r_{0} and over the first 150T_{0} (color scale) of run R10M3C2 (accreting); values have been normalized by the initial, unsigned vertical field at this radius.

Open with DEXTER
Several hundred inner orbits later, one polarity of the toroidal magnetic field can be vertically removed out of the disk, leading to a onesided outflow. Among these runs with ι_{ϕ} = ± 1, most have B_{z}> 0 and β< 5 × 10^{4}, the exception being run R1M3. These configurations are stable attractors in the sense that these disks never return to an odd symmetry of B_{ϕ} about the midplane.
5.2. Magnetothermal winds
We have shown that all runs display a vertical outflow, although it is disorganized for nonaccreting disks (cf. Sect. 4.4). We observed no difference between two and threedimensional winds. Our winds exhibit several properties of steadystate, magneticallydriven jets. However, they become superAlfvénic before reaching the ideal MHD regime, contrarily to all published models of magneticallydriven jets from accretion disks. This could explain why, although they also heated the base of the wind, Casse & Ferreira (2000) never achieved an ejection efficiency as high as the one we obtain. It should be possible to design models going continuously from thermallydriven to magneticallydriven winds. Our simulations provide such a link.
One important control parameter for magneticallydriven winds is the disk magnetization (1 /β). At a comparably low disk magnetization, Murphy et al. (2010) also obtained superfastmagnetosonic winds, but with a larger magnetic lever arm (see their Figs. 8 and 14, and also Stepanovs & Fendt 2016). However, they used constant α viscosity and resistivity coefficients, with prescribed vertical profiles to mimic turbulent transport in the disk. This suggests that different transport regimes within disk may lead to different wind properties.
Fig. 33 Wind mass loss rate relative to the disk mass ṁ_{W}/m_{d} as a function of the initial midplane magnetization β; the symbols and color coding are the same as in Fig. 31; the two dashed lines indicate the ṁ_{W} ~ β^{− 1/2} scaling for R1 and R10 runs, bottom and top, respectively.

Open with DEXTER
We plot the wind mass loss rate ṁ_{W} of our twodimensional runs in Fig. 33 as a function of the midplane magnetization β. Runs R1M3 (blue circle) and R10P3 (red square), both of which have ι_{ϕ} = ± 1 (cf. Fig. 31), also have higher mass loss rates than the other simulations of the same radial range. Given this degree of freedom, we find no clear dependence of ṁ_{W} with the polarity of the initial magnetic field alone. There is no apparent correlation of ṁ_{W} with the temperature contrast k either.
The wind mass loss rate typically scales as ṁ_{W} ~ β^{− 1/2} in runs R1 and R10 taken separately. This is consistent with the shearingbox measurements of Bai & Stone (2013), regardless of the fastmagnetosonic point being crossed in the computational domain (see Sect. 4.1.4 of this paper, and Sect. 3.4 of Lesur et al. 2013). In physical units, the wind mass loss rate is (27)The fact that ṁ_{W}/m_{d} increases by a factor , from R1 runs to R10 runs, means that Ṁ_{W} is roughly independent of the inner radius. We can sum the contributions over [ 1,100 ] au to get (28)
6. Summary
We have performed global simulations of protoplanetary disks in the nonideal MHD framework. Our model includes both radial and vertical density stratification, spanning one decade in radius to separately cover the ranges from 1 au to 10 au and from 10 au to 100 au, with 20 disk scale heights vertically. The ionization fraction is computed dynamically, and all three nonideal MHD effects are accounted for. The disk is embedded in a warm corona, with several temperature contrasts.
In the disk, the flow is essentially laminar and evolves over hundreds of local orbital periods. Angular momentum is transported by a largescale magnetic stress, unsuited for an α viscosity prescription. The radial transport of angular momentum causes no net mass accretion in our disk model. The vertical flux of angular momentum can take both orientations through the disk. If angular momentum is transported from the disk midplane to the surface, then a magnetized wind is launched and the disk accretes at rates on the order of 10^{7}M_{⊙}/ yr. Conversely, angular momentum can be transported from the disk surface to the midplane, resulting in a largescale meridional circulation. This circulation is characterized by the gas flowing radially inward at the surface, and outward in the midplane. In this case, a turbulent and low density wind is observed, causing no net mass accretion. Accreting and nonaccreting regions can coexist in one single disk, the boundary between the two domains evolving on secular timescales. The Hall drift can reduce the angular momentum flux in the midplane, depending on the polarity of the vertical magnetic field threading the disk, but the overall contrast in stress is only within a factor of three.
Because of the presence of a warm corona, the winds we obtain are magnetothermal. They constitute a new class of solutions because the plasma can reach superAlfvénic speeds before entering the ideal MHD regime. The mass loading of the wind is driven by the Lorentz force, but the subsequent acceleration is predominantly thermal. We have linked the wind mass loss rate to the disk magnetization, and recovered the ṁ_{W} ∝ β^{− 1/2} relation. Several of our simulations also exhibit asymmetric winds where magnetic ejection occurs on one side of the disk only. We have associated this state with the expulsion of the electric current sheet, usually located near the disk midplane. We speculate that this configuration is a stable attractor for the disk, allowing it to evacuate angular momentum at higher rates than the symmetric situation. Onesided molecular outflows (Pety et al. 2006) could be a consequence of such magnetic configurations.
Finally, we have identified a selforganization process leading to the formation of axisymmetric density rings. To these density rings are associated zonal flows, able to trap dust particles. The vertical magnetic flux becomes concentrated in density minima. We have argued that ambipolar diffusion alone is responsible for this process. Bai & Stone (2014) also observed enhanced magnetic flux concentrations in MRI turbulence simulations. They proposed a mechanism driven by ideal MHD electromotive forces. In our case, we have shown that the concentration mechanism relies solely on ambipolar diffusion. We are therefore looking at a different mechanism from the one they proposed. We presume that Gressel et al. (2015) did not observe this phenomenon because of the lower magnetization and ionization fraction in their simulations. We have shown that the Hall drift works against the confinement of magnetic flux in our case. This demonstrates that Halldriven selforganization (Kunz & Lesur 2013; Béthune et al. 2016) is inefficient in stratified simulations, as already suggested by stratified shearing boxes (Lesur et al. 2014; Bai 2015).
We note that we have not explored systematically the global transport of poloidal magnetic flux in our simulations. The poloidal field being a key ingredient for MHD winds, any longterm prediction for the evolution of these disks implies a parametrization for the evolution of this field (Suzuki et al. 2016). This transport depends strongly on the vertical disk structure (e.g. Guilet & Ogilvie 2012, 2013), and nonideal effects add more complications to this picture (Bai & Stone 2016). In our simulations, we found that transport of flux was highly sensitive to the presence of selforganized structures, which act as physical boundaries for the radial transport of poloidal field. This is to be expected since selforganization is after all a consequence of poloidal flux transport. For this reason, we believe that any description of poloidal flux transport needs to incorporate the possibility of selforganization, without which flux transport could be largely overestimated.
The main caveats of our study are related to the thermodynamics and chemistry of protoplanetary disks. The validity of our prescription for the temperature distribution should be compared with selfconsistent, radiative transfer simulations. By omitting small dust grains, we may also have severely underestimated the magnitude of nonideal plasma effects. Our main justification is practical in nature since both these treatments come with large computational overhead. These limitations will need to be addressed in future work.
Reduced chemical models can nonetheless be computationally affordable, see for example Turner et al. (2007), Ilgner & Nelson (2008).
Unless limiting the Alfvén velocity by some artificial procedure; see for example the appendix of Miller & Stone (2000).
Acknowledgments
We thank Matthew Kunz and Mario Flock, as well as our anonymous referee for providing thoughtful comments on the manuscript. This work was granted access to the HPC resources of IDRIS under the allocation 2016042231 made by GENCI. Some of the computations presented in this paper were performed using the Froggy platform of the CIMENT infrastructure (https://ciment.ujfgrenoble.fr), which is supported by the RhôneAlpes region (GRANT CPER07_13 CIRA), the OSUG@2020 labex (reference ANR10 LABX56), and the Equip@Meso project (reference ANR10EQPX2901) of the programme Investissements d’Avenir supervized by the Agence Nationale pour la Recherche.
References
 Aresu, G., Kamp, I., Meijerink, R., et al. 2011, A&A, 526, A163 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Bai, X.N. 2011, ApJ, 739, 50 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N. 2015, ApJ, 798, 84 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N., & Goodman, J. 2009, ApJ, 701, 737 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N., & Stone, J. M. 2011, ApJ, 736, 144 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N., & Stone, J. M. 2013, ApJ, 769, 76 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N., & Stone, J. M. 2014, ApJ, 796, 31 [NASA ADS] [CrossRef] [Google Scholar]
 Bai, X.N., & Stone, J. M. 2016, ApJ, submitted [arXiv:1612.03912] [Google Scholar]
 Bai, X.N., Ye, J., Goodman, J., & Yuan, F. 2016, ApJ, 818, 152 [NASA ADS] [CrossRef] [Google Scholar]
 Balbus, S. A., & Hawley, J. F. 1991, ApJ, 376, 214 [NASA ADS] [CrossRef] [Google Scholar]
 Balbus, S. A., & Papaloizou, J. C. B. 1999, ApJ, 521, 650 [NASA ADS] [CrossRef] [Google Scholar]
 Balbus, S. A., & Terquem, C. 2001, ApJ, 552, 235 [NASA ADS] [CrossRef] [Google Scholar]
 Bans, A., & Königl, A. 2012, ApJ, 758, 100 [NASA ADS] [CrossRef] [Google Scholar]
 Beckwith, K., Hawley, J. F., & Krolik, J. H. 2008, ApJ, 678, 1180 [NASA ADS] [CrossRef] [Google Scholar]
 Benisty, M., Juhász, A., Boccaletti, A., et al. 2015, A&A, 578, L6 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Béthune, W., Lesur, G., & Ferreira, J. 2016, A&A, 589, A87 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Bitsch, B., Crida, A., Morbidelli, A., Kley, W., & DobbsDixon, I. 2013, A&A, 549, A124 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Blandford, R. D., & Payne, D. G. 1982, MNRAS, 199, 883 [NASA ADS] [CrossRef] [Google Scholar]
 Brogan, C. L., Perez, L. M., Hunter, T. R., et al. 2015, ApJ, 808, L3 [NASA ADS] [CrossRef] [Google Scholar]
 Burrows, C. J., Stapelfeldt, K. R., Watson, A. M., et al. 1996, ApJ, 473, 437 [NASA ADS] [CrossRef] [Google Scholar]
 Cabrit, S. 2007, Lect. Notes Phys., 723, 21 [NASA ADS] [CrossRef] [Google Scholar]
 Casse, F., & Ferreira, J. 2000, A&A, 361, 1178 [NASA ADS] [Google Scholar]
 Chandrasekhar, S. 1956, ApJ, 124, 232 [NASA ADS] [CrossRef] [Google Scholar]
 Cieza, L., Padgett, D. L., Stapelfeldt, K. R., et al. 2007, ApJ, 667, 308 [NASA ADS] [CrossRef] [Google Scholar]
 Contopoulos, J., & Lovelace, R. V. E. 1994, ApJ, 429, 139 [NASA ADS] [CrossRef] [Google Scholar]
 D’Alessio, P., Calvet, N., & Hartmann, L. 2001, ApJ, 553, 321 [NASA ADS] [CrossRef] [Google Scholar]
 Donati, J.F., Paletou, F., Bouvier, J., & Ferreira, J. 2005, Nature, 438, 466 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Edwards, S., Hartigan, P., Ghandour, L., & Andrulis, C. 1994, AJ, 108 [Google Scholar]
 Evans, C. R., & Hawley, J. F. 1988, ApJ, 332, 659 [NASA ADS] [CrossRef] [Google Scholar]
 Ferreira, J. 1997, A&A, 319, 340 [NASA ADS] [Google Scholar]
 Ferreira, J., & Pelletier, G. 1993, A&A, 276, 625 [NASA ADS] [Google Scholar]
 Ferreira, J., & Pelletier, G. 1995, A&A, 295, 807 [NASA ADS] [Google Scholar]
 Fleming, T. P., Stone, J. M., & Hawley, J. F. 2000, ApJ, 530, 464 [NASA ADS] [CrossRef] [Google Scholar]
 Flock, M., Dzyurkevich, N., Klahr, H., Turner, N. J., & Henning, T. 2011, ApJ, 735, 122 [NASA ADS] [CrossRef] [Google Scholar]
 Flock, M., Fromang, S., González, M., & Commerçon, B. 2013, A&A, 560, A43 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Fricke, K. 1968, ZAp, 68, 317 [Google Scholar]
 Fromang, S., & Nelson, R. P. 2006, A&A, 457, 343 [NASA ADS] [CrossRef] [EDP Sciences] [MathSciNet] [Google Scholar]
 Fromang, S., Terquem, C., & Balbus, S. A. 2002, MNRAS, 329, 18 [NASA ADS] [CrossRef] [Google Scholar]
 Fromang, S., Lyra, W., & Masset, F. 2011, A&A, 534, A107 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Fromang, S., Latter, H., Lesur, G., & Ogilvie, G. I. 2013, A&A, 552, A71 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Fukagawa, M., Tsukagoshi, T., Momose, M., et al. 2013, PASJ, 65 [Google Scholar]
 Gammie, C. F. 1996, ApJ, 457, 355 [NASA ADS] [CrossRef] [Google Scholar]
 Goldreich, P., & LyndenBell, D. 1965, MNRAS, 130, 125 [NASA ADS] [CrossRef] [Google Scholar]
 Goldreich, P., & Schubert, G. 1967, ApJ, 150, 571 [NASA ADS] [CrossRef] [Google Scholar]
 Gressel, O., Turner, N. J., Nelson, R. P., & McNally, C. P. 2015, ApJ, 801, 84 [NASA ADS] [CrossRef] [Google Scholar]
 Guilet, J., & Ogilvie, G. I. 2012, MNRAS, 424, 2097 [NASA ADS] [CrossRef] [Google Scholar]
 Guilet, J., & Ogilvie, G. I. 2013, MNRAS, 430, 822 [NASA ADS] [CrossRef] [Google Scholar]
 Haisch, Jr., K. E., Lada, E. A., & Lada, C. J. 2001, ApJ, 553, L153 [NASA ADS] [CrossRef] [Google Scholar]
 Hartigan, P., Edwards, S., & Ghandour, L. 1995, ApJ, 452, 736 [NASA ADS] [CrossRef] [Google Scholar]
 Hawley, J. F., & Stone, J. M. 1998, ApJ, 501, 758 [NASA ADS] [CrossRef] [Google Scholar]
 Hawley, J. F., Gammie, C. F., & Balbus, S. A. 1995, ApJ, 440, 742 [NASA ADS] [CrossRef] [Google Scholar]
 Hayashi, C. 1981, Prog. Theor. Phys. Suppl., 70, 35 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Ilgner, M., & Nelson, R. P. 2008, A&A, 483, 815 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Jin, L. 1996, ApJ, 457, 798 [NASA ADS] [CrossRef] [Google Scholar]
 Kunz, M. W. 2008, MNRAS, 385, 1494 [NASA ADS] [CrossRef] [Google Scholar]
 Kunz, M. W., & Balbus, S. A. 2004, MNRAS, 348, 355 [NASA ADS] [CrossRef] [Google Scholar]
 Kunz, M. W., & Lesur, G. 2013, MNRAS, 434, 2295 [NASA ADS] [CrossRef] [Google Scholar]
 Lesur, G., Ferreira, J., & Ogilvie, G. I. 2013, A&A, 550, A61 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lesur, G., Kunz, M. W., & Fromang, S. 2014, A&A, 566, A56 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lin, M.K., & Youdin, A. N. 2015, ApJ, 811, 17 [NASA ADS] [CrossRef] [Google Scholar]
 Lovelace, R. V. E., Li, H., Colgate, S. A., & Nelson, A. F. 1999, ApJ, 513, 805 [NASA ADS] [CrossRef] [Google Scholar]
 Mignone, A., Bodo, G., Massaglia, S., et al. 2007, ApJS, 170, 228 [NASA ADS] [CrossRef] [Google Scholar]
 Mignone, A., Flock, M., Stute, M., Kolb, S. M., & Muscianisi, G. 2012, A&A, 545, A152 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Miller, K. A., & Stone, J. M. 2000, ApJ, 534, 398 [NASA ADS] [CrossRef] [Google Scholar]
 Murphy, G. C., Ferreira, J., & Zanni, C. 2010, A&A, 512, A82 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Muto, T., Grady, C. A., Hashimoto, J., et al. 2012, ApJ, 748, L22 [NASA ADS] [CrossRef] [Google Scholar]
 Nakano, T., & Umebayashi, T. 1986, MNRAS, 218, 663 [NASA ADS] [CrossRef] [Google Scholar]
 Nelson, R. P., Gressel, O., & Umurhan, O. M. 2013, MNRAS, 435, 2610 [NASA ADS] [CrossRef] [Google Scholar]
 Nomura, H., Tsukagoshi, T., Kawabe, R., et al. 2016, ApJ, 819, L7 [NASA ADS] [CrossRef] [Google Scholar]
 O’Keeffe, W., & Downes, T. P. 2014, MNRAS, 441, 571 [NASA ADS] [CrossRef] [Google Scholar]
 O’Sullivan, S., & Downes, T. P. 2006, MNRAS, 366, 1329 [NASA ADS] [CrossRef] [Google Scholar]
 Padgett, D. L., Brandner, W., Stapelfeldt, K. R., et al. 1999, AJ, 117, 1490 [NASA ADS] [CrossRef] [Google Scholar]
 Pelletier, G., & Pudritz, R. E. 1992, ApJ, 394, 117 [NASA ADS] [CrossRef] [Google Scholar]
 PerezBecker, D., & Chiang, E. 2011, ApJ, 735, 8 [NASA ADS] [CrossRef] [Google Scholar]
 Pessah, M. E., Chan, C.K., & Psaltis, D. 2006, MNRAS, 372, 183 [NASA ADS] [CrossRef] [Google Scholar]
 Pety, J., Gueth, F., Guilloteau, S., & Dutrey, A. 2006, A&A, 458, 841 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pudritz, R. E. 1985, ApJ, 293, 216 [NASA ADS] [CrossRef] [Google Scholar]
 Rao, R., Girart, J. M., Lai, S.P., & Marrone, D. P. 2014, ApJ, 780, L6 [NASA ADS] [CrossRef] [Google Scholar]
 RodgersLee, D., Ray, T. P., & Downes, T. P. 2016, MNRAS, 463, 134 [NASA ADS] [CrossRef] [Google Scholar]
 Salmeron, R., & Wardle, M. 2008, MNRAS, 388, 1223 [NASA ADS] [Google Scholar]
 Salmeron, R., Königl, A., & Wardle, M. 2011, MNRAS, 412, 1162 [NASA ADS] [Google Scholar]
 Sano, T., & Stone, J. M. 2002, ApJ, 577, 534 [NASA ADS] [CrossRef] [Google Scholar]
 SeguraCox, D. M., Looney, L. W., Stephens, I. W., et al. 2015, ApJ, 798, L2 [NASA ADS] [CrossRef] [Google Scholar]
 Shakura, N. I., & Sunyaev, R. A. 1973, A&A, 24, 337 [NASA ADS] [Google Scholar]
 Simon, J. B., Lesur, G., Kunz, M. W., & Armitage, P. J. 2015, MNRAS, 454, 1117 [NASA ADS] [CrossRef] [Google Scholar]
 Steinacker, A., & Henning, T. 2001, ApJ, 554, 514 [NASA ADS] [CrossRef] [Google Scholar]
 Stepanovs, D., & Fendt, C. 2016, ApJ, 825, 14 [NASA ADS] [CrossRef] [Google Scholar]
 Stoll, M. H. R., & Kley, W. 2014, A&A, 572, A77 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Suzuki, T. K., & Inutsuka, S.I. 2009, ApJ, 691, L49 [NASA ADS] [CrossRef] [Google Scholar]
 Suzuki, T. K., & Inutsuka, S.I. 2014, ApJ, 784, 121 [NASA ADS] [CrossRef] [Google Scholar]
 Suzuki, T. K., Ogihara, M., Morbidelli, A., Crida, A., & Guillot, T. 2016, A&A, 596, A74 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Turner, N. J., Sano, T., & Dziourkevitch, N. 2007, ApJ, 659, 729 [NASA ADS] [CrossRef] [Google Scholar]
 Umebayashi, T., & Nakano, T. 1981, PASJ, 33, 617 [NASA ADS] [Google Scholar]
 Umebayashi, T., & Nakano, T. 2009, ApJ, 690, 69 [NASA ADS] [CrossRef] [Google Scholar]
 Urpin, V., & Brandenburg, A. 1998, MNRAS, 294, 399 [NASA ADS] [CrossRef] [Google Scholar]
 van der Marel, N., van Dishoeck, E. F., Bruderer, S., et al. 2013, Science, 340, 1199 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Wardle, M. 1999, MNRAS, 307, 849 [NASA ADS] [CrossRef] [Google Scholar]
 Wardle, M. 2007, Ap&SS, 311, 35 [NASA ADS] [CrossRef] [Google Scholar]
 Wardle, M., & Koenigl, A. 1993, ApJ, 410, 218 [NASA ADS] [CrossRef] [Google Scholar]
 Wardle, M., & Ng, C. 1999, MNRAS, 303, 239 [NASA ADS] [CrossRef] [Google Scholar]
 Weidenschilling, S. J. 1977, MNRAS, 180, 57 [NASA ADS] [CrossRef] [Google Scholar]
 Williams, J. P., & Cieza, L. A. 2011, ARA&A, 49, 67 [NASA ADS] [CrossRef] [Google Scholar]
 Woitke, P., Min, M., Pinte, C., et al. 2016, A&A, 586, A103 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Xu, R., & Bai, X.N. 2016, ApJ, 819, 68 [NASA ADS] [CrossRef] [Google Scholar]
 Yang, H., Li, Z.Y., Looney, L., & Stephens, I. 2016, MNRAS, 456, 2794 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Initial conditions
We construct steady, locally isothermal, hydrodynamic disk solutions to the mass and momentum Eqs. (3)and (4). We first prescribe an isothermal sound speed distribution . The use of helps building simple analytical solutions. The distance unit r_{0} = 1 in this section. With the gravitational potential Φ = −1 /R, the momentum equations in spherical coordinates can be written We can isolate v_{ϕ} and equate the two lines; defining f ≡ log (ρ), x ≡ log (R) and y ≡ −log (sin(θ)), we obtain (A.3)This can be solved by the method of characteristics, once a midplane density profile ρ(r,z = 0) = ρ_{0}(r/r_{0})^{n} has been prescribed: (A.4)and it is straightforward to obtain for the velocity field (A.5)To have a constant opening angle of the disk, we set a constant sound to Keplerian speed ratio: c_{s,disk}/v_{Kepler} = 5%, i.e., α = −1. In this case, the disk midplane density must decrease with n = −2 in order to produce the desired surface density profile Σ(r) ≡ ^{∫}ρdz ~ r^{−1}.
We define the diskcorona transition as the location where the disk equilibrium density is one thousandth of the local midplane density: ρ(r,z_{i}) = 10^{3}ρ(r,z = 0). The transition angle is then given by sin(θ_{i}) = 1 + log (10^{3}) (h/r)^{2}, corresponding to a constant z_{i} ≈ 3.72h ≡ H.
At a given cylindrical radius, the isothermal sound speed is increased up to a factor k higher than the midplane value. This ratio of corona to disk temperature is constant with cylindrical radius, and fixed to k = 6 for most runs. The transition from the disk to the warm corona is smoothed in the interval sin(θ) ∈ [sin(θ_{i})−0.2(h/r),sin(θ_{i})], such that (A.6)in order to avoid strong gradients and, if possible, resolve the physics at the transition. The gas in the corona is thus fully heated at a height z_{c}/h ≈ 4.68.
The coronal density distribution takes the same form as in Eq. (A.4), except this time the solution is extended from the disk surface and not from the midplane. In order to continuously match the isothermal pressure fields at the interface, the factor ρ_{0} in Eq. (A.4)must be replaced by ρ_{0} → ρ(R,θ_{i})[c_{s,disk}(R,θ_{i}) /c_{s,corona}(R,θ)]^{2}.
The velocity field in the corona takes exactly the same form as (A.5). Due to the vertical temperature gradient, there is a vertical shear in azimuthal velocity in the transition layer ∂_{z}v_{ϕ} ≠ 0; we verified via hydrodynamic simulations that this layer quickly relaxes to a steady and stable state. We add a white noise to the three components of the initial velocity field, with amplitude 1% of the local sound speed, so as to quickly trigger the MRI.
The initial magnetic field has only B_{z} ≠ 0. It is initialized via its vector potential B = ∇ × A to ensure the solenoidal condition ∇·B = 0 from the beginning. To set a constant average/midplane β, the magnetic field intensity must decrease as r^{− 3/2}, whence , with B_{0} the intensity of the magnetic field at the inner radius r_{0} (see the appendix of Suzuki & Inutsuka 2014). The initial conditions deviates from a true MHD equilibrium, but only at order 1 /β.
Appendix B: Boundary conditions
Three dimensional simulations are periodic in the azimuthal direction. The remaining boundary conditions are listed below. These boundary conditions are designed to prevent boundarydriven flows while remaining relatively simple. To isolate the corners at the inner radial boundary, we define the critical radius r_{c}/r_{0} ≡ (1 + sin(π/ 2−θ_{0}))/2, with θ_{0} = 20(h/r) the polar extent of the computational domain in one hemisphere.

ρ: zero gradient through all boundaries, with a lower bound ρ_{c} = 10^{6}ρ_{0} at the inner radial boundary;

P: isothermal distribution ρc_{s}(r,θ)^{2} at all boundaries;

v_{R}: zero gradient through all boundaries; outward c_{s}(R,θ) as lower bound at the outer radial boundary in the corona;

v_{θ}: zero gradient through all boundaries; outward c_{s}(R,θ) as lower bound at both polar boundaries;

v_{ϕ}: zero gradient through polar and outer radial boundaries; at the inner radial boundary: initial Keplerian velocity in the disk, constant angular velocity v_{ϕ}/R in the corona;

B_{R}: zero gradient through polar boundaries if r>r_{c}, zero value otherwise;

B_{θ}: zero value at inner radial boundary, zero gradient through outer radial boundary;

B_{ϕ}: zero gradient through radial and polar boundaries if r>r_{c}, zero value otherwise.
We complete these boundary conditions with buffer zones, inside the computational domain to limit the influence of the boundaries on the disk. The inner buffer includes both the disk and the corona in {(R,θ)  R< 1.05r_{0}}. The outer buffer includes only the disk in . Let w_{b} be the radial width of the considered buffer. Within the buffer, we explicitly relax a given field X to some prescribed distribution X_{0}: (B.1)with a characteristic frequency scale (B.2)and a linear modulation m(R), equal to 1 at the domain boundary and 0 at the other edge of the buffer (in the active domain). Only the three components of the velocity field are modified inside the buffers in continuity with the boundary conditions:

v_{R}: relaxed to zero at both boundaries;

v_{θ}: relaxed to maintain a constant angular velocity v_{θ}/R, sampled at the edge of the buffer on the active domain side;

v_{ϕ}: relaxed to the initial velocity in the disk region of both buffers, and to a constant angular velocity v_{ϕ}/R in the corona region of the inner buffer, also sampled at the buffer edge.
Appendix C: Internal conditions
In addition to the buffer zones, we control the values of each computational grid cell and at each time step. The first reason is to avoid excessively high Alfvén velocities, imposing small time steps to satisfy the CFL stability criterion. This is one of the main difficulties with global, stratified MHD simulations including a net magnetic flux. A common remedy is to impose a lower bound, i.e., a floor value on the density. However, we checked that arbitrarily low densities are well handled in the absence of magnetic field, and we found that a density floor could produce significant pressure gradients in the outer corona. We therefore increase the density only when the Alfvén velocity becomes too large. With our prescribed temperature distribution, the Alfvén velocity seldom reaches v_{A} ≲ v_{0}, which we set as its upper limit.
The second control performed on the whole computational domain is related to the gas temperature distribution. Since we do not solve for the radiation field, we enforce a locally isothermal equilibrium, i.e., a constant sound speed distribution c_{0}(r,z). For a steady toroidal flow, the vertical shear of azimuthal velocity is given by (C.1)which depends on the thermodynamics of the flow. Our locally isothermal equilibrium has a nonzero vertical shear, and is therefore subject to the vertical shear instability (Goldreich & Schubert 1967; Fricke 1968; Urpin & Brandenburg 1998). It was shown by Nelson et al. (2013) that this instability could be strongly attenuated by letting the entropy distribution reorganize, and then relaxing the temperature distribution over a fraction of orbital period. For this reason, we evolve the total energy density assuming an ideal gas:
with γ = 7/5 corresponding to cold diatomic molecules. We then bring the isothermal sound speed back to its initial distribution, over a fraction of local orbital period: (C.4)Radiative transfer simulations predict short cooling rates in the bulk of the disk (Flock et al. 2013; Stoll & Kley 2014). We verified via hydrodynamic simulations that ϵ = 1/10 would, indeed, force this instability to saturate at an imperceptibly small level. This value is comparable to the threshold derived by Lin & Youdin (2015) with our set of parameters, ϵ_{0} ~ 1/8.
Appendix D: Caps on nonideal MHD effects
We apply two different limiters on nonideal effects. In the first place, our simplified chemical model cannot properly represent the strong degree of ionization high in the corona. We therefore multiply the diffusivities η_{O,H,A} in Eq. (5)by a factor exp^{(}−x_{e}/ 10^{8}^{)}. This coefficient ensures a smooth decrease of the ambipolar diffusivity until up to eight scale heights.
Because we use an explicit integration scheme, all three nonideal effects impose severe constraints on the admissible timesteps satisfying the CourantFriedrichLewy (CFL) stability criterion. We add a second cap to prevent excessively small timesteps. The strongest constraint come from the Hall drift, so we choose to limit the ratio ℓ_{H}/h(r) ≤ 4. This limit affects only the inner region r ≲ 2.3r_{0} for runs at r_{0} = 1 au, and does not concern runs at r_{0} = 10 au. The ohmic and ambipolar diffusivities are limited via their associated Reynolds numbers R_{O,A} ≡ Ωh^{2}/η_{O,A} ≥ 1/4. This limiter only affects ambipolar diffusion in the surface layers z ≳ 3h of the disk. Once we have applied the first cap on the ionization fraction, this second limiter forces the saturation values of η_{A} only in runs R1P2 and R10P2, i.e., where the initial magnetization is the strongest. In these two runs, the Reynolds number is saturated at R_{A} ≈ 1/4 in the surface layers from z ≳ 2.6h to 3h.
All Tables
All Figures
Fig. 1 Northern half of the computational grid; from the midplane to the pole: deep disk region (dark blue), disk surface region (cyan), diskcorona transition layer (yellow) and corona (red).

Open with DEXTER
In the text
Fig. 2 Vertical profiles in runs R1–P4 (from 1 au to 10 au, with weak B_{z}> 0) at r = 5r_{0} = 5 au: initial (solid blue) and final (dashed green at 300T_{0}) ionization fractions and , and final sound speed (red dots) in units of the midplane orbital velocity.

Open with DEXTER
In the text
Fig. 3 Vertical profiles of dimensionless numbers characterizing nonideal effects in the initial conditions at r = 5 au (left panel) and r = 50 au (right panel): inverse of the ambipolar Elsasser number (solid blue), inverse of the ohmic Reynolds number (dashed blue, multiplied by 10^{3} for visibility, both at 5 and 50 au), and ratio of the Hall length to the local pressure scale height ℓ_{H}/h (green dots).

Open with DEXTER
In the text
Fig. 4 Snapshot of run R10M3C2 (fiducial) at t = 200T_{0}, showing the toroidal magnetic field in color background (blue to red), the poloidal velocity field in units of local sound speed (green arrows in the corona), and the orientation of the angular momentum flux caused by magnetic stress (purple arrows in the disk); ⟨B_{z}⟩ < 0 in this case.

Open with DEXTER
In the text
Fig. 5 Vertical profiles in run R10M3C2 (fiducial), averaged in time from 200T_{0} to 600T_{0}, and in spherical radius from 5r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of the vertical field B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses ℳ_{rϕ} and ℳ_{zϕ}, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and ion minus electron radial velocity, normalized by the local Keplerian velocity and the vertically averaged density. Fifth panel: ambipolar diffusivity η_{A} (solid blue), ohmic diffusivity η_{O} (dashed blue, increased by a factor 10^{4} for visibility), and Hall length ℓ_{H} (green dots).

Open with DEXTER
In the text
Fig. 6 Radial profiles of normalized stress in R10M3C2 (fiducial), averaged in time between 200T_{0} and 600T_{0}. The radial components of Maxwell (red dots) and Reynolds (dashed blue) are averaged over the disk height, whereas the vertical Maxwell stress (solid green) is measured at the disk surface z = ± H.

Open with DEXTER
In the text
Fig. 7 Accretion in the disk region of run R10M3C2 (fiducial), between r ∈ [3,8]r_{0}; the actual mass flux (solid black) is decomposed into radial (dashed blue) and vertical (red dots) torques as explicited in Eq. (9); the sum is drawn (dashed cyan) to validate this decomposition.

Open with DEXTER
In the text
Fig. 8 Velocities projected on a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, and normalized by the Keplerian velocity at the launching radius v_{K0}; flow velocity v (solid black), sound speed c_{s} (dashed orange), Alfvén velocity v_{A} (dashed green), slow magnetosonic speed v_{−} (dashed blue) and fast magnetosonic speed v_{+} (red dots).

Open with DEXTER
In the text
Fig. 9 Acceleration along a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, normalized by the Keplerian acceleration a_{K0} at the streamline base. The sum of the different forces (dashed cyan) is shown to validate this decomposition.

Open with DEXTER
In the text
Fig. 10 Angular momentum along a streamline passing through (r = 6r_{0},z = 5h) in run R10M3C2 (fiducial), averaged from 400T_{0} to 500T_{0}, normalized to its value at the streamline base; the total angular momentum (solid black) is decomposed into matter (dashed blue) and magnetic (red dots) components as explicited in Eq. (17).

Open with DEXTER
In the text
Fig. 11 Vertical profiles of horizontal magnetic stress, normalized by the vertically averaged pressure in the disk ℳ_{rϕ}/ ⟨P⟩_{z} in runs 3DR1P4 (solid blue, Ω·B> 0) and 3DR1M4 (dashed red, Ω·B< 0), averaged in time over 50T_{0} and radially from 3r_{0} to 6r_{0}; the green dots show the average ratio ℓ_{H}/h in this same region.

Open with DEXTER
In the text
Fig. 12 Averaged flow poloidal map for run R10M3 (from 10 au to 100 au, with B_{z}< 0) from 400T_{0} to 700T_{0}; magnetic field lines are regularly sampled along the midplane, and the velocity field is indicated with green arrows over the background density field.

Open with DEXTER
In the text
Fig. 13 Same as Fig. 8 for a streamline passing through (r = 7r_{0},z = 5h) in run R10M3, averaged from 400T_{0} to 700T_{0}. The fastmagnetosonic point is clearly crossed within the computational domain.

Open with DEXTER
In the text
Fig. 14 Contributions to the Bernoulli invariant ℬ (solid black) as explicited in Eq. (20), along a streamline passing through (r = 7r_{0},z = 5h) in run R10M3, averaged from 400T_{0} to 700T_{0}; the gravitational contribution is not shown.

Open with DEXTER
In the text
Fig. 15 Same as Fig. 9 in run R10M3, averaged in time between 400T_{0} and 700T_{0}, with a streamline passing through (r = 7r_{0},z = 5h).

Open with DEXTER
In the text
Fig. 16 Snapshot of run R1P4C4 (from 1 au to 10 au, with weak B_{z}> 0) at t = 1000T_{0}, showing the toroidal magnetic field in color background (blue to red), the poloidal velocity field in units of local sound speed (green arrows in the corona), and the orientation of the angular momentum flux caused by magnetic stress (purple arrows in the disk). The orientation of the angular momentum flux is reversed compared to the fiducial, accreting case.

Open with DEXTER
In the text
Fig. 17 Vertical profiles in run R1P4C4, averaged in time from 400T_{0} to 1000T_{0}, and in spherical radius from 5r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of the vertical field B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and electron minus ion radial velocity, normalized by the local Keplerian velocity and the vertically averaged density.

Open with DEXTER
In the text
Fig. 18 Contributions to the induction of toroidal magnetic field in run R1P4C4, as explicited in Eq. (22), averaged in time from 400T_{0} to 1000T_{0} and in spherical radius from 5r_{0} to 8r_{0}, normalized by the local Keplerian frequency and the local initial magnetic field.

Open with DEXTER
In the text
Fig. 19 Same as Fig. 18 for the radial magnetic field B_{R}; see Eq. (21).

Open with DEXTER
In the text
Fig. 20 Same as Fig. 16 for run R1P4 at t = 1000T_{0}. The disk exhibits both an accreting (inner) and a nonaccreting (outer) region.

Open with DEXTER
In the text
Fig. 21 Averaged flow poloidal map for run R1M3 (from 1 au to 10 au, with moderate B_{z}< 0) from 800T_{0} to 1000T_{0}; magnetic field lines are sampled along the midplane, and the velocity field is indicated with green arrows over the background toroidal field. The polar asymmetry and the absence of B_{ϕ} sign reversal within the disk are obvious.

Open with DEXTER
In the text
Fig. 22 Vertical profiles in run R1M3, averaged in time from 800T_{0} to 1000T_{0}, and in spherical radius from 6r_{0} to 8r_{0}. First panel: fluid velocity, normalized by the local Keplerian value v_{K}; the disk mean value has been subtracted from the azimuthal component. Second panel: magnetic field, normalized by the vertically averaged value of B_{z}. Third panel: horizontal (solid blue) and vertical (dashed red) magnetic stresses, normalized by the vertically averaged pressure (cf. Eq. (8)). Fourth panel: radial mass flux (solid blue), and ion minus electron radial velocity, normalized by the local Keplerian velocity and average density.

Open with DEXTER
In the text
Fig. 23 Evolution of the symmetry coefficients ι_{ϕ} and σ_{ϕ} in run R1P2; data have been averaged over bins of 10T_{0}.

Open with DEXTER
In the text
Fig. 24 Vertical profiles in run R1P2, averaged in time between 120T_{0} and 130T_{0}, and in spherical radius between 5.5r_{0} and 6r_{0}; upper panel: sonic Mach number for the radial Alfvén velocity (solid blue) and electron minus ion velocity, normalized by the Keplerian velocity (dashed red); lower panel: induction of radial magnetic field.

Open with DEXTER
In the text
Fig. 25 Averaged flow poloidal map for run R1P2 (from 1 au to 10 au, with strong B_{z} > 0), from 500T_{0} to 700T_{0}; magnetic field lines are sampled along the midplane, and the velocity field is indicated with green arrows over the background density field. Magnetic field lines are accumulated in low density rings.

Open with DEXTER
In the text
Fig. 26 Radial profiles in run R1P2, vertically averaged through the disk from 500T_{0} to 700T_{0}; first panel: density (solid blue) and vertical magnetic field (dashed red), normalized by their initial profiles; second panel: ideal (solid blue) ambipolar (dashed red) and Hall (black dots, multiplied by 50 for visibility) electromotive forces, given by Eq. (24); third panel: toroidal component of the electric current J_{ϕ} (solid blue), and of its projection J_{⊥ ϕ} normal to the magnetic field; the vertical lines mark the location of magnetic field maxima.

Open with DEXTER
In the text
Fig. 27 Ambipolardriven selforganization mechanism: the electric current J is mainly radial, and the magnetic field B is mainly toroidal; as a result, the signs of J_{ϕ} and J_{⊥ ϕ} are opposed; this is equivalent to a negative diffusivity for B_{z} (cf. Eq. (24)).

Open with DEXTER
In the text
Fig. 28 Radial profiles of normalized stress in R1P2, averaged in time between 500T_{0} and 700T_{0}.

Open with DEXTER
In the text
Fig. 29 Radial profiles in run R1P2, vertically averaged through the disk from 500T_{0} to 700T_{0}, of the variations of angular velocity Ω relative to Keplerian Ω_{K} (solid blue), and dimensionless radial shear ∂log ρ/∂log r (dashed red).

Open with DEXTER
In the text
Fig. 30 Spacetime diagram of vertically and azimuthally averaged β_{z} in runs R1P3 (upper panel) and 3DR1P3 (lower panel); only the first 300T_{0} of the twodimensional run are shown.

Open with DEXTER
In the text
Fig. 31 Symmetry coefficients σ_{ϕ} and ι_{ϕ} in our set of 2D simulations, averaged over representative time intervals; colors indicate the initial midplane magnetization β, blue corresponding to B_{z}< 0; runs in [ 1,10 ] au are plotted with circles, runs in [ 10,100 ] au are plotted with squares; different background colors correspond to different diskcorona temperature contrast k; the error bars correspond to standard deviations over time.

Open with DEXTER
In the text
Fig. 32 Evolution of the toroidal magnetic field B_{ϕ} along a vertical cut at r = 5r_{0} and over the first 150T_{0} (color scale) of run R10M3C2 (accreting); values have been normalized by the initial, unsigned vertical field at this radius.

Open with DEXTER
In the text
Fig. 33 Wind mass loss rate relative to the disk mass ṁ_{W}/m_{d} as a function of the initial midplane magnetization β; the symbols and color coding are the same as in Fig. 31; the two dashed lines indicate the ṁ_{W} ~ β^{− 1/2} scaling for R1 and R10 runs, bottom and top, respectively.

Open with DEXTER
In the text
