Formation of the helium extremeUV resonance lines
^{1} Institute of Theoretical Astrophysics, University of Oslo, PO Box 1029 Blindern 0315 Oslo Norway
email: thomas.golding@astro.uio.no; mats.carlsson@astro.uio.no
^{2} Institute for Solar Physics, Department of Astronomy, Stockholm University, AlbaNova University Centre, 106 91 Stockholm, Sweden
email: jorrit.leenaarts@astro.su.se
Received: 2 August 2016
Accepted: 30 September 2016
Context. While classical models successfully reproduce intensities of many transition region lines, they predict helium extremeUV (EUV) line intensities roughly an order of magnitude lower than the observed value.
Aims. Our aim is to determine the relevant formation mechanism(s) of the helium EUV resonance lines capable of explaining the high intensities under quiet Sun conditions.
Methods. We synthesised and studied the emergent spectra from a 3D radiationmagnetohydrodynamics simulation model. The effects of coronal illumination and nonequilibrium ionisation of hydrogen and helium are included selfconsistently in the numerical simulation.
Results. Radiative transfer calculations result in helium EUV line intensities that are an order of magnitude larger than the intensities calculated under the classical assumptions. The enhanced intensity of He iλ584 is primarily caused by He ii recombination cascades. The enhanced intensity of He iiλ304 and He iiλ256 is caused primarily by nonequilibrium helium ionisation.
Conclusions. The analysis shows that the long standing problem of the high helium EUV line intensities disappears when taking into account optically thick radiative transfer and nonequilibrium ionisation effects.
Key words: Sun: atmosphere / Sun: chromosphere / Sun: transition region / radiative transfer / line: formation
© ESO, 2017
1. Introduction
The formation mechanism of the He i and He ii extremeUV (EUV) resonance lines is a topic that has been discussed for many decades. Some of the first calibrated spectral observations of the EUV helium lines, and the EUV wavelength range in general, became available in the 1960s around the time when the Orbiting Solar Observatory series of satellites was launched. Whilst models were capable of explaining the intensities of many transition region lines, they did not explain the helium intensities that were observed. In particular, Jordan (1975) found that the observed intensities of these lines were an order of magnitude larger than derived values based on emission measure models. Furthermore, values in similar ranges have been confirmed by more recent studies (MacPherson & Jordan 1999; Pietarila & Judge 2004; Giunta et al. 2015) using classical modelling similar to that of Jordan (1975). Pinning down the relevant formation mechanism(s) of the helium lines will be important in guiding interpretations of observations.
Jordan (1975) suggested a possible intensity enhancement mechanism. The collisional excitation rate of the helium resonance lines is highly sensitive to temperature. It was therefore proposed that if cold ions in some way got mixed with hot electrons, more photons would be produced. One possible physical mechanism that would create such a mix is particle diffusion. This was added by Fontenla et al. (1990, 1991, 1993) in a semiempirical 1D model, and gave enough intensity in the hydrogen Lymanα without the need for the temperature plateau at 20 kK present in the Vernazza et al. (1981) models. Another mechanism is the socalled velocity redistribution (VR; Jordan 1980) which was also investigated by Andretta et al. (2000; who invented the term), Smith & Jordan (2002), and Pietarila & Judge (2004). The driver of the latter mechanism is turbulent fluid motions that transport cold atoms into hotter regions. While both the particle diffusion and the VR mechanisms do enhance the helium EUV line intensities, they affect only the photon production due to collisional excitation.
Another suggested mechanism is the photoionisationrecombination (PR) mechanism (Zirin 1975, 1996). In short; half of the EUV photons emitted in the transition region and coronal lines will be lost into space and the other half will constitute a coronal illumination of the chromosphere and be absorbed in the continua of either helium or hydrogen. The resulting photoionised helium atoms will recombine and deexcite through a cascade event, and ultimately emit a helium resonance photon. In such a scenario more EUV photons emitted from the corona would increase the number of helium resonance line photons produced. Andretta & Jones (1997) investigated this idea and found that incident radiation from the corona could enhance the line intensity of He i λ584 in very quiet regions, but had a marginal effect on more active regions. Later he also found that the PR mechanism can not be the primary formation mechanism of He ii λ304 in quiet regions (Andretta et al. 2003). The subordinate helium lines, however, have been shown to be sensitive to coronal illumination (Wahlstrom & Carlsson 1994; Avrett et al. 1994; Andretta & Jones 1997; Mauas et al. 2005; Centeno et al. 2008; Leenaarts et al. 2016).
In this paper we study the formation of the helium EUV resonance lines by exploiting stateoftheart 3D numerical models and 3D nonlocal thermodynamic equilibrium (NLTE) radiative transfer including the effects of nonequilibrium ionisation. The paper is laid out as follows: in Sect. 2 we describe our method of computing the line intensities, in Sects. 3 to 4 we describe our model atom and model atmosphere, in Sect. 5 we follow a classical approach and assess the helium line enhancement calculated from our model, in Sect. 6 we describe how the helium resonance lines are formed in the model, and in Sect. 7 we discuss our results. Finally, in Sect. 8 we summarise and draw conclusions.
2. Method
We compare and investigate line intensities from the solar atmosphere at disc centre (μ = 1). The line intensity, I, is given by the frequency integral over the specific intensity emerging from the atmosphere, I_{ν}(μ), (1)where ν is frequency and D denotes the frequency domain relevant to the line under consideration. I_{ν}(μ) is the solution of the equation of radiative transfer (2)where s is the distance along a ray and η_{ν} and χ_{ν} are the frequency dependent emissivity and opacity, respectively. In Sects. 2.1 and 2.2 we describe how we solve Eq. (2).
2.1. Nonequilibrium radiative transfer with Multi3d
We use Multi3d (Leenaarts & Carlsson 2009) to solve the equation of radiative transfer coupled to a particle conservation equation and a set of equilibrium rate equations. The transfer equation is solved using an extremumpreserving third order Hermite interpolation scheme (e.g. Ibgui et al. 2013). The code solves the rate equations using the formulation of Rybicki & Hummer (1991, 1992).
Given a model atom with N atomic states constituting M ion stages and a set of transitions, the statistical equilibrium rate equations take the form (3)where P_{ij} is the rate coefficient giving the probability per unit time of a transition from the ith to the jth state. In principle it is possible to express N equilibrium rate equations, but they constitute a linearly dependent set of equations which is why we replace one of them by the particle conservation equation, (4)where n is proportional to the mass density by an abundance dependent factor. We refer to the intensity calculated with this setup, solving the radiative transfer equation (Eq. (2)) together with N−1 rate equations (Eq. (3)) and one particle conservation equation (Eq. (4)), as the NLTE solution.
We know that nonequilibrium effects on the helium lines are lost in the NLTE solution (Golding et al. 2014). In that paper we also show that the processes that affect the ionisation state of helium are slow compared to the processes that populate the excited states. We can therefore approximate nonequilibrium effects by constraining the radiative transfer solution by nonequilibrium ion fractions (for an analysis of the timedependent rate equations in evolving plasmas see Judge 2005). We do this by solving the equilibrium rate equations (Eq. (3)) for the N−M excited states of the atom. The M ion fraction equations replace the ground state rate equations. Let f_{j} denote the fraction of atoms in the jth ion stage. The ion fraction equations then take the form (5)where d_{ij} = 1 if i is a state in the jth ion stage and d_{ij} = 0 if i is not a state in the jth ion stage. We modify Multi3d so that it solves this alternative set of equations when ion fractions are given as input. We refer to the solution of this set of equations as the nonequilibrium NLTE solution (NENLTE).
2.1.1. Test of the nonequilibrium NLTE radiative transfer
Fig. 1 Emergent He iλ584 line profiles from the Radyn simulation compared to the NLTE and NENLTE radiative transfer solutions from Multi (three left panels). The top right panel shows the line profile in the three approaches for the snapshot indicated by the yellow lines. The bottom right panel shows the number density of the upper level of the transition in the three approaches. The grey line shows the temperature with scale to the right.

Open with DEXTER
We now check whether the method described in Sect. 2.1 for computing the NENLTE solution matches the emergent intensity of a dynamic solar atmosphere model. Such a test can only be carried out in a 1D geometry because it is not possible, with contemporary computer resources, to construct a dynamic 3D model with a selfconsistent time dependent NLTE description of the radiative transfer.
The dynamic solar atmosphere model is computed with the radiationhydrodynamics code Radyn (Carlsson & Stein 1992, 1995, 1997, 2002). Radyn solves the conservation equations of mass, momentum, charge, and energy, as well as the radiative transfer equation (Eq. (2)) and a set of nonequilibrium rate equations for the atomic number densitites, (6)where v is the bulk velocity.
We use the NErun from Golding et al. (2014) as a reference model. Each snapshot of the reference model describes the state of the atmosphere at a given time. For each snapshot we write input files for the 1D radiative transfer code Multi (Carlsson 1986) and compute the NLTE solution. The modifications made to Multi3d are made also in Multi. Nonequilibrium ion fractions, f_{j}, are available from the reference Radyn model. We use these as input together with the Multi input files and for each snapshot compute the NENLTE solution with the modified version of Multi.
In Fig. 1 we compare the time dependent emergent intensity of the He iλ584 resonance line with the results from the NLTE and NENLTE solutions. Due to shocks, the sawtooth pattern is evident in all three intensities. The NENLTE solution reproduces the intensity brightenings occurring at the onset of some of the shocks. This is a nonequilibrium effect and is not recovered in the NLTE solution. The He iiλ304 line has brightenings as well (shown in Fig. 8 of Golding et al. 2014), and these are also reproduced in the NENLTE solution and lost in the NLTE solution (not shown here).
From this we conclude that the NENLTE method implemented in Multi3d will produce relevant nonequilibrium effects on the helium spectrum, given the appropriate nonequilibrium ionisation state as input.
2.2. Optically thin line formation
Assuming optically thin conditions, we neglect the last term of Eq. (2). In this case the line intensity becomes a simple lineofsight integral along the ray S, (7)where η is the frequencyintegrated line emissivity given by η = ^{∫}_{D}η_{ν}dν. The frequency integrated emissivity can be expressed as (8)where A_{ul} is the Einstein coefficient for spontaneous radiative deexcitation, h is Planck’s constant, ν_{0} is the frequency of the line, n_{u} is the number density of atoms in the upper level of the line, n_{ion} is the number density of atoms in the ion stage, n_{el} is the number density of atoms of the element, and n_{H} is the number density of hydrogen atoms. This expression is general; n_{u} is dependent on the intensity, as well as n_{e} and T. The evauluation of Eq. (8) becomes simple if we make two additional assumptions. First, that the processes affecting n_{ion} are independent of the processes affecting the number densities of the excited states within an ion stage. Second, that the system is in a steady state condition. We will refer to these three assumptions collectively as the optically thin equilibrium approximation. The fraction (n_{u}/n_{ion}) is then found by solving a set of equilibrium rate equations (Eq. (3)) and a normalised particle conservation equation (Eq. (5) divided by n_{ion}). The transition rate coefficients are only made up of terms involving collisional excitation, collisional deexcitation and spontaneous radiative deexcitation. The collisional terms are expressed by n_{e}q(T), where q(T) is dependent on the specific transition. The radiative spontaneous deexcitation rate is given by the Einstein A_{ul} coefficient. The ionisation equilibrium fraction (n_{ion}/n_{el}), is found in a similar way. The transition rate coefficients are in this case constructed from terms made up of collisional ionisation, dielectronic recombination and spontaneous radiative recombination. All of these terms are linear in n_{e}, and this makes (n_{ion}/n_{el}) dependent on temperature only. Under the optically thin equilibrium approximation we denote these two fractions as (n_{u}/n_{ion})_{eq} and (n_{ion}/n_{el})_{eq}. The optically thin equilibrium emissivity, η_{eq}, is then expressed as (9)where G(T,n_{e}) is defined as (10)This function will typically have only a weak dependence on n_{e} and be sharply peaked in temperature. We will refer to the temperature where G peaks as the formation temperature of the line.
2.2.1. Differential emission measure modelling
A differential emission measure distribution (DEM), Φ(T), gives an indication of how much radiating material is present at different temperatures of a solar region or feature. It is defined as, (11)It can be used to compute the thin line intensities under equilibrium conditions, (12)When a set of line intensities are known, it is possible to invert this equation and obtain an estimate of Φ(T) (see, for example, Cheung et al. 2015, and references therein). Since G is also a (weak) function of n_{e}, an assumption about the electron density as function of temperature is required. A common assumption is to use a constant electron pressure, P_{e} = k_{B}n_{e}T, where k_{B} is Boltzmann’s constant.
3. Helium model atom
We use a 13level helium model atom to perform radiative transfer calculations. It has nine He i states, three He ii states and the fully ionised state He iii. To construct this atom we used the 33level helium model atom from Golding et al. (2014) as a basis. For He i we kept the ground state n = 1 and six n = 2 excited states unchanged. All singlet n = 3 states were merged to form one representative state. This was also done for all triplet n = 3 states. All the He i excited states with n ≥ 4 were neglected. For He ii we kept the ground state n = 1 unchanged. All the n = 2 states were merged to one representative state, and all the n = 3 states were merged to one representative state. He ii excited states with n ≥ 4 were neglected. The helium abundance is set to 0.1 helium atoms per hydrogen atom.
4. Model atmosphere
We use a snapshot from a 3D radiationmagnetohydrodynamic simulation as our model atmosphere. The simulation was run with the code Bifrost (Gudiksen et al. 2011) and features nonequilibrium ionisation of hydrogen (Leenaarts et al. 2007) and helium (Golding et al. 2016). The ionisation state of helium is strongly dependent on the radiative losses from the transition region and corona (EUV photons) which leads to photoionisation in the chromosphere. The radiative losses are taken into account in the simulation and they selfconsistently give rise to the coronal illumination. Other than the nonequilibrium helium ionisation, the simulation has the same setup as the enhanced network simulation described by Carlsson et al. (2016). The spatial domain of the simulation is 24 × 24 × 17 Mm^{3}, spanning from the convection zone at z = −2.5 Mm to the corona at z = 14.5 Mm. z = 0 Mm is defined as the average height where the optical depth at 5000 Å is unity. The simulation has a resolution of 504 × 504 × 496 grid points. The snapshot we use as the model atmosphere represents the physical state of the atmosphere approximately 20 min after the nonequilibrium ionisation was switched on. This is long enough for potential startup effects to have vanished. According to figures shown in Golding et al. (2016), the ionisation state of helium relaxes to chromospheric conditions on timescales of approximately 10 to 15 min. The simulation provides all the quantities that we need (ρ, v, T, n_{e}, n_{i} of hydrogen, and f_{j} of helium) at each grid point of the snapshot.
5. Enhancement factors and the classical approach
Helium line enhancement factors from different studies.
We followed a similar procedure to that of Giunta et al. (2015). In short, they observed a set of lines with formation temperatures in the range ^{10}log (T) = 4.3 to 6.25, including resonance lines of He i and He ii. Line intensities were spatially and temporally averaged. Based on a subset of these line intensities they inverted Eq. (12) to obtain a DEM. Then they used the derived DEM to compute the intensities of all the observed lines, I_{DEM} (also with Eq. (12)). The discrepancy between observed and modelled line intensities was quantified by an enhancement factor defined as the ratio of the observed intensity to the DEMmodelled intensity. For most of the lines, the enhancement was around one, except for a few lines including the resonance lines of He ii. Further, similar studies have been conducted elsewhere (Jordan 1975; MacPherson & Jordan 1999; Pietarila & Judge 2004). In Table 1 we sum up their resulting enhancement factors for the helium lines.
The lines observed by Giunta et al. (2015) are listed in their Tables 2–4. We computed the line intensities for all of the listed lines assuming optically thin equilibrium conditions (defined in Sect. 2.2). For He iλ584, He iiλ304, and He iiλ256 we also computed the NENLTE thick line intensities.
5.1. Thin calculations
We assumed optically thin equilibrium conditions and computed the EUV line intensities with Eq. (7) from all the columns of the model atmosphere. To obtain the equilibrium line emissivities, η_{eq}, of the various lines on each point of the model atmosphere, we exploited the atomic database and software tools from the Chianti package (Dere et al. 1997; Del Zanna et al. 2015). We used the chianti.ioneq ionisation equilibrium file and coronal abundances from Schmelz et al. (2012). For He iλ584, He iiλ304, and He iiλ256 we used the helium model atom described in Sect. 3 to calculate η_{eq}. These thin intensities are denoted I_{th}.
5.2. Thick calculations
We ran the NENLTE mode of Multi3d to compute the nonequilibrium helium line intensities from the model atmosphere. To make the problem computationally tractable we halved the horizontal resolution of the model atmosphere so that it is given on a 252 × 252 × 496 grid. The line intensities computed are He i λ584, He ii λ304, and the He ii λ256. These line intensities are denoted I_{RT}.
Fig. 2 Cumulative distributions of thin line intensities, I_{th}, computed from the model atmosphere. Horizontal lines in each panel indicate the location of the first and third quartile. Red vertical lines indicate the observed values.

Open with DEXTER
5.3. Verification of the model atmosphere
To assess how well our model atmosphere represents solar transition region and coronal conditions we compared our intensity, I_{th}, with observed values. The selection of lines and their observed values are listed in Table 7 of Giunta et al. (2015). These are the lines they used to derive their DEM distribution, and they are selected to span a large temperature range. The observed values are of a quiet Sun region.
Figure 2 shows the cumulative distribution of I_{th} for the selected lines. The red vertical line in each panel indicates the observed value, and the horizontal grey lines show the first and third quartile. Our model seems to produce reasonable intensities compared to the observations in most of the lines shown, however there are exceptions in the low and high temperature ends. The synthetic intensities of the low temperature Si ii λ1309 line are not likely to be realistic since this line does not form under optically thin conditions (Lanzafame 1994). The observed intensity of the hightemperature Si xii λ520 line is far below the interquartile range of the synthetic intensity distribution. However, since the model atmosphere represents an enhanced network region, we expect there to be more hot plasma present than is the case for quiet Sun conditions, and thus higher synthetic intensities of the hot lines.
The model atmosphere produces transition region and coronal line intensities of the same order of magnitude as that observed in quiet Sun regions. We therefore conclude that our model is suitable for a study of the helium EUV resonance lines under quiet Sun conditions.
5.4. Deriving the DEM from the model atmosphere
We followed Giunta et al. (2015) and derived a DEM based on a spatial average of our computed line intensities, ⟨ I_{th} ⟩. We used three densitysensitive line ratios to estimate the electron density at three different temperatures. The density sensitive line ratios and their values are listed in Table 2. These are the same line ratios as the ones used by Giunta et al. (2015). The electron pressure varies less than the electron density over the temperature range. For this reason we used the average electron pressure of P_{e}/k_{B} = n_{e}T = 2 × 10^{15} cm^{3} K to derive the DEM. The line intensities we used to derive the DEM are the eleven lines shown in Fig. 2. To perform the inversion we used the XRT inversion code included in the Chianti package (Dere et al. 1997; Del Zanna et al. 2015). The resulting DEM is shown in Fig. 3.
5.5. Enhancement factors
We calculated the modelled line intensities, I_{DEM}, with Eq. (12) assuming a constant electron pressure (equal to the pressure used to derive the DEM). Figure 4 shows the synthetic enhancement factor, ⟨ I_{th} ⟩ /I_{DEM}, for all our included lines, except for the helium lines where the enhancement factor was computed using ⟨ I_{RT} ⟩ /I_{DEM}. These are given as a function of formation temperature. Our DEM distribution successfully reproduces the observed intensities for most of the lines, including those not included for the DEM inversion (black diamonds). The helium lines stand out with enhancement factors of approximately 7 for He i λ584 and He ii λ256, and 10 for He ii λ304. These values are comparable to values reported in earlier studies (see Table 1). We therefore consider the long standing problem of the anomalous helium line intensities in the quiet Sun as solved. The helium enhancement factors are caused by opticallythick radiative transfer effects and/or the effects of nonequilibrium ionisation. In the following section we investigate which effects are important for the formation of He iλ584, He iiλ256, and He iiλ304.
6. Relevant effects for the line intensities
Line ratios used to estimate the electron pressure.
We found in the previous section that the spatially averaged intensity, ⟨ I_{RT} ⟩, is higher than that obtained from the DEM distribution. Compared to the simple 1D DEM thin line formation, we are including much more physics in the full NENLTE radiative transfer case. Among these ingredients are multidimensional atmospheric structure and a nonequilibrium ionisation state. Ignoring radiative transfer effects, we begin this analysis by testing whether or not the enhanced intensity is due to these two ingredients.
First we asses how the 3D atmospheric structure alters the helium line intensity. The intensities computed by lineofsight integration (Eq. (7)) assuming optically thin equilibrium conditions include possible effects of such structure since the emissivity is calculated for each grid point in the model atmosphere based on the local values of temperature and electron density. To quantify the effect we define the line intensity ratios, The values of the ratios for the helium lines are given in Table 3. R_{DEM} is the inverse of the enhancement factor, and has a value lower than 1 for the three helium lines considered. The values of R_{th} are very similar to the values of R_{DEM}. This means that the helium line intensities derived from the DEM approximately reproduce the spatial average of the helium line intensities under optically thin equilibrium conditions. Or in other words, the multidimensional atmospheric structure does not explain the enhanced intensity.
Fig. 3 Differential emission measure derived from the model atmosphere. The DEM is derived from the intensities of the lines shown in Fig. 2.

Open with DEXTER
Fig. 4 Enhancement factors for all the modelled lines. The lines selected for DEM inversion are indicated by red diamonds. The helium lines are indicated by black stars. The blue diamonds show the enhancement factors for the helium lines if we use their optically thin equilibrium intensity as the “observation”. The black diamonds show the enhancement factor for all other lines included in the study.

Open with DEXTER
Next we test the effect of nonequilibrium helium ionisation. To do this we compute the optically thin nonequilibrium intensities, I_{th,NE}. These intensities are calculated using the lineofsight integration in Eq. (7) of the thin nonequilibrium emissivity, η_{neq}, which features the same excitation mechanism as the thin equilibrium emissivity (n_{u}/n_{ion})_{eq}, however we let the ion fraction be given by the nonequilibrium value from the model atmosphere (n_{ion}/n_{el})_{neq}. Then we can express the emissivity, (15)We are interested in how the spatial average of the thin nonequilibrium line intensity differs from its equilibrium counterpart. We therefore define the ratio (16)The values of this ratio are given in Table 3.
Compared to R_{th}, R_{th,NE} is halved for the He i line and increases by a factor of three for the He ii lines. In other words, if the lines are only excited by collisions, taking the nonequilibrium ionisation state into account results in fewer He iλ584 photons and more He iiλ304 and He iiλ256 photons than what is predicted by assuming ionisation equilibrium (as described in Sect. 2.2). Figure 5 shows the ion fractions and corresponding emissivities for the He iλ584 and He iiλ304 lines in a network region column. We choose a network region column because the network regions feature the strongest emission and contribute the most to the averages that go into R_{th}, and R_{th,NE}. We inspected a representative sample of columns in the snapshot, and they all behave qualitatively the same. The nonequilibrium He i ion fraction is lower than the ionisation equilibrium value, and this makes the nonequilibrium He iλ584 emissivity lower. It is the inverse for the He iiλ304 emissivity; the nonequilibrium He ii ion fraction has a tail that reaches into the high temperature transition region (at roughly z = 2.68 Mm) which results in a nonequilibrium emissivity higher than the corresponding equilibrium value.
I_{RT} and I_{th,NE} are computed from an identical atmosphere model and with identical ion fractions. Opticallythick radiative transfer effects therefore remain the only reason why R_{th,NE} is not equal to one. The ratio is closer to one for the He ii lines than for the He i line. This suggests that the radiative transfer effects are more important for the latter.
Ratios of average line intensities illustrating the effect of thick radiative transfer.
Fig. 5 Details of the thin line formation of He i λ584 (left column) and He ii λ304 (right column). Upper panels: line emissivities (solid, scale to the left) and temperature (dashed, scale to the right). Bottom panels: ion fractions (solid, scale to the left) and temperature (dashed, scale to the right). The black lines show the values corresponding to ionisation equilibrium and the blue lines show the values corresponding to nonequilibrium ionisation.

Open with DEXTER
6.1. Radiative transfer effects on the He EUV lines
Fig. 6 Comparison of the NENLTE thick and nonequilibrium thin line formation of He i λ584 (left column) and He ii λ304 (right column). Upper panels: contribution functions (scale to the left) for thick formation (solid black) and thin formation (solid red). For context the temperature is also shown (dashed curve, scale to the right). Two additional scales are drawn in each of the two upper panels. The upper scale shows the optical depth at line center. The lower scale shows the optical depth for the continuum. Bottom panels: net rates into the upper level of the transition. Collisional processes are indicated by red lines and radiative transitions are indicated by black lines.

Open with DEXTER
We now turn to the optically thick formation of the helium EUV line intensities. Figure 6 shows the details for a network column (the same one as in Fig. 5). Here we display a contribution function, f(z). This represents the contribution to the total line intensity as a function of height. We define it by using the formal solution of Eq. (2) (Mihalas 1978, p. 38) to rewrite Eq. (1), (17)The contribution function is equal to the emissivity (Eq. (8)) when the line formation is thin.
First we consider the He iλ584 line. The thick contribution function has a larger value than the thin contribution function at all depths where it is significant. It is also more extended in space. The number of photons released in the transition is closely related to the number density of atoms in the excited state (Eq. (8)). In the lower panel we therefore show which processes populate the upper level of the transition in the thick calculation. Practically all of the transitions into the upper level are balanced by a radiative deexcitation releasing a He iλ584 photon. There is some collisional excitation in the transition region above z = 2.6 Mm (which causes all of the emission in the thin calculation). The dominant processes in the chromosphere below are radiative transitions from higher energy singlet states and collisional transitions from the triplet states. There is also a significant net radiative rate into the upper state from the lower energy singlet state 1s2s. The singlet state 1s2s is populated mainly by collisions from the triplet states (not shown in the figure). In the chromosphere the triplet states are populated mainly by recombinations from He ii 1s (e.g. Andretta & Jones 1997; Centeno et al. 2008). This means that a significant amount of the He iλ584 photons are due to recombination from singly ionised helium followed by a cascade down to the upper level of the line transition, either through the singlet system or the triplet system. Recombination into excited states is not included in thin modelling. A DEM analysis would therefore never account for these photons.
Now we consider the He iiλ304 line. The thick contribution function is more extended in height than the thin contribution, however both the thin and thick contribution functions peak in the transition region. The thin f has a higher peak than the thick f because it is not depressed by optical depth effects. Collisional excitation from the He ii ground state is the dominant process populating the upper level of the transition where the contribution function is significant. There is a smaller contribution to the total He iiλ304 line intensity that comes from the chromosphere. Here recombination of He iii is the main contribution in populating the excited state.
For the He iiλ304 line there are two radiative transfer effects at play: the first one is backscattering of photons. When a collisionally excited He ii ion deexcites, it releases a photon that travels either up into space or down towards the chromosphere. The line opacity in the chromosphere is high and the photon destruction probability is low. The photon will thus be scattered around. Since the destruction probability is low, a large fraction of the downwardemitted photons will eventually escape upwards into space.
Under idealised conditions, where the photon production happens in a truly thin layer and the destruction probability is zero, all photons eventually escape, and therefore ⟨ I_{RT} ⟩ = 2 ⟨ I_{th,NE} ⟩ and R_{th,NE} = 0.5. Under realistic conditions, the proportionality constant is smaller than two.
The calculated value of R_{th,NE} is lower than 0.5, or equivalently ⟨ I_{RT} ⟩ > 2 ⟨ I_{th,NE} ⟩, which means that backscattering alone is not sufficient. We explain this by the second effect, which is the recombination from He iii. The last step of the recombination cascade produces a He iiλ304 photon. These photons are primarily created in the optically thick chromosphere and are then released into space after a sequence of scattering steps, adding to the thick line intensity.
Turning finally to the He ii λ256 we have R_{th,NE} = 0.61. This line is also optically thick in the chromosphere, therefore we expect that the backscattering effect is important. Since R_{th,NE} is significantly higher than 0.5, a fraction of the line photons must be destroyed. Figure 7 shows the net rates into the excited state of the line in the same network column as shown in Fig. 6. Indeed, He iiλ256 photons are absorbed and transformed into He ii Balmerα (and later 304) photons. The dominant processes populating the upper level of the line are otherwise very similar to those populating the excited state of the He iiλ304 line, with the recombination of He iii in the chromosphere. However, this recombination is the beginning of the downward cascade and the production of a He ii Balmerα photon and a He iiλ304 photon.
Fig. 7 Net rates into upper level of the He ii λ256 line transition. The red lines indicate collisional transitions. The black lines indicate radiative transitions.

Open with DEXTER
To sum up we find that the He i λ584 line is in large part formed by recombination cascades and that the resonance lines of He ii are mostly collisionally excited. We have found this based on radiative transfer modelling where we have taken time dependent ionisation driven by coronal illumination into account. Now we evaluate the effect of how time dependence and coronal illumination affect the intensities of the helium EUV resonance lines.
6.2. Nonequilibrium effects
Ratios of average line intensities illustrating the effect of nonequilibrium ionisation.
Fig. 8 Details on the He ii λ304 thick line formation under equilibrium and nonequilibrium conditions. Upper panel: contribution functions (solid lines, scale to the left) and temperature (dashed line, scales to the right). Lower panel: fraction of He as He ii (solid lines, scale to the left) and temperature (dashed line, scales to the right).

Open with DEXTER
To identify the nonequilibrium effects inherent in I_{RT} we compute an equilibrium solution I_{RTE} and compare the two. The equilibrium solution is computed by using equilibrium ion fractions as constraints in the NENLTE mode of Multi3d. The equilibrium ion fraction are computed on the basis of the coronal illumination present in the Bifrost simulation. The simulation uses a 3level helium model atom. To advance the atomic populations, Bifrost computes the radiative and collisional ionisation and recombination transition rate coefficients for every time step. The radiative ionisation coefficient indirectly contains the coronal illumination. We obtain the equilibrium ion fractions by using the radiative and collisional transition coefficients from the Bifrost simulation to solve two equilibrium rate equations (Eq. (3)) and one particle conservation equation (Eq. (4)). This way both I_{RT} and I_{RTE} include the effects of coronal illumination, but all nonequilibrium effects are removed from I_{RTE}. The equilibrium line intensities, I_{RTE}, are in principle comparable to line intensities computed from a radiative transfer statistical equilibrium setup where coronal illumination is taken into account, either as an incoming EUV radiation field in the upper boundary (Avrett et al. 1994; Wahlstrom & Carlsson 1994; Andretta & Jones 1997; Pietarila & Judge 2004; Mauas et al. 2005; Centeno et al. 2008), or as an extra emissivity included in the calculations (Leenaarts et al. 2016).
Table 4 shows the ratios of the spatially averaged line intensities, (18)Roughly a tenth of the He i λ584 photons and half of the He ii λ304 and λ256 photons can be attributed to nonequilibrium effects. Figure 8 shows the difference of equilibrium and nonequilibrium He ii λ304 line formation in the same column as the column featured in Fig. 6. In the transition region, where the line is collissionally excited, the nonequilibrium contribution function is higher than the equilibrium contribution function. This is consistent with the differences in the He ii fraction. In the high temperature transition region the equilibrium ion fraction is lower than the nonequilibrium ion fraction. In other words, timedependent ionisation permits He ii to exist in a hotter environment than equilibrium conditions permit. The result is more collisional excitation and a higher line intensity. This applies to both of the He ii lines.
6.3. Effects of coronal illumination
Fig. 9 Joint probability distributions of the ratio R_{CI} = I_{RT0}/I_{RTE} as a function of I_{RTE}. Top to bottom panels show the relations for He iλ584, He iiλ304, and He iiλ256.

Open with DEXTER
Ratios of average line intensities illustrating the effect of coronal illumination.
Now we assess the effects of coronal illumination. To remove this effect, and this effect alone, we need to run a new Bifrost simulation including nonequilibrium ionisation but with the photoionisation switched off, and, with a snapshot from this simulation, calculate the NENLTE radiative transfer solution with the new ion fractions. This exceeds our budget for computing time so we, instead, compare the equilibrium line intensities, I_{RTE}, with NLTE line intensities, I_{RT0}. The former includes the effect of coronal illumination, the latter does not.
Table 5 gives the ratio (19)for the three resonance lines. The value for all of them is approximately 1. This suggests that the effect of coronal illumination is negligible for the mean quantities. Andretta & Jones (1997) find that the effect of an incident EUV radiation field influences the line intensity of He iλ584 for only their models featuring a low density transition region. Their models with a high density transition region have a low sensitivity to the coronal illumination. The high intensity network regions in our model correspond to the high density transition region models of Andretta & Jones (1997). These regions dominate in the line intensity averages, and this explains why the values of R_{CI} are approximately equal to 1. To verify this explanation we visualise the effect of coronal illumination for all columns of our model in Fig. 9, which shows the distribution of I_{RT0}/I_{RTE} as a function of I_{RTE}. For the He iλ584 line, the ratio is lower than 1 in low intensity regions and approximately 1 in high intensity regions. This is also the trend for the He iiλ304 and He iiλ256 lines, showing that the effect of the coronal illumination is more important in low intensity regions.
7. Discussion
Fig. 10 Average line profiles based on the NENLTE intensity of the whole model atmosphere.

Open with DEXTER
Suggestions for various enhancement mechanisms have been made in the past. Particle diffusion (Fontenla et al. 1993) and velocity redistribution (Andretta et al. 2000) are examples that would both lead to a mixing of hot electrons and cold ions. Presence of a macroscopic velocity field across the transition region would have a qualitatively similar effect, as was shown by Fontenla et al. (2002) in static 1D models. Our model atmosphere and radiative transfer calculations take time dependent 3D flows and nonequilibrium ionization into account, and we end up with another scenario of hot electrons exciting cold atoms (shown in Fig. 8). While we do not rule out possible effects due to particle diffusion and velocity redistribution, we can safely say that nonequilibrium effects enhance the intensities.
The calculated intensities are dependent on the ionization state, and the ionization state is dependent on the 3D structure and 3D radiation of the atmosphere. Modelling the radiation field in 1D will potentially lead to erroneous ion fractions and therefore erroneous intensities. For instance, a chromospheric structure may be exposed to EUV radiation from the sides as well as from the top. Modelling the radiation in 1D would only expose such a structure to EUV radiation from the top, which would result in a lower photoionization rate and fewer ions. An example of this is given in Fig. 7 of Leenaarts et al. (2016) where a comparison between 1D and 3D radiative transfer shows that an exposed chromospheric structure has a higher number density of He ii in the 3D case than in the 1D case.
Another enhancement mechanism that has been suggested is the PRmechanism. We have shown that a significant amount of the He i λ584 photons are created in recombination cascades. This is valid in both network and internetwork regions of our model. According to Milkey (1975) the PRmechanism should lead to a central reversal in the line profile. Figure 10 shows the average profiles of all three of the studied resonance lines, where the intensity is from NENLTE radiative transfer calculation. The He iλ584 profile has a clear central reversal, even after averaging over all the columns. We found that the coronal illumination is important for the 584 line intensity in the lowintensity internetwork regions, but less so in the high intensity network regions. The column shown in Fig. 6 is from such a high intensity network column, and the figure shows the effect of recombination cascades. This suggests that the photoionisation in the network is dominated by internal sources of EUV photons and not an externally set coronal illumination. The possible internal sources of photons capable of ionising He i included in the calculations are He iiλ304, He iiλ256, and the two helium continua. Also, photons from the hydrogen Lyman continuum shortward of 504 Å are capable of ionising He i. The hydrogen Lyman continuum is included as a background element, and the contribution is determined by the nonequilibrium hydrogen populations from the Bifrost simulation. An investigation of the relative importance of these internal photon sources is beyond the scope of the present study.
These findings are consistent with Andretta & Jones (1997), who find that the resonance line of neutral helium has a low sensitivity to coronal illumination in models with a high density transition region. The question is then: have He iλ584 central reversals been observed? A central reversal was measured by Phillips et al. (1982). Wilhelm et al. (1997) reported single peaked average profiles based on observations from SOHO/SUMER (Wilhelm et al. 1995). Later both Peter (1999) and Judge & Pietarila (2004) found indications of central reversals, also based on observations from SOHO/SUMER. The line was also observed with SOHO/CDS (Harrison et al. 1995), but since the CDS instrument response function is broad, any doublepeaked He iλ584 profiles would have been washed out as was shown by Mauas et al. (2005). Our results can be brought into doubt if central reversals are uncommon features for the He iλ584 profile. They have been observed, but not ubiquitously. However, the observation of narrow doublepeaked profiles may have been prevented by an overly low spectral resolution of the relevant instruments. We believe therefore that the central reversal present in our modelled He iλ584 profiles is not in conflict with observations. However, further studies on this issue are merited.
We found that the resonance lines of He ii are primarily excited by collisions. The role of PR is moderate for He iiλ304 and marginal for He iiλ256. This is also reflected in the average profiles shown in Fig. 10: the He iiλ304 profile has a slightly flattened peak and the He iiλ256 profile appears Gaussian. Our finding that the He ii lines are collisionnally excited in the quiet Sun is in agreement with what has been concluded in earlier studies (Jordan et al. 1993; Andretta et al. 2003; Jordan & Brosius 2007).
8. Summary and conclusion
We use the code Multi3d to solve the radiation transfer problem for helium on a radiationMHD simulation snapshot. By constraining the radiative transfer solution with the nonequilibrium helium ion fractions, we are able to obtain nonequilibrium NLTE atomic spectra. The EUV resonance lines He iλ584, He iiλ304, and He iiλ256 have intensities an order of magnitude higher than what is achieved when we assume optically thin equilibrium conditions. This difference is in line with the difference between observed and modelled intensities reported in the literature.
The high NENLTE intensity of He iλ584 is explained by large contributions from recombination cascades. The high NENLTE intensity of He iiλ304 and He iiλ256 is explained primarily by nonequilibrium effects. A higher number of He ii ions are present in the high temperature transition region than what is permitted under equilibrium conditions. The collisional excitation rates of the He ii line transitions increase with temperature. Thus there is more collisional excitation and more photons produced in the lines when nonequilibrium ionisation is taken into account.
We conclude that the problem of the anomalously high helium EUV line intensities disappears when taking into account optically thick radiative transfer and nonequilibrium ionisation effects.
Acknowledgments
This research was supported by the Research Council of Norway through the grant Solar Atmospheric Modelling, through grants of computing time from the Programme for Supercomputing, and by the European Research Council under the European Union’s Seventh Framework Programme (FP7/2007–2013)/ERC Grant agreement No. 291058. Some computations were performed on resources provided by the Swedish National Infrastructure for Computing (SNIC) at PDC Centre for High Performance Computing (PDCHPC) at the Royal Institute of Technology in Stockholm.
