1. Introduction

Bars are common features in disc galaxies, with nearly two thirds of nearby galaxies showing strong or weak bars (e.g., de Vaucouleurs et al. 1991; Eskridge et al. 2000; Knapen et al. 2000; Marinova & Jogee 2007; Menéndez-Delmestre et al. 2007; Barazza et al. 2008; Aguerri et al. 2009; Marinova et al. 2009; Méndez-Abreu et al. 2010; Masters et al. 2011). These bars are dynamically important as they drive secular evolution by moving gas towards the galactic center (Athanassoula et al. 2013; Heller & Shlosman 1994; Shlosman & Noguchi 1993) and transfer angular momentum throughout the galaxy (Lynden-Bell & Kalnajs 1972; Weinberg 1985; Athanassoula & Misiriotis 2002; Marinova & Jogee 2007); thereby changing the kinematics of the gas and the properties of the galaxy in general.

Of particular importance is the effect of the bar on the velocity maps and rotation curves. Typically, the gas is assumed to be moving in circular orbits and its observed velocity is used to determine the mass distribution of galaxies (de Blok et al. 2008; Randriamampandry & Carignan 2014). This approximation works quite well for unbarred galaxies since the deviations from circular motion are small (Bosma 1978) but, in barred galaxies, the gas flows along the bar. Regan et al. (1999) using CO(1−0) emission-line observations found that the molecular gas in the inner part of barred galaxies is moving along the bar instead of in circular orbits. These flows are non-circular in nature and strongly affect rotation curves derived under the assumption of axisymmetry. Results from Hi observations have also confirmed that the gas streaming along the bar produces large scale non-circular flows (Bosma 1978) on the observed rotation velocities. The precise effect of non-circular flows on the observed rotation curves depends on the orientation of the bar relative to the major axis of the observed disk (see e.g., Valenzuela et al. 2007; Spekkens & Sellwood 2007; Dicaire et al. 2008; Randriamampandry et al. 2015).

Hydrodynamic or N-body simulations are ideal to characterize and quantify these non-circular flows since the exact gravitational potential due to the mass is known for all the snapshots. In this work, a suite of N-body simulations is used to quantify the size of the observed deviations and compare them to the intrinsic non-circularity found in the simulations. We have selected snapshots of isolated galaxies in the GalMer (Chilingarian et al. 2010) database that have the strongest bars in order to study the largest possible effects of the bar. In addition to the characterization and quantization of the non-circularity, we also test the ability of the DiskFit algorithm (Spekkens & Sellwood 2007) to recover the circular and non-circular components of the gaseous motion based on the observed velocity map.

The paper is organized as follows: a brief description of the GalMer database is given in Sect. 2. In Sect. 3, we describe the method used to measure the bar properties. In Sect. 4, we present the method used to characterize and quantify the non-circular motions, and the results are discussed in Sect. 5. Finally, in Sect. 6, we summarize the main results and highlight some possible future works.

2. The GalMer database

The GalMer database (Chilingarian et al. 2010) consists of a large set of Tree-SPH simulations of galaxies with different morphological types and sizes. The main objective of the GalMer project is to study galaxy evolution through mergers. It can also be used to study isolated galaxies by choosing the second galaxy pair as “none”. The simulation results are publicly available and accessible online¹. The simulations are designed to cover a wide range of morphological types from giant ellipticals to dwarf spirals. The initial parameters of the GalMer models used are given in Table 1. The models used in this study are: the giant spirals (gSa, gSb and gSd) which are massive and large in size, the intermediate spirals (iSa, iSb and iSd) with medium sizes and masses and the dwarf spirals (dSa, dSb and dSd) with low masses and small sizes. The models are classified as Sa, Sb and Sd galaxies depending on the importance of the bulge component and of the mass fraction (see Table 1). The Sa models have prominent bulge and lower gas fraction similar to early type spirals, the Sb models have smaller bulge but larger gas fraction than the Sa model and the Sd models are bulge-less with a gas fraction similar to late type spirals (See Chilingarian et al. 2010, for details). The snapshots with the strongest bars are shown in Fig. 1 for all nine models used in this work. The giants Sa, Sb and Sd are shown in the top panels, the intermediate or medium mass spirals in the middle panels and the dwarfs or low mass spiral in the bottom panels.

The GalMer database uses a go-on-the-fly algorithm which enables the user to obtain the masses, the velocity maps and other properties for every snapshot. The radial velocities maps are obtained by projecting the velocity components of each particle into a line-of sight (LOS) radial velocity assuming an infinite distance. The pixel size depends on the zoom that is chosen by the user on the online tool. The LOS radial velocity is given by: ${\mathit{V}}_{\mathrm{r}}\mathrm{=}{\mathit{V}}_{\mathit{X}}\cos \mathit{\varphi }\cos \mathit{\theta }\mathrm{+}{\mathit{V}}_{\mathit{Y}}\sin \mathit{\varphi }\cos \mathit{\theta }\mathrm{+}{\mathit{V}}_{\mathit{Z}}\sin \mathit{\theta ,}$(1)where V_X, V_Y andV_Z are the velocity components for each particles, ϕ and θ are the azimuthal and polar angles respectively (Chilingarian et al. 2010).

The GalMer database does not provide the observed uncertainties for the mock velocity fields.

Fig. 1 Gas and stellar distribution maps for the snapshots with the strongest bars as defined by their bar strengths and lengths. The giants Sa, Sb and Sd are shown on the top panels, the intermediate or medium mass on the middle panels and the dwarf or low mass spirals on the bottom panels. The pixel scale is 0.1 kpc using a zoom of 10 on the online tools (see http://galmer.obspm.fr/).

3. Bar properties

There are several methods used to determine the strength and size of a bar in the literature. The two most commonly used methods are ellipse fitting and Fourier decomposition. Ellipse fitting is often used for observed galaxies, while Fourier decomposition is typically used for simulations.

Ellipse fitting consists of finding the set of iso-density (surface brightness) ellipses. The ellipticity of each ellipse is then used as a proxy for the bar strength as a function of radius. The largest value of the ellipticity, ϵ_max, is used to describe the overall bar strength while the bar length is taken to be the location of rapid changes in either the bar ellipticity of the surface brightness, or defined as the radius where there is a significant change of the position angle of the ellipses (eg., Díaz-García et al. 2016).

In Fourier decomposition, the image or density maps are modeled as a Fourier series (Salo et al. 2010):

$\begin{array}{ccc}& & {\mathit{a}}_{\mathit{m}}\mathrm{=}\frac{\mathrm{1}}{\mathit{\pi }}{\mathrm{\int }}_{\mathrm{0}}^{\mathrm{2}\mathit{\pi }}\mathrm{\Sigma }\mathrm{\left(}\mathit{r,\theta }\mathrm{\right)}\cos \mathrm{\left(}\mathit{m\theta }\mathrm{\right)}\mathrm{d}\mathit{\theta ,}\\ & & {\mathit{b}}_{\mathit{m}}\mathrm{=}\frac{\mathrm{1}}{\mathit{\pi }}{\mathrm{\int }}_{\mathrm{0}}^{\mathrm{2}\mathit{\pi }}\mathrm{\Sigma }\mathrm{\left(}\mathit{r,\theta }\mathrm{\right)}\sin \mathrm{\left(}\mathit{m\theta }\mathrm{\right)}\mathrm{d}\mathit{\theta }\mathit{.}\end{array}$The m = 0 and m = 2 components are calculated. Then the total second moment, A₂, is calculated as: ${\mathit{A}}_{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{=}\sqrt{{\mathit{a}}_{\mathrm{2}}^{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{+}{\mathit{b}}_{\mathrm{2}}^{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}}\mathit{.}$(4)The phase is found by: ${\mathrm{\Phi }}_{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{=}\arctan \left(\frac{{\mathit{a}}_{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}}{{\mathit{b}}_{\mathrm{2}}\mathrm{\left(}\mathit{r}\mathrm{\right)}}\right)\mathrm{·}$(5)The total bar strength is given by the A₂/A₀ component and the bar length is found by either a large dip in surface brightness or a large change of phase (Laurikainen et al. 2004, 2005). This method has been applied to determine the bar length using the mass distributions of N-body simulations (e.g., Debattista & Sellwood 2000), and using images obtained from observations (e.g., Aguerri et al. 1998, 2003).

4. Characterization of non-circular motions

4.1. Different forms of non-circular motions

The amplitude of non-circular motions varies between galaxies. These motions complicate the study of the dynamics of gas in disc galaxies and diminish the usefulness of the rotation curves derived assuming axisymmetry. These motions are usually less than 20  km s^-1 in magnitude (Bosma 1978) and vary in azimuthal phase relative to the disk major axis so that the overall impact on rotation curves is typically small. Other large scale deviations from circular motion can be divided into three types. The first is a kinematic warp: in this case, the PA and inclination changes with radius (see Christodoulou et al. 1993; Józsa 2007). The commonly used package ROTCUR (Begeman 1989) allows these parameters to vary as a function of radius which make it ideal to deal with this type of non-circular motion. The second type is large scale asymmetries due to tidal interactions with another galaxy. This produces an unusual shape of the outer part of the Hi distribution that typically requires detailed simulation to decipher (eg, Gerhard & Fall 1983; Oh et al. 2015). The third type, which we are interested in, is the non-circular motion induced by a bar-like structure which is also known as oval or bar distortions (eg., Spekkens & Sellwood 2007). In this case, the deviation from circular flows is due to the gas streaming along the bar.

4.2. Non-circular motions within the simulations

The true rotation velocities (expected rotation curve) at a given radius can be obtained from the gravitational potential and its derivatives in the simulation by computing the average forces. The expected circular velocity is given by: $\mathrm{⟨}{\mathit{V}}_{\mathrm{expected}}^{\mathrm{2}}\mathrm{⟩}\mathrm{=}\mathit{r}⟨\frac{\mathit{\partial }\mathrm{\Phi }}{\mathit{\partial r}}⟩\mathrm{=}\mathit{r}⟨{\mathit{F}}_{\mathrm{r}}⟩\mathit{,}$(6)where F_r is the radial force from the particles calculated azimuthally on a grid and Φ is the gravitational potential. A grid of concentric rings divided into angular bins is used in order to increase the force calculation speed.

The intrinsic non-circular components of the gas velocities can be determined a number of ways. A simple approach is to bin the gas particles in radial and angular bins and calculate the differences between the flow within a cell and the expected RC. These can then be used to calculate the rms for the tangential and radial velocities as a function of radius.

A slightly more elegant approach is to calculate the m = 0 and m = 2 Fourier moments for both the tangential and radial velocities. This allows a comparison between the strength and orientation of the velocity moments and the mass moments. It is also particularly useful because the DiskFit algorithm (see Sect. 4.3.2), breaks down the observed velocity map into non-circular radial and tangential components that are similar to the intrinsic Fourier moments.

The Fourier components are given by: $\begin{array}{ccc}{\mathit{V}}_{\mathrm{t}}\mathrm{\left(}\mathit{r,\theta }\mathrm{\right)}\mathrm{=}{\mathit{A}}_{\mathrm{0}\mathit{,}\mathrm{t}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{+}\sum _{\mathit{m}\mathrm{=}\mathrm{1}}^{\mathrm{\infty }}{\mathit{A}}_{\mathit{m,}\mathrm{t}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\cos \mathrm{[}\mathit{m\theta }\mathrm{+}{\mathit{\theta }}_{\mathit{m,}\mathrm{t}}\mathrm{(}\mathit{r}\mathrm{\left)}\mathrm{\right]}\mathit{,}& & \\ {\mathit{V}}_{\mathrm{r}}\mathrm{\left(}\mathit{r,\theta }\mathrm{\right)}\mathrm{=}{\mathit{A}}_{\mathrm{0}\mathit{,}\mathrm{r}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{+}\sum _{\mathit{m}\mathrm{=}\mathrm{1}}^{\mathrm{\infty }}{\mathit{A}}_{\mathit{m,}\mathrm{r}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\cos \mathrm{[}\mathit{m\theta }\mathrm{+}{\mathit{\theta }}_{\mathit{m,}\mathrm{r}}\mathrm{(}\mathit{r}\mathrm{\left)}\mathrm{\right]}\mathit{,}& & \end{array}$whereA_m,t(r) and A_m,r(r) are the tangential and radial Fourier mth velocity moments respectively, θ, θ_m,t(r) and θ_m,r(r) are the angular phases.

4.3. Non-circular motions from mock observations

4.3.1. Tilted ring analysis

Generally, the observed velocities are described as ${\mathit{V}}_{\mathrm{obs}}\mathrm{=}{\mathit{V}}_{\mathrm{sys}}\mathrm{+}{\mathit{V}}_{\mathrm{c}}\mathrm{\left(}\mathit{r}\mathrm{\right)}\sin \mathrm{\left(}\mathit{i}\mathrm{\right)}\mathit{,}$(9)where V_sys is the systemic velocity and i is the inclination angle. ROTCUR (Begeman 1989) is widely used to extract V_c from two dimensional velocity maps.

The harmonic decomposition, pioneered by Franx et al. (1994), has been implemented into the GIPSY task RESWRI. This task is ideal for small scale departure from circular motions but not for large non-circular flows such as those induced by a bar. We do not include higher order harmonic components in the tilted ring analysis carried out in this work.

Fig. 2 Example of bar properties calculation for the gSb model. The gas density map in arbitrary unit is shown in the top left panel and the stellar density map in the bottom left panel. Comparison between the radial variation of the Fourier amplitudes A2 derived from the gas density map (dotted blue line), the stellar density map (continuous black line) and the ellipticity obtained by fitting ellipses to the stellar map (dashed red line) are shown in the top right panel. The phases are shown in the bottom right panel, lines and symbols are the same in both panels. The vertical dashed green line is the bar length estimated from the Fourier amplitudes, rA2, and the vertical black dashed line is the bar length estimated from the ellipticity, rϵ. The ellipse in the center of each map shows where the bar are located.

4.3.2. DiskFit analysis

Spekkens & Sellwood (2007) adopted a different approach when dealing with large scale non-circular motions induced by bars. Their method is based on modeling the tangential and radial components of the velocity at a given point as a Fourier series and by assuming that the non-circular flow is caused by a bar and that the non-axisymmetric distortion can be described by the m = 2 radial and tangential Fourier moment.

The DiskFit algorithm is designed to account for non-circular flows such as bi-symmetric distortion, kinematic warp and lopsidedness (see Spekkens & Sellwood 2007, for details).

For a bi-symmetric flow from a bar the velocity map is modeled using: $\begin{array}{ccc}\hspace{0.17em}\begin{array}{c}\begin{array}{c}\end{array}{\mathit{V}}_{\mathrm{model}}\mathrm{=}{\mathit{V}}_{\mathrm{sys}}\mathrm{+}\sin \mathrm{\left(}\mathit{i}\mathrm{\right)}\mathrm{\left[}{\mathit{V}}_{\mathrm{t}}\cos \mathrm{\right(}\mathit{\theta }\mathrm{)}\mathrm{-}{\mathit{V}}_{\mathrm{2}\mathit{,}\mathrm{t}}\cos \mathrm{(}\mathrm{2}{\mathit{\theta }}_{\mathit{b}}\mathrm{\left)}\cos \mathrm{\right(}\mathit{\theta }\mathrm{)}\\ \begin{array}{c}\end{array}\\ \begin{array}{c}\end{array}\mathrm{-}{\mathit{V}}_{\mathrm{2}\mathit{,}\mathrm{r}}\sin \mathrm{\left(}\mathrm{2}{\mathit{\theta }}_{\mathit{b}}\mathrm{\right)}\sin \mathrm{\left(}\mathit{\theta }\mathrm{\right)}\mathit{,}\end{array}& & \end{array}$(10)where V_t is the circular velocity, V_2,t and V_2,r the amplitudes of the tangential and radial component of the noncircular motions for a bi-symmetric flow model, and θ and θ_b are the angle in the disk plane relative to the projected major axis and angle relative to the bar axis respectively (see Spekkens & Sellwood 2007).

DiskFit uses a bootstrap method to estimate the uncertainties on the parameters using χ² minimization technique: ${\mathit{\chi }}^{\mathrm{2}}\mathrm{=}\sum _{\mathit{n}\mathrm{=}\mathrm{1}}^{\mathit{N}}{\left(\frac{{\mathit{V}}_{\mathrm{obs}}\mathrm{\left(}\mathit{x,y}\mathrm{\right)}\mathrm{-}{\sum }_{\mathit{k}\mathrm{=}\mathrm{1}}^{\mathit{k}}{\mathit{\omega }}_{\mathit{k,n}}{\mathit{V}}_{\mathit{k}}}{{\mathit{\sigma }}_{\mathit{n}}}\right)}^{\mathrm{2}}\mathit{,}$(11)where V_obs (x,y) is the observed velocity at the position (x,y) on the sky, σ_n is the uncertainty, ω_k,n is a weighting function which includes the trigonometric factors and also defines an interpolation scheme for the projected model (Spekkens & Sellwood 2007; Sellwood & Sánchez 2010).

5. Discussion of the results

The bar properties and the effect of the non-circular motion on the rotation curves are discussed in this section. The bar properties (bar strength and bar radius) obtained directly from the simulations and from the images are compared in Sect. 5.1. In order to see the effect of the bar more clearly, we select the snapshot from each of the nine isolated galaxy runs that has the strongest bar (see Fig. 1). We make mock observations of each snapshot with different bar orientations at a constant inclination of 60 degrees and a pixel size of 0.1 kpc. Each snapshot was then analyzed using both ROTCUR and DiskFit. DiskFit returns both the inferred circular and non-circular motions, while ROTCUR only returns the circular component. Therefore, we define the non-circular motions from ROTCUR as: ${\mathit{V}}_{\mathrm{NCM}}\mathrm{=}{\mathit{V}}_{\mathrm{ROTCUR}}\mathrm{-}{\mathit{V}}_{\mathrm{expected}}\mathit{.}$(12)The ROTCUR analysis is discussed in Sect. 5.2.1 and the DiskFit analysis in Sect. 5.2.2.

5.1. Bar properties: simulation vs. observations

An example of the simulation analysis is shown in Fig. 2. The left-hand panels show the gas (upper) and stellar (lower) surface densities for the gSb snapshot. The right-hand panels show the intrinsic bar strengths and orientations using the Fourier and ellipse fitting methods. There is a number of interesting things to note in Fig. 2. Firstly, the gas and stellar bars are different. The gas bar is significantly stronger, but they both have similar bar lengths. This is most likely due to the gas’ increased sensitivity to the bar’s perturbations because of its lower velocity dispersion. Secondly, the ellipse fitting analysis gives a shorter bar. This is due to the Fourier method including similarly oriented spiral structure at larger radii. The ellipse method more accurately determines the switch from the bar to the spiral structure. Aguerri et al. (2009) argued that the ellipse fitting method could under-estimate the actual bar length, and the difference between the bar length estimated from the Fourier and ellipse fitting technique could also depend on the bar surface brightness profile. The shorter bar obtained from the ellipse fitting technique has also been noticed by other authors (e.g, Erwin 2005; Michel-Dansac & Wozniak 2006).

Fig. 3 Comparison between the intrinsic bar radii obtained using the Fourier decomposition and the ellipses fitting methods estimated from the simulation. The dashed line is the one to one line.

Fig. 4 Comparison between the bar properties estimated within the simulation to those from images obtained from pseudo-observations. The maximum Fourier m = 2 amplitude estimated within the simulation is plotted against those obtained from images on the top left panel. Comparison between the maximum ellipticity measured within the simulation and from images is shown on the bottom left panel. The right panels show comparison between the bar radius estimated within the simulation with those measured from images, the bar radius obtained using the Fourier method is on the top panel and those obtained using the ellipse fitting technique on the bottom panel.

Fig. 5 Example of the “intrinsic” rotation curve calculation for the gSb model. First column: the tangential velocities map is shown in the top panel and the tangential Fourier moments map in the bottom panel. Second column: the radial velocities map is shown in the top panel and the radial Fourier moment map in the bottom panel. Third column: the top panel shows the comparison between the expected circular velocities Vexpected calculated from the gravitational potential as a solid black line and the Fourier A0(Vt) as a long-dashed magenta line. The expected and Fourier axisymmetric radial velocities are shown as solid blue and dashed green lines, respectively. The non-circular velocities as a function of radius are plotted in the bottom panel. The continuous black line and the long-dashed blue line are the rms velocities estimated from the residual maps, and the dashed lines are the m = 2 Fourier components. The ellipse in the center of each map shows the location and orientation of the bar.

In addition, the value of ϵ is larger than A₂/A₀ for the stars across the extent of the bar. However, this does not indicate a disagreement regarding the bar strength, because the two quantities are determined using radically different methods. The Fourier method draws concentric circular rings and calculates the Fourier moments, while the ellipse fitting method attempts to draw iso-density ellipses. Figure 3 shows comparison between the bar radii estimated from the ellipse fitting to those obtained from the Fourier decomposition for all the models. The bar radii estimated from the ellipse fitting are shorter than those obtained from the Fourier decomposition as illustrated in the example in Fig. 2.

Fig. 6 Ratio between VNCM = VROTCUR−Vexpected and Vexpected as a function of radius for the gSb, iSb and dSb models. The vertical dashed lines show 0.5, 1 and 2rbar estimated from the Fourier decomposition. Each rotation curve was derived from mock galaxies with projected bar orientation between 0 and 90 degrees. The projected bar PA are shown on top of each figure.

Fig. 7 Rotation curve error ΔV = [Vrotcur−Vexpected] /Vexpected at R = 0.5rbar where rbar is the bar radius estimated from the Fourier decomposition for all the Sb models. The giant Sb model is presented as red squares, the intermediate Sb as magenta circles and the dwarf or low mass Sb as green diamonds.

Figure 4 shows comparisons between the simulated and observed bar strengths and radii using the nine snapshots. This figure shows that the measured bar properties estimated within the simulation are similar to those obtained from pseudo-observations using stellar images.

5.2. Non-circular motions

A sample of the velocity flows found in the simulations is shown in Fig. 5. The upper left and middle panels show the binned velocity flows for the tangential and radial velocities respectively and the lower left and lower middle panels show the corresponding Fourier models. The upper right panel shows the expected rotation curve and compares it to the average tangential velocity flow and the m = 0 Fourier moment. This panel shows that the average velocity, the Fourier moment, and the expected rotation curve are all in agreement. The lower right panel shows the non-circular radial and tangential velocities calculated either using the rms method or the Fourier moments. In this case, the Fourier measure is slightly larger than the rms measurement. This result is easily understood through the method used. The m = 2 Fourier moments should equal the maximum deviation from circular motion, while the rms measure should be smaller as it averages the square of the deviations throughout the ring.

5.2.1. ROTCUR analysis

The rotation curves are derived from the velocity maps downloaded from the GalMer database. The bar orientation angle was varied between 0° and 90° for each snapshot. Figure 6 shows the deviations of the ROTCUR rotation curves from the expected rotation curve as a function of radius for the snapshots with the strongest bar for the gSb, iSb and dSb models. The ROTCUR rotation curves agree with the expected curve at approximatively 1 bar length, however they slightly increase between 1 and 2 bar lengths due to the perturbation caused by the spiral arm structures before returning to the true rotation curve at 2 bar lengths. Beyond 2 bar lengths, the curves all agree with the expected curve. The projected bar PA is shown in the top corner of each panel. The vertical dashed lines show 0.5, 1 and 2 bar radius. The Fig. 6 implies that the rotation curves measured using ROTCUR are smaller than the expected rotation curves inside the bar radius when the bar PA is less than 40° and larger than the expected velocities when the projected bar orientation is larger than 60°.

Fig. 8 DiskFit results for a giant Sb model, Left panel: the observed velocities field (top) and the residual velocities (bottom). Right panel: the DiskFit model (top) and a comparison between Vt, V2t and V2r with the amplitude of the m = 0 and m = 2 Fourier mode A0 and A2 (bottom).

Figure 7 shows the variation of the rotation curve error, which is the difference between the ROTCUR rotation curve and the expected rotation curve normalized by the expected rotation curve as a function of radius for nine different bar orientations. The velocity at R = 0.5r_bar is used to estimate the rotation curve error. This often corresponds to the maximum ellipticity ϵ_max (Michel-Dansac & Wozniak 2006). The magnitude of the rotation curve error is zero or very small when the bar is oriented at 45° from the major axis. The velocity at half the bar length is more than 40% larger than the expected value when the bar is perpendicular to the major axis, and 40% smaller when the bar is parallel to the major axis. There seems to be a systematic increase or decrease of the velocities derived by ROTCUR at half the bar radius depending on the orientation of the bar. This has been previously investigated in the literature (see e.g., Spekkens & Sellwood 2007). The reason for ROTCUR under or over-estimating the velocities is that when the bar is aligned with the major axis, most of the gas and stars are found at the apocenter of their elliptical orbits at each radius near the major axis. This gas is moving more slowly than it would if it was moving in circular orbits, and the rotation curve is under-estimated if this effect isn’t taken into account. Conversely, bars that project along the minor axis place gas and stars close to the epicenter along the major axis, which implies that the rotation curve will be over-estimated if bar-like flows are ignored (Spekkens & Sellwood 2007). This shows the importance of using a specifically designed packages such as DiskFit when deriving the rotation curves of barred galaxies.

5.2.2. DiskFit analysis

DiskFit (Spekkens & Sellwood 2007) is specifically designed to account for non-circular motions induced by bars. However, it is well known that the DiskFit algorithm fails when the bar is parallel or perpendicular to the major axis of the galaxy (Sellwood & Sánchez 2010; Randriamampandry et al. 2015). This failure is due to a degeneracy in Eq. (10) for θ_b = 0 or 90°.

The inclination, disk PA, disk kinematic center (x_c, y_c) and bar PA were allowed to vary during the fits. The systemic velocity V_sys is fixed to zero. A bi-symmetric distortion model (m = 2) is considered up to R = 2.5r_bar, then the non-axisymmetric flows are set to zero beyond this radius. The disk inclinations and PAs derived from DiskFit are in agreement with the expected values within the error bars. Five bootstraps were used to estimate the uncertainties on the parameters.

Fig. 9 Ratio between the Fourier amplitudes and the DiskFit velocities at R = 0.5rbar (estimated from the Fourier decomposition of the stellar surface densities) for the spiral Sa models, giants (blue), intermediate (green) and dwarf (red). The ratio ΔVt = (Vt−A0,t) /A0,t is plotted in the top panel, ΔV2r = (V2r−A2,r) /A2,r in the middle panel and ΔV2t = (V2t−A2,t) /A2,t in the bottom panel. The shaded area shows the range of bar orientations where DiskFit fails to recover the bar orientation or velocities, or where the uncertainties on the returned parameters are large.

Fig. 10 Same as Fig. 9 but for the Sb models.

Fig. 11 Same as Fig. 9 but for the Sd models.

Figure 8 shows a sample DiskFit analysis for the gSb snapshot with a bar angle of approximatively 45°. The observed velocity field is in the top left panel, the DiskFit bi-symmetric model is shown in the top right panel and the residual velocity (data-model) is in the bottom left panel. Only a few pixels in the innermost part of the residual map have values larger than 40  km s^-1.

Comparisons between the Fourier amplitudes and the DiskFit velocities for the Sa, Sb and Sd models are shown in Figs. 9−11 respectively. The ratio ΔV_t = (V_t−A_0,t) /A_0,t is plotted in the top panel, ΔV_2r = (V_2r−A_2,r) /A_2,r in the middle panel and ΔV_2t = (V_2t−A_2,t) /A_2,t in the bottom panel. The shaded gray area shows where DiskFit fails to recover the bar orientation or velocities, or where the uncertainties on the returned parameters are large, which is about 10° from the symmetry axes. There is a number of interesting things to note in these figures. Firstly, DiskFit successfully recovers the rotation curve and the non-circular components for all the models for the bar orientations ranging between 10° and 80°. Unlike the ROTCUR analysis, there is no systematic under or over estimation of the velocities. There is a larger scatter in the inferred non-circular moments. However, the scatter may be due to the resolution of the velocity maps and more work is required before any definite conclusions are reached.

6. Summary

We present an analysis of the strongest barred snapshots of nine isolated GalMer simulations. We characterized the intrinsic bar strengths and non-circular motions and compared them to mock observations of the systems.

We found that:

• The bar lengths estimated from ellipse fitting are shorter thanthose estimated from the Fourier decomposition techniquewhich is consistent with previous studies (e.g.,Erwin 2005; Aguerriet al. 2009).

• The Fourier decomposition technique gives similar results for the bar properties when applied directly to the simulation or to the images obtained from mock observations.

• ROTCUR systematically under-estimates the velocities when the bar is parallel to the major axis and overestimates them when the bar is perpendicular to the major axis for all the models. This shows the importance of properly accounting for the non-circular motions induced by the bar when deriving rotation curves (see Spekkens & Sellwood 2007; Dicaire et al. 2008; Randriamampandry et al. 2015).

• The magnitude of the rotation curves error when ROTCUR is used depends only on the orientation of the bar and it is not correlated with either the bar strength or the bar length.

• DiskFit is able to reproduce the amplitudes of the Fourier m = 0 and m = 2 components when the bar is at an intermediate PA.

• Unlike ROTCUR, DiskFit does not show a systematic over-estimation or under-estimation of the inner part of the rotation curves.

• DiskFit fails to recover the bar orientation or velocities, or return large parameter uncertainties when the bar is closer than 10 degrees to either the minor or the major axis (see also Sellwood & Sánchez 2010).

As future work, we will be using new simulations of a sample of four barred galaxies. This will allow us to perform a direct comparison between the simulation with the Hi and ancillary data from observations, as well as putting a tighter constraint on the bar orientation range where DiskFit fails.
