1. Introduction

The asymptotic giant branch (AGB) phase occurs when stars from 0.8 to 8 M are undergoing their last nuclear burning (Iben & Renzini 1983; Herwig 2005) and is a particularly interesting environment in which to study molecule formation and destruction. As shown in Fig. 1, the distribution and chemistry of species in the outer expanding circumstellar envelopes (CSEs), namely daughter species, are driven by hot (10002000 K) and shocked processes in the inner CSE where parent species are formed.

There are three types of AGB stars: C-rich (C/O > 1), S-type (C/O 1), and O-rich (M-type, C/O < 1). The largest variety of molecules is found in the CSE of C-rich stars, from simple CO to long carbon chains (e.g., Loup et al. 1993; Guélin et al. 1999; Cernicharo et al. 2000; Wakelam et al. 2010). The best-investigated AGB star, both observationally and theoretically, is the nearest C-rich star, IRC +10216 (e.g., Millar et al. 2000; Cernicharo et al. 2000; Woods et al. 2003; Cordiner & Millar 2009; Decin et al. 2010a; De Beck et al. 2012; Cherchneff 2012; McElroy et al. 2013; Li et al. 2014). To date, more than 44% of the 180 identified species in the interstellar medium (ISM) or CSEs1 have been detected in this star, with some being first detections in astrophysical environments, e.g., the cyanide anion CN (Agúndez et al. 2010b) and FeCN (Zack et al. 2011). A relatively small but increasing number of investigations have been made into S-type AGB stars (e.g., Ramstedt et al. 2006, 2009, 2011; Schöier et al. 2011; Danilovich et al. 2014), in which the central stars are undergoing evolution from an O-rich to a C-rich phase. During this transition, mixed chemistry may occur, especially when the O-rich material is stored in a stable disk around the central star, and features of both C-rich and O-rich chemistry may appear (Willems & de Jong 1986; Szczerba et al. 2007). This interesting dual chemistry may continue to post-AGB stars, and even proto-planetary nebulae (pPNe; see Gielen et al. 2011, and references therein).

thumbnail Fig. 1

Schematic structure of the CSE for an O-rich AGB star, which is divided into six regions for modeling purposes. (I): a degenerate C/O core and He/H burning shell; (II): a convective atmosphere; (III): a shocked inner wind where some parent species (mainly H2O, CO, and SiO) are formed; (IV): an intermediate expanding envelope where gas-phase chemistry may play a role; (V): an outer CSE where daughter species are formed primarily by photodissociation; (VI): the interstellar medium (ISM). This study focusses on the outer CSE where chemistry is mainly driven by the photodissociation and photoionization of molecules.

Open with DEXTER

Significant progress in the investigation of O-rich CSEs has been driven by new telescopes (Ziurys et al. 2007; Tenenbaum et al. 2010; Decin 2012), especially the Heterodyne Instrument for the Far-Infrared (HIFI) on board the Herschel Space Observatory (Pilbratt et al. 2010), which provided velocity-resolved spectra at far-infrared wavelengths that are not accessible from the ground. Several small molecules have been identified in O-rich evolved stars, for instance, CO, H2O, HCN, HNC, CN, OH, SiS, SiO, and NO (e.g., Cho & Ukita 1998; Ziurys 2006; Schöier et al. 2007; Ziurys et al. 2009; Maercker et al. 2009; Decin et al. 2010b; Quintana-Lacaci et al. 2013; Velilla Prieto et al. 2015). In addition, some O-bearing inorganic species, e.g., AlO and AlOH, have been identified in the supergiant VY Canis Majoris (Tenenbaum & Ziurys 2010).

Moreover, emission from polycyclic aromatic hydrocarbons (PAHs) and fullerenes C60 have also surprisingly been found in O-rich binary post-AGB sources (Gielen et al. 2011). All of these studies clearly show a rich inventory of molecules due to complex chemistry in the CSEs around O-rich central stars. The Atacama Large Millimeter/submillimeter Array (ALMA) is now starting to provide very sensitive, spatially resolved images of AGB envelopes as shown by the resolved shells of the AGB star R Sculptoris by Maercker et al. (2012). It is therefore appropriate to revisit the chemistry in these sources with an updated chemistry network.

Table 1

Envelope parameters and assumptions for IK Tau in our fiducial model.

In this work, we mainly focus on the well-observed O-rich AGB star, IK Tau (also known as NML Tau). This source has a large mass-loss rate of ~4.5 × 10-6M yr-1 (De Beck et al. 2010) in a wind that expands at a terminal velocity of 24 km s-1 (Justtanont et al. 2012). We note that these values are model dependent and may be different from those deduced from other observations (e.g., Maercker et al. 2008; Decin et al. 2010b). A few parent species (i.e., those formed close to the stellar photosphere) have been detected in the inner CSE of IK Tau in recent years, for instance, CO, HCN, CS, SiS, SiO, SO, and SO2 (Decin et al. 2010b; Kim et al. 2010), H2O (Decin et al. 2010c), NH3 (Menten et al. 2010), and PN and PO (De Beck et al. 2013). Schöier et al. (2013) conducted a survey of HCN in a sample of 69 stars that included all three types of AGB stars, including IK Tau, and concluded that the HCN abundances in C-rich AGB stars are, on average, around two orders of magnitude higher than those in O-rich stars. Fractional abundances of only two daughter species have been deduced from observations of IK Tau, CN (Decin et al. 2010b; Kim et al. 2010) and HCO+ (Pulliam et al. 2011). OH emission was identified but not quantified (Polehampton et al. 2010). In addition, thermal CO and SiO polarization has been mapped for IK Tau to study the orientation of its magnetic field (Vlemmings et al. 2012).

Willacy & Millar (1997) built a model specifically for O-rich CSEs and discussed the chemistry of daughter species in four sources: R Dor, TX Cam, OH231.8 +4.2, and IK Tau. At that time, only limited observational data and a restricted chemical network were available; therefore, some assumptions made in that work have since been discounted, e.g., CH4 was assumed to be a parent species, but the observations by Marvel (2005) provided no evidence for CH4 based on sensitive searches for the chemically related CH3OH and C2H molecules. Agúndez et al. (2010a) employed an improved model to investigate the chemistry in both O-rich and C-rich AGB stars, and suggested that the model predictions could be altered by taking into account a clumpy structure for the CSE, even with a simple approach. An improved list of parent species from observations was employed, but some parent species, e.g., NH3 and HCN, had not yet been observed at that time, and therefore were not included as parents. The assumed abundances of parent species is very important in the simulation of outer CSE chemistry because these species trigger and drive the chemistry of daughter species. Previously, local thermodynamical equilibrium (LTE) predictions were used to determine the parent species. However, predictions from shock-induced non-LTE calculations (Duari et al. 1999; Cherchneff 2006) significantly differ from these; for example, Cherchneff (2006) concluded that four species (CO, SiO, HCN, and CS) can exist in both C-rich and O-rich stars. The conclusion was consistent with the previous observations (e.g., Bujarrabal et al. 1994) and was further confirmed via the observations of Decin et al. (2008).

In previous work we developed a model that, for the first time, accurately treated the photodissociation of two significant parent species, CO and N2, in the CSE of a C-rich star, IRC +10216 (Li et al. 2014). Here, we adapt this model to study the chemistry of O-rich AGB stars. The recent progress of both observations and models makes a detailed and more reliable simulation possible. The chemistry of a large number of potentially observable species, including C-, N-, O-, Si-, S-, P-, Cl-, and F-bearing species are discussed.

The paper is organized as follows: the CSE model and improvements in this study are described in Sect. 2, followed by the results and discussion in Sect. 3, and conclusions in Sect. 4. A general investigation of the effects of varying the mass-loss rate and expansion velocity on the distributions of species is included in Appendix A.

thumbnail Fig. 2

Gas density, visual extinction, and gas temperature as a function of radius for the CSE of IK Tau from the center of the star towards the outside of the envelope. The radius is given in units of cm and stellar radii, R.

Open with DEXTER

2. Methods

2.1. Improvements in the model

The CSE model assumes that the gas expands in a smoothly expanding envelope with a constant mass-loss rate and velocity. The main assumptions of the model and envelope parameters of the O-rich AGB star, IK Tau, are listed in Table 1. More details about the CSE model can be found in McElroy et al. (2013), Millar et al. (2000), and Cordiner & Millar (2009). The kinetic temperature of the gas, T, number density of molecular hydrogen, n(H2), and visual extinction, AV, are shown in Fig. 2. The density follows a r-2 behavior dictated by conservation of mass and the temperature structure is calculated according to the following relation enforcing a 10 K lower limit, (1)where ri is the inner radius of our model. Extinction of the incident radiation is derived assuming purely absorbing grains and using standard values for the interstellar gas-to-dust ratio and extinction curve (Bohlin et al. 1978; Savage & Mathis 1979).

The chemistry of daughter species in the outer CSE is dominated by photodissociation. Far-ultraviolet photons from all directions of the interstellar medium are assumed to contribute to the photodissociation rate of each species. IK Tau is of spectral type M6 with an effective temperature 2100 K (see, e.g, Duari et al. 1999); hence, the UV flux arising from the star itself is negligible. The model is assumed to be fully spherically-symmetric (SS model, Li et al. 2014) and accurately calculates the shielding effects of molecules in an isotropic interstellar radiation field.

The fifth release of the UMIST Database for Astrochemistry (UDfA, McElroy et al. 2013), hereafter Rate12, which contains 6173 gas-phase reactions involving 467 species, is further updated with a few new rate coefficients for the most significant nitrogen reactions (Wakelam et al. 2013) and is adopted in all of the calculations. Very minor differences (within 2%) of the predicted peak abundances of the species are found when using these new rate coefficients compared with those using Rate12.

The treatment of N2 and CO photodissociation is the same as that described in our previous work (Li et al. 2014). Accurate photodissociation rates and shielding functions of N2 (Li et al. 2013; Heays et al. 2014) are used. These data come from a concerted laboratory (e.g., Ajello et al. 1989; Helm et al. 1993; Sprengers et al. 2004; Stark et al. 2008; Lewis et al. 2008a; Heays et al. 2011) and theoretical (e.g., Spelsberg & Meyer 2001; Lewis et al. 2005, 2008b; Ndome et al. 2008) effort over the last two decades. The CO photodissociation calculation uses the new rate and self-shielding functions from Visser et al. (2009). In the CSE model from (McElroy et al. 2013), the photodissociation rates of N2 and CO were adopted from van Dishoeck (1988), with self-shielding of CO treated only approximately (Morris & Jura 1983).Photodissociation of H2 is not included in this work because it is fully self-shielded even at the largest radius considered in the model, for instance, the column density of H2 is 3.5 × 1018 cm-2 at 7 × 1017 cm, corresponding to a shielding factor of ~10-4 (Lee et al. 1996), which means photodissociation of molecular hydrogen is negligible. In our model reactions of atomic hydrogen are included, but generally they are unimportant because the fraction of H is usually small in regions in which chemistry is active. Other models that treat these processes explicitly show that atomic H starts to become significant (n(H)/n(H2) > 10-4) only in the very outer part of the envelope, beyond 3 × 1017 cm (Glassgold & Huggins 1983). Such a low atomic H fraction should not have a significant effect on the chemistry, although there could be very small effects at the outer edge due to charge transfer with H, for example.

2.2. New list of parent species

The identification and abundance of parent species at inner radii is the first question to consider when modeling CSE chemistry. Typically three methods are used to constrain the parent species: TE predictions, shock-induced non-LTE predictions, and observations. The main benefit of theoretical predictions (TE and non-LTE) is that such models can provide a detailed list of all parent species. However, the disadvantage is that models are never as accurate as reality. Even assuming that the fundamental basis for the formation of these molecules is correct, the uncertainties in the physical processes in the inner CSE, chemical networks, and the initial abundances may still be significant. On the other hand, although high-quality data from powerful telescopes (e.g., Herschel, APEX, ALMA) provide direct constraints, some species are non-detectable. For example, N2, which is predicted to be the major elemental N reservoir in the inner layers; N2 is symmetric and thus possesses no electric-dipole-allowed pure rotational spectrum. In addition, the identification of many species is not straightforward owing to the lack of detailed molecular data. Moreover, deduced results from spatially unresolved spectra are sometimes very model-dependent, which means considerable uncertainties also possibly exist.

Thanks to the recent progress in observations of O-rich AGB stars (e.g., Decin et al. 2010a,b,c; Kim et al. 2010; Menten et al. 2010; De Beck et al. 2013) and shock-induced non-LTE simulations (e.g., Cherchneff 2006), we are now able to employ an improved list of parent species (see Table 2) in this study. Wherever they are available, we employ the abundances of parent species from the latest high-quality observations, otherwise those from shock-induced non-LTE abundances are adopted. Predictions from TE will only be used when no data are available from non-LTE or observational investigations. The effect of uncertainties in the abundances assumed for parent species is discussed in Sect. 3.12. We note that we do not simulate the chemistry in the intermediate envelope (100 R) within which gas-phase chemistry may alter the abundances of parent species.

Table 2

Initial fractional abundances f0(X)a of parent species, relative to H2, for the O-rich AGB star, IK Tau.

3. Results

3.1. General chemistry

Photochemistry induced by external UV photons dominates the chemistry in the expanding envelope of an AGB star. Generally, the formation and destruction processes of daughter species are controlled by the conversion XY X X+, as shown in Fig. 3. A major finding in this work is that photoionization of molecules is also significant in the outer layers: XY XY+. In this sense, the CSE chemistry of O-rich AGB stars differs from that found in standard photon-dominated region (PDR) models in which the ion-molecule chemistry of O-bearing species is driven by charge exchange reactions with abundant cations (see, e.g., Sternberg & Dalgarno 1995; Jansen et al. 1995a,b).

The synthesis continues with X+ (and XY+) abstracting H from H2 by ion-molecule reactions forming molecular hydride cations, which is frequently followed by dissociative recombination that leads to neutral molecular hydrides, and ends up in the formation of atoms or cations at the edge of the CSE. The model predicts that negative ions are not abundant in O-rich AGB stars.

thumbnail Fig. 3

General pathways for parent species giving rise to daughter species in the outer CSE of an O-rich AGB star.

Open with DEXTER

thumbnail Fig. 4

Column densities of H2O, CO, and N2 as a function of radius. The asterisks indicate a value of the column density that corresponds to a self-shielding factor of 0.4 for these molecules. Shielding effects become considerable when the column densities are higher than those indicated.

Open with DEXTER

thumbnail Fig. 5

Fractional abundances, relative to H2, of N2 and N (top panel) and C+, C, and CO (bottom panel) as a function of radius. Solid lines: from the SS model (Li et al. 2014), full shielding (dust + self- + H2 + H) are considered using an updated N2 photodissociation rate and self-shielding function (Li et al. 2013). Dashed lines: calculated from a model similar to that of McElroy et al. (2013), but adopting assumptions specifically for IK Tau. In this model only dust shielding is considered when calculating N2 photodissociation, and CO self-shielding is treated only approximately.

Open with DEXTER

3.2. Impact of new N2 and CO photodissociation rates

A proper treatment of the shielding of both N2 and CO photodissociation has a significant impact on the chemistry in the outer CSE of AGB stars. Among the various shielding effects, self-shielding is the most important factor in reducing the photodissociation rate of N2 and CO (Li et al. 2014). As shown in Fig. 4, self-shielding of CO and N2 becomes considerable at a large radius, around 2 × 1017 cm, where photodissociation from the external interstellar field is important. To accurately investigate the chemistry at smaller radii, we have considered full shielding (from dust, molecular H2, atomic H, and the molecule itself) of both N2 and CO in all of our calculations.

Figure 5 shows that the location of the transition zone from N2 N is shifted outwards by a factor of 7 when accurately considering shielding effects of N2 with the SS model, whereas the location for the conversion from CO C+ moves outwards by a factor of 2 when using updated shielding functions. These changes result in an important difference in the distributions of some daughter species whose chemistry is directly related to these species, e.g., NO and N2H+, as illustrated in Fig. 6. Other species, for instance HCN and CN, are less affected.

thumbnail Fig. 6

Fractional abundances of HCN, CN, N2H+, and NO, relative to H2, as a function of radius. Solid and dashed lines exhibit the results calculated from the SS model (Li et al. 2014) and those based on the updated model of McElroy et al. (2013), respectively.

Open with DEXTER

Another highly abundant species, H2O, is found to be significantly self-shielded in high abundance regions such as the planet-forming zones of circumstellar disks (Bethell & Bergin 2009). In the case of O-rich AGB stars, the self-shielding of H2O is only considerable at radii less than 2 × 1015 cm, where the photodissociation of H2O has not yet started to dominate its chemistry. This implies that the abundance of H2O is too low to be self-shielded at larger radii where photodissociation becomes significant, and it is not necessary to consider self-shielding of H2O in the CSE of AGB stars.

3.3. O-bearing species

We now discuss the chemistry of daughter species with column densities higher than 1011 cm-2 based on their chemical families. To avoid repetition, species that can be included in multiple subsections are only discussed once. For instance, the molecule CNO, which could be discussed in the subsections of C-, O-, or N-bearing species, is only discussed in the section for N-bearing species.

The dominant chemistry for many species depends on radius owing to the large gradient in the physical conditions (i.e., visual extinction, temperatures, and gas density) in the CSEs of AGB stars. Thus, the dominating formation and destruction routes might be different in other O-rich AGB stars. In addition, different assumed abundances of parent species may lead to quite different reaction paths for the daughter species.

The most abundant O-bearing daughter species triggered by the chemistry of H2O are OH, O2, and H3O+, whose radii of peak abundance are found in the region of (1−4) × 1016 cm, as shown in panel (a) of Fig. B.1. The chemistry of OH and O2 is relatively simple; they form mainly via the reactions H3O+ is mainly formed through (4)where H2O+ comes from various routes with the relative importance depending on radius, for instance, In the inner CSE, e.g., 2 × 1015 cm, OH+ is mainly generated by (8)where He+ is generated by cosmic-ray ionization. Direct OH photoionization becomes important for radii within 1017 cm, while H + O produces OH+ at larger radii. As noted above, this is different from traditional diffuse/PDR chemistry (e.g., Gerin et al. 2010) because of the high abundance of OH here. H is formed by the reaction between H2 and H, where H comes from the cosmic-ray ionization of H2.

The destruction of most O-bearing species is dominated by photodissociation. In addition to H2O, photodissociation of other O-bearing species, e.g., SiO, SO, CO2, and PO, among others, can liberate atomic oxygen at the outer edge of the CSE. CO is the main contributor at radii greater than 1017 cm, where Av is less than 0.3 mag. The chemistry of CO is discussed in the following section. The O-bearing cations are predominantly destroyed by dissociative recombination with electrons; e.g., H3O+ can be destroyed by the reaction (9)The fraction of electrons is an important factor in the ion-molecule chemistry (see panel a of Fig. B.1). Initially, at inner radii, e.g., 2 × 1015 cm, electrons mainly arise from the cosmic-ray ionization of H2, (10)where crp denotes cosmic-ray particles. As the radius increases to the region where the photodissociation of H2O becomes important, for instance at 1016 cm, electrons are produced by the process shown in Eq. (7). Farther out in the CSE, e.g., 3 × 1016 cm, contributions are mainly from three channels: At the edge of the CSE, with radius greater than 1017 cm, the electron density is controlled by the most abundant element, C. Farther in, the electron fraction as a function of radius is significantly affected by the assumption of key parent species, especially H2O, CO, SiS, and SiO.

3.4. C-bearing species

Carbon is mostly in the form of CO before it is converted into C+ at the edge of the envelope (panel b of Fig. B.1). The CO C C+ conversion controls the carbon chemistry. The non-self-shielding parent species, CO2, is less abundant and photodissociates from a radius of 3 × 1016 cm outwards. Four carbon compounds, CH, CH2, CH, and CH are found to be quite abundant, and are distributed at radii greater than 3 × 1016 cm where the temperature is less than 50 K (in our model ~10 K; see Fig. 2). Therefore, their emission would only be detectable from low rotational energy levels.

The formation of CH2 varies with radius. For instance, at 3 × 1016 cm, it is mainly formed by (14)The chemistry of SiCH is discussed in Sect. 3.6. At 1017 cm, CH2 is mainly produced by (15)In both cases, CH is formed through (16)whereas CH arises from the following process at all radii: (17)CH is generated through multiple channels, by and (20)In the above reactions, most of the CH+ is produced via the photoionization of CH, and is destroyed by the process described in Eq. (19) at all radii. The destruction of the neutral carbon hydrides, CH and CH2, is dominated by photodissociation, whereas that of most cations, e.g., CH, is via dissociative recombination. Interestingly, the destruction of CH is dominated by Eq. (17) rather than electrons. The chemistry of four other C-bearing species, namely C2, C2H, CH3OH, and HCO+, are discussed in Sect. 3.12.

3.5. N-bearing species

The chemistry of the parent species ammonia, NH3, controls the distribution of most N-bearing species, among which eight are found above the 10-11 abundance threshold (panel c of Fig. B.1). These species are mainly located at radii between 5 × 1015 and 5 × 1016 cm from the star. The most abundant daughter species generated by NH3 are NH2 and NH, which have peak fractional abundances around 10-6. By analogy with the corresponding oxygen and carbon species, NH2 is produced by the photodissociation of NH3 at radii less than its peak radius, 2.2 × 1016 cm, whereas dissociative recombination of NH with e dominates at greater radii. NH is the product of the photodissociation of NH3 and NH2 throughout the entire CSE, but with a significant contribution from the reaction between NH and e when the radius is greater than 1 × 1017 cm.

The relatively abundant cation, NH, is mainly formed through the photoionization of NH3 for radii inside its peak abundance, and by the reaction between NH and H2 at greater radii. NH comes from the photoionization of NH2 and reactions between NH+ and H2. The chemistry of NH is less complex, and forms mainly via the reaction between NH and H2. Only at very inner radii, e.g., 2 × 1015 cm, is it formed by the reaction of NH3 and H3O+.

The chemistry of NH3 also gives rise to other N-bearing species, such as HNO, NO, HNC, and HCNH+ (panel d of Fig. B.1) at radii between 1016−1017 cm. First, the breaking down of NH3 generates NH2, which reacts with atomic O and produces HNO. Then, HNO is photodissociated to NO. The formation channels of NO vary with radius, e.g., a non-negligible amount of NO is formed from the reaction between N and OH in the inner regions 2 × 1015 cm, and by OCN + O at radii greater than 5 × 1017 cm.

Throughout the CSE, HNC is mainly produced via HCNH+, in the following two reactions (21)and (22)The formation of HCNH+ is complex. At radii less than 1016 cm it is mainly formed via the reaction between H3O+ and HCN. However, at larger radii it is entirely formed via (23)where HCN+ is the product of reactions between C+ + NH2, and CN+ + H2. CN+ comes from the reaction between C+ and NH. Therefore, HCN contributes most to the formation of HNC in the inner regions whereas NH3 plays the most important role in the outer regions.

Another important N-bearing parent species, HCN, controls the chemistry of CN, OCN, and NH2CN (panel e of Fig. B.1). In our model, HCN starts to photodissociate at a radius of 1016 cm, breaking down into its daughter species, CN. We note that there are other (but very minor) routes leading to the formation of CN at its peak radius, for instance, the photodissociation of HNC, and the reaction between OCN and H. Its destruction at large radii is simply dominated by photodissociation.

The species OCN is mainly formed via (24)at radii less than 8 × 1016 cm, whereas dissociative recombination dominates its formation at greater radii, via with reaction rate constants that are assumed equal, 1.5 × 10-7 cm3 s-1. However, HNCO+ and HOCN+ are totally formed by the reaction between OCN and H (with a reaction rate constant of 1.6 × 10-8 cm3 s-1) and so comprise a cyclic formation pathway and not the dominant route to OCN bond formation. The rates for the above reactions are adopted from Quan et al. (2010), where more detailed discussions on these species can be found.

The chemistry of NH2CN is dependent on both NH3 and HCN. This species is simply formed by the reaction (27)and destroyed by photodissociation, (28)We note that more recent rate coefficients and branching ratios for the CH + NO reaction can be found in Bergeat et al. (1999) and references therein. These make no significant differences to our results.

3.6. Si-bearing species

The photodissociation/photoionization processes of parent species, SiO/SiS Si Si+, control the silicon chemistry and gives rise to other Si-bearing species (panels g and h of Fig. B.1). Similar to N-bearing species, most silicon compounds have peak abundances for radii between 1016 and 1017 cm. In total, seven high-abundance daughter molecules are found: SiS+, SiO2, SiOH+, SiN, HNSi, SiN+ and SiNH2+.

In the inner layers, at radii smaller than 2 × 1016 cm, the abundance of Si is higher than Si+ and its formation is dominated by the photodissociation of SiO. As the distance from the star increases, Si is photoionized to form Si+ and therefore contributes to the electron density. SiS+ comes from SiS, via charge exchange, (29)around its peak radius, and by the reaction between C+ and SiS in other regions. Its destruction is dominated by (30)The presence of OH at a high abundance (~10-5) generates a significant abundance of SiOH+ in an O-rich CSE, which is destroyed by dissociative recombination in the outer layers, Reactions (31) and (32) dominate the formation and destruction of SiO+. Similarly, the parent species NH3 generates NH, then increases the abundance of SiN+, which is formed and destroyed via the following processes at all radii: SiNH2+ is formed and destroyed in a very similar way, via The chemistry of SiO2 is triggered by SiO, via the following reaction throughout the envelope: (40)SiN is mainly generated by Eq. (38) within 1016 cm, but from the photodissociation of HNSi at greater radii. At all radii, HNSi is produced by Eq. (39). The destruction of all of these neutral silicon compounds is dominated by photodissociation, although their actual rates are quite uncertain and are experimentally difficult to measure.

The species HCSi peaks at a relatively larger radius, 4 × 1016 cm, arising from SiS through and (44)and is dissociated by UV photons.

3.7. S-bearing species

The conversion from the parents SO2/SO/SiS S S+ in the CSE is the key to the sulphur chemistry (panels i and j of Fig. B.1). The increase in atomic S is caused by the photodissociation of SO and SO2 (first releasing SO then S) at radii less than 1016 cm, with a contribution from the breaking down of SiS at larger radii, 3 × 1016 cm. Beyond this point, S is converted into S+ by photoionization. The less abundant parent species, H2S and HS, play a less important role in the chemical network.

In total, we find four abundant daughter species. At all radii, OCS is formed via (45)and NS is formed via (46)Similar to other neutral species, the destruction of OCS and NS is dominated by photodissociation. NS+ has a relatively low abundance, coming from NH reacting with S+. Like most cations, it is destroyed by dissociative recombination. SO+ is produced by the following two reactions, and, again, is destroyed by dissociative recombination.

3.8. P-bearing species

PN and PO are the two phosphorus-bearing parent species in our model. The conversion process PN/PO P P+, which is dominated by the photodissociation and photoionization, controls the phosphorus chemistry (panel k in Fig. B.1).

There are no experimental or theoretical studies of PN photodissociation. When employing a lower photodissociation rate of 5 × 10-12 s-1 provided by the Rate12 reaction network, our model produces a significant and likely unrealistic abundance of PN at very large radii where all other molecular species have been destroyed by the interstellar radiation field. This is also due to the neglect of PN photoionization in Rate12 despite the low ionization threshold of this molecule (Wu & Fehlner 1975) and a photoabsorption cross section that is likely to be comparable to that of electronically similar CO and N2. Thus, we adopted an improved PN photodissociation rate of 2.0 × 10-10 s-1, which is comparable to the N2 photodissociation rate (Li et al. 2013), together with an additional photoionization rate of 2.0 × 10-10 s-1 with γ = 3.0 for (49)to update the phosphorus chemistry.

Three species, HPN+, PH, and PN+, are found to be abundant. HPN+ is mainly formed via (50)and destroyed by three channels assumed to have equal branching ratios: PH arises from Eq. (51) at radii smaller than 1 × 1016 cm. Contribution from the routes becomes more important as the radius increases. The peak abundance of PH varies with the abundance of P+. The destruction of the neutral species PH is dominated by photodissociation. The main change of employing the modified PN photodissociation and photoionization rates is the destruction of the unrealistically high density of PN at large radii, and a resultant increase in PN+ abundance. The main destruction pathway of PN+ is dissociative recombination.

Further work on the PN photoprocesses is necessary to constrain our estimated rates.

3.9. Cl-bearing species

The chemistry of Cl-bearing species is initiated by the photodissociation of the parent species, HCl (panel f of Fig. B.1). The most abundant Cl-bearing daughter molecule in this model is H2Cl+. The breakdown of HCl leads to two species, At all radii, ~90% of HCl goes to Eq. (56) whereas ~10% goes to Eq. (57). H2Cl+ is formed via (58)and destroyed by (59)The cation Cl+ arises from the photoionization of Cl. It is worth mentioning that H2Cl+, HCl+, and H2O+ have been detected by the Herschel space observatory in the diffuse interstellar medium (e.g. Gerin et al. 2010, 2013; Lis et al. 2010; De Luca et al. 2012; Neufeld et al. 2012). Another Cl-bearing species, NaCl, has been found in IK Tau with an abundance of 4 × 10-9 (Milam et al. 2007). Unfortunately we do not have the chemistry of Na-bearing species in our network, thereby an extension of the chemical network would be useful for a further understanding of the chlorine chemistry. Our model shows that the abundance of CCl+ is negligible and is not shown in the plot.

3.10. F-bearing species

This is the first time that F-chemistry is included in a CSE model of an O-rich AGB star. The photodissociation of the parent species, HF, liberates atomic F and gives rise to other F-bearing species (panel l of Fig. B.1). Three daughter species, SiF+, CF+, and H2F+ are found to be very abundant. In particular, SiF+ has not been detected in the ISM because of the depleted elemental abundance of silicon. However, we predict that it may be detectable in IK Tau at a radius of ~1016 cm. At all radii, SiF+ and CF+ are formed by the reactions and are destroyed by H2F+ is formed via two routes, where HF+ arises from (66)and (67)The destruction of H2F+ is dominated by (68)and (69)

Table 3

Calculated total column densities, peak abundances (relative to H2), and peak radii of the daughter molecules in the CSE of the O-rich AGB star, IK Tau.

3.11. Comparison with observations

The calculated fractional abundances, peak radii, and total column densities of the top 37 daughter species in IK Tau are presented in Table 3. Observational information is only available for CN and HCO+. For CN the calculated peak abundance, total column density, and peak radius are in good agreement with the observations from Kim et al. (2010) and Decin et al. (2010b). For HCO+ the calculated peak radius is in excellent agreement with the observations of Pulliam et al. (2011), but the fractional abundance and total column density are orders of magnitude lower than the observations. This is discussed in the following section. The calculated total column densities of a few parent species, such as HCN, CS, SiS, SiO, SO, and SO2, are also compared to the observational results (Kim et al. 2010). Agreements are within a factor of 10 demonstrating that the parent species’ abundances are not altered significantly by gas-phase chemistry en route through the inner region of the outer envelope. However, we note that we have neglected gas-phase chemical processing through the intermediate envelope which may also affect the parent species’ abundances. A thorough comparison with observations requires calculations of the excitation and radiative transfer to compute line intensities rather than column densities, which is beyond the scope of the present work.

3.12. Sensitivities to the initial abundances

The assumed abundance of parent species is of particular importance for the predicted distribution and abundance of daughter species. The identification and abundance of most of these species at inner radii can be well constrained by both observations and theoretical models. However, the initial abundances of some parent species (e.g., N2) remain unclear. In addition, there is some discussion in the literature concerning the presence of additional species (e.g., atomic S and CH4) in the inner envelope with non-negligible abundances (see, e.g., Willacy & Millar 1997; Cherchneff 2006). A possible solution for inferring the presence and abundance of these species is via a few relevant daughter species.

Methane (CH4) is not assumed to be a parent species in the current study, based on the conclusions from the observational work of Marvel (2005), where the upper limits on abundances for C2H and CH3OH (methanol) were deduced to be 9.7 × 10-9 and 4.5 × 10-9, respectively. Gobrecht et al. (2016) also find that CH4 is not formed efficiently via gas-phase chemistry in the inner wind (r ≲ 10 R) in their model of IK Tau. Our model results are in general agreement with these conclusions. In the earlier photochemical model of Willacy & Millar (1997), CH4 was assumed to be a parent molecule with a large fractional abundance, 3.0 × 10-5, to explain the chemistry of a few carbon species, especially the unexpected presence of HCN in O-rich envelopes. At that time HCN was thought to be a daughter species that formed via reactions between atomic N, CH2, and CH3, which are photoproducts of N2 and CH4. The presence of CH4 as a parent also significantly increases the fractions of both C2H and CH3OH, by which one can constrain the upper limits for methane.

We find that the maximum abundance of CH4 in the O-rich AGB star IK Tau is 2.5 × 10-6 in order to be consistent with the observed upper limit for the C2H abundance (see panel a of Fig. B.2). Regardless of the inclusion or exclusion CH4 as a parent molecule in the model, the predicted CH3OH is at least 5 orders of magnitude lower than its observational upper limit, peaking at radii between 1015−1016 cm. One of the most important channels for CH3OH formation is via the chemistry of CH is discussed in Sect. 3.4. We note that in dense interstellar clouds, CH3OH is mainly formed on grain surfaces (Watanabe & Kouchi 2002; Garrod & Herbst 2006; Geppert et al. 2006; Fuchs et al. 2009) which is neglected here; however, the physical conditions in the CSE are not amenable to ice formation. Typically, ices exist in regions where Av> 1 which corresponds to the high temperature region (>600 K) in our model of IK Tau (see Fig. 2). Nevertheless, our results for gas-phase methanol are well within the observed upper limit from Marvel (2005).

At the radii where C2 possesses its peak abundance, it mainly arises from (72)C2H can be formed via multiple channels, among which the following routes contribute most: HCO+ has been detected in IK Tau, with an abundance of 4.4 × 10-8 at a radius of 3.9 × 1016 cm (Pulliam et al. 2011). The current model gives a peak radius that is in excellent agreement with this observation, but produces a lower abundance of HCO+. This is the case even where the cosmic-ray ionization rate of H2 is increased with respect to its standard value in our models of 1.2 × 1017 s-1 by a scaling factor χ up to a value of × 1000. The inclusion of the maximum amount of CH4 consistent with observations, 2.5 × 10-6, only increases HCO+ by a minor amount (see panel b of Fig. B.2). Another model assuming a higher abundance for the initial CO only slightly enhances the peak abundance of HCO+. At the radius of its peak abundance, i.e., 3 × 1016 cm, HCO+ is mainly formed from C+ with CO+ and HOC+ as intermediates via the reactions and (81)Only a minor amount (10%) of HCO+ is formed by the reaction between C+ and H2O. If the abundance of parent species in our model photodissociating to form C+ is increased, then a minor enhancement of HCO+ results: (82)The peak abundance of HCO+ may also be enhanced by the inclusion of the neutral analogue HCO as a parent species. A potential route to HCO in the inner CSE is via the reaction between H and CO with a third body (see, e.g., Baulch et al. 2005). The backwards reaction has a large energy barrier (8000 K Baulch et al. 2005), potentially leading to appreciable abundances of HCO. The inclusion of HCO formation and destruction in models of the inner CSE of O-rich AGB stars are worth investigating in the future.

The electron abundance, which has been discussed in Sect. 3.3, is the most significant factor in destroying many cations. The C-, S-, and Si-bearing parent species contribute most to the formation of electrons depending on the radius. However, the abundances of C and Si related species are strongly constrained as discussed in Sect. 2.2 and here we only explore the effect of the uncertainty introduced by the unknown amount of atomic S among the parent species. In our fiducial model we exclude atomic S as a parent species. However, the shock-induced non-LTE simulation of Cherchneff (2006) suggested that most elemental S is in atomic form for O-rich AGB stars, which was further confirmed in the latest simulations specifically focussing on IK Tau (Cherchneff, priv. comm.). Since the solar abundance of elemental S relative to H2 is 2.6 × 10-5 (Asplund et al. 2009), and we have 1.1 × 10-5 in SiS in our model (see Table 2), we assume the maximum amount of S in the inner CSE to be 1.5 × 10-5. As can be seen in panel c of Fig. B.2, the uncertainty of including or excluding atomic S has a minor effect on the total abundance of electrons, and therefore on HCO+. Interestingly, NS is found to be sensitive to the initial abundance of atomic S, and may be useful as a diagnostic measurement. More interestingly, as can be seen in panel d of Fig. B.2, both NS and NO are not affected much by the initial N2 abundance. It is hard to detect N2 directly, but it can be indirectly constrained by the abundance of N2H+, which is mainly formed via the reaction (83)At larger radii, e.g., 1017 cm, its formation is dominated by where the He+ is generated by cosmic-ray ionization. In all situations, the abundance of N2H+ is directly related to the initial abundance of N2, but this species has not yet been detected in the CSEs of AGB stars.

4. Concluding remarks

We simulated the chemistry in O-rich circumstellar envelopes of AGB stars. We have calculated radial abundances suitable for guiding future observational studies and identified the most abundant species. Our model includes the latest gas-phase reaction network and photodissociation processes, including a spectroscopically realistic treatment of N2 and CO self-shielding. The H2O column is found to be too low to self shield. With the proper self-shielding factors, the N N2 and C+ CO transitions are shifted outward by factors of 7 and 2, respectively, in the fiducial model representing IK Tau. We also adopt a selection of precursor parent species based on observations and the latest non-LTE model of the interior CSE of IK Tau.

There are few quantitative observational constraints on the molecular abundances in IK Tau, but based on our experience with the C-rich CSE surrounding IRC +10216 (Li et al. 2014) we expect order-of-magnitude accuracy for our predictions of C-, N-, O-, and Si-bearing molecules. The reaction networks for less abundant elements (S, P, Cl, and F) are not as well known, but significant abundances of their host molecules are predicted by our model. Many molecules have peak abundance between 1016 to 1017 cm from the star where the ionization and dissociation of parent species provides a source of radicals but where molecules are still somewhat shielded from interstellar radiation. Key steps in the intervening chemistry are hydrogen abstraction of radical ions with H2 and the production of neutral fragments by dissociative recombination and the ultimate destruction of all molecules by the ISRF.

We find chemical links between potentially observable daughter molecules and the abundances of parent species in the inner CSE. Observationally derived upper limits for the amount of C2H and CH in IK Tau provide a low constraint on the relative abundance of the potential parent CH4, <2.5 × 10-6. We also find that observations of NS and N2H+ could provide indirect constraints on the parent abundances of atomic S and N2.

Our modeled molecular abundances are also sensitive to the assumed physical parameters of the CSE. We find that the stellar mass-loss rate, which is usually not straightforward to obtain from observations, has a large impact on the calculated abundances. On the other hand, variations in the envelope expansion velocity and cosmic-ray ionization rate are not as significant (see Appendix A).

Many of the predictions of our models (both overall abundances and peak abundance radii) can be tested directly by spatially resolved observations with ALMA in the near future.
