1. Introduction

The fundamental quantity that is routinely measured in a microlensing event is the Einstein timescale tE, (1)where xDL/DS. It depends on the lens mass M, the lens and source distances from Earth DL and DS, and the lens-source relative velocity V. Consequently, the lens mass cannot be inferred without any knowledge of x and V. This degeneracy in tE can be resolved via the equation M = θE/κπE, with κ a constant, if the angular Einstein radius θE = tEV/DL and the microlens parallax , (2)can both be measured from the event light curve (Gould 2013, from now on G13). The quantity θE is measured via finite source effects in high-magnification single-lens events and in a large number of the planetary ones. G13 has shown that for planetary events (tE ≈ 20 days) with peak amplifications Amax ≳ 20, a satellite placed in geosynchronous orbit would measure the microlens parallax πE, providing lens masses. This result is especially important in the perspective of the Wide Field Infrared Space Telescope (WFIRST) mission (Barry et al. 2011): a geosynchronous orbit is currently a strong alternative to the second Lagrangian point (L2) (Spergel et al. 2015). In particular, G13 studies the regime where the satellite orbital period P is much shorter than the shortest timescale of the microlens event, teffβtE, with β the lens-source impact parameter in units of θE. The following scaling law for the relative error on πE is predicted: (3)where R is the satellite orbital radius. The sensitivity to πE increases towards shorter Einstein timescales. However, Eq. (3)does not apply when PβtE, as correlations between πE and the other model parameters, such as β and tE, start to affect the error on πE.

In this paper, after briefly setting up the Fisher matrix analysis in Sect. 2, we extend the analysis of G13 to shorter Einstein timescales in Sect. 3, to cover events raised by Jupiter-mass lenses (tE ≈ 1 day). Then, in Sect. 4 we study the capabilities of a low Earth orbit satellite to detect microlens parallax in case of Earth-mass lenses (tE ≈ 0.1 days).

2. Fisher matrix analysis

The Fisher information matrix provides a way to predict, in a Bayesian framework, constraints on the best fit of a theoretical model to observational data. It allows the covariance matrix of the model parameters to be estimated via their posterior probability distribution (Sellentin et al. 2014). The Fisher matrix is a fast, analytical alternative to time-consuming methods such as the Markov-Chain Monte Carlo, even though its reliability is not always guaranteed (Vallisneri 2008).

The physical observable of a microlensing event is the light flux F, (4)where Fs, Fb, and are the source, blending, and baseline fluxes, and νFb/ (Fs + Fb) defines the blending ratio. In a point source-point lens (PSPL) model, the amplification factor A is given by , where u is the magnitude of the lens-source separation vector u as seen by the observer. For an inertial observer, , where τ ≡ (tt0) /tE and t0 is the peak time. The inertial observer model is thus described by five parameters: .

Under the assumption of Gaussian errors, the Fisher matrix elements are given by (Sellentin et al. 2014) (5)where the index k spans the set of N independent observations, and σ is the flux error. We have assumed Poisson noise-limited photometry with , where σm is the magnitude error at the light curve baseline. In the case of continuous observations, i.e. tE ≫ 1, where f is the number of observations per unit time, the sum appearing in Eq. (5)can be approximate by an integral over time, (6)Since the parallax signal contributing to the matrix comes from a few teff near τ = 0, the boundaries of integration can be safely extended to infinity, as shown in Eq. (6), if the observations last more than a few event timescales1. Once the Fisher matrix is computed, the covariance matrix of the model parameters is given by its inverse, -1 (Sellentin et al. 2014).

2.1. Parallax effect for an Earth orbit satellite

Observations from an Earth orbit satellite are affected by the parallax effect of its non-inertial motion, in the same way as for a telescope on Earth (Hardy & Walker 1995). We thus consider an observatory in circular orbit around Earth with radius R and period P (ω = 2π/P as its angular velocity). If λ denotes the latitude of the source star with respect to the plane of this orbit, the projection of the satellite trajectory onto the plane of the sky is an ellipse with semimajor and semiminor axes R and Rsin(λ), respectively. Following G13, one then defines ϵ = ϵR/ 1 AU and ϵRsin(λ) / 1 AU. Let θ denote the direction of the lens-source relative motion in the plane of the sky with respect to the projected major axis of the satellite orbit. The lens-source separation vector seen by the satellite is given by u = (τcosθβsinθ + ϵπEcos(ωtEτ + ϕ)sinθ + βcosθ + ϵπEsin(ωtEτ + ϕ)), where ϕ is the satellite orbital phase with respect to the peak time t0 (Hardy & Walker 1995, G13). If one introduces the microlens parallax vector πE = (π,π) = πE(cosθ,sinθ), the non-inertial observer model is described by seven parameters: . The two additional flux derivatives ∂F/π and ∂F/π appearing in the Fisher matrix (5)are proportional to ∂u/π and ∂u/π, respectively, with (7)The approximate equalities mean we neglect terms that are linear in πE. Moreover, one can assume . These approximations are justified as long as ϵπEβ-1 ≪ 1. In the following analysis, the above inequality is safely verified. G13 also assumes its validity.

2.2. Sensitivity to πE

Once the Gaussian approximation to the posterior probability distribution of π and π is known via the Fisher matrix, one can forecast the sensitivity of microlensing observations to πE through standard error propagation. Since small variations in the parallax parameters are related by δπE ≃ cosθδπ + sinθδπ, the 1-σ error on πE is given by the equation (8)where cov(π,π) is the covariance between the two parallax parameters. In principle, depends on both θ and ϕ.

To present results that are independent of the geometry of the event, we summarise the information contained into Eq. (8)by finding the extrema of over θ,ϕ ∈ [ 0,2π ]. To do this, one first notices that, according to Eq. (7), , , and cov(π,π) do not depend on θ, but only on ϕ. One can thus analytically find the extrema of over the θ range, (9)where the plus and minus signs stand for the maxima and minima. The values of θ that correspond to these extrema are given by 2. Then, one can find the extrema of Eq. (9)over the ϕ range numerically, and they only depend on tE and β: (10)We note that for PβtE, the covariance between π and π vanishes, and become independent of ϕ, and the extrema of are simply given by and .

3. Geosynchronous orbit satellite

thumbnail Fig. 1

Relative error on πE plotted against tE for a GSO satellite. We assume 3 min exposures, σm = 0.01, and zero blending. For β = 0.1 the region σπE/πE ∈ [ σπE, min,σπE, max ] /πE is shown, along with the G13 prediction. For β = 0.05,0.025,0.01, and 0.005, the minimum relative error σπE, min/πE is plotted.

We then consider the case of a geosynchronous orbit (GSO) satellite, orbiting in the equatorial plane and targeting the Galaxy bulge, P = 23h56min4s, R = 6.6 R, λ = 30°. We assume f = 1 observation / 3 min, which is reasonable for a WFIRST-like satellite (G13) and a magnitude error at baseline σm = 0.01. Figure 1 shows the predicted relative error σπE/πE as a function of the Einstein timescale tE, for zero blending (ν = 0). Since, from Eq. (2), πE depends on DL, DS, and V, we consider a typical disk lens at DL = 4 kpc and V = 200 km s-1 (DS = 8 kpc for a source in the bulge of the Galaxy).

For an impact parameter β = 0.1, which corresponds to a peak amplification Amax ≈ 10, we plot the region σπE, minσπEσπE, max to take the variations induced by the parameters ϕ and θ into account. Figure 1 clearly shows two different regimes. For tE ≫ 1 day, the relative error on πE scales as tE1 / 2, in agreement with Eq. (3), the analytic prediction of G13. For tE ≪ 1 day, the relative error increases by decreasing tE, as a result of the correlations between π,π, and the other parameters ν,t0,tE, and β. In the intermediate region 1 day ≤ tE ≤ 3 days, a maximum sensitivity to πE is attained. In particular, at tE ≈ 3 days, the error range is very narrow around σπE/πE ≈ 9%. By decreasing tE, σπE, max increases steeply, while σπE, min still decreases to a minimum value of about 7% at tE ≈ 1 day. This means that one can end up with a good sensitivity to πE even at tE ≈ 1 day, where the maximum relative error is already a steep function of the Einstein timescale.

For smaller impact parameters, β< 0.1, Fig. 1 shows the minimum relative error σπE, min/πE. The region of maximum sensitivity to πE clearly moves to higher Einstein timescales. If one considers the Einstein timescale which minimizes σπE, min/πE, it approximately scales according to (11)Indeed, it separates the two regimes βtEP and βtEP. To estimate the minimum relative error for a given β, one can write that, approximately, σπE, min/πEtE1 / 2βR-1g(βtEω), where g(y) is a function that tends to 1 for y → ∞, to match Eq. (3). Since Eq. (11)implies , one obtains (12)Equations (11)and (12)are in good agreement with Fig. 1. The maximum sensitivity to πE increases slowly by decreasing the impact parameters β, while the range of the Einstein timescales that allow for a parallax detection clearly widens.

thumbnail Fig. 2

Ratio σπE, min(ν) /σπE, min(ν = 0) against ν for a GSO satellite and β = 0.1, with the same assumptions as in Fig. 1. Three Einstein timescales are shown: tE = 1, 3, and 10. Clearly the error diverges for ν → 1.

From the above analysis and Eq. (1), it follows that a GSO satellite is naturally optimized to measure microlens parallax πE in events raised by free-floating objects with masses spanning from a fraction to a few dozens MJup. The peak amplifications for such a measure can be as low as 10, or even somewhat lower for closer lenses. If, additionally, the Einstein angle θE can be measured via finite source effects (starting at Amax ≈ 50 for a Jupiter-mass lens and a Sun-like source, see Eq. (14)), the lens mass can be inferred for this class of events.

Analogously, since for a bulge source the Einstein radius scales as RE = tEV = 0.12 AU (M/MJup)1 / 2(x(1 − x) / 0.25)1 / 2, a GSO satellite is naturally optimized to discover planets in tight orbits around low-mass brown dwarfs3. In particular, as a matter of speculation, it could lead to the discovery of miniature planetary systems around planetary-mass brown dwarfs4. In fact, disks have been found in the past fifteen years to surround brown dwarfs with masses in the range 5−15 MJup (see, for example, Luhman et al. 2005b,a). In particular, the disk around OTS 44 has been estimated at roughly 30 M (Joergens et al. 2013). The question of whether planets can form out of such disks naturally arises, but very little is known about these hypothetical planetary systems, even from a theoretical point of view. Gravitational microlensing could thus lead to fundamental discoveries in this field.

3.1. Blending

G13 adopts in Eq. (5), meaning that it neglects the blending flux Fb by stating that one is “only concerned with the scaling of the errors when the source is relatively highly magnified”. Actually, Eq. (4)shows that the information contained in the Fisher matrix thanks to the source flux amplification is scaled by a factor 1 − ν; i.e., the light curve provides less information about the model parameters if the blending factor ν is bigger. This is illustrated in Fig. 2, where we plot the ratio σπE, min(ν) /σπE, min(ν = 0) against ν for β = 0.1 and different values of the Einstein timescale tE. The error roughly doubles at ν ≈ 0.6, and the detection of πE becomes quite hopeless for ν ≳ 0.9. Blending can thus highly affect the sensitivity to πE and it must always be taken into account in survey planning. It is also important to point out that, even for very low values of the blending factor, ν → 0, this parameter still affects the sensitivity to the other ones. Indeed, a small variation δν produces a change in the total flux F according to | δF | /F ≃ (A − 1)δν/ [ (1 − ν)A + ν ]. For ν → 0 and A ≫ 1, one obtains | δF | /Fδν, which means that the contribution of ν to the Fisher matrix is different from zero even for vanishing blending factors. Gould’s assumption in G13 is only valid for ν → 0 and PβtE, because in this regime the correlations between ν and the parallax parameters π and π turn out to vanish5.

4. Low Earth orbit satellite

thumbnail Fig. 3

Relative error on πE plotted against tE for a LEO satellite at 550 km above the Earth’s surface. We assume 3 min exposures, σm = 0.01, and zero blending. For β = 0.1 the region σπE/πE ∈ [ σπE, min,σπE, max ] /πE is shown. For β = 0.05,0.025,0.01, and 0.005, the minimum relative error σπE, min/πE is plotted.

Using a space telescope in low Earth orbit (LEO), such as the Hubble Space Telescope (HST), measuring microlens parallaxes was first proposed by Honma (1999). In G13 Gould argues that this would generally be useless, since the corresponding ϵ = R/ 1 AU is too small. However, substituting Kepler’s third law, P2R3, in Eq. (12)leads to the following scaling law: (13)The maximum sensitivity to πE decreases slowly when one reduces the orbit radius, and what changes between a GSO and a LEO is just a factor of (6.6)1 / 4 ≈ 1.6. Moreover, Eqs. (11)and (1)show that the timescale at which a LEO satellite is most sensitive to πE coincides with the typical Einstein timescale of an Earth-mass object.

These properties are clearly shown in Fig. 3, where we consider a LEO satellite with HST-like orbital parameters. We assume an orbit radius R = R + 550 km (P = 1 h 35.5 min) and an event latitude λ = 60° for a bulge source, since the Hubble inclination above the equatorial plane is 28.5°. The predicted relative error σπE/πE is plotted against the Einstein timescale tE for DL = 4 kpc, V = 200 km s-1, and zero blending (ν = 0). We assume f = 1 observation / 3 min and σm = 0.01 as in Fig. 1, to allow for a quick comparison with the GSO. The plot shows the same physics as in Fig. 1, with two different regimes that arise for each choice of β. At β = 0.1, the maximum sensitivity to πE corresponds to Einstein timescales of one to several hours. According to Eq. (1), these tE are typical of lens masses ranging from M to the super-Earth/ice giant transition. With a minimum relative error of roughly 10%, Fig. 3 suggests that a detection of πE for these lenses should be possible for β ≲ 0.1−0.2. Since finite source effects easily arise for these kinds of lenses (see Sect. 4.1) and can provide a measure of θE, a LEO survey satellite could discover populations of free-floating objects ranging from terrestrial planets to super-Earths and ice giants. This would be a fantastic prospective for microlensing and exoplanet science in general. Clearly, a LEO survey would be affected by blending limitations, similar to the GSO. Moreover, the effects of Earth umbra have to be taken into account, because it reduces the fraction of the orbital period available to follow the source star (see Sect. 4.2).

For β< 0.1, Eqs. (11)and (12)are consistent with Fig. 3, similar to what is obtained for the GSO. In particular, we point out that with peak amplifications of several dozen, a LEO satellite should also be able to measure microlens parallax for tE ≈ 1 day events, especially if ground-based observations are also available.

4.1. Finite source effects

Finite source effects arise when the impact parameter β is comparable to ρ = RSx/RE, the projection of the source star radius RS onto the lens plane, measured in units of the Einstein radius RE. Taking a Sun-like source as reference, the parameter zβ/ρ is given by (14)Equation (14)shows that finite source effects are clearly measurable for β = 0.1 and . Moreover, they are always detectable for β< 0.1 and since Eq. (11)implies that .

The Fisher analysis presented in Sect. 2 considers a point source. Can this assumption invalidate the error predictions of Fig. 3? The peak amplification influences σπE via the relation Amaxβ-1. Therefore, finite source effects strongly modify the error predicted by a PSPL model if the maximum amplification of a finite source model, (Witt & Mao 1994), is much smaller than β-1, that is, . Because , finite source effects strongly affect the error predictions only for z ≪ 1 / 2 (Witt & Mao 1994), which corresponds to tE ≪ 0.1 days at β = 0.1 for source stars not much bigger than the Sun. As Fig. 3 shows, these timescales are, however, of little importance since the error is already too big. For lower values of the impact parameter, β< 0.1, and , the predictions are a priori strongly affected by finite source effects. However, since Fig. 3 shows that for , the sensitivity to πE rapidly saturates when one reduces β, we do not expect important deviations even for these timescales.

In the case of giant-like source stars, RS ≳ 10 R, finite source effects are dominant since peak amplifications can be much lower than what is predicted by a PSPL model. Basically, one can think in terms of an effective impact parameter β = β (2z)-1. For RS ≳ 10 R and tE = 0.1 days, one has and β ≃ 1, and Fig. 3 suggests that σπE would not guarantee a robust parallax detection. At tE = 1 day, one gets β ≳ 0.1, and the parallax sensitivity is still marginal. Therefore, the finite source effects of giant-like stars seem to exclude robust measurements of πE for Earth-mass lenses. However, larger sources generally yield smaller photometric errors σm, and a parallax detection could still be feasible for closer lenses, i.e., DL ≲ 500 pc or x ≲ 0.06, and RS ≲ 10 R (see Eq. (14)).

4.2. Earth umbra

The Earth shadow can represent a significant limitation to the capabilities of a LEO satellite. It reduces the fraction η of the orbital period available to observe the microlensed source star. We calculate the dependence of this fraction on the orbital radius R and the event latitude λ over the orbital plane, (15)For R = R + 550 km, η has a minimum value of 63% at λ = 0°, and it slowly increases to 79% for λ = 60°. For λλ ≡ arcsin(R/R) ≈ 67°, the source star is always visible from the satellite. Consequently, even if the analysis of Sect. 4 is strictly valid for continuous observations (η = 1), Eq. (15)seems to indicate that Earth umbra does not invalidate its general conclusions when one tracks bulge stars. There is also some room to minimize the impact of the Earth shadow by adjusting the satellite orbital parameters. For an altitude of 1000 km, for example, the angle λ decreases to 60°. Moreover, increasing satellite inclination above the equatorial plane can substantially reduce the shadow impact.

5. Conclusions

The present study employs a numerical Fisher matrix analysis to assess the feasibility of measuring microlens parallaxes by means of Earth orbit satellites. It extends the previous analytical analysis of Gould (2013) to shorter Einstein timescales. We predict that, at Amax ≳ 5−10, a GSO satellite could detect microlens parallaxes for free-floating lenses with masses spanning from a fraction to a few dozen MJup (providing their mass if θE is also measured via finite source effects). It could also discover planets in tight orbits around very low-mass brown dwarfs. Moreover, at β ≲ 0.1−0.2, a LEO satellite could discover free-floating objects ranging from terrestrial planets to super-Earths and ice giants. It could also detect, at β ≲ 0.05, microlens parallaxes for Jupiter-mass free-floaters. Limitations to these results can be the strong requirements on the photometry (0.01 mag error with three-minute exposures), the effects of blending, and in case of a LEO satellite, the Earth umbra. It is useful to note that, even though this study adopts a single-lens model, we extrapolated its results to binary-lens events. Indeed, as far as a parallax effect is concerned, the fundamental quantity is the projected separation between the source star and the lens centre of mass. In planetary events this almost coincides with the host. What really differentiates the two kinds of events is that finite source effects are needed to measure θE and estimate the lens mass: they are not routinely measured in single-lens events, while they are for binary ones.


Substitution (6)causes the element to diverge, meaning that an arbitrary precision on can be attained by observing enough in the baseline of the light curve. The parameter can thus be safely considered as a constant and can be removed from the Fisher analysis.


The extrema σπE, ±(ϕ) correspond to a lens-source relative motion aligned with one of the principal axes of the bivariate Gaussian distribution which approximates the posterior probability distribution of π and π in the Fisher matrix analysis, when one marginalises over the remaining parameters.


Han et al. (2013) report the discovery of such a system. However, the mass ratio of this binary appears too high to envisage that the companion formed in a protoplanetary disk around the host.


These could also be interpreted as free-floating planet-moon systems (Bennett et al. 2014).


We note that, if for a given event ν = 0 holds exactly, the parameter ν must be removed from the corresponding Fisher analysis, and the present predictions provide an upper bound to σπE.


F. M. is grateful to N. Cornuault, L. Pittau, and C. Ranc for the frequent and fruitful discussions. The authors acknowledge the support of PERSU Sorbonne Université and the Programme National de Planétologie.
