1. Introduction

Feedback mechanisms from quasars (QSOs) are considered to be crucial for galaxy evolution (see King 2010; Fabian 2012 and King & Pounds 2015). During the bright active phase, active galactic nuclei (AGN) are believed to drive energetic outflows that expel gas at large scales from their host galaxies (e.g. Granato et al. 2004; Di Matteo et al. 2005; Menci et al. 2008; King 2010; Zubovas & King 2012; Fabian 2012; Faucher-Giguère & Quataert 2012; Zubovas & King 2014; Nayakshin 2014; Costa et al. 2014, 2015), hence removing the supply of cold gas required for star formation (SF) activity. According to some of these models, the black hole (BH) achieves a critical mass during the later stages of a merging event, and the energy output of the associated AGN is so large that radiation pressure drives a fast outflow in the nuclear region that sweeps away the gas in the host galaxy. When the feedback phase is completed, the stellar population in the host galaxy continues to grow mainly through minor or major mergers with other galaxies (e.g. Baldry et al. 2004; Pérez-González et al. 2008). At the same time, the lack of gas around the nucleus slows the growth of the BH down. Models invoke feedback mechanisms to explain the origin of the correlation between the mass of supermassive BHs and the mass and velocity dispersion of host galaxy bulges observed in the local Universe (e.g. Magorrian et al. 1998; Marconi & Hunt 2003; Ferrarese & Ford 2005; Kormendy & Ho 2013). Essentially, the observed correlations can be explained as the result of the balance between the outward-radiation force generated by the AGN and the inward-gravitional force of the host galaxy (e.g. King 2010; Fabian 2012).

Quasar-driven outflows extending to kpc-scales have been resolved both locally (e.g. Feruglio et al. 2010, 2013b,a, 2015; Rupke & Veilleux 2011, 2013; Cicone et al. 2012; Rodríguez Zaurín et al. 2013, 2014; Cicone et al. 2014; Aalto et al. 2015) and at high redshift (e.g. Alexander et al. 2010; Nesvadba et al. 2011; Harrison et al. 2012, 2014; Maiolino et al. 2012; Cano-Díaz et al. 2012; Cresci et al. 2015; Cicone et al. 2015) in ionised, atomic, and molecular gas. Despite impressive advances in data quality and analysis in the past decade, the main properties of these energetic outflows remain largely unknown. The exact outflow morphologies and driving mechanisms are still poorly known: it is debated whether their morphology is conical or shell-like, and the physical process responsible for the coupling of the energy or momentum released by the central AGN with the galaxy interstellar medium is likewise unclear (e.g. inner winds and shocks, radiation pressure on dust). According to one such scenario, the fast wind, accelerated close to the BH by radiation pressure, shocks the interstellar medium (ISM) of the host galaxy and creates a bubble of hot gas that expands at high velocities (~1000 km s-1). If the post-shock material does not cool efficiently, energy is conserved, the bubble expands adiabatically, and the outflow is energy-driven. On the other hand, if the post-shock material cools efficiently, for example, due to Compton-cooling by AGN photons, only momentum is conserved and the outflow is momentum-driven. Since the efficiency of the cooling process, dominated by inverse-Compton scattering, drops with increasing shock radius, there is a critical distance (~100 pc1 kpc) beyond which the extended outflows can only be energy-driven (Zubovas & King 2012). Recent observations of kpc-scale outflows in local AGNs support this scenario (Cicone et al. 2014; Feruglio et al. 2015; Tombesi et al. 2015).

Moreover, it is unclear whether molecular and ionised outflows are accelerated by the same mechanism, if they have the same spatial distribution, or if they occur on similar timescales. So far, there are only a few observations of both molecular and ionised AGN-driven outflows in the same galaxy: SDSS J1356+1026 is an example of an obscured QSO where molecular and ionised outflows have different properties, that is outflow rates, velocities, radii, morphologies, and time scales (Greene et al. 2012; Sun et al. 2014).

The forbidden emission line doublet [Oiii] at λ = 5007,4959 Å is a good tracer of ionised outflows on large scales since it cannot be produced at high densities and so cannot trace the sub-parsec scales of the broad line region (BLR). In the presence of outflows, the spectral profile of the [Oiii]λ5007 emission line can be highly asymmetric, with a broad, blue-shifted wing that is rarely observed in star-forming regions. For this reason, the [Oiii]λ5007 emission line has been used to identify outflowing ionised gas in low-redshift and high-z AGNs. Recent integral field observations of the [Oiii]λ5007 emission have provided quantitative measurements of the outflowing gas properties in AGN at low redshifts z < 0.5 (e.g. Greene et al. 2011; Harrison et al. 2014). At higher redshift, z ~ 2, Alexander et al. (2010) found evidence for galactic-scale ionised outflows by mapping the [Oiii]λ5007 emission line in ultra-luminous IR galaxies (ULIRGs) hosting type 1 AGNs. Cano-Díaz et al. (2012) observed an ionised outflow that extended up to ~8 kpc in a QSO at z ~ 2.4. Finally, Brusa et al. (2015) and Perna et al. (2015) detected broad [Oiii]λ5007 blue wings in a sample of obscured AGN that revealed outflows extended over several kiloparsecs. In one case of the latter sample, the ionised outflow extended up to ~12 kpc and is anti-correlated with the presence of star formation in the host galaxy (Cresci et al. 2015), similarly to what was found by Cano-Díaz et al. (2012).

In this paper, we present a kinematical analysis of the [Oiii]λ5007 emission line observed in six high-luminosity (Lbol > 1047 erg/s) quasars at z ~ 2.4. The line profiles and the velocity maps obtained by the kinematical analysis show ionised outflows extended on scales larger than 2−3 kpc from the nucleus. This is one of the first observations of extended ionised outflows in QSO or type 1 AGN; most AGN-driven outflows have so far been observed in type 2 AGN. We present a new method for measuring outflow properties from integral-field unit (IFU) data when the source is only marginally spatially resolved. We show that the typical signature of outflows, that is, asymmetric line profiles and blue-shifted components in the velocity maps, can be described by two point sources (the central AGN source and the outflowing material) separated by a distance of a few kpc. We find that the ionised gas most likely traces only a fraction of the total outflowing gas, unless ionised outflows have a different origin than the molecular ones.

The paper is organised as follows: in Sect. 2 we present the sample selection and properties, in Sect. 3 we show the data analysis and spectral fitting. The results of our data analysis are presented in Sect. 4. Finally, in Sect. 5 we discuss the main results, that is, the nature of ionised outflows and the comparison with other observations. A H0 = 67.3 km s-1 Mpc-1, ΩM = 0.315, ΩΛ = 0.685 cosmology is adopted throughout this work (Planck Collaboration XVI 2014).

Table 1

Properties of our quasar sample

2. Sample selection

We selected six QSOs at z ~ 2.4 with large [Oiii]λ5007 equivalent widths (>10 Å in the rest frame) and bright H-band magnitude (<16.5 mag) from the samples of Shemmer et al. (2004), Netzer et al. (2004), and Marziani et al. (2009). The luminosities of the objects in our sample are in the range L = 1047−1048 erg/s, making them the highest luminosity sources where outflows have been spatially mapped. These characteristics are chosen to maximise our chances of detecting signatures of feedback on the host galaxy. As explained in Sect. 1, the cosmic epoch corresponding to z ≃ 2 is crucial for the growth of the most massive galaxies and BHs, and shows the highest activity both in star formation and in BH accretion (e.g. Madau & Dickinson 2014). The selected objects at the high end of the QSO luminosity function are those where we expect to detect feedback in action, at least according to current galaxy evolutionary models (e.g. Hopkins et al. 2006). Moreover, the targets were selected depending on their particular [Oiii] profile. The large [Oiii]λ5007 equivalent width is expected to allow us to easily recover the kinematical maps of the ionised gas, a challenging task in luminous QSOs where narrow emission lines are usually weak (e.g. Netzer et al. 2004). Finally, the bright ionised line profile can be easily de-blended from the broad Hβ and FeII emission, which are associated with the BLR. Based on near-IR spectra available from the literature (Shemmer et al. 2004; Netzer et al. 2004; Marziani et al. 2009), we also chose our objects such that the contamination from broad FeII emission is expected to be weak.

The basic properties of the observed objects are given in Table 1. One of our sources, 2QZJ0028, has previously been studied by Cano-Díaz et al. (2012) and was reobserved with a much longer integration time. Their results are confirmed.

3. Observations and data reduction

The targets, whose properties are described in Table 1, were observed in February and September 2012 using the near-IR integral field Spectrograph for INtegral Field Observations in the Near Infrared (SINFONI) at the Very Large Telescope (VLT). The observations were obtained in H-band (λ ~ 1.45−1.85 μm, where [Oiii]λ5007, [Oiii]λ4959 and Hβ are detected), in seeing-limited mode with a spatial scale of 0.250′′ and medium spectral resolution of R = 3000. In all observations, the object was moved across the 8′′× 8′′ field of view to perform the sky subtraction. A standard star for telluric correction and flux calibration was observed shortly after or before the on-source exposures. The total on-source integration time is over 3 h per target. The airmasses are different for each target and span a range between ~1.0 and ~1.4.

After removing cosmic rays from the raw data using the L.A. cosmic procedure (van Dokkum 2001), we used the ESO-SINFONI pipeline to reduce the data. The final data cubes produced by the ESO-SINFONI pipeline have a spatial scale of 0.125′′× 0.125′′ and a field of view of about 8′′× 8′′. The estimated angular resolution is ~0.4−0.6′′, based on a 2D-Gaussian fitting of the flux map of the spatially unresolved broad Hβ line (see Sect. 4.1).

4. Data analysis

Figure 1 shows the H-band spectra extracted from the nuclear region of each QSO from an aperture of 0.25′′× 0.25′′. The spectra clearly show the broad Hβ and the strong emission-line doublet [Oiii]λλ5007,4959. In addition to these components, weak FeII emission lines are also visible in two out of the six QSOs (LBQS0109 and HE0251). The asymmetric [Oiii]λ5007 profiles suggest the presence of ionised outflows in most of the targets (LBQS0109, 2QZJ0028, HB8905, HB8903, and HE0251). A prominent blue wing is the typical signature of high-velocity gas moving toward the line of sight. The Hβ emission line shows asymmetric velocity profiles as well as, in some cases, two distinct emission peaks (i.e. HB8903). In all spectra the Hβ line is a sum of two different components: a very broad (FWHM> 2000 km s-1) one that is associated to the BLR emission, and a fainter, narrower (FWHM ~ 500−1200 km s-1) component that is most likely associated with NLR emission.

thumbnail Fig. 1

Upper panel: spectra of the six QSOs if our sample. Each spectrum is extracted from a nuclear region of 0.25′′× 025′′ (2 × 2 pixel). The different components in the fit for each line (Hβ, [Oiii] and FeII) are shown in green, and the red line is the total fit. The shaded yellow regions indicate the zone affected by strong sky-line residuals that are excluded from the fit. Lower panel: fit residuals, obtained as a difference between observed and model spectra.

Open with DEXTER

4.1. Fitting procedure

To understand the dynamics and the main properties of the ionised outflows, we performed a kinematical analysis of the forbidden lines.

First, we extracted the spectrum of each QSO from a nuclear region of 0.25′′× 0.25′′ where the signal-to-noise ratio (S/N) is highest. We simultaneously fitted the continuum, Hβ and [Oiii] emission lines by minimising χ2 using the IDL routine MPFIT (Markwardt 2009).

The [Oiii]λ5007 line profile is very complex in these objects, and a single Gaussian function is unable to reproduce the asymmetric velocity profiles, therefore we fitted the emission-line doublet using either multiple Gaussian components or a broken power-law convolved with a Gaussian distribution. Initially, we fitted the emission line using two Gaussian components, one broad (FWHM > 1000 km s-1) and one narrow (FWHM< 1000 km s-1), and, when necessary, added a third component to minimise the χ2 value. Since in a few cases the [Oiii]λ5007 emission line exhibits a very asymmetric line profile with blue wings extended to |v| > 1000 km s-1, we replaced the multi-Gaussian components with a broken power-law profile convolved with a Gaussian distribution. We did not add additional Gaussian components to avoid an unnecessary large number of free fitting parameters. We do not attribute any physical meaning to the individual fitting component, and we measured gas kinematics by analysing the total line profile. Therefore, using either multiple Gaussian components or a broken-power law does not change the results of this work, provided that the quality of the fit is similar. The two emission lines of the [Oiii] doublet, originating from the same upper level, were fitted by imposing the same central velocity and velocity dispersion, with the intensity ratio I(5007) /I(4959) fixed at ~3.

Hβ is well described by a broad (BLR) and a narrow component (NLR). We used a broken power-law profile for the very broad component (FWHM > 2000 km s-1) since it usually provides a good fit to QSO broad emission lines (Nagao et al. 2006). The model used for the Hβ profile of 2QZJ0028 shows a broad red wing that is probably caused by continuum or FeII emission, so we do not attribute any physical meaning to this red-shifted emission. A similar profile is visible in Fig. 1 of Cano-Díaz et al. (2012). Since the narrower Hβ is weak and sometimes only marginally detected, it is not possible to reliably constrain its profile and kinematics. We therefore assume that it has the same average velocity and velocity profile as [Oiii]λ5007.

Finally, we used a power law for the continuum, and for the spectra showing FeII emission, we used the FeII template from Tsuzuki et al. (2006). These best-fitting solutions are used as first guesses in the pixel-to-pixel fitting of the kinematical analysis described in the following.

Before performing a spatially resolved kinematical analysis, we tested whether the kinematics of the ionised gas is spatially resolved. Following the method described in Carniani et al. (2013), we analysed the flux residual maps obtained with a pixel-by-pixel kinematical fitting with the components just described, after assuming that the targets are spatially unresolved. In this case, the H-band spectrum is expected to be the same in any spaxel apart for a different normalisation. The residual maps (Fig. 2) at the wavelength range of [Oiii]λ5007 indicate that the forbidden line emission is kinematically resolved in all but one of the quasars, that is, HE0251. In fact, if the emission were unresolved, we would expect to observe both a spectral profile and a residual map consistent with the noise, as in the case of HE0251. The flat residual at the wavelength range of Hβ indicates that the broad component of Hβ is spatially unresolved, consistently with an Hβ origin in the BLR.

thumbnail Fig. 2

Residuals from the pixel-per-pixel fitting assuming that the QSO emission is not spatially resolved. Left panels: residual spectra extracted from a region of 0.25′′× 0.25′′, where the residual map, obtained by collapsing the [Oiii]λ5007 spectral channel, probably shows a spatially resolved emission. Dashed lines indicate the wavelength of the doublet [Oiii]λ5007, and the dotted line shows the Hβ position. The red shaded region denotes the wavelength range over which the residual [Oiii]λ5007 emission has been integrated to produce the maps shown on the right. Right panels: residual maps obtained by collapsing the spectral channels corresponding to the residual [Oiii]λ5007 emission, as shown by the red region in the left panels. In the first five maps the clear [Oiii]λ5007 residual emission suggests that the emitting region is spatially resolved. The “noise” residual map of HE0251 indicates that the sources are not resolved.

Open with DEXTER

After testing that the [Oiii]λ5007 line emission is kinematically resolved in five of the six sampled QSOs, we performed a pixel-by-pixel fitting of the data cubes by allowing the spectral components to vary, except for the broad Hβ, which is not spatially resolved. Figure 3 shows the kinematical properties of the ionised gas as obtained from the fit of the [Oiii]λ5007 line:

  • zeroth-moment map (i.e., line flux map; first panel);

  • first-moment map (i.e., median velocity map; second panel);

  • blueshifted velocity map, v10, the velocity at the tenth percentile of the overall emission-line profile (third panel); fitted in each spatial pixel;

  • line width map , W80, the velocity width of the line that contains 80% of the emission-line flux (fourth panel); this is defined as W80 = v90v10, where v10 and v90 are the velocities at tenth and ninetieth percentiles, respectively. For a Gaussian profile, W80 is approximately the full width at half maximum (FWHM).

The observed kinematical maps are the results of the convolution of the intrinsic ones with the PSF of the observations. Where the [Oiii]λ5007 emission line was fitted with multiple Gaussians, line profiles are based on the sum of all Gaussian components. The maps were obtained by selecting only those spatial pixels with a S/N equal to or higher than 2. We defined the S/N as the ratio between the peak of the [Oiii]λ5007 line and the rms of the residuals. Zero velocities correspond to the peak position either of the narrow (FWHM < 1000 km s-1) and strongest Gaussian component or of the broken power-law one of the [Oiii]λ5007 profile estimated in the preliminary spectral fitting. The zero-velocity wavelength was also used to refine the redshift of each QSO (Table 1) providing the velocity of the host galaxy. The inferred redshift and [Oiii]λ5007 line width are consistent, within the errors, with those estimated by Shemmer et al. (2004) and Marziani et al. (2009).

The v10 maps (Fig. 3, third panel) show strongly blue-shifted regions that are spatially associated with high-velocity dispersion (>400 km s-1, Fig. 3, forth panels). The broad [Oiii]λ5007 profile cannot be explained by a rotating gas component, which in local star-forming galaxies has typical FHWM values of about ~250 km s-1. Moreover, the morpholgy of the velocity maps, suggesting the presence of a conical blue-shifted region, is completely different from the typical “spider” diagram of a disc. Consequently, both the [Oiii]λ5007 profile and the velocity maps suggest that in at least five out of six QSOs we detect ionised outflowing gas with velocities >300 km s-1.

We only detect the blue-side outflows because the red side is probably obscured by dust in the host galaxy along the line of sight. For this reason, the [Oiii]λ5007 line emission is asymmetric, with a prominent blue-shifted wing. While this is what commonly happens, in some cases the particular orientation of the line of sight with respect to the source can result in red-shifted outflows (e.g. Rodríguez Zaurín et al. 2013; Bae & Woo 2014; Perna et al. 2015).

The next step is to understand the physical mechanisms that expel the ionised gas out to a distance of a few kpc from the centre of the host galaxy.

thumbnail Fig. 3

[Oiii]λ5007 flux, median velocity, v10, and velocity dispersion map. The maps are obtained by selecting pixels with a S/N > 2. The velocity maps are characterised by blue-shifted regions with a high velocity dispersion. Contours represent the total Hβ line surface brightness at 90%, 50%, and 30% of the peak value.

Open with DEXTER

5. Outflow properties

In the following, we estimate the mass, average velocity, and radius of the high-velocity winds. We then infer the mass outflow rate, momentum rate, and kinetic power and compare them with previous works (Greene et al. 2012; Cicone et al. 2014; Harrison et al. 2014; Sun et al. 2014; Brusa et al. 2015; Cresci et al. 2015; Feruglio et al. 2015).

5.1. Outflow and radius

Given the uncertainties on the driving mechanism, we used a simple model to estimate the physical properties of the outflow. In this model, the outflow is represented by a shell-like cloud ejected from the nucleus within a cone and with a filling factor equal to 100%. We assumed that the physical size of the outflowing material is smaller than the spatial resolution typical of our datasets. This model is defined by the mass of the cloud, Mo, the distance between the cloud and the location of the AGN, Ro, and the averaged cloud velocity, vo. The outflow mass rate is given by (1)where τdyn is the dynamical time, that is, the time taken by the ionised gas to reach a distance Ro with an average velocity vo. We note that assuming either a shell or a uniformly filled cone with a filling factor equal to 1 (e.g. Maiolino et al. 2012) changes the o estimate by a factor of 3. Since this factor is constant, it does not affect the main conclusions of this work, but we take it into account when comparing our results with previous ones.

The extension of an outflow (Ro) is usually trivially estimated from the observed flux or velocity maps (e.g. Harrison et al. 2014; Cresci et al. 2015). However, in our cases, the [Oiii]λ5007 emission is only marginally spatially resolved in each QSO, therefore the kinematical maps in Fig. 3 are affected by PSF smearing, and the sizes of the regions showing blue-shifted emission (Fig. 3) do not directly provide the parameter Ro to be used in Eq. (1). Furthermore, the sizes of the outflowing regions are affected by the choice of S/N threshold adopted in plotting the maps. In particular, assuming a S/N threshold larger than 2, the blue regions would be smaller than those shown in Fig. 3. For these reasons, we cannot estimate Ro from our observations by using the flux or velocity maps as in previous works, where emission lines are clearly spatially resolved. Therefore, we decided to estimate Ro by using spectroastrometry, which allows position measurements on scales smaller than the spatial resolution of the observations. Spectroastrometry consists of measuring the photo-centroid in each velocity channel. If outflowing ionised gas is moving away at a distance R from the QSO, we expect that the centroid of light emission extracted from blue-shifted velocities channels of [Oiii]λ5007 will be displaced by the same amount R with respect to the QSO position, identified by the BLR and/or continuum emission. By means of a simple simulation, we show in Sect. 5.3 that spectroastrometry can, indeed, provide information on the outflow position at scales that are significantly smaller than the limit imposed by the spatial resolution of the observations.

thumbnail Fig. 4

Left panels: the points show the [Oiii]λ5007 velocity v versus the distance R of the [Oiii]λ5007 photocentre from the continuum (indicated by the dashed line). The arrows indicate the velocity vo = v(Ro) corresponding to the distance R0. Right panels: [Oiii]λ5007 photocentre position in the field of view. Symbols are coloured according to their velocity (the velocity scale is reported in the colour bar). The dotted line indicates the project direction of the outflow as inferred by comparing the spectroastrometry results with velocity maps (Fig. 3).

Open with DEXTER

We applied the spectroastrometry technique to the [Oiii]λ5007 line emission after subtracting the best-fit model of the continuum, broad Hβ and FeII emission. To maximise the S/N for our measurements and minimise the uncertainty due the spectral resolution, we rebinned the spectra by three velocity channels (~105 km s-1). The centroid of the [Oiii]λ5007 emission in each rebinned velocity channels was, then, estimated by a 2D Gaussian fitting. The QSO position was estimated by applying the same spectroastrometry technique to the continuum and the broad Hβ emission.

Table 2

Outflow properties.

The results of the spectroastrometric analysis are displayed in Fig. 4. In the left panels, we plot the distance R of the emission line photocentre from the continuum one as a function of velocity v. The right panels show the photocentre position on the sky in each velocity channel. The reliable spectroastrometric measurements for the [Oiii]λ5007 emission line were selected to satisfy the following criteria:

  • S/N higher than 1.5 for the line flux in each spectral channel of therebinned spectra extracted from a0.25″ × 0.25″

  • FWHM of the 2D Gaussian equal or larger than that of the PSF of the observations.

In all targets, the [Oiii]λ5007 blue-wing centroids are displaced at least 0.05′′, that is, 0.4 kpc, from the continuum position and, in some cases, we observe an offset in the red wavelengths as well. This latter offset may be caused by three reasons: (i) the continuum is not well subtracted during the kinematic analysis; (ii) the [Oiii]λ5007 emission line associated to outflows is so large that the displacement is also slightly observable in the red wings; (iii) the red wings are emitted by the receding outflows that are not completely obscured by dust in the disc. An additional explanation, which will be discussed in a companion paper, is that in two out of six QSOs a fraction of the red [Oiii]λ5007 line emission is associated with star formation in the host galaxy, which causes a displacement from the continuum centre.

Since the position of the photocentre at high blue velocities reveals an extended ionised outflow, we adopted Ro equal to the largest distance measured for the approaching gas, and vo = v(R0) as measured from our maps (see arrows in Fig. 4). Since the spectra were rebinned by three velocity channels, the error on v0 due to the spectral resolution typical of our datasets is negligible. Ro and vo for each quasar are listed in Table 2.

5.2. Outflow mass

A great challenge in estimating the mass of the wind is caused by its multiphase nature. Only a fraction of the mass of the outflows is in the warm ionised phase traced by [Oiii]λ5007. Recent works estimated the mass of ionised outflows either using Hβ emission line (e.g. Liu et al. 2013; Harrison et al. 2014) or using the [Oiii]λ5007 line (e.g. Cano-Díaz et al. 2012). So far, it is unclear which is the best tracer of ionised gas powered by AGN feedback. To compare two different measurements carried out with these two different tracers, we discuss how the mass of ionised outflows can be constrained through the observations of [Oiii]λ5007 and Hβ.

The [Oiii]λ5007 luminosity is given by (2)where f is the filling factor, ne the electron density, n(O2 +) the density of O2 + ions, and j[OIII](ne,Te) the line emissivity. n(O2 +) can be written as

and, with a reasonable assumption, n(O2 +) = n(O),

where [O/H] − [O/H] is the metallicity relative to solar with a solar oxygen abundance of [O/H] ~8.86 (Centeno & Socas-Navarro 2008). The factor (1.2)-1 takes into account a 10% number density of He atoms with respect to H atoms:

Assuming a typical temperature (Te ≃ 104 K) and electron density (ne ≃ 500 cm-3) for the NLR, the line emissivity is

This line emissivity was estimated making use of PyNeb (Luridiana et al. 2015). Based on this, Eq. (2) can be rewritten as (3)where is the volume-averaged squared density. The gas mass can be expressed as (4)where is the average molecular weight, mp is the proton mass, and we have taken into count that a 10% number density of He atoms with respect to H atoms:

Finally, from combining Eqs. (3) and (4), we obtain (5)where . For Te = 104 K and ne = 500 cm-3 we obtain a mass of

We note that the gas mass is sensitive to temperature and density of the clouds.

Now we similarly derive M from Hβ. The Hβ luminosity can be expressed as (6)where jHβ is line emissivity and np is the proton density that can be written as

At the typical temperature and density of the NLR, the line emissivity of Hβ also estimated with PyNeb is

By combining Eqs. (4) with (6) of LHβ , we derive (7)For Te ~ 104 K and ne ~ 500 cm-3 we obtain a mass of

From comparing the two masses at the same temperature and density, we derive (8)with [O/H] = [O/H] , Te ~ 104 K and ne ~ 500 cm-3, the same values as assumed in the following analysis. The [Oiii]λ5007/Hβ ratio measured in Seyfert galaxies typically is ~10, providing M[OIII]/MHβ ~ 0.5. This apparent discrepancy is the consequence of the different volumes from which [Oiii]λ5007 and Hβ are emitted: in the above example the volume of Hβ emitting gas is ~2 higher than that of [Oiii]λ5007. Therefore, Hβ emission traces a higher ionised gas mass than [Oiii]λ5007. The mass estimated from [Oiii]λ5007 is therefore considered as a lower limit on the ionised gas mass.

5.3. Simulations of spectroastrometric observations of outflows

In Sect. 5.1 we have described our method for estimating Ro, which is not affected by the spatial resolution of the data and by the S/N threshold used to map velocities.

In the following, we present results of simple simulations of outflowing gas that validate the spectroastrometric method. We note that the purpose of this work is not to build an outflow model to fit our observations, but the only purpose of this simulation is to show that the extension of the flux or velocity maps when the source is marginally resolved can provide incorrect estimates of the outflow extension due to PSF smearing. We also show that an ionised clump with a given velocity that is located a few kpc away from the AGN can appear as a blue-shifted region extended over ~510 kpc in velocity maps, which is larger than the real outflow extension.

thumbnail Fig. 5

Cartoon showing the basic structure of our model. The outflow (solid blue curve) is perpendicular to the galaxy plane. v indicates the direction of the outflow and r is the distance from the QSO. This model assumes that the outflow is marginally resolved but it is not larger than the PSF dimension (dashed purple line).

Open with DEXTER

We considered a simple model of an outflow (Fig. 5) based on the following assumptions.

  • 1.

    The outflow has a biconical geometry with the axisapproximately more or less perpendicular to the host galaxy disk;indeed, the AGN wind, although roughly isotropic, cannotpropagate through the galaxy disk because of its high density.

  • 2.

    The receding half-cone is not observed because its emission is absorbed by the dust in the host galaxy. This geometry best explains the asymmetric [Oiii]λ5007 profile with a prominent blue wing over 1000 km s-1.

  • The surface brightness distribution of the outflow is parameterised by where the vector r is the distance from the QSO. We note that the surface brightness distribution and the opening angle of the cone are not fundamental for these simulations, since the spatial resolution of our data is not high enough to resolve the surface brightness profile. We assume an opening angle of 30 deg. identifies the photocentre of the surface brightness of the ionised cloud. I0 is proportional to the outflow mass defined in Eq. (4).

  • 4.

    The ionised gas in the outflow has an average velocity and a velocity dispersion .

Therefore the input parameters are the outflow mass , the distance of the ionised clouds from the centre of the QSO, the average velocity , and the velocity dispersion of the ionised gas.

To reproduce the [Oiii]λ5007 line profile of LBQS0109, we simulated a QSO with an outflow characterised by M (Eq. (5)), arcsec (i.e. ~0.4 kpc), km s-1 and km s-1. We also considered a point source at the location of the AGN describing the gas at the systemic velocity with a velocity dispersion ~400 km s-1 and an amplitude scaled so as to reproduce the observed line profile. The total [Oiii]λ5007 emission was then projected onto the sky plane, assuming a galaxy disc inclination of 10 deg, that is, almost face-on, as is typical of QSOs. Finally, we convolved the surface brightness maps in each spectral channel with the PSF and added Gaussian noise to match the sensitivity of our observations.

thumbnail Fig. 6

[OIII]λ5007 emission lines extracted from a nuclear region of 0.25′′× 0.25′′. The blue line is the [Oiii]λ5007 emission line of LBQS0109 after subtracting all the other best-fit components. The red line is the ionised emission line obtained from the simulated data.

Open with DEXTER

The comparison between the [Oiii]λ5007 line profile extracted from the simulated data and that from the observations is shown in Fig. 6. Both spectra were extracted from a nuclear region of 0.25′′× 0.25′′. The simulated emission line presents prominent blue wings similarly to the real spectrum of LBQS0109. We then performed the kinematic analysis on the simulated data as described in Sect. 4.1. The flux, velocity, and velocity dispersion maps (Fig. 7) obtained from the simulations are similar to those shown in Fig. 3 extracted from observations. Indeed, the velocity map shows blue-shifted velocities in the outflow region extended over 0.5′′ (i.e. ~4.2 kpc). This means that the simulation confirms that the blue-shifted region suffers from beam smearing, and its size does not match the real radius of the outflow.

thumbnail Fig. 7

[OIII] flux, velocity, and velocity dispersion map obtained from the simulated [Oiii]λ5007 data. The regions with S/N< 2 are masked out.

Open with DEXTER

Since the simulated outflow well describes the asymmetric [Oiii]λ5007 profile and the velocity gradient observed in our datasets, we carried out the spectroastrometry analysis on the simulated data to estimate the average velocity and radius of the ionised gas to compare these derived values with the input parameters. The offset of the photocentroids at different velocities are shown in Fig. 8. The radius Ro (~0.05′′) and the average velocity v(Ro) (~1450 km s-1) estimated from spectroastrometry are consistent with the initial input parameters. Clearly, provided that the S/N is high enough, the spectroastrometry method can provide the position and the velocity of outflows with an accuracy well below the seeing limit. Moreover, since the integral flux of [Oiii]λ5007 at high blue-shifted velocity (−2500 km s-1<v<v(Ro)) is consistent with about half of the total flux emitted from the ionised outflowing gas, the outflow luminosity can be inferred from (9)where λ0 is the wavelength corresponding to v0. When the [Oiii]λ5007 emission line was well described by a multi-Gaussian fit, the luminosity value calculated with Eq. (9) and the one estimated from the broad Gaussian component, as typically done in the literature, are consistent within the errors. In the multi-Gaussian fit we therefore estimated Lo from the broad component, and in the other case we measured the luminosity of the gas using Eq. (9).

Since the narrow Hβ component has the same profile as [OIII], we can measure the outflow luminosity for both the emission lines using the same equation. From the luminosity we derive the mass of the ionised outflows by using Eqs. (4) and (7). As the [Oiii]λ5007/Hβ ratio measured in each QSO is ~10, the mass inferred by Hβ is twice higher than that estimated by [Oiii]λ5007 (see Eq. (8)). The luminosity and mass of the outflow are listed in Tables 1 and 2, respectively. Since HE0251 is not spatially resolved, we cannot estimate the outflow luminosity using the method described above. In this case, we fitted the [Oiii]λ5007 with two Gaussian components and inferred the outflow luminosity from the broad Gaussian component.

thumbnail Fig. 8

Spectroastrometry results obtained from the simulated data. On the left, centroid offset of [Oiii]λ5007 emission respect to continuum emission (dashed line) at different wavelengths. On the right, the photocentroid position in each velocity. Colour-coding corresponds to velocity offset.

Open with DEXTER

6. Results

To investigate the nature of the ionised wind, we need to estimate the main quantities of the outflows: mass outflow rate, momentum rate, and kinetic power. Theoretical models (e.g. Zubovas & King 2012; Faucher-Giguère & Quataert 2012) predict tight relations between these quantities and the AGN bolometric luminosity, LAGN. In particular, the correlation between the momentum rate and LAGN provides an indicator of the nature of the feedback mechanism. In this section we derive the main properties of the AGNs in our sample and compare them with the prediction of the models. As explained in Sect. 5.3, the low spatial resolution of our observations does not allow us to discern whether our outflows are single explosive events or refilled with clouds ejected from the galactic disc. Hence, we assumed a simple model where a single ionised cloud is ejected outward of the nuclear region and the mass outflow rate is equal to the mass of the outflow divided by the dynamical timescale (see Eq. (1)). The dynamic time is the time that it takes a clump of ionised gas in outflow to reach a fixed distance from the QSO. We derived o values in the range 6−700M  yr-1. We assumed an average outflow mass rate error of ± 50%, which takes in account the uncertainties associated with the gas physical properties (i.e. density and temperature), flux calibrations, and R0 and v0 estimates due to projection effects. For each source we estimated two value of o that were calculated by using Hβ and [Oiii]λ5007, respectively. Since the [Oiii]λ5007 outflow luminosities are aboutten times higher than those from Hβ, the outflow masses inferred from the hydrogen emission line are abouttwicehigher than those estimated by [Oiii]λ5007.

thumbnail Fig. 9

Left panel: outflow velocity as a function of the AGN bolometric luminosity. The blue circles denote the results from this work; the open circles mark the velocities of ionised gas (mainly [Oiii]λ5007): the red, orange, purple, and black circles are the estimates obtained from Harrison et al. (2014), Brusa et al. (2015), Cresci et al. (2015), and Greene et al. (2012), respectively. The green, black, and brown squares denote the velocities of the molecular outflows from Cicone et al. (2014), Sun et al. (2014), and Feruglio et al. (2015). Right panel: outflow rates as a function of the AGN bolometric luminosity. Notation is the same as in the left panel, expect that open circles represent the estimates obtained with [OIII]-inferred masses, while the filled ones denote the estimates based on Hβ. We recalculated the outflow properties inferred by previous works to make them consistent with our estimates (see text). The solid line is the best-fit relation to the averages of filled and empty circles.

Open with DEXTER

In Fig. 9 we plot the outflow velocity and mass rate as a function of the AGN luminosity. LAGN is derived by using the relation LAGN~ 6λL(λ5100 Å) from Marconi et al. (2004). The solid and empty blue points are the o estimated for five out of six QSOs; we were unable to infer the value of HE0251 since we were unable to measure the size of the outflow. The red points represent the ionised outflows observed in type 2 AGN at redshift 0.08 ≲ z ≲ 0.2 (Harrison et al. 2014); the orange and purple points are adopted from Brusa et al. (2015) and Cresci et al. (2015), who mapped ionised outflows in six X-ray selected obscured QSOs at z ~ 1.5; and the black circle corresponds to the ionised outflow in an obscured radio-quiet QSO at z ~ 0.123 (Greene et al. 2012). For consistency with our work, we re-calculated the outflows properties using an electronic density of ne = 500 cm-3 and a temperature of Te = 104 K. We note that the outflow masses from literature may be overestimated since we used the luminosities from the total [Oiii]λ5007 and Hβ profiles.

In addition to ionised outflows, we compared our results with those obtained from molecular outflows (green, black, and brown solid squares; Cicone et al. 2014; Sun et al. 2014; and Feruglio et al. 2015, respectively). The molecular outflow properties were re-estimated assuming a shell-like cloud model (Eq. (1)).

In Fig. 9 we show that the outflow velocity v0 and outflow rate are correlated with the AGN luminosity, although with a large scatter. The increase in velocity and outflow rate with increasing AGN luminosity is consistent with the idea that a luminous AGN pushes away the surrounding gas through a radiatively driven fast wind whose kinetic power is a fraction of the AGN luminosity. However, it is difficult to establish a direct relation between AGN luminosity, velocity, and outflow rate. The acceleration process of the outflow by the fast wind and the fraction of the kinetic power injected might vary from object to object; moreover, the observed AGN luminosity may not represent the long-term average luminosity that in the end is responsible for driving the outflow. For these reasons, we do not expect tight correlations between velocity, outflow rate, and AGN luminosity, as observed. Indeed, previous studies on more heterogenous samples, but smaller luminosity ranges, did not find any significant correlation between the outflow velocities and the AGN luminosities (e.g. Veilleux et al. 2013; Brusa et al. 2015). In the luminosity range where we have data from both CO and [OIII] (1044.5 erg/s ≲ LAGN ≲ 1046.5 erg/s), the velocities of the ionised outflows are a factor ~2 higher than those of the molecular gas, which is consistent with higher masses of molecular gas in both momentum- and energy-driven scenarios, but also with different acceleration and deceleration processes. However, given the heterogeneous nature of the sample and the non-uniform measurements of outflow velocities, we cannot draw any firm conclusions. Moreover, there is only one galaxy (black circle and square in Fig. 9) where both molecular and ionised outflows are detected. This discrepancy is even more evident when comparing molecular with ionised outflow rates. Cicone et al. (2014) fitted a a log-linear relation between and LAGN for their molecular outflows and found Log10() = 2.84 + 0.720 × Log10(LAGN/ 1046 erg/s), where we have corrected for the factor 3 discrepancy described in Sect. 5.1. Here, we fitted the same relation between and LAGN by fixing the slope to that of Cicone et al. (2014), (10)Since the velocities and the radii of ionised outflows are similar to those of molecular outflows, we interpret the offset between the two LAGN correlations as an indication that the ionised gas only traces a small fraction of the total gas mass. Comparing the normalisation of the LAGN relation inferred from our data with that obtained from molecular outflows, we can infer that the outflow rate of the ionised gas is a small fraction (<10%) of the molecular outflow, suggesting that outflow masses are dominated by molecular gas. However, since molecular and ionised outflow rates are not estimated in the same objects and the relations have quite a large scatter, it is not possible to estimate the exact fraction of ionised gas in the outflows. On the other hand, the different normalisation could indicate that two different acceleration mechanisms are at work. Future ALMA observations of the molecular gas in these objects are essential to distinguish between these two different scenarios.

Figure 10 shows the kinetic power of outflowing gas as a function of AGN luminosity where the outflow kinetic energy rate is given by

We indicate with solid, dashed, and dotted lines the locus of points that have an outflow kinetic power that is 100%, 5%, and 0.1% of the AGN luminosity, respectively. Recent AGN feedback models (e.g. King 2010; Zubovas & King 2012; Lapi et al. 2014) predict a coupling efficiency between AGN-driven outflows and AGN power of about ~5%, which is needed to explain the MBHσ relation observed in local galaxies. Although the molecular outflow observations are consistent with the models within the errors, the kinematic power estimated from ionised outflows is only <0.1% of the LAGN. This percentage is too low to explain the MBHσ relation. Since the kinetic energy is proportional to the outflow mass, we cannot discern whether the nature of ionised outflows is different from that of molecular ones or, as discussed above, the [Oiii]λ5007 (and Hβ) line emission only traces a small fraction (<10%) of the total outflowing gas.

thumbnail Fig. 10

Kinetic power as a function of the AGN bolometric luminosity. Symbols and colours as in Fig. 9. The solid, dashed, and dotted lines correspond to Pk = 100%,5%,and0.1%LAGN, respectively.

Open with DEXTER

The last fundamental parameter of the outflows is the outflow momentum rate defined as voo. Energy-driven outflow models predict that the momentum of the large-scale outflow is boosted compared to the nuclear wind (or AGN radiation pressure momentum ), that is, voo ~ 20LAGN/c (Zubovas & King 2012). In Fig. 11 we observe that molecular outflows follow the relation predicted by models (see Cicone et al. 2014 for more details), while ionised outflows are below the 1:1 relation. This could simply be the consequence of the discrepancy between the outflow masses of ionised and molecular gas.

Finally, we may conclude that the main difference between molecular and ionised outflows is the fraction of total gas mass pushed away from the AGN-driven wind. This is confirmed by the higher outflow rates (right panel of Fig. 9) and kinetic power (Fig. 10) of molecular outflows and by their lower outflow velocities (left panel of Fig. 9).

thumbnail Fig. 11

Outflow momentum rate as a function of photon momentum of the AGN. Symbols and colours as in Fig. 9. The dotted and dashed line correspond to ~ 20 LAGN/c and ~ LAGN/c, respectively.

Open with DEXTER

7. Conclusions

We performed seeing-limited, near-IR integral-field spectroscopic observations with SINFONI of a sample of six high-luminosity (Lbol = 1013−1014L) QSOs at redshift z ~ 2.4. [Oiii]λ5007 emission lines, red-shifted into the H band, are characterised by large FWHMs (>1000 km s-1) and prominent blue wings, indicative of fast outflows accelerated by the powerful AGN. We summarise our results below.

  • The [Oiii]λ5007 emission line is spatially resolvedin five out of six sources and is extended over several kiloparsecs.

  • The analysis of the [Oiii]λ5007 kinematical maps suggests conical outflows associated with regions of high-velocity dispersions (>500 km s-1). The physical properties of the outflows, that is, mass, outflow rate, kinetic energy, and momentum rate, were estimated with a new method based on spectroastrometry, which is not affected by PSF smearing, at variance with results from previous works. The reliability of this method was confirmed with a simple simulation, but more accurate modelling will be developed in future work.

  • Both ionised and molecular outflow velocities are weakly correlated with the observed AGN luminosity, despite the large scatter, and at a given AGN luminosity the velocity of the ionised gas is roughly a factor 2 higher than that of the molecular one. However, given the heterogenous nature of the combined sample, we cannot draw any firm conclusions.

  • Mass and momentum rates, as well as kinetic powers, increase with AGN bolometric luminosity in a similar way to what is observed in molecular outflows in the local Universe. The ionised gas properties define relations with AGN luminosity that are parallel with those of molecular gas. In particular, ionised outflow rates are ~50 times lower than molecular ones. The kinetic power carried by ionised outflows is of ~0.1−0.05% of the AGN luminosity compared to ~5% for molecular outflows. Finally, momentum rates are of the order of LAGN/c, a factor ~20−50 smaller than for molecular outflows.

  • These discrepancies between ionised and molecular outflows can be explained with the fact that ionised gas traces a smaller fraction of the total gas mass. Alternatively, they are an indication of different acceleration mechanisms for the molecular and the ionised gas. Observations with ALMA would allow us to measure the molecular gas mass in these objects and distinguish between these two scenarios.

Acknowledgments

We thank the anonymous referee for comments and suggestions that improved the paper. We acknowledge financial support from INAF under the contracts PRIN-INAF-2011 (“Black Hole growth and AGN feedback through cosmic time”) and PRIN MIUR 2010-2011 (“The dark Universe and the cosmic evolution of baryons”). M.B. acknowledges support from the FP7 Career Integration Grant “eEASy” (CIG 321913). C.F. gratefully acknowledges financial support from PRIN MIUR 2010-2011, project “The Chemical and Dynamical Evolution of the Milky Way and Local Group Galaxies”, prot. 2010LY5N2T. E.P. acknowledges financial support from INAF under the contract PRIN-INAF-2012. Funding for this work has also been provided by the Israel Science Foundation grant 284/13.
