What can the spatial distribution of galaxy clusters tell about their scaling relations?^{⋆}
Argelander Institute für Astronomie, Universität Bonn,
auf dem Hügel 71, 53121 Bonn, Germany INAF
Osservatorio Astronomico di Roma, via di Frascati 33
00040
Monte Porzio Catone
Italy
email:
abalan@astro.unibonn.de
Received:
6
June
2013
Accepted:
20
January
2014
Context. The clustering of galaxy clusters is sensitive not only to the parameters characterizing a given cosmological model, but also to the links between cluster intrinsic properties (e.g., the Xray luminosity, Xray temperature) and the total cluster mass. These links, referred to as the cluster scaling relations, represent the tip of the iceberg of the socalled crossroads between cosmology and astrophysics on the cluster scale.
Aims. In this paper we aim to quantify the capability of the inhomogeneous distribution of galaxy clusters, represented by the twopoint statistics in Fourier space, to retrieve information on the underlying scaling relations. To that end, we make a case study using the mass–Xray luminosity scaling relation for galaxy clusters and study its impact on the clustering pattern of these objects.
Methods. To characterize the clustering of galaxy clusters, we define the luminosityweighted power spectrum and introduce the luminosity power spectrum as direct assessment of the clustering of the property of interest, in our case, the cluster Xray luminosity. Using a suite of halo catalogs extracted from Nbody simulations and realistic estimates of the mass–Xray luminosity relation, we measured these statistics with their corresponding covariance matrices. By carrying out a Fisher matrix analysis, we quantified the content of information (by means of a figure of merit) encoded in the amplitude, shape, and full shape of our probes for twopoint statistics.
Results. The full shape of the luminosity power spectrum, when analyzed up to scales of k ~ 0.2 h Mpc^{1}, yields a figure of merit that is two orders of magnitude above the figure obtained from the unweighted power spectrum, and only one order of magnitude below the value encoded in Xray luminosity function estimated from the same sample. This is a significant improvement over the analysis developed with the standard (i.e., unweighted) clustering probes.
Conclusions. The measurements of the clustering of galaxy clusters and its explicit dependence on the cluster intrinsic properties can contribute to improving the degree of knowledge regarding the underlying links between cluster observables and cluster masses. We therefore suggest future clustering analysis of galaxy clusters to implement the weighted statistics and especially the luminosity (or any other property of interest) power spectrum when aiming at simultaneously constraining cosmological and astrophysical parameters.
Key words: largescale structure of Universe / galaxies: clusters: general / Xrays: galaxies: clusters
Appendices are available in electronic form at http://www.aanda.org
© ESO, 2014
1. Introduction
The current understanding of the observed abundance and clustering of galaxy clusters relies on the largescale statistical properties of dark matter halos (e.g., Bardeen et al. 1986; Jenkins et al. 2001; Smith et al. 2003; Warren et al. 2006; Tinker et al. 2008). Accordingly, the mapping between cluster observables (e.g., Xray luminosities, Xray temperatures) and cluster mass is an ingredient of paramount relevance in the process of retrieving cosmological information from galaxy cluster experiments (see, e.g. Pierpaoli et al. 2003; Stanek et al. 2006, 2010; Allen et al. 2011; Semboloni et al. 2013; Planck Collaboration XX. 2014). Such mapping, referred to as the cluster scaling relations, represents a simple way of characterizing the complex baryonic processes taking place within galaxy clusters with only few parameters (see, e.g. Sarazin 1988; Mo et al. 2010; Stanek et al. 2010; Kravtsov & Borgani 2012).
The cluster scaling relations are often calibrated by direct measurements of clusterintrinsic properties and masses (e.g., Finoguenov et al. 2001; Stanek et al. 2006; Giodini et al. 2009; Pratt et al. 2009; Planck Collaboration XII. 2011). The usefulness of these measurements strongly depends on factors such as the definition of mass and the dynamical state of galaxy clusters (e.g., Rasia et al. 2012) that are potentially plagued by systematic effects. In view of this, some studies adopt a selfcalibrated approach in which the set of scaling relations and cosmological parameters are jointly constrained (e.g., Mantz et al. 2010; Rapetti et al. 2013) using the cluster abundance as a cosmological probe (e.g., Böhringer et al. 2002; Vikhlinin et al. 2009; Allen et al. 2011; Planck Collaboration XX. 2014).
Beyond the onepoint statistics of galaxy clusters, their spatial distribution, which is often statistically characterized by either the power spectrum P(k) or its Fourier counterpart, itself the twopoint correlation function ξ(r) (e.g., Peebles 1980), can provide insight into the links between light and matter on cluster scales (e.g., Pillepich et al. 2012). A simple example of this is the phenomenon of halobias, i.e., the increase in the halos clustering strength as a function of the halo mass (e.g., Kaiser 1986; Mo & White 1996; Sheth & Tormen 1999; Tinker et al. 2005; Pillepich et al. 2010). Observationally, this behavior has been detected as a function of intrinsic properties, such as the Xray luminosity (e.g., Schuecker et al. 2001; BalagueraAntolínez et al. 2011), allowing us to explore the attributes of the scaling relation by means of the amplitude of the clustering signal. We refer to this as the indirect clustering dependence upon intrinsic properties. On the other hand, a direct scrutiny of the impact of cluster intrinsic properties on the clustering pattern can be achieved by means of the socalled marked (or weighted) statistics (e.g., Schlather 2001). Marked statistics have been applied to galaxy redshift samples (e.g., Sheth 2005; Skibba et al. 2006; Skibba & Sheth 2009; White & Padmanabhan 2009) as an attempt to explore the environmental dependence and clustering of a given intrinsic property of galaxies, such as luminosities, stellar masses, and colors.
In this paper we quantify the ability of the threedimensional clustering signal from galaxy clusters to retrieve information on the underlying cluster scaling relations, represented here by the link between the cluster masses and Xray luminosities. To this end, we measure the twopoint markedstatistics in Fourier space by means of the luminosityweighted power spectrum and the luminosity power spectrum. The latter is introduced – to our knowledge – for the first time in this paper, as an attempt to explicitly study the Xray luminosity dependence of the clustering of galaxy clusters. We use a suite of halo catalogs built from Nbody simulations, together with a realistic estimate of cluster scaling relations, and carried out a Fishermatrix analysis to determine the sensitivity of these clustering probes to the parameters characterizing the scaling relation. We stress that our analysis is not a forecast for a particular experiment in view of a given cosmological model. Instead, we present a comparison between different clusteringrelated probes that can be implemented in forthcoming galaxy cluster samples in order to extract astrophysical and cosmological information. Our findings suggest that the direct assessment of the clustering of Xray luminosity (or other physical properties) can help establish tight constraints on the cluster scaling relations.
The outline of this paper is as follows. In Sect. 2 we introduce the suite of Nbody simulations and the scaling relations used to assign observables to the dark matter halos. We introduce the cluster luminosityweighted power spectrum and the luminosity power spectrum and define a set of observables from which the information on the scaling relation is retrieved. In Sect. 3 we evaluate the information content in those observables. We summarize our conclusions in Sect. 4.
2. Probes for cluster scaling relations
2.1. Halo catalogs
We base our analysis on the LBASICC Nbody simulations (Angulo et al. 2008) represented by a suite of N = 50 realizations of the same flat ΛCDM cosmological model at redshift zero. The simulations are characterized by a matter density parameter Ω_{mat} = 0.237, a baryon density parameter Ω_{ba} = 0.046, a dimensionless Hubble parameter h = 0.73^{1}, linear rms mass fluctuations within 8 h^{1} Mpc of σ_{8} = 0.773, and a scalar spectral index n_{s} = 0.997, following the evolution of 448^{3} dark matter particles in a comoving box with volume V = (1340 h^{1} Mpc)^{3}. Halo catalogs were built by means of a friendsoffriends algorithm, characterized by a linking length of 0.2 times the mean interparticle separation and a minimum mass of 1.73 × 10^{13} h^{1}M_{⊙} (which corresponds to ten dark matter particles).
2.2. Cluster scaling relation
We assign Xray luminosities^{2}L to dark matter halos by means of a lognormal conditional probability distribution (hereafter scaling relation), specifying the probability that a cluster has an Xray luminosity in the range L,L + dL, conditional on its mass M: (1)where ℓ ≡ log ^{(}L/(10^{44}erg s^{1} h^{2})^{)} and denotes the intrinsic scatter in ℓ at a fixed mass scale M, i.e., . For the mean of the scaling relation we use a power law with amplitude α and slope γ, (2)As fiducial values we use α = −0.64, γ = 1.27 and σ = 0.15, with . These numbers follow from realistic estimates of the cluster’s massX ray luminosity relation (e.g., BalagueraAntolínez et al. 2012). However, the exact figures are not relevant for the purposes of this work, as long as we are not constructing galaxycluster catalogs constrained to follow a particular selection function. The Fisher matrix analysis presented in Sect. 3 is be dedicated to the sensitivity of a set of observables – to be defined in Sect. 2.3 – to the set of parameters .
For the forthcoming analysis, we consider objects with luminosities within the range 3 × 10^{42} ≤ L/(h^{2} erg s^{1}) ≤ 5 × 10^{44}, which leads to realizations with N_{cl} ~ 4 × 10^{5} entries. To study the dependence of clustering with luminosity, we split this range in n_{ℓ} = 10 disjoint and equally logspaced bins. When the luminosity dependence is not explicitly shown in the forthcoming expressions, it is assumed that clusters with luminosities in the full luminosity range have been considered for the analysis.
2.3. Clustering estimates
2.3.1. Definitions
Let n_{w}(r;L) denote the number density of weighted (or marked) halos at a position r and luminosity L and its mean value. We aim to measure the luminosityweighted power spectrum by defining the fluctuation . Similarly, let denotes the unmarked cluster fluctuation, with as the mean number density of clusters with luminosity L. As weight we use the cluster Xray luminosity, , where is the first sample moment (or mean) of the luminosity in the sample. By definition , which in turn implies that . The quantity n_{w}(r;L) denotes an inhomogeneous marked point process, in which two sources of stochasticity are present, namely, the associated to the sampling process giving rise to the observed n(r;L) and the one due to the stochastic nature of the marks. We assume that the halo distribution n(r;L) is the result of an inhomogeneous Poisson point process. Strictly speaking, a Poisson model cannot properly describe the distribution of galaxy clusters since these objects are subject to the socalled halo exclusion effects (e.g., Porciani & Giavalisco 2002; Tinker et al. 2005; Smith et al. 2007). This effect arises because halos are treated as disjointed entities that are not allowed to overlap, leading to a correlation function ξ(r) → −1 on scales below the minimum scale probed by the halo catalog (for an ideal sample of spherical halos, this scale equals twice the radius of the smaller halo, e.g., Peebles 1980). We discuss this subject briefly in Appendix B.
2.3.2. Probes of clustering
The weighted halos are embedded into a 380^{3} cubic grid using a cloudincell mass assignment scheme (Hockney & Eastwood 1988). We use the FFTW algorithm (Frigo & Johnson 2012) to compute the Fourier transform of δ_{w}(r;L), , correcting thereafter for aliasing effects (see e.g., Angulo et al. 2008). We next obtain estimates^{3} of the unmarked P(k;L), the cross power spectrum between the unweighted and weighted halo density fields and the luminosityweighted power spectrum by where ⟨·⟩_{ki} denotes average in spherical shells of width Δk = 2πV^{−1/3} centered at k_{i}. The second term in Eq. (3) corresponds to the Poisson shotnoise correction (e.g., Peebles 1980), an extra variance of the halo field induced by discreetness. Similarly, the extra variance in Eqs. (4) and (5) are the product of the variance related to the Poisson pointlike process and the one induced by the luminosity distribution. The term denotes the second sample moment of the weights within the jth luminosity bin. Again, in Eq. (4), .
Fig. 1 Mean power spectra , and (defined in Sect. 2.3) obtained from the ensemble of Nbody simulations for galaxy clusters within the full luminosity range as described in the text. The 60% of the Nyquist frequency is marked with an arrow. The shaded regions denote the standard deviation obtained from the ensemble of Nbody simulations.

Open with DEXTER
Fig. 2 Ratio between the spectra and to the cluster power spectrum , shown in real space. The horizontal lines show the predictions presented in Appendix A. The shaded regions denote the standard deviation obtained from the ensemble of Nbody simulations. The inset shows a closeup of the ratio , showing a clear scaledependent trend from scales k ≳ 0.06 h Mpc^{1}.

Open with DEXTER
Along with the measurements in real space, we also measured twopoint statistics in redshift space by means of the distantobserver approximation, i.e., shifting the position of dark matter halos along the xaxis x → x + v_{x}/H_{0} where v_{x} is the xcomponent of the peculiar velocity of the halo center of mass. We keep Fourier modes up to a ~60% of the Nyquist frequency k_{Ny} = 0.89 h Mpc^{1}, where the corrections due to the assignment scheme are accurate (e.g., Cole et al. 2005).
Different power spectra defined in the text.
In Fig. 1 we show the mean of the realspace power spectra and (computed using the full luminosity range) with the corresponding standard deviation obtained from the ensemble of realizations of the LBASICC simulation. At first glance, the estimates of marked power spectra behave as scaled versions of . Indeed, on large scales (k ≲ 0.04 h Mpc^{1}), the ratios are described well by a constant factor, as explicitly shown in Fig. 2. This suggests that the amplitude of the marked power spectra can be explained, as a first approximation, by including the information of the scaling relation within a sort of luminosity bias. Indeed, the theoretical expectations described in Appendix A and represented in Fig. 2 by the solid lines show that this is the case.
A more careful analysis reveals, though, a scale dependence of the ratios , which is statistically significant even on large and intermediate scales k ≳ 0.04 h Mpc^{1} (also present in redshift space). This is shown in the inset of Fig. 2. We note that and are equally affected by the nonlinear evolution of the underlying matter density field and the exclusion effect (i.e., they are estimated from the same sample and thus the smallest populated bin of separation is the same, albeit differently weighted), as well as by the same scaledependent halomass bias (see, e.g., Tinker et al. 2005). Therefore, the scale dependency observed in the ratios can be regarded as a signature of the distribution of the weights w_{i}w_{j} within pairs at different separations, suggesting that the shape of the luminosityweighted power spectrum is sensitive to the scaling relation . This is explored in Sect. 3.
2.3.3. Introducing a new probe
As an attempt to isolate the signal of the clustering of the Xray luminosity from the unmarked power spectrum, we define . This fluctuation has zero mean, , and variance , where ⟨· ⟩ denotes an average over an ideal ensemble of realizations. We refer to this variance as the luminosity power spectrum. Thus defined, the variable δ_{L} accounts for the fluctuations in the weighted number density with respect to the unweighted number density. Since by construction both number densities share the same mean value, this simple subtraction avoids us from having to assume that the observed mean number density is the true mean density, and thus, the estimates of the luminosity power spectrum are free of the socalled integral constraint (e.g., Peacock & Nicholson 1991). Since the mean number density only enters into the definition of δ_{L} as a normalization, the possible difference between the observed and true number density would equally affect all Fourier modes in P_{L}(k;L) by some constant factor. The estimates of the luminosity power spectrum are obtained following the same procedure as described in the previous section, namely, a shellaverage of the estimate with a shotnoise correction S_{L}: (6)According to the definition of δ_{L}(r), the luminosity power spectrum can be written as the combination of the luminosityweighted power spectra . Thus, we can identify the shotnoise correction with , where . Figure 1 shows the mean of the estimates of P_{L}(k) as determined from the ensemble of Nbody simulations (in the full luminosity range), together with its standard deviation. As shown in Fig. 2, on large scales the shape of can be understood as a biased halo power spectrum, i.e., P_{L}(k)/P(k) ~ const., which is even prevailing on intermediate scales (~0.1 h Mpc^{1}). In view of the results shown in Appendix A, the luminosity power spectrum can be thought of as directly probing the mean scaling relation.
Table 1 summarizes the definitions of the different power spectra introduced in this section.
2.4. Twopoint statistics as probe for cluster scaling relations
Generally, the information related to the parameters of a model explaining the observed twopoint statistics can be extracted in three different ways: i) using the amplitude of the clustering signal; ii) using its full shape (e.g., Sánchez et al. 2012); or iii) isolating particular features such as the position of the baryonic acoustic peak in the correlation function (e.g., Anderson et al. 2012; Hong et al. 2012) or the turnover in the power spectrum (e.g., Reid et al. 2010; Poole et al. 2013). We study the information content in cases i) and ii), and leave the assessment of the dependence of particular features for future studies, e.g., the acoustic peak in the correlation function, on the cluster scaling relations.
2.4.1. Amplitude
The information contained in the amplitude of the clustering signal can be extracted by defining ratios of spectra by the underlying matter power spectrum or in a less modeldependent fashion, by the clustering of the same population of objects at a given luminosity (e.g., Norberg et al. 2002). As suggested by panel b of Fig. 1, such ratios are approximately constant on large scales (e.g., k ≲ 0.04 h Mpc^{1}). We define for each realization q = 1, ··· ,N, the following ratios: (7)Our set of largescale luminositydependent observables is then defined as , where ⟨·⟩_{δk} denotes the average over wavenumbers in the range δk = [0.01, 0.04] h Mpc^{1}. The first three probes r_{1, 2, 3}(L) are defined as ratios of a given power spectrum in different luminosity bins with respect to the same statistics, the latter measured in a fixed (reference) luminosity bin L_{ref}, thereby providing estimates of relative biases of the marked spectra. The ratios r_{4, 5}(L) are instead defined by the unmarked power spectrum in the same luminosity bin, and we refer to these as estimates of absolute bias^{4}. Similarly, the ratios r_{6, 7}(L) are estimates of relative and absolute bias extracted from the luminosity power spectrum. In these expressions L_{ref} is taken as containing the value L_{⋆} = 0.63 × 10^{44} erg s^{1}h^{2}, the typical Xray luminosity of galaxy clusters up to redshift z ~ 0.2 (BalagueraAntolínez et al. 2012). We checked that our results do not change substantially when other values of L_{ref} are used, except for the highluminosity bins, wherein the clustering estimates display a low signaltonoise ratio. In Appendix A we show the theoretical predictions for these ratios.
2.4.2. Full shape
The measurements of the luminosityweighted power spectrum shown in Sect. 2.3 revealed that the scaling relation not only affects the amplitude of the weighted power spectra , but can also play a role in shaping their broadband signal. To quantify the information encoded in the full shape of the measured spectra P(k), , and P_{L}(k), we use their estimates in the range of wave numbers 0.02 ≤ k/(h Mpc^{1}) ≤ 0.2, with Fourier modes, and use the full Xray luminosity range.
As pointed out in Sect. 2.3, the variance of the fluctuations of the luminosityweighted and luminosity power spectrum has a contribution that embodies two forms of randomness: one associated to the finite number of halos, the other to the distribution of the marks compared to its mean. These two effects are represented by Eq. (6). The shotnoise subtraction in the power spectrum of galaxy clusters is a delicate issue. As rare objects, clusters display number densities that are low enough to generate a shotnoise contribution that can be traceable even on the largest scales. As an example of its relevance, it can be seen that estimates of power spectra without shotnoise correction can generate a scaledependent bias on scales where the ratios between corrected spectra were fairly described by a constant factor (see, e.g., Pollack et al. 2012). Strictly speaking, not subtracting the shotnoise correction from the estimates of power spectra is not an off base procedure, given that this correction is a model in itself and as such can be included in the modeling of the clustering signal. To asses the impact of the shotnoise correction in the amount of information we can retrieve, we consider below the case when the information content from the luminosity power spectrum is extracted from its shotnoise uncorrected estimate.
3. Results: information content
In this section we carry out a Fisher matrix analysis (see, e.g., Tegmark et al. 1997) in order to quantify the amount of information on the massX ray luminosity scaling relation that our clusteringrelated observables contain. Before proceeding, we recall that in the context of galaxy cluster experiments, onepoint statistics – such as cluster number counts – represent the standard probe for cosmological parameters and scaling relations (e.g., Majumdar & Mohr 2004; Lima & Hu 2004; Cunha & Evrard 2010; Pillepich et al. 2012). To compare our results – which are based on twopoint statistics – with a onepoint statistics probe, we use the Xray luminosity function (XLF hereafter) measured in equally logspaced bins. Given that the cosmological parameters are kept fixed throughout the analysis^{5}, the information content in the XLF can provide a fair level of comparison to assess the capability of the clustering probes in retrieving information on the cluster scaling relation against the standard procedures. Our set of observables is summarized as (8)where the index j runs from (1, ··· , n_{ℓ}) for the ratios r_{ν}(L), for the power spectra, and for the XLF. For each observable, its mean and covariance matrix C are given by and respectively, where ⟨·⟩_{ens} denotes averages over the ensemble of realizations of the LBASICC simulations.
The Fisher matrix represents the ensemble average of the Hessian of the natural logarithm of the likelihood function of a data set given a model, and its customary application aims to forecast uncertainties of a set of model parameters from a given experiment. Our approach is slightly different, though, since we aim to quantify the sensitivity of each of the observables defined in Eq. (8) to the set of parameters (defined in Sect 2.2) using measurements and covariance matrices directly extracted from the simulations. In other words, we assume perfect knowledge of model and the covariance for our observables. Under the assumption that the observables are drawn from a Gaussian distribution, the elements of the Fisher matrix F are written as (9)where ,x ≡ ∂/∂x and x_{fid} denotes the fiducial values of the parameters , defined in Sect. 2.2. The covariance matrix of the parameters of the model is , and the marginal error of each parameter is obtained from the CramérRao inequality . We used a doubleside variation to accurately estimate the derivatives with respect to the parameters. This leads us to computing 27(models) × 50(realizations) × 2(real and redshiftspace estimates)× 3(marked spectra)× 10 (luminosity bins) = 8.1 × 10^{5} estimates of power spectrum.
Three key aspects of our Fisher matrix analysis are taken into account. Firstly, by means of the socalled D’Agostino K2 goodnessoffit test, we have verified that the distribution of the observables defined in Eq. (8) within the suite of realizations of the Nbody simulations is compatible to 95 per cent confidence with a normal distribution within the ranges of the Xray luminosity and wavenumbers of interest. Secondly, we note that when computing the Fisher matrix for all our observables (with mean values ), we omit the term containing the derivatives of the covariance matrix, since it adds spurious information that shrinks the marginalized errors considerably (Carron 2013). Finally, when exploring the information content encoded solely in the shape of the power spectra, we treat the amplitude of the mean spectra as a nuisance parameter. Under the assumption that these amplitudes have flat or Gaussiandistributed priors, analytical marginalization of the covariance matrix over these parameters is possible (e.g., Lewis & Bridle 2002; Taylor & Kitching 2010). For a flat prior on these amplitudes, the inverse of the marginalized covariance matrix is obtained by subtracting the factor from the original inverted covariance matrix.
Fig. 3 Joint 1σ error ellipses for the parameters { α,γ,σ } of the scaling relation , obtained from the Fishermatrix analysis in real (shaded area) and redshift (dotted lines contours) space, using the set r_{ν = 1, ··· , 7}(L) defined in Eq. (7) as observables. The small filled contours represent the results using the XLF.

Open with DEXTER
Fig. 4 Joint 1σ error ellipses for the parameters { α,γ,σ } of the scaling relation , obtained from the Fishermatrix analysis of power spectra P(k), and P_{L}(k) defined in Sect. 2.3. Results are shown in real (shaded area) and redshift (dotted lines) space. The estimates of these spectra are obtained within the fullluminosity range and using Fourier modes in the interval 0.02 < k/(h Mpc^{1}) < 0.2. The solid contours represent the results using the XLF. The right block of panels shows the results using after marginalizing over the amplitude of the power spectra. The left block shows the results using the full shape. The color of the first row is meant to highlight the results obtained with the luminosity power spectrum.

Open with DEXTER
We quantify the information obtained from each of our observables by a figure of merit (FoM hereafter) defined as the inverse of the area of the marginalized 68% error ellipse of each pair of parameters. We also compute the total FoM given by the volume of the threedimensional 68% error ellipsoid. We present the results from the Fisher matrix analysis in Figs. 3 and 4. Figure 6 condenses the FoM derived from our set of observables. We draw our conclusions based on these three figures.
3.1. Information content in the amplitude
Figure 3 shows the joint 1σ error ellipses obtained from the Fishermatrix analysis of the set r_{ν = 1, ··· , 7}(L). The results are presented in real and redshift space. We next draw some conclusions based on this figure, in conjunction with Fig. 6.

The sensitivity to the parameters of the scaling relation varies little between the observables r_{1, 2, 3}(L). This is also true when these observables are measured in redshift space. The estimates associated to absolute biases r_{4, 5}(L) are slightly more sensitive to the signal of the spectra in redshift space.

When the ratios are defined by the unmarked power spectrum (i.e., r_{4, 5}(L)), the marginalized errors on the amplitude, σ_{α}, decrease while σ_{γ} increases, with a net decrease in the total FoM. Therefore, the set r_{1, 2, 3}(L) proves to be more sensitive to the set {γ,σ}, while the set r_{4, 5}(L) sets tighter constraints on amplitude α.

The estimates of relative bias extracted from the luminosity power spectrum r_{6}(L) generate FoM that are approximately two orders of magnitude above those obtained from the luminosity weighted power spectrum, say r_{3}(L), marking a noticeable improvement. The total FoM of derived from this probe is only ~40 times below the one derived from the XLF. On the other hand, the estimate of absolute bias r_{7}(L) sets poor constraints.

In general, better constraints are obtained from the estimates of relative bias. As pointed out before, the selection of the reference luminosity does not affect our conclusions, except for very high values of L_{ref}.
We conclude that, regarding the amplitude of the cluster power spectrum, the unmarked analysis is accurate enough and no extrainformation is gained by measuring the luminosity dependence of the amplitude of the luminosityweighted power spectrum. On the other hand, we have shown that the estimates of luminosity bias obtained from the luminosity power spectrum, r_{6}(L), allows us to retrieve an amount of information on the scaling relation that is only one order of magnitude below the one characterizing the XLF.
3.2. Information content in the full shape
Figure 4 shows the error ellipses from the analysis of the full shape of the power spectra , , and , both in real and in redshift space, with Fourier modes in the range 0.02 < k/(h Mpc^{1}) < 0.2. The left hand panel in that figure corresponds to the results obtained after marginalizing the covariance matrix of each observable with respect to an overall amplitude, while the right hand panel shows results obtained after using the information encoded in the full shape. This figure confirms the intuitive prediction that more information (smaller error ellipses) is gained when the full shape is used in the analysis. We complement the information shown in Fig. 4 with the information shown in Figs. 5 and 6. From these we conclude the following.

The marked power spectra generate higher FoM compared to P(k), due mainly to their sensitivity to the slope of the scaling relation γ. These three spectra are almost equally sensitive to the intrinsic scatter σ and the amplitude α.

A gain in information content on the scaling relation is obtained from the luminosity power spectrum, with FoM increased approximately by an order of magnitude over what is obtained with , or, ~40 times below what characterizes the information encoded in the XLF.
Fig. 5 FoM obtained from the 1σ error ellipsoids of the parameters of the scaling relation as a function of the maximum wavenumber k_{max}. The FoM shown correspond to the information contained in the full shape of the clustering probes.
Open with DEXTER
Figure 5 shows the behavior of the FoM related to the full shape of the observables , , and , as a function of the maximum wavenumber used in the analysis, k_{max}. We see that the ratio of the FoM contained in the luminosity power spectrum P_{L}(k) to that of the unweighted power spectrum P(k) ranges from a factor 10^{2} with k_{max} ~ 0.07 h Mpc^{1} to ~20 with k_{max} ~ 0.2 h Mpc^{1}. The trend of the different FoM with the maximum wavenumber is as expected; i.e, the higher the number of Fourier modes, the higher the content of information in the Fisher matrix.

To emphasize the relevance of the shotnoise correction, we repeated our analysis using the shotnoise uncorrected estimates of the different power spectra. As a result, the FoM obtained are higher than those presented in Fig. 6, as has been explicitly portrayed for the case of the shotnoise uncorrected luminosity power spectrum (denoted by ). The ratios between the FoM obtained from the uncorrected estimates to those derived from the corrected ones (using their full shape as probes) are ~3, 21, and 23 for , and P_{L} respectively, illustrating how sensitive the clustering signal of galaxy clusters to the shotnoise correction is. Furthermore, the total FoM associated to is a factor ~2.5 smaller than the corresponding value obtained from the XLF, which is noticeable if we compare it to the factors ~15 and ~2 × 10^{3} derived from and P(k) respectively^{6}. The shotnoise correction (either Poissonlike or scaledependent) is always demanded, if not in the measurement, then in the model adopted for interpreting the clustering signal. Not doing that can lead to biased interpretations of the observed power spectra, which degenerate into spurious tight constraints on the parameters of interest.
In summary, Fig. 6 attempts to answer the question posed by the title of this paper. The improvement in the FoM obtained from the luminosity power spectrum with respect to the standard probes (i.e., unweighted clustering analysis) represents the main result of our analysis.
Fig. 6 FoMs obtained from the 1σ error ellipses of each pair of parameters of the scaling relation, taken from the different observables μ_{j} defined in Eq. (8). By FoM we denote the figure of merit computed as the volume of the 3dimensional 68% error ellipsoid. To facilitate the understanding of this figure, the dark gray, gray and light gray areas denote observables accounting for the amplitude, the shape and the full shape of power spectra respectively. Results are shown in real space. Noticeably, the luminosity power spectrum P_{L} provides more information regarding the scaling relation than the luminosityweighted spectra, and display a total FoM that is ~10^{2} times that of the unweighted power spectrum. We show the estimates derived from the luminosity power spectrum , in order to emphasize how high FoM can be obtained when no shotnoise correction is spuriously implemented in the measurements.

Open with DEXTER
4. Discussion and conclusions
In this paper we aimed to explore the capability of the socalled marked statistics of galaxy clusters to retrieve information on the links between cluster masses and cluster Xray luminosities. To this end, we assigned Xray luminosities to dark matter halos in a suite of Nbody simulations and measured luminosityweighted power spectra and luminosity power spectrum , as defined in Sect. 2.3. The luminosity power spectrum has been defined such that it directly measures the clustering of Xray luminosity. The definition of the luminosity power spectrum can be extrapolated to other probes of twopoint statistics, such as the angular power spectrum. This can be especially suitable in cases where no redshiftinformation is available and clusters are identified by a redshift independent intrinsic property, such as the SZ signal (e.g., Planck Collaboration XXIX. 2014).
We extracted the information related to the scaling relation by dissecting the clustering signal in three different parts: first, we isolated the largescale information on the power spectra measured in different luminosity bins, and measured estimates of luminosity bias. Second, we explored the information encoded in the shape of the clustering signal, and third, we considered their full shape (i.e., shape and amplitude). This yields a total of twelve observables. By carrying out a Fisher matrix analysis, we quantified the amount of information regarding the cluster scaling relation from each of these observables through the definition of a FoM. In terms of the amplitude, we showed that the information encoded in the estimates of cluster luminosity bias measured from the unweighted power spectrum P(k) is close to what is obtained from the bias of the weighted spectra , so that no sensitive gain of information is achieved. However, a relevant increase in the information content is obtained when estimates of relative bias are extracted from the luminosity power spectrum, reaching FoM that are only one order of magnitude below the values derived from the XLF analysis. Similarly, when exploring the information content within the full shape of the power spectra, we found that the information associated to P_{L}(k) overcomes that of the spectra and P(k): the resulting FoM of the P_{L} is a factor of ~100 (~10) with respect to that of the unweighted (weighted) power spectrum. The gain in information obtained from the estimates of the luminosity power spectrum with respect to the unweighted analysis represents the main result of this paper.
The results presented show, though, that the XLF still encodes more astrophysical information than our best clustering probe, the luminosity power spectrum. This implies that the contribution of the latter in the constraints of astrophysical parameters within a joint XLFclustering analysis could be subdominant, at least in the case where the cosmological sector is fixed. In a more realistic scenario, though, Pillepich et al. (2012) show that the combination of cluster number counts and the standard (i.e, unweighted) angular cluster power spectrum for the eROSITA experiment can set constraints that are tighter than those derived from the number counts alone. Nevertheless, these authors emphasize that this trend can be reversed after variations in the selection function of the sample in their study. A direct comparison between our approach and the Pillepich et al. (2012) analysis is not applicable, since, as we already pointed out, we are not interested in assessing the ability of a certain model to explain a given experiment, and also because we have kept the cosmological parameters fixed, thereby ignoring all possible correlations between the cosmological and the astrophysical sector. In view of our results, it can be expected that the joint analysis of number counts and some Xproperty angular power spectrum can contribute to improving the FoM in the work of Pillepich et al. (2012). This is currently under study.
An obvious question arises, as to the feasibility of the clustering signal to set precise constraints on cluster scaling relations in future galaxycluster surveys. From the observational point of view, the volume of the Nbody simulations we used to create cluster catalogs mimics that of a fullsky complete sample to a maximum redshift of z ~ 0.3. The resulting mean number density resembles what is expected from the eROSITA experiment (Pillepich et al. 2012). Therefore the precision to which only the scaling relation could be constrained from these forthcoming samples – when redshifts are available and using P_{L}(k) – can be of the same order as that obtained from our analysis. On the other hand, the volumes that will be probed by the forthcoming surveys will generate statistical errors on the estimates of power spectra that might be compatible to the systematic errors present when modeling clustering. This situation is especially noticeable on small scales – probed by a large number of modes – where the clustering signal is dominated by the nonlinear evolution of the matter density field, the scaledependent halomass bias, the halo exclusion, and ultimately baryonic effects.
In Fig. 6 we displayed our results such that relevant FoM are obtained, especially for the luminosity power spectrum, when we include Fourier modes up to a scale of k ~ 0.2 h Mpc^{1} in our analysis. From a theoretical perspective, extending the analysis to such values of wavenumbers might be a point of concern. On these scales, highly complex processes (e.g., nonlinear evolution of the matter density field, scaledependent halo biasing and halo exclusion effect) become nonnegligible. In the past two decades, major progress in the understanding of some of these processes has been accomplished. In that regard, there are several attempts to describe the nonlinear evolution of dark matter, either based on numerical fits to Nbody simulations (e.g., Peacock & Dodds 1996; Smith et al. 2003) or on theoretical predictions (e.g., Bernardeau et al. 2002; Crocce & Scoccimarro 2006; McDonald 2007; Matsubara 2011). The link between dark matter and halos – the halomass bias – has also been an active area of research, regarding its nature and fitting formulae for its implementation. Even if these theoretical predictions accurately describe the results from Nbody simulations, baryonic effects within galaxy clusters (e.g., radiative cooling, star formation, feedback mechanism due to AGN and supernova) can severely spoil the expectations of modeling the observed clustering signal to the accuracy achieved by stateofthe art cosmological simulations of dark matter. Indeed, such effects have been shown to substantially modify the abundance and clustering of clusters with respect to pure dark matterbased predictions (e.g., Stanek et al. 2009; Rudd et al. 2008; van Daalen et al. 2011; Cui et al. 2012; BalagueraAntolínez & Porciani 2013). In view of the plethora of models accounting for the baryonic effects that shape the intracluster medium and the small scales (astrophysical, instead of cosmological) where these effects take place, precise modeling of the abundance and clustering of galaxy clusters based on Nbody simulations is still far from being achieved. Even though it is beyond the scope of this paper to discuss the impact of the systematic effects present on the modeling of the quantities mentioned above, we recognize their relevance in extracting accurate information regarding the parameters describing the observed clustering pattern of galaxy clusters (especially using the luminosity power spectrum) from forthcoming galaxy and galaxy cluster surveys such as eROSITA, DES (The Dark Energy Survey Collaboration 2005), or Euclid (Laureijs et al. 2011). We notice that the only model that we have explicitly implemented in our analysis makes the assumption that the halo distribution behaves like a Poisson point process, which is a debatable hypothesis (see, e.g., CasasMiranda et al. 2002; Smith et al. 2007). With this assumption, the shotnoise correction of the halo power spectrum is represented by subtracting a white noise from the raw power spectrum. However, even simple toy models assuming spherical halos reveal a scaledependent shot noise. We discuss this briefly in Appendix B.
The weighted twopoint statistics proves itself to be an interesting tool for characterizing the explicit dependence of the clustering of galaxy clusters on intrinsic properties. The implementation of these statistics, either in Fourier space (as we have shown in this paper) or in configuration space (see, e.g., Sheth 2005), can contribute setting tight constraints on the parameters that characterize the physics of the intracluster medium, interestingly intertwining cosmology and astrophysics on the galaxy clusterscale.
Acknowledgments
I am grateful to Raúl Angulo for making the LBASICC II simulations available. I thank Cristiano Porciani and Nina Roth for useful discussions and suggestions, as well as the anonymous referee for comments that helped improve the presentation and content of the manuscript. I acknowledge support through the SFBTransregio 33 “The Dark Universe” by the Deutsche Forschungsgemeinschaft (DFG).
References
 Allen, S. W., Evrard, A. E., & Mantz, A. B. 2011, ARA&A, 49, 409 [NASA ADS] [CrossRef] [Google Scholar]
 Anderson, L., Aubourg, E., Bailey, S., et al. 2012, MNRAS, 427, 3435 [NASA ADS] [CrossRef] [Google Scholar]
 Angulo, R. E., Baugh, C. M., Frenk, C. S., & Lacey, C. G. 2008, MNRAS, 383, 755 [NASA ADS] [CrossRef] [Google Scholar]
 BalagueraAntolínez, A., & Porciani, C. 2013, JCAP, 4, 22 [NASA ADS] [CrossRef] [Google Scholar]
 BalagueraAntolínez, A., Sánchez, A. G., Böhringer, H., et al. 2011, MNRAS, 413, 386 [NASA ADS] [CrossRef] [Google Scholar]
 BalagueraAntolínez, A., Sánchez, A. G., Böhringer, H., & Collins, C. 2012, MNRAS, 425, 2244 [NASA ADS] [CrossRef] [Google Scholar]
 Bardeen, J. M., Bond, J. R., Kaiser, N., & Szalay, A. S. 1986, ApJ, 304, 15 [NASA ADS] [CrossRef] [Google Scholar]
 Bernardeau, F., Colombi, S., Gaztañaga, E., & Scoccimarro, R. 2002, Phys. Rep., 367, 1 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Bianchi, D., Guzzo, L., Branchini, E., et al. 2012, MNRAS, 427, 2420 [NASA ADS] [CrossRef] [Google Scholar]
 Böhringer, H., Collins, C. A., Guzzo, L., et al. 2002, ApJ, 566, 93 [NASA ADS] [CrossRef] [Google Scholar]
 Carron, J. 2013, A&A, 551, A88 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 CasasMiranda, R., Mo, H. J., Sheth, R. K., & Boerner, G. 2002, MNRAS, 333, 730 [NASA ADS] [CrossRef] [Google Scholar]
 Cole, S., Percival, W. J., Peacock, J. A., et al. 2005, MNRAS, 362, 505 [NASA ADS] [CrossRef] [Google Scholar]
 Cooray, A., & Sheth, R. 2002, Phys. Rep., 372, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Crocce, M., & Scoccimarro, R. 2006, Phys. Rev. D, 73, 063519 [NASA ADS] [CrossRef] [Google Scholar]
 Cui, W., Borgani, S., Dolag, K., Murante, G., & Tornatore, L. 2012, MNRAS, 423, 2279 [NASA ADS] [CrossRef] [Google Scholar]
 Cunha, C. E., & Evrard, A. E. 2010, Phys. Rev. D, 81, 083509 [NASA ADS] [CrossRef] [Google Scholar]
 Finoguenov, A., Reiprich, T. H., & Böhringer, H. 2001, A&A, 368, 749 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Frigo, M., & Johnson, S. G. 2012, Astrophysics Source Code Library ascl:1201.015 [Google Scholar]
 Giodini, S., Pierini, D., Finoguenov, A., et al. 2009, ApJ, 703, 982 [NASA ADS] [CrossRef] [Google Scholar]
 Hamilton, A. J. S. 1998, in The Evolving Universe, ed. D. Hamilton, Astrophys. Space Sci. Lib., 231, 185 [Google Scholar]
 Hockney, R. W., & Eastwood, J. W. 1988, Computer simulation using particles (Beistol: Hilger) [Google Scholar]
 Hong, T., Han, J. L., Wen, Z. L., Sun, L., & Zhan, H. 2012, ApJ, 749, 81 [NASA ADS] [CrossRef] [Google Scholar]
 Jenkins, A., Frenk, C. S., White, S. D. M., et al. 2001, MNRAS, 321, 372 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Kaiser, N. 1986, MNRAS, 222, 323 [NASA ADS] [CrossRef] [Google Scholar]
 Kaiser, N. 1987, MNRAS, 227, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Kravtsov, A. V., & Borgani, S. 2012, ARA&A, 50, 353 [NASA ADS] [CrossRef] [Google Scholar]
 Laureijs, R., Amiaux, J., Arduini, S., et al. 2011 [arXiv:1110.3193] [Google Scholar]
 Lewis, A., & Bridle, S. 2002, Phys. Rev. D, 66, 103511 [NASA ADS] [CrossRef] [Google Scholar]
 Lima, M., & Hu, W. 2004, Phys. Rev. D., 70, 043504 [NASA ADS] [CrossRef] [Google Scholar]
 Majumdar, S., & Mohr, J. J. 2004, ApJ, 613, 41 [NASA ADS] [CrossRef] [Google Scholar]
 Mantz, A., Allen, S. W., Ebeling, H., Rapetti, D., & DrlicaWagner, A. 2010, MNRAS, 406, 1773 [NASA ADS] [Google Scholar]
 Matsubara, T. 2011, Phys. Rev. D, 83, 083518 [NASA ADS] [CrossRef] [Google Scholar]
 McDonald, P. 2007, Phys. Rev. D, 75, 043514 [NASA ADS] [CrossRef] [Google Scholar]
 Mo, H. J., & White, S. D. M. 1996, MNRAS, 282, 347 [NASA ADS] [CrossRef] [Google Scholar]
 Mo, H., van den Bosch, F. C., & White, S. 2010, Galaxy Formation and Evolution (Cambridge, UK: Cambridge Universiy Press) [Google Scholar]
 Norberg, P., Baugh, C. M., Hawkins, E., et al. 2002, MNRAS, 332, 827 [NASA ADS] [CrossRef] [Google Scholar]
 Peacock, J. A., & Dodds, S. J. 1996, MNRAS, 280, L19 [NASA ADS] [CrossRef] [Google Scholar]
 Peacock, J. A., & Nicholson, D. 1991, MNRAS, 253, 307 [NASA ADS] [CrossRef] [Google Scholar]
 Peebles, P. J. E. 1980, The largescale structure of the universe (Princeton University Press) [Google Scholar]
 Pierpaoli, E., Borgani, S., Scott, D., & White, M. 2003, MNRAS, 342, 163 [NASA ADS] [CrossRef] [Google Scholar]
 Pillepich, A., Porciani, C., & Hahn, O. 2010, MNRAS, 402, 191 [NASA ADS] [CrossRef] [Google Scholar]
 Pillepich, A., Porciani, C., & Reiprich, T. H. 2012, MNRAS, 422, 44 [NASA ADS] [CrossRef] [Google Scholar]
 Planck Collaboration XII. 2011, A&A, 536, A12 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Planck Collaboration XX. 2014, A&A, in press, DOI: 10.1051/00046361/201321521 [Google Scholar]
 Planck Collaboration XXIX. 2014, A&A, in press, DOI: 10.1051/00046361/201321523 [Google Scholar]
 Pollack, J. E., Smith, R. E., & Porciani, C. 2012, MNRAS, 420, 3469 [NASA ADS] [CrossRef] [Google Scholar]
 Poole, G. B., Blake, C., Parkinson, D., et al. 2013, MNRAS, 429, 1902 [NASA ADS] [CrossRef] [Google Scholar]
 Porciani, C., & Giavalisco, M. 2002, ApJ, 565, 24 [NASA ADS] [CrossRef] [Google Scholar]
 Pratt, G. W., Croston, J. H., Arnaud, M., & Böhringer, H. 2009, AA, 498, 361 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Rapetti, D., Blake, C., Allen, S. W., et al. 2013, MNRAS, 432, 973 [NASA ADS] [CrossRef] [Google Scholar]
 Rasia, E., Meneghetti, M., Martino, R., et al. 2012, New J. Phys., 14, 055018 [NASA ADS] [CrossRef] [Google Scholar]
 Reid, B. A., Percival, W. J., Eisenstein, D. J., et al. 2010, MNRAS, 404, 60 [NASA ADS] [CrossRef] [Google Scholar]
 Rudd, D. H., Zentner, A. R., & Kravtsov, A. V. 2008, ApJ, 672, 19 [NASA ADS] [CrossRef] [Google Scholar]
 Sánchez, A. G., Scóccola, C. G., Ross, A. J., et al. 2012, MNRAS, 425, 415 [NASA ADS] [CrossRef] [Google Scholar]
 Sarazin, C. L. 1988, S&T, 76, 639 [NASA ADS] [Google Scholar]
 Schlather, M. 2001, Bernoulli, 7, 99 [CrossRef] [Google Scholar]
 Schuecker, P., Böhringer, H., Guzzo, L., et al. 2001, A&A, 368, 86 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Semboloni, E., Hoekstra, H., & Schaye, J. 2013, MNRAS, 434, 148 [NASA ADS] [CrossRef] [Google Scholar]
 Sheth, R. K. 2005, MNRAS, 364, 796 [NASA ADS] [CrossRef] [Google Scholar]
 Sheth, R. K., & Tormen, G. 1999, MNRAS, 308, 119 [NASA ADS] [CrossRef] [Google Scholar]
 Skibba, R. A., & Sheth, R. K. 2009, MNRAS, 392, 1080 [NASA ADS] [CrossRef] [Google Scholar]
 Skibba, R., Sheth, R. K., Connolly, A. J., & Scranton, R. 2006, MNRAS, 369, 68 [NASA ADS] [CrossRef] [Google Scholar]
 Smith, R. E., Peacock, J. A., Jenkins, A., et al. 2003, MNRAS, 341, 1311 [NASA ADS] [CrossRef] [Google Scholar]
 Smith, R. E., Scoccimarro, R., & Sheth, R. K. 2007, Phys. Rev. D., 75, 063512 [NASA ADS] [CrossRef] [Google Scholar]
 Smith, R. E., Reed, D. S., Potter, D., et al. 2012, MNRAS, submitted [arXiv:1211.6434] [Google Scholar]
 Stanek, R., Evrard, A. E., Böhringer, H., Schuecker, P., & Nord, B. 2006, ApJ, 648, 956 [NASA ADS] [CrossRef] [Google Scholar]
 Stanek, R., Rudd, D., & Evrard, A. E. 2009, MNRAS, 394, L11 [NASA ADS] [CrossRef] [Google Scholar]
 Stanek, R., Rasia, E., Evrard, A. E., Pearce, F., & Gazzola, L. 2010, ApJ, 715, 1508 [NASA ADS] [CrossRef] [Google Scholar]
 Taylor, A. N., & Kitching, T. D. 2010, MNRAS, 408, 865 [NASA ADS] [CrossRef] [Google Scholar]
 Tegmark, M., Taylor, A. N., & Heavens, A. F. 1997, ApJ, 480, 22 [NASA ADS] [CrossRef] [Google Scholar]
 The Dark Energy Survey Collaboration. 2005 [arXiv:astroph/0510346] [Google Scholar]
 Tinker, J. L., Weinberg, D. H., Zheng, Z., & Zehavi, I. 2005, ApJ, 631, 41 [NASA ADS] [CrossRef] [Google Scholar]
 Tinker, J., Kravtsov, A. V., Klypin, A., et al. 2008, ApJ, 688, 709 [NASA ADS] [CrossRef] [Google Scholar]
 Tinker, J. L., Robertson, B. E., Kravtsov, A. V., et al. 2010, ApJ, 724, 878 [NASA ADS] [CrossRef] [Google Scholar]
 van Daalen, M. P., Schaye, J., Booth, C. M., & DalZla Vecchia, C. 2011, MNRAS, 415, 3649 [NASA ADS] [CrossRef] [Google Scholar]
 Vikhlinin, A., Kravtsov, A. V., Burenin, R. A., et al. 2009, ApJ, 692, 1060 [NASA ADS] [CrossRef] [Google Scholar]
 Warren, M. S., Abazajian, K., Holz, D. E., & Teodoro, L. 2006, ApJ, 646, 881 [NASA ADS] [CrossRef] [Google Scholar]
 White, M., & Padmanabhan, N. 2009, MNRAS, 395, 2381 [NASA ADS] [CrossRef] [Google Scholar]
 Wu, H.Y., Zentner, A. R., & Wechsler, R. H. 2010, ApJ, 713, 856 [NASA ADS] [CrossRef] [Google Scholar]
Online material
Appendix A: The clustermass bias
The ratios r_{ν}(L) defined in Sect. 2.4.1 can be predicted under the assumption that, on large scales, dark matter halos of a given mass M are biased tracers of the underlying dark matter distribution. In the socalled local bias model, to zeroth order in perturbation theory (e.g., Cooray & Sheth 2002), this is expressed as P(k;M) = b^{2}(M)P_{mat}(k), where P_{mat}(k) denotes the power spectrum of the dark matter and b(M) is a scaleindependent halomass bias. Given a halo mass function n(M)dM (i.e., the number of dark matter halos with masses between M and M + dM per unit comoving volume) and a selection function (i.e., the probability of having a cluster with mass M given some selection criteria), the realspace marked power spectra can be written as (e.g., Cooray & Sheth 2002; Sheth 2005), where (A.1)and (A.2)is the effective clustermatter bias. For a given bin of Xray luminosity, the selection function φ(M,L) can be expressed as the average of the scaling relation given by Eq. (1) in that luminosity bin. The ratios r_{1, 2, 3}(L) in real space can therefore be interpreted as estimates of b(L)/b(L_{ref}), b_{w}(L)b(L) /(b(L_{ref})b_{w}(L_{ref})), and b_{w}(L)/b_{w}(L_{ref}) respectively. Also, the information contained in the ratio r_{4}(L) is the same as contained in the ratio r_{5}(L), since these are estimates of the ratio (b_{w}(L) /b(L))^{1/2} and b_{w}(L)/b(L) respectively. Accordingly, the luminosity power spectrum can be written as (A.3)from which the predictions for the ratios r_{6, 7}(L) can be readily obtained. According to Eq. (1), the moments of the luminosity L are linked to the scaling relation via . Therefore, the bias is directly sensitive to the mean of the scaling relation, yet indirectly (only through ) to the intrinsic scatter.
Fig. A.1 Ratio r_{3}(L) (top panels) defined in Eq. (7), and luminosity bias b(L) (bottom panels) obtained in the range 0.02 ≤ k/(h Mpc^{1}) ≤ 0.08. Results are shown in real (right panel) and redshift (left panel) space. For readability, we only show the standard deviation obtained from the Nbody simulations with shaded regions. The lines represent the predictions presented in Sect. 2.4.1 using expressions for the halomass bias as reported by different authors, MW: Mo & White (1996); ST: Sheth & Tormen (1999); T: Tinker et al. (2010); and P: Pillepich et al. (2010).

Open with DEXTER
The redshiftspace estimates of the ratios r_{ν}(L) can be obtained in a similar way. Under the planeparallel approximation, the largescale signal of the redshiftspace cluster power spectrum P^{s}(k;L) can be described by the socalled Kaiser effect (e.g., Kaiser 1987; Hamilton 1998) P^{s}(k;L) = (1 + 2β/3 + β^{2}/5)P(k;L), where and f ≡ dlnD(a)/dlna is the growth index (D(a) represents the growth factor) (e.g., Peebles 1980). Given the cosmology and redshift output of the LBASICC simulations that we used, f = 0.44. The Kaiser effect can be generalized to the marked power spectra (e.g., Skibba et al. 2006) as (A.4)and (A.5)where . We have checked whether these expressions describe the ratios r_{ν}(L). To this end, the halo abundance n(M) is taken to be described by the fitting formulae of Jenkins et al. (2001), which is suitable for simulations such as the LBASICC. A crucial step is to choose the halomass bias b(M). In Fig. A.1 we show predictions for the ratio r_{3}(L), obtained using some examples of prescriptions for this quantity: Mo & White (1996), Sheth & Tormen (1999), Tinker et al. (2010). and Pillepich et al. (2010). To witness the performance of these prescriptions, the bottom panels in Fig. A.1 show the luminosity bias obtained similar to what is described by Eq. (7), using the estimates of the matter power spectrum of the LBASICC II simulation. This figure shows that i) as established by a number of studies, a scaleindependent halomass bias is a fair modeling of the cluster power spectrum on large scales; ii) the Kaiser effect is a good description of the redshiftspace power spectra, at least within the range of masses and scales probed by our analysis (see, e.g., Bianchi et al. 2012, for a broader discussion on this subject); iii) when assessing the ability of a model to retrieve either cosmological or astrophysical information from one or twopoint statistics, extreme caution is required in view of the discrepancies observed between models and the simulations. In particular, more accurate models of halomass function and halomass bias are demanded, given the small statistical errors expected from forthcoming surveys (see, e.g., Cunha & Evrard 2010; Wu et al. 2010; Smith et al. 2012) with volumes comparable to that of the LBASICC simulation. The differences between the different fitting formulae presented in Fig. A.1 can be caused by several effects, namely, the difference cosmological models and/or parameters used in the Nbody simulations used to fit each of them, the characteristics of the haloidentification algorithm (which introduces systematic effects both in the mass function and the halomass bias), and the way the biases are measured (i.e, either from the correlation function, the power spectrum, or by means of countin cells experiments). It is beyond the scope of this work to analyze these differences in detail; however, we note that different fitting formulae can provide a good description of the measured luminosity bias at different ranges of Xray luminosity. In particular, the results from Tinker et al. (2010) generate a fair description for luminosities above ~3 × 10^{43} h^{2} erg s^{1}. Lower luminosities correspond to halos defined by a relatively low number of dark matter particles, where resolution effects can be relevant. Finally, iv) the discrepancies between the different prescription of halomass bias are slightly diminished when we work with estimates of relative biases instead of absolute biases.
Appendix B: Halo exclusion
Dark matter halos are not pointlike objects. As a consequence, the idea that their spatial distribution can be described as a Poissonpoint process drawn from a realization of an underlying continuous field with a positive correlation function (Peebles 1980) is, strictly speaking, not a realistic assumption. So far, a statistical description of halo distribution that takes their finite size into account is not fully accomplished. Instead, simple geometrical approaches have been developed to empirically model the exclusion effect within the context of the twopoint correlation function. Here we briefly illustrate how this model works. Assuming that we can assign a radius to each spherical halo, the correlation function can be written as (e.g., Porciani & Giavalisco 2002) (B.1)where , with ⟨RM ⟩ denoting the expected radius of a cluster with mass M. In this expression, b(M) denotes the darkmatter halo scaleindependent bias, B(r) denotes a possible scaledependency in the halomatter bias (e.g., Tinker et al. 2005), while ξ_{mat}(r) is the full nonlinear matter correlation function. For halos with masses within an infinitesimally narrow range, this expression predicts a sharp transition towards ξ_{h}(r) = −1 at a scale equal to twice the radius of the halo. This transition becomes smoother when halos with different masses (and thus sizes) are included. In Fourier space, the exclusion is translated to a lack of power on small scales, which goes counter to the effect of the nonlinear clustering. Since the exclusion effect is more evident when more massive halos are considered, such lack of power displays a clear trend with the characteristic mass (or Xray luminosity) of the sample. The halo power spectrum from Eq. (B.1) can be separated into three components: (B.2)The first term is the halo power spectrum with a scaleindependent bias. The second term is the Fourier transform of the −1 in Eq. (B.1), where j_{1}(x) denotes the spherical Bessel function of first order. The third contribution can be written as (B.3)
where the kernel is given by , with (B.4)and (B.5)In the limit (i.e., no halo exclusion), both the second term on the right hand side of Eq. (B.3) and the kernel G_{2} go to zero. In that case a nonlinear contribution to the cluster power spectrum relies on the behavior of the scaledependent halomass bias B(r). In the limit of an homogeneous distribution, we end up with a power spectrum of the form . Thus, to obtain an unbiased estimation of the cluster power spectrum (of spherically symmetric nonoverlapping clusters), this last term would need to be subtracted from the raw estimates (as in Eq. (3)), together with the white shot noise . The combination of these two effects can be regarded as scaledependent shotnoise.
Fig. B.1 Halo exclusion: ratio between the measured cluster power spectrum described in Sect. 2.3 and the expected linear cluster power spectrum b^{2}(L)P_{mat}(k), for clusters in four different bins of Xray luminosity characterized by a luminosity L_{i}, with L_{3} > L_{2} > L_{1}. The luminosity bias b^{2}(L) is that measured from the simulations. The shaded regions and the solid line represent the standard deviation and the mean, respectively, obtained from the Nbody simulations.

Open with DEXTER
Figure B.1 depicts the halo exclusion effect as measured from the ensemble of halos presented in Sect. 2.1. As pointed out above, the strength of the effect scales with the luminosities (or masses) of the objects considered in the analysis. Therefore, this signal can be used to retrieve information on the underlying scaling relation (e.g., massXray luminosity when analyzing cluster samples or the massnumber of hosted galaxies when analyzing a galaxy redshift survey) (e.g., Porciani & Giavalisco 2002). Finally, the exclusion effect is attenuated when observed in redshift space, simply because pairs of halos are observed to be closer due to their peculiar velocities. For instance, exploring the power spectrum obtained from the full luminosity sample shows that in real space exclusion sets in at k ~ 0.2 h Mpc^{1}, while this value shifts to ~0.3 h Mpc^{1} in redshift space.
All Tables
All Figures
Fig. 1 Mean power spectra , and (defined in Sect. 2.3) obtained from the ensemble of Nbody simulations for galaxy clusters within the full luminosity range as described in the text. The 60% of the Nyquist frequency is marked with an arrow. The shaded regions denote the standard deviation obtained from the ensemble of Nbody simulations.

Open with DEXTER
In the text
Fig. 2 Ratio between the spectra and to the cluster power spectrum , shown in real space. The horizontal lines show the predictions presented in Appendix A. The shaded regions denote the standard deviation obtained from the ensemble of Nbody simulations. The inset shows a closeup of the ratio , showing a clear scaledependent trend from scales k ≳ 0.06 h Mpc^{1}.

Open with DEXTER
In the text
Fig. 3 Joint 1σ error ellipses for the parameters { α,γ,σ } of the scaling relation , obtained from the Fishermatrix analysis in real (shaded area) and redshift (dotted lines contours) space, using the set r_{ν = 1, ··· , 7}(L) defined in Eq. (7) as observables. The small filled contours represent the results using the XLF.

Open with DEXTER
In the text
Fig. 4 Joint 1σ error ellipses for the parameters { α,γ,σ } of the scaling relation , obtained from the Fishermatrix analysis of power spectra P(k), and P_{L}(k) defined in Sect. 2.3. Results are shown in real (shaded area) and redshift (dotted lines) space. The estimates of these spectra are obtained within the fullluminosity range and using Fourier modes in the interval 0.02 < k/(h Mpc^{1}) < 0.2. The solid contours represent the results using the XLF. The right block of panels shows the results using after marginalizing over the amplitude of the power spectra. The left block shows the results using the full shape. The color of the first row is meant to highlight the results obtained with the luminosity power spectrum.

Open with DEXTER
In the text
Fig. 5 FoM obtained from the 1σ error ellipsoids of the parameters of the scaling relation as a function of the maximum wavenumber k_{max}. The FoM shown correspond to the information contained in the full shape of the clustering probes.

Open with DEXTER
In the text
Fig. 6 FoMs obtained from the 1σ error ellipses of each pair of parameters of the scaling relation, taken from the different observables μ_{j} defined in Eq. (8). By FoM we denote the figure of merit computed as the volume of the 3dimensional 68% error ellipsoid. To facilitate the understanding of this figure, the dark gray, gray and light gray areas denote observables accounting for the amplitude, the shape and the full shape of power spectra respectively. Results are shown in real space. Noticeably, the luminosity power spectrum P_{L} provides more information regarding the scaling relation than the luminosityweighted spectra, and display a total FoM that is ~10^{2} times that of the unweighted power spectrum. We show the estimates derived from the luminosity power spectrum , in order to emphasize how high FoM can be obtained when no shotnoise correction is spuriously implemented in the measurements.

Open with DEXTER
In the text
Fig. A.1 Ratio r_{3}(L) (top panels) defined in Eq. (7), and luminosity bias b(L) (bottom panels) obtained in the range 0.02 ≤ k/(h Mpc^{1}) ≤ 0.08. Results are shown in real (right panel) and redshift (left panel) space. For readability, we only show the standard deviation obtained from the Nbody simulations with shaded regions. The lines represent the predictions presented in Sect. 2.4.1 using expressions for the halomass bias as reported by different authors, MW: Mo & White (1996); ST: Sheth & Tormen (1999); T: Tinker et al. (2010); and P: Pillepich et al. (2010).

Open with DEXTER
In the text
Fig. B.1 Halo exclusion: ratio between the measured cluster power spectrum described in Sect. 2.3 and the expected linear cluster power spectrum b^{2}(L)P_{mat}(k), for clusters in four different bins of Xray luminosity characterized by a luminosity L_{i}, with L_{3} > L_{2} > L_{1}. The luminosity bias b^{2}(L) is that measured from the simulations. The shaded regions and the solid line represent the standard deviation and the mean, respectively, obtained from the Nbody simulations.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
