1. Introduction

Supermassive black hole (SMBH) binaries (SMBHBs) are thought to be common in the Universe as a natural outcome of galaxy mergers (Begelman et al. 1980). Such systems are among the loudest sources of gravitational waves (GWs) potentially detectable with current pulsar timing array campaigns (Verbiest et al. 2016; Agazie et al. 2024) and future space-based GW interferometers (e.g., LISA, Amaro-Seoane et al. 2017, 2023). However, theoretical expectations on the rates of detectable binary mergers are still highly uncertain; such uncertainties could in principle be reduced through the electromagnetic identification of bona fide SMBHBs (De Rosa et al. 2019).

Unfortunately, several challenges complicate the unambiguous identification of these sources and, to date, no definite observational confirmation of any SMBHB has been made yet. The only binary candidate, spatially resolved through very long baseline radio interferometry observations, is the radio galaxy 0402+379 (Rodriguez et al. 2009; Burke-Spolaor 2011) showing two flat-spectrum radio cores with a projected separation of ≈7 pc (see also Kharb et al. 2017 for a 0.35 pc binary in the spiral galaxy NGC 7674). At smaller separations, unresolvable with current facilities except for the closest active galactic nuclei (AGNs), SMBHBs have been searched-for either through photometric variability in their light curve (Valtonen et al. 2008; Ackermann et al. 2015; Graham et al. 2015a; Li et al. 2016, 2019; Charisi et al. 2016; Sandrinelli et al. 2016, 2018; Severgnini et al. 2018; Liu et al. 2019; Serafinelli et al. 2020; Chen et al. 2020; Covino et al. 2020) or by looking for peculiar spectral features (Tsalmantza et al. 2011; Eracleous et al. 2012; Ju et al. 2013; Shen et al. 2013; Wang et al. 2017).

If the two black holes are at a separation such that at least one of them still retains its own broad-line region (BLR), then we expect broad emission lines (BELs) to be shifted in frequency with respect to their respective narrow emission lines (NELs) and to evolve in time over a binary orbital period. Unfortunately, asymmetric emission line profiles could also be explained by eccentric BLRs (Eracleous et al. 1997), as well as circular BLRs featuring deviations from an axisymmetric emissivity profile; for example, as hot spots (Jovanović et al. 2010) or spiral patterns (Storchi-Bergmann et al. 2017). In addition, even symmetric BLRs might appear as asymmetric in observations in the presence of partial obscuration from dust (Gaskell & Harrington 2018), or if the BLR is attached to a recoiling SMBH (Volonteri & Madau 2008). In these cases, the obvious way of checking for the presence of a SMBHB would be to measure the expected drift in wavelengths by observing the candidate over a binary orbital period1.

At smaller separations where the BLR is either truncated (Montuori et al. 2011) or shared by both SMBHs, photometric variability is still expected over orbital timescales due to periodic fueling from the circumbinary material (e.g., Hayasaki et al. 2008; Tiede et al. 2024), Doppler boosted (DB) emission (D’Orazio et al. 2015), or periodic gravitational lensing from the companion of the active component of the SMBHB (D’Orazio & Di Stefano 2018; Davelaar & Haiman 2022a,b). Even in these cases, alternative interpretations have been proposed for quasi-periodically modulated sources, either assuming Lense-Thirring driven precessing jets (Sandrinelli et al. 2016; Britzen et al. 2018) or only apparent (quasi-)periodicities due to the effect of correlated noise together with the intrinsic difficulties affecting the analysis of short (compared to the searched-for periodicities) time series (Vaughan et al. 2016; Liu et al. 2018; Covino et al. 2019).

One of the strongest candidate SMBHBs identified through periodicity in its light curve is PG 1302−102; a quasar with a median V-band magnitude of 15.0 and a redshift of 0.2784 showing variability in multiple bands (Liu et al. 2024) as well as the presence of BELs (Graham et al. 2015b). This object has been observed across multiple wavelengths, including optical (Graham et al. 2015b), ultraviolet (D’Orazio et al. 2015; Xin et al. 2020), infrared (Jun et al. 2015), and X-rays (Saade et al. 2024)2. The modulation of PG 1302−102 has been explained through the DB emission of an unequal-mass binary: when the secondary black hole accretes matter onto a mini-disk, the emission is DB due to the relativistic3 orbital motion of the secondary. PG 1302−102 also exemplifies the well-known challenge of determining the intrinsic nature of a quasar based on the observation of a limited number of periodic cycles (Covino et al. 2019); indeed, its true nature remains a topic of debate. For instance, Vaughan et al. (2016) argue that the light curve observed in PG 1302−102 is better described with a damped random walk model (Kelly et al. 2009) rather than a sinusoid with uncorrelated noise (see also Graham et al. 2015b). This hypothesis is supported by the fact that PG 1302−102 was selected as the most periodic source from a sample of ∼250 000 light curves. With such ratios (i.e., 1 in 250 000), it is likely that one will find some quasar that appears periodic purely by coincidence. Similarly, Liu et al. (2018) measured a decreased evidence for periodicity when additional data were included in the modeling. Conversely, Zhu & Thrane (2020) show that if correlated noise is combined with sinusoidal variation then quasi-periodic oscillation is the most favored explanation for PG 1302−102 variability.

In this paper, we aim to further clarify the nature of PG 1302−102. We apply a fully Bayesian approach to the highest-resolution spectrum of this source, observed using the Echelle SPectrograph for Rocky Exoplanets and Stable Spectroscopic Observations (ESPRESSO, Pepe et al. 2021) on the Very Large Telescope (VLT). Specifically, we present an improved characterization of the broad and narrow line region properties of PG 1302−102, by examing the emission lines for substructures, such as nonsymmetric, redshifted, and blueshifted components.

This paper is organized as follows: in Sect. 2 we describe the collected data and the reduction process; in Sect. 3 we detail our procedure for determining the best description of the spectrum also providing a physically motivated interpretation for the BLR of PG 1302−102; in Sect. 4 we discuss the implication of our findings in relation with the putative binary nature of PG 1302−102; and, finally, in Sect. 5 we provide a short summary of our work.

2. Data

PG 1302−102 was observed with VLT ESPRESSO in early 2018, during the instrument’s third commissioning run. Three exposures of 1200 s each were taken on February 27, February 28, and March 3. The instrument was operated in SINGLEHR mode, meaning that it was accepting light from VLT Unit Telescope (UT) at a time (respectively, UT2, UT1, and UT3 for the three exposures), using the 140 μm fibre for high resolution. The detector was binned by 2 in the spatial direction and by 1 in the spectral direction, achieving a resolving power of approximately 138 000.

The data were reduced with the official pipeline released by ESO4, version 1.3.2. Standard calibrations were used to remove the instrumental signature and calibrate the spectra into physical units. Wavelength calibration was performed using the instrument built-in Fabry-Pérot interferometer, with a ThAr lamp acting as an absolute reference. Flux calibration was performed with the aid of two spectro-photometric standard stars (HR 4963 for February 27 and March 3, HR 5501 for March 3). The final products of the pipelines were three reduced (flat-fielded, sky-subtracted, wavelength- and flux-calibrated) spectra, provided both in order-by-order and merged format.

To perform the analysis, we coadded the three reduced spectra using the ESPRESSO Data Analysis Software (DAS)5, version 1.04. We chose the order-by-order format to preserve the original detector binning throughout the coaddition procedure (merged spectra are already rebinned on a fixed wavelength grid). The coaddition was performed with the approach described in Cupani et al. (2016), equalizing the flux from the different exposures and appropriately weighting the contributions to each bin of the final spectrum. In what follows, unless otherwise specified, all quantities should be considered to be in the rest frame system.

3. Modeling of the spectrum

Here, we describe the specific steps needed to obtain an accurate model of the spectrum of PG 1302−102. More precisely, in Sect. 3.1, we present the scenario of a BLR orbiting in circular motion around a common center of mass of a putative SMBHB. Such a model, in a simplified configuration, can be represented by a Gaussian broad emission profile shifted in wavelength with respect to the rest frame emission of its narrow line. In Sect. 3.2, we propose an alternative disk-like BRL model whose emissivity distribution is distorted by the presence of an azimuthal perturbation. In this scenario, the resulting emission features are not necessarily Gaussian and can trace the presence of bulk motion, possibly associated with the presence of a SMBHB, in the BLR.

3.1. Multi-Gaussian fit

In this section, we focus on the identification of substructures and asymmetries in the BELs and NELs of the spectrum of PG 1302−102, which may be an indication of the presence of a SMBHB. More specifically, we aim at identifying in the emission lines one or multiple broad components shifted in wavelength that could be associated with the orbital motion of a SMBHB.

In Fig. 1, we show the spectrum considered for the analysis. We selected the rest-frame spectral region from 4150 Å to 5325 Å; such choice balances the need to maximize the amount of information extracted from the data with the computational performance of the fit6. The selected region is large enough to include the Hγ and Hβ BELs and the [OIII] forbidden NELs. Increasing the region further would not have led to significant changes in the extracted best-fit parameters, since it already includes the most prominent emission lines in the wavelength range covered by ESPRESSO for this source.

thumbnail Fig. 1.

Data considered in the analysis. In the panel, we show the flux normalized to a reference flux, F0, as a function of the rest-frame wavelength of the spectrum of PG 1302−102 at the ESPRESSO native resolution.

The full spectrum is modeled as the superposition of different components whose free parameters are constrained by fitting the data with a nested sampling algorithm (Skilling 2004). This approach was chosen since it allows us to measure the Bayesian evidence (Z)7, which we use to compare different models and assess the optimal number of components to be included in the fit. More specifically, the search for the optimal model for the spectrum of PG 1302−102 involved a step-by-step process where models of increasing complexity were compared with each other. This approach automatically prevents overfitting as the Bayesian evidence, being an integral over the whole parameter space, is penalized for models with a larger number of parameters. The initial model consisted of a power-law continuum along with broad and narrow Gaussian emission lines centered at the expected redshift of the source. From this baseline, we included additional emission components and allowed the already included BELs to be shifted in wavelength. At each stage, we checked that any proposed modification was statistically justified by an increase in the Bayesian evidence. The fiducial model (hereinafter Model 1) was selected based on the highest Bayesian evidence.

Model 1 accounts for a smooth broken power law continuum parameterized as:

F ( λ ) = A cont ( λ λ cont ) α cont [ 1 + ( λ λ cont ) β cont ] γ cont , $$ \begin{aligned} F(\lambda ) = A_{\mathrm{cont}}\left(\frac{\lambda }{\lambda _{\mathrm{cont}}}\right)^{\alpha _{\mathrm{cont}}}\left[1+\left(\frac{\lambda }{\lambda _{\mathrm{cont}}}\right)^{\beta _{\mathrm{cont}}}\right]^{\gamma _{\mathrm{cont}}}, \end{aligned} $$(1)

where Acont is the normalization, λcont is the wavelength break and, αcont is the slope at λ ≪ λcont, while βcont and γcont define the slope at λ ≫ λcont and ensure a smooth transition at λ ≃ λcont. The modeling of all emission lines (i.e., Hγ, Hβ, and the [OIII]8 with the Fe contribution discussed separately) includes a narrow Gaussian component with shared parameters for redshift (z) and full width at half maximum (FWHM). These common parameters are applied consistently across the different lines in terms of their velocities. Additionally, we included a broad Gaussian emission for the Hβ and Hγ whose FWHMB have been assumed to be the same. Moreover, for both emission lines, we accounted for a possible redshift in wavelength (see “Prior range” in Table 1) with respect to their associated narrow component. This choice was necessary to obtain a reasonably good fit of the spectrum and was also supported by the increase in the Bayesian evidence compared to a model with a fixed centroid. For all [OIII] and Balmer NELs, we included an additional blueshifted Gaussian component, as a single narrow Gaussian emission profile could not adequately fit the data. The additional Gaussians share the same wavelength shift (ΔμO) and width (FWHMO) for each line. This choice was again driven by the observed increase in the Bayesian evidence when including such additional components. As we shall further discuss in this section and in Sect. 4, this strongly suggests the presence of an outflow in the narrow line regions of PG 1302−102.

Table 1.

Summary of the model parameters for the multi-Gaussian fit of the spectrum.

The considered region of the spectrum contains a contribution from the Fe emission lines (Boroson & Green 1992; Véron-Cetty et al. 2004; Tsuzuki et al. 2006). We accounted for the Fe contribution following Calderone et al. (2017). More precisely, we consider all the BELs and NELs listed in Véron-Cetty et al. (2004) and, for each of these lines we included a Gaussian component. All the Fe NELs have the same redshift and FWHM as the narrow components of the Hγ, Hβ, and [OIII]. Similarly, we assume the Fe BELs to have the same FWHM (FWHMB) and shift in wavelength (ΔμB) as the broad components of the Hγ and Hβ.

Each Gaussian has a different amplitude parameter Aj (see Table 1 for the definition of the different subscripts) defined as the peak of each Gaussian relative to a common reference flux9. The amplitude ratio between the [OIII]λ4959 Å and the [OIII]λ5007 Å is assumed to be 1:3 (Osterbrock & Ferland 2006), while the ratio of the individual Fe lines is taken from Véron-Cetty et al. (2004). We note that our approach is one of the most general in treating the Fe contribution in type I AGNs; we allow for independent broad and narrow emissions across all expected wavelengths without constraining the fit to any specific template. To check if our results depend on the specific method adopted to model the Fe contribution, we compared it against other approaches (e.g., Boroson & Green 1992; Tsuzuki et al. 2006; Marziani et al. 2009) where the Fe contribution is modeled by applying a Gaussian kernel on a reference template. We find that the considered templates were statistically unfavored and that the estimates on the other parameters were not significantly affected by the specific method adopted.

Finally, Model 1 includes an additional “very” broad component that is also significantly redshifted if it is associated with the Hβ emission line (see the discussion below). Such component is described through a Gaussian profile with its own amplitude (AVB), wavelength shift with respect to the Hβ narrow line (ΔμVB), and FWHM (FWHMVB) parameters. As we discuss below, the same component is not statistically required, and therefore not included in Model 1 for the Hγ. Model 2 is a replica of Model 1, but for the fact that it does not include the additional very broad component.

We report in Table 1 a summary of the model parameters, their prior10 and the best-fit estimates from Model 1 and Model 2. The last row of Table 1 reports the evidence of the two models that points toward a decisive preference (according to Jeffreys 1939) for Model 1 against Model 2 (Δlog Z = 1209). The most significant differences among the estimated parameters of the two models regard the continuum and the broad component of the Balmer line. The differences in the continuum parameters might be explained as a consequence of the relatively small wavelength range considered. Although the parameters defining the continuum of Model 1 and Model 2 are quite different, still, the predicted continuum flux is almost indistinguishable between the two cases in the considered wavelength range. On the other hand, the difference in the broad Balmer lines is mainly due to the inclusion of the very broad Gaussian component in Model 1, which reduces ΔμB (from ≃12 Å to ≃7 Å in the case of the Hβ) compared to Model 2. Still, in both cases, the presence of asymmetry towards red wavelengths remains evident for the Balmer lines.

Fig. 2 shows the result of the fit of Model 1 against the ESPRESSO data (the results obtained from Model 2 are reported in Appendix A). The top panel shows the data in gray with a Gaussian smoothing (σ ≃ 0.07 Å) and the best-fit model with a black line. The contributions of the continuum and each individual emission line to the overall spectrum are highlighted in different colors. The bottom panel shows the residuals defined as the difference between the model and the data divided by the error where the typical error on the data is ≃0.045 in units of F0. Overall, Model 1 reproduces the data well, as can be deduced by the lack of strong systematics in the residuals and the agreement observed between the smoothed spectra.

thumbnail Fig. 2.

Best-fit result of Model 1 on the ESPRESSO data. The top panel shows the data in gray smoothed with a Gaussian Kernel (σ ≃ 0.07 Å), the best-fit model (black line), and all the emission components identified by different colors: Hγ in gold, Hβ in red, [OIII] in cyan, Fe in light-blue, very broad Hβ in brown, and the continuum in dark blue. The vertical dashed lines indicate, from left to right, the rest-frame emission wavelength of the Hγ, [OIII]λ4363.2 Å, Hβ, and [OIII]λ4958.9 Å, λ5006.8 Å. The bottom panel represents the residuals defined as (data-model)/error, and the horizontal dashed black line at the zero level of residuals is plotted to guide the eyes.

The superposition of the different Gaussian contributions results in emission profiles that deviate from a symmetric shape. More specifically, the BELs of the Hγ, Hβ are clearly redshifted (see ΔμB ≃ 440 km/s in Table 1). Such an asymmetric shape of the emission profile was already observed in Graham et al. (2015b) although only for the Hβ and the Hα11 and not for the Hγ. In this work, given the high resolution of the ESPRESSO data, we confirm the presence of such a redshifted component and characterize its features with higher precision. Moreover, we also detect, for the first time, the presence of such redshifted asymmetry in the Hγ emission line. Given our results and the considerations made in Graham et al. (2015b) about the presence of a similar redshifted component in the Hα, we argue that such behavior could be common among all the Balmer lines.

Our fiducial model indicates the presence of an additional broad (FWHMVB ≃ 12 600 km/s) Gaussian component that appears to be very redshifted (ΔμVB ≃ 4000 km/s) if associated to the Hβ emission. The improvements in the modeling when including such component are quite significant as can be deduced by comparing the residual between Figs. 2 and A.1 in the region comprising the Hβ and [OIII] doublet and by the increase in the Bayesian evidence. This is the first time such a broad and extremely redshifted component has been detected in PG 1302−102. However, it seems that a non-negligible fraction of quasars, with a spectrum similar to that of PG 1302−102 (i.e., asymmetric and redshifted Hβ emission line), shows the presence of such feature (e.g., Sulentic et al. 2002; Marziani et al. 2009). The physical origins of this peculiar component are still debated (see Sect. 4 for a more detailed discussion), and its inclusion is usually justified on empirical grounds, as it significantly improves the fit residuals. If such a component is connected to a process in the BLR, it might be reasonable to expect its presence to be ubiquitous in all the Balmer lines. We attempted fitting for an additional very broad and very redshifted component also for the Hγ emission line without finding any increase in the Bayesian evidence and, therefore rejecting the detection of such a component in the Hγ12.

The additional Gaussian component included in the modeling of [OIII], Hγ, and Hβ NELs is shifted toward bluer wavelengths, (ΔμO ≃ −340 km/s) and is relatively broad (FWHMO ≃ 1260 km/s). Given the observed properties, we interpret it as the presence of an ionized gas outflow affecting the NLR of PG 1302−102. We stress that, this is the first detection of a possible outflow component in PG 1302−102, which has only been made possible thanks to the high resolution of ESPRESSO.

From the BELs parameter (i.e., FWHMB), assuming the BLR being virialized and the broad component of the Balmer lines tracing the gravitational potential dominated by a SMBH, we can estimate its mass (MBH) through single epoch method (see Table 4 of Shen et al. 2024):

log 10 ( M BH M ⊙ ) = 0.85 + 0.5 log 10 ( L 5100 10 44 erg / s ) + 2.0 log 10 ( FWHM km / s ) , $$ \begin{aligned} \log _{10}{\left(\frac{M_{\mathrm{BH}}}{M_{\odot }}\right)} =&0.85+ 0.5\log _{10}\left({\frac{L_{5100}}{10^{44}\,\mathrm{erg/s}}}\right)\nonumber \\&+2.0\log _{10}{\left(\frac{\mathrm{FWHM}}{\mathrm{km/s}}\right)}, \end{aligned} $$(2)

where L5100 is the luminosity at λ = 5100 Å and the FWHM is the full width at half maximum of the broad Hβ emission line. If relying on the estimates from Model 1, using L5100 = (3.66 ± 0.03)×1045 erg/s and FWHM = FWHMB = 3972 ± 18 km/s, we get log10MBH/M⊙ = 8.83 ± 0.46, where most of the error comes from propagating the scatter of Eq. (2). This number is in line with previously reported estimation (Graham et al. 2015b).

3.2. Single disky broad-line region with a spiral perturbation

BLRs are often considered spherically symmetric and virialized. However, multiple observational results, mostly from reverberation mapping campaigns, have proven this is not always the case (Eracleous et al. 1995; Bentz et al. 2010; Grier et al. 2017). This is especially true when emission lines deviate from pure Gaussianity (Zastrocky et al. 2024) as this is often tracing the presence of sub-structures in the BLR clouds distribution or deviations from virial equilibrium (Pancoast et al. 2014). Even though the structure of the BLR has been typically investigated with velocity-resolved reverberation mapping, here we follow an approach closer to that presented in Raimundo et al. (2020) on single epoch observations. Similarly to what is done in that work, we employ a nested sampling approach for the parameter estimation; however, instead of focusing on the BLR kinematics, we consider asymmetric deviation in its emissivity. Our semi-analytic model is based on Storchi-Bergmann et al. (2003) where asymmetric emission lines are modeled by introducing a spiral perturbation in a disk-like BLR rotating in circular Keplerian motion around its SMBH. Such kind of perturbations are expected to arise in the self-gravitating part of accretion disks (Wang et al. 2022).

In what follows, we summarize the main assumptions of the model “spiral model” hereinafter that is described in detail in Sottocorno et al. (in prep.). The BLR is assumed to be on a razor-thin disk-like configuration whose axial symmetry is broken due to the presence of a spiral perturbation. Under these assumptions, the BLR emissivity profile reads:

ϵ ( ξ , ϕ ) = ξ − 1 · exp [ − ( ξ − ξ c ) 2 2 σ ξ c 2 ] × { 1 + A 2 exp [ − 4 log 2 δ 2 ( ϕ − ψ 0 ) 2 ] + A 2 exp [ − 4 log 2 δ 2 ( 2 π − ϕ + ψ 0 ) 2 ] } , $$ \begin{aligned} \epsilon (\xi , \phi ) =&\xi ^{-1}\cdot \exp \left[-\frac{(\xi -\xi _c)^2}{2\sigma _{\xi _c}^2}\right]\nonumber \\&\times \Biggl \{1 +\frac{A}{2}\exp \left[-\frac{4\log {2}}{\delta ^2}(\phi - \psi _0)^2\right]\nonumber \\&+\frac{A}{2}\exp \left[-\frac{4\log {2}}{\delta ^2}(2\pi - \phi + \psi _0)^2\right]\Biggr \}, \end{aligned} $$(3)

where ξ is the cylindrical radius normalized to the gravitational radius Rg = GMBH/c2, and ϕ is the azimuthal angle. ξc and σξc are the radial position and the extent of the bulk of the emissivity profile respectively, while A and δ define the relative intensity of the spiral perturbation with respect to the underground Gaussian emissivity and the azimuthal width of the spiral, respectively. Finally, ϕ − ψ0 denotes the azimuthal distance from the ridge of the spiral arm, where ψ0 = ϕ0 + log10(ξ/ξsp)/tanp. Here ϕ0 is the initial angular position of the spiral at the innermost radius of the spiral ξsp, while p is the spiral pitch angle.

The emissivity profile of Eq. (3) differs from that assumed by Storchi-Bergmann et al. (2003) for a Gaussian multiplicative factor in the radial dependence of the emissivity. This choice ensures that the bulk of the BLR emissivity is localized close to the radius predicted by the luminosity-radius relation (Bentz et al. 2009; Shen et al. 2024).

The emission line profiles of the BLR are the emissivity-weighted sum of the contribution coming from each resolution element of the BLR scaled by a luminosity normalization parameter LHβ (for the Hβ) and LHγ (for the Hγ). We assume each resolution element to emit as a Gaussian centered at the Hβ (or Hγ) Doppler-shifted wavelength and whose width is regulated by a broadening parameter, σλ. The Doppler shift of each resolution element is computed by assuming the BLR is inclined by an angle, i, with respect to line-of-sight.

A summary of the model parameters together with the assumed priors and the best-fit parameters is reported in Table 2. We assumed either uniform or log-uniform priors for most of the parameters, except for the inclination angle which follows a uniform distribution for sin i. We allowed a maximum inclination angle of π/4 since for a higher inclination angle, we do not expect to observe BELs due to the obscuration from the dusty torus. Moreover, we assume the BLR extending between 200 and 18 000 gravitational radii, which, in the case of a 108.8 M⊙ BH, becomes from ≃0.006 pc to ≃0.58 pc. This number must be considered as an order of magnitude estimate of the BLR size since the gravitational radius is affected by the error propagation on the BH mass. Still, since the spiral model does not explicitly depend on the BH mass, the results regarding the appearance of PG 1302−102 BLR will remain unchanged. Finally, since the Hβ and Hγ emission line might not necessarily be localized at the same distance from the SMBH and subject to the same dynamics (Kuhn et al. 2024), we included different radial lengths, widths, and broadening parameters for the two lines.

Table 2.

Summary of the spiral model parameters.

The spiral model presented here does not account for anything else besides a broad emission component at a chosen reference wavelength (the Hβ and Hγ in our case). For this reason, in order to apply such a model directly to the spectrum presented in Fig. 1, we must account for all the sources of emission that are not associated with a broad component (“background model” hereinafter). Since the spiral model has a higher computational cost, to limit the number of iterations before reaching convergence we fixed the background model to the best fit obtained in Model 1 excluding the broad Gaussian contribution associated with the Hβ, Hγ, and the very broad and redshifted component. Even with this approximation the overall parameter estimation required more than a week13 before reaching convergence. Therefore, in order to obtain a complete parameter estimation without excluding any data14 in a reasonable amount of time, we followed the approach outlined in Rigamonti et al. (2022, 2023), implementing a GPU parallelization strategy for a much faster (few hundred times) computation of the likelihood function.

The top panel of Fig. 3 shows the best-fit spiral model in black (see Table 2 for the estimated parameters) on top of the ESPRESSO data in gray. The gold line refers to the broad emission from the spiral BLR, while all the other colors refer to the components of the background model that have been taken from Model 1. The bottom panel represents the residuals defined as (data-model)/error. Compared to Model 1, the spiral model provides a better fit to the data, reducing the residuals both in the region dominated by the Hβ and the Hγ. Notably, the spiral model is able to account for the excess at λ ≃ 5000 Å giving a physical interpretation to the very broad and very redshifted component included in Model 1. The same model, without changing the overall geometrical structure15 of the BLR, improved the fit of the Hγ emission (see Sect. 4 for a more detailed discussion). Notably, even though we did not impose any prior relating the scale radius, width, and broadening of the Hβ and Hγ we found quite similar parameters. This suggests that the two emission regions, and possibly all the Balmer lines, share similar dynamics (FWHMHβ ≃ FWHMHγ) and are spatially coherent (ξc, Hβ ≃ ξc, Hγ), with the Hγ emission region being slightly more compact than the Hβ (σξc, Hβ ≳ σξc, Hγ).

thumbnail Fig. 3.

Best-fit result of the spiral model on the ESPRESSO data. The top panel shows the data in gray smoothed with a Gaussian Kernel (σ ≃ 0.07 Å), the best-fit model in black, the spiral model in gold, and all the emission components of the background model identified by different colors: Hγ in brown, Hβ in red, [OIII] in cyan, Fe in light-blue and the continuum in dark blue. The vertical dashed lines indicate, from left to right, the rest-frame emission wavelength of the Hγ, [OIII]λ4363.2 Å, Hβ, and [OIII]λ4958.9 Å, λ5006.8 Å. The bottom panel represents the residuals defined as (data-model)/error, the horizontal dashed black line at the zero level of residuals is plotted to guide the eyes.

The specific features of the resulting emission profile can be better understood by inspecting Fig. 4, where we show the projected emissivity distribution of the Hβ (see Fig. B.1 for the Hγ) and the map of the BLR Doppler shift. The left column shows the projected emissivity profile together with a zoomed version in the central region. The emissivity steeply decreases after the first 1000 gravitational radii as a consequence of the exponential cut-off and the ξ−1 decline. Interestingly, the spiral perturbation is extremely thin in terms of azimuthal width (δ = 0.0085) although very intense (log10A = 4.22) suggesting a strong perturbation of the BLR compared to the underlying disk. The right side of the plot shows the Doppler shift of each BLR element, which, as is expected, decreases following the Keplerian law. The spiral perturbation encompasses the region of the BLR that has a positive Doppler shift, explaining why the emission profile is redshifted. The innermost region, characterized by the highest Doppler factor but lower flux16, is responsible for modeling the excess observer at λ ≃ 5000 Å. Conversely, the emissivity at larger radii, where the Doppler shift is less significant and the flux emitted from the perturbation becomes less important compared to that from the BLR disk, accounts for the shape of the emission around the bulk of the line (i.e., λ ≃ 4861 Å).

thumbnail Fig. 4.

Projected Hβ emission and Doppler shift of the spiral BLR best-fit. The top left panel is the projected BLR emissivity normalized to the maximum emissivity for the Hβ, while the right top panel represents the Doppler shift of each BLR element. The bottom panels show a zoom of the emissivity (left) and Doppler shift (right) on the central region of the BLR.

4. Discussion

The ESPRESSO spectrum of PG 1302−102 clearly revealed the presence of asymmetric emission profiles (in this case skewed toward redder wavelengths) for the broad component of the Balmer lines. This feature was already detected in previous works (e.g., Boroson & Green 1992; Jackson et al. 1992; Graham et al. 2015b) although at a much lower spectral resolution compared to the ESPRESSO data presented here. Also, we detected an excess at λ ≃ 5000 Å possibly associated with a very redshifted and very broad component originating from the Hβ.

The presence of asymmetric BELs has often been associated with the existence of a SMBHB; this hypothesis is particularly intriguing in the case of PG 1302−102, which has already been identified as a candidate SMBHB due to the modulation in its optical light curve (Graham et al. 2015b). As was discussed in Sect. 1, the asymmetric emission profile of a SMBHB can result from the orbital motion of two black holes. This occurs when the separation between the black holes is large enough for at least one to retain its own BLR. To satisfy this condition the BLR should not cross the Hill radius of the black hole17. The obvious way to test this hypothesis would be to observe, on an orbital timescale (i.e., ≃5.5 ± 0.15 yr for PG 1302−102, Zhu & Thrane 2020), the expected Doppler drift in the BEL profiles (Popović 2012). Optical spectra of PG 1302−102 taken at different times are already available (Boroson & Green 1992; Graham et al. 2015b) possibly allowing us to check if a wavelength shift over 5 years is present. However, the spectrum presented in Graham et al. (2015b) was taken in April 2014, while ours was during March 2018, giving a time difference too close to the binary orbital period. Similarly, the spectrum presented in Boroson & Green (1992) was taken in April 1990, which, assuming the 5.5 year period of the binary, would be close to exactly 5 periods before our observation. Also, 18 optical spectra of PG 1302−102 were taken from January to June 1990 by Jackson et al. (1992); even in that case no variability was observed in the Hβ emission line. Still, we have analyzed the spectra presented in Boroson & Green (1992) (the only one publicly available) without finding statistically meaningful differences in the emission profile. The error on the estimated ΔμB was large enough to be consistent both with the presence of the Doppler shift reported in Table 1 or with zero shift. We do not exclude this behavior from being caused by the low resolution and low S/N of the data.

In the case of PG 1302−102, it would be tempting to compare the periodicity of the light curve (i.e., ≃5.5 ± 0.15 yr, Zhu & Thrane 2020) with the observed shift in the Balmer BELs (see Fig. 2). In the case of the less redshifted component (i.e., ΔμB ≃ 450 km/s), assuming circular motion and a binary of mass 108.8 M⊙, we obtain an upper limit for the separation of the two BHs of ≃14 pc18. This is not inconsistent with the ≃5.5-year period observed in the light curve (Zhu & Thrane 2020), which, still assuming circular motion, corresponds to a separation of R ≃ 0.015 pc (see Eq. 1 of Yu & Lu 2001). However, it must be said that even excluding any kind of obscuration, only few specific combinations of the binary inclination (i) and azimuthal (ϕ) angle result in the right deprojection of the velocity to obtain the 5.5 yr period. Either the plane of the binary is close to face-on or the line joining the two black holes is parallel to the line of sight. By assuming a uniform distribution for ϕ between −π/2 and π/2 and a distribution uniform in sin i between 0 and π/4 we can give a rough estimate of the probability of obtaining the right deprojection of the velocity to get the 5.5 yr period of ≃4%19. Therefore, although the data do not completely rule out the hypothesis of two distinct BLRs producing the observed BEL asymmetry, this scenario is very unlikely.

Our alternative explanation for the asymmetric emission of the Balmer BEL invokes the presence of a perturbation that breaks the axis symmetry in the disk of a single BLR, which could either surround a single SMBH or a binary SMBH system. Following Storchi-Bergmann et al. (2003), we modeled the perturbation with a spiral overdensity. Our analysis indicates such model being statistically preferred20 over a model with a single Gaussian component for both the BELs (Δlog Z = 13 437), a model with a single Gaussian for the Hγ and two Gaussians for the Hβ (Δlog Z = 1080) and two Gaussians for both lines (Δlog Z = 6147).

We expect multiple kinds of perturbations, not necessarily spiral in nature, arising from different physical processes in BLRs. The spiral model is just a simple way to approximate asymmetric emission due to asymmetric emissivity distribution. Indeed, we are not interested in discussing the specific parameters of the spiral model determined in the fit. Instead, we want to stress that even a quite simple toy model is capable of characterizing (still with statistical significance) distorted emission lines. Nevertheless, the presence of spirals in BLR disks seems not to be very uncommon. Theoretical studies (Wang et al. 2022) suggest that non-axisymmetric perturbations (spiral structures) may inevitably grow in the self-gravitating parts of AGN accretion disks. These regions are spatially overlapped with BLRs. It is therefore reasonable to believe that inhomogeneities in the self-gravitating parts of accreting disks might be the origin of the spiral arms in disk-like BLRs. Such hypotheses are also supported by the growing number of reverberation mapping velocity-resolved delay analyses. In such studies there are evidences of the common presence of disk-like BLR consistent either with Keplerian motion, inflow, outflow, or with a complex configuration (Bentz et al. 2010; Grier et al. 2012; Du et al. 2018; Zastrocky et al. 2024). We also observe that the expected BLR size inferred from the luminosity-radius relation (Bentz et al. 2009; Shen et al. 2024; Wang & Woo 2024) is a few times larger than the predicted separation of PG 1302−102 (≃0.015 pc). This implies that the individual BLRs of the two SMBHs in PG 1302−102, if really present, should have already settled in a single BLR. However, given the large uncertainties on the BLR size estimates (typically on the order of 0.3 dex) it might be possible that the two BLRs are still in the process of merging and, therefore have been disturbed as a consequence of the passage of two SMBHs. This scenario gives a complementary explanation to that of gravitational instabilities.

We note also that if the variability of PG 1302−102 is due to Doppler boosting, as in the model presented in D’Orazio et al. (2015), observable effects should be evident by comparing multiple spectra taken at different times (Ji et al. 2021; Bertassi et al., in prep.). Indeed, we expect variability in BELs to be different depending on the geometry of the BLR (disturbed or not) and on the source of variability itself (Doppler-boost vs. red noise). Song et al. (2021) analyzed a few spectra taken at different times of PG 1302−102 containing multiple BELs (Lyα, CIV and CIII) without observing variability consistent with the Doppler boosting scenario unless assuming strong misalignment between the BLR and the plane of the binary21. However, their analysis was limited to a few good-quality spectra taken at different times, a factor that could have affected their findings.

Consistently with the results from RM campaigns on AGNs with asymmetric Hβ emission (Zastrocky et al. 2024), we argue that the BLR of PG 1302−102 shows deviations from a purely spherical or disk-like emissivity distribution. We do not exclude the recent merger of two separate BLRs being a possible cause of such perturbations. However, given the absence of variability in the BELs emission, we argue that self-gravitating instabilities are more likely to be an explanation for the emission coming from the BLR.

The perturbed BLR scenario is also supported by its capability of simultaneously reproducing the peculiar emission profiles of the Hγ, Hβ, and the observed flux excess at λ ≃ 5000 Å. Indeed, the analysis presented in Sect. 3.1 of the spectrum of PG 1302−102 revealed an additional component, which, if associated with the Hβ, demonstrates high redshift (ΔμVB ≃ 4000 km/s) and a large broadening (FWHMVB = 12 600 km/s). This is the first time such component has been detected in PG 1302−102, however, the same feature has already been observed in different quasars (e.g., class B1 and B1+ quasar, Sulentic et al. 2002). One possibility could be this component not being associated with the Hβ but with the emission from the Fe. In our approach, we fixed the ratios of the different Fe multiplets from Véron-Cetty et al. (2004). Different conditions and geometries of the BLR and of the ionizing source might play a role in changing the multiplet ratios without needing any further components. In the case where the component is associated with the Hβ, gravitational redshift from gas close to the SMBH might be a possible explanation. In such case, assuming only gravitational redshift, we estimated a distance of ≃70 gravitational radii to get a redshift of ≃4000 km/s (i.e., the peak of the very broad component). It is not clear if, at such small distances from the BH, there are the physical conditions to efficiently produce Balmer emission lines. It is also unclear whether this feature should be expected in all Balmer lines, as our analysis indicates the lack of any very redshifted component in the Hγ. As was already anticipated in Sect. 3.2, the disk-like BLR model with the spiral perturbation can capture and explain the asymmetric emission of the Hβ and Hγ close to the bulk of the line (i.e., ΔμB ≃ 450 km/s) and the excess (or the lack of it in the case of the Hγ) at much longer wavelengths. This provides not only a self-consistent and physically motivated explanation for the complex nature of the BLR of PG 1302−102 but also a viable explanation for the whole class of quasar showing the same very redshifted component, which, until now, has only been investigated empirically.

Finally, the origin of the BLR disturbance might be connected to outflows. Our analysis has revealed the presence of ionized outflows on NLR scales in PG 1302−102. Few works have reported evidence for a connection between outflows in broad and narrow line regions as the two may be connected and part of the same feedback mechanism (Vietri et al. 2020). Therefore, it might be possible that the redshifted components of the BLR are partially tracing the radial motion of the gas or that the disturbance in the disk originates from feedback from the central AGN. In this case, due to dust absorption and obscuration, it is generally expected to preferentially observe outflows instead of inflows. If AGN winds are really the cause of the observed emission profile, the fact that we detect only a redshifted component without any blueshifted counterpart at least implies quite a peculiar configuration and dynamics of the gas and the dust in the BLR of PG 1302−102. Only precise and long monitoring reverberation mapping campaigns will shed light on the real nature of PG 1302−102 either by characterizing its BLR transfer function or by testing the binary hypothesis against newly proposed models (Dotti et al. 2022, 2023; Bertassi et al., in prep.).

5. Summary and conclusions

In this work, we conducted the first fully Bayesian analysis on the high-resolution ESPRESSO spectrum of the binary black hole candidate PG 1302−102. Our Bayesian approach, based on the nested sampling algorithm, measures the posterior probability distribution of all the model parameters and the evidence of the model, which we use to assess if an emission component is statistically required. Our methodology coupled with the high quality of the data (R ≃ 138 000) allowed us to confirm (for the Hβ) and detect (for the Hγ) the presence of a redshifted broad emission component (Δμ ≃ 450 km/s, FWHMB = 3981 km/s) for which we provided accurate measurements of its properties. We also detected an additional Gaussian component that, if associated with the Hβ, implies high redshift (ΔμVB ≃ 4000 km/s) and a large broadening (FWHMVB = 12 600 km/s); notably the same component is not detected in the Hγ. Finally, we discovered and characterized the presence of blueshifted broad component (Δμ ≃ −350 km/s, FWHMO = 991 km/s) in all the analyzed narrow lines (Hβ, Hγ, and [OIII]) that we explained as a gas outflow. From the width of the BELs we estimated a dynamical mass of MBH ≃ 108.8 M⊙ for PG 1302−102.

We discussed two scenarios as viable explanations for the complex emission of the Balmer lines. A possibility is the presence of a black hole binary carrying around the BLR during the orbital motion. In this case, assuming a period of the binary of ≃5.5 yr (Zhu & Thrane 2020) and the typical luminosity-radius relations with their uncertainties for the average BLR size (Bentz et al. 2009; Shen et al. 2024; Wang & Woo 2024), we conclude that the BLRs of the individual black holes should be either already settled in a single BLR or in the process of merging and, therefore highly disturbed and truncated. The alternative explanation assumed the BLR to be a disk orbiting in Keplerian circular motion around a single SMBH with a non-axisymmetric emissivity distribution modeled as a spiral overdensity. We showed that accounting for a perturbation in the BLR, a disk-BLR model well-fitted the data. This approach simultaneously explains the asymmetric emission of the Hβ and Hγ close to the bulk of the line and the flux excess (or the lack of it in the case of the Hγ) at much longer wavelengths. A comparison of the Bayesian evidence of the spiral perturbation model with a simpler multi-Gaussian model showed a clear statistical preference for the former. This strongly suggests that the BLR of PG 1302−102 is a complex system, demonstrating that, when feasible, geometrical and dynamical modeling of the BLR should always be preferred over an empirical superposition of unphysical components. Our approach could indeed be extended to other sources, possibly explaining all those objects showing emission line features similar to that of PG 1302−102.

Still, the physical origins of the perturbation are unclear and a connection with the possible presence of a black hole binary cannot be ruled out. However, given the growing evidence from theoretical (Wang et al. 2022) and observational (Zastrocky et al. 2024) works demonstrating the common presence of disturbed BLRs, we argue that an origin related to self-gravitating instabilities may be more plausible. Future spectroscopic monitoring of PG 1302−102 is surely needed to better characterize the nature of this source and the structure of its BLR.

1

Given the typical binary separations involved in order to be conclusive, such test could require up to ≳10 − 100 yr (Tsalmantza et al. 2011; Eracleous et al. 2012).

2

See also (Liu et al. 2024) for photometric reverberation mapping measurement obtained combining such light curves.

3

Estimates from the periodicity and the predicted mass of the putative binary give a separation of ≃0.01 pc and, therefore relativistic motion.

6

Due to the high spectral resolution of ESPRESSO data, we are already considering ≃138 000 data points in the fit. Increasing this number further would mainly result in a worsening of computational performance. We note that fitting the current data requires about 5 million likelihood evaluations resulting in a total computational cost for a single parameter estimation of about 40 hours.

7

We stress that, comparing the Bayesian evidence of two models is formally the best approach to model selection. Indeed, differently from other indicators (i.e., χ2, BIC, AIC), the Bayesian evidence automatically accounts for the dimensionality of the parameter space without assuming any shape of the posterior distribution.

8

[OIII] emission line rest-frame wavelengths: 4363.2 Å, 4958.9 Å, and 5006.8 Å.

9

The spectrum considered in the analysis is normalized to a reference flux F0 = 2.96 × 10−15 erg/s/cm2/Å chosen to have a flux close to 1 at λ ≃ 5100 Å.

10

We assumed either uniform or log-uniform priors for all the parameters.

11

The authors report the presence of a redshifted tail also in the Hα. Since that line does not fall in the observed wavelength range we cannot confirm its presence.

12

Even fixing the amplitude ratio AHβB/AHβVB to be the same of AHγ/AHγVB we did not observe any increase in the model evidence.

13

On an 8-core machine equipped with 13th Gen Intel(R) Core(TM) i7-1355U.

14

A possibility could have been to focus on the Hβ only reducing the analyzed wavelength range and the overall computational cost of the parameter estimation.

15

We note that i, A, δ, ϕ0, and p are the same for the Hβ and Hγ.

16

The emissivity is higher but the area is smaller.

17

We note that in the case of a disk-like BLR, the radius decreases by a factor of ≃4 − 5 due to the lack of stability in circular orbits outside of it Runnoe et al. (2015).

18

Since we do not know the inclination angle and the phase of the putative binary any radius smaller than 14 pc cannot be rejected.

19

This estimate takes into account the error on the period of the binary (≃0.15 yr) and the error of the black hole mass (≃0.5 dex). If we had assumed to know precisely the black hole mass, the probability would have decreased to ≃0.1%.

20

We note that we cannot directly compare the evidence presented in Table 1 with the evidence estimated in Sect. 3.2 since the two models have been optimized on different slices of the data.

21

If the binary plane is perpendicular to the BLR, then, in the reference frame of the BLR, the Doppler effect should be smaller. However, given the extended size of the BLR and the uncertainties on its geometry, it is not clear what the net effect would be on the variability of broad lines.
