Fig. 4.


Download original image

Centre-to-limb variation of Q ¯ / I ¯ $ \overline{Q}/\overline{I} $ (left panel) and U ¯ / I ¯ $ \overline{U}/\overline{I} $ (right panel) signals as function of μ = cos(θ). The results are obtained for χ = 0 and with the FAL-C atmospheric model, considering uniform horizontal (θB = π/2 and χB = 0) magnetic fields of different strengths (see the legend). Dash-dotted, dashed, and solid lines correspond to CRD, PRD–AA, and PRD–AD calculations, respectively.
