The role of general relativity on icy body reservoirs under the effects of an inner eccentric Jupiter
^{1}
Instituto de Astrofísica de La Plata, CCT La PlataCONICETUNLP,
Paseo del Bosque S/N,
1900
La Plata,
Argentina
email: mzanardi@fcaglp.unlp.edu.ar
^{2}
Facultad de Ciencias Astronómicas y Geofísicas, Universidad Nacional de La Plata,
Paseo del Bosque S/N,
1900
La Plata,
Argentina
^{3}
Department of Physics and Astronomy, University of California,
Los Angeles,
CA
90095,
USA
^{4}
Mani L. Bhaumik Institute for Theoretical Physics, Department of Physics and Astronomy, UCLA,
Los Angeles,
CA
90095,
USA
Received:
17
October
2017
Accepted:
1
April
2018
Context. Recent studies have analyzed the dynamical evolution of outer small body populations under the effects of an eccentric inner massive perturber, which result from a planetary scattering event. These investigations suggest that such outer reservoirs are composed of particles on prograde and retrograde orbits, as well as particles whose orbit flips from prograde to retrograde and back again showing a coupling between the inclination i and the ascending node longitude Ω (TypeF particles).
Aims. We analyze the role of the general relativity (GR) on the dynamics of outer particles under the influence of an inner eccentric Jupitermass planet produced by a planetary scattering event. In particular, we are interested in studying how the GR affects the dynamical evolution of the outer TypeF particles, which experience an eccentric Lidov–Kozai mechanism.
Methods. To do this, we carried out Nbody simulations with and without GR effects. Such a detailed comparative analysis allows us to strengthen our understanding concerning the GR and eccentric Lidov–Kozai combined effects on the dynamical evolution of outer particles.
Results. When the GR is included, the extreme values of Ω are obtained for retrograde inclinations, while the minimum and maximum inclinations allowed for TypeF particles increase in comparison with that derived without GR effects. According to this, if the GR is included in the simulations, the range of prograde (retrograde) inclinations of the libration region is reduced (increased) with respect to that obtained in absence of GR. We find two new classes of particles when GR effects are included in the simulations. On the one hand, there are particles whose orbital plane flips from prograde to retrograde and back again without experiencing a coupling between i and Ω. On the other hand, retrograde particles show a strong coupling between i and Ω. We infer that GR may significantly modify the dynamical properties of the outer reservoirs that evolve under the effects of an eccentric inner perturber.
Key words: planets and satellites: dynamical evolution and stability / minor planets, asteroids: general / methods: numerical
© ESO 2018
1 Introduction
The secular dynamics of a system composed of an outer body orbiting around an inner binary is complex. Most of the studies carried out to date have analyzed the effects of a far away massive perturber on the inner binary. In particular, Lidov (1962) and Kozai (1962) developed pioneering works aimed at analyzing the secular perturbations of an inner test particle produced by an outer massive perturber on a circular orbit. In this scenario, the authors showed that the test particle conserves the vertical angular momentum, and thus its orbit oscillates periodically, exchanging eccentricity for inclination. An interesting result derived by Kozai (1962) indicates that if the inclination of the particle is between 39.2° and 140.8°, its pericenter argument shows librations coupled with the inclination and eccentricity. In this libration regime, Kozai (1962) showed that particles of very low eccentricity cannot remain on a circular orbit along its evolution. In particular, if the inclination of the particle is close to 90°, its maximum eccentricity is nearly unity. This dynamical behavior is the socalled standard Lidov–Kozai mechanism.
In recent years, the eccentric Lidov–Kozai mechanism for an inner test particle has been the focus of several investigations. In particular, Lithwick & Naoz (2011) and Katz et al. (2011) studied the dynamical behavior of a massless particle that orbits a star under the effects of an outer perturber up to the octupole level of secular approximation. Such works showed that if the planet has an eccentric orbit, the vertical angular momentum is no longer conserved and the eccentric Lidov–Kozai mechanism can lead to a peculiar evolution on the test particle whose orbit can flip reaching prograde and retrograde inclinations together with high eccentricities. Many others authors have made important progress concerning the effects of an outer and eccentric perturber on the evolution of an inner test particle. In fact, Libert & Delsate (2012) analyzed the dynamical evolution of an inner body with high inclination in the presence of an eccentric and outer perturber. Moreover, Li et al. (2014) developed a study about chaos in the eccentric Lidov–Kozai mechanism in the inner test particle limit. In addition, Antognini (2015) derived expressions for the timescales of Lidov–Kozai oscillations up to the quadrupole and octupole levels in the test particle case. A detailed description of the eccentric Lidov–Kozai mechanism and its applications for an inner test particle can be found in Naoz (2016).
The secular perturbations of an outer test particle that evolves under the effects of an inner and eccentric perturber have also been studied in the literature by several authors. First, Ziglin (1975) analyzed the secular evolution of a far away planet in a binarystar system in the context of the restricted elliptical threebody problem. From a doubly averaged disturbing function, the author found that the dynamical behavior of the outer test particle is strongly dependent on the eccentricity of the inner binary. In fact, if the orbit of the binary is circular, the node of a particle always precesses, while if the orbit of the binary is elliptic, nodal librations take place. Moreover, Ziglin (1975) derived an expression for the width of the libration zone observing that the greater the eccentricity of the inner binary, the bigger the libration region. Then, Thomas & Morbidelli (1996) studied the secular evolution of the minor planets of the outer solar system under the perturbations of the four giant planets on coplanar and circular orbits. They found that the Kozai resonance fails to excite the eccentricities from quasicircular orbits even with very large inclinations. However, the resonance modifies the dynamical evolution of the very eccentric orbits, such as those associated with the large period comets. Later, Farago & Laskar (2010) studied the case of a far away body orbiting an inner binary up to the quadrupole level of the secular approximation in the context of the threebody problem. For the particular case in which the outer body is a massless test particle, Farago & Laskar (2010) obtained results consistent with those derived by Ziglin (1975). Recently, Naoz et al. (2017) and Zanardi et al. (2017, hereafter Paper I) carried out two complementary works aimed at analyzing the dynamical evolution of outer test particles under the effects of an eccentric inner massive perturber. In fact, Naoz et al. (2017) studied the secular evolution of a far away test particle orbiting an inner massive binary up to the octupole level of approximation. From this analysis, the angular momentum of the outer test particle is conserved at the quadrupole level, which indicates that its eccentricity remains constant. However, Naoz et al. (2017) showed that secular interactions up to the octupole level lead to variations of the eccentricity of the test particle and introduces higher level resonances, which may produce chaos. In this context, Zanardi et al. (2017) made use of Nbody simulations and analyzed the dynamical evolution of outer test particles in the presence of an eccentric inner Jupitermass planet resulting from a planet–planet scattering event around a 0.5 M_{⊙} star. The results derived by these authors suggest that planetary scattering scenarios lead to an efficient production of outer small body reservoirs composed ofparticles with prograde and retrograde inclinations, and others whose orbit flips from prograde to retrograde and back again in their evolution. The dynamical features of these flipping particles, which show a strong correlation between the inclination i and longitude of ascending node Ω, were supported by the analytical results derived by Naoz et al. (2017). Such particles, whose orbital plane flips showing a coupling between i and Ω, were called TypeF particles by Zanardi et al. (2017).
One of the effects that can modify the dynamical properties of a given system derived from the eccentric Lidov–Kozai mechanism is general relativity (GR; Ford et al. 2000a,b; Naoz et al. 2013; Sekhar et al. 2017). For the particular case of an outer test particle orbiting an inner binary, Naoz et al. (2017) suggested that the inclination excitation can be suppressed (produced) for systems with GR precession faster (slower) than the quadrupole precession. According to this, GR effects may significantly modify the dynamical structure of outer small body reservoirs that evolve under the influence of an inner eccentric perturber.
The main goal of the present research is to analyze the role of GR on the dynamics of outer particles under the influence of an inner eccentric Jupitermass planet. In particular, we are interested in studying how GR affects the dynamical evolution of the outer TypeF particles, which experiment an eccentric Lidov–Kozai mechanism. To do this, we include GR forces in the Nbody code and rerun those simulations of the Paper I that produce systems in which at least one TypeF particle exists in the resulting small body population and that evolve under the influence of an inner eccentric Jupitermass planet. A detailed comparative analysis between the Nbody simulations without GR and the GRincluded simulations carried out in the present research will allow us to strengthen our understanding concerning the GR and eccentric Lidov–Kozai combined effects on the dynamical evolution of outer particles. The present paper is structured as follows. In Sect. 2, we present the scenario of our simulations and the numerical code used for carrying out the Nbody integrations. A detailed analysis of the results about the dynamical properties of the small body reservoirs resulting from our numerical simulations is shown in Sect. 3. Finally, Sect. 4 describes the discussions and conclusions of our study.
Fig. 1 Orbital parameters e vs. a of the surviving planets in each of the 12 TypeF simulations. The color palette represents the timescale of GR (Eq. (1)), which leads to the precession of the planet’s pericenter argument. The orbital elements illustrated here correspond to those adopted for each surviving planet immediately after the dynamical instability event simulated in Paper I.

Open with DEXTER
2 Nbody simulations: scenarios of work and numerical code
In Paper I, Zanardi et al. (2017) analyzed the evolution of systems initially composed of three Jupitermass planets located close to their dynamical instability limit together with an cold outer disk of test particles around a 0.5 M_{⊙} star, which undergo strong planetary scattering events. In particular, that work was based on the analysis of 21 Nbody simulations, in which a single Jupitermass planet survives in the system after the dynamical instability event. Thus, the study developed by Zanardi et al. (2017) offers a detailed description about the main dynamical features of outer test particles evolving under the influence of an eccentric inner perturber. According to that shown in Paper I, the resulting outer reservoirs are composed only of particles on prograde orbits (hereafter TypeP particles) in 7 of 21 simulations, while in 2 of 21, TypeP particles coexist with particles on retrograde orbits (hereafter TypeR particles). The most important result derived in Paper I is the existence of TypeF particles with very peculiar dynamical properties, which are present in 12 of those 21 Nbody simulations with a single surviving Jupitermass planet. As we have already mentioned, the TypeF particles have orbits that flip from prograde to retrograde and back again showing a coupling between the inclination i and the ascending node longitude Ω. In general terms, the TypeF particles coexist with TypeP and R particles in the outer small body reservoirs that result from those 12 Nbody simulations, which emerge as very auspicious scenarios to analyze the dynamical features of the various classes of particles. The present work is based on the 12 aforementioned simulations, which are called TypeF simulations.
Figure 1 illustrates the distribution of each surviving Jupitermass planet in the orbital element space eccentricity e versus semimajor axis a, which are associated with the 12 TypeF simulations. Such orbital elements correspond to those adopted for each surviving planet immediately after the dynamical instability event simulated in Paper I. These parameters are referenced to the barycenter and invariant plane of the system, whose xaxis coincides with the pericenter of the planet. The semimajor axis a and eccentricity e of such planets range from 0.76 au to 10 au and 0.22 to 0.94, respectively. In such a figure, the color palette represents the orbit GR precession timescale in a first order postNewtonian approximation, which can be estimated as (1)
(Einstein 1916) where a, e, and m represent the semimajor axis, eccentricity, and mass of the planet, respectively, m_{⋆} is the mass of the star, c the speed of light, and k^{2} the gravitational constant. The orbit GR precession takes place on timescales that range from 23.4 Myr to 3400 Myr for the planets represented in Fig. 1. As shown in Naoz et al. (2017), the GR precession of the inner planet’s pericenter argument translates to a precession of the outer particle’s ascending node longitude. Taking into account the strong correlation between the orbital inclination and ascending node longitude of the TypeF particles (Zanardi et al. 2017; Naoz et al. 2017), the GR may play an important role in the dynamical properties of such particles and in the global structure of the outer small body reservoirs that evolve under the influence of an inner eccentric giant planet.
To study this, we carried out two new sets of Nbody simulations, which are based on the 12 TypeF simulations. The first set of simulations only includes gravitational forces in the evolution of each of the 12 aforementioned systems (hereafter NoGR simulations), while the second set incorporates GR effects in the integration of each of such systems (hereafter GR simulations). We remark that all Nbody simulations were carried out using the MERCURY code (Chambers 1999). In particular, we made use of the Bulirsch–Stoer algorithm with an accuracy parameter of 10^{−12}. To include the GR effects, we modified the MERCURY code including an additional acceleration from the GR corrections derived by Anderson et al. (1975), which is given by (2)
where m_{⋆} represents the mass of the star, k^{2} the gravitational constant, c the speed of light, r and v the astrocentric position and velocity vectors, respectively, and r = r. It is worth noting that this is a first order postNewtonian approximation. The Hamiltonian and its connection to the threebody problem are shown in Naoz et al. (2013).
The NoGR and GR simulations of the present work were developed assuming as initial conditions the orbital parameters of the systems immediately after the instability event when a single planet survives in the system (hereafter post IE orbital parameters), for each of the 12 TypeF simulations of the Paper I. Figure 2 shows the post IE inclination i and eccentricity e of all particles and the eccentric inner perturber of the 12 TypeF simulations, where the color palette represents the post IE semimajor axis a of the particles and of the surviving giant planet. It is worth noting that the orbital elements of all bodies illustrated in Fig. 2 reference the barycenter and invariant plane of the system, where xaxis is oriented to the pericenter of the surviving planet. All Nbody simulations of the present research are integrated for a time span of 2t_{GR} in order to explore the role of the GR in the dynamical evolution of the test particles.
Fig. 2 Orbital elements i vs. e of all particles (small circles) and the surviving Jupitermass planet (big circle) immediately after the instability event for each of the 12 TypeF simulations of the Paper I. The color palette represents the semimajor axis of all particles and of the giant planet of each system immediately after the instability event.

Open with DEXTER
3 Results
We describe the results of our Nbody simulations with the aim of analyzing the role of the GR on the dynamical properties of the outer test particles that evolve under the effects of an eccentric inner Jupitermass planet. Hereafter, the subscripts 1 and 2 are used to refer to the mass and orbital parameters of the inner planet and outer test particles, respectively. Moreover, we remark that the orbital parameters of the outer test particles are referenced to the barycenter and invariant plane of the system, where xaxis coincides with the pericenter of the planet. It is worth noting that when GR is included, the inner planet’s pericenter argument precesses for which the ascending node longitude of the test particles is referenced to a rotating system.
3.1 Role of GR on dynamical evolution of TypeF particles
Figure 3 shows trajectories of evolution of a given TypeF particle in an inclination i_{2} versus ascending node longitude Ω_{2} plane, which result from the NoGR (red curve) and GR (blue curve) simulations.
According to Naoz et al. (2017), the time evolution of the inclination i_{2} and ascending node longitude Ω_{2} of an outer test particle up to the quadrupole level of secular approximation without GR is given by
where m_{1}, a_{1}, and e_{1} are the mass, semimajor axis, and eccentricity of the inner planet, respectively; a_{2}, e_{2}, and P_{2} the semimajor axis, eccentricity, and orbital period of the outer test particle; and m_{⋆} the mass of the central star. On the one hand, the minimum and maximum inclinations for libration trajectories are obtained for values of the ascending node longitude Ω_{2} of 90° or 270°. On the other hand, the extreme values of the ascending node longitude Ω_{2} for libration trajectories are associated with an inclination i_{2} = 90°. These correlations between i_{2} and Ω_{2} in absence of GR can be seen in the red curve represented in Fig. 3.
The inclusion of GR modifies the orbital properties of a TypeF particle concerning the evolution of its inclination i_{2} and ascending node longitude Ω_{2}. The time evolution of the inclination i_{2} of an outer test particle for the quadrupolelevel of approximation with GR does not show changes in comparison with Eq. (3). Thus, the minimum and maximum inclinations for libration trajectories are also obtained for values of the ascending node longitude Ω_{2} of 90° or 270°. On the other hand, the time evolution of the ascending node longitude Ω_{2} of an outer test particle for the quadrupole level of approximation significantly changes with the inclusion of GR. In fact,Naoz et al. (2017) showed that the GR precession of the inner planet’s pericenter argument ω_{1} translates to a precession of the outer particle’s ascending node longitude Ω_{2}. Thus, working in the rotating frame of the orbit of the inner planet, the time evolution of the ascending node longitude Ω_{2} due to the secular evolution up to the quadrupole level of approximation together with the precession of the ascending node longitude induced by GR effects is given by (5)
where is given by Eq. (4), and is expressed by (6)
Naoz et al. (2017). The minus sign of this equation indicates that the ascending node longitude’s precession of the outer test particle is in the opposite direction from the pericenter argument’s precession of the inner planet, which is caused by GR effects. From this, we can find the minimum and maximum ascending node longitude for libration trajectories by setting = 0 in Eq. (5). Thus, the values of the inclination i_{2} that satisfy this condition are given by the following expression (7)
where A is a constant that depends on the mass of the inner planet m_{1} and the mass of the star m_{⋆}, and it is given by (8)
where c is the speed of light and k^{2} the gravitational constant. Since A < 0, the extreme values of the ascending node longitude Ω_{2} are obtained for values of the inclination i_{2} higher than 90° when the GR effects are included. This shift of the inclination from 90° toward retrograde values can be seen in the blue curve represented in the Fig. 3, which illustrates the evolution of a given outer test particle including GR effects. From Eq. (7), it is worth noting that the values of the inclination i_{2} that lead to extreme values of the ascending node longitude Ω_{2} depend on the semimajor axis a_{1} and the eccentricity e_{1} of the inner planet and on the semimajor axis a_{2}, the eccentricity e_{2}, and the ascending node longitude Ω_{2} of the outer test particle. Thus, for given values of a_{1} and e_{1}, the larger the semimajor axis a_{2} and the smaller the eccentricity e_{2}, the higher the inclination i_{2} for which the ascending node longitude Ω_{2} reaches extreme values. Moreover, the dependence of Eq. (7) on Ω_{2} indicates that the value of the inclination i_{2} associated with extreme values of theascending node longitude Ω_{2} changes while the orbit of the particle flips.
Another important point of our analysis is related to the minimum and maximum inclination that can reach one TypeF particle under the influence of an inner planet with a given eccentricity. In absence of GR, Naoz et al. (2017) showed that the secular Hamiltonian up to the quadrupole level of approximation is expressed by (9)
This f_{quad} is an energy function that can be used to determine the extreme values of the inclination i_{2} for libration trajectories, which are obtained for values of the ascending node longitude Ω_{2} of 90° or 270°. Thus, considering the conservation of energy on the separatrix between the minimum value of the ascending node longitude (Ω_{2} = 0°, i_{2} = 90°) and the extreme values of the inclination (Ω_{2} = 90°, ), it is possible to obtain that (10)
Thus, in absence of GR, the extreme values of the inclination i_{2} on libration trajectories only depend on the eccentricity e_{1} of the inner planet (Ziglin 1975; Farago & Laskar 2010; Naoz et al. 2017; Zanardi et al. 2017).
According to the equations of motion up to the quadrupole level of approximation proposed by Naoz et al. (2017), (11)
where f_{quad} is given by Eq. (9). When the GR effects are included in the analysis and working in the rotating frame of the orbit of the inner planet, an integral of motion f appears, which adopts the following expression: (12)
If the integral of motion f given by Eq. (12) replaces f_{quad} in Eq. (11), the expression of given by Eq. (5) is obtained. A general detailed study about the secular and hierarchical threebody problem including postNewtonian corrections can been found in Naoz et al. (2013).
Now, we can use the integral of motion f given by Eq. (12) to determine the extreme values of the inclination i_{2} for librationtrajectories including GR effects, which are associated with values of the ascending node longitude Ω_{2} of 90° or 270° as in the absence of GR. To do this, we must consider the conservation of f on the separatrix between the minimum value of the ascending node longitude (Ω_{2} = 0°, ) and the extreme values of the inclination (Ω_{2} = 90°, ). It is worth noting that when GR is included the minimum of the ascending node longitude Ω_{2} on the separatrix is equal to 0° and is obtained for a value of the inclination given by Eq. (7), while in absence of GR. From this, the extreme values of the inclination can be obtained from the following expression: (13)
where A is the constant given by Eq. (8).
Figure 4 shows the maximum and minimum inclination allowed for libration trajectories as a function of the planet’s eccentricity e_{1} for different values of the semimajor axis a_{2} and the eccentricity e_{2} of the test particle. In both panels, we set a value of 1 au for the planet’s semimajor axis a_{1}. The extreme values of the inclination in absence of GR are illustrated by the black curves and they only depend on the eccentricity of the planet, as in Eq. (10). When the GR is included, the minimum and maximum values of the inclination depend on the semimajor axis a_{1}, eccentricity e_{1}, and mass of the planet m_{1}, and the semimajor axis a_{2} and the eccentricity e_{2} of the test particle, as in Eqs. (13)–(16). In general terms, our results indicate that the GR increases the minimum and maximum values of the inclination i_{2} allowed for libration trajectories in comparison with those that correspond in absence of GR. It is worth noting that the smaller the eccentricity of the particle, the higher the minimum and maximum values of the inclination of the particle allowed for libration trajectories. This can be observed in both panels of Fig. 4, where the blue, green, and red curves illustrate the extreme values of the inclination of a TypeF particle for eccentricities e_{2} of 0.1, 0.5, and 0.8, respectively, when the GR effects are included. Moreover, we infer that the greater the particle’s semimajor axis a_{2}, the higher the minimum and maximum values of the inclination of the particle. This can be seen in Fig. 4, where we use values of 15 au and 25 au for the particle’s semimajor axis a_{2} in the top and bottom panels, respectively.
As we see in the next sections, an increase of the minimum and maximum inclinations allowed for libration trajectories has important consequences in the suppression and generation of orbital flips when the GR effects are included in the simulations.
Fig. 3 Coupling between the inclination i_{2} and the ascending node longitude Ω_{2} of a given TypeF particle, which result from the NoGR (red curve) and GR (blue curve) simulations. The initial orbital elements of this particle are a_{2} = 20.72 au, e_{2} = 0.62, i_{2} = 144.84°, ω_{2} = 42.15° and Ω_{2} = 222.30°. The inner planet of such a system has a semimajor axis a_{1} = 0.95 au and an eccentricity e_{1} = 0.74. The red and blue horizontal lines represent the inclination values for which the ascending node longitude reaches extreme values for NoGR and GR simulations, respectively.

Open with DEXTER
Fig. 4 Minimum and maximum inclination allowed for libration trajectories as a function of the eccentricity of the planet. The black curves represent the correlation in absence of GR. The blue, green, and red curves in both panels show the extreme values of the inclination for eccentricity e_{2} of 0.1, 0.5, and 0.8, respectively, when the GR effects are included. Moreover, we adopt a particle’s semimajor axis a_{2} of 15 au and 25 au in the top and bottom panels, respectively. Finally, we consider a semimajor axis a_{1} = 1 au for the planet in both panels.

Open with DEXTER
Fig. 5 Evolution in time of the inclination (normalized to t_{GR}) of three different particles of the same system, which were TypeF particles in absence of GR and then were suppressed by GR effects. The blue and red curves represent the temporal evolution of the particles’ inclination with and without GR effects. The semimajor axis and eccentricity of the inner planet are a_{1} = 1.32 au, e_{1} = 0.56, and the orbit GR precession timescale is t_{GR} = 130 Myr. Left panel: the initial orbital parameters of the particle are a_{2} = 20.74 au, e_{2} = 0.42, i_{2} = 43.30°, ω_{2} = 108.35°, and Ω_{2} = 233.28°. Middle panel: the initial orbital parameters of this particle are a_{2} = 44.25 au, e_{2} = 0.724, i_{2} = 36.65°, ω_{2} = 290.77°, and Ω_{2} = 284.67°. Right panel: the initial orbital parameters of the outer test particle are a_{2} = 160 au, e_{2} = 0.93, i_{2} = 38.39°, ω_{2} = 287.95°, and Ω_{2} = 279.02°.

Open with DEXTER
3.2 Suppression of TypeF particles
Naoz et al. (2017) suggested that the inclination of a given outer test particle is suppressed if its quadrupole precession is slower than the GR precession of the inner perturber of the system. Nevertheless, when GR precession acts on timescales larger (or even similar) than the quadrupolar precession, it can produce excitations in the inclination of the particle. A behavior like this was previously observed by Naoz et al. (2013), who studied the resonant postNewtonian excitations of the eccentricity of an inner binary that is orbited by an outer massive perturber. In this context, similar results were derived by Fabrycky & Tremaine (2007) and Liu et al. (2015).
Figure 5 shows the evolution in time of the inclination of three different particles of the same system with and without GR effects. The orbital parameters of the inner Jupitermass planet are a_{1} = 1.32 au and e_{1} = 0.56, while the GR precession timescale given by Eq. (1) is t_{GR} = 130 Myr. In the left panel it can be seen that the suppression of the flips is efficient for a test particle whose libration period of inclination is only a small fraction of the GR precession timescale associated with the orbit of the inner planet. In the middle panel, the orbital flip is suppressed when the libration period of the inclination of the particle is similar to the GR timescale of the planet, while the right panel shows that the orbital flip is suppressed for a particle whose libration period of inclination is significantly greater than the GR precession timescale of the planet. According to this, our results suggest that the suppression of the orbital flips is not sensitive to the period of libration associated with the inclination of the particle.
A relevant result obtained from our study indicates that the suppression of the orbital flips is due to an increase in the minimum inclination allowed for the TypeF particles when the GR effects are included in the simulations. Thus, an increase in such minimum values of the inclination leads to a libration region that is more constrained in comparison with that obtained in absence of GR. In other words, the GR effects reduce the range of prograde inclinations for the libration regime. We note that the minimum inclination allowed for libration trajectories, which is derived from Eqs. (13)–(16), depends on the semimajor axis a_{1}, the eccentricity e_{1}, and the mass m_{1} of the planet, and the semimajor axis a_{2} and eccentricity e_{2} of the particle. According to that discussed in the previous section and illustrated in Fig. 4, the range of prograde inclinations for libration trajectories is more constrained for particles of low eccentricity and large semimajor axis.
To understand the suppression mechanism in the global structure of the outer reservoirs, we carried out occupation maps in the (a, e) and (a, i) orbital planes of a given system whose inner Jupitermass planet has a semimajor axis a_{1} = 1.48 au and an eccentricity e_{1} = 0.69. These maps are shown in Fig. 6, where the top and bottom panels illustrate the occupation maps of the corresponding system, which were developed from the results derived by the NoGR and GR simulations, respectively. Each of these plots shows the normalized time fraction spent by the test particles in different regions of the (a, e) and (a, i) orbital planes during the whole integration time. The color code indicates the permanence time spent in each region, where blue and red represent the most and least visited zones, respectively. We also remark that these plots are maps of probability since the portion of time spent in each zone is normalized. Moreover, in each map, the filled blue circle illustrates the inner Jupitermass planet, while the small black dots represent the surviving TypeF particles at the end of every simulation.
The top panel of Fig. 6 shows that most of the surviving TypeF particles in the NoGR simulation are located between 10 au and 30 au and most of them have very low values of the eccentricity e_{2} ≲ 0.1, but a few of them also survive with eccentricities e_{2} between 0.1 and 0.9. However, when the GR effects are included, the dynamical properties of the outer particles significantly change, which can be observed in the bottom panels of Fig. 6. In general terms, the orbital flips of particles with eccentricities e_{2} ≲ 0.1 are suppressed, while particles with eccentricities e_{2} ≳ 0.1 keep their orbital flips showing a coupling between the inclination i_{2} and ascending node longitude Ω_{2}. This change in the dynamical behavior of the particles is due to an increase in the minimum inclination allowed for libration trajectories when the GR effects are included. To understand it, we illustrate in Fig. 7 the minimum inclination as a function of the semimajor axis of all TypeF particles that result from the NoGR simulation. In particular, the top panel shows the TypeF particles with eccentricities e_{2} < 0.1 as filled black circles, while the bottom panel illustrates the TypeF particles with eccentricities e_{2} between 0.1 and 0.5 (filled blue circles) and between 0.5 and 0.8 (filled red circles). To analyze the suppression mechanism of orbital flips, we must take into account the minimum inclination allowed for libration trajectories with and without GR effects. The dashed horizontal black line in both panels of Fig. 7 illustrates the minimum inclination allowed for TypeF particles in absence of GR, which is given by Eq. (10) and for this planetary system whose inner planet’s eccentricity is e_{1} = 0.69, has a constant value of 25.1°. The black, blue, and red curves represent the minimum inclination allowed for TypeF particles for values of the eccentricity of the particle e_{2} of 0.1, 0.5, and 0.8, respectively, when the GR effects are included. The top panel of Fig. 7 shows that most of the TypeF particles with eccentricities e_{2} ≲ 0.1 have minimum inclinations lower than the minimum inclination allowed for libration trajectories when the GR is included. Thus, the suppression mechanism of orbital flips is efficient over such particles of low eccentricity, which can be confirmed from the absence of TypeF particles with e_{2} ≲ 0.1 in the maps with GR of the bottom panels of Fig. 6. It is worth noting that a few TypeF particles of very low eccentricity and semimajor axes a_{2} ≲ 13 au are located above the black curve in the top panel of Fig. 7, which indicates that they should keep their orbital flips in the GR simulation. In fact, such TypeF particles survive in the maps with GR of Fig. 6. The TypeF particles that survive in the NoGR simulation with eccentricities e_{2} ≳ 0.1 are illustrated in the bottom panel of Fig. 7. From this, it is possible to observe that most of these particles are located above the black, blue, and red curves, for which their minimum inclinations result in higher than the minimum inclination allowed for libration trajectories when the GR is included. Thus, such particles should keep their orbital flips, which is confirmed from the existence of TypeF particles with eccentricities e_{2} between 0.1 and 0.8 in the maps with GR of Fig. 6.
The suppression mechanism of orbital flips has been very efficient in the set of Nbody simulations developed in the present work. In fact, in 9 of the 12 TypeF simulations, the GR effects suppress between 5% and 86% of the TypeF particles of the NoGR simulations and have a median value for the suppression percentage of ~40%. In this context, the most relevant case corresponds to the system illustrated in Fig. 6, in which 86% of the TypeF particles of the NoGR simulation are suppressed by GR.
A natural consequence of the suppression of TypeF particles by GR effects is the increase in the number of the TypeP particles. In fact, an increase in the minimum inclination allowed for libration trajectories with GR leads to the evolution of particles on prograde initial orbits following circulatory trajectories with prograde inclinations when the suppression mechanism of orbital flips is produced. In particular, in more than half of our simulations we obtained an increase of TypeP particles when GR effects are included. In fact, the number of TypeP particles has been increased between 25% and 91% in the GR simulations in comparison with the number obtained from the NoGR simulations. It is worth noting that a case of special interest is that system illustrated in the maps of Fig. 6. Indeed, the number of TypeP particles in the resulting system from the NoGR and GR simulations is equal to 16 and 638, respectively. In this particular case, the generation of TypeP particles by the suppression of TypeF particles due to GR effects is very important, leading to significant changes in the dynamical structure of the outer reservoirs. Such behavior can be observed in the occupation maps (Ω_{2}, i_{2}), which are represented in Fig. 8. Both panels show the differences in the (Ω_{2}, i_{2}) plane of the same system illustrated in Fig. 6 for the NoGR and GR simulations. The left panel illustrates the coupling between the inclination i_{2} and ascending node longitude Ω_{2} of the TypeF particles when the GR effects are absent in the Nbody simulations. These correlations are represented for the blue and green libration regions, which are the zones most visited by the surviving TypeF particles. The right panel shows a significant increase of the number of TypeP particles in the system because the suppression mechanism of TypeF particles turns out to be very efficient when the GR effects are included in the simulations. The effects of this suppression mechanism can be seen on the greenregions in the right panel of Fig. 8, which represent the zones most visited by the surviving TypeP particles.
We conclude that the efficiency of the suppression mechanism of orbital flips when the GR effects are included in a given system is strongly dependent of the semimajor axes, eccentricities, and inclinations of the particles.
Fig. 6 Orbital planes (a, e) and (a, i). The color regions represent zones where the particles can be found with different levels of probability. The big blue circle illustrates the Jupitermass planet of the system and the black dots represent the surviving TypeF particles. Top panel: resulting system in absence of GR. Bottom panel: resulting system when the GR effects are included. The Jupitermass planet of the system has a_{1} = 1.48 au and e_{1} = 0.69.

Open with DEXTER
Fig. 7 Minimum inclination as a function of the semimajor axis of the TypeF particles resulting from the NoGR simulation corresponding to the system illustrated in the top panel ofFig. 6. The top panel shows the TypeF particles with eccentricities e_{2} < 0.1 (filled black circles), while the bottom panel illustrates the TypeF particles with eccentricities e_{2} between 0.1 and 0.5 (filled blue circles) and between 0.5 and 0.8 (filled red circles). The dashed horizontal black line represents the minimum inclination allowed for TypeF particles in absence of GR, which is equal to 25.1°. The black, blue, and red curves represent the minimum inclination allowed for libration trajectories for values of the particle’s eccentricity e_{2} of 0.1, 0.5, and 0.8, respectively. The planet of the system has a semimajor axis and an eccentricity of a_{1} = 1.48 au and e_{1} = 0.69, respectively.

Open with DEXTER
Fig. 8 Orbital planes (Ω_{2}, i_{2}). The color regions represent zones where the particles can be found with different levels of probability. Left panel: resulting system in absence of GR. Right panel: resulting system when the GR effects are included. The Jupitermass planet of the system has a_{1} = 1.48 au and e_{1} = 0.69.

Open with DEXTER
Fig. 9 Evolution of an outer particle that results from the NoGR (red curve) and GR (blue curve) simulations. The semimajor axis and eccentricity of the inner planet are a_{1} = 0.95 au and e_{1} = 0.73, and the orbit GR precession timescale is t_{GR} = 39 Myr. The horizontal dashed black line represents a value of the inclination i_{2} of 90°. Left panel: evolution in time (normalized to t_{GR}) of the particle’s inclination i_{2}. Right panel: evolution of the particle in the inclination i_{2} vs. ascending node longitude Ω_{2} plane. The initial conditions of the particle are a_{2} = 35.75 au, e_{2} = 0.85, i_{2} = 152.48°, ω_{2} = 202.18°, and Ω_{2} = 41.03°.

Open with DEXTER
3.3 Generation of TypeF particles
A clear consequence of the increase in the maximum inclination allowed for libration trajectories with GR is the generation of TypeF particles from particles that evolve on retrograde orbits in absence of GR. Figure 9 shows the evolution of a given particle that results from the NoGR (red curve) and GR (blue curve) simulations, in a system whose inner Jupitermass planet has a semimajor axis a_{1} of 0.95 au and an eccentricity e_{1} of 0.73, while the GR precession timescale given by Eq. (1) is of 39 Myr. The left panel of Fig. 9 illustrates the time evolution of the particle’s inclination i_{2}. The evolution of the inclination i_{2} and the ascending node longitude Ω_{2} of the test particle is shown in the right panel of Fig. 9. From this, the test particle evolves on retrograde orbits in absence of GR, while when the GR effects are included in the simulations, the orbit of such a particle flips from retrograde to prograde and back again showing a coupling between the inclination i_{2} and ascending node longitude Ω_{2}. GR effects increase the maximum inclination allowed for TypeF particles, which enlarges the range of retrograde inclinations for libration trajectories.
The generation mechanism of orbital flips from particles that evolve on retrograde orbits in absence of GR is present in half of all our simulations. In fact, in 6 of the 12 TypeF simulations, 3.7–31.7% of TypeR particles of the NoGR simulations become TypeF particles when the GR effects are included. This generation percentage has a median value of ~11.6%.
It is important to remark that the number of TypeF particles produced from particles on retrograde orbits in absence of GR is lower than the number of TypeP particles generated from the suppression of TypeF particles discussed in the previous subsection. It is worth noting that this result is a clear consequence of the initial conditions used in the present study. We assumed as initial conditions of our work the orbital parameters of the 12 TypeF simulations defined from the Paper I immediately after the instability event, when a single Jupitermass planet survives in the system. In fact, Fig. 2, which reflects the initial orbital parameters of those 12 TypeF simulations used in the present work, shows that the number of particles with initial inclinations higher than 90° is much lower than the number associated with inclinations <90°. Thus, we conclude that, when the GR is included in the simulations, the mechanism of suppression of orbital flips and generation of TypeP particles is more efficient than the production of TypeF particles from particles that evolve on retrograde orbits in absence of GR.
3.4 Flipping particles without coupling between inclination and ascending node longitude
The GR simulations show the existence of particles whose orbital planes flip reaching prograde and retrograde inclinations without experiencing a coupling between the inclination i_{2} and ascending node longitude Ω_{2}. Because of the absence of coupling between i_{2} and Ω_{2}, they are not TypeF particles and so we simply call them flipping particles.
A flipping particle does not show coupling between the orbital inclination i_{2} and ascending node longitude Ω_{2} because i_{2} is always less than the necessary value to obtain extreme values of Ω_{2} in any point of the trajectory, which is given by Eq. (7). Thus, Ω_{2} is not constrained between two specific values for which such an angle evolves in a circulatory regime.
This behavior can be observed in Fig. 10, which shows the evolution of the inclination i_{2} and ascending node longitude Ω_{2} of a test particle of a given system in NoGR (red curve) and GR (blue curve) simulations, which has an initial semimajor axis a_{2} = 20.792 au and a high initial eccentricity e_{2} = 0.705. In such a system, the inner planet has a semimajor axis a_{1} = 0.867 au and an eccentricity e_{1} = 0.8. In the NoGR simulation, such a particle flips experiencing a coupling between i_{2} and Ω_{2}. In the GR simulation, the particle evolves on a circulation trajectory since the inclination i_{2} at Ω_{2} = 90° and 270° is higher than the inclination i_{2} allowed for libration trajectories, which is given by Eq. (13). Beyond this, the particle’s orbit flips from prograde to retrograde and back again reaching a significant maximum inclination i_{2} = 145.825°. In fact, the particle can reach retrograde inclinations without experiencing a coupling between i_{2} and Ω_{2} since the inclination i_{2} is always less than the necessary value to obtain extreme values of Ω_{2} in any point of the trajectory, which is calculated from Eq. (7) and illustrated by black points in Fig. 10.
Our study indicates that 6 of 12 TypeF simulations that include GR effects do not produce flipping particles, while, in the others 6 GRsimulations, the number of flipping particles ranges between 23% and 77% of the number of TypeF particles of the system.
Fig. 10 Evolution of the inclination i_{2} and ascending node longitude Ω_{2} of a given particle resulting from the NoGR (red curve) and GR simulations (blue curve). The black dots illustrate the values of the particle’s inclination i_{2} for which the ascending node longitude reaches extreme values given by Eq. (7). The horizontal dashed black line represents a value of the inclination i_{2} of 90°. The planet of the system has a semimajor axis a_{1} of 0.867 au and an eccentricity e_{1} of 0.8. The initial conditions of the particle are a_{2} = 20.792 au, e_{2} = 0.705, i_{2} = 51.09°, ω_{2} = 157.95°, and Ω_{2} = 52.9°.

Open with DEXTER
3.5 TypeR particles with coupling between inclination and ascending node longitude
Our study shows that of the 161 TypeR particles that survived in all our GR simulations, only 4 of them experience a coupling between the inclination i_{2} and ascending node longitude Ω_{2}. Figure 11 shows the evolution of the inclination i_{2} and the ascending node longitude Ω_{2} of two different outer particles of a same system resulting from NoGR (red curve) and GR (blue curve)simulations. The inner planet associated with such a system has a semimajor axis a_{1} = 0.736 au and an eccentricity e_{1} = 0.529. In the NoGR simulations, the orbital plane of every particle flips showing a coupling between i_{2} and Ω_{2}, which is observed in the red curves illustrated on the two panels of Fig. 11. When GR effects are included in the simulations, the dynamical evolution of such particles shows significant changes. In the top panel, the blue curve describes a libration trajectory where the minimum inclination i_{2} ranges between 103.7° and 106.25°, and the values of i_{2} to obtain extreme values of Ω_{2}, which are illustrated as black points, slightly oscillate between 109° and 110.2°. The ascending node longitude Ω_{2} is constrained between two specific values, while the particle only acquires retrograde inclinations during its whole evolution. In the bottom panel, the blue curve illustrates a libration trajectory where the minimum inclination i_{2} ranges between 91.4° and 96.1°, and the values of i_{2} that produce extreme values of Ω_{2}, which are represented as black points, significantly oscillate between 115.32° and 144.75°. As the particle represented in the top panel, the inclination i_{2} only adopts retrograde values while the ascending node longitude Ω_{2} maintains constrained between two given values.
As we have already mentioned, the generation of this class of particles is not efficient in the GR simulations developed in the present research. However, we consider that it is very important to carry out a detailed description of these simulations to reach a correct understanding of the structure dynamical of the outer small body reservoirs.
Fig. 11 Evolution of the inclination i_{2} and ascending node longitude Ω_{2} of a given particle resulting from the NoGR (red curve) and GR simulations (blue curve). The black dots illustrate the values of the particle’s inclination i_{2} for which the ascending node longitude reaches extreme values, which is given by Eq. (7). The horizontal dashed black line represents a value of the inclination i_{2} of 90°. The planet of the system has a semimajor axis a_{1} of 0.736 au and an eccentricity e_{1} of 0.529. Toppanel: The initial conditions of the particle are a_{2} = 15.05 au, e_{2} = 0.143, i_{2} = 106.58°, ω_{2} = 93.67°, and Ω_{2} = 272°. Bottom panel: The initial conditions of the particle are a_{2} = 28.39 au, e_{2} = 0.784, i_{2} = 98.63°, ω_{2} = 90.51°, and Ω_{2} = 251.74°.

Open with DEXTER
4 Conclusions
In this paper, we have studied the role of GR on the evolution of icy small body reservoirs under the effects of an eccentric inner Jupitermass planet produced by a planetary scattering event. To carry out our research, we selected 12 scenarios of work of Paper I, adopting as initial conditions of the test particles the orbital parameters immediately after a dynamical instability event when a single Jupitermass planet survives in each system. To study how the GR effects modify the orbital properties of the test particles, we carried out two sets of Nbody simulations, one of which only included gravitational forces in the evolution (NoGR simulations), while the other also incorporated GR effects in the integration of each of such systems of work (GR simulations).
In absence of GR, the ascending node longitude Ω_{2} of a particle can evolve in two different regimes: libration or circulation. In the libration regime, the ascending node longitude Ω_{2} adopts extreme values for i_{2} = 90°, while the minimum and maximum values of the inclination of the particle allowed for libration trajectories only depends on the eccentricity e_{1} of the inner planet. When the GR effects are included in the simulations, the properties of the particles that evolve on libration mode significantly change. In fact, the extreme values of the ascending node longitude Ω_{2} are obtained for retrograde inclinations, while the minimum and maximum inclination allowed for libration trajectories depends on the mass m_{1}, semimajor axis a_{1}, and eccentricity e_{1} of the inner planet, and the semimajor axis a_{2} and eccentricity e_{2} of the particle. In a given system, the smaller the eccentricity and the greater the semimajor axis of the particle, the higher the minimum and maximum values of the particle’s inclination allowed for libration trajectories. In this context, our results suggest that the minimum and maximum inclination allowed for the libration regime increase in comparison with those values derived without GR effects. According to this, if the GR is included in the simulations, the range of prograde (retrograde) inclinations of the libration region is reduced (increased) with respect to that obtained in absence of GR. It is important to remark that we derived analytical expressions up to quadrupole level of the secular approximation for the inclination that produces the extreme values of the ascending node longitude (Eq. (7)) and for the minimum and maximum inclination allowed for libration trajectories (Eqs. (13)–(16)) when the GR effects are included.
These points have important consequences in the dynamical evolution of the outer particles of a given system. If the range of prograde inclinations for libration trajectories is reduced, the GR results in an efficient suppression mechanism of TypeF particles, which leads to generation of TypeP particles. According to that discussed in the previous paragraph, we notice that the suppression of TypeF particles is an extremely efficient mechanism for very low eccentricity orbits. If the GR enlarges the range of retrograde inclinations for the libration region, TypeR particles in NoGR simulations can evolve as TypeF particle when GR effects are included. However, the suppression mechanism of TypeF particles is the most important in our simulations owing to a strong preponderance of prograde orbits in the initial conditions of the test particles immediately after the dynamical instability event modeled in Paper I.
We remark that a general analysis concerning the structure of the outer small body populations resulting from the GR simulations shows a great diversity of dynamical behaviors. In fact, besides the TypeP, R and F particles that also are present in the outer reservoirs resulting from the NoGR simulations, we distinguished two new classes of particles when GR effects are included. First, the socalled flipping particles, which flip from prograde to retrograde and back again along their evolution without a coupling between the inclination i_{2} and ascending node longitude Ω_{2}. Then, particles that evolve on retrograde orbits show a strong coupling between the inclination i_{2} and ascending node longitude Ω_{2}.
The present research allows us to infer that the GR effects can modify the dynamical structure of outer reservoirs formed from planetary scattering events and evolve under the influence of an inner and eccentric massive perturber. These results have important consequences in the evolution of debris disks associated with planetary systems that host a single inner gaseous giant on an eccentric orbit. In fact, the GR effects must be included in the models aimed at analyzing the debris disks in that class of systems to carry out a correct description concerning the dynamic of such structures. This task is crucial for future studies that develop a collisional evolution of the debris disks with the main goal to quantify their production rate of dust.A comparative analysis between our numerical results and observational data obtained from Spitzer will allow us to constraint our theoretical models and to strengthen our understanding about the collisional and dynamical evolution of the outer reservoirs associated with planetary systems that host an inner and eccentric gaseous giant.
Acknowledgements
This work was partially financed by CONICET and Agencia de Promoción Científica, through the PIP 0436/13 and PICT 20141292. M.Z., G.d.E., and R.D. acknowledge the financial support by FCAGLP for extensive use of its computing facilities. S. N. acknowledges partial support from a Sloan Foundation Fellowship. Finally, we thank the anonymous referee for valuable suggestions, which helped us toimprove the manuscript.
