How to constrain mass and spin of supermassive black holes through their disk emission
^{1}
Dipartimento di Fisica “G. Occhialini”, Università di Milano – Bicocca,
Piazza della Scienza 3,
20126
Milano, Italy
email: sam.campitiello@gmail.com
^{2}
INAF – Osservatorio Astronomico di Brera,
via E. Bianchi 46,
23807
Merate, Italy
^{3}
INAF – Osservatorio Astronomico di Trieste,
via Tiepolo 11,
34131
Trieste, Italy
Received:
5
September
2017
Accepted:
19
November
2017
We investigate the global properties of the radiation emitted by the accretion disk around Kerr black holes. Using the Kerr blackbody numerical model, we build an analytic approximation of the disk emission features focusing on the pattern of the produced radiation as a function of the black hole spin, mass, accretion rate and viewing angle. The assumption of having a geometrically thin disk limits our analysis to systems emitting below ~0.3 of the Eddington luminosity. We apply this analytical model to four blazars (whose jets are pointing at us) at high redshift that show clear signatures of disk emission. For them, we derive the black hole masses as a function of spin. If these jetted sources are powered by the black hole rotation, they must have high spin values, further constraining their masses.
Key words: galaxies: active / quasars: general / black hole physics / accretion, accretion disks
© ESO 2018
1 Introduction
A growing number of supermassive black holes (SMBHs) with masses M ~ 10^{8}–10^{10} M_{⊙} have been observed at high redshifts, but the issue of how they grew so rapidly is still open and under debate. Two possible scenarios can be used in this context: merging between two or multiple black holes, and accretion of material onto the black hole at a high rate (e.g., Haiman & Loeb 2001; Yoo & Escude 2004; Volonteri & Rees 2005; Li et al. 2007; Pelupessy et al. 2007 Tanaka & Haiman 2009). In the latter scenario, accretion affects both the black hole mass and its angular momentum (Bardeen 1970): an initially nonrotating black hole reaches its maximum spin when it has roughly doubled its mass through coherent accretion Thorne (1974). This suggests that highredshift SMBHs should spin rapidly due to their large mass assembled in less than a Gyr (i.e., at redshift ~6). The high angular momentum is a crucial ingredient for the production of powerful relativistic jets (Blandford & Znajek 1977; Tchekhovskoy et al. 2011).
Knowing the mass and spin of SMBHs is necessary to better understand their physics and evolution, even in connection with their host galaxies (e.g., Magorrian et al. 1998; Gebhardt et al. 2000; Ferrarese & Merrit 2000; Marconi & Hunt 2003; Häring & Rix 2004; Gültekin et al. 2009; Beifiori et al. 2012; Kormendy & Ho 2013; McConnell & Ma 2013; Reines & Volonteri 2015). A common evolution is suggested, requiring some form of feedback (see the review by Fabian (2012) and references therein). However, the widely applicable black hole estimation methods still suffer from large uncertainties.
As for the ladder of distances, there is a similar ladder concerning black hole masses. There are primary methods based on masers within the accretion disk (see, e.g., Greene et al. 2010; Kuo et al. 2011; and the review by Tarchi 2012) or indirect methods based on broad emission line widths, gas kinematic tracing and reverberation mapping (e.g., Blandford & McKee 1982; Peterson 1993; Peterson et al. 2004; Onken et al. 2004; Ferrarese & Ford 2005 and references therein; Vestergaard & Peterson 2006; Bentz et al. 2009) leading to the virial mass (e.g., Vestergaard 2002; McLure & Jarvis 2002; Greene & Ho 2005; Vestergaard & Osmer 2009; McGill et al. 2008; Wang et al. 2009; Shen et al. 2011). The latter methods bear large uncertainties (≳0.4–0.5 dex) that are built on the main calibrating correlations used to find the virial mass, and on their systematics (Peterson et al. 2004; Collin et al. 2006; Shen et al. 2008; Marconi et al. 2008; Kelly et al. 2009; Shen & Kelly 2010; Park et al. 2012).
An alternative method is based on the fit of the accretion disk spectrum. In the simplest case, it depends only on the black hole mass M and the accretion rate Ṁ, related to two observables: the disk total luminosity and its peak frequency (hereafter “SED fitting method”; see Calderone et al. 2013). This method is based on the standard alphadisk, geometrically thin, optically thick down to the innermost radius described by Shakura & Sunyaev (1973; hereafter SS), around a nonrotating black hole (BH) and with no relativistic effects included. By fitting the optical/UV SED of AGNs, several authors have determined the black hole mass and the accretion rate (e.g., Shields 1978; Malkan & Sargent 1982; Malkan 1983; Sun & Malkan 1989; Zheng et al. 1995; Trakhtenbrot et al. 2017; Ghisellini & Tavecchio 2009; Sbarrato et al. 2013; Calderone et al. 2013; Capellupo et al. 2015, 2016). Other authors included relativistic effects to describe the emission from the blackbodylike disk (e.g., Novikov & Thorne 1973; Page & Thorne 1974; Riffert & Herold 1995).
However, the origin of the socalled “big blue bump” emission in AGNs is still under debate. As discussed extensively in Koratkar & Blaes (1999) and references therein, simple thermal models do not provide a good description of the accretion disk emission. As these authors point out, some of the most significant inconsistencies of the standard SS disk are:

The broadband continuum slopes α_{ν} (with F_{ν} ∝ ν^{αν}) at optical/nearUV wavelengths found in the literature (e.g., Neugebauer et al. 1979; Berk et al. 2001; Bonning et al. 2007; Davis et al. 2007) are incompatible with the slope α_{ν} = 1∕3, expected from the accretion disk model. We note, however, that the 1/3 slope can be seen at frequencies much lower than the peak, namely in nearIR/optical, where other components contribute (see, e.g., Kishimoto et al. 2008; Calderone et al. 2013).

The spectrum from a simple accretion disk does not reproduce the observed power law extending at Xrays and the soft Xray excess. This is explained by associating the Xray emission to a hot corona sandwiching the accretion disk itself (see, e.g., Pounds et al. 1986; Nandra & Pounds 1994; Fabian & Miniutti 2005).

AGNs with different disk luminosities peak, on average, at similar frequencies (Sanders et al. 1989; Walter & Fink 1993; Davis et al. 2007; Laor & Davis 2011a), but it might not be an evidence against the SS model.

Microlensing observations in AGNs suggest that the accretion disks are larger than the standard αdisk model predicts. Rauch & Blandford (1991), using Scharzschild holes, found that a thermal accretion disk is too large (by a factor ~3) to fit within the microlensing size constraint. Jaroszynski et al. (1992) found instead that accretion disks were consistent with the microlensing constraint, using Kerr holes.
The ongoing discussion is being enriched by the recent discoveries of quasars, at redshifts 2 < z < 6, showing notonly the big blue bump, but also its peak, unaffected by the intervening IGM absorbing material (e.g., Shaw et al. 2012; Ai et al. 2017 for the case of SDSS J010013.02+280225.8 at z = 6.3). In several cases, a SS model provides a good fit to these quasars’ thermal emission. On the other hand, we are aware that this model is too simple to describe in detail the emission coming from the inner regions of the disk affected by strong relativistic effects. Also, the thickness of the disk must not be neglected: Laor & Netzer (1989, hereafter LN89) and McClintock et al. (2006) stated that, in order to be thin (z_{r}∕r < 0.1, where z_{r} is the disk halfthickness) and to be described by the Novikov & Thorne (1973) accretion theory, a disk must have ℓ_{Edd} = L_{d}∕L_{Edd} ≲ 0.3 for a = 0.9982 (ℓ_{Edd} ≲ 0.25 for a < 0). Hence, the results coming from these thin disk models with ℓ_{Edd} > 0.3 could be unreliable (see also Straub et al. 2011 and Wielgus et al. 2016 for the case of ultraluminous Xray sources).
A more complete, relativistic emission model is the Kerr blackbody (KERRBB), designed for Galactic binaries and described by Li et al. (2005, hereafter Li05), who implemented it in the interactive Xray spectral fitting program XSPEC (see Arnaud 1996 and references therein). In this paper we extend this model to SMBHs showing a good match with observational data (see Sect. 5). Since KERRBB describes a thin disk, its results are valid for L_{d} < 0.3L_{Edd}. For larger values, one should use numerical models that account for the disk vertical structure (e.g., slim disks Abramowicz et al. 1988; Sadowski et al. 2011; Straub et al. 2011; Polish doughnuts, Wielgus et al. 2016).
With our approach, we will introduce simple analytic tools to study the impact of different spin values and inclination angles on observable features of the accretion disks surrounding SMBHs. This is an improvement with respect to early works (e.g., Cunningham 1975; Zhang et al. 1977), mostly in the field of Xray binary black holes, since these works explored relativistic correction factors for a limited range of black hole spins and disk inclinations. Our work provides analytic approximations for these factors across the full parameter range of a and θ, under the assumption that KERRBB provides a reasonable description of the spectrum emitted by a disk around both stellar and SMBHs.
In Sect. 2 we describe the basic assumptions of the KERRBB model. In Sect. 3 we focus on how to find accurate analytical formulae that can readily describe the emission pattern of the radiation emitted by disks around Kerr holes (including the case of zero spin). Specifically, in Sect. 3.3 we give the prescription for how to scale from stellar black holes to SMBHs. In Sect. 4 we show that an observed spectrum can be reproduced by a family of KERRBB solutions with different black hole masses, accretion rates and spins. In Sect. 5 we apply the KERRBB model to four blazars finding how their black hole masses change as a function of their spins. In this work, we adopt a flat cosmology with H_{0} = 68 km s^{−1} Mpc^{−1} and Ω_{M} = 0.3, as found by Planck Collaboration XIII (2015).
2 Assumptions on the KERRBB model
For a classical SS model, the observed bolometric disk luminosity scales with the viewing angle θ as (1)
where L_{d} is the total disk luminosity and η = R_{g}∕2R_{in} ~ 0.083 is the Newtonian radiative efficiency (R_{g} is the gravitational radius). As shown in Calderone et al. (2013), the peak frequency ν_{p} and luminosity of the observed disk spectrum scale with the black hole mass and accretion rate as
where Log and Log . With a fixed inclination angle, these simple analytic expressions can be used to infer univocally the black hole mass M and the accretion rate Ṁ. Once we know ν_{p} and , we aim to build an analogous analytic scaling for the KERRBB case.
The KERRBB model is a numerical code that describes the emission from a thin, steady state, general relativistic accretion disk around a rotating black hole. The local emission is assumed to be a blackbody. It was developed by Li et al. (2005) and is an extension of a previous relativistic model called GRAD (Hanawa 1989; Ebisawa et al. 1991), which assumes a nonrotating black hole. KERRBB is the most complete public code for fitting accretion disk spectra because it takes into account all the relativistic effects (i.e. Doppler beaming, gravitational redshift, lightbending, selfirradiation, Li05) and also the effects related to the black hole spin a that determines the inner radius of the disk, the innermost stable circular orbit (ISCO). This radius (R_{ISCO}) controls the radiative efficiency of the system (see also Sect. 3 and Appendix D in Li05). The flux coming from each annulus of the disk, emits like a diluted blackbody with the hardening factor f_{col} = T_{col}∕T_{eff}, where T_{eff} (R) is the effective temperature of the disk given by the StefanBoltzmann law, and T_{col} is the color temperature. The flux also depends on the radius R and the dimensionless black hole spin a (the relativistic flux is fully described in Page & Thorne 1974). The total disk luminosity is a function of the adimensional spin a because the efficiency is related to the BH angular momentum: η = 0.038 for a = −1, η = 0.057 for a = 0, η = 0.324 for a = +0.9982; for a = +1, we formally have η = 0.4226, but this spin value can be reached only by ignoring the capture of radiation by the black hole (Thorne 1974).
In this work, we ignored the Comptonization process described by the hardening factor f_{col} since KERRBB modifies the whole spectrum. The assumption of a color temperature T_{col} higher than the effective local temperature T_{eff} could be true if, for instance, a hot corona is located above and below an otherwise standard accretion disk. In this case, the Comptonization process occurring in the corona can be mimicked by assuming T_{col} > T_{eff}. Although in an AGN the hot corona is present and active, it is so only in the inner regions of the accretion disk, while it is unimportant at larger radii. Hence the KERRBB model must account for this effect only at small radii and the corresponding Xray emission cannot be approximated by a higher temperature of the disk but must be treated as a separate process. Therefore, in this work, we set the hardening factor f_{col} = 1 and do not account for the Comptonization process.
Fig. 1
Schematic view of the photon emission pattern of an accretion disk around a black hole. A distant observer is at the bottom of the figure and sees the disk faceon. For the classical SS model, photon trajectories (red lines) go straight to a distant observer; they are not affected by any relativistic effect. For the KERRBB model, photon trajectories (dotted black lines) are affected by lightbending and change their paths towards different directions with respect to the SS case (the region where lightbending is stronger is inside the dashed blue circle). Along with a lower efficiency, this explains why the KERRBB with the same spin (a = 0) is dimmer than the SS model when observed faceon. The photons emitted in the outer region of the disk are not affected by relativistic effects since they are far from the black hole influence, hence theSS model and the KERRBB model are similar. If the black hole is maximally spinning (a = 0.9982), the disk moves closer to the black hole and relativistic effects become stronger, which along with the larger efficiency make the disk brighter than the previous cases, even if the disk is edgeon with respect the observer. The top axis is the logarithmic distance from the central black hole in units of Rg: R_{ISCO} and radius R_{PEAK} (radius at which the SS emitted flux is maximized) are shown as well.

Open with DEXTER
3 Analytic approximation of KERRBB disk emission
3.1 Disk bolometric luminosity
As shown in Sect. 2, for the classical nonrelativistic SS model, Eq. (1) describes the bolometric luminosity observed at an angle θ, related to the total disk luminosity L_{d} = ηṀc^{2}. Equation (1) is no longer valid in the general relativistic case (Cunningham 1975). In fact, relativistic effects modify not only the size of the inner radius of the disk, but also the pattern of the emitted photons: Fig. 1 compares schematically the photon paths in the cases of SS and a = 0 KERRBB. In this latter case, lightbending plays a crucial role because it bends the photon trajectories towards different directions with respect to the normal of the disk. This effect, along with a lower efficiency η, explains why the a = 0 KERRBB model is dimmer than the SS one, when observed faceon. If the black hole is maximally spinning, the disk moves closer to the black hole and relativistic effects become stronger. Therefore, the efficiency is larger and the relativistic effects stronger, so that the disk is bright even for edgeon observers (see also Fig. 3). Thus, the emission pattern depends rather strongly on the black hole spin a. Our task is to find an analytic expression for the pattern. To this end, we wrote the observed KERRBB bolometric disk luminosity as (4)
This equation must satisfy (5)
Using Eq. (4), this implies (6)
First, we consider the bolometric luminosity of the spectra given by the KERRBB code as a function of the viewing angle θ, for given values of Ṁ, M and a. In this way, we derive the emission pattern numerically. Then we search for an analytic expression that could interpolate the numerical results with good accuracy (see Fig. B.2). We assume that the first term of the analytic expression is cos θ, for an easy comparison with Eq. (1). Therefore, considering Eq. (4), we assume (7)
A good match is found using the following functional form: (8)
In this form, f(θ, a) differs from the numerical result by less than ~1% (see Sect. B.1 for the polynomial function approximation). All the parameters A, B, C, D, E and F are functions of the spin a. We then repeat this analysis using different spin values. With this approach, we study how the values of these parameters change by changing the spin. Again, we search for an analytical function that interpolates the numerical results (see Fig. B.3). We find that a good representation is given by the following function: (9)
The values of α, β, γ, δ, ϵ, ι, κ are listed in Table B.1. The accuracy of Eq. (9) is ~ 1%. For any spin value, the values in Table B.1 can be used to calculate the parameters A,B,... F of Eq. (8). The observed luminosity can therefore be obtained for any disk inclination angle in the range [0^{°}: 85^{°}] (i.e., the angle range of KERRBB). As an example, in the case with a = 0 (η = 0.057), the function that interpolates the observed disk luminosity for different angles θ is (10)
Fig. 2
Emission pattern for different models. The radial axis is the observed efficiency, given by η_{obs} ≡ f(θ, a)η(a), i.e., the observed luminosity normalized on Ṁc^{2} (the accretion rate is the same for each model). Left panel: classical nonrelativistic SS model (dashed blue line) compared with a = −1 (orange line), a = 0 (green line) and a = 0.797 (red line) KERRBB patterns. For the SS model (η_{SS} ~ 0.083), the observedefficiency is η_{obs} = 2cosθη_{SS} ≈ 0.17cosθ. The a = 0.797 case describes the most similar KERRBB model to a SS with the same parameters (mass and accretion rate) at θ = 0^{°}. At different viewing angles, the KERRBB model is brighter. For the SS model, the emission has a circular pattern while for KERRBB, the pattern is “warped” by the relativistic effects. Right panel: SS model (dashed blue line) compared with a = −1 (green line), a = 0.95 (orange line) and a = 0.9982 (red line) KERRBB patterns. For the extreme KERRBB, the emission is strongly modified with respect to the others and the observed disk luminosity is larger for larger angles. Red dots indicate the angle at which the KERRBB observed disk luminosity is maximized, obtained through Eq. (11): for a ≲ 0.8, θ_{max} ~ 2^{°}; for a = 0.95, θ_{max} ~ 25^{°}; for a = 0.9982, θ_{max} ~ 64^{°} (see Table 1 for other spin values).

Open with DEXTER
3.2 Pattern
Through Eq. (4), whose explicit form is Eq. (8), it is possible to study the emission pattern of the Kerr black hole accretion disk. It is interesting to compare it with the pattern of the SS model (i.e. with its cos θ pattern in Eq. (1)). Relativistic effects radically change the θdependence. The observed luminosity is not maximized at 0^{°} any longer, but at a different angle θ_{max}. Setting the derivative of Eq. (8) with respect to θ to zero, we find (11)
with a mean uncertainty of ~5^{°}. The angle θ_{max} increases for increasing spin. For spins a ≲ 0.9, θ_{max} is less than ~10^{°}, i.e., relativistic effects do not strongly modify the emission pattern. For a > 0.9, relativistic effects become stronger: for example, θ_{max} ≃ 25^{°} for a = 0.95 and ≃65^{°} for a = 0.9982 (see Table 1 for other spin values). We note that Eq. (11) is equal to zero also for θ = 90^{°}; this solution must not be considered because Eq. (8) is defined in the interval [0^{°}: 85^{°}].
Figure 2 shows the emission pattern for different models; the radial axis is the observed efficiency η_{obs} ≡ f(θ, a)η(a) for different viewing angles. In the SS case (dashed blue line), η_{obs} = 2cosθη_{SS} ≈ 0.17cosθ. The left panel compares the KERRBB patterns for a = −1 (orange line), 0 (green line) and 0.797 (red line). We note that the SS model, when observed at θ = 0^{°} is well approximated by the KERRBB model with a = 0.797. Indeed the efficiency of a nonspinning black hole (η = 0.057) is lower than the Newtonian one, generally assumed for a SS model (η_{SS} ~ 0.083). Therefore, to match the SS luminosity a larger efficiency is needed, and hence a larger spin. Furthermore, at θ = 0^{°} lightbending decreases the emission in the relativistic case. An even larger spin is thus required to match the SS emission. For the same reason, at larger angles the KERRBB model is brighter. The right panel compares the SS model with the a = −1 (green line), 0.95 (orange line) and 0.9982 (red line) KERRBB patterns. As expected, for larger spins the KERRBB emission is strongly modified and the observed disk luminosity is larger for larger angles. Red dots indicate the angles at which the observed disk luminosity is maximized. The strong modification of the spectrum emission due to the combination of viewing angle and spin is also visualized in Fig. 3: the blue spectra correspond to a = 0, the red spectra to a= 0.9982 (M and Ṁ are the same). In the a = 0 case, relativistic effects are very weak and the spectrum almost follows the cos θ–law. Instead, in the a = 0.9982 cases, is almost constant, even for the largest viewing angles. This is due to the combination of different relativistic effects (Doppler beaming, gravitational redshift and lightbending) along with the black hole spin: the trajectories of the energetic photons coming from the innermost region of the disk (which are very close to the horizon for a → 1) are bent in all directions and the intensity of radiation is almost the same at all viewing angles.
Fig. 3
KERRBB model behavior at different angles and spins. All models have the same M and Ṁ. When a = 0 (blue lines), the disk luminosity decreases as the viewing angle increases in a way similar to cos θ. When the spin is maximal (a = 0.9982, red lines), the lightbending effect, along with Doppler beaming and gravitational redshift are so strong that the luminosity is almost the same, even at large angles. In this case, the trajectories of the energetic photons, produced close to the black hole horizon, are bent in all directions making the radiation intensity almost the same at all viewing angles. For a fixed viewing angle, the lowfrequency part of the spectrum is almost the same for both a = 0 and a = 0.9982; this emission is related to the outer region of the disk where relativistic effects are not as important.

Open with DEXTER
Fig. 4
KERRBB accretion disk spectra with different masses, accretion rates and black hole spins. Left panel: the initial 10M_{⊙} spectrum(blue thick solid line) moves horizontally (i.e., in frequency) when the black hole mass changes (red arrow), and diagonally (i.e., in both frequency and luminosity) when the accretion rate changes (orange arrow). The position of the peak in frequency ν and luminosity νL_{ν} for a givenspin value follows the same shifting equations found by Calderone et al. (2013). Right panel: when Ṁ increases, the 10 M_{⊙} spectrum peak also increases (orange arrow), but less than the increase related to the increase of the spin (green arrow). When a changes the lowfrequency part of the spectrum remains constant, but this occurs at frequencies not visible in the figure. The lowfrequency flux is produced by the outer regions of the disk, unaffected by the black hole spin. About this effect, see also Fig. 3.

Open with DEXTER
3.3 Scaling with black hole mass and accretion rate
In the SS model the position of the peak frequency ν_{p} and the peak luminosity scale with the mass and the accretion rate according to Eqs. (2) and (3). It is possible to find analogous scalings for the KERRBB case. Fixing a and θ in the KERRBB model, the peak position scales following Eqs. (2) and (3), as in SS (Fig. 4). In fact, the assumption of a local blackbody emission leads to a similar temperature profile (Novikov & Thorne 1973; Page & Thorne 1974). Therefore, we write the general KERRBB scalings as
where the functions g_{1} and g_{2} describe the dependencies on the black hole spin a and the viewing angle θ.
Since in the following we apply our method to blazars, believed to have θ ~ 0^{°}, here we are focusing on this case. Therefore, we derived g_{1}(a, θ = 0^{°}) and g_{2}(a, θ = 0^{°}): (14)
Table 2 gives the parameter values of the two functions. Equation (14) approximates numerical data better than ~ 1%. This process can be repeated also for any value of θ, using the corresponding KERRBB results.
It is important to note that the peak frequency and luminosity, described by Eqs. (12) and (13), are degenerate in mass, accretion rate and spin (if θ is fixed). In other words, the same spectrum can be fitted by a family of solutions, by changing M, Ṁ and a in a proper way. Figure 5 shows this degeneracy: starting from model A, by changing M, Ṁ and a we can obtain spectrum D, which is equal to the initial spectrum A^{1}. The overlapping of two models can be done because, as shown in Fig. 4 the accretion rate and the spin move the spectrum peak in different directions.
Since the KERRBB spectrum moves on the Log ν, Log νL_{ν} plane according to Eqs. (12) and (13), we can scale the spectrum from stellar to SMBH masses with fixed spin and θ. This procedure can be done if the emission processes from an accretion disk around a stellar black hole and a SMBH are the same. In our case, in both systems the emission is assumed to be a multicolor blackbody. Figure 6 shows an example of our procedure: starting from a stellar black hole mass (thin solid blue line), the spectrum can be shifted in frequency and luminosity by quantities related to the initial and the final mass: (15)
In this way, it is possible to describe the accretion disk emission data related to SMBHs with KERRBB. In Appendix A, Eqs. (15) are expressed as a function only of the black hole mass. This is possible if the Eddington ratio is the same (Eq. (A.1)).
Values of the viewing angle θ_{max} at which the disk bolometric luminosity is maximized, for different spins, obtained through Eq. (11).
Parameters of the functions g_{1} and g_{2} in Eqs. (12) and (13), written as a general functional (14), in the case with the viewing angle 0^{°}.
Fig. 5
Emission peak of the KERRBB spectrum in the same position for different values of the black hole mass M, accretion rate Ṁ and spin a which shows that there is a family of solutions. Consider spectrum A (thick solid blue line): if M increases at constant Ṁ and spin, spectrum B is obtained. Now, if the spin increases, but M and Ṁ are constant, spectrum C is obtained because a larger spin corresponds to a larger efficiency. Finally, if Ṁ decreases, spectrum D is obtained, which is almost exactly equal to the initial spectrum A (they differ slightly in the highfrequency, exponential part).

Open with DEXTER
Fig. 6
Scaling mass and accretion rate from a stellar black hole to a SMBH. The initial KERRBB model (thin solid blue line) is first shifted in frequency by changing the mass value then in luminosity (and frequency) by changing the accretion disk value according to Eqs. (15). In this way, it is possible to describe the accretion disk emission data related to SMBHs with KERRBB. The initial and the final spectra have the same Eddington ratio L∕L_{Edd} = 0.053. In Appendix A, Eqs. (15) are expressed as a function only of the black hole mass by considering that the Eddington ratio of the initial and the final models must be equal. The lowfrequency part of the spectra is not shown in order to have a clearer figure.

Open with DEXTER
4 Family of KERRBB solutions
Knowing the two observables ν_{p} and , we can identify a family of solutions with M, Ṁ, a and θ linked by Eqs. (12) and (13). In specific cases, it is possible to have independent information on some of these parameters. For instance, for blazars we know that θ = 0^{°}. In this case, if we know the spin we can estimate both M and Ṁ. If instead we have information on the mass, we can estimate a and Ṁ.
Figure 7 illustrates how a, M and Ṁ are related in the case of θ = 0^{°} for a disk emission peaking at Log ν_{p} ≈ 15.05 and Log . This figure shows the allowed solutions as a curve in the Ṁ –M plane. Each point of this curve is associated with a single spin value, as shown by the colorcoding. This is the basis to observationally constrain the physical parameters of a blazar disk, as detailed in Sect. 5.
Fig. 7
KERRBB solutions for a spectrum with Log ν_{p} ≈ 15.05 and Log (Table 3). Black hole spins are constrained using an independent black hole mass estimate Log M_{BH, ind} = 9.1 ± 0.1. In this case, the range of the allowed black hole spins is .

Open with DEXTER
4.1 Constraining the black hole spin
Let us assume that we are observing ν_{p} and . If we have an independent estimate of the black hole mass with its uncertainty (e.g., through the virial method), we can constrain spin and accretion rate of the system. Figure 7 shows Ṁ and a can be found. The vertical stripe corresponds to the independent mass estimate (with its uncertainty). This intercepts the curve of solutions and identifies a range of possible Ṁ and spins. Clearly, the narrower the range of black hole masses, the more precise the Ṁ and a estimates. When no independent mass estimate is available, a rough limit can be given by assuming that the disk luminosity is subEddington: this yields a lower limit on M and a, and an upper limit on Ṁ.
4.2 Constraining the black hole mass
Parallel to the previous subsection, let us now suppose that we have an independent estimate on the black hole spin and its uncertainties. Figure 7 shows that this range corresponds to a section of the solution curve, allowing one to find a corresponding range of M and Ṁ. Differently from the black hole mass estimates, which are easily applicable and widely used, deriving the spin is more difficult. However, there is a general consensus that relativistic jets are generated by tapping the rotational energy of black holes with large spins. In the next section we will use this property to derive the black hole masses and accretion rates of two blazars.
5 Application to blazars
To apply our method, we choose a class of sources for which we know the inclination and for which we believe that their black holes are rapidly spinning. As explained above, this allows us to constrain their masses and accretion rates.
We selected the blazar S5 0014+813 (z = 3.366), already studied by Kuhr et al. (1981, 1983); Ghisellini et al. (2009) and Sbarrato et al. (2016); the blazar SDSS J013127.34032100.1 (z = 5.18), already studied by Yi et al. (2014) and Ghisellini et al. (2015); and the blazars SDSS J074625.87+254902.1 and SDSS J161341.06+341247.8, both from the FermiLAT and SDSS catalogs (Shen et al. 2011; Shaw et al. 2012). Their high redshifts shift the accretion disk peak in an observable frequency range, namely in the optical band.
In the SED fitting process, we assume a disk inclination angle of θ = 0^{°} appropriate for blazars: if a larger angle is used (but still <5^{°}), the results do not change significantly. We did not consider the frequencies higher than the Lyman α line (Log ν = 15.4) because a prominentabsorption feature is usually present due to intervening clouds absorbing hydrogen Lyman alpha photons at wavelengths <1216 Å. Also, we did not account for IR data points (Log ν < 14.5) probably related to the emission of a dusty torus and/or a nonthermal emission (i.e. synchrotron).
Figure 8 shows the SEDfit of the four blazars along with the Lyman α line position (orange line). The SEDfitting solutions for the black hole mass M_{Kerr} and accretion rate Ṁ_{Kerr} are shown in Fig. 9. The relative SS solutions are shown with blue dots. Figure 10 shows the Eddington ratio of the sources as a function of the black hole spin.
Fig. 8
Top left panel: SED of the blazar S5 0014+813 along with a KERRBB model (blue line). The model has ν_{p} ≈ 15.33 and . The SS mass is Log M_{SS} = 9.96; the KERRBB mass limits, corresponding to a = −1 and a = 0.9999, are Log M_{Kerr} = 9.59 − 10.16. In the SED fitting process we did not account for the data point at Log ν ~ 15.4, probably contaminated by the Lyman α line. Top right panel: SED of the blazar SDSS J013127.34032100.1 along with a KERRBB model (blue line). The solid blue line has ν_{p} ≈ 15.21 and . The relative SS mass is Log M_{SS} = 9.91; the KERRBB mass limits, corresponding to a = −1 and a = 0.9999 are Log M_{Kerr} = 9.54 − 10.11. The solid black line is the continuum extrapolated from Yi et al. (2014). Bottom left panel: SED of the blazar SDSS J074625.87+254902.1 along with a KERRBB model (blue line). The model has ν_{p} ≈ 15.38 and . The SS mass is Log M_{SS} = 9.07; the KERRBB mass limits, corresponding to a = −1 and a = 0.9999, are Log M_{Kerr} = 8.70 − 9.26. The solid black line is the continuum extrapolated from the SDSS catalog. Bottom right panel: SED of the blazar SDSS J161341.06+341247.8 along with a KERRBB model (blue line). The model has ν_{p} ≈ 15.22 and . The SS mass is Log M_{SS} = 9.45; the KERRBB mass limits, corresponding to a = −1 and a = 0.9999, are Log M_{Kerr} = 9.08 − 9.65. The solid black line is the continuum extrapolated from the SDSS catalog. In all panels, the orange vertical line highlights the Lyman α line position; we did not consider the frequencies higher than this line for our fit. The IR data (Log ν < 14.5) are probably related to the emission of a dusty torus and/or a nonthermal emission (i.e., synchrotron) and we did not account for them for the fit.

Open with DEXTER
Fig. 9
KERRBB fit solutions of the four blazars. The SS solutions for the same spectrum peak position (blue dots) correspond to the KERRBB solutions with a ~ 0.8 (see Table 4 for the peak position and other parameters). KERRBB black hole mass (accretion rate) is larger (smaller) than the SS value for a ~ > 0.8.

Open with DEXTER
Fig. 10
KERRBB Eddington ratio of the sources as a function of the black hole spin (θ = 0^{°}). The dotted line represents the thin disk Eddington ratio limit following LN89. According to this limit, the results could be trustworthy for only two sources because of the thin nature of the disk.

Open with DEXTER
5.1 S5 0014+813
The SS mass and accretion rate are Log M_{SS} = 9.96 and Ṁ_{SS} = 182.9 M_{⊙} yr^{−1}, with the spectrum peak in the same position: Sbarrato et al. (2016) gave a confidence range of Log M_{BH} = 9.87 − 10, using a SS model. Assuming a black hole spin a ≲ 0.8 (a ≳ 0.8), the KERRBB mass (accretion rate) is smaller (larger) than the SS value. If the black hole has a spin a = 0.9, the mass will be Log M_{0.9} = 10.04; if is maximally spinning (a = 0.9982), the mass will be Log M_{0.9982} = 10.14. The accretion rate Ṁ_{0.9} = 153.3 M_{⊙} yr^{−1} and Ṁ_{0.9982} = 106.4 M_{⊙} yr^{−1}. In the SEDfitting process we did not account for the photometric point at Log ν ~ 15.4 (Fig. 8, left panel), probably contaminated by the Lyman α line. Through the SED fitting process, we found that for all spin values, the Eddington ratio of the source is ℓ_{Edd} ≳ 0.95 (Fig. 10), in contrast with LN89 and the Eddington ratio limit for thin disks. For this reason, a different model must be used given the high accretion rates (e.g. slim disk).
5.2 SDSS J013127.34032100.1
The SS massand accretion rate are Log M_{SS} = 9.91 and Ṁ_{SS} = 47.8 M_{⊙} yr^{−1}, with the spectrum peak in the same position: Ghisellini et al. (2015) found a range of Log M_{BH} = 9.95–10.11 using a SS model. If the black hole has a spin a = 0.9, the mass will be Log M_{0.9} = 9.99; if maximally spinning (a = 0.9982), the mass will be Log M_{0.9982} = 10.09. The accretion rate Ṁ_{0.9} = 40 M_{⊙} yr^{−1} and Log Ṁ_{0.9982} = 27.8 M_{⊙} yr^{−1}. Yi et al. (2014) estimated the virial mass of the blazar using MgII line: they found (Log ) with systematic uncertainty of ~0.4–0.5 dex. That estimate is smaller than the value found in this work, but compatible if one considers the large systematic uncertainty on the virial mass. Regarding the Eddington ratio, it is always ℓ_{Edd} < 0.59 and, following LN89, it is easy to see in Fig. 10 that this source is close the limit of the thin disk reliability; as for S5 0014+813, afurther check with a different model is necessary.
5.3 SDSS J074625.87+254902.1
The SS massand accretion rate are Log M_{SS} = 9.07 and Ṁ_{SS} = 4.5 M_{⊙} yr^{−1}, with the spectrum peak in the same position. If the black hole has a spin a = 0.9, the mass will be Log M_{0.9} = 9.15; if maximally spinning (a = 0.9982), the mass will be Log M_{0.9982} = 9.25. The accretion rate Ṁ_{0.9} = 3.8 M_{⊙} yr^{−1} and Log Ṁ_{0.9982} = 2.6 M_{⊙} yr^{−1}. From the Shen et al. (2011) catalog, the virial mass of the black hole is found from the CIV line: M_{BH} = 9.59 ± 0.16, with systematic uncertainty of ~0.4–0.5 dex. This estimate is larger than our result, but compatible if one considers the large systematic uncertainty on the virial mass. The Eddington ratio is always ℓ_{Edd} < 0.38; following the LN89 Eddington ratio limit, one can find that for a < 0.25 the thin disk approximation is no longer valid (Fig. 10).
5.4 SDSS J161341.06+341247.8
The SS mass and accretion rate are Log M_{SS} = 9.45 and Ṁ_{SS} = 6.3 M_{⊙} yr^{−1}, with the spectrum peak in the same position. If the black hole has a spin a = 0.9, the mass will be Log M_{0.9} = 9.53; if maximally spinning (a = 0.9982), the mass will be Log M_{0.9982} = 9.64. The accretion rate will be Ṁ_{0.9} = 5.3 M_{⊙} yr^{−1} and Log Ṁ_{0.9982} = 3.7 M_{⊙} yr^{−1}. From the Shen et al. (2011) catalog, the virial mass of the black hole is found from the MgII line: M_{BH} = 9.69 ± 0.02 with systematic uncertainty of ~0.4–0.5 dex. This estimate is slightly larger than our result. The Eddington ratio is always ℓ_{Edd} < 0.23, in agreement with LN89.
6 Summary and conclusions
In this work, we studied the radiation and emission pattern from an accretion disk around a spinning black hole. We built an analytic approximation of the numerical model KERRBB (Li et al. 2005), developed for Xray binaries and accounting for all the relativistic effects. With this approach we managed to extend its use to SMBHs. Then we applied our analytic method to four wellknown highredshift blazars in order to derive a new estimate of their black hole mass and accretion rate. We hope that this method will allow an easy use of a relativistic and rather complete accretion disk model.
6.1 Accretion disk emission pattern
In Sect. 3, we studied how the observed luminosity of the accretion disk depends on the viewing angle and the BH spin. We obtained a phenomenological function f(θ, a) in Eq. (8) that closely approximates the variation of the observed luminosity at different θ and a values. The availability of an analytic expression for the bolometric luminosity related to a spinning black hole can be extremely useful in the analysis of the disk emission features. The pattern can be visualized in Fig. 2 which shows the following:

A larger spin implies a larger bolometric luminosity. The increase of luminosity and the strength of the relativistic effects on the pattern are more pronounced for a ≳ 0.8.

At a fixed viewing angle, there is a KERRBB model equivalent to a SS one with the same parameters (mass and accretion rate). At θ = 0^{°}, the equivalent KERRBB has spin a ~ 0.8. In fact, in order to emit the same luminosity, the KERRBB emission must have a larger efficiency, hence a larger BH spin value. In this way, the two models are equivalent around θ = 0^{°} but, at larger viewing angles, the KERRBB model is brighter because of the strong relativistic effects.

Relativistic effects modifies the pattern at different viewing angles: the simple cosθ–law (followed by the SS model) is no longer valid, mostly due to lightbending. Hence the maximum observed luminosity is no longer at θ = 0^{°} but at larger viewing angles for larger spin values (see Table 1).

The relativistic KERRBB disk emission pattern could be a useful tool for studying the disk’s surrounding environment (Broad Line Region, dusty torus) which absorbs a fraction of the disk luminosity. In this way it is possible to constrain some of the AGN properties (Campitiello et al., in prep.).
6.2 Scale relations and family of solutions
Both the SS and KERRBB models rely upon the assumption of a geometrically thin and optically thick disk. Therefore, the KERRBB disk emission scales with black hole mass and accretion rate as in the SS case (Calderone et al. 2013). This is used to scale the KERRBB spectrum from a stellar to a SMBH. Using KERRBB results, we derived Eqs. (12) and (13) to express peak frequency and luminosity of the spectrum as a function of a, M, Ṁ and θ. As illustrated in Fig. 5, for any given viewing angle, the same spectrum can be reproduced by a family of solutions with different values of the parameters. Since the spin values are limited in the range [−1, 0.9999], we expect to find limited ranges also for M and Ṁ.
In general, we have four free parameters and two observables (ν_{p} and ). In specific cases, we have some reliable indications about the viewing angle. Therefore, if we independently know one of the three remaining parameters, we can estimate the other two.
6.3 Application to data: mass and spin estimate
In Sect. 5 we used KERRBB to fit four blazars (S5 0014+813, SDSS J013127.34–032100.1, SDSS J074625.87+254902.1, SDSS J161341.06+341247.8). Their blazar nature guarantees a very small viewing angle. Furthermore, we can confidently assume a large value of the spin of their black holes. Hence, we estimated the SMBH mass considering a = 0.9 and a = 0.9982. Figure 8 shows the SED of the two blazars and the model, while Fig. 9 shows how M and Ṁ change as a function of the spin for the entire spin range listed in Table 4. We obtained Log M_{BH} ~ 10.05 and 10.14 (S5 0014+813, for a = 0.9 and 0.9982 respectively), Log M_{BH} ~ 9.98 and 10.09 (for SDSS J0131–0321), Log M_{BH} ~ 9.15 and 9.25 (for SDSS J0746+2549), Log M_{BH} ~ 9.53 and 9.64 (for SDSS J1613+3412).
These sources have different Eddington ratios for a ≥ 0.9, from ~1 to ~ 0.11 (Table 4): the KERRBB solutions related to S5 0014+813, SDSS J013127.34032100.1 and SDSS J074625.87+254902.1 (only for a < 0.25) are in contrast with the assumption of LN89 regarding the thin nature of the disk. This suggests that the disk might be slim or thick and it is necessary to check these sources with different models that account for the modification due to the vertical structure and the high accretion rates. Instead the results related to the source SDSS J161341.06+341247.8 are more trustworthy. We conclude that, although the sources are near or below the Eddington limit, the KERRBB model can be used to obtain a good fit of the data. Also, even if this model is incomplete and inappropriate for extreme luminous sources (and/or for certain spin values), it can be used as a means to understand the nature of the disk; in other words, if a source has ℓ_{Edd} > 0.3 (calculated with KERRBB), this suggests that the thin disk approximation is not valid and one should use a slim/thick disk model (e.g., SLIMBB, Polish doughnuts; Sadowski et al. 2011; Straub et al. 2011; Wielgus et al. 2016).
In principle, we could use our method to find the BH spin once a reliable estimate of the BH mass is available. Currently, the virial BH masses have an average uncertainty of 0.4–0.5 dex, which leads only to a poor constraint on a. However, when more precise BH mass estimates are available, the method will provide robust spin estimates and thus new insights into BH physics.
Results from the fit of four blazars.
Appendix A: Shifting equations
Equations (15) describe the relations that allow us to rescale the initial spectrum with mass M_{in} and Ṁ _{in} to a new spectrum with final M_{fin} and Ṁ_{fin}, with a fixed black hole spin. If, in the transformation, the Eddington ratio ℓ = L∕L_{Edd} remains the same, the equations become functions only of the black hole mass. In fact, we can write
where C = 6.32 ⋅ 10^{4} erg s^{−1} g^{−1}. With ℓ_{Edd} = ηṀc^{2}∕CM, if we assume the same Eddington ratio ℓ_{in} = ℓ_{fin}, the relation between Ṁ and M can be found and it leads to (A.1)
Appendix B: KERRBB Observed luminosity
In Sect. 3.1, we showed that an analytic expression that approximates the observed frequency integrated luminosity of an accretion disk around a rotating black hole can be written as (B.1)
where L_{d} = η(a)Ṁc^{2} is the total disk luminosity. All the parameters A, B, C, D, E, F are functions only of the black hole spin a, like the radiative efficiency η(a). In order to find the expression for the observed luminosity, for a given value of a, a set of viewing angles θ has been chosen (from 0^{°} to 85^{°}), and the integrals over frequency of the KERRBB spectra have been computed. We fitted the KERRBB spectra and found the empirical expression (B.1). Figure B.2 shows the bolometric luminosities of the KERRBB spectra as a function of the viewing angle, for spin a = −1, − 0.6, 0.6 and 0.998 (red dots), and the fitting function (B.1) (blue line). We note the different behaviors: in the cases a = −1, − 0.6 and 0.6, the bolometric luminosity between the cases 0^{°} and 85^{°} decreases by a factor of ~ 7, 6.6 and 4.4, respectively^{2}. In the case with a = 0.998, the strong relativistic effects cause the luminosity to reach a maximum value at ~ 64^{°} (see Table 1), and then make it drop at larger viewing angles. The cases with 0^{°} and 85^{°} have almost the same luminosity (see also Figure 3), contrary to the smallspin cases. We note how the residuals are always on the order of ~ 0.01%, hence function (B.1) represents a very good approximation.
Fig. B.2
KERRBB disk bolometric luminosity (in units of erg/s) as a function of the viewing angle of the disk, in the cases with a = −1, a = −0.6, a = 0.6 and a = 0.998, with Ṁ = 10^{18} g/s. The fitting function (blue line) has the general form of (8) with different values for the parameters, in the different cases. We note the different behaviors: in the cases a = −1, − 0.6 and 0.6, the bolometric luminosity, between the cases 0^{°} and 85^{°}, decreases by a factor of ~7, 6.6 and 4.4, respectively. In the case with a = 0.998, the luminosity reaches a maximum value at ~64^{°} (see Table 1) then drops at larger viewing angles.

Open with DEXTER
Figure B.3 shows the parameters A, B, C, D, E and F for different values of the spin in order to find their dependence on it. As shown in Sect. 3.1, the common fitting equation (blue line) can be written as (B.2)
Fig. B.3
Parameters A, B, C, D, E and F of Eq. (8) as a function of the black hole spin a. The fitting function (blue line) has the general form of Eq. (9). We note how the residuals are always on the order of 1% (or less), except for F (on the order of ~10%). These relatively large residuals for F could be reduced using more than six parameters for the fit, but we found it unnecessary for the aim of this work. Red bars are associated with the uncertainties on the parameter values from the fit of the bolometric luminosity at different viewing angles (Fig. B.2.)

Open with DEXTER
The values of α, β, γ, δ, ϵ, ι, κ are listed Table B.1. we note how the residuals are always on the order of 1% (or less), except for F (on the order of ~ 10%). These large uncertainties could be reduced using more than six parameters for the fit, but we found it unnecessary for the aim of this work.
Polynomial approximation of the observed disk luminosity
Once a, Ṁ and θ are fixed, Eq. (B.1) needs 37 parameters for the description of the observed frequency integrated disk luminosity with an accuracy of ≲1%. Another approximation for can be expressed with the following polynomial function: (B.3)
The 12 parameters of this function are given in Table B.2. The function is valid for a ∈ [−1: 0.998] and θ ∈ [0^{°}: 80^{°}]. The accuracy of this polynomial approximation is ~10%, less accurate than Eq. (B.1) (differences growing with spin, larger for θ ≳ 70^{°}), but still good enough to obtain the bolometric disk luminosity for a wide range of spins and angles (Fig. B.1). However, because of its accuracy, this approximation does not allow the user to study the emission pattern precisely, as Eq. (B.1) does (see Fig. 2).
Fig. B.1
KERRBB disk bolometric luminosity as a function of the viewing angle of the disk, fitted bythe best function (Eq. (B.1), blue lines) and the polynomial function (Eq. (B.3), red lines) for different spin values. Dots represent the KERRBB results with Ṁ = 10^{18} g/s. By increasing the spin, the differences between the two functions grow.

Open with DEXTER
Appendix C: Relations between mass, accretion rate and spin
As shown before, the corrected equations for the KERRBB peak frequency and luminosity are Eqs. (12) and (13). By fitting the variation of the spectrum peak position at different spin values and fixed θ = 0^{°}, functions g_{1}(a, θ = 0^{°}) and g_{2}(a, θ = 0^{°}) have been expressed as a functional given by Eq. (14). As pointed out before, the frequency ν_{p} and the luminosity are degenerate in mass, accretion rate and spin (if the viewing angle θ is fixed); the same KERRBB spectrum (i.e., the emission peak in the same position) can be fitted by a family of solutions by changing the black hole mass, accretion rate and spin in the proper way (see Fig. 5). It is important to note that when the disk viewing angle θ is fixed, the quantities M, Ṁ and a are connected to each other: knowing the value of one of them fixes the values of the other two. Given a peak position , using Eqs. (12) and (13), the relations between the black hole mass M the accretion rate Ṁ and the black hole spin a can be found easily. Figure C.1 (left panel) shows the relation between the accretion rate Ṁ and the black hole spin a: it is easy to see that by increasing the spin (i.e., increasing the radiative efficiency η), the accretion rate must decrease in order to keep the same peak luminosity. The right panel shows the relation between the black hole mass M and the spin a: by increasing the spin, the black hole mass must increase as well. Figure 5 is useful to explain this feature: by increasing the spin value, the spectrum peak moves to higher frequencies and luminosities, hence by increasing the mass value and decreasing the accretion rate, the peak moves to lower frequencies and luminosities (i.e. to the initial position). We note that the KERRBB mass (accretion rate) is larger (smaller) than the SS value only for spin values a ≳ 0.8.
Fig. C.1
Top panel: relation between the accretion rate Ṁ and the spin a: different lines are related to different values of peak luminosity . Bottom panel: relation between the black hole mass M and the spin a: different lines are related to different couples of peak frequency and luminosity . For every line, the spectrum peak ν_{p} – and the viewing angle θ = 0^{°} remain fixed. The SS solutions (horizontal dotted lines) with the same peak frequency and luminosity correspond to the KERRBB model with a ~ 0.8 (vertical dotted line). Since the spectrum peak moves to higher frequencies and luminosities by increasing the spin value (see Fig. 5), the mass and the accretion rate must increase and decrease, respectively, in order to keep the spectrum peak in the same position.

Open with DEXTER
