Contribution of modecoupling and phasemixing of Alfvén waves to coronal heating
School of Mathematics and Statistics, University of St. Andrews, North Haugh, St. Andrews, Fife, KY16 9SS, UK
email: pp25@standrews.ac.uk
Received: 14 November 2016
Accepted: 14 March 2017
Context. Phasemixing of Alfvén waves in the solar corona has been identified as one possible candidate to explain coronal heating. While this scenario is supported by observations of ubiquitous oscillations in the corona carrying sufficient wave energy and by theoretical models that have described the concentration of energy in smallscale structures, it is still unclear whether this wave energy can be converted into thermal energy in order to maintain the milliondegree hot solar corona.
Aims. The aim of this work is to assess how much energy can be converted into thermal energy by a phasemixing process triggered by the propagation of Alfvénic waves in a cylindric coronal structure, such as a coronal loop, and to estimate the impact of this conversion on the coronal heating and thermal structure of the solar corona.
Methods. To this end, we ran 3D MHD simulations of a magnetised cylinder where the Alfvén speed varies through a boundary shell, and a footpoint driver is set to trigger kink modes that mode couple to torsional Alfvén modes in the boundary shell. These Alfvén waves are expected to phasemix, and the system allows us to study the subsequent thermal energy deposition. We ran a reference simulation to explain the main process and then we varied the simulation parameters, such as the size of the boundary shell, its structure, and the persistence of the driver.
Results. When we take high values of magnetic resistivity and strong footpoint drivers into consideration, we find that i) phasemixing leads to a temperature increase of the order of 10^{5} K or less, depending on the structure of the boundary shell; ii) this energy is able to balance the radiative losses only in the localised region involved in the heating; and iii) we can determine the influence of the boundary layer and the persistence of the driver on the thermal structure of the system.
Conclusions. Our conclusion is that as a result of the extreme physical parameters we adopted and the moderate impact on the heating of the system, it is unlikely that phasemixing can contribute on a global scale to the heating of the solar corona.
Key words: Sun: corona / Sun: oscillations / Sun: magnetic fields / magnetohydrodynamics (MHD) / waves
© ESO, 2017
1. Introduction
The coronal heating has been an unsolved problem for several decades, and the mechanism behind the milliondegree hot solar corona is still unclear. Of course, all this time has not been passed idly, and different generations of instruments and models have brought further insights to the problem. We recommend De Moortel & Browning (2015) and references therein for a comprehensive review.
One of the candidates suggested to explain coronal heating is phasemixing of Alfvén waves (Heyvaerts & Priest 1983), which is one of the main models where Alfvén waves are put forward to explain the thermal structure of the solar corona (see Arregui 2015, for a more extended review). In this specific model, localised smallscale gradients develop when Alfvén waves propagate at different speeds and these are preferred locations where magnetic and kinetic energy can be converted into heating. Recently, this model has fallen under careful scrutiny from the coronal physics community because theoretical results and observations have opened the possibility for phasemixing to explain coronal heating (e.g. Cargill et al. 2016).
Oscillations in the solar corona have been observed for more than a decade, and some studies have suggested that the damping of waves could be connected with coronal heating (Nakariakov et al. (1999). However, observations of ubiquitous Alfvén waves have only more recently concluded that waves carry enough energy to account for the coronal heating (Tomczyk et al. 2007; Jess et al. 2009; McIntosh et al. 2011), where wave disturbances are sufficiently intense to power the quiet Sun and coronal holes, while active regions remain off the range by an order of magnitude (see also De Moortel & Nakariakov 2012, for a more comprehensive review). Morton & McLaughlin (2013) focused on lowamplitude oscillations, where the authors found that wave activity is low over an extended period of time, and these oscillations would not be able to match the energy requirements of active regions. Threlfall et al. (2013) identified unambiguous wave propagations by simultaneously measuring the velocity and displacement of observed coronal loops that López Ariste et al. (2015) have interpreted as combined propagation of kink and sausage wave modes.
At the same time, a number of studies have shown that transverse waves are damped in the solar corona, opening the way for the possibility that the energy previously observed in the form of waves could be converted into coronal heating. Morton et al. (2014) analysed the power spectra of transverse motions in the solar corona and chromosphere and have discovered frequencydependent transmission profiles generated by the damping of kink waves in the lower corona. Hahn et al. (2012) came to similar conclusions from observing the line width of coronal lines in coronal holes, adding that such damping could account for a major portion of the energy required to heat these structures. Pascoe et al. (2016) observed and analysed the damping of some coronal loop oscillations by making a detailed seismologic analysis to retrive the loop parameters, while Goddard et al. (2016) examined a large set of kink oscillations to carry out a statistical study on how these oscillations undergo damping in the solar corona. Additionally, other studies have compared observed heating properties with models in order to constrain the models. Van Doorsselaere et al. (2007) found that coronal loop heating profiles match a resistive wave heating mechanism better than a viscous one. Okamoto et al. (2015) observed the oscillations of threads of a coronal prominence, identified as standing Alfvén waves, and their subsequent damping, and Antolin et al. (2015) argued that the observed damping of the oscillations is enhanced by the development of KelvinHelmotz instabilities at the boundaries of the threads.
On the theoretical side, the highly structured solar corona suggests the presence of numerous interfaces between the many magnetic structures where plasma and magnetic field vary and offers the ideal environment where Alfvén waves can propagate at different speeds. At the same time, such coronal structures are anchored to the base of the corona where footpoints move horizontally as a result of photospheric and chromospheric motions, which means that they move transversally to the magnetic field and are likely to cause phasemixing of transverse waves. In this context, the magnetohydrodynamical (MHD) numerical experiments of Pascoe et al. (2010), Pascoe et al. (2011), Pascoe et al. (2012), and Pascoe et al. (2013) have shown that phasemixing can be triggered in the solar corona when kink oscillations of coronal loops lead to the propagation of Alfvénic waves along the inhomogeneous flux tube. It has been reliably proven that this process leads to the concentration of wave energy in the inhomogeneous boundary shell and the formation of smallscale structures. This model has also described that the structures generated by the phasemixing on the boundary shell become increasingly smaller. This result has been validated in different and increasingly realistic configurations, and it has been concluded that this energy eventually needs to be dissipated. Earlier on, ideal MHD simulations by Poedts & Boynton (1996) had estimated the heating that is due to phasemixing of Alfvén waves propagating along a magnetised cylinder by assuming turbulent heating following the ideal evolution. Soler et al. (2016) ran a similar analysis of propagating Alfvén waves in prominences, but approached the problem from an analytical point of view and also estimated the heating that can derive from this process. They found that wave heating can contribute a fraction of the radiative losses and only under certain conditions.
These data and numerical experiments have opened up the possibility that the damping of kink oscillations could contribute to the coronal heating, and with this premise, phasemixing is a likely candidate mechanism that could enhance the damping of waves and lead to the conversion into coronal heating. The aim of this work is therefore to test this hypothesis and to assess the possible contribution to coronal heating that can derive from the damping of kink waves through phasemixing.
To this end, we continue the study of Pascoe et al. (2010), where MHD simulations of a magnetised cylinder with the presence of a driver at one of the footpoints are used to simulate the propagation of a kink mode in a coronal loop and the subsequent modecoupling with the (m = 1) Alfvén mode of the loop and dissipation of these waves through phasemixing. In our simulations we also account for nonideal terms such as magnetic resistivity and thermal condution in order to investigate how much energy is converted into heating and how the plasma temperature changes following this process. To do so, we first run a reference MHD simulation where a single pulse driver is set in, and we analyse the energy deposition in the boundary shell. We then run a series of simulations where we investigate the role of the width and shape of the boundary shell, and how the results change when a continuous driver acts instead of a single pulse.
The paper is structured as follows: in Sect. 2 we describe our reference model, in Sect. 3 we analyse our reference simulation in full detail, in Sect. 4 we vary some properties of the boundary shell and the driver, and in Sect. 5 we discuss our results and draw some conclusions.
2. Model
In order to investigate the deposition of thermal energy in the solar corona during the modecoupling and phasemixing, we devise a numerical experiment following the same pattern as introduced by Pascoe et al. (2010), Pascoe et al. (2011), and Pascoe et al. (2012).
2.1. Initial condition
We consider a cylindrical flux tube where we define an interior region, a boundary shell, and an exterior region (Fig. 1). The system is set in a Cartesian reference frame with z being the direction along the cylinder axis, and x and y define the plane across the cylinder section. The origin of the axes is placed at the centre of one footpoint of the cylinder. The cylinder has radius a, the interior region has radius b, and the boundary shell covers a fraction l = ^{(}a−b^{)}/a of the cylinder radius. The boundary shell is the ring between radii b and a, and the exterior region is the rest of the domain beyond radius a.
Fig. 1 Sketch to illustrate the geometry of our system and the Cartesian axes.

Open with DEXTER
The interior region is denser than the exterior, and the density increases over the boundary shell defined as a function of ρ_{e}, ρ_{i}, a, and b: (1)where is the radial distance from the centre of the cylinder, ρ_{e} is the density in the exterior region, and ρ_{i} is the density in the interior. The temperature of the plasma, T, is assumed uniform at T_{0}, and the thermal pressure, p, is set by the equation of state (2)where m_{p} is the proton mass and k_{b} is the Boltzmann constant. The flux tube is initially in equilibrium, and in order to allow the propagation of kink waves and provide magnetohydrostatic equilibrium, we set a nonuniform magnetic field, B, along the zdirection: (3)which balances the varying thermal pressure, where B_{e} is the value of the field in the exterior region, p_{e} is the thermal pressure in the exterior region (derived from ρ_{e} and T_{0}), and p is the local value of the thermal pressure. In Table 1 we list the values of the free parameters used to set up our specific experiment.
Parameters.
Fig. 2 Cuts of our initial condition for our MHD model across the cylinder. a) Density; b) zcomponent of the magnetic field; and c) Alfvén speed.

Open with DEXTER
Fig. 3 Settings for the driver. a) Time evolution of the cylinder centre footpoint displacement as a function of time (blue line) and the consequent velocity displacement (red line). b) Map of the density of the driver at t = 0.5P with the velocity arrow overplotted. The maximum velocity in the cylinder at this time is V_{0}, according to Table 2.

Open with DEXTER
Figure 2 shows the value of ρ, B_{z}, and the corresponding Alfvén speed (V_{A}) across the cylinder. In particular, V_{A} is higher in the exterior region and decreases in the boundary shell, where the maximum gradient is at r ≃ 0.8a. With the present parameters, the plasma β is uniformly β = 0.02.
2.2. Driver
A driver acts on the system in order to initiate the propagation of Alfvénic waves within the system (represented in pink in our sketch in Fig. 1). The driver is prescribed by the displacement along the xaxis of the flux tube below the lower z boundary of the cylinder and by the consequent velocity perturbation. Specifically, Fig. 3a (blue line) shows the position of the centre of the flux tube as a function of time, whose expression is given by (4)where V_{0} is the amplitude of the speed of the displacement, ω = 2π/P is the angular frequency derived by the period of the oscillations P, and V_{0}/ω is the following spatial displacement of the centre of the flux tube. The driver sets in at t = 0 and stops at t = P. This displacement of the flux tube leads to a uniform velocity perturbation within the interior region and the boundary shell that is described by the time derivative of Eq. (4) (Fig. 3a, red line): (5)As in Pascoe et al. (2011), this choice for the driver combines an oscillatory motion at the footpoint (~sin(ωt)) with an envelope of sin(ω/ 2t) to ensure a smooth (continuous) acceleration at t = 0. In the exterior region, we assume that the system reacts to the flux tube motion as a 2D dipole velocity configuration, so that the x and y components of the velocity in the exterior region can be written as a function of time and space as This choice allows a smooth transition between the boundary shell and the exterior region as the velocity amplitude is never discontinuous and mimics plasma flows around the magnetised cylinder when in motion. Figure 3b shows the driver configuration at t = P/ 2 when the velocity is maximum and the flux tube is at its rest position.
Parameters.
Table 2 summarises the values we used to set up the driver in our numerical experiment.
The value of V_{0} we chose is one tenth of the Alfvén speed in the interior and is a relatively high value with respect to the usually considered horizontal footpoint motions (Threlfall et al. 2013). The period of the driver is designed to produce a visible effect on the present numerical experiment and is not meant to represent a significant frequency in the power spectrum of the corona. At the same time, while the period is well below the peak of the 5 min, oscillations of the order of seconds could still contribute to the power spectrum of the velocity perturbation at the coronal footpoints.
2.3. MHD simulation
In order to study the evolution of the system caused by the footpoint driver, we used the MPIAMRVAC software (Porth et al. 2014) to solve the MHD equations, where thermal conduction, magnetic diffusion, and joule heating are treated as source terms: (8)
(9)(10)(11)where t is time, v velocity, η the magnetic resistivity, c the speed of light, the current density, and F_{c} the conductive flux (Spitzer 1962). The total energy density e is given by (12)where γ = 5/3 denotes the ratio of specific heats.
In our numerical experiments we adopted a value of η that is set uniformly as η = 10^{9}η_{S}, where η_{S} is the classical value at T = 2 MK (Spitzer 1962).
The computational domain is composed of 512 × 256 × 512 cells, distributed on a uniform grid. The simulation domain extends from x = −2 Mm to x = 2 Mm, from y = −2 Mm to y = 0 Mm (where we model only half of a flux tube) and from z = 0 Mm to z = 40 Mm in the direction of the initial magnetic field. The boundary conditions are treated with a system of ghost cells, and we have periodic boundary conditions at both x boundaries, reflective boundary conditions at the y boundary crossing the centre of the flux tube, and outflow boundary conditions at the other y boundary. The driver is set as a boundary condition at the lower z boundary and outflow boundary conditions are set at the upper z boundary.
3. Reference simulation
The evolution of the MHD simulation allows us to analyse how the process of modecoupling and phasemixing leads to the deposition of thermal energy in the system. As soon as the driver sets in, a wavetrain propagates into the domain, and we illustrate the evolution that follows in Fig. 4, where we show maps of density contrast (ρ(t)−ρ(0)) /ρ(0), the xcomponent of the velocity and temperature of the plasma at t = P and t = 4P in a projection of the 3D simulation box where we cut two vertical planes at x = 0 and y = 0 and a horizontal plane at the z coordinates of the trail of the wavetrain propagating at the Alfvén speed of the interior region.
Fig. 4 3D cuts of the MHD simulation where show maps of density contrast (ρ(t)−ρ(0)) /ρ(0) (left column), v_{x} (centre column), and temperature change (T(t)−T(0)) (right column) on the x = 0 and y = 0 plane and the horizontal plane at the z = (t−P)V_{A0} coordinate at t = 1P (upper row) and t = 4P (lower row).

Open with DEXTER
The evolution described by the y = 0 plane is the expected evolution of an oscillation of the flux tube along the x direction, where we see weak compression and rarefaction according to the phase of the driver, alternating positive and negative v_{x} regions, and no significant temperature change. Additionally, an acoustic mode follows the propagation of the transverse wave and leads to a visible compression and rarefaction at z = 5 Mm at t = 4P.
The evolution on the plane x = 0 is of greater interest for the present work. The velocity patterns are in line with what has been found and thoroughly analysed by Pascoe et al. (2010), where the modecoupling and phasemixing lead to the concentration of velocity structures in the boundary shell. The amplitude of the driver (10% of the Alfvén speed) leads to weakly nonlinear dynamics.
As the purpose of this work is to identify the capacity of these phenomena to convert the magnetic and kinetic energy concentrated in the boundary shell into plasma heating, we address the temperature change in the boundary shell at t = 4P (Fig. 4 right column). We find that a region of increased temperature along the vertical direction inside the boundary shell is formed. This region has a slightly variable width and extends over about 45° on the xy plane, as we see in the horizontal cut at t = 4P. In this simulation the heating is of the order to 5 × 10^{4} K and reaches 7 × 10^{4} K in some regions.
Fig. 5 Temperature difference (T(t)−T(0)) cuts. a) Cuts at x = 0 and z = 26.6 Mm (where the maximum temperature is found) between t = 3.2P (thinnest line) and t = 5P (thickest line). The vertical red dashed lines are the borders of the boundary shell, and the red lines are placed at the location of the maximum gradient of the Alfvén speed at each time. b) Staggered cuts along the z direction on the x = 0 at the initial location of the maximum gradient of the Alfvén speed. The green line follows the location of the maximum temperature increase in both plots.

Open with DEXTER
Figure 5a shows the temperature increase profile at z = 26.60 Mm from t = 3.2P to t = 5P with a cadence of 0.1P (from the thinnest to the thickest line) where the red vertical line marks the position of the maximum gradient of the Alfvén speed. The temperature starts to increase in the boundary shell near its border with the exterior region, where the kinetic energy is higher. Then the temperature increase profile maximum drifts towards the centre of the boundary shell and stops at the position where the gradient of the Alfvén speed is maximum, and from there it develops in a temperature increase profile centred at that position. The green line in Fig. 5a follows the maximum of the temperature increase that approaches the centre of the boundary shell in three consecutive segments, each determined by the arrival of one of the velocity peaks induced by the driver. The location of the maximum gradient of the Alfvén speed does not change over this time frame. Figure 5b stacks cuts of the temperature increase along the zdirection at different times every 0.1P at the y coordinate where the maximum of the gradient of the Alfvén speed is situated. We note that the bump in the temperature increase is located at higher z as the evolution progresses until t = 4P, when it settles at about z = 27 Mm. At the same time, its magnitude increases as well. At t = 5P the maximum temperature increase is 7 × 10^{4} K. It should also be noted that at each time the maximum temperature increase lags the perturbation, as is visible from the wave that propagates from the origin towards the edge of the domain.
Fig. 6 Maps on the x = 0 plane of a) ∇^{2}B_{x} and b) the temperature difference (T(t)−T(0)) at t = 4P with Poynting flux vectors overplotted where this is more intense. In panel a) the dashed blue lines define the borders of the boundary shell.

Open with DEXTER
Similar conclusions can be made based on Fig. 6, where we show maps of the quantity ∇^{2}B_{x} (Fig. 6a) and temperature increase (Fig. 6b) at t = 4P on the x = 0 plane. The black arrows represent the Poynting flux (only where its intensity is above a threshold), and we chose ∇^{2}B_{x} because it is some order of magnitude larger than ∇^{2}B_{y} and ∇^{2}B_{z}. As we are investigating a nonideal heating mechanism, we focus on ∇^{2}B_{x} because where this term is large, magnetic diffusivity operates and magnetic energy is converted into heating. Where ∇^{2}B_{x} is locally large, the Poynting vector shows a transfer of energy from the exterior to the boundary shell. This creates favourable conditions for the diffusivity term to act, and thus, the conversion into thermal energy starts. Therefore, the temperature increase becomes visible only after (or following) the transfer of energy to the boundary shell has occurred, together with the formation of regions with high ∇^{2}B_{x}.
Fig. 7 Temperature difference evolution of two points on the x = 0 plane at the location of the maximum gradient of the Alfvén speed at z = 26.60 Mm (red line, where the maximum temperature in the simulation is reached at t = 5P) and at z = 13.32 Mm (blue line).

Open with DEXTER
Additionally, the heating takes place over a bounded period of time from when the phasemixing starts to occur until the process of conversion of energy into thermal energy is concluded. Figure 7 shows the temperature evolution of two points at z = 13.32 Mm (blue line) and z = 26.60 Mm (red line) at the x = 0 plane at the location of the maximum gradient of the Alfvén speed. The vertical lines show the time at which a wave that propagates from the lower boundary at the Alfvén speed of the exterior region reaches the two points (fronts), and the time at which a wave that propagates from the lower boundary when the driver ends at the speed of the Alfvén speed of the interior region (trails). The temperature remains constant as long as no perturbation reaches the point, it then steadily increases as the energy concentrated in the boundary shell is dissipated, and it finally remains constant again. While this evolution is common for both points, the final temperature depends on the z coordinate because the amount of energy that can be converted into heating depends on the intensity of the gradients of the magnetic field, which become steeper in z the more out of phase adjacent propagating waves are. At the same time, because of the progressive damping of waves, there is more kinetic energy available at lower zcoordinates than higher up. In the present analysis the time integral of the kinetic energy in the boundary shell that crosses the z = 13.32 Mm surface is 20% higher than the time integral of the kinetic energy that crosses the z = 26.60 Mm.
In order to further investigate how the energy is converted into heating, we ran a simulation where we set η = 0 to exclude the resistivity effects. In MHD simulation terms, this corresponds to adopting numerical resistivity, which is the lowest resistivity value that a given MHD simulation can achieve. The simulation with η = 0 shows an evolution very similar to the one in Sect. 3, except that no significant temperature increase occurs through phasemixing (lower than 5 × 10^{3} K).
Fig. 8 a) Difference in energy in the boundary shell between time t and t = 1 P: magnetic (blue lines – B_{x}, magenta lines – B_{z}), kinetic (green lines), and thermal (red lines) energy for the simulations with η = 10^{9}η_{S} and η = 0. b) Difference in the energy in the boundary shell between the simulation with η = 10^{9}η_{S} and η = 0 normalized to the thermal energy difference between the two simulations at each time. Note that the horizontal axis in both panels starts at t = 1 P, i.e. when the boundary driving has terminated.

Open with DEXTER
Figure 8a shows the change in magnetic energy (associated with and ), kinetic, and thermal energy in the boundary shell compared to the time t = P (when the driver has stopped) as a function of time in the two simulations. The magnetic energy associated with remains negligible throughout the entire evolution. The main difference is that the thermal energy significantly increases in the simulation where η = 10^{9}η_{S}, while it shows only a very modest change in the simulation without resistivity. This corresponds to a visible drop in magnetic (B_{x}) and kinetic energy in the simulation with resistivity, when the driver has transmitted energy into the system. In addition, the localised heating leads to an increase in the plasma pressure in the boundary shell and hence (to conserve pressure balance) to a decrease in B_{z}. This decrease is clearly visible from the magenta lines in Fig. 8a. The oscillations in the B_{z}magnetic energy are due to the driverinduced transverse wave motions, as the equilibrium magnetic field is not constant in the domain. This analysis shows again that the nonideal MHD terms are essential to convert the energy concentrated in the boundary shell into heating. In Fig. 8b we set equal to 1 the difference of the thermal energy in the boundary shell at any given time between the simulation with resistivity and the one without. The corresponding difference in magnetic (B_{x}) and kinetic energy is about the same, at a value of −0.6. This result suggests that the kinetic and magnetic energy contribute to the same extent in providing the system with thermal energy, as expected for Alfvén waves and predicted in Heyvaerts & Priest (1983).
Fig. 9 Thermal energy difference as a function of time a) in the same point as in Fig. 7 at z = 26.60 Mm and b) integrated in the entire x = 0 plane. The red dashed line in both plots is an estimate of the radiative losses for the region of interest.

Open with DEXTER
However, the open question is whether this energy input can match the radiative losses in order to answer to which extent this heating mechanism can contribute to the coronal heating. In Fig. 9a we show the internal energy evolution in a plasma element located on the phasemixing shell at z = 26.60 Mm (same as red line in Fig. 7) as a function of time compared with an estimate of the cumulated radiative losses following from the density and temperature evolution of the same plasma element. We find that the energy deposition in a single plasma element can largely overcome the radiative losses. However, the question is not whether the heating mechanism can maintain coronal temperature in a single favourable location, but if it can supply sufficient energy for entire coronal structures. Figure 9b shows the result when the same analysis is carried out and integrated on the upper three quarters of the x = 0 plane of the present simulation (we exclude the lower part to avoid spurious variations that are due to the lower boundary of the simulation and the propagation of the acoustic mode). As the heating is localised in a narrow region near the phasemixing shell, the energy contribution to this extended domain is insufficient to balance the energy lost by radiation of the plasma on the plane x = 0. This spatial domain is arbitrary and plotted just to show the effect of the spatial limitation of the heating. Conditions would be even less favourable to maintain a coronal temperature in this regime if we considered a 3D domain instead.
4. Investigating the parameter space
In Sect. 3 we have described the mechanism that leads to the deposition of thermal energy in the boundary shell as a result of the phasemixing of propagating Alfvén waves. Our estimation of the thermal energy contribution from this mechanism seems to be inconclusive as to whether it can definitely overcome the radiative losses. In light of this, it is essential to address the role of the boundary shell in this mechanism in order to assess how much the energy deposition can differ from what we have analysed so far. To do so, we ran simulations where the boundary shell of the cylinder varies in width and where it has a more complex structure.
4.1. Boundary shell width
Using the setup explained in Sect. 2, we ran two more simulations in which we only changed the width of the boundary shell by using l = 0.75 (wider boundary shell) and l = 0.35 (narrower boundary shell) with respect to Table 1. These were analysed in combination with the reference simulation with l = 0.5 described in Sect. 3 to investigate how the modecoupling and phasemixing are affected by Alfvén speed gradients. A narrower boundary shell leads to a steeper Alfvén speed profile (as all other parameters in the setup have remained unchanged), implying that phasemixing will become more efficient (i.e. the damping length will be shorter Heyvaerts & Priest 1983). The modecoupling process that feeds kinetic and magnetic energy into the shell region also depends on the Alfvén speed profile in the shell region, but now a wider shell (a milder Alfvén speed gradient) leads to more efficient modecoupling (Pascoe et al. 2010, 2012, 2013). Hence, the deposition of thermal energy is dependent on the combined efficiency of modecoupling and phasemixing and how the resistivity effects interact with these mechanisms, so that it is not a priori obvious which configuration will be most efficient. The purpose of this experiment is to assess which effect dominates the dynamics and how this influences the nonideal effects in the simulation, in particular the heating.
Fig. 10 3D cuts as in Fig. 4 of v_{x} in the left column and temperature difference, (T(t)−T(0)), right column, at t = 4P for the simulation with l = 0.35 (upper row) and with l = 0.75 (lower row).

Open with DEXTER
Figure 10 shows 3D cuts of v_{x} and T on the x = 0 and y = 0 planes at t = 4P for the simulations with l = 0.35 and l = 0.75, to be compared with the simulation with l = 0.5 (Fig. 4). The velocity phasemixing patterns are visibly narrower in the simulation with l = 0.35 and visibly wider in the simulation with l = 0.75 as they entirely fill the boundary shell. Similar variations are found in the extension of the temperature increase region, where the temperature increase is dependent on the size of the boundary shell, however. The region in which the heating occurs is narrowest in the simulation with l = 0.35, and the maximum temperature increase is ΔT ≃ 10^{5} K, while the simulation with l = 0.75 show the largest heated region where ΔT ≃ 5 × 10^{4} K.
Fig. 11 Evolution of the wave energy (blue lines) and thermal energy (red lines) in the loop boundary layer as a function of time for different widths of the boundary (l = 0.35, dashed line; l = 0.50, continuous line; l = 0.75, dotted line).

Open with DEXTER
In order to assess which configuration (wide or narrow boundary shell) leads to more efficient deposition of thermal energy, we analysed the time evolution of the wave energy (kinetic + magnetic energy associated to B_{x}) and the thermal energy in the boundary shell (Fig. 11). Initially (t< 1 P), energy is injected into the domain (blue lines), including the boundary shell, by the driver. This initial increase is followed by a second rise, where the modecoupling process transfers wave energy into the shell region. However, phasemixing is already taking place at this stage, as is evident from the increase in thermal energy. The thermal energy starts to rise before the wave energy reaches its maximum value. Following this maximum, dissipation through phasemixing is clearly the dominant process in the shell region: wave energy is converted into thermal energy at a faster rate than it is transferred into the layer by modecoupling. From comparing the thermal energy curves (red lines), it is clear that the increase in thermal energy is largest for the narrow boundary layer (dashed red line). This is in agreement with Fig. 10, which showed a larger increase in temperature in the boundary layer at t = 4 P for the simulation with the smallest boundary width (l = 0.35).
Fig. 12 Time evolution of the time derivative of the average kinetic energy in the boundary shell (continuous lines) and in the interior region (dashed lines) for the three simulations with l = 0.35 (red lines), l = 0.50 (black lines), and l = 0.75 (blue lines).

Open with DEXTER
In order to further describe how the width of the boundary shell affects the energy transfer to the boundary shell, we show the time derivative of the average kinetic energy in the interior region and in the boundary shell in Fig. 12. We focus on the average kinetic energy because i) it is the form of energy that is initially pumped into the system and more clearly drifts to the boundary shell; and ii) by averaging over the domain, we compensate for two effects: first, the narrower boundary shell simulation has more total kinetic energy because it has more plasma in the simulation box, and second, the broader boundary shell simulation has more kinetic energy in the boundary shell because the shell is larger. In Fig. 12 the time derivative is large and positive for t<P while the driver is pumping kinetic energy into both the interior and boundary shell. After t = 1 P, the average kinetic energy in the interior diminishes and it increases in the boundary shell. The time derivative of the average kinetic energy in the interior is negative for all simulations, and the simulation with l = 0.75 is the one where it is minimum. The time derivatives of the interior region and the boundary shell are opposite in sign, and the total kinetic energy remains roughly constant, with variations of the order of 1%. This confirms that in this first phase the modecoupling dominates the dynamics, that the kinetic energy is transferred from the interior to the boundary shell, and that a broader boundary shell makes the energy transfer via modecoupling more efficient. This phase continues until t ~ 2.5P, when the time derivative of the average kinetic energy in the boundary shell changes sign. In this second phase, dissipation dominates, and hence the time derivative of the average kinetic energy in the boundary shell is negative for all the simulations. In this regime the narrower boundary shell simulation is more efficient in dissipating energy as its time derivative is lower. At the same time, the time derivative in the interior region approaches zero because there is less and less energy to dissipate, without ever showing a regime change, as the waves keep damping in that region. After t = 4P, the propagating waves interact with the upper boundary of the simulation box and the kinetic energy undergoes variations because a part leaves the domain.
Figure 13 shows the temperature evolution of the point on the x = 0 plane that reaches the highest temperature at the end of the simulation from the time at which heating starts. We find that the final temperature depends on the width of the boundary shell, while the timescale over which thermal energy energy is deposited is not dependent on the width of the boundary shell because the time taken from the start of the temperature increase to the final temperature is the same for all three simulations. In all three simulations, the final temperature is reached in about one period. Figure 13 also shows that the maximum of temperature is reached at lower z (and earlier in time), as the boundary shell becomes narrower.
Fig. 13 Temperature difference evolution of the points with highest temperature on the x = 0 plane at the location of maximum gradient of Alfvén speed in each simulation: l = 0.75 (dotted line), l = 0.50 (continuous line), and l = 0.35 (dashed line). Note that the time axes have been shifted so that we plot the elapsed time from when the heating starts. At the end of each line, we report the zcoordinate of the point and the time at which the heating of the point starts.

Open with DEXTER
4.2. Structure of the boundary shell
The boundary shell structure we have investigated so far is relatively simple, where the density smoothly increases towards the interior region and the gradient of the Alfvén speed peaks near the centre of the boundary shell. In order to address how the location of the heating depends on the structure of the boundary shell, we devised a different simulation where we changed the structure of the boundary into a profile with two peaks in the gradient of the Alfvén speed (Fig. 14).
Fig. 14 Density (blue lines) and gradient of Alfvén speed (red lines) across the cylinder for the simulation with a smooth boundary shell (dashed lines) and the simulation with a twostep boundary shell (continuous lines).

Open with DEXTER
In this simulation the boundary shell extends from b = 0.25 to a = 1(l = 0.75), and the density increases in two steps similar to Eq. (1), each extending for half of the boundary shell. The density profile is given by (13)This density profile prescribes a boundary shell of width 0.75 Mm where the density in the interior and exterior region are the same as in the simulation with l = 0.75. The two gradients of the Alfvén speed peaks are smaller and larger than the equivalent profile for the simulation with a smooth boundary shell.
Fig. 15 3D cuts as in Fig. 4 of v_{x} in the left panel and temperature difference, (T(t)−T(0)), right panel, at t = 4P for the simulation with l = 0.75 and a twostep boundary shell.

Open with DEXTER
Figure 15 shows the evolution of the system at t = 4P equivalent to Fig. 10, and the modecoupling and temperature increase patterns do not show great differences with respect to the simulation with a smooth boundary profile. We only find that the v_{x} phasemixing pattern becomes slightly more structured with a variable width and that the temperature increases at two different locations on the boundary shell, where the temperature increase is more signficant at the more external peak.
Fig. 16 Temperature difference, (T(t)−T(0)), cut across the cylinder on the x = 0 plane at z = 31.91 Mm for the simulations with l = 0.75 with the smooth boundary shell (dashed line) and the twostep boundary shell (continuous line).

Open with DEXTER
Figure 16 shows the temperature increase on the plane x = 0 at z = 31.91 Mm at t = 5P for the two simulations with a boundary shell l = 0.75 Mm. We find that the temperature increase follows the structure of the boundary shell, with as many temperature peaks as the gradient of the Alfvén speed peaks. The peaks are also located in the same positions as the peaks of the gradient of the Alfvén speed, and the temperature increase is proportional to the intensity of the Alfvén speed gradient.
Fig. 17 Thermal energy difference between t and t = 0 in the boundary shell as a function of time for the simulation with l = 0.75 and a smooth boundary shell (dashed line) and a twostep boundary shell (continuous line).

Open with DEXTER
However, as shown in Fig. 17, this does not lead to a visible change in the thermal energy deposited in the boundary shell, where in the simulation with a twostep boundary shell only 2% more thermal energy is deposited in the boundary shell.
4.3. Continuous driver
To conclude our investigation, we analysed the evolution of the system when a continuous driver (instead of a single pulse) is used to perturb the system. This is a step towards a configuration where the footpoints are continuously displaced by photospheric motion. In this simulation we used all the parameters outlined in Sect. 2, with the only difference that we did not switch off the driver after one pulse, but let it continue.
Fig. 18 3D cuts as in Fig. 4 of v_{x} in the left column and temperature difference, (T(t)−T(0)), right column, at t = 6P (upper row) and t = 12P (lower row) for the simulation with continuous driver.

Open with DEXTER
Figure 18 shows the evolution of the system after t = 6P and t = 12P. The v_{x} pattern shown on the plane x = 0 indicates that the phasemixing occurs in a similar way for each consecutive period of the driver as the same pattern as is visible in Fig. 4 repeats. However, as each wave train encounters conditions that increasingly depart from the initial condition, the shape of the phasemixing pattern becomes less regular and has more internal structuring. The temperature increase pattern shows significant differences with respect to our previous simulation, as the plasma reaches higher temperatures and the heated region broadens in time.
Fig. 19 Temperature difference evolution of the point on the x = 0 plane at the location of the maximum gradient of the Alfvén speed at z = 26.60 Mm for the simulation with continuous driver (black continuous line), compared to the same temperature evolution for the simulation with single pulse (red line). The overplotted grid is horizontally spaced by 1P and vertically spaced by the final temperature increase in the singlepulse simulation. The blue straight line would be the temperature evolution if the same initial temperature increase is gained at each pulse.

Open with DEXTER
Figure 19 shows the temperature increase evolution of a single plasma element located at the steepest Alfvén speed location on the x = 0 plane at z = 26.60 Mm, and the overplotted grid is spaced one period horizontally and vertically by the temperature increase after one pulse. The temperature increase starts after t = 3P, and it increases mostly linearly until t = 7P, when four pulses have crossed the plasma element. After t = 7P, the temperature increase is no longer linear in time, and each pulse contributes with an increasingly smaller temperature rise. At t = 12P, the temperature increase slightly exceeds ~5 × 10^{5} K.
Fig. 20 Difference in energy in the boundary shell between time t and t = 0 for the simulations with a continuous driver as a function of time: wave energy (blue line) and thermal energy (red line).

Open with DEXTER
Similar conclusions can be drawn from the evolution of the energy in the boundary shell (Fig. 20), where we find that the thermal energy steadily increases until t = 11P. After t = 2P, the thermal energy increases at the expense of the wave energy that enters the boundary shell. However, the wave energy remains constant after t = 5P, when the entire zextension of the domain is filled by the wave propagation. After t = 11P, the thermal energy becomes saturated.
Figure 21 compares the thermal energy increase in the boundary shell at x = 0 with an estimate of the radiative losses (as in Fig. 9). In this simulation the thermal energy deposition largely overcomes the radiative losses because energy is continuously injected into the system. It also should be noted that the increase in thermal energy is not linear, and each pulse deposits an increasingly higher amount of thermal energy because the deposition of energy drifts to lower and higher z coordinates after the shells initially involved saturate.
Additionally, the prolonged effect of the driver on the system leads to the fragmentation of the structure of the boundary shell in the time span of a few periods. Figure 22 shows the evolution of v_{x} and the temperature difference (T−T_{0}) on a cross section placed at z = 30 Mm at t = 6P and t = 12P. The cross sections show regular patterns at t = 6P, when that cross section has been reached by only one pulse. The velocity patterns are concentric around the centre, and negative and positive velocity regions alternate. The temperature increase is contained within an annular arc region of the boundary shell. Once more, pulses reach this location, the patterns of v_{x} and T−T_{0} become more irregular, and smallerscale structures appear. The temperature increase extends to higher radial distances from the centre of the cylinder and is no longer an annular arc. The velocity pattern also becomes irregular and involves more external shells from the centre of the cylinder. These structures develop when the system loses the initial symmetry about the x = 0 plane, and analysis of the involved forces suggests that the loss of symmetry originates from the oscillations of the magnetic field induced by the driver. This evolution is comparable with the development of KelvinHelmholtz instabilities reported in Terradas et al. (2008), Antolin et al. (2015), and Magyar & Van Doorsselaere (2016), with the difference that in our model the conditions for a development of the instability are built through the passage of several propagating waves, while in these studies the instability is triggered by standing oscillations. It has been shown that the development of KelvinHelmholtz instabilities amplifies the effect of resonant absorption (or phasemixing) of Alfvén waves on plasma heating by developing smallerscale structures at the boundary shell where wave energy is more favourably converted into heating (Browning & Priest 1984). The present simulation shows comparable dynamics, as the thermal energy deposition in the boundary shell significantly accelerates after t = 9P, when the first KelvinHelmholtz instabilitylike structures appear. However, the high resistivity we have adopted prohibits the development of visible smallscale vortices.
Fig. 21 Thermal energy difference as a function of time integrated in the entire x = 0 plane for the simulation with a continuous driver (red line) and for the simulation with a single pulse (black line). The red dashed line is an estimate of the radiative losses in the same region.

Open with DEXTER
Fig. 22 Maps on the plane z = 30 Mm of the temperature difference, (T(t)−T(0)) (left column), and v_{x} (right column) at t = 6P (upper row) and t = 12P (lower row) for the simulation with a continuous driver.

Open with DEXTER
Fig. 23 Temperature difference, (T(t)−T(0)), cut across the cylinder on the x = 0 plane at z = 26.60 Mm from t = 0 to t = 12P with 1P cadence from the thinnest to the thickest line. The red vertical dashed lines mark the borders of the boundary shell.

Open with DEXTER
One consequences of the expansion of the region involved in the temperature increase is that the heating is not bounded to the initial boundary shell, but extends in time to regions initially outside of the boundary shell. Figure 23 shows the temperature increase on the x = 0 plane at z = 26.60 Mm from t = 0 to t = 12P with a 1P cadence (from the thinnest to the thickest line). The temperature increase profile is always a curve with one peak that reaches 0.55 MK at the end of the simulation. We also see that the position of the centre of the peak slightly moves in time, but more importantly, while at the beginning the heating is only appreciable in the initial boundary shell (between y = [−1,−0.5]), at the end it extends from y = −1.3 to y = −0.2. This results is also in line with what has been found by Antolin et al. (2015).
5. Discussion and conclusions
We have developed a simple model of a magnetised cylinder that is perturbed at one of its footpoints by a transverse displacement. The configuration we have adopted leads to the phasemixing of propagating Alfvén waves in the loop shell region, and we focused our analysis on the heating that follows. The aim of this modelling effort is to investigate the contribution of phasemixing of Alfvén waves to the coronal heating problem.
In many respects, our model is a simplification of a coronal loop structure, and it does not address more complex features of these magnetic structures. Certainly, our modelling starts from a condition where the coronal loop is already in place and with a temperature above the chromospheric and photospheric temperatures. Therefore, the key to interpret our results is whether such a mechanism can at least maintain the loop structure against the radiative losses.
Although our study is not conclusive on the matter, it sheds light on some relevant aspects of the contribution from phasemixing to coronal heating, and it helps identify some points where this model is in disagreement with observations.
First of all, our numerical experiments show that phasemixing is a plausible mechanism in the corona, where we have used plasma and magnetic field parameters that are in the observed or measured range. We also showed that a timelimited oscillation propagating from the footpoint leads to a timelimited energy deposition that increases the plasma temperature by a certain amount. This process is in line with the impulsive manner in which coronal heating is observed to work (Warren et al. 2011; Reale 2010). Finally, we showed that the energy deposition is comparable with the radiative losses, thus keeping phasemixing as a candidate to maintain the high temperature of the solar corona. Given the physics and geometry of the solar corona, where magnetic field structures act as vertical wave guides and observed horizontal motions at the base of the corona perturb these magnetic structures out of equilibrium, inevitably leading to the upward propagation of Alfvénic waves, phasemixing has to occur. The unanswered question is whether this is just a marginal process in the solar corona or whether it dominates the temperature evolution.
Here, major concerns are still challenging phasemixing as a mechanism to justify coronal heating on a larger scale, and here we list some. Fist of all, the model can match the radiative loss estimation only with the adoption of a very high magnetic resistivity. In our simulations we used a resistivity 10^{9} times the value predicted by the classical theory (at a 2 MK temperature), and such an amplification of the resistivity is not only essential to overcome the numerical resistivity (inherent to any MHD code), but more importantly, also to achieve a significant increase in the plasma temperature in the model. Similarly, we had to adopt a relatively large amplitude driver in order to stimulate an appreciable deposition of thermal energy in the model. Velocities of the order of 10 km s^{1} are typically measured as motions of coronal structures, while in our case the peak velocity is higher than 100 km s^{1}. Our velocity is also much higher than the one used in Pascoe et al. (2010), and at about 10% of the Alfvén speed, our system probably evolves in a weakly nonlinear regime. Moreover, the measured power spectrum of the oscillations of the solar corona peaks at 5 min because of the forcing photospheric oscillations. The period of our driver is instead at 6 s, which may not be a significant frequency of the coronal power spectrum. This is especially relevant because longer oscillation periods would probably lead to slower heating timescales in this model. Finally, our model has certainly led to the heating of the boundary shell, but does not address how the centre of the loop would obtain a significant amount of thermal energy to sustain the loop structure against radiative cooling. This is a concern intrinsic to the phasemixing process, which concentrates wave energy only on the boundary shell (Cargill et al. 2016). Even the single case we addressed, in which the temperature increase eventually involved regions beyond the boundary shell, it needs several oscillations to set in. The question remains open whether this extension needs to be triggered earlier in order to balance radiative losses, particularly in the core of the loop.
The aforementioned problems seem to pose major concerns for the validation of phasemixing as a mechanism for coronal heating on a global scale. The model we described seems to match the observations only by pushing the physical parameters to conditions that are extremely unlikely to occur in the solar corona. At the same time, it is useful to outline some uncertainties about the coronal physics that could still open the way to the possibility that phasemixing can explain coronal heating. It is widely accepted that the combination of a classical resistivity value and the spatial resolution at which we resolve coronal structure are not able to explain the magnetic energy conversion in the solar corona. One possibility is that the development of gradients on spatial scales much smaller than our current spatial resolution can affect the largerscale evolution and thus amplify the role of the classical diffusivity terms. Another possibility is that the classical theory simply fails when small spatial scales become relevant. In any case, the question on how the Ohmic heating operates in the solar corona still holds and the efficiency of any magnetic energy conversion mechanism remains uncertain. The intensity of the driver has also been questioned, but it is currently not possible to separate the lineofsight projection effects when coronal flows are measured from Doppler velocities. While we can state that average observed speeds are of the order of 10 km s^{1}, it is therefore more difficult to determine whether this average comes from a collection of comparable motions or from the residual of the lineofsight cancellation of much faster motions (De Moortel & Pascoe 2012). Similarly, it needs to be addressed whether the development of KelvinHelmholtz instabilities triggered by phasemixing could make the whole mechanism more efficient. Finally, while it is true that our model takes only a monochromatic wave packet with a specific period into account that seems not to be relevant for the solar corona, it is also true that such simple drivers are unlikely to occur at the dynamic base of the solar corona. It is more plausible that actual drivers in the solar corona are composed of a more complex spectrum. This means that frequencies of the order of seconds are also a component of the spectrum and that a realistic wave packet that is more energy rich would provide the system with more energy than what we have modelled with a monochromatic pulse.
Our partial conclusion is that phasemixing does not seem to be a viable mechanism to explain the largescale heating of the solar corona, even though it is likely that some energy deposition takes place through this mechanism. At the same time, further analysis is needed to validate the present results and to complete the investigation. To begin with, we will run a comparable analysis over longer timescales and with a different class of drivers, also including the effects of radiative losses and various types of background heating in the energy balance, in order to more conclusively address whether phasemixing can sustain the thermal structure of a coronal loop.
Acknowledgments
This research has received funding from the European Research Council (ERC) under the European Union’s Horizon 2020 research and innovation programme (grant agreement No. 647214) and from the UK Science and Technology Facilities Council. This work used the DiRAC Data Centric system at Durham University, operated by the Institute for Computational Cosmology on behalf of the STFC DiRAC HPC Facility (www.dirac.ac.uk. This equipment was funded by a BIS National Einfrastructure capital grant ST/K00042X/1, STFC capital grant ST/K00087X/1, DiRAC Operations grant ST/K003267/1 and Durham University. DiRAC is part of the National EInfrastructure. We acknowledge the use of the open source (gitorious.org/amrvac) MPIAMRVAC software, relying on coding efforts from C. Xia, O. Porth, R. Keppens.
References
 Antolin, P., Okamoto, T. J., De Pontieu, B., et al. 2015, ApJ, 809, 72 [NASA ADS] [CrossRef] [Google Scholar]
 Arregui, I. 2015, Phil. Trans. R. Soc. London Ser. A, 373, 20140261 [NASA ADS] [CrossRef] [Google Scholar]
 Browning, P. K., & Priest, E. R. 1984, A&A, 131, 283 [NASA ADS] [Google Scholar]
 Cargill, P. J., De Moortel, I., & Kiddie, G. 2016, ApJ, 823, 31 [NASA ADS] [CrossRef] [Google Scholar]
 De Moortel, I., & Nakariakov, V. M. 2012, Phil. Trans. Roy. Soc. Lond. Ser. A, 370, 3193 [NASA ADS] [CrossRef] [Google Scholar]
 De Moortel, I., & Pascoe, D. J. 2012, ApJ, 746, 31 [NASA ADS] [CrossRef] [Google Scholar]
 De Moortel, I., & Browning, P. 2015, Phil. Trans. R. Soc. London Ser. A, 373, 20140269 [NASA ADS] [CrossRef] [Google Scholar]
 Goddard, C. R., Nisticò, G., Nakariakov, V. M., & Zimovets, I. V. 2016, A&A, 585, A137 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Hahn, M., Landi, E., & Savin, D. W. 2012, ApJ, 753, 36 [NASA ADS] [CrossRef] [Google Scholar]
 Heyvaerts, J., & Priest, E. R. 1983, A&A, 117, 220 [NASA ADS] [Google Scholar]
 Jess, D. B., Mathioudakis, M., Erdélyi, R., et al. 2009, Science, 323, 1582 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 LópezAriste, A., Luna, M., Arregui, I., Khomenko, E., & Collados, M. 2015, A&A, 579, A127 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Magyar, N., & Van Doorsselaere, T. 2016, A&A, 595, A81 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 McIntosh, S. W., de Pontieu, B., Carlsson, M., et al. 2011, Nature, 475, 477 [NASA ADS] [CrossRef] [Google Scholar]
 Morton, R. J., & McLaughlin, J. A. 2013, A&A, 553, L10 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Morton, R. J., Verth, G., Hillier, A., & Erdélyi, R. 2014, ApJ, 784, 29 [NASA ADS] [CrossRef] [Google Scholar]
 Nakariakov, V. M., Ofman, L., Deluca, E. E., Roberts, B., & Davila, J. M. 1999, Science, 285, 862 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Okamoto, T. J., Antolin, P., De Pontieu, B., et al. 2015, ApJ, 809, 71 [NASA ADS] [CrossRef] [Google Scholar]
 Pascoe, D. J., Wright, A. N., & De Moortel, I. 2010, ApJ, 711, 990 [NASA ADS] [CrossRef] [Google Scholar]
 Pascoe, D. J., Wright, A. N., & De Moortel, I. 2011, ApJ, 731, 73 [NASA ADS] [CrossRef] [Google Scholar]
 Pascoe, D. J., Hood, A. W., de Moortel, I., & Wright, A. N. 2012, A&A, 539, A37 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pascoe, D. J., Hood, A. W., De Moortel, I., & Wright, A. N. 2013, A&A, 551, A40 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pascoe, D. J., Goddard, C. R., Nisticò, G., Anfinogentov, S., & Nakariakov, V. M. 2016, A&A, 589, A136 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Poedts, S., & Boynton, G. C. 1996, A&A, 306, 610 [NASA ADS] [Google Scholar]
 Porth, O., Xia, C., Hendrix, T., Moschou, S. P., & Keppens, R. 2014, ApJS, 214, 4 [NASA ADS] [CrossRef] [Google Scholar]
 Reale, F. 2010, Liv. Rev. Sol. Phys., 7, 5 [Google Scholar]
 Soler, R., Terradas, J., Oliver, R., & Ballester, J. L. 2016, A&A, 592, A28 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Spitzer, L. 1962, Physics of Fully Ionized Gases (Physics of Fully Ionized Gases, 2nd edn. (New York: Interscience) [Google Scholar]
 Terradas, J., Andries, J., Goossens, M., et al. 2008, ApJ, 687, L115 [NASA ADS] [CrossRef] [Google Scholar]
 Threlfall, J., De Moortel, I., McIntosh, S. W., & Bethge, C. 2013, A&A, 556, A124 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Tomczyk, S., McIntosh, S. W., Keil, S. L., et al. 2007, Science, 317, 1192 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Van Doorsselaere, T., Andries, J., & Poedts, S. 2007, A&A, 471, 311 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Warren, H. P., Brooks, D. H., & Winebarger, A. R. 2011, ApJ, 734, 90 [NASA ADS] [CrossRef] [Google Scholar]
