Issue
A&A
Volume 601, May 2017



Article Number  A21
Number of page(s)  12
Section  Astrophysical processes
DOI  https://doi.org/10.1051/00046361/201629315
Published online  21 April 2017
Constant entropy hybrid stars: a first approximation of cooling evolution
^{1} Grupo de Gravitación, Astrofísica y Cosmología, Facultad de Ciencias Astronómicas y Geofísicas, Paseo del Bosque S/N, 1900 La Plata, Argentina
email: mmariani@fcaglp.unlp.edu.ar
^{2} Consejo Nacional de Investigaciones Científicas y Técnicas (CONICET), Rivadavia 1917, 1033 Buenos Aires, Argentina
^{3} Department of Physics, San Diego State University, 5500 Campanile Drive, San Diego, CA 92182, USA
Received: 14 July 2016
Accepted: 21 December 2016
Aims. We aim to study the possibility of a hadronquark phase transition in the interior of neutron stars, taking into account different schematic evolutionary stages at finite temperature. We also discuss the strange quark matter stability in the quark matter phase. Furthermore, we aim to analyze the astrophysical properties of hot and cold hybrid stars, considering the constraint on maximum mass given by the pulsars J16142230 and J0348+0432.
Methods. We have developed a computational code to construct semianalytical hybrid equations of state at fixed entropy per baryon and to obtain different families of hybrid stars. An analytical approximation of the field correlator method is developed for the quark matter equation of state. For the hadronic equation of state we use a table based on the relativistic mean field theory, without hyperons. The phase transition was obtained imposing the Maxwell conditions, by assuming a high surface tension at the interface hadronquark. We solved the relativistic structure equations of hydrostatic equilibrium and mass conservation for hybrid star configurations.
Results. For the different equations of state obtained, we calculated the stability window for the strange quark matter, lepton abundances, temperature profiles and contours profiles for the maximum mass star depending on the parameters of the field correlator method. We also computed the massradius and gravitational massbaryonic mass relationships for different hybrid star families.
Conclusions. We have analyzed different stages of hot hybrid stars as a first approximation of the cooling evolution of neutron stars with quark matter cores. We obtain cold hybrid stars with maximum masses ≥2 M_{⊙} for different combinations of the field correlator method parameters. In addition, our study based on the gravitational mass – baryonic mass plane shows a late phase transition between hadronic and quark matter during the protohybrid star evolution, in contrast with previous studies of protoneutron stars.
Key words: stars: neutron / equation of state / dense matter
© ESO, 2017
1. Introduction
A protoneutron star (protoNS) is the remaining old degenerated core of an intermediate mass star (between 10 and 25 solar masses at the zero age main sequence) after a supernova typeII or typeIb/Ic explosion (Woosley et al. 2002). Its evolution could be described roughly by three characteristic isentropic stages: first, the new born neutron star (NS) has an entropy per baryon s ~ 1 (in units of Boltzmann constant), with an abundance of trapped neutrinos, Y_{ν} ≠ 0, whose fraction is set by requiring the total fraction of leptons Y_{l} ≃ 0.4. This stage is dominated by neutrino diffusion, but as the neutrino mean free path is much smaller than the star radius, they remain trapped. The first ~ 15 seconds, the protoNS radiates its lepton excess (deleptonization) and the neutrino flux produces an increase in the temperature. The star reaches the maximum heating in this second stage, and its inner matter has entropy per baryon s ≃ 2. Next, the neutrino mean free path begins to increase, becoming much larger than the radius of the star. The fraction Y_{ν} ≠ 0 evolves to a state in which Y_{ν} = 0, because the matter becomes transparent to neutrinos. Once the electron chemical potential reaches the muon mass value, muons start to appear. The arising of muons reduces the number of electrons and affects the proton fraction of the stellar matter. The deleptonization process continues, and after a few minutes the third stage takes place. The entropy per baryon decreases to s = 0 and the protoNS cools down remaining transparent to neutrinos with Y_{ν} = 0. The resulting object after these three stages is a cold and stable NS (Burrows & Lattimer 1986; Steiner et al. 2000).
In the chaotic rearrangement period of deleptonization and cooling described above, a phase transition to an exotic state of matter, like hyperons, Bose condensates or quark matter, could appear (Benvenuto & Lugones 1999; Benvenuto et al. 1989; Benvenuto & Horvath 1989; Prakash et al. 2001) inside the protoNS. In the case of quark matter, studies of the quantum chromodynamics (QCD) phase diagram predicts that the crossover shown by Lattice calculations at vanishing chemical potential, will become a firstorder phase transition at intermediate temperatures and high baryon chemical potentials (see Yin et al. 2012 and references therein). It may be plausible that this scenario of matter under extreme conditions occurs in the interior of NS, as we get closer to the innermost core of the star, from the outer to the inner core, where the matter is compressed to densities several times the nuclear matter saturation density (n_{0} ~ 0.16 fm^{3}).
Most of the mass of a NS is contained in the inner and outer cores and its equation of state (EoS) has not yet been well determined. The discovery of the massive PSR J16142230 and PSR J0348+0432 (~ 2 M_{⊙}) NS, whose masses have been very accurately determined (Demorest et al. 2010; Antoniadis et al. 2013; Fonseca et al. 2016), has placed limits on a wide variety of EoS. Many EoS had to be ruled out, and the internal composition of NS had to be reconsidered, because a viable EoS should, at least, reproduce the mass value of these observed NS.
At the end of the process of the NS formation, the degenerate neutron pressure partially counteracts the gravity force. The repulsive nuclear force beats the neutron degeneracy pressure resulting in less compact and more rigid structures supported by a stiffer EoS. For this reason NS masses are larger than ~ 0.7 M⊙, the maximum star mass derived by TolmanOppenheimer and Volkoff equations (Tolman 193916; Oppenheimer & Volkoff 193917) if a noninteracting degenerated neutron gas is considered as forming NS. Thus, strong interactions are crucial in obtaining NS configurations that are compatible with measured NS masses.
Some alternative models for the EoS include strange matter in form of hyperons (see, for example Bednarek et al. 2012; Yamamoto et al. 2014; Katayama & Saito 2015). Although hyperons soften the EoS, massive NS with hyperons would be possible, considering certain relationships between the coupling constants and interactions between the particles involved in the hadronic matter composing their interiors (Oertel et al. 2016). Another possibility is that NS could contain pure quark matter. However, to obtain stars as heavy as two solar masses, it should be feasible to adjust some of the parameters which mediates the interaction between quarks (Orsaria et al. 2014; Weber et al. 2014) and/or that quark matter is a color superconductor (Bonanno & Sedrakian 2012; Zdunik & Haensel 2013). Whatever the matter composing the interior of a NS may be (quarks or hadrons or a mixing of both phases), the EoS describing the matter should be stiff enough to obtain massive NS.
Regarding quark matter inside compact objects, for many years the models most used to describe it have been the MIT bag model (Chodos et al. 1974) and the Nambu JonaLasinio (NJL) model (Nambu & JonaLasinio 1961a,b). Some modifications to these models have been implemented to obtain a more suitable description of quark matter at high densities in the context of hybrid stars (HS), NS with a quark matter core surrounded by a shell of hadronic matter (see Chatterjee & Vidaña 2016 and references therein). Recently, for the description of quark matter phase inside cold NS, the field correlator method (FCM) has been used (Plumari et al. 2013; Logoteta & Bombaci 2013; Burgio & Zappalà 2016). The FCM is a nonperturbative approximation of QCD which includes, from the first principles, the confinement dynamics in terms of field correlators. The model is parametrized through the gluonic condensate, G_{2}, and the quarkantiquark static potential for long distances, V_{1}, taking into account the confinement. These two parameters control the EoS of the deconfined quark phase.
In the framework of the isentropic stages described at the beginning, we have studied the occurrence of a first order phase transition from hadronic to quark matter in protoNS, assuming the surface tension at the interface hadronquark is such that a sharp phase transition is the favorable scenario for the deconfinement (Alford et al. 2015; RaneaSandoval et al. 2016). The hybrid EoS that models the protoNS is obtained using the simplest method for constructing a first order phase transition by considering an isobaric transition with one conserved charge, for example, the baryonic chemical potential. This is known as Maxwell construction.
To obtain the phase transition and the astrophysical quantities for the study of HS, a computational code called NeStOR (NeutronStarObject Research) has been developed. This code contains a set of routines and scripts to calculate several EoS at finite temperature and constant entropy. The combination of different programming languages provided in the code establishes the essential conditions for an unique determination of the matter equilibrium composition in the protoHS, that is, the requirements of beta equilibrium, charge neutrality and the conservation of baryonic and leptonic number. The program also computes particle abundances and the stellar structure of a spherically symmetric compact object by integrating the relativistic equations of hydrostatic equilibrium for different model parameters. Through this code it is also possible to compare the values of the maximum baryonic mass of each family of stars for the three stages considered. Supposing that the baryonic mass remains constant during the process of thermal evolution, the gravitational mass of the star, which corresponds to the total stellar energy, changes during the evolution of the protoNS. Then, a study of the evolution in a gravitational mass – baryonic mass plane must be taken into account, giving the possibility of knowing in which stage takes place the phase transition from hadronic matter to quark matter. The description of protoNS evolution along constant baryonic mass sequences have been already discussed in Bombaci (1996).
Thereby, using the NeStOR code, it is possible to analyze the thermal evolution of protoHS through snapshot sequences at constant entropy, also considering their characteristic composition at each stage. A semianalytical calculation of the FCM at finite temperature is used to describe the quark matter phase at the inner cores. For the hadronic phase, we employ a table containing an EoS created for astrophysical simulations of protoNS (Shen et al. 2010a,b, 2011).
The paper is organized as follows. In Sect. 2, we give the thermodynamic expressions for the quark matter as functions of temperature and chemical potential, and we discuss the choice of the parameters of the FCM as well as the stability of strange quark matter. The thermodynamic conditions for the construction of the hybrid EoS and the phase transition hadronquark are presented in Sect. 3, together with the description of the hadronic and leptonic EoS. In Sect. 4 we explain briefly the calculations at constant entropy, giving the snapshot sequences of thermal evolution. In Sect. 5 we show the results about the structure of hot and cold HS and we analyze the gravitational massbaryonic mass plane for some representative combinations of the FCM parameters. A summary of the work and conclusions are provided in Sect. 6. Details of the calculations and treatment of quark matter are given in Appendix A.
2. Quark matter EoS within the field correlator method
2.1. Correlators and the phase diagram
The microscopic EoS describing the matter in the inner core of the hot and cold HS (HHS and CHS henceforth) is based on the FCM approach (Dosch 1987; Dosch & Simonov 1988; Simonov 1988). In the FCM approach, it is assumed, as a first approximation, that single quark and gluon lines (single line approximation) interact in nonperturbative way, using strength field correlators, with vacuum fields (gluon condensates and quark condensates, Simonov & Trusov 2007a).
The confined and deconfined phases are governed by four Gaussian field correlators: the colorelectric, D^{E}(x), , and colormagnetic, D^{H}(x), , field correlators. The fields D^{E} and D^{H} are of pure nonperturbative origin, whereas and contain all perturbative diagrams, but also nonperturbative contributions. The nonperturbative information is given through the string tension, quarks and gluons are connected by straightline NambuGoto strings (Nefediev et al. 2009), which is a characteristic integral of Gaussian correlators (Di Giacomo et al. 2002). Thus, in the lowest nonperturbative approximation the partition function factorizes into a product of onegluon and onequark (antiquark) contributions, and then the corresponding thermodynamic potential can be calculated.
Through the thermodynamic potential, thermodynamic properties of the quark matter can be stated in terms of a T−μ phase diagram, as shown in Fig. 1, where the confined phase (hadrons) is separated from the deconfined quarkgluon plasma phase. For temperatures T>T_{c}, being T_{c} the critical temperature, the correlator D^{E}(x), and the electric string tension associated, vanishes, while the deconfining electric part, , and magnetic correlators D^{H}(x), , are the responsible for the dynamics of the deconfined phase.
Fig. 1 Schematic phase diagram in the T−μ plane. The lower curve defines the phase transition between confined and deconfined matter for V_{1} = 0.01 GeV and G_{2} = 0.006 GeV^{4}, while the upper one defines the phase transition curve for V_{1} = 0.10 GeV and G_{2} = 0.016 GeV^{4}. The shaded area indicates the region of the FCM parameters considered in this work, 0.01 GeV ≤ V_{1} ≤ 0.10 GeV and 0.006 GeV^{4} ≤ G_{2} ≤ 0.016 GeV^{4}.

Open with DEXTER
The phase diagram shown in Fig. 1, obtained through the semianalytical treatment detailed in Sect. 2.2, is in agreement with the results of Simonov & Trusov (2007b,a).
2.2. Thermodynamic quantities of the quark matter
The FCM is parametrized through the gluoncondensate G_{2}, generated by D^{E}(0), , D^{H}(0) and , and the large distance static quarkantiquark, , potential V_{1}, generated by , (Simonov & Trusov 2007a). Even though the single line approximation turn off the quarkgluon interaction, a strong interaction of quarks and gluons with the nonperturbative vacuum field exist (Nefediev et al. 2009). In this way, using singlegluon and singlequark contributions, the quark and gluon pressures, P_{q} and P_{g}, respectively, are given by (Simonov & Trusov 2007b,a; Nefediev et al. 2009) (1)where (2)with ν = m_{q}/T, μ_{q} the quark chemical potential, m_{q} the bare quark mass, T the temperature, and (3)Considering u, d and s quarks, the total quarkgluon plasma pressure, P_{qg}, is given by (4)where, is the antiquarks contribution and P_{vac} is the vacuum pressure given by (Simonov & Trusov 2007b,a; Nefediev et al. 2009) (5)where N_{f} = 3 is the number of flavors.
Since Eq. (1) coincides with the pressure for a free FermiDirac quark gas in the limit V_{1} = 0, we built a double power series expansion in terms of and (μ_{q}−V_{1}/ 2) /T to calculate Eq. (1) semianalytically. The calculation was made by adapting the approximation developed in the work of Masperi & Orsaria (2004), for a strange free quark gas at finite temperature. Details of the calculation are given in Appendix A.
On the other hand, Eq. (3) can be solved analytically: (6)where Li_{s} [z] is the Jonquière’s function.
The energy density ϵ_{qg} reads (7)where , is the quark number density and , is the entropy density.
The large distance potential, V_{1}, is given by (8)It can be shown (Kuz’menko et al. 2004) that since at large separations the string acts on quark with the force , which is the string tension related with Λ_{QCD}, then in Eq. (8) can be normalized according to exp( −ξ/λ) being λ ~ 0.2 fm the correlation length of QCD vacuum in accordance with lattice results, and .
Even though the phenomenological value of V_{1} and G_{2} are constrained by lattice calculations at zero baryonic density and finite temperature, the behavior of quark gluonplasma at low temperatures and large chemical potential, as occurs in the core of NS, could be very different (Burgio & Zappalà 2016). On the other hand, the sum rules of the QCD have determined a numerical value for G_{2}, but it has a large uncertainty: G_{2} = (0.012 ± 0.006) GeV^{4} (Shifman et al. 1979a,b).
As the static potential V_{1} depends on the temperature, we have analyzed its variation in a range corresponding to the temperatures obtained for protoHS. Solving Eq. (8), V_{1} can be rewritten as (9)in agreement with the result obtained by Bombaci & Logoteta (2013) in Eq. (9), if one considers and ħc = 1. At this point, is is worth noting that if we take V_{1}(T_{c}) = 0.5 GeV, which is a value independent of the number of quark flavors (see Simonov & Trusov 2007b,a) we obtain a critical temperature T_{c} ~ 270 MeV, the critical temperature of a hot pure gluon plasma without quarks (see Simonov 1999; Stoecker et al. 2016 for details). However, for T_{c} ~ 150 MeV, corresponding to the chiral transition, the approximately value of V_{1}(0) should be V_{1}(0) ~ 0.65 GeV according to Eq. (9). Additionally, the potential V_{1} and the gluon condensate G_{2} are related for the deconfinement transition at zero chemical potential at the critical temperature, T_{c}, and can be calculated through (Bombaci & Logoteta 2013) (10)where, a_{0} ~ 0.44 for three flavors.
On the other hand (except at T_{c}), G_{2} is essentially independent on the temperature (Burgio & Zappalà 2016). It is important to note at this point, the analysis about the dependence of G_{2} and V_{1} on the temperature is at vanishing chemical potential. There are no simulations of lattice QCD at high chemical potential, and at finite chemical potential standard lattice methods can not be used because the sign problem of QCD at nonzero baryon density (Fodor & Katz 2002). Additionally, for the range of temperatures obtained in this work in the framework of protoNS, 0 MeV <T< 60 MeV, we found that the variation of V_{1} is only 0.2% and it does not have any impact on the results. A detailed study of V_{1} related to the lattice QCD and the measured NS masses has been carried out by Bombaci & Logoteta (2013) and Plumari et al. (2013).
Thereby, attempting to impose any restrictions to V_{1} and/or G_{2} in a regime of low temperatures and high densities we will treat them as free parameters, independent of the temperature and/or the baryonic chemical potential. We have chosen three representative sets of parameters in the V_{1}−G_{2} plane: Set 1 = (V_{1} = 0.02 GeV, G_{2} = 0.016 GeV^{4}), Set 2 = (V_{1} = 0.03 GeV, G_{2} = 0.010 GeV^{4}) and Set 3 = (V_{1} = 0.10 GeV, G_{2} = 0.007 GeV^{4}). The choice of these sets also ensure a minimum maximum mass value of ~ 2 M_{⊙} in the MR diagram for cold NS.
2.3. Stability of quark matter
Since Bodmer (1971) and Witten (1984) opened up the field with the hypothesis of strange quark matter, many authors have studied and discussed the possibility that the inner core of compact objects is composed of such form of matter (Glendenning 1996; Schmitt 2010 and references therein).
The strange quark matter hypothesis suggests that strange quark matter would be the true ground state of strong interactions, that is, its energy per baryon should be less than that of the isotope ^{56}Fe (~ 930 MeV), the most bound nucleus. This hypothesis can be explained easily through the MIT Bag model if one consider noninteracting massless quarks. But this is an oversimplified treatment of the issue, because the effect of a finite strange quark mass, as well as a nonzero strong coupling constant, constraints the value of the Bag constant in the model to get stable quark matter (Weber 2005). In addition, studies of dense quark matter within more realistic models, like the NJL model, do not support the idea of absolutely stable strange quark matter (Buballa 2005). The main reason is the dynamical mass of the strange quark.
If massless u, d and s quarks at zero temperature and pressure are considered in the MIT Bag model, strange quark matter would be more stable than nonstrange quark matter because the conversion of about one third of u and d quarks into s quarks via weak interactions, decreases the energy of the system, due that baryon number is shared among three Fermi seas instead of two. But if the matter is described considering dynamical quark masses, like in the NJL model, the strange quark mass remains still large at densities where chiral symmetry is almost restored in the nonstrange sector, and then nonstrange quark matter tends to be energetically more favored than strange quark matter. The conversion of a d quark into a s quark costs too much energy.
It has been suggested that there would be other phases of strange quark matter, color superconducting phases like the colorflavor locked (CFL), more favorable to the stability condition due the emergence of diquark condensates (Lugones & Horvath 2002). However, although the formation of diquark condensates reduces the energy per baryon, it is still larger than that of ^{56}Fe if dynamical quark masses are considered (Buballa 2005).
Recent studies about the strange quark matter hypothesis in the framework of the FCM (Pereira 2013), show that for some choices of the parameters G_{2} and V_{1}, the energy per baryon can be lower than the energy per nucleon of the ^{56}Fe. According to Pereira (2013), the stability window strongly depends on the values of the FCM parameters: as V_{1} increases, from V_{1} = 0 GeV to V_{1} = 0.5 GeV, G_{2} must decrease in order to keep the energy per baryon of the quark matter less than 930 MeV.
We have also analyzed the stability of pure quark matter under our semianalytical approach. Taking the quark masses m_{u} = 2.3 MeV, m_{d} = 4.8 MeV and m_{s} = 95 MeV, we have calculated the energy per baryon at zero temperature and pressure. The results are shown in Fig. 2. We obtain a narrow stability window which is very sensitive to the FCM parameters, in agreement with the results of Pereira (2013).
From Fig. 2 it is evident that the values of G_{2} associated with the stability of strange quark matter are out of the range of values estimated through the QCD sum rules, G_{2} = (0.012 ± 0.006) GeV^{4}. However, we found that it is possible to obtain a strange star (SS) with M ≥ 2 M_{⊙} by combining V_{1} and G_{2} values inside the stability region. For example, taking V_{1} = 0.1 GeV and G_{2} = 0.002 GeV^{4}, we obtain a set of cold stable SS with M_{max} = 2.01 M_{⊙}.
Fig. 2 Stability window in the G_{2}−V_{1} plane. The colored area under the ϵ/n_{b} = 930 MeV curve indicates the stability region of the strange quark matter (m_{u} = 2.3 MeV, m_{d} = 4.8 MeV, m_{s} = 95 MeV) at zero temperature and pressure. The solid line indicates where the energy per baryon of the quark matter matches with the energy per nucleon in the ^{56}Fe most bound nucleus. Considering the QCD sum rules, the estimated value of G_{2} = (0.012 ± 0.006) GeV^{4} is out of the stability region.

Open with DEXTER
In this work we consider a metastable quark matter phase, taking G_{2} = (0.012 ± 0.006) GeV^{4} according with the QCD sum rules, but out of values determining the stability window.
3. General conditions for the hybrid EoS and phase transition
Lattice gauge simulations at finite temperature in QCD quark matter (Yasutake et al. 2013) suggest a range of the surface tension ~ 10−100 MeV fm^{2} between the interface hadronquark. If the surface tension is bigger than a critical value, which is estimated to be ~ 40 MeV fm^{2} then a sharp phase transition, between hadronic and quark phases, is favored via Maxwell construction (Endo et al. 2006; Yasutake et al. 2014).
Due the uncertainty in the value of the surface tension we assume an abrupt phase transition between hadronic and quark matter. Thus, in order to assemble the hybrid EoS, we work under the Maxwell construction, in which the crossing of both hadronic and quark EoS curves in the μ−P plane defines (or not) the phase transition.
Baryonic and electric charges are conserved locally. For the inner core of the HS, such conditions are given by (11)where n_{u}, n_{d} and n_{s} are the quark number densities, n_{e} and n_{μ} are electron and muon densities, respectively, and n_{B} is the baryonic number density.
Betaequilibrium condition determines the following relationships between the chemical potentials of the particles involved: (12)where μ_{i = u,d,s} are the quark chemical potentials and the subscripts b, e and ν indicates baryon, electron and neutrino chemical potentials, respectively.
The outer core EoS is composed by nucleonic degrees of freedom (neutrons and protons), electrons, muons and neutrinos in betaequilibrium with local charge conservation (Shen et al. 2011).
By setting equal pressure and baryonic chemical potential during the phase transition in the NeStOR code, we establish the conditions to determine the thermodynamic properties of HHS and CHS cores.
Fig. 3 Hybrid EoS for a particular pair of the FCM parameters, V_{1} = 0.03 GeV and G_{2} = 0.010 GeV^{4} (Set 2), for the three stages of constant entropy per baryon.

Open with DEXTER
The EoS for the different stages of thermal evolution for the Set 2 are shown in Fig. 3. As the star cools, the EoS becomes stiff. The baryonic densities at the transition points are n_{B} ~ 0.53 fm^{3} for s ≃ 1, n_{B} ~ 0.34 fm^{3} for s ≃ 2, and n_{B} ~ 0.33 fm^{3} for s = 0. In the case of s ≃ 1 although neutrinos soften the EoS, their contribution shifts the transition to higher densities. The transition pressure are P_{t} = 253.79 MeV fm^{3}, for s ≃ 1 and P_{t} = 86.87 MeV fm^{3} and P_{t} = 70.41 MeV fm^{3} for s ≃ 2 and s = 0 respectively. The behavior of the EoS for Set 3 is similar to that of Set 1.
For the outer core of the HS we have used the hadronic EoS constructed by Shen et al. (2010a). This EoS is built using the relativistic mean field (RMF) model with a density dependent coupling that is a slightly modified form of the original NL3 interaction (see Shen et al. 2010a, for details). The outer core is composed of neutrons, protons and electrons and we have included neutrinos in the NeStOR code. The complete EoS for astrophysical simulations in protoNS is detailed in Shen et al. (2011).
For nuclear matter at subnuclear densities we have considered the work of Shen et al. (2010b), where a Virial expansion for a nonideal gas composed of neutrons, protons, alpha particles, and nuclei is used to build the low density EoS at finite temperature. The minimum energy densities obtained through the NeStOR code were ϵ ~ 2 × 10^{10} g/cm^{3} for s ~ 1, ϵ ~ 4 × 10^{7} g/cm^{3} for s ~ 2 and ϵ ~ 2 × 10^{7} g/cm^{3} for s = 0. For lower density values, we have considered the Baym–Pethick–Sutherland (BPS) crustal model (Baym et al. 1971).
The leptonic contribution is provided by electrons, electronneutrinos and muons. For electrons and muons we have considered the same expressions used for quark matter, under s = 0 and s ≃ 2 scenarios, making the correspondent correction in the degeneracy factor and setting V_{1} = 0, which mimics exactly a FermiDirac gas at finite temperature. Under s ≃ 1 scenario, we had some numerical instabilities due the inclusion of electronneutrinos. To avoid this, we use a massless finitetemperature Sommerfeld expansion for the electrons (Lugones et al. 2009), (13)which simplifies the numerical calculation without loss of generality. For the electronneutrinos we have used the same expansion taking into account the appropriate correction in the degeneracy factor.
Fig. 4 Lepton densities n_{l} as a function of baryonic density, n_{B}, considering the Set 2 for the three fixed entropies: a) s ≃ 1, with lepton abundances Y_{Le} = 0.4 and Y_{Lμ} = 0, b) s ≃ 2, and c) s = 0. Hatched areas indicate the phase transition zone. In panels b) and c) Y_{ν} = 0, and muons are present.

Open with DEXTER
Figure 4 shows the lepton densities for the different fixed entropy stages considered, taking the Set 2 as an example. In Fig. 4a, it can be seen that the lepton density reaches values relatively high (~40%n_{B}) before the zone of the phase transition due there is also a high proton fraction in the hadronic phase. The contribution of neutrinos to the pressure shifts the phase transition to quark matter at higher densities, because the inclusion of more degrees of freedom in the system soften the EoS and therefore is more difficult to reach the pressure of quark matter at high densities. We should remark that the high abundance of neutrinos and their contribution to the pressure is the result of the condition, Y_{Le} = 0.4. At this stage we obtain that neutrinos density, n_{ν}, goes from zero to ~ 0.02 fm^{3}, almost the same maximum density reached by the muons in the following stage. Electrons and neutrinos are also present in the quark phase. In Fig. 4b, the leptonic fraction decreases in the left side of the phase transition zone, and after the peak in the hadronic region the proton fraction drop off and matter gets neutron rich. There is very little amount of electrons in the quark phase. The entropy zero stage at the left side of Fig. 4c shows a decrease in the density of electrons and muons for the hadronic phase. For the quark phase, muons do not contribute and the density of electrons is negligible. For Set 1 and Set 3 the analysis of the lepton densities is similar.
4. Snapshots of thermal evolution for protoHS
Until the protoNS reaches the thermal equilibrium, it undergoes a process of thermal evolution. The evolutionary scenario is based on a dynamical calculation with schematic EoS (see Prakash et al. 1997 and references therein). The different stages of such process are studied by considering three sequential snapshots of constant entropy per baryon. According the thermodynamic properties, each stage can be characterized as follows (Burrows & Lattimer 1986; Steiner et al. 2000; Shao 2011). First, when the NS is born, neutrinos created in beta reactions are trapped because their mean free paths are small compared with the star radius and there is leptonic abundance conservation in the star matter. No muons are present because trapped neutrinos inhibit their existence. Therefore, this stage is characterized by the conditions (14)and entropy per baryon, s ≈ 1.
After ~ 10–20 s, neutrino diffusion deleptonized the star matter and the presence of muons becomes relevant. Thus, regarding the lepton abundances, (15)Neutrino diffusion yield most of its energy to the protoNS, heating it. At this stage, the entropy per baryon reaches s ≈ 2.
Finally, after a few minutes, the star cools down and it can be characterized by an entropy per baryon, s = 0. At this stage, there is also absence of neutrinos, with (15)We show the evolution of the temperature as a function of the baryonic density in Fig. 5, Set 2, for entropies s ≠ 0. When s ≃ 1 the maximum temperature reached is T = 31.66 MeV, whereas if s ≃ 2 the maximum temperature corresponds to T = 57.19 MeV. The evolution of the temperatures for Set 3 is similar to that of Set 1.
Fig. 5 Snapshots of the temperature as a function of baryonic density in units of the saturation nuclear density for the Set 2.

Open with DEXTER
Thereby, we can characterize three different stages of the NS thermal evolution, in a simplified way, through an isentropic state. This approach allow us to study the structure and composition of NS modeled as HS during their thermal evolution on their first minutes of existence.
5. Structure of HS
Once the hybrid EoS is obtained, we have the necessary input to solve the TolmannOppenheimerVolkoff (TOV) equations, which are the relativistic structure equations of hydrostatic equilibrium and mass conservation for a spherically symmetric configuration given by where r is the radius, P(r) and ϵ(r) are the pressure and energy density at a radius r, m(r) is the mass bounded by the radius r and G is the universal gravitational constant.
Equations (16) and (17) are integrated solving the HS structure, giving for each set of parameters a family of stars with different initial conditions for the central energy density. Thus, the EoS determines the massradius relationship for each group of stars.
To solve Eqs. (16) and (17), and following the works of Logoteta & Bombaci (2013), Burgio & Zappalà (2016), Plumari et al. (2013), we have chosen several combinations of V_{1} (0.01 GeV <V_{1}< 0.10 GeV) and G_{2} = (0.012 ± 0.006) GeV^{4}. By combining these range of values for the FCM parameters as inputs in the NeStOR code, we obtain several data and tables as outputs of the program. The main microscopicthermodynamic results are the hybrid EoS, particle abundancesdensity and temperaturedensity relationships. The macroscopicastrophysics results are the massradius, the masscentral energy density and the gravitational massbaryonic mass relationships. In the V_{1}−G_{2} plane, we also construct contours of the maximum mass as is shown in Fig. 6.
For the stage corresponding to zero entropy, a V_{1}−G_{2} plane was constructed to determine the families of HS in which it is possible to obtain a minimum maximum mass star of 2 M_{⊙}. In Fig. 6, we show the variation of the maximum mass as a function of the FCM parameters V_{1} and G_{2}. We obtain contours from M_{max} ≈ 1.5 M_{⊙} to M_{max} ≈ 2.7 M_{⊙} depending on the combination of the parameters. In Fig. 7, we show in detail the M_{max} = 2.0 M_{⊙} contour.
Fig. 6 Maximum mass of each family of stars as a function of V_{1} and G_{2} at s = 0. Inside each contour area, the maximum mass increases monotonically as the values V_{1} and G_{2} increase.

Open with DEXTER
Fig. 7 Contour line for M_{max} = 2 M_{⊙} as a function of V_{1} and G_{2} at s = 0. Shaded region below the curve indicates stars with masses <2 M_{⊙}.

Open with DEXTER
Table 1 shows the masses and radii computed for different combinations of the FCM parameters. We have used the upper and lower bounds for both maximum masses and radii obtained, corresponding to the four corners of Fig. 6. We also have chosen these parameter values to determine the shaded area delimited by the solid curves in the phase diagram of Fig. 1.
Maximum mass, M_{max}, and radius, R_{Mmax}, for the extreme values of the FCM parameters, V_{1} and G_{2}, at different fixed entropy per baryon.
As was mentioned before, we have considered different combinations of the parameters in the plane V_{1}−G_{2} in order to fulfill the M_{max} ≳ 2 M_{⊙} condition. Besides this requirement, we have chosen three particular sets of parameters (Set 1, Set 2 and Set 3) so as to cover an extensive and representative region of different combinations in the V_{1}−G_{2} plane. The massradius relationship for these sets and for s ≃ 1, s ≃ 2 and s = 0 are shown in Figs. 8–10. It can be seen there are stable branches for the stellar structure up to a maximum value, M_{max}, from which unstable configurations are obtained as radii become smaller. Also, for each massradius relationship, there is a particular mass value, M_{hyb}, which indicates the phase transition between hadronic and quark matter and the appearance of HS. Table 2 shows the values of M_{hyb} and M_{max} obtained for the three sets.
Maximum mass, M_{max}, and mass associated to the appearance of the quark matter core in the MR relationship, M_{hyb}, for the three sets of the FCM parameters, V_{1} and G_{2}, at different fixed entropy per baryon.
Fig. 8 MR relationship for Set 1 (V_{1} = 0.02 GeV, G_{2} = 0.016 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
Fig. 9 MR relationship for Set 2 (V_{1} = 0.03 GeV, G_{2} = 0.010 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
Fig. 10 MR relationship for Set 3 (V_{1} = 0.10 GeV, G_{2} = 0.007 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
We have computed the three stages of constant entropy for protoHS through a simplified evolutionary process, from an initial state in which s ≃ 1 to a final state with s = 0. However, to make a suitable analysis of the protoHS evolution, it is more appropriate to study the evolutionary process in the gravitational mass – baryonic mass plane, along a constant baryonic mass path.
Until now, we have used the term “mass”, M, to refer the NS gravitational mass, given by(18)From here on we will use M_{G} for the gravitational mass to distinguish it from the baryonic mass, M_{B}, given by (19)where m_{N} is the nucleon mass and n_{B}(r) is the baryonic number density.
The study of the evolutionary process of protoNS in a M_{G}−M_{B} plane was developed before by Bombaci (1996). He has pointed out that the concept of NS maximum mass introduced by Tolmann, Oppenheimer and Volkoff (Tolman 193916; Oppenheimer & Volkoff 193917), M_{TOV}, defined as the maximum gravitational mass of a NS before becoming unstable and collapsing into a black hole, is partially inadequate when the first few seconds of NS evolution process are considered. He proposed that the study of gravitational mass  baryonic mass plane is the best way to analyze the stability of protoNS and the maximum mass concept. In order to apply this study to protoHS, we consider that the baryonic mass remains constant during the three stages of the evolution process because most of the matter accretion occurs in previous stages of the protoNS (Chevalier 1989).
The results of the M_{G}−M_{B} plane for the three sets of parameters considered in this work are shown in Fig. 11 (Set 1), Fig. 12 (Set 2), and Fig. 13 (Set 3). Each plane contains the three isentropic stages, s ≃ 1, s ≃ 2 and s = 0, taken into account for the evolution of the protoHS. It can be seen that M_{G} increases with M_{B} up to a maximum value, after which the solutions become unstable. These unstable branches have been removed in all the plots to make the figures more readable.
Fig. 11 M_{G}−M_{B} plane for Set 1 (V_{1} = 0.02 GeV, G_{2} = 0.016 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
Fig. 12 M_{G}−M_{B} plane for Set 2 (V_{1} = 0.03 GeV, G_{2} = 0.010 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
Following the study of Bombaci (1996), we analyze qualitatively the evolution of protoHS through Fig. 14 considering the baryonic mass remains constant during the thermal evolution of the HS. We use this figure in order to clarify the evolution of HS from the s ≃ 1 to the s = 0 stages because it is representative of the behavior of M_{G}−M_{B} curves shown in the Figs. 11, 12 and 13. The dots labeled by a, b, c represent the maximum mass configuration corresponding to the isentropic curves s ≃ 1, s ≃ 2 and s = 0, respectively. Also, it is convenient to define as the baryonic/gravitational mass associated to i = a, b, c, d, and f in the Fig. 14.
We will also define four baryonic mass ranges: , , and . The evolutionary process of the protoHS can be followed starting from the s ≃ 1 curve, downwards along a constant baryonic mass vertical line. If , as the vertical line crosses the s ≃ 2 and s = 0 curves, the protoNS will remain stable, the neutrinos will escape and it will end as a cold NS in the s = 0 curve. If the protoNS will reach a stable configuration in the s ≃ 2 curve and the neutrinos will escape, but then it will collapse to a black hole, meaning that no cold stable configurations are possible for these values of baryonic mass. For , the protoNS newly formed will collapse shortly afterwards to a black hole. Finally, for , the protoNS will never form and the supernovae remnant will collapse to a black hole.
Fig. 13 M_{G}−M_{B} plane for Set 3 (V_{1} = 0.10 GeV, G_{2} = 0.007 GeV^{4}). In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core.

Open with DEXTER
Fig. 14 Enlarged M_{G}−M_{B} plane for V_{1} = 0.03 GeV and G_{2} = 0.010 GeV^{4} close to the maximum mass configurations. In each constantentropy curve, the rounded dot indicates the appearance of the quark matter core. The squared points a, b and c indicate the maximum mass configuration for s ≃ 1, s ≃ 2 and s = 0, respectively. The squared dot d indicates the initial configuration that evolves, through a constant baryonic mass vertical line, to the maximum mass configuration of the curve s ≃ 2. Only for protoHS with baryonic masses , a constant baryonic mass vertical line can be drawn across the dots f, e and c and the three isentropic curves. Thus, such stars will remain stable, surviving the evolutionary process towards a cold HS.

Open with DEXTER
The possibility of a phase transition in the protoNS is indicated by rounded dots in the M_{G}−M_{B} plane, suggesting the appearance of a quark matter core. Configurations with smaller baryonic masses than the associated to the rounded dot in each curve (, i = 1,2,0) are purely hadronic, while configurations with greater baryonic masses are NS with a quark matter core. From Figs. 11, 12 and 13, it can be seen that quark matter could be formed during the constant baryonic mass evolution. Thus, a protoNS having a baryonic mass ending as a stable cold NS, would begin as purely hadronic and become an HS with a quark matter core after the whole cooling process.
According to our results, the sequence of snapshots suggests that a quark matter core may be formed during the cooling process between the stages with entropies per baryon s ≃ 2 and s = 0. This is in contrast with the predictions of earlier studies where the deconfinement of quark matter occurs some seconds after the core bounce (Benvenuto et al. 1989; Benvenuto & Horvath 1989) or the transition from nuclear to quark matter takes place during the stage with s ≃ 1 (Benvenuto & Lugones 1999).
The first order phase transition between hadronic and quark matter in the protoNS is triggered by the nucleation of a critical size drop of the new stable quark phase in the metastable hadronic phase. It has been suggested in a detailed study of the effects of quark matter nucleation on the evolution of protoNS by Bombaci et al. (2011) and Bombaci et al. (2016) that if the nucleation time is greater than the cooling time for a protohadronic star, then quark matter nucleation is not likely to occur in a newly formed star.
The calculation of the nucleation time depends on the properties at the interface between the hadronic and quark matter phases and it is out of the scope of this study. But based on the results of Bombaci et al. (2011) and Bombaci et al. (2016) , we assume that the nucleation time of quark matter is less than the cooling time of the protoNS during its evolution when the entropy per baryon decreases from s ≃ 2 to s = 0. In this way, is feasible the protoNS evolves into a cold hybrid configuration with a quark matter core.
Our results show that it is always possible to obtain hydrostatic stable configurations for the different parameter combinations used. Also, for some particular combinations, the two solar masses for the gravitational maximum mass star are reached. It is worth noting that an increase in the value of V_{1} or G_{2} generates an increase in the value of such maximum mass. For CHS, s = 0, stable configurations may suggest that PSR J16142230 and PSR J0348+0432 stars could be HS.
Although there is not still an accurate enough determination of NS radii, we have considered the constraint imposed by two recent studies on NS: a lower limit of R> 10.7 km for NS with masses M = 1.4 M⊙ established by Chen & Piekarewicz (2015), and an upper limit of R< 16.8 km, inferred from the NS RX J1856375 Boshkayev et al. (2016). The radii obtained for the CHS are within the range set by such limits.
6. Summary and conclusions
In this work we have studied, in a very simplified way, the thermal evolution of protoNS modeled as HS, considering a successive sequence of constant entropy per baryon snapshots. The evolution started in a hot stage, with and entropy per baryon of s ≃ 1 and where trapped neutrinos have been subjected to the condition Y_{Le} = 0.4. In the following stage, after ~ 15 s, neutrinos diffuse and warm the star being s ≃ 2 and Y_{νe} = 0. Finally, after a few minutes, the star cools down and the last stage is reached, where s = 0.
We used a tabulated EoS to describe the hadronic phase of the protoHS and the FCM for the description of quark matter. To analyze how the results for protoHS evolution depend on the FCM parameters, we have taken into account three different combinations of V_{1} and G_{2}.
The use of the NeStOR code to construct the hybrid EoS, allowed us to study the HS structure via the integration of the TOV equations as well as the gravitational mass  baryonic mass plane, M_{G}−M_{B}. The hybrid EoS was constructed at finite temperature, taking into account the characteristic composition for each evolutionary stage. For the hadronic phase, we used an EoS constructed for astrophysical simulation of protoNS. We have obtained, for each constant entropy stage, a family of stable HS, with a characteristic massradius relationship. Considering the constraints from astrophysical observations of NS, we have studied the variation of the maximum mass star with the different combination of FCM parameters, for each family.
Also in the framework of the FCM semianalytical quark matter EoS, we analyzed the stability of strange quark matter within the strange quark matter hypothesis. The results obtained from our semianalytical quark EoS are in agreement with previous works using the FCM, both the simplified phase diagram of the QCD as the stability of the strange quark matter. Under the simplified model of thermal evolution considered in this work, the temperature profiles obtained for the HHS are in agreement with the dynamical calculations with schematic EoS of the thermal evolution of NS.
Regarding the concept of maximum mass for protoNS, we have also analyzed the M_{G}−M_{B} plane. The cooling evolution was studied considering the baryonic mass conservation during the whole process (Bombaci 1996). We have schematically analyzed the baryonic mass ranges, separating the newly born NS, which will evolve to stable CHS from those that will collapse afterwards to a black hole.
The study of the gravitational massbaryonic mass plane for protoHS, has revealed in which of the three stages of constant entropy considered, a phase transition from hadronic matter to quark matter could occur in the context of the microscopic models used in this work. Our results suggest that an early (s ≃ 1) phase transition between quark matter and hadronic matter is not produced for the baryonic mass ranges in which the protoHS end as stable CHS, but the formation of stable CHS is possible due a late phase transition, after the stage s ≃ 2. This contrasts with previous studies (Benvenuto et al. 1989; Benvenuto & Horvath 1989; Benvenuto & Lugones 1999) where pure hadronic stars are converted to quark stars within the first seconds after their birth.
It is worth pointing out that our model is a simplified treatment of the thermal evolution. The calculation of the quark matter nucleation rate and the nucleation time, due to thermal nucleation mechanisms in the framework of the EoS considered, would provide a better understanding of the finite size effects of the phase transition between hadronic and quark matter. These further calculations are beyond the scope of this work.
We have obtained stable CHS that easily reach the two solar masses for the maximum mass star for several combination of the FCM parameters. According our results, the pulsars J16142230 and J0348+0432 would contain quark matter in their inner cores. However, we note that we have neither considered hyperons in the hadronic phase nor the color superconductivity in the quarkgluon plasma phase. The inclusion of either of these two contributions will modify the EoS of each phase and therefore the critical point where the transition occurs. The effects of such contributions should be studied in a future work.
Future observations of neutrinos in supernovae, as well as the observation of Xray and γray emissions of young pulsars will enable the astrophysicist community to carry out simulations on real thermal evolution that will contribute to the understanding of the underlying physics of NS.
