1. Introduction

One of the key questions regarding the formation of stars in galaxies is related to the way gas condenses and how it cycles from the hot and diffuse phase to cold and dense structures where stars form. This process is related to the formation of the cold neutral medium (CNM) and the atomic-molecular (or H i-H2) transition. One of the frameworks in which this general process is understood is related to colliding flows where a region of the warm neutral medium (WNM) undergoes an increase of pressure that facilitates the rapid cooling of the gas to the stable CNM phase. This process has been studied in several numerical simulations (Hennebelle & Pérault 1999; Audit & Hennebelle 2005; Vàzquez-Semadeni et al. 2006; Hennebelle et al. 2007; Inoue & Inutsuka 2009; Saury et al. 2014). One way of witnessing the formation of cold structures in a colliding flow is by looking at the effects of clouds falling onto the Milky Way disk.

thumbnail Fig. 1

Median (left) and standard deviation (right) spectra of the 21 cm emission in the Draco area. The GBT data used are from Martin et al. (2015). The LVC, IVC, and HVC velocity ranges are indicated by vertical dashed lines.

Our Galaxy, as all galaxies, is an open and dynamical system. Matter is constantly arriving on the Galactic disk. Part of this gas is the result of the Galactic fountain: hot gas rises into the halo from stellar winds and supernovae then returns to the disk due to gravity (Shapiro & Field 1976; Bregman 1980; Putman et al. 2012). Matter also arrives from intergalactic space in the form of either gas stripped from satellite galaxies or gas from the intergalactic medium (IGM). The origin of the material falling into the disk can partly be determined by its metallicity.

The high-velocity clouds (HVC) in our Galaxy are considered possible direct evidence for extragalactic infalling gas. Measurements of the metallicity of HVC gas range from very low (0.1) up to solar (Collins et al. 2007). The intermediate-velocity clouds (IVC) are closer to the Galactic layer. Most of these clouds are part of the Galactic fountain, but some should be matter of extragalactic origin that interact with the disk. At this point it is unclear if the amount of new material entering the disk is sufficient to maintain the star formation rate of galaxies (Peek et al. 2008; Sancisi et al. 2008).

This influx of matter from the halo also adds kinetic energy to the interstellar medium (ISM). It is a way to input the supernovae energy into interstellar turbulence at some distance from where it was produced. One important question relates to the physical properties of the infalling gas and the impact it has on the star formation cycle in galaxies (Heitsch & Putman 2009; Joung et al. 2012). Given the significant velocity (10s to 100s of km s-1) with which matter encounters the Galactic disk, it is expected to be shocked and undergo dynamical instabilities. The thermal distribution of the gas, its density structure, and the amount of molecular gas produced in the end is not well constrained observationally, partly because of the lack of observations that show this situation clearly.

The Draco nebula (hereafter Draco), an icon among the IVCs, probably provides the best opportunity to understand these processes and resulting physical conditions. By chance there is little structured local ISM gas in the direction of Draco, allowing a very clear view of the matter entering the disk even in integrated (dust or gas) emission.

In this paper we complement what is already known about Draco by presenting Herschel-SPIRE (Griffin et al. 2010) maps of the nebula, revealing the fine details of its structure, and especially of its Rayleigh-Taylor front. We used these observations to quantify the typical length of the Rayleigh-Taylor instability, putting some constraints on the gas viscosity and properties of turbulence in Draco. The high resolution of the Herschel-SPIRE data also allows us to characterize the statistical properties of the small-scale structures formed in the postshock region, which enables us to quantify the outcome of the cloud collision in terms of structure formation.

The paper is organized as follows. In Sect. 2 we summarize what is known about Draco. Section 3 presents the data used for this study, how we computed the map of the column density, and a description of the structure of the Rayleigh-Taylor instability front. The small-scale structure is analyzed in Sect. 4. Our results are discussed in Sect. 5 and summarized in Sect. 6.

2. The Draco nebula

thumbnail Fig. 2

H i column density maps in the direction of Draco for the LVC (bottom), IVC (middle), and HVC (top). Data were obtained at the Green Bank Telescope; they are part of the GHIGLS survey (Martin et al. 2015). The column density maps are the same as those used in Planck Collaboration XXIV (2011).

2.1. A molecular intermediate velocity cloud

Draco is the most studied diffuse IVC at high Galactic latitude (l ≈ 91°, b ≈ 38°). It was first observed at 21 cm by Goerigk et al. (1983) at a velocity v~−25 km s-1, following calibration observations obtained with the Effelsberg 100 m telescope (Kalberla et al. 1982). More recently, a 5° × 5° region centered on Draco was observed at 21 cm with the Green Bank Telescope (GBT) as part of the GHIGLS survey (Martin et al. 2015). A smaller area was also covered at higher angular resolution with the interferometer of the Dominion Radio Astrophysical Observatory as part of the DHIGLS survey (Blagrave et al. 2017). In this region of the sky, three specific H i velocity components are seen: IVC, HVC, and a low-velocity cloud, LVC, which corresponds to the gas in the solar neighborhood. These three velocity components show up in the median and standard deviation 21 cm spectra (Fig. 1). Figure 2 presents their column density map based on the GHIGLS data. To identify the three components, we used the standard deviation spectrum of the 21 cm emission (Fig. 1 – right) following Planck Collaboration XXIV (2011). These maps indicate that the H i column density in this direction of the sky is dominated by Draco, both in absolute value and variations.

Goerigk et al. (1983) noticed that the H i cloud coincides with a faint optical nebula seen in the Palomar Observatory Sky Survey (POSS). These authors estimated that the ratio of dust extinction to H i column density, NHI, is unusually high, a factor 10 higher than typical values for diffuse clouds, which led them to conclude that most of the gas is in molecular form. From the analysis of their 21 cm data and its comparison with X-ray measurements, Goerigk et al. (1983) also suggested that Draco is the result of the interaction of Galactic halo gas entering the disk and that the details of its front-like structure is the result of the Rayleigh-Taylor (RT) instability.

The presence of molecular gas was attested by Mebold et al. (1985) and Rohlfs et al. (1989) who carried CO observations of the brightest part of the nebula and found clumps of strong molecular emission at the boundary of the nebula. CO emission has also been detected by Planck (Planck Collaboration XIII 2014). In addition, Stark et al. (1997) reported the detection of CH emission at 3.3 GHz and Park et al. (2009) presented far-UV (FUV) observations showing the molecular hydrogen fluorescence over the whole nebula.

Draco is part of the Magnani et al. (1985) catalog of high Galactic latitude molecular clouds (MBM 41 to 44). According to Magnani & Smith (2010) there are only five other regions at high Galactic latitude where intermediate velocity molecular gas (CO) has been detected; Draco is the region at the lowest Galactic latitude and the largest on the sky (about 4° × 4°).

Molecular gas was also revealed indirectly by X-ray data; Moritz et al. (1998) estimated that up to 70% of the hydrogen is molecular in the brightest parts of the nebula. Draco also appears as a shadow in the soft X-ray ROSAT data, enabling to measure the column density of hydrogen independently (Burrows & Mendenhall 1991; Snowden et al. 1991). These measurements also imply that most of the gas is in molecular form. Similar conclusions are reached by comparing dust and 21 cm data (Herbstmeier et al. 1993; Planck Collaboration XXIV 2011).

One specific feature of Draco is that it shows unusually strong CO emission for a diffuse cloud. It has significant CO emission on lines of sight where the total column density (derived either from dust emission or X-rays) is much lower than the usual threshold of 0.5−1 × 1021 cm-2 where molecular gas is usually seen in the ISM. In addition, large values of the ratio W(12CO) /N(H2) were deduced by Herbstmeier et al. (1993), Moritz et al. (1998). Also, Herbstmeier et al. (1994) observed higher CO transitions (up to J = 3−2) to look for unusual excitation conditions but they found line ratios compatible with the average values found in cirrus clouds. This is indicative of a high CO abundance that is potentially caused by an increase of the density due to the collision of a halo cloud entering the Milky Way disk.

2.2. Hot gas

There have been a few studies looking for hot gas in the area of Draco. Hirth et al. (1985) and Kerp et al. (1999) showed an excess of X-ray emission that seems to be spatially correlated with Complex C, but no clear relationship with Draco itself could be established. On the other hand, based on FUV observations, Park et al. (2009) reported the detection of several ionic lines in the direction of Draco, especially C IV, Si II, and O III]. The C IV and Si II lines are seen outside Draco, possibly coming from the hot ionized Galactic layer. In addition, there is an excess of C IV, correlated with the dust emission of Draco. This excess is also seen in Hα and O III], but not in Si II. Because of the absence of Si II, the authors concluded that the C IV, Hα, and O III] emission in Draco cannot be the result of photoionization but it could be from the radiative cooling of warm, shocked gas.

2.3. Distance

An important clue informing any self-consistent description is the location of Draco in the Galaxy. Many attempts to estimate its distance have been made using different techniques. Star counts and color excess methods were used by Mebold et al. (1985), Goerigk & Mebold (1986), Penprase et al. (2000) giving distance estimates of 800 <d< 1300 pc. On the other hand, as pointed out by Lilienthal et al. (1991), both these methods have potential biases especially at low AV. The only direct measure of the distance to Draco came from the detection of Na I D absorption lines at the systemic velocity of Draco in the spectrum of one star with known parallax distance (Gladders et al. 1998). Combined with the nondetection for other foreground stars, Gladders et al. (1998) estimated that 463-136+192d618-174+243pc\hbox{$463^{+192}_{-136}\le d\le 618^{+243}_{-174}~{\rm pc}$}.

In the following, we adopt a distance of 600 pc. At the latitude of Draco, this distance corresponds to a height above the Galactic plane of z = 370 pc. As the half width at half maximum of the WNM in the Galactic disk is ~ 265 pc (Dickey & Lockman 1990), Draco is located in the upper part of the diffuse Galactic disk (or lower Galactic halo). What is clear is that Draco is out of the Local Bubble and so it must shadow X-rays coming from the Galactic halo.

The fact that Draco is located in the outer part of the Galactic disk is compatible with the fact that its brightness in the optical is comparable to clouds with dust properties typical of the disk (Mebold et al. 1985). It suggests that Draco is illuminated by a fairly standard interstellar radiation field and so is not likely to be located at kpc distances. A similar argument can be made from its infrared brightness.

thumbnail Fig. 3

Draco nebula at 250 μm as observed with Herschel-SPIRE. From the comparison with Planck and H i data, the 250 μm brightness is proportional to gas column density (see Sect. 3). The color scale shown in this image translates to 0 < NH < 6.2 × 1021 cm-2.

thumbnail Fig. 4

Rayleigh-Taylor instability structure as seen in the 250 μm SPIRE map. The blue lines give the apparent distance between fingers.

3. Herschel-SPIRE map of Draco

Draco was observed with Herschel PACS (110 and 170 μm) and SPIRE (250, 350 and 500 μm) as part of the open-time program “First steps toward star formation: unveiling the atomic to molecular transition in the diffuse interstellar medium” (P.I. M.-A. Miville-Deschênes). A field of 3.85° × 3.85° was observed in parallel mode. Unfortunately, an error occurred during the acquisition of the PACS data making them unusable. Therefore, the results presented here are solely based on SPIRE data, especially the 250 μm map that has the highest angular resolution.

The SPIRE data were reduced using a standard procedure with HIPE v13. We used the product available on the Herschel IdOc Database (HESIOD1). The zero level of each map was set by correlation with Planck data (see Appendix A). The SPIRE 250 μm map of Draco is shown in Fig. 3. In what follows, we use the 250 μm map converted to total hydrogen column density, NH. The details of this conversion are given in Appendix A.

thumbnail Fig. 5

Draco nebula. RGB image combining Herschel-SPIRE 250 μm (red) and WISE 12 μm (blue) from Meisner & Finkbeiner (2014). The green channel is the average of the two others. The size of the mosaic is ~5° × 5°. The angular resolution of both maps is comparable (17.6′′ for SPIRE 250 μm and 15′′ for WISE 12 μm).

The Herschel data reveals for the first time the structure of matter in Draco at physical scales down to 0.05 pc (resolution of 17.6′′ at 250 μm). The wispy and filamentary structure already seen in previous data (21 cm, far-infrared) is striking here. At the front structure at low declination where RT type structure were already identified, the SPIRE data reveals a wealth of clumpy structures organized in finger type structures.

One of the most striking features of the Herschel observations of Draco is the structure of the front that shows periodic half shells that are similar to structures produced by the Rayleigh-Taylor instability. A close-up view of the shock front is given in Fig. 4 revealing the typical arches. The size of the arches is variable and the identification of the fingers is not always obvious. Nevertheless, we found a variation of about a factor of two with an average angular size of \hbox{$12\farcm5$} . Assuming a distance of 600 pc and that the structures are orientated perpendicular to the line of sight, the typical length of the instability structure in Draco is λmax ≈ 2.2 pc. In Sect. 5.2.1 we discuss on how this typical length might provide some information on the viscosity of the gas and on some properties of interstellar turbulence.

The 250 μm dust emission map reveals a higher dynamic range of the column density than 21 cm data. The H i column density (Fig. 2) ranges from 1 to 3 × 1020 cm-2, while the dust emission indicates a range from 3 to 50 × 1020 cm-2. It even reaches NH = 1 × 1022 cm-2 for a few pixels in the brightest parts in the southern region of the nebula. Part of this difference is due to different angular resolution of the GBT (9) and SPIRE (17.6′′) data. Nevertheless, even when brought to the same angular resolution, a significant difference remains between the column density estimated with dust emission and 21 cm data. This confirms previous studies based on such a comparison and that showed that a significant portion of the bright region of Draco is composed of molecular hydrogen (Herbstmeier et al. 1993; Planck Collaboration XXIV 2011).

Figure 5 presents another view that combines SPIRE 250 μm and WISE 12 μm data (Meisner & Finkbeiner 2014). This image highlights strong variations of the relative abundance of smaller dust grains with respect to bigger dust grains. In particular, in the front-like structure, where strong CO emission is observed, there is almost no 12 μm emission, indicating a relative lack of smaller dust grains. One possibility is that smaller dust grains have disappeared through coagulation on bigger grains in a denser environment, similar to what is seen in molecular clouds. If that is the case, the color variations in Fig. 5 could somehow reflect the variations of the gas density. Other possibilities might relate back to the pre-existing grain populations in the WNM and their response to the collision. The spectacular variations of the dust color ratio from dense to diffuse parts of the nebula encompass rich information on the evolution of interstellar dust in compressed environments. The image shown in Fig. 5 clearly deserves a dedicated and detailed analysis that we leave for a future study.

4. Small-scale structures

The Herschel-SPIRE data provide a striking view of the small-scale structure of Draco (Figs. 35). In this section we characterize this structure and compare it with that seen in molecular clouds.

4.1. Structure identification

To characterize the general morphology of the nebula we broke it into individual structures using the 2D version of the clumpfind algorithm (Williams et al. 1994) that has been used extensively to identify structures in molecular clouds, the Milky Way, and external galaxies. Because it identifies islands above some brightness thresholds, clumpfind does not make any assumption concerning the shape or size of the structures. On the other hand, as it identifies structures using contours, clumpfind is rather sensitive to noise because it breaks contours at low brightness level.

To identify structures on the original 250 μm map, we had to set the lowest threshold value of clumpfind to a value higher than the noise level. The noise level at the pixel size is relatively high compared to the brightness of some of the diffuse emission seen at larger scales. The result was that only the brightest structures were identified by clumpfind, leaving out more diffuse parts of the nebula that are visible by eye. To minimize the effect of noise, we applied clumpfind on a version of the map convolved by a Gaussian kernel. Empirically we found that a kernel of FWHM = 30.5′′, corresponding to a decrease of the angular resolution by a factor of two, from 17.6′′ to 35.2′′, eliminates the effect of noise. The smoothed map was then projected on a coarser grid with a pixel size that is twice the original size (from 6′′ to 12′′).

We therefore applied clumpfind on the smoothed Herschel-SPIRE 250 μm map, converted to NH, with 40 threshold values, equally spaced in log, from 1.25 × 1021 to 2.0 × 1022 cm-2 (corresponding to 5 to 80 MJy sr-1). The lowest threshold value is rather conservative but it rejects any contamination by galaxies while providing little impact on the properties of the identified structures. We stress that the results presented here do not depend significantly on the details of these choices (size of the smoothing kernel and threshold levels of clumpfind). A total of 5028 structures were identified. Their properties are described next.

thumbnail Fig. 6

Histogram of the size of each structure computed using the eigenvalues of the inertia matrix.

4.2. Physical properties

For each structure we defined a typical size, L, its mass, M, and its density, n. The histograms of these quantities are shown in Figs. 6 to 9.

4.2.1. Size of structures

For each structure identified we estimated a typical size, taking the brightness distribution of the structure into account; in the definition of the size, brighter pixels have a larger weight. This definition is less sensitive to noise and to the sensitivity of an observation. The method used to estimate L is described in Appendix B.

thumbnail Fig. 7

dN/ dlog (M) diagram for the identified structures. The red line is a power-law fit for range where M ≥ 2 M.

At a distance of 600 pc, the angular resolution of the 250 μm map translates into a physical distance of 0.05 pc. This is the FWHM of the smallest structure that can be identified in the map. The way the size is estimated (see Appendix B), the smallest size that can be found corresponds to L = 0.75 FWHM, so the minimum value L can have is in fact 0.04 pc. By degrading the resolution of the original image by a factor of two, the minimum L is doubled to 0.08 pc. This corresponds exactly to the lowest value of L found here (see Fig. 6). The distribution of L has quite a narrow distribution; 50% of the structures are lower in size than twice the resolution (L ≤ 0.16 pc) and 90% of them are lower in size than three times the resolution (L ≤ 0.24 pc). The largest value of L is 0.47 pc.

The fact that we are finding physical sizes that are similar to the resolution implies that the emission is varying strongly at small scales. This is compatible with the visual impression given by Figs. 35. The range of sizes found here is likely to be a combination of the angular resolution of the Herschel-SPIRE data and of how close small-scale structures are. The size of a structure found by clumpfind is influenced by the distance to its neighbors. The fact that we find that 90% of the structures are lower in size than 0.25 pc is indicative that matter is structured significantly at scales smaller than that value.

4.2.2. Mass

The mass of each structure is defined as M=NHtotD2tan2(δ)μmH,\begin{equation} M = N_{\rm Htot} \, D^2 \, \tan^2(\delta)\, \mu m_{\rm H}, \end{equation}(1)where NHtot is the total column density of a structure, summed over all pixels, D the distance, δ the pixel angular size, and μ the molecular weight. Here we assumed μ = 1.4 to take elements heavier than hydrogen into account.

The total amount of mass in the structures identified is ~ 5.2×103M. The mass distribution of the structures is shown in Fig. 7. The mass ranges from 0.1 to 20 M with a median value of 0.53 M. We fitted the high mass part of the distribution using a power-law dN/ dlog (M) ∝ Mα assuming a 1/N\hbox{$1/\!\sqrt{N}$} uncertainty for each data point. The exact value of the power-law exponent depends on the range over which the fit is performed. For M ≥ 2 M we obtain α = 1.4. We noticed that the low end of the mass distribution has a shape similar to a log-normal distribution.

The value of α found for Draco is significantly different of that found for giant molecular clouds in general (α ~ 0.8 for M > 104M, Solomon et al. 1987; Kramer et al. 1998; Heyer et al. 2001; Marshall et al. 2009). On the other hand, a mass distribution with a similar shape (log-normal plus power-law tail) and a similar range in mass was found in a study of the core mass function (CMF) in Aquila by Könyves et al. (2010). These authors found that the high mass part of their dN/ dlog (M) is compatible with a power law with a slope of α = 1.5. We also note that Peretto & Fuller (2010) found similar α values for small scale fragments of molecular clouds. These similarities are intriguing given the large difference in physical conditions between the cores of Aquila rift, the fragments of molecular clouds, and the clumps of Draco, and considering that different methods were used to identify structures.

We note a general trend between the mass and size of the structures that is similar to what is observed in more massive molecular clouds. Figure 8 shows a log-log density plot of the mass of the structures versus their size. The low end of the diagram is well modeled by a power-law M = 45 L2.3, where L and M have units of pc and M, respectively. On the other hand, the structures with sizes larger than 0.2 pc or masses larger than 1 M seem to depart from this relation; these structures are systematically more massive than what the relation predicts.

Several studies have highlighted such a relationship with a very similar exponent. Roman-Duval et al. (2010) found Mr2.26 for molecular clouds having sizes in the range 0.730 pc. Heithausen et al. (1998) found Mr2.31 for scales ranging from 0.01 to 1 pc. A similar mass-size relation is seen in numerical simulations where there is no gravity, and with or without heating and cooling processes included (Kritsuk et al. 2007; Federrath et al. 2009; Audit & Hennebelle 2010). Because of the fact that this relation is seen in different physical conditions, including isothermal gas, it is often attributed to turbulence.

thumbnail Fig. 8

Two-dimensional histogram of M vs. L. The grayscale is proportional to the density of points. The red line is not a fit. It is indicative of the trend seen at low values of L and M.

thumbnail Fig. 9

dN/ dlog (n) diagram. The blue line is a log-normal fit of the distribution of the density n.

4.2.3. Gas density

The gas density of each structure is defined by n=3M4πL31(μ+fH2)mH,\begin{equation} n = \frac{3 M}{4\pi L^3} \frac{1}{(\mu+f_{\rm H2}) m_{\rm H}}, \end{equation}(2)where fH2 = MH2/ (MHI + MH2) is the portion of the hydrogen that is in molecular form. It is expected that fH2 varies across the Draco field; Herbstmeier et al. (1993) estimated that the molecular portion varies from 0.04 to 0.7. The details of the H i-H2 transition in Draco is beyond the scope of the present paper. Here we assume a constant value of fH2 = 0.5.

The histogram of n (Fig. 9) is very well represented by a log-normal distribution (i.e., log (n) is Gaussian distributed) with a median value of 1.0 × 103 cm-3 and a standard deviation of 0.14 in log 10(n). The density values given here assume that half of the hydrogen atoms are in H2. The majority of the structures have a density higher than the 12CO J = 1−0 critical density (nH2 ~ 750 cm-3).

In general, it is observed that smaller molecular clouds have higher densities. This is related to the very clumpy and open structure of molecular clouds, which implies a volume filling factor lower than unity. In other words, the mass does not scale with L3 (see Fig. 8), therefore the density estimated over large physical scales is an underestimate of the density at small scales, explaining why the average density in GMCs is found to be smaller than the critical density of CO. For instance, from the sample of molecular clouds of Roman-Duval et al. (2010), one obtains that nH2⟩ = 800L-0.64. For the typical size of a structure in Draco (L = 0.15 pc, see Fig. 6) that relationship would predict nH2⟩ = 2.7 × 103 cm-3, only a factor of 3 more than what we estimated. Given the large dispersion of the nH2L relation observed in the ISM, the values obtained here seem typical for molecular clouds.

4.2.4. Jeans mass

To evaluate the gravitational stability of the structures in Draco we compared their mass with the Jeans mass that gives the maximal mass of a stable isolated and spherical clouds (Lequeux 2005), Mj=(1μmH)2(52kTG)3/2(43πn)1/2,\begin{equation} M_j = \left(\frac{1}{\mu m_{\rm H}}\right)^2 \, \left( \frac{5}{2} \frac{k T}{G} \right)^{3/2} \, \left(\frac{4}{3} \pi n\right)^{-1/2}, \end{equation}(3)where μ is the molecular weight (equals to 1.4 or 2.4 for fully atomic or molecular hydrogen, respectively).

Only 1% of the structures have a mass larger than the Jeans mass (Fig. 10). These structures are the more massive. They encompass 15% of the total mass of the structure identified.

thumbnail Fig. 10

dN/ dlog (M/MJeans) diagram.

5. Discussion

The Herschel-SPIRE observations of Draco reveal two important aspects of the gas structure resulting from the collisions of two flows. The observations reveal a dense front with regularly spaced fingers of dense gas, a structure typical of the RT instability, and numerous and contrasted small-scale structures (clumps).

5.1. Formation scenario

According to what was proposed very early on (Kalberla et al. 1984; Mebold et al. 1989; Rohlfs et al. 1989), Draco seems to be the result of the compression of warm gas in the outer part of the Galactic WNM layer (z ~ 370 pc) because of the collision with a cloud falling from the Galactic halo onto the disk. Whether the cloud at the origin of the collision was part of the Galactic fountain or from the intergalactic medium is difficult to establish at this point.

Benjamin & Danly (1997) suggested that IVCs and HVCs have trajectories in the Galactic halo that are compatible with clouds falling on the Galactic disk, attracted by the Milky Way gravitational potential, and slowed down by their interaction with the Galactic ISM. In this scenario, IVCs and HVCs would have reached their terminal velocity.

According to these authors the terminal velocity depends on the Galactic height, z, of the cloud, its column density, NH, the gravitational acceleration of the galaxy, g(z), the density distribution of the halo gas, n(z), and on a parameter that quantify the efficiency of the friction, Cd, vt(z)=2NHg(z)Cdn(z)·\begin{equation} v_{\rm t}(z) = \sqrt{\frac{2\, N_{\rm H}\, g(z)}{C_{\rm d}\, n(z)}}\cdot \label{eq:terminal_velocity} \end{equation}(4)The total gravitational acceleration (gas and stars) is approximated by g(z)=9.5×10-9tanh(z/400pc).\begin{equation} g(z)= 9.5 \times 10^{-9}\, {\rm tanh} (z/{\rm 400~pc}). \end{equation}(5)The gas distribution is the sum of the H i layer (Dickey & Lockman 1990), the WIM layer (Reynolds 1993), and of a hot ionized layer (Wolfire et al. 1995), shown in Fig. 11 (for details, see Benjamin & Danly 1997). Like in Benjamin & Danly (1997), we assumed Cd = 1.

Benjamin & Danly (1997) stressed that this picture is compatible with the observations as clouds closer to the plane have lower absolute velocity than clouds far away. Draco fits that picture. Assuming a column density of NH = 1.3 × 1020 cm-2 and a height above the plane of z = 370 pc, its observed velocity (v = vLSR/sinb = 40 km s-1) is comparable to its expected terminal velocity (vt ≈ 50 km s-1, see Fig. 11 and Benjamin 1999).

thumbnail Fig. 11

Terminal velocity (top) and deceleration (middle) as a function of Galactic height for a cloud of NH = 1.3 × 1020 cm-2. The bottom panel is the gas density vs. z, including the H i, the WIM, and the HIM. The dotted lines indicate the range in distance of Gladders et al. (1998) and the dashed lines show the corresponding values on each curve.

If Draco has indeed reached its terminal velocity, its average velocity does not inform us on its origin (Galactic fountain or extragalactic gas). Draco could have once been an HVC but it would have slowed down as it interacted with the ISM of the disk. One fact that could favor the Galactic fountain origin is the bright dust and CO emission, showing that it contains a significant amount of heavy elements. On the other hand, the matter that composes Draco today could be Galactic gas swept up by an originally low metallicity cloud that has been slowed down by the Galactic ISM. At z = 370 pc above the Galactic plane, the total column density (H i+H+) encountered by a cloud coming from infinity is about NH = 1 × 1020 cm-2, estimated by integrating n(z) (Fig. 11) for z> 370 pc. This is similar to the column density of Draco itself. Therefore, a large portion of the mass of Draco could be composed of Galactic gas with near solar metallicity even though the original cloud had a low metallicity. A detailed study of the metallicity of the gas in Draco could provide some answers to that question.

There has been some speculation about the potential role of the HVC component seen at vLSR ~ −150 km s-1 in the formation of Draco (Hirth et al. 1985). The morphology of the three H i components (Fig. 2) could suggest that the IVC (Draco) is the result of the dynamical interaction between the HVC and LVC. Along those lines, Pietz et al. (1996) proposed that faint 21 cm emission at velocities between the HVC and IVC could be due to an inelastic collision of HVC gas with the Galactic thick disk. This emission is extremely faint (see Fig. 1). If Draco is the result of gas being decelerated from 100 to 20 km s-1, one would expect to see significant 21 cm emission at all velocities. One possibility could be that the original HVC was composed of two components: one component that has already hit the disk and produced Draco and a second component that is on its way and that we observe today at v < −100 km s-1.

Whatever the origin and metallicity of the infalling cloud, it seems likely that it has accelerated and pressurized WNM gas at rest in the Galactic layer, producing a shocked front of denser gas that is progressing toward us in the diffuse ISM. The structure of Draco itself, with its long cometary plumes, is indeed reminiscent of a dense cloud moving in a more diffuse medium (Odenwald & Rickard 1987). The structure of the front, with its sharp increase in column density, is also indicative of a shock. Assuming T = 8000 K and taking elements heavier than hydrogen into account, Draco moves with respect to the Galactic ISM with a Mach number of M = 5.8. This scenario is compatible with the FUV observations of Park et al. (2009) that show the presence of hot gas due to shock heating. In addition, these conditions are favorable for the development of a RT instability at the interface and for the formation of CNM out of compressed WNM through the thermal instability (Saury et al. 2014).

5.2. Turbulence

In this section we use the RT typical length, combined with velocity information from the 21 cm data, to estimate parameters of interstellar turbulence, such as the rate of transferred energy, ϵ, the Reynolds number, Re, and the turbulence dissipation scale, ld. The values of these parameters estimated for Draco are summarized in Table 1.

5.2.1. Rayleigh-Taylor instability and gas viscosity

The RT instability occurs when two fluids are accelerated toward each other. For the incompressible case, the fluids cannot interpenetrate freely; bubbles of the light fluid rise into the heavy fluid forming finger structures. It appears that such structures are also observed in compressible fluids, like supernovae remnants (Ellinger et al. 2012). In our case, the fingers are pointing toward the Galactic plane, indicating that Draco is denser than the medium in which it is moving toward, i.e., the Galactic WNM layer.

For two incompressible fluids of constant viscosity separated by a horizontal boundary, Chandrasekhar (1961) showed that the RT instability typical length is given by λmax=4π(νkin2Aa)1/3,\begin{equation} \lambda_{\rm max}=4\pi \cbra{\frac{\nu_{\rm kin}^2A}{a}}^{1/3}, \label{eq:Chandrasekhar} \end{equation}(6)where νkin is the kinematic viscosity, a is the acceleration, and A=ρ1ρ2ρ1+ρ2\begin{equation} A=\frac{\rho_1-\rho_2}{\rho_1+\rho_2} \end{equation}(7)is the Atwood number that takes values between 0 and 1. Here ρ1 and ρ2 are the density of the heavier and lighter fluids, respectively.

The Chandrasekhar study of hydrodynamic stability was made for incompressible fluids, which is not the case in the ISM. However, Ribeyre et al. (2004) studied the compressible case for supernovae and concluded that compressibility slows down the growth of the RT instability, but it has no important impact on λmax. The typical length of the RT instability in supernovae is usually estimated with Eq. (6)(Ellinger et al. 2012). The same assumption is made here. Interestingly, Eq. (6)offers us the opportunity to estimate the gas viscosity knowing the instability typical length, the gas acceleration, and A.

What acceleration should be considered here? In the classical picture of two fluids, one on top of the other, a is the gravitational acceleration. Here the gas is slowed down by the friction with the Galactic ISM. In fact the cloud is decelerating as it gets closer to the disk, slowly reaching v = 0.

In this context, a cloud entering the disk is slowed down by the friction with the ISM. The deceleration can be estimated by at=vtdvtdz·\begin{equation} a_{\rm t} = v_{\rm t} \, \frac{{\rm d} v_{\rm t}}{{\rm d}z}\cdot \end{equation}(8)Assuming that Draco has reached its terminal velocity, and using Eq. (4)for vt, we estimated that its deceleration is a = 2.3 × 10-8 cm s-2.

The parameter A depends on the density of the two fluids. The density of the gas at a height above the plane of z ≈ 370 pc, the assumed location of Draco, is n = 0.07 cm-3 (see Fig. 11). For Draco, the density can be estimated using the dust emission and 21 cm data. The gas column density, averaged over the whole nebula, is about 1.3 × 1020 cm-2. Draco spans about 3° on the sky, which translates into 30 pc at a distance of 600 pc. Assuming a depth of 30 pc for the infalling cloud, its average density would be on the order of 1.4 cm-3. This is an averaged value that represents the density of the WNM in Draco. The density is certainly larger at the shock front where strong CO emission (as well as CH, Stark et al. 1997) is observed (the CO critical density is on the order of 103 cm-3). Assuming n1 = 1.4 cm-3 and n2 = 0.07 cm-3, the Atwood number is A = 0.90.

Table 1

Properties of the turbulence in Draco.

The RT length, λmax, is the one estimated from the periodic structure observed at the dense front (Fig. 4). Even though describing the front as RT-like structure is appealing, the determination of the typical scale is difficult and somewhat uncertain. The arch-like structures have sizes ranging from 1.5 to 3.2 pc, with an average value of λmax = 2.2. Using this average value, the kinematic viscosity computed with Eq. (6)is νkin = 6.3 × 1022 cm2 s-1.

It is interesting to compare νkin to the more classical molecular viscosity νmol=131σn32kTμmH·\begin{equation} \nu_{\rm mol}=\frac{1}{3}\frac{1}{\sigma n}\sqrt{\frac{3}{2}\frac{kT}{\mu m_{\rm H}}}\cdot \end{equation}(9)For typical values of temperature and density for the CNM (T = 100 K, n = 30 cm-3) and WNM in Draco (T = 8000 K, n = 1.4 cm-3) and assuming σ = 1 × 10-15 cm-2 for the hydrogren cross-section (Lequeux 2005), the molecular viscosity is νmol = 1.0 × 1018 cm2 s-1 and νmol = 2.0 × 1020 cm2 s-1 for the CNM and WNM, respectively. The value of the WNM (the largest of the two) is more than 300 times smaller than what is estimated using the RT typical length and Eq. (6). That results depends on the distance to the power 3/2. Even if we assumed a distance to Draco of 400 pc, the kinematic viscosity would still be more than 200 times larger than the molecular viscosity. This is also much larger than the uncertainty of less than a factor of 2 on λmax.

5.2.2. Energy transfer rate

An important parameter that characterizes the turbulent cascade of energy is the energy transfer rate by unit of mass, ϵ=12vl¯3l·\begin{equation} \epsilon = \frac{1}{2} \frac{\bar{v_l}^3}{l}\cdot \end{equation}(10)Here l and vl¯\hbox{$\bar{v_l}$} represent the typical scale and typical average velocity of the flow. We assumed l ~ 30 pc for the largest scale of the flow. The average velocity of the gas at that scale is best estimated by looking at the width of the 21 cm line, averaged over the whole region. Using the 21 cm GBT data (Fig. 2), we estimated the velocity dispersion of the IVC component to be σv = 10.7 km s-1, which is likely to be dominated by the warm phase. Removing the thermal contribution to the line width (assuming T = 8000 K), this reduces to σv = 7.0 km s-1. Assuming a Gaussian distribution of velocity, this corresponds to an average velocity of vl¯=8/πσv=11.2\hbox{$\bar{v_l} = \sqrt{8/\pi}\,\sigma_v=11.2$} km s-1.

The energy transfer rate of the WNM in Draco is ϵ=3.9×10-3LM-1\hbox{$\epsilon = 3.9\times 10^{-3}~L_\odot~M_\odot^{-1}$}. This value is slightly higher than that estimated for the H i in the solar neighborhood (ϵ~10-3LM-1\hbox{$\epsilon \sim 10^{-3}~L_\odot~M_\odot^{-1}$}; Hennebelle & Falgarone 2012).

5.2.3. Reynolds number

By combining velocity information from the 21 cm data with the measurement of νkin, one can estimate the Reynolds number of the flow Re=lvl¯νkin·\begin{equation} Re = \frac{l\, \bar{v_l}}{\nu_{\rm kin}}\cdot \end{equation}(11)For Draco, we find Re = 1600, a value significantly smaller than the more traditional estimates for the ISM (Re ~ 105; Chandrasekhar 1949). This difference is explained by the fact that νkinνmol as Re is usually computed assuming that the dissipation of turbulent energy is dominated by molecular viscosity.

5.2.4. Dissipation scale

Turbulent energy in the ISM is dissipated via either viscous (hydrodynamical) or resistive (MHD) processes, depending on which process happens at the largest scale (Benjamin 1999; Hennebelle & André 2013). The scale at which turbulent energy is dissipated is ld(ν3ϵ)1/4·\begin{equation} l_{\rm d} \approx \left( \frac{\nu^3}{\epsilon} \right)^{1/4}\cdot \end{equation}(12)Like for Re, the scale at which turbulent energy is dissipated depends on what process is more efficient at transforming motion into heat. Assuming that ν = νkin, the dissipation scale is ld = 0.1 pc. This is close to two to three orders of magnitude larger than what is generally estimated for the WNM (ld ~ 0.003 pc) and the CNM (ld ~ 2 AU), assuming that the dissipative process is molecular viscosity (Lequeux 2005).

The other potential dissipative process is the ion-neutral friction. Following Lequeux (2005), the ambipolar diffusion typical scale is lAD=πμmHB2Xσvnn3/2,\begin{equation} l_{\rm AD} = \sqrt{\frac{\pi}{\mu m_{\rm H}}} \frac{B}{2X\,\langle\sigma v\rangle \, n_n^{3/2}}, \label{eq:ldiss} \end{equation}(13)where X is the ionization ratio, nn the density of neutrals, and σv the collision rate between ions and neutral (assumed to be the Langevin rate 2 × 10-9 cm3 s-1). For typical conditions in the ISM, from warm gas to molecular clouds, lAD is often larger than the dissipation scale for molecular viscosity. This is the case in Draco; assuming nn = 1.4 cm-3 (the density of the compressed WNM) and B = 6μG, which is a typical value for the WNM in the solar neighborhood (Beck 2001), the ambipolar diffusion scale is also lAD = 0.1 pc.

The kinematic viscosity estimated from the RT-like structures indicates that the dissipation of energy happens at a scale of ~ 0.1 pc; this is much larger than the dissipation scale of molecular viscosity but is in agreement with what is expected if ambipolar diffusion is the dominant process of energy dissipation.

5.2.5. Wardle instability

Given that the magnetic field seems to play an important role in dynamics, one could consider that the structure of the front is the result of the Wardle instability (Wardle 1990). This instability occurs because of the velocity difference between neutrals and ions, when the Alfven Mach number, MA, is greater than 5. The Alfven speed in a WNM with n = 0.1 cm-3 and B = 6μG is VA = 35.0 km s-1. Considering that the velocity of the shock is 40 km s-1, the Alfven Mach number is MA = 1.1. This suggests that the Wardle instability is not dominant in Draco.

5.3. Dense structures

Using the two-dimensional version of clumpfind on the Herschel-SPIRE 250 μm, converted to NH, structures of sizes from 0.08 to 0.5 pc were revealed. Interestingly, these small structures share many properties with sub-structures found in more massive molecular clouds as well as with prestellar cores. First, the mass distribution ranging from 0.1 to 20 M with a median value of 0.53 M is very similar to a prestellar core mass distribution (Könyves et al. 2010). In addition, the mass-size relation (ML2.3) is typical of that seen in more massive molecular clouds. Figure 5 also shows that the 12 μm emission from smaller dust grains is extremely weak compared to the big grain emisson at 250 μm, as is observed in dense parts of molecular clouds (Stepnik et al. 2003).

On the other hand, unlike prestellar cores (Könyves et al. 2010) and unlike molecular clouds (Roman-Duval et al. 2010), 85% of the structures found in Draco are not gravitationally bound. This is compatible with the fact that the density histogram is found to be log-normal, something generally associated with compressive supersonic flows without gravity (Kritsuk et al. 2007). Also, even though the structures in Draco are dense enough (n~1000 cm-3) to explain the strong CO emission observed, the density of these structures is 100 times less than that seen in prestellar cores.

We suggest that the formation of dense structures seen in Draco is the result of the transition from the WNM to cold and dense gas through the thermal instability of H i. This transition is favored by the compression of the warm gas at the interface between the Galactic layer and the infalling matter. As shown in several numerical simulations, the increase of density of the WNM sends the gas in a thermally unstable state that favors the transition to the CNM (Hennebelle & Pérault 1999; Audit & Hennebelle 2005; Vàzquez-Semadeni et al. 2006; Inoue & Inutsuka 2009; Saury et al. 2014). If the increase in density is sufficient, the formation of molecules is expected; using hydrodynamic simulations of a strong shock wave propagating into WNM, Koyama & Inutsuka (2000) showed that it can produce a thin and dense H2 layer via thermal instability. They also predicted fragmentation of the thermally collapsed layer into small molecular structures, similar to that seen in Draco. An increase of density would also favor faster evolution of interstellar dust through grain-grain collision. The low abundance of small dust grains in the densest parts of the front favors a coagulation process (sticking of smaller grains onto bigger grains, Köhler et al. 2012).

The fact that the CMF and fragments of molecular clouds mass spectrum have a similar power-law index has been used as an argument in favor of turbulence being responsible for the fragmentation and structuration of matter in dense environments. On the other hand, because of the fact that most of these objects are gravitationally bound, it is difficult to exclude the role of gravity. In this context, Draco is interesting as it reveals a clear example of dense structures that are formed through hydrodynamical processes combined with the thermal instability of H i with the exact same statistical properties as gravitationally bound systems.

The small-scale structures of Draco have statistical properties of a thermally bistable turbulent flow. Numerical simulations (e.g., Saury et al. 2014) have shown that the formation of CNM structures happens when the WNM is thermally unstable (i.e., compressed) and if the cooling time is shorter than then dynamical time. These two conditions must be satisfied in order for the transition to occur. The cloud collision provides the necessary increase in WNM density but at the same time, the input of kinetic energy increases the amplitude of the turbulent motions, lowering the dynamical time. The formation of CNM can then only occur if part of the turbulent energy is dissipated such that dynamical time becomes larger than the cooling time lower than the cooling time. The small-scale structures of Draco have sizes slightly larger (0.1 to 0.5 pc) than the WNM dissipation scale estimated here (ld = 0.1 pc). This correspondance could be a coincidence; the minimum size of the structures found here is limited by the angular resolution and noise level of the data. Nevertheless, in the absence of higher resolution data, the observations presented here are compatible with the idea that the dissipation of turbulent energy of the WNM via the ambipolar diffusion provides favorable conditions for the formation of dense structures at scales close to ld.

6. Conclusion

We presented Herschel-SPIRE observations of the Draco nebula, a diffuse high Galactic latitude interstellar cloud located about 370 pc above the Galactic plane. Draco is likely to be the result of the compression of diffuse gas of the outer WNM layer by the collision of a cloud falling from the Galactic halo. It offers a unique opportunity to study the formation of dense structures in a colliding flow.

The Herschel data reveal the fine details of the structure of this cloud, especially of a front that shows a typical Rayleigh-Taylor instability structure. We were able to estimate the gas kinematic viscosity from the typical length of this structure. Combined with 21 cm GBT data, we estimated the Reynolds number (Re = 1600), the energy transfer rate (ϵ = 3.9 × 10-3LM-1\hbox{$M_\odot^{-1}$}), and the dissipation scale of the turbulent cascade (ld = 0.1 pc). The viscosity and dissipation scale are typical of values that would be found in the WNM in the case in which the turbulent energy dissipation is dominated by ambipolar diffusion.

The SPIRE 250 μm map reveals high contrast structures with a wealth of small-scale clumps. Using the clumpfind algorithm, a total of 5028 structures were identified, with physical sizes ranging from 0.08 to 0.5 pc, where the lower limit is set by the angular resolution of the data. The mass spectrum is very close to that of prestellar cores (in terms of shape and range), even though the densities in Draco are 100 times lower. The high mass part of the mass spectrum is well represented by a power-law dN/ dlog (M) ∝ M-1.4, such as that seen for prestellar cores and molecular clouds fragments. On the other hand, the majority of the structures (85% in mass) are not gravitationally bound. This is corroborated by the fact that the density spectrum clearly follows a log-normal distribution.

The results presented here reveal dense structures formed in a colliding flow where gravity is not a dominant process. We showed that these structures are likely to be the result of the transition from the WNM to CNM through the H i thermal instability. We propose that the formation of dense structures is favored by the dissipation of the turbulent energy in the WNM through ambipolar diffusion, at a scale of lAD = 0.1 pc. The energy dissipation favors the formation of small CNM structures at scales slightly larger than lAD. The fact that these structures share many statistical properties with denser environments is an indication of the importance of interstellar turbulence and thermal instability in shaping the structure of the ISM.
