1. Introduction

Blazars are a class of active galactic nuclei (AGN), where the jet is closely aligned with the line of sight (Blandford & Rees 1974) according to the AGN unification scheme. This amplifies the non-thermal jet emission due to relativistic beaming.

Blazars exhibit a two-component spectral energy distribution (SED), where the low-energy component is attributed to synchrotron emission of relativistic electrons, and the high-energy component originates from inverse Compton (IC) scattering of ambient soft photons by the same electron population. Such soft photon fields include the synchrotron photons (synchrotron self-Compton, SSC), photons from the accretion disk (IC/disk), and thermal photon fields, such as the broad-line region, or the dusty torus (IC/DT). Soft photon fields are also provided by the galactic starlight, or from the cosmic microwave background (IC/CMB). A review of these leptonic models is given by, e.g., Böttcher (2007). In hadronic models, proton interactions and resulting pion decay and leptonic cascade processes are responsible for the high-energy emission (e.g., Böttcher et al. 2013; Weidinger & Spanier 2015; Cerruti et al. 2015). These processes usually require greater jet powers and much higher magnetic field strengths than the leptonic models and are therefore under criticism (e.g., Zdziarski & Böttcher 2015; Petropoulou & Dimitrakoudis 2015). In this work we will concentrate on leptonic processes.

BL Lac objects can be characterized by the peak position of their synchrotron component in the SED. Low-energy peaked BL Lac objects (LBLs) exhibit the synchrotron maximum below 1014Hz, while intermediate-energy peaked BL Lac objects (IBLs) peak between 1014Hz and 1015Hz, and high-energy peaked BL Lac objects (HBLs) peak above 1015 Hz.

The blazar AP Librae, located at redshift z = 0.0486 and at the coordinates RA = 15h17m41.8s, Dec = −24°22′19.5′′ (J2000), exhibits a strictly increasing X-ray energy spectrum. In combination with the lack of optical emission lines it is classified as an LBL. However, some observational features of this source do not fit into this category.

Since LBLs exhibit their synchrotron peak frequency below 1014Hz and the X-rays originate from the IC process, the maximum electron Lorentz factor in the electron energy distribution does not significantly exceed ~104 for reasonable values of the magnetic field strength on the order of ~0.1 G. Hence, one would not expect very high-energy γ-ray (VHE, E> 100 GeV) emission from these objects. Nevertheless, AP Librae has been clearly detected by observations with the HESS telescope array (HESS Collaboration et al. 2015) and the SED extends to energies of a few TeV. Currently, AP Librae is the only LBL listed in the TeVCat1, a catalog that gathers all sources detected above 100 GeV. Despite selection biases, this makes AP Librae an exceptional source.

High-resolution X-ray observations led to the detection of extended X-ray jets in many AGN. However, owing to the small viewing angle, it is surprising to observe extended X-ray emission in blazars. An extended X-ray jet has been detected in AP Librae by Kaufmann et al. (2013), which has thus become one of only six BL Lac objects listed in the X-JET database2. In three of these objects the X-ray emission is attributed to synchrotron emission, while in AP Librae the X-ray photon index of 1.8 ± 0.1 suggests IC emission. The X-ray morphology of AP Librae’s jet exactly follows the radio morphology as observed with the VLA. This suggests a common origin of the radio and X-ray radiation. The detection of the extended X-ray jet further demonstrates AP Librae’s peculiar state.

The detection in VHE implies an extremely broad high-energy component spanning 10 orders of magnitude in frequency. Owing to the observed cut-off of the synchrotron emission below the X-rays and other observational constraints, the broad high-energy component cannot be explained in the usual one-zone blazar model. Even by considering possible, observationally unconstrained extensions of the one-zone model (such as external photon fields like the BLR or the dusty torus), the VHE emission cannot be explained.

In this work, we explore the possibility that the extended jet contributes to the total SED in the VHE γ-ray regime. In fact, our model explains the VHE emission as originating mostly from the extended jet by IC/CMB radiation. This model has also been suggested, for example, for the extreme BL Lac object 1ES 1101-232 (Böttcher et al. 2008). However, the observational basis in 1ES 1101-232 is less well constrained than in AP Librae.

The paper is organized as follows. First, we present the data set in Sect. 2, and give a special emphasis to resolved structures on arcsec and milliarcsec scales. Section 3 contains the actual modeling, where we confirm the failure of the one-zone model, and then explain the SED by modeling the resolved structures. The details of the numerical code are given in Appendix A. In Sect. 4 we discuss the power requirements of our model, potential observations to verify our theory, and compare AP Librae to similar sources. Our conclusions are presented in Sect. 5.

We use a standard cosmology with H0 = 70 km s-1 Mpc-1, implying a luminosity distance of AP Lib of dL = 6.48 × 1026cm. The corresponding angular scale equals 1 arcsec = 0.95 kpc.

Since the observations in different energy bands exhibit different resolutions, we invoke the following nomenclature. We refer to core for any data that is unresolved irrespective of the scale. Resolved structures are referred to as the jet. The compact region, which is typically used to explain a blazar SED within the “one-zone” model, is referred to as the blob.

We will model the jet from its base out to arcsec scales. Owing to observational constraints, it is divided into two parts. With increasing distance from the center these are the pc-jet on milliarcsec scales, and the extended jet on arcsec scales. This choice will be discussed in detail in Sects. 2.1.1 and 3.3.

2. Structure and SED of AP Librae

thumbnail Fig. 1

SED of AP Librae. Data attributed to the core on arcsec scales is shown as black dots. Blue squares correspond to the extended jet data. The open diamond at 15 GHz is the flux from component 0 of the MOJAVE observations. The orange open squares are the γ-ray data from Fermi-LAT and the HESS experiment where no discrimination between core and jet is possible.

AP Librae has been extensively observed in all energy bands, but most of the energy bands have not been observed simultaneously. This is unfortunate, since AP Lib is known to be highly variable at optical frequencies (e.g., Webb et al. 1988; Carini et al. 1991). We assume that the chosen data represents an average state of the source.

The SED is shown in Fig. 1. The black dots represent data attributed to the core region on arcsec scales, while the blue squares correspond to the extended jet data. The orange open squares mark the γ-ray data, where no discrimination concerning the angular extent is possible. The details of each energy range are presented below.

2.1. Radio

The radio data points presented in Fig. 1 of the core emission are derived from VLA observations (Cassaro et al. 1999), from Kühr et al. (1981), from the MOJAVE catalog (Lister et al. 2013), and from the Planck Legacy Archive (PR1)3. At ~20 GHz the SED exhibits a break from a ν1 to a softer ν0.8 spectrum.

The data point of the extended jet at 1.36 GHz is taken from Cassaro et al. (1999). The extended jet emerges to the southeast. It bends after ~10 arcsec to the northeast and has been traced out to 40 arcsec.

2.1.1. MOJAVE observations

On milliarcsec scales (1 milliarcsec corresponds roughly to 1 pc) the jet is resolved by the MOJAVE VLBI observations at 15 GHz. We show the average flux (observations between 1998 and 2013) of the milliarcsec core (component 0 as given in the MOJAVE catalog) as the open diamond in Fig. 1. Component 0 is variable, but fluxes have not varied by more than a factor 2 within the 15 yr of observations. The vertical error bar displays the temporal variation within the data set. The black filled data point at 15 GHz is the average of the total flux of each MOJAVE observation, including both the component 0 and the resolved milliarcsec jet. This suggests that all black radio points in the SED are likely to contain flux from the actual blazar zone and an extended region of pc scales.

Lister et al. (2013) discovered three knots which they were able to follow over a few years. These resulted in the measurement of a maximum apparent speed of the jet of βapp = vapp/ c = 6.39.

The MOJAVE data indicates a continuous jet on 10 milliarcsec scales emerging to the south in all observations since 20074. Beyond these scales the jet bends to the southeast, which corresponds to the direction of the extended jet on arcsec scales.

2.2. Infrared, optical, UV

In the infrared, optical, and UV bands we use the data presented in Kaufmann et al. (2013) and Hervet et al. (2015).

The infrared data is taken from the WISE mission, while the optical and UV data points are derived from Swift-UVOT observations. All data was taken in 2010 and is corrected for Galactic absorption, and for the contribution of the host galaxy.

As stated above, AP Librae is highly variable at optical frequencies. This makes it difficult to determine the average flux state. Kaufmann et al. (2013) present R- and B-band data taken with the ATOM telescope located at the HESS site in Namibia. Their data is an average over the time range of the 2FGL catalog (data taken between 2008 and 2010; Nolan et al. 2012). The data points are compatible with the Swift-UVOT measurement.

Despite observations with large optical telescopes and the Hubble Space Telescope, no hint of the extended jet has been observed at optical wavelengths so far (e.g., Scarpa et al. 2000). This is due to the fact that the host galaxy is very bright in the optical even several arcsec from the core (values for the half-light radius in the literature range from 3.7 arcsec, Scarpa et al. 2000, up to 6.72 arcsec; Pursimo et al. 2002). Hence, the jet emission could be hidden by the starlight.

2.3. X-rays

AP Librae was observed with the Chandra satellite in 2003. The high spatial resolution of Chandra allowed the detection of the kpc-jet in the X-ray regime by Kaufmann et al. (2013), who also derived the spectral indices for both the core and the jet. The filled black points in Fig. 1 belong to the core region of the blazar, while the blue filled squares show the data of the extended jet. The photon index of the core emission equals 1.58 ± 0.04, which is consistent with AP Librae being an LBL and the X-ray radiation originating from IC emission. The extended jet photon index of 1.8 ± 0.1 indicates that the X-ray jet is also IC dominated.

The X-ray jet detected by Chandra is spatially coincident with the extended jet at 1.36 GHz and emerges to the southeast (Kaufmann et al. 2013). Beyond the bend in the radio, the X-ray emission is much weaker than before the bend and fades rapidly.

The hard X-ray data point above the Chandra core spectrum in Fig. 1 is taken from the Palermo 100-month Swift-BAT catalog5. The photon index of the Swift-BAT measurement is given as 1.69 ± 0.14. This is consistent with the Chandra core spectrum. The flux level has been steady within errors over all the Palermo Swift-BAT catalogs (39 months, 54 months, 66 months, and 100 months). Hence, this value is not particularly influenced by potential flaring events in this energy band.

The consistency of the Chandra core spectrum and the Swift-BAT spectrum give confidence that the Chandra observations were conducted during a quiescent period. If this were not the case, then the quiescence spectrum would be harder than the Chandra core spectrum, which would complicate the modeling beyond the current constraints (see Sect. 3). A Swift-XRT spectrum from 2011 exhibits a slightly higher flux than the Chandra core spectrum, which is consistent with the assumption of the Chandra core spectrum representing an average spectral state (Kaufmann et al. 2013).

2.4. Gamma rays

The data at γ-ray energies is taken from HESS Collaboration et al. (2015), and include measurements from the Fermi satellite in the high-energy (HE, E> 100 MeV) band and from the HESS experiment in the VHE band. A distinction between the core and the extended jet is not possible at these energies owing to the lack of the necessary spatial resolution.

The Fermi data points are taken from the long quiescence period in HE, where no variability is detected. HESS Collaboration et al. (2015) also report an outburst of AP Librae in the Fermi-LAT energy range with a maximum flux increase of a factor 3.5 above the quiescence level. The entire flaring episode with a relatively long decay lasted for about 100 days before the flux returned to pre-flare levels. We examined this flare to ascertain that it is not caused by confusion with a luminous GeV flare in the nearby quasar PKS 1510-089 that is coincident with the AP Librae outburst.

The HESS data was taken in 2010 and 2011. No indication of flux variability at the VHE energy range has been published. No HESS result is reported for the Fermi flare period in 2013.

We de-absorbed the spectral points using the EBL model of Franceschini et al. (2008), giving an intrinsic flux roughly 32% higher than the absorbed flux at 1 TeV.

3. Modeling AP Librae

The observed characteristics of the extraordinary source are studied using the leptonic steady-state code of Böttcher et al. (2013). Details are presented in Appendix A. There we also describe our addition to the code used to model the extended component. This is assumed to be homogeneous. It is treated as an ensemble of identical subunits, and the combined emission of the subunits gives the total flux of the extended component.

Below we first consider constraints on the free parameters, which can be deduced from the observations. These constraints and our modeling rule out the one-zone model. We explore whether the SED can be reproduced by considering the emission of the entire jet. It will be divided into two parts. These are the pc-jet, which describes the structures on milliarcsec scales resolved by the MOJAVE observations, and the extended jet on kpc scales, which is probed by radio and X-ray measurements.

3.1. Constraints

The most obvious difficulty for modeling AP Librae is the broad inverse Compton component in combination with the Swift-BAT measurement at hard X-rays. The latter is a long-term average and not significantly influenced by potential outbursts. Since it coincides with an extrapolation of the Chandra core spectrum, the IC component (which is responsible for the X-ray emission) must exhibit a hard power law over two orders of magnitude in energy. The absence of any curvature in this energy range restricts the minimum electron Lorentz factor γmin to values above 102 assuming a standard electron spectral index s = 2, as is discussed in detail in Appendix B.1.

The hard X-ray energy flux exceeds the flat Fermi-LAT level. This indicates that the peak frequency of the inverse Compton component is located below the Fermi energy range. In turn, this requires that the maximum electron Lorentz factor γmax not be much larger than 104 in order to meet the fluxes at γ-rays.

These constraints on the electron distribution determine the synchrotron component in most characteristics. The magnetic field B0 is limited to 0.01−0.1 G by the optical and UV measurements.

Generally, using a self-consistent model implies that two out of five parameters of the broken power law of the electron distribution function are determined by other parameters. The break Lorentz factor γbr, as given in Eq. (A.1), depends sensitively on the source radius and the magnetic field. Furthermore, the slope of the second power law is restricted to values s + 1, as given in Eqs. (A.3) and (A.4). Since the standard Fermi acceleration mechanisms provide spectral indices on the order of s ~ 2, the parameter space is already much reduced.

From the measurement of the maximum apparent speed of the radio knots on pc-scales, the values of the Doppler factor δb and the angle between the inner jet and the line of sight ϑobs can be deduced following Eqs. (2.71) and (2.72) of Böttcher (2012). The bulk Lorentz factor Γb is not empirically constrained. Throughout the paper we assume a non-decelerating jet and set Γb = 10 in all components. This value is chosen to avoid the so-called Doppler factor crisis in blazars (e.g., Henri & Sauge 2006). This gives δb = 17.8 and ϑobs = 2° in the inner regions of the jet. Our conclusions are insensitive to this assumed value.

Using these constraints, we give the modeling results below. The input parameters for the models are given in Table 1. The results of the combined model are listed in Table 2.

3.2. One-zone model

Table 1

Input parameters for the models.

Table 2

Resulting parameters for the individual components using the input parameters of Table 1.

thumbnail Fig. 2

One-zone SSC model. Data points are as in Fig. 1. The lines correspond to synchrotron (green), SSC (blue), and the sum (thick red).

thumbnail Fig. 3

One-zone model including thermal radiation fields and associated IC emission. Data points are as in Fig. 1. The lines correspond to synchrotron (green), accretion disk (gray), DT field (dotted gray), SSC (blue), IC/disk (cyan), IC/DT (black), and the sum (thick red).

Here we present a one-zone model of AP Librae fulfilling the previously mentioned observational constraints. This model is described by the parameters given in the first column of Table 1 and is shown in Fig. 2. We know from the MOJAVE observations that the radio data of the arcsec core contain emission from an extended region on milliarcsec scales. Thus, the one-zone model is not expected to fit the flux measurements in the radio (shown as black points in Fig. 1), but rather the unresolved flux on milliarcsec scales (shown as the open diamond).

The model fits the X-ray part of the SED. The hard X-ray spectrum in reproduced by an electron distribution with γmin = 160 for a standard spectral index of s = 2. We refer to Appendix B.1 for a detailed justification of this value.

The peak energy of the IC component is located in the range from 100 keV to 100 MeV. In order to fulfill the Fermi flux measurement at 100 MeV the SSC component must cut off below 100 MeV resulting in a maximum electron Lorentz factor of 104. Thus, the electron distribution is quite narrow spanning less than two orders of magnitude in energy.

With these constraints on the electron distribution, the synchrotron component is determined except for the magnetic field. Choosing B0 = 0.04 G allows the fit of the flux of radio component 0, and the optical/near-infrared regime. The UV data is not fitted well by synchrotron emission alone (see below).

While the resulting SSC emission fits the X-ray spectrum, it is unable to explain the γ-ray spectrum, owing to the excess at MeV energies compared to the Fermi flux level. Even the contribution of the second-order SSC emission, which is indicated in Fig. 2 by the second hump of the blue curve at ~1024Hz, cannot account for the γ-ray flux.

Since AGN are associated with accreting systems, we expect AP Librae’s supermassive black hole of mass Mbh = 2.5 × 108 M (Woo et al. 2005) to be surrounded by an accretion disk. Since there is no evidence of the disk in the data, we can use the flux measurements in the optical/UV to set a maximum limit on the disk’s luminosity. In Fig. 3 we add the thermal emission of a Shakura-Sunyaev-type disk (Shakura & Sunyaev 1973) with luminosity LD = 1.3 × 1044 erg/s. The combination of the disk and the synchrotron component fits the Swift-UVOT flux measurements.

The disk emission is IC scattered by the electrons in the blob. However, the outward direction of the relativistic motion of the blob, and its distance from the accretion disk result in a minor contribution to the overall spectrum.

The accretion disk emission can be scattered by material surrounding the black hole on ~pc scales. Since there is no indication of such a component in the data, the modeled flux level must be weak. The parameters of this potential photon field listed in Table 1 suit a very weak dusty torus (DT). Following Eq. (A.6) the energy density of the DT field becomes uDT = 1.1 × 10-7erg/cm3 implying a luminosity of LDT = 4.0 × 1042 erg/s. This is more than 1 order of magnitude below the luminosity of the accretion disk. This accounts for the non-detection of the DT field, as can be seen in Fig. 3.

However, the DT field can be IC scattered by the blob electrons. Owing to the geometry of the photon field, it is blue-shifted in the frame of the blob increasing both the maximum energy of the IC photon and the IC/DT flux. The parameters of the DT field were chosen such that the IC/DT component helps to explain the γ-ray emission. The flat Fermi level is represented well by the superposition of the SSC and the IC/DT components. The slight underestimate in Fig. 3 of the Fermi flux level could be accounted for by choosing a slightly higher energy density in the DT field. However, our choice is in anticipation of the contribution of the extended jet at these energies (see Sect. 3.3 and Fig. 4).

The IC kinematics in the Klein-Nishina regime imply a firm cut-off at the observed frequency νmax = δbγmaxmec2/ h = 2.2 × 1025Hz. The IC component cuts off at this frequency, even though in most parts of the IC spectrum scatterings occur in the Thomson regime. Thus, the one-zone model cannot account for the VHE emission. Neither the disk nor the DT field can circumvent this conclusion. Invoking these fields to explain some parts of the SED is of minor importance compared to the failure of the one-zone model as a whole.

Synchrotron self-absorption can influence the synchrotron spectrum at low radio frequencies. Following Eq. (7.146) of Dermer & Menon (2009), the turn-over frequency can be determined by (1)with the scalings R = 1015R15cm, B0 = bG, and the electron density ne. With the model parameters (see also Table 2), we derive νssa = 7.6 × 108Hz. Therefore, synchrotron-self absorption within the blob does not affect the model.

thumbnail Fig. 4

Model including the extended components. Data points are as in Fig. 1. The lines correspond to the total emission of the blob in Fig. 3 (thick, dashed red), synchrotron of the pc-jet (dash-dotted green), IC/DT of the pc-jet (dash-dotted black), synchrotron of the extended jet (solid green), IC/CMB of the extended jet (solid red), and the sum of all components (thick, solid red).

The electrons cool mostly via the SSC channel with a cooling time of ~140 days for the highest energy electrons. Such a long cooling time is expected, since the model aims to explain the time-averaged SED. Fast flaring episodes would require a time-dependent approach (e.g. Zacharias & Schlickeiser 2012; Chen et al. 2014).

We note that it would also be possible to reproduce the emission of the one-zone model with an electron distribution of lower γmin if a very hard spectral index of the electron population is assumed. Appendix B.2 illustrates that for an index of s = 1.5 the minimum electron Lorentz factor γmin might be as low as 30. Recent works on the theory of relativistic shocks (e.g., Cerutti et al. 2012; Summerlin & Baring 2012; Schlickeiser 2015; Werner et al. 2016) claim that hard electron distributions are possible in certain circumstances. It is beyond the scope of this paper to investigate whether these circumstances are realized in AP Librae’s jet, and it also cannot circumvent the necessity of additional components (cf. Fig. B.2). This clearly confirms the results of other authors (Tavecchio et al. 2010; Hervet et al. 2015) that the standard one-zone model fails to reproduce the broad-band SED of AP Librae, even if additional external photon fields with poor observational constraints are taken into account. This deficit of the one-zone model is independent of the precise details of assumptions beyond the observational constraints.

Below we concentrate on contributions from the large-scale jet in order to successfully explain the SED.

3.3. Jet model

As discussed in Sect. 2.1.1, the MOJAVE data resolves the jet emission on pc-scales. This demonstrates that a significant fraction of the total flux measured in radio at moderate angular resolution is confined in a region significantly smaller than the extended jet on arcsec scales, and yet much larger than the single zone described in Sect. 3.2. We refer to this region as the pc-jet. We take this region into account in addition to the one-zone model in order to explain the radio data. The one-zone model (or blob) now represents a small region moving within the pc-jet region.

The pc-jet is constrained by the condition that the combination of the two components should not exceed the radio and infrared data. The parameters of the pc-jet are summarized in the second column of Table 1, and the resulting fit is shown in Fig. 4. The combination of the blob and the pc-jet matches the synchrotron component very well. Empirical parameters of the pc-jet are the projected length of 10 pc and a radius of 1 pc. The de-projected length of this part of the jet is ~290 pc. The combination of the blob and the pc-jet at 15 GHz equals the total flux from the MOJAVE observations.

Since SSC emission depends strongly on the local synchrotron photon density at any point within the jet, the SSC flux of the pc-jet is very low. The part of the jet immersed in the photon field of the accretion disk is very small since the photon density drops rapidly with height above the disk. These photon fields can be safely ignored. However, about 0.6% of the pc-jet are immersed in the DT photon field. Even though the electron density is low in the jet, the large jet volume within rDT contains a number of electrons that is only a factor of ~20 smaller than the total number of electrons in the blob. Hence, the IC/DT component of the pc-jet cannot be neglected, even though it does not contribute significantly to the overall flux (see Fig. 4).

In the pc-jet the electrons are cooled predominantly by synchrotron emission, and the highest energy electrons cool on a time scale of about 100 yr. This cooling time is not long enough for electrons to cross the length of this jet region, and re-acceleration must take place on scales smaller than 30 pc.

In principle, the synchrotron emission of the pc-jet could be scattered in the much denser blob medium. This effect can be neglected, however, because in the immediate vicinity of the blob the synchrotron emission is very weak, and owing to the same bulk speeds there is no Doppler enhancement.

We assume the same observing angle for the blob and the pc-jet, since there is no indication of a change in direction within the 10 milliarcsec jet. Beyond this distance the jet turns towards the southeast, which is the same direction as the jet on arcsec scales. The bend is assumed to correspond to an intrinsic change of the viewing angle, amplified by the foreshortening. The change is assumed to result in an observing angle of the extended jet of . This reduces the Doppler factor to 13.5.

The projected length of the extended jet in X-rays is about 10 kpc, while the widths of the jet is about 1 kpc (see Fig. 2 in Kaufmann et al. 2013). Since the radio and X-ray emission rapidly fade beyond the second bend at ~12 arcsec of the jet, we do not take any emission from beyond that point into account.

Owing to the sparse data set of the extended jet, the parameters are less well constrained than for the core component. The photon index of the jet X-ray spectrum, ΓX = 1.8 ± 0.1, results in a spectral index of the SED of α = 0.2 ± 0.1 (if defined as νFννα). This implies an IC origin of the X-ray emission. On these scales the only plausible external soft photon field is the CMB, while the synchrotron radiation is too weak to induce a significant amount of SSC emission. In the Thomson limit the spectral index of IC/CMB radiation follows the same dependence on the electron spectral index as the synchrotron spectral index (s = 3−2α), and so the electron spectral index is given by s = 2.6 ± 0.2.

The minimum electron Lorentz factor is restricted to values below ~40, or else the jet X-ray spectrum would not be fitted. There is no observational constraint on the maximum electron Lorentz factor. Klein-Nishina effects are not important for the IC/CMB process as long as γmax ≲ 108.

At γ-rays the poor spatial resolution means that it is not possible to discriminate between core and extended emission. Since the core parameters fail to reproduce the VHE measurement, we invoke the extended jet. Using the IC/CMB model we can infer constraints on more parameters. Since the IC/CMB spectrum is determined by the electron distribution, we can use the observed VHE spectrum to derive the maximum electron Lorentz factor. In the Thomson limit the observed scattered photon energy depends on the characteristic CMB photon energy following . With νmax ~ 1027Hz we find γmax ~ 5 × 106.

Extrapolating the jet X-ray spectrum to higher energies implies an observed break frequency of ~1025Hz. This gives γbr ~ 5 × 105, which is related to the escape time scale parameter ηesc by Eq. (A.1). Assuming that the cooling is dominated by IC/CMB cooling, we find ηesc ~ 15. This implies that electrons reside in any given subunit of the jet for only a small amount of time.

The assumption of dominating IC/CMB cooling is well justified given that the Compton dominance CD is much larger than unity. Taking the ratio of the measured X-ray and radio fluxes of the extended jet, the CD is at least 30. The CD can be estimated by the ratio of the IC/CMB and synchrotron energy densities, giving CD = 1.62 × 10-11b/B0)2. Hence, the magnetic field is smaller than ~7.3 μG. However, the X-ray flux is produced by electrons at the low-energy end of the electron distribution, while the radio flux is from electrons with higher energies. Thus, the real CD should be taken at different frequencies, which are related to the same electron Lorentz factor. Owing to the lack of other measurements of the extended jet we cannot give a tighter constraint, but the CD could be about a factor of 10 larger than the ratio of the X-ray and radio fluxes. Estimating the CD as the ratio of the respective energy densities is only a rough approximation, since it does not take into account the different beaming properties of synchrotron radiation and IC radiation of external fields (Dermer 1995).

The remaining parameters have been chosen to allow the modeling of both the resolved spectra and the VHE measurement, and are given in the third column of Table 1. The resulting model is presented in Fig. 4 as the solid lines, giving an excellent fit to the observed fluxes of the jet and the VHE measurement. The model will be discussed extensively in Sect. 4.

The cooling time of the highest energetic electrons in the extended jet is on the order of 850 years. This is a factor of 300 below the light travel time along the extended jet, and demonstrates the need for constant re-acceleration of the electrons on scales smaller than the widths of the jet.

Since the medium in the extended components is much thinner than in the blob, synchrotron self-absorption can be neglected entirely in the large-scale jet following Eq. (1).

The combined fit of the blob and the entire jet gives a satisfactory representation of the data of AP Librae with the major implication that the extended jet is responsible for the VHE regime.

3.3.1. Comparison to multizone models

Recently, Hervet et al. (2015) presented their model to explain the spectrum of AP Librae. They developed a multizone model, which is similar to our modeling in some ways.

However, their explanation of the VHE emission differs substantially from our model. Their electron distribution function has not been derived from first principles, which sets the break Δs of the slope of the electron distribution function (see Eqs. (A.3) and (A.4)), but was assumed ad hoc to take up arbitrary values. This allowed the electron distribution to be extended to γmax = 4 × 106 using a steep spectrum after the break electron Lorentz factor. Thus, they were able to keep the blob IC emission below the Fermi level and the high-energy end of the synchrotron component below the X-ray measurement, while explaining the VHE flux with emission from the one-zone blob. Owing to the self-consistent approach, we have no freedom for Δs, and cannot raise γmax beyond ~104 in the blob.

So far, the data does not lead to a firm conclusion whether to decide if the core or the large-scale jet is responsible for the VHE emission. In Sect. 4.2 we present several ways to test our scenario, and compare our interpretation to other BL Lac objects with extended jet emission in Sect. 4.4. These arguments support the view that the VHE emission originates in the extended jet.

4. Discussion

4.1. Particle population and power requirements

The parameters of the electron distribution derived by the code are listed in Table 2. In all cases the cooling operates in the slow mode, which gives a break in the electron distribution of unity. In combination with the canonical value of s = 2.0, this restricts the blob maximum Lorentz factors to 104.

The electron densities decrease outward, as is expected for an expanding jet. In order to reach quasi-neutrality of the plasma, we assume one proton per radiating electron. As is common in leptonic models, these protons are assumed to be cold and do not contribute to any emission process. As can be seen in Table 2, the protons dominate the particle energy density in all cases.

The photon energy density urad emerging from the emission site is calculated from the model SEDs as (2)The resulting values are also listed in Table 2. In each component the radiation energy density is several orders of magnitude below the particle energy density, and only in the blob does it exceed the magnetic energy density. Hence, AP Librae’s jet is radiatively inefficient.

The accretion disk luminosity is on the order of a few times 10-3 times the Eddington luminosity, which is Ledd = 3.75 × 1046 erg/s in the case of AP Librae. The total jet power in each case is calculated by (3)where the sum includes the energy densities in electrons, protons, magnetic field, and radiation. The entire jet obeys the Eddington limit. This is noteworthy for the extended jet, as we discuss in Sect. 4.2.

It seems counterintuitive that the electrons in the jet should exhibit higher energies than in the blob close to the initial acceleration region. However, our jet model requires continuous re-acceleration of the particles throughout the jet. Since the maximum Lorentz factor is restricted by the equality of the acceleration and the cooling rate, and the cooling rate drops farther out in the jet due to the weaker magnetic field and less intense soft radiation fields, the maximum Lorentz factor would increase with increasing distance from the core, if the acceleration rate does not drop as strongly as the cooling rate. This is reasonable, since the cooling and acceleration rates have different dependencies on the underlying parameters, such as the magnetic field (e.g., Baring 2012). We will elaborate more on the high electron Lorentz factors in Sect. 4.4.

In many blazar modeling attempts, equipartition between the magnetic field and the radiating particles is assumed. This reduces the free parameters, and results in the lowest energy budget required to fit the data. We have not taken this into account, and basically all components are far away from equipartition. The equipartition parameters is defined as ϵeq,e = uB/ue. The blob is particle dominated, while the pc-jet and the extended jet are magnetic field dominated. We do not include the cold proton population in this value, because they do not contribute to the emission processes. If we included the protons in the equipartition parameter, the ratios would decrease, and the extended jet would be considered particle dominated. Interestingly, the extended jet is very close to equipartition, and this condition can be realized without a drastic change in the parameters. The equipartition magnetic field would result in 2.2 μG, while the other parameters would remain unchanged.

4.2. Extended jet

The IC/CMB modeling of the extended jet reproduces the observations. The IC/CMB model has been used in many sources with extended jets, but has several potentially problematic implications (Harris & Krawczynsky 2006).

First of all, it requires a decent amount of beaming, which implies a relativistic flow on kpc-scales coupled with a small viewing angle. Unfortunately, dynamic range limits preclude any detection of movement in the large-scale jets inhibiting the determination of the bulk Lorentz factors. The small viewing angle results in very large physical sizes of the jets on the order of Mpc scales. Even though some radio galaxies with such large jets have been observed, a larger number of misaligned sources should have been observed for any more closely aligned large-scale jet. In our modeling we only consider the part of the jet that is upstream of the bend, and has an angular size of roughly 10 arcsec. This corresponds to about 10 kpc at the distance of AP Librae. Owing to the small viewing angle of only the de-projected length of the jet becomes ~140 kpc. Considering that the jet continues for about 10 arcsec beyond the bend, AP Librae’s jet appears to extend up to 300 kpc, rivaling the largest radio galaxies.

However, there are several arguments in favor of strong beaming in the case of AP Librae. The particularly sharp bend in the radio and X-ray maps at ~10 arcsec could be due to a low angle between the jet and the line of sight. At small viewing angles a small intrinsic bend of the jet is significantly enhanced in the observer’s frame and in the projection on the sky. Since the X-ray flux strongly decreases beyond the bend (cf. Fig. 2 in Kaufmann et al. 2013), we interpret this as a reduction in the observed IC flux due to reduced beaming. The synchrotron emission is not as influenced by this beaming effect as the IC emission (Dermer 1995). More sensitive mapping at radio and X-ray frequencies could test this prediction.

Furthermore, the counter-jet has not been detected in radio maps on arcsec and milliarcsec scales or in the X-ray map. Since jets should emerge on both sides of the accretion disk, the counter jet must be much weaker than the observed jet. Under the assumption that both jets are intrinsically identical, the counter-jet must be strongly de-beamed. Since far away from the black hole there is still no sign of the counter-jet, we can further conclude that even at great distances the jet must exhibit relativistic speeds without significant deceleration. Otherwise, there should be signs of the counter-jet at great distances from the black hole.

Since the electrons emitting in the X-ray band are less energetic than the radio emitting electrons, the power in relativistic particles is high and in some cases exceeds the Eddington luminosity even without accounting for cold protons. Our modeling suggests that in AP Librae the Eddingtion luminosity constraint holds for the large-scale jet even with the dominating contribution of cold protons.

Additionally, in the few sources where the synchrotron component of the extended jet is well constrained by detections up to the optical and/or UV band, the IC/CMB model usually predicts a measurable and steady flux in the Fermi band. Using this prediction, Meyer & Georganopoulos (2014) and Meyer et al. (2015) ruled out the IC/CMB model for the quasars 3C 273 and PKS 0637-752. An inversion of this test could be useful for AP Librae. As implied by our modeling, the Fermi and HESS data can be satisfactorily explained by the IC/CMB model. Owing to the required highly relativistic electrons, the jet is expected to emit synchrotron emission up to the UV band. Since the contribution of the galaxy in the UV band is much smaller than in the optical and IR bands, the jet should be detectable despite its proximity to the bright core. If the jet is not detected in the UV with an upper limit below the predicted flux of our model curve, the IC/CMB is ruled out as the origin of the VHE emission because the required electron energies cannot be matched.

The HE and VHE domain could be used to implicitly test our model. In the model presented here, the VHE emission is produced in the extended jet. Owing to the large spatial extent, the light crossing time is large, and the emitted flux is not expected to change on time scales shorter than several thousand years. The observed flux in the energy range dominated by jet emission is therefore expected not to drop below the level reproduced by the model. A reassuring argument is the relatively stable lightcurve recorded with the Fermi satellite. Apart from the flare in 2013, which lasted for several months, no significant variability has been recorded and the lightcurve is well fit by a constant (HESS Collaboration et al. 2015). Unfortunately, the low flux of the flare of AP Librae in the high-energy domain does not allow detailed spectroscopic studies. The spectrum integrated over the entire flare extends only up to 10 GeV. This is consistent with the model described in this paper. Below ~30 GeV the emission is dominated by IC scattering originating in the compact blob, and is thus subject to variations on short time scales. A temporal increase in the electron density in the blob can easily account for the variation. Unfortunately, the sparse multiwavelength data set inhibits the construction of a meaningful model. At energies higher than ~30 GeV the emission is dominated by the extended jet and no changes in the total flux are expected.

An increase in the flux at VHE energies during a flare might still originate from an additional flaring component and would thus not rule out our model. However, this component should also reveal itself at lower energies by changing the spectrum in the UV and potentially in the X-ray band because of the higher γmax required for such a flare.

On the other hand, the flux above ~30 GeV should not drop below the observed level, because this could not be explained by emission processes in the extended jet. More observations on this source by the HESS experiment and the future Cherenkov Telescope Array are strongly encouraged.

4.3. Scenario for the jet structure in AP Librae

The preceding results and discussions are combined in a scenario that reproduces the observations.

This scenario includes a continuous jet being launched by the central engine. The densities in these extended zones are very low, and the electrons mostly produce synchrotron radiation through interactions with the ambient magnetic field. Only the large size of the extended jet of more than 140 kpc (de-projected) allows for significant IC emission produced by interactions with the CMB. The electrons in the jet are continuously reaccelerated throughout the jet. This may be achieved in turbulence producing numerous acceleration regions on scales of a few percent of the jet widths, which are too small to be resolved by radio or X-ray observations conserving the observed homogeneity. The acceleration process itself could be a combination of shocks, reconnection or shear layer acceleration, depending on the microscopic properties of the turbulent regions within the large-scale structure. For simplicity, we assume that the initial electron energy distribution is preserved as in the model of Blandford & Königl (1979).

Occasionally, an overdensity like the blob considered in Sect. 3 is launched, which may be more magnetized than the continuous jet medium. The blob moves outward, expands, and dissolves into the surrounding jet medium. Owing to the initial higher densities, the blob emits X-rays and HE γ-rays through IC interactions with the synchrotron, accretion disk, and isotropic radiation fields. The last two become less important as the blob moves outward.

This scenario explains the observational features. Most importantly, the MOJAVE observations show that blobs emerge from the central engine, but in most cases cannot be followed over more than a few months. Only three components were identified in more than one observation, which allowed the derivation of the apparent speed of the jet (Lister et al. 2013). If this is not related to dynamic range limits, this could be interpreted as blobs dissolving into the jet medium.

4.4. Comparison to BL Lac objects with extended X-ray jets

Table 3

Properties of BL Lac objects with extended X-ray jets.

Currently, six BL Lac objects are listed in the X-JET database. We present some of their properties in Table 3.

The sources do not exhibit a clear trend concerning the X-ray emission process, because for only three sources (OJ 287, AP Librae, S5 2007+77) the photon indices clearly imply an IC origin. The other sources have been modeled with synchrotron emission. The radiation process is independent of redshift. There might be a correlation to the magnetic field strength in the extended jets, since the IC/CMB dominated jets require a smaller magnetic field (<10 μG) than the synchrotron dominated ones (>50 μG).

Comparing our extended jet model, constrained by the VHE γ-ray measurement, to the parameters used for OJ 287 (Marscher & Jorstad 2011) and S5 2007+777 (Sambruna et al. 2008), similar values with respect to magnetic field, electron distribution, and the respective powers are found. The magnetic fields are on the order of a few μG, the minimum electron Lorentz factors on the order of ~50, and the electron spectral indices are ~2.5 (as listed in Table 3). The powers in magnetic field and relativistic particles are on the order of a few 1045 erg/s. Optical and/or infrared observations on OJ 287 and S5 2007+777 have not revealed the jets. With the resulting upper limits, the maximum electron Lorentz factor can be constrained to a few times 105, and thus VHE emission is not expected from the extended jets of these sources.

As mentioned in Sect. 4.1, we require a maximum electron Lorentz factor of 5 × 106, much higher than the maximum Lorentz factor of the core (~104). However, considering the sources listed in Table 3, such high Lorentz factors in extended jets seem to be common. Especially in the sources where the X-ray emission is considered to be of synchrotron origin, a maximum Lorentz factor on the order of ~108 is required (Sambruna et al. 2007). Hence, extended jets must be efficient particle accelerators.

5. Conclusions

We have modeled the broad-band spectrum of the LBL source AP Librae, which is unusual both for its broad-band γ-ray emission and for its extended X-ray jet. Owing to the spectral features in the X-ray and γ-ray emission the electron distribution function is strongly constrained. This rules out an explanation of the SED by a single-zone model. The failure of the one-zone model is confirmed by quantitative modeling, as has also been noted by other authors (Tavecchio et al. 2010; Hervet et al. 2015). Since the maximum of the IC component is located in the energy range between 100 keV and 100 MeV (the Swift-BAT and the Fermi-LAT measurements), the maximum electron Lorentz factor is restricted to a low value (~104), which is inadequate to explain the VHE emission. Even the addition of observationally unconstrained external fields, such as the accretion disk or the dusty torus, cannot account for the VHE flux. For standard values of the electron spectral index of s ~ 2, the hard spectrum in the X-rays further constrains the minimum electron Lorentz factor to greater than 102, which is inadequate to model parts of the radio and infrared spectrum. Instead, it is demonstrated that emission from the extended jet may be responsible for many parts of the SED. The synchrotron component is due to a superposition of the one-zone blob, and the jet on pc-scales. This model is supported by VLBI observations of the MOJAVE program, which resolves the jet on these scales.

For the VHE emission we have invoked the extended jet on arcsec scales. Considering IC scattering of the CMB in a uniform jet resulted in a successful fit of the data. The parameters are reasonable with minimum electron Lorentz factor γmin = 40, electron spectral index s = 2.6, and magnetic field B0 = 2.3 μG. The success of our model depends critically on the value of the maximum electron Lorentz factor. If electrons are accelerated to γmax = 5 × 106 throughout the jet, the IC/CMB emission contributes strongly in the VHE regime.

The parameters of the extended jet model match those of modeling attempts of the sources OJ 287 (Marscher & Jorstad 2011) and S5 2007+777 (Sambruna et al. 2008). These sources are also BL Lac objects with an extended, IC dominated X-ray jet. The inferred parameters, especially the values of the magnetic field on the order of a few μG and the parameters of the electron distribution (γmin ~ 50, s ~ 2.5), are similar to our parameters. Thus, extended jets must be efficient accelerators on all scales. since the entire volume of the jet is required to produce the emission (Böttcher et al. 2008).

We have also presented explicit tests to confirm the extended jet origin of the VHE emission in AP Librae. This includes a direct detection of the jet in the UV band, and an indirect confirmation if the flux at VHE γ-rays does not drop below the average level. This confirmation is important, because the emission of VHE radiation by an extended blazar jet would be an extraordinary result, which might even have consequences for the acceleration of ultra high-energy cosmic rays. Further observations of AP Librae in all energy bands is strongly encouraged.

If other jets exhibit extended VHE emission, these sources could be resolved by the future Cherenkov Telescope Array (CTA) owing to its superior angular resolution compared to the current generation of Cherenkov experiments.

Note added in proof. While this paper was undergoing the referee process, we became aware of a publication by Sanchez et al. (2015), which also interprets the TeV emission as originating in the large-scale jet. These authors use a one-zone model for the jet emission, which gives different results and parameters than our extended jet model.


The authors wish to thank Markus Böttcher for the numerical code and fruitful discussions. We also thank G. Bicknell and S. Kaufmann for discussions. We thank the anonymous referee for a constructive report, which helped to clarify the presentation. This work was supported by the German Ministry for Education and Research (BMBF) through Verbundforschung Astroteilchenphysik grant 05A11VH2. This research has made use of data from the MOJAVE database that is maintained by the MOJAVE team (Lister et al. 2009). This paper is based on observations obtained with Planck (, an ESA science mission with instruments and contributions directly funded by ESA Member States, NASA, and Canada.
