Context. For 61 transiting hot Jupiters, the projection of the angle between the orbital plane and the stellar equator (called the spinorbit angle) has been measured. For about half of them, a significant misalignment is detected, and retrograde planets have been observed. This challenges scenarios of the formation of hot Jupiters.
Aims. In order to better constrain formation models, we relate the distribution of the real spinorbit angle Ψ to the projected one β. Then, a comparison with the observations is relevant.
Methods. We analyse the geometry of the problem to link analytically the projected angle β to the real spinorbit angle Ψ. The distribution of Ψ expected in various models is taken from the literature, or derived with a simplified model and Monte Carlo simulations in the case of the disktorquing mechanism.
Results. An easy formula to compute the probability density function (PDF) of β knowing the PDF of Ψ is provided. All models tested here look compatible with the observed distribution beyond 40 degrees, which is so far poorly constrained by only 18 observations. But only the disktorquing mechanism can account for the excess of aligned hot Jupiters, provided that the torquing is not always efficient. This is the case if the exciting binaries have semimajor axes as large as ~10^{4} AU.
Conclusions. Based on comparison with the set of observations available today, scattering models and the Kozai cycle with tidal friction models can not be solely responsible for the production of all hot Jupiters. Conversely, the presently observed distribution of the spinorbit angles is compatible with most hot Jupiters having been transported by smooth migration inside a protoplanetary disk, itself possibly torqued by a companion.
Key words: planets and satellites: formation / planets and satellites: dynamical evolution and stability / planetdisk interactions / methods: statistical
© ESO, 2014
1. Introduction
The existence of closein giant planets whose orbits lie in close proximity to their host stars is now well established (e.g., Cumming 2011). Although these objects constitute the best observationally characterised sample of exoplanets, their origins remain puzzling from a theoretical point of view. As insitu formation of hot Jupiters is problematic (Chiang & Laughlin 2013), it is likely that these objects have formed beyond the iceline in the protoplanetary disk (i.e, at an orbital separation of a few AU) and have since been transported inwards (Lin et al. 1996). Traditionally, smooth migration forced by interaction with the protoplanetary disc in which planets form, has been invoked to facilitate transport (Lin & Papaloizou 1986; Lin et al. 1996; Wu & Murray 2003; Crida & Morbidelli 2007; Papaloizou et al. 2007). Recently, substantially more violent processes have been proposed to account for the generation of hot Jupiters (Fabrycky & Tremaine 2007; Nagasawa et al. 2008; Beaugé & Nesvorný 2012). However, the dominance of the roles played by each mechanism remains controversial (Dawson et al. 2012). Accordingly, observations of the stellar spinplanetary orbit misalignment has been invoked as a means of differentiating among the proposed models.
Among the ~ 1000 exoplanets detected to date, ~ 60 have an observed measure of the angle between their orbital plane and the equatorial plane of their host star (e.g., Winn et al. 2007; Triaud et al. 2010). Traditionally, this has been achieved through the RossiterMcLaughlin effect (Mac Laughlin 1924); however, recently novel techniques involving asteroseismology (Huber et al. 2013) and starspot measurements (Hirano et al. 2012) have also been utilised to this end. A wide variety of measured angles have been reported to date, and many exoplanets are apparently characterised by spinorbit misalignment: the orbital obliquity differs significantly from 0. Instinctively, this is surprising as planets are supposed to form within a protoplanetary disk whose angular momentum direction is the same as that of the star. Therefore, the origin of the spinorbit misalignment has received considerable attention over the past few years.
A promising way to disentangle the roles of the various transport mechanisms, is to analyse the observed distribution of the spinorbit angles, and to compare it to the expected distribution from a given model. However, observations only provide the projected spinorbit angle, not the real one. Accordingly, in Sect. 2, we describe the 3D geometry of the problem, and we infer the distribution of the projected spinorbit angles from the real ones (and viceversa).
In Sect. 3, we compute the distributions of the projected spinorbit angles expected from various mechanisms, devoting special attention to the disktorquing model (Batygin 2012). Within the framework of the disktorquing mechanism, a (possibly transient) companion to a young star makes the protoplanetary disk precess around the binary’s axis, so that the plane in which planets eventually form and the equatorial plane of the central star can differ. Contrary to the violent category of migration mechanisms – e.g., planetplanet scattering (Rasio & Ford 1996; Ford & Rasio 2008) and Kozai resonance (Wu & Murray 2003; Fabrycky & Tremaine 2007; Naoz et al. 2011) – this process predicts that all the planets of the system can share the same misalignment. The recent discovery of significant misalignment among a multitransiting system (Huber et al. 2013) therefore puts emphasis on this model.
Using analytical arguments and Monte Carlo simulations, we find that the current observational aggregate can be well explained by the disktorquing effect, implying that diskdriven planet migration in (torqued) disks could be the dominant source of (mis)aligned hot Jupiters.
2. 3D geometry of the spinorbit angle
There is considerable confusion in the literature about the spinorbit angle. Let us define precisely what we are interested in here. The true misalignment angle is actually the angle between two vectors in 3D space: L_{p}, the orbital angular momentum of the planet, and L_{s}, the angular momentum of the spin of the star. As such, it can only lie between 0 and 180 degrees (there are no negative angles in 3D). This real, 3D angle is denoted below as Ψ.
The projections of these two vectors onto the plane of the sky (noted ${{L}}_{\mathrm{p}}^{\mathrm{\prime}}$ and ${{L}}_{\mathrm{s}}^{\mathrm{\prime}}$) form an oriented angle, which in principle could range between − 180° and + 180°. However, whether the angle (${{L}}_{\mathrm{p}}^{\mathrm{\prime}}\mathit{,}{{L}}_{\mathrm{s}}^{\mathrm{\prime}}$) is positive or negative when measured clockwise, corresponds to the same 3D configuration, observed from either side of the star, from the ascending or descending node. In any case, the two cases are indistinguishable observationally (A. Triaud, priv. comm.). Thus, it does not make sense to report negative angles. The projected spinorbit angle should also be expressed as between 0° and 180°. Still, on exoplanets.org, one finds many negative projected spinorbit angles, taken from published articles. This angle is sometimes noted λ (e.g., Fabrycky & Winn 2009, exoplanets.org), and sometimes it is noted as β (e.g., Triaud et al. 2010). The projected angle is denoted below as β, and will be taken as the absolute value of the misalignment angle β or λ reported in the literature.
Fig. 1 Right: 3D representation of the problem. The yellow sphere is the unit sphere centred on the star. P marks the direction of the orbital angular momentum vector L_{p} and S that of the stellar spin L_{s}. The dashed circle passing through points A and S gathers all the points making an angle Ψ with P. It is represented in the top left. Top left: circle of the unit sphere gathering all the points at colatitude Ψ with respect to the orbital angular momentum vector of the planet. A is the point facing the observer; S is the point corresponding to the direction of the stellar spin. A and S are projected on the diameter of this circle perpendicular to the line of sight onto A′ and S′; φ_{s} is then $\begin{array}{c}{[}_{}\\ \mathit{A}{\mathit{A}}^{\mathrm{\prime}}\mathit{S}\end{array}$. Bottom left: projected plane, as seen by the observer. The previous dashed circle is now a dashed horizontal line, on which A′ and S′ are the projections of A and S along the direction of the line of sight. The arc PR defines an angle Ψ, while the projected spinorbit angle β is $\begin{array}{c}{[}_{}\\ {\mathit{A}}^{\mathrm{\prime}}\mathit{O}{\mathit{S}}^{\mathrm{\prime}}\end{array}$, marked in red.
2.1. Relation between the real and projected spinorbit angle
Assume that Ψ is fixed. Which β will be observed? What is the probability density function (PDF) of β?
This question has already been addressed in general by Fabrycky & Winn (2009). They provide β (that they note λ) as a function of Ψ and i_{o}, the inclination of the orbital angular momentum with respect to the line of sight. Here, we propose a simpler, one column derivation, making the assumption that the observer is exactly in the orbital plane (i_{o} = π/ 2); this is appropriate because all the planets with known spinorbit angle transit their host star, so  π/ 2 − i_{o}  is very small. In this case, ${{L}}_{\mathrm{p}}\mathrm{=}{{L}}_{\mathrm{p}}^{\mathrm{\prime}}$ is perpendicular to the line of sight, and is in the plane of the sky. Let us consider spherical coordinates (r,φ,θ) centred on the star, such that colatitude θ = 0 corresponds to the north pole of the orbit, the direction of L_{p}; the origin of the longitude (θ = 90°, φ = 0) corresponds to the direction of the observer. In these coordinates, L_{s} has a colatitude θ_{s} = Ψ. Its azimuth φ_{s}^{1} can be anything between 0 and 2π, with a uniform distribution. Clearly, if φ_{s} ≡ 0 [ π ], the observer sees β = 0 if Ψ <π/ 2, and β = π if Ψ >π/ 2; conversely, if and only if φ_{s} = ± π/ 2 the observer sees β = Ψ exactly.
This configuration is shown in the right panel of Fig. 1. The point O is the centre of the unit sphere, and P and S are the intersection of the sphere with the vectors L_{p} and L_{s} respectively. The point A has colatitude θ = Ψ and azimuth φ = 0, facing the observer, while R has colatitude θ = Ψ and azimuth φ = π/ 2, appearing on the limb of the star for the observer. Accordingly, OA = OS = OP = OR = 1.
The plane (OPR) is the plane perpendicular to the line of sight passing through O: it is the plane of the sky as seen by the observer, onto which everything is orthogonally projected, along the direction of the line of sight.
The circle gathering all the points with colatitude Ψ is the dashed circle passing through A, S, and R. This circle is represented in the top left of Fig. 1. The orthogonal projections of A and S onto the plane (OPR), are A′ and S′ respectively. The centre of this dashed circle is A′, and its radius is obviously A′A = A′S = A′R = sinΨ. Thus, A′S′ = sinΨ  sinφ_{s} .
In the projected plane (shown in bottom left of Fig. 1), the angle between the north pole of the orbit and the spin of the star appears to be $\mathit{\beta}\mathrm{=}\begin{array}{c}{}_{[}\\ \mathit{PO}{\mathit{S}}^{\mathrm{\prime}}\end{array}$. As A′ is the orthogonal projection of S′ on the (OP) line, we have tanβ = A′S′/OA′, where OA′ = cosΨ is negative when Ψ >π/ 2. Finally, $\begin{array}{ccc}& & \mathit{\beta}\mathrm{=}\mathrm{arctan}\left(\mathrm{\left}\mathrm{sin}{\mathit{\phi}}_{\mathrm{s}}\mathrm{\right}\hspace{0.17em}\mathrm{tan}\mathrm{\Psi}\right)\mathrm{\equiv}\mathit{G}\mathrm{\left(}{\mathit{\phi}}_{\mathrm{s}}\mathrm{\right)}\\ & & \mathrm{\left}{\mathit{\phi}}_{\mathrm{s}}\mathrm{\right}\mathrm{=}\mathrm{arcsin}\left(\frac{\mathrm{tan}\mathit{\beta}}{\mathrm{tan}\mathrm{\Psi}}\right)\mathrm{\xb7}\end{array}$This is equivalent to Eq. (11) of Fabrycky & Winn (2009), with i_{o} = π/ 2, Ω = φ_{s} and λ = β.
2.2. Probability density function of β, for fixed Ψ
Now, as the distribution of φ_{s} is uniform in the interval [ 0;2π [, and  sin(x)  =  sin(π − x)  =  sin(π + x)  =  sin(2π − x) , it is sufficient to consider a uniform distribution for , with probability density 2 /π. In this case, β is a monotonic function of φ_{s}. It is well known that if X is a random variable of probability density function f_{X}, and Y = G(X) with G a monotonic function, then the PDF of Y is ${\mathit{f}}_{\mathit{Y}}\mathrm{\left(}\mathit{y}\mathrm{\right)}\mathrm{=}{\mathit{f}}_{\mathit{X}}\mathrm{\left(}{\mathit{G}}^{1}\mathrm{\right(}\mathit{y}{\mathrm{\left)}}^{\mathrm{\right)}}\mathrm{\times}\left{\mathrm{\left(}{\mathit{G}}^{1}\mathrm{\right)}}^{\mathrm{\prime}}\mathrm{\left(}\mathit{y}\mathrm{\right)}\right\mathit{.}$(3)Thus, using Eq. (1) for fixed Ψ, the PDF of β is: $\mathit{f}\mathrm{\left(}\mathit{\beta}\mathrm{\right}\mathrm{\Psi}\mathrm{)}\mathrm{=}\{\begin{array}{c}\\ \frac{\mathrm{2}}{\mathit{\pi}}\frac{\mathrm{1}\mathrm{+}{\mathrm{tan}}^{\mathrm{2}}\mathit{\beta}}{\mathrm{(}{\mathrm{tan}}^{\mathrm{2}}\mathrm{\Psi}\mathrm{}{\mathrm{tan}}^{\mathrm{2}}\mathit{\beta}{\mathrm{)}}^{\mathrm{1}\mathit{/}\mathrm{2}}}& \mathrm{if}\mathit{\beta}\mathrm{\in}\mathrm{\mathcal{T}}\mathit{,}\\ \mathrm{0}& \mathrm{otherwise}\end{array}$(4)where $\mathrm{\mathcal{T}}\mathrm{=}\mathrm{\{}\mathrm{0}\u2a7d\mathit{\beta}\mathit{<}\mathrm{\Psi}\mathit{<}\frac{\mathit{\pi}}{\mathrm{2}}\mathrm{\}}\mathrm{\cup}\mathrm{\{}\frac{\mathit{\pi}}{\mathrm{2}}\mathit{<}\mathrm{\Psi}\mathit{<}\mathit{\beta}\u2a7d\mathit{\pi}\mathrm{\}}$.
This equation is identical to Eq. (19) of Fabrycky & Winn (2009)^{2}.
Figure 2 shows the decimal logarithm of f(β  Ψ) in the β − Ψ plane. For a given real spinorbit angle Ψ_{0}, the PDF of the observed projected angle β can be found by going along a Ψ = Ψ_{0} line in the figure. One can check analytically that for all Ψ, ${{}^{\mathrm{\int}}}_{\mathit{\beta}\mathrm{=}\mathrm{0}}^{\mathit{\beta}\mathrm{=}\mathit{\pi}}\mathit{f}\mathrm{\left(}\mathit{\beta}\mathrm{\right}\mathrm{\Psi}\mathrm{)}\hspace{0.17em}\mathrm{d}\mathit{\beta}\mathrm{=}\mathrm{1}$, as it should.
Fig. 2 Contour map of f(β  Ψ) as defined by Eq. (4). The contours correspond to values 10^{k}, with k =−1.5, − 1...1, 1.5; the curves corresponding to f = 1 and f = 0.1 are marked. Note that f actually diverges towards + ∞ approaching the Ψ = β line.
2.3. Conversion of the PDF of Ψ into the PDF of β
If now Ψ has its own PDF w(Ψ), the corresponding PDF of β will be: $\mathit{f}\mathrm{\left(}\mathit{\beta}\mathrm{\right)}\mathrm{=}{\mathrm{\int}}_{\mathrm{\Psi}\mathrm{=}\mathrm{0}}^{\mathrm{\Psi}\mathrm{=}\mathit{\pi}}\mathit{f}\mathrm{\left(}\mathit{\beta}\mathrm{\right}\mathrm{\Psi}\mathrm{\left)}\mathit{w}\mathrm{\right(}\mathrm{\Psi}\mathrm{)}\mathrm{d\Psi}\mathit{.}$(5)Computing this integration corresponds to summing vertically in Fig. 2, after having given to every horizontal line a weight w(Ψ).
For example, assuming a uniform w(Ψ) = 1 /π, one gets the doublepeaked distribution shown in Fig. 3. On the other hand, assuming that Ψ is isotropically distributed, w(Ψ) = (sinΨ) / 2, one can solve Eq. (5) and find f(β) = 1 /π, uniform, as expected. The observed distribution of β (see histogram in Fig. 5) is neither flat nor reminiscent of the distribution shown in Fig. 3, implying that the real distribution of Ψ is neither uniform, nor isotropic.
Fig. 3 Representation f(β) when w(Ψ) = 1 /π (uniform distribution of Ψ).
2.4. Deprojection
Let i_{s} be the angle between the stellar angular momentum L_{s} and the line of sight; an isotropic distribution of L_{s} on the unit sphere gives to i_{s} a PDF $\mathit{f}\mathrm{\left(}{\mathit{i}}_{\mathrm{s}}\mathrm{\right)}\mathrm{=}\frac{\mathrm{1}}{\mathrm{2}}\mathrm{sin}\mathrm{\left(}{\mathit{i}}_{\mathrm{s}}\mathrm{\right)}$ between 0 and π. On the projected plane (bottom left of Fig. 1), we now have OS′ = sini_{s}, and OA′ = OS′ × cosβ = OR × cosΨ = cosΨ. Thus, $\mathrm{\Psi}\mathrm{=}\mathrm{arccos}\mathrm{(}\mathrm{cos}\mathit{\beta}\mathrm{\times}\mathrm{sin}{\mathit{i}}_{\mathrm{s}}\mathrm{)}\mathrm{=}{\mathit{G}}_{\mathrm{2}}\mathrm{\left(}{\mathit{i}}_{\mathrm{s}}\mathrm{\right)}\mathit{.}$(6)Note that i_{s} or π − i_{s} give exactly the same projection. One can therefore assume that i_{s} is distributed between 0 and π/ 2 with PDF f(i_{s}) = sin(i_{s}). Then, using Eqs. (3) and (6), one gets: $\mathit{f}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right}\mathit{\beta}\mathrm{)}\mathrm{=}\{\begin{array}{c}\\ \frac{\mathrm{cos}\mathrm{\Psi}}{\mathrm{cos}\mathit{\beta}}\frac{\mathrm{sin}\mathrm{\Psi}}{\sqrt{{\mathrm{cos}}^{\mathrm{2}}\mathit{\beta}\mathrm{}{\mathrm{cos}}^{\mathrm{2}}\mathrm{\Psi}}}& \begin{array}{c}\\ \mathrm{if}\mathrm{0}\mathit{<}\mathit{\beta}\mathit{<}\mathrm{\Psi}\mathit{<}\mathit{\pi}\mathit{/}\mathrm{2}\\ \mathrm{or}\mathit{\pi}\mathit{/}\mathrm{2}\mathit{<}\mathrm{\Psi}\mathit{<}\mathit{\beta}\mathit{<}\mathit{\pi ,}\end{array}\\ \mathrm{0}& \begin{array}{c}\\ \mathrm{otherwise}\mathit{,}\end{array}\end{array}$(7)in agreement with Eq. (21) of Fabrycky & Winn (2009).
Then, the PDF of Ψ can be deduced from the observations of β: $\mathit{f}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right)}\mathrm{=}\sum _{\mathit{i}}\mathit{f}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right}{\mathit{\beta}}_{\mathit{i}}\mathrm{)}$(8)where the index i spans the whole sample.
Applying this to the data found on exoplanets.org at the end of 2013, we get an irregular curve peaked at each of the β_{i}, as f(Ψ  β_{i}) diverges towards + ∞ as Ψ → β_{i}. This curve is displayed as a thin blue line in Fig. 4. To avoid this, one could smooth the data using the errorbars σ_{i} and compute: $\begin{array}{ccc}\mathit{f}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right)}\mathrm{=}\sum _{\mathit{i}}\mathrm{\int}\frac{\mathrm{1}}{\sqrt{\mathrm{2}\mathit{\pi}}{\mathit{\sigma}}_{\mathit{i}}}\mathrm{exp}\left(\mathrm{}\frac{\mathrm{(}\mathit{\beta}\mathrm{}{\mathit{\beta}}_{\mathit{i}}{\mathrm{)}}^{\mathrm{2}}}{\mathrm{2}\hspace{0.17em}{{\mathit{\sigma}}_{\mathit{i}}}^{\mathrm{2}}}\right)\mathit{f}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right}\mathit{\beta}\mathrm{)}\mathrm{d}\mathit{\beta}\mathit{.}& & \end{array}$However, the σ_{i} are so diverse (from 0.3 to 60°) that this operation would only degrade the information, without completely smoothing the curve. Therefore, we prefer to operate similar to the observations of β and build a histogram: we average f(Ψ) on successive intervals of 20° width. This is represented in Fig. 4 as the red stairs, while the histogram of the observations of β is shaded grey. It seems here that aligned hot Jupiters are a minority. However, one should realize that if all hot Jupiters were actually aligned, Ψ = β = 0, but Eq (7) gives f(Ψ  β = 0) = max { cosΨ, 0 }; it is therefore almost impossible that the first step of the red stairs is the highest step, even if there is a large majority of aligned hot Jupiters.
In any case, with only 18 cases with β> 40° in the data, and large error bars, the statistics is rather poor to infer the PDF of Ψ accurately. Therefore, in what follows, we prefer to infer the PDF of β from various mechanisms, and compare it directly with the observed distribution of β.
Fig. 4 Grey shaded histogram: distribution of the observed projected spinorbit angle β (taken as  β  or  λ  in the data from exoplanets.org). Thin blue curve: f(Ψ), as given by Eq. (8). Red stairs: histogram of the PDF of Ψ with bins of 20°.
Fig. 5 Distribution of the spinorbit angle expected in the disktorquing mechanism. Thin red line: distribution of Ψ, given by Eq. (11). Thick blue line: corresponding PDF of β. Background histogram: observations.
3. Application to proposed mechanisms
In this section, we compute/take the PDF of Ψ that is expected from several mechanisms of formation of hot Jupiters. Then, we compute the corresponding PDF of β using Eq. (5), and compare it with the distribution of the observations. The distribution of the observations is shown as a grey shaded histogram in Figs. 5, 7, and 8. The bins have a width of 20°, and many of them contain only two cases. This small number statistics is prone to significant variations with new observations, or change of the bins: one object more or less in a bin represents a 50% variation. Nonetheless, it appears robust that the distribution of the projected spinorbit angle beyond 60° is almost uniform. Models should account for this.
To be more precise, assuming the small number of planets in our bins follows a Poisson process of parameter λ, when N are found in a bin, the likelihood of λ is given by λ^{N}exp(−λ) /N ! . Thus, in the bins where two are found, one can say with 50% confidence that 1.17 <λ< 3.16 and with 95% confidence that 0.31 <λ< 6.34.
3.1. Disk torquing
Contemporary observational surveys suggest that a considerable fraction of solartype stars are born as binary or multiple systems (Ghez et al. 1993; Kraus et al. 2011). Moreover, most stars form in embedded cluster environments (Lada & Lada 2003) where dynamical evolution can lead to the acquisition of transient companions (Malmberg et al. 2007). Recently, Batygin (2012) showed that the presence of a companion to a young star can force the protoplanetary disk to precess around the binary’s axis, so that the plane in which planets eventually form and the equatorial plane of the central star can differ.
3.1.1. Analytic simple model
Denoting the angle between the orbital plane of the companion and the stellar equator as i′ (therefore, ), Ψ evolves between 0 and 2i′ in this mechanism. At first sight of Fig. 2 of Batygin (2012), it seems reasonable to consider this evolution as linear with time, back and forth. In the end, the PDF of Ψ is a uniform distribution between 0 and 2i′: $\mathit{f}\mathrm{(}\mathrm{\Psi}\hspace{0.17em}\mathrm{}\hspace{0.17em}{\mathit{i}}^{\mathrm{\prime}}\mathrm{)}\mathrm{=}\frac{\mathrm{1}}{\mathrm{2}{\mathit{i}}^{\mathrm{\prime}}}\mathrm{if}\mathrm{0}\u2a7d\mathrm{\Psi}\u2a7d\mathrm{2}{\mathit{i}}^{\mathrm{\prime}}\mathrm{;}\mathrm{0}\mathrm{otherwise}\mathrm{.}$(9)The PDF of i′ should correspond to an isotropic distribution of the orbital angular momentum vector of the companion with respect to the stellar spin, thus it reads: $\mathit{g}\mathrm{\left(}{\mathit{i}}^{\mathrm{\prime}}\mathrm{\right)}\mathrm{=}\mathrm{sin}\mathrm{\left(}{\mathit{i}}^{\mathrm{\prime}}\mathrm{\right)}\mathit{.}$(10)Now, the PDF of Ψ is given by: $\begin{array}{ccc}{\mathit{f}}_{\mathit{B}\mathrm{12}}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right)}& \mathrm{=}& \int \begin{array}{c}\mathit{\pi}\mathit{/}\mathrm{2}\\ \mathrm{0}\end{array}\mathit{f}\mathrm{\left(}\mathrm{\Psi}\hspace{0.17em}\mathrm{\right}\hspace{0.17em}{\mathit{i}}^{\mathrm{\prime}}\mathrm{\left)}\mathit{g}\mathrm{\right(}{\mathit{i}}^{\mathrm{\prime}}\mathrm{)}\mathrm{d}{\mathit{i}}^{\mathrm{\prime}}\\ & \mathrm{=}& \int \begin{array}{c}\mathit{\pi}\mathit{/}\mathrm{2}\\ \mathrm{\Psi}\mathit{/}\mathrm{2}\end{array}\frac{\mathrm{sin}\mathrm{\left(}{\mathit{i}}^{\mathrm{\prime}}\mathrm{\right)}}{\mathrm{2}{\mathit{i}}^{\mathrm{\prime}}}\hspace{0.17em}\mathrm{d}{\mathit{i}}^{\mathrm{\prime}}\\ {\mathit{f}}_{\mathit{B}\mathrm{12}}\mathrm{\left(}\mathrm{\Psi}\mathrm{\right)}& \mathrm{=}& \end{array}$(11)where $\mathrm{Si}\mathrm{\left(}\mathit{x}\mathrm{\right)}\mathrm{=}{{}^{\mathrm{\int}}}_{\mathrm{0}}^{\mathit{x}}\frac{\mathrm{sin}\mathrm{\left(}\mathit{t}\mathrm{\right)}}{\mathit{t}}\hspace{0.17em}\mathrm{d}\mathit{t}$, which has unfortunately no easy analytical expression. Nonetheless, this expression can be computed numerically. In Fig. 5, f_{B12} is displayed as the red thin curve; it looks linear, but it’s actually not a straight line. The corresponding PDF of β (using Eq. (5)) is shown as the blue thick curve. The major difference between the two curves enlights the necessity of taking the projection into account. In the background, the histogram of the observations shows a good agreement with the predicted distribution of the projected angles. The PDF of β is normalised to have 18 planets with β> 40°, like the data.
With this normalisation, the number of planets with β< 20° (resp. 20°<β< 40°) is only 14.2 (resp. 6.8), while 34 (resp. 9) are observed. This excess of aligned planets in the observations should not bother us. Indeed, hot Jupiters form in the protoplanetary disk, and migrate inwards irrespective of the multiplicity of the stellar system. Thus, if the protoplanetary disk is not torqued (e.g., the star is always single), the hot Jupiters are expected to be aligned. If the protoplanetary disk is torqued by a companion, then the planets will be misaligned, with the distribution given above. The apparent excess of aligned hot Jupiter can therefore be interpreted as the fraction of disks that were never significantly torqued. We come back on this issue in the next subsection.
3.1.2. Monte Carlo simulations
Within the framework of the model proposed by Batygin (2012), the stellar spin axis is taken to remain in the primordial plane of the disk for all time. Physically, this simplifying assumption corresponds to a nonaccreting, unmagnetised young stellar object that rotates at a negligibly slow rate. This picture is somewhat contrary to real premainsequence stars, which typically accrete ~10^{8} M_{⊙}/year from the disk (Hartmann 2008; Hillenbrand 2008), have ~1 kGauss magnetic fields at the stellar surface (Shu et al. 1994; Gregory et al. 2010), and rotate with characteristic periods in the range P_{rot} ≃ 1−10 days (Herbst et al. 2007). Accordingly, Batygin & Adams (2013) examined magnetically and gravitationally facilitated diskstar angular momentum transfer with an eye towards constraining the conditions needed for the acquisition of spinorbit misalignment. They showed that the excitation of spinorbit misalignment is only quenched when the host star continuously spins up because of gravitational contraction (i.e., the stellar field is too weak for magnetic breaking to occur; see Shu et al. 1994; Matt & Pudritz 2005a,b). However, they also found that the process by which spinorbit misalignment is attained is somewhat more complicated than that described in Batygin (2012). Specifically, as the disk mass decreases throughout its lifetime, the gravitational coupling between the star’s quadrupole moment (that arises from rotational deformation) and the torqued disk gives rise to orbital obliquity via a secular resonance encounter between the stellar spinaxis precession frequency and the disktorquing frequency (see Batygin & Adams 2013, for details).
Cumulatively, the more complete model of Batygin & Adams (2013) does not easily lend itself to analytic manipulation. As a result, to derive the associated distribution of projected misalignment angles, we perform a Monte Carlo simulation, utilising their perturbative model (for brevity, we shall not rehash their formalism here, but instead refer the reader to their description). As above, the inclinations of the binary companion stars are taken to be isotropic, the binary semimajor axis is drawn from a logflat distribution spanning 10^{2.5}−a_{max} AU (where a_{max} can vary, see caption of Fig. 6; Kraus et al. 2011), while the eccentricity and the primarytoperturber mass ratio are taken to be uniform in the intervals [0, 1] and [0.1, 10], respectively (see Kraus et al. 2008). The primary star’s mass and the disk’s initial mass are also drawn from uniform distribution spanning [0.5, 1.5] M_{⊙} and [0.01, 0.05] M_{⊙}, respectively (Herczeg & Hillenbrand 2008). For all simulations, a surface density profile of the form Σ ∝ r^{1} is assumed. The disk’s outer edge is taken to lie between 10^{1.5} and 10^{2} AU (Levison et al. 2008; Anderson et al. 2013), while the inner edge corresponds to the stellar corotation radius (Koenigl 1991; Shu et al. 1994). In turn, the stellar rotation periods are randomly chosen to lie between 1 and 10 days in rough agreement with the observational samples of Littlefair et al. (2010) and Affer et al. (2013). Following Gallet & Bouvier (2013), premain sequence rotational evolution is ignored because of the inherent complexities. Finally, the disk mass loss, stellar structure, and stellar gravitational contraction are modelled as described in Batygin & Adams (2013).
Fig. 6 Distributions of the projected spinorbit angle found in Monte Carlo simulations as described in the text, for three values of the maximum of the logflat distribution of the semimajor axis of the binary. Top right: a_{max} = 10^{3} AU. Middle: a_{max} = 10^{3.75} AU. Bottom left: a_{max} = 10^{4.5} AU.
Fig. 7 Distributions produced by the Monte Carlo simulations, normalised to 18 cases with β> 40°. Thin blue: a_{max} = 10^{3} AU. Thick green: a_{max} = 10^{3.75} AU. Red: a_{max} = 10^{4.5} AU. Background histogram: observations.
With the aforementioned ingredients in place, we compute the disktorquing frequency as described in Batygin (2012, see Eqs. (6) and (7) in Sect. I), while the rest of the calculation follows directly from Sect. 4 of Batygin & Adams (2013). The results are shown in Fig. 6. One thousand random sets of parameters have been chosen with the distributions described above, and the resulting 1000 final spinorbit angles have been binned in bins of 20° width to produce a histogram, to be compared to the observations (Fig. 5). Three cases are presented, where the only difference is the assumed value of a_{max}, the maximum possible value of the semimajor axis of the binary; from left to right, a_{max} = 10^{3}, 10^{3.75}, and 10^{4.5} AU. The fraction of disks that will experience a negligible torquing appears to be very sensitive to a_{max}. However, the distribution of the angles in the torqued cases remains unchanged, and close to the observations, as can be seen in Fig. 7. In this figure, the three distributions obtained by the three sets of Monte Carlo simulations have been normalised to have 18 planets with β> 40°, like in the data. They are represented in blue, green, and red stairs, and are very similar beyond 40°. In the background, the histogram of the data is shown in grey bars. All the three stairs are within 1 count of the histogram, signaling excellent agreement.
The choices of input parameters employed in the simulations are essentially naive estimates, predominantly guided by observational surveys. The observed agreement between the data and the model is thus compelling. However, with a considerable number of marginally constrained (and in some cases poorly understood) values at hand, it would not come as a surprise if the utilised model admitted significant variability in the distributions it could produce. Although a complete search of the parameter space is well beyond the scope of this study, it is noteworthy (as already alluded to above) that the model appears to be most sensitive to the orbital distribution of binary companions. While the median widest allowed binary orbit (10^{3.75} ≃ 5600 AU) in the simulation was motivated by the observational study of Kraus et al. (2011), if we reduce this range to 10^{3} AU, the enhancement near β = 0 in Fig. 6 disappears entirely. On the contrary, if the range is extended to 10^{4.5} AU, the enhancement near aligned orbits grows by almost a factor of ~2, although in both cases the shape of the PDF in the significantly misaligned region remains unchanged. The physical reason behind this is not exceedingly difficult to understand. As binary orbits get wider, the free precession (i.e., torquing) frequency of the disk decreases. This allows stars to adiabatically trail their disks for extended periods of time (Batygin 2012). In turn, this means that by the time the secular resonance encounter between the stellar spinaxis precession rate and the disk precession rate happens, the disk mass is systematically lower, leading to smaller excitation of misalignment.
Fig. 8 Distribution of β expected from several mechanisms of forming hot Jupiters. Background histogram: observations.
Ideally, one would like to examine the sensitivity of the model to the assumed parameters in greater detail, although for such an activity to be meaningful, the underlying physics (particularly in the case of premainsequence rotational evolution) must await some clarification. Therefore, we leave this exercise for a later study.
3.2. Other mechanisms
3.2.1. Perturbations to the planetary orbit
A few processes of formation of hot Jupiters have been proposed by several authors, who provide the expected distribution of the final inclination of the hot Jupiter with respect to its initial orbital plane. As already argued in Sect. 2, this angle should be Ψ in the end. We have collected these data from the papers, and derived the expected distribution of the projected spinorbit angle β. We refer the reader to the original papers for a detailed explanation of how the distributions of Ψ were derived by the authors. The data is originally in the form of a histogram (α_{i},N_{i}), where α_{i} is the angle at the centre of the bin, and N_{i} the number of planets with Ψ in this bin. From this, we constructed f = ∑ _{i}f(β  Ψ = α_{i})N_{i}, the distribution of β. We then bin f using the same bins as in the original histogram. We checked that spreading the N_{i} planets among angles different from α_{i} in the bin does not change the final histogram of β significantly.
The results are shown in Fig. 8. The red line with + symbols labelled F.T. 2007 represents the distribution of β expected in the Fabrycky & Tremaine (2007) mechanism of Kozai cycles with tidal friction (their Fig. 10b providing Ψ in bins of 10°). The blue line with stars labelled N.I.B.2008 corresponds to the distribution found by Nagasawa et al. (2008) in their model of planetplanet scattering, tidal circularisation, and Kozai mechanism; the data is taken from their Fig. 11c, which shows the histogram of Ψ of formed closein planets in all simulations, with bins of 0.1 rad. The green line with circles labelled B.N.2012 corresponds to the distribution found by Beaugé & Nesvorný (2012) in their model of multiplanet scattering, in the case of three planets after 1 Gyr of evolution (their Fig. 16). All the distributions of β have been normalised to have 18 cases with β> 40°, for an easier comparison.
The agreement between the curves and the histogram beyond 40° is in general satisfactory. Based on the small number of planets observed in each bin, it seems impossible to exclude one or the other mechanism at present. However, none of these processes can individually account for the sharp peak at β< 20°. To this end, Beaugé & Nesvorný (2012) point out that “it is possible that the population of hot Jupiters with β< 20° have a different origin”.
It should be noted, however, that Beaugé & Nesvorný (2012) had studied other scenarios, varying the inital number of planets, and the final age of the systems. Four different cases are shown in their paper, giving four different distributions. In particular, we have checked that the case with four planets, after 3 Gyr of evolution, once normalised to the β> 40° cases, would give an excess of aligned hot Jupiters compared to the observations. Thus, one can not exclude that a combination of all the distributions matches the observations. We found that their four published distributions give an excess of planets in the 20°<β< 60° range, but this concerns only four cases. Actually, the observations do sample the parameter space (in age and unknown initial conditions), so making a combination would be appropriate.
3.2.2. Perturbations to the stellar apparent spin
Along a completely different line of thought, Rogers et al. (2012, 2013) have proposed the misalignments to arise from the modulation of the outer layers of the host stars by interior gravity waves, rather than relics left behind by the dominant transport mechanism.
Cébron et al. (2011, 2013) also suggest that the excitation of the elliptical instability in the star by the tides raised by the planet could give an apparent tilted rotation axis. Even the total spin of the star could change direction, if the coupling with the planet is efficient. This will also lead to misalignment between a star and its hot Jupiter.
In order to assess the viability of these intriguing ideas, an expected distribution of spinorbit angles should be generated within the framework of these models, and compared against the observed distribution via a treatment such as that presented in this work.
4. Discussion and conclusion
In this paper, we provide a simple derivation of the probability density function of the projected spinorbit angle β, for fixed real spinorbit angle Ψ. This allows us to link models (that produce distributions of Ψ) to observations (that measure β).
Firstly, our geometric description shows that only positive values for β and Ψ are sensible. These angles are between 0 and 180°, where Ψ = 0 corresponds to prograde aligned orbits, and Ψ = 180° to retrograde aligned orbits. In particular, the notation λ = −β often found in the litterature is irrelevant.
Second, we find that the observed distribution of β presents a significant excess of quasialigned hot Jupiters (β< 20°) compared to the one expected from most models. This suggests that the scattering models and the Kozai cycle tidal friction models can not be solely responsible for the production of hot Jupiters. In previous studies (see Winn et al. 2010; Albrecht et al. 2012), the excess of nearlyaligned hot Jupiters has been attributed to tidal realignment of the star. However, Rogers & Lin (2013) recently pointed out that tidal realignment preferentially leads to prograde aligned, retrograde aligned, or orthogonal spinorbit angles, in some contradiction with the observed distribution (Lai 2012).
Third, in the simplest variant of the disktorquing model, the overrepresentation of quasialigned planets is also not reproduced if the binaries responsible for the excitation of orbital obliquity have orbital semimajor axes smaller than ~ 10^{3} AU. However, within the framework of the picture envisioned by Batygin & Adams (2013), alternative explanations are possible. These include adiabatic trailing of the host star, and early stripping or nonexistance of the binary companion. In fact, the fraction of aligned disks increases dramatically with the maximum semimajor axes of the exciting binaries, a_{max}. To this end, it is also worth noting that the wide binary fraction in star formation environments is a strong, growing function of primary stellar mass Kraus et al. (2011). Thus, a thorough investigation of the massdependence of the disktorquing mechanism appears worthwhile.
On the other hand, the expected distribution of β for β> 40° in the disktorquing model hardly depends on a_{max}, and is in very good agreement with the observations. Although other parameters, poorly constrained, can have an influence on the distribution of Ψ and β in the disktorquing mechanism, we can conclude that the presently observed distribution of the spinorbit angles is compatible with most hot Jupiters having been transported by smooth migration inside a protoplanetary disk, possibly torqued by a companion.
This angle φ_{s} was noted Ω by Fabrycky & Winn (2009).
