1. Introduction

The Herschel Reference Survey (HRS) is a complete sample of nearby galaxies defined to study the physical properties of the interstellar medium (ISM) in galaxies of different morphological type and luminosity (Boselli et al. 2010a). Composed of 322 galaxies, it has recently been observed by Herschel with the SPIRE (Ciesla et al. 2012) and PACS (Cortese et al., in prep.) instruments. To provide the community with the largest possible set of homogeneous data, our team has undertaken several observational campaigns or collected data from the literature to cover the widest possible range in wavelengths. These data include deep UV imaging with GALEX (Cortese et al. 2012a; Boselli et al. 2011), mid-infrared imaging with IRAC on Spitzer and WISE (Ciesla et al., in prep.), MIPS Spitzer photometry (Bendo et al. 2012), Hα imaging (Boselli et al., in prep.), and medium-resolution integrated optical spectroscopy (Boselli et al. 2014a).

This paper presents new CO observations of 59 HRS galaxies obtained at the Kitt Peak 12 m radiotelescope. These new CO data, combined with those available for both the other HRS objects and for other nearby galaxies recently mapped in the 12CO(1–0) line with various instruments, are used to compare different prescriptions to correct for aperture-effects single-beam observations. The new CO data, combined with those already available in the literature for the rest of the sample, are homogenised to produce a complete catalogue of CO fluxes and realistic uncertainties for all the observed HRS. We also collected Hi data from the literature and homogenised it for nearly the whole sample. These CO and Hi data are crucial for any detailed study of the physical properties of the ISM.

The cold gas is the dominant phase of the ISM in late-type galaxies. It exceeds in mass the dust component by ~a factor of 100–200 (Sodroski et al. 1994). This cold gas component can be observed easily in local galaxies. The atomic hydrogen (Hi) can be observed directly through the emission of the spin inversion line at 21 cm (1420 Mhz). Because of its symmetric structure, the molecular hydrogen (H2) has no permanent electric dipole moment. Dipole rotational transitions are thus strongly forbidden, making it very hard to directly observe the cold phase of this molecule, which in late-type galaxies has generally a temperature of ~10 K. For this reason, the molecular hydrogen mass is generally determined through observing of the second most aboundant molecule in the cold ISM, carbon monoxide, under the assumption that CO is a good tracer of H2 (Young & Scoville 1991). Indeed it has been shown that the dynamical mass of the giant molecular clouds is tightly related to the intensity of the CO line. The most commonly used method of determining the molecular hydrogen mass is based on observing of the 12CO(1–0) rotational line at 2.6 mm (115 GHz) and assuming a given conversion factor XCO between the intensity of the CO line and the H2 column density (see Boselli 2011).

In recent years, several works have questioned the existence of a standard conversion factor, but rather indicated that XCO might change with the different physical conditions characterising the properties of the ISM, such as the hardness of the ionising and non-ionising stellar radiation fields, and the metallicity and the density of the gas (Boselli et al. 2002; Bell et al. 2007; Bolatto et al. 2008, 2013; Liszt et al. 2010; Leroy et al. 2011; Shetty et al. 2011a,b; Narayanan et al. 2012; Sandstrom et al. 2013). We thus determined molecular gas masses using both a constant or a luminosity-dependent XCO conversion factor. As constant value we used the one determined in the Milky Way using γ-ray absorption data from COBE (XCO = 2.3 × 1020 cm-2/(K km s-1), or else, if expressed as αCO = 3.6 M/(K km s-1 pc-2), Strong et al. 1988), which is generally assumed to be representative of environments similar to those encountered in the solar neighbourhood in terms of metallicity and radiation field. As variable conversion factor, we adopt the calibration proposed by Boselli et al. (2002) based on the H-band luminosity, log XCO [cm-2/(K km s-1)] = −0.38 × log LH [LH ⊙] + 24.23. We chose this calibration because it can be determined easily for all HRS galaxies, for which an H-band magnitude is available from 2MASS. Furthermore, this calibration is a mean calibration compared to those proposed in the literature (Bolatto et al. 2013).

The paper is structured as follows. Section 2 describes the HRS sample, while Sects. 3 and 4 present the new CO observations. In Sect. 5 we discuss and apply different aperture correction techniques to the whole set of CO data available in the literature for the entire HRS sample, and we thus derive total CO fluxes and molecular gas masses. Section 6 gives homogenised Hi data for the whole sample. A brief conclusion is given in Sect. 7. Despite the presence of several complete samples of nearby galaxies with CO data (Sage 1993; FCRAO survey, Young et al. 1995; Boselli et al. 1997; Sauty et al. 2003; Lisenfeld et al. 2011; Saintonge et al. 2011), the HRS is the only one with the complete set of far-infrared and sub-millimetric Herschel data necessary for a detalied study of the properties of the ISM of normal galaxies. At the same time, it is a statistically significant, complete sample of nearby galaxies spanning a wide range in morphological type and stellar mass, making it ideally suited to study the cold gas properties of normal galaxies. It can be used, for instance, to extend to lower stellar masses (by a factor of ~10) the reference work of Saintonge et al. (2011) on the COLD GASS sample, which only includes massive galaxies. We thus devote three other specific works to the analysis of the gas properties of the HRS using this unique set of data. One, already published, analyses the effects of the environment on the Hi scaling relations of the sample (Cortese et al. 2011). A second one is focussed on determining the mean total and molecular gas scaling relations of the HRS (Boselli et al. 2014b), while the last one treats the effects of the environment on the molecular gas content of cluster objects (Boselli et al. 2013). The interested reader can find the results of other works based on the combined analysis of the Herschel and the other multifrequency data in Cortese et al. (2012b; dust scaling relations along the Hubble sequence), Smith et al. (2012; dust properties of early-type galaxies), Boselli et al. (2012; far infrared colours), Boquien et al. (2012, 2013; dust attenuation properties in resolved galaxies) or in the publication of several papers during the science demonstration phase of the instrument (Boselli et al. 2010b; Cortese et al. 2010; Eales et al. 2010; Gomez et al. 2010; Pohlen et al. 2010; Sauvage et al. 2010).

2. The sample

The Herschel Reference Survey (HRS) is an Herschel/SPIRE guaranteed time key project aimed at observing a complete, K-band-selected (K ≤ 8.7 mag for early-types, K ≤ 12 for type Sa), volume-limited (15 ≲ D ≲ 25 Mpc) sample of nearby galaxies. The HRS survey, as well as the selected sample, are extensively presented in Boselli et al. (2010a). Briefly, the sample is composed of 322 galaxies out of which 260 are late-type systems1. Galaxies were selected in the K-band taken as a proxy for galaxy stellar mass (Gavazzi et al. 1996). The sample includes objects in environments of different densities, from the core of the Virgo cluster to loose groups and fairly isolated systems. As defined, the present sample is ideal for any statistical study of the mean galaxy population of the nearby universe.

thumbnail Fig. 1

Comparison between the integrated SCO fluxes determined by Kuno et al. (2007) and those determined by Helfer et al. (2003; red filled dots), Chung et al. (2009a; blue filled triangles), our own observations of the two galaxies NGC 4548 and NGC 4579 with the IRAM radiotelescope (green filled squares) and the extrapolated fluxes of the FCRAO survey (Young et al. 1995; cyan empty circles) on logarithmic scale for all galaxies in common (left) and on linear scale for those objects with SCO in the range 100–5000 Jy km s-1 sampled by the HRS (right). The linear best fit to the data, determined assuming the Kuno et al. (2007) data as independent variable in the range 100–5000 Jy km s-1, are shown by the red dotted line (Helfer et al. 2003), the blue long dashed line (Chung et al. 2009a) and the cyan solid line (Young et al. 1995). The short dashed black line shows the 1:1 relationships.

Open with DEXTER

The galaxies observed in this work are late-type systems of K-band magnitude brighter than K < 10, expressely selected to complete the sample down to this K-band magnitude limit (142/151 of the late-types). Including our new observations, 225 out of the 322 HRS galaxies (143 detections), 168/260 for late-type (134 detected), and 57/62 for early-type systems (9 detected) have 12CO(1–0) data.

We also compile and homogenise 21 cm Hi data from the literature for all galaxies in the HRS. Hi data are available for 315 out of the 322 galaxies of the sample. The whole HRS sample with its main characteristics is given in Table 1, arranged as follows:

  • Column 1: Herschel Reference Sample (HRS) name, from Boselli et al. (2010a).

  • Column 2: Zwicky name, from the Catalogue of Galaxies and of Cluster of Galaxies (CGCG; Zwicky et al. 1961–1968).

  • Column 3: Virgo Cluster Catalogue (VCC) name, from Binggeli et al. (1985).

  • Column 4: Uppsala General Catalog (UGC) name (Nilson 1973).

  • Column 5: New General Catalogue (NGC) name (Dreyer 1888).

  • Column 6: Index Catalogue (IC) name (Dreyer 1908).

  • Columns 7 and 8: J2000 right ascension and declinations, from NED.

  • Column 9: Morphological type, from NED, or from our own classification if not available.

  • Column 10: Distance, in Mpc. Distances have been determined from the recessional velocity assuming a Hubble constant H0 = 70 km s-1 Mpc-1 for galaxies outside the Virgo cluster, and assumed to be 23 Mpc for galaxies belonging to the Virgo B cloud, 17 for the other Virgo members (Gavazzi et al. 1999).

  • Column 11: Total K-band magnitude (KStot), from 2MASS (Skrutskie et al. 2006).

  • Column 12: g-band optical isophotal diameter (24.5 mag arcsec-2), from Cortese et al. (2012a). For the HRS galaxies without SDSS images, the g-band isophotal diameter was determined from the relation r24.5(g) = 0.871(±0.017)r25(B) + 6.041(±2.101) (Spearman correlation coefficient ρ = 0.92), where r25(B) is the radius given in NED. This relation was determined using the HRS galaxies with both sets of data.

  • Column 13: Inclination of the galaxy, determined using the prescription based on the morphological type described in Haynes & Giovanelli (1984) and the i-band ellipticity given in Cortese et al. (2012a).

  • Column 14: Heliocentric radial velocity (in km s-1), from Hi data when available, otherwise from NED.

  • Column 15: Cluster or cloud membership, from Gavazzi et al. (1999) for Virgo & Tully (1988) or Nolthenius (1993) whenever available, or from our own estimate otherwise.

  • Column 16: Code to indicate whether Hi data are available (1) or not (0).

  • Column 17: Code to indicate whether CO data are available (1) or not (0).

3. Observations

CO observations were carried out during four remote-observing runs from the Laboratoire d’Astrophysique de Marseille in spring 2008 and 2009 using the NRAO Kitt Peak 12 m telescope2. One hundred forty-one hours were allocated to this project, out of which ~20 h lost for bad weather conditions or technical problems. At 115 GHz [12CO(1–0)], the telescope’s half-power beam width (HPBW) is 55, which corresponds to 5.3 kpc at the average distance of 20 Mpc of the HRS galaxies. Weather conditions were fairly good, with typical zenith opacities of 0.15–0.25. The pointing accuracy was checked every night by broad band continuum observations of nearby planets or the radiogalaxy 3C273, with an average error of 5 rms. We used a dual-polarisation SIS mixer, with a receiver temperature for each polarisation of about Tsys = 300–400 K (in scale) at the elevation of the sources. We used a dual beam-switching procedure, with two symmetric reference positions offset by 4′ in azimuth. The backend was a 256 channel filter bank spectrometer with channel width of 2 MHz. Each six-minute scan began by a chopper wheel calibration on a load at ambient temperature, with an OFF-ON-ON-OFF set of pointings for each scan. Galaxies were observed at their nominal coordinates listed in Table 1. Fifteen objects with an optical diameter exceeding three arcminutes were also mapped along the major axis, with two one-beam off positions. The face-on galaxy HRS 42 (NGC 3596) was observed along a cross with one beam offset. The total integration time was on average 120 min ON+OFF (i.e. 60 min on the source), yielding rms noise levels of about 3 mK (in the scale) after velocity smoothing to 15.7 km s-1. The baselines were flat owing to the use of beam-switching, thereby requiring only linear baselines to be subtracted. The antenna temperature was corrected for telescope and atmospheric losses. In the following analysis we use the scale. This scale can be transformed into the main-beam brightness temperature scale, Tmb, with /0.84 (where the main beam efficiency is ηmb = 0.54 and the forward scattering and spillover efficiency ηfss = 0.68). The scale can be converted into flux using 39 Jy/K.

Table 3

Independent observations of HRS 48 (NGC 3631).

4. Results

4.1. Results of our observations

The 12CO(1–0) spectra of all the observed galaxies, reduced with the CLASS package (Forveille et al. 1990), are shown in Fig. 1. The observational results are listed in Table 2. Of the 59 observed galaxies, 13 were not detected. Table 2 is arranged as follows:

  • Column 1: HRS name.

  • Columns 2 and 3: RA and Dec pointing offset, in arcsec.

  • Column 4: Detection flag, 1 for detected, 0 for undetected sources.

  • Column 5: Observing run: 1, 2 and 3 are for the three 2008 runs, 4 for the 2009 run.

  • Column 6: rms noise, in mK, on the scale, measured after the spectra are smoothed to a velocity resolution δVCO = 15.7 km s-1.

  • Column 7: Number of scans (ON+OFF). Each scan is six minutes long.

  • Column 8: Intensity of the I(CO) line () in K km s-1 (area definition), which corresponds to the area under the profile of the line measured in between the upper and lower limits in velocity within which the line is detected. Galaxies are considered as detected whenever the signal-to-noise, defined as is greater than 2, where ΔI(CO) is defined in Eq. (2). For undetected galaxies, the reported value is an upper limit determined as follows: (1)where σ is the rms noise of the spectrum, WHI the Hi line width, and δVCO the spectral resolution (here taken at δVCO = 15.7 km s-1). For galaxies with WHI unavailable, the Hi width has been determined assuming a standard WHI = 300sin(i) km s-1, where i is the galaxy inclination, with a minimum value of WHI = 50 km s-1 for almost edge-on systems.

  • Column 9: Error on the intensity of the CO line, ΔI(CO), computed as (2)where σ is the rms noise of the spectrum, WCO the CO linewidth (given in Col. 11), and δVCO the spectral resolution.

  • Column 10: Heliocentric velocity determined from the CO line (Gaussian fit), in km s-1 (optical definition v = cz = Δλ/λ0). The estimated error is comparable to the resolution, thus ~15 km s-1.

  • Column 11: Full width at zero level of the CO line, in km s-1, with an estimated error of ~20 km s-1. For galaxies with a suffix a the width of the CO line is the full width half maximum (FWHM) determined from a Gaussian fit. The width of the CO line generally corresponds to the width of the Hi line, indicated by the red horizontal line in Fig. 1.

  • Column 12: Peak temperature, in scale (K).

4.2. Uncertainty on the I(CO) data

In Col. 9 ΔI(CO) gives the error on the intensity of the CO line as determined from the typical rms of the observed galaxies. A different estimate of this uncertainty can be determined by comparing independent measurements of the same galaxy. All galaxies observed in this work are new CO observations and thus do not have any similar data in the literature. The only exception is HRS 48 (NGC 3631), observed at the beginning of each run for checking the tuning of the instrument on a CO-bright source and for testing the repeatability of the observations. We thus have three different CO observations of the same galaxy that can be compared. The same galaxy also has two other independent single-beam observations, one from the FCRAO survey (Young et al. 1995) and a second one from the CO survey of nearby galaxies done with the Onsala radio telescope by Elfhag et al. (1996). Table 3 gives the different I(CO) values obtained within our observing runs and in the literature. Given that the data obtained by the FCRAO (Young et al. 1995) and the Onsala surveys have been obtained in different beams and on different temperature scales, we also compare the total extrapolated CO fluxes obtained as described in the following sections. Table 3 shows that by using exactly the same telescope configuration we have differences from one to another observing run in the CO flux estimate of HRS 48 as large as 30%. The comparison with other data available in the literature, here done on the extrapolated CO fluxes of HRS 48 to remove any first-order dependence on the aperture correction and telescope temperature scale, gives differences with the mean value obtained in this work of the order of 8–13%. These differences are significantly smaller than those observed within our own independent data for the bright HRS 48. We recall, however, that for this particular object, our three independent observations were done with a significantly smaller number of scans (~6 scans each) than our typical observations of the other HRS galaxies (~20 scans). Given that the uncertainty on the CO intensity I(CO) depends on the rms of the spectrum (see Eq. (2)), we thus expect that for HRS 48, the quite large dispersion in our data is partly due to the low integration time. Table 3 shows, however, that the difference between our own observations of HRS 48 are larger than the expected uncertainties. Given the peaked distribution of the emitting molecular gas in galaxies, it is conceivable that small pointing offstes can be the origin of this discrepancy. In other words, the relation given in the previous section to estimate the uncertainty on single-beam observations slightly underestimates ΔI(CO). The error on the CO central beam observations done in this work should thus be of the order of 30%.

5. CO data from the literature

5.1. Unit transformation

The 12CO(1–0) data available in the literature come from a wide variety of references and for this reason are often given on different scales, as summarised in Table 4. Data coming from the FCRAO telescope are generally presented on the scale (observed source antenna temperature corrected for atmospheric attenuation, radiative loss, and rearward scattering and spillover), those from the 12 m Kitt Peak telescope on the scale (observed source antenna temperature corrected for atmospheric attenuation, radiative loss, and rearward and forward scattering and spillover), while those from the IRAM 30, the SEST, and the Onsala telescopes on the Tmb scale (source brightness temperature as measured by the main diffraction beam of the telescope). The different temperature scales can be transformed into a common scale following the prescription of Kutner & Ulich (1981). The temperature can be transformed into the antenna temperature as (3)where ηfss is the forward spillover and scattering efficiency, while the main beam temperature can be obtained as (4)where ηmb is the main beam efficiency. For the definition of a complete and consistent set of data for the HRS galaxies it is thus necessary that all these observations are homogenised on a commun scale. We thus decided to provide, for all galaxies, 12CO(1–0) fluxes in units of Jy km s-1. For a source with a Gaussian profile observed with a Gaussian beam of similar size, the constant necessary to transform main beam temperatures (in K) into fluxes (in Jy) is given by the relation (Wilson et al. 2009): (5)where θ is the FWHM of the beam and ν is the frequency. For sources extended with respect to the beam, as is the case for all HRS galaxies, the transformation of main beam temperatures into Jy is much more complex and requires the antenna pattern and the distribution of the emitting source (Wilson et al. 2009). Since a priori the CO distribution of the emitting galaxies within the antenna pattern is unknown, astronomers generally transform antenna temperatures into CO fluxes using a constant whose typical value for each telescope, determined with Eq. (5), is listed in Table 4. For consistency with previous works, however, we adopt the same constants as used in the literature and as given in the original references where the CO data have been published. We prefer to use the values published in the original references just to make it easy any direct comparison with the already published data. These conversion constants might differ slightly (15%) from those given in Table 4, which are mean values determined for galaxies at redshift z = 0.

Table 4

Main parameters of the different radio telescopes.

Table 5

Best fit to the relations between integrated CO fluxes: SCOy = a × SCOKuno + b.

5.2. Integrated data of mapped galaxies

5.2.1. Total CO fluxes

Some of the 225 HRS galaxies with CO data have been completely mapped either with a multibeam detector or in interferometric mode and have thus high-quality integrated CO fluxes. Of these, 18 objects have been observed by Kuno et al. (2007) with the 25 beams BEARS array mounted on the 45 m Nobeyama Radio Observatory telescope, 19 objects by Chung et al. (2009a) with the 16 beams SEQUOIA array on the 13.7 m FCRAO radio telescope, and 2 other galaxies with the IRAM 30 m radio telescope by our team (see below). Ten galaxies have also been observed during the BIMA SONG survey of nearby galaxies with the Owens Valley Radio Observatory in interferometric mode by Helfer et al. (2003). To these, we can add 71 galaxies observed along the major axis during the FCRAO CO survey of nearby galaxies by Young et al. (1995). Another object, NGC 4565, has also been partly mapped with the IRAM 30 m (Neininger et al. 1996) and with the 45 m Nobeyama (Sofue & Nakai 1994) radiotelescopes. Because of the complete coverage of the stellar disc, in particular for the single-dish observations done at the Nobeyama, IRAM, and FCRAO radio telescopes, we consider that all these data are of much higher quality than other single-beam observations that require aperture corrections. We thus decided to use mapped observations whenever possible instead of single beam data.

A few of these objects have integrated data taken by more than one survey. We compared the different sets of data to isolate those that we consider of higher quality. To do that, we cross-matched the different surveys, including galaxies outside the HRS sample (22 extra objects) to increase the statistics, and compared the different sets of data in Fig. 1. All data were first transformed into CO fluxes (in Jy km s-1) using the prescriptions indicated in the original papers for a correct comparison. For the FCRAO data of Young et al. (1995) we used the extrapolated SCO fluxes provided in this reference in the comparison. Figure 1 shows that the multibeam observations of Kuno et al. (2007) and those obtained by our team using the IRAM radio telescope agree within 20% (SCOKuno/SCOIRAM = 0.83 ± 0.03), while a certain scatter is present when the data of Kuno et al. (2007) are compared with those obtained by the other teams. All the other datasets give SCO fluxes that are generally smaller than those of Kuno et al. (2007). The difference between the Kuno et al. (2007) and those obtained by the other surveys does not seem to depend on the total flux of the emitting sources, with the exception of the BIMA SONG data of Helfer et al. (2003). Here there is a clear deviation from the one-to-one relation at high SCO fluxes, that could be easily ascribed to a non complete coverage of the stellar disc in the more extended sources combined with a slightly lower sensitivity to the diffuse emission of interferometric observations with respect to the multibeam observations done by Kuno et al. (2007). The difference with Chung et al. (2009a) might also come from a higher sensitivity of the Nobeyama radio telescope with respect to the FCRAO. The difference with the SCO fluxes of Young et al. (1995) probably comes from the rough extrapolation technique applied to the major axis CO data. The difference between these two sets of data is, however, remarkably small, indicating that overall the total SCO flux of spiral galaxies can be fairly well deduced using a very simple observing technique combined with an appropriate aperture correction.

This observational evidence suggests that the set of data of Kuno and collaborators be considered as reference, and the others be corrected using best fitting relations to minimise the scatter in the comparison with Kuno et al. (2007). To avoid any systematic effect in the correction due to size, we fit the Helfer et al. (2003) and Young et al. (1995) vs. Kuno et al. (2007) CO flux relations using only CO data in the range 100 < SCO < 5000 Jy km s-1, which is the range in the CO flux covered by the HRS galaxies. No restriction in the Chung et al. (2009a) data is required given that the fluxes of all their galaxies are within this range. The best linear fits to the data, shown in Fig. 1, are given in Table 5.

For the Young et al. (1995) data, however, the proposed correction does not significantly decrease the mean ratio and the scatter in the SCOKuno/SCOYoung(corrected) ratio. Indeed, the mean ratio SCOKuno/SCOYoung determined using the full set of original data published by Young et al. (1995) for all galaxies in common between these two surveys is SCOKuno/SCOYoung = 1.10 ± 0.44, while the one determined using the corrected data is SCOKuno/SCOYoung(corrected) = 0.90 ± 0.34. The majority of the HRS galaxies mapped by Young et al. (1995) without any other higher quality data from Kuno et al. (2007), Helfer et al. (2003), or Chung et al. (2009a), however, have only three detected beams along the major axis, and their total CO flux is SCOKuno < 5000 Jy km s-1. If we restrict the comparison of the Young et al. (1995) and Kuno et al. (2007) data to the subsample of HRS galaxies in common, the ratio determined with the originally published data, SCOKuno/SCOYoung = 1.29 ± 0.51, can be compared to that determined using the corrected data, SCOKuno/SCOYoung(corrected) = 1.33 ± 0.55. The proposed correction does not introduce any significant improvement in the data. We thus decided not to apply any correction to the FCRAO Young et al. (1995) data of the HRS galaxies.

thumbnail Fig. 2

Comparison between the integrated SCO flux determined by Kuno et al. (2007) and those determined by Helfer et al. (2003; red filled dots), Chung et al. (2009a; blue filled triangles), corrected as described in the text, and the extrapolated fluxes of the FCRAO survey (Young et al. 1995; cyan empty circles), for all HRS galaxies in common, on logarithmic (upper panel) and on linear scales (lower panel). The short dashed black line shows the 1:1 relationships.

Open with DEXTER

Figure 2 shows the relationship between the different integrated CO fluxes corrected using the prescriptions given in Table 5 and those of Kuno et al. (2007) for the HRS galaxies with 100 < SCO < 5000 Jy km s-1. Given the dispersion in the corrected relations seen in Fig. 2 and in Table 5, we decided to take the Kuno et al. (2007), Helfer et al. (2003), Chung et al. (2009a), and Young et al. (1995) data in order of priority (whenever multiple datasets are available)3. The quality of the FCRAO data of Young et al. (1995), however, strongly depends on the number of detected beams along the major axis. When only three beam observations are available, the comparison with the Kuno et al. (2007) data indicates that the dispersion in the relation is higher than that we obtained using only the central beam, and we extrapolated it using our own prescriptions (see below). We thus decided to use the extrapolated CO fluxes of Young et al. (1995) only when more than three detections along the major axis are available; otherwise, we consider the galaxies as observed only in the central beam and measure their total emission using our own prescriptions.

We thus end up with 37 HRS galaxies with integrated data, 17 from Kuno et al. (2007), 0 from Helfer et al. (2003)4, 6 from Chung et al. (2009a), and 13 from Young et al. (1995). To these we can add a galaxy, NGC 4565 (HRS 213), partly mapped by Neininger et al. (1996) with the IRAM radiotelescope and by Sofue & Nakai (1994) with the Nobeyama radiotelescope. By correcting their own independent sets of data to extend the measure of the CO flux to the whole galaxy, they end up with a total flux of SCO = 1672.2 Jy km s-1 and SCO = 1643 Jy km s-1, respectively. There is also an earlier estimate of the CO flux of this galaxy by Richmond & Knapp (1986) from observations taken with the Bell Laboratories radiotelescope, which gives SCO = 4487 Jy km s-1. Our own estimate based on the extrapolation of the central single beam as described in Sect. 5.3, gives SCO3D = 1550 Jy km s-1, a value much closer to the estimates of Neininger et al. (1996) and Sofue & Nakai (1994). We thus decided to take for this object SCO = 1672.2 Jy km s-1.

5.2.2. Uncertainties on integrated data

Table 5 and Fig. 2 can also be used to estimate the typical uncertainty on the integrated data. The comparison between Kuno et al. (2007) with our own observations of two HRS galaxies done with the IRAM radio telescope indicates that SCOKuno/SCOIRAM = 0.83 ± 0.03. Despite the lack of statistics, this comparison indicates that the two sets of data are consistent within ~17%. This uncertainty should be shared between the two different sets of data. The uncertainty on the Kuno et al. (2007) CO fluxes is thus assumed to be of the order of 12%. The uncertainty in the Helfer et al. (2003) data is also comparable. The one in the Chung et al. (2009a) data is ~40%, while in the Young et al. (1995) extrapolated data slightly larger (~45%). It is hard to estimate the uncertainty on the CO flux of NGC 4565 given that the three independent measurements come from the extrapolation of observations of a fraction of this edge-on galaxy. Two independent measurements are consistent within 2%, and the third one is different by a factor of ~3. We thus arbitrarily assume for this source an uncertainty of ~30%.

5.3. Single-beam observations of the centres of galaxies

5.3.1. Extrapolation of the central beam

The majority of the 225 HRS galaxies with CO data have only one single-beam observation in their central position. For these objects the beam of the telescope does not necessarily cover the whole surface of the stellar disc. These CO data must thus be corrected for aperture effects to derive total CO fluxes of the observed galaxies. The extrapolation of the central beam observation can be done using either empirical relations calibrated on nearby mapped galaxies or analytic functions known to reproduce the radial distribution of the CO emission well. The first method has been proposed by Saintonge et al. (2011), who simulated the observation of the galaxies mapped by Kuno et al. (2007) with Gaussian beams of different sizes. Using this technique, the total CO flux SCOSaintonge(tot) of a galaxy with a central beam flux SCO(CB) is given by the relation (6)where N.Beam is the size of the galaxy in number of beams: (7)with D25(B) the 25 mag arcsec-2 isophotal B-band diameter5, and θ the FWHM of the beam of the radiotelescope (see Table 4), both measured in arcseconds.

The second approach has recently been proposed by Lisenfeld et al. (2011). Considering that the CO emission of nearby mapped galaxies is represented well by an exponential disc of scale length rCO: (8)where SCO(0) is the CO emission in the centre of the galaxy. The total CO flux of an exponential disc is given by the relation: (9)As discussed in Lisenfeld et al. (2011), the scale length of the CO emitting disc, rCO, is correlated well with the optical scale length of the stellar disc and with r25, the optical 25 mag arcsec-2 isophotal radius6. The observations of the THINGS sample of nearby objects done by Leroy et al. (2008) indicates that, on average, rCO/r25 = 0.2. Lisenfeld et al. (2011) derive a consistent value using different sets of data, from the BIMA SONG survey of Regan et al. (2001), to the sample of Nishiyama & Nakai (2001) observed with the Nobeyama radiotelescope, to the FCRAO galaxies mapped by Young et al. (1995) along the major axis. The CO emission of the observed galaxies within the central beam can be determined by convolving the CO intensity profile with a Gaussian beam: (10)where i is the inclination of the disc. The integral given in Eq. (10) can be solved numerically, and SCO(0) can be determined by comparing Eq. (10) with the CO flux observed in the central beam. With Eq. (9), it can be used to derive the total SCO2D(tot) of the observed galaxies.

thumbnail Fig. 3

Definition of the referential of the galaxy (black) and that of the observer (red) in the case of a face-on (left) and an edge-on (left) galaxy. The referential of the observer corresponds to the referential of the galaxy rotated by angle i around the x axis.

Open with DEXTER

Table 6

Disc scale height for edge-on galaxies.

Our sample includes a large number of edge-on galaxies such as NGC 4565. For these objects the integral given in Eq. (10) does not consider that the molecular gas disc also has a given thickness in the z direction orthogonal to the plane of the disk. We thus modify the prescription of Lisenfeld et al. (2011) to take into account that the molecular gas disc has a 3D-distribution. Consistently with what is generally assumed for the dust distribution in edge-on galaxies (Xilouris et al. 1999; De Looze et al. 2012), we assume an exponential distribution even in the z direction: 11where zCO is the scale height of the disc. The total CO flux is then (12)To compute the total CO flux of the galaxy, we first compute the flux detected in the central beam. We do so in the referential of the observer defined by the orthogonal axes x, y, and z, where the last is the coordinate along the line of sight (Fig. 3). The referential of the observer corresponds to the referential of the galaxy rotated by angle i. We obtain the following equation in cartesian coordinates: (13)Mapped CO observations of edge-on galaxies are needed to estimate the typical scale height of the CO disc in spirals. NGC 891 is the only edge-on galaxy fully mapped in the 12CO(1–0) line (Scoville et al. 1993; Yim et al. 2011). The most recent BIMA-SONG observations of this object have revealed that the scale height of the CO disc is zCO ≃ 0.185 kpc (Yim et al. 20117) or, equivalently, zCO/r25 ~ 1 /101. Previous observations of the same galaxy have given a z-scale ranging from 0.160 kpc in the nucleus to zCO = 0.276 kpc at the edge (Scoville et al. 1993). To check whether these values of zCO are representative of normal, spiral galaxies, we compared them to the typical scale height of the dust component of other edge-on galaxies. Indeed, given the tight correlation between dust and molecular gas, we can reasonably assume that the thickness of the dusty disc is comparable to that of the molecular gas. The scale height of the dust disc can be measured using either far-infrared (dust in emission) or optical (dust in absorption) images. From the analysis of the Herschel/SPIRE images of the same galaxy, Bianchi & Xilouris (2011) have determined that zdust = 0.200 kpc, consistently with zCO ≃ 0.185 kpc determined by Yim et al. (2011). Using energy transfer models adapted to reproduce the far-infrared emission observed by Herschel of the edge-on galaxy NGC 4565, De Looze et al. (2012) derive zdust = 2.5 arcsec, corresponding to zdust/r25 ~ 1/194. The analysis of the optical images of seven nearby edge-on galaxies done by Xilouris et al. (1997, 1999) gives values of zdust/r25 ranging from 1/50 to 1/184, as summarised in Table 6. The mean value determined from all these data is zdust/r25 ≃ 1/99, consistent with zCO/r25 ~ 1/101 determined by Yim et al. (2011) in NGC 891. A similar value (zdust/r25 = 1/108) has been also obtained from the direct analysis of seven edge-on galaxies observed by Herschel (Verstappen et al. 2013). Since r24.5(g) ≃ r25(B), we assume zCO/r25(B) = zCO/r24.5(g) = 1/100.

To understand which among these three different recipes is considered the most likely to estimate the total CO emission of galaxies, we applied them to all the objects observed by Kuno et al. (2007) for which single-beam observations are available and compared the extrapolated fluxes to those measured using the CO maps.

thumbnail Fig. 4

Comparison of single-beam observations corrected for aperture effects using the prescription based on a 3D-distribution of the molecular gas (Eq. (11); left panels) and that of Saintoinge et al. (2011) (Eq. (6); right panels) on logarithmic (upper panels) and linear (in the range 0–5000 Jy km s-1 sampled by the HRS galaxies) scales (lower panels) for galaxies with integrated data from Kuno et al. (2007). Different symbols are used for galaxies observed in the FCRAO survey of Young et al. (1995; cyan), Stark et al. (1986; magenta), and other references (black). Filled dots are for galaxies with D25(B)/θ ≤ 5, empty symbols for those objects with D25(B)/θ > 5. The short dashed black line shows the 1:1 relationships.

Open with DEXTER

Figure 4 shows the relationship between the CO fluxes extrapolated from central-beam observations as described in this text and the total CO fluxes given in Kuno et al. (2007) for those galaxies with single-beam observations available in the literature. The comparison uses the extrapolation prescription proposed by Saintonge et al. (2011) (Eq. (6), right panels) and the one proposed in this work based on a 3D-distribution of the molecular gas (Eq. (11)). The extrapolation recipe proposed by Lisenfeld et al. (2011) gives basically the same results as the one proposed in this work, with the exception of edge-on galaxies where it underestimates the total CO flux by a few percent (see Fig. 5).

Table 7

Comparison between extrapolated single-beam observations and integrated fluxes from Kuno et al. (2007).

Table 8

Total CO emission of edge-on galaxies.

Figure 4 and Table 7 show that both the 2D- (Eq. (8)) and the 3D- (Eq. (11)) analytic prescriptions given above are more appropriate than the empirical relation of Saintonge et al. (2011). Indeed this last recipe systematically underestimates the total CO flux whenever the beam size of the telescope is smaller than one fifth of the optical diameter of the target (empty symbols). We have also tested whether the use of a slightly differenty exponential disc scale lengths in Eqs. (8) and (11) gives better agreement between the CO fluxes extrapolated from the central-beam observations and the integrated values of Kuno et al. (2007). Using a higher rCO/r24.5 ratio than the canonical value of 0.2 indicated by Lisenfeld et al. (2011) leads to ratios SCO3D/SCOKuno ≃ 1 in those galaxies with SCOKuno < 5000 Jy km s-1, but at the same time systematically overestimates SCO3D(tot) in the brightest galaxies. We thus decided to adopt the correction given in Eq. (11), keeping rCO/r24.5 = 0.2 for all galaxies with only one single-beam observation.

We can also check whether the assumption of a 3D molecular gas disc with zdust/r24.5 ≃ 1 /100 is appropriate for extrapolating single-beam observations of edge-on galaxies. To do that, we extrapolate all single-beam observations of nearby edge-on galaxies with data available in the literature for which accurate estimates of the total CO emission are available from complete or partial CO mapping (see Table 8). Table 8 indicates that, despite the large difference either in the CO fluxes of the central beam observations or in those determined from interferometry, partially mapped or major axis mapped edge-on galaxies, the total CO fluxes determined using the prescriptions given in this work in Eq. ((8); 2D) or Eq. ((11); 3D) are close to the broad range of observational data. Equation (8) gives, as expected, slightly lower values (a few per cent) than Eq. (11) just because it assumes an infinitely thin disc in the z direction (see Fig. 5). The comparison between aperture-corrected and total CO fluxes given in Table 8 suggests that the 2D extrapolations underestimate the total CO emission more than the 3D one does (but only by a few%). We thus decided to prefer and adopt the 3D recipe given in Eq. (11) in this work.

5.3.2. Uncertainties on single beam extrapolated data

By comparing the flux extrapolated from single-beam observations to the integrated value for galaxies in the Kuno et al. (2007) sample, we can quantify the typical uncertainty in the total CO emission due to a combined effect of the uncertainty on the I(CO) measurement and of the aperture correction. Figure 6 shows the relationship between the ratio of the total CO flux as determined from the 3D-extrapolation of the central-beam observation to the total value determined from the maps for galaxies in the Kuno et al. (2007) sample as a function of the surface of the galaxy covered by the telescope beam. Figure 6 shows that whenever the beam covers more than 10% of the surface of the disc, the mean uncertainty in the total, extrapolated CO flux is of the order of 44% (SCO3D/SCOKuno = 1.01 ± 0.44). In the remaining galaxies, where the beam covers less than 10% of the surface of the galaxy, the mean uncertainty in the total CO flux estimate is as large as 123% (SCO3D/SCOKuno = 1.46 ± 1.14).

thumbnail Fig. 5

Relationship between the ratio of the 2D (Eq. (9)) vs. 3D (Eq. (12)) aperture corrections SCO2D/SCO3D and the ratio of the molecular gas scale height of the disc to the beam size zCO/θ for the HRS galaxies of the sample. Black open circles are for galaxies with an inclination 80 deg, red symbols for edge-on systems (i > 80 deg). The black solid line gives the relation determined for model edge–on galaxies.

Open with DEXTER

thumbnail Fig. 6

Relationship between the ratio of the total CO flux as determined from the extrapolation of the central beam observation to the total value determined from the maps for galaxies with integrated data from Kuno et al. (2007) as a function of the filling factor ff, defined as the fraction of the galaxy covered by the central beam (lower panel). Different symbols are used for the galaxies observed in the FCRAO survey of Young et al. (1995; cyan), Stark et al. (1986; magenta) and other references (black). Filled dots are for galaxies with D25(B)/θ ≤ 5, empty symbols for those objects with D25(B)/θ > 5. The solid line shows the one ratio, the long dashed lines the typical 1σ uncertainty (44%) for galaxies where the beam size covers more than 10% of the total optical surface of the galaxy, the dotted line 1σ uncertainty (123%) for galaxies where the beam size covers less than or equal to 10% of their surface. The upper panel shows the distribution in the area covered by the central beam for all HRS galaxies with available CO data (black histogram). The blue histogram gives the distribution of all galaxies observed by our team, including previous data (Boselli et al. 1995, 2002; Sauty et al. 2003), while the red one only those observed in this work.

Open with DEXTER

5.4. Multiple beam observations

Some HRS galaxies have multiple observations along the major axis. These data can be combined and extrapolated to determine total CO luminosities as done with different techniques found in the literature. Typical examples are the method of Solomon & Sage (1988) or that of the FCRAO team (Young et al. 1995). While the former use different polynomials to combine the emission in the different beams, the latter use the radial variation in the CO emission to deduce a CO profile (exponential, Gaussian, etc.) that is later used to fit and extrapolate the observations. More recently, Saintonge et al. (2011) have proposed a very simple prescription previously determined by simulating the observation through two adjacent beams (one central, the second one beam off-centre) of the Kuno et al. (2007) sample of mapped galaxies. The simulations have been done using beams of different sizes. Multiple beam observations of the HRS galaxies come mainly from the FCRAO survey of Young et al. (1995), with a few from our own observations. As previously discussed, the FCRAO gives quite accurate extrapolated fluxes for these objects, values that we adopt here. There are, however, a few objects with only two or three detected beams along the major axis, where the extrapolation of the FCRAO is not very accurate. This is probably because, with such a small sampling, it is hard to accurately deduce a radial profile of the CO emission. Eighteen HRS galaxies have two or three detections along the major axis (from the FCRAO survey, 4, and from our own observations presented in this work, 14). It is thus worth understanding whether this radial information can be used to constrain the distribution of the molecular gas along the disc better and thus allow more accurate determination of the total CO emission. To do this we applied an updated version of the technique used by the COLD GASS survey (Saintonge et al. 2011) for galaxies observed in the central position (SCO(CB)) and in an adjacent beam (SCO(adj)) along the major axis. Following this technique, the total CO flux of the galaxy is given by the relation (14)where fOFF is the ratio of the flux measured in the two beams:

thumbnail Fig. 7

Comparison of multiple beam observations along the major axis corrected for aperture effects using the prescription based on a 3D-distribution of the molecular gas and assuming only the central beam (Eq. (11); left panels) and that of Saintoinge et al. (2011) (Eq. (13); right panels) on logarithmic (upper panels) and linear (in the range 100–5000 Jy km s-1 sampled by the HRS galaxies) scales (lower panels) for galaxies with integrated data from Kuno et al. (2007). Different symbols are used for galaxies observed in the FCRAO survey of Young et al. (1995; cyan), Stark et al. (1986; magenta) and other references (black). Filled dots are for galaxies with D25/θ ≤ 5, empty symbols for those objects with D25/θ > 5. The short dashed black line shows the 1:1 relationships.

Open with DEXTER

Table 9

Comparison between total CO fluxes extrapolated using the 3D aperture correction using only the central beam proposed in this work (Eq. (11)) and the Saintonge et al. (2011) multiple-beam prescriptions (Eq. (13)) for galaxies in the Kuno et al. (2007) sample.

(15)where SCOSaintongeMB(tot) stands for the total, extrapolated CO flux determined from multiple beam observations. The variable fOFF gives an empirical estimate of the slope of the radial variation of the CO emission. We then compared the total CO fluxes determined using this relation with the integrated fluxes of Kuno et al. (2007) in Fig. 7. Different and independent sets of data are available from the FCRAO survey of Young et al. (1995), from Stark et al. (1996), from this work, and from several other references in the literature. Table 9 gives for comparison the mean values of the ratio SCO3D/SCOKuno and SCOSaintoingeMB/SCOKuno for those galaxies in the Kuno et al. (2007) sample with multiple beam observations along the major axis. Figure 7 and Table 9 indicate that the CO fluxes extrapolated using Eq. (11), hence not taking the CO observations along the major axis into account, are on average more accurate than those extrapolated using the multi-beam prescription of Saintonge et al. (2011). These last, indeed, generally underestimate the total CO emission of the observed galaxies, while the 3D extrapolation is quite accurate if the size of the galaxy does not exceed about five times the FWHM of the telescope beam. Most of the galaxies of the HRS, and in particular those observed in this work, match this condition. We thus adopted a 3D-extrapolation correction also for these objects with two- or three-beam observations along the major axis.

5.5. The homogenised CO data catalogue

Single-beam observations of HRS galaxies are available from different references in the literature or from our own observations, including those presented in this work. Several objects have multiple, independent observations. Overall there are 344 independent pointings on 225 HRS galaxies. We have collected all these data and listed them in Table 10, arranged as follows

  • Column 1: HRS name.

  • Column 2: Telescope coded as in Table 4.

  • Column 3: Number of independent beams for this reference.

  • Column 4: Beam size θ, in arcseconds.

  • Column 5: Sign for the observation: 1 for detected sources, 0 for undetected objects.

  • Column 6: Intensity of the CO line in the central beam, in K km s-1, on the temperature scale (listed in Col. 9) as indicated in the original paper where the data are presented. No intensities are given for undetected galaxies.

  • Column 7: rms the observations, in mK, expressed on the temperature scale as indicated in the original paper where the data are presented (Col. 9).

  • Column 8: Velocity resolution of the smoothed CO spectra, in km s-1.

  • Column 9: Temperature scale.

  • Column 10: Reference to the data.

  • Column 11: Jy/K calibration constant used to transform temperature brightnesses into CO fluxes. These might differ from those reported in Table 4 if the CO intensities are expressed on other scales than those generally used for the telescope, or if the authors expressely indicate different calibration factors in their original papers.

  • Column 12: Extrapolated CO flux SCO3D, or upper limit, in Jy km s-1. CO intensities measured in the central beam, and upper limits are extrapolated to total values using Eq. (11). Upper limits in the central beam are determined as described in Sect. (3; Eq. (1)).

  • Column 13: Filling factor of the central beam, defined as the ratio of the surface covered by the beam of the telescope to the optical area of the galaxy.

  • Column 14: A flag indicates those data used for measuring the total CO emission of HRS galaxies (flag = 1) or those not used (flag = 0).

  • Column 15: Notes to single-beam observations. 1: Assumed in . 2: Transformed from the original table to this scale. 3: Partly mapped galaxy, with an equivalent beamsize assumed to be θ = 36 arcsec.

This new set of extrapolated data are then cross-matched with those with available complete mapping (see Sect. 5.2) to select the best available data. Total CO emission from mapped galaxies are taken in the order described in Sect. 5.2. If no integrated CO data are available, the total SCO emission is taken from extrapolated single-beam observations. When, for the same galaxy, different sets of data are available, we give the mean value determined by combining detections. If detections and undetections are available for the same object, we check that the detections are consistent with the upper limits, and give the detection as final result.

Multiple central-beam observations are useful for inferring a realistic uncertainty on the extrapolated CO emission of the HRS galaxies. For those objects with multiple observations, we quantify the uncertainty by measuring the standard deviation from the mean value determined using only detections. When the uncertainty drops to values lower than 20%, we assume a conservative error of 20%. For galaxies with available integrated CO maps from the literature, we assume the standard uncertainties determined as described in Sect. 5.2 for the different references. For those with only one central beam detection available, we assume a mean uncertainty determined as described in Sect. 5.3 according to the correction factor, namely 44% if the surface of the beam covers more than 10% of the total surface of the galaxy, 123% if the sampled area is smaller. Figure 8 shows the ratio of the central beam to the extrapolated CO fluxes, which corresponds to the aperture correction, as a function of the surface of the galaxy covered by the telescope beam (filling factor ff in Table 11). Figure 8 shows that most of the galaxies observed in this work or by our team in previous observing runs (Boselli et al. 1995, 2002) have been covered by the beam of the telescope by more than 10% of their surface, thus have relatively low errors in the extrapolated CO flux.

thumbnail Fig. 8

Relationship between the ratio of the central beam to total extrapolated CO flux ratio (aperture correction) as a function of the filling factor ff, defined as the fraction of the galaxy covered by the central beam for all the HRS galaxies with available single-beam observations (lower panel). Red symbols are for those galaxies observed in this work, blue symbols for other objects observed by our team in previous surveys, while the remaining black circles those with data available in the literature. The upper panel shows the distribution in the filling factor for all the HRS galaxis observed in CO. The blue histogram gives the distribution of all galaxies observed by our team, including previous data (Boselli et al. 1995, 2002; Sauty et al. 2003), while the red one only those observed in this work.

Open with DEXTER

thumbnail Fig. 9

CO data of the HRS galaxies observed in this work, in order of increasing HRS name. Left: the r-band SDSS image of the observed galaxies with superimposed the position covered by the beam of the telescope (red solid line). Right: observed 12CO(1–0) spectra smoothed to a velocity resolution of 15.7 km s-1. Intensities are in scale.

Open with DEXTER

The final results are given in Table 11, arranged as follows:

  • Column 1: HRS name.

  • Column 2: Sign for the observation: 1 for detected sources, 0 for undetected objects.

  • Column 3: SCO flux, in Jy km s-1.

  • Column 4: Error on the SCO flux, in Jy km s-1.

  • Column 5: Signal-to-noise S/N, defined as the ratio of the total CO flux to the uncertainty in the CO line, this last defined as in Col. 9 of Table 2. The S/N is given only for galaxies with single-beam observations.

  • Column 6: Filling factor ff, defined as the ratio of the surface covered by the beam of the telescope to the optical area of the galaxy.ff = Int indicates galaxies with CO integrated maps, ff = MA, those objects mapped along the major axis with more than three detected beams (fron the FCRAO survey).

  • Column 7: Logarithm of the molecular hydrogen mass, M(H2)c, determined assuming the standard Galactic conversion factor XCO = 2.3 × 1020 cm-2/(K km s-1) (Strong et al. 1988). The molecular hydrogen mass of galaxies (in solar units) is determined from the relation: (16)where D is the diatance (in Mpc) given in Table 1.

  • Column 8: Logarithm of the molecular hydrogen mass, M(H2)v, determined by assuming the H-band luminosity dependent conversion factor log XCO = −0.38 × log LH + 24.23, where XCO is in cm-2/(K km s-1) and LH in solar units (Boselli et al. 2002).

  • Column 8: References to the CO data.

6. HI data

The Hi integrated data are available for 315 out of the 322 HRS galaxies. We collected them from a wide variety of references in the literature. Among these, we have favored those coming from the Hi survey ALFALFA (Giovanelli et al. 2005) and recently published in Haynes et al. (2011). An important fraction of the HRS galaxies is not observable from Arecibo. For these galaxies, we preferred the homogenised data of Springob et al. (2005), then those available in the literature by chosing those with the highest S/N, lower rms, or with available spectra in the published papers. The Hi data for the HRS are given in Table 12, arranged as follows

  • Column 1: HRS name.

  • Column 2: Sign for the observation: 1 for detected sources, 0 for undetected objects.

  • Column 3: rms, in mJy. Not all references in the literature give this entity, thus the rms is available only for a (large) portion of the HRS galaxies.

  • Column 4: Hi flux SHI, in Jy km s-1. For undetected galaxies, the SHI is an upper limit to the Hi flux, defined as (17)where WHIexp = 300 km s-1 is the expected Hi line width of the observed galaxy.

  • Column 5: Logarithm of the Hi mass, in M, determined from the relation: (18)where the distance D, expressed in Mpc, is taken from Table 1. The typical uncertainty on the Hi mass is 15%.

  • Column 6: Hi line width WHI measured at 50% of the peak flux, in km s-1, corrected for instrumental broadening and cosmological redshift as in Catinella et al. (2012). Observed WHIo are corrected following the relation: (19)where the broadening correction Δs is given by (20)where δVHI is the velocity resolution. The ALFALFA data have been corrected using a different prescription. To have homogenised data, we removed the ALFALFA correction and applied consistently the correction given in Eqs. (18), (19). For some galaxies, the data presented in the original papers cannot be homogeneously corrected using this prescription (line width measured not at 50% of the intensity peak, lack of any information on the velocity resolution in the data). For these galaxies, we report the value given in the literature, but not corrected for broadening and cosmological redshift. These galaxies can be recognised by the flag given in Col. 8.

  • Column 7: Hi-deficiency parameter (HI-def), defined as the difference in logarithmic scale between the expected and the observed Hi mass of a galaxy of given angular size and morphological type (Haynes & Giovanelli 1984). The Hi-deficiency for all the HRS galaxies is determined using the recent calibration of Boselli & Gavazzi (2009).

  • Column 8: Flag for the WHI line width measurement: “1” corrected for broadening and cosmological redshift; “2” uncorrected values.

  • Column 9: Reference to the Hi data.

7. Conclusion

We have presented new 12CO(1–0) observations of 59 late-type galaxies of the Herschel Reference Survey done with the 12 m Kitt Peak radiotelescope. By comparing the total CO emission of fully mapped nearby galaxies, including edge-on systems, to CO fluxes corrected for aperture effects using different prescriptions developed in this work or proposed in the literature, we identified the most accurate recipe for extrapolating central single-beam observations of extended galaxies. The central-beam observation was corrected for the Gaussian shape of the beam and extrapolated assuming a 3D exponential distribution of the molecular gas. The typical scale length of the CO emitting disc is rCO = 0.2r24.5, where r24.5 is the optical, g- (or B-band) isophotal radius at the 24.5 mag arcsec-2 (25 mag arcsec-2), while its scale height is zCO = 1/100r24.5. This scale height was calibrated on well known nearby edge-on systems and is comparable to the typical scale height of the dusty disc observed either in absorption using optical images or in emission using far-infrared data.

We applied this new recipe to our new CO data and to all the CO data available in the literature to build the most complet set of molecular gas data for the HRS, which is now available for 225 out of the 322 objects composing the sample. We also collected and homogenise Hi data from the literature for 315 HRS galaxies. Both Hi and CO data are used to estimate the total Hi and H2 molecular gas content of the targets. All these data are available on an HRS-dedicated web page on the HeDaM database: http://hedam.lam.fr/. These data are used to study the molecular and total gas scaling relations of the HRS galaxies (Paper II) and the effects of the environment on the molecular gas phase by comparing the molecular gas content of isolated and Virgo cluster galaxies of the sample (Paper III).


1

With respect to the original sample given in Boselli et al. (2010a), we removed the galaxy HRS 228 whose new redshift indicates it as a background object. We also revised the morphological type for 6 galaxies: NGC 5701, now classified as Sa; NGC 4438 and NGC 4457, now Sb; NGC 4179, now S0; VCC 1549, now dE; and NGC 4691 now Sa.

2

The Kitt Peak 12-m telescope was operated by the Arizona Radio Observatory.

3

The only exception is the galaxy HRS 91, NGC 4192, for which we adopt the flux given in Young et al. (1995) since much closer to three independent estimates from single beam observations. The flux of Kuno et al. (2007) is indeed underestimated by a factor of 2, as indicated by the position that this galaxy would take in the vs. scaling relation given in Paper III.

4

All HRS galaxies in the BIMA SONG survey have been observed by Kuno et al. (2007).

5

For the sample of galaxies with integrated values in the literature used for comparing the different aperture corrections, is the -band isophotal diameter given in NED.

6

For the sample of galaxies with integrated values in the literature used for comparing the different aperture corrections, is the isophotal radius derived from the optical diameter given in NED, which generally corresponds to the -band isophotal diameter at 25 mag arcsec. For the HRS galaxies we use the -band isophotal radius given in Table 1.

7

The analytic function adopted in this work to reproduce the z-scale distribution of the molecular gas is Gaussian, not exponential, thus not directly comparable to the one adopted in this work.
