1. Introduction

Intermediate mass stars (1–8 M) undergo extreme mass loss during the late stages of their evolution. The mechanisms that dominate those stellar outflows are also responsible for shaping the ejecta. Hints of asymmetries are numerous in many stars characterising these late stages. Almost all of planetary and proto-planetary nebulae (Sahai et al. 2007) observed by the Hubble Space Telescope1 exhibit asymmetries in their shape, while bipolarity and equatorial dusty discs are very common as well.

Most proposed shaping mechanisms for bipolar nebulae involve binarity (Zijlstra 2007), since a source of angular momentum is required to drive the ejecta in directions perpendicular to the orbital plane. Interaction between the ejecta and the orbiting companion can lead to the formation of torii, discs and jets, the last perpendicular to the binary system’s plane. During common envelope evolution, accretion discs can be formed leading to the ejection of jets, thus forming bipolar nebulae (Soker & Livio 1994). Discs can be formed during wind accretion preceding common envelope stage as well (Mastrodemos & Morris 1998), but have too low a mass to be the direct cause of the shaping of the older nebula (Chesneau et al. 2007). The discs appear to be a remnant of the shaping process.

Discs are rather small in size (a few milliarcseconds), compared to the surrounding nebulae (many arcsecs), and their dust re-emits stellar radiation in the infrared. Observations of such small structures near evolved stars can only be performed with the use of high-angular resolution techniques like the infrared Very Large Telescope Interferometer (VLTI), i.e. planetary nebulae (Chesneau et al. 2006, 2007; Lagadec et al. 2006); VLTP star (Chesneau et al. 2009); Mira stars (Tatebe et al. 2006, 2007, 2008); carbon stars (Ohnaka & Boboltz 2008; Ohnaka et al. 2008; Sacuto et al. 2011; Deroo et al. 2007b); OH/IR stars (Deroo et al. 2007a,b; Chesneau et al. 2005b); post-AGB stars (Deroo et al. 2006; Matsuura et al. 2006); proto-planetary nebulae (Murakawa et al. 2008; Ohnaka et al. 2006). Two of the best-studied examples of elongated and axisymmetric bipolar planetary nebulae are M2-9 and Menzel 3. They present tightly pinched waists and symmetric lobes. They are also spectroscopic twins at visual and IR wavelengths (Smith  2003; Smith & Gehrz 2005). This paper focuses on M2-9. The lobes of the nebula extend up to 22″ at each side of the bright central core. Schwarz et al. (1997) found that the nebula has polar knots extending up to 52″ from the central source (core). The core is dominated by Hα emission scattered by dust in the visual, as well as free-free emission in radio (diameter  ≲ 3″).

A lighthouse beam is seen inside the bipolar lobes and a series of observations at different epochs revealed that it is a by product of the mechanism responsible for the shaping of the planetary nebula. The lighthouse effect was witnessed by knots in the nebula known as early as 1952 (Allen & Swings 1972), was monitored from 1989 to 2007, revealing a period of  ~100 years. This feature can be created by orbital motion and is the best evidence that the core engulfs a binary system. In addition to that, the high-excitation lines seen in M2-9 suggest that the illuminating source is a hot and compact star, i.e. a white dwarf (WD) (Schwarz et al. 1997; Lim & Kwok 2000; Livio & Soker 2001), not to be confused with the primary star whose ejecta now constitute the nebula. In such a scenario, dust originating from the primary will settle in the binary system’s orbital plane in the form of a disc, torus or spiral.

The distance of M2-9 is uncertain. Many authors quote a distance of 1000 pc in the absence of a tight constraint (Hora & Latter 1994; Livio & Soker 2001; Smith & Gehrz 2005). Schwarz et al. (1997) propose a much closer distance of 640 ± 100 pc, based on expansion parallax measurements of the outer lobes. We derive a larger distance in this paper, confirmed by Corradi (priv. comm.) who reanalysed the data of Schwarz et al. (1997). For all the mass estimates described below, the assumed distance2 was different from the one presented in this paper.

Bachiller et al. (1990) mentioned a total amount of molecular gas in the nebula higher than 10-3 MFeibelman (1984) gave a gaseous mass of 0.21 M and mass of dust 2.1 × 10-3 M for the entire nebula, but Lenzuni et al. (1989) estimated a higher total dust mass by IRAS observations (~5.4 × 10-3 M).

The core of M2-9 was resolved using millimetric interferometry (Plateau de Bure, 5″ × 3″ beam), showing that the molecular gas is distributed in a ring-like structure extended about 6″ east-west. A kinematical age  ~2100 years was derived from the expansion of the CO gas in the nebula (Zweigle et al. 1997).

Observations by Smith & Gehrz (2005) within the last decade showed that in the core the mass of warm gas is 9.2 × 10-4 M and that of warm dust 4 × 10-6 M, while in the lobes the mass of cold gas is 0.78 M and that of cool dust is 3.4 × 10-3 M.

We present observations of the core of M2-9 in the near- and mid-infrared (Sect. 2). We have detected a dusty disc in the core with the use of high-angular resolution techniques. The geometric constraints of the disc were defined with the use of radiative transfer models. Our results are presented in Sects. 3 and 4. A detailed discussion can be found in Sects. 5 and 6, where we elaborate scenarios on the disc’s structure. In Sect. 7, we compare our findings with the disc of Menzel 3. Our conclusions are in the final section.

2. Observations

2.1. VLTI

M2-9 was observed in the N band (7.5−13.5   μm) with MIDI (Leinert et al. 2003, 2004), the mid-infrared recombiner of the VLTI with the use of only two Unit Telescopes (UTs). We used a typical MIDI observing sequence as described in Przygodda et al. (2003). MIDI can make single-dish acquisition images with a field-of-view of about 3″ with a spatial resolution of about 0.25″ at 8.7 μm, and provides a flux calibrated spectrum at low spectral resolution (in this case R = 30) and several visibility spectra from the sources (Chesneau et al. 2005a,b), i.e. spectrally dispersed information on the spatial extension of the source. Only four visibility measurements could be obtained, due to bad weather conditions.

The observations of M2-9 with MIDI were performed in April, June and August 2007 and March 2008 in the so-called SCI_PHOT mode, meaning that the photometry of each telescope is recorded simultaneously to the fringes. The errors, including the internal ones and the ones from the calibrator diameter uncertainty, range from 5% to 10%. The accuracy of the absolute flux calibration is about 10–13%. For the flux calibration, HD 163917 (F12   μm = 16.54 Jy) was used. A Cohen template for a K0III star was used (HD 180711, F12   μm = 21.35 Jy). The log of the observation is given in Table 1. We used two different MIDI data reduction packages: MIA developed at the Max-Planck-Institut für Astronomie and EWS developed at the Leiden Observatory3.

Table 1

Observing log.

thumbnail Fig. 1

Composition of HST/STIS (black) and NACO/Ks (red) images. North is up and east is on the left. The infrared emission contours follow the lines of the HST scattering in the visible, not only in the core but in a north-west region as well. The unresolved core is less than 0.1″ in Ks. Contours from the centre to low levels are 95, 10, 2, 0.8, 0.4, 0.2, 0.1, 0.05, 0.025 and 0.015% of the maximum, respectively. Noise appears in the last two lower levels and those reveal the extended nebula as it is evident on the northern and southern part of the image. The diffuse light is increasing smoothly from the 0.05 to the 10% level.

Open with DEXTER

2.2. NACO

We observed M2-9 with the near-infrared adaptive optics instrument NACO (Lenzen et al. 2003; Rousset et al. 2003) as well, using three broad-band filters centred respectively at 2.18 μm (Ks), 3.8 μm (L′) and 4.78 μm (M′). The Ks data were taken during the night of 3 July 2006, and the L′-band and M′-band data on 18 August 2006. These observations were complemented with close-by PSF calibrations using HD 155078 (F5V) in L′ and HD 156971 (F1III) in M′. We used the S27 (Ks) and L27 (L′, M′) camera mode to obtain a field of view of 28″ × 28″ and the pixel scale of 27.1 mas per pixel. Jittering was used to remove the sky and for the M′ observations chopping was also used. The reduction procedure followed for MIDI and NACO data of M2-9, is the same as the one described for Mz3 in Chesneau et al. (2007).

Our Ks, L′ and M′ observations of Mz3 (Chesneau et al. 2007) and M2-9 with NACO revealed an unresolved core at diameters less than 0.1″. Figure 1 is a composite image of a Hubble Space Telescope (HST) STIS/CCD image in the visible and our Ks-band image, the latter being an improved near-infrared view of the source compared to Aspin et al. (1988). One can notice a broad near-infrared emission around the core of M2-9 (diameter  < 5″) and some enhanced emission in the lobes as well (~10″ from the core; more prominent at north-west). These are attributed to scattering. Near-infrared photometry gave mL = 4.12 and mM = 2.5 and these are included in Fig. 6.

2.3. ISO

We have reduced and analysed archived4 data from ISOCAM (Cesarsky et al. 1996), the Infrared Space Observatory’s (ISO) infrared camera. The satellite was mounted with a 60 cm Ritchey-Chrétien Cassegrain telescope. Ten exposures have been recorded in 1996 for a range of wavelengths from 3.0 to 14.9 μm with both short-wave (SW) and long-wave (LW) filters (bandwidths stated in Table 2). Each frame is 32 × 32 pixels with an effective field-of-view 45″ × 45″ and the spatial scale of each pixel is 1.5″. The standard software CIA was used to reduce and analyse the data (Table 2) in the procedure described in the manual. Photometric errors were consistent for each detector. In ISOCAM the physical detector pixel size is 1″ and the Airy disc pattern increases with wavelength from 1″ to 3.5″ (see Blommaert et al. 2003, p. 44) thus the core of M2-9 was not resolved by this instrument. The broad infrared emission from the core did not permit the detection of any other significant structure in its vicinity either.

An infrared spectrum has also been retrieved from ISO Short Wavelength Spectrometer (SWS) using short- and long-wavelength gratings (Kessler et al. 1996). The aperture area varies with wavelength range and grating: it is 14″ × 20″ for 2.38−12.0   μm, 14″ × 27″ for 12.0−27.5   μm, 20″ × 27″ for 27.5−29.0   μm and 20″ × 33″ for 29.0−45.2   μm (see Fig. 6).

thumbnail Fig. 2

Positioning of the Spitzer/IRS slits over a F656N exposure of M2-9 (Hubble Space Telescope Legacy Archive). Both slits were centred on top of the northern lobe, the Short-High (green; 4.7″ × 11.3″) at a PA = 131.2°and the Long-High (red; 11.1″ × 22.3″) at a PA = 46.1°. North is up, east is left. The underlying Hα image comes from 1996. By the time that Spitzer observed M2-9, the underlying structure of M2-9 was rather different, and the nebular structure inside the green aperture had changed.

Open with DEXTER

Table 2

ISOCAM photometry.

2.4. Spitzer

Calibrated data were extracted from the Spitzer Space Telescope5 Archive. M2-9 has been observed with both the InfraRed Array Camera (IRAC) and the InfraRed Spectrograph (IRS). Unfortunately, the core’s strong infrared emission has saturated IRAC rendering those observations useless.

High-resolution spectra (Fig. 3) by IRS revealed important information on the nebular dusty and gaseous chemistry. Two slits were positioned over the northern lobe and avoided the core (Fig. 2): Short-High slit (9.9−19.6   μm) is 4.7″ × 11.3″ at PA = 131.2° and Long-High slit (18.7−37.2   μm) is 11.1″ × 22.3″ at PA = 46.1°.

thumbnail Fig. 3

High-resolution spectra of the northern lobe of M2-9 by IRS/SPITZER. Upper curve corresponds to the Short-High slit and lower curve to the Long-High (for slit orientation, see Fig. 2). The inset in the upper plot is a close-up of the PAH emission features.

Open with DEXTER

2.5. AKARI

We include mid-infrared data from the AKARI satellite6 IRC Point Source Catalogue archive (Murakami et al. 2007). M2-9 has been observed with the InfraRed Camera (Onaka et al. 2007) at two infrared bands, namely S9W (6.7−11.6   μm) and L18W (13.9−25.6   μm) with respective effective wavelengths at 9 and 18 μm (see Fig. 6).

thumbnail Fig. 4

Top: normalised visibility vs. wavelength for M2-9 revealing two crystalline silicate absorption bands at 9.8 and 11.4 μm; they are identified as forsterite. For the sake of clarity only the nearest to the equatorial plane measurement (M2-9_1: 40.2 m, 107.3°) is shown here. Bottom: mass absorption coefficients for forsterite (solid) and enstatite (dash) taken by Koike et al. (2000, 2006).

Open with DEXTER

3. Results

3.1. Spectral energy distribution

The integrated flux, as detected by MIDI (field-of-view:  ~0.4″ with UTs), in Fig. 6 clearly shows a 20% difference between the MIDI and the ISO spectra. Since the rectangular aperture of ISO (14″ × 22″) was positioned over the central area of M2-9 (excluding the largest part of the lobes) and it increased in size for bands larger than 12 μm (including part of the lobes near the central source), it is expected that ISO detected a more extended source than MIDI. The fact that both spectra have similar shape and only slightly different flux levels, indicates that they both detected almost the same compact source.

Both ISO and MIDI spectra, shown in Fig. 6, have been dereddened using the Savage & Mathis (1979) law for AV = 2.5 (Torres-Peimbert & Arrieta 1998).

The two Spitzer slits were positioned on top of the northern lobe, but they have probed different parts of the nebula. In more detail (Fig. 3):

  • Short-High: the spectrum is very weak compared tothe continuum of both MIDI and ISO, which were posi-tioned over the core, but there are many interesting fea-tures. There is a broad poly-aromatic hydrocarbons (PAHs,i.e. signature of C-rich chemistry) emission at 11 μm and much fainter broad regions at 12.3 and 12.8 μm. [NeII], [NeIII], [FeII] and [SIII] lines are seen at 12.8, 15.6, 17.9 and 18.7 μm, respectively. No other PAHs have been detected near the core by ISO, whereas it is unclear whether the 11.4 μm emission at 10% of the continuum of MIDI spectrum originates from PAH (Fig. 4). This suggests that the 11 μm feature resides in the lobe.

  • Long-High: there is an indication of a broad feature at 33.5 μm (forsterite) but the neighbouring broad shallow absorption from 30−34   μm suggests that they may both not be real. Prominent gaseous emission lines are also present: [FeIII] (22.9 μm), [OIV] (25.9 μm), [SIII] (33.48 μm) and [SiII] (34.8 μm). All those require a high excitation state and would be expected near a white dwarf.

thumbnail Fig. 5

Gaussian size distribution of the disc (±5%) for each baseline (Table 1) in N band implementing the dusty structure’s evolution in the mid-infrared.

Open with DEXTER

3.2. Interferometry

Our VLTI observations of the core of M2-9 reveal the presence of a dusty flat-like structure. Visibilities decrease as the PA of the projected baselines increases (Fig. 5), suggesting an increase of the dust opacity. Thus, MIDI has probed the existence of a flattened structure along the equatorial plane of the nebula.

The core is significantly resolved by the 40–50 m baselines, with visibilities of the order of 0.1–0.2. Our observations showed that the flattened structure is compact, typically 25 × 35 mas at 8 μm, and 37 × 46 mas at 13 μm (Fig. 5). The dusty structure is more elongated along the planetary nebula’s equatorial plane, compared to the direction of the lobes. Therefore, the disc’s geometrical size can be constrained (see Sects. 4 and 6).

Subtracting the continuum from each spectrally dispersed visibility, one may enhance subtle visibility fluctuations that could not be distinguished otherwise. Significant signatures of forsterite (Mg2SiO4) are observed as small (~5–10%) dips in the visibility curves (Fig. 4) at 9.8 and 11.4 μm (Molster et al. 2002). We confirmed the validity of this, since both features were present in the uncalibrated visibilities and they were absent in the calibrator data. In addition, the peaks nearly match the emission curves of forsterite grains measured in the laboratory by Koike et al. (2000, 2006). The visibility decrease at typically 10% shows that the forming regions of these features are resolved and thus slightly more extended than the continuum and amorphous silicate regions (as already observed in young stellar objects, van Boekel et al. 2004).

4. Physical parameters of the disc

In this section we present the modelled disc and the constraints introduced by the fitting procedure.

4.1. Model

The 3D radiative transfer code MC3D, which is based on the Monte Carlo method and solves the radiative transfer problem self-consistently, has been used in this work (Wolf et al. 1999; Wolf 2003). It simulates the temperatures produced by dusty configurations and creates as observables spectral energy distributions and wavelength-dependent images of the dusty environments, as well as polarisation maps. The density law used in this model is where r is the radial distance in the disc midplane, R is the stellar radius, β is the vertical density parameter, α is the density parameter in the midplane and h0 is the scale height at a given distance from the star (Shakura & Syunyaev 1973; Wood et al. 2002). We have used the distribution of Mathis et al. (1977) for the grain sizes: n(b) ∝ b-3.5, where b is the grain size, assuming that the dust grains have spherical symmetry.

The dust residing around evolved stars may be oxygen- or carbon-rich (O-, C-rich), or even a combination of both. This is determined by the abundance of each element during the AGB phase. Spectroscopic observations did not reveal any 3.3   μm PAHs in the core of M2-9 (Smith & McLean 2008), but other PAH features are present in the lobes (this work, Sect. 3.1). The nebula is O-rich with C/O < 0.5 (Liu et al. 2001), thus the dust is expected to be O-rich. The model contained only amorphous silicate dust, since the exact percentage of crystalline silicates that is locked within the disc is unknown.

Table 3

Parameters of the best fitted model for M2-9 and Mz3 (Chesneau et al. 2007).

We have chosen a certain position angle (PA) of the gaseous nebula to fit the observed visibilities. According to Phillips & Cuesta (1999), the PA of M2-9 is  −2°. We support this estimation from the positions of the two ansae at  ~52″ from the core and finding the best fit at the same position angle (Table 3).

thumbnail Fig. 6

At 1.2 kpc: MIDI spectrum (blue) compared with the ISO spectrum (black – solid: 14″ × 20″ aperture, dashes: 14″ × 27″ aperture), ISOCAM data (green crosses), AKARI data (open circles), the TIMMI2 photometric measurements of Smith & Gehrz (2005) with an aperture of 4″(cyan triangles), IRAS measurements (circles) and Cohen & Barlow (1974) photometry (purple stars, 11″ beam). The NACO L′ and M′ band are also included (magenta stars, aperture 0.4″). The red line is the best model with the full aperture (~1″). All spectra have been dereddened using the Savage & Mathis (1979) law.

Open with DEXTER

thumbnail Fig. 7

MIDI visibilities, compared with the best model (dashed-dotted lines, χ2 = 3.17, see Table 3). The visibility curves are for the baselines M2_9-1 to M2_9-4 from top to bottom and left to right (Table 1). Individual χ2 are 2.61, 5.33, 3.05 and 1.69 for each curve respectively.

Open with DEXTER

thumbnail Fig. 8

Flux distribution of the model at 8, 10 and 13 μm. Images on the top belong to M2-9 and the ones on the bottom to Mz3. A small amount of light emerges at 8 μm while the flux comes from inner disc parts at 13 μm.

Open with DEXTER

4.2. Fitting results

Following the success of fitting a disc model for the core of Mz3 and knowing that those two objects are similar, we chose parameter ranges for the disc in M2-9 similar to those of Mz3 (Table 3). A more in-depth presentation on general MC3D fitting, can be found in Sauter et al. (2009).

  • The disc’s inner rim radius was chosen by fitting the observedvisibilities with Gaussian uniform discs, thus estimating theirdiameters in milliarcseconds, and converting those into physicalunits.

  • We adopted an initial value for the mass of warm dust derived by Smith & Gehrz (2005), but it was increased in order to recreate the silicate absorption features. Parameter α was fixed likewise to a certain value, where we would see silicates in absorption and at flux levels between those set by ISO and MIDI spectra. In this paper, we do not probe the large amount of cold dust that was observed by Smith & Gehrz (2005).

  • Low visibilities indicated a resolved structure, or else a very dense medium, so a scale height, h0 higher than 20 AU, was chosen initially, with increments of 5 AU, and a moderate flaring, β, with steps of 0.01, in order to fit the observed visibilities (Fig. 7).

The reconstruction of the disc’s image was made with the use of MC3D. The models of its spectral energy distribution (SED) and visibility amplitudes have been compared to the MIDI data and the observed SED. After careful examination of all possible parameters, the model with the best fit, is one that resembles the best geometrical shape for a flared disc. The model’s parameters are shown in Table 3.

We were able to define a lower and an upper limit to constrain the size of the disc’s structure from a theoretical basis and from our observational data. A projected baseline on the equatorial direction of M2-9 would probe the full size of the disc. In our case, this telescope configuration was not accomplished.

The distance of 640 pc suggested by Schwarz et al. (1997) led us to many difficulties in fitting the observations. Even with scaling down the luminosity and the size of the disc or modifying the dust content, thus the optical depth, no improvement was found in fitting both the SED and the visibilities. Significant geometrical structures should have been detected in the dispersed visibilities for such a nearby source, yet the observed dispersed visibilities are very smooth. None of our models could fit the distance and luminosity assumed so far. Our best fits were found for a larger distance, namely  ~1200 pc (Table 3, Figs. 68). Recent calculations7 put M2-9 at a distance of 1300  ±  200 pc (Corradi, priv. comm.).

The mass of dust, density and geometric parameters used in this model, represented the best fit for the opaque structure detected by MIDI in our line-of-sight (74°). A similar inclination of 73° was also found independently by Solf (2000) for the polar lobes and by Zweigle et al. (1997) for the CO torus.

To fit the near-infrared flux, we have selected a cooler star (15 000 K) as the illuminating source than what was proposed by Smith & Gehrz (2005) (30 000 K). From Fig. 6 one can notice that the shape of both MIDI and ISO spectra is the same; the only difference is the flux level. We preferred to fit the ISO spectrum, because our model has a larger aperture than that of MIDI. Our best fit for the MIDI visibilities was found by optimising the model’s total χ2, taking into account the restricted field-of-view of MIDI. The current fit has a total χ2 = 3.17 (Fig. 7).

We preferred to fit the visibilities rather than achieve a better fit for the SED. We could not fit our data by decreasing the outer radius, since these modifications increased the silicate absorption feature and lowered the visibilities, suggesting either a denser or a larger, resolved structure (without altering the shape of the spectrum that was due to colder dust). Expanding the outer radius imposed a new problem: more cold dust must be deposited in the disc, thus the predicted flux of the model exceeds actual measured levels at wavelengths longer than 12 μm. For our best fit, the disc’s optical depth in the N band is τ10   μm = 4.6. The fit is sensitive to parameters α, β and h0, as small changes in those values instantly altered the disc’s opacity. The model in use does not include a puffed-up inner rim.

A single illuminating source is assumed for the dusty disc; in this case the red giant. Thus, the contribution from the companion in both the heating and shaping processes is not included and cannot be reproduced. This drawback may partly explain the difficulty in fitting the spectral energy distribution. The binary interactions lead us to consider a different disc geometry.

Due to the limited number of baselines, our selection of geometric parameters was restricted. We have found an acceptable disc model to fit the observational data, which implies a general agreement in terms of emission and spatial distribution of the bulk of the dust in the core of the system. Despite this, it is also true that the source is complex, probably engulfing a binary, and that the passive disc model is probably not a good description of the reality. This source clearly requires interferometric imaging either with aperture masking techniques (Tuthill et al. 2006) or with MATISSE/VLTI (Lopez et al. 2008).

5. The mass of the components and an accretion disc

Spectrophotometry of the core has shown an intrinsic amount of (high-excitation) iron emission lines ([Fe ii] and Fe iii], Allen & Swings 1972) This gives an electron temperature for the core  ~10 000 K and an electron density of 107   cm-3 (similar to Mz3, Smith  2003). As it is mentioned in that work, at such high core densities collisional de-excitation prevails and weak forbidden nitrogen lines in the core are not a surprise. Iron was found in the northern lobe as well (Fig. 3). Hora & Latter (1994) have also detected iron lines that have a high ionisation potential, proving the presence of a particle beam or supersonic shock interface inside M2-9. Hα emission from the core is optically thick with broad wings due to scattering (Balick 1989; Arrieta & Torres-Peimbert 2003). Polarisation measurements in the optical revealed an elliptical polarisation in the core of M2-9, which was consistent in every observed waveband (namely B, R and I). Aspin & McLean (1984) explain this as scattered continuum from the central ionising source by an extended ionised dusty torus around the core (diameter  ≲ 4″). All this indicates that the illuminating source of M2-9 must be a hot and compact star.

A lifetime of a planetary nebula is  ~10 000 years and that of a white dwarf billions of years. Thus, material ejected by what is now the secondary, a white dwarf, is already dissolved in the interstellar medium. We expect that the material that composes M2-9 at the moment, originates from what is now the primary, an evolved giant, either an AGB or a post-AGB star.

According to Akashi & Soker (2008) shaping of the ejecta of a tight-waist PN is possible by an accretion disc around the secondary. An accretion disc could be bright enough and illuminate part of the disc that has been detected by MIDI. We believe that the disc found in the core of M2-9, engulfs an evolved star (AGB or post-AGB) and a WD, namely the primary and secondary components of the binary. The first one is the main heating source for the dust at  ~2500 L (Table 3), while the second one obtains its luminosity from an accretion disc, although it is the main ionising source for the nebula (lighthouse beam).

The most probable scenario to explain the observables of Schwarz et al. (1997) is that the mass-losing star transfers material onto the secondary at a rate of  = 10-6 M yr-1 at supersonic speeds (5−10   km   s-1) feeding the accretion disc of a white dwarf. A luminosity of  ~100 L was estimated for the ionising source from radio observations (Purton et al. 1982). The following equation by Soker (2004) was used in order to calculate accretion luminosities for the white dwarf: (3)where acc is the mass accretion rate, is the mass loss rate of the primary, MWD is the mass of the accreting white dwarf, a is the binary separation and vs is the wind speed.

Table 4 displays a range of accretion luminosities () for different secondary masses for the above-mentioned accretion rates and velocities, assuming a binary separation of 30 AU and a WD radius of 6000 km. Our findings confirm a WD mass of 0.6–0.8 M, previously suggested by Livio & Soker (2001) and in accordance to Gesicki & Zijlstra (2007).

We can see that the accretion luminosities for a wind velocity  ~10 km   s-1 are not high enough to evaporate dust up to 15 AU (inner rim). The cool primary’s luminosity (2500   L) is sufficient though.

Table 4

Accretion luminosities for a range of WD masses and different companion mass outflows.

6. Where is the companion relative to the dust source?

It has long been believed that M2-9 engulfs a binary system. The lighthouse effect is an indirect, but rather convincing evidence of binarity. The assumption of circularity is based on the fact that no evident acceleration nor deceleration of the lighthouse’s angular velocity has been observed to date (Corradi, priv. comm.)8Livio & Soker (2001) have used a typical mass for a white dwarf of 0.6 M and 0.8 M for a post-AGB star, leading to an orbital separation of 27 AU, assuming a circular orbit.

The VLTI observations of a compact dusty structure impose some constraints, which are not trivial for the interpretation of this system. However, these interferometric observations are also limited in the sense that they do not provide any closure phase, nor absolute astrometry as in radio interferometry. It is therefore not possible to locate precisely the position of the compact dusty structure.

6.1. The inner dusty disc

The size of the dusty structure detected by MIDI by the baseline closer to the equatorial plane (M2-9_1; Table 1) is approximately 33 mas (Fig. 5). Extrapolating to a projected baseline at 90° (equatorial plane) we would expect a minimum size of 41 mas. From that we presume that the central cavity must be smaller than this size. Our modelling has showed that a diameter of approximately 30 ± 2 AU (or  ~25 mas) fits the inner portion of the disc (Table 3). We did not find a better fit to the MIDI data than the one presented here by increasing the disc’s inner rim.

We have used a relation for dust sublimation radius (Rsub in AU) by Tuthill et al. (2001): (4)where L is the stellar luminosity and Tsub is the dust sublimation temperature. For a star of 2500 L (Table 5) it is suggested that the inner rim of the disc must reside at a distance larger than 4 AU but within the limits defined by the MIDI observations. Neither an 100 L heating source, such as the accretion disc in the case of M2-9, nor the 553 L source suggested by Schwarz et al. (1997), fit the observational data.

Table 5

Dust sublimation radii in AU for two stellar luminosities.

We estimated orbital periods for the binary by using the observations of 18 years from Doyle et al. (2000). From those, it can be seen that the lighthouse beam covered less than 20% of the perimeter of the lobes within that time scale. We found that the period ranges from 90 to 120 years.

A binary system should reside within the structure detected by MIDI. By applying simple Keplerian physics (assuming circular orbits), we have used several mass ratios9 for the binary components to estimate the corresponding orbital diameters, for periods of 90 and 120 years, in physical units and converted them to angular sizes for a distance of 1.25 kpc (Table 6).

As seen in Table 6 orbital diameters that fit within the extrapolated angular size of 41 mas range from 42–52 AU. This is larger than our best fit model, where the size of the disc’s inner cavity is 30 AU. We should draw attention though to the fact that the disc’s inner rim is centred at the heating source, which in turn is not positioned on the binary’s centre-of-mass. The model in use cannot reproduce a partially illuminated disc or a disc with an off-centre illuminating source. Thus, we believe that the companion is truncating the disc, since its heating capabilities are minimal.

We can only surmise that high-angular resolution radio observations could establish the astrometric position of the companion (WD/accretion disc).

6.2. The exterior torus

The obtained NACO images are fully dominated by the central source and lack dynamical range in its close vicinity (Fig. 1). At  ~3″ from the core Zweigle et al. (1997) found that the CO emission is coming from a large ring, whose centre seemed offset by 0.5 ± 0.3″ from the compact radio source (<0.1″ and unresolved at 1.3 cm, Bignell 1983). More recent Plateau de Bure data (Castro-Carrizo et al., in prep.) with 0.3″ angular resolution confirm the presence of an offset, and detect additional CO emission coming from regions at a distance of  ~1″ from the centre.

Table 6

Binary orbital diameters in AU (also converted in mas for a distance = 1.25 kpc), at two different periods, 120 and 90 years

Molecular hydrogen spectroscopy has yielded two different velocity components at distances  ≲ 0.5″ latitudinally from the central illuminating source: 10.9 km   s-1 (blue-shifted) and 123.7 km   s-1 (red-shifted). This points to a H2 disc-like structure (Smith et al. 2005).

Spiral structures (as expected in a symbiotic type system) can be formed by binary interactions during the ejection of the primary’s CO envelope (Edgar et al. 2008), yet this is not clear at this point for the case of M2-9. If there are spirals, they are seen at a high inclination (pole-on). Our source is edge-on. The differential phases of the disc detected by VLTI are small, lying within a range of  ± 10°, i.e. well below some strong signature from dusty rings reported in the literature (Deroo et al. 2007a; Ohnaka et al. 2008).

7. Comparing discs: M2-9 and Menzel 3

These two bipolar nebulae are spectroscopic twins and both exhibit complex gaseous shell structures. Both are extended at similar sizes. Their main parts, including the lobes, are 43″ and 38″ at length and  ~15″ at width, for M2-9 and Mz3 respectively. The ansae of M2-9 are 115″ apart, while the farther regions of Mz3 are at about 130″.

Distances to both objects are not well determined and the estimates given stand for the best fits to the observational data: M2-9 at 1.2 kpc, Mz3 at 1.4 kpc. Indirect evidence for binarity in the case of M2-9 are the lighthouse knots in the nebula and the fast outflows observed in Hα (as recently studied in the case of the Red Rectangle, Witt et al. 2009), and for Mz3, the X-ray jet (Kastner et al. 2003) and also fast outflow seen in Hα.

Whereas Mz3 was unresolved in all infrared filters, some significant extensions of the nebular core at larger diameters in both equatorial and polar directions were found for M2-9, as already suspected in some other observations. Our observations in the mid-infrared have revealed that they both have very compact dusty discs in their cores.

The discs have been resolved with high-angular resolution techniques and their composition is similar (amorphous silicates). In addition, the discs are in the equatorial planes of the planetary nebulae (that is, perpendicular to the bipolar ejecta) and at similar inclination from the rotation axis (~74°).

The disc inside M2-9 is larger in terms of size (Fig. 8) and hot dust mass compared to Mz3: 1.5 × 10-5 M and 9 × 10-6 M, respectively. In both cases, the total amount of material is 0.5−1   M, which points to progenitors of several Solar masses. This is in line with the high nitrogen content found by Smith  (2003) for Mz3. In addition, the disc of M2-9 exhibits some degree of crystallinity (Fig. 4), which may indicate that it is older, or that the physical conditions for annealing prevail. There are no such features in Mz3 (Fig. 9).

In the work of Smith  (2003) it is shown that the optical to infrared SED of Mz3 required two components; a hot star and a cool star. M2-9 has a very similar SED in the optical to that of Mz3, thus it is probable that it has similar components.

Assuming a circular orbit might be an oversimplification. Binaries containing a WD and another evolved star, may have eccentric orbits. When main sequence stars will ascend to the red giant branch and then to the AGB, it should be expected that despite strong mass-loss the eccentricity will persist, leading to variations in the building up of an accretion disc and the generation of jets. This may lead to short and strong events of large mass ejection, related to the building of large scale structures seen in the nebula, and in the equatorial plane as well.

thumbnail Fig. 9

Normalised visibilities vs. wavelength for Mz3 (Chesneau et al. 2007). The prominent feature belongs to the bright 12.8 μm [NeII] nebular emission line. The noise increase at 9.7 μm corresponds to the narrow ozone feature. Observed baselines are indicated within the legend.

Open with DEXTER

8. Conclusions

We present the discovery of a complex dusty disc inside the elongated bipolar planetary nebula M2-9, with the use of infrared interferometry, for which we have derived geometrical constraints and chemical composition. Our findings show that the disc is much smaller than the extended dusty structure around the nebula’s core with an inner rim of 15 AU at 1.2 kpc and that it is primarily composed of silicates. This suggests that the dusty material is derived from the AGB envelope of the primary and has survived its evolution onwards. The disc is also aligned with the equatorial axis of the nebula. It is probable that the dust is heated by the primary, evolving star (0.6–1.4 M), but it is also partially heated and truncated by the accretion disc of the secondary, a white dwarf (0.6–1 M).

There are similarities between the disc found in M2-9 and that of its spectroscopic twin, Mz3. Although the sample is small, many bipolar planetary nebulae and proto-planetary nebulae (e.g. M2-9, Mz3, OH231.8+4.2, Hen 2-113, CPD-56°8032) have dusty structures (discs/tori/spirals) around their cores. Some of them are known to engulf binary systems. Binarity in the cores and dusty structures around them may explain the shaping of the ejecta into bipolar shapes. Thus, an extended study of those bipolar proto-planetary and planetary nebulae would be advised to establish whether this is a global tendency.

M2-9 is yet another example of an object with silicate chemistry within the disc, suggesting that the material was ejected during the oxygen-rich phase of the primary star. Nevertheless, there are PAHs in the lobes of the nebula, at a much lower percentage, most probably formed after the dissociation of carbon monoxide.


2

All mass estimates with an assumed distance of 1 kpc (except for Lenzuni et al. 1989, 2.37 kpc.)

7

Revision of the expansion data.

8

Bearing in mind though, that intensive monitoring of the nebula occurred only in the last 20 years (Doyle et al. 2000).

9

Within the Chandrasekhar limit for the WD.
