1 Introduction

The unusually hard and bright X-ray emission of the B0.5 IVe star γ Cassiopeiae has been a puzzle ever since its discovery (see Smith et al. 2016 for a review and Rauw et al. 2022 for a recent observational study). Over the last two decades, a number of similar objects have been identified (e.g. Lopes de Oliveira et al. 2006; Nazé & Motch 2018; Nazé et al. 2020, 2022b; Nazé & Robrade 2023), and γ Cas is now the prototype of a steadily growing class of over 30 (currently) known objects (Nazé & Robrade 2023). All of them are early Be or late Oe stars. They display log L_X values (in the 0.5–10 keV band) ranging from ~31.6 to 33.2, log(L_X/L_bol) between ~−6.2 and −4, and their X-ray emission is due to a thermal plasma with a temperature kT ≥ 5 keV.

Several scenarios have been formulated to explain this X-ray emission. Historically, the first explanation that was proposed was accretion onto a neutron star (NS) companion (White et al. 1982). However, the absence of pulsations and X-ray bursts as well as the thermal nature and luminosity of the X-ray emission are arguments against this scenario. Postnov et al. (2017) nevertheless revived the idea of a NS companion. They suggested that the properties of γ Cas could be explained provided the companion were a rapidly spinning magnetic NS. This object would then be in the propeller regime, where the rapid rotation of the magnetosphere prohibits accretion. Accretion onto a white dwarf companion was proposed by several authors as an alternative to the NS scenario (e.g. Murakami et al. 1986; Tsujimoto et al. 2023; Gies et al. 2023, and references therein). To power the observed level of X-ray emission, this white dwarf scenario would require a rather large mass-transfer rate from the Be star. In view of these difficulties and to account for the observed correlation between X-ray and UV variability, Smith et al. (1998) and Smith & Robinson (1999) elaborated another scenario in which small-scale magnetic fields at the Be star surface interact with a magnetic field generated in the Be disk. Finally, Langer et al. (2020) proposed that the hard X-ray emission might come from the collision between the wind of a stripped helium subdwarf (sdO) companion and the circumstellar disk of the Be star. In addition to a number of conceptual problems, this scenario was refuted by observing the X-ray properties of a sample of established and suspected Be + sdO systems (Nazé et al. 2022b).

Much like other Be stars, γ Cas and a number of its siblings have been found to be binary systems with orbital periods in the range of several weeks to several months (Nazé et al. 2022a, and references therein). The nature of the companions remains uncertain, but the most likely values of the companion masses allow for stripped helium subdwarfs, white dwarfs, or, in some cases, NSs.

To discriminate between the various scenarios, a different road must be followed. In the present work, we focus on the fluorescent Fe Kα emission line near 6.4 keV seen in the X-ray spectra of γ Cas stars (e.g. Giménez-García et al. 2015, and references therein). The strength of these lines offers a diagnostic of the properties of the illuminating hard X-ray source and of the illuminated material. Moreover, in the future, X-ray microcalorimeters on board the X-ray and Imaging Spectroscopy Mission (XRISM, Ishisaki et al. 2022) and Athena (Barret et al. 2023) will provide high spectral resolution over the 6–7 keV energy band. This will then allow the detailed morphologies of the Fe Kα line to be observed, thereby offering an even more powerful diagnostic. As a first application, the present paper concentrates on the Postnov et al. (2017) scenario, in which the hard X-rays are thought to arise from a shell of hot material around a NS in the propeller regime. Section 2 describes the ingredients of our calculations of synthetic fluorescent Fe Kα line profiles in the propelling NS scenario. The results of the model applied to the specific case of γ Cas are presented in Sect. 3, whilst Sect. 4 outlines the cases of two other γ Cas stars. The implications of our results are discussed in Sect. 5.

2 The Fe Kα fluorescent line

The illumination of a cloud of relatively cool gas by a bright source of hard X-rays leads to inner-shell photoionization of the atoms and ions in the cool material. In this process, a photon with an energy above the K-shell ionization edge of the corresponding ion is absorbed, thereby creating a vacancy on the K shell. This vacancy is filled by an electron from the L or M shell decaying to the K shell. The excess energy of this electron is shed either via Auger auto-ionization or by the emission of a fluorescent line photon (e.g. Palmeri et al. 2003). When the de-excitation involves an electron from the L shell or the M shell, the fluorescent photons are named respectively Kα or Kβ. Fluorescent emission of Fe Kα photons is of particular interest, because the corresponding line occurs in a relatively clean spectral domain around 6.4 keV and because Fe ions have relatively high fluorescent yields¹ near 0.3 (Kallman et al. 2004). In X-ray astrophysics, the Fe Kα line bears a considerable diagnostic potential for both the properties of the primary source of hard X-rays and the properties of the illuminated gas. Observationally, fluorescent Fe Kα lines have been found in various astrophysical environments, including accretion disks around supermassive black holes in active galactic nuclei (e.g. Tanaka et al. 1995; Brenneman & Reynolds 2006), accretion disks around NSs in low-mass X-ray binaries (e.g. Cackett et al. 2008), accretion flows onto white dwarfs (e.g. Ezuka & Ishida 1999; Xu et al. 2016), flaring or outbursting pre-main-sequence stars (e.g. Skinner et al. 2016; Hamaguchi et al. 2010), and highly active late-type stars (e.g. Drake et al. 2008; Czesla & Schmitt 2010). However, with the clear exception of γ Cas stars (Giménez-García et al. 2015) and possibly some Wolf-Rayet stars (Oskinova et al. 2012), fluorescent Fe Kα emission is not seen in the X-ray spectra of massive stars (e.g. Rauw 2022, for a review on X-ray emission of massive stars).

2.1 Modelling fluorescent emission

In γ Cas stars, several media provide reservoirs of material that can potentially contribute to the fluorescent line emission. These include cool plasma in the vicinity of the primary source of hard X-rays, the Be circumstellar disk and the Be photosphere. If the fluorescence arises from hard X-rays illuminating an optically thin slab of cold material, then the ensuing line emission strength is essentially proportional to the column density of the slab. For re-processor column densities higher than 10²⁴ cm⁻², this simple relation breaks down, and absorption and scattering effects become important (Kallman 1995). For a given column density of the fluorescent material, the Fe Kα line luminosity scales mostly with the flux of the illuminating source at the position of the fluorescent material. The equivalent width (EW) of the fluorescent Fe Kα line is mostly set by the solid angle occupied by the fluorescent material as seen from the illuminating hard X-ray source. In the present work, where we focus on the propeller scenario, we can safely neglect the contribution from the Be photosphere as the source of hard X-rays is typically located at a distance of several tens of Be stellar radii (a ~ 35 R_* for γ Cas), therefore leading to a very small contribution to the EW.

We provide here an overview of our model calculations for the fluorescent line profile. We started by considering a cell of material at location d from the primary X-ray source and at location r from the centre of the Be star. The cell has a hydrogen particle density n_H(r) and its volume is dV. To compute the iron K-shell ionization in the cell, we integrated the hard X-ray photon flux per unit energy f(E, d) attenuated by the optical depth (τ(E, d)) along the path of the incoming ionizing photon times the K-shell ionization cross-section σ(E). The hard X-ray spectrum is represented by an APEC optically thin thermal plasma model (Smith et al. 2001) of solar abundance (Asplund et al. 2009) extended at energies above 100 keV by a bremsstrahlung continuum. τ(E, d) is obtained by multiplying σ(E) by the column density of iron atoms along the line joining the cell to the source of hard X-rays. The K-shell photo-ionization cross-sections are modelled using the parametrizations of Verner & Yakovlev (1995) for the Fe ion under consideration. The Fe Kα emissivity of a cell of material that is exposed to the hard X-ray source (i.e. the primary source as seen from the cell is not occulted by the Be star) is given by $$\begin{array}{l}{j}_{\text{K}\alpha }(r,d)=E_{\text{K}\alpha }{z}_{\text{Fe}}{x}_{\text{ion }}{\omega }_{\text{ion+1 }}{n}_{\text{H}}(r)\\ {\displaystyle {\int }_{{\text{E}}_{\text{thres }}}^{\infty }\sigma }(E)f(E,d)\mathrm{\hspace{0.17em}exp\hspace{0.17em}}(-\tau (E,d))\hspace{0.17em}\text{d}E,\end{array}$$(1)

where E_thres is the threshold energy for K-shell ionization (Verner & Yakovlev 1995), E_Kα is the energy of the Kα line (Yamaguchi et al. 2014), z_Fe is the abundance of iron with respect to hydrogen (Asplund et al. 2009), x_ion is the relative abundance of a specific Fe ion, and ω_ion+1 the associated Kα fluorescent yield (Kallman et al. 2004).

The contribution of the cell to the total line luminosity is then evaluated as $$\text{d}{L}_{K\alpha }(r,d)=j_{\text{K}\alpha }(r,d)\mathrm{\hspace{0.17em}exp\hspace{0.17em}}\left(-\tau \left(E_{\text{K}\alpha },r,d,n\right)\right)\text{d}V\mathrm{obs}(r,d,n)$$(2)

where j_Kα given by Eq. (1) is expressed in units erg s⁻¹ cm⁻³, and the obs(r, d, n) parameter is equal to 1 or 0 depending on whether or not the cell can be seen by the observer located in the direction n. The quantity τ(E_Kα, r, d, n) yields the optical depth at the energy of the Kα line from the position (r, d) along the direction n.

To compute synthetic line profiles as they would be seen by an external observer, we distinguished between the individual line profiles and the morphology of the full Fe Kα complex. Indeed, we must keep in mind that what we call the Kα line is actually an unresolved array of transitions that arise from the various combinations of L and K shell electronic configurations (Palmeri et al. 2003). Each of these transitions has its own energy and intrinsic strength. The resulting morphology of the Fe Kα line is thus obtained by convolving the energy distribution of the transitions with the individual line profile weighted by the intrinsic strength of the transitions. For the computation of the individual line profile, we accounted for the Doppler shift of each cell of fluorescent material and built a histogram of the line emission in radial velocity bins of 50 km s⁻¹. Doppler shifts arise for instance from the Keplerian rotation of the material in the cir-cumstellar Be disk. As the illuminating source (in the present scenario associated with the NS) orbits around the Be star, the Doppler shift of those parts of the Be disk that are closest to the source, and thus produce the strongest contribution to the fluorescent line, varies. Therefore, the contribution of the Be disk to the individual line profile is expected to change its morphology as a function of orbital phase.

2.2 Fluorescence from the circumstellar Be disk

The decretion disk of the Be star provides an important reservoir of relatively cool material that can contribute to the formation of the Fe Kα line. In the scenario that we test here, the disk is illuminated by a roughly point-like source associated with the hot shell around the NS’s magnetosphere. To model the fluorescence from the disk, a number of input parameters are needed. These include the properties of the hard X-ray emission, estimates of the mass and radius of the Be star, the density profile of the circumstellar disk, the disk’s inclination to our line of sight, as well as orbital parameters of the binary system.

The X-ray spectrum of γ Cas is described well by a combination of up to four optically thin thermal plasma components, with the hottest plasma providing the dominant contribution. For this hot component, Rauw et al. (2022) determined a mean plasma temperature of kT = 12.5 keV and a mean flux, corrected for absorption by the interstellar medium, of 1.5 × 10⁻¹⁰ erg cm⁻² s⁻¹ in the 2.0–10.0 keV energy band. To convert the fluxes into luminosities, we adopted a distance of 190 pc (Nazé & Motch 2018). The fluorescent Fe Kα line observed in the XMM-Newton and Chandra spectra of γ Cas has an EW in the range between 34 and 59 eV (Rauw et al. 2022).

The mass of the B0.5 IVe star is usually estimated between 15 and 17 M_⊙ (Stee et al. 1998; Sigut & Jones 2007). We thus adopted a value of 16 M_⊙. Estimates of the stellar radius range between 8.2 and 10 R_⊙ (Quirrenbach et al. 1997; Stee et al. 1998, 2012; Sigut & Jones 2007; Klement et al. 2017), with a majority of values at 10 R_⊙.

There is considerably more dispersion among the literature values of the disk parameters. This could result from either a genuine epoch-dependence of the disk properties or degeneracies of the model parameters. For the disk inclination, the literature values, based either on interferometric observations or fitting of the Hα line profile, range between 42° (Stee et al. 2012) and 59° (Sigut et al. 2020). The majority of the values gather around 45° (Quirrenbach et al. 1997; Stee et al. 1998; Silaj et al. 2010) and we thus adopted this value. With the stellar mass and radius considered here, the Keplerian rotation speed at the inner edge of the disk amounts to v_rot(R_*) = 550 km s⁻¹, in agreement with the (550 ± 50) km s⁻¹ obtained by Stee et al. (2012) using interferometry. For the hydrogen number density distribution of the decretion disk, we adopted the commonly used power-law relation (e.g. Hummel & Vrancken 2000) $$n_{\text{H}}(r,z)=n_0{\left(\frac{r}{R_{*}}\right)}^{-\alpha }\exp \left|-\frac{1}{2}{\left(\frac{z}{H(r)}\right)}^2\right|,$$(3)

where r and z are the radial and vertical coordinates of the axisymmetric disk, n₀ is the hydrogen number density at the inner edge of the disk, and H(r) is the disk scale height, which varies with r as $$H(r)=\frac{c_{\text{s}}\left(R_{*}\right)R_{*}}{v_{\text{rot }}\left(R_{*}\right)}{\left(\frac{r}{R_{*}}\right)}^{\frac{3-p}{2}}\text{, }$$(4)

with c_s(R_*) the speed of sound at the inner disk edge and p is the power-law exponent of the radial temperature profile of the disk as introduced by Kurfürst et al. (2014). According to these authors, p should be in the range 0–0.5. Here we adopt p = 0. 25. Assuming solar chemical composition, the density determinations in the literature correspond to n₀ in the range 3.6 × 10¹² cm⁻³ and 3.6 × 10¹⁴ cm⁻³ (Stee et al. 1998; Sigut & Jones 2007; Silaj et al. 2010; Grzenia et al. 2013; Klement et al. 2017; Sigut et al. 2020). This rather wide range probably reflects a mix of genuine variability, model degeneracy, and model limitations. Discarding the two most extreme values yields a mean of 2.2 × 10¹³ cm⁻³, which we adopted as our default value. For α, one can find values ranging from 1.5 to 3.95 (Silaj et al. 2010; Grzenia et al. 2013; Klement et al. 2017; Sigut et al. 2020). We adopted α = 2.5 as our default value. In low-eccentricity Be binary systems, the circumstellar disk is expected to be truncated by gravitational interaction with the companion at the 3:1 resonance radius (Okazaki & Negueruela 2001). In the case of γ Cas, this resonance radius corresponds to about 176 R_⊙ (Rauw et al. 2022), which we adopted as the outer radius of the Keplerian disk.

The binary orbit of γ Cas has a period of 203.523 days and is nearly circular (Nemravová et al. 2012; Smith et al. 2012). The semi-amplitude of the radial velocity curve of the Be star amounts to 4.1 km s⁻¹ and leads to a mass function of 0.00146 M_⊙ (Rauw et al. 2022). Adopting a mass of 16 M_⊙ for the Be star and an orbital inclination of 45° yields a mass estimate of 1.1 M_⊙ for the companion and an orbital separation of a = 375 R_⊙ (Rauw et al. 2022). This corresponds to a mass ratio $q=\frac{m_{\text{NS}}}{m_{\text{Be}}}=0.07$. Using the formalism of Eggleton (1983), we estimated the radii of the Roche lobe of the binary components to be 0.61 a for the Be star and 0.18 a for the NS. Our default model parameters for γ Cas are summarized in Table 1. Throughout this paper, we assume that the companion’s orbital plane coincides with the Be star’s equatorial plane, which itself contains the circumstellar Be disk.

The presence of a hard X-ray source near the disk could in principle alter the ionization of the disk material. This is expressed via the ξ parameter defined as $$\xi =\frac{4\pi F_{\text{X}}}{n_{\text{e}}},$$(5)

where n_e is the electron density and F_X is the X-ray flux over the 1–1000 Ry energy domain (e.g. Kallman et al. 2004). Figure 1 illustrates the distribution of this ionization parameter over the Be decretion disk. The value of ξ inside the disk is the result of two competing effects. On the one hand, the r^−α dependence of n_e with distance from the centre of the Be star implies higher ξ values as r increases for a given F_X. On the other hand, the dependence of F_X on d⁻² where d is the distance from the source of hard X-rays (located here at x = 375 R_⊙, y = 0), leads to a reduction of ξ as we move away from the NS’s position. The largest values of ξ are thus logically expected in the outer areas of the Be disk facing directly the source of hard X-rays. Our calculations show that the highest values of log ξ is expected to be about −4.0. Given this low value of ξ, the ionization state of the Be disk is not strongly impacted by the presence of the hard X-ray source (Kallman et al. 2004).

The vertical column density of the Be disk, measured from the disk plane where most of the fluorescence takes place, is given by $$\begin{array}{l}{\displaystyle {\int }_0^{+\infty }{n}_{\text{H}}}(r,z)\text{\hspace{0.17em}d}z=n_0{\hspace{0.17em}(\frac{r}{R_{*}})}^{-\alpha }\mathrm{\hspace{0.17em}H}(r)\sqrt{\frac{\pi }{2}}\\ =n_0{\hspace{0.17em}(\frac{r}{R_{*}})}^{\frac{3-p}{2}-\alpha }\frac{{\mathrm{\hspace{0.17em}c}}_{\text{s}}\left(R_{*}\right)R_{*}}{v_{\text{rot}}\left(R_{*}\right)}\sqrt{\frac{\pi }{2}}.\end{array}$$(6)

Because $\frac{3-p}{2}-\alpha$ is negative for all values of α that have been proposed for γ Cas, the maximum value of the column density occurs at the inner edge of the disk and amounts to $n_0\frac{c_{\text{S}}\left(R_{*}\right)R_{*}}{v_{\text{rot}}\left(R_{*}\right)}\sqrt{\pi /2}$. With the default model parameters of Table 1, this quantity amounts to 6.3 × 10²³ cm⁻², making the inner disk mildly optically thick. In the present case, most of the fluorescence occurs however in the outer disk regions where the column density is significantly lower and the relevant parts of the disk are thus optically thin.

Fig. 1 Distribution of the ionization parameter, ξ, over the Be decretion disk for our γ Cas default model (Table 1). The hard X-ray source is located to the right at x = 375 R⊙, y = 0. The labels on the different contours correspond to the value of log ξ (from –4.0 for the blue-violet contour to –6.5 for the red contour). The hatched area lies in the shadow of the Be star and is thus not illuminated by the hard X-ray source.

2.3 Fluorescence from the cool propeller shell

Postnov et al. (2017) proposed that the γ Cas phenomenon could be explained if the companion of the Be star is a rapidly rotating magnetic NS in the so-called propeller stage. In this situation, direct accretion of material onto the NS is inhibited by the centrifugal barrier of the NS’s rigidly rotating magnetosphere, which at its outer boundary rotates faster than the Keplerian velocity. As a result, the gravitationally captured material from the Be star outflow would accumulate in a shell around the magnetosphere. Postnov et al. (2017) infer a gravitational luminosity of the shell equal to $L_{\text{X}}=\frac{G{M}_{\text{NS}}{\dot{M}}_{\text{BHL}}}{R_{\text{A}}}$ where M_NS is the mass of the NS, ${\dot{M}}_{\text{BHL}}$ is the rate at which mass is accumulated via the Bondi-Hoyle-Lyttleton mechanism, and R_A is the NS’s Alfvén radius. At R_A, for which Postnov et al. (2017) propose a value of 10⁴ km, the shell material would reach temperatures of order T_A ≃ 100 MK as the infalling material bounces against the rigidly rotating magnetosphere.

This shell of gravitationally captured material should extend between RA and the Bondi-Hoyle-Lyttleton radius for capture of material from the Be outflow $R_{\text{BHL}}=\frac{2G{\mathrm{\hspace{0.17em}M}}_{\text{NS}}}{v_0^2}$. Here v₀ is the relative velocity at which the material from the Be wind or disk outflow encounters the NS. For a NS mass near 1.1 M_⊙ and considering v₀ ~ 100 km s⁻¹ (Smith et al. 2017), R_BHL amounts to about ~2.9 × 10⁷ km or 42 R_⊙.

Postnov et al. (2017) consider that the material in the shell behaves as an adiabatic ideal gas. This assumption then leads to a radial profile of the temperature and density that decreases outwards as $$T(s)=T_{\text{A}}\frac{R_{\text{A}}}{s}$$(7)

and $$n_{\text{e}}(s)=n_{e, \text{A}}{\left(\frac{R_{\text{A}}}{s}\right)}^{2/3},$$(8)

where s is the radial distance from the NS.

Postnov et al. (2017) further consider that the gas in the shell moves in turbulent motion at a velocity $$v_{\text{turb }}(s)=ϵ\sqrt{\left(\frac{\gamma kT(s)}{m}\right)}\text{, }$$(9)

with $ϵ\le 1,\gamma =\frac{5}{3}$, and m the mean mass of particle. Postnov et al. (2017) adopt v_turb = 1000 km s⁻¹ for the hottest gas². Over the radiative cooling time of ~1000 s, the hot gas would therefore travel out to a distance of order R_B ~ 100 R_A ~ 10⁶ km. This distance is significantly (29 times) smaller than R_BHL. We can thus assume that the hot plasma, which would constitute the primary X-ray source located between R_A and R_B, should be surrounded by a second shell of cooler gas (T < 1 MK) possibly extending out to R_BHL. A schematic view of this situation is provided in Fig. 2. The boundary between these two shells is somewhat arbitrarily set to the radial coordinate s where a temperature of 1 MK is reached according to Eq. (7). In reality, due to the turbulence (see Eq. (9)), several gas temperatures likely coexist over a given range of the radial coordinate s.

Adopting the value n_HA = 10¹³ cm⁻³ advocated by Postnov et al. (2017), the ionization parameter ξ (Eq. (1)) amounts to 0.22 at the inner boundary of the cool shell (R_B). This parameter decreases outwards as s^−4/3, reaching 0.0024 at R_BHL. According to Fig. 5 of Kallman et al. (2004), photoionization of iron would then result in Fe VI and Fe VII being the dominant ionization stages near the inner boundary of the cool shell. Farther out in the cool shell, photoionization would have a significantly lower impact, leaving Fe IV and Fe V as the dominant ionization stages. If we instead adopted n_H,A = 5 × 10¹⁴ cm⁻³ (see Sect. 3.2), then log ξ would be reduced by –1.70 and photoionization plays no significant role in setting the ionization stage of iron. Whilst we assume here for simplicity that the fluorescent emission involves ions of a single ionization stage, this assumption has no impact on our main conclusions regarding the overall strength of the fluorescent line.

We thus considered the contribution of this putative cool shell to the fluorescent emission. For this purpose, we discretized the cool shell into 100 sub-shells of linearly increasing radius. Each of these sub-shells is discretized according to polar angle (in steps of 1°) as measured from the direction of the line of sight towards the observer. Whilst the properties of the cool shell solely depend on the radial coordinate s and are independent of polar angle, the column density along the pathway from each sub-shell element to the observer does depend on polar angle. This column density is integrated numerically to compute the optical depth τ at the energy of the Fe Kα photons. The total fluorescent line emission results from the sum of the emission of each sub-shell element attenuated by the associated exp(−τ).

We can estimate the column density towards the primary X-ray source that this shell of cool material would produce $$\begin{array}{l}{N}_{\text{H}}={\displaystyle {\int }_{R_{\text{B}}}^{R_{\text{BHL}.}}{n}_{\text{H}}}\text{\hspace{0.17em}d}s={\displaystyle {\int }_{R_{\text{B}}}^{R_{\text{BHL}}}{n}_{\text{H},\text{A}}}{\left(\frac{R_{\text{A}}}{s}\right)}^{3/2} \text{d}s\\ =2n_{\text{H},\text{A}}{R}_{\text{A}}{\left(\frac{R_{\text{A}}}{R_{\text{B}}}\right)}^{1/2}\left[1-\sqrt{\frac{R_{\text{B}}}{R_{\text{BHL}}}}\right].\end{array}$$(10)

With n_H,A ≃ 10¹³ cm⁻³ and R_A = 10⁴ km (Postnov et al. 2017), we obtain a column density of around 1.6 × 10²¹ cm⁻². This value is comparable to the column densities found empirically in the spectral fitting of the X-ray spectra of γ Cas, although the obser-vationally determined column density varies strongly from one epoch to the other (Rauw et al. 2022). The existence of a shell of cool material around the primary X-ray source is thus not inconsistent with the observations.

As indicated in Eq. (9), the motion of the gas in the Bondi-Hoyle-Lyttleton volume is assumed to be dominated by turbulence with a turbulent velocity that is a fraction of the local speed of sound. As the temperature decreases outwards, the turbulent velocity should thus decrease from about 100 km s⁻¹ at R_B to about 20 km s⁻¹ at R_BHL. Hence, we expect the contribution of the cool shell to the Fe Kα line profile to have a relatively narrow shape, consisting of the combination of Gaussian line profiles of decreasing widths as we consider the contribution of layers of larger radii. The centre of this profile is expected to be shifted in velocity by the NS’s orbital motion. From the most recent orbital solution of γ Cas, we can estimate an amplitude of the orbital motion of the companion of K_NS ≃ 60 km s⁻¹. In our model, we thus assume that the line flux from a layer of radius s in the cool shell is distributed in a Gaussian profile of variance ${\sigma }^2=\frac{v_{\text{turb }}(s)}{2\mathrm{\hspace{0.17em}ln\hspace{0.17em}}2}$ and centred at K_NS sin (2 π ϕ). Here ϕ is the orbital phase with φ = 0 at the inferior conjunction of the NS star³. The contribution of the entire cool shell to the individual line profile is then obtained by combining the contributions from each sub-shell of radius s between R_B and R_BHL.

Fig. 2 Schematic illustration of the shells of hot and cool material in the propeller NS scenario. The different radii (RA, RB and RBHL) are not to scale. The curved trajectories illustrate the motion of heated particles as they drift outwards over the cooling time.

3 Results

3.1 Fe Kα emission from the Be disk

We discretized the Be disk into 18 000 cells, each of them spanning 2° in azimuthal angle, and extending over a radial distance dr = (R_out – R_*)/100. Our code computes the contribution of each cell according to Eq. (1), accounting for the cell’s visibility and illumination by the primary X-ray source. We ran our code assuming seed Fe ions of Fe I, Fe II, Fe III, or Fe IV. The resulting line luminosities and EWs are very similar for each of these ions. In the following we focus on the line profiles and line characteristics obtained assuming Fe IV seed ions. With our default parameters, we obtain a total line luminosity⁴ of 9.1 × 10²⁸ erg s⁻¹ and an EW of 1.35 eV. The individual line profiles for three different orbital phases are shown in Fig. 3. As expected, the line emission from the Be disk displays phase-dependent shifts of the line centroid (by about 200 km s⁻¹ peak-to-peak) as well as phase-dependent changes of the full width at half maximum (FWHM). The most important conclusion though is the fact that, with our default parameters, the predicted line EW is much lower than the observed range of EWs (from 34 to 59 eV, Rauw et al. 2022). Whilst we focus mostly on the comparison between the observed and synthetic EWs, exactly the same conclusions are reached by comparing observed and synthetic line fluxes. Indeed, in our calculations the continuum radiation against which the EW is computed is evaluated from the model that best fits the observed spectra, thus making both quantities, line flux and EW, equivalent.

Given our above discussion about the uncertainties affecting the density profile of the Be disk, we can ask ourselves what would be the impact of a different assumption on n₀ and α. The highest value of n₀ (3.6 × 10¹⁴ cm⁻³) was proposed by Grzenia et al. (2013), along with a value of α = 3.95 (i.e. the steepest density profile proposed for the disk of γ Cas). We thus tested this combination of parameters in our model, keeping all other parameters identical. This results in an EW of 0.83 eV, lower than what we have found with our default parameters. The reason is the high value of α, which leads to low densities in the outer disk regions, which are closest to the hard X-ray source. Hence, instead of looking for higher values of n₀, we tried a flatter power law. We thus adopted the density distribution proposed by Silaj et al. (2010) who derived α = 1.5 and n₀ = 4.5 × 10¹³ cm⁻³. These parameters lead to an EW of 5.90eV, about 4.5 times higher than the value for our default model. The corresponding line profiles are shown in the right panel of Fig. 3. Yet, this value of the EW is still well below the observed values. As a last step, we thus assumed that, instead of being truncated at the 3:1 resonance radius, the disk extended out to the radius of the Be star’s Roche lobe, namely R_out = 229R_⊙. For our default density profile, this assumption leads to EW = 2.18 eV, while we obtain 13.6eV when adopting the most extreme density profile (Silaj et al. 2010). The 13.6 eV value likely represents an upper limit to the contribution that we can expect from the Be disk in the case of γ Cas and assuming the NS propeller scenario.

Whilst Postnov et al. (2017) attributed the observed Fe Kα line to fluorescence from the Be disk, our results show that the EWs of the line contributed by the Be disk would be significantly smaller than the observed values. Therefore, we conclude that, additional contributions to the line are needed if the properties of γ Cas are to be explained by a propeller NS scenario.

Fig. 3 Predicted normalized individual Fe Kα line profiles for the Be disk. The line profiles are binned into velocity bins of 50 km s−1 and are normalized by dividing by the total flux over the entire line profile. The blue, black and red profiles correspond to orbital phases 0.75, 0.00 and 0.25 where phase 0.0 corresponds to the inferior conjunction of the NS. The left and right panels respectively illustrate the profiles obtained with our default set of parameters (Table 1) and with the disk density distribution of Silaj et al. (2010).

3.2 Fe Kα emission from the cool propeller shell

As a next step, we considered the contribution to the Fe Kα line from the cool shell around the NS’s magnetosphere. If we use the parameter n_H,A = 10¹³ cm⁻³ advocated by Postnov et al. (2017), we obtain an EW of the shell contribution of 0.77 eV. Together with the disk contribution for the default parameters this yields a total EW of 2.12 eV. This is again much lower than the observed line strength. If we rather set n_H,A = 5.0 × 10¹⁴ cm⁻³, the shell contributes 33.9 eV and the total EW becomes 35.3 eV. The corresponding individual line profiles are illustrated in Figs. 4 and 5, respectively, for n_H,A = 10¹³ cm⁻³ and n_H,A = 5.0 × 10¹⁴ cm⁻³.

As pointed out above, the Fe Kα feature is not a single line, but instead a complex array of transitions. To illustrate this, the total simulated profiles computed for the set of default parameters are displayed for four orbital phases in Fig. 6. For the purpose of this figure, we have adopted an Fe IV ionization stage for the fluorescent material, though we stress that very similar results are obtained for other ionization stages. In this plot, the blue histograms illustrate the synthetic spectrum with energy bins of 1 eV. The black curves illustrate the result of a convolution of this synthetic spectrum with a Gaussian whose FWHM is equal to 6 eV, which roughly mimics the instrumental response of the Resolve X-ray microcalorimeter aboard the XRISM satellite. Whilst the strength of the line simulated here (EW = 2.12 eV) is well below the actually observed value, it is worth stressing that the expected global shifts of the centroids with orbital phase are very similar if we assume higher values of n_H,A or a flatter disk density profile. The amplitude of these shifts are well within the reach of future high-resolution and high-sensitivity instruments such as Resolve on XRISM or the X-ray Integral Field Unit (X-IFU) on Athena, which should have energy resolutions of 5–7 eV and ≤4 eV, respectively.

As we have shown before, the hydrogen column density towards the primary X-ray source scales linearly with n_H,A (Eq. (10)). As long as the cool shell remains optically thin, the EW of the fluorescent line also scales linearly with n_H,A. At high densities, the relation between EW and N_H deviates however from a straight line because of the increasing optical depths. These relations are illustrated in Fig. 7. The horizontal axis of this figure indicates N_H in logarithmic scale. The vertical axis yields the EW of the full fluorescent Fe Kα line (i.e. including the contribution from the Be disk) in logarithmic scale. The corresponding curve is shown by the red line for the Be disk with the default parameters. The magenta lines delimit the range of observed values of EW(Fe Kα) from 34 to 59 eV. The cyan hatched area corresponds to the values of N_H towards the hot component as determined observationally (Rauw et al. 2022). These values range between 0.035 × 10²²cm⁻² and 1.38 × 10²² cm⁻². Figure 7 shows that the EW model curve does not cross the intersection between the cyan and magenta areas. Reproducing the observed EW range requires n_H,A of 4.7 × 10¹⁴ cm⁻³−10¹⁵ cm⁻³, whilst the highest observed absorbing column density restricts n_H,A to values below 8 × 10¹³cm⁻³. The highest value of the observed column density (1.38 × 10²² cm⁻²) was measured in an XMM-Newton observation in January 2021 when the X-ray spectrum of γ Cas was extremely absorbed (Rauw et al. 2022). The second highest value (1.16 × 10²² cm⁻²) was observed in January 2022. However, those high values are thought to be due to transient clouds crossing our line of sight. Most of the time, the column density is at least a factor of 3 lower than in January 2021 (Rauw et al. 2022), which pushes the upper limit on n_H,A towards even lower values of about 2.5 × 10¹³ cm⁻³. Therefore, in the propeller scenario with the default model parameters we obtain a mismatch by typically a factor of 20 between the values of n_H,A required to explain the EW(Fe Kα) and the values allowed by the observed column density⁵.

A by-product of the above is that, as long as the reprocessing material remains optically thin, one would expect a linear relation between the column density of cool material towards the primary X-ray source and the EW of the fluorescent Fe Kα line. Such a relation is indeed expected theoretically for a spherically symmetric distribution of the reprocessing material (e.g. Kallman et al. 2004), and was empirically established for a sample of X-ray binaries (Torrejón et al. 2010). Yet, no such correlation was found in multi-epoch X-ray data of γ Cas (Rauw et al. 2022).

At this stage, it is important to point out that increasing the value n_H,A to match the strength of the observed fluorescent line would also impact the overall X-ray luminosity of the propelling NS. According to Eq. (6) of Postnov et al. (2017), the X-ray luminosity of the hot shell scales with $n_{\text{H,A}}^2$. Therefore, increasing n_H,A by a factor of ~20 would not only lead to a mismatch with the observed column density, but would also imply a theoretical X-ray luminosity that exceeds the observed one by a large factor.

We tested whether extending the outer radius of the cool shell to the NS’s Roche lobe radius would make a significant change. The answer is no: compared to the situation where the outer radius was set to R_BHL, the EW of the line arising from the cool shell increases only by <10%.

As we have shown in Sect. 3.1, the contribution from the disk would be an order of magnitude higher if we adopt a flatter disk density profile (Silaj et al. 2010) and assume the disk to extend out to the Be star’s Roche lobe radius. The dashed blue line in Fig. 7 illustrates this situation. In this case, a range of n_H,A values between 2.7 × 10¹⁴ and 7.0 × 10¹⁴ cm⁻³ would allow a match between the total theoretical EW and the range of observed values. Even for this extreme disk model, we still find a mismatch by an order of magnitude between the n_H,A densities required to explain the EW(Fe Kα) and the values of n_H,A allowed from the observed column density.

Fig. 4 Predicted normalized individual Fe Kα line profiles for the propeller NS scenario with nH,A = 1013 cm−3. The line profiles are binned into velocity bins of 50 km s−1 and are normalized by dividing by the total flux over the entire line profile. The blue, black, and red profiles correspond to orbital phases 0.75, 0.00, and 0.25. The left and right panels respectively display the contribution of the cool shell around the propelling NS and the sum of this contribution and of the emission arising from the Be disk.

Fig. 5 Same as the right panel of Fig. 4, but for nh,a = 5.0 × 1014 cm−3.

Fig. 6 Illustration of the global line profile (i.e. combining the disk and shell contributions and accounting for the full array of transitions), adopting the default parameters of γ Cas at four different orbital phases. The blue histogram shows the spectrum binned in energy bins of 1 eV, whereas the black line provides the result of the convolution with an instrumental response of 6 eV. The magenta lines indicate the position of the centroids of the Kα1 and Kα2 subgroups at phase ϕ = 0.0.

Fig. 7 Dependence of the total EW(Fe Kα) from both the cool shell around the propelling NS and the Be disk on the hydrogen column density towards the hot X-ray plasma (evaluated according to Eq. (10)). The red and dashed blue curves illustrate the total EW(Fe Kα) computed respectively for the default model parameters and assuming a Be disk with a Silaj et al. (2010) density profile and extending out to the radius of the Roche lobe. The horizontal magenta lines illustrate the range of the observed EW values. The hatched cyan area illustrates the range of observed hydrogen column densities.

4 Other γ Cas stars

We now turn to the question whether other γ Cas stars display Fe Kα lines that agree with the predictions of the Postnov et al. (2017) model. For this purpose, we consider the cases of π Aqr and ζ Tau. Though there are other γ Cas stars that are brighter in X-rays (e.g. BZ Cru), we focus here on objects with well-established orbital periods and Be disk density profiles. Indeed, a good knowledge of both properties is crucial for our modelling. Among the known γ Cas stars that are established binary systems, π Aqr has the shortest orbital period (84.1 days; Bjorkman et al. 2002), thus illustrating a situation where the companion is closer to the Be disk, which should lead to an enhanced fluorescence by the disk material. On the other hand, ζ Tau illustrates the case of a shell star, where the system is seen in the plane of the Be disk. The parameters of these stars are discussed in Appendix A and are summarized in Table 1.

4.1 π Aqr

Applying our code to the parameters of the π Aqr system (assuming an amplitude of 8.1 km s⁻¹ for the Be star’s RV curve, Nazé et al. 2019a; Tsujimoto et al. 2023), we obtained once again rather low EWs. The contribution from the Be disk would only amount to 0.32 eV. Assuming n_H,A = 10¹³ cm⁻³, the cool shell would provide 0.75 eV. The combined EW then amounts to 1.07 eV, which is much smaller than the observed value of 68 ± 8 eV (Tsujimoto et al. 2023), and such a weak line would simply remain undetected with current X-ray observatories.

Adopting the same parameters, the value of the column density due to the cool shell would become 1.6 × 10²¹ cm⁻², which is close to the observed value (2.6 × 10²¹ cm⁻²). If the cool propeller shell were to account for most of the observed fluorescent line, and taking optical depth effects into account, the n_H,A density would have to be at least 120 times higher than our assumed value. This would then lead to a column density near 1.9 × 10²³ cm⁻² towards the primary X-ray source. This value is 75 times higher than the observational column density, which de facto rules out the existence of such large values of n_H,A.

For the π Aqr system, we note that R_BHL ≃ 38 R_⊙ is essentially identical to the radius of the NS’s Roche lobe (37.4R_⊙), provided that the NS has a mass of 1 M_⊙ (which is the case for the 8.1 km s⁻¹ amplitude). If instead, we adopt the larger RV amplitude found by Bjorkman et al. (2002) then the NS mass becomes 2.1 M_⊙ and the Bondi-Hoyle-Lyttleton radius (80 R_⊙) would exceed the NS’s Roche lobe radius (47.3 R_⊙) by a significant factor. Hence, if the larger RV amplitude holds, we would have to stop the integration at the NS’s Roche lobe radius, and the EW contributed by the cool shell would thus only increase by 0.03 eV reaching 0.35 eV.

Likewise, if we allow the Be disk to extend out to the Roche lobe radius of the Be star, but keeping the same density profile as before (n₀ = 0.45 × 10¹³ cm⁻³, α = 2.5), we obtain an EW of 0.45 eV, which will not resolve our issue. Explaining a significant fraction of the observed fluorescent line strength by the effect of the disk, would typically require an increase in n₀ by at least an order of magnitude, as well as a flatter density profile.

We thus conclude that, in the case of π Aqr, we are left with the same dilemma as for γ Cas: with the best estimates of the system characteristics it is simply not possible to explain the strength of the observed Fe Kα line within the framework of the propelling NS scenario.

4.2 ζ Tau

Finally, we consider the ζ Tau system. Using our code with the default parameters yields an EW of the truncated Be disk contribution between 1.14 and 1.20 eV depending on orbital phase. If instead the disk extended out to the Be star’s Roche lobe, then it would contribute between 1.67 and 1.73 eV. The mild phase dependence arises from the near edge-on inclination of the Be disk: depending on the orbital phase the Be star occults some parts of the disk illuminated by the primary X-ray source. Accordingly, the highest and lowest emission strengths would be observed respectively at inferior and superior conjunction of the NS. Likewise, adopting n_H,A = 10¹³ cm⁻³, the cool shell around the propeller would provide 0.70 eV (or 0.73 eV if the shell extends out to the NS’s Roche lobe). This results in a combined EW of 1.84–1.90 eV if we consider the default parameters, which is again much smaller than the observed strength of ~55 ± 8 eV (Nazé et al., in prep.).

The associated column density towards the primary source due to the cool shell would be equal to 1.6 × 10²¹ cm⁻², which is much smaller than the value determined from the Chandra spectrum (1.55 × 10²³ cm⁻², Nazé et al. 2022b) or from a recent XMM-Newton observation (1.76 × 10²³ cm⁻², Nazé et al., in prep.). Due to the orientation of the Be disk with respect to our line of sight, such an extremely high value could, to a large extent, reflect the absorption by the Be disk rather than the sole effect of the shell. In the context of our present study, where we wish to test the scenario of a primary X-source arising from the hot shell of a NS in the propeller stage, the observational column density could be reproduced by an increase in n_H,A by a factor of ~100 to n_H,A = 1.0 × 10¹⁵ cm⁻³. Such a value of the density at the Alfvén radius would render the cool shell mildly optically thick. Accounting for the optical depth, we estimate an EW of 54.5 eV for the corresponding cool shell contribution. Compared to an optically thin shell, the optical depth of the shell leads to a reduction of the EW by 22%. Whilst a value of n_H,A = 1.0 × 10¹⁵ cm⁻³ could thus explain both the observed column density and EW of the Fe Kα line, according to Eq. (6) of Postnov et al. (2017), it would imply a drastic increase in the X-ray luminosity of the hot shell well beyond the observed value.

5 Discussion

X-ray spectra of γ Cas stars display a prominent Fe line complex that includes a clear contribution of a fluorescent line due to low-ionization Fe atoms. Our calculations indicate that the model proposed by Postnov et al. (2017) struggles to account for the observed strengths of these fluorescent Fe Kα lines. With the default parameters of the propeller model, the predicted line strength would be way too low for this line to be detectable in all three of the stars investigated in this study.

A way to overcome the problem would be to invoke geometrical effects that either prevent us from seeing the true level of the intrinsic primary X-ray emission or lead to the true column density of the reprocessing material being much higher than what is estimated from the observed photo-absorption column density. Whilst such a scenario could hold for a single system observed at a specific phase (e.g. similar to a high-mass X-ray binary in eclipse), it seems unlikely for three systems that have been observed at a variety of orbital phases and always yielded a similar global picture.

In our model, we consider reprocessing by material in the Be disk and in a cool shell around the propelling NS. One could speculate that the polar wind of the Be star plays some role in the fluorescent process. Using International Ultraviolet Explorer (IUE) spectra, Prinja (1989) detected a wind signature in the CIV λλ 1548, 1550 doublet of γ Cas. From a fit to the line profile, he inferred a terminal wind velocity of 1500 km s⁻¹ and a value of $\log \left[\dot{M}q\left({\text{C}}^{3+}\right)\right]=-10.46\left(\text{ in }{M}_{\odot }{\hspace{0.17em}\text{yr}}^{-1}\right)$. Assuming the same ionization fraction in Be-star winds as in O-star winds, this value would correspond to a mass-loss rate of 3.8 × 10⁻⁸ M_⊙ yr⁻¹. Smith & Robinson (1999) and Cranmer et al. (2000) measured a higher terminal velocity of 1800 km s⁻¹ from the blue edge of discrete absorption components in the Si IV λλ 1394, 1403 lines observed in Hubble Space Telescope spectra. Adopting a mass-loss rate of 5 × 10⁻⁸ M_⊙ yr⁻¹ and a wind velocity of 1500 km s⁻¹, a generous upper limit on the electron density at the position of the NS is ~1.7 × 10⁶ cm⁻³ (see also Cranmer et al. 2000). This is about 50 times lower than the density of the cool shell at its outer boundary, R_BHL, assuming n_H,A = 10¹³ cm⁻³. Hence, this polar wind is extremely unlikely to play any significant role in the formation of the fluorescent line.

The results of our calculations depend on the atomic parameters that were used. Atomic parameters used in astrophysics are subject to uncertainties, and the quantities used in our calculations are no exception to that rule. Comparing Fe K fluorescent transition probabilities computed with different approximations, Palmeri et al. (2003) concluded that the atomic parameters are likely accurate to 10%. To increase the strength of the synthetic lines up to the level of the observed lines, one would need to increase the fluorescence yields and cross-section by much more than this 10%. Moreover, fluorescence yields are by definition lower than 1, but to match the observed line strengths, one would have to increase them by more than a factor of 3, which would make them exceed this upper limit.

Finally, one could ask whether the usage of solar Fe abundance (Asplund et al. 2009) is appropriate. A higher than solar Fe abundance could indeed alleviate the mismatch between calculations and observations. Yet, we need to keep in mind that fluorescent Fe Kα is not the only Fe line in the X-ray spectrum of γ Cas. The primary X-ray spectrum also displays several Fe XVII lines around 0.7–0.8 keV as well as the Fe XXV triplet near 6.7 keV and the Fe XXVI Ly α lines at 6.97 keV. These features help constrain the Fe abundance in global fits of the X-ray spectrum. Such fits do not provide any evidence of higher than solar abundance, and instead yield a sub-solar Fe abundance (Smith et al. 2004; Lopes de Oliveira et al. 2010; Rauw et al. 2022), which would only increase the discrepancy.

Torrejón et al. (2010) analysed Fe K fluorescent lines in Chandra High Energy Transmission Grating high-resolution spectra of a sample of X-ray binaries, including nine high-mass X-ray binaries (HMXBs) and γ Cas. They established that the wavelengths of the fluorescent Fe Kα lines indicate that they arise from Fe ions up to Fe X. Torrejón et al. (2010) further found that the lines are narrow (FWHM < 5 mÅ), which indicates that the reprocessing material is unlikely to rotate at high velocities (as would be the case for the inner regions of an accretion disk close to an accreting NS). The empirical relation between the EW (Fe Kα) and the column density of the absorbing material suggests a roughly spherical distribution of the reprocessing material. Torrejón et al. (2010) also showed that X-ray binaries display a so-called X-ray Baldwin effect, that is to say, an anti-correlation between the X-ray luminosity and EW(Fe Kα). This result was confirmed by Giménez-García et al. (2015) based on an independent sample of the XMM-Newton European Photon Imaging Camera (EPIC-pn) spectra of HMXBs. This effect was interpreted as a decrease in the volume of reprocessing material due to increasing ionization when the X-ray luminosity increases. In the propeller scenario for γ Cas stars, one could expect a very similar behaviour, as the boundary between the hot and cool shell would move farther out in response to an increase in the X-ray luminosity, thereby decreasing the available volume of reprocessing material. Quite interestingly though, this effect is not observed in γ Cas stars as a group (Giménez-García et al. 2015) nor in γ Cas itself when considering observations from different epochs (Rauw et al. 2022). This suggests that the conditions for fluorescence are fundamentally different in supergiant HMXBs and γ Cas stars.

We thus conclude that the observed strength of Fe Kα in γ Cas stars is at odds with the propeller NS scenario. This is actually not the only problem that this scenario encounters. Smith et al. (2017) previously refuted the propeller scenario on other grounds. Indeed, it does not account for the observed correlations between the UV and X-ray emission of γ Cas because the density assumed by Postnov et al. (2017) at the Alfvén radius is too low compared to the density required to explain the very short decay time of the shots seen in the X-ray light curve. Indeed, the X-ray emission of γ Cas stars varies over many different timescales, from a few seconds to months and years. The most rapid variations take the form of shots on timescales as short as 4s (Smith et al. 1998). Such short decay times require densities of >10¹⁴ cm⁻³, which exceed those assumed by Postnov et al. (2017) for the shell of the propeller NS. Finally, based on evolutionary considerations, Smith et al. (2017) show that the short duration of a propeller phase is unlikely to account for the number of γ Cas stars compared to the population of known Be HMXBs. This argument has been reinforced over the last few years as the number of known γ Cas stars has considerably increased since 2017 (Nazé & Motch 2018; Nazé et al. 2020, 2022b; Nazé & Robrade 2023). Therefore, in view of the various results and considerations in this paper as well as the other problems identified by Smith et al. (2017), we can now answer the question raised in the title of this article: it seems very unlikely that the γ Cas phenomenon traces a population of Be stars orbited by a propelling NS.

Acknowledgements

G.R. thanks Dr. Patrick Palmeri for discussion about the details of the fluorescence mechanism, as well as Jahanvi and Drs. Yaël Nazé, Myron Smith and Christian Motch for numerous discussions about various aspects of γ Cas stars. This research is supported by the BELgian federal Science Policy Office (BELSPO) and the European Space Agency through the PRODEX HERMeS grant.

Appendix A Stellar and disk parameters of π Aqr and ζ Tau

In this appendix we provide an overview of the literature on π Aqr and ζ Tau, which is relevant for the input parameters needed for our model (see Table 1).

Pi Aqr (also known as HD 212571) is classified as a B1 III-IVe star. The γ Cas nature of its X-ray emission was discovered by Nazé et al. (2017). The hot plasma component has a temperature of 11.5 keV (Nazé et al. 2017; Nazé & Motch 2018), and the flux (corrected for interstellar absorption) amounts to 1.07 × 10⁻¹¹ erg cm⁻² s⁻¹ in the 0.5–10 keV energy range. The circumstellar hydrogen column density was found to be 0.26 × 10²² cm⁻² (Nazé et al. 2017). The EW of the Fe Kα line is reported at a value of (68 ± 8) eV by Tsujimoto et al. (2023). Bjorkman et al. (2002) observed π Aqr when the disk had cleared away and showed that it is a binary with an essentially circular orbit with a period of 84.1 days. These authors obtained an SB2 orbital solution with a semi-amplitude of 16.7 km s⁻¹ for the Be star, and 101.4 km s⁻¹ for the weak Hα emission line that moved in anti-phase with the absorption line of the B1 star. Their results imply dynamical masses of m_Be sin³ i = 12.4 M_⊙ and m_comp sin³ i = 2.0 M_⊙ (Bjorkman et al. 2002). However, more recent studies, performed when the disk had re-developed, led to a significantly lower semi-amplitude of the Be star’s orbital motion of about 8.1 km s⁻¹ (Nazé et al. 2019a,b; Tsujimoto et al. 2023). This situation implies considerable uncertainties on the masses of the components: the Be star’s dynamical mass m_Be sin³ i = 12.4 M_⊙ obtained by Bjorkman et al. (2002) was converted into a mass of (14 ± 1) M_⊙ by Zharikov et al. (2013), whilst Catanzaro (2013) and Nazé et al. (2019b) respectively estimate 13 and (11 ± 1.5) M_⊙. Adopting the lower semi-amplitude of the Be star’s RV curve, the dynamical masses become m_Be sin³ i = 10.6 M_⊙ and m_comp sin³ i = 0.85 M_⊙. We adopt here a mass of the Be star of 12.7 M_⊙, which is the mean of the above estimates. Kepler’s third law then implies a semi-major axis of 193 R_⊙ for the lower RV semiamplitude and 198 R_⊙ for the higher RV semi-amplitude. For the stellar radius, Zharikov et al. (2013) estimated 13.0 R_⊙ whilst other literature estimates rather fall in the range 5.9 to 7.7 R_⊙ (Catanzaro 2013; Arcos et al. 2018; Nazé et al. 2019b). The larger radius proposed by Zharikov et al. (2013) most likely stems from their higher distance estimate of 740 pc, whilst Hipparcos and Gaia parallaxes rather suggest a distance around 240 pc (Nazé & Motch 2018; Arcos et al. 2018). Here, we adopt a value of 6.5 R_⊙ for the stellar radius. This then leads to a Keplerian velocity of 610 km s⁻¹ at the inner edge of the Be disk. Effective temperatures between 23.3 and 27.6kK are quoted in the literature (Bjorkman et al. 2002; Frémat et al. 2005; Touhami et al. 2010; Zharikov et al. 2013; Arcos et al. 2018; Nazé & Motch 2018; Nazé et al. 2019b). We take the mean of 25 kK. Orbital and/or disk inclinations are estimated between 50–75° (Bjorkman et al. 2002), 45° (Silaj et al. 2010), 65–85° (Zharikov et al. 2013), 60° (Arcos et al. 2017), 50–75° (Nazé et al. 2019b), and (56 ± 5)° (Sigut & Ghafourian 2023). The lowest values would lead to an unusually large absolute dynamical mass for the Be star. We thus adopt a value of 70^° consistent with the estimated dynamical minimum mass and our above mass estimate for the B1 star. The density at the inner edge of the disk was evaluated to be 10⁻¹¹ gcm⁻³ (Silaj et al. 2010), 6 × 10⁻¹³ gcm⁻³ (Catanzaro 2013), 7.5 × 10⁻¹²−10⁻¹¹ gcm⁻³ (Arcos et al. 2017). This rather wide range reflects at least partially the epoch-dependence of the disk strength which has increased significantly over the last decade (Nazé et al. 2019a; Tsujimoto et al. 2023). The values of Arcos et al. (2017) were obtained at epochs close to the XMM-Newton observation. Hence, we adopt here a value of 10⁻¹¹ gcm⁻³ which translates into an hydrogen number density of 4.5 × 10¹² cm⁻³. The disk density power-law exponent α of π Aqr ranges between 2.5 and 3.5 (Silaj et al. 2010; Catanzaro 2013; Arcos et al. 2017). We adopted α = 2.5, the value from Arcos et al. (2017). With q = 0.165 (higher RV amplitude) or q = 0.080 (lower RV amplitude), the Roche lobe radius of the Be star is estimated respectively to 106.3 or 115.0 R_⊙. Likewise, for the companion we obtain a Roche lobe radius of 47.3 or 37.4 R_⊙. Finally, the 3:1 resonance truncation radius of the Be disk amounts to 91 R_⊙.

Zeta Tau (= HD 37202) is a B1 IVe shell star. A first estimate of the characteristics of its X-ray spectrum was derived by Nazé et al. (2022b) from a heavily piled-up Chandra spectrum. A plasma temperature of 11.1 ± 4.3 keV was inferred, along with a flux of 1.66 × 10⁻¹¹ erg cm⁻² s⁻¹ evaluated over the 0.5–10 keV band and corrected for ISM absorption. The cir-cumstellar absorption column was found to be rather high with (15.5 ± 2.0) × 10²² cm⁻². A recent, pile-up free, XÍMM-Newton observation yielded a plasma temperature of 9.0 ± 0.3 keV, an ISM-corrected flux of 1.76 × 10⁻¹¹ erg cm⁻² s⁻¹ and a circumstellar column density of (17.6 ± 0.2) × 10²² cm⁻² (Nazé et al. in prep.). The mass of the Be star is estimated close to 11.2 M_⊙ (Gies et al. 2007; Carciofi et al. 2009; Ruždjak et al. 2009; Touhami et al. 2011). For the mean stellar radius, values of 5.5 R_⊙ (Gies et al. 2007; Touhami et al. 2011) or 6.1 R_⊙ (Cochetti et al. 2019) are given in the literature. Carciofi et al. (2009) accounted for the rotational flattening and rather proposed 5.9 and 7.7 R_⊙, respectively, for the polar and equatorial radii. Since we use the stellar radius as the inner radius of the disk, which is assumed to lie in the equatorial plane, we adopt a radius of 7.7 R_⊙. These numbers lead to an orbital velocity of 525 km s⁻¹ at the inner edge of the circumstellar disk. Mean effective temperatures were derived in the range from 19.0 to 20.1 kK (Grundstrom & Gies 2006; Gies et al. 2007; Cochetti et al. 2019). Accounting for gravity darkening, Carciofi et al. (2009) inferred 18.0 and 25.0kK, respectively, at the equator and at the pole. We adopt here a value of 20 kK. The inclination of the Be disk is usually given in the range from 75^° to 89^° (Grundstrom & Gies 2006; Gies et al. 2007; Carciofi et al. 2009; Touhami et al. 2011) with the exception of Cochetti et al. (2019) who rather quote an inclination of 67^°. We adopt a value of 85^°, consistent with the shell aspect of the Balmer lines. Estimates of the density at the inner edge of the disk range from 5.9 × 10⁻¹¹ gcm⁻³ to 1.9 × 10⁻¹⁰ gcm⁻³ (Gies et al. 2007; Carciofi et al. 2009; Touhami et al. 2011). The mean value 1.3 × 10⁻¹⁰ g cm⁻³ translates into a hydrogen number density of 5.8 × 10¹³ cm⁻³. The α exponent ranges between 2.9 and 3.5 (Gies et al. 2007; Carciofi et al. 2009; Touhami et al. 2011; Klement et al. 2019) and we adopt a value of 3.0. The p exponent was assumed to be 0 by Carciofi et al. (2009). ζ Tau has an orbital period of 132.987 days and a likely companion mass of 0.87–1.02 M_⊙ (Ruždjak et al. 2009), which results in a mass ratio q = 0.086. Kepler’s third law then yields an orbital separation of 252 R_⊙, and the Roche lobe radii are estimated to 148.7 R_⊙ for the Be star and 49.9 R_⊙ for its companion. The 3:1 truncation radius of the Be disk amounts to 118 R_⊙. The semi-amplitude of the Be star’s orbital motion is 7.4 km s⁻¹ (Ruždjak et al. 2009; Nazé et al. 2022b). For the distance of ζ Tau, we adopt 136pc (Nazé et al. 2022b).
