Fast analytical calculation of the random pair counts for realistic survey geometry
Aix Marseille Univ., CNRS, CNES, LAM, Marseille, France
email: michelandres.breton@lam.fr
Received:
6
October
2020
Accepted:
14
December
2020
Galaxy clustering is a standard cosmological probe that is commonly analysed through twopoint statistics. In observations, the estimation of the twopoint correlation function crucially relies on counting pairs in a random catalogue. The latter contains a large number of randomly distributed points, which accounts for the survey window function. Random pair counts can also be advantageously used for modelling the window function in the observed power spectrum. Since pair counting scales as 𝒪(N^{2}), where N is the number of points, the computational time to measure random pair counts can be very expensive for large surveys. In this work, we present an alternative approach for estimating those counts that does not rely on the use of a random catalogue. We derived an analytical expression for the anisotropic randomrandom pair counts that accounts for the galaxy radial distance distribution, survey geometry, and possible galaxy weights. We show that a prerequisite is the estimation of the twopoint correlation function of the angular selection function, which can be obtained efficiently using pixelated angular maps. Considering the cases of the VIPERS and SDSSBOSS redshift surveys, we find that the analytical calculation is in excellent agreement with the pair counts obtained from random catalogues. The main advantage of this approach is that the primary calculation only takes a few minutes on a single CPU and it does not depend on the number of random points. Furthermore, it allows for an accuracy on the monopole equivalent to what we would otherwise obtain when using a random catalogue with about 1500 times more points than in the data at hand. We also describe and test an approximate expression for datarandom pair counts that is less accurate than for randomrandom counts, but still provides subpercent accuracy on the monopole. The presented formalism should be very useful in accounting for the window function in nextgeneration surveys, which will necessitate accurate twopoint window function estimates over huge observed cosmological volumes.
Key words: cosmology: miscellaneous / largescale structure of Universe / methods: numerical / methods: statistical
© M.A. Breton and S. de la Torre 2021
Open Access article, published by EDP Sciences, under the terms of the Creative Commons Attribution License (https://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
1. Introduction
The spatial distribution of galaxies has a long history of providing cosmological parameter constraints (e.g., Strauss et al. 1992; Vogeley et al. 1992; Maddox et al. 1996; Peacock et al. 2001; Cole et al. 2005; Tegmark et al. 2006; Percival et al. 2010; Blake et al. 2012; de la Torre et al. 2013; Alam et al. 2017; eBOSS Collaboration 2020, and references therein). This arises from the fact that the statistical properties of galaxies, particularly spatial ones, can be predicted by cosmological models. When analysing galaxy clustering, we usually compress the information by using summary statistics, the most natural one being the twopoint correlation function or its Fourier counterpart in the power spectrum. This is due to the nearly Gaussian nature of primordial matter perturbations, which are almost fully described by their twopoint statistics. Although gravitational evolution leads to nonGaussianity, and in turn, nonvanishing higherorder npoint statistics, twopoint statistics continues to be very informative.
Despite the cosmological principle that implies that the correlation function is isotropic, meaning that it is only a function of the norm of the separation vector, because of the way the lineofsight distance is measured in redshift surveys and the presence of peculiar velocities, the observed correlation function becomes anisotropic. These velocities are induced on large scales by the coherent convergence of matter towards overdensities as part of the general process of structure growth. This anisotropy makes observed galaxy npoint statistics sensitive to the strength of gravity acting on the largescale structure (Kaiser 1987; Guzzo et al. 2008).
Formally, the twopoint correlation function is the excess probability of finding a pair of objects at a given distance, with respect to the expectation in a random Poisson distribution of points. In practice, we rely on statistical estimators to measure the correlation function from galaxy survey data. The first estimator was proposed by Peebles & Hauser (1974), taking the form ξ_{PH}(s) = DD(s)/RR(s)−1, where DD and RR are the normalised number of distinct pairs separated by a vector s, in the data and random samples, respectively. The latter sample is constructed such that random points follow the same radial and angular selection functions as the data. Other estimators were later proposed (Hewett 1982; Davis & Peebles 1983; Hamilton 1993) to reduce the estimation variance, notably induced by discreteness and boundary effects. In particular, the Landy & Szalay (1993) minimumvariance estimator was designed such that for any survey geometry, its variance is nearly Poissonian. This estimator, defined as
makes use of additional datarandom pairs DR. To estimate the correlation function, we therefore need to compute the number of pairs as a function of the separation. To avoid introducing bias in the estimator and to minimise variance, the random catalogue must be much larger than the data catalogue (Landy & Szalay 1993; Keihänen et al. 2019). We usually consider that taking at least about 20−50 times more random points than objects in the data is enough to avoid introducing additional variance (e.g., Samushia et al. 2012; de la Torre et al. 2013; Sánchez et al. 2017; Bautista et al. 2021). A problem is that the computational time for direct pair counting scales as 𝒪(N^{2}), with N the number of elements in a given sample. Nonetheless, the complexity can be reduced, at best, to 𝒪(N) using appropriate algorithms and various efficient codes that implement them have been developed (e.g., Moore et al. 2001; Jarvis et al. 2004; Alonso 2012; Hearin et al. 2017; Marulli et al. 2016; Slepian & Eisenstein 2016; Sinha & Garrison 2020). For the randomrandom pairs calculation specifically, additional strategies can be used to speed up the computation beyond parallelisation, such as splitting the random sample and averaging the counts over subsamples (Keihänen et al. 2019). Still, for large surveys, the computational time for estimating the correlation function, especially randomrandom pairs, can become an issue. In particular, nextgeneration surveys such as Euclid (Laureijs et al. 2011) or DESI (DESI Collaboration 2016), will necessitate random samples as large as about 3 × 10^{8} objects in several redshift bins, or even larger if we consider a single, wideredshift bin (e.g., Mueller et al. 2019; Castorina et al. 2019).
The role of randomrandom pair counts in the correlation function estimator is to account for the survey selection function, that is, the effective observed volume and its impact on the datadata pair counts. In Fourier space instead, common estimators for the power spectrum (e.g., Feldman et al. 1994; Yamamoto et al. 2006) provide a direct estimate of the windowconvolved power spectrum. To be able to compare theoretical predictions to observations, it is necessary to convolve the model power spectrum with the survey window function. This convolution is computationally expensive in the likelihood analysis, but it can be done efficiently by performing a multiplication in configuration space, as proposed by Wilson et al. (2017). The latter shows that the windowconvolved power spectrum multipoles moments can be written as:
where ℋ denotes the Hankel transform, are coefficients, ξ_{ℓ}(s) are model correlation function multipole moments, 𝒩 is a normalisation factor, RR_{ℓ}(s) are the multipole moments of the randomrandom pair counts, and Δs is the bin size in s (Wilson et al. 2017; Beutler et al. 2017).
Randomrandom pairs counts are a purely geometrical quantity that depends on cosmology only through the radial selection function, which is defined in terms of the radial comoving distance. In the case of a simple geometry, such as a cubical volume with constant number density and periodic boundary conditions, the RR pair counts can be predicted from the appropriately normalised ratio between the spherical shell volume at s and the total volume. In the case of a realistic survey geometry, and taking advantage of the fact that radial and angular selection functions are usually assumed to be uncorrelated, Demina et al. (2018) developed a semianalytical method to compute the RR and DR pair counts along the directions parallel and transverse to the line of sight, but still using a random sample to account for angular correlations. In fact, the process of spectroscopic observation can break this assumption, making radial and angular selection functions partially correlated. Nonetheless, in practice, as in the case of fibre or slit collision, for instance, we can assume independence in building RR but while applying an object or pairwise weighting scheme to account for those correlations (e.g., de la Torre et al. 2013; Bianchi & Percival 2017; Ross et al. 2017).
In this paper, we provide general expressions for the anisotropic RR and DR pair counts in the case of a realistic survey geometry, including the cases for the different definitions of the pair’s line of sight. We apply this formalism to the VIMOS Public Extragalactic Redshift Survey (VIPERS, Guzzo et al. 2014; Garilli et al. 2014) and Sloan Digital Sky Survey Baryon Oscillation Spectroscopic Survey (SDSSBOSS, Eisenstein et al. 2011; Dawson et al. 2013) and we perform an assessment of the accuracy of the method.
This paper is organised as follows. Section 2 presents the formalism for randomrandom and datarandom pair counts. This formalism is applied and its accuracy assessed in Sect. 3. We conclude in Sect. 4.
2. Formalism
In this section, we provide the analytical formalism for the randomrandom and datarandom pair counts.
2.1. Randomrandom pairs
In a survey sample where sources are selected in redshift, the number of sources in a given radial distance interval [r_{min}, r_{max}] is:
with p(r) the number of sources as function of the radial distance r and
where W(θ, φ) is the survey angular selection function in spherical coordinates. The latter encodes the probability of observing a source at any angular position on the sky and takes values from 0 to 1. Here, n(r) is the source number density given by
with ⟨W⟩ the angular selection function averaged over the full sky. We note that radial weights, such as those of Feldman et al. (1994), can be included straightforwardly in the p(r), such that this becomes a weighted radial distribution in the equations. The total number of observed sources is therefore:
In RR(s), we correlate points at two different positions r_{1} and r_{2} and it is convenient to write
with s = r_{2} − r_{1} and μ = r_{1} ⋅ s/r_{1}s. RR is obtained by integrating the angular and radial selection functions first over (r_{1}, θ, φ) and then over the volume defined by the separation () as:
where θ_{1}, φ_{1} (θ_{2}, φ_{2}) are the angular positions at r_{1} (r_{2}). Let us define and , we have then
and the correlation function of the angular selection function is
In our case, since we autocorrelate randoms points, RR will only depend on the angular separation (for crosscorrelations with different angular selection functions, we would need to keep the angular dependence). This means that we can write ω(ϕ) = ω(ϕ), where we have
We note that in the absence of an angular mask, that is, when we evenly probe the full sky, ω(ϕ) = 1. In compiling these results, we find that:
We note that we have implicitly assumed an ‘endpoint’ definition for the pair line of sight, that is, for every separation, the direction of the line of sight coincides with that of r_{1}. With this definition, we can just use for the integral limits in Eq. (12). In the case of the ‘midpoint’ definition for the pair line of sight, where μ = r ⋅ s/rs with , we can use the same equation, but we need to change the integral limits for each {r_{1}, s, μ} as:
We note that for the endpoint definition it is important to compute pairs with μ < 0 since the correlation function in that case is not symmetric by pair exchange. For applications involving randomrandom multipole moments directly, the latter can be defined as:
with ℒ_{ℓ} the Legendre polynomial of order ℓ. For the endpoint definition, μ^{†} = μ, while for the midpoint definition we have
with . Finally, we note that in order to crosscorrelate tracers with different radial selection functions but the same angular selection function, we can use the same formalism but with different n_{A}(r_{1}) and n_{B}(r_{2}) in Eqs. (12)–(14).
2.2. Datarandom pairs
The Landy & Szalay (1993) estimator includes datarandom pairs to minimise variance. A similar formalism to that used for randomrandom pair counts can be employed to evaluate datarandom pair counts. However, contrarily to the RR case, we now have to crosscorrelate a discrete set of sources with a continuous random distribution. The discrete limit of Eq. (3) is
with δ_{D} the Dirac delta function, r = (r, θ, φ), and r_{i} the ith source position in the data vector. We can then use the same methodology as in Sect. 2.1. To make the computation of the datarandom pair counts tractable we make the assumption:
with and the angular position in the data vector. Under this assumption, the angular correlation at a particular point is given by that of the whole sample. For a largeenough N and a sufficiently homogeneous angular sampling of the data, the approximation should hold. We find that:
with
where we integrate over all the data and angular selection function positions. In practice, we can crosscorrelate a map containing the galaxy number density per pixel with the angular selection function map. Introducing a generic data weight w_{i}, for each source and assuming that the angular crosscorrelation function does not depend on the pair orientation, we obtain
We can already see that the calculation involves a sum over all data sources, which is potentially more computationally expensive to evaluate than in the RR and direct paircounting cases. Nonetheless, to make the computation efficient, we can approximate this by taking the continuous limit on the sum and write it out similarly as we do for the RR case:
where the angular crosscorrelation function, ω_{DR}, can be written as ω_{DR} = ⟨W_{1}W_{2}⟩, with W_{1} as a pixelated map containing (weighted) source counts and W_{2} as the angular selection function as in Sect. 2.1. In this case, the normalisation on W_{1} and W_{2} does not matter since the final result is proportional to . In principle, Eq. (21) should be close to Eq. (20) when the p(r) is fine enough to faithfully reproduce data radial overdensities.
3. Application
In this section, we apply our formalism for RR and DR pair counts to the case of BOSS and VIPERS redshift surveys and test its accuracy.
3.1. Numerical implementation
The method takes as input the radial distance distribution of sources and the correlation function of the angular selection function. To compute the latter, we first produce a HEALPIX (Górski et al. 2005) fullsky map from the survey angular mask, which is generally in form of a list of distinct spherical polygons with associated weights. We infer the angular correlation function from the maps using POLSPICE (Szapudi et al. 2001; Chon et al. 2004), which takes advantage of HEALPIX isolatitude pixelation scheme to quickly evaluate the angular correlation function ω(θ) with fast spherical harmonic transforms. The CPU time to compute the angular correlation function depends on the map resolution, but it is generally quite efficient. The map resolution is controlled by the nside^{1} parameter. For instance, for BOSS it takes 3, 20 and 130 min on a single CPU for nside = 2048, 4096, and 8192, respectively. For VIPERS, it takes 6, 40, and 320 min for nside = 8192, 16384, and 32768, respectively. We note that we compute the angular power spectra until ℓ_{max} = 3 × nside; it is possible to reduce the run time by reducing ℓ_{max}. The main limitation is memory since this operation needs to load the fullsky map, which can be difficult for highresolution maps. Once the correlation function of the angular mask, average map value ⟨W⟩, and average map squared value ⟨W^{2}⟩ are computed, we can estimate the pair counts. This can be done by numerically evaluating the multidimensional integrals of Eqs. (12) and (20) (or (21)), respectively, for RR and DR. We tested different integration schemes, namely:

GSL (Gough 2009) integration algorithm cquad;

CUBA library (Hahn 2005) set of optimised algorithms for multidimensional integration: vegas, suave, divonne and cuhre.
In each case, we need to specify a maximum tolerance on the integral relative error ε. The GSLcquad algorithm only performs onedimensional integrals, and we thus implement nested integrals with same ε to perform the full threedimensional integral. There are three potential sources of error associated to the analytical pair count calculation: the p(r) estimation, the ω(θ) estimation, and the precision on numerical integrals. In our methodology, the error level associated to each source is controlled respectively by the binning in p(r), angular map resolution nside, and ε. In the last case however, we note that different algorithms can yield slightly different results even if ε is very small.
Regarding the performances of the RR implementation, for the two considered surveys and considering 6000 bins in (s, μ), the full RR(s, μ) based on Eq. (12) takes about 5−20 min on a single CPU using the CUBA library, even for ε ≈ 10^{−6} (GSL takes significantly more time when ε < 10^{−3}). In principle, we gain an additional factor of two when using the pair lineofsight midpoint definition, as in that case, there is a symmetry along the line of sight for autocorrelation and we only need to compute μ > 0 pairs. The run time depends on the number of bins in (s, μ) but also in principle, on the shape of the integrand, as for complex p(r) or ω(θ), the integrals will take more time to converge (although, in our case, we did not see any noticeable difference). For the RR multipole moments in Eq. (14), the calculation only takes about 5 s with CUBA algorithms using 30 bins in s, independently of the adopted value of ε.
Regarding DR, the run times for the approximation in Eq. (21) are similar to those for RR by definition. However, the evaluation of Eq. (20) leads to large computational times of up to several weeks on a single CPU for large datasets. The run times scale linearly with the number of objects in the data sample. In that case, direct datarandom pair counting might be more efficient.
The C code that follows this implementation is publicly available^{2}. It can be used with any input p(r) and ω(θ) to predict RR or DR pair counts.
3.2. Survey selection functions
We consider two realistic redshift survey selection functions, those of SDSSBOSS DR12 CMASS (Alam et al. 2015) and VIPERS PDR2 (Scodeggio et al. 2018) galaxy samples. We use the public galaxy catalogues^{3} and associated angular masks. Those two samples have complementary properties and thus allow testing the method in different conditions. Indeed, while BOSS survey is wide and has a low galaxy number density, VIPERS is much narrower and denser. Each survey is composed of two separated fields on the sky but here we only consider the BOSS North Galactic Cap (NGC) and VIPERS W1 fields and we focus on 0.5 < z < 0.75 and 0.7 < z < 1.2 redshift intervals for BOSS and VIPERS, respectively.
The radial selection functions are shown in Fig. 1. The BOSS p(r) is estimated from the data by taking the histogram of galaxy comoving distances and cubicspline interpolating between the bins. In the case of VIPERS, we use the fitting function for the redshift distribution given in de la Torre et al. (2013). We assumed two cosmologies to convert redshift to comoving distance: flat ΛCDM with Ω_{m} = 0.31 and Ω_{m} = 0.25 for BOSS and VIPERS, respectively. Nonetheless, the choice of fiducial cosmology has no impact on the accuracy of the analytical predictions.
Fig. 1.
Adopted radial distance distribution p(r) for the BOSS NGC CMASS sample at 0.5 < z < 0.75 (blue solid curve) and VIPERS W1 sample at 0.7 < z < 1.2 (red dashed line). The distributions are normalised so that the integral is unity. The vertical solid (dashed) lines show the adopted sample limits for BOSS (VIPERS).

Open with DEXTER
The angular selection functions that we used for VIPERS W1 and BOSS NGC are presented in Appendix A. In total, the surface covered by the BOSS NGC (VIPERS W1) field is 7427.4 deg^{2} (10.7 deg^{2}). The angular selection function enters in Eq. (12) through its autocorrelation function. The latter are given in Figs. 2 and 3, respectively for BOSS and VIPERS.
Fig. 2.
Top panel: twopoint correlation function of the BOSS angular selection function obtained from a HEALPIX map with nside = 8192. Bottom panel: relative difference on the angular twopoint correlation function with respect to lower resolution maps, i.e. nside = 2048, 4096 in blue and orange curves, respectively.

Open with DEXTER
Fig. 3.
Top panel: twopoint correlation function of the VIPERS angular selection function obtained from a HEALPIX map with nside = 65536. Bottom panel: relative difference on the angular twopoint correlation function with respect to lower resolution maps, i.e. nside = 8192, 16834, 32768 in blue, orange, and green curves, respectively.

Open with DEXTER
We test different map resolutions by varying the HEALPIX resolution parameter nside from 2048 to 8192. For BOSS, the correlation function is very smooth. The relative difference between nside = 2048, 4096 cases and nside = 8192 is roughly constant, at 0.1% and 0.05% respectively. In the case of VIPERS, the angular mask has more smallscale features but similarly, the relative differences between angular correlation functions based on different map resolutions are nearly constant in scale. The bias is larger than in the BOSS case, with a relative difference with respect to nside = 65536 of 4%, 2%, and 0.5%, respectively for nside = 8192, 16834, 32768. This difference is due to the fact that we need a significantly higher map resolution to correctly account for the angular selection function as illustrated in Fig. 4. The latter figure shows a detail of the VIPERS angular mask pixelated at nside = 8192 and nside = 65536. Overall, the convergence of the angular correlation function with increasing nside, allows us to assess that resolutions of nside = 8192 and nside = 65536 are sufficiently accurate for BOSS and VIPERS respectively. We note that while the map resolution impacts the estimation of the angular selection function twopoint correlation function, it also changes the estimation of n(r) through ⟨W⟩, which partly compensates the bias from ω(θ) in the final RR and DR estimations.
Fig. 4.
Detail of the VIPERS W1 angular mask showing the impact of HEALPIX resolution on the sampling of the survey angular mask.

Open with DEXTER
3.3. RR counts
We compare our analytical prediction for RR with the average randomrandom counts ⟨RR⟩, obtained from 100 random samples constructed using the same radial and angular selection functions. Within the considered redshift intervals, there are 435185 BOSS and 24316 VIPERS galaxies and we generate 3 × 10^{7} and 3.9 × 10^{6} points per random sample, respectively (i.e. multiplicative factors of about 70 and 160 with respect to the data) with the radial distributions shown in Fig. 1. We compute the pair counts from the random samples using the fast CORRFUNC paircounting code (Sinha & Garrison 2020). Our method predicts anisotropic RR(s, μ) counts, but to simplify the comparison, we consider the first three even multipoles, that is, RR_{ℓ}(s) = (2ℓ+1)/2∑_{i}RR(s, μ_{i})ℒ_{ℓ}(μ_{i})Δμ with ℓ = 0, 2, 4, where linear bins μ_{i} extend from −1 to 1. Those comparisons are presented in Fig. 5 for BOSS and in Fig. 6 for VIPERS. We see that for both surveys, the relative difference between the analytical computation and ⟨RR⟩ is well within the variance of the random samples. We compare the results obtained with different numerical integration algorithms (see figure insets and Sect. 3.1) and find that cuhre tends to depart from the others algorithms, which is understandable since it is intrinsically different from the others. If we ignore cuhre, we see that, at most, the relative difference between the analytical computation and ⟨RR⟩ remains within 3 × 10^{−5} for BOSS and 1.7 × 10^{−4} for VIPERS on the monopole, and about 10^{−3} for the quadrupole and hexadecapole for both surveys.
Fig. 5.
Relative difference between the analytical and random cataloguebased mean ⟨RR⟩ paircount multipole moments (ℓ = 0, 2, 4, in the top, middle, and bottom panels, respectively) for BOSS. The grey shaded area shows the standard deviation among the random catalogues, while blue, orange, green, red, and purple curves present the relative differences obtained with vegas, suave, divonne, cuhre, and gsl algorithms, respectively, when using ε = 10^{−5}.

Open with DEXTER
Fig. 6.
Same as Fig. 5, but for VIPERS.

Open with DEXTER
The variance on the random sample counts depends on the number of points in the sample and, thus, we may ask what is the number of random points needed to achieve the same accuracy as in the analytical method. Keihänen et al. (2019) showed that the relative variance on RR in a given bin is:
with N_{r} the number of random points, and G^{p}, G^{t} terms are (Landy & Szalay 1993):
with ⟨n_{p}⟩ and ⟨n_{t}⟩ the number of pairs and triplets averaged over several realisations. While G^{p} can easily be estimated from the random samples, we directly solve for G^{t} from the estimated var(RR). We can then deduce which N_{r} give standard deviations similar to 3 × 10^{−5} and 1.7 × 10^{−4} for the monopole. We found that we need an additional factor of at least 20(10) for BOSS (VIPERS) in the number of random points. Therefore, the analytical method allows the achievement of the same accuracy as by using a random sample with about 20 × 70 (10 × 160) more points than data in BOSS (VIPERS). Finally, we note that CUBA integration algorithms have parameters that can be potentially further finetuned to achieve better accuracy.
3.4. DR counts
In the DR case, we need to rely on approximations. Under the approximation in Eq. (17), we have two possibilities to calculate DR counts: either a discrete sum over all source distances as in Eq. (20) or by further approximating the discrete sum by an integral as in Eq. (21). In the last case, we can already anticipate that the results will depend on the input p(r_{1}), particularly its ability to reproduce lineofsight structures in the data. In Figs. 7 and 8, we show different estimations of the data p(r_{1}) in VIPERS and BOSS, varying the bin size in r_{1}. In the limit where p(r_{1}) resembles a sum of Dirac delta functions, Eq. (21) should be equivalent to Eq. (20). For the random part we use in p(r_{2}) the distributions provided in Fig. 1. It is worth noting that we use cubic splines to model the data distributions in Figs. 7 and 8. While other ways of estimating p(r_{1}) could have been chosen, we only focus on the relative importance of the binning, and therefore, the method used for the estimation is irrelevant here (however, it would be necessary for an accurate, indepth characterisation of the radial selection function).
Fig. 7.
Estimated radial distance distribution p(r) in the VIPERS sample at 0.7 < z < 1.2 using different linear bin size in r. The distributions are normalised so that the integral is unity. The blue dotteddashed, red dashed, and black solid lines are the distributions obtained when using large, intermediate, and small bin sizes, respectively.

Open with DEXTER
Fig. 8.
Same as Fig. 7, but for BOSS.

Open with DEXTER
Following the same methodology as in Sect. 3.3, we compute ⟨DR⟩ for both surveys using the same data catalogue and 100 random samples, which we later compare to the predictions based on Eqs. (20) and (21) using different input data p(r_{1}). In the case of VIPERS, we find that when using Eq. (20), the discrepancy between the analytical prediction and direct pair counting is on the order of 1% for the monopole, up to several percent for the quadrupole and hexadecapole, as shown in Fig. 9. Moreover, we see that the prescription in Eq. (21) leads to a systematic bias of up to about 2% on the monopole when using a large binning in the input p(r_{1}), but converges towards Eq. (20) result when a small binning is adopted, as expected.
Fig. 9.
Relative difference between the analytical and random cataloguebased mean ⟨DR⟩ multipoles (ℓ = 0, 2, 4, in the top, middle, and bottom panels, respectively) for VIPERS. The grey shaded area shows the standard deviation among the random catalogues. The predictions use Eq. (17) and p(r) with large (blue), intermediate (red), and small (black) bin sizes. These use vegas with ε = 10^{−5}. The green line shows the prediction of Eq. (20) obtained with GSL using ε = 10^{−4}.

Open with DEXTER
In the case of BOSS, we find similar trends but with an higher accuracy, as shown in Fig. 10. We find at most a difference of 5 × 10^{−4} on the monopole between the analytical solution, either Eqs. (20) or (21) with a fine p(r_{1}), and direct pair counting. Regarding the quadrupole and hexadecapole, the relative difference is about 1%. Here, the approximation in Eq. (17) is more appropriate since the data sample is larger. This explains the improved accuracy that is reached. We emphasise that the variance in Figs. 9 and 10 only comes from the random samples since a single data catalogue is used. Therefore, increasing the number of random points would reduce this variance. Overall, because of the approximation in Eq. (17), our analytical DR predictions remain biased, exceeding the typical variance introduced by random sampling in direct pair counting.
Fig. 10.
Same as Fig 9 but for BOSS. Here. the prediction of Eq. (20) in green is obtained with GSL using ε = 10^{−3}.

Open with DEXTER
4. Conclusion
In this paper, we present general analytical expressions for the randomrandom and datarandom pair counts in the case of a realistic survey geometry. The main results are given in Eqs. (12) (or (14) for the multipole moments) for RR and in Eq. (21) for DR. These expressions can be solved numerically in an efficient way. This method, which does not rely on generating random mocks, only takes as input the comoving radial distance distribution in an assumed cosmology and the angular selection function twopoint correlation function, which only needs to be estimated a single time for a given survey. Once those quantities are provided, the full computation takes about a few minutes to obtain anisotropic pair counts RR(s, μ) and a few seconds for its multipole moments, using a single CPU and standard libraries for threedimensional integration.
We tested this method in the context of the BOSS and VIPERS survey geometries and found excellent agreements with expected RR pair counts. The predicted counts exhibit a high accuracy for the cases investigated in this work, equivalent to that we would obtain by performing pair counting in random samples of about 1400−1600 more random points than data in those surveys for the monopole. The main advantage is that the method is fast and does not rely on any spatial sampling, while usually we need to generate a random catalogue with at least 50 times the number of objects in the data. We believe that this can be of some use for future surveys with large data samples and very expensive RR pair count calculations.
The DR pair counts can also be calculated analytically based on certain approximations. We found that the results are slightly biased with respect to the expected counts. For VIPERS and BOSS, we found a bias with respect to direct pair counts of 1% and 0.05%, respectively, for the monopole, up to several percents on the quadrupole and hexadecapole. This bias should decrease with the increasing number of data points. When estimating DR for several data samples, we need to compute, for each sample, its angular twopoint correlation function with respect to the survey angular selection function.
Overall, the method presented in this paper for efficiently evaluating the survey window twopoint function should be very useful when dealing with massive galaxy surveys. The formulae provided are fast in terms of the speed of the evaluation. With further efficient parallelisation (e.g., Hahn 2015), we should be able to compute RR and DR in an extremely small amount of time. In that case, we could imagine RR and DR being evaluated in different cosmologies at each step of a cosmological likelihood analysis. This opens up new horizons for the way we analyse galaxy survey data in the future.
Available at http://data.sdss.org/sas/dr12/boss/lss/ (BOSS) and http://vipers.inaf.it/relpdr2.html (VIPERS).
Acknowledgments
We thank Eric Jullo for his help on dealing with partial, highresolution HEALPIX maps and his comments on the draft. We thank the Instituto de Astrofísica de Andalucía (IAACSIC), and the Spanish academic and research network (RedIRIS, http://www.rediris.es) in Spain for providing the skun@IAA_RedIRIS server that allowed us to run the calculations for highresolution nside = 65535 maps. This work has been carried out thanks to the support of the OCEVU Labex (ANR11LABX0060) and of the Excellence Initiative of AixMarseille University – A*MIDEX, part of the French ‘Investissements d’Avenir’ programme. Funding for SDSSIII has been provided by the Alfred P. Sloan Foundation, the Participating Institutions, the National Science Foundation, and the U.S. Department of Energy Office of Science. The SDSSIII website is http://www.sdss3.org/. SDSSIII is managed by the Astrophysical Research Consortium for the Participating Institutions of the SDSSIII Collaboration including the University of Arizona, the Brazilian Participation Group, Brookhaven National Laboratory, Carnegie Mellon University, University of Florida, the French Participation Group, the German Participation Group, Harvard University, the Instituto de Astrofisica de Canarias, the Michigan State/Notre Dame/JINA Participation Group, Johns Hopkins University, Lawrence Berkeley National Laboratory, Max Planck Institute for Astrophysics, Max Planck Institute for Extraterrestrial Physics, New Mexico State University, New York University, Ohio State University, Pennsylvania State University, University of Portsmouth, Princeton University, the Spanish Participation Group, University of Tokyo, University of Utah, Vanderbilt University, University of Virginia, University of Washington, and Yale University.
References
 Alam, S., Albareti, F. D., Allende Prieto, C., et al. 2015, ApJS, 219, 12 [Google Scholar]
 Alam, S., Ata, M., Bailey, S., et al. 2017, MNRAS, 470, 2617 [Google Scholar]
 Alonso, D. 2012, ArXiv eprints [arXiv:1210.1833] [Google Scholar]
 Bautista, J. E., Paviot, R., Vargas Magaña, M., et al. 2021, MNRAS, 500, 736 [Google Scholar]
 Beutler, F., Seo, H.J., Saito, S., et al. 2017, MNRAS, 466, 2242 [Google Scholar]
 Bianchi, D., & Percival, W. J. 2017, MNRAS, 472, 1106 [Google Scholar]
 Blake, C., Brough, S., Colless, M., et al. 2012, MNRAS, 425, 405 [Google Scholar]
 Castorina, E., Hand, N., Seljak, U., et al. 2019, JCAP, 2019, 010 [Google Scholar]
 Chon, G., Challinor, A., Prunet, S., Hivon, E., & Szapudi, I. 2004, MNRAS, 350, 914 [Google Scholar]
 Cole, S., Percival, W. J., Peacock, J. A., et al. 2005, MNRAS, 362, 505 [Google Scholar]
 Davis, M., & Peebles, P. J. E. 1983, ApJ, 267, 465 [Google Scholar]
 Dawson, K. S., Schlegel, D. J., Ahn, C. P., et al. 2013, AJ, 145, 10 [Google Scholar]
 de la Torre, S., Guzzo, L., Peacock, J. A., et al. 2013, A&A, 557, A54 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Demina, R., Cheong, S., BenZvi, S., & Hindrichs, O. 2018, MNRAS, 480, 49 [Google Scholar]
 DESI Collaboration (Aghamousa, A., et al.) 2016, ArXiv eprints [arXiv:1611.00036] [Google Scholar]
 eBOSS Collaboration (Alam, S., et al.) 2020, ArXiv eprints [arXiv:2007.08991] [Google Scholar]
 Eisenstein, D. J., Weinberg, D. H., Agol, E., et al. 2011, AJ, 142, 72 [Google Scholar]
 Feldman, H. A., Kaiser, N., & Peacock, J. A. 1994, ApJ, 426, 23 [Google Scholar]
 Garilli, B., Guzzo, L., Scodeggio, M., et al. 2014, A&A, 562, A23 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Górski, K. M., Hivon, E., Banday, A. J., et al. 2005, ApJ, 622, 759 [Google Scholar]
 Gough, B. 2009, GNU Scientific Library Reference Manual (Network Theory Ltd.) [Google Scholar]
 Guzzo, L., Pierleoni, M., Meneux, B., et al. 2008, Nature, 451, 541 [Google Scholar]
 Guzzo, L., Scodeggio, M., Garilli, B., et al. 2014, A&A, 566, A108 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Hahn, T. 2005, Comput. Phys. Commun., 168, 78 [Google Scholar]
 Hahn, T. 2015, J. Phys. Conf. Ser., 608, 012066 [Google Scholar]
 Hamilton, A. J. S. 1993, ApJ, 417, 19 [Google Scholar]
 Hearin, A. P., Campbell, D., Tollerud, E., et al. 2017, AJ, 154, 190 [Google Scholar]
 Hewett, P. C. 1982, MNRAS, 201, 867 [Google Scholar]
 Jarvis, M., Bernstein, G., & Jain, B. 2004, MNRAS, 352, 338 [Google Scholar]
 Kaiser, N. 1987, MNRAS, 227, 1 [Google Scholar]
 Keihänen, E., KurkiSuonio, H., Lindholm, V., et al. 2019, A&A, 631, A73 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Landy, S. D., & Szalay, A. S. 1993, ApJ, 412, 64 [Google Scholar]
 Laureijs, R., Amiaux, J., Arduini, S., et al. 2011, ArXiv eprints [arXiv:1110.3193] [Google Scholar]
 Maddox, S. J., Efstathiou, G., & Sutherland, W. J. 1996, MNRAS, 283, 1227 [Google Scholar]
 Marulli, F., Veropalumbo, A., & Moresco, M. 2016, Astron. Comput., 14, 35 [Google Scholar]
 Moore, A. W., Connolly, A. J., Genovese, C., et al. 2001, in Mining the Sky, eds. A. J. Banday, S. Zaroubi, & M. Bartelmann, 71 [Google Scholar]
 Mueller, E.M., Percival, W. J., & Ruggeri, R. 2019, MNRAS, 485, 4160 [Google Scholar]
 Peacock, J. A., Cole, S., Norberg, P., et al. 2001, Nature, 410, 169 [Google Scholar]
 Peebles, P. J. E., & Hauser, M. G. 1974, APJS, 28, 19 [Google Scholar]
 Percival, W. J., Reid, B. A., Eisenstein, D. J., et al. 2010, MNRAS, 401, 2148 [Google Scholar]
 Ross, A. J., Beutler, F., Chuang, C.H., et al. 2017, MNRAS, 464, 1168 [Google Scholar]
 Samushia, L., Percival, W. J., & Raccanelli, A. 2012, MNRAS, 420, 2102 [Google Scholar]
 Sánchez, A. G., Scoccimarro, R., Crocce, M., et al. 2017, MNRAS, 464, 1640 [Google Scholar]
 Scodeggio, M., Guzzo, L., Garilli, B., et al. 2018, A&A, 609, A84 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Sinha, M., & Garrison, L. H. 2020, MNRAS, 491, 3022 [Google Scholar]
 Slepian, Z., & Eisenstein, D. J. 2016, MNRAS, 455, L31 [Google Scholar]
 Strauss, M. A., Davis, M., Yahil, A., & Huchra, J. P. 1992, ApJ, 385, 421 [Google Scholar]
 Szapudi, I., Prunet, S., Pogosyan, D., Szalay, A. S., & Bond, J. R. 2001, ApJ, 548, L115 [Google Scholar]
 Tegmark, M., Eisenstein, D. J., Strauss, M. A., et al. 2006, Phys. Rev. D, 74, 123507 [Google Scholar]
 Vogeley, M. S., Park, C., Geller, M. J., & Huchra, J. P. 1992, ApJ, 391, L5 [Google Scholar]
 Wilson, M. J., Peacock, J. A., Taylor, A. N., & de la Torre, S. 2017, MNRAS, 464, 3121 [Google Scholar]
 Yamamoto, K., Nakamichi, M., Kamino, A., Bassett, B. A., & Nishioka, H. 2006, PASJ, 58, 93 [Google Scholar]
Appendix A: VIPERS and SDSSBOSS survey footprints
In Figs. A.1 and A.2, we provide the footprints and angular masks for VIPERS W1 and SDSSBOSS CMASS NGC fields, respectively, which we used in this analysis. In the case of BOSS angular mask, each distinct mask polygon has an associated tiling success rate, which is a measure of the completeness in associating fibres to potential spectroscopic targets in the survey. We use this quantity as a weight in defining the angular selection function. In the case of VIPERS, the angular selection function is taken to be unity inside the spectroscopic mask (quadrantshaped polygons) and null otherwise, except in the regions of the photometric mask (circular and starshaped polygons), where it is also set to zero.
Fig. A.1.
VIPERS W1 footprint.

Open with DEXTER
Fig. A.2.
BOSS CMASS NGC footprint.

Open with DEXTER
