Estimates of cluster masses in screened modified gravity
^{1} Institute of Theoretical
Astrophysics, University of Oslo, Postboks 1029, 0315 Oslo, Norway
email: maxbg@astro.uio.no
^{2} Astrophysics, University of Oxford,
DWB, Keble Road,
Oxford, OX1 3RH,
UK
Received:
5
April
2016
Accepted:
9
September
2016
We use cosmological hydrodynamical simulations to study the effect of screened modified gravity models on the mass estimates of galaxy clusters. In particular, we focus on two novel aspects: (i) we study modified gravity models in which baryons and dark matter are coupled with different strengths to the scalar field, and; (ii) we put the simulation results into the greater context of a general screenedmodified gravity parametrization. We have compared the mass of clusters inferred via lensing versus the mass inferred via kinematical measurements as a probe of violations of the equivalence principle at Mpc scales. We find that estimates of cluster masses via Xray observations is mainly sensitive to the coupling between the scalar degree of freedom and baryons – while the kinematical mass is mainly sensitive to the coupling to dark matter. Therefore, the relation between the two mass estimates is a probe of a possible nonuniversal coupling between the scalar field, the standard model fields, and dark matter. Finally, we used observational data of kinetic, thermal and lensing masses to place constraints on deviations from general relativity on cluster scales for a general parametrization of screened modified gravity theories which contains f(R) and Symmetron models. We find that while the kinematic mass can be used to place competitive constraints, using thermal measurements is challenging as a potential nonthermal contribution is degenerate with the imprint of modified gravity.
Key words: largescale structure of Universe / dark energy / gravitation / galaxies: clusters: general / Xrays: galaxies: clusters / galaxies: kinematics and dynamics
© ESO 2016
1. Introduction
Over a decade has passed since the indisputable discovery of the accelerated expansion of the Universe (Riess et al. 1998; Perlmutter et al. 1999) but its physical origin is still unknown. A possible – and rather popular – solution is to modify the theory of general relativity (GR). This has been done for a number of years and lead to numerous theories of modified gravity (for reviews, see, e.g., Amendola & Tsujikawa 2010; Clifton et al. 2012). The main challenge for many modified gravity theories are measurements of the gravitational strength on Earth and in the solar system (e.g., Bertotti et al. 2003; Will 2006; Williams et al. 2004), which confirm the predictions of GR with great precision. One viable solution to this is to employ a socalled screening mechanism which restores GR in the solar system. Screening mechanisms are usually triggered by large local matter density or spacetime curvature and lead to a convergence of the gravitational strength to its value predicted by GR.
For the subcategory of the extension of GR in the scalar sector^{1}, that is, by adding a coupled scalar field to the EinsteinHilbert action, several possible screening mechanisms are on the market (see, e.g., Khoury 2010; Joyce et al. 2015). They can be categorized as follows:

Screening because of the scalar field value – also often denoted as Chameleon screening. This group can be further divided into screening mechanisms that affect directly the coupling strength – such as the Dilaton (Damour & Polyakov 1994) and the Symmetron (Hinterbichler & Khoury 2010; Hinterbichler et al. 2011) screening – as well as mechanisms that alter the range of the additional force. The latter screening is often dubbed Chameleon screening (Khoury & Weltman 2004b,a; Gannouji et al. 2010; Mota & Shaw 2007).

Screening due to derivatives of the field value – also called Vainshteinlike screening. Here, one can differentiate between screening due to the first or the second derivative of the scalar field. Screening mechanisms belonging to the former group are the kMouflage (Babichev et al. 2009; Zumalacarregui et al. 2010; Brax & Valageas 2014) and DBionic screening (Burrage & Khoury 2014) whereas the latter group consists of the eponymous Vainshtein screening (Vainshtein 1972).
It is important to differentiate between the screening mechanism and the particular theory of gravity employing this mechanism. For instance, particular theories employing the Vainshtein screening are the DGP model (Dvali et al. 2000), Galileons (Nicolis et al. 2009), and, massive gravity (de Rham 2014).
This wealth of theoretical alternatives to GR stands in stark contrast to the observational findings which, so far, confirm GR on a variety of environments & scales (for observational reviews see, e.g., Koyama 2016; Baker et al. 2015; Bull et al. 2015) although deviations in many observables are predicted. Apart from the background cosmology (e.g., Koennig et al. 2014; Brax et al. 2004; Hinterbichler et al. 2011, for the Vainshtein, Chameleon and Symmetron, respectively) usually Nbody codes are used to study screened modified gravity models (for a review of the numerical techniques, see Winther et al. 2015). The most common approach is to start a Λ cold dark matter (ΛCDM) and a modified gravity simulation using the same initial conditions and then analyze the deviations between the simulation outputs at later times. In this way, deviations in the matter power spectrum (Oyaizu et al. 2008; Li et al. 2011, 2012, 2013; Bourliot et al. 2007; Llinares & Mota 2013; Puchwein et al. 2013), the halo mass function (Schmidt 2010; Barreira et al. 2013; Clifton et al. 2005; Davis et al. 2012; Achitouv et al. 2015), the velocity field (Corbett Moran et al. 2014; Hellwing et al. 2014; Gronke et al. 2015a; Fagernes Ivarsen et al. 2016), gravitational lensing (Barreira et al. 2015b; Tessore et al. 2015; Higuchi & Shirasaki 2016) and many other quantities have been found. These predictions give valuable insights into the way in which mechanisms act on the environment. However, exactly how transferable to observations they are, is questionable due to the neglecting of baryonic effects which are somewhat degenerate with the enhancement of gravity (Puchwein et al. 2013; Arnold et al. 2014; Hammami et al. 2015), and, more importantly the direct comparison with another, alternative “Universe” – a technique which is certainly not possible with real data.
Another problem associated with the confrontation of the numerical predictions with real data is the richness of the modified gravity landscape. Not only is the above mentioned number of models incomplete (and steadily increasing) but each model has its own (often multidimensional) parameter space. This makes the classical approach, by which we mean, using a suite of Nbody simulations to constrain the model parameter spaces onebyone, unfeasible. One alternative is to speed up the numerical simulations tremendously as done by Mead et al. (2015), Barreira et al. (2015a) and Winther & Ferreira (2015). Alternatively, one can try to unify the predictions of several modified gravity models potentially allowing to rule out (parts of parameter spaces) of several models at once. This path was taken theoretically by Brax et al. (2012a,b) who developed a framework in which it is possible to describe the Chameleonlike screening mechanisms with two free functions. Gronke et al. (2015b) present a fully empirical parametrization of screened modified gravity models using three parameters which captures a number of models & model parameters.
In this paper, we want to revisit some classical quantities associated with screened modified gravity models, namely the dynamical, lensing and thermal mass estimates of clusters of galaxies in the light of (i) the Gronke et al. (2015b) parameterisation, and; (ii) the possibility of unequal coupling; that the enhancement of gravity is not the same for baryons and dark matter.
In this work, we use , , and, denote values today with a subscript zero.
2. Methods
Fig. 1
Ratio of kinetic and lensing mass for the analyzed f(R) models (left panel) and Symmetron models (right panel). The horizontal lines and markers show the width and center of the transition region as defined in Sect. 2.4, respectively.

Open with DEXTER
2.1. Screened modified gravity models
In this subsection we introduce very briefly the Symmetron (Hinterbichler & Khoury 2010; Hinterbichler et al. 2011) and the Hu & Sawicki (2007)f(R) model. For more details we refer to the original papers, to reviews featuring these models (e.g., Clifton et al. 2012; Khoury 2013), or, to our previous work where we introduce the models in more detail (e.g. Gronke et al. 2014; Hammami et al. 2015).
The Hu & Sawicki (2007)f(R) model is a f(R) model featuring the Chameleon screening mechanism, i.e., it has a reduction of both the range and the strength of the fifth force in high density regions. The model features two free parameters,  f_{R0}  and n, where former controls the range of the fifth force in vacuum and the latter does not have much impact (Hu & Sawicki 2007). We consider three models with log _{10}  f_{R0}  = (−4, −5, −6) and n = 1. For the Hu & Sawicki (2007)f(R) model, the maximum enhancement of the gravitational force with respect to GR is fixed to .
The Symmetron (Hinterbichler & Khoury 2010; Hinterbichler et al. 2011) inherits a symmetry breaking effective potential leading to a diminishing fifthforce in highdensity environments. The model parameters are the scale factor of average symmetry breaking a_{ssb}, the range of the force in vacuum λ_{ψ}, and, the coupling parameter β. The maximum enhancement of gravity is in this case (Gronke et al. 2015b) (1)
2.2. Nbody simulations and halo selection
We used a modified version (Hammami et al. 2015) of the ISIS (Llinares et al. 2014) simulation, which in turn is based on the adaptivemesh code RAMSES (Teyssier 2002). The initial conditions were created using Grafic (Bertschinger 1999) starting at a redshift z = 49. The simulation parameters used are (Ω_{CDM0}, Ω_{b0}, Ω_{Λ0}, H_{0}, B, N) = (0.227, 0.045, 0.727, 70 km s^{1} Mpc^{1}, 200 Mpc h^{1}, 256) for the f(R) simulation set and (0.3, 0.05, 0.65, 65 km s^{1} Mpc^{1}, 256 Mpc h^{1}, 256) for the Symmetron simulation set, where B denotes the sidelength of the simulation box and N the number of particles in the box. Furthermore, the modified gravity parameters used are identical to Hammami et al. (2015), Hammami & Mota (2015) and are summarized in Tables 1 and 2. The simulations contains both dark matter particles and baryons which are treated as a simple ideal fluid^{2}. All the results in this paper comes from analyzing the z = 0 snapshot of the simulations.
Overview of the equal coupled model parameters for the Symmetron and f(R) models.
The halos were identified using the spherical overdensity halo finder AHF (Amiga Halo Finder, Knollmann & Knebe 2009). For the analysis we used only halos consisting of at least 100 particles which limits the smallest halo we can probe to M ~ 3 × 10^{12}M_{⊙}h^{1}. In the high mass end the simulationbox limits the maximum halomasses we can study and the largest halos in our simulations has mass M ~ 2−3 × 10^{15}M_{⊙}h^{1}. We have checked that the massfunction of our simulation agrees to ~10%−20% to simulations with larger boxsize and also to the Tinker et al. (2008) fit to the massfunction in the range M ∈ [10^{13},8 × 10^{14}] M_{⊙}h^{1}. The total number of halos in this massrange in our simulations, which is what we used for the upcoming analysis, is ~8000.
2.3. Halo mass estimates
After identifying the halos with AHF we define three kinds of mass estimates:

1.
the lensing mass M_{lens} as the M_{200c} as given by AHF;

2.
the thermal mass M_{therm} constructed using the temperature and density profiles as (2)where k_{B} is the Boltzmann constant, r ~ R_{200c} is the virial radius of the halo, m_{p} is the proton mass and μ = 0.59 is the mean molecular weight of the gas^{3}; and

3.
the kinetic mass M_{kin} calculated from the velocity disperion via (3)where M_{0}, σ_{0} and α are fitting values, and, σ_{DM} is the onedimensional velocity dispersion of all the dark matter particles within the virial radius R_{200c}. For (M_{0},σ_{0},α) we adopt the values found by Evrard et al. (2008), namely (M_{0},σ_{0}α) = (10^{15}M_{⊙}h^{1}, 1082.9 km s^{1}, 0.3361).
2.4. A universal parametrization of screened modified gravity models
The parametrization of Gronke et al. (2015b) is based on the simple idea that in screened modified gravity theories, the fifth force is screened for the most massive halos, while being completely unscreened for the very lightest halos and voids, where the fifth force is in full play and achieves it’s theoretical maximum value. This implies that there has to be a transition scale where the enhancement of the gravitational force is about half its theoretical maximum.
In Gronke et al. (2015b), this transition scale is phrased in terms of halo mass (M_{200}), and thus, dubbed μ_{200}. In other words: The (mass weighted) average fifth force in a halo with mass μ_{200} is roughly γ_{max}/ 2 that of the Newtonian prediction. The second parameter is the width of this transition region, say, when the enhancement of gravity is between 20 and 80 percent of γ_{max}. This width is quantified with a third halfwidth parameter W. In conclusion, this means that fully screened (completely unscreened) halos are expected to have masses ≲μ_{200}/W (≳ μ_{200}W) and, thus, the effective gravitational constant in these halos is simply G (γ_{max}G).
In order to map the parameters of several screenedmodified gravity theories Gronke et al. (2015b) solved the full field equations on an isolated NFW density profile obtaining full gravitational force profiles – and hence also the mass averaged enhancement of gravity – for a wide range of model parameters and halo masses. Additionally, they also use the more general screened modified description of Brax et al. (2012b) to obtain a similar seminumerical mapping. As a result Gronke et al. (2015b) provide fitting formulas for the DGP, HuSawicki f(R) and Symmetron model parameters to the universal (μ_{200},γ_{max},W) set of which we use the latter two in Sect. 4.2. For more details on how these remapping rules were developed we refer the reader to Gronke et al. (2015b).
Fig. 2
Ratio of thermal and lensing mass for the analyzed f(R) models (left panel) and Symmetron models (right panel). The horizontal lines and markers show the width and center of the transition region as defined in Sect. 2.4, respectively.

Open with DEXTER
Fig. 3
Mass ratios for the analyzed models with nonuniversal coupling. The left panel shows the ratio of the kinetic and lensing mass and the right panel shows the ratio of the thermal and lensing mass.

Open with DEXTER
3. Results
In this section we present the results from the numerical Nbody simulation in the case of universal (Sect. 3.1) and nonuniversal coupling (Sect. 3.2).
3.1. Models with universal coupling
Figure 1 shows the ratio of the lensing and kinetic masses (as given by Eq. (3)) for the simulated f(R) (left panel) and the Symmetron models (right panel). The shaded bands in this figure denote the error of the mean in each bin. Similarly, Fig. 2 shows the ratio of the thermal mass and the lensing mass for the analyzed models.
Both figures show the same – well known – features: (i) a large deviation for smaller mass halos (which are unscreened); (ii) a decline for intermediate masses when the screening kicks in; and; (iii) the fully screened highmass halos where the deviation is essentially zero. We want to highlight, however, that this deviation is between measures of the same simulation. This is in contrast to what is often presented in similar studies – where the deviation between the modified gravity and the ΛCDM simulation is displayed. Therefore, finding similar trends as these studies (e.g. Arnold et al. 2014; Gronke et al. 2014; Falck et al. 2015) is reassuring.
In addition to the data points, Fig. 1 also displays the estimated transition scales (as described in Sect. 2.4). Specifically, the value of expected centroid of the transition scale μ_{200} and the halfwidth of the transition W is marked with a matching symbol and colored lines, respectively.
3.2. Models with nonuniversal coupling
Figure 3 shows the mass ratios M_{kinetic}/M_{lens} and M_{thermal}/M_{lens} (left and right panel, respectively) for the models with nonuniversal coupling, i.e., for which the fifth force acts differently on the baryons and the darkmatter. The models presented are variations of the Symmetron B model (see Table 2). Clearly, the same trends as in Sect. 3.1 are visible. However, this time different coupling combinations are sensitive to different observables. In particular, the model where dark matter is stronger coupled is more sensitive to the kinetic mass estimate, and, the model where the baryons are stronger coupled shows a (much) stronger variation in the thermal mass.
This effect can be seen more clearly in Fig. 4 where we show the ratio between the thermal and the kinetic mass. Here, the model with stronger baryonic coupling shows a clear positive deviation ≳50%, and the stronger dark matter coupled model a negative deviation. This is interesting as the equally coupled model is much closer to the ΛCDM prediction. Note, that the discrepancy between the two mass scales in both the ΛCDM cases comes from the imperfect calibration of our massestimates and the resulting small deviations at the lowmass end. This could be overcome using higherresolution simulations or better calibrated predictors.
This means that by studying solely the M_{x}/M_{lens} ratios in Fig. 3 one could construct a model which mimics the effect of a universal coupling (or vice versa). For instance, increasing the darkmatter coupling to β_{DM} ~ 1.0 (while leaving β_{gas} = 0.1 untouched) one could obtain a similar kinematic mass estimate as in the Symmetron B model. Or, to state another example, increasing the coupling to baryons for the “DM0.1G1” model slightly will lead to an thermal mass estimate as found in Symmetron B . However, this degeneracy can be broken when comparing directly the thermal, and, kinetic mass estimates as in Fig. 4.
Overview of the mixed coupled models.
Fig. 4
Mass ratios between the thermal and kinematic mass for the models with nonuniversal coupling (see Sect. 3.2).

Open with DEXTER
4. Discussion
4.1. Comparison to semianalytic predictions
The semianalytic predictions of Gronke et al. (2015b) for the position and width of the transition scale as well as the maximum enhancement of gravity (see Sect. 2.4) can be tested against the results from the Nbody simulation.
Our findings can be summarized as follows:

The centroid of the transition region, μ_{200}, is lower in the Nbody simulations than predicted by the semianalytic model. This is clearly visible for the FofR05 model, as here the full transition is within the mass scale of our simulation. In this case the offset is circa half an order of magnitude. This offset is due to the fact that in Gronke et al. (2015b) the impact of the fifth force on a complete, isolated halo – i.e., out to R = 10R_{vir} – was analyzed. As in reality, e.g., tidal effects from nearby halos play an important role for the behavior in the outer regions, we constraint our analysis here to 1R_{vir} – which is also closer to observations. Other, however, subdominant factors are the inclusion of baryonic effects in this study (see Hammami et al. 2015, for a full discussion of baryonic effects on modified gravity simulations), and, the higher environmental density of the halos in the Nbody simulation.

The halfwidth of the transition region, W, can only be compared to the FofR05 model for the reasons explained above. In this one case, the prediction fit quite well.

For a virialized halo, the velocity dispersion squared is proportional to the gravitational constant – as per definition a in a virialized halo two times the kinetic is equal to minus the potential energy. Using now the definitions of the velocity dispersion (Eq. (3)), of γ, and requires that M_{kin} → M_{lens} for γ → 0, one finds (4)Thus, the maximum deviation found for this mass ratio for the f(R) models (see Fig. 1) fits the theoretical estimate of ~0.53 using γ_{max} = 1 / 3 (and α = 0.3361 as described in Sect. 2.3). For the Symmetron models considered, the unscreened masses lie below the mass resolution of our simulations making the prediction untestable.

Likewise we can construct a relation for the thermal mass. Using the relation of Terukina et al. (2014)M = M_{GR} + M_{Fψ}, we obtain M_{thermal}/M_{lens} ∝ γ + 1. The maximum deviation found for the thermal mass ratio for the f(R) models can then be read from Fig. 2, and is consistent with the theoretical prediction γ_{max} = 1 / 3.
Figure 5 shows the μ_{200} − γ_{max} predictions (filled symbols) with the width of the transition region marked as horizontal line. The same figure displays the resulting parameters from the Nbody simulation as unfilled symbols with arrows denoting limits due to the mass resolution of the simulations.
4.2. Observational constraints
Masses of clusters can be inferred using different massestimates. Within conformally invariant modified gravity theories with a screening mechanisms, different massestimates may result into different inferred values for the mass. For instance, while the mass inferred via lensing gives the same value as in General Relativity (independently of the size and the environment of the halo), the mass measured via dynamical methods (e.g. inferred from velocity dispersion measurements) may result into a different value, specially for small and isolated halos (Winther et al. 2012). In this section, we use existing lensing and dynamical mass measurements and compare them with each other in order to constrain the modified gravity parameter space.
Fig. 5
Observational constraints on screened modified gravity theories presented in the μ_{200} − γ_{max} parametrization described in Sect. 2.4. The filled symbols with horizontal lines show the semianalytic μ_{200} and W predictions. The unfilled symbols show the simulation results with arrows denoting limits due to the mass resolution of the simulations. The black line shows the constraints from M_{kin} and M_{lens} observations resulting in the exclusion of the grey shaded region (see Sect. 4.2 for details).

Open with DEXTER
4.2.1. Lensing versus kinetic mass measurements
We use lensing and kinematic mass measurements from the Sloan Digital Sky Survey (SDSS, Sheldon et al. 2009). In particular, we use the lensing and kinetic mass estimates from Johnston et al. (2007) and Becker et al. (2007), respectively. In order to combine the two masses, we use the richness of a cluster which represents the number of detected galaxies associated with a cluster^{4} and is therefore independent of the chosen mass estimate. This procedure allows us to constrain the maximally allowed deviation from GR across several massscales.
For the lensing masses we use the massrichness relation given by Johnston et al. (2007) who used 130 000 clusters of galaxies. They found a relation given by (5)where is again the measured richness of the cluster.
The dynamical mass measurements were taken from Becker et al. (2007) who found (6)where b_{v} denotes the bias.
When combining the observations we fixed the value of the bias b_{v} to its maximum value under the constraint that the two mass measurements agree within 1σ throughout the considered massrange – i.e., in the range M/M_{⊙}h^{1} ∈ [7 × 10^{12}, 5 × 10^{14}] which is the overlapping massrange of the observations – yielding b_{v} = 1.03. This leaves us with a conservative constraint for the maximally allowed overprediction of the kinetic mass compared to the lensing mass. This constrained can be converted to a maximally allowed enhancement of gravity using Eq. (4)for every halomass in the considered mass range, i.e., we can map the observational limits of M_{kin}/M_{lens} to an maximally allowed γ(M) – or, in the language of the universal description of Gronke et al. (2015b) introduced in Sect. 2.4 to a constraint in the (γ_{max},μ_{200})plane. To recap: in this picture, μ_{200} is the halo mass where the enhancement of gravity (and, thus, the ratio M_{kin}/M_{lens} or M_{therm}/M_{lens} reaches half of its theoretical value, and γ_{max} is this maximally enhancement of gravity (and, therefore, sets via Eq. (4)the upper bound on the mass ratio).
Fig. 6
Current constraints on the HuSawicki f(R) model with n = 1. References (updated list from Lombriser 2014): dwarf galaxies (Jain & VanderPlas 2011; Vikram et al. 2013), distance indicators in dwarf galaxies (Jain et al. 2013), solar system (Hu & Sawicki 2007; Lombriser et al. 2014), strong gravitational lenses (SLACS, Smith 2009), stacked phasespace distribution (Lam et al. 2012), cluster abundance + CMB (Cataneo et al. 2015), coma gas measurements (Terukina et al. 2014), cluster profiles (XMM Newton, Wilcox et al. 2015), matter bispectrum (GilMarín et al. 2011), galaxy infall kinematics (Zu et al. 2014), cluster abundance (Chandra, Schmidt et al. 2009; Ferraro et al. 2011), cluster density profiles (maxBCG, Lombriser et al. 2012), supernova monopole radiation (Upadhye & Steffen 2013), CMB ISWlensing bispectrum (Hu et al. 2013; Munshi et al. 2014).

Open with DEXTER
Figure 5 shows the 2 − σ observational constraint as a black line, and the resulting ruled out region of the γ − μ_{200} parameter space as grey shaded region. Note, that this region does not extent to greater masses as one might naively assume as higher kinetic masses throughout the entire probed massrange can be explained with a constant bias. However, these greater masses are ruled out by halo abundance measurements for (e.g. Cataneo et al. 2015).
In addition, Fig. 6 shows this constraint on the modeldependent parameter space for the HuSawicki f(R) model with n = 1 which we obtained by comparing our full simulation results (Fig. 1) to the allowed mass ratio deviation in each mass bin. This means we did not use the semianalytical (μ_{200},γ_{max}) − (M_{kin},M_{therm})relation but used the full simulation and, hence, could rule out only some few values of  f_{R0} . In spite of that this rather conservative limit^{5}, using the kinematic mass estimates of clusters is still competitive with other measurements at this lengthscale.
4.2.2. Thermal versus lensing mass measurements
In order to compare the lensing and thermal mass of the clusters we took measurements from Zhang et al. (2010) and Mahdavi et al. (2013). These two datasets provide both thermal and lensing mass measurements and uncertainties for a total of 58 clusters in the mass range M/M_{⊙}h^{1} ∈ [5 × 10^{13}, 3 × 10^{15}] so there was no need to combine the mass estimates in a similar fashion as in the previous section. We divided the data for the thermal mass measurements by the data for the lensing mass measurements while properly propagating the error. As we’re interested in a systematic deviation, we binned the data in 6 (lensing) mass bins which we stratified so that roughly the same number of halos are in each bin.
An important point to bear in mind when working with thermal mass estimates is the fact that the measured quantity in this case is the temperature of the intracluster gas. The conversion to a mass assumes hydrostaticequilibrium (as done, e.g., in Zhang et al. 2010; Mahdavi et al. 2013; Arnold et al. 2014). However, it has been shown that in reality the pressure of the intracluster medium will have a significant nonthermal component generated by random gas motions and turbulence (Evrard 1990; Rasia et al. 2004; Kay et al. 2004; Dolag et al. 2005; Lau et al. 2009). This means the inferred thermal mass given a temperature T will be slightly lower than the true mass of the cluster.
While empirical models exist in order to quantify the magnitude of this deviation (where the nonthermal component yield variations to the mass from 10% to 30%, Laganá et al. 2010) we want to stress that these were calibrated against pure ΛCDM simulations, and thus their results cannot be taken into account when dealing with modified gravity. One has to consider instead that if gravity is truly enhanced, the temperature of the intracluster medium will be hotter and, thus, the inferred thermal mass will be greater (as shown in Sect. 3). This means the effect of any nonthermal physics (such as cosmic rays Pfrommer 2008) is degenerate with modified gravity and, consequently, at the present time thermal measurements cannot be used to constrain modified gravity.
Fig. 7
Ratio of thermal and lensing mass for ΛCDM and Symmetron D, the Symmetron model with the largest deviations from ΛCDM. Also included is the hypothetical measurements obtained by including the nonthermal contribution described in Sect. 4.2.2

Open with DEXTER
Figure 7 illustrates this degeneracy. Here, we compare the M_{therm}/M_{lens} results of the Symmetron D model and our ΛCDM simulation (already shown in Fig. 2) to hypothetical measurements where we modeled the contribution of nonthermal pressure as (7)which resembles the functional forms fitted to ΛCDM simulations (Shaw et al. 2010; Battaglia et al. 2012 and see also Appendix A). Thus, our proposed nonthermal contribution is not unreasonable. Modeling a nonthermal contribution as given by Eq. (7)while keeping the total pressure P_{total} = P_{therm} + P_{non − thermal} (and, thus, the halo structure) constant is equivalent to rescaling the temperature as since naturally P_{therm} ∝ T.
As Fig. 7 shows in the case of a nonthermal contribution the M_{therm} measurement (which is carried out the same way as done by observations, i.e., assuming no nonthermal contribution) matches the lensing mass reasonably well in the case of modified gravity. We achieved this by choosing the functional form of in Eq. (7)as (8)with M_{13} ≡ M/ (10^{13}M_{⊙}h^{1}) and . This serves as an example of how unknown nonthermal physics can cancel out any signal originating from modified gravity – which is a severe problem when trying to place constraints on the modifications of gravity using thermal measurements.
This problem will be alleviated once the contribution of nonthermal effects can be directly quantified using observational data (e.g., by measuring directly the intracluster turbulence). In the sequel of this subsection, we assume this has been done and is has been shown the contribution of the nonthermal components is negligible. We do this in order to show which constraints on modified gravity can be placed hypothetically using thermal mass estimates.
Figures 5 and 6 show the resulting hypothetical constraints where we used the M_{thermal}/M_{lens} ∝ γ + 1 relation described in Sect. 4.1. Note that in this case we did not consider a constant bias throughout the mass range which would shift the thermal mass measurements. Instead, we simply allowed for a maximum deviation from the (mean of the) measured mass ratio of 2σ. For conversion to the f(R) constraints we used – as in the previous section – our full simulation output (Fig. 2) and, thus, under the discussed assumptions found the rather conservative limit  f_{R0}  < 10^{4} as presented in Fig. 6.
4.3. Caveats
Using clusters of galaxies to constrain modified gravity theories can be challenging as several sources of uncertainty have to be taken into account. From the observational side these uncertainties are immense for individual clusters but can be overcome when using a large number of objects – if no effect alters the measured kinematic or thermal masses systematically. As this is uncertain in particular for the kinematic mass estimates we fixed the bias to a conservative value which should counteract the effect^{6}. This leads, however, to the fact that near constant modifications of gravity throughout the whole measured mass range would not be detected.
Another important cause of uncertainty is the theoretical modeling where – although we included (basic) baryonic physics – not all important physical effects are taken into account. For instance, it is expected that supernovea and AGN feedback mechanisms are somewhat degenerate with the enhancement of gravity and, thus, weaken constraints on modified gravity theories (see e.g. Puchwein et al. 2013; Mead et al. 2016). This is in particular problematic for the thermal mass measurements as the “nonthermal pressure component” is not well understood theoretically as well as essentially completely unconstrained observationally. As explained in Sect. 4.2.2 the nonthermal contribution is degenerate with the effect of modified gravity which makes the use of thermal measurements in order to constrain gravity only possible if there is independent measurements of the nonthermal contributions. Future missions will be able to measure the nonthermal pressure component and, hence, turn this systematic degeneracy into a factor with (potentially large) uncertainties (Laganá et al. 2010). Until then one has to resort to other probes (such as the kinematic mass) in order to constrain modified gravity theories. However, as these probes mainly rely on the dynamics of dark matter, models which are only coupled to baryons evade current constraints (see Sect. 3.2).
Overall, we want to stress that although clusters of galaxies are a powerful tool to constrain gravity on intermediate scales, also big uncertainties are associated with it which have to be dealt with. Nevertheless, they have the potential to close the gap between largescale and local experiments as well as to probe the impact of gravity on darkmatter and baryons independently.
5. Conclusions
Using a hydrodynamic Nbody code, we studied the effect of screened modified gravity models on the mass estimates of galaxy clusters. In particular, we focused on two novel aspects: (i) we studied modified gravity models in which baryons and dark matter are coupled with different strengths to the scalar field, and; (ii) we put the simulation results into the greater context of a general screenedmodified gravity parametrization.
Our findings in these matters can be summarized as follows:

The lensing mass of a cluster can differ tremendously from its kinematic or thermal mass in modified gravity theories. In screened modified gravity theories the magnitude of variation varies from a maximum to zero from the unscreened mass range to the screened one, respectively. This makes the mass measurements of clusters a powerful probe of gravity in different length scales and environments.

Differently coupled dark matter and baryons are hard to detect observationally as degeneracies exist. However, as the thermal mass is stronger affected by the baryonic coupling than the kinetic mass, possessing information about the three discussed mass estimates can break this degeneracy.

We placed the specific Symmetron and f(R) models studied on a common parameter space which we also constrained using kinematic, lensing, and, thermal mass observations.

The ratio of the kinetic and lensing mass yields competitive constraints on the modification of gravity. Using thermal measurements, on the other hand, is currently unfeasible since the effect of nonthermal contributions is degenerate with a potential signal of modified gravity. This well be alleviated when these contributions are quantified in a modelindependent way.
is dependent on the limiting magnitude of the survey. Therefore, we ensured that the our mass measurement data both used the Sloan Digital Sky Survey (SDSS, Sheldon et al. 2009) data.
