1. Introduction

Applying corrections for dust extinction is a ubiquitous task executed in disciplines throughout astronomy, yet key concerns persist regarding the topic. Cited color-excess and total-to-selective extinction ratios are contested (Turner 2012; Nataf et al. 2016), and a debate continues regarding the compositional nature of dust and the source(s) behind diffuse interstellar absorption lines. The matter is exacerbated by the dependence of certain extinction ratios (AV/E(B−V) = RV,BV) on Galactic longitude ℓ (Schlafly et al. 2016), as exemplified by observations of the young cluster Westerlund 2 (ℓ ~ 280°, RV,BV ~ 4 versus ⟨RV,BV⟩ ~ 3.11, Carraro et al. 2013). Yet the challenge inherent in determining those ratios often requires the adoption of results tied to separate sight lines and stellar populations, with a potential penalty being the propagation of systematic uncertainties. Caution is likewise warranted when aiming to subvert such difficulties by assuming a linear relationship between reddening and distance, since numerous sight lines are characterized by non-linear trends (Neckel et al. 1980). More broadly, Pejcha & Kochanek (2012) and Nataf et al. (2016) argued that extinction laws adopted in surveys aiming to constrain cosmological models should be revisited (e.g., Riess et al. 2011), and there exist optimal passband combinations displaying less systematic and random scatter (see also Ngeow 2012).

As a result of the aforementioned uncertainties, infrared observations are of particular importance when establishing the cosmic distance scale, as the wavelength regime exhibits a reduced sensitivity to dust obscuration relative to optical data (i.e., Aλ ~ λ− β). Therefore, potential and often unconstrained variations in the extinction law are less onerous on the uncertainty budget (e.g., Δμ0). Spitzer observations of Cepheids throughout the Local Group exemplify that advantage (Scowcroft et al. 2011; Majaess et al. 2013), in concert with infrared monitoring of star clusters (Chené et al. 2012; Moni Bidin et al. 2014). For example, uncertainties associated with the reddening of the Large Magellanic Cloud, a pertinent anchor of the cosmic distance scale, are comparatively marginal in the mid-infrared where ⟨A3.6 μm/E(B−V)⟩ ~ 0.18 (Majaess et al. 2013). An added advantage of infrared observations is the mitigated impact of compositional differences between calibrating and target standard candles when establishing distances, as line blanketing may affect optical BV observations (Caldwell & Coulson 1985; Majaess et al. 2009).

In this study, reddening and total-to-selective extinction ratios (e.g., AJ/E(J−Ks)) are inferred from a diverse stellar demographic. That was accomplished by examining new JHKs observations from the VVV survey (Minniti et al. 2010), wherein RR Lyrae and Type II Cepheid variables were discovered toward the Galactic bulge and an adjacent region of the Galactic disk, in tandem with multiband infrared (e.g., Spitzer 3.6 μm) and optical data for O stars and classical Cepheids throughout the Galaxy. The analysis aims to provide key insight regarding extinction, and assess whether the data corroborate findings implying a potential link between the Galactocentric distance and dust size, as indicated by red clump stars (Zasowski et al. 2009; Gontcharov 2013, discussion and references therein).

thumbnail Fig. 1

Apparent color ratios for Type II Cepheids (top panel) and RR Lyrae (lower panel) variables identified in the VVV and GLIMPSE surveys (S1 ≃ 3.6 μm). The stars are key for establishing a sizable Galactocentric baseline to evaluate reputed extinction ratio variations. For clarity purposes, only uncertainties along the ordinate are displayed.

2. Analysis

2.1. Determining color-excess and total extinction ratios

The desired extinction ratios can be determined via differing approaches. A comparison of E(J−λ) /E(J−Ks) and λ-1 yields RJ,JKs = AJ/E(J−Ks) as λ → ∞, thus providing the coefficient linking the color-excess to the total extinction (Figs. 1 and 2). That coefficient may be determined from the apparent stellar colors to bypass potentially uncertain intrinsic colors (e.g., E(J−Ks) = (J−Ks)−(J−Ks)0). E(J−λ)/E(J−Ks)=XJλ,JKs(J−λ)−(J−λ)0(J−Ks)−(J−Ks)0=XJλ,JKs(J−λ)−(J−λ)0=XJλ,JKs(J−Ks)−XJλ,JKs(J−Ks)0(J−λ)=XJλ,JKs(J−Ks)+β.\begin{eqnarray} \nonumber &&E(J-\lambda)/E(J-K_{\rm s}) = X_{J \lambda ,JK_{\rm s}} \\ \nonumber &&\frac{(J-\lambda)-(J-\lambda)_{0}}{(J-K_{\rm s})-(J-K_{\rm s})_0} = X_{J \lambda ,JK_{\rm s}} \\ \label{eq1} &&(J-\lambda)-(J-\lambda)_{0} = X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s}) -X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s})_{0} \\ \label{eq2} &&(J-\lambda)= X_{J \lambda ,JK_{\rm s}}(J-K_{\rm s})+\beta. \end{eqnarray}Where X is the color-excess ratio, and β is constant for stars sharing common intrinsic colors. Color-excesses with extended baselines should be selected (e.g., J−Ks) to foster diminished uncertainties.

O stars are lucrative targets given their small intrinsic color spread (e.g., (B−V)0, Turner 1994), and are bright along with their longer-period classical Cepheid counterparts. Yet excess infrared emission endemic to O stars and their ambient environment may bias mid-infrared colors (e.g., W4 ~ 22 μm), and hence determinations of the desired extinction ratios. The angular resolution associated with longer-wavelength mid-infrared photometry is likewise too coarse for dense nascent regions, although Spitzer observations are preferred owing to their improved resolution relative to WISE. Indeed, the W2 (4.6 μm) reddening ratio cited in Table 1 for O stars is systematically larger than inferred from the bracketing Spitzer photometry (S2,S3), which hints at the onset of contamination.

thumbnail Fig. 2

Mean color-excess ratios for the classical Cepheid, Type II Cepheid, and RR Lyrae variables analyzed. The mean near-infrared total-to-selective extinction ratio determined is ⟨RJ,JKs⟩ = 1.49 ± 0.05, and convergence is apparent beyond 3.4 μm. The bracketing fits represent ± 1σ.

Intrinsic colors for RR Lyrae and Cepheid variables are linked to the pulsation period (i.e., Mλ1−Mλ2 ~ αlog P + β). However, the expression is an approximation, especially for optical passbands where the instability strip exhibits sizable width (i.e., a temperature spread) and a metallicity term may be significant. Rotation may likewise play a role (Anderson et al. 2014). Therefore, variables with similar pulsation periods may feature different absolute optical magnitudes. Yet at infrared wavelengths the effect is relatively marginal since the observations primarily track radius changes, rather than those tied to the temperature. For certain variable classes, Eq. (1) may consequently be recast as: (J−λ)=XJλ,JKs(J−Ks)−XJλ,JKs(J−Ks)0+(J−λ)0(J−λ)=XJλ,JKs(J−Ks)−XJλ,JKs(αlogP+β)+(γlogP+δ)(J−λ)=XJλ,JKs(J−Ks)+logP(−XJλ,JKsα+γ)−XJλ,JKsβ+δ(J−λ)=XJλ,JKs(J−Ks)+ζlogP+η.\begin{eqnarray} \nonumber (J-\lambda)&=& X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s})-X_{J \lambda ,JK_{\rm s}}(J-K_{\rm s})_{0} + (J - \lambda)_{0} \\[3mm] \nonumber (J-\lambda)&=& X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s})-X_{J \lambda ,JK_{\rm s}}(\alpha \log{P} +\beta)+(\gamma \log{P} +\delta) \\[3mm] \nonumber (J-\lambda)&=& X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s}) + \log{P} (-X_{J \lambda ,JK_{\rm s}} \alpha + \gamma) -X_{J \lambda ,JK_s} \beta +\delta \\[3mm] \label{eq5} (J-\lambda)&=& X_{J \lambda ,JK_{\rm s}} (J-K_{\rm s})+\zeta \log{P} + \eta. \end{eqnarray}(3)A caveat to Eq. (3) arises when treating 4.5 μm and 4.6 μm Cepheid photometry, as the period-color relation becomes non-linear. The (3.6 μm−4.5 μm) color is approximately constant for shorter-period Cepheids, and subsequently transitions into a bluer convex trough at longer periods (Majaess et al. 2013). That trend is partly attributable to the temperature dependence of CO absorption and dissociation (Hackwell & Gehrz 1974; Scowcroft et al. 2011). RR Lyrae variables are significantly hotter than classical or Type II Cepheids, and likely immune to that effect. The pulsation term may be negligible for infrared passbands owing to the aforementioned reduced temperature dependence (Rayleigh-Jeans tail of the Planck function).

Table 1

Color-excess ratios.

The following total extinction ratio may now be evaluated from the total-to-selective extinction ratio derived via Eq. (2) (or (3)). AKs/AJ=1−RJ,JKs-1.\begin{eqnarray} \label{eq3} A_{K_{\rm s}}/A_{J}&=&1-{R_{J,JK_{\rm s}}}^{-1}. \end{eqnarray}(4)Separate total extinction ratios (Aλ1/Aλ2) may be established once one is known (Eq. (4)), and by making use of the expression described by Eqs. (2) or (3). Aλ/AJ=(−1/RJ,JKs)(J−λ)−β(J−Ks)+1=(AKS/AJ−1)E(J−λ)E(J−Ks)+1=AJAKs−AλAKs−AJ2+AλAJ+AJ2−AJAKsAJ(AJ−AKs)=Aλ/AJ.\begin{eqnarray} \label{eq4} A_\lambda / A_J &=& (-1/R_{J,JK_{\rm s}})\frac{(J-\lambda)-\beta}{(J-K_{\rm s})}+1 \\ \nonumber &=& ( A_{K_{\rm S}}/A_J-1) \frac{E(J-\lambda)}{E(J-K_{\rm s})}+1 \\ \nonumber &=& \frac{A_J A_{K_{\rm s}}-A_{\lambda} A_{K_{\rm s}} -A_{J}^2+A_{\lambda} A_{J} + A_{J}^2-A_J A_{K_{\rm s}}}{A_J(A_J-A_{K_{\rm s}})} \\ \nonumber &=& A_\lambda / A_J. \end{eqnarray}(5)The final method employed here to assess the total-to-selective extinction ratio involves exploiting a sample at a common distance. RR Lyrae and Cepheids present an advantage since their intrinsic color and magnitude may be estimated from their pulsation period (i.e., Mλ ~ αlog P + β), and contamination by AGB and red giant stars is less problematic. A disadvantage is that those variables are not as ubiquitous as red clump stars. Ks−MKs−AKs=μ0Ks−(αlogP+β)−RKs,JKs((J−Ks)−(J−Ks)0)=μ0Ks−αlogP−β−RKs,JKs(J−Ks)−RKs,JKs(γlogP+δ)=μ0Ks=RKs,JKs(J−Ks)+ζlogP+η.\begin{eqnarray} \nonumber &&K_{\rm s} - M_{K_{\rm s}}-A_{K_{\rm s}}=\mu_0 \\[3mm] \nonumber &&K_{\rm s}-(\alpha \log{P} +\beta) - R_{K_{\rm s},JK_{\rm s}} ((J-K_{\rm s})-(J-K_{\rm s})_0)=\mu_0 \\[3mm] \nonumber &&K_{\rm s}-\alpha \log{P} - \beta - R_{K_{\rm s},JK_{\rm s}} (J-K_{\rm s})-R_{K_{\rm s},JK_{\rm s}}(\gamma \log{P}+\delta)=\mu_0 \\[3mm] \nonumber &&K_{\rm s}=R_{K_{\rm s},JK_{\rm s}} (J-K_{\rm s})+ \zeta \log{P}+\eta.\\ \label{eq7} \end{eqnarray}(6)Sizable samples can be binned as a function of the pulsation period (e.g., bulge RR Lyrae variables), and consequently Eq. (6) may be transformed to: Ks=RKs,JKs(J−Ks)+τ.\begin{equation} \label{eq8} K_{\rm s}=R_{K_{\rm s},JK_{\rm s}} (J-K_{\rm s})+ \tau. \end{equation}(7)The common distance approach warrants caution when applied to targets along certain bulge sight lines, where significant substructure, a rich stellar field, and sizable extinction prevail. Smith et al. (2007) note that stellar distances along such sight lines can be biased by blending, and linked parameters would be compromised (see also Majaess 2010).

2.2. O stars and the variable star demographic

Majaess et al. (2013) utilized O stars to ascertain an approximate relation between the optical and mid-infrared color-excess and total-to-selective extinction ratios (i.e., E(3.6 μm−4.5 μm) /E(B−V) and A3.6 μm/E(B−V)). That analysis is now expanded to the broader Galaxy and other stellar populations, namely ~ 300 O stars and classical Cepheids, and ~ 1.5 × 103 Type II Cepheids and RR Lyrae variables.

Data from release v1.1 of the Galactic O-star spectroscopic survey (Maíz-Apellániz et al. 2004; Sota et al. 2011, 2014) were correlated with 2MASS, GLIMPSE, and WISE observations (e.g., Wright et al. 2010). The CDS X-Match Service was employed to match the data, typically using r< 1.5″. Apparent colors (J−λ) were compared to (J−Ks), where λ = JHKsW1S1S2W2S3 (see Table 1). The S4 (8 μm) and W3 (12 μm) passbands were ignored to circumvent a significant absorption profile putatively associated with silicate.

The classical Cepheid analysis was carried out using optical observations compiled by Berdnikov et al. (2000), in concert with infrared 2MASS, GLIMPSE, and WISE data. Increased statistics were favored over a limited sample tied to multi-epoch mean magnitudes. The 4.5 μm, 4.6 μm, and 12 μm data were ignored when determining the total-to-selective extinction ratio for reasons described above (i.e., CO and the broad silicate absorption profile). Conversely, the baseline was extended to W4 (22 μm) as contributions from dust (re)emission appear benign relative to the situation for O stars.

A search was undertaken for RR Lyrae variables and Type II Cepheids in the DRV4 release of the VVV survey. The observations provide a critical extension of the Galactocentric baseline, thereby permitting key trends to be identified. The VVV survey is a near-infrared, wide-field, multi-epoch, and high-resolution campaign monitoring stars in the Galactic bulge, and an adjacent region of the disk (Minniti et al. 2010; Saito et al. 2012). The survey, which was carried out from the VISTA 4-m telescope (Paranal), strived to extend existing near-infrared surveys beyond their faint limit by ~ 3−6 mag. Preliminary analyses of the wide-field campaign, which covers nearly 520 square degrees, indicate that in excess of a billion celestial targets were detected. To identify the variable stars sought, lightcurve (Fourier) templates were inferred from RR Lyrae and Type II Cepheids discovered by the OGLE survey (Soszyński et al. 2011a,b), and observed by the VVV survey. The templates were then used to identify variables throughout the broader region where the surveys lack overlap. The GLS2 period-search algorithm was employed (Zechmeister & Kurster 2009), and detections were screened against the templates via a χ2 scheme. Type II Cepheids and classical Cepheids display similar lightcurves, and a clean separation of the populations amid photometric uncertainties is challenging. However, the two populations share similar colors, making their differentiation in this instance relatively unimportant as the broader trends are sought, and the population II class dominates within the bulge (Dékány et al. 2015). A broader discussion concerning the topic is deferred to Hajdu et al. (in prep.). Aperture photometry for the RR Lyrae and Type II Cepheid variables were adopted verbatim from the CASU pipeline (Minniti et al. 2010), which include photometric zero-points tied to extinction estimates. Those extinction corrections are potentially sizable for shorter wavelength VVV Z and Y photometry, which are not investigated here, and are comparatively small for J, H, and Ks bands. The study’s broader conclusions are relatively unaffected owing to such small corrections being incorporated into color ratios. The CASU data were subsequently tied to 2MASS using secondary standards, and the transformation coefficients were near unity as the filter sets are similar. The principle (systematic) uncertainty is likely attributable to the nature of the aperture photometry utilized (Sect. 3). Certain brighter Type II Cepheids are saturated in the VVV survey, and possess inaccurate photometry. Indeed, saturation occurs for the longer-period and least obscured Type II Cepheids throughout the bulge, and variables at the structure’s forefront. A final catalog of variables detected in the VVV survey will be published in a separate study, where a rigorous discussion of completeness is provided (e.g., accounting for biases toward obscured regions and areas with limited multi-epoch sampling, Dékány et al., in prep.).

A σ-clip (generally 3σ) approach was adopted to mitigate spurious data, in concert with fitting algorithms that avert outliers (e.g., robust fitting). Photometric color uncertainties from separate surveys are inhomogeneous, and may bias fits toward brighter and less-reddened objects. Indeed, the apparent color ratios of the latter stars exhibit sizable uncertainties, and may skew results toward higher ratios. Thus establishing a broad color baseline assumed priority, and sizable statistics ensured that the formal random uncertainties were often dominated by systematics linked to the fitting algorithms. Uncertainties cited in Table 1 are tied to the spread in the latter.

3. Results

The results stemming from infrared photometry of such diverse populations point toward certain similar color-excess ratios (Table 1), although the O-star ratios digress rapidly beyond 3.6 μm, likely owing to infrared excess and contamination from the ambient young environment surrounding the targets. Bandwidth effects may likewise offset the ratios determined (for a discussion on divergent interpretations see Berdnikov et al. 1996). Bandpasses are not infinitesimally small, and hence differential extinction presumably occurs across the filter. The impact partly depends on the stellar energy distribution and dust attenuation.

thumbnail Fig. 3

Optical color-excess ratios vary as a function of the Galactic sight line (top panels), in relative contrast to those tied solely to infrared photometry (e.g., E(J−3.5μm)/E(J−Ks)\hbox{$E(J-\overline{3.5~\mu {\rm m}})/E(J-K_{\rm s})$}, bottom panels). Classical Cepheids and O stars display different optical trends with extrema along separate sight lines. The binned results were overlaid with arbitrary (running mean and polynomial) fits to highlight the variations.

Optical ratios (E(V−λ) /E(B−V)) diverge significantly as a function of ℓ, and the bulk trends differ between the classical Cepheid and O-star populations (Fig. 3). Conversely, relatively slight deviations of E(J−3.5μm)/E(J−Ks)\hbox{$E(J-\overline{3.5 ~\mu {\rm m}})/E(J-K_{\rm s})$} are observed as a function of ℓ. The results were subsequently binned to reduce uncertainties. Furthermore, the residuals tied to AJ/E(J−Ks) are not readily correlated with a pseudo2 determination of the Galactocentric distance (Figs. 3 and 4). The Galactocentric distance was computed according to the following expression, RG=d2cosb−2R0dcosbcosℓ+R02\hbox{$ R_{\rm G}=\sqrt{{d}^2 \cos{b}-2 R_0 {d} \cos{b} \cos{\ell}+{R_0}^2}$}, where R0 is the distance to the Galactic center and d is the classical Cepheid distance. The distance was evaluated after examining new near-infrared observations of LMC classical Cepheids by Macri et al. (2015), from which the following first-order absolute period-Wesenheit relation was established: WJ,JKs−W0,J,JKs = J−RJ,JKs(J−Ks)−(−3.18log P−2.67) = μ0 (assuming μ0,LMC = 18.45, see also Gieren et al. 2015). That Wesenheit function (reddening-free, Madore 1982) was adopted since RJ,JKs appears relatively constant across the Galaxy to within the uncertainties, thus mitigating uncertainties associated with color-excess estimates. A similar exercise was not carried out for the O stars granted their absolute magnitudes are acutely sensitive to the spectral classifications assigned, in stark contrast to their intrinsic colors (Turner 1994).

The mean near-infrared total-to-selective extinction ratio for classical Cepheids, Type II Cepheids, and RR Lyrae variables is ⟨AJ/E(J−Ks)⟩ = ⟨RJ,JKs⟩ = 1.49 ± 0.05, which implies ⟨AKs/AJ⟩ = 0.33 ± 0.02 via Eq. (4). The total-to-selective extinction ratio was derived from a polynomial fit with preferential weighting towards the longest-wavelength passband. Sight lines (ℓ) projected along the Galactic bulge are not characterized by highly anomalous near-infrared color-excess ratios, while optical data for O stars adhere to larger ratios relative to the mean (ultimately, multiepoch and multiband PSF photometry with increased sample resolution is preferable for the bulge). However, the common distance approach described by Eqs. (6) and (7) yielded a discrepant finding relative to the apparent color approach, namely that RJ,JKs ~ 1 characterizes the bulge RR Lyrae variables. The former requires strict constraints on the sample analyzed, and bulge substructure further complicates the analysis. Majaess (2010) noted there is a bias for smaller R0 because stars are preferentially sampled toward the near side of the bulge owing to extinction, and an uncertainty in characterizing how a mean distance to the group relates to R0. Furthermore, it was remarked that values of R0 may be biased by blending, and certain determinations of total-to-selective extinction ratios for bulge sight lines are impacted. The density and surface brightness increase markedly as ℓ,b → 0°. Evidence of blending emerges when assessing the computed RR Lyrae distances as a function of | b | (Fig. 5). Distance offsets become readily apparent for variables near the Galactic center, as RR Lyrae become brighter because of contaminating flux from neighboring stars. The aperture photometry utilized is particularly sensitive to that effect. A similar trend is present for RR Lyrae variables near the bright and crowded centers of globular clusters (Majaess et al. 2012a,b). The value of R required to resolve the problem is inconsistent with the results implied by the stellar colors. The distances were computed using Ks and J period-magnitude relations inferred from LMC and nearby RR Lyrae stars (e.g., Borissova et al. 2009).

thumbnail Fig. 4

Optical color-excess ratios (binned) inferred from classical Cepheids exhibit a dependence on the pseudo Galactocentric distance or metallicity (likely largely stellar in origin). That contrasts the results tied solely to the infrared photometry analyzed (e.g., bottom panel, E(J−3.4 μm) /E(J−Ks)). In concert with the trend delineated by O stars (Fig. 3), the findings contradict a paradigm linking a strict and marked decreasing dust grain size with increasing Galactocentric distance. The Luck et al. (2011) metallicity gradient is conveyed.

thumbnail Fig. 5

Caution is warranted when applying the common distance approach (Eq. (7)) to infer extinction properties for stars along the Galactic center sight line, where extinction and blending are acute (ℓ,b → 0°). Proximate distances observed for bulge RR Lyrae are likely linked to flux introduced by neighboring stars.

The optical reddening and total-to-selective extinction ratios correlate with ℓ. For the O stars examined, a maximum RV,BV is observed along the ℓ ~ 290° sight line, and minima are located toward ℓ ~ 133° and ℓ ~ 78°. A separate trend is delineated by the classical Cepheid optical data, where extrema lie near the anti-center and ℓ ~ 30°. The O-star results are inconsistent with a strict Galactocentric dependence, as the RV,BV extrema are offset by ~ 180° (ℓ ~ 78 → 280°), and a higher ratio characterizes the Galactic bulge sight line. Conversely, the optical ratio characterizing classical Cepheids features a Galactocentric metallicity or distance dependence (Fig. 4). That Cepheid trend may be partially explained by metallicity-dependent optical stellar (Cepheid) colors. Majaess et al. (2009) identified that a BV period-magnitude relation tied to Galactic classical Cepheids yields distances featuring a period-dependence when applied to lower-abundance SMC Cepheids. Caldwell & Coulson (1985) likewise suggested that the BV color is sensitive to metallicity, whereby lower-abundance Cepheids exhibit bluer intrinsic colors. Therefore the larger optical color-excess ratios observed toward the anti-center are expected, as the Galactocentric metallicity gradient shifts to lower abundances. Hitherto the results disfavor the interpretation that classical Cepheid and O-star optical colors convey that markedly smaller grains dominate at increasing Galactocentric distance, as indicated by certain red clump infrared analyses. Dust extinction is a complex phenomenon sensitive to a suite of variables (size, density, chemical composition, environment, etc.). Admittedly, if the Cepheid metallicity (BV) effect described is significantly larger than model predictions then the trend in Fig. 4 could potentially invert, and thus support red clump predictions. Yet, the infrared-based Cepheid results would remain unchanged, and in concert with the O-star findings are irreconcilable with that theory. The mean optical total-to-reddening ratios are ⟨AV/E(B−V)⟩ = ⟨RV,BV⟩ ~ 3.1 (classical Cepheids) and ⟨RV,BV⟩ ~ 3.3 (O stars). Those values are tied to the longest-wavelength passband and are cited as approximate means owing to the acute dependence on ℓ. Caution is warranted with regards to the O-star estimate since emission is a concern beyond > 3.6 μm, however, the stars probe key nascent regions and the young disk.

The O-star trends with Galactic longitude are consistent with the results of Whittet (1979) and Patriarchi et al. (2003). Yet Whittet (1979) argued that local dust reputedly associated with Gould’s Belt was responsible, and that is not supported by the Neckel et al. (1980) analysis, which implies that the bulk of the extinction occurs beyond the Belt’s extent. Moreover, the present O-star results contradict theories advocating that a sizable fraction of young star forming regions should universally exhibit significantly high RV. The O-star and Cepheid findings likewise disfavor hypotheses that spiral arms (forefront or trailing sections) easily explain the Galactic longitude trends (e.g., Crézé 1972), as the aforementioned stellar populations may be interspersed within the arms and local structure exists (e.g., spur) possibly extending into Puppis (Majaess et al. 2009; Carraro et al. 2015). A fine-tuned ad hoc explanation may be required for that theory to explain the suite of Galactic longitude trends (O-star, classical Cepheid, and red clump). Lastly, the recent Schlafly et al. (2016, their Fig. 17) results for the inner Galactic plane are broadly similar to the Galactocentric trend delineated by the classical Cepheids, however, as argued earlier the optical (BV) variations observed for those Cepheids are thought to stem mainly from metallicity-dependent stellar colors.

4. Conclusion

New near-infrared observations from the VVV survey were employed to help establish color-excess and total extinction ratios across the Galaxy. To that end, Type II Cepheids and RR Lyrae variables were identified throughout the bulge and an adjacent region of the disk. The VVV observations were paired with mid-infrared observations, and used to determine the desired ratios via apparent stellar colors (Sect. 2.1). The ensuing results were compared to color-excess ratios inferred from O stars and classical Cepheids occupying the broader Milky Way. In sum, a strict paradigm linking smaller dust grains with increasing Galactocentric distance, as inferred from infrared data for red clump stars, is not supported by the results.

The optical analysis indicates that O stars exhibit a maximum ratio (RV,BV) along the ℓ ~ 290° sight line, and minima are located toward ℓ ~ 133° and ℓ ~ 78° (Fig. 3). Conversely, the classical Cepheid optical data display extrema along the anti-center and ℓ ~ 30° sight lines. Yet the infrared colors imply a ratio (⟨E(J−3.5μm)/E(J−Ks)⟩=1.28±0.03σ\hbox{$\langle E(J-\overline{3.5 ~\mu {\rm m}})/E(J-K_{\rm s}) \rangle =1.28\pm0.03 \sigma$}) that is relatively constant in comparison to optical determinations (Figs. 3 and 4). The O-star color-excess ratios are particularly affected by emission beyond 3.6 μm, however, the classical Cepheid, Type II Cepheid, and RR Lyrae variables may be characterized by ⟨RJ,JKs⟩ = 1.49 ± 0.05 (Fig. 2), which implies ⟨AKs/AJ⟩ = 0.33 ± 0.02. The common distance approach yielded inconsistent (lower) results relative to those inferred from stellar colors for the bulge population. The former procedure is rather sensitive to the sample’s distribution, and may be partially skewed by heavy extinction and blending (Fig. 5). The mean optical total-to-selective extinction ratios are sensitive to ℓ, but are approximately ⟨AV/E(B−V)⟩ = ⟨RV,BV⟩ = 3.1 (classical Cepheids) and ⟨RV,BV⟩ = 3.3 (O stars). The ratios are consistent with the Berdnikov et al. (1996) and Pejcha & Kochanek (2012) findings, and larger than the mean determined by Tian et al. (2014, RV,BV = 2.40 ± 1.05, from high b. Yet ultimately the J,JKs passband combination, and certain others (Ngeow 2012; Nataf et al. 2016), present desirable advantages when establishing cosmic distances to Cepheids, which are used to constrain the Hubble constant, the Universe’s age, and cosmological models (Freedman & Madore 1996; Riess et al. 2011; Ngeow et al. 2014).

1

Tian et al. (2014) obtained ⟨RV,BV⟩ = 2.40 ± 1.05 from high latitude SDSS BHB stars, whereas Turner (1976) determined ⟨RV,BV⟩ ~ 3.1 from open clusters.

2

The result conveyed in Fig. 4 is tied to the integrated extinction properties along the Sun-target sight line, and is merely an approximation of any Galactocentric dependence.

Acknowledgments

D. Majaess is grateful to the following individuals and consortia whose efforts, advice, or encouragement enabled the research: 2MASS, WISE, GLIMPSE (Spitzer), L. Berdnikov, OGLE (A. Udalski, I. Soszynski), J. Maíz-Apellániz, N. Walborn, C. Ngeow, L. Macri, D. Balam, B. Skiff, G. Carraro, CDS (F. Ochsenbein, T. Boch, P. Fernique), arXiv, and NASA ADS. D. Minniti is supported by FONDECYT Regular No. 1130196, the BASAL CATA Center for Astrophysics and Associated Technologies PFB-06, and the Ministry for the Economy, Development, and Tourism’s Programa Iniciativa Científica Milenio IC120009, awarded to the Millennium Institute of Astrophysics (MAS). W.G. gratefully acknowledges financial support for this work from the BASAL Centro de Astrofisica y Tecnologias Afines (CATA) PFB-06, and from the Millennium Institute of Astrophysics (MAS) of the Iniciativa Milenio del Ministerio de Economia, Fomento y Turismo de Chile, grant IC120009.

References

  1. Anderson, R. I., Ekström, S., Georgy, C., et al. 2014, A&A, 564, A100 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  2. Berdnikov, L. N., Vozyakova, O. V., & Dambis, A. K. 1996, Astron. Lett., 22, 334 [NASA ADS] [Google Scholar]
  3. Berdnikov, L. N., Dambis, A. K., & Vozyakova, O. V. 2000, A&AS, 143, 211 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  4. Borissova, J., Rejkuba, M., Minniti, D., Catelan, M., & Ivanov, V. D. 2009, A&A, 502, 505 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  5. Caldwell, J. A. R., & Coulson, I. M. 1985, MNRAS, 212, 879 [NASA ADS] [CrossRef] [Google Scholar]
  6. Carraro, G., Turner, D., Majaess, D., & Baume, G. 2013, A&A, 555, A5 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  7. Carraro, G., Vázquez, R. A., Costa, E., Ahumada, J. A., & Giorgi, E. E. 2015, AJ, 149, 12 [NASA ADS] [CrossRef] [Google Scholar]
  8. Chené, A.-N., Borissova, J., Clarke, J. R. A., et al. 2012, A&A, 545, A54 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  9. Crézé, M. 1972, A&A, 21, 85 [NASA ADS] [Google Scholar]
  10. Dékány, I., Minniti, D., Majaess, D., et al. 2015, ApJ, 812, L29 [NASA ADS] [CrossRef] [Google Scholar]
  11. Freedman, W. L., & Madore, B. F. 1996, in Clusters, Lensing, and the Future of the Universe, ASP Conf. Proc., 88, 9 [NASA ADS] [Google Scholar]
  12. Gieren, W., Pilecki, B., Pietrzyński, G., et al. 2015, ApJ, 815, 28 [NASA ADS] [CrossRef] [Google Scholar]
  13. Gontcharov, G. A. 2013, Astron. Lett., 39, 83 [NASA ADS] [CrossRef] [Google Scholar]
  14. Hackwell, J. A., & Gehrz, R. D. 1974, ApJ, 194, 49 [NASA ADS] [CrossRef] [Google Scholar]
  15. Luck, R. E., Andrievsky, S. M., Kovtyukh, V. V., Gieren, W., & Graczyk, D. 2011, AJ, 142, 51 [NASA ADS] [CrossRef] [Google Scholar]
  16. Macri, L. M., Ngeow, C.-C., Kanbur, S. M., Mahzooni, S., & Smitka, M. T. 2015, AJ, 149, 117 [NASA ADS] [CrossRef] [Google Scholar]
  17. Madore, B. F. 1982, ApJ, 253, 575 [NASA ADS] [CrossRef] [Google Scholar]
  18. Maíz-Apellániz, J., Walborn, N. R., Galué, H. Á., & Wei, L. H. 2004, ApJS, 151, 103 [NASA ADS] [CrossRef] [Google Scholar]
  19. Majaess, D. 2010, Acta Astron., 60, 55 [NASA ADS] [Google Scholar]
  20. Majaess, D., Turner, D., & Lane, D. 2009, Acta Astron., 59, 403 [NASA ADS] [Google Scholar]
  21. Majaess, D., Turner, D., Gieren, W., & Lane, D. 2012a, ApJ, 752, L10 [NASA ADS] [CrossRef] [Google Scholar]
  22. Majaess, D., Turner, D., & Gieren, W. 2012b, PASP, 124, 1035 [NASA ADS] [CrossRef] [Google Scholar]
  23. Majaess, D., Turner, D. G., & Gieren, W. 2013, ApJ, 772, 130 [NASA ADS] [CrossRef] [Google Scholar]
  24. Minniti, D., Lucas, P. W., Emerson, J. P., et al. 2010, New Astron., 15, 433 [NASA ADS] [CrossRef] [Google Scholar]
  25. Moni Bidin, C., Majaess, D., Bonatto, C., et al. 2014, A&A, 561, A119 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  26. Nataf, D. M., Gonzalez, O. A., Casagrande, L., et al. 2016, MNRAS, 456, 2692 [NASA ADS] [CrossRef] [Google Scholar]
  27. Neckel, T., Klare, G., & Sarcander, M. 1980, A&AS, 42, 251 [NASA ADS] [Google Scholar]
  28. Ngeow, C.-C. 2012, ApJ, 747, 50 [NASA ADS] [CrossRef] [Google Scholar]
  29. Ngeow, C.-C., Gieren, W., & Klein, C. 2014, IAU Symp., 301, 123 [NASA ADS] [Google Scholar]
  30. Patriarchi, P., Morbidelli, L., & Perinotto, M. 2003, A&A, 410, 905 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  31. Pejcha, O., & Kochanek, C. S. 2012, ApJ, 748, 107 [NASA ADS] [CrossRef] [Google Scholar]
  32. Riess, A. G., Macri, L., Casertano, S., et al. 2011, ApJ, 730, 119 [NASA ADS] [CrossRef] [Google Scholar]
  33. Saito, R. K., Hempel, M., Minniti, D., et al. 2012, A&A, 537, A107 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  34. Schlafly, E. F., Meisner, A. M., Stutz, A. M., et al. 2016, ApJ, 821, 78 [NASA ADS] [CrossRef] [Google Scholar]
  35. Scowcroft, V., Freedman, W. L., Madore, B. F., et al. 2011, ApJ, 743, 76 [NASA ADS] [CrossRef] [Google Scholar]
  36. Smith, M. C., Woźniak, P., Mao, S., & Sumi, T. 2007, MNRAS, 380, 805 [NASA ADS] [CrossRef] [Google Scholar]
  37. Sota, A., Maíz Apellániz, J., Walborn, N. R., et al. 2011, ApJS, 193, 24 [NASA ADS] [CrossRef] [Google Scholar]
  38. Sota, A., Maíz Apellániz, J., Morrell, N. I., et al. 2014, ApJS, 211, 10 [NASA ADS] [CrossRef] [Google Scholar]
  39. Soszyński, I., Udalski, A., Pietrukowicz, P., et al. 2011a, Acta Astron., 61, 285 [NASA ADS] [Google Scholar]
  40. Soszyński, I., Dziembowski, W. A., Udalski, A., et al. 2011b, Acta Astron., 61, 1 [NASA ADS] [Google Scholar]
  41. Tian, H.-J., Liu, C., Hu, J.-Y., Xu, Y., & Chen, X.-L. 2014, A&A, 561, A142 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  42. Turner, D. G. 1976, AJ, 81,1125 [NASA ADS] [CrossRef] [Google Scholar]
  43. Turner, D. G. 1994, J. Roy. Astron. Soc. Can., 88, 176 [NASA ADS] [Google Scholar]
  44. Turner, D. G. 2012, Ap&SS, 337, 303 [NASA ADS] [CrossRef] [Google Scholar]
  45. Whittet, D. C. B. 1979, A&A, 72, 370 [NASA ADS] [Google Scholar]
  46. Wright, E. L., Eisenhardt, P. R. M., Mainzer, A. K., et al. 2010, AJ, 140, 1868 [NASA ADS] [CrossRef] [Google Scholar]
  47. Zasowski, G., Majewski, S. R., Indebetouw, R., et al. 2009, ApJ, 707, 510 [NASA ADS] [CrossRef] [Google Scholar]
  48. Zechmeister, M., & Kurster, M. 2009, A&A, 496, 577 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
